Increase cleaning
efficiency and
productivity.
Efficient | Low energy, water & detergent consumption
Ergonomic | Redesigned drive paddle & squeegee lift system
Easy to Use | Customizable settings simplify your operation
From hospitals and schools, to sports centers and
REV
Efficiency revitalized.
manufacturing floors, the Advance SC500™ walk-behind
scrubber ushers in a new wave of productivity in the places
where cleaning professionals need it most. With a modern
design engineered to provide better control and improved
sightlines, this compact 20 inch and 12 gallon disc or
orbital scrubber cleans both effectively and quietly.
Already one of the quietest compact scrubbers, the SC500
has a Quiet Mode for daytime cleaning environments.
With a revolutionary flow regulation system that adjusts the solution
output based on the speed of the machine, SC500 ensures consistent
cleaning results using less water and chemical while improving
productivity per tank. Combine that with the exclusive EcoFlex™
system—which allows for variable detergent (including ultra-low) or
water-only cleaning—and the SC500 is in a category of its own when
it comes to sustainability and efficient cleaning.
Ergonomically inclined.
Available with
TrackClean
Centralized Fleet Management
The extremely maneuverable SC500 features a low center of gravity
and an easily accessible variable speed, pressure sensitive control
paddle. That means virtually anyone can control the SC500’s traction
drive system, effortlessly propelling it forward at whatever speed
feels comfortable and appropriate for the cleaning application.
Ease of use maximized.
Every facet of the SC500 has been fine-tuned for an optimal user
experience. The unique multi-function display and control panel grants
managers—using the yellow Superuser key—access to adjustable
cleaning parameters. Operators—using the gray key—are able to start
cleaning at the beginning of their shift. They don’t need to take the time
to change machine settings before they start.
1
8
Two key system with separate controls
1
for the Superuser (yellow key) and
Operator (gray key)
5
4
6
5
Mechanical foot pedals allow for
2
hassle-free raising and lowering of
the squeegee
Easy click off/on brush/pad holder with
3
control panel button (disc model only)
7
2
No-nonsense pinch-to-control tank
4
drain hose simply works
Solution tank easily fills via front grate,
5
sink-attachable hose, or side fill port
Recovery tank tilts back easily, allowing
6
full access to the batteries and the
EcoFlex™ System detergent bottle
Standard onboard charger makes
7
charging convenient without returning
to a charging station
Ergonomic and easy to use operator
8
paddle controls speed and
solution flow
3
Optional REV™ orbital scrubbing on the X20R
model allows for chemical-free floor stripping,
adding to the many uses of this robust machine.
Customizable timeout countdown shuts the
machine off after 5 minutes of inactivity for
enhanced safety and efficiency.
Optional splashguard keeps water in the path
of the squeegee even at the fastest
operation speeds.
Raise, lower or even double the brush
pressure right from the dashboard for
even more cleaning power.
Under the hood.
SC500™ Specifications
Models SC500™ Disc SC500™ REV
Scrub Path 20 in (50.8 cm) 20 in (50.8 cm)
Batteries 130 Ah Wet / 140 Ah AGM 130 Ah Wet / 140 Ah AGM
Battery Count 2 2
Solution Tank 12 gal (45 L) 12 gal (45 L)
Recovery Tank 12 gal (45 L) 12 gal (45 L)
Brush Speed 155 RPM 2,250 RPM Orbital / 30 RPM Pad
Brush Pressure 33 / 66 lb (15 / 30 kg) 49 / 66 lb (22.2 / 30 kg)
Brush Motor(s) 450 W 560 W
Squeegee Width 26.5 in (67.3 cm) 26.5 in (67.3 cm)
Vacuum Motor 280 W 280 W
Waterlift / Airflow 29.9 in (76 cm) H2O 29.9 in (76 cm) H2O
Vacuum Motor 100 CFM 100 CFM
Sound Level 60 dB A Silent / 63 dB A Normal 61 dB A Silent / 65 dB A Normal
Drive Motor 200 W 200 W
Length 48.3 in (127.7 cm) 48.3 in (127.7 cm)
Width 20.9 in (72 cm) 20.9 in (72 cm)
Height 41.9 in (106.3 cm) 41.9 in (106.3 cm)
Weight (w/o Batteries) 187.4 lb (83 kg) 194 lb (85 kg)
Onboard Charger Standard Standard
Onboard Detergent EcoFlex™ System Standard EcoFlex™ System Standard
Traction Drive Standard Standard
Variable Solution Flow Standard Standard
Smart Key Standard Standard
Orbital Scubbing N/A Standard
Multifunction Display Standard Standard
Quiet Mode Standard Standard
Productivity (Theoretical Max) 24,552 ft2 (2,280m2) 24,552 ft2 (2,280m2)
Run Time Continous 3.5 Hours 3.5 Hours
Part Numbers 56383557 w/ 130 Ah wet batteries
56383558 w/ 140 Ah maint-free (AGM) batteries
Specifications subject to change without notice.
56383555 w/ 130 Ah wet batteries
56383556 w/ 140 Ah maint-free (AGM) batteries
™
SC500
SNAP
IT!
™
SC500
Optional Accessories:
• Short-trim pad holder with pad retainer
• Wide variety of pads
• Wide variety of brushes
• Bristle splash skirt
• Gum squeegee blade kit
• Red gum squeegee blade kit
• Polyurethane (PU) squeegee blade kit
™
• Replacement operator key
• Replacement super user key
• EcoFlex™ bottle assembly, 1.3 gallons
• Battery watering can with automatic shut-off
• Mop and trash kit
• Automatic water filling kit
• Wet pick up kit
• Rotomold wipe on tank protectant
TrackClean
Centralized Fleet Management
Increase productivity with TrackClean asset management technology installed on
your fleet of machines to monitor, verify and improve operational effectiveness.
Learn more: http://www.advance-us.com/TrackClea
Visit http://www.advance-us.com/SC500 or contact your
Advance sales representative to learn more.
©2015 Nilfisk. Form L3413A 5-20-15
n
14600 21st Avenue North
Plymouth, MN 55447-3408
www.advance-us.com
Phone 800-850-5559
Fax 800-989-6566
240 Superior Boulevard
Mississauga, Ontario, Canada L5T 2L2
www.nilfisk-advance.ca
Phone 800-668-8400
Fax 800-263-5111
