NEXCOM NISE 300 User Manual

NEXCOM International Co., Ltd.

Industrial Computing Solutions

Fan-less Computer NISE 300

User Manual

NEXCOM International Co., Ltd.

Published December 2014

www.nexcom.com

Content

Contents

Preface

Copyright ............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations ...............................................................viii

Safety Precautions .................................................................................. ix

Technical Support and Assistance ............................................................ x

Conventions Used in this Manual ............................................................ x

Global Service Contact Information ........................................................ xi

Package Contents ................................................................................. xiii

Ordering Information ............................................................................xiv

Chapter 1: Product Introduction

Overview ................................................................................................1

Key Features ...........................................................................................1

Hardware Specifications ..........................................................................2

Knowing Your NISE 300 .......................................................................... 4

Front View ...........................................................................................4

Rear View ............................................................................................ 4

Mechanical Dimensions ...........................................................................6

Chapter 2: Jumpers and Connectors

Before You Begin ....................................................................................7

Precautions ............................................................................................7

Jumper Settings ......................................................................................8

Locations of the Jumpers and Connectors for NISB 300 ........................... 9

Jumpers ................................................................................................ 11

CMOS Pin Header ..............................................................................11

ME Pin Header Clear ..........................................................................11

AT/ATX Mode Select ..........................................................................12

Connector Pin Definitions .....................................................................13

External I/O Interfaces - Front Panel ...................................................13

9V to 30VDC Input ........................................................................13

USB 2.0 ..........................................................................................13

USB 3.0 ..........................................................................................14

HDMI ............................................................................................. 14

DVI-I ..............................................................................................15

CFast .............................................................................................15

LAN1 and LAN2 Ports .....................................................................16

LED Indicators ................................................................................17

Power Switch ................................................................................. 17

Internal Connectors ........................................................................... 18

External SMBus .............................................................................. 18

SIM Card Line-out Pin Header ........................................................18

SIM Card Mic-in Pin Header ...........................................................19

SIM Card Socket ............................................................................19

ii

NISE 300 User Manual

Content

DC-In Power Connector .................................................................20

Reset JST Connector .......................................................................20

LVDS Channel A Connector ............................................................ 21

LVDS Channel B Connector ............................................................ 21

SATA3 Connector 2 ........................................................................22

SATA3 Connector 1 ........................................................................22

SATA3 Power Connector 1 .............................................................23

SATA3 Power Connector 2 .............................................................23

USB 2.0 JST Connector ...................................................................24

COM3-6 Connector .......................................................................24

COM5 Connector ..........................................................................25

COM4 Connector ..........................................................................25

COM3 Connector ..........................................................................26

Battery Connector .......................................................................... 26

GPIO Pin Header ............................................................................27

GPIO LED Pin Header ......................................................................27

Smart Fan1 Connector ..................................................................28

USB Connector .............................................................................28

Mini-PCIe Connector (3.5G/LTE) .....................................................29

Mini-PCIe Connector (mSATA) ........................................................30

Mini-PCIe Connector 1 ................................................................... 31

Mini-PCIe Connector 2 ................................................................... 32

Mini-PCIe Connector 3 ................................................................... 33

Mini-PCIe Connector 4 ................................................................... 34

Board to Board Connector .............................................................35

Chapter 3: System Setup

Removing the Top Cover ....................................................................... 36

Removing the Bottom Cover ................................................................. 37

Installing a SO-DIMM ............................................................................ 38

Installing a mSATA Module ...................................................................40

Installing a Wi-Fi Module ......................................................................42

Installing an Antenna ............................................................................ 44

Installing a SIM Card .............................................................................47

Installing a SATA Hard Drive ..................................................................49

Installing a CFast Card ..........................................................................52

Packing ................................................................................................. 54

Chapter 4: BIOS Setup

About BIOS Setup ................................................................................. 56

When to Configure the BIOS .................................................................56

Default Configuration ........................................................................... 57

Entering Setup ...................................................................................... 57

Legends ................................................................................................ 57

BIOS Setup Utility .................................................................................. 59

Main .................................................................................................59

Advanced ......................................................................................... 59

Chipset ..............................................................................................69

Boot .................................................................................................. 74

Security .............................................................................................76

Save & Exit ........................................................................................76

Appendix A: Power Consumption.........................78

Appendix B: Watchdog Timer Setting...................79

Appendix C: GPI/O Programming Guide...............80

iii

NISE 300 User Manual

Preface

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

NISE 300 is a trademark of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

iv

NISE 300 User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

NEXCOM is a global citizen for building the digital infrastructure. We are committed to providing green

products and services, which are compliant with European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2011/65/EU, to be your trusted green partner and to protect our environment.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2013 will be RoHS compliant. They will use the usual NEXCOM naming convention.

v

NISE 300 User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in accordance with industry standard. NEXCOM warrants that products will be free from defect in material and workmanship for 2 years, beginning on the date of invoice by NEXCOM. HCP series products (Blade Server) which are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪ Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪ Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen messages, and describe the problems on the “NEXCOM RMA Service Form” for the RMA number apply process.

▪ Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, please note clearly which components are included. Otherwise, NEXCOM is not responsible for the devices/parts.

▪ Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage and deterioration during transportation. In case of damages occurred during transportation, the repair is treated as “Out of Warranty.”

▪ Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

System Level

▪ Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistor, capacitor.

▪ Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪ Replace with 3rd party products if needed.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪ Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

vi

NISE 300 User Manual

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory modules. If the instructions for the chassis and power supply are inconsistent with these instructions or the instructions for accessory modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the described procedures only at an ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

vii

NISE 300 User Manual

Preface

CAUTION!

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Danger of explosion if battery is incorrectly replaced.

CAUTION!CAUTION!

Replace with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

viii

NISE 300 User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been approved for use with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work

according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

ix

NISE 300 User Manual

Preface

CAUTION!

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

CAUTION!CAUTION!

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

Safety Warning: This equipment is intended for installation in a Restricted Access Location only.

x

NISE 300 User Manual

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 www.nexcom.com

America

USA NEXCOM USA

2883 Bayview Drive, Fremont CA 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 Email: sales@nexcom.com www.nexcom.com

Asia

Taiwan NEXCOM Intelligent Systems

Taipei Office

13F, No.920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7796 Fax: +886-2-8226-7792 Email: sales@nexcom.com.tw

www.nexcom.com.tw

NEXCOM Intelligent Systems Taichung Office

16F, No.250, Sec. 2, Chongde Rd., Beitun Dist., Taichung City 406, R.O.C. Tel: +886-4-2249-1179 Fax: +886-4-2249-1172 Email: sales@nexcom.com.tw www.nexcom.com.tw

Japan NEXCOM Japan

9F, Tamachi Hara Bldg., 4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 Email: sales@nexcom-jp.com www.nexcom-jp.com

China

NEXCOM China

1F & 2F, Block A, No. 16 Yonyou Software Park, No. 68 Beiqing Road, Haidian District, Beijing, 100094, China Tel: +86-010-5704-2680 Fax: +86-010-5704-2681 Email: sales@nexcom.cn www.nexcom.cn

xi

NISE 300 User Manual

Preface

Chengdu Office

9F, Shuxiangxie, Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061, China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 Email: sales@nexcom.cn www.nexcom.cn

Shanghai Office

Room 603/604, Huiyinmingzun Plaza Bldg., 1, No.609, Yunlin East Rd., Shanghai, 200333, China Tel: +86-21-5278-5868 Fax: +86-21-3251-6358 Email: sales@nexcom.cn www.nexcom.cn

Shenzhen Office

Room1707, North Block, Pines Bldg., No.7 Tairan Rd., Futian Area, Shenzhen, 518040, China Tel: +86-755-8332-7203 Fax: +86-755-8332-7213 Email: sales@nexcom.cn www.nexcom.cn

Wuhan Office

1-C1804/1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 Email: sales@nexcom.cn www.nexcom.cn

Europe

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 Email: sales.uk@nexcom.eu www.nexcom.eu

Italy NEXCOM ITALIA S.r.l

Via Gaudenzio Ferrari 29, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9625570 Email: nexcomitalia@nexcom.eu www.nexcomitalia.it

xii

NISE 300 User Manual

Preface

Package Contents

Before continuing, verify that the NISE 300 package that you received is complete. Your package should have all the items listed in the following table.

Item Part Number Name Description Qty

1 4NCPF00204X00 Terminal Blocks 2P Phoenix Contact:1777989 5.08mm Female DIP Green 1 2 4NCPM00203X00 Terminal Blocks 2P Phoenix Contact:1803578 3.81mm Male DIP Green 1 3 50311F0100X00 (H)Round Head Screw w/Spring+Flat Washer Long FEI:P3x6L P3x6 iso/SW6x0.5 NI 1 4 50311F0295X00 Flat Head Screw Long FEI:F2x4 NYLOK NIGP F2x4 NIGP NYLOK 2 5 50311F0326X00 Flat Head Screw Long FEI:F3x5 NYLOK NI+Heat Treatment F3x5 NYLOK NI+Heat Treatment 8 6 50311F0330X00 Round Head Screw Long FEI:P2x3 ISO+Nylon P2x3 NI NYLOK 12 7 5040450007X00 (H)NISE 300 IO Bracket VER.A for Antenna CHYUAN-JYH 57.6(L)x2.5(W)x25.35(H)(mm) Aluminum Alloy 1 8 5060900226X00 Mini PCIe Bracket CHYUAN-JYH 29x30x2.1mm SPCC t=1.0mm NI 1

9 6012200052X00 PE Zipper Bag #8 170x240mm, w/China RoHS Symbol 1 10 6012200053X00 PE Zipper Bag #3 100x70mm, w/China RoHS Symbol 1 11 60177B0272X00 (N)NISE 300 Quick Reference Guide VER:B SIZE:A4 KRAMER 1 12 602DCD0786X00 (N)NISE 300 DVD Driver VER:1.0 JCL 1 13 7800000078X00 DVI-I TO VGA Adapter For NISE 104 ST:ADDH27B DVI-I (24+5)Pin Male to VGA 15Pin Female 1

xiii

NISE 300 User Manual

Preface

Ordering Information

The following information below provides ordering information for NISE 300.

• Barebone

NISE 300 System (P/N: 10J00030000X0)

• 19V, 120W AC to DC power adapter w/o power core (P/N: 7400120013X00)

xiv

NISE 300 User Manual

Chapter 1: Product Introduction

Overview

Key Features

▪ Onboard BGA type 4th Generation Intel® Core™ i7/i5/i3 Processor

®

▪ Mobile Intel

▪ 2x USB 3.0; 2x USB 2.0

▪ 6x Mini-PCIe, 2x RS232/422/485 with Auto Flow

▪ Support 1x mSATA, 1x CFast and 2x 2.5” SATA

▪ User-friendly I/O design; all I/O interfaces at front

▪ Support wireless communication; optional for Wi-Fi or 3G modules

▪ Support +9V and +30VDC input; support ATX power mode

▪ Easy replacement for RTC battery

▪ Dual Intel

QM87 PCH

®

GbE LAN Ports, support WoL, Teaming & PXE

1

NISE 300 User Manual

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪ Onboard BGA type 4th generation Intel® Core™ i7/i5/i3 processors

– Core™ i7-4712HQ, Quad Core™, 3.3GHz – Core™ i5-4402E, Dual Core™, 1.6GHz (Onboard Default) – Core™ i3-4112E, Dual Core™, 1.8GHz – Celeron 2002E, Dual Core™, 1.5GHz

▪ Mobile Intel

Main Memory

▪ 2x DDR3/DDR3L SO-DIMM sockets, support up to 8GB DDR3/DDR3L

1333/1600 RAM, un-buffered and non-ECC

®

QM87 PCH

▪ 2x Intel

®

82574L GbE LAN Ports, support PXE/Teaming/WoL ▪ 1x External CFast socket ▪ 1x SIM Card holder ▪ 1x External RTC Li-ion Battery holder ▪ 1x Line out and 1x Mic-in

Internal I/O Interface

▪ 4x GPI and 4 GPO (5V, TTL Type) ▪ 4x COM Ports Box Header (RS232 only) ▪ 1x USB 2.0 Internal Connector, for USB dongle ▪ 2x USB 2.0 Internal Box Header

Display Option

▪ Three independent displays

- VGA+DVI-D (through DVI-I Y Cable) + HDMI

▪ Dual independent displays

- DVI-D + VGA

- HDMI + VGA

Front I/O Interface

▪ ATX power on/off switch ▪ 1x Remote Power ON/OFF Switch ▪ 1x Power Status/1x HDD Access LEDs ▪ 2x USB3.0 ports (Blue Color, 900mA per each) ▪ 2x USB2.0 Ports (500mA per each) ▪ 1x DVI-I, 1x HDMI ▪ 2x DB9 for COM1 & COM2

- support RS232/422/485 with Auto Flow Control

- support 5V/12V/Ring function by jumper setting

Storage Device

▪ 1x CFast (SATA 3.0) ▪ 1x mSATA (SATA 3.0) ▪ 2x 2.5” HDD (SATA 3.0)

Expansion Slot

▪ 1x Mini-PCIe socket for GSM/Wi-Fi

1x Mini-PCIe socket for mSATA 4x Mini-PCIe socket for expansion modules

Power Requirement

▪ ATX Power Mode ▪ Typical +9V ~ +30VDC Input ▪ Power adapter: Optional AC to DC power adapter (+19VDC, 120W)

2

NISE 300 User Manual

Chapter 1: Product Introduction

Dimensions

▪ 310mm (W) x 212mm (D) x 80mm (H) without Wall-Mount bracket

Environment

▪ Operating Temperature: Ambient with air flow: -5°C to 55°C (According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)

▪ Storage Temperature: -40°C to 85°C

▪ Operating humidity: 10% ~ 90% relative humidity, non-condensing Limits to be at 90% RH at max 40°C

▪ Shock Protection: HDD: 20G, half sine, 11ms, IEC60068-27 CFast: 50G, half sine, 11ms, IEC60068-27

▪ Vibration Protection w/HDD Condition: Random: 0.5Grms @ 5~500 Hz, IEC60068-2-64 Sinusoidal: 0.5Grms @ 5~500 Hz, IEC60068-2-6

Certifications

▪ CE/FCC Class A

OS Support List

▪ Windows 7 32-bit and 64-bit

▪ Windows 8.1 32-bit and 64-bit

Optional Fieldbus Kit

88J50090E00X0

88J50090E01X0

88J50090E02X0

88J50090E03X0

88J50090E04X0

88J50090E13X0

88J50090E15X0

FBI 90E-PNM KIT (w/25cm Cable) FBI 90E-EP KIT (w/25cm Cable) FBI 90E-ECM KIT (w/25cm Cable) FBI 90E-PBM KIT (w/25cm Cable) FBI 90E-DNM KIT (w/25cm Cable) FBI 90E-COM KIT (w/25cm Cable) FBI 90E-S3M KIT (w/25cm Cable)

Optional Module Kit

88J00030004X0

88J00030009X0

88J00030002X0

88JK0ECOM03X0

88JK0ECOM07X0

NISE300 3.5G Module Kit SIERRA: MC8090(SMS) NISE300 3.5G Module Kit SIERRA: MC8092(SMS) NISE300 WiFi Module Kit INTEL: 7260.HMWWB.R NISE300 WiFi Module Kit INTEL: 7260.HMWBNWB.R

NISKECOM3 UNIVERSAL KIT (w/25 cm DB26 cable)

NISKECOM4 UNIVERSAL KIT (w/25 cm DB26 cable)

PROFINET Master Module Kit

EtherNet/IP Master Module Kit

EtherCAT Master Module Kit

PROFIBUS Master Module Kit

DeviceNet Master Module Kit

CANopen Master Module Kit

SERCOSIII Master Module Kit

US

EU

Dual Band Wireless-AC 7260, 2x2 AC+BT, HMC WLAN+ BLUETOOTH COMBO MODULE Mini-PCIe to 4x COM Module w/isolation RS232/422/485 Auto Flow Control w/Universal Bracket Mini-PCIe to 4 PORT RS232 MODULE w/ Universal Bracket

3

NISE 300 User Manual

Chapter 1: Product Introduction

Knowing Your NISE 300

Front View

Remote On/Off Switch

9-30V DC Input Fieldbus

USB 2.0 USB 3.0

Remote On/Off Switch

Used to connect a remote to power on/off the system.

USB 3.0/2.0 Ports

Two USB 3.0 and two USB 2.0 ports to connect the system with USB 3.0/2.0 devices.

COM1 and COM2

Support RS232/422/485 with auto flow control.

COM1 COM2

Audio Connectors

DVI-IHDMI CFast

SIM

LAN

LEDs

Power Switch

Rear View

Antenna Cover

Audio Connectors

A line-out and mic-in port to connect speakers or microphones.

LAN

2 Intel GbE LAN to connect the system to a local area network.

LEDs

Indicates the power status and hard drive activity of the system.

4

NISE 300 User Manual

Chapter 1: Product Introduction

9-30V DC Input

Used to plug a DC power cord.

HDMI

Used to connect a high-definition display.

DVI-I

Used to connect a digital LCD panel.

SIM

Used to install a SIM card.

CFast

Used to install a CFast card.

Fieldbus

4 expansion slots for add-on fieldbus modules.

Power Switch

Press to power-on or power-off the system.

Antenna Cover

Used to connect an external antenna for Wi-Fi module.

5

NISE 300 User Manual

Chapter 1: Product Introduction

Mechanical Dimensions

333

212

310

80

86.30

6

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

This chapter describes how to set the jumpers and connectors on the NISE 300 motherboard.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: – A Philips screwdriver – A flat-tipped screwdriver – A set of jewelers screwdrivers – A grounding strap – An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching a metal object. Static electricity can damage many of the electronic components. Humid environments tend to have less static electricity than

dry environments. A grounding strap is warranted whenever danger of static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal body of any other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation.

▪ Use correct screws and do not over tighten screws.

7

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

3

2

1

3

2

8

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors for NISB 300

The figures below are the top and bottom views of the NISB 300 main board used in NISE 300. It shows the locations of the jumpers and connectors.

Top View

14

2

1

2

CN1

3

1

2

4

CN2

2

1

CN2

DC-IN Power

FAN1

DIMM1

DIMM2

545349474543413937353321292725232119171513

R57

USB1

51

8

72

74 204

71

73 C85

72

74

711

73

U8

BF BE BC BA AW AU AR AN AL AJ AG AE AC AA W U R N L J G E C A

97531

11

CN3

USB2

14

18

9

5

41

1

4

CN3

USB2

USB1

USB 3.0USB 2.0

HDMI

CN9: miniPCIe#5

41

20 2

CN5

19 1

20 2

CN6

203

204

203

19 1

J5

16

CN11

JP4

34

12

Add-On Card Support Cable Length

mS ATA N/A

Fieldbus I/O 15cm

CN10: miniPCIe#6

Add-On Card Support Cable Length

AM

BE

A

K

Y

1

U18

10

22

34

45

CN9 CN10

52

252

MSATA

miniPCIe#5

MH4MH3

3.5G/L TE

miniPCIe#6

15 117513811517

18 16 2

JP6

JP5

1

JP3

910

12

34

12

33

JP7

1

33

JP8

11

JP2

40

39

J1

12

CN7

1

2

CN4

1

9

17

8

16

24

DVI-I

CN8

P17

B9B1A9A1

B10B2A10A2

LED1

CFAST

LAN

J4

JP9

SW1

LED1

C1 C2

A1 A2

LED1

Power Switch

LED

1

3

1

SW1

GSM Module N/A Wi-Fi Module 30cm

9

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

1

4

7

CN15

CN16 CN20 CN19

CN13

25117

16

J6J9

1

10

1

10

J7J8

miniPCIe#1 miniPCIe#2

16 25117

CN14

miniPCIe#3 miniPCIe#4

1852

MH5MH6 MH5MH6

1852

MH5MH6 MH5MH6

4

CN17

16 25117

CN18

Bottom View

711 1

1852

IDE1

CN13: miniPCIe#1

Add-On Card Support Cable Length

Fieldbus I/O 15cm

CN17: miniPCIe#2

Add-On Card Support Cable Length

Fieldbus I/O 15cm

NISK300LAN-IO 25cm

CN14: miniPCIe#3

Add-On Card Support Cable Length

Fieldbus I/O 25cm

NISK300LAN-IO 25cm

CN18: miniPCIe#4

Add-On Card Support Cable Length

Fieldbus I/O 15cm

NISK300LAN-IO 25cm

SIM Card

10

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Jumpers

CMOS Pin Header

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP2

1 3

Pin Definition

1 RTC_RST#_PU 2 RTC_RST# 3 CLR_CMOS

1-2 On: default

ME Pin Header Clear

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP7

1 3

Pin Definition

1 SRTC_RST#_PU 2 SRTC_RST# 3 CLR_ME

1-2 On: default

11

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

AT/ATX Mode Select

Connector type: 1x3 3-pin header, 2.54mm Connector location: JP9

1 3

Pin Definition

1 NC 2 PWRON# 3 AT_MODE

1-2 On: default

12

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces - Front Panel

9V to 30VDC Input

Connector type: 1x2 2-pin terminal block Connector location: CN2

2 1

Pin Definition

1 VIN_GND 2 VIN

USB 2.0

Connector type: Dual USB 2.0 ports Connector location: USB1

1

5

Pin Definition Pin Definition

1 5VSB 2 USB_6N 3 USB_6P 4 GND 5 5VSB 6 USB_7N

7 USB_7P 8 GND MH1 F_GND MH2 F_GND MH3 F_GND MH4 F_GND

4

8

13

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

USB 3.0

Connector type: Dual USB 3.0 ports Connector location: USB2

9

1

10 13

Pin Definition Pin Definition

1 5VSB 2 USB_0N 3 USB_0P 4 GND 5 USB3_RX0_N 6 USB3_RX0_P 7 GND 8 USB3_TX0_N

9 USB3_TX0_P 10 5VSB 11 USB_1N 12 USB_1P 13 GND 14 USB3_RX1_N 15 USB3_RX1_P 16 GND 17 USB3_TX1_N 18 USB3_TX1_P

MH1 F_GND MH2 F_GND MH3 F_GND MH4 F_GND

5

4

1418

HDMI

Connector type: HDMI port Connector location: CN3

18

2

Pin Definition Pin Definition

1 HDMI_DATA2_P_R 2 GND 3 HDMI_DATA2_N_R 4 HDMI_DATA1_P_R 5 GND 6 HDMI_DATA1_N_R 7 HDMI_DATA0_P_R 8 GND

9 HDMI_DATA0_N_R 10 HDMI_CLK_P_R 11 GND 12 HDMI_CLK_N_R 13 NC 14 NC 15 HDMI2_CTRL_CLK 16 HDMI2_CTRL_DATA 17 NC 18 HDMI2_VCC5 19 HDMI2_HPD_R MH1 F_GND

MH2 F_GND MH3 F_GND MH4 F_GND

19

1

14

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

DVI-I

Connector type: 24-pin D-Sub, 2.0mm-M-180 Connector location: CN4

1 8

17 24

Pin Definition Pin Definition

1 CHC_TX2_N 2 CHC_TX2_P 3 GND 4 NC 5 NC 6 DVI_I_DDC_C 7 DVI_I_DDC_D 8 VSYNC_VGA

9 CHC_TX1_N 10 CHC_TX1_P 11 GND 12 NC 13 NC 14 DVI_I_5V 15 GND 16 DVI_I_5V 17 CHC_TX0_N 18 CHC_TX0_P 19 GND 20 DDCCLK_VGA 21 DDCDATA_VGA 22 GND 23 CHC_CLK_P 24 CHC_CLK_N

MH1 F_GND MH2 F_GND

C1 RED_VGA C2 GREEN_VGA C3 BLUE_VGA C4 HSYNC_VGA

C5B CRT_GND C5A VGADET

CFast

Connector type: CFast Socket Connector location: CN8

S1 S7 PC1 PC17

Pin Definition Pin Definition

S1 GND PC6 NC S2 SATA_TXP0 PC7 GND S3 SATA_TXN0 PC8 CFAST_LED1_C S4 GND PC9 CFAST_LED2_C S5 SATA_RXN0 PC10 NC S6 SATA_RXP0 PC11 NC

S7 GND PC12 NC PC1 CFAST_CDI PC13 VCC3 PC2 GND PC14 VCC3 PC3 NC PC15 GND PC4 NC PC16 GND PC5 NC PC17 CFAST_CDO

15

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

LAN1 and LAN2 Ports

Connector type: Dual RJ45 port with LEDs Connector location: LAN1A (LAN1) and LAN1B (LAN2)

LAN1

A1 A8

ACT LINK

B1 B8

LAN2

ACT LINK

LAN1

Pin Definition Pin Definition

A1 MDI0P_LAN1 A2 MDI0N_LAN1 A3 MDI1P_LAN1 A4 MDI1N_LAN1 A5 MDI2P_LAN1 A6 MDI2N_LAN1 A7 MDI3P_LAN1 A8 MDI3N_LAN1

A9 VCC_LAN1 A10 GND A11 3VSB A12 LED_ACT#_LAN1 A13 LINK100#_LAN1 A14 LINK1G#_LAN1

MH1 F_GND

LAN2

Pin Definition Pin Definition

B1 MDI0P_LAN2 B2 MDI0N_LAN2 B3 MDI1P_LAN2 B4 MDI1N_LAN2 B5 MDI2P_LAN2 B6 MDI2N_LAN2 B7 MDI3P_LAN2 B8 MDI3N_LAN2

B9 VCC_LAN2 B10 GND B11 3VSA B12 LED_ACT#_LAN2 B13 LINK100#_LAN2 B14 LINK1G#_LAN2

MH2 F_GND

16

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

LED Indicators

Connector location: LED1

Power

HDD

LED Status

Power

CFast/HDD Blinking: Active

Pin Definition

A1 LED_HDDP A2 LED_PWRP C1 HD_LEDN C2 LED_PWRN

Light On: Power On Light Off: Power Off

Power Switch

Connector location: SW1

Pin Definition Pin Definition

1 GND 2 PBT_PU 3 PBT_PU 4 GND

A1 PWR_SW_P C1 PWR_SW_N

MH1 GND MH2 GND

17

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

43

21

Internal Connectors

External SMBus

Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP4

Pin Definition

1 GND 2 VCC3 3 SMB_DATA 4 SMB_CLK

SIM Card Line-out Pin Header

Connector type: 1x3 3-pin header, 2.0mm pitch Connector location: JP8

1 3

Pin Definition

1 LOUT_RL 2 LOUT_RR 3 ANGND

18

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

SIM Card Mic-in Pin Header

Connector type: 1x3 3-pin header, 2.0mm pitch Connector location: JP3

1 3

Pin Definition

1 MIC_RL 2 MIC_RR 3 ANGND

SIM Card Socket

Connector location: IDE1

C5 C6 C7

SW2 SW1

Pin Definition Pin Definition

C1 UIM_PWR C2 UIM_RESET C3 UIM_CLK C5 GND C6 UIM_VPP C7 UIM_DATA

SW1 NC SW2 NC

C1 C2 C3

19

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

12

34

DC-In Power Connector

Connector type: 2x2 4-pin header Connector location: CN1

Pin Definition

1 GND 2 GND 3 VIN 4 VIN

Reset JST Connector

Connector type: 1x2 2-pin header, 2.5mm pitch Connector location: J4

12

Pin Definition

1 PM_RESET#_J 2 GND

20

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

11 22

LVDS Channel A Connector

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN5

9 0

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA 3 PANEL1_VDD 4 LVDSA_DATA0 5 LVDSA_DATA3 6 LVDSA_DATA#0 7 LVDSA_DATA#3 8 PANEL1_VDD

9 GND 10 LVDSA_DATA1 11 LVDSA_CLK 12 LVDSA_DATA#1 13 LVDSA_CLK# 14 GND 15 GND 16 PANEL1_BACKLIGHT 17 LVDSA_DATA2 18 PANEL1_BACKLIGHT 19 LVDSA_DATA#2 20 GND

MH1 GND MH2 GND

LVDS Channel B Connector

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN6

9 0

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA 3 PANEL1_VDD 4 LVDSB_DATA0 5 LVDSB_DATA3 6 LVDSB_DATA#0 7 LVDSB_DATA#3 8 PANEL1_VDD

9 GND 10 LVDSB_DATA1 11 LVDSB_CLK 12 LVDSB_DATA#1 13 LVDSB_CLK# 14 GND 15 GND 16 PANEL1_BACKLIGHT 17 LVDSB_DATA2 18 PANEL1_BACKLIGHT 19 LVDSB_DATA#2 20 GND

MH1 GND MH2 GND

21

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

SATA3 Connector 2

Connector type: 1x7 7-pin header, 1.27mm pitch Connector location: CN16

71 71

Pin Definition Pin Definition

1 GND 2 SATA_TXP5 3 SATA_TXN5 4 GND 5 SATA_RXN5 6 SATA_RXP5 7 GND

SATA3 Connector 1

Connector type: 1x7 7-pin header, 1.27mm pitch Connector location: CN19

Pin Definition Pin Definition

1 GND 2 SATA_TXP1

3 SATA_TXN1 4 GND

5 SATA_RXN1 6 SATA_RXP1

7 GND

22

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

14

SATA3 Power Connector 1

Connector type: 1x4 4-pin header, 2.54mm pitch Connector location: CN15

Pin Definition

1 +12V 2 GND 3 GND 4 VCC5

SATA3 Power Connector 2

Connector type: 1x4 4-pin header, 2.54mm pitch Connector location: CN20

Pin Definition

1 +12V

2 GND

3 GND

4 VCC5

23

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

61

10 1

USB 2.0 JST Connector

Connector type: 1x6 JST, 6-pin header, 2.0mm pitch Connector location: J5

Pin Definition Pin Definition

1 5VSB 2 USB_10N 3 USB_10P 4 USB_11N 5 USB_11P 6 GND

COM3-6 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J6

Pin Definition Pin Definition

1 SP6_DCD_CN10_22 2 SP6_RXD_CN10_32

3 SP6_TXD_CN10_24 4 SP6_DTR_CN10_34

5 GND 6 SP6_DSR_CN10_36

7 SP6_RTS_CN10_26 8 SP6_CTS_CN10_38

9 SP6_RI_CN10_28 10 VCC5

MH1 GND MH2 GND

24

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

10 1

COM5 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J9

Pin Definition Pin Definition

1 SP5_DCD_CN10_2 2 SP5_RXD_CN10_12 3 SP5_TXD_CN10_4 4 SP5_DTR_CN10_14 5 GND 6 SP5_DSR_CN10_16 7 SP5_RTS_CN10_6 8 SP5_CTS_CN10_18 9 SP5_RI_CN10_8 10 VCC5

MH1 GND MH2 GND

COM4 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J8

Pin Definition Pin Definition

1 SP4_DCD_CN10_21 2 SP4_RXD_CN10_31

3 SP4_TXD_CN10_23 4 SP4_DTR_CN10_33

5 GND 6 SP4_DSR_CN10_35

7 SP4_RTS_CN10_25 8 SP4_CTS_CN10_37

9 SP4_RI_CN10_19 10 VCC5

MH1 GND MH2 GND

25

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

10 1

COM3 Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J7

Pin Definition Pin Definition

1 SP3_DCD_CN10_1 2 SP3_RXD_CN10_11 3 SP3_TXD_CN10_3 4 SP3_DTR_CN10_13 5 GND 6 SP3_DSR_CN10_15 7 SP3_RTS_CN10_5 8 SP3_CTS_CN10_17 9 SP3_RI_CN10_7 10 VCC5

MH1 GND MH2 GND

Battery Connector

Connector type: 1x2 2-pin header, 1.25mm pitch Connector location: J1

12

Pin Definition

1 GND

2 BAT

26

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

19

21

43

21

GPIO Pin Header

Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: JP5

0

Pin Definition Pin Definition

1 VCC5 2 GND 3 GPO24 4 GPI20 5 GPO25 6 GPI21 7 GPO26 8 GPI22 9 GPO27 10 GPO27

GPIO LED Pin Header

Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP6

Pin Definition

1 GPO_LED0

2 GND

3 GPO_LED1

4 GND

27

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

14

Smart Fan1 Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: FAN1

Pin Definition

1 GND 2 +12V 3 FAN_TAC1 4 FAN_CTL1

USB Connector

Connector type: USB Port Connector location: CN11

1 4

Pin Definition

1 5VSB

2 USB_12N

3 USB_12P

4 GND

28

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Connector (3.5G/LTE)

Connector location: CN10

12

51 52

Pin Definition Pin Definition

1 MIC_R 2 3VSB 3 MIC_L 4 GND 5 LOUT_R 6 1V5 7 LOUT_L 8 UIM_PWR

9 GND 10 UIM_DATA 11 CN6_REFCLK- 12 UIM_CLK 13 CN6_REFCLK+ 14 UIM_RESET 15 GND 16 UIM_VCCP 17 NC 18 GND 19 NC 20 3VSB 21 GND 22 CN6_RESET 23 PEG_RXN0_MINI 24 3VSB 25 PEG_RXP0_MINI 26 GND

29

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMBCLK_MAIN 31 CN6_PCIETXN 32 SMBDATA_MAIN 33 CN6_PCIETXP 34 GND 35 GND 36 USB_4N 37 GND 38 USB_4P 39 3VSB 40 GND 41 3VSB 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 1V5 49 NC 50 GND 51 NC 52 3VSB

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Connector (mSATA)

Connector location: CN9

12

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB_MINI6

3 NC 4 GND

5 NC 6 1V5

7 PCIE_CLKREQ#7 8 NC

9 GND 10 NC 11 CLK_PCIE_MINI4_N 12 NC 13 CLK_PCIE_MINI4_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 3VSB 21 GND 22 BUF_PLT_RST# 23 PCIE_mSATA_RXP 24 3VSB_MINI6 25 PCIE_mSATA_RXN 26 GND

30

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMBCLK_MAIN 31 PCIE_TXN3_MINI_PCIE 32 SMBDATA_MAIN 33 PCIE_TXP3_MINI_PCIE 34 GND 35 GND 36 USB_5N 37 GND 38 USB_5P 39 3VSB_MINI6 40 GND 41 3VSB_MINI6 42 NC 43 PCIE_mSATA_RXN 44 NC 45 NC 46 NC 47 NC 48 1V5 49 NC 50 GND 51 PCIE_mSATA_SEL_51 52 3VSB_MINI6

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Connector 1

Connector location: CN13

12

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB_MINI2

3 NC 4 GND

5 NC 6 1V5

7 PCIE_CLKREQ#2 8 NC

9 GND 10 NC 11 CLK_PCIE_MINI2_N 12 NC 13 CLK_PCIE_MINI2_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 3VSB 21 GND 22 BUF_PLT_RST# 23 PCIE_RXN3_MINI_PCIE 24 3VSB 25 PCIE_RXP3_MINI_PCIE 26 GND

31

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMBCLK_MAIN 31 PCIE_TXN3_MINI_PCIE 32 SMBDATA_MAIN 33 PCIE_TXP3_MINI_PCIE 34 GND 35 GND 36 USB_9N 37 GND 38 USB_9P 39 3VSB_MINI2 40 GND 41 3VSB_MINI2 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 1V5 49 NC 50 GND 51 NC 52 3VSB_MINI2

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Connector 2

Connector location: CN17

12

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB_MINI4

3 NC 4 GND

5 NC 6 1V5

7 PCIE_CLKREQ#4 8 NC

9 GND 10 NC 11 CLK_PCIE_MINI4_N 12 NC 13 CLK_PCIE_MINI4_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 3VSB 21 GND 22 BUF_PLT_RST# 23 PCIE_RXN8_MINI_PCIE 24 3VSB 25 PCIE_RXP8_MINI_PCIE 26 GND

32

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMBCLK_MAIN 31 PCIE_TXN8_MINI_PCIE 32 SMBDATA_MAIN 33 PCIE_TXP8_MINI_PCIE 34 GND 35 GND 36 USB_3N 37 GND 38 USB_3P 39 3VSB_MINI4 40 GND 41 3VSB_MINI4 42 NC 43 GND 44 NC 45 PCIE_TXN4_MINI_PCIE 46 NC 47 PCIE_TXP4_MINI_PCIE 48 1V5 49 PCIE_RXN4_MINI_PCIE 50 GND 51 PCIE_RXP4_MINI_PCIE 52 3VSB_MINI4

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Connector 3

Connector location: CN14

12

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB_MINI1

3 NC 4 GND

5 NC 6 1V5

7 PCIE_CLKREQ#1 8 NC

9 GND 10 NC 11 CLK_PCIE_MINI1_N 12 NC 13 CLK_PCIE_MINI1_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 3VSB 21 GND 22 BUF_PLT_RST# 23 PCIE_RXN1_MINI_PCIE 24 3VSB 25 PCIE_RXP1_MINI_PCIE 26 GND

33

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMBCLK_MAIN 31 PCIE_TXN1_MINI_PCIE 32 SMBDATA_MAIN 33 PCIE_TXP1_MINI_PCIE 34 GND 35 GND 36 USB_8N 37 GND 38 USB_8P 39 3VSB_MINI1 40 GND 41 3VSB_MINI1 42 NC 43 GND 44 NC 45 PCIE_TXN2_MINI_PCIE 46 NC 47 PCIE_TXP2_MINI_PCIE 48 1V5 49 PCIE_RXN2_MINI_PCIE 50 GND 51 PCIE_RXP2_MINI_PCIE 52 3VSB_MINI1

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Connector 4

Connector location: CN18

12

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB_MINI3

3 NC 4 GND

5 NC 6 1V5

7 PCIE_CLKREQ#3 8 NC

9 GND 10 NC 11 CLK_PCIE_MINI3_N 12 NC 13 CLK_PCIE_MINI3_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 3VSB 21 GND 22 BUF_PLT_RST# 23 PCIE_RXN6_MINI_PCIE 24 3VSB 25 PCIE_RXP6_MINI_PCIE 26 GND

34

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMBCLK_MAIN 31 PCIE_TXN6_MINI_PCIE 32 SMBDATA_MAIN 33 PCIE_TXP6_MINI_PCIE 34 GND 35 GND 36 USB_2N 37 GND 38 USB_2P 39 3VSB_MINI3 40 GND 41 3VSB_MINI3 42 NC 43 GND 44 NC 45 PCIE_TXN5_MINI_PCIE 46 NC 47 PCIE_TXP5_MINI_PCIE 48 1V5 49 PCIE_RXN5_MINI_PCIE 50 GND 51 PCIE_RXP5_MINI_PCIE 52 3VSB_MINI3

NISE 300 User Manual

Chapter 2: Jumpers and Connectors

1

24

39

Board to Board Connector

Connector type: 2x20 40-pin header, 2.0mm pitch Connector location: CN7

0

Pin Definition Pin Definition

1 COM2_DCD# 2 COM1_DCD#

3 COM2_RXD 4 COM1_RXD

5 COM2_TXD 6 COM1_TXD

7 COM2_DTR# 8 COM1_DTR#

9 GND 10 GND 11 COM2_DSR# 12 COM1_DSR# 13 COM1_DSR# 14 COM1_RTS# 15 COM2_CTS# 16 COM1_CTS# 17 COM2_RI# 18 COM1_RI# 19 GND 20 GND 21 HDA_SPKR 22 COM2_232_EN# 23 HDA_SDOUT 24 COM2_422_EN# 25 HDA_BIT_CLK 26 COM2_485_EN# 27 HDA_SDIN0 28 COM1_232_EN# 29 HDA_SYNC 30 COM1_422_EN# 31 HDA_RST# 32 COM1_485_EN# 33 VCC5_POK 34 BAT 35 PBT_PU 36 ICH_SP_RI 37 GND 38 5VSB 39 +12V 40 5VSB

35

NISE 300 User Manual

Chapter 3: System Setup

CAUTION!

Chapter 3: System Setup

Removing the Top Cover

Prior to removing the chassis cover, make sure the unit’s power

CAUTION!CAUTION!

1. Locate the 2 screws on the back of the top cover and remove them. 2. Lift up the cover and remove it from the chassis.

is off and disconnected from the power sources to prevent electric shock or system damage.

36

NISE 300 User Manual

Chapter 3: System Setup

Removing the Bottom Cover

1. Locate the 8 screws on the bottom cover and remove them. 2. Remove the bottom cover.

37

NISE 300 User Manual

Chapter 3: System Setup

Installing a SO-DIMM

Remove the top cover first.

1. Locate the SO-DIMM socket. 2. Release the lock on the SO-DIMM socket.

SO-DIMM sockets

Lock

38

NISE 300 User Manual

Chapter 3: System Setup

3. Insert the modules into the sockets at an 90 degree angle. Apply firm even pressure to each end of the module until it slips into the socket.

39

NISE 300 User Manual

Chapter 3: System Setup

Installing a mSATA Module

1. Locate the Mini-PCIe slot (CN9) on the board. 2. Insert the mSATA module into the Mini-PCIe slot at 45 degree angle

until the gold-plated connector on the edge of the module completely disappears into the slot.

Mini PCI Express slot

(CN9)

40

NISE 300 User Manual

Chapter 3: System Setup

3. Push the mSATA module down and secure it with screws.

Screw

41

NISE 300 User Manual

Chapter 3: System Setup

Installing a Wi-Fi Module

1. Locate the Mini-PCIe slot (CN10) and insert the Wi-Fi module into the Mini-PCIe slot at 45 degree angle until the gold-plated connector on the edge of the module completely disappears into the slot.

Mini PCI Express slot

(CN10)

Wi-Fi module

2. Push the Wi-Fi module down and secure it with screws.

Mounting screw

42

NISE 300 User Manual

Chapter 3: System Setup

3. Connect the antenna to the RF connector on the Wi-Fi module. 4. Ensure the antenna cable is secured tightly to the I/O bracket.

RF connector

43

NISE 300 User Manual

Chapter 3: System Setup

Installing an Antenna

1. Remove the original I/O cover at the back. 2. Insert the antenna jack into the I/O cover hole.

Antenna jack

44

NISE 300 User Manual

Chapter 3: System Setup

3. Insert Ring 1 onto the antenna jack. 4. Insert Ring 2 onto the antenna jack.

Ring 1 Ring 2

45

NISE 300 User Manual

Chapter 3: System Setup

5. Secure the external antenna onto antenna jack.

Antenna

46

NISE 300 User Manual

Chapter 3: System Setup

Installing a SIM Card

1. Locate the SIM card socket on the front panel. 2. Push the yellow button to release the SIM card holder.

SIM card socket

47

Push button

NISE 300 User Manual

Chapter 3: System Setup

3. Place the SIM card into the SIM card holder and secure it to the original position.

48

NISE 300 User Manual

Chapter 3: System Setup

Installing a SATA Hard Drive

1. Locate the internal HDD bracket. 2. Unmount the screws to remove the HDD bracket.

HDD bracket Mounting screw

49

NISE 300 User Manual

Chapter 3: System Setup

3. Place the 2.5” HDD onto the HDD bracket and secure it with screws. 4. Secure the SATA connector to the HDD bracket.

Mounting screw

50

NISE 300 User Manual

Chapter 3: System Setup

5. Secure the HDD bracket back to its original position.

Mounting screw

51

NISE 300 User Manual

Chapter 3: System Setup

Installing a CFast Card

1. Locate the CFast socket on the front panel. 2. Remove the cover of the CFast socket and insert the CFast card.

CFast socket

52

NISE 300 User Manual

Chapter 3: System Setup

3. Secure the CFast cover to the original position.

53

NISE 300 User Manual

Chapter 3: System Setup

Packing

NISE 300 plastic bag and EPE reference.

Front View of Packing Rear View of Packing

54

NISE 300 User Manual

Chapter 3: System Setup

Top View of Packing Bottom View of Packing

55

NISE 300 User Manual

Chapter 4: BIOS Setup

This chapter describes how to use the BIOS setup program for the NISE 300. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals

▪ Video display type and display options

▪ Password protection from unauthorized use

▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

▪ This program should be executed under the following conditions:

▪ When changing the system configuration

▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock

▪ When redefining the communication ports to prevent any conflicts

▪ When making changes to the Power Management configuration

▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

56

NISE 300 User Manual

Chapter 4: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of beeps

will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup. Another way to enter Setup is to power on the computer and wait for the following message during the POST:

Legends

Key Function

Moves the highlight left or right to select a menu.

Moves the highlight up or down between sub¬menus or fields.

Exits the BIOS Setup Utility.

Scrolls forward through the values or options of the highlighted field.

Scrolls backward through the values or options of the highlighted field.

Selects a field.

Displays General Help.

Load previous values.

Load optimized default values.

TO ENTER SETUP BEFORE BOOT PRESS

Press the

key to enter Setup:

Ctrl

+

Alt

+

57

Saves and exits the Setup program.

Press <Enter> to enter the highlighted sub¬menu

NISE 300 User Manual

Chapter 4: BIOS Setup

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press .

58

NISE 300 User Manual

Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Advanced Chipset Boot SecurityMain

BIOS Information BIOS Vendor Core Version Compliancy Project Version Build Date and Time

Processor Information Name Brand String Frequency Processor ID Stepping Number of Processors Microcode Revision GT Info

IGFX VBIOS Version Memory RC Version Total Memory Memory Frequency

PCH Information Name PCH SKU

American Megatrends

4.6.5.4 UEFI 2.3.1; PI 1.2 N300-006 x64 02/27/2014 15:13:09

Haswell Intel(R) Core(TM) i5-440 306c3 C0 2Core(s) / 4Thread(s) 8 GT3 (800 MHz)

2170

1.5.0.0 2048 MB (DDR3) 1333 Mhz

LynxPoint QM87

Save & Exit

▲

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

▲

Advanced

The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

Setting incorrect field values may cause the system to malfunction.

Main

► CPU Conguration

► SATA Conguration ► USB Conguration ► IT8783F Super IO Conguration ► IT8783F H/W Monitor ► Smart Fan Function

Advanced Chipset Boot Security

Save & Exit

CPU Conguration Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

59

NISE 300 User Manual

Chapter 4: BIOS Setup

CPU Configuration

This section is used to configure the CPU.

Advanced

CPU Conguration

Intel(R) Core(TM) CPU i5-4402E CPU @ 1.60GHz CPU Signature Processor Family Microcode Patch FSB Speed Max CPU Speed Min CPU Speed CPU Speed Processor Cores Intel HT Technology Intel VT-x Technology Intel SMX Technology 64-bit EIST Technology CPU C3 state CPU C6 state CPU C7 state

L1 Data Cache L1 Code Cache L2 Cache L3 Cache

306c3 6 8 100 MHz 1600 MHz 800 MHz 1600 MHz 2 Supported Supported Supported Supported Supported Supported Supported Supported

32 kB x 2 32 kB x 2 256 kB x 2 3072 kB

Advanced

▲ ▲

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

▲▲

Max CPU Speed Min CPU Speed CPU Speed Processor Cores Intel HT Technology Intel VT-x Technology Intel SMX Technology 64-bit EIST Technology CPU C3 state CPU C6 state CPU C7 state

L1 Data Cache L1 Code Cache L2 Cache L3 Cache

Hyper-threading

Active Processor Cores Limit CPUID Maximum Intel Virtualization Technology EIST Turbo Mode CPU C states

1600 MHz 800 MHz 1600 MHz 2 Supported Supported Supported Supported Supported Supported Supported Supported

32 kB x 2 32 kB x 2 256 kB x 2 3072 kB

[Enabled]

[All] [Disabled] [Enabled] [Disabled] [Disabled] [Disabled]

Enabled for Windows XP and

Linux (OS optimized for HyperThreading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology).

When Disabled only one thread

per enabled core is enabled.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Hyper Threading

Enables or disables hyper-threading technology.

Active Processor Cores

Select the number of cores to enable in each processor package.

Limit CPUID Maximum

The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.

Intel® Virtualization Technology

Enables or disables Intel® Virtualization technology.

EIST

Enables or disables Intel® SpeedStep.

Turbo Mode

Enables or disables turbo mode.

CPU C States

Enable CPU C States Support for power saving. It is recommended to keep C3, C6 and C7 all enabled for better power saving.

60

NISE 300 User Manual

Chapter 4: BIOS Setup

SATA Configuration

This section is used to configure the SATA drives.

Advanced

SATA Controller(s)

SATA Mode Selection

CFAST SATA 2 MS ATA SATA 1

[Enabled]

[AHCI]

Empty Empty TS32GMSA630 (32.0GB) Empty

SATA Controller(s)

Enables or disables the SATA controller.

Enable or disable SATA Device.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

SATA Mode Selection

Configures the SATA as IDE, AHCI or RAID mode.

IDE This option configures the Serial ATA drives as Parallel ATA physical storage device. RAID This option allows you to create RAID or Intel Matrix Storage configuration on Serial ATA devices. AHCI This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.

61

NISE 300 User Manual

Chapter 4: BIOS Setup

USB Configuration

This section is used to configure the USB.

Advanced

USB Conguration

USB Module Version

USB Devices: 2 Keyboards, 2 Hubs

Legacy USB Support USB3.0 Support XHCI Hand-off EHCI Hand-off

USB hardware delays and time-outs:

Device reset time-out

8.10.27

[Enabled] [Enabled] [Enabled] [Enabled]

[20 sec]

USB mass storage device Start Unit command time-out.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Legacy USB Support

Enable Enables Legacy USB. Auto Disables support for Legacy when no USB devices are connected. Disable Keeps USB devices available only for EFI applications.

XHCI Hand-off

This is a workaround for OSs that does not support XHCI hand-off. The XHCI ownership change should be claimed by the XHCI driver.

EHCI Hand-off

This is a workaround for OSs that does not support EHCI hand-off. The EHCI ownership change should be claimed by the EHCI driver.

Device Reset Time-out

Configures the USB mass storage device start unit command time-out.

USB3.0 Support

Enables or disables USB 3.0 controller support.

62

NISE 300 User Manual

Chapter 4: BIOS Setup

IT8783F Super IO Configuration

This section is used to configure the serial ports.

Advanced

IT8783F Super IO Conguration

IT8783F Super IO Chip



Serial Port 0 Conguration



Serial Port 1 Conguration



Serial Port 2 Conguration



Serial Port 3 Conguration



Serial Port 4 Conguration



Serial Port 5 Conguration

IT8783F

Super IO Chip

Displays the Super I/O chip used on the board.

Set Parameters of Serial Port O (COMA)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 0 Configuration

This section is used to configure serial port 0.

Advanced

Serial Port 0 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port 0 Mode Onboard Serial Port Max Baud Rate

[Enabled]

IO=3F8h; IRQ=4;

[IO=3F8h; IRQ=4;] [RS232] [115200 bps]

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Onboard Serial Port 0 Mode

Select this to change the serial port mode to RS232, RS422, RS485 or RS485 Auto.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

63

NISE 300 User Manual

Chapter 4: BIOS Setup

Serial Port 1 Configuration

This section is used to configure serial port 1.

Advanced

Serial Port 1 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port 1 Mode Onboard Serial Port Max Baud Rate

[Enabled]

IO=2F8h; IRQ=3;

[IO=2F8h; IRQ=3;] [RS232] [115200 bps]

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 2 Configuration

This section is used to configure serial port 2.

Advanced

Serial Port 2 Conguration

Serial Port

Device Settings

Change Settings RS485 Auto Direction Onboard Serial Port Max Baud Rate

[Enabled]

IO=3E8h; IRQ=6;

[IO=3E8h; IRQ=6;] [Disabled] [115200 bps]

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Onboard Serial Port 1 Mode

Select this to change the serial port mode to RS232, RS422, RS485 or RS485 Auto.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

RS485 Auto Direction

Enables or disables RS485 auto direction.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

64

NISE 300 User Manual

Chapter 4: BIOS Setup

Serial Port 3 Configuration

This section is used to configure serial port 3.

Advanced

Serial Port 3 Conguration

Serial Port

Device Settings

Change Settings RS485 Auto Direction Onboard Serial Port Max Baud Rate

[Enabled]

IO=2E8h; IRQ=7;

[IO=2E8h; IRQ=7;] [Disabled] [115200 bps]

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 4 Configuration

This section is used to configure serial port 4.

Advanced

Serial Port 4 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=2F0h; IRQ=11;

[IO=2F0h; IRQ=11;] [115200 bps]

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

RS485 Auto Direction

Enables or disables RS485 auto direction.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

65

NISE 300 User Manual

Chapter 4: BIOS Setup

Serial Port 5 Configuration

This section is used to configure serial port 5.

Advanced

Serial Port 5 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=2E0h; IRQ=10;

[IO=2E0h; IRQ=10;] [115200 bps]

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

66

NISE 300 User Manual

Chapter 4: BIOS Setup

IT8783F H/W Monitor

This section is used to monitor hardware status such as temperature, fan speed and voltages.

Advanced

Pc Health Status

CPU Temperature System Temperature CPU FAN Speed CPU:Vcore +3V +5V +12V

: +50 °c : +28 °c : N/A : +1.712 V : +3.296 V : +5.017 V : +11.827 V

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

CPU Temperature

Detects and displays the current CPU temperature.

CPU:Vcore

Detects and displays the Vcore CPU voltage.

+3V

Detects and displays 3.3V voltage.

+5V

Detects and displays 5V voltage.

+12V

Detects and displays 12V voltage.

System Temperature

Detects and displays the current system temperature.

CPU FAN Speed

Detects and displays the current CPU fan speed.

67

NISE 300 User Manual

Chapter 4: BIOS Setup

Smart Fan Function

This section is used to configure the fan’s function.

Advanced

PC Health Status

Smart Fan Mode

[Full on Mode]

Smart Fan Mode Full on Mode Automatic Mode Manual Mode

Smart Fan Mode Select

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Smart Fan Mode

Selects the mode of the fan, the options are Full on Mode, Automatic Mode and Manual Mode.

68

NISE 300 User Manual

Chapter 4: BIOS Setup

Chipset

This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and access to system memory resources.

Advanced Chipset Boot SecurityMain

PCH-IO Conguration

►

System Agent (SA) Conguration

Save & Exit

PCH Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

PCH-IO Configuration

This section is used to configure PCH-IO configuration.

Chipset

Intel PCH RC Version Intel PCH SKU Name Intel PCH Rev ID

►

PCH Azalia Conguration

Restore AC Power Loss

PCIE1 PCIE2 PCIE7 PCIE5 PCIE3 PCIE4 MS ATA PCIE6

INT Pin 1 Assignment INT Pin 2 Assignment INT Pin 3 Assignment INT Pin 4 Assignment INT Pin 5 Assignment INT Pin 6 Assignment INT Pin 7 Assignment INT Pin 8 Assignment

1.5.0.0 QM87 05/C2

[Power On]

[Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled]

[Auto] [Auto] [Auto] [Auto] [Auto] [Auto] [Auto] [Auto]

USB Conguration settings

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Restore AC Power Loss

Select AC power state when power is re-applied after a power failure.

PCH-IO Configuration

PCH-IO parameters.

System Agent (SA) Configuration

System Agent (SA) parameters.

PCIE1 to PCIE7

Enables or disables PCIE1/2/3/4/5/6/7.

mSATA

Enables or disables mSATA.

INT Pin 1 Assignment to INT Pin 8 Assignment

Configures the IRQ assignment for INT Pin 1/2/3/4/5/6/7/8.

69

NISE 300 User Manual

Chapter 4: BIOS Setup

PCH Azalia Configuration

Chipset

PCH Azalia Conguration

Azalia

[Auto]

Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled Enabled = Azalia will be unconditionally Enabled Auto = Azalia will be enabled if present, disabled otherwise.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Azalia

Control Detection of the Azalia device.

Disabled Azalia will be unconditionally disabled. Enabled Azalia will be unconditionally Enabled. Auto Azalia will be enabled if present, disabled otherwise.

System Agent (SA) Configuration

This section is used to configure the System Agent (SA) configuration.

Chipset

System Agent Bridge Name System Agent RC Version VT-d Capability

VT-d

Graphics Conguration

►

NB PCIe Conguration

►

Memory Conguration

►

Haswell

1.5.0.0 Supported

[Enabled]

Check to enable VT-d function on MCH.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

VT-d

Enables or disables VT-d function on MCH.

70

NISE 300 User Manual

Chapter 4: BIOS Setup

Graphics Configuration

Chipset

Graphics Configuration IGFX VBIOS Version IGfx Frequency

Internal Graphics

DVMT Total Gfx Mem LCD Control

►

2170 800 MHz

[Auto]

[256M]

Keep IGD enabled based on the setup options.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Internal Graphics

Keep IGD enabled based on the setup options.

DVMT Total Gfx Mem

Selects DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device.

71

NISE 300 User Manual

Chapter 4: BIOS Setup

LCD Control

Chipset

LCD Control

Primary IGFX Boot Display

Secondary IGFX Boot Display LCD Panel Type Active LFP Panel Color Depth

[DVI]

[Disabled] [1280x1024 Dual 24bit] [No LVDS] [18 Bit]

Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Primary IGFX Boot Display

Select the video device which will be activated during POST. Has no effect if external graphics is present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display.

Active LFP

Select the Active LFP configuration.

No LVDS VBIOS does not enable LVDS. Int-LVDS VBIOS enables LVDS driver by Integrated encoder.

Panel Color Depth

Select the LFP Panel Color Depth.

Secondary IGFX Boot Display

Select the secondary display device.

LCD Panel Type

Select the LCD panel used by the internal graphics device by selecting the appropriate setup item.

72

NISE 300 User Manual

Chapter 4: BIOS Setup

NB PCIe Configuration

This section is used to configure Northbridge PCI Express settings.

Chipset

NB PCIe Conguration

PEG0

PEG0 - Gen X

PEG1

PEG1 - Gen X

PEG2

PEG2 - Gen X

Enable PEG

Not Present

[Auto]

x1 Gen1

[Auto]

x1 Gen1

[Auto]

Congure PEG0 B0:D1:F0

Gen1-Gen3

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

PEG0 - Gen X

Configure PEG0 B0:D1:F0 Gen1-Gen3.

PEG1 - Gen X

Configure PEG1 B0:D1:F1 Gen1-Gen3.

Memory Configuration

This section displays the information of the memory installed in the system.

Chipset

Memory Information

Memory RC Version Memory Frequency Total Memory Memory Voltage DIMM#0 DIMM#1 DIMM#2 DIMM#3 CAS Latency (tCL) Minimum delay time CAS to RAS (tRCDmin) Row Precharge (tRPmin) Active to Precharge (tRASmin)

XMP Prole 1 XMP Prole 2

1.5.0.0 1333 Mhz 2048 MB (DDR3)

1.50v 2048 MB (DDR3) Not Present Not Present Not Present 9

9 9 24 Not Supported Not Supported

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

PEG2 - Gen X

Configure PEG2 B0:D1:F2 Gen1-Gen3.

Enable PEG

Enables or disables the PEG slot.

73

NISE 300 User Manual

Chapter 4: BIOS Setup

Boot

This section is used to configure the boot features.

Advanced

Boot Configuration

Setup Prompt Timeout

Bootup NumLock State

Quiet Boot Fast Boot

Launch PXE OpROM policy Onboard LAN PXE

Boot Option Priorities

Boot Option #1

Hard Drive BBS Priorities

Setup Prompt Timeout

Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.

Chipset

Boot

1

[On]

[Disabled] [Disabled]

[Enabled] [Disabled]

[P4: TS32GMSA630 . . .]

SecurityMain

Save & Exit

Number of seconds to wait for setup activation key.

65535(OxFFFF) means indenite

waiting.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Quiet Boot

Enabled Displays OEM logo instead of the POST messages. Disabled Displays normal POST messages.

Fast Boot

Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options.

Launch PXE OpROM Policy

Controls the execution of UEFI and legacy PXE OpROM.

Onboard LAN PXE

Enables or disables onboard LAN PXE ROM.

Hard Drive BBS priorities

Use the Hard Disk Drive BBS priorities options to set the order of the legacy devices in this group.

Bootup NumLock State

This allows you to determine the default state of the numeric keypad. By default, the system boots up with NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys.

74

NISE 300 User Manual

Chapter 4: BIOS Setup

Boot Option Priorities

Adjust the boot sequence of the system. Boot Option #1 is the first boot device that the system will boot from, next will be #2 and so forth.

Boot Option #1

Advanced

Boot Option #1

Chipset

Sets the system boot order.

Boot

[P4: TS32GMSA630 . . .]

SecurityMain

Save & Exit

Sets the system boot order

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

75

NISE 300 User Manual

Chapter 4: BIOS Setup

Security

Advanced Chipset Boot SecurityMain

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights. The password length must be in the following range: Minimum length 3 Maximum length 20

Administrator Password

User Password

HDD Security Conguration:

P4: TS32GMSA630

Administrator Password

Select this to reconfigure the administrator’s password.

User Password

Select this to reconfigure the user’s password.

HDD Security Configuration

Select this to configure the HDD security password.

Save & Exit

Set Administrator Password

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Save & Exit

Advanced Chipset Boot SecurityMain

Save Changes and Exit

Discard Changes and Exit Save Changes and Reset Discard Changes and Reset

Save Options

Save Changes Discard Changes

Restore Defaults Save as User Defaults Restore User Defaults

Boot Override

P4: TS32GMSA630

Launch EFI Shell from lesystem device

Save Changes and Exit

To save the changes and exit the Setup utility, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes. You can also press <F4> to save and exit Setup.

Discard Changes and Exit

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting. You can also press <ESC> to exit without saving the changes.

Save & Exit

Set Administrator Password

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

76

NISE 300 User Manual

Chapter 4: BIOS Setup

Save Changes and Reset

To save the changes and reset, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes and Reset

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting.

Save Changes

To save changes and continue configuring the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes

To discard the changes, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes to discard all changes made and restore the previously saved settings.

Restore Defaults

To restore the BIOS to default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Save as User Defaults

To use the current configurations as user default settings for the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Boot Override

To bypass the boot sequence from the Boot Option List and boot from a particular device, select the desired device and press <Enter>.

Launch EFI Shell from filesystem device

To launch EFI shell from a filesystem device, select this field and press <Enter>.

Restore User Defaults

To restore the BIOS to user default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecing Yes.

77

NISE 300 User Manual

Appendix A: Power Consumption

NISE 300 Power Consumption Table

Purpose

The purpose of the power consumption test is to verify the power dissipation of system, and the loading of power supply.

Test Equipment/Software

▪ PROVA CM-07 AC/DC CLAMP METER

Device Under Test

▪ DUT: sys#1

Test Procedure

1. Power up the DUT, boot into Windows 7 x64 Ultimate

2. Entering standby mode (HDD power down)

3. Measure the power consumption and record it.

4. Run Burn-in test program to apply 100% full loading

5. Measure the power consumption and record it.

Test Result

Sys #1

(Disabled Turbo Boot)

+19V +30V

Full-Loading Mode 2.49A 1.61A

Total 47.31W 48.3W

Standby S3Mode 0.13A 0.11A

Total 2.47W 3.3W

(Disabled Turbo Boot)

Sys #1

Test Equipment/Software

System Configuration

Chassis CHASSIS NISE300 VER:B

CPU Intel® Core™ i5-4402E Processor (3M Cache, up to 2.70 GHz)

Memory Transcend 4GB DDR3 1600 SO-DIMM (TS512MSK64V6H) X2

CPU board N/A

Mother board NISB300 REV:B

HDD HDD 2.5" SATA 160GB HITACHI:HTS545016B9A300 X2

FDD N/A

CD-ROM N/A

CFast Apacer CFast 32GB

Power Supply POWER ADAPTER FSP120-ACB 120W 24V/5A w/PSE MARK

Add-on Card mSATA (TS128GMSA740), NISK300LAN (x2), Sierra 8790V

CPU Cooler NISE300 CPU HEATSINK SHYUNG SHUHN

System FAN N/A

Keyboard Microsoft Wired Keyboard 600

Mouse Microsoft Basic Optical Mouse

Monitor ASUS VS228

Sys#1

78

NISE 300 User Manual

Appendix B: Watchdog Timer Setting

ITE8783 WatchDog Programming Guide

#define SUPERIO_PORT 0x2E #define WDT_SET 0x72 #define WDT_VALUE 0x73

void main(void) { #Enter SuperIO Configuration outportb(SUPERIO_PORT, 0x87); outportb(SUPERIO_PORT, 0x01); outportb(SUPERIO_PORT, 0x55); outportb(SUPERIO_PORT, 0x55);

# Set LDN outportb(SUPERIO_PORT, 0x07); outportb(SUPERIO_PORT+1, 0x07);

# Set WDT setting outportb(SUPERIO_PORT, WDT_SET); outportb(SUPERIO_PORT+1, 0xC0); # Use the second # Use the minute, change value to 0x40 # Set WDT sec/min outportb(SUPERIO_PORT, WDT_VALUE); outportb(SUPERIO_PORT+1, 0x05); #Set 5 seconds }

79

NISE 300 User Manual

Appendix C: GPI/O Programming Guide

GPI/O (General Purpose Input/Output) pins are provided for custom system design. This appendix provides definitions and its default setting for the ten GPI/O pins in the NISE 300. The pin definition is shown in the following table:

Pin GPI/O mode

1 VCC - - 2 GND - -

3 GPO0 Low A04h (Bit4) 4 GPI0 High A04h (Bit0)

5 GPO1 Low A04h (Bit5) 6 GPI1 High A04h (Bit1)

7 GPO2 Low A04h (Bit6) 8 GPI2 High A04h (Bit2)

9 GPO3 Low A04h (Bit7) 10 GPI3 High A04h (Bit3)

Control the GPO pin (3/5/7/9) level from I/O port A04h bit (4/5/6/7). The bit is Set/Clear indicated output High/Low

PowerOn

Default

Address Pin GPI/O mode

PowerOn

Default

80

Address

NISE 300 User Manual

Appendix C: GPI/O Programming Guide

GPIO programming sample code

#define GPIO_PORT 0xA04 #define GPO0 (0x01 << 4) #define GPO1 (0x01 << 5) #define GPO2 (0x01 << 6) #define GPO3 (0x01 << 7)

#define GPO0_HI outportb(GPIO_PORT, GPO0) #define GPO0_LO outportb(GPIO_PORT, 0x00) #define GPO1_HI outportb(GPIO_PORT, GPO1) #define GPO1_LO outportb(GPIO_PORT, 0x00) #define GPO2_HI outportb(GPIO_PORT, GPO2) #define GPO2_LO outportb(GPIO_PORT, 0x00) #define GPO3_HI outportb(GPIO_PORT, GPO3) #define GPO3_LO outportb(GPIO_PORT, 0x00) void main(void) { GPO0_HI; GPO1_LO; GPO2_HI; GPO3_LO; }

81

NISE 300 User Manual

NEXCOM NISE 300 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Copyright

Disclaimer

Acknowledgements

Regulatory Compliance Statements

Declaration of Conformity

RoHS Compliance

Warranty and RMA

Safety Information

Installation Recommendations

Safety Precautions

Technical Support and Assistance

Conventions Used in this Manual

Global Service Contact Information

Package Contents

Ordering Information

Chapter 1: Product Introduction

Overview

Key Features

Hardware Specifications

Knowing Your NISE 300

Front View

Rear View

Mechanical Dimensions

Chapter 2: Jumpers and Connectors

Before You Begin

Precautions

Jumper Settings

Locations of the Jumpers and Connectors for NISB 300

Jumpers

CMOS Pin Header

ME Pin Header Clear

AT/ATX Mode Select

Connector Pin Definitions

External I/O Interfaces - Front Panel

9V to 30VDC Input

USB 2.0

USB 3.0

HDMI

DVI-I

CFast

LAN1 and LAN2 Ports

LED Indicators

Power Switch

Internal Connectors

External SMBus

SIM Card Line-out Pin Header

SIM Card Mic-in Pin Header

SIM Card Socket

DC-In Power Connector

Reset JST Connector

LVDS Channel A Connector

LVDS Channel B Connector

SATA3 Connector 2

SATA3 Connector 1

SATA3 Power Connector 1

SATA3 Power Connector 2

USB 2.0 JST Connector

COM3-6 Connector

COM5 Connector

COM4 Connector

COM3 Connector

Battery Connector

GPIO Pin Header

GPIO LED Pin Header

Smart Fan1 Connector

USB Connector

Mini-PCIe Connector (3.5G/LTE)

Mini-PCIe Connector (mSATA)

Mini-PCIe Connector 1

Mini-PCIe Connector 2

Mini-PCIe Connector 3

Mini-PCIe Connector 4

Board to Board Connector

Chapter 3: System Setup

Removing the Top Cover
