SC500
PARTS LIST
Model: 9087352020 - 9087353020
11/14 (1)
FORM NO. 9099981000
PARTS LIST
TABLE OF CONTENTS
GENERAL VIEW ......................................................................................................................................................... 2
SOLUTION TANK ........................................................................................................................................................ 4
RECOVERY TANK ...................................................................................................................................................... 6
MOTOR DRIVE ........................................................................................................................................................... 8
MOTOR DRIVE (MODEL ADVANCE) ....................................................................................................................... 10
PADDLE AND DASHBOARD .................................................................................................................................... 12
REAR WHEELS ........................................................................................................................................................ 14
SQUEEGEE SYSTEM............................................................................................................................................... 16
DISC DECK ............................................................................................................................................................... 18
REV DECK ................................................................................................................................................................ 20
REV DECK ................................................................................................................................................................ 21
ELECTRICAL COMPONENTS .................................................................................................................................. 22
ELECTRICAL COMPONENTS (ADVANCE) ............................................................................................................. 24
BATTERY CHARGER ............................................................................................................................................... 26
ECOFLEX SYSTEM .................................................................................................................................................. 28
ACCESSORIES......................................................................................................................................................... 30
ACCESSORIES......................................................................................................................................................... 32
ACCESSORIES......................................................................................................................................................... 34
WIRING DIAGRAM ................................................................................................................................................... 36
RECOMMENDED PARTS ......................................................................................................................................... 38
OPTIONAL ................................................................................................................................................................ 39
WHEN ORDERING PARTS
* Use the part numbers from the “Ref. No.” columns in this parts list.
* Specify the model and serial number of the machine.
* Use the space below to record the model and serial number for future reference.
Model Serial No.
* = Optional
# = Modied item No. or New item No.
[ ] = Not shown
10/14 SC500 - 9099981000 1
PARTS LIST
3
GENERAL VIEW
11
7
8
5
12
1
9 4
14
2
10
6
13
2 SC500 - 9099981000 10/14
GENERAL VIEW
KIT ITEM REF. NO. QTY DESCRIPTION
1 9100000736 1 DECALS ADVANCE SC500 KIT
2 - 1 WHEELS REAR-SQUEEGEE ASSEMBLY
3 - 1 TANK RECOVERY ASSEMBLY
4 - 1 MOTOR DRIVE ASSEMBLY
5 - 1 TANK SOLUTION ASSEMBLY
6 - 1 SQUEEGEE ASSEMBLY
7 - 1 PADDLE ASSEMBLY
8 - 1 PANEL CONTROL ASSEMBLY
9 - 1 DECK BRUSH ASSEMBLY
10 - 1 SYSTEM SOLUTION ASSEMBLY
11 - 1 ECOFLEX ASSEMBLY
12 - 1 CHARGER BATTERY ASSEMBLY
13 - 1 REV MOTOR DRIVE ASSEMBLY
14 - 1 REV BRUSH ASSEMBLY
PARTS LIST
10/14 SC500 - 9099981000 3
PARTS LIST
SOLUTION TANK
24
5
17
18
16
21
11
22
9
25
14
15
2
11
7
6
23
26
27
1
3
20
13
11
19
3
4
11
10
12
81127
4 SC500 - 9099981000 10/14
SOLUTION TANK
KIT ITEM REF. NO. QTY DESCRIPTION
K2 1 1 SCREW 5X35 SELF THD TAPPING AW20 BLACK
K2 2 8 TIE CABLE 4.8x200 BLACK
K2 3 1 WASHER 6X18X1.5 UNI6593 SS
K2 4 2 SCREW CYL HD 5X20 SELF L. PLASTOFAST
K1 5 4 SCREW CYL HD 5X25 SELF L. PLASTOFAST
K2 6 1 CAP BLACK
K2 7 8 HOLDER.FLAT TIE
8 9100000803 1 VALVE ELBOW PKD
K2 9 2 SCREW 3.9X22 UNI6955 SS
10 9100000574 2 FITTING STRAIGHT G1/2 D.20 KIT
K2 11 13 SCREW CYL HD 5X16 SELF L. PLASTOFAST
12 9098446000 1 HOSE SOLUTION
13 909 6380 000 1 CLAMP KIT
14 9100000899 1 FILTER WATER INLET PKD
15 9100000804 1 TANK SOLUTION 40 LT GREY PKD
16A 9100000805 1 ACTUATOR LINEAR 24V DC STRK 120MM PKD
16B 9100000806 1 ACTUATOR LINEAR 24V DC STRK 98MM PKD
K1 17 4 PLATE FOR JACK MOTOR RETAINER
K1 18 1 PIN CYLINDR. D.8X140 ISO2338 NO TEMPERED
19 9100000807 1 BOX F CHARGER CABLE PKD
20 9100000808 1 RUBBER SOLUTION CAP PKD
K1 21 2 BEARING CYLINDRICAL IGUS GSM-0809-12
22 9100000809 1 COVER CHEMICAL MIX PUMP PKD
K3 23 1 CABLE SAFETY F TANK
24* 9100000703 1 HOSE FILLING
K2 25 2 WASHER M4 UNI6592 SS
K3 26 1 SCREW CYL HD 5X16 SELF L. PLASTOFAST
K3 27 1 SCREW M5X16 UNI7687 SS
[K1] 9100000737 1 ACTUATOR FIXING KIT
[K2] 9100000738 1 HARDWARE SOLUTION TANK KIT
[K3] 9100000794 1 CABLE SAFETY F TANK KIT
PARTS LIST
A: FOR DISC DECK VERSION
B: FOR REV DECK VERSION
10/14 SC500 - 9099981000 5
PARTS LIST
RECOVERY TANK
12
18
32
30
31
29
28
33
16
17
11
3
19
8
6
4
7
5
1
27
26
15
25
24
2
9
20
23
10
22
14
13
21
6 SC500 - 9099981000 10/14
RECOVERY TANK
KIT ITEM REF. NO. QTY DESCRIPTION
K4 1 145 0543 000 1 CLAMP 14/32-52
K4 2 9 SCREW M5X12 UNI7687
K1 3 2 SCREW M6X16 UNI7687 SS
K1 4 9100000928 1 GASKET FLOAT SUPPORT PKD
K4 5 2 NUT JAW M6X6 INOX SS
K1 6 1 CAGE FLOAT
K2 7 1 TRAY DEBRIS
K2 8 1 COVER DEBRIS TRAY
9 9100000812 1 HOSE DRAIN BLACK PKD
10 9100000889 1 CLIP HOSE STOPPING 2 PCS SET
11 9100000813 1 TANK RECOVERY 40 LT GREY PKD
12 9100000814 1 COVER TANK GREY PKD
13 9100000815 1 COVER F VACUUM MOTOR SOUNDPR. PKD
14 9100000816 1 HOSE SUCTION BLACK PKD
15 9100000904 1 MOTOR VACUUM 24V 280W CPL KIT
15* 9100000491 1 HIGH POWER VACUUM MOTOR 24V 450W KIT
9100000753 1
9100000817 1 BALL FLOATING PKD
16
9100000818 1 CAGE FLOAT HALF 2 PCS SET
17
18 9100000819 1 GASKET BULB RUBBER L.1670MM PKD
K1 19 2 WASHER 6X18X1.5 UNI6593 SS
K4 20 1 CLAMP CABLE BLACK
21 9100000820 1 HARNESS VACUUM MOTOR PKD
K4 22 4 SCREW CYL HD 5X20 SELF L. PLASTOFAST
23 9100000821 1 SUPPORT EXT. INSULATION VAC. MOTOR PKD
K4 24 1 TIE CABLE 4.8x200 BLACK
K3 25 1 O-RING 2.5X109 EPDM
26 9100000822 1 SUPPORT INT. INSULATION VAC. MOTOR PKD
K3 27 1 GASKET COLLECTOR
K3 28 1 RUBBER SEALING DOMEL UPPER
29 9100000823 1 MOTOR VACUUM 24V 280W PKD
30 9100000824 1 SUPP. UPPER F VAC. MOTOR SOUNDPR. PKD
K3 31 1 MOTOR GASKET LOWER DOMEL
K3 32 1 GASKET VACUUM MOTOR
909 5065 000 1 FILTER ANTIFOAMING
33*
K1 9099767000 1 SUPPORT FLOAT KIT
K2* 9100000795 1 TRAY DEBRIS KIT
K3 9100000739 1 GASKETS VACUUM MOTOR KIT
K4 9100000740 1 HARDWARE RECOVERY TANK KIT
INSTRUCTIONS INSTALL. KIT 9100000491
PARTS LIST
10/14 SC500 - 9099981000 7
PARTS LIST
7
MOTOR DRIVE
13
10
2
8
3
4
5
6
12
15
9
1
14
11
16
8 SC500 - 9099981000 10/14
MOTOR DRIVE
KIT ITEM REF. NO. QTY DESCRIPTION
K1 1 146 0769 000 2 KEY 6X6X40 UNI6604A
2 9100000825 1 LEVER EXT. FOR DECK LIFTING 2 PCS SET
3A 9100000826 1 LEVER INT. FOR DECK LIFTING 2 PCS SET
4 9100000743 1 MOTOR DRIVE 200W 24V PKD
5 9100000921 1 MOTOR ELECTRIC 200W 24V
6 9100000922 1 CARBON BRUSHES KIT 2 PCS
K1 7 8 SCREW M8X30 UNI5739
K1 8 8 SPACER 8.1X13X10.3
K1 9 1 TIE CABLE 4.8X430 WHITE
K1 10 6 WASHER M8 UNI6592
K1 11 2 WASHER 8.5X32X2 SS
K1 12 4 WASHER NORD LOCK M10
K1 13 8 WASHER NORD LOCK M8
14 9100000830 2 WHEEL D.200X50 GREY-BLACK 2 PCS SET
K1 15 4 SCREW M10X20 UNI5931
K1 16 2 SCREW M8X20 UNI5739 SS
[K1] 9100000744 1 HARDWARE DRIVE MOTOR KIT
A: LEVER ONLY FOR DISC VERSION
PARTS LIST
10/14 SC500 - 9099981000 9
PARTS LIST
PADDLE AND DASHBOARD
3
89
1011
17 13
20 19
16
7 2 5 21
1
4
6
15
18
12
14
10 SC500 - 9099981000 10/14
PADDLE AND DASHBOARD
KIT ITEM REF. NO. QTY DESCRIPTION
K1 1 4 SCREW TORX T20
K1 2 2 SCREW 4.2X19 SELF THD HEX HD ISO10510
3 9100000835 1 HANDLE BAR PKD
4 9100000836 1 SHAFT LEVERS CONNECTION PKD
K1 5 1 ROD POTENTIOMETER
K1 6 2 SUPPORT F LEVER CONNECTION SHAFT
7 9100000837 1 POTENTIOMETER 5K PKD
8 9100000838 1 LEVER LT DRIVING PKD
9 9100000839 1 CASING F LEFT LEVER PKD
10 9100000840 1 LEVER RT DRIVING PKD
11 9100000841 1 CASING F RIGHT LEVER PKD
12 9100000842 1 CARD DISPLAY PKD
13 9100000843 1 KEY OPERATOR COMPLETE PKD
14 9100000844 1 COVER HANDLE BAR PKD
15 9100000845 1 HARNESS CONTROL PANEL PKD
16A 9100000846 1 DASHBOARD CONTROL PANEL PKD
16B 9100000847 1 DASHBOARD CONTROL PANEL PKD
17 9100000848 1 KEY SERVICE COMPLETE PKD
K1 18 4 SCREW 3.9X9.5 THD FORM
K1 19 4 WASHER M6 UNI6592
K1 20 4 SCREW CYL HD 6X30 SELF L.PLAST
K1 21 2 SCREW 3.9X9.5 UNI6955
[K1] 9100000745 1 PADDLE AND DASHBOARD FIXING KIT
PARTS LIST
A: FOR DISC DECK VERSION
B: FOR REV DECK VERSION
10/14 SC500 - 9099981000 11
PARTS LIST
REAR WHEELS
4
33
34
35
23
21
32
28
24
22
3
29
11
12
7
27
10
31
15
5
20
30
1
2
14
6
17
8
19
18
25
12 SC500 - 9099981000 10/14
9
16
26
13
REAR WHEELS
KIT ITEM REF. NO. QTY DESCRIPTION
K1 1 1 SCREW M8X100 UNI5737
K1 2 1 SCREW M8X140 HEX HD ISO4014
K1 3 2 SCREW M10X80 UNI5739
K1 4 1 SCREW M10X60 UNI5739
K1 5 2 SCREW M5X20 UNI5931
K1 6 1 SCREW M5X40 UNI5931
K1 7 4 SCREW M10X30 UNI5931
K1
K1 9 2 NUT SELF L. M8 UNI7474
K1 10 3 NUT SELF L. M10 UNI7474
K1 11 4 WASHER M10 UNI6592
K1 12 4 WASHER NORD LOCK M10
K1 13 1 WASHER 10X40X2.5 UNI6593
K1 14 2 SPACER 8.5X15X33
K1 15 2 WASHER 5X20X1.5 UNI6593
K1 16 9100000902 2 BEARING FLANGE IGLIDUR 2 PCS SET
K1 17 2 BEARING FLANGED
K1 20 8 BUSHING FLANGED
K1 26 1 SPACER 10.5X30X30.3
K1 29 4 CLAMP DOUBLE WIRE SPRING D.18
K1 30 2 WASHER 8X24X2 FLAT ISO7093
K1 31 9100000903 1 WASHER THRUST GTM 3254-015 PKD
K1 35 2 SCREW M5X10 DIN7500
8 3 NUT SELF L. M5 UNI7474
18 9100000849 1 LEVER GAS SPRING LEFT PKD
19 9100000850 1 LEVER GAS SPRING RIGHT PKD
21 9100000851 1 SUPPORT REAR WHEELS-SQUEEGEE PKD
22 9100000852 1 SUPPORT UPPER F SQUEEGEE PKD
23 9100000853 1 SUPPORT LOWER F SQUEEGEE PKD
24 9100000854 1 LEVER SQUEEGEE LIFT 2 PCS SET
25 9100000855 1 SPRING GAS 30 KG PKD
27 9100000856 1 WHEEL PIVOTING 2 PCS SET
28 9100000857 1 SLEEVE SUCTION HOSE PKD
32 9100000796 1 HOSES SOLUTION SYSTEM KIT
33 9100000860 1 FILTER WATER PKD
34 9100000861 1 NET WATER FILTER REINFORCED PKD
[K1] 9100000746 1 SUPPORT SQUEEGEE FIXING KIT
PARTS LIST
10/14 SC500 - 9099981000 13
PARTS LIST
SQUEEGEE SYSTEM
20
1
21
9
5
6
3
19
2
18
17
10
16 11 8 22 15
11 13
12 4 714
14 SC500 - 9099981000 10/14
SQUEEGEE SYSTEM
KIT ITEM REF. NO. QTY DESCRIPTION
K1 1 2 WASHER 6X18X1.5 UNI6593 SS
K1 2 1 NUT SELFLOCKING LOW M8 UNI7474 SS
K1 3 1 WASHER 8X24 UNI6592 SS
K1 4 6 WASHER 5X15X1.2 UNI6593 SS
5 9100000862 1 KNOB LOBES M8 FEMALE PKD
6 9100000747 1 SQUEEGEE 730MM/29 PRE-ASSEMBLED PKD
K1 7 3 SPACER 5.1X8X28.5 PLASTIC
8 9100000791 2 KNOB M8X30 THD STUD SS PKD
9 9097637000 1 SQUEEGEE FIXING KIT
10 9100000559 3 WHEEL D.51 GREY PKD
11* 9100000810 1 BLADE SQUEEGEE 740MM 29 GUM KIT
11* 9100000490 1 BLADE SQUEEGEE 730MM 29 PU KIT
11* 9100000060 1 BLADE SQUEEGEE 730MM 29 RED GUM KIT
K1 12 1 SCREW M5X50 UNI5737 SS
13 9100000864 1 STRAP ELASTIC F REAR SQUEEGEE BL. PKD
K1 14 3 NUT SELFLOCKING LOW M5 UNI7474 SS
K1 15 2 SCREW M5X45 UNI5737 SS
16 9100000865 1 STRAP FRONT SQUEEGEE BLADE PKD
17 9100000866 1 SUPPORT SQUEEGEE WHEEL PKD
K1 18 1 SCREW M8X50 HEX HD F/THD SS ISO4017
K1 19 1 NUT HEX M8 ISO4035 SS
K1 20 2 SCREW 5X35 SELF THD TAPPING AW20 BLACK
21 9100000867 1 GUIDE WHEEL 2 PCS SET
K1 22 2 NUT HEX M8 UNI5588 SS
[K1] 9100000748 1 HARDWARE SQUEEGEE KIT
PARTS LIST
10/14 SC500 - 9099981000 15
PARTS LIST
DISC DECK
11
26
40
39
32
29
34
16
9
31
25
42
37
30
28
38
35
22
18
4
7
10
2
17
15
1
36
41
14
21
19
2
20
23
12
27
3
33
5
6
8
24
13
16 SC500 - 9099981000 10/14
DISC DECK
KIT ITEM REF. NO. QTY DESCRIPTION
K2 1 1 PIN PLATE FIXING
2 9100000797 1 HOSES BRUSH DECK KIT
K3 3 2 SCREW M8X20 UNI5739 SS
K1 4 1 SCREW M8X30 UNI5739
K3
K3
K3 7 3 NUT SELFLOCKING LOW M8 UNI7474 SS
K3 8 1 WASHER 6.6X24X2 UNI6593 SS
K2 9 5 WASHER 8.5X32X2 SS
K3
K3
K3
K3 13 1 SCREW M6X16 UNI5739 SS
K2
K3 15 2 SCREW 3.5X16 SELF THD PAN PHIL F PLASTIC
K2 16 1 WASHER 10X30X2
K3
K3 24 1 WASHER NORD LOCK M6 DIN25201
K3 27 2 SCREW PAN HD SELF 4x12 SS
K1 28 1 WASHER 15
K2 29 1 WASHER M5 UNI6592 SS
K1 30 1 WASHER 8X24X2 FLAT ISO7093
K2 31 2 NUT SELF L. M6 UNI7474 SS
K2 32 1 NUT SELFLOCKING LOW M5 UNI7474 SS
K3 33 4 WASHER 6X18X1.5 UNI6593 SS
K2 34 1 KNOB
K1 35 1 ROLLER BUMPER D.160 BLACK
K2 36 1 BUFFER
K1 37 1 CAP. BLACK
K1 38 1 SPACER 9X15X13
K2 39 1 CAP FOR KNOB
K3 40 2 TIE CABLE 4.8X430 WHITE
K2 41 1 PLATE.VIBRATION DAMPING
5 5 WASHER M6 UNI8842A SS
6 4 SCREW M6X25 UNI5739 SS
10 1 SCREW M8X16 UNI5739 SS
11 1 TIE CABLE 4.8x200 BLACK
12 3 WASHER M8 UNI8842A SS
14 2 SCREW M6X40 UNI5739 SS
17 1 CLAMP 6.6X 7
18 9100000868 1 VIBRATION DAMPING M8 60SH 2 PCS SET
19 9100000869 1 COVER SOLUTION HOSE SUPPORT PKD
20 9100000870 1 SOLENOID VALVE 24V PKD
21 9100000871 1 HUB BRUSH PKD
22 9100000872 1 PLATE BRUSH DECK HOLDER PKD
23 9100000873 1 DECK BRUSH PKD
25 9100000874 1 REDUCTION GEARMOTOR 450W 24V PKD
26 9098376000 1 CARBON BRUSHES KIT 4 PCS
42 9100000875 1 KEY 5X5X30 DIN6885 2 PCS SET
909 6887 000 1 ROLLER BUMPER KIT
[K1]
[K2] 9100000750 1 DECK BRUSH ADJUST. KIT
[K3] 9100000751 1 HARDWARE BRUSH DECK KIT
PARTS LIST
10/14 SC500 - 9099981000 17
PARTS LIST
REV DECK
28
50
23
34
35
36
44
46
24
29
27
40
3
5
54
55
20
17
48
2
43
42
49
47
26
16
4
45
52
18
8
51
12
31
32
30
33
12
10
25
38
11
39
37
19
21
22
14
9
15
1
41
13
18 SC500 - 9099981000 10/14
6
7
REV DECK
KIT ITEM REF. NO. QTY DESCRIPTION
K2 1 2 WASHER LK 1/4 REGSS
K1 2 1 SCREW M8X40 UNI5739
K2 3 2 WASHER M10 UNI1751B
K3 4 3 WASHER M6 UNI6592 SS
K2
K2
K2 7 6 SCR HEX LOC 1/4 20 X 0.75
K5 8 3 SCR PAN PHIL LOC SS 1/4 20X.50
K2 9 6 SCREW PAN PHIL LOC SS 1/4-20 X 1.00
K6
K6
K3 16 1 SHIELD SPLASH
K4 18 1 ECCENTRIC
K5 19 1 DRIVER MOTOR
K5
K6 25 2 HOSE CLEAR
K3 26 3 SCREW M6X20 UNI5739 SS
K2 27 1 SCREW M8X16 UNI5739 SS
K2 28 1 TIE CABLE 4.8x200 BLACK
K2 29 1 WASHER M8 UNI8842A SS
K6 30 1 HOLDER RUBBER T
K6 31 1 HOSE SILICONE D.4X7
K6 32 1 HOSE SILICONE RUBBER
K6 33 1 HOSE SILICONE RUBBER
K2 36 2 SCREW PAN HD SELF 4x12 SS
K5 37 1 BEARINGBALL OBS-18 6008
K6 38 2 HOSEBARB 3/8 X 90 DEG
K5 39 1 RETAINER BEARING
K2 40 2 SCREW 3/8-24 X 1 HEX HEAD
K2 41 4 NUTHEX SERRATED FLANGE1/4-20
K1 42 2 WASHER 15
K1 43 1 WASHER 8X24X2 FLAT ISO7093
K2 44 2 SCREW M4X12 UNI7687
K3 45 3 NUT SELF L. M6 UNI7474 SS
K2 46 2 NUT SELF L. M4 UNI7474 SS
K1 47 1 ROLLER BUMPER D.160 BLACK
K1 48 1 CAP. BLACK
K1 49 1 SPACER 9X15X13
K2 50 1 TIE CABLE 4.8X430 WHITE
K4 52 1 KEY 3/16 X 3/16 X 3/4 LG
5 2 WASHER M10 UNI6592
6 4 SCR FLT PHIL LOC 1/4-20 X 0.75
10 1 TEE HOSE 3/8X3/8X3/8 PLSTC
11 2 GROMMET .500 E00059
12 56382991 1 KIT-ISOLATOR BOOST HD
13 9098979000 1 STUD STABILIZER KIT
14 56390002 1 WEIGHT COUNTER
15 9100000900 1 PLATE F DECK MOTOR PKD
17 56390012 1 HOUSING BRUSH
20 56390037 1 DECAL-REV EMBOSSED
21 1 GASKET DRIVER
22 56390044 1 PAD DRIVER ASSY
23 56390072 1 MOTOR 24VDC
24 56412287 1 MOTOR BRUSH/SPRING KIT
34 9100000870 1 SOLENOID VALVE 24V PKD
35 9100000876 1 PLATE BRUSH DECK HOLDER PKD
51 9100000901 1 GASKET ADHESIVE 12X5 L.1090MM PKD
[K1] 9100000749 1 ROLLER BUMBER D.160 BLACK KIT
[K2]
[K3]
[K4]
[K5]
[K6]
9100000756 1 HARDWARE BRUSH DECK KIT
9098982000 1 SPLASH GUARD KIT
9098984000 1 KIT-ECCENTRIC
9098983000 1 DRIVER KIT
9100000757 1 HOSES BRUSH DECK KIT
PARTS LIST
10/14 SC500 - 9099981000 19
PARTS LIST
ELECTRICAL COMPONENTS
659821612 4
14
3
10
7
14 11
13
20 SC500 - 9099981000 10/14
ELECTRICAL COMPONENTS
KIT ITEM REF. NO. QTY DESCRIPTION
1 9100000877 1 FUSE MIDIFUSE 100A PKD
2 9100000878 1 FUSE BLADE 3A PKD
K2 3 4 WASHER 5X15X1.5 UNI6593
4 9100000879 1 CONTROLLER MAIN MACHINE PKD
5 9100000880 1 COVER BOX ELECTRIC COMP. PKD
K2 6 11 SCREW CYL HD 4X16 SELF L. PLAS
K2 7 3 SCREW 5X35 SELF THD TAPPING AW20 BLACK
K1 8 1 GASKET UPPER ELECTRONIC COVER
K1 9 2 GASKET SIDE ELECTRONIC COVER
10 9100000881 1 HARNESS MACHINE SC500 53B/20B PKD
11 9100000885 1 HANDLE FOR BATTERY CONNECTOR PKD
K2 12 1 CLAMP CABLE BLACK
13 9100000887 1 HARNESS BATTERY US PKD
14 9100000884 1 CONNECTOR RED 120A 2 PCS SET
[K1] 9100000798 1 GASKETS COVER KIT
[K2] 9100000799 1 HARDWARE ELECT. COMPONENTS KIT
PARTS LIST
10/14 SC500 - 9099981000 21
PARTS LIST
BATTERY CHARGER
3
4
1
5
6
2
7
22 SC500 - 9099981000 10/14
BATTERY CHARGER
KIT ITEM REF. NO. QTY DESCRIPTION
1 3 TIE CABLE 4.8x200 BLACK
2 1 TIE CABLE 2.9x130 BLACK
3 1 HOLDER.FLAT TIE
4 1 SCREW CYL HD 5X16 SELF L. PLASTOFAST
5 9100000888 1 CHARGER BATT. O/B 24V 13A 100-230V PKD
6 4 SCREW 3.5X12
7 9100000890 CABLE EXTENSION US PLUG L.2000MM PKD
PARTS LIST
10/14 SC500 - 9099981000 23
PARTS LIST
ECOFLEX SYSTEM
5
6
4
8
2
9
3
7
10
1
24 SC500 - 9099981000 10/14
ECOFLEX SYSTEM
KIT ITEM REF. NO. QTY DESCRIPTION
1 1 CHEMICAL TANK
2 1 INSERT-DRY BRAKE
3 1 CAP
4 1 CAP DRY BREAK 1/8 BARB
5 9100000891 1 HOSE SILICONE D.4X7 L.300MM PKD
6 9100000892 1 PUMP CHEMICAL MIX PKD
7 9100000893 1 SENSOR WATER LEVEL PKD
8 1 SUPPORT WATER LEVEL SENSOR
9100000923 1 INSTRUCTIONS INSTALL. KIT 9100000008
K2
K2
9 9097023000 1 ADAPTER CHEMICAL TANK
10 9097022000 1 SENSOR CHEMICAL MIX LEVEL
[K2]* 9098025000 1 ADAPTER CHEMICAL KIT
PARTS LIST
10/14 SC500 - 9099981000 25
PARTS LIST
ACCESSORIES
1
2
26 SC500 - 9099981000 10/14
ACCESSORIES
KIT ITEM REF. NO. QTY DESCRIPTION
1* 9099826000 1 SPLASH GUARD 510MM 20 KIT
2* 9100000065 1 MOP AND TRASH KIT
PARTS LIST
10/14 SC500 - 9099981000 27
PARTS LIST
ACCESSORIES
K1
8
7
4
2
5
3
1
6
28 SC500 - 9099981000 10/14
ACCESSORIES
KIT ITEM REF. NO. QTY DESCRIPTION
K1 1 9100000894 1 ELBOW CURVED M/F PKD
K1 2 9098777000 1 HOLDER RUBBER 90 F HOSE D.10 PKD
K1 3 9100000622 1 GASKET RUBBER D.11.5X19 H8 BLACK PKD
K1 4 1 FITTING QUICK 1/2 GAS
K1 5 1 NUT G 1/2 DIN 431 A SS
K1 6 9100000897 1 VALVE WATER STOP PKD
K1 7 9100000898 1 SUPPORT WATER STOP PKD
K1 8 5 SCREW 3.5X10 THD FORMING SS
K1* 9100000005 1 AUTOMATIC WATER FILLING KIT
PARTS LIST
10/14 SC500 - 9099981000 29
PARTS LIST
ACCESSORIES
1
7
2
3
4
8
5
6
30 SC500 - 9099981000 10/14
ACCESSORIES
KIT ITEM REF. NO. QTY DESCRIPTION
1* L08837025 1 BRUSH DISC 530MM 21 PROLENE
1* L08837026 1 BRUSH DISC 530MM 21 PROLITE
1* L08837027 1 BRUSH DISC 530MM 21 UNION MIX
1* L08837028 1 BRUSH DISC 530MM 21 MIDLITE GRIT 180
1* L08837029 1 BRUSH DISC 530MM 21 MID GRIT 240
1* L08837065 1 BRUSH DISC 530MM 21 MAGNA GRIT 46
1* L08837066 1 BRUSH DISC 530MM 21 DYNA GRIT 80
1* L08837067 1 BRUSH DISC 530MM 21 AGLITE GRIT 500
2* L08837018 1 PAD HOLDER 530MM
3 L08603966 1 RING NYLON
4 56505195 1 PAD RETAINER
5* 9099671000 1 PAD HOLDER FLAT 20 508MM
6* 10001955 1 PAD 20 508MM ECO BLACK 5PCS
6* 10001956 1 PAD 20 508MM ECO BLUE 5PCS
6* 10001957 1 PAD 20 508MM ECO BROWN 5PCS
6* 10001958 1 PAD 20 508MM ECO GREEN 5PCS
6* 10001959 1 PAD 20 508MM ECO RED 5PCS
6* 10001960 1 PAD 20 508MM ECO WHITE 5PCS
6* 10002348 1 PAD 20 508MM ECO BRILLIANCE RED 2PCS
6* 10002349 1 PAD 20 508MM ECO BRILLIANCE BLUE 2PCS
6* 10002350 1 PAD 20 508MM ECO BRILL. YELLOW 2PCS
6* 10002351 1 PAD 20 508MM ECO BRILLIANCE GREEN 2PCS
7* 56390008 1 BRUSH NYLON REV
8* 56390079 1 MICROFIBER PAD
PARTS LIST
10/14 SC500 - 9099981000 31
PARTS LIST
WIRING DIAGRAM
32 SC500 - 9099981000 10/14
WIRING DIAGRAM
PARTS LIST
KEY
BAT - 24 V BATTERIES
C1 9100000884 CONNECTOR RED 120A 2 PCS SET
C2 - BATTERY CHARGER MAIN CONNECTOR
C3 - BATTERY CHARGER SUB-CONNECTOR
CH 9100000888 CHARGER BATT. O/B 24V 13A 100-230V PKD
EB1 9100000879 CONTROLLER MAIN MACHINE PKD
EB2 9100000842 CARD DISPLAY PKD
EB3 (A) 9100000846 DASHBOARD CONTROL PANEL PKD
EB3 (B) 9100000847 DASHBOARD CONTROL PANEL PKD
EB4 - TRACKUNIT PUSH-BUTTON (OPTIONAL)
EV1 9100000870 SOLENOID VALVE 24V PKD
F1 9100000877 FUSE MIDIFUSE 100A PKD
F2 9100000878 FUSE BLADE 3A PKD
M1 (A) 9100000874 REDUCTION GEARMOTOR 450W 24V PKD
M1 (B) 56390072 MOTOR 24VDC
M2 9100000823 MOTOR VACUUM 24V 280W PKD
M3 9100000828 MOTOR ELECTRIC 200W 24V PKD
M3 9100000921 MOTOR ELECTRIC 200W 24V
M4 9100000892 PUMP CHEMICAL MIX PKD
M5 (A) 9100000805 ACTUATOR LINEAR 24V DC STRK 120MM PKD
M5 (B) 9100000806 ACTUATOR LINEAR 24V DC STRK 98MM PKD
RV1 9100000837 POTENTIOMETER 5K PKD
SW1 9100000893 SENSOR WATER LEVEL PKD
REF. NO.
DESCRIPTION
(A): FOR DISC DECK VERSION
(B): FOR REV DECK VERSION
KEY COLOUR
BK BLACK
BU LIGHT BLUE
BN BROWN
GN GREEN
GY GREY
OG ORANGE
KEY COLOUR
PK
RD
VT
WH
YE YELLOW
PINK
RED
VIOLET
WHITE
10/14 SC500 - 9099981000 33
PARTS LIST
RECOMMENDED PARTS
REF. NO. QTY
9100000829 1 BAND ELASTIC F EXTENSION CABLE PKD
9100000922 1 CARBON BRUSHES KIT 2 PCS
9100000810 1 BLADE SQUEEGEE 740MM 29 GUM KIT
9100000490 1 BLADE SQUEEGEE 730MM 29 PU KIT
9100000060 1 BLADE SQUEEGEE 730MM 29 RED GUM KIT
9100000922 1 CARBON BRUSHES KIT 2 PCS
9098376000 1 CARBON BRUSHES KIT 4 PCS
9100000794 1 CABLE SAFETY F TANK KIT
9100000812 1 HOSE DRAIN BLACK PKD
9100000889 1 CLIP HOSE STOPPING 2 PCS SET
9100000816 1 HOSE SUCTION BLACK PKD
9100000904 1 MOTOR VACUUM 24V 280W CPL KIT
9100000819 1 GASKET BULB RUBBER L.1670MM PKD
9100000921 1 MOTOR ELECTRIC 200W 24V
9100000823 1 MOTOR VACUUM 24V 280W PKD
9100000739 1 GASKETS VACUUM MOTOR KIT
9100000830 1 WHEEL D.200X50 GREY-BLACK 2 PCS SET
9100000843 1 KEY OPERATOR COMPLETE PKD
9100000902 2 BEARING FLANGE IGLIDUR 2 PCS SET
9100000855 1 SPRING GAS 30 KG PKD
9100000856 1 WHEEL PIVOTING 2 PCS SET
9100000857 1 SLEEVE SUCTION HOSE PKD
9100000903 1 WASHER THRUST GTM 3254-015 PKD
9100000796 1 HOSES SOLUTION SYSTEM KIT
9100000861 1 NET WATER FILTER REINFORCED PKD
9100000559 3 WHEEL D.51 GREY PKD
9100000864 1 STRAP ELASTIC F REAR SQUEEGEE BLADE PKD
9100000865 1 STRAP FRONT SQUEEGEE BLADE PKD
9100000867 1 GUIDE WHEEL 2 PCS SET
9100000797 1 HOSES BRUSH DECK KIT
9100000870 1 SOLENOID VALVE 24V PKD
9100000871 1 HUB BRUSH PKD
9100000874 1 REDUCTION GEARMOTOR 450W 24V PKD
56390072 1 MOTOR 24VDC
56412287 1 MOTOR BRUSH/SPRING KIT
9100000901 1 GASKET ADHESIVE 12X5 L.1090MM PKD
9100000798 1 GASKETS COVER KIT
9100000803 1 VALVE ELBOW PKD
9098446000 1 HOSE SOLUTION
909 6380 000 1 CLAMP KIT
9100000899 1 FILTER WATER INLET PKD
9100000805 1 ACTUATOR LINEAR 24V DC STRK 120MM PKD
9100000808 1 RUBBER SOLUTION CAP PKD
9100000743 1 MOTOR DRIVE 200W 24V PKD
9100000811 1 HOSE FILLING PKD
9100000820 1 HARNESS VACUUM MOTOR PKD
9099767000 1 SUPPORT FLOAT KIT
9100000837 1 POTENTIOMETER 5K PKD
9100000842 1 CARD DISPLAY PKD
9100000845 1 HARNESS CONTROL PANEL PKD
9100000846 1 DASHBOARD CONTROL PANEL PKD
9100000847 1 DASHBOARD CONTROL PANEL PKD
9100000848 1 KEY SERVICE COMPLETE PKD
9100000860 1 FILTER WATER PKD
9100000747 1 SQUEEGEE 730MM/29 PRE-ASSEMBLED PKD
9100000868 1 VIBRATION DAMPING M8 60SH 2 PCS SET
9100000873 1 DECK BRUSH PKD
56382991 1 KIT-ISOLATOR BOOST HD
9100000879 1 CONTROLLER MAIN MACHINE PKD
9100000881 1 HARNESS MACHINE SC500 53B/20B PKD
9100000884 1 CONNECTOR RED 120A 2 PCS SET
DESCRIPTION
NORMAL WEAR
ORDINARY MAINTENANCE
EXTRA ORDINARY MAINTENANCE
34 SC500 - 9099981000 10/14
OPTIONAL
PARTS LIST
REF. NO. QTY
9100000703 1 HOSE FILLING PKD
9100000491 1 HIGH POWER VACUUM MOTOR 24V 450W KIT
9100000795 1 TRAY DEBRIS KIT
9100000843 1 KEY OPERATOR COMPLETE PKD
9100000848 1 KEY SERVICE COMPLETE PKD
909 5065 000 1 FILTER ANTIFOAMING
9100000810 1 BLADE SQUEEGEE 740MM 29 GUM KIT
9100000490 1 BLADE SQUEEGEE 730MM 29 PU KIT
9100000060 1 BLADE SQUEEGEE 730MM 29 RED GUM KIT
9098025000 1 ADAPTER CHEMICAL KIT
9099826000 1 SPLASH GUARD 510MM 20 KIT
9100000065 1 MOP AND TRASH KIT
9100000005 1 AUTOMATIC WATER FILLING KIT
L08837025 1 BRUSH DISC 530MM 21 PROLENE
L08837026 1 BRUSH DISC 530MM 21 PROLITE
L08837027 1 BRUSH DISC 530MM 21 UNION MIX
L08837028 1 BRUSH DISC 530MM 21 MIDLITE GRIT 180
L08837029 1 BRUSH DISC 530MM 21 MID GRIT 240
L08837065 1 BRUSH DISC 530MM 21 MAGNA GRIT 46
L08837066 1 BRUSH DISC 530MM 21 DYNA GRIT 80
L08837067 1 BRUSH DISC 530MM 21 AGLITE GRIT 500
L08837018 1 PAD HOLDER 530MM
9099671000 1 PAD HOLDER FLAT 20 508MM
10001955 1 PAD 20 508MM ECO BLACK 5PCS
10001956 1 PAD 20 508MM ECO BLUE 5PCS
10001957 1 PAD 20 508MM ECO BROWN 5PCS
10001958 1 PAD 20 508MM ECO GREEN 5PCS
10001959 1 PAD 20 508MM ECO RED 5PCS
10001960 1 PAD 20 508MM ECO WHITE 5PCS
10002348 1 PAD 20 508MM ECO BRILLIANCE RED 2PCS
10002349 1 PAD 20 508MM ECO BRILLIANCE BLUE 2PCS
10002350 1 PAD 20 508MM ECO BRILL. YELLOW 2PCS
10002351 1 PAD 20 508MM ECO BRILLIANCE GREEN 2PCS
56390008 1 BRUSH NYLON REV
56390079 1 MICROFIBER PAD
DESCRIPTION
10/14 SC500 - 9099981000 35
A Nilfisk-Advance Brand
14600 21st Avenue North
Plymouth, MN 55447-3408
www.advance-us.com
Phone: 800-989-2235
Fax: 800-989-6566
©2014 Nilfisk-Advance, Inc.
Loading...
