Nilfisk Captor 4300B, Captor 4800B, CR 1100B, 1200B Instruction manual

Captor

™

4300B, 4800B

CR 1100B, 1200B

Instructions For Use Instrucciones de uso

Advance MODEL 56303000 (4800), 56303001 (4300) 56303591 (4300 AXP), 56303592 (4800 AXP) Nilﬁ sk MODEL 56303004 (CR 1200), 56303005 (CR 1100 / OBS)

2/04 revised 3/08 Form Number 56041577

A-English B-Español

TABLE OF CONTENTS

Page

Introduction ...................................................................................A-4

Parts and Service ...........................................................................A-4

Nameplate ......................................................................................A-4

Uncrating the Machine ....................................................................A-4

Cautions and Warnings ..................................................................A-5

Consignes de prudence et de sécurité ...........................................A-6

General Information ........................................................................ A-7

Battery Installation ..................................................................A-8 - A-9

Know Your Machine / Operator’s Compartment ..............A-10 – 13

Preparing the Machine for Use

Pre-Operational Checklist .............................................................A-14

Main Broom ..................................................................................A-14

Scrub Brush Installation ......................................................A-14 - A-15

Filling the Solution Tank ................................................................A-16

Detergent (AXP™/EDS™) System .....................................A-16 - A-17

Operating the Machine

Sweeping ......................................................................................A-18

Emptying the Hopper .................................................................... A-18

Scrubbing .....................................................................................A-19

Emptying the Recovery Tank ........................................................ A-19

ENGLISH / A-3

After Using the Machine

After Use .......................................................................................A-20

Maintenance Schedule

Maintenance Schedule .................................................................A-20

Charging the Battery .....................................................................A-21

Main Broom Maintenance .............................................................A-22

Side Broom Maintenance .............................................................A-23

Squeegee Maintenance ................................................................A-24

Hopper Dust Control Filter ............................................................ A-25

Hydraulic Oil .................................................................................A-25

Drive Wheel Gear Case Oil ..........................................................A-26

Lubrication ....................................................................................A-26

Circuit Breaker Location ...............................................................A-26

Troubleshooting .................................................................A-27 – A-28

Technical Speciﬁ cations ...............................................................A-29

revised 11/07

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-3

A-4 / ENGLISH

INTRODUCTION

This manual will help you get the most from your Nilﬁ sk-Advance™ Sweeper / Scrubber. Read it thoroughly before operating the machine. References to “right” and “left” in this manual mean right or left as seen from the driver’s seat.

Note: Bold numbers or letters in parentheses indicate an item illustrated on pages 10 – 13 unless referred to a speciﬁ c ﬁ gure number.

P ARTS AND SERVICE

Repairs, when required, should be performed by your Authorized Nilﬁ sk-Advance Service Center, who employs factory trained service personnel, and maintains an inventory of Nilﬁ sk-Advance original replacement parts and accessories.

Call the NILFISK-ADVANCE INDUSTRIAL DEALER named below for repairs or service. Please specify the Model and Serial Number when discussing your machine.

(Dealer, afﬁ x service sticker here.)

NAMEPLATE

The Model Number and Serial Number of your machine are shown on the Nameplate, located on the wall of the operator’s compartment. This information is needed when ordering repair parts for the machine. Use the space below to note the Model Number and Serial Number of your machine for future reference.

MODEL ________________________________________________ SERIAL NUMBER _______________________________________ Note: Reference the separately supplied engine manufacture’s maintenance and operator manual for more detailed engine speciﬁ cation and

service data.

UN-CRATING

Upon delivery, carefully inspect the shipping crate and the machine for damage. If damage is evident, save all parts of the shipping crate so that they can be inspected by the trucking company that delivered the machine. Contact the trucking company immediately to ﬁ le a freight damage claim.

1 After removing the crate, remove the wooden blocks next to the wheels and any hold down straps. 2 Check the hydraulic oil level. 3 Read the instructions in the Preparing the Machine For Use section of this manual, then install the battery. 4 Place a ramp next to the front end of the pallet. 5 Read the instructions in the Operating Controls and Operating the Machine sections of this manual. Slowly drive the machine forward

down the ramp to the ﬂ oor. Keep your foot lightly on the brake pedal until the machine is off the pallet.

CAUTION!

Use extreme CAUTION when operating this machine. Be certain that you are thoroughly familiar with all operating instructions before using this machine. If you have any questions, contact your supervisor or your local Nilﬁ sk-Advance Industrial Dealer. If the machine malfunctions, do not try to correct the problem unless your supervisor directs you to do so. Have a qualiﬁ ed company mechanic or an authorized Nilﬁ sk-Advance Dealer service person make any necessary corrections to the equipment. Use extreme care when working on this machine. Loose clothing, long hair, and jewelry can get caught in moving parts. Turn the Key Switch OFF and remove the key before servicing the machine. Use good common sense, practice good safety habits and pay attention to the yellow decals on this machine. Drive the machine slowly on inclines. The drive pedal will control machine speed while descending inclines. DO NOT turn the machine on an incline; drive straight up or down. The maximum rated incline for sweeping and scrubbing is 6°. The maximum rated incline during transport is 8°.

A-4 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

ENGLISH / A-5

CAUTIONS AND WARNINGS SYMBOLS

Nilﬁ sk-Advance uses the symbols below to signal potentially dangerous conditions. Always read this information carefully and take the necessary steps to protect personnel and property.

DANGER!

Is used to warn of immediate hazards that will cause severe personal injury or death.

WARNING!

Is used to call attention to a situation that could cause severe personal injury.

CAUTION!

Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.

Read all instructions before using.

GENERAL SAFETY INSTRUCTIONS

Speciﬁ c Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.

WARNING!

* This machine shall be used only by properly trained and authorized persons. * While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. * Keep sparks, ﬂ ame and smoking materials away from battery. Explosive gases are vented during normal operation. * Charging the battery produces highly explosive hydrogen gas. Charge battery only in well-ventilated areas away from open

ﬂ ame. Do not smoke while charging the battery.

* Remove all jewelry when working near electrical components. * Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels. * Never work under a machine without safety blocks or stands to support the machine. * Do not dispense ﬂ ammable cleaning agents, operate the machine on or near these agents, or operate in areas where

ﬂ ammable liquids exist.

* Do not clean this machine with a pressure washer. * Only use the brushes provided with the appliance or those speciﬁ ed in the instruction manual. The use of other brushes

may impair safety.

CAUTION!

* This machine is not approved for use on public paths or roads. * This machine is not suitable for picking up hazardous dust. * Use care when using scariﬁ er discs and grinding stones. Nilﬁ sk-Advance will not be held responsible for any damage to

ﬂ oor surfaces caused by scariﬁ ers or grinding stones.

* When operating this machine, ensure that third parties, particularly children, are not endangered. * Before performing any service function, carefully read all instructions pertaining to that function. * Do not leave the machine unattended without ﬁ rst turning the key switch off (O), removing the key and applying the parking

brake.

* Turn the key switch off (O) before changing the brushes, and before opening any access panels. * Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts. * Use caution when moving this machine in below freezing temperature conditions. Any water in the solution or recovery

tanks or in the hose lines could freeze.

* The battery must be removed from the machine before the machine is scrapped. The disposal of the battery should be

safely done in accordance with your local environmental regulations.

* Do not use on surfaces having a gradient exceeding that marked on the machine. * All doors and covers are to be positioned as indicated in the instruction manual before using the machine.

SAVE THESE INSTRUCTIONS

revised 11/07

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-5

A-6 / ENGLISH

CONSIGNES DE PRUDENCE ET DE SÉCURITÉ SYMBOLES

Les symboles reproduits ci-dessous sont utilisés pour attirer l’attention de l’opérateur sur des situations dangereuses. Il est donc conseillé de lire attentivement ces indications et de prendre les mesures adéquates en vue de protéger le personnel et le matériel.

DANGER!

Ce symbole est utilisé pour mettre l’opérateur en garde contre les risques immédiats pouvant provoquer des dommages corporels graves, voire entraîner la mort.

ATTENTION!

Ce symbole est utilisé pour attirer l’attention sur une situation susceptible d’entraîner des dommages corporels graves.

PRUDENCE!

Ce symbole est utilisé pour attirer l’attention de l’opérateur sur une situation qui pourrait entraîner des dommages corporels minimes, ou des dommages à la machine ou à d’autres équipements.

Lire toutes les instructions avant d’utiliser l’appareil.

CONSIGNES GENERALES DE SECURITE

Les consignes spéciﬁ ques de prudence et de sécurité mentionnées ici ont pour but de vous informer de la survenance de tout risque de dommages matériels ou corporels.

ATTENTION!

* Cette machine ne pourra être utilisée que par du personnel parfaitement entraîné et dûment autorisé.

* Evitez les arrêts subits lorsque la machine est chargée et se trouve sur des rampes ou des plans inclinés. Evitez les virages serrés. Adoptez

une vitesse réduite lorsque la machine est en descente. Ne nettoyez que lorsque la machine monte la pente.

* Eloignez les batteries de toutes ﬂ ammes, étincelles ou substance fumigène. Les gaz explosifs sont ventilés pendant le fonctionnement normal. * De plus, du gaz hydrogène explosif s’échappe des batteries lorsqu’elles sont en charge. Ne procédez au chargement des batteries que dans

une zone bien ventilée, loin de toute ﬂ amme. Ne fumez pas à proximité des batteries lorsqu’elles sont en charge.

* Otez tous vos bijoux lorsque vous travaillez à proximité de composants électriques. * Positionnez la clé de contact sur off (O) et déconnectez les batteries avant de procéder à l’entretien des composants électriques. * Ne travaillez jamais sous une machine sans y avoir placé, au préalable, des blocs de sécurité ou des étais destinés à soutenir la machine * Ne déversez pas d’agents nettoyants inﬂ ammables, ne faites pas fonctionner la machine à proximité de ces agents ou d’autres liquides

inﬂ ammables.

* Ne nettoyez pas cette machine avec un nettoyeur à pression. * Utilisez uniquement les brosses fournies avec l’appareil ou celles spéciﬁ ées dans le manuel d’instructions. L’utilisation d’autres brosses peut

mettre la sécurité en péril.

PRUDENCE!

* Cette machine n’est pas conçue pour une utilisation sur les chemins ou voies publics. * Cette machine n’est pas conçue pour le ramassage des poussières dangereuses. * N’utilisez pas de disques de scariﬁ cateur ni de meules. Nilﬁ sk-Advance ne pourra en aucun cas être tenue pour responsable des dommages

occasionnés à vos sols par ce type d’équipement (vous risquez également d’endommager le système d’entraînement des brosses). * Lors de l’utilisation de cette machine, assurez-vous que des tiers, et notamment des enfants, ne courent pas le moindre risque. * Avant de procéder à toute opération d’entretien, veuillez lire attentivement toutes les instructions qui s’y rapportent. * Ne laissez pas la machine sans surveillance sans avoir, au préalable, coupé le contact, enlevé la clé de contact (O) et tiré le frein à main. * Positionnez la clé de contact sur off (O) avant de remplacer les brosses ou d’ouvrir tout panneau d’accès. * Prenez toutes les mesures nécessaires pour éviter que les cheveux, les bijoux ou les vêtements amples ne soient entraînés dans les parties

mobiles de la machine. * Faites attention lorsque vous déplacez cette machine dans un endroit où la température peut descendre sous 0°. Car l’eau contenue dans les

réservoirs de solution ou de récupération ou dans les conduites risquerait de geler et par là même d’endommager les valves et raccords de la

machine. Rincez avec un liquide de lave-glace. * Prenez soin d’enlever les batteries de la machine avant de mettre cette dernière au rebut. Pour ce qui est de l’élimination des batteries,

conformez-vous aux réglementations locales en matière d’environnement.

* N’utilisez pas sur des surfaces dont la pente dépasse celle mentionnée sur la machine. * Toutes les portes et couvercles doivent être dans la position mentionnée dans le manuel d’instruction avant de mettre la machine en service.

CONSERVEZ SOIGNEUSEMENT CES INSTRUCTIONS

A-6 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

revised 11/07

ENGLISH / A-7

HOPPER SAFETY SUPPORT

WARNING!

Make sure the Hopper Safety Support (HH) is in place whenever attempting to do any maintenance work under or near the raised hopper. The Hopper Safety Support (HH) holds the hopper in the raised position to allow work to be performed under the hopper. NEVER rely on the machine’s hydraulic components to safely support the hopper.

JACKING THE MACHINE

CAUTION!

Never work under a machine without safety stands or blocks to support the machine.

• When jacking the machine, do so at designated locations (Do Not jack on the hopper) - see jacking locations (11)

TRANSPORTING THE MACHINE

CAUTION!

Before transporting the machine on an open truck or trailer, make sure that . . .

• All access doors are latched securely.

• The machine is tied down securely - see tie-down locations (4).

• The machine parking brake is set.

TOWING OR PUSHING A DISABLED MACHINE

CAUTION!

If the machine must be towed or pushed, make sure the Main Power Switch (CC) is in the OFF position and do not move the machine faster than a normal walking pace (2-3 miles per hour) and for short distances only. If the machine is to be moved long distances the rear drive wheel needs to be raised off the ﬂ oor and placed on a suitable transport dolly.

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-7

A-8 / ENGLISH

BATTERY INSTALLATION

See Figure 1 & 2. The battery required for this machine is sold separately. The maximum battery weight for this machine is 1,875 lbs (850

kg); the minimum battery weight is 1,400 lbs (635kg). For proper battery installation, please consult your Nilﬁ sk-Advance Industrial Dealer. DO NOT attempt to install the battery with an overhead hoist or forklift; it can only be installed with a battery cart. Connect the connector plug (A) on the battery to the machine plug behind the steering wheel. Make sure the battery is ﬁ rmly seated against the End Brace (B) on the driver’s side of the battery compartment. Reinstall the battery Stop Plate (C) on the left side of the compartment and snug up the Bumpers

(D) so the battery cannot slide from side-to-side. NOTE: The Battery Disconnect Tab (E) has to be assembled to the Battery Connector Plug (A) on the battery.

WARNING!

Battery weight in excess of 1,875 lbs (850 kg) or below 1,400 lbs (635kg) may cause the premature failure of parts including

the tires, and may result in decreased stability and control, which could cause personal injury or death and/or property damage. Use of a battery in excess of the weight limit will void the warranty.

IMPORTANT!

Follow instructions packed with the battery and charger before charging the battery. Read the instructions for Charging the Battery in the Maintenance section of this manual.

FIGURE 1

A-8 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

FIGURE 2

ENGLISH / A-9

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-9

A-10 / ENGLISH

KNOW YOUR MACHINE

1 Operator’s Seat 2 Strobe Light (optional / standard on Nilﬁ sk Models) 3 Solution Tank Fill 4 Tie Down Locations 5 Recovery Tank Drain Hose 6 Recovery Tank Latch 7 Left Battery Compartment Access Panel 8 Main Broom Left Access Door 9 Hopper Cover Prop Rod 10 Front Wheel 11 Jacking Location 12 Left Side Broom

13 Hopper Cover Latch 14 Headlights 15 Right Side Broom 16 Hopper Cover 17 Dust Control Filter 18 Dust Control Shaker Assembly 19 Shaker Assembly Latch 20 Battery 21 Battery Compartment Door 22 Steering Wheel

A-10 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

KNOW YOUR MACHINE (CONTINUED)

23 Electrical Compartment Door 24 Water Level Gauge 25 Recovery Tank Lid 26 Recovery Tank “Tip-Out” Grip 27 Hydraulic Power Unit (Reservoir & Filter) 28 Right Battery Compartment Access Panel 29 Main Broom Right Access Door 30 Access Door Latch 31 Skirt Assembly 32 Inline Solution Filter 33 Solution Tank Drain Hose 34 Rear Roller Bumper 35 Squeegee Tool Handle 36 Squeegee Tool Assembly 37 Tail Light

ENGLISH / A-11

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-11

A-12 / ENGLISH

CONTROL PANEL

A Low Battery Indicator B Horn * Horn ON Indicator C Parking Brake Indicator (not used) D Headlights * Headlight ON Indicator E Machine Needs Service Indicator F Hydraulic Filter Plugged Indicator G Speed Switch * Speed Switch Indicator H Scrub Pressure Decrease Switch * Scrub Pressure Decrease Indicator I Scrub Pressure Increase Switch * Scrub Pressure Increase Indicator J Scrub Pressure Display K Solution Switch * Solution ON Indicator L Solution Tank Empty Indicator M Recovery Tank Full Indicator N Vacuum System Switch * Vacuum System ON Indicator O Scrub System OFF Switch * Scrub System Indicator P Side Broom ON * Side Broom ON Indicator

Q Main Broom ON Indicator R Light Sensor S Shaker Switch * Shaker ON Indicator (left) * Dust Filter Plugged Indicator (right / optional) T Dust Control Switch * Dust Control ON Indicator U Side Broom UP/OFF Switch * Side Broom OFF Indicator V Open Dump Door Switch * Open Dump Door Indicator W Hopper Open Indicator X Hopper Overtemp Indicator Y Close Dump Door Switch * Close Dump Door Indicator Z Lower Hopper Switch * Lower Hopper Indicator AA Raise Hopper Switch * Raise Hopper Indicator BB Hour Meter Display CC Main Power Switch DD Battery Condition Indicator

A-12 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

OPERATOR’S COMPARTMENT

EE Solution Flow Control Lever FF Main Broom Raise/Lower (ON/OFF) Lever GG Main Broom Adjust Knob HH Hopper Safety Support Lever II Control Panel JJ Main Broom Overload Indicator Light KK Emergency Battery Disconnect LL Tilt Wheel Lever MM Drive Pedal NN Brake Pedal OO Parking Brake Latch PP Operator Seat Adjustment Lever

ENGLISH / A-13

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-13

A-14 / ENGLISH

PRE-OPERATIONAL CHECKLIST

Before Each Use: * Inspect the machine for damage or oil and water leaks. * Check the hydraulic oil level (27). * Make sure the recovery tank is empty. * Make sure the battery charger is not connected to the machine. * Check battery charge condition.

In the Driver’s Seat: * Be sure that you understand the operating controls and their functions. * Adjust the seat to allow easy reach of all controls. * Insert the Master Key and turn the Ignition Key Switch (CC) to the ON position. Check for proper operation of the Horn (B), Hour Meter

(BB) and Headlights (14). Turn the Ignition Key Switch (CC) OFF.

* Check the Parking Brake Latch (OO). The latch must hold its (locked parked) setting ﬁ rmly with out easily being released.

(Report all defects immediately to service personnel).

Plan Your Cleaning in Advance: * Presweep heavily littered areas for more efﬁ cient operation. * Arrange long runs with a minimum of stopping or starting. * Allow 6 inches of broom path overlap to ensure complete coverage. * Avoid making sharp turns, bumping into posts, or scraping the side of the machine.

MAIN BROOM

Several different main brooms are available for this machine. Contact your Nilﬁ sk-Advance dealer if you need help selecting the best broom for the surface and litter that you will be sweeping. NOTE: Reference broom maintenance for installation steps.

SCRUB BRUSH INSTALLATION

1 Make sure the Key Switch (CC) is off (O). See Figure 3. Remove side skirt assemblies for easier access. NOTE: Loosen large Black

Knob (A) at the front of each skirt mounting bracket, slide the skirt assembly forward and lift straight UP and off scrub deck.

2 To mount the brushes (or pad holders) align the lugs on the brush with the holes on the mounting plate and turn to lock in place

according to rotation directions shown in Figure 4.

A-14 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

FIGURE 3

ENGLISH / A-15

FIGURE 4

TOP VIEW OF SCRUB DECK SHOWING DIRECTION TO ROTATE

BRUSHES WHILE INSTALLING FOR EACH BRUSH MOTOR

Outside arrows represent brush installation rotation direction. Inside arrows represent brush motor rotation while scrubbing.

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-15

A-16 / ENGLISH

FILLING THE SOLUTION TANK

The solution tank ﬁ ll (3) is located at the left rear corner of the machine and has a 75 gallon (284 liter) maximum capacity. Fill the tank with the proper dilution of cleaning chemical mixed with water according to the manufacturer’s recommendations. If using a powdered chemical, mix it with water in a bucket before putting it into the machine’s solution tank. NOTE: DO NOT ﬁ ll the tank past the Maximum Level on the Water Level Gauge (24). NOTE: AXP/EDS machines can either be used conventionally with detergent mixed in the tank or the AXP/EDS detergent dispensing system can be used. When using the AXP/EDS detergent dispensing do not mix detergent in the tank, plain water should be used.

CAUTION!

Use only low-sudsing, non-ﬂ ammable, non-caustic cleaning chemicals intended for machine application.

DETERGENT SYSTEM PREPARATION AND USE (AXP/EDS MODELS ONLY)

Fill the detergent cartridge with a maximum of 2.2 gallons (8.32 Liters) of detergent. SERVICE NOTE: Remove the detergent cartridge from the detergent box prior to ﬁ lling to avoid spilling detergent on the machine. It is recommended that a separate cartridge be used for each detergent you plan to use. The detergent cartridges have a white decal on them so you can write the detergent name on each cartridge to avoid mixing them up. The detergent cartridge has a Magnetic Slider (A) on one end that needs to be set to the proper dilution ratio according to the dilution instructions on the manufacturer’s bottle. Slide the Magnet Slider (A) to the appropriate location on Detergent Dilution Ratio Decal (B). When installing a new cartridge, remove the Cap (C) and place the cartridge in the detergent box. Install the Dry Break Cap (D) as shown. The system should be purged of previous detergent when switching to a different detergent. SERVICE NOTE: Move machine over ﬂ oor drain before purging because a small amount of detergent will be dispensed in the process.

To Purge When Changing Chemicals:

1 Disconnect and remove the detergent cartridge. 2 Turn the Key Switch (CC) ON and press the Detergent ON/OFF Switch (RR) for at least 2 seconds. NOTE: Once activated the purge process takes 10 seconds. See

illustration on next page for Detergent System indicators. Normally one purge cycle is adequate to purge the system.

To Purge Weekly:

1 Disconnect and remove the detergent cartridge. Install and connect a Cartridge ﬁ lled with clean water 2 Turn the Key Switch (CC) ON and press the Detergent ON/OFF Switch (RR) for at least 2 seconds. NOTE: Once activated the purge process takes 10 seconds. See

illustration on next page for Detergent System indicators. Normally one purge cycle is adequate to purge the system. The Detergent Box (E) has a Detergent Level Viewing Slot (F) for keeping track of how much detergent is remaining in the cartridge. When the detergent level is nearing the bottom of this slot it is time to reﬁ ll or replace the cartridge.

General Use:

The detergent (AXP/EDS) system is enabled when the Key Switch (CC) is turned on and reverts to the last state (Chem On or Chem Off) it was in prior to the last power down. The current Solution Flow Rate (VV) and the last used Detergent Ratio (WW) (if in “Chem On” state) are displayed. The Status LED (YY) indicates the status of the system as follows:

GREEN: Solution not low and chemical pump ON (pumping solution and chemical) BLINKING GREEN: Purge has been activated LED OFF: Solution ﬂ ow position = 0 or solution solenoid is OFF ORANGE: Solution ON and Chemical OFF (pumping solution only) BLINKING RED: Solution low and chemical pump ON (pumping solution only)

No detergent is dispensed until the scrub system is activated and the Drive Pedal (MM) pushed forward. The detergent ratio can be varied by subsequently pressing the Detergent Ratio Increment and Decrement Switches (SS & TT). The detergent ﬂ ow rate increases or decreases with the solution ﬂ ow rate but the detergent ratio remains the same unless changed. During scrubbing, the detergent system can be turned off at any time by pressing the Detergent ON/ OFF Switch (RR) to allow scrubbing with water only. On AXP/ EDS models the solution ﬂ ow rate (40%-100%) is electronically controlled and is displayed (VV) on the AXP/EDS display panel as shown below. SERVICE NOTE: Follow the “To Purge Weekly” instructions above if the machine is going to be stored for an extended period of time or if you plan to discontinue use of the detergent (AXP/EDS) system. The Display Panel (UU) will display an Error Code “E1” (XX) in the lower left corner if the magnetic slider circuit board (ZZ) becomes disconnected or malfunctions.

A-16 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

revised 3/08

DETERGENT SYSTEM PREPARATION AND USE (AXP/EDS MODELS ONLY)

ENGLISH / A-17

revised 3/08

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - A-17

A-18 / ENGLISH

OPERATING THE MACHINE

This is a rider-type automatic ﬂ oor sweeping and scrubbing machine. It is designed to sweep up debris, lay down cleaning solution, scrub the ﬂ oor, and vacuum dry all in one pass. The sweeping and scrubbing operations can also be performed separately.

The controls were designed with one touch operation in mind. For single pass scrubbing the user can simply depress one switch and all scrub functions on the machine will be ready to go. For sweeping, the operator can simply lower the main broom and all sweeping functions will be ready to go.

Use the Drive Pedal (MM) to control the speed of the machine. The speed of the machine will increase as the pedal is pushed closer to the

ﬂ oor. Do not press the Drive Pedal (MM) until the Main Power Switch (CC) has been turned on.

SWEEPING

Follow the instructions in preparing the machine for use section of this manual. 1 While seated on the machine, adjust the seat and steering wheel to a comfortable operating position using the adjustment controls (PP)

and (LL). 2 Release the Parking Brake (OO). To transport the machine to the work area, apply even pressure with your foot on the front of the Drive

Pedal (MM) to go forward or the rear of the pedal for reverse. Vary the pressure on the foot pedal to obtain the desired speed. 3 Push the Lower Hopper Switch (Z) to make sure the hopper is seated properly. 4 Move the Main Broom Lever (FF) to the SWEEP (middle notch) position to lower and enable the main broom. NOTE: The dump door

opens automatically when the main broom (FF) is lowered and closes when the broom is raised. Use the FULL FLOAT (last notch forward) position only when sweeping extremely rough or uneven ﬂ oors. Use at other times will only

increase broom wear. 5 When sweeping dry ﬂ oors, push the Dust Control Switch (T) to turn ON the dust control system. When sweeping ﬂ oors with puddles, push the Dust Control Switch (T) to turn OFF the dust control system before the machine enters a

puddle. Turn the dust control system back ON when the machine is back on completely dry ﬂ oor. When sweeping wet ﬂ oors, keep the Dust Control Switch (T) OFF at all times. 6 Lower the Side Broom(s) (P) when sweeping along walls or curbs. Raise the Side Broom(s) (U) when sweeping in open areas. Push

and hold the Side Broom ON/DOWN Switch (P) to lower and start the side broom motor(s). NOTE: Hold the switch until the side

broom(s) have lowered to the desired level. Side broom sweeping pattern is adjusted by pushing switches (P & U) until the desired

amount of down pressure is achieved. NOTE: If the side broom(s) were not raised and turned OFF after last use, they will automatically

lower and turn ON when the main broom is lowered and starts. 7 Drive the machine straight forward at a quick walking speed. Drive the machine slower when sweeping large amounts of dust or debris

or when safe operation dictates slower speeds. Overlap passes 6 inches (15 cm). 8 If dust comes out of the broom housing while sweeping, the Dust Control Filter (17) may be clogged. Push the Shaker Switch (S) to

clean the dust control ﬁ lter. The dust control system (T) will automatically turn OFF while the shaker is running and turn ON after the

shaker turns OFF (the shaker runs for 20 seconds). 9 Check behind the machine occasionally to make sure that the machine is picking up debris. Dirt left behind in the path of the machine

usually indicates that the machine is moving too fast, the broom needs to be adjusted, or the hopper is full.

EMPTYING THE HOPPER

WARNING!

1 Push the Shaker Switch (S) to remove excess dirt from the dust control ﬁ lter. SERVICE NOTE: For best shaker performance always

run the shaker with the hopper fully down.

2 Drive the machine close to a large trash receptacle and hold the Raise Hopper Switch (AA) until the hopper is all the way up. NOTE:

The dump door automatically closes when switch (AA) is pushed. You regain control of the dump door as soon as the hopper begins to

raise so you can dump at any height if necessary. 3 Move the machine forward until the hopper is over the receptacle, then press the Open Dump Door Switch (V) to open the dump door

and empty the hopper. 4 Check the back of the hopper and the front of the broom housing. Use a broom, if necessary, to remove litter from these areas. The

back of the hopper must seal tightly against the front of the broom housing for proper operation. 5 Back the machine away from the receptacle until the hopper will clear it, and then lower the hopper (Z). NOTE: The dump door will

automatically open when sweep function is resumed.

A-18 - FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B

+ 42 hidden pages
