Whole Home AC2200 Tri-band WiFi System
Data Sheet
RBK23W
Overview
Orbi™ is the simplest and smartest way to
enjoy high-speed WiFi in every corner of
your home. This Orbi WiFi System kit of
three covers homes up to 5,000 square feet
with strong WiFi signals. Innovative Tri-band
WiFi helps maximize the Internet speeds
available in your home, even as more devices
connect. This system now includes NETGEAR
Armor™, advanced cyber security for all your
devices.
Features
Your Home & Yard. Covered.
This kit of three delivers 2.2Gbps
maximum WiFi speeds for homes up
to 5,000 sq †.
Manage Your Kids’ Screen Time.
Circle® Smart Parental Controls let you
easily manage content & time online on
any device.
Enjoy better WiFi. Everywhere.
One WiFi Network.
Enjoy the convenience of a single
WiFi name for your whole home.
Simple & Secure.
Use the Orbi app and NETGEAR Armor
to create your secure whole home
WiFi in minutes.
PAGE 1 OF 4
Whole Home AC2200 Tri-band WiFi System
e
e
House Diagram
Orbi Satellite
5,000 Square Feet
of Orbi WiFi Coverage
DE DI CAT ED WI FI CO NN EC TIO N
Orbi Router
DE DI CAT ED W IFI
CO NN EC TI ON
Orbi Satellite
Data Sheet
RBK23W
> 100 Mbps
Internet speed over
5,000 sq ft range
1
1
Internet plan and devices that suppor t
these speeds are required.
INTERNET
Simple setup from your
smartphone or tablet.
Use the Orbi app to set up and manag
your network. To find the app, scan on
of the following QR codes or search for
NETGEAR Orbi in the Apple App Store
or Google Play Store.
NETGEAR Armor empowers you to
eliminate vulnerabilities or simply know
the status of your home network and
devices, anytime, anywhere. Get instant
notications when malicious threats
are detected, block unknown devices
from joining your Orbi home network or
take action on vulnerabilities as they are
discovered easily through the Orbi App.
PAGE 2 OF 4
Whole Home AC2200 Tri-band WiFi System
Internet Gigabit Ethernet port
Data Sheet
RBK23W
Orbi Router (RBR20)
Orbi Wall Plug Satellite (RBW30)
Sync
Power on/o
PAGE 3 OF 5
Whole Home AC2200 Tri-band WiFi System
What’s In the Box?
• One (1) Orbi Router (RBR20)
• Two (2) Orbi Wall Plug Satellites (RBW30)
• One (1) 2m Ethernet cable
• One (1) 12V/1.5A power adapter
• Quick start guide
What Do I Need for Orbi to Work?
• High-speed Internet connection
• Connect to existing modem or gateway
Physical Specifications
• Orbi Router (RBR20)
- Dimensions: 5.6 x 2.4 x 6.6 in
- Weight: 1.05 lb
• Orbi Wall Plug Satellite (RBW30)
- Dimensions: 3.3 x 3.0 x 6.34 in each
- Weight: 0.67 lb
Technical Specifications
• Orbi AC2200 Router & Wall Plug Satellites
(866 + 866 + 400Mbps)
• Simultaneous Tri-band WiFi
- Radio 1: IEEE® 802.11b/g/n 2.4GHz–
256-QAM support
†
Data Sheet
RBK23W
- Radio 2: IEEE® 802.11a/n/ac 5GHz–
256QAM support
- Radio 3: IEEE® 802.11a/n/ac 5GHz–
256QAM support
• Dedicated backhaul technology
• Four (4) high-performance antennas with high-
power amplifiers each
• Implicit/Explicit Beamforming for 2.4 & 5GHz
bands (866+866+400Mbps)
†
• MU-MIMO capable for simultaneous data
streaming on multiple devices
• Two (2) 10/100/1000Mbps Gigabit Ethernet
ports (Router)
- 1 WAN & 1 LAN
• Security
- Comprehensive anti-virus & data the
protection for your PC, Mac® and mobile devices
with NETGEAR Armor
™
- Standards-based WiFi Security (802.11i,
128-bit AES encryption with PSK)
- Guest WiFi network is easy to setup separate &
secure Internet access for guests
• Voice Control
- Amazon Alexa
™
- The Google© Assistant
• Circle® Smart Parental Controls manage content
and time online for all your devices. Learn more
at netgear.com/circle
This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller. www.netgear.com/warranty
* 90-day complimentary technical support following purchase from a NETGEAR authorized reseller.
†
Maximum wireless signal range derived from IEEE standard 802.11 specifications. Actual data throughput and data over distance will vary. Network conditions and
environmental factors, including volume of network traffic, building material and construction, and network overhead, result in lower actual data throughput rate and
wireless coverage.
1
Internet plan and devices that support these speeds are required.
2
NETGEAR Armor™ is free during the trial period. A yearly subscription, after the trial period, protects all of your connected devices. Visit www.netgear.com/armor
3
Circle® Smart Parental Controls includes the Free Basic Plan. Fees apply for a Premium Plan. Visit netgear.com/circle for more information.
For indoor use only.
For regulatory compliance information, visit http://www.NETGEAR.com/about/regulatory
NETGEAR, the NETGEAR Logo, and Orbi are trademarks and/or registered trademarks of NETGEAR, Inc. Apple and the Apple logo are trademarks of Apple Inc., registered in the
U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. Google Play and the Google Play logo are trademarks of Google, LLC.
Any other trademarks mentioned herein are for reference purposes only. ©2020 NETGEAR, Inc.
NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA , www.NETGEAR.com/support D-RBK23W-2
PAGE 4 OF 4
