MultiSync LCD1760VMTM
(L172EP) color monitor
2.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful: ”How to Identify and Resolve Radio-TV Interference Problems.“ This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.
1
LCD1760VM0527.p65 6/2/03, 11:21 AM1
Contents
Your new NEC MultiSync® LCD monitor box* should contain the following:
• MultiSync LCD1760VM™ monitor with tilt base
• Power Cord
• Video Signal Cable
• Audio Cable
• User’s Manual
• Cable Management Cover
Power Cord
Video Signal Cable
Audio Cable
MultiSync® LCD1760VM
User’s Manual
*Remember to save your original box and packing material to transport or ship the monitor.
LCD1760VM0527.p65 6/2/03, 11:21 AM2
TM
Cable Management Cover
2
Quick Start
To attach the MultiSync® LCD monitor to your system, follow these instructions:
1. Turn off the power to your computer.
2. Connect the audio cable to “AUDIO INPUT” on the back of the monitor and the other
end to the “Audio out” terminal of the computer (Figure A.1).
3. For the PC or MAC with DVI digital output: Connect the DVI signal cable to the connector of the display card in your system (Figure B.1). Tighten all screws.
For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable to the connector of the display card in your system (Figure B.2). Tighten all screws.
For the MAC: Connect the MultiSync Macintosh cable adapter to the computer, then attach the 15-pin mini D-SUB signal cable to the MultiSync Macintosh cable adapter (Figure C.1). Tighten all screws.
TM
NOTE: To obtain the MultiSync LCD1760VM
NEC-Mitsubishi Electronics Display of America, Inc. at (800) 632-4662.
4. Remove cable cover. Connect the 15-pin mini D-SUB of the video signal cable and DVI signal cable (not included) to the appropriate connector on the back of the monitor (Figure D.1).
5. Headphones may be connected to the “Headphones” output on the front of the monitor’s bezel marked “ sound from the speakers will be disabled. Headphones can be purchased from your local electronics store.
Connect one end of the power cord to the monitor and the other end to the power outlet.
6. Collect cables and keep them at backside of the stand (Figure D.2). And cover the cables by the optional Cable management Cover (Figure D.3). Please check Tilt, Rise and Lower monitor screen when you manage cables.
NOTE: If you use this monitor at AC125-240V, please refer to Recommended Use
section of this manual for proper selection of power cord.
7. The Vacation Switch on the right side of the monitor must be turned on (Figure F.1). Turn on the monitor with the Power Button and the computer.
NOTE:
8. Analog input only. No-touch Auto Adjust automatically adjusts the monitor to optimal
NOTE: For download information on the Windows
NOTE: If you have any problems, please refer to the Troubleshooting section of this
The Vacation Switch is a true on/off switch. If this switch is on the OFF position, the monitor cannot be turned on using the front button. DO NOT switch on/ off repeatedly.
settings upon initial setup for most timings. For further adjustments, use the following
®
controls:
OSM
• Auto Adjust Contrast
• Auto Adjust Refer to the Controls section of this User’s Manual for a full description of these OSM controls.
your MultiSync LCD Manual.
User’s Manual.
” (Figure E.1). While the headphones are connected, the
1760VM monitor, refer to the References section of this User’s
Macintosh cable adapter, call
®
95/98/Me/2000/XP INF file for
(not included)
LCD1760VM0527.p65 6/2/03, 11:21 AM3
3
Quick Start –continued
Figure A.1
LCD1760VM0527.p65 6/2/03, 11:21 AM4
Figure B.2
C.1
4
Quick Start –continued
Cable cover
Figure D.1
Input1 (D-Sub)
Input2 (DVI)
LCD1760VM0527.p65 6/2/03, 11:21 AM5
Figure D.2
Input1 (D-Sub)
Input2 (DVI)
Figure D.3
5
Quick Start –continued
vacation
switch
power button
Figure E.1
Raise and Lower Monitor Screen
The monitor may be raised or lowered. To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1).
NOTE: Handle with care when raising or lowering the monitor screen.
Figure F.1
Figure RL.1
Tilt and Swivel
Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel as desired
LCD1760VM0527.p65 6/2/03, 11:21 AM6
(Figure TS.1)
.
Figure TS.1
6
Quick Start –continued
Remove Monitor Stand for Mounting
Figure S.1
To prepare the monitor for alternate mounting purposes:
1. Disconnect all cables.
2. Place hands on each side of the monitor and lift
up to the highest position.
3. Place monitor face down on a non-abrasive surface (Figure S.1).
4. Remove the hinge cover (Figure R.1 and Figure R.2).
5. Remove the 4 screws connecting the monitor to the stand and lift off the
stand assembly (Figure R.3) the monitor is now ready for mounting in an alternate manner.
6. Connect the AC cord, signal cable and audio cable to the back of the
monitor (Figure R.4).
7. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.
Handle with care when removing stand.
Figure R.1
Figure R.2
Figure R.3
LCD1760VM0527.p65 6/2/03, 11:21 AM7
Figure R.4
7
Quick Start –continued
This LCD monitor is designed for use with a flexible arm. Please use the attached screws (4pcs) as shown in the picture when installing. To meet fhe safety requirements, the monitor must be mounted to an arm which
guaranties the necessary stability under consideration of the weight of the monitor.
The LCD monitor shall only be used with an approved arm (e.g. GS mark).
Specifications
4 Screws (4M)
(MAX depth: 8.5mm)
Replace Screws
100mm
If using other screws, check depth of hole.
Thickness of Bracket (Arm)
2.0~3.2mm
Tighten all screws.
100mm
LCD1760VM0527.p65 6/2/03, 11:21 AM8
Weight of LCD assembly: 4.7kg (MAX)
8
Controls
OSM® (On-Screen Manager) control buttons on the front of the monitor function as follows:
To access OSM menu, press any of the control buttons ( < , > , –, +,
EXIT
). To change signal input, press the SELECT button. NOTE: OSM must be closed in order to change signal input.
Menu
EXIT Exits the OSM controls.
< / > Moves the highlighted area left/right to select control menus.
/+
SELECT RESET/MUTE Resets the highlighted control menu to the factory setting. When no OSM
NOTE: When RESET is pressed in the main and sub-menu, a warning window allowing you to cancel the RESET function by pressing the EXIT button.
Exits to the OSM main menu.
Moves the highlighted area up/down to select one of the controls. Moves the bar left/right to increase or decrease the adjustment. Active Auto Adjust function. Enter the OSM controls. Enter the OSM sub menu.
menu is shown, the speaker sound will be muted.
will appear
Sound
Volume
Control the sound volume of speakers and headphone. To mute the speaker sound, press the MUTE key.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO
AUTO (Analog input only)
Adjusts the image displayed for non-standard video inputs.
Auto Adjust (Analog input only)
Automatically adjusts the Image Position and H. Size settings and Fine settings.
Image Controls (Analog input only)
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
H.SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
LCD1760VM0527.p65 6/2/03, 11:21 AM9
9
Controls –continued
AccuColor® Control Systems
AccuColor® Control Systems: Six color presets select the desired color setting (sRGB and NATIVE color presets are standard and cannot be changed). R,G,B: Increases or decreases Red, Green or Blue color depending upon which is selected. The change in color will appear on screen and the direction (increase or decrease) will be shown by the bars.
NATIVE: sRGB: sRGB mode dramatically improves the color fidelity in the desktop
environment by a single standard RGB color space. With this color supported environment, the operator could easily and confidently communicate color without further color management overhead in the most common situations.
Tools
LANGUAGE: OSM® control menus are available in seven languages. OSM Position: You can choose where you would like the OSM control
image to appear on your screen. Selecting OSM Location allows you to manually adjust the position of the OSM control menu left, right, down or up.
OSM TURN OFF: The OSM control menu will stay on as long as it is in use. In
the OSM Turn Off submenu, you can select how long the monitor waits after the last touch of a button to shut off the OSM control menu. The preset choices are 10, 20, 30, 45, 60 and 120 seconds.
OSM LOCK OUT: This control completely locks out access to all OSM control functions without Mute, Sound Volume, Brightness and Contrast. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked out. To activate the OSM Lock Out function, press SELECT, then “+” key and hold down simulta­neously. To de-activate the OSM Lock Out, press SELECT, then “+” key and hold down simultaneously.
RESOLUTION NOTIFIER: This optimal resolution is 1280 x 1024. If ON is selected, a message will appear on the screen after 30 seconds, notifying you that the resolution is not at 1280 x 1024.
HOT KEY: You can adjust the sound volume and brightness directly. When this function is set to ON, you can adjust the brightness with volume with + or - key, while the OSM menu is off.
OFF TIMER: Monitor will automatically power-down when the end user has selected a pre-determined amount of time.
Original color presented by the LCD panel that is unadjustable.
< or >
, sound
FACTORY PRESET: Selecting Factory Preset allows you to reset all OSM control settings back to the factory settings. The RESET button will need to be held
down for several seconds to take effect. Individual settings can be reset by highlighting the control to be reset and pressing the RESET button.
LCD1760VM0527.p65 6/2/03, 11:21 AM10
10
Controls –continued
Information
DISPLAY MODE: Indicates the current display resolution and frequency setting of the monitor.
MONITOR INFO.: Indicates the model and serial numbers of your monitor.
®
OSM
Warning: OSM Warning menus disappear with Exit button.
NO SIGNAL: This function gives a warning when there is no signal present. After power is turned on or when there is a change of input signal or video is inactive, the No Signal window will appear. RESOLUTION NOTIFIER: This function gives a warning of use with opti­mized resolution. After power is turned on or when there is a change of input signal or the video signal doesn’t have proper resolution, the Resolution Notifier window will open. This function can be disabled in the TOOL menu. OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After the power is turned on or there is a change of input signal or the video signal doesn’t have proper timing, the Out Of Range menu will appear.
LCD1760VM0527.p65 6/2/03, 11:21 AM11
11
Recommended Use
Safety Precautions and Maintenance
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE
FOLLOWING WHEN SETTING UP AND USING
THE MULTISYNC® LCD COLOR MONITOR:
DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or
removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.
Do not spill any liquids into the cabinet or use your monitor near water.
Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage
points, which can be harmful or fatal or may cause electric shock, fire or equipment failure.
Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.
Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall,
causing serious damage to the monitor.
When operating the MultiSync LCD monitor with its AC 125-240V power supply, use a power
supply cord that matches the power supply voltage of the AC power outlet being used. The power supply cord you use must have been approved by and comply with the safety standards of your country. (Type H05VV-F should be used in Europe)
In UK, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use
with this monitor. If a power cord is not supplied with this monitor, please contact your supplier.
Do not place any objects onto the monitor and do not use the monitor outdoors.
The inside of the flourescent tube located within the LCD monitor contains mercury.
Please follow the bylaws or rules of your municipality to dispose of the tube properly.
Immediately unplug your monitor from the wall outlet and refer servicing to qualified service personnel under the following conditions:
When the power supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the monitor.
If the monitor has been exposed to rain or water.
If the monitor has been dropped or the cabinet damaged.
If the monitor does not operate normally by following operating instructions.
Do not bend power cord.
Do not use monitor in high temperatured, humid, dusty, or oily areas.
• If glass is broken, handle with care.
Do not cover vent on monitor.
If monitor or glass is broken, do not come in contact with the liquid crystal and handle with care.
Allow adequate ventilation around the monitor so that heat can properly dissipate. Do
not block ventilated openings or place the monitor near a radiator or other heat sources. Do not put anything on top of monitor.
The power cable connector is the primary means of detaching the system from the
CAUTION
Image Persistence
Image persistence is when a residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be avoided.
To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.
NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
power supply. The monitor should be installed close to a power outlet which is easily accessible.
Handle with care when transporting. Save packaging for transporting.
12
LCD1760VM0527.p65 6/2/03, 11:21 AM12
Recommended Use –continued
CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR
CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE
FOLLOWING WHEN YOU POSITION THE MONITOR:
For optimum performance, allow 20 minutes for
warm-up.
Adjust the monitor height so that the top of the
screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.
Position your monitor no closer than 16 inches and no further away than 28 inches from your eyes. The optimal distance is 20 inches.
Rest your eyes periodically by focusing on an
object at least 20 feet away. Blink often.
Position the monitor at a 90° angle to windows and other light sources to
minimize glare and reflections. Adjust the monitor tilt so that ceiling lights do not reflect on your screen.
If reflected light makes it hard for you to see your screen, use an anti-glare filter.
Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid using
any cleaning solution or glass cleaner!
Adjust the monitor’s brightness and contrast controls to enhance readability.
Use a document holder placed close to the screen.
Position whatever you are looking at most of the time (the screen or
reference material) directly in front of you to minimize turning your head while you are typing.
Avoid displaying fixed patterns on the monitor for long periods of time to avoid
image persistence (after-image effects).
Get regular eye checkups.
Ergonomics
To realize the maximum ergonomics benefits, we recommend the following:
Use the preset Size and Position controls with standard signals
Use the preset Color Setting
Use non-interlaced signals with a vertical refresh rate between 60-75Hz
Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient contrast
For more detailed information on setting up a healthy work environment, write the American National Standard for Human Factors Engineering of Visual Display Terminal Workstations – ANSI-HFS Standard No. 100-1988 – The Human Factors Society, Inc. P.O. Box 1369, Santa Monica, California 90406.
LCD1760VM0527.p65 6/2/03, 11:21 AM13
13
Loading...
+ 33 hidden pages
