NEC Express5800, N8100-2557F, N8100-2561F, R120h-1M System Configuration Manual

NEC Express5800/R120h-1M

System Configuration Guide

Introduction

This document contains product and configuration information that will enable you to configure your system. The guide will ensure fast and

proper configuration of your NEC Express5800 server.

July 12, 2018 Revision 7.0

NEC Corporation

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 2

Contents

MODEL LINEUP ............................................................................................................. 4

8x 2.5-inch Drive Model ........................................................................................................ 4

4x 3.5-inch Drive Model ........................................................................................................ 4

TECHNICAL SPECIFICATION ....................................................................................... 5

Specification .............................................................................................................................. 5

CONFIGURATION DIAGRAM ........................................................................................ 7

EXPANSION SLOT MAP ................................................................................................ 8

SERVER CONFIGURATION ........................................................................................... 9

1 Base Models ......................................................................................................................... 9

2 Processors ........................................................................................................................... 9

3 Memory ............................................................................................................................... 12

4 Internal Storage .................................................................................................................. 14

4.1 Drive Configuration .................................................................................................... 14

4.2 Drive Models .............................................................................................................. 15

4.3 Optional Rear Drive Cages ........................................................................................ 15

4.4 Storage Controllers and Options ................................................................................ 16

4.5 Internal Drives ............................................................................................................ 17

5 Optical Drive ....................................................................................................................... 20

6 Flash FDD ........................................................................................................................... 20

7 PCI Riser Card / PCI Card .................................................................................................. 21

7.1 PCI Riser Card ........................................................................................................... 21

7.2 List of PCI Riser Card................................................................................................. 21

7.3 Network Interface Controller ....................................................................................... 22

7.4 External Storage Controller ........................................................................................ 24

7.5 GPU Computing Card ................................................................................................ 25

7.6 Serial Port Adapter ..................................................................................................... 26

7.7 ExpEther Board .......................................................................................................... 26

8 Other Add-in Components ................................................................................................ 27

8.1 Power Supply ............................................................................................................. 27

8.2 High Performance CPU Heat Sink ............................................................................. 28

Type of CPU Heat Sink ....................................................................................................... 28

8.3 Fan Kit ........................................................................................................................ 28

8.4 Front Panel Kit ........................................................................................................... 29

8.5 Trusted Platform Module Kit ....................................................................................... 29

8.6 USB Memory Kit ......................................................................................................... 29

9 Factory Server Setting Service ......................................................................................... 30

9.1 Memory RAS Settings ................................................................................................ 30

RAID Configuration Service ....................................................................................... 30

10 Add-on Components ........................................................................................................ 30

10.1 17-inch LCD Console Drawer ................................................................................... 30

10.2 KVM Switch .............................................................................................................. 31

10.3 Server Management License ................................................................................... 31

10.4 Dust Proof Filter Kit .................................................................................................. 31

10.5 Slide Rail Kit ............................................................................................................. 31

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 3

10.6 Cable Management Arm ........................................................................................... 32

10.7 Starter Pack DVD ..................................................................................................... 32

10.8 Flash FDD ................................ ................................................................ ................ 32

REFERENCES .............................................................................................................. 33

External Views.......................................................................................................................... 33

Front and Rear Views ......................................................................................................... 33

Dimensions (mm) ..................................................................................................................... 35

General Supplementary Matters ............................................................................................. 36

Memory Supplementary Matters ............................................................................................ 37

Internal Drive Supplementary Matters ................................................................................... 39

Supported PCI Cards and Installable Slots ........................................................................... 42

OS Support Matrix for PCI Cards and Embedded Controllers ............................................. 44

Supported Tape and Removal Disk Backup Drive List ......................................................... 44

Copyright Notice and Liability Disclaimer ............................................................................. 45

REVISION HISTORY ..................................................................................................... 46

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 4

Model Lineup

8x 2.5-inch Drive Model

4x 3.5-inch Drive Model

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 5

Technical Specification

Specification

Model

R120h-1M

8x 2.5-inch Drive Model

4x 3.5-inch Drive Model

Part Number

N8100-2557F

N8100-2561F

Processor

Type

Intel® Xeon® Processor Bronze 3104(6C/6T, 1.70 GHz, 8.25MB, TDP 85W) Bronze 3106(8C/8T, 1.70 GHz, 11MB, TDP 85W) Silver 4108(8C/16T, 1.80 GHz, 11MB, TDP 85W) Silver 4110(8C/16T, 2.10 GHz, 11MB, TDP 85W) Silver 4112(4C/8T, 2.60 GHz, 8.25MB, TDP 85W) Silver 4114(10C/20T, 2.20 GHz, 13.75MB, TDP 85W) Silver 4116(12C/24T, 2.10 GHz, 16.50MB, TDP 85W) Gold 5115(10C/20T, 2.40 GHz, 13.75MB, TDP 85W) Gold 5118(12C/24T, 2.30 GHz, 16.50MB, TDP 105W) Gold 5120(14C/28T, 2.20 GHz, 19.25MB, TDP 105W) Gold 5122(4C/8T, 3.60 GHz, 16.50MB, TDP 105W) Gold 6126(12C/24T, 2.60 GHz, 19.25MB, TDP 125W) Gold 6128(6C/12T, 3.40 GHz, 19.25MB, TDP 115W) Gold 6130(16C/32T, 2.10 GHz, 22MB, TDP 125W) Gold 6132(14C/28T, 2.60 GHz, 19.25MB, TDP 140W) Gold 6134(8C/16T, 3.20 GHz, 24.75MB, TDP 130W) Gold 6136(12C/24T, 3 GHz, 24.75MB, TDP 150W) Gold 6138(20C/40T, 2 GHz, 27.50MB, TDP 125W) Gold 6140(18C/36T, 2.30 GHz, 24.75MB, TDP 140W) Gold 6142(16C/32T, 2.60 GHz, 22MB, TDP 150W) Gold 6144 (3.50 GHz, 8C/16T, 24.75MB, TDP 150W) Gold 6146 (3.20 GHz, 12C/24T, 24.75MB, TDP 165W) Gold 6148(20C/40T, 2.40 GHz, 27.50MB, TDP 150W) Gold 6150(18C/36T, 2.70 GHz, 24.75MB, TDP 165W) Gold 6152(22C/44T, 2.10 GHz, 30.25MB, TDP 140W) Gold 6154(18C/36T, 3 GHz, 24.75MB, TDP 200W) Platinum 8153(16C/32T, 2 GHz, 22MB, TDP 125W) Platinum 8156(4C/8T, 3.60 GHz, 16.50MB, TDP 105W) Platinum 8158(12C/24T, 3 GHz, 24.75MB, TDP 150W) Platinum 8160(24C/48T, 2.10 GHz, 33MB, TDP 150W) Platinum 8164(26C/52T, 2GHz, 35.75MB, TDP 150W) Platinum 8168(24C/48T, 2.70 GHz, 33MB, TDP 205W) Platinum 8170(26C/52T, 2.10 GHz, 35.75MB, TDP 165W) Platinum 8176(28C/56T, 2.10 GHz, 38.50MB, TDP 165W) Platinum 8180(28C/56T, 2.50 GHz, 38.50MB, TDP 205W) Gold 6134M(8C/16T, 3.20 GHz, 24.75MB, TDP 130W) Gold 6140M(18C/36T, 2.30 GHz, 24.75MB, TDP 140W) Gold 6142M(16C/32T, 2.60 GHz, 22MB, TDP 150W) Platinum 8160M(24C/48T, 2.10 GHz, 33MB, TDP 150W) Platinum 8170M(26C/52T, 2.10 GHz, 35.75MB, TDP 165W) Platinum 8176M(28C/56T, 2.10 GHz, 38.50MB, TDP 165W) Platinum 8180M(28C/56T, 2.50 GHz, 38.50MB, TDP 205W)

Number of Processors

1 or 2

Chipset

Intel® C621 Chipset

Memory

Type

DDR4-2666 Registered DIMM (8/16/32GB) DDR4-2666 Load Reduced DIMM (64/128GB)

Standard Capacity

0 GB

Maximum Capacity

3 TB (24 x 128 GB)

Memory protection

ECC, x4 SDDC, x4 DDDC, Memory Mirroring, Memory Sparing

Internal Storage

Standard Capacity

0 GB

Disk Controller

SATA : 6Gb/s, RAID 0/1/5/6/10/50/60 (Optional) SAS: 12 Gb/s, RAID 0/1/5/6/10/50/60 (Optional)

Hot Plug

Supported

Optical Disk Drive

Optional

Optical Drive Bays

1 Standard Disk Drive Bays

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 6

Model

R120h-1M

8x 2.5-inch Drive Model

4x 3.5-inch Drive Model

Expansion Slots

Standard

Total: 4 slots available 1 PCIe 3.0 x16 (x16 connector) 1 PCIe 3.0 x8 (x8 connector) 1 PCIe 3.0 x8 (x8 connector) for a dedicated RAID card 1 PCIe 3.0 x8 (x8 connector) for a dedicated LOM controller * The slot mix changes by installing an optional riser card.

Video

Controller (VRAM)

Integrated in Server Management Controller (16MB)

Resolution

640x480, 800x600, 1,024x768, 1,280x1,024, 1,600x1,200, 1,920x1,200

Interfaces

Front: 1x USB3.0, 1x USB2.0 (BMC) Rear: 2x USB3.0, 1x VGA (15-pin mini D-sub), 1x Management LAN connector (RJ-45), 4x Data LAN connector (RJ-45), 1x Serial (9-pin mini D-sub, Optional) Internal: 2x USB3.0, 2x SATA 2.0

Redundant Fan

Standard, hot plug

Redundant Power Supply

Optional, hot plug

Power Supply

1-2 x 500 Watt, 800 Watt, 1600 Watt 80 PLUS® Platinum certified hot plug PSU 500Watt, 800 Watt : 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz 800Watt, 1600 Watt : 200-240 VAC ± 10% 50 / 60 Hz ± 3 Hz

Dimensions (W x D x H )

434.6 x 707.0 x 42.9 mm

17.1 x 27.8 x 1.7 in (1U)

434.6 x 749.8 x 42.9 mm

17.1 x 29.5 x 1.7 in (1U)

Temperature, Relative Humidity (non-condensing)

Operating: 10° to 35° C / 50° to 95° F, 8 to 90% Non-Operating: -30° to 60° C / -22° to 140° F, 5 to 95%

Regulatory and Safety

FCC, UL/cUL, CB, CE, Mexico (CoC), RCM, RoHS, WEEE

Operating Systems

Microsoft® Windows Server® 2012 R2 Standard Microsoft® Windows Server® 2012 R2 Datacenter Microsoft® Windows Server® 2016 Standard Microsoft® Windows Server® 2016 Datacenter Red Hat Enterprise Linux 7.3 or later VMware ESXi™ 6.0 Update 3 VMware ESXi™ 6.5 Update 1

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 7

Configuration Diagram

8x 2.5-inch Drive Model

Legend: Standard Components Mandatory Components

4x 3.5-inch Drive Model

Legend: Standard Components Mandatory Components

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 8

Expansion slot Map

Legend

Remarks

Standard

LOM

PCIe 3.0 x8, x8 connector, for a dedicated LOM controller

RAID

PCIe 3.0 x8, x8 connector, for a dedicated RAID Card

1st Riser (Standard)

Slot 1

PCIe 3.0 x16, x16 connector, Full-height, up to 3/4 length

Slot 2

PCIe 3.0 x8, x8 connector, Low Profile, 168mm length

N8116-53 1st Riser (Option)

Slot 1

PCIe 3.0 x16, x16 connector, Full-height, up to 3/4 length

Slot 2

PCIe 3.0 x16, x16 connector, Low Profile, 168mm length

Internal

2x M.2 SATA SSD Slot for OS Boot

N8116-55 3rd Riser (Option)

Slot 3

PCIe 3.0 x16, x16 connector, Low Profile, 168 mm length

2CPU required

N8116-54 3rd Riser (Option)

Slot 3

PCIe 3.0 x16, x16 connector, Full-height, up to 3/4 Length

2CPU required

NOTE:

 By selecting PCI Riser Card, standard Riser can be exchanged and 3rd Riser can be expanded. Refer to “PCI Riser Card” for

available Riser Card and detailed specifications

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 9

Server Configuration

1 Base Models

Product Name / Description

Part Number

NEC Express5800/R120h-1M 8x 2.5-inch Drive Model

No processor, no RAM, no HDD, no ODD, no Rail, no Power Supply Unit. Including : Front Bezel, 2.5-inch Drive Cage

N8100-2557F

NEC Express5800/R120h-1M 4x 3.5-inch Drive Model

No processor, no RAM, no HDD, no ODD, no Rail, no Power Supply Unit. Including : Front Bezel, 3.5-inch Drive Cage

N8100-2561F

NOTE:

 The base model must be ordered with a Processor kit, a Memory kit, a Power Supply kit and a Slide Rail kit

2 Processors

Available sockets: 2

Category

Product Name / Description

Part Number

Bronze 3100

Xeon Bronze 3104 Processor Kit

Intel® Xeon ® Bronze 3104 (1.70 GHz, 6C/6T, 8.25MB, TDP 85W)

N8101-1107 (1st) N8101-1108 (2nd)

Xeon Bronze 3106 Processor Kit

Intel® Xeon ® Bronze 3106 (1.70 GHz, 8C/8T, 11MB, TDP 85W)

N8101-1109 (1st) N8101-1110 (2nd)

Silver 4100

Xeon Silver 4108 Processor Kit

Intel® Xeon ® Silver 4108 (1.80 GHz, 8C/16T, 11MB, TDP 85W)

N8101-1111 (1st) N8101-1112 (2nd)

Xeon Silver 4110 Processor Kit

Intel® Xeon ® Silver 4110 (2.10 GHz, 8C/16T, 11MB, TDP 85W)

N8101-1113 (1st) N8101-1114 (2nd)

Xeon Silver 4112 Processor Kit

Intel® Xeon ® Silver 4112 (2.60 GHz, 4C/8T, 8.25MB, TDP 85W)

N8101-1115 (1st) N8101-1116 (2nd

Xeon Silver 4114 Processor Kit

Intel® Xeon ® Silver 4114 (2.20 GHz, 10C/20T, 13.75MB, TDP 85W)

N8101-1117 (1st) N8101-1118 (2nd)

Xeon Silver 4116 Processor Kit

Intel® Xeon ® Silver 4116 (2.10 GHz, 12C/24T, 16.50MB, TDP 85W)

N8101-1119 (1st) N8101-1120 (2nd)

Gold 5100

Xeon Gold 5115 Processor Kit

Intel® Xeon ® Gold 5115 (2.40 GHz, 10C/20T, 13.75MB, TDP 85W)

N8101-1121 (1st) N8101-1122 (2nd)

Xeon Gold 5118 Processor Kit

Intel® Xeon ® Gold 5118 (2.30 GHz, 12C/24T, 16.50MB, TDP 105W)

N8101-1123 (1st) N8101-1124 (2nd)

Xeon Gold 5120 Processor Kit

Intel® Xeon ® Gold 5120 (2.20 GHz, 14C/28T, 19.25MB, TDP 105W)

N8101-1125 (1st) N8101-1126 (2nd)

Xeon Gold 5122 Processor Kit

Intel® Xeon ® Gold 5122 (3.60 GHz, 4C/8T, 16.50MB, TDP 105W)

N8101-1127 (1st) N8101-1128 (2nd)

Gold 6100

Xeon Gold 6126 Processor Kit

Intel® Xeon ® Gold 6126 (2.60 GHz, 12C/24T, 19.25MB, TDP 125W)

N8101-1129 (1st) N8101-1130 (2nd)

Xeon Gold 6128 Processor Kit

Intel® Xeon ® Gold 6128 (3.40 GHz, 6C/12T, 19.25MB, TDP 115W)

N8101-1131 (1st) N8101-1132 (2nd)

Xeon Gold 6130 Processor Kit

Intel® Xeon ® Gold 6130 (2.10 GHz, 16C/32T, 22MB, TDP 125W)

N8101-1133 (1st) N8101-1134 (2nd)

Xeon Gold 6132 Processor Kit

Intel® Xeon ® Gold 6132 (2.60 GHz, 14C/28T, 19.25MB, TDP 140W)

N8101-1135 (1st) N8101-1136 (2nd)

Xeon Gold 6134 Processor Kit

Intel® Xeon ® Gold 6134 (3.20 GHz, 8C/16T, 24.75MB, TDP 130W)

N8101-1137 (1st) N8101-1138 (2nd)

Xeon Gold 6136 Processor Kit

Intel® Xeon ® Gold 6136 (3 GHz, 12C/24T, 24.75MB, TDP 150W)

N8101-1139 (1st) N8101-1140 (2nd)

Xeon Gold 6138 Processor Kit

Intel® Xeon ® Gold 6138 (2 GHz, 20C/40T, 27.50MB, TDP 125W)

N8101-1141 (1st) N8101-1142 (2nd)

Xeon Gold 6140 Processor Kit

Intel® Xeon ® Gold 6140 (2.30 GHz, 18C/36T, 24.75MB, TDP 140W)

N8101-1143 (1st) N8101-1144 (2nd)

Xeon Gold 6142 Processor Kit

Intel® Xeon ® Gold 6142 (2.60 GHz, 16C/32T, 22MB, TDP 150W)

N8101-1145 (1st) N8101-1146 (2nd)

Xeon Gold 6144 Processor Kit

Intel® Xeon ® Gold 6144 (3.50 GHz, 8C/16T, 24.75MB, TDP 150W)

N8101-1147 (1st) N8101-1148 (2nd)

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 10

Xeon Gold 6146 Processor Kit

Intel® Xeon ® Gold 6146 (3.20 GHz, 12C/24T, 24.75MB, TDP 165W)

N8101-1149 (1st) N8101-1150 (2nd)

Xeon Gold 6148 Processor Kit

Intel® Xeon ® Gold 6148 (2.40 GHz, 20C/40T, 27.50MB, TDP 150W)

N8101-1151 (1st) N8101-1152 (2nd)

Xeon Gold 6150 Processor Kit

Intel® Xeon ® Gold 6150 (2.70 GHz, 18C/36T, 24.75MB, TDP 165W)

N8101-1153 (1st) N8101-1154 (2nd)

Xeon Gold 6152 Processor Kit

Intel® Xeon ® Gold 6152 (2.10 GHz, 22C/44T, 30.25MB, TDP 140W)

N8101-1155 (1st) N8101-1156 (2nd)

Xeon Gold 6154 Processor Kit

Intel® Xeon ® Gold 6154 (3 GHz, 18C/36T, 24.75MB, TDP 200W)

N8101-1157 (1st) N8101-1158 (2nd)

Platinum 8100

Xeon Platinum 8153 Processor Kit

Intel® Xeon ® Platinum 8153 (2 GHz, 16C/32T, 22MB, TDP 125W)

N8101-1159 (1st) N8101-1160 (2nd)

Xeon Platinum 8156 Processor Kit

Intel® Xeon ® Platinum 8156 (3.60 GHz, 4C/8T, 16.50MB, TDP 105W)

NOTE:

- The processor kit is make-to-order product.

N8101-1161 (1st) N8101-1162 (2nd)

Xeon Platinum 8158 Processor Kit

Intel® Xeon ® Platinum 8158 (3 GHz, 12C/24T, 24.75MB, TDP 150W)

NOTE:

- The processor kit is make-to-order product.

N8101-1163 (1st) N8101-1164 (2nd)

Xeon Platinum 8160 Processor Kit

Intel® Xeon ® Platinum 8160 (2.10 GHz, 24C/48T, 33MB, TDP 150W)

N8101-1165 (1st) N8101-1166 (2nd)

Xeon Platinum 8164 Processor Kit

Intel® Xeon ® Platinum 8164 (2 GHz, 26C/52T, 35.75MB, TDP 150W)

N8101-1167 (1st) N8101-1168 (2nd)

Xeon Platinum 8168 Processor Kit

Intel® Xeon ® Platinum 8168 (2.70 GHz, 24C/48T, 33MB, TDP 205W)

NOTE:

- The processor kit is make-to-order product.

N8101-1169 (1st) N8101-1170 (2nd)

Xeon Platinum 8170 Processor Kit

Intel® Xeon ® Platinum 8170 (2.10 GHz, 26C/52T, 35.75MB, TDP 165W)

NOTE:

- The processor kit is make-to-order product.

N8101-1171 (1st) N8101-1172 (2nd)

Xeon Platinum 8176 Processor Kit

Intel® Xeon ® Platinum 8176 (2.10 GHz, 28C/56T, 38.50MB, TDP 165W)

NOTE:

- The processor kit is make-to-order product.

N8101-1173 (1st) N8101-1174 (2nd)

Xeon Platinum 8180 Processor Kit

Intel® Xeon ® Platinum 8180 (2.50 GHz, 28C/56T, 38.50MB, TDP 205W)

N8101-1175 (1st) N8101-1176 (2nd)

Gold 6100

Xeon Gold 6134M Processor Kit

Intel® Xeon ® Gold 6134M (3.20 GHz, 8C/16T, 24.75MB, TDP 130W)

NOTE:

- The processor kit is make-to-order product.

N8101-1177 (1st) N8101-1178 (2nd)

Xeon Gold 6140M Processor Kit

Intel® Xeon ® Gold 6140M (2.30 GHz, 18C/36T, 24.75MB, TDP 140W)

NOTE:

- The processor kit is make-to-order product.

N8101-1179 (1st) N8101-1180 (2nd)

Xeon Gold 6142M Processor Kit

Intel® Xeon ® Gold 6142M (2.60 GHz, 16C/32T, 22MB, TDP 150W)

NOTE:

- The processor kit is make-to-order product.

N8101-1181 (1st) N8101-1182 (2nd)

Platinum 8100

Xeon Platinum 8160M Processor Kit

Intel® Xeon ® Platinum 8160M (2.10 GHz, 24C/48T, 33MB, TDP 150W)

NOTE:

- The processor kit is make-to-order product.

N8101-1183 (1st) N8101-1184 (2nd)

Xeon Platinum 8170M Processor Kit

Intel® Xeon ® Platinum 8170M (2.10 GHz, 26C/52T, 35.75MB, TDP 165W)

NOTE:

- The processor kit is make-to-order product.

N8101-1185 (1st ) N8101-1186 (2nd)

Xeon Platinum 8176M Processor Kit

Intel® Xeon ® Platinum 8176M (2.10 GHz, 28C/56T, 38.50MB, TDP 165W)

NOTE:

- The processor kit is make-to-order product.

N8101-1187 (1st) N8101-1188 (2nd)

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 11

Xeon Platinum 8180M Processor Kit

Intel® Xeon ® Platinum 8180M (2.50 GHz, 28C/56T, 38.50MB, TDP 205W)

NOTE:

- The processor kit is make-to-order product.

N8101-1189 (1st) N8101-1190 (2nd)

NOTE:

 The processor kit for the 1st CPU must be ordered with a base model.  The processor models must be the same to configure dual processor system.  High performance CPU heat sink is shipped with the processor with 130 Watt or higher and Platinum 8156, Gold 6128, 5122. The

standard CPU heat sink is shipped with all other processors.

 Estimated production lead time for the make-to-order processor kits will be approximately 3 months.  When using 3 slots (Except LOM slot and RAID slot), it is necessary to purchase the riser card option after setting it to 2 CPU

configuration

The maximum number of logical processors supported by OS

See the table below for the maximum number of logical processors that you can actually use on your system.

Operating Systems

Number of Logical

Processors Supported

by Operating Systems

Maximum Available

Number of Logical

Processors

Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Datacenter

640 1

112

Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Datacenter

640 1

112

Red Hat Enterprise Linux 7

384

112

VMware ESXi 6.0

480

112

VMware ESXi 6.5

576

112

The maximum numbers of logical processors when using Hyper-V are below:

- Windows Server 2012 R2: 320

- Windows Server 2016: 512

Maximum memory capacity

Maximum available memory capacity depends on the type of processor, see below.

CPU

Maximum memory capacity per CPU

Processor containing an “M” in the model

Xeon ® Platinum 8160M, 8170M, 8176M, 8180M Xeon ® Gold 6134M, 6140M, 6142M

1.5TB

others

768GB

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 12

3 Memory

Memory Configuration Feature Comparison

See the table below for feature comparisons of memory configurations supported.

Independent Channel

Memory Sparing

Memory Mirroring

Performance

Best

Better

Good

Data Protection

Multiple single bit error protection

Multiple single bit and multi bit error protection

Redundancy

Partly

Fully

Data Correction

ECC, x4 SDDC

Available Memory

Full physical memory

Two ranks of memory per channel : Half physical memory Four ranks of memory per channel : 3/4 physical memory Eight ranks of memory per channel : 7/8 physical memory 16 ranks of memory per channel : 3/4 physical memory

Half physical memory

Available Memory Channels

6 6 6

Notes

All DIMMs in the system must be identical. Eight or twelve DIMMs per a processor are supported, two DIMMs are populated per channel

All DIMMs in the system must be identical. Twelve DIMMs per processor are supported,

NOTE:

 Single Rank Memory (N8102-708/-709) does not support Memory Mirroring Mode Configuration Service.  Refer to “9.1 Memory RAS Settings”

Memory

Available slots: 12 per processor

Category

Product Name / Description

Part Number

Registered DIMM (RDIMM)

8GB DDR4-2666 REG Memory Kit (1x8GB/SR)

1 x 8GB Registered ECC DIMM, DDR4-2666(PC4-2666), Single Rank

N8102-708

8GB DDR4-2666 REG Memory Kit (1x8B/DR) 1 x 8GB Registered ECC DIMM, DDR4-2666(PC4-2666), Dual Rank

NOTE:

- This is make-to-order product.

N8102-714

16GB DDR4-2666 REG Memory Kit (1x16GB/SR)

1 x 16GB Registered ECC DIMM, DDR4-2666(PC4-2666), Single Rank

N8102-709

16GB DDR4-2666 REG Memory Kit (1x16GB/DR)

1 x 16GB Registered ECC DIMM, DDR4-2666(PC4-2666), Dual Rank

N8102-710

32GB DDR4-2666 REG Memory Kit (1x32GB/DR)

1 x 32GB Registered ECC DIMM, DDR4-2666(PC4-2666), Dual Rank

N8102-711

Load Reduced DIMM (LRDIMM)

64GB DDR4-2666 LR Memory Kit (1x64GB/QR)

1 x 64GB Load Reduced ECC DIMM, DDR4-2666(PC4-2666), Quad Rank

N8102-712

128GB DDR4-2666 LR Memory Kit (1x128GB/OR)

1 x 128GB Load Reduced ECC DIMM, DDR4-2666(PC4-2666), Octal Rank

N8102-713

NOTE:

 Minimum one memory kit per processor must be installed.  It is recommended to install memory kits in multiples of 6 identical DIMMs for 6-channel symmetric memory configurations to

increase memory transfer speed.

 Mix configurations of RDIMM and LRDIMM are not supported. Do NOT mix LRDIMM 64GB with LRDIMM 128GB.  If you install more than six times N8102-713 128GB DDR4-2666 LR Memory Kit, you require one of the following CPU Processor

codes containing an “M” (N8101-1177/-1178/-1179/-1180/-1181/-1182/-1183/-1184/-1185/-1186/-1187/-1188/-1189/-1190)

 See page 37 for additional memory configuration information.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 13

Maximum Memory Speed

See the table below for the actual maximum memory transfer speed. DDR4 memory speed depends on CPU series.

Processor Type

DIMM Speed

Xeon ® Platinum 8100 Series Xeon ® Gold 6100 Series Xeon ® Gold 5122 Processor

2666 MHz Xeon ® Gold 5100 Series (Except Xeon ® Gold 5122 Processor) Xeon ® Silver 4100 Series

2400 MHz Xeon ® Bronze 3100 Series

2133 MHz

Maximum Available Memory

See the table below for the maximum memory size that you can actually use on your system.

Operating Systems

Maximum Memory Size Supported by Operating Systems

Maximum Available Memory

Microsoft Windows Server 2012 R2 Standard 1 Microsoft Windows Server 2012 R2 Datacenter 1

4 TB

3 TB

Microsoft Windows Server 2016 Standard

Microsoft Windows Server 2016 Datacenter 1

24 TB

3 TB

Red Hat Enterprise Linux 7

12TB

3 TB

VMware ESXi 6.0 2

6 TB

3 TB

VMware ESXi 6.5 3

12TB

3 TB

The maximum available memory size of Hyper-V systems is below:

- Windows Server 2012 R2 : 4 TB

- Windows Server 2016 : 24 TB

Up to 4 TB of the main memory is available to each virtual machine.

Up to 6 TB of the main memory is available to each virtual machine.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 14

4 Internal Storage

4.1 Drive Configuration

Choose appropriate drive model and optional drive cages in accordance with the type and number of the drive you want to install.

List of the number that Internal Drives can be mounted

Base Model

Front cage

Rear Cage

Inside the server (Mounted on Option Riser Card

1,2

)

2.5-inch Drive Model

Standard : 8x 2.5-inch SAS/SATA Drive Expansion : 2x 2.5-inch SAS/SATA Drive

Standard : Expansion : 1x 2.5-inch SAS/SATA Drive

Standard : Expansion : 2x M.2 SATA SSD (available soon)

3.5-inch Drive Model

Standard : 4x 3.5-inch SAS/SATA Drive

1 By selecting Option 1st Riser Card, up to two M.2 SATA SSD can be mounted. It is impossible to connect RAID controller to M.2

SATA SSD.

2 Mix configurations of Rear Cage and M.2 SATA SSD for installing PCI Riser Card are not supported.

Drive Bay for 2.5-inch Drive Model

Eight 2.5-inch drive bays are standard. With an optional 2.5-inch drive cage, up to ten 2.5-inch drive bays can be equipped.

 Standard eight drives are available, if add more drive, Expansion Drive cage is needed.  Standard internal cable is attached.  Standard internal cable can be connected up to eight SAS/SATA Drives.

Drive Bay for 3.5-inch Drive Model

Four 3.5-inch drive bays are equipped as standard

 Standard four drives are available.  Standard internal cable is attached.  Standard internal cable can be connected up to four SAS/SATA Drives.

Rear Drive Bay for 2.5-inch and 3.5-inch Drive Model

With an optional drive cage installed into the PCI Slot 1, one 2.5-inch drive bay can be added.

NOTE:

 In default factory configuration, there are some conditions of drive types and RAID levels can be installed. Refer to “Condition of

internal drives in default factory configuration.” in References

 Up to 10 drives can be installed in Non-RAID (Embedded SATA) configuration.

Refer to “Conditions for mixing of Internal Drives” in References.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 15

4.2 Drive Models

4.2.1 8x 2.5-inch Drive model

Category

Product Name / Description

Part Number

Front

2.5-inch Hot Plug Drive Cage Kit (SAS/SATA) Including internal cable, for 8x 2.5-inch Drive Model

(standard)

2x2.5-inch Hot Plug Drive Cage Kit(SAS/SATA)

Including internal cable, for 8x 2.5-inch Drive Model

NOTE:

- The Drive Cage Kit cannot be installed if N8117-03 Internal DVD Drive

Installation Kit is installed.

N8154-89

4.2.2 4x 3.5-inch Drive model

Category

Product Name / Description

Part Number

Front

3.5-inch Hot Plug Drive Cage Kit (SAS/SATA) Including internal cable, for 4x 3.5-inch Drive Model

(standard)

4.3 Optional Rear Drive Cages

Category

Product Name / Description

Part Number

Rear

1x2.5-inch Hot Plug Drive Cage Kit(SAS/SATA, Rear)

Including internal cable

N8154-92

NOTE:

 Up to one N8154-92 1x2.5-inch Hot Plug Drive Cage Kit (SAS/SATA, Rear) can be installed  If equipped with N8154-92 1x2.5-inch Hot Plug Drive Cage Kit (SAS/SATA, Rear), 1

Riser card cannot be mounted

 After the drives are fully mounted on the Front Drive Cage, the drive should be mounted on the Rear Drive Cage

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 16

4.4 Storage Controllers and Options

4.4.1 Embedded SATA Controller

Category

Product Name / Description

Part Number

Storage Controller

Embedded SATA Controller

10 x 6Gb/s SATA drive, 2x M.2 drive(available soon)

(Standard)

Cable

Internal SATA Cable

(Standard)

NOTE:

 Hot plug insertion/removal are not supported in the configuration.

4.4.2 Embedded SATA RAID Controller (RAID 0/1/10)

Category

Product Name / Description

Part Number

Storage Controller

Embedded SATA Controller

10 x 6Gb/s SATA, 2x M.2 drive(available soon)

(Standard)

Cable

Internal SATA Cable

(Standard)

NOTE:

 For factory installation, up to ten drives can be installed in the system.  The Embedded SATA RAID Controller is available for Windows operating system only.

4.4.3 RAID Controller for Dedicated PCI Slot

Choose the appropriate RAID controller in accordance with RAID feature required, the number of drives to install and whether a full-length PCI card is installed.

Category

Product Name / Description

Part Number

Storage Controller

8 Ports / Standard Heat Sink

RAID Controller (RAID 0/1)

RAID 0/1/5/10 and SAS HBA mode, 0MB, Int. 8 ports, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s, Standard Heat Sink

N8103-189

RAID Controller (2GB, RAID 0/1/5/6)

RAID 0/1/5/6/10/50/60, 2GB, Int. 8 ports, PCIe 3.0 x8, SAS 12Gb/s, SATA, 6Gb/s, Standard Heat Sink

N8103-190

16 Ports / Standard Heat Sink

RAID Controller (4GB, RAID 0/1/5/6)

RAID 0/1/5/6/10/50/60, 4GB, Int. 16 ports, PCIe 3.0 x8, SAS 12Gb/s, SATA, 6Gb/s, Standard Heat Sink

NOTE:

The RAID Controller is supported on 8x 2.5 Drive Model Only.

N8103-191

8 Ports / Low Profile Heat Sink

RAID Controller (RAID 0/1)

RAID 0/1/5/10 and SAS HBA mode, 0MB, Int. 8 ports, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s, Low Profile Heat Sink

N8103-192

RAID Controller (2GB, RAID 0/1/5/6)

RAID 0/1/5/6/10/50/60, 2GB, Int. 8 ports, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s, Low Profile Heat Sink

N8103-193

16 Ports / Low Profile Heat Sink

RAID Controller (4GB, RAID 0/1/5/6)

RAID 0/1/5/6/10/50/60, 4GB, Int. 16 ports, PCIe 3.0 x8, SAS 12Gb/s, SATA, 6Gb/s, Low Profile Heat Sink

NOTE:

The RAID Controller is supported on 8x 2.5 Drive Model Only.

N8103-194

Battery Backup

Battery Backup Unit

Lithium-ion Battery for N8103-190/-191/-193/-194/-196/-201 RAID controller.

N8103-198

NOTE:

 The RAID controller with low profile heat sink is required when a full-length PCI card is installed.  One battery backup unit must be installed per one system.  If you select long PCI Cards or GPU Computing Card, Low Profile Heat Sink is needed.  N8103-189/-192 support RAID5 in addition to RAID 0/1 although the product name does not contain “5”. If higher performance is

needed, choose RAID controller with cache memory.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 17

4.4.4 RAID Controller for Standard PCI Slot

Category

Product Name / Description

Part Number

Storage Controller

RAID Controller (RAID 0/1)

RAID 0/1/5/10 and SAS HBA mode, 0MB, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s

N8103-195

RAID Controller (2GB, RAID 0/1/5/6)

RAID 0/1/5/6/10/50/60, 2GB, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s

N8103-201

Battery Backup

(Necessary for N8103-201)

Battery Backup Unit

Lithium-ion Battery for N8103-190/-191/-193/-194/-196/-201 RAID controller. 1 battery provides power to all RAID controller.

N8103-198

Cable

(Necessary for N8103-195 / -201)

Internal SAS/SATA Cable

For 2.5-inch Drive Model

K410-376(00)

Internal SAS/SATA Cable

For 3.5-inch Drive Model

K410-377(00)

NOTE:

 The RAID controller must be installed after shipment.  One battery backup unit must be installed per one system.  N8103-195 supports RAID5 in addition to RAID 0/1 although the product name does not contain “5”. If higher performance is

needed, choose RAID controller with cache memory.

4.5 Internal Drives

4.5.1 2.5-inch SATA Hard Disk Drives

Category

Product Name / Description

Part Number

512n Sector

1TB 7.2K Hot Plug 2.5-inch SATA HDD

1 x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm, 512n sector

N8150-596

512e Sector

2TB 7.2K Hot Plug 2.5-inch SATA HDD 1 x 2 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm, 512e sector

N8150-545

NOTE:

 512e sector drives are not available for VMware ESXi 6.0 system.  All drives within a RAID array should be of the same type, capacity and rotation speed.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

4.5.2 2.5-inch SATA Solid State Drives

Category

Product Name / Description

Part Number

Read Intensive DWPD ≈ 1

240GB Hot Plug 2.5-inch SATA SSD

1 x 240GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive

N8150-1704

480GB Hot Plug 2.5-inch SATA SSD

1 x 480GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive

N8150-1705

960GB Hot Plug 2.5-inch SATA SSD

1 x 960GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive

N8150-1706

1.92TB Hot Plug 2.5-inch SATA SSD

1 x 1.92TB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive

N8150-1707

3.84TB Hot Plug 2.5-inch SATA SSD

1 x 3.84TB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive

N8150-1708

Value Endurance DWPD ≈ 3

240GB Hot Plug 2.5-inch SATA SSD

1 x 240GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance

N8150-1700

480GB Hot Plug 2.5-inch SATA SSD

1 x 480GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance

N8150-1701

960GB Hot Plug 2.5-inch SATA SSD

1 x 960GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance

N8150-1702

1.92TB Hot Plug 2.5-inch SATA SSD

1 x 1.92TB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance

N8150-1703

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 18

NOTE:

 All drives within a RAID array should be of the same type, capacity.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

4.5.3 2.5-inch SAS Hard Disk Drives

Category

Product Name / Description

Part Number

512n Sector / 10,000 rpm

300GB Hot Plug 2.5-inch SAS HDD

1 x 300 GB SAS HDD, 2.5-inch, 12Gb/s, 10,000 rpm, 512n sector

N8150-546

600GB Hot Plug 2.5-inch SAS HDD

1 x 600 GB SAS HDD, 2.5-inch, 12Gb/s, 10,000 rpm, 512n sector

N8150-547

1.2TB Hot Plug 2.5-inch SAS HDD

1 x 1.2TB SAS HDD, 2.5-inch, 12Gb/s, 10,000 rpm, 512n sector

N8150-549

512e Sector / 10,000 rpm

1.8TB Hot Plug 2.5-inch SAS HDD

1 x 1.8TB SAS HDD, 2.5-inch, 12Gb/s, 10,000 rpm, 512e sector

N8150-550

2.4TB Hot Plug 2.5-inch SAS HDD 1 x 2.4 TB SAS HDD, 2.5-inch, 12Gb/s, 10,000 rpm, 512e sector

N8150-591

512n Sector / 15,000 rpm

300GB 15K Hot Plug 2.5-inch SAS HDD

1x 300 GB SAS HDD, 2.5-inch, 12Gb/s, 15,000 rpm, 512n sector

N8150-551

600GB 15K Hot Plug 2.5-inch SAS HDD

1x 600 GB SAS HDD, 2.5-inch, 12Gb/s, 15,000 rpm, 512n sector

N8150-552

512e Sector / 15,000 rpm

900GB 15K Hot Plug 2.5-inch SAS HDD

1x 900 GB SAS HDD, 2.5-inch, 12Gb/s, 15,000 rpm, 512e sector

N8150-553

 512e sector drives are not available for VMware ESXi 6.0 system.  All drives within a RAID array should be of the same type, capacity and rotation speed.  Up to two kinds of drives selected from SAS 10K HDDs, SAS 15K HDDs, SATA HDDs, SATA SSDs can be mixed.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

4.5.4 2.5-inch SAS Solid State Drives

Category

Product Name / Description

Part Number

Middle Endurance DWPD ≈ 10

400GB Hot Plug 2.5-inch SAS SSD

1 x 400GB SAS SSD, 2.5-inch, 12Gb/s, 512n sector, Middle Endurance

N8150-748

800GB Hot Plug 2.5-inch SAS SSD

1 x 800GB SAS SSD, 2.5-inch, 12Gb/s, 512n sector, Middle Endurance

N8150-749

Value Endurance DWPD ≈ 3

400GB Hot Plug 2.5-inch SAS SSD

1 x 400GB SAS SSD, 2.5-inch, 12Gb/s, 512n sector, Value Endurance

N8150-750

800GB Hot Plug 2.5-inch SAS SSD

1 x 800GB SAS SSD, 2.5-inch, 12Gb/s, 512n sector, Value Endurance

N8150-751

Read Intensive DWPD ≈ 1

480GB Hot Plug 2.5-inch SAS SSD

1 x 480GB SAS SSD, 2.5-inch, 12Gb/s, 512n sector, Read Intensive

N8150-752

960GB Hot Plug 2.5-inch SAS SSD

1 x 960GB SAS SSD, 2.5-inch, 12Gb/s, 512n sector, Read Intensive

N8150-753

NOTE:

 All drives within a RAID array should be of the same capacity.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 19

4.5.5 3.5-inch SATA Hard Disk Drives

Category

Product Name / Description

Part Number

512n Sector

1TB 7.2K Hot Plug 3.5-inch SATA HDD

1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512n sector

N8150-554

2TB 7.2K Hot Plug 3.5-inch SATA HDD

1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512n sector

N8150-555

4TB 7.2K Hot Plug 3.5-inch SATA HDD

1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512n sector

N8150-557

512e Sector

6TB 7.2K Hot Plug 3.5-inch SATA HDD

1 x 6 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512e sector

N8150-558

8TB 7.2K Hot Plug 3.5-inch SATA HDD

1 x 8 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512e sector

N8150-559

10TB 7.2K Hot Plug 3.5-inch SATA HDD

1 x 10 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512e sector

N8150-560

12TB 7.2K Hot Plug 3.5-inch SATA HDD 1 x 12 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm, 512e sector

N8150-587

NOTE:

 512e sector drives are not available for VMware ESXi 6.0 system.  All drives within a RAID array should be of the same type and capacity.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

3.5-inch Near Line SAS Hard Disk Drives

Category

Product Name / Description

Part Number

512e Sector

4TB 7.2K Hot Plug 3.5-inch SAS HDD

1 x 4 TB Near Line SAS HDD, 3.5-inch, 12Gb/s, 7,200 rpm, 512e sector

N8150-597

8TB 7.2K Hot Plug 3.5-inch SAS HDD

1 x 8 TB Near Line SAS HDD, 3.5-inch, 12Gb/s, 7,200 rpm,

512e sector

N8150-562

10TB 7.2K Hot Plug 3.5-inch SAS HDD

1 x 10 TB Near Line SAS HDD, 3.5-inch, 12Gb/s, 7,200 rpm, 512e sector

N8150-563

12TB 7.2K Hot Plug 3.5-inch SAS HDD 1 x 12 TB Near Line SAS HDD, 3.5-inch, 12Gb/s, 7,200 rpm, 512e sector

N8150-589

NOTE:

 512e sector drives are not available for VMware ESXi 6.0 system.  All drives within a RAID array should be of the same capacity.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

 Near Line SAS HDDs (7200 rpm) and SAS-HDDs (10,000rpm / 15,000rpm) are equipped with SAS interface, they have the same

maximum transfer speed and error recovery capabilities from the perspective of the interface specification, however Near Line SAS HDDs have the same I/O performance and endurance life as SATA HDDs(7200rpm) have.

M.2 SATA Solid State Drives

Category

Product Name / Description

Part Number

Value Endurance DWPD ≈ 1.5

240GB Non-hot-plug M.2 SATA SSD

1 x 240 GB M.2 SATA SSD, Value Endurance

N8150-1709

Read Intensive

DWPD ≈ 0.5

480GB Non-hot-plug M.2 SATA SSD

1 x 480 GB M.2 SATA SSD, Read Intensive

N8150-1710

NOTE:

 Optional riser card kit with M.2 connector is required.  M.2 SATA SSD is connected to Embedded SATA controller in Single connection or On-board RAID configuration regardless of

whether optional RAID controllers are installed or not.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 20

5 Optical Drive

Up to one drive can be installed

Category

Product Name / Description

Part Number

Internal

Installation Kit

Internal DVD Drive Installation Kit

Installation kit for 8x2.5-inch Drive Model

NOTE:

- The Installation Kit cannot be installed if N8154-89 2x2.5-inch Hot Plug

Drive Cage Kit (SAS/SATA) is installed.

- Displayport on this kit is not supported.

N8117-03

Cable

Internal SATA Cable for DVD Drive

For 4x3.5-inch Drive Model

K410-375(00)

Drive

Internal Slim DVD-ROM drive

Slim DVD-ROM drive, SATA

N8151-137

Internal DVD-Super Multi Drive

Slim DVD Super Multi drive, including writing software, SATA

NOTE:

- Not supported for Linux or VMware

N8151-138

External

External DVD-ROM Drive

Slim DVD-ROM drive, USB bus powered, 1.6A require, USB

N8160-102

NOTE:

 If N8151-137/-138 Internal Slim DVD-ROM drive/ Internal DVD-Super Multi Drive selected, N8117-03 Internal DVD Drive

Installation Kit is needed for 8x2.5-inch Drive Model.

 If N8117-03 Internal DVD Drive Installation Kit is selected, an Internal DVD drive must be selected.  If N8151-137/-138 Internal Slim DVD-ROM drive/ Internal DVD-Super Multi Drive selected, K410-375(00) is needed for 4x 3.5-inch

Drive Model.

6 Flash FDD

Up to one drive can be installed.

Product Name / Description

Part Number

Flash FDD

USB flash emulating USB floppy disk, Native capacity 1.44 MB

N8160-96

NOTE:

 Up to one drive can be connected.  Choose the Flash FDD if you need to prepare an alternative device for a floppy drive.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 21

7 PCI Riser Card / PCI Card

Up to three PCI riser cards can be installed in the system and 1st riser card is installed as standard. Up to two PCI cards can be mounted on the 1st riser card. To install three or more PCI cards, 3rd PCI riser card is required. HDD cage is required for HDD installation

7.1 PCI Riser Card

7.1.1 PCI Slot Configuration

The system supports three types of the PCI slot configuration. Choose an appropriate configuration in accordance with the type of PCI cards you want to install and whether you need M.2 .slots.

Using 3xPCI slot (Slot1: FullHeight, Slot2: LowProfile, Slot3: LowProfile)

Using 2xPCI slot (Slot1: FullHeight, Slot3: FullHeight)

7.2 List of PCI Riser Card

Category

Product Name / Description

Part Number

1st Riser

1st Riser Card(2xPCI)

Riser card for slot 1 with one PCIe 3.0 x16 slot and one GPU power connector, and riser card for slot 2 with one PCIe 3.0 x8 slot

NOTE:

- No power cable for GPU is included.

(Standard)

1st Riser Card Kit(2xPCI + 2xM.2 SATA SSD)

Riser card for slot 1 and 2 with one PCIe 3.0 x16 slot and two M.2 SATA connector

NOTE:

- The Riser Card Kit cannot be installed if the Rear Drive Cage Kit is

installed.

N8116-53

3rd Riser

3rd Riser Card Kit(1xPCI)

Riser card for slot 3 with one PCIe 3.0 x16 slot

NOTE:

- The Riser Card Kit is supported in dual-processor configuration.

N8116-55

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 22

3rd Riser Card Kit(1xPCI + 1xGPU Installation Kit)

Riser card for slot 3 (physically occupied from slot 2 to slot 3) with one PCIe 3.0 x16 slot and one GPU power connector, Including two power cables for GPU

NOTE:

- The Riser Card Kit is supported in dual-processor configuration.

- N8154-92 1x2.5-inch drive cage (SAS/SATA, rear) can’t be installed

when N8116-53 1st riser card (2x PCI + 2xM.2 SATA SSD) is selected

N8116-54

NOTE:

 If N8116-53 1st Riser Card (2xPCI + 2xM.2 SATA SSD) is selected, 1x2.5-inch Drive Cage (SAS/SATA, rear) can’t be installed.

7.3 Network Interface Controller

Category

Product Name / Description

Part Number

LOM Card

1GbE

Quad Port 1000BASE-T LOM Card

Broadcom BCM5719 PCIe 2.0(x4)

N8104-171

Quad Port 1000BASE-T LOM Card

Intel Ethernet Controller I350 PCIe 2.0(x4)

N8104-172

10GbE

Dual Port 10GBASE-T LOM Card

QLogic 57810S PCIe 2.0(x8)

N8104-173

Dual Port 10GBASE-T LOM Card

Intel X550

PCIe 3.0(x4)

N8104-175

Dual Port 10GBASE SFP+ LOM Card

Intel Ethernet Controller X710 PCIe 3.0(x8)

NOTE:

- N8104-189 SFP+ Module is required to connect with an optical cable.

- Up to two SFP+ Modules can be installed.

- Twinax cable can be installed.

N8104-176

25GbE

Dual Port 25GBASE SFP28 LOM Card

Cavium 45604 PCIe 3.0(x16)

NOTE:

- N8104-190 SFP28 Module is required to connect with an optical cable.

- Up to 2 SFP28 Modules can be installed.

- Twinax cable can be installed

N8104-177

Adapter

1GbE

Dual Port 1000BASE-T Adapter

Broadcom BCM5720 Gigabit Ethernet Controller PCIe 2.0(x1)

N8104-178

Dual Port 1000BASE-T Adapter

Intel Ethernet Controller I350 PCIe 2.0(x4)

NOTE:

- Network cables with RJ-45 plug covers cannot be used.

N8104-180

Quad Port 1000BASE-T Adapter

Broadcom BCM5719 Gigabit Ethernet Controller PCIe 2.0(x4)

NOTE:

- Network cables with RJ-45 plug covers cannot be used.

N8104-179

Quad Port 1000BASE-T Adapter

Intel Ethernet Controller I350 PCIe 2.0(x4)

NOTE:

- Network cables with RJ-45 plug covers cannot be used.

N8104-181

10GbE

Dual Port 10GBASE-T Adapter

QLogic 57810S PCIe 2.0(x8)

N8104-182

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 23

Dual Port 10GBASE-T Adapter

Cavium QL41401, PCIe3.0(x8)

N8104-183

Dual Port 10GBASE-T Adapter

Intel X550-AT2, PCIe3.0(x4)

N8104-184

Dual Port 10GBASE SFP+ Adapter

QLogic 57810S PCIe 2.0(x8)

NOTE:

- N8104-189 SFP+ Module is required to connect with an optical cable.

- Up to 2 SFP+ Modules can be installed.

- Twinax cable can be installed

N8104-185

Dual Port 10GBASE SFP+ Adapter

Intel Ethernet Controller X710 PCIe 3.0(x8)

NOTE:

- N8104-189 SFP+ Module is required to connect with an optical cable.

- Up to 2 SFP+ Modules can be installed.

- Twinax cable can be installed

N8104-186

25GbE

Dual Port 25GBASE SFP28 Adapter

Cavium QL41401, PCIe3.0(x8)

NOTE:

- N8104-190 SFP28 Module is required to connect with an optical cable.

- Up to 2 SFP28 Modules can be installed.

N8104-187

SFP Module

10GbE

SFP+ Module (10G-SR)

1 x SFP+ Module

N8104-189

25GbE

SFP28 Module (25G-SR)

1x SFP28 Module SFP28 can be connected to 25G BASE adapter

NOTE:

It is not factory installation option.

N8104-190

NOTE:

 The NIC cards must be installed under the maximum configuration limits for networking when running with VMware systems. For

more detail, see the Networking Maximum in the Configuration Maximums document for VMware.

- For VMware ESXi 6.0: https://www.vmware.com/pdf/vsphere6/r60/vsphere-60-configuration-maximums.pdf

- For VMware ESXi 6.5: https://www.vmware.com/pdf/vsphere6/r65/vsphere-65-configuration-maximums.pdf

NIC Teaming feature - NIC Teaming and bonding features

The Express5800 server supports NIC teaming which is the ability to configure multiple NICs to a virtual single network interface for dual path and load balancing to fault tolerance and Network Loading Balancing.

See the table below for supported network interfaces and OS combinations.

Network Interface

Team

Operating Systems

1GbE NIC

On-board LAN Interface N8104-171/-178/-179

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

1GbE NIC

N8104-172/-180/-181

Up to four ports per one team

Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

10GbE NIC

N8104-173/-182

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

10GbE NIC

N8104-175/-184

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 24

10GbE NIC

N8104-183

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

10GbE NIC

N8104-185

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

10GbE NIC

N8104-176/-186

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3 VMware ESXi 6.0 Update3 VMware ESXi 6.5 Update1

25GbE NIC

N8104-177/-187

Up to four ports per one team

Windows Server 2012 R2 Windows Server 2016 Red Hat Enterprise Linux 7.3

NOTE:

 The Bonding function of 10GBASE is available for mode 1 (active-backup) and mode 4 (802.3 ad).  Mixing 1000 BASE teaming, 10 GBASE teaming, and 25 GBASE teaming in one system is supported. For Windows Server 2012

R2, Windows Server 2016, Red Hat Enterprise Linux, up to 5 teams per system can be installed.

7.4 External Storage Controller

7.4.1 RAID Controller

Category

Product Name / Description

Part Number

Controller

RAID Controller (4GB, RAID0/1/5/6)

RAID0/1/5/6/10/50/60, 4GB, 8 External port PCIe 3.0 x8, SAS 12Gb/s, SATA 6Gb/s

N8103-196

Battery Backup

Battery Backup Unit

Lithium-ion Battery for RAID controller.

N8103-198

NOTE:

 Only one SAS JBOD Enclosure can be connected to one RAID controller.  4Kn sector drives are not supported with the RAID controller.  One battery backup unit must be installed per one system.  To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of

becoming multiple hard drives failure during the RAID rebuilding process.

 It is recommended to set RAID array configuration drives up to eight in order to minimize the risk of becoming multiple hard drives

failure.

7.4.2 Fibre Channel / SAS Controller

Category

Product Name / Description

Part Number

Fibre Channel

Fibre Channel Controller (1ch)

Cavium QLogic, QLE2690 16Gb/s, Optical, PCIe 3.0 x8

NOTE:

- The controller is qualified with NEC Storage M series, OS support

WS2012R2 and WS2016

- The controller is qualified with NEC Storage T series, OS support

WS2012R2, WS2016 and RHEL7.3

N8190-165

Fibre Channel Controller (2ch)

Cavium QLogic, QLE2692 16Gb/s, Optical, PCIe 3.0 x8

NOTE:

- The controller is qualified with NEC Storage M series, OS support

WS2012R2 and WS2016.

- The controller is qualified with NEC Storage T series, OS support

WS2012R2, WS2016 and RHEL7.3

N8190-166

Fibre Channel Controller (1ch)

N8190-163

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 25

Broadcom, LPe31000 16Gb/s, Optical, PCIe 3.0 x8

NOTE:

- The controller is qualified with NEC Storage M series.

- The controller is not qualified with NEC Storage T series

Fibre Channel Controller (2ch)

Broadcom, LPe31002 16Gb/s, Optical, PCIe 3.0 x8

NOTE:

- The controller is qualified with NEC Storage M series.

- The controller is not qualified with NEC Storage T series

N8190-164

Fibre Channel Controller (1ch)

Broadcom, LPe32000 32Gb/s, Optical, PCIe 3.0 x8

NOTE:

- The controller is qualified with NEC Storage M series.

- The controller is not qualified with NEC Storage T series

N8190-171

Fibre Channel Controller (2ch)

Broadcom, LPe32002 32Gb/s, Optical, PCIe 3.0 x8

NOTE:

- The controller is qualified with NEC Storage M series

- The controller is not qualified with NEC Storage T series

N8190-172

SAS

SAS Controller

12Gb/s SAS, ext. 8(SFF-8644 x2), PCIe 3.0 x8

NOTE:

- Support tape connection via Device Expansion Unit only

N8103-197

SAS Controller

LSI SAS9300-8e Host Bus Adapter

12Gb/s SAS, ext. 8(SFF-8644 x2), PCIe 3.0(x8)

NOTE:

- Support for connection to NEC Storage T series and M series and LTO.

- The controller is not qualified with Tape drive connection via Device

Expansion Unit.

- Please download the driver kit from Express5800 web site

- This controller is an factory installation option. Select N8103-184 for the

field upgrade use after shipment.

N8103-E184

NOTE:

 Please refer to the NEC Storage website for supported OS and device  For FC-SAN boot, please refer to “FC SAN Boot Configuration Guide”  For the cluster configuration, please refer to the Express Cluster website  Fibre Channel (FC) link speed varies by types and length of cables

7.5 GPU Computing Card

Product Name / Description

Part Number

GPU Computing Card

NVIDIA Tesla P4

N8105-51

NOTE:

 When installing N8105-51 GPU Computing Card, please select the following items.

- N8101-1285 High Performance CPU Heat sink Kit (In some CPU Processor kits, a high-performance CPU heat sink is attached as standard)

- N8181-157 High Performance Fan Kit (In some Base Models, High Performance Fans are attached as standard)

 When installing N8105-51 GPU Computing Card, please meet below items

- System memory under 1TB in total

- If you select RAID Controller, Low Profile Heat Sink type (N8103-192/-193/-194) is needed.

- Up to one N8105-51 GPU can be installed

- Operating under 35 degrees Celsius

- Optional drive cage is not supported

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 26

7.6 Serial Port Adapter

Product Name / Description

Part Number

Additional Serial Port Kit

Serial port Connector

N8117-09

NOTE:

 Up to one Serial Port Adapter can be installed.

7.7 ExpEther Board

It is connected to ExpEther I/O Expasion Unit(40G)

Product Name / Description

Part Number

ExpEther Board

PCIe 3.0(x8), 2x40G QSFP+ port

N8104-165

NOTE:

 Up to two ExpEther Board can be installed.  QSFP+ module is required.  It is supported to directly connect to ExpEther I/O Expansion Unit.  It is not factory installation option. Please contact your sales representative for further information.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 27

8 Other Add-in Components

8.1 Power Supply

Category

Product Name / Description

Part Number

1 PSU Required Up to 2 PSU

500W Hot Plug Power Supply

1 x 500 Watt 80 PLUS® Platinum

N8181-159

800W Platinum Hot Plug Power Supply

1 x 800 Watt 80 PLUS® Platinum

N8181-160

800W Titanium Hot Plug Power Supply

1 x 800 Watt 80 PLUS® Titanium

NOTE:

- Support 200 VAC inlet only

N8181-161

1600W Hot Plug Power Supply

1 x 1600 Watt 80 PLUS® Platinum

NOTE:

- Support 200 VAC inlet only

N8181-162

800W -48VDC Hot Plug Power Supply

1 x 800 Watt 80 PLUS® Platinum

NOTE:

- Support -48 VDC inlet only

- This is make-to-order product.

N8181-163

NOTE:

 Minimum one power supply kit must be installed.  The power units must be the same to configure redundancy.

Available Power Supplies

See the table below for available power supplies based on the number and type of processor, and the number and type of DIMMs.

Number of Processors

Type of Processor

Type of DIMMs

Number of DIMMs

GPU

Available Power

Supply

1CPU

Processor with 150 Watt or less

RDIMM Up to 6 No

500W, 800W, 1600W

Yes

800W, 1600W

7 or more

800W, 1600W

64GB LRDIMM

- - 800W, 1600W

128GB LRDIMM

- - 1600W

Processor with 160 Watt or more

RDIMM

- - 800W, 1600W

64GB LRDIMM

- - 800W, 1600W

128GB LRDIMM

- - 1600W

2CPU

Processor with between 85 Watt and 150 Watt

RDIMM

Up to16

Yes

800W, 1600W

17 or more No

800W, 1600W

Yes

1600W

64GB LRDIMM

Up to 10

Yes

800W, 1600W

11 to 17or more

Yes

1600W

Up to 18

800W, 1600W

19 or more

1600W

128GB LRDIMM

- - 1600W

Processor with 165 Watt or more

- - -

1600W

 128GB LRDIMM requires 1600W power supply.

Guideline of Maximum Power Consumption

See the following table for the guideline of the maximum power consumption based on the TDP and Input voltage. The actual maximum power consumption varies depend on the type of processor while the TDP of processor is the same.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 28

100VAC Input

CPU TDP

8x 2.5-inch

4x 3.5-inch

85 Watt

766W / 767VA

679W / 679VA

105 Watt

816W / 816VA

727W / 728VA

115 Watt

832W / 833VA

744W / 745VA

125 Watt

870W / 871VA

781W / 782VA

130 Watt

878W / 878VA

789W / 789VA

140 Watt

885W / 887VA

822W / 822VA

200VAC Input

CPU TDP

8x 2.5-inch

4x 3.5-inch

85 Watt

736W / 737VA

657W / 658VA

105 Watt

780W / 781VA

701W / 702VA

115 Watt

795W / 796VA

716W / 717VA

125 Watt

829W / 830VA

750W / 751VA

130 Watt

836W / 837VA

756W / 757VA

140 Watt

866W / 867VA

786W / 787VA

150 Watt

884W / 887VA

814W / 815VA

165 Watt

926W / 927VA

846W / 846VA

200 Watt

1012W / 1015VA

942W / 943VA

205 Watt

1012W / 1015VA

942W / 943VA

NOTE:

 This table shows maximum power consumption with 64GB LRDIMM.

8.2 High Performance CPU Heat Sink

Product Name / Description

Part Number

High Performance CPU Heat Sink Kit

Including two high performance CPU heat sink

N8101-1285

NOTE:

 The kit is required if you need to replace the standard CPU heat sink.

Type of CPU Heat Sink

The heat sink attached varies depending on the processor type.

CPU

Type of CPU Heat Sink

All CPU’s with a TPD of 130W or higher and the following specific models, Platinum 8156, Gold 6128 and Gold 5122

High Performance CPU Heatsink

Others

Standard CPU Heatsink

8.3 Fan Kit

Product Name / Description

Part Number

Redundant Fan Kit

5x Hot-plug redundant cooling fans

(Standard)

High Performance Fan Kit

7x Hot-plug redundant cooling fans

N8181-157

NOTE:

 High-performance fans are products that require arrangements for specific configurations.  The cable management arm is required if you want to replace a fan unit while the system is running

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 29

8.4 Front Panel Kit

Product Name / Description

Part Number

Status LED

LED indicator for power, system status and aggregate NIC activity

(Standard)

Status LED Panel Kit

Standard LED indicator plus LED indicator for CPU, Memory, Fan, Power supply, PCI Riser, individual NIC activity For 4x 3.5-inch drive model

N8117-07

Status LED Panel Kit

Standard LED indicator and LED indicator for CPU, Memory, Fan, Power supply, PCI Riser, and individual NIC activity For 8x 2.5-inch drive model

N8117-08

Front DisplayPort Kit

One DisplayPort connector and one USB connector For 4x3.5-inch model

N8117-05

NOTE:

 You can monitor the status of each part from BMC management console or NEC ESMPRO. Ordering the Status LED Panel Kit, you

can check the detailed status of devices directly.

8.5 Trusted Platform Module Kit

Product Name / Description

Part Number

Trusted Platform Module Kit

TPM 2.0 module

N8115-35

NOTE:

 The kit is not available in China.  The kit is not removable after attachment.  The kit supports only with Windows operating system configured with UEFI boot mode.  "Chipset-TPM" in BIOS setup menu must be activated prior to use of this product.  To use Windows BitLocker drive encryption, be sure to keep the "recovery password" of BitLocker function. The recovery password

is required to restore data for hardware replacement during a system error.

8.6 USB Memory Kit

Product Name / Description

Part Number

8GB USB Memory

Support boot VMware ESXi from USB memory

N8106-017

Dual 8GB microSD Kit(USB)

Including 2x 8GB microSD, USB dual microSD memory card reader, RAID1 Support

N8106-016

NOTE:

 The USB Memory Kit is installed in the system when you order it with the base model.  The kit does not include VMware ESXi installation media and license.  The USB Memory Kit cannot be installed, if M.2 SATA Solid State Drives are installed.  To use VMware vSAN, combination of vSAN certified hardware is required.  The USB Memory Kit cannot be installed if M.2 SATA Solid State Drives are installed.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 30

9 Factory Server Setting Service

9.1 Memory RAS Settings

If you need to change the BIOS settings for the memory RAS feature in the factory, select the appropriate configuration service.

Product Name / Description

Part Number

Memory Mirroring Mode Configuration Service

Setup option to change the Memory RAS of BIOS menu to Memory Mirroring Mode

NESV16-013

Memory Sparing Mode Configuration Service

Setup option to change the Memory RAS of BIOS menu to Memory Sparing Mode

NESV16-014

NOTE:

 It is an option only for factory setup  Single Rank Memory (N8102-708/-709) does not support Memory Mirroring Mode Configuration Service (NESV16-013)

RAID Configuration Service

If RAID configuration setup is NOT needed when a RAID controller is installed at the factory, select this option service.

Product Name / Description

Part Number

RAID Config Option(None)

Server setting option service without RAID configuration setup when a RAID controller is installed.

NESV16-039

10 Add-on Components

10.1 17-inch LCD Console Drawer

Category

Product Name / Description

Part Number

Drawer w/ KVM

Drawer

17-inch LCD Console Drawer (8port)

17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM switch, 1U height

N8143-106F

Cable

Switch Unit Connection Cable Set (USB, 1.8m)

1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A

K410-118(1A)

Switch Unit Connection Cable Set (USB, 3m)

3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A

K410-118(03)

Switch Unit Connection Cable Set (USB, 5m)

5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A

K410-118(05)

Drawer w/o KVM

Drawer

17inch LCD Console Unit 1U

17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height, 4-pin USB B to 4-pin USB A cable 2 m, PS/2 Y-splitter cable 2m, 15-pin mini D-sub VGA cable 2 m

N8143-105F

17inch LCD Console Drawer (1port)

17-inch LCD, US 103-keys Keyboard with 10-key, Touch pad with 3-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8 m, Two PS/2 cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m

N8143-108F

17.3inch LCD Console Drawer (1port)

17.3-inch wide Full HD LCD, US 103-keys Keyboard with 10-key, Touch pad with 2-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m, DVI-D cable 1.8m

N8143-122F

Keypad

Keyboard Unit (JP)

JP 108-keys Keyboard with 10-key for N8143-108F 17inch LCD Console Drawer (1port)

N8143-109

Keyboard Unit (UK)

UK 104-keys Keyboard with 10-key, for N8143-108F 17inch LCD Console Drawer (1port)

N8143-111

NOTE:

 There are two VGA connectors on R120h-1M, one on the front side and one on the rear side. However, the front side only works

when both are connected at the same time.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 31

10.2 KVM Switch

Category

Product Name / Description

Part Number

KVM Switch

Server Switch Unit (8 server)

1U USB 8 port KVM switch

N8191-14F

Cable

KVM

Switch Unit Connection Cable Set (USB, 1.8m)

1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A

K410-118(1A)

Switch Unit Connection Cable Set (USB, 3m)

3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A

K410-118(03)

Switch Unit Connection Cable Set (USB, 5m)

5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A

K410-118(05)

Cascading

Switch Unit Connection Cable 1.8 m

1.8 m, 1 x 15-pin mini D-sub - 1x 15-pin mini D-Sub / 2x PS/2

K410-119(1A)

10.3 Server Management License

Choose the following license kit to use additional remote management features

Product Name / Description

Part Number

License for Remote Management (Advanced)

License per server Remote console:

- Integrated Remote Console (IRC) with full functionality Remote media:

- Virtual media access via Integrated Remote Console (IRC)

- Scripted virtual media access System management:

- Global team collaboration for up to six consoles

- Integrated Remote Console (IRC) recording and playback

N8115-33

License for Remote Management (Scale-Out)

License per server Remote console:

- Text-based remote console via SSH

- Integrated Remote Console (IRC) under Pre-OS System management:

- Email alert

- Remote Syslog feature

- Virtual Serial Port recording and playback

N8115-34

NOTE:

 Remote management features are not available for virtual machines.

10.4 Dust Proof Filter Kit

Product Name / Description

Part Number

Dust Proof Filter Kit

Including the filter attachment kit and 10 sets of dust proof filters

N8147-32

NOTE:

 The Dust Proof Filter Kit is make-to-order products. Please consult your sales representative in regard to the production lead time.

10.5 Slide Rail Kit

Product Name / Description

Part Number

Tool-free Slide Rail Kit for 1U-2.5inch Server

For 8x 2.5-inch Drive Model

N8143-131

Tool-free Slide Rail Kit for 1U-3.5inch Server

For 4x 3.5-inch Drive Model

N8143-132

Slide Rail Kit for 1U-2.5" Server

For 8x 2.5-inch Drive Model

N8143-127

Slide Rail Kit for 1U-3.5" Server

For 4x 3.5-inch Drive Model

N8143-128

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 32

10.6 Cable Management Arm

Product Name / Description

Part Number

Cable Management Arm for 1U Server

NOTE:

The cable management arm is required if you want to replace a fan unit while the system is running.

N8143-125

10.7 Starter Pack DVD

The starter pack DVD includes the software and driver qualified by NEC. In order to obtain technical support from NEC, please be sure to install the software and drivers provided with the starter pack. The latest DVD image can be downloaded for free from NEC website during the warranty or maintenance contract period.

Product Name / Description

Part Number

Express5800/R120h-1M, R120h-2M Starter Pack

UL9020-B108

NOTE:

 By applying Starter Pack, Driver software qualified by NEC can be installed. To use servers, UL9020-B108 Starter Pack or Starter

Pack downloaded from Web site must be installed.

 Starter Pack may be updated without notice. The latest version of Start Pack is available in Web site. Starter Pack can be

downloaded within Warranty term.

 User Guide of this product is supplied as PDF file in NEC Web site.

10.8 Flash FDD

Choose the Flash FDD if you need to prepare an alternative device for a floppy drive.

Category

Product Name / Description

Part Number

External

Flash FDD

USB flash emulating USB floppy disk, Native capacity 1.44 MB

N8160-96

NOTE:

 Up to one drive can be connected.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 33

References

External Views

Front and Rear Views

Front View for 8x 2.5-inch Drive Model

Legend

2.5-inch Drive Bays

Health LED

Optional Drive Bay

LINK/ACT LED

Pull-out Tab

USB 3.0 Connector

Power On/standby button/LED

iLO Service Connector

UID button LED

Front View for 4x 3.5-inch Drive Model

Legend

3.5-inch Drive Bays

Health LED

Optional Drive Bay

LINK/ACT LED

Pull-out Tab

USB 3.0 Connector

Power On/standby button/LED

iLO Service Connector

UID button LED

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 34

Rear View

Legend

PCI Slots (Full-Height)

NIC ports 1-4(1Gb)

PCI Slots (Low-Profile)

Management Port

Power Supply

Serial Port Connector (optional)

AC Inlet

USB 3.0 Connectors

AC Power LED

UID LED

Power Supply (optional)

Flexible LOM (optional)

VGA Connector (optional)

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 35

Dimensions (mm)

8x 2.5-inch Drive Model

4x 3.5-inch Drive Model

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 36

General Supplementary Matters

HDD

 The Capacity of Hard disk drive is indicated in decimal not binary. 1GB＝1000^3B、1TB=1000^4B.

PCI expansion slot

 Transfer speed of PCI Express

 PCI Express (PCIe): 2.5Gb/s (simplex) per lane  PCI Express 2.0 (PCIe 2.0): 5Gb/s (simplex) per lane  PCI Express 3.0 (PCIe 3.0): 8Gb/s (simplex) per lane

Time display

 A system clock is affected by temperature conditions in storage. If high accuracy of the system clock is required, use of

NPT servers is recommended.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 37

Memory Supplementary Matters

Installation rule

 The number of memory which can be installed varies depending on number of installed CPUs.  This installation rule is defined to maximize performance efficiently in multiple cores and tasks operation.  Registered DIMM (RDIMM), Load Reduced DIMM (LRDIMM) can be installed up to 12 per 1CPU.  Mixing of RDIMM and LRDIMM is not allowed to be installed.

When installing DIMMs, higher capacity memory must be installed preferentially, if this rule is ignored, it may cause failures of DIMMs. This rule applies to the factory installation.

For dual CPU system, install DIMM to CPU1 firstly and then to CPU2 alternately. Memory population varies with number of installed DIMMs. In installation of 5, 7, 9 or 11 DIMMs per CPU, optimal performance might NOT be obtained. Other memory populations are recommended.

Single CPU system

Dual CPU system

1-3x DIMM(s) 4x DIMMs

5-7x DIMMs 8x DIMMs

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 38

9x DIMMs 10x DIMMs

11-12x DIMMs

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 39

Internal Drive Supplementary Matters

Conditions of internal drives in the default factory configuration

In the default factory configuration, there are some conditions of drive types and RAID levels that can be installed as below.

Common

 For the shipment with a RAID array, select the drives in the same capacity as many as needed.  In the default factory configuration, up to two types of Internal Drives can be installed in accordance with the following conditions

and restrictions.

Conditions for mixing Internal Drives in the default factory configuration

 Up to two types of Internal Drives can be installed in the default factory configuration.  M.2 SATA SSD can be installed at the factory regardless of mixing Internal Drives.  The type of Internal Drives is classified according to form factors (2.5”/3.5”), interfaces (SAS/SATA), devices (HDD/SSD), Data

transfer speeds, and rotational speeds. The current categories are below.

 3.5 inch SAS HDD, 12Gb/s, 7,200rpm  3.5 inch SATA HDD, 6Gb/s, 7,200rpm  2.5 inch SAS HDD, 12Gb/s, 10,000rpm  2.5 inch SAS HDD, 12Gb/s, 15,000rpm  2.5 inch SAS SSD, 12Gb/s  2.5 inch SATA HDD, 6Gb/s, 7,200rpm  2.5 inch SATA SSD, 6Gb/s

For example, 2.5 inch SATA HDD, 1TB, 7,200rpm 512n sector and 2.5 inch SATA HDD, 2TB, 7,200rpm 512n sector are regarded as the same type of Internal Drives.

Common restrictions of mixing Internal Drives in the default factory configuration

 Internal Drives with a different sector size cannot be mixed, even if they are the same type.

For example, a mixing of 2.5 inch SATA HDD, 1TB, 7,200rpm 512n sector and 2.5 inch SATA HDD, 2TB, 7,200rpm 512e sector is NOT supported in the default factory configuration.

 SSDs of different Endurance (ME, VE, RI) cannot be mixed, even if they are the same type.

For example, a mixing of 2.5 inch SATA SSD, 400GB, 6Gb/s VE (Value Endurance) and 2.5 inch SATA HDD, 800GB, 6Gb/s RI (Read Intensive) is NOT supported in the default factory configuration.

Mounting order of mixing Internal Drives in the default factory configuration

 In the default factory configuration, the drive mounting order is defined as below.  The Internal drives is installed in the order of Front Cage, Middle Cage, Rear Cage.

Order

2.5 inch Drives

Order

3.5 inch Drives

2.5 inch SAS HDD

3.5 inch SAS HDD

2.5 inch SAS SSD

3.5 inch SATA HDD

2.5 inch SATA HDD

2.5 inch SATA SSD

 The Internal drives are installed in the ascending order of a slot number, when the same type of the drives are selected, the drives

are installed according to the order below.

Order

Factors

Priority; high

Priority; middle

Priority; low

Drive capacity

Smaller

Bigger

Data transfer speed

6Gb/s

12Gb/s

Rotational speed

7,200rpm

10,000rpm

15,000rpm

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 40

RAID controller configuration

 RAID level 0, 1, 5, 6, 10 can be installed for the default factory configuration. Selectable RAID levels are depending

on the RAID controller.

 Capacity of Logical drive can be within 2TB with legacy boot mode, capacity of logical drive can be within the total

capacity of logical disks with UEFI boot mode.

 As the factory shipment, initial cache policy of RAID controllers is Write Through for N8103-189, Write back for

N8103-190/191/193/194.

RAID configuration for the default factory shipment

Available RAID level is determined by the RAID configurations and the number of drives as below.

RAID configuration for shipment

Number of Drives

Number of Drives in RAID levels

Non RAID

1～10

Non

Embedded RAID configuration (RAID 0/1/10)

RAID0(Single drive)

RAID1

2 in RAID1、1 for hot spare

4/6/8

4/6/8 in RAID10

5/7 9 (3.5inch model only)

4/6/8 in RAID10, 1 for a hot spare

10 (3.5inch model only)

8 in RAID10, 2 in RAID1

RAID controller configuration(RAID 0/1/10)

RAID0(Single drive)

RAID1

3 2 in RAID1, 1 for a hot spare

4/6/8

4/6/8 in RAID10

5/7

4/6 in RAID10, 1 for a hot spare

RAID controller configuration (RAID 0/1/5/6/10)

RAID0(Single drive)

RAID1

3-8

RAID5

9 8 in RAID 5, 1 in RAID0(Single drive)

8 in RAID 5, 2 in RAID 1

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 41

Conditions for mixing of Internal Drives after shipment

 RAID controller is required for mixing of Internal Drives  Mixed Internal Drives cannot be installed in the same RAID array.  When using hot spare disk for different RAID arrays which consist of various type of drives, assign “Dedicated Hot Spare” to each

RAID arrays with the same type of drive, to prevent from mixing different type of drives in a RAID array. “Global Hot Spare” cannot be used.

Mixing of different type of drives

Two types of drive can be installed in standard drive cage (8slots) and optional drive cage (8slots), in total, up to four types of drive using both cages. There is nine “type”, such as SAS HDD 10,000rpm(512n), SAS HDD 10,000rpm(512e), SAS HDD 15,000rpm(512n), SAS HDD 7,200rpm(512e), SATA HDD 7,200rpm(512n), SATA HDD 7,200rpm(512e), SATA SSD(ME/VE/RI).

See some examples as below.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 42

Server Management

The integrated server management controller provides superior remote control and system management features listed in the table below.

Standard

Remote

Management

License

(Scale-out)

Remote

Management

License

(Advanced)

Authentication with Active Directory and LDAP



Two-factor and Kerberos authentication



Virtual media access via Integrated Remote Console (IRC)



Scripted virtual media access



Integrated Remote Console (IRC)

Pre-OS Only



Global team collaboration for up to six consoles



Integrated Remote Console (IRC) recording and playback



Virtual Serial Port recording and playback



Text-based remote console via SSH



Email alert



Remote Syslog feature



Advanced power management (power history graph, power capping)



BMC federation management



BMC detection for BMC federation

  

Remote serial console (Virtual Serial Port)



Server Health Summary

  

Restart BMC form web-based management console

  

Redfish™API



Agentless Management



Server Health monitoring



Web-based GUI

  

Virtual power buttons

  

SSH / SMASH Command-Line Protocol (including serial console redirection)

  

IPMI / DCMI (including serial console redirection)

  

Supported PCI Cards and Installable Slots

Three PCI Slot Configuration

Part Number

Product Name

RAID

FLOM

SLOT1

SLOT2

SLOT3

NOTE

N8103-189

RAID Controller (RAID 0/1)

1 - - - - N8103-190

RAID Controller (2GB, RAID 0/1/5/6)

1 - - - -

Up to 1

N8103-191

RAID Controller (4GB, RAID 0/1/5/6)

1 - - - -

Up to 1

N8103-192

RAID Controller (RAID 0/1)

1 - - - -

N8103-193

RAID Controller (2GB, RAID 0/1/5/6)

1 - - - -

Up to 1

N8103-194

RAID Controller (4GB, RAID 0/1/5/6)

1 - - - -

Up to 1

N8103-195

RAID Controller (4GB, RAID 0/1)

- - 3 1 2 N8103-201

RAID Controller (2GB, RAID 0/1/5/6)

- - 3 1 2

Up to 1

N8103-196

RAID Controller (4GB, RAID 0/1/5/6)

- - 3 1 2

For external devices. Up to 1

N8103-197

SAS Controller

- - 3 1 2

For external devices

N8104-171

Quad Port 1000BASE-T LOM Card

- 1 - - -

N8104-172

Quad Port 1000BASE-T LOM Card

- 1 - - - N8104-173

Quad Port 10GBASE-T LOM Card

- 1 - - - N8104-175

Dual Port 10GBASE-T LOM Card

- 1 - - - N8104-176

Quad Port 10BASE SFP+ LOM Card

- 1 - - -

N8104-178

Dual Port 1000BASE-T Adapter

- - 3 1 2

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 43

N8104-179

Quad Port 1000BASE-T Adapter

- - 3 1 2

Network cables with RJ-45 plug covers cannot be used.

N8104-180

Dual Port 1000BASE-T Adapter

- - 3 1 2

Network cables with RJ-45 plug covers cannot be used.

N8104-181

Quad Port 1000BASE-T Adapter

- - 3 1 2

Network cables with RJ-45 plug covers cannot be used.

N8104-182

Dual Port 10GBASE-T Adapter

- - 3 1 2

N8104-183

Dual Port 10GBASE-T Adapter

- - 3 1 2 N8104-184

Dual Port 10GBASE-T Adapter

- - 3 1 2

N8104-185

Dual Port 10GBASE SFP+ Adapter

- - 3 1 2 N8104-186

Dual Port 10GBASE SFP+ Adapter

- - 3 1 2 N8104-187

Dual Port 10GBASE SFP28 Adapter

- - 3 1 2 N8105-51

GPU Computing Card

- - 1 3 2

Up to 1

N8190-165

Fibre Channel Controller (1ch)

- - 3 1 2

Can’t mix with

N8190-163/-164/-171/-172

N8190-166

Fibre Channel Controller (2ch)

- - 3 1 2

Can’t mix with

N8190-163/-164/-171/-172

N8190-171

Fibre Channel Controller (1ch)

- - 3 1 2

Can’t mix with N8190-165/-166

N8190-172

Fibre Channel Controller (2ch)

- - 3 1 2

Can’t mix with N8190-165/-166

N8190-163

Fibre Channel Controller (1ch)

- - 3 1 2

Can’t mix with N8190-165/-166

N8190-164

Fibre Channel Controller (2ch)

- - 3 1 2

Can’t mix with N8190-165/-166

N8103-184

SAS Controller

- - 3 1 2

Up to 3. Up to 2 for NEC Storage M series

Two PCI Slot Configuration

Part Number

Product Name

RAID

FLOM

SLOT1

SLOT3 N8103-189

RAID Controller (RAID 0/1)

1 - - -

N8103-190

RAID Controller (2GB, RAID 0/1/5/6)

1 - - -

N8103-191

RAID Controller (4GB, RAID 0/1/5/6)

1 - - -

N8103-192

RAID Controller (RAID 0/1)

1 - - -

N8103-193

RAID Controller (2GB, RAID 0/1/5/6)

1 - - -

N8103-194

RAID Controller (4GB, RAID 0/1/5/6)

1 - - -

N8103-195

RAID Controller (4GB, RAID 0/1)

- - 1 2

N8103-201

RAID Controller (2GB, RAID 0/1/5/6)

- - 1 2

N8103-196

RAID Controller (4GB, RAID 0/1/5/6)

- - 1 2

N8103-197

SAS Controller

- - 1 2

N8104-171

Quad Port 1000BASE-T LOM Card

- 1 - -

N8104-172

Quad Port 1000BASE-T LOM Card

- 1 - -

N8104-173

Quad Port 10GBASE-T LOM Card

- 1 - -

N8104-175

Dual Port 10GBASE-T LOM Card

- 1 - -

N8104-176

Quad Port 10BASE-SFP+ LOM Card

- 1 - -

N8104-178

Dual Port 1000BASE-T Adapter

- - 1 2

N8104-179

Quad Port 1000BASE-T Adapter

- - 1 2

N8104-180

Dual Port 1000BASE-T Adapter

- - 1 2

N8104-181

Quad Port 1000BASE-T Adapter

- - 1 2

N8104-182

Dual Port 10GBASE-T Adapter

- - 1 2

N8104-184

Dual Port 10GBASE-T Adapter

- - 1 2

N8104-185

Dual 10GBASE SFP+ Adapter

- - 1 2

N8104-186

Dual 10GBASE SFP+ Adapter

- - 1 2

N8104-187

Dual Port 10GBASE SFP28 Adapter

- - 1 2

N8105-51

GPU Computing Card

- - 1 2

N8190-165

Fibre Channel Controller (1ch)

- - 1 2

N8190-166

Fibre Channel Controller (2ch)

- - 1 2

N8190-171

Fibre Channel Controller (1ch)

- - 1 2

N8190-172

Fibre Channel Controller (2ch)

- - 1 2

N8190-163

Fibre Channel Controller (1ch)

- - 1 2

N8190-164

Fibre Channel Controller (2ch)

- - 1 2

N8103-184

SAS Controller

- - 1 2

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 44

OS Support Matrix for PCI Cards and Embedded Controllers

Part number

Product Name

WS 20

WS 2012 R2 RHEL

ESXi

6.5

ESXi

6.0

Embedded SATA non-RAID Controller

 

Embedded SATA RAID Controller



- - -

N8103-189

RAID Controller (RAID 0/1)



N8103-190

RAID Controller (2GB, RAID 0/1/5/6)



N8103-191

RAID Controller (4GB, RAID 0/1/5/6)





N8103-192

RAID Controller (RAID 0/1)



N8103-193

RAID Controller (2GB, RAID 0/1/5/6)



N8103-194

RAID Controller (4GB, RAID 0/1/5/6)





N8103-195

RAID Controller (4GB, RAID 0/1)

 

N8103-201

RAID Controller (2GB, RAID 0/1/5/6)



N8103-196

RAID Controller (4GB, RAID 0/1/5/6)



N8103-197

SAS Controller



-

N8103-184

SAS Controller







N8104-171

Quad Port 1000BASE-T LOM Card



N8104-172

Quad Port 1000BASE-T LOM Card

-

N8104-173

Quad Port 10GBASE-T LOM Card



N8104-175

Dual Port 10GBASE-T LOM Card



N8104-176

Quad Port 10BASE SFP+ LOM Card



N8104-177

Dual Port 25GBASE SFP28 LOM Card



-

N8104-178

Dual Port 1000BASE-T Adapter



N8104-179

Quad Port 1000BASE-T Adapter



N8104-180

Dual Port 1000BASE-T Adapter

- 

N8104-181

Quad Port 1000BASE-T Adapter

- 

N8104-182

Dual Port 10GBASE-T Adapter



N8104-183

Dual Port 10GBASE-T Adapter



N8104-184

Dual Port 10GBASE-T Adapter



N8104-185

Dual Port 10GBASE SFP+ Adapter



N8104-186

Dual Port 10GBASE SFP+ Adapter



N8104-187

Dual Port 10GBASE SFP28 Adapter



-

N8190-165

Fibre Channel Controller (1ch)





N8190-166

Fibre Channel Controller (2ch)





N8190-171

Fibre Channel Controller (1ch)





N8190-172

Fibre Channel Controller (2ch)





N8190-163

Fibre Channel Controller (1ch)



N8190-164

Fibre Channel Controller (2ch)



Supported Tape and Removal Disk Backup Drive List

See the following table for supported tape and removal disk backup drives. An optional tape drive enclosure is needed to connect the backup drives to the server.

Category

Product Name / Description

Part Number

LTO

Internal LTO (SAS)

LTO5, Half height, Native capacity 1.5 TB

N8151-141

Internal LTO (SAS)

LTO6, Half height, Native capacity 2.5 TB

N8151-142

Internal LTO (SAS)

LTO7, Half height, Native capacity 6 TB

N8151-143

RDX

Internal RDX (USB)

N8151-139

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 45

The information contained herein is subject to change without notice. Microsoft and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or

other countries Intel and Xeon are registered trademarks or trademarks of Intel Corporation or its subsidiaries in the United States and other

countries. Linux is a trademark of Linus Torvalds. Red Hat is a registered trademark of Red Hat, Inc. in the U.S. All other products, brands, or trade names used in this document are trademarks or registered trademarks of their respective holders. NEC shall not be liable for technical or editorial errors or omissions contained herein. For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less.

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 46

Revision History

Revision

Date

Description

7.0

July 12, 2018

New products added:

● 240GB Hot Plug 2.5-inch SATA SSD / N8150-1700

● 480GB Hot Plug 2.5-inch SATA SSD / N8150-1701

● 960GB Hot Plug 2.5-inch SATA SSD / N8150-1702

● 1.92TB Hot Plug 2.5-inch SATA SSD / N8150-1703

● 240GB Hot Plug 2.5-inch SATA SSD / N8150-1704

● 480GB Hot Plug 2.5-inch SATA SSD / N8150-1705

● 960GB Hot Plug 2.5-inch SATA SSD / N8150-1706

● 1.92TB Hot Plug 2.5-inch SATA SSD / N8150-1707

● 3.84TB Hot Plug 2.5-inch SATA SSD / N8150-1708

● 2.4TB Hot Plug 2.5-inch SAS HDD / N8150-591

● 12TB 7.2K Hot Plug 3.5-inch SATA HDD / N8150-587

● 12TB 7.2K Hot Plug 3.5-inch NLSAS HDD / N8150-589

● 240GB Non-Hot Plug M.2 SATA SSD / N8150-1709

● 480GB Non-Hot Plug M.2 SATA SSD / N8150-1710

● 8GB DDR4-2666 REG Memory Kit (1x8B/DR) / N8102-714

Discontinued products deleted:

● 240GB Hot Plug 2.5-inch SATA SSD / N8150-739

● 480GB Hot Plug 2.5-inch SATA SSD / N8150-740

● 960GB Hot Plug 2.5-inch SATA SSD / N8150-741

● 1.92TB Hot Plug 2.5-inch SATA SSD / N8150-742

● 240GB Hot Plug 2.5-inch SATA SSD / N8150-743

● 480GB Hot Plug 2.5-inch SATA SSD / N8150-744

● 960GB Hot Plug 2.5-inch SATA SSD / N8150-745

● 1.92TB Hot Plug 2.5-inch SATA SSD / N8150-746

● 3.84TB Hot Plug 2.5-inch SATA SSD / N8150-747

Correction of errors

6.0

April 27, 2018

New products / service added:

● 1TB 7.2K Hot Plug 2.5-inch SATA HDD / N8150-596

● 4TB 7.2K Hot Plug 3.5-inch SAS HDD / N8150-597

● SAS Controller / N8103-E184 (Factory Installation only)

● RAID Config Option(None) / NESV16-039

Discontinued products deleted:

● 150GB Non-hot-plug M.2 SATA SSD / N8150-778 (Replacement part number to be

released soon.)

Others:

● Enable to mix Internal devices in the default factory configuration

● Enable to use Internal DVD-ROM drive when the Embedded SATA Controller is used

Correction of errors

5.1

March 26, 2018

Others:

● N8103-184 connects to NEC Storage M series

● Some improvements in description

Correction of errors

5.0

January 25, 2018

Discontinued products deleted:

● 1TB 7.2K Hot Plug 2.5-inch SATA HDD / N8150-544 (Replacement part number to be

released soon.)

● 4TB 7.2K Hot Plug 3.5-inch SAS HDD / N8150-561 (Replacement part number to be

released soon.)

● 3TB 7.2K Hot Plug 3.5-inch SATA HDD / N8150-556 (No replacement planed)

● Quad Port 25GBASE QSPF28 Adapter / N8104-188

Others:

Correction of errors

4.0

December 22, 2017

New products added:

● 400GB Hot Plug 2.5-inch SAS SSD / N8150-748

● 800GB Hot Plug 2.5-inch SAS SSD / N8150-749

● 400GB Hot Plug 2.5-inch SAS SSD / N8150-750

● 800GB Hot Plug 2.5-inch SAS SSD / N8150-751

● 480GB Hot Plug 2.5-inch SAS SSD / N8150-752

● 960GB Hot Plug 2.5-inch SAS SSD / N8150-753

● Dual Port 25GBASE SFP28 Adapter / N8104-187

● Dual Port 25GBASE SFP+ LOM Card / N8104-177

● SFP28 Module(25G-SR) / N8104-190

● SAS Controller / N8103-184

Others:

SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-1M

NEC Corporation Revision 7.0 – July 2018 47

● Updated the table of the Available Power Supplies

● SAS Expander supported SATA drives

● Information in References is updated

3.0

November 22, 2017

New products added:

● Xeon Gold 6144 Processor Kit / N8101-1147, N8101-1148

● Xeon Gold 6146 Processor Kit / N8181-1149, N8101-1150

● 3.84TB Hot Plug 2.5-inch SATA SSD / N8150-747

● 240GB Hot Plug 2.5-inch SATA SSD / N8150-739

● Dual Port 10GBASE-T Adapter / N8104-183

● Dual Port 10GBASE-T Adapter / N8104-184

● Slide Rail Kit for 1U-2.5" Server / N8143-127

● Slide Rail Kit for 1U-3.5" Server / N8143-128

Others:

● Added the table of guideline of the maximum power consumption

● Added VMware ESXi 6.5 to the list of operating system supported

● Updated OS support matrix

.2.0

October 19, 2017

New products added:

● 4TB 7.2K Hot Plug 3.5-inchSAS HDD / N8150-561

● 8TB 7.2K Hot Plug 3.5-inchSAS HDD / N8150-562

● 10TB 7.2K Hot Plug 3.5-inchSAS HDD / N8150-563

● 150GB Non-hot-plug M.2 SATA SSD / N8150-778

● Fibre Channel Controller (1ch) / N8190-171

● Fibre Channel Controller (2ch) / N8190-172

Discontinued product deleted:

● 120GB Non-hot plug M.2 SATA SSD / N8150-754

Others:

● Updated the OS support matrix

● Updated Supported PCI Cards and Installable Slots matrix

● Added the table of maximum power consumption

1.1

September 15, 2017

Others:

● Added note when ordering M.2 SATA SSD

● Updated the table of available power supplies

● Corrected the type of processors with high performance heatsink as standard

1.0

August 29, 2017

Initial release

NEC Express5800, N8100-2557F, N8100-2561F, R120h-1M System Configuration Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
