NEFF U15E52N5AU User Manual
Built-in oven
[en] Instruction manual
U15E52.5AU
Ú Table of contents
[en]Instruction manual
Important safety information..................................................... 4
Causes of damage .............................................................................5
Energy and environment tips....................................................5
Saving energy......................................................................................5
Environmentally-friendly disposal.....................................................5
Your new appliance .................................................................... 6
Control panel .......................................................................................6
Operating modes ................................................................................7
Your accessories ........................................................................ 8
Accessories .........................................................................................8
Inserting accessories .........................................................................8
Shelf positions .....................................................................................8
Optional accessories .........................................................................9
Before using the appliance for the first time ...........................9
Setting the clock .................................................................................9
Cleaning the appliance......................................................................9
Operating the appliance ............................................................9
Switching on the appliance...............................................................9
Switching off the appliance............................................................10
Changing the basic settings .......................................................... 10
Automatic safety cut-out ................................................................. 10
Electronic clock........................................................................11
Clock display .................................................................................... 11
Timer .................................................................................................. 11
Cooking time .................................................................................... 11
End of operation .............................................................................. 12
Preset operation...............................................................................12
Setting the clock .............................................................................. 12
Rapid heat up...................................................................................12
Checking, correcting or deleting settings ................................... 13
Childproof lock .........................................................................13
Lock....................................................................................................13
Permanent lock ................................................................................ 13
Baking .......................................................................................14
Baking on one level......................................................................... 14
Baking on two or more levels ....................................................... 14
Baking table......................................................................................14
Baking table for ready-made products ........................................ 16
Tips and tricks .................................................................................. 16
Roasting and braising.............................................................. 17
Roasting............................................................................................. 17
Braising..............................................................................................17
Tables for roasting and braising...................................................18
Tips and tricks .................................................................................. 19
Grilling.......................................................................................20
Circo-roasting ...................................................................................20
Radiant grilling.................................................................................. 20
Grilling table......................................................................................20
CircoTherm® eco ......................................................................22
Low-temperature cooking .......................................................23
Using Low-temperature cooking ................................................... 23
Table for Low-temperature cooking ............................................. 23
Tips and tricks .................................................................................. 23
Defrost.......................................................................................24
Defrosting with CircoTherm® ........................................................ 24
Defrost................................................................................................ 24
Yoghurt...................................................................................... 24
Cleaning and care ....................................................................24
Cleaning the appliance exterior .................................................... 25
Cleaning the cooking compartment.............................................25
Self-cleaning surfaces.....................................................................26
Oven cleaning................................................................................... 26
Removing and fitting the appliance door....................................26
Cleaning the door panels............................................................... 27
Cleaning the hook-in racks ............................................................ 27
Faults and repairs ....................................................................28
Replacing the oven light bulb........................................................ 29
Changing the door seal..................................................................29
After-sales service ...................................................................29
E number and FD number ............................................................. 29
Test dishes................................................................................ 30
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.neff-
international.com and in the online shop www.neff-
eshop.com
3
: Important safety information
Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
This appliance may be used by children
over the age of 8 years old and by persons
with reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
mains or switch off the circuit breaker in
the fuse box.
Risk of fire!
■
A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating
element and catch fire. Do not place
greaseproof paper loosely over
accessories during preheating. Always
weight down the greaseproof paper with a
dish or a baking tin. Only cover the
surface required with greaseproof paper.
Greaseproof paper must not protrude over
the accessories.
Risk of burns!
■
The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■
Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■
Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with
care.
Risk of scalding!
■
The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■
When you open the appliance door, hot
steam may escape. Open the appliance
door with care. Keep children at a safe
distance.
Risk of scalding!
■
Water in a hot cooking compartment may
create hot steam. Never pour water into
the hot cooking compartment.
Risk of injury!
Risk of fire!
■
Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off
the appliance and unplug it from the
4
Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
Risk of electric shock!
■
Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug
or switch off the fuse in the fuse box.
Contact the after-sales service.
Risk of electric shock and serious injury!
■
The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact
with hot parts of the appliance.
Risk of electric shock!
■
Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■
When replacing the cooking compartment
bulb, the bulb socket contacts are live.
Before replacing the bulb, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box.
Risk of electric shock!
■
A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of burns!
The appliance will become very hot on the outside during the cleaning function. Never touch the appliance door. Allow the appliance to cool down. Keep children at a safe distance.
Causes of damage
Caution!
■ Accessories, foil, greaseproof paper or ovenware on the
cooking compartment floor: do not place accessories on the
cooking compartment floor. Do not cover the cooking
compartment floor with any sort of foil or greaseproof paper.
Do not place ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will cause heat
to accumulate. The baking and roasting times will no longer
be correct and the enamel will be damaged.
■ Water in a hot cooking compartment: do not pour water into
the cooking compartment when it is hot. This will cause
steam. The temperature change can cause damage to the
enamel.
■ Moist food: do not store moist food in the cooking
compartment when it is closed for prolonged periods This will
damage the enamel.
■ Fruit juice: when baking particularly juicy fruit pies, do not
pack the baking tray too generously. Fruit juice dripping from
the baking tray leaves stains that cannot be removed. If
possible, use the deeper universal pan.
■ Cooling with the appliance door open: only allow the cooking
compartment to cool when it is closed. Even if the appliance
door is only open a little, front panels of adjacent units could
be damaged over time.
■ Very dirty door seal: If the door seal is very dirty, the
appliance door will no longer close properly when the
appliance is in use. The fronts of adjacent units could be
damaged.Always keep the door seal clean.
■ Appliance door as a seat, shelf or worktop: Do not sit on the
appliance door, or place or hang anything on it. Do not place
any cookware or accessories on the appliance door.
■ Inserting accessories: depending on the appliance model,
accessories can scratch the door panel when closing the
appliance door. Always insert the accessories into the
cooking compartment as far as they will go.
■ Carrying the appliance: do not carry or hold the appliance by
the door handle. The door handle cannot support the weight
of the appliance and could break.
Energy and environment tips
Here you can find tips on how to save energy when baking and
roasting and how to dispose of your appliance properly.
Note: For this appliance, an energy consumption value has
been established that meets DIN EN 50304/DIN EN 60350.
This energy consumption value is 30% below that for energy
efficiency class A.
Depending on the appliance equipment, the additional
NeffLight® lighting was switched off while measuring
(see section: Switching off NeffLight®).
Saving energy
Only preheat the oven if this is specified in the recipe or in the
operating instruction tables.
Use dark, black lacquered or enamelled baking tins. They
absorb the heat particularly well.
Open the appliance door as little as possible during cooking,
baking or roasting.
It is best to bake several cakes one after the other. The cooking
compartment is still warm. This may reduce the baking time for
the second cake.
For longer cooking times, you can switch the oven off
10 minutes before the end of the cooking time and use the
residual heat to finish cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning used
electrical and electronic appliances (waste electrical
and electronic equipment - WEEE). The guideline
determines the framework for the return and recycling
of used appliances as applicable throughout the EU.
5
Your new appliance
;C
#
+
K
In this section, you will find information on
■ the control panel
■ the operating modes
Control panel
Controls and indicators Use/meaning
Main oven
(
0
8 ±
@
H
õ
Main oven
õ
Temperature display Cooking compartment temperature indicator and heating indicator
Information button Displays the current temperature while the appliance is heating up
Temperature selector Sets the temperature (see section: Switching on the appliance)
Operating mode selector Selects the required operating mode (see section: Switching on the appli-
3
(see section: Switching on the appliance)
Calls up the Basic settings menu
(see section: Changing the basic settings)
Changes the settings in the Basic settings menu
(see section: Changing the basic settings)
ance)
Electronic clock (Rapid heat up)
P
X KJ
`
Top oven
h
)"
)*
)2 ±
):
Pop-out operating knob
The rotary, temperature and operating mode selectors can all
be popped out. Push the required operating knob to pop it in or
6
Electronic clock display Displays the time; also includes clock functions and Rapid heat up (see
Clock function button Selects the required clock function or Rapid heat up (see section: Elec-
Rotary selector Selects the settings within each clock function or switches on Rapid heat
ô
Top oven
ô
Operating mode selector Selects the required operating mode (see section: Operating the appli-
Temperature display Cooking compartment temperature indicator and heating indicator
Information button Displays the current temperature while the appliance is heating up
Temperature selector Sets the temperature (see section: Switching on the appliance)
section: Electronic clock)
tronic clock)
up (see section: Electronic clock)
ance)
(see section: Switching on the appliance)
out.
Operating modes
Here is an overview of the operating modes of your appliance.
Main oven
Operating mode Use
3
%
0
4
+
(
$
/
“
z
õ
CircoTherm® For baking and roasting on one or more levels
Top/bottom heating For baking and roasting on one level. Ideal for cakes with moist toppings (e.g. cheese-
cake)
Pizza setting For frozen ready-made products and dishes which require a lot of heat from under-
neath. (see section: Baking)
Circo-roasting For poultry and larger pieces of meat
Full-surface grill For large amounts of flat, small items for grilling (e.g. steaks, sausages)
Centre-area grill For small amounts of flat, small items for grilling (e.g. steaks, bread)
Bottom heating For food and baked items on which you want a crust to form, or which need more
browning on the underside. Switch on Bottom heating at the end of the baking time for
a short time only.
Slow cooking For tender pieces of meat that are to be cooked medium/medium rare or à point
CircoTherm® eco* For energy-efficient baking and roasting on one level, without the need to preheat.
Oven cleaning For regeneration of the self-cleaning surfaces in the cooking compartment
\
* Type of heating used to determine the energy efficiency class in accordance with EN 50304
Top oven ô
Operating mode Use
%
+
(
$
z
\
Interior lighting Provides assistance when cleaning and caring for the cooking compartment
Top/bottom heating Ideal for cakes with moist toppings (e.g. cheesecake)
Full-surface grill For large amounts of flat, small items for grilling (e.g. steaks, sausages)
Centre-area grill For small amounts of flat, small items for grilling (e.g. steaks, sausages)
Bottom heating For food and baked items on which you want a crust to form, or which need more
browning on the underside
Oven cleaning For regeneration of the self-cleaning surfaces in the cooking compartment
Interior lighting Provides assistance when cleaning and caring for the cooking compartment
7
Your accessories
In this section, you will find information on
■ Your accessories
■ the correct way to insert the accessories into the cooking
compartment
■ the shelf positions
■ the optional accessories
Accessories
The following accessories are included with your appliance:
Wire rack
for baking in baking tins, roasting in
roasting dishes and grilling
Universal pan, enamelled
for baking moist cakes, roasting,
grilling and collecting drops of
liquid during cooking
Insert grid
for roasting and grilling
Note: The wire insert is always used
together with the universal pan. In
this combination, the wire insert is
placed in the universal pan.
Note: The baking tray and universal pan may become distorted
when the appliance is in operation. This is caused by the
considerable temperature differences acting on the
accessories. These differences may occur if only a part of the
accessory is covered with food, or if frozen items such as pizza
are placed on the accessory.
When inserting the baking tray or the universal pan, check
■ that the lug (a) is in the rear part of the of the accessory
■ that the sloping edge of the accessory faces towards the
appliance door when it is inserted
D
D
Shelf positions
The shelf positions in the cooking compartment are counted
from the bottom up.
Note: When baking and roasting with CircoTherm®
use shelf position 2. This will adversely affect air circulation and
your baking and roasting results will not be as good.
Bottom oven
The cooking compartment in the bottom oven has four shelf
positions.
õ
3, do not
Inserting accessories
The accessories are equipped with a locking function. The
locking function prevents the accessories from tilting when they
are pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to work
properly.
When inserting the wire rack, check
■ that the lug (a) is pointing downwards
■ that the lug (a) is in the rear part of the wire rack
D
D
Top oven
The cooking compartment of the top oven has two shelf
positions.
ô
8
Optional accessories
You can buy optional accessories from your after-sales service
or from specialist retailers. A comprehensive range of products
for your appliance can be found in our brochures or on our
home page.
Optional accessories Ordering no.
System steamer N8642X3
Roasting pan, enamelled Z1272X0
Glass pan Z1262X0
CLOU® 4x telescopic shelf with full extension
Bread-baking stone Z1913X0
Before using the appliance for the first time
In this section, you can read about
■ How to set the clock after connecting up your appliance
■ How to clean your appliance before using it for the first time
Setting the clock
Note: When you press the KJ clock function button, you have
3 seconds to set the clock using the rotary selector. Should this
have been insufficient for you, you can amend the clock time
later.
‹:‹‹ flashes in the clock display.
1. Briefly press the KJ clock function button to go to the
setting mode.
KJ and 3 symbols light up. ‚ƒ:‹‹ appears in the
The
clock display.
2. Set the current time using the rotary selector.
Your setting is accepted after 3 seconds.
Changing the clock
To subsequently change the time, press the
button repeatedly until the
Change the time with the rotary selector.
KJ and 3 symbols light up again.
KJclock function
Cleaning the appliance
Clean your appliance before using it for the first time.
1. Remove the accessories from the cooking compartment.
2. Completely remove any residual packaging (e.g. chips of
polystyrene) from the cooking compartment.
3. Clean the accessories and cooking compartment with hot
soapy water (see section: Cleaning and care).
4. Keep the kitchen ventilated while the appliance is heating up.
Heat with Top/bottom heat
5. Afterwards, wipe the cooled cooking compartment with hot,
soapy water.
6. Clean the outside of the appliance with a soft, damp cloth
and soapy water.
Z1755X2
% at 240 °C for 60 minutes.
Operating the appliance
In this section, you can read about
■ how to switch your appliance on and off
■ how to select an operating mode and temperature
■ how you can change the basic settings
■ when your appliance switches off automatically
Switching on the appliance
1. Turn the operating mode selector until the desired operating
mode is selected.
A default temperature appears on the temperature display.
2. Turn the temperature selector to change the default
temperature.
Notes
■ You can only start the operating mode / Low-temperature
cooking if neither
display.
■ If no default temperature is displayed, the temperature of your
selected operating mode is a fixed setting. You cannot
change this temperature.
Operating mode Default temper-
CircoTherm® 160 40 - 200
3
* Turn the temperature selector beyond 275 °C.
in the temperature display
• nor œ are shown in the temperature
ature in °C
Temperature
range in °C
‚Ÿ£ appears
9
Operating mode Default temper-
Top/bottom heat 170 50 - 275
%
CircoTherm intensive 220 50 - 275
0
Circo-roasting 170 50 - 250
4
Full-surface grill 220 50 - 275
+
Full-surface grill
(intensive)**
Centre-area grill 180 50 - 275
(
Centre-area grill
(intensive)**
Bottom heat 200 50 - 225
$
Low-temperature
/
cooking
CircoTherm® Eco 160 40 - 200
“
Oven cleaning Fixed setting
z
Interior lighting Fixed setting
^
* Turn the temperature selector beyond 275 °C.
in the temperature display
Current temperature
Press the
3 seconds.
Note: The current temperature can only be displayed with
operating modes with a default temperature.
Heating indicator
The heating indicator displays the rising temperature in the
cooking compartment.
■ Temperature reached (figure A)
■ Appliance reheating (figure B)
± info button. The current temperature appears for
ature in °C
Fixed setting
Fixed setting
Fixed setting
Temperature
range in °C
‚Ÿ£ appears
$ %
Changing the basic settings
Your appliance has various basic settings, which are preset at
the factory. You can, however, change these basic settings as
required.
The basic settings for both ovens can be activated using the
operating controls on the
To change the basic settings,
■ the appliance must be switched off.
■ the childproof lock and timer function must be switched off
1. Press and hold the ± info button for 3 seconds to go to
the basic settings menu.
In the temperature display,
2. Press the ± info button briefly and repeatedly until the setting
symbol for the current basic setting of a submenu is
displayed in the temperature display (e.g.
3. Using the temperature selector, set the required basic setting
within a submenu (e.g.
4. Press and hold the ± info button for 3 seconds.
Your basic setting is saved.
You can change the following basic settings:
Basic settings menu
Submenu Basic setting Setting
Childproof lock Appliance controls
Audible signal Audible signal off
õ bottom oven.
™‚‹ appears.
™„ƒ).
™„„).
unlocked
Appliance controls locked
Appliance controls permanent lock
Audible signal 30 seconds
Audible signal 2 minutes
Audible signal 10 minutes
symbol
™‚‹
™‚‚
™ƒ‚
™„‹
™„‚
™„ƒ
™„„
Switching off the appliance
Turn the operating mode selector to the Û position. The
appliance is switched off.
The appliance has a cooling fan. After the appliance is switched
off, the cooling fan may continue to run.
You can see in the temperature display whether there is high or
low residual heat in the cooking compartment.
Temperature display
•
œ
Meaning
Residual heat high (above 120 °C)
Residual heat low (between
60 °C and 120 °C)
Automatic safety cut-out
The automatic safety cut-out is activated if your appliance is
switched on and you have not made any settings for a long
time.
The length of time after which your appliance switches itself off
depends on the settings that you make.
‹‹‹ flashes in the temperature display. Appliance operation is
interrupted.
Turn the operating mode selector to the
deactivate it.
Û position to
10
