NILFISK SC450 User Manual

™

SC450

Battery Operated Scrubber

Smart cleaning.

A Nilfisk-Advance Brand

SC450

™

Battery Operated Scrubber

Ideal applications include:

• Hospitals/Healthcare Facilities

• Schools and Universities

• Churches and Religious Facilities

• Hotels

• Commercial Cleaning

• Manufacturing Facilities

• Distribution/Warehouse

• Government Buildings and Installations

• Airports, Train Stations and Bus Depots

• Casinos

• Ofce Buildings

• Health Clubs

SC450™ Automatic Scrubber Designed for Reliable,
Cost-Efficient Performance

Dependable, easy-to-use scrubber
solution simplifies cleaning operation
while maximizing the bottom line

The Advance SC450™ automatic scrubber provides simple,
cost-effective performance for daily scrubbing needs.
With reliable operation, high productivity and low
maintenance—all at a budget-friendly value—this
contractor-grade machine is designed to satisfy a wide

range of applications. The 10.5 gallon SC450 features a
20 inch scrub path to accommodate both small and large
jobs. From hospitals and schools to manufacturing facilities

and warehouses, the SC450 provides the flexibility needed

for today’s hardworking contractor.

Effortless operation

Designed with simple and intuitive controls, the SC450
ensures easy operator training. A unique two-button
control panel allows users to quickly switch between
scrub and vacuum functions. For enhanced ease-of-use,
the vacuum motor automatically shuts off when the tank

is full to prevent overflow, while the brushes and water

turn off while the machine is in neutral. A safety on/off

switch is located on the handle for operator convenience,

enabling a quick shut down if needed. The pad-assist

machine also minimizes operator labor, easily pulling the
machine across the floor during operation.

Easy maintenance

Featuring open access to all critical machine components,

the SC450 provides easy maintenance. A large,

11.9 gallon recovery tank can be simply lifted to inspect
and clean tank access to oat shut-off. The squeegee

blade can be easily removed or rotated without the use
of tools.

Sustainable cleaning solution

Operating at a sound level of only 68 dB A, the SC450 meets
LEED-EB and GS-42 noise standards—allowing for daytime

cleaning or cleaning of noise-sensitive areas. Solution
Control™ calibrates the machine’s solution flow, which

enables users to meet green cleaning requirements by

minimizing the use of water and detergent. The SC450 is also
available with maintenance-free AGM batteries, eliminating
safety concerns associated with traditional wet-acid batteries.

Wrap-around ergonomic handle
system provides operator comfort

Easy-to-access, 11.9 gallon recovery
tank allows for simple cleanup

Front ll, 10.5 gallon solution tank

Variable pad driven assistance

Edge guide enables easy
wall cleaning

Safety on/off switch is located

on the handle for operator
convenience

Center-pivot designed

squeegees provide 100%
water pickup on turns

Non-marking rear wheels

for maneuverability

Easy-to-use control panel allows operators
to operate the SC450™ by only using two
buttons and a switch.

The SC450™ tips back with minimal pressure

required for efcient transportation.

Adjustable machine deck provides
increased down pressure to optimize
scrubbing for heavy-duty applications.

Solution drain hose also functions as the
solution level indicator while large
recovery drain hose offers soft, squeezable

section to enable manual ow control.

Large recovery tank with easy access
allows easy inspection and cleaning.

Tool-less squeegee blades can be rotated
for use on both sides to save
replacement costs.

Technical Specifications

Model SC450

Max Speed 3 mph (4.83 kph)
Voltage 24 V
IP Protection Class IPX4
Insulation Class I
Brush Motor 480 W
Vacuum Motor Power 330 W
Airflow 36 L/Sec
Vacuum 1,200 MPA
Sound Pressure Level 68 dB A
Maximum Run Time 140 min
Productivity Rate Theoretical / Actual 15,748 ft2 / 7,308 ft2
Scrubbing Width 20 in (50.8 cm)
Min. Turn-around Aisle Width 46 in (116.8 cm)
Water Flow 0.105 - 0.422
Solution Tank 10.5 gal (39.75 L)
Recovery Tank 11.9 gal (45.05 L)
Squeegee Width 30 in (76.2 cm)
Brush Pressure 66 lb (29.94 kg)
Brush Speed 154 RPM
Brush Size (1) 20 in (50.8 cm)
Dimensions (L x W x H) 46.2 in x 22 in x 38.6 in

(117.35 cm x 55.88 cm x 98.04 cm)

Battery Compartment Size (L x W x H) 13.7 x 13.7 x 11.8 in

(34.80 cm x 34.80 cm x 29.97 cm)
Weight without Batteries 167 lb (75.75 kg)
Weight with Batteries 285 lb (129.27 kg)
Part Number

Specifications are subject to change without notice.

56383128 with 105 Ah wet batteries, two each

56383129 with 98 Ah maint-free (gel) batteries, two each

™

Accessories and options

• Squeegee Blade Kits

• Integrated Solution Fill Hose

• Wet Pick Up Kit

• Scrub & Vac Kit

• 20 inch (51 cm) Disc Deck Kit Complete
with Squeegee

• Battery Watering Can with Automatic Shut-off,
2 quart (1.9 L)

• Roto-mold Wipe on Tank Protectant,
1 quart (.9 L) Bottle

• Multiple Brushes Available

• Short-trim Pad Holder with Pad Retainer

• Bristle Splash Skirt

SNAP

IT!

Productivity

The Advance SC450™ is the ultimate contractor-grade machine. With simple,

reliable performance, less maintenance and endless flexibility, the SC450

ensures superior cleaning results—all while remaining within your

maintenance budget.

Smart cleaning.

Our products are designed using innovative

technologies that increase productivity and

drive down the cost to clean.

Maintain peak performance with Nilsk

Genuine OEM Parts.

©2013 Nilfisk-Advance, Inc. Form L3290A 1-21-13
