Safety Precautions
Do not subject the device to severe impact or drop it from heights.
Do not use t he device in extrem e hot or col d, dust y or dam p conditions. Do not
expose it to direct sunlight.
Avoid using the device near strong magnetic fields .
Normal f unct ionin g of t he pr oduct may be dis tur bed by ESD. I f so, sim ply res et
and resta rt the dev ice fo llo wing the in struc tio n manua l. Duri ng file t ransm issio n,
please handle with care and operate in a static-free environment.
Keep the device away from water and ot her liquids. I n the event that wa ter or
other liquids enter the device, power off the product immediately and clean the
device.
Do not use ch emicals to c lean the dev ice in or der to av oid corrosion. Clean it
with a dry cloth.
Do not install this equipment in a confined space such as a book case or similar
unit. The ventilation should not be impeded by covering the ventilation openings
with items such as newspaper , table -cloths, cu rtains etc.
No naked flame sources, such as lighted candles, should be placed on the
apparatus.
Attention should be drawn to environmental aspects of battery dispo sal .
Use the apparatus in moderate climates.
We are not responsible for damage or lost data caused by malfunction, misuse,
modification of the device or battery replacement.
Do not att empt t o disass emb le, repai r or mo dify the pro duct. This wil l inva lid ate
the warranty.
If the devic e will no t be used fo r an extende d perio d of time, pl ease char ge the
battery at least once per month to maintain battery life.
Charge the battery if:
a) The battery level icon displays (An empty battery)
b) The device powers off automatically when restarted.
c) There is no response when pressing keys with keys unlocked and ba ttery full.
Do not interrupt the connection when the device is being formatted or
transferring files. Otherwise, data may be corrupted or lost.
When the device is used as a portable HD, please use only per the instructions.
Otherwise, permanent data loss could occur.
Please use and install data using the attachmen ts/acces sories pro vided and only
according to the manufacturer’s instruction.
Please refer to the information on the bottom of the device for electrical and
safety information before installing data or operating t he device.
To reduce th e risk of fi re or electr ic shock , do not expo se this dev ice to rain or
moisture. The device should not be exposed to dripping or splashing. Never
place objects filled with liquids, such as vases, on the device.
There is danger of explosion if the battery is replaced incorrectly. Replace only
with the same or equivalent type.
1
The battery (battery or batteries or battery pack) should not be exposed to
excessive heat such as sunlight, fire or the like.
Please follow responsible procedu res for battery disposal.
If the power adaptor disconnected from the device, the device will remain
operable as long as the battery has sufficient charge .
The power adaptor is a CLASS II apparatus with double insulation, and no
external ground is provided.
Safety symbol explanation:
- The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of e l ectric shock.
- To reduce the risk of electric shock, do not remove the cover (o r back) as
there are no user-serviceable parts inside. Refer servicing to qualified
personnel.
- The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating a nd maintenan ce instruc tions in
the lite rature acc ompanying the device.
- Correct Disposal of this product. This marking indicates that this
product should not be disposed of with other household waste in the EU. T o
prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustain able reuse of mate rial resources . To dispose of your used device,
please use the return and collection systems available in your area or
contact the retailer where the product was purchased. They can take this
product for safe environmental recycling.
This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
CE in which countries where the product may be u se d freely: Germany, UK, Italy,
Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg,
Austria, Finland, Sweden, Norway and Iceland.
2
Listening Cautions
This product respects the current regulations for limiting the output volume of
consumer audio devices to a safe level. By listening to your device with
headphones or earbuds at high volumes, you run the risk of permanent damage
to your ears . Even if you get used to list ening at high volumes and it seems
normal to yo u, y ou s t il l ri sk t he po ss ib i li t y of d am agi n g yo ur he a rin g. R edu c e the
volume of yo ur device to a reasonable lev el to avoid permanent heari ng damage.
If you hear ringing in your ears, reduce the volume or shut off your device. This
device has been tested with the supplied earphones. In order to preserve your
hearing, it is advised that you use only the following headphone models: the
earphones supplied with your device, or any other headphones that respect the
current regulations. Other types of headphones may produce higher volume
levels.（At full power ,the prolonged li stening o f the w alkman can dam age the ea r
of the use）
Do not use while operating a motorized vehicle. It may create a traffic hazard
and is illegal in many areas.
You should use extreme caution or temporarily discontinue use in potentially
hazardous situations created by obstructed hearing.
Even if your headphones or earphones are the open-air type designed to let you
hear outside sounds, don’t turn up the volume so high that you can’t hear what’s
around you.
Sound can be deceiving. Over time your hearing “comfort level” adapt s to higher
volumes of sound. What sounds “normal” can actua lly be loud and harmf ul to
your hearing. Guard against this by setting the volume of you r dev ice at a safe
level BEFORE your hearing adapts.
To establish a safe volume level:
a. Start your volume control at a low setting.
b. Slowly increase the sound until you can hear it comfortably and clearly,
and withou t distortion. O nce you have establ ished a comfortab le sound
level, l eave it there.
This manual may not reflect your actual device’s operation. All information is subject to change
without prior notification. Please follow your actual device’s operational procedures.
3
Table of Content
Safety Precautions ................................................................................................... 1
Listening Cautions .................................................................................................... 3
Packing C ontents ..................................................................................................... 5
Features & Functionality ........................................................................................... 5
Basic Connections ................................................................................................... 6
Basic Operation ....................................................................................................... 9
Maintenance .......................................................................................................... 13
Major Specifications ............................................................................................... 14
FCC Statement ...................................................................................................... 15
4
Feature
Functionality
Connect a headset, headphones, microphones, or
record audio, or make web phone calls.
Connect USB devices, via an optional USB
, for transferring data, music,
3. HDMI port
Connect HD television via optional HDMI cable, for
switching the display to wider screen.
4. microSD card slot
Reads and writes files stored on a microSD card.
5. Microphone
Records sounds.
Provides sound input while making calls using
Packing Contents
When you get your Nextbook device, be sure to check the following items are
included in the package:
M ain Unit ● USB cable ● AC Adaptor ●User’s Manual
Features & Functionality
1. Audio port (3.5 mm)
2. Micro-USB port
other audio equipment to listen to stereo sound,
power to the tablet and charge the battery.
conversion cable
photos, videos, and so on.
5
6. Front-facing camera
Capture a front view picture or record videos.
7. Charging indicator
Indicate s the battery-charge status.
8. Power but ton
Press to turn the display on or off.
9. Volume+/- buttons
Press to increase/decrease volume
10. Windows button
Press to open the Windows Start screen.
11. Rear camera
Captures pictures or videos.
12. Speaker
Provides audio output.
1. Both cameras do not support zoom, face tracking.
to connected USB devices.
Caution:
web-based apps.
Use while making video calls.
Press and hold to turn the tablet on or off.
Press for quick access to the most recently used
app or most recently viewed screen.
Note:
2.The Micro-USB port does not support connecting to a computer, or power sharing
Basic Connections
Charging the tablet
Note: If using the tablet for the first time, or after a long perio d of idle time , charge the
battery for more than half an hour before turning it on, to ensure system stability.
The tablet has a built-in rechargeable battery. Charge the device when the battery
level is l ow.
1. Connect the power cable into the power adapter.
2. Connect the Micro-USB cable to the Micro-USB port on the tablet.
3. Connect the power adapter to an electrical outlet and charge the tablet until the
battery is fully charged.
1. Charge the battery in an ambient temperature of 0 °C to 35 °C.
6
Note:
2. Use only the supplied power adapter to charge your tablet. Using unauthorized
power adapters or Micro-USB cables may severely damage your tablet.
1. The battery is not fully charged when you unpack your tablet.
2. A fully discharged battery takes about 4 hours to fully charge .
3. When the battery is being charged, the LED indicator lights red, and when the
battery has been fully charged, the LED indicator lights orange.
4. The LED indicator will light 4-5 seconds later after the adapter has been
connected to the tablet and the wall outlet.
Turning On the Tablet
Note: This Nextbook device has been equipped with Windows 8.1 system at the
factory, so user need not perform Windows setup again before using for the first time.
1. Press and hold the Power button for 2 seconds to turn on your tablet. The lock
screen appears.
2. Swipe-up your finger from the bottom of the display to switch to the login screen,
and then enter password to log in to Wind ows.
Now the tablet is ready for use when the Windows Start screen is displayed.
Note: If the login screen is not enabled in Windows 8.1, you will be taken directly from
the lock screen to the Start screen.
Turning Off the Tablet
Y ou can turn off the tablet in two ways:
Using the Power button:
1. Press and hold the Power button for at least 4 seconds.
2. Swipe-down the shutdown confirmation screen to the bottom edge of the display
to turn off the tablet.
Using Charms:
1. Swipe-in from the right edge of the display to access Charms.
2. Touch Settings → Power → Shut down to turn off the tablet.
7
1. Pick up a microSD card.
2. Align the mi croSD card so that the pins are poin ted toward the card slot.
3. Push the microSD card into the card slot.
to displ ay all icons in t he notification area.
Turning On/Off screen
Usually, user can press once the power button to turn on/ off the screen display.
Optionally, user can also use the Charms:
1. Swipe-in from the right edge of the display to access Charms.
2. Touch Settings → Power → Sleep to turn off the screen.
Inserting a microSD card
Removing a microSD card
Caution: Removing the mic roSD card while it is in use m ay cause data loss or result
in application errors. Make sure all save o perations to the micro SD card are complete
before removing the microSD card.
1. Touch the Desktop tile to enter Desktop mode.
2. Touch Safely Remove Hardware in the notification area at the bottom-right
corner of the screen.
Note: If you do not see Safely Remove Hard ware , touch Show Hidden Icons
3. Touch Eject SD Memory Card. A message appears confirmin g that the
microSD card can be safely removed. If a warning message appears
stating the microSD card cannot be removed, ensure all data transfers
involving the microSD card are complete.
4. Press on the microSD card to release it.
5. Slide the card out after it pops out from the microSD card slot.
Using Headphones
You can connect a headset or headphones to the audio port of your tablet.
Warning: Listening to loud music for an extended period of time can lead to
hearing loss.
1. Connect headphones to the audio port (3.5 mm) on the tablet.
2. Insert the earphones in your ears and adjust the volume level to a comfortable
level.
Note: When yo u c onnect an aud io device to t he 3.5 mm audi o jack, the integrated
speakers on your tablet are muted automatically
.
8
Finger Gesture
You can do
Touch buttons on the screen.
Touch and Hold
Display detailed information about an item.
Caution: To prevent damage to the headphones when disconnecting it from the
tablet, pull the connector instead of the cable.
Basic Operation
Wi-Fi Setting
Turning On/Off Wi-Fi:
1. Swipe-in from the right edge of the display to access C harms.
2. Touch Settings → Network icon .
3. Swipe Wi-Fi icon left or right to turn Wi-Fi on or off.
Connecting to a network:
1. Swipe-in from the right edge of the display to access Charms.
2. Touch Settings → Available .
3. Selec t an available network from the list a nd touch Connect.
Gestures
Your tablet has a multi-touch display. You can touch the screen to operate the tablet.
Touch
Tap gently on the display with
your fingertip.
Touch and hold your finger on
the display.
Select it ems on the screen, inc luding options,
entries, images, and icons.
Start apps.
Input text using the on-screen keyboard.
Open the context menu of an item to perform
further actions.
9
Keeping your finger in
your fingertip to the desired
3. Take your finger off the
Zoom in
Touch the display with two
fingers and then move the
Touch the display with two
fingers and then move the
work only in one orientation.
Drag
1. Touch and hold your finger
on an item on the screen.
2.
contact with the display, move
location.
display to drop the item in the
desired location.
Swipe or Slide
Move your finger in a vertical
or horizontal direction on the
display.
fingers apart.
Zoom out
fingers closer.
Move items such as images and icons on the
screen.
Scroll through the Start screen, web pages,
lists, entr i es, photo s, contacts , a n d so on.
Close an ap p. (Swipe th e app to the bott om of
the display.)
Enlarge the view of an image or web page.
Reduce the view of an image or web page.
Screen Orientation
For optimal viewing experience, the screen orientation changes automatically to
portrait or landscape format depending on how you hold the tablet. You can disable
automatic screen rotation and lock the screen in portrait or landscape mode.
Note: Some apps may not support automatic screen rotation and are designed to
Locking the screen orientati on
1. Ch ange the screen to the desired orientation.
10
2. Swipe-in from the right edge of the display to access Charms.
3. Touch Settings → Screen .
4. Touch toggle to lock the screen orientation, or touch toggle to unlock
the screen orientation.
Windows 8.1 Start Screen
The Windows 8.1 Start scr ee n displays a list of defa ult and custom Live Tiles, which
act as a shortcut to Mail, Windows Explorer, Weather app, Calendar, Windows Store,
Internet Explorer, and other installed apps.
Live Tiles on your Start screen change and update in real time to show news and
sports updates, weather updates, social-networking feeds, and so on.
The tile-based user interface gives you direct acce s s t o y o ur most recently u sed ap ps ,
emails, photos, music, videos, contacts , u p d ates from social-networking sites, and
frequently viewed websites. You can pin your favorite apps as tiles to customize the
Start screen.
Y ou also can pers onalize the Start screen by setting your favorite picture as the
wallpaper.
Note: Live Tiles can be added or removed by using Pin to taskbar , Pin to Start
or Unpin from Start options.
Accessing the Start screen
When you computer boots into Windows, the Start screen appear s by default . To
access the start screen from any other window or app, use any of the following
methods.
Press the Windows button.
Swipe-in from the right edge of the display to access Charms, and then touch the
Start icon .
11
If you are at the Start sc reen, press ing the Start icon takes you to the most
recent ly used app or mos t recently v iewed screen.
Note: The functionality of the Start icon is same as Windows button
.
Swipe left
1. Swipe-in from the right edge of the display to show the charms. Charms provide
access to the system com mands, such as Start, Se arch, Share, Devices, a nd
Settings options.
2. From the Start screen, swiping left until you reach the end of the tile view will
bring up the Apps icon. Touch Apps icon to show an alphabetical list of all
apps installed on your tablet.
Swipe right
1. Swipe-in quickly from the left edge of the display to swit c h the currently running
apps.
2. Swipe-in slowly from the left edge of the display to show thumbnails of open apps.
3. Swipe-in and out on the left edge of the display to show a list of the most recently
used apps .
Swipe up/down
1. From Start screen, swipe-in from the bottom or top edge of the display to show
the Customize icon . Touch Customize to organize the tiles on your Start
screen.
2. Swipe-in from the top to the bottom of an app to dock or close the app.
Synchronizing Your Tablet
Using a Microsoft account
If your computer has Microsoft Windows 8.1 installed, you can synchronize user
settings of your tablet with your computer using a Microsoft account. When you sign in
with your Microsoft account on your tablet, your settings, including internet brows er
history, app settings, and personal files etc., are syn ch ronized with other Windows 8.1
PCs and tablets computers.
1. On the tablet, access Charms and click Settings → Change PC Settings →
Accounts → Your account → Connect to a Microsof t Acc ount to switch your
computer local account to your M icrosoft acc ount.
2. Click Settings → Change PC Settings → OneDrive → Sync settings to
12
not shipped with the tablet.
see the options for synchronizing your data and settings.
Copy music, photos, and videos
1. Connect your tablet to a USB storage device with a Micro-USB to standard USB
conversion cable, then transfer files to or from the USB storage device.
2. After transferr i ng files, use the Safely Remove Hardware wiza rd to remove the
USB storage device.
Note: The Micro-USB to standard USB conversion cable is sold separately and is
Maintenance
Cleaning Your Tablet
Caution:
Before you clean your tablet, disconnect all the cables and turn off the tablet. Clean
your tablet with a soft cloth dampened with wate r. Do not use l iquid or aerosol
cleaners, which may contain flammable substances .
1. Turn off your ta ble t.
2. Disconnect any attached devices, headphones, and speakers from the tablet and
from their electrical outlets.
3. Mois ten a soft, lint-free cloth with either water or a display cleaner, and wipe the
surface of the tablet until it is clean. Do not allow water from the cloth to seep
down to the tablet ports or buttons.
Caution:
1. To avoid damaging the tablet or display, do not spray cleaning solution directly
onto the display. Only use products specifically designed for cleaning display s
and follow the instructions included with the product.
2. Do not clean the keyboard with a moist cloth.
Refreshing your tablet
Refreshing your tablet w ill restore Windows to original factory settings without dele ting
any of your personal files, installed apps from Windows Store, or person alization
settings.
To restore your tablet:
1. Swipe-in from the right edge of the display to access C harms.
2. Touch Settings → Change PC settings→ Update and recovery→
Recovery.
13
Note:
created on the desktop after the process is complete.
Caution:
the required data before you proceed.
Item
Descriptions
Intel BayTrail-T CR, Quad core/1.8GHz (Z3735G)
DDR
1GB
Internal Memory
EMMC: 32GB
Expandable Memory
Micro SD card: up to 64 GB
3.5mm Earphone
Front Webcam
Front camera, 0.3 Mega Pixels; rear camera, 2.0 Mega Pixels
Bluetooth
Support
Display
Resolution,1280*800 Pixels, 8 inch LCD HD
AC Adapter: Micro USB 5V/2 A
3. Touch Get started under Refresh your PC without affecting your files.
4. Read the warning and touch Next after you read the warning.
Apps installed from the Window s S tore are automatically reinstalled after the refresh
is complete. Apps installed from sources other than the Windows Store are removed
and have to be manually installed. A list of apps removed during this process is
Resetting your tablet
Resetting your tablet will return the system to original factory settings.
1. Swipe-in from the right edge of the display to access C harms.
2. Touch Settings → Change PC settings → Update and recovery→
Recovery.
3. Touch Get started under Remove everything and reinstall Windows.
4. Read the warning and touch Next after you read the warning.
In shutdown status, user can press and hold Power & Vol- keys at the same time to
boot the device and enter Recovery mode, for the purpose of repairing or resetting the
system.
Resetting your tablet erases all data from your tablet, including your account
configuration, apps, music, pictures, files, and so on. Make sure that you back up all
Major Specifications
CPU
Operation system Windows 8.1 with Bing
Interfaces
Connection Agreement WiFi (802.11 b/g/n); BT4.0
Power Supply
USB 2.0 high speed /Micro SD (compatible SDHC, up to 64GB) card
Rechargeable lithium battery, 4000mAh;
14
Battery charging time
Battery
playback; About 6 hours of web browsing.
Storage T emp.
Operation RH
Ambient Temp.
Storage RH
About 4 hours
About 6 hours of music playback;- About 4 hours of video
-20℃ ～ +65℃
0℃ ～ +40℃
20% ～ 90% (40℃)
20% ～ 93% (40℃)
IC Cauti on.
FCC Statement
RSS-Gen Issue 4 November 2014"&"CNR-Gen 4e edition Novembre 2014:
- English:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause
interference, and (2) This device must accept any interference, including interference
that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions
suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoi t accepter tou t brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
FCC Caution.
This device complies with part 15 of t he FCC Rules. Operation is s ubject to the
following two conditions: (1) This device may not cause harmful interfere nce, and (2)
this device must accept any interference received, including interference that may
cause und esired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could vo id the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful inter ferenc e in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interf erence to rad io communic ations. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between theequipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to w hich the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The devic
e can be used in portable exposure condition without restriction.
15
This manual was correct and complete at the time of printing. However, new
specifications and updates can occur at any time without prior notice. No part of this
manual may be copied, re published, reproduced, transmi t ted or distributed in any way
without prior written consent of E Fun. Any unauthorized distribution of this manual is
expressly forbidden.
E Fun may find it n ecessary to modif y, am end or otherwise ch ange or update this
manual. We reserve the right to do this at any time, without any prior notice. All
specific ations and features are subject to change without notice. All screen shots
shown are simulated and may not represent the actual screen on production units
sold to cons umers.
For instruction manuals, updated drivers or other information, be sure to visit our
website at:
www.nextbookusa.com
Or write to us at:
E Fun
West Covina, CA 91791
USA
Copyright © 2015
16
Loading...
