Netgear Nighthawk EX7000 User manual

Nighthawk AC1900

WiF Range Extender

Model EX7000 User Manual

December 2014

202-11469-01

350 East Plumeria Drive

San Jose, CA 95134

USA

Nighthawk AC1900 WiF Range Extender

Support

Thank you for selecting NETGEAR products.

After installing your device, locate the serial number on the label of your product and use it to register your product at

https://my.netgear.com. You must register your product before you can use NETGEAR telephone support. NETGEAR

recommends registering your product through the NETGEAR website.

For product updates and web support, visit http://support.netgear.com.

Phone (US & Canada only): 1-888-NETGEAR.

Phone (Other Countries): Check the list of phone numbers at http://support.netgear.com/general/contact/default.aspx.

Compliance

For regulatory compliance information, visit http://www.netgear.com/about/regulatory.

See the regulatory compliance document before connecting the power supply.

Trademarks

Chapter 1 Overview

Unpack Your Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Top Panel LEDs and Front Panel USB Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Attach the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Attach the Rubber Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Attach the Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Retrieve and Display the Product Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

When to Use Your Extender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

How the Extender Works. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Support for the 801.11ac Networking Standard. . . . . . . . . . . . . . . . . . . . . . . . . 12

Chapter 2 Get Started

Install the Extender to Boost Your WiFi Range . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Set Up the Extender Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Use WPS to Connect the Extender to Your WiFi Router . . . . . . . . . . . . . . . . . 14

Use a Web Browser to Connect the Extender to Your WiFi Router. . . . . . . . 15

Choose a Location and Check the Signal Strength . . . . . . . . . . . . . . . . . . . . . 17

Connect Ethernet-Enabled Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Install the Extender as an Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Run Smart Setup Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Chapter 3 Optimize Extender Performance

Boost Your Video Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjust the WiFi Coverage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Chapter 4 Extender Network Settings

View Connected Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

View WiFi Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Change the WiFi Network Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Turn Off the SSID Broadcast to Create a Hidden Network . . . . . . . . . . . . . . . . . 29

Disable or Enable the WiFi Radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Change the WiFi Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Use WPS to Add a Computer to the Extender’s WiFi Network. . . . . . . . . . . . . . 32

Use WPS with the Push Button Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Use WPS with the PIN Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Deny Access to a Computer or WiFi Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

AC1900 WiFi Range Extender

Set Up an Access Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Change the Extender’s Device Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Set Up the Extender to Use a Static IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Chapter 5 Maintain and Monitor the Extender

Change the Extender User Name and Password. . . . . . . . . . . . . . . . . . . . . . . . . . 40

Turn Password Protection Off and On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Recover a Forgotten User Name or Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Automatically Adjust for Daylight Saving Time. . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Manually Set the Extender Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Back Up and Manage the Extender Configuration . . . . . . . . . . . . . . . . . . . . . . . . 43

Back Up the Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Restore the Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Return the Extender to Its Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . 44

Update the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Turn the NETGEAR Logo LED On or Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Restart the Extender Remotely. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Chapter 6 Share a USB Storage Device

USB Storage Device Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Share Files Across Your WiFi Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Access a USB Storage Device Attached to the Extender. . . . . . . . . . . . . . . . . . . 51

Turn the USB Port Off and On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Add a Network Folder on a USB Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Password-Protect a Folder on a USB Storage Device . . . . . . . . . . . . . . . . . . . . . 54

Use the Extender USB Port to Share a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Chapter 7 Use the Extender as a Media Server

Specify ReadyDLNA Media Server Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Play Media from a USB Drive on TiVo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Chapter 8 Share a USB Printer Through the Extender

Set Up ReadySHARE Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Use the Shared Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

View or Change the Status of a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Use the Scan Feature of a Multifunction USB Printer . . . . . . . . . . . . . . . . . . . . . 64

Change NETGEAR USB Control Center Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Chapter 9 FAQs and Troubleshooting

FAQs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Cannot Connect to the Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Cannot Join a WiFi Network and Receive an Error Message. . . . . . . . . . . . . . . . 72

AC1900 WiFi Range Extender

Appendix A Factory Settings and Technical Specifications

Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Technical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

1. Overview

The NETGEAR Nighthawk AC1900 WiFi Range Extender boosts your existing network range

and speed, delivering dual-band WiFi at speeds up to 1900 Mbps. The Nighthawk combines excellent range with maximum WiFi performance. It works with any standard WiFi router and is ideal for HD video streaming and gaming. Get the whole-home connectivity you need for tablets, smartphones, laptops and more.

You can also use the extender in access point mode as a WiFi access point and create a new

WiFi hotspot by using a wired Ethernet connection.

This chapter covers the following topics:

• Unpack Your Extender

• Top Panel LEDs and Front Panel USB Port

• Rear Panel

• Attach the Stand

• Attach the Rubber Feet

• Attach the Antennas

• Retrieve and Display the Product Label

• When to Use Your Extender

• How the Extender Works

• Support for the 801.11ac Networking Standard

Note: For more information about the topics covered in this manual, visit the

support website at support.netgear.com.

Note: Firmware updates with new features and bug fixes are made

available from time to time on downloadcenter.netgear.com. Some products can regularly check the site and download new firmware, or you can check for and download new firmware manually.

AC1900 WiFi Range Extender

Unpack Your Extender

Your box contains the following items:

Stand

Rubber feet (4)

Power adapter

Extender

Antennas (3)

Top Panel LEDs and Front Panel USB Port

Use the LEDs during installation to find the best location for the extender or to monitor the extender performance. The following figure shows the extender in an upright position, with the stand attached. (For information about attaching the stand, see Attach the Stand on page 9.)

NETGEAR Logo LED

2.4 GHz Link Rate LED 5 GHz Link Rate LED Device to Extender LED

LAN LEDs (1 through 5)

USB LED

USB 3.0 port

Figure 1. LEDs and USB port

Overview

AC1900 WiFi Range Extender

The following table describes the LEDs.

Table 1. Front panel LEDs

LED Description

• Green. The 2.4 GHz WiFi connection between the extender and

the WiFi router is optimum.

2.4 GHz Link Rate

5 GHz Link Rate

• Amber.

the WiFi router is good.

• Red.

WiFi router is poor.

• Off.

2.4 GHz WiFi band.

• Green. The 5 GHz WiFi connection between the extender and the

WiFi router is optimum.

• Amber. The

WiFi router is good.

• Red.

WiFi router is poor.

• Off.

5 GHz WiFi band.

The 2.4 GHz WiFi connection between the extender and

The 2.4 GHz WiFi connection between the extender and the

The extender and the WiFi router are not connected using the

GHz WiFi connection

The 5 GHz WiFi connection between the extender and the

The extender and the WiFi router are not connected using the

between the extender and the

LAN (1 through 5)

Device to Extender

USB

• Green. An Ethernet device is connected to the LAN port.

• Off. No Ethernet device is connected to the LAN port.

• Green. The extender is connected to a computer or WiFi device.

• Amber. The extender is starting or

about one minute, the LED turns green.

• Off.

• Solid green. A USB device is connected to the USB port.

• Off. No USB device is connected to the USB port.

The extender is not connected to a computer or WiFi device.

is applying WiFi settings. After

When the extender is powered on, the LEDs light amber for about one minute.

If you press the WPS button, the Link Rate LEDs

and the Device to Extender LED blink

green for two minutes. For information about using WPS, see Use WPS to Connect the

Extender to Your WiFi Router on page 14.

The Device to Extender LED blinks amber during a firmware update.

Overview

AC1900 WiFi Range Extender

Rear Panel

The following figure shows the ports, buttons, antennas, and connector on the rear panel of the extender.

Ethernet LAN ports (5)

Reset button

WPS button

Power On/Off button

Power connector

Figure 2. Rear panel

Antennas

Attach the Stand

If you prefer to place the extender in the upright (vertical) position, attach the stand that comes with the extender.

 To attach the stand:

1. Place the stand on a flat surface.

2. Hold the extender in upright position with

the left side of the extender pointing down.

The left side is the one with three rectangular openings.

The top panel of the extender and the three vertical support posts of the stand must face the same direction.

3. Lower the extender onto the stand until the

support posts of the stand snap into the rectangular openings of the extender.

Overview

AC1900 WiFi Range Extender

Attach the Rubber Feet

If you prefer to place the extender in horizontal position, you can attach the rubber feet that come with the extender.

 To attach the rubber feet:

1. Place the extender upside down, with the red panel facing you.

The red panel is the bottom.

2. In each corner, attach a rubber foot in such a way that it covers the triangle.

Attach the Antennas

 To attach the antennas:

1. Align the antennas with the antenna posts on the extender.

2. Attach the antennas on the threaded antenna posts.

3. Position the antennas for the best WiFi performance.

Overview

AC1900 WiFi Range Extender

Retrieve and Display the Product Label

The product label that you can retrieve from the extender contains the login URL, serial number, security PIN, MAC addresses of the radios, and other information.

 To retrieve the product label from the extender:

1. Place the extender upside down, with the red panel facing you.

The red panel is the bottom.

2. Locate the label handle with NETGEAR printed on it, and pull out the product label.

Label handle

Figure 3. Pulling out the product label

When to Use Your Extender

NETGEAR recommends that you connect through the extender network only when the WiFi device is in a “dead zone” where connection from the existing network is poor or nonexistent. Data traffic routed through the extender is inherently slower than traffic routed directly from the network.

How the Extender Works

The extender works like a bridge between a WiFi router (or a WiFi access point) and a WiFi device outside the range of the WiFi router. The extender performs two main jobs:

• The extender connects to a working WiFi network.

When the extender connects over WiFi to an existing network, it functions as a network client, similar to how a WiFi device connects to a network.

• The extender acts as an access point for WiFi devices.

Overview

AC1900 WiFi Range Extender

The extender broadcasts its own WiFi network that WiFi devices can join. In its role as an access point, the extender performs tasks that WiFi routers do, such as broadcasting its network name (SSID).

The extender must do each of these jobs so that both ends of the bridge are in place.

WiFi Range Extender

Boosts the range of your existing WiFi and creates a stronger signal in hard-to-reach areas.

Existing WiFi

Sometimes your router does not provide the WiFi coverage you need.

Figure 4. Range extender in a home

Support for the 801.11ac Networking Standard

The extender supports the 802.11ac networking standard. This new standard offers better speed, improved reliability, and more range than older WiFi networking standards.

The extender is backward compatible with earlier WiFi standards. However, to get the benefits of 802.11ac, your WiFi router must support the 802.11ac WiFi networking standard.

To learn more about the 802.11ac WiFi networking standard, visit

http://www.netgear.com/landing/80211ac/.

Figure 5. Speed comparison between the 802.11n and 802.11ac standards

Overview

2. Get Started

This chapter covers the following topics:

• Install the Extender to Boost Your WiFi Range

• Install the Extender as an Access Point

• Log In to the Extender After Installation

• Run Smart Setup Installation

AC1900 WiFi Range Extender

Install the Extender to Boost Your WiFi Range

The most common way to use the extender is to boost the range of your existing WiFi network. You can also use the extender as a WiFi access point and create a new WiFi hotspot by using a wired Ethernet connection. For information about access point installation, see Install the Extender as an Access Point on page 18.

Set Up the Extender Hardware

 To set up the extender hardware:

1. Attach the stand or the rubber feet.

For more information, see Attach the Stand on page 9 or Attach the Rubber Feet on page 10.

2. Attach the antennas.

For more information, see Attach the Antennas on page 10.

3. T

urn on your extender.

Place the extender close to your WiFi router. Plug the extender into an electrical outlet. Press the Power button if necessary

The NETGEAR LED lights white and the Link Rate LEDs and the Device to Extender LED light amber and then turn off.

Use WPS to Connect the Extender to Your WiFi Router

You can use WiFi Protected Setup (WPS) to connect the extender to your WiFi router without typing your existing router’s WiFi network name (SSID) or WiFi password. If you do not want to use WPS, see Use a Web Browser to Connect the Extender to Your WiFi Router on page 15.

 To use WPS to connect the extender to your WiFi router:

1. Make sure that the extender is powered on.

2. Press the WPS button on the extender

Both Link Rate LEDs minutes.

3. Within two minutes, press the WPS button on your WiFi router.

4. Add a WiFi band.

and the Device to Extender LED blink green for two

If your WiFi router supports the 5 GHz band (not all routers do), and you want to extend that band, repeat and check that the 5 GHz Link Rate LED lights green to confirm the connection.

Get Started

AC1900 WiFi Range Extender

Use a Web Browser to Connect the Extender to Your WiFi Router

You can use a web browser to log in to the extender and set up its WiFi connection to your existing WiFi router.

 To use a web browser to connect the extender to your WiFi router:

1. On a computer, tablet, or smartphone, open the WiFi connection manager and connect

to the extender network called NETGEAR_EXT.

When you are connected to the extender, the Device to Extender LED green.

2. Launch a web browser.

The first time that you log in to the extender, the Create Account screen displays. If the Create Account screen does not display, go to www.mywifiext.net.

3. Complete the fields and click the NEXT button.

lights solid

4. Click the WiFi RANGE EXTENDER button.

The extender scans for WiFi signals and finds the WiFi networks in your area and displays a list.

5. If you do not want to extend both WiFi bands, clear the 2.4GHz WiFi Networks or the 5

GHz WiFi Networks check box.

6. Select your WiFi network and click the NEXT

Get Started

button.

AC1900 WiFi Range Extender

If your existing WiFi network is hidden, select the Manually input my wireless SSID radio button and type your WiFi network name.

7. When prompted, enter the password to connect to your WiFi network and click the NEXT

button.

The extender connects to your existing router’s WiFi network.

8. Complete the fields to name your extended networks and click the NEXT button.

The extender applies your settings. This means that its WiFi network names and WiFi passwords change to the ones that you entered. To make this change, the extender must disconnect the computer or WiFi device that you are using from its WiFi network.

The following screen displays:

9. Use a WiFi network manager on the computer or WiFi device to connect to the new

extended WiFi network, and click the Continue button.

Get Started

AC1900 WiFi Range Extender

10. Click the Next button.

You are prompted to log in and register your product.

Choose a Location and Check the Signal Strength

Now that the extender is connected to your WiFi router, you can move it to a location that will boost your WiFi range. The location that you choose must be within the range of your existing WiFi router network. The ideal location to place the extender is halfway between your WiFi router and your WiFi device.

Figure 6. Extender location

The best connection is established with a clear line of sight between the extender and the WiFi router and a clear line of sight between the extender and the WiFi device that you are using.

 To move the extender to a good location and check the signal strength:

1. Move the extender to a location where you can boost your WiFi range.

The location you choose must be within the range of your existing WiFi router network.

2. Plug the extender into an electrical outlet at the new location and restart the extender.

Unless the extender is outside the range of your WiFi router, the extender connects automatically to the WiFi router

The Link Rate LEDs help you choose a spot with a good connection between the extender and the router. The following tables describe how the LEDs show the quality of the connection.

2.4 GHz and 5 GHZ LED Status LED Color Performance

Both the Link Rate LED and the Device to Extender LED are green.

and The extender provides the best performance.

The Link Rate LED is amber and the Device to Extender LED is green.

The Link Rate LED is red.

The Link Rate LED is off. The extender is not connected to the router.

and The extender provides a workable performance.

The extender provides a poor performance.

Get Started

AC1900 WiFi Range Extender

3. If the extender is not connected or the connection is poor, move the extender closer to

your WiFi router and try again until the 2.4 GHz or 5 GHz Link Rate LED is green, or at least amber.

4. Use a WiFi network manager on the computer or mobile device to connect to the extender’s

newly created WiFi network.

By default, the extender adds _2GEXT to the end of the 2.4 GHz network name and _5GEXT to the end of the 5 GHz network name, for example:

• Existing network name. MyNetworkName

• New extended 2.4 GHz network name.

• New extended 5 GHz network name. MyNetworkName_5GEXT

5. Select the new network and use your WiFi router password to connect.

You are now using your extended WiFi network.

MyNetworkName_2GEXT

Connect Ethernet-Enabled Devices

After the extender is connected to your existing WiFi network, you can connect wired devices to the extender using Ethernet cables. Those devices can then access your existing network through the extender’s WiFi connection.

Ethernet LAN ports (5)

Figure 7. Rear panel Ethernet LAN ports

Install the Extender as an Access Point

You can cable your extender to your existing router and then set up the extender in access point mode to work to create a new WiFi hotspot.

 To use the extender in access point mode:

1. Attach the stand or the rubber feet.

For more information, see Attach the Stand on page 9 or Attach the Rubber Feet on page 10.

2. Attach the antennas.

For more information, see Attach the Antennas on page 10.

Get Started

AC1900 WiFi Range Extender

3. Use an Ethernet cable to connect your router to the Ethernet port on the extender.

Ethernet

Extender Ethernet LAN port

WiFi router

4. Turn on your extender.

Plug the extender into an electrical outlet. Press the Power button if necessary.

The NETGEAR LED lights white and the Link Rate LEDs and the Device to Extender LED light amber and then turn off.

5. Use a WiFi network manager on a computer or WiFi device to find and connect to the

NETGEAR_EXT (SSID) WiFi network.

After the connection with the computer or WiFi device is established, the Device to Extender LED

lights solid green.

Note: In access point mode, you can connect your computer or WiFi device

to the extender only using a WiFi connection.

6. Launch a web browser

7. Enter www.mywifiext.net in the address field of the browser

The first time that you log in to the extender, the Create Account screen displays.

Get Started

AC1900 WiFi Range Extender

8. Complete the fields and click the NEXT button.

9. Click the ACCESS POINT button.

The extender checks for an Internet connection through the router that you connected to the extender.

10. When prompted, set the network name (SSID), security option, and password for each WiFi

band, and click the NEXT button.

Your settings are applied.

11. Use a WiFi network manager on the computer or WiFi device to connect to the new access

point WiFi network.

12. Click the CONTINUE

button.

A message displays that you successfully created an access point.

Log In to the Extender After Installation

You can log in to the extender to view or change the extender’s settings.

 To log in to the extender:

1. Use a WiFi network manager on a computer or WiFi device to find and connect to the

new extended WiFi network.

After the connection with the computer or WiFi device is established, the Device to Extender LED

2. Launch a web browser.

3. Enter www.mywifiext.net

A login screen displays.

4. Enter your email address and password and click the LOG IN button.

The Status screen displays.

lights solid green.

in the address field of the browser.

Get Started

AC1900 WiFi Range Extender

Run Smart Setup Installation

You can use Smart Setup to change the extender settings. This is an easy way to connect the extender to a different router or to change the extender WiFi network name (SSID) or WiFi password.

 To run Smart Setup:

1. Use a WiFi network manager on a computer or WiFi device to find and connect to the

new extended WiFi network.

After the connection with the computer or WiFi device is established, the Device to Extender LED

2. Launch a web browser.

3. Enter www.mywifiext.net in the address field of the browser

A login screen displays.

4. Enter your email address and password and click the LOG IN button.

lights solid green.

The Status screen displays.

5. Click the SMART SETUP button.

The Welcome screen displays.

6. Click the

WIFI RANGE EXTENDER button.

The extender scans for WiFi signals and finds the WiFi networks in your area and displays a list.

7. If you do not want to extend both WiFi bands, clear the 2.4GHz W

iFi Networks or the 5

GHz WiFi Networks check box.

8. Select your WiFi network and click the NEXT

button.

9. When prompted, enter the password to connect to your WiFi network and click the NEXT

button.

The extender connects to your existing router’s WiFi network.

10. Complete the fields to name your extended networks and click the NEXT button.

The extender applies your settings to its WiFi network names and WiFi passwords. During this change, the extender disconnects you from its WiFi network.

Get Started

AC1900 WiFi Range Extender

The following screen displays:

11. Use a WiFi network manager on the computer or WiFi device to connect to the new

extended WiFi network and click the Continue button.

12. Click the Next button.

The Status screen displays.

Get Started

3. Optimize Extender Performance

This chapter covers the following topics:

• Boost Your Video Streaming

• Adjust the WiFi Coverage

+ 53 hidden pages

Netgear Nighthawk EX7000 User manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

1. Overview

Unpack Your Extender

Top Panel LEDs and Front Panel USB Port

Rear Panel

Attach the Stand

Attach the Rubber Feet

Attach the Antennas

Retrieve and Display the Product Label

When to Use Your Extender

How the Extender Works

Support for the 801.11ac Networking Standard

2. Get Started

Install the Extender to Boost Your WiFi Range

Set Up the Extender Hardware

Use WPS to Connect the Extender to Your WiFi Router

Use a Web Browser to Connect the Extender to Your WiFi Router

Choose a Location and Check the Signal Strength

Connect Ethernet-Enabled Devices

Install the Extender as an Access Point

Log In to the Extender After Installation

Run Smart Setup Installation

3. Optimize Extender Performance
