DDS Tape Drive
User’s Guide
SDT-9000 Series
1997 Sony Corporation
This document contains proprietary
information which is protected by
copyright.
All rights reserved. No part of this
document may be photocopied,
reproduced or translated to another
language without prior written consent
of Sony.
The information contained in this
document is subject to change without
notice.
SONY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO
THIS DOCUMENT.
Sony shall not be liable for error
contained herein, indirect, special,
incidental or consequential damages in
connection with the furnishing,
performance or use of this document.
VORSICHT
Diese Ausrüstung erfüllt die
Europäischen EMC-Bestimmungen für
die Verwendung in folgender /
folgenden Umgebung(en):
• Wohngegenden
• Gewerbegebiete
• Leichtindustriegebiete
(Diese Ausrüstung erfüllt die
Bestimmungen der Norm EN55022,
Klasse B.)
Contents
Introduction .......................................4
Product Features........................4
Precautions ................................5
Installation .........................................6
SCSI Connection/Setting the
SCSI ID/Option Switches......6
Mounting Holes........................7
Remodeling from 5.25" Model
to 3.5" Model .........................9
Orientation...............................10
Operation .........................................11
Location of 3 LEDs ................. 11
LED Indication for
Drive Status .........................12
Drive Operation.......................13
Emergency Cassette Removal
Procedure .............................14
Interface Implementation.................16
Supported SCSI Messages ......16
Supported SCSI Commands....16
Specification ....................................17
Product Specifications.............17
Third Party Support Contacts
(In the USA) ...............................19
Sony Contacts .................................. 21
2
SDT-9000 DDS-3 Tape Drive
Conglatulation on your purchase of the Sony DDS-3 drive SDT-9000.
This drive is a high capacity data storage device using 4mm DAT (Digital
Audio Tape) technology. The SDT-9000 drive achieves high data
reliability through Read-After-Write, an additional level of Error
Correction Code, and other features.
The Sony SDT-9000 drive stores data on tape using a standard format
called DDS (Digital Data Storage), DDS-3, DDS-2, DDS-DC and DCLZ
formats. These formats are used by many other DDS tape drive
manufacturers, providing a broad range of compatible tape drives.
The Sony SDT-9000 is fully READ and WRITE compatible with the DDS3, DDS-2, DDS and DDS-DC format tapes.
3
Introduction
Product Features
SDT-9000
(With Data Compression)
Data Capacity
Transfer Rate
(sustained)
• Supported Formats: DDS-3, DDS-2, DDS, DDS-DC and DCLZ
• High Burst Transfer Rate- 5MB/sec Asynchronous
• Large 2MB Buffer
• 3.5" Standard Height, 5.25" Half Height
• Embedded SCSI Interface
• Supports Variable or Fixed Record Length
• Supports SCSI-2 Sequential-access Devices Command Set
• Read After Write (RAW)
• Frame Rewrite Function
• Three Levels of Error Correction Code (ECC)
• Quick Search (200 times normal Read/Write speed)
• Random Read
• N-Group Write Option
• Dual Partition Option
• SCSI Disconnection/Arbitration
24 GB (typical)*
2.4 MB/sec (typical)*
10MB/sec Synchronous
* Assuming 2:1 compression. Actual capacity and transfer rate may vary
since compression is depending upon data type.
4
Precautions
Installation
Avoid placing the drive in a location subject to:
– high humidity
– high temperature
– mechanical shock and vibration
– direct sunlight
Operation
* Do not move the drive while it is operating. Doing so may cause a
malfunction.
* Avoid exposing the drive to sudden changes from low to high in
temperature. This may cause water condensation to collect inside the
drive. If the ambient temperature should suddenly rise while the drive is
turned on, wait at least one hour before turning on the drive. If you
attempt to operate the drive immediately after a sudden increase in
temperature, a malfunction may occur.
* Do not turn off the drive while a tape is inside the drive.
Transportation
* Keep the original packing materials for possible future shipments of the
drive.
* Be sure to remove any tapes from drive prior to transportation. After
removing the drive from the computer, repack the drive into its original
packaging.
5
Installation
SCSI Connection/Setting the SCSI ID/Option Switches
Power Connector
2
3
4
GND
GND
5 V
SCSI ID
SCSI ID
210
0
1
2
3
4
5
6
7
12 V
1
.
T
P
D
R
SCSI 50 pin Connector
Jumpers
(Non-shielded)
Terminator Power
SCSI ID 2
SCSI ID 1
SCSI ID 0
RESERVED
DC DISABLE
SCSI PARITY
TERMINATOR ON
Ter m Power
Provided
Not
Provided
210
.
T
P
D
R
TERMINATOR POWER
Terminators
Disabled
Enabled
Note :
6
210
.
T
P
D
R
SCSI Parity
Enabled
Disabled
= CLOSED/Jumper
= OPEN/Jumper not installed
Don’t care
210
.
T
P
D
R
Terminators
Enabled
Disabled
210
.
T
P
D
R
Terminator OnSCSI ParityDC Disable
Mounting Holes
For 3.5" Standard Height (SDT-9000)
(0.20 in)
5±0.3mm
21±0.3mm
(0.83 in)
(3.70 in)
94±0.3mm
3.8±0.5mm
(0.15 in)
21±0.3mm
(0.83 in)
(0.20 in)
5±0.3mm
31±0.3mm
(1.22 in)
60±0.3mm
(2.36 in)
90±0.3mm
(3.54 in)
42±0.3mm
(1.65 in)
90±0.3mm
(3.54 in)
60±0.3mm
(2.36 in)
70±0.3mm
(2.76 in)
146±0.5mm
(5.75 in)
3-M3 (depth 3mm)
(depth 0.12 in)
6-M3 (depth 3mm)
(depth 0.12 in)
3-M3 (depth 3mm)
(4.00 in)
101.6±0.5mm
(depth 0.12 in)
(1.62 in)
41.2±0.5mm
7
For 5.25" Half Height (SDT-9000/R)
(
)
(5.87 in)
149±0.5mm
(0.86 in)
21.8±0.3mm
(5.50 in)
139.6±0.4mm
21.8±0.3mm
(0.39 in)
9.9±0.3mm
(3.70 in)
94±0.3mm
(0.86 in)
9.9±0.3mm
47.5±0.3mm
31±0.3mm
(1.22 in)
50.7±0.3mm
47.5±0.3mm
(0.39 in)
(1.87 in)
(2.00 in)
(1.87 in)
42±0.3mm
(1.65 in)
79.2±0.3mm
(3.12 in)
70±0.3mm
(2.76 in)
79.2±0.3mm
(3.12 in)
79.2±0.3mm
(3.12 in)
4-M3
6-M3 (depth 3mm)
(depth 0.12 in)
(5.75 in)
146±0.5mm
4-M3
4-M3
(1.62 in)
41.2±0.5mm
7±0.3mm
0.28 in
