NEXTBOOK Flexx 11, NXW116QC264 Instruction Manual [fr]

Safety Precautions

zDo not subject the device to severe impact or drop it from heights.

zDo not use the device in extreme hot or cold, dusty or damp conditions. Do not expose it to direct sunlight.

zAvoid using the device near strong magnetic fields.

zNormal functioning of the product may be disturbed by ESD. If so, simply reset and restart the device following the instruction manual. During file transmission, please handle with care and operate in a static-free environment.

zKeep the device away from water and other liquids. In the event that water or other liquids enter the device, power off the product immediately and clean the device.

zDo not use chemicals to clean the device in order to avoid corrosion. Clean it with a dry cloth.

zDo not install this equipment in a confined space such as a book case or similar unit. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc.

zNo naked flame sources, such as lighted candles, should be placed on the apparatus.

zAttention should be drawn to environmental aspects of battery disposal.

zUse the apparatus in moderate climates.

zWe are not responsible for damage or lost data caused by malfunction, misuse, modification of the device or battery replacement.

zDo not attempt to disassemble, repair or modify the product. This will invalidate the warranty.

zIf the device will not be used for an extended period of time, please charge the battery at least once per month to maintain battery life.

zCharge the battery if:

a)The battery level icon displays (An empty battery)

b)The device powers off automatically when restarted.

c)There is no response when pressing keys with keys unlocked and battery full.

zDo not interrupt the connection when the device is being formatted or transferring files. Otherwise, data may be corrupted or lost.

zWhen the device is used as a portable HD, please use only per the instructions. Otherwise, permanent data loss could occur.

zPlease use and install data using the attachments/accessories provided and only according to the manufacturer’s instruction.

zPlease refer to the information on the bottom of the device for electrical and safety information before installing data or operating the device.

zTo reduce the risk of fire or electric shock, do not expose this device to rain or moisture. The device should not be exposed to dripping or splashing. Never place objects filled with liquids, such as vases, on the device.

zThere is danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type.

1

zThe battery (battery or batteries or battery pack) should not be exposed to excessive heat such as sunlight, fire or the like.

zPlease follow responsible procedures for battery disposal.

zIf the power adaptor disconnected from the device, the device will remain operable as long as the battery has sufficient charge.

zThe power adaptor is a CLASS II apparatus with double insulation, and no external ground is provided.

zSafety symbol explanation:

-The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

-To reduce the risk of electric shock, do not remove the cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel.

-The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the device.

- Correct Disposal of this product. This marking indicates that this product should not be disposed of with other household waste in the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of your used device, please use the return and collection systems available in your area or contact the retailer where the product was purchased. They can take this product for safe environmental recycling.

zThis equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

zCE in which countries where the product may be used freely: Germany, UK, Italy, Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg, Austria, Finland, Sweden, Norway and Iceland.

2

Listening Cautions

zThis product respects the current regulations for limiting the output volume of consumer audio devices to a safe level. By listening to your device with headphones or earbuds at high volumes, you run the risk of permanent damage to your ears. Even if you get used to listening at high volumes and it seems normal to you, you still risk the possibility of damaging your hearing. Reduce the volume of your device to a reasonable level to avoid permanent hearing damage. If you hear ringing in your ears, reduce the volume or shut off your device. This device has been tested with the supplied earphones. In order to preserve your hearing, it is advised that you use only the following headphone models: the earphones supplied with your device, or any other headphones that respect the current regulations. Other types of headphones may produce higher volume levels. At full power ,the prolonged listening of the walkman can damage the ear of the use

zDo not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many areas.

zYou should use extreme caution or temporarily discontinue use in potentially hazardous situations created by obstructed hearing.

zEven if your headphones or earphones are the open-air type designed to let you hear outside sounds, don’t turn up the volume so high that you can’t hear what’s around you.

zSound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of sound. What sounds “normal” can actually be loud and harmful to

your hearing. Guard against this by setting the volume of your device at a safe level BEFORE your hearing adapts.

To establish a safe volume level:

a.Start your volume control at a low setting.

b.Slowly increase the sound until you can hear it comfortably and clearly, and without distortion. Once you have established a comfortable sound level, leave it there.

This manual may not reflect your actual device’s operation. All information is subject to change without prior notification. Please follow your actual device’s operational procedures.

3

Table of Content

!"#$%&'()$*"+%,-./'0000000000000000000000000000000000000000000000000000000000000000000000000'1!

2,/%$.,.3'4"+%,-./'0000000000000000000000000000000000000000000000000000000000000000000000000'5!

("*6,.3'4-.%$.%/'00000000000000000000000000000000000000000000000000000000000000000000000000'7!

8$"%+)$/'9'8+.*%,-.":,%&'0000000000000000000000000000000000000000000000000000000000000000000'7!

;"/,*'4-..$*%,-./'0000000000000000000000000000000000000000000000000000000000000000000000000'<!

;"/,*'=>$)"%,-.'0000000000000000000000000000000000000000000000000000000000000000000000000000'?!

@",.%$.".*$'0000000000000000000000000000000000000000000000000000000000000000000000000000000'15!

@"A-)'!>$*,#,*"%,-./'0000000000000000000000000000000000000000000000000000000000000000000000'17!

844'!%"%$B$.%'0000000000000000000000000000000000000000000000000000000000000000000000000000'17!

4

11.Rear camera	Captures pictures or videos.
12.Windows button	Press to open the Windows Start screen.
	Press for quick access to the most recently used app or
	most recently viewed screen.
13.Volume+/- buttons	Press to increase/decrease volume
14.Power button	Press and hold to turn the tablet on or off.
	Press to turn the display on or off.
15. Speaker	Provides audio output.

Note:

1.Both cameras do not support zoom, face tracking.

2.User can connect a keyboard and USB mouse to this tablet if necessary.

Basic Connections

Charging the tablet

Note: If using the tablet for the first time, or after a long period of idle time, charge the battery for more than half an hour before turning it on, to ensure system stability.

The tablet has a built-in rechargeable battery. Charge the device when the battery level is low.

1.Plug the power adapter into the DC-In socket.

2.Connect the power adapter to an electrical outlet and charge the tablet until the battery is fully charged.

Caution:

1.Charge the battery in an ambient temperature of 0 °C to 35 °C.

2.Use only the supplied power adapter to charge your tablet. Using unauthorized

power adapters may severely damage your tablet.

Note:

1.The battery is not fully charged when you unpack your tablet.

2.A fully discharged battery takes about 5 hours to fully charge.

3.When the battery is being charged, the LED indicator lights red, and when the battery has been fully charged, the LED indicator lights orange.

Turning On the Tablet

Note: This Nextbook device has been equipped with Windows 8.1 system at the factory, so user need not perform Windows setup again before using for the first time.

1.Press and hold the Power button for 2 seconds to turn on your tablet. The lock screen appears.

2.Swipe-up your finger from the bottom of the display to switch to the login screen,

6

and then enter password to log in to Windows.

Now the tablet is ready for use when the Windows Start screen is displayed.

Note: If the login screen is not enabled in Windows 8.1, you will be taken directly from the lock screen to the Start screen.

Turning Off the Tablet

You can turn off the tablet in two ways:

Using the Power button:

1.Press and hold the Power button for at least 4 seconds.

2.Swipe-down the shutdown confirmation screen to the bottom edge of the display to turn off the tablet.

Using Charms:

1.Swipe-in from the right edge of the display to access Charms.

2. Touch Settings

Power

Shut down to turn off the tablet.

Turning On/Off screen

Usually, user can press once the power button to turn on/ off the screen display. Optionally, user can also use the Charms:

1.Swipe-in from the right edge of the display to access Charms.

2. Touch Settings

Power

Sleep to turn off the screen.

Inserting a microSD card

1.Pick up a microSD card.

2.Align the microSD card so that the pins are pointed toward the card slot.

3.Push the microSD card into the card slot until it locks into place.

Removing a microSD card

Caution: Removing the microSD card while it is in use may cause data loss or result in application errors. Make sure all save operations to the microSD card are complete

7

before removing the microSD card.

1.Touch the Desktop tile to enter Desktop mode.

2.Touch Safely Remove Hardware in the notification area at the bottom-right corner of the screen.

Note: If you do not see Safely Remove Hardware , touch Show Hidden Icons to display all icons in the notification area.

3.Touch Eject SD Memory Card. A message appears confirming that the microSD card can be safely removed. If a warning message appears stating the microSD card cannot be removed, ensure all data transfers involving the microSD card are complete.

4.Press on the microSD card to release it.

5.Slide the card out after it pops out from the microSD card slot.

Using Headphones

You can connect a headset or headphones to the audio port of your tablet.

Warning: Listening to loud music for an extended period of time can lead to hearing loss.

1.Connect headphones to the audio port (3.5 mm) on the tablet.

2.Insert the earphones in your ears and adjust the volume level to a comfortable level.

Note: When you connect an audio device to the 3.5 mm audio jack, the integrated speakers on your tablet are muted automatically.

Caution: To prevent damage to the headphones when disconnecting it from the tablet, pull the connector instead of the cable.

Connecting the Keyboard

For the sake of using convenience, this device is designed to be equipped with a dedicated keyboard. Follow these steps to connect the keyboard to your tablet:

1.Place the dedicated keyboard on an even and stable plane (e.g. desk);

8

2.Hold your tablet with two hands, align the connector and the two magnetic contacts on the keyboard to the jack and positioning slots at the bottom of the tablet.

3.As soon as the keyboard is connected to the tablet, it is ready for use.

4.You can rotate the tablet to overlap the keyboard as you do with a laptop.

Note:

1.This keyboard is a plug-and-play device; you can connect/disconnect it anytime.

2.There is no notification or indication for the keyboard connection, except for appearance of the mouse icon (arrow) as you put your hand onto the touch area.

3.When the tablet overlaps on the keyboard, the display will be turned off; as soon as it is erect, the display will be turned on again.

4.Since the keyboard is powered by the tablet, it has no built-in battery inside.

Warning:

The maximum angle between the tablet and the keyboard is 120 degrees, so DO NOT rotate the tablet greater than that angle; otherwise, it may cause damage to the tablet and the keyboard.

Instructions for using the cool function keys:

FN+ESC	Backlight	FN+F9	Mute
FN+F2	Play/Pause	FN+F10	Vol-
FN+F3	Stop	FN+F11	Vol+
FN+F4	Previous (Skip-)	FN+F12	Enable/Disable touchpad
FN+F5	Next (Skip+)	FN+NumLk	Lock/unlock numeric keys
FN+F6	Music Player	Menu	Context menu
FN+F7	Mail	FN+Up/Down	Page Up/Down
FN+F8	Home Page	FN+Left/Right	Home/End

To remove the keyboard from tablet, you need to push down the button at the top center of the keyboard with one hand, then lift it up with the other hand gently.

Basic Operation

Wi-Fi Setting

Turning On/Off Wi-Fi:

1.Swipe-in from the right edge of the display to access Charms.

2. Touch Settings

Network icon

.

3. Swipe Wi-Fi icon left or right to turn Wi-Fi on or off.

Connecting to a network:

1.Swipe-in from the right edge of the display to access Charms.

2. Touch Settings

Available

.

3.Select an available network from the list and touch Connect.

9

Gestures

Your tablet has a multi-touch display. You can touch the screen to operate the tablet.

	Finger Gesture	You can do
	Touch	Select items on the screen, including options, entries,
	Tap gently on the display with your	images, and icons.
	fingertip.
		Start apps.
		Touch buttons on the screen.
		Input text using the on-screen keyboard.
	Touch and Hold	Display detailed information about an item.
	Touch and hold your finger on the
		Open the context menu of an item to perform further
	display.
		actions.
	Drag
	1. Touch and hold your finger on
	an item on the screen.
	2. Keeping your finger in contact	Move items such as images and icons on the screen.
	with the display, move your fingertip
	to the desired location.
	3. Take your finger off the display to
	drop the item in the desired
	location.
	Swipe or Slide	Scroll through the Start screen, web pages, lists,
	Move your finger in a vertical or	entries, photos, contacts, and so on.
	horizontal direction on the display.
		Close an app. (Swipe the app to the bottom of the
		display.)
	Zoom in
	Touch the display with two fingers
	and then move the fingers apart.	Enlarge the view of an image or web page.

10
