WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE
THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS
CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK • DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This

symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause

electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this
unit has been included. Therefore, it should be read carefully in order to avoid any problems.

Canadian Department of Communications Compliance Statement

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations

according to C.S.A. C22.2 No. 950.

FCC Information

1.

Use the attached specified cables with the
radio and television reception.

(1)

Please use the supplied power cord or equivalent to ensure FCC compliance.

(2) Shielded captive type signal cable.

Use of other cables and adapters may cause interference with radio and
television reception.

2.

This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio fre­quency energy, and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the users will be
required to correct the interference at their expense.

RDF225WG

color monitor so as not to interfere with

If necessary, the user should contact the dealer or an experienced radio/television
technician for additional suggestions. The user may find the following booklet, prepared
by the Federal Communications Commission, helpful: ”How to Identify and Resolve
Radio-TV Interference Problems.“ This booklet is available from the U.S. Government
Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.

No user serviceable parts inside. Do not attempt to modify this equipment. If modified,
your authority to operate this equipment might be voided by FCC.

1

RDF225WGmanual051804.p65 5/18/04, 10:02 AM1

Contents

Your new RDF225WG monitor box* should contain the following:

• RDF225WG monitor with tilt/swivel base

• Power Cord

• Video Signal Cable (D-Sub to D-Sub)

• User’s Manual

Video Signal Cable

Power Cord

User’s Manual

* Remember to save your original box and packing material to transport or ship the monitor.

2

RDF225WGmanual051804.p65 5/18/04, 10:03 AM2

Quick Start

To attach the monitor to your system, follow these instructions:

1. Turn off the power to your computer.

2. If necessary, install the display card into your system. For more information,
refer to the display card manual.

3. For the PC: Connect the 15-pin mini D-SUB of the captive signal cable to the
connector of the display card in your system (Figure A.1). Tighten all screws.

For the Mac: Connect the Macintosh cable adapter (not included) to the
monitor connector on the Macintosh (Figure B.1). Attach the 15-pin mini D­SUB end of the signal cable to the Macintosh cable adapter on the computer

(Figure B.1). Tighten all screws.

NOTE: To obtain the Macintosh cable adapter, call NEC-Mitsubishi Electronics

Display of America, Inc. at [phone].

4.

Connect the other end of the signal cable to the connector on the back of the monitor.

5. Connect one end of the power cord to the monitor and the other end to the
power outlet (Figure C.1).

6. Turn on the monitor (Figure D.1) and the computer.

NOTE: The Windows® 98/2000/Me/XP INF file download from http://www.nmv.co.jp/

NOTE: If you have any problems, please refer to the Troubleshooting section of

this User’s Manual.

Figure A.1

15-pin

mini

D-SUB

Video Signal Cable

RDF225WGmanual051804.p65 5/18/04, 10:03 AM3

Figure B.1

Mac Adapter

(Not Included)

Video Signal Cable

3

Quick Start –continued

Figure C.1

Power Button

RDF225WGmanual051804.p65 5/18/04, 10:03 AM4

Power Indicator

Figure D.1

4

Controls

OSD (On-Screen Display) control buttons on the front of the monitor function
as follows:

Main Menu Sub-Menu

EXIT Exits the OSD menu. Exits to the OSD controls

main menu.

Note : Deactivates the OSD menu and activates the OSD menu when the OSD is
turned off.

CONTROL Moves the highlighted Moves the highlighted area
/ area left/right to select left/right to select one of the

one of the sub-menus. controls.
Note : When the OSD menu is off, it acts as a Hot key for Brightness.

CONTROL Has no function. Moves the bar in the – or +
–/+ direction to decrease or

increase the adjustment.

Note : Deactivates the OSD menu and to adjust Contrast with Hot key set “ON”.

SELECT Enters sub-menu. Has no function.
RESET Resets all the controls within Resets the highlighted control

the highlighted menu to the factory setting.
to the factory setting.

Note: Deactivates the OSD menu and Hot Key for input connector (INPUT 1 2).
Note: When RESET is pressed in the main and sub-menu, a warning window will

appear allowing you to select the reset function.

Brightness/Contrast Controls

Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.

Degauss: Eliminates the buildup of stray magnetic fields which alter the correct scan of the

electron beams and affect the purity of the screen colors, focus and convergence. When
activated, your screen image will jump and waver a bit as the screen is demagnetized.

Caution: Please allow a minimum of 20 minutes to elapse between uses of the Degauss
Control.

Constant Brightness: Sustains the brightness and screen color levels consistently over the

normal life of the monitor. The Constant Brightness function requires a 30 minute warm­up of the monitor before the feature is fully functional.

Size and Position Controls

Auto Adjust: Automatically adjust the horizontal and vertical size and position settings for
the applicable timing signal.

NOTE: Auto Adjust is unavailable with no image signal or narrow size of image signal input.
Left/Right: Moves the image horizontally (left or right).
Down/Up: Moves the image vertically (up or down).
Narrow/Wide: Decreases or increases the horizontal size of the image.
Short/Tall: Decreases or increases the vertical size of the image.

5

RDF225WGmanual051804.p65 5/18/04, 10:03 AM5

Controls –continued

Color Control System

Color presets selects the desired color setting. The bar is replaced by the color setting
choice. Each color setting is adjusted at the factory to the stated Kelvin. If a setting is
adjusted, the name of the setting will change from Kelvin to Custom except sRGB mode.
Red, Green, Blue: AccuColor Control System decreases or increases the monitor's red,
green or blue color guns depending upon which is selected. The change in color will
appear on screen and the direction (decrease or increase) will be shown by the bars.

Geometry Controls

The Geometry controls allow you to adjust the curvature or angle of the sides of your
display.
In/Out (pincushion): Decreases or increases the curvature of the sides either inward or
outward.
Left/Right (pincushion balance): Decreases or increases the curvature of the sides either to
the left or right.

Tilt (parallelogram): Decreases or increases the tilt of the sides either to the left or right.
Align (trapezoidal): Decreases or increases the bottom of the screen to be the same as the top.
Rotate (raster rotation): Rotates the entire display clockwise or counterclockwise.
Corner Correction: Allows you to adjust the geometry of the corners of your display

Top, Top Balance, Bottom or Bottom Balance.

Tools 1

Moiré Canceler: Moiré is a wavy pattern which can sometimes appear on the screen. The
pattern is repetitive and superimposed as rippled images. When running certain applications,
the wavy pattern is more evident than in others. To reduce moiré, adjust the level by using –/+
CONTROL buttons.
Linearity: This selection allows you to adjust the spacing of the area on the screen. The purpose of
this control is to ensure that a one-inch circle is a true one-inch circle wherever it is on the screen.
The best way to determine the vertical linearity is as follows:

• Draw equally spaced horizontal lines using a drawing application that has a ruler.

•

Use the Vertical Balance control to adjust the lines near the top and bottom of your screen.

• Use the LINEARITY (VER.) control to adjust the spacing between the lines near the center and

top of your screen.

Convergence: Aligns all three colors (R,G,B) to form a single color (white). The purpose of
this control is to ensure that a white line drawn on the screen is as crisp and clear as
possible.

• Use the CONVERGENCE (HOR.) control to adjust the alignment of the lines in the up/down

direction.

•

Use the CONVERGENCE (VER.) control to adjust the alignment of the lines in the left/right direction.

•

Use the V-CONVERGENCE-TOP control to adjust the alignment of the top area of the white line in the up/
down direction.

• Use the V-CONVERGENCE-BOTTOM control to adjust the alignment of the bottom area of the white line in

the up/down direciton.

—

RDF225WGmanual051804.p65 5/18/04, 10:03 AM6

6

Controls –continued

Corner Purity Control: Eliminates picture impurities that may result from the earth’s
magnetic field. While in the sub-menus (TL: Top Left, TR: Top Right, BL: Bottom Left, BR:
Bottom Right or L/R: Left/Right, use the –/+ control buttons to fine tune the Corner Purity
corrections.
NOTE: We recommend that you perform Corner Purity correction while running a typical
application such as a spreadsheet or text document.

Tools 2

Language: OSD controls menus are available in 6 languages.
OSD Position: You can choose where you would like the OSD controls menu to appear on

your screen. Selecting OSD Position allows you to manually adjust the OSD controls menu
position from among Center, Top left, Top right, Bottom left and Bottom right.

OSD Turn Off: The OSD controls menu will stay on as long as it is in use. In the OSD Turn
Off sub-menu, you can select how long the monitor waits after the last touch of a button
for the OSD controls menu to disappear. The preset choices are 5 thru 120 seconds.

O

SD Lock Out: This control completely locks out access to all OSD controls functions except

Brightness and Contrast. When attempting to activate OSD controls while in the lock out
mode, a screen will appear indicating that OSD controls are locked out. To activate the
OSD Lock Out function, press SELECT and hold + down simultaneously. To deactivate the
OSD Lock Out, press SELECT and hold + down simultaneously.

Off Mode:

OTE: For standard systems and graphics boards, keep the factory setting at ENABLE

N
NOTE: Don’t keep the monitor on when ‘No Signal’ is applied. This could cause image

Clamp Pulse Position Control: Operating your monitor at a nonstandard timing may

cause images to appear darker than normal or have color distortion. Use of the EdgeLock
control will adjust images to their normal state.

Hot Key: This selection allows you to use as brightness control and –/+ as
contrast control.

Factory Preset: Selecting Factory Preset allows you a reset most OSD control settings back
to the factory settings. A warning statement will appear to confirm that you do want to
reset ALL settings. Individual settings can be reset by highlighting the control to be reset
and pressing the RESET button.

Enable: The Off Mode works normally and all

stages of energy savings are utilized.

Disable: The Off Mode is not used.

.

burn in on the screen due to the ‘No Signal’ message being displayed.

Information

Display Mode: Indicates the current mode and frequency setting of the monitor.
Monitor Info: Indicates the model and serial numbers of your monitor.

7

RDF225WGmanual051804.p65 5/18/04, 10:03 AM7

Recommended Use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE

FOLLOWING WHEN SETTING UP AND USING

THE MITSUBISHI COLOR MONITOR:

• DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or

removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to
qualified service personnel.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage

points, which can be harmful or fatal or may cause electric shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall,

causing serious damage to the monitor.

•

Keep the monitor away from high capacity transformers, electric motors and other devices such as
external speakers or fans, which may create strong magnetic fields.

• If possible, position the monitor so that it is facing the east to minimize the effects of the earth’s

magnetic field.

• Changing the direction of the monitor while it is powered on may cause image discoloration. To

correct this, turn the monitor off for 20 minutes before powering it back on.

• When operating the monitor with its AC 220-240V worldwide power supply, use a power supply

cord that matches the power supply voltage of the AC power outlet being used. The power supply
cord you use must have been approved by and comply with the safety standards of your country.
(Type H05VV-F should be used except in UK)

• In UK, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use with

this monitor. If a power cord is not supplied with this monitor, please contact your supplier.

Cleaning Your Monitor

A special coating is provided on the glass (CRT) surface of this monitor to reduce a reflection and
static electricity on the glass surface. Due to the delicate coating on the glass surface, use a lint-free,
non-abrasive cloth (cotton or equivalent) and a non-alcohol, neutral, non-abrasive cleaning solution
to minimize dust. If the screen requires more than a light cleaning, apply a soft neutral detergent and
water directly to a soft cloth and use it upon wringing water, to clean the glass surface. Clean your
monitor regularly.

CAUTION:

Benzene, thinner, acid/alkaline detergent, alcohol detergent, detergent with abrasive powder,
detergent with anti-static agent, detergent for cleaning.

Immediately unplug your monitor from the wall outlet and refer servicing to qualified service personnel
under the following conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If the monitor does not operate normally by following operating instructions.

CAUTION

The following agents will cause damage to the CRT when cleaning the glass surface:

• Allow adequate ventilation around the monitor so that heat can properly

dissipate. Do not block ventilated openings or place the monitor near a
radiator or other heat sources. Do not put anything on top of monitor.

• The power cable connector is the primary means of detaching the system

from the power supply. The monitor should be installed close to a power
outlet which is easily accessible.

• Handle with care when transporting. Save packaging for transporting.

RDF225WGmanual051804.p65 5/18/04, 10:03 AM8

8

Recommended Use –continued

CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR

CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE

FOLLOWING WHEN YOU POSITION THE MONITOR:

• Adjust the monitor height so that the top of

the screen is at or slightly below eye level.
Your eyes should look slightly downward
when viewing the middle of the screen.

• Position your monitor no closer than 16 inches

and no further away than 24 inches from your
eyes. The optimal distance is 20 inches.

• Rest your eyes periodically by focusing on

an object at least 20 feet away. Blink often.

• Position the monitor at a 90° angle to

windows and other light sources to minimize
glare and reflections. Adjust the monitor tilt so that ceiling lights do not reflect
on your screen.

• If reflected light makes it hard for you to see your screen, use an anti-glare filter.

• Adjust the monitor’s brightness and contrast controls to enhance readability.

• Use a document holder placed close to the screen.

• Position whatever you are looking at most of the time (the screen or

reference material) directly in front of you to minimize turning your head
while you are typing.

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomics benefits, we recommend the following:

• Adjust the Brightness until the background raster disappears

• Do not position the Contrast control to its maximum setting

• Use the preset Size and Position controls with standard signals

• Use the preset Color Setting and Sides Left/Right controls

• Use non-interlaced signals with a vertical refresh rate over 75-160 Hz

• Do not use primary color blue on a dark background, as it is difficult to see

and may produce eye fatigue due to insufficient contrast

For more detailed information on setting up a healthy work environment, write the
American National Standard for Human Factors Engineering of Visual Display Terminal
Workstations – ANSI-HFS Standard No. 100-1988 – The Human Factors Society, Inc.
P.O. Box 1369, Santa Monica, California 90406.

RDF225WGmanual051804.p65 5/18/04, 10:03 AM9

9
