Nikon AX-110 User Manual

Flatbed Scanner
ScanTouch 110
User’s Manual
Nikon
ScanTouch 110 User's Manual i
Cautions
• The reproduction of all or part of this manual without our permis­sion is prohibited.
• The information contained in this manual is subject to change without notice.
• We have made every effort to produce a perfect manual, but should you find any mistakes, we would be grateful if you would kindly let us know.
• We shall take no responsibility for consequences resulting from the operation of this product, despite the terms mentioned above.
Indication
The indications in this manual signify important safety precau­tions. In order to use this product safely, please read every section
where these indications are placed before beginning operation of this product. These indications are also placed in the table of contents so users can find them easily.
Indication
The indications in this manual signify the need for caution when using the products. These indications are placed in sections that should be read by users before beginning operation, in order to avoid damage to the product.
Trademark Information
Macintosh is a registered trademark of Apple Computer, Inc. Microsoft is a registered trademark and Windows is a trademark of Microsoft Corporation. IBM PC/AT is a trademark of International Business Machines Corporation. Other brand or product names are the trademarks or registered trademarks of their respective holders.
ii
Nikon
Important Safeguard
• Read all of instructions.
• Save these instructions for later use.
• Follow all warning and instructions marked on the product.
• When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer that have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazards.
• Do not use this product near water or in rainy/moist situation.
• Do not place on an unstable table to avoid the series damage to the product.
• The product should be operated only from the type of power source
indicated on the marketing label.
• Do not attempt to service this product yourself as opening or removing the
enclosure may expose you to dangerous voltage or other hazards.
• This unit has an autoranging input circuitary suitable 120VAC and
240VAC.
• The sound pressure level at the operators position according to IEC 704-
1:1982 is equal or less than 70dB(A).
Wichtige Sicherheitshinweise
• Bitte lesen Sie sich diese Hinweise sorgfaltig durch.
• Heben Sie diese Anleitung für den späteren Gerauch auf.
• Alle Heiweise und Warnungen die sich am Geräten befinden sind zu
beachten.
• Wenden sie sich mit allen Fragen die Service und Reparatur betreffen an
Ihren Servicepartner. Somit stellen Sie die Betriebssicherheir des Gerätes sicher.
• Benutzen Sie dieses Produkt nicht in der Nähe von wasser oder in
regerischer/feuchter Umgebung.
• Stellen Sie es nicht auf eine unstabile Unterlage um Schaden an dem
Produkt zu vermedien.
• Das Produkt sollte nur mit der auf dem Etickert angegebenen Stromquelle
betrieben werden.
• Versuchen Sie nicht, Reparaturen selber durchzuführen, da das Öffnen oder
die Entfernung des Gehäuses Sie hoher Spannung oder anderen Gefahren aussetzt.
• Der Arbeitsplatzbezogene Schalldurckpegel nach DIN 45 635 beträgt 70db
(A) oder weniger.
• Die Nerzanschlußsteckdose Soll nahe dem Gerät angebracht und leicht
zugänglich sein.
Nikon
ScanTouch 110 User's Manual iii
Federal Communications Commission (FCC) Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer­ence to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
iv
Modifications
The FCC requires the user to be notified that any changes or modifica­tions made to this device that are not expressly approved by Nikon Corporation may void the user’s authority to operate the equipment.
SCSI Cable
Please use the SCSI cable listed on page 5 in the user’s Manual sup­plied with the scanner. Using other interface cables may exceed the limits of the class B Part 15 of FCC rules.
Nikon
Notice for customers in Canada
This class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations.
ATTENTION
Cet appareil numérique de la class B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
When Taking the Unit Out of The Country
The use of this product may violate local laws and restrictions in some countries. If this is the case, we cannot bear any responsibility for any violations resulting from the use of this product.
Nikon
ScanTouch 110 User's Manual v
Notice concerning prohibition of copying or reproduction
Note that simply being in possession of material which has been copied or reproduced by means of a scanner may be punishable by law.
• Items prohibited by law from being copied or reproduced
Do not copy or reproduce paper money, coins, securities, govern­ment bonds, or local government bonds, even if such copies or reproductions are stamped “Sample”.
The copying or reproduction of paper money, coins, or securities which are circulated in a foreign country is prohibited.
The copying or reproduction of unused postage stamps or post cards issued by the government without obtaining approval from the government is prohibited.
The copying or reproduction of stamps issued by the government and certified documents stipulated by law is prohibited.
• Cautions on certain copies and reproductions
The government has issued cautions on copies or reproductions of securities issued by private companies (shares, bills, checks, gift certificates, etc.), commuter passes, or coupon tickets, except when a minimum of necessary copies are to be provided for business use by a company. Also, do not copy or reproduce passports issued by the government, licenses issued by public agencies and private groups, ID cards, and tickets, such as passes and meal coupons.
vi
• Comply with copyright notices
The copying or reproduction of works such as books, music, paintings, woodcut prints, maps, drawings, movies, and photographs which are copyrighted creative works is prohibited except when it is done for personal use at home or for similar restricted and non­commercial use.
Nikon
Contents
1. Overview ................................................................. 1
2. Before Operating the Scanner...............................2
2.1 Power Supply Precautions ..............................................2
2.2 Handling Precautions ...................................................... 4
2.3 If You Notice Anything Abnormal .................................... 7
2.4 Storage and Operating Locations ...................................7
2.5 Transportation Precaution............................................. 10
3. Parts Identification ............................................... 11
3.1 Inspection...................................................................... 11
3.2 Components.................................................................. 11
3.3 Main Body ..................................................................... 13
Contents
A Closer Look ............................................................... 13
Rear View ..................................................................... 14
Unlocking the Scanner.................................................. 15
Nikon
4. Connecting the Scanner ...................................... 16
4.1 Before Connection ........................................................ 16
4.2 Connecting the Power Cord .......................................... 17
4.3 Connecting the SCSI Cable .......................................... 19
Connecting to the Macintosh computer......................... 20
Connecting to the IBM PC/AT or compatible computer.20
SCSI Chain Connection with Other Devices .................21
4.4 Setting the SCSI ID....................................................... 23
ScanTouch 110 User's Manual vii
Contents
5. Operation .............................................................. 24
5.1 Turning on the Power.................................................... 24
5.2 Setting a Document ...................................................... 26
6. Maintenance.......................................................... 29
6.1 Static Electricity Precautions......................................... 29
6.2 Cleaning........................................................................ 30
7. Troubleshooting ................................................... 31
Appendix: Specifications.....................................34
Index...................................................................... 36
viii
Nikon

1. Overview

1. Overview
Thank you for purchasing your Nikon Flatbed Scanner ScanTouch 110. This manual describes the procedures for unpacking, setting up, and connecting the scanner, with emphasis on hardware use and precautions. Please read this manual thoroughly to ensure proper operation of your scanner.
For an explanation of how to scan and reproduce images with ScanTouch 110, please refer to the software manual.
We hope that you will find this manual helpful.
ScanTouch 110 is a low priced, full-color flatbed scanner with high­resolution, and is capable of scanning images at high speed.
• The optical resolution is 300 dpi x 600 dpi, and high resolution of
4800 dpi x 4800dpi is achieved through the software interpolation.
• The scanning area is 8.5 inches (216 mm) wide by 11.7 inches
(297mm) long, enabling scanning of letter-size documents.
Nikon
• It offers very high speed scanning of approximately 24 seconds for
a color A4 size document at 300dpi.
• Installing the optional Transparency Adapter enables scanning of
transparencies.
• Installing the optional Auto Document Feeder, enables consecutive
scanning of multiple documents.
ScanTouch 110 User's Manual 1

2. Before Operating the Scanner

2. Before Operating the Scanner

2.1 Power Supply Precautions

In order to use the ScanTouch 110 safely and correctly, and to prevent problems, pay careful attention to the following points:
• Be sure to use an AC100V-120V/AC 200V - 240V, 50/60Hz power supply. The power cord should be changed according to the power voltage.
When using a power voltage of more than AC 125V
Use a suitable power cord compliant with the safety standards of the country in which it is used, with a plug of AC 250V, 15A rating (NEMA 6P-15), and insulation of at least SVT type and more than AWG18 in thickness.
When using a power voltage of AC 125V or less
Use a suitable power cord compliant with the safety standards of the country in which it is used, with a plug of AC 125V, 10A rating and insulation of at least SVT type and more than AWG18 in thickness.
• Be sure that the electrical outlet of the power supply is grounded. Carry out the grounding in common with the other machines it is being connected with. Unless common grounding is used, a ground loop will occur, which will cause electric shock and noise static.
* The shape of the plug depends on the country of use.
2
Nikon
2. Before Operating the Scanner
• Do not ground the unit to a gas pipe or a water pipe.
• When plugging in or unplugging the power cord, be sure to touch
only the plug. Pulling on the cord can cause breakage and failure or electric shock.
* The shape of the plug depends on the country of use.
Nikon
• Do not extend the power cord of the product, as this may cause a
malfunction.
* The shape of the plug depends on the country of use.
ScanTouch 110 User's Manual 3
2. Before Operating the Scanner

2.2 Handling Precautions

• Before turning the power on, ensure that the carriage lock is in the unlocked position: . Likewise, turn the carriage lock on the scanner to the locked position: , to avoid damaging the internal optical assembly during transportation.
Remarks
• Keep the unit horizontal, with the document cover facing upward, and ensure that it is placed on a flat and stable surface for use. Failure may result if the unit is not used in a flat and level horizontal position.
4
Nikon
2. Before Operating the Scanner
• On no account disassemble the unit. The high-voltage components
inside the unit can cause electric shock.
• Do not put any foreign objects inside the unit. If flammable objects,
metal or water come into contact with the interior of the unit, failure, fire, and/or electric shock may result.
Nikon
• Do not subject the unit to any strong shocks. This can cause
breakage and failure.
• Do not place any heavy objects on the document setting glass, or
push down on the glass, as this can cause breakage and failure.
ScanTouch 110 User's Manual 5
Loading...
