N8100-1478F/1479F/1480F
NEC Express5800/R140a-4
User's Guide
1st Edition
11-2008
ONL-510_001_03-R140a4-100-99-0810
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is the
valuable property of NEC Corporation (NEC) and /or its licensors. NEC and/or its licensors, as
appropriate, reserve all patent, copyright and other proprietary rights to this document, including all
design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are
expressly granted to others.
The NEC product(s) discussed in this document are warranted in accordance with the terms of the
Warranty Statement accompanying each product. However, actual performance of each such
product is dependent upon factors such as system configuration, customer data, and operator control.
Since implementation by customers of each product may vary, the suitability of specific product
configurations and applications must be determined by the customer and is not warranted by NEC.
To allow for design and specification improvements, the information in this document is subject to
change at any time, without notice. Reproduction of this document or portions thereof without prior
written approval of NEC is prohibited.
First Printing, November 2008
Copyright 2008
NEC Corporation
7-1 Shiba 5-Chome, Minato-Ku
Tokyo 108-8001, Japan
All Rights Reserved
Printed in Japan
Keep this User’s Guide at hand for quick reference at anytime necessary.
SAFETY INDICATIONS
Follow the instructions in this User’s Guide for your safety to use the server.
The server contains components with possible danger, hazards that may cause by ignoring warnings,
and preventive actions against such hazards.
Server components with possible danger are indicated with a warning label placed on or around them
as well as described in this User’s Guide.
In the User’s Guide or warning labels, "WARNING" or "CAUTION" is used to indicate a degree of
danger. These terms are defined as follows:
WARNING
CAUTION
Precautions and notices against hazards are presented with one of the following three symbols. The
individual symbols are defined as follows:
This symbol indicates the presence of a hazard.
An image in the symbol illustrates the hazard type. (Attention)
This symbol indicates prohibited actions. An image in the symbol illustrates a particular
prohibited action. (Prohibited Action)
This symbol indicates mandatory actions. An image in the symbol illustrates a
mandatory action to avoid a particular hazard. (Mandatory Action)
(Example)
Indicates the presence of a hazard that may result in death or serious
personal injury.
Indicates the presence of a hazard that may cause minor personal injury,
including burns, or property damage.
Symbol to draw attention
Term indicating a degree of danger
CAUTION
High temperature.
Immediately after the server is powered off, its internal components such as
hard disk drives are very hot. Leave the server until its internal components
fully cool down before installing/removing any component.
Symbol indicating a prohibited
action (may not always be
indicated)
Description of a danger
SYMBOLS USED IN THIS USER'S GUIDE AND WARNING LABELS
Attentions
Indicates that improper use may cause an electric shock.
Indicates that improper use may cause personal injury.
Indicates that improper use may cause fingers to be caught.
Indicates that improper use may cause the clip of a hand.
Indicates that improper use may cause fumes or fire.
Indicates a general notice or warning that cannot be specifically identified.
Indicates that improper use may cause loss of eyesight due to laser beam.
Prohibited Actions
Indicates a general prohibited action that cannot be specifically identified.
Do not disassemble, repair, or modify the server. Otherwise, an electric shock or fire
may be caused.
Mandatory Action
Unplug the power cord of the server. Otherwise, an electric shock or fire may be
caused.
Indicates a mandatory action that cannot be specifically identified. Make sure to follow
the instruction.
SAFETY INDICATIONS BY COLOR OF THE PARTS
Only green area is available for hot swap or hot plug operation. To avoid electric shock, disconnect
all AC cords before accessing to other parts especially blue area inside the system.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
CE Statement
Warning: This is a Class A product. In domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures (EN55022).
BSMI Statement
CLASS 1
LASER PRODUCT
This system is classified as a CLASS 1 LASER PRODUCT. This label
is located on the internal optical disk drive installed in your system.
Trademarks
NEC ESMPRO and NEC EXPRESSBUILDER are trademarks of NEC Corporation.
Microsoft, Windows, Windows Server, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in
the United States and other countries.
Intel, Pentium, and Xeon are registered trademarks of Intel Corporation.
PCI Express is a trademark of Peripheral Component Interconnect Special Interest Group.
Datalight is a registered trademark of Datalight, Inc.
ROM-DOS is a registered trademark of Datalight, Inc.
AT is a registered trademark of International Business Machines Corporation in the United States and other countries.
Adaptec and its logo is a registered trademark of Adaptec, Inc. of United States.
SCSISelect is a trademark of Adaptec, Inc. of the United States.
LSI and the LSI logo design are trademarks or registered trademarks of LSI Corporation.
Adobe, Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated.
DLT and DLTtape are trademarks of Quantum Corporation of the United States.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their
respective trademark owners.
Windows Server 2008 stands for Microsoft® Windows Server® 2008 Standard operating system and Microsoft® Windows
Server® 2008 Enterprise operating system. Windows Vista stands for Microsoft® Windows Vista® Business operating
system. Windows Server 2003 x64 Editions stands for Microsoft® Windows Server® 2003 R2, Standard x64 Edition
Operating system and Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition operating system, or Microsoft®
Windows Server® 2003, Standard x64 Edition operating system and Microsoft® Windows Server® 2003, Enterprise x64
Edition operating system. Windows Server 2003 stands for Microsoft® Windows Server® 2003 R2, Standard Edition
operating system and Microsoft® Windows Server® 2003 R2, Enterprise Edition operating system, or Microsoft® Windows
Server® 2003, Standard Edition operating system and Microsoft® Windows Server® 2003, Enterprise Edition operating
system. Windows XP x64 Edition stands for Microsoft® Windows® XP Professional x64 Edition operating system.
Windows XP stands for Microsoft® Windows® XP Home Edition operating system and Microsoft® Windows® XP
Professional operating system. Windows 2000 stands for Microsoft® Windows® 2000 Server operating system and
Microsoft® Windows® 2000 Advanced Server operating system, and Microsoft® Windows® 2000 Professional operating
system. Windows NT stands for Microsoft® Windows NT® Server network operating system version 3.51/4.0 and
Microsoft® Windows NT® Workstation operating system version 3.51/4.0. Windows Me stands for Microsoft® Windows®
Millennium Edition operating system. Windows 98 stands for Microsoft® Windows®98 operating system. Windows 95
stands for Microsoft® Windows®95 operating system. WinPE stands for Microsoft® Windows® Preinstallation
Environment.
Momentary voltage drop prevention:
This product may be affected by a momentary voltage drop caused by lightning. To prevent a
momentary voltage drop, an AC uninterruptible power supply (UPS) unit should be used.
Notes:
(1) No part of this manual may be reproduced in any form without the prior written permission of
NEC Corporation.
(2) The contents of this User's Guide may be revised without prior notice.
(3) The contents of this User’s Guide shall not be copied or altered without the prior written
permission of NEC Corporation.
(4) All efforts have been made to ensure the accuracy of all information in this User’s Guide. If
you notice any part unclear, incorrect, or omitted in this User’s Guide, contact the service
representative where you purchased this product.
(5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or
consequential damages arising from the use of this User’s Guide regardless of Item (4).
PREFACE
Welcome to the NEC Express5800/R140a-4 server.
The NEC Express5800 server holds powerful performance and employs the latest technology to
implement a computer for the next generation. With its potential capabilities, the server may be used
as the workstation PC that configures a client-server system and provides high-speed processing and
superior reliability.
Read this User’s Guide thoroughly to fully understand handling of the server and appreciate its
functions to the maximum extent.
i
ii
ABOUT THIS USER'S GUIDE
This User’s Guide is a guide for proper setup and use of the server.
This User’s Guide also covers useful procedures for dealing with difficulties and problems that may
arise during setup or operation of the server. Keep this manual for future use.
The following describes how to proceed with this User’s Guide.
How to Use This User's Guide
To aid you in finding information quickly, this User’s Guide contains the following information:
Chapter 1 Notes on Using Your Server
includes information that needs attention to use the server. Make sure to read this chapter
before setting up and using the server.
Chapter 2 General Description
includes information necessary to use the server, such as names and functions of its
components, handling of the floppy disk and optical disk drives. It also includes
requirements and advisory information for transfer and disposal of the server.
Chapter 3 Setting Up Your Server
tells you how to select a site, unpack the system, assemble the rack-mount subsystem,
make cable connections, and power on your system.
Chapter 4 Configuring Your Server
tells you how to configure the system and provides instructions for running the BIOS Setup
Utility and the RAID Configuration Utility, which is used to configure SAS devices in your
system. This chapter also provides information on base board and I/O riser board jumper
settings.
Chapter 5 Installing the Operating System with Express Setup
describes how to install the operating system.
Chapter 6 Installing and Using Utilities
describes how to install the utilities for the server. It also includes a description on using the
attached "NEC EXPRESSBUILDER" DVD.
Chapter 7 Maintenance
provides you with all the information necessary to maintain successful operation of the
server. This chapter also includes a description on relocating and storing the server.
Chapter 8 Troubleshooting
contains helpful information for solving problems that might occur with your system.
Chapter 9 Upgrading Your Server
provides you with instructions for upgrading your system with an additional processor,
optional memory, optional add-in cards, hard disk drives, peripheral devices, and power
supply.
Appendix A Specification
provides specifications for your server.
Appendix B Other Precautions
provides supplementary notes on using the server.
Appendix C IRQ and I/O Port Address
provides a list of factory-set IRQs and I/O port addresses assigned.
Appendix D Installing Windows Server 2008
describes how to install Microsoft Windows Server 2008 without using Express Setup. Using
the Express Setup tool is recommended for installing Windows Server 2008.
See Chapter 5 for details.
Appendix E Installing Windows Server 2003 x64 Editions
describes how to install Microsoft Windows Server 2003 x64 Editions without using Express
Setup. Using the Express Setup tool is recommended for installing Windows Server 2003
x64 Editions. See Chapter 5 for details.
Appendix F Installing Windows Server 2003
describes how to install Microsoft Windows Server 2003 without using Express Setup. Using
the Express Setup tool is recommended for installing Windows Server 2003. See Chapter 5
for details.
Appendix G Product Configuration Record Table
provides a table to be filled with your server configuration.
Text Conventions
iii
The following conventions are used throughout this User’s Guide. For safety symbols, see
"SAFETY INDICATIONS" provided earlier.
IMPORTANT:
NOTE:
Items that are mandatory or require attention when using the server.
Notes give important information about the material being described.
IN THE PACKAGE
The carton contains various accessories, as well as the server itself. See the packing list to make
sure that you have everything and that individual components are not damaged. If you find any
component missing or damaged, contact your service representative.
Store the provided accessories in a designated place for your convenience. You will need
them to install an optional device or troubleshoot the server, as well as to set it up.
Make a backup copy of each provided floppy disk, if any. Store the original disk as the
master disk in a designated place, and use its copy.
Improper use of any provided floppy disk or DVD-ROM may alter your system
environment. If you find anything unclear, immediately ask your service representative for
help.
iv
CONTENTS
Preface ..............................................................................................................................................i
About This User's Guide..................................................................................................................ii
In the Package................................................................................................................................ iii
Chapter 1 Notes on Using Your Server........................................................................ 1-1
Warning Labels ............................................................................................................................ 1-2
Safety Notes................................................................................................................................. 1-3
General .................................................................................................................................... 1-3
Notes on Installing and Accessing the Rack Cabinet............................................................... 1-5
Power Supply and Power Cord Use......................................................................................... 1-6
Installation, Relocation, Storage, and Connection................................................................... 1-7
Cleaning and Working with Internal Devices.......................................................................... 1-9
During Operation....................................................................................................................1-11
For Proper Operation ................................................................................................................. 1-12
Transfer to Third Party............................................................................................................... 1-14
Consumables.............................................................................................................................. 1-15
Disposal of the Server................................................................................................................ 1-15
User Support .............................................................................................................................. 1-17
Chapter 2 General Description ..................................................................................... 2-1
Overview...................................................................................................................................... 2-2
Top View ................................................................................................................................. 2-3
Front View ............................................................................................................................... 2-4
Front View (with Front Bezel Removed) ................................................................................ 2-5
Front View (Switches and LEDs)............................................................................................ 2-6
Rear View ................................................................................................................................ 2-7
Internal View ........................................................................................................................... 2-8
Base Board .............................................................................................................................. 2-9
Memory Board ...................................................................................................................... 2-10
I/O Riser Board ..................................................................................................................... 2-10
SAS Riser Board.................................................................................................................... 2-11
Standard Features....................................................................................................................... 2-12
Power Supplies ...................................................................................................................... 2-13
Peripheral Bays...................................................................................................................... 2-14
Memory Mirroring Feature.................................................................................................... 2-15
System Cooling ..................................................................................................................... 2-16
System Board Features .......................................................................................................... 2-16
Security.................................................................................................................................. 2-20
NEC EXPRESSBUILDER.................................................................................................... 2-21
NEC ESMPRO ......................................................................................................................2-22
Maintenance Tools................................................................................................................. 2-22
System Diagnostic Utility...................................................................................................... 2-22
NEC DianaScope................................................................................................................... 2-22
Using Your Server.......................................................................................................................2-23
Front Bezel.............................................................................................................................2-23
POWER/SLEEP Switch.........................................................................................................2-24
POST......................................................................................................................................2-26
Floppy Disk Drive..................................................................................................................2-31
Optical Disk Drive .................................................................................................................2-31
Chapter 3 Setting Up Your Server ................................................................................ 3-1
Setup Flow....................................................................................................................................3-2
Selecting a Site .............................................................................................................................3-3
Installing or Removing the Server into/from the Rack.............................................................3-6
Checking Components .............................................................................................................3-7
Required Tools .........................................................................................................................3-8
Installation Procedure...............................................................................................................3-8
Removal Procedure ................................................................................................................3-16
Connecting Peripheral Devices...................................................................................................3-18
Connecting Power Cord..............................................................................................................3-21
Turning On the Server ................................................................................................................3-23
Installing Operating System .......................................................................................................3-25
Installing Utilities .......................................................................................................................3-25
Making Backup Copies of System Information..........................................................................3-26
v
Chapter 4 Configuring Your Server.............................................................................. 4-1
System BIOS ~ SETUP ~ .............................................................................................................4-1
Starting SETUP Utility.............................................................................................................4-2
Description on On-Screen Items and Key Usage.....................................................................4-3
Configuration Examples...........................................................................................................4-4
Menu and Parameter Descriptions ...........................................................................................4-9
RAID System Configuration ......................................................................................................4-36
RAID......................................................................................................................................4-36
Features of Onboard RAID Controller (MegaRAID ROMB)................................................4-43
Before Using WebBIOS .........................................................................................................4-48
Using WebBIOS.....................................................................................................................4-50
Configuring Virtual Disk........................................................................................................4-63
Operation of Various Features ................................................................................................4-80
WebBIOS and Universal RAID Utility ..................................................................................4-90
Battery for Onboard RAID Controller (MegaRAID ROMB) ................................................4-93
Configuring Base Board Jumpers...............................................................................................4-94
Clearing CMOS Data .............................................................................................................4-95
Clearing Password..................................................................................................................4-95
vi
Chapter 5 Installing the Operating System with Express Setup ............................... 5-1
About Express Setup.................................................................................................................... 5-2
Windows Server 2003.................................................................................................................. 5-3
Notes on Windows Installation................................................................................................ 5-3
The Flow of Setup ................................................................................................................... 5-8
Installing the Windows Server 2003........................................................................................ 5-9
Installing and Setting Device Drivers.................................................................................... 5-19
Setting for Solving Problems................................................................................................. 5-29
Installing Maintenance Utilities............................................................................................. 5-41
Updating the System - Applying Service Pack -.................................................................... 5-41
Making Backup Copies of System Information .................................................................... 5-42
Installing with the OEM-FD for Mass Storage Device.......................................................... 5-43
Chapter 6 Installing and Using Utilities .......................................................................6-1
NEC EXPRESSBUILDER .......................................................................................................... 6-2
Autorun Menu ......................................................................................................................... 6-6
Parameter File Creator ................................................................................................................. 6-7
Parameter File.......................................................................................................................... 6-8
NEC ESMPRO .......................................................................................................................... 6-18
Functions and Features ..........................................................................................................6-18
NEC DianaScope ....................................................................................................................... 6-19
Universal RAID Utility.............................................................................................................. 6-20
Setup with Express Setup ...................................................................................................... 6-20
Manual Setup......................................................................................................................... 6-20
Using Universal RAID Utility via Network .......................................................................... 6-21
Chapter 7 Maintenance.................................................................................................. 7-1
Making Backup Copies................................................................................................................ 7-1
Cleaning....................................................................................................................................... 7-2
Cleaning the Server ................................................................................................................. 7-3
Cleaning the Interior................................................................................................................ 7-4
Cleaning the Keyboard/Mouse ................................................................................................ 7-5
Cleaning CD/DVD-ROM........................................................................................................ 7-6
Maintenance Tools ....................................................................................................................... 7-7
Starting Maintenance Tools ..................................................................................................... 7-7
Function of Maintenance Tools ............................................................................................... 7-9
Maintenance Tools with Remote Console ..............................................................................7-11
System Diagnostics.................................................................................................................... 7-13
Test Items .............................................................................................................................. 7-13
Startup and Exit of System Diagnostics ................................................................................ 7-13
Relocating/Storing the Server.................................................................................................... 7-16
vii
Chapter 8 Troubleshooting ........................................................................................... 8-1
System Viewers ............................................................................................................................8-2
LED ..............................................................................................................................................8-3
POWER/SLEEP LED ..............................................................................................................8-3
STATUS LED...........................................................................................................................8-4
DISK ACCESS LED................................................................................................................8-6
LAN ACCESS LED .................................................................................................................8-6
UID LED..................................................................................................................................8-7
Power Unit LED.......................................................................................................................8-8
Fan Error LED..........................................................................................................................8-9
Access LED............................................................................................................................8-10
Hard Disk Drive LED (DISK LED).......................................................................................8-11
LAN Connector LEDs............................................................................................................8-12
PCI Slot LEDs........................................................................................................................8-13
Error Messages ...........................................................................................................................8-14
Error Messages after Power-on..............................................................................................8-14
POST Error Messages ............................................................................................................8-15
Beep Codes.............................................................................................................................8-30
Error Messages on Virtual LCD.............................................................................................8-31
Solving Problems........................................................................................................................8-44
Problems with Server .............................................................................................................8-44
Problems with Windows.........................................................................................................8-54
Problems with NEC EXPRESSBUILDER ............................................................................8-61
Problems with Express Setup.................................................................................................8-62
Problems with Parameter File Creator ...................................................................................8-63
Error Message during RAID System Configuration ..............................................................8-64
Error Message for Battery for Onboard RAID Controller (MegaRAID ROMB)...................8-65
Problems with Windows Autorun Menu ................................................................................8-66
Collecting Event Log..................................................................................................................8-67
Collect Configuration Information .............................................................................................8-68
Collecting Dr. Watson Diagnostic Information...........................................................................8-69
Memory Dump ...........................................................................................................................8-69
Preparing for Memory Dumping............................................................................................8-69
Saving the Dump File.............................................................................................................8-70
Recovery for Windows Server 2003 x64 Editions and Windows Server 2003...........................8-70
Remote Management Feature.....................................................................................................8-71
Changing Setting for Management LAN ...............................................................................8-71
Resetting the Server....................................................................................................................8-72
Forced Shutdown........................................................................................................................8-73
viii
Chapter 9 Upgrading Your Server ................................................................................9-1
Safety Notes................................................................................................................................. 9-2
Anti-static Measures .................................................................................................................... 9-3
Preparing for Installation and Removal ....................................................................................... 9-4
Device Installation or Removal Procedure .................................................................................. 9-5
2.5-inch Hard Disk Drive ........................................................................................................9-5
Power Supply Unit .................................................................................................................9-11
Server ~ Pulling Out from the Rack Cabinet ~...................................................................... 9-13
Top Cover .............................................................................................................................. 9-15
5-inch Device ........................................................................................................................ 9-17
PCI Board.............................................................................................................................. 9-20
Memory Board ...................................................................................................................... 9-45
DIMM.................................................................................................................................... 9-49
Processor ............................................................................................................................... 9-60
Appendix A Specifications ........................................................................................... A-1
Appendix B Other Precautions .................................................................................... B-1
Transfer Rate of the On-board LAN Controller ......................................................................B-1
Server Management Software .................................................................................................B-1
Floppy Disk .............................................................................................................................B-1
Using a Client Machine Which Has a CD Drive.....................................................................B-2
CD/DVD-ROM .......................................................................................................................B-3
Tape Media ..............................................................................................................................B-4
Keyboard .................................................................................................................................B-5
Mouse ......................................................................................................................................B-6
Appendix C IRQ and I/O Port Address........................................................................ C-1
Appendix D Installing Windows Server 2008 ............................................................. D-1
Before Installing Windows Server 2008 ......................................................................................D-1
Optional Board Supported by NEC EXPRESSBUILDER......................................................D-1
Service Pack Which EXPRESSBUILDER Supports ..............................................................D-2
Installing Service Pack ............................................................................................................D-2
Updating System .....................................................................................................................D-2
Installing on the Mirrored Volume...........................................................................................D-2
MO Device ..............................................................................................................................D-2
Media such as DAT .................................................................................................................D-2
About the System Partition Size..............................................................................................D-3
Installing Windows Server 2008..................................................................................................D-5
Installation of Windows Server 2008 ......................................................................................D-6
Updating the System - Applying Service Pack -....................................................................D-16
ix
Driver Installation and Advanced Settings ................................................................................D-18
Setting for Receive Side Scaling...........................................................................................D-18
LAN Driver and PROSet.......................................................................................................D-18
Network Driver .....................................................................................................................D-20
Optional Network Board Driver (N8104-121/125)............................................................... D-20
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................D-21
Setting WOL .........................................................................................................................D-23
Graphics Accelerator Driver.................................................................................................. D-23
Installing Disk Array Controller Driver (N8103-90)............................................................. D-24
Installing RAID Controller Driver (N8103-115)...................................................................D-24
Installing SAS Controller Driver (N8103-104).....................................................................D-24
Installing SCSI Controller Driver (N8103-107).................................................................... D-24
Installing Fibre Channel Controller Driver (N8190-127/131)...............................................D-24
About Windows Activation ...................................................................................................D-25
Setting for Collecting Memory Dump (Debug Information).....................................................D-30
Appendix E Installing Windows Server 2003 x64 Editions........................................ E-1
Before Installing Windows Server 2003 x64 Editions................................................................. E-1
Optional Board Supported by NEC EXPRESSBUILDER...................................................... E-1
Service Pack Which EXPRESSBUILDER Supports .............................................................. E-2
Installing Service Pack ............................................................................................................ E-2
Updating System ..................................................................................................................... E-2
Re-installing to the Hard disk drive which has been upgraded to Dynamic Disk ...................E-2
MO Device.............................................................................................................................. E-2
Media such as DAT ................................................................................................................. E-2
About the System Partition Size.............................................................................................. E-3
Installing Windows Server 2003 x64 Editions............................................................................. E-4
Creating "Windows Server 2003 x64 Edition OEM-Disk for EXPRESSBUILDER" ............ E-5
Windows Server 2003 x64 Editions Clean Installation ........................................................... E-7
Updating the System - Applying Service Pack - ..................................................................... E-9
Driver Installation and Advanced Settings ................................................................................ E-15
Setting for Receive Side Scaling........................................................................................... E-15
PROSet.................................................................................................................................. E-16
Network Driver ..................................................................................................................... E-18
Optional Network Board Driver (N8104-121/125/126/123A).............................................. E-19
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................ E-20
Setting WOL ......................................................................................................................... E-22
Graphics Accelerator Driver.................................................................................................. E-23
Installing Disk Array Controller Driver (N8103-90)............................................................. E-23
Installing RAID Controller Driver (N8103-115)................................................................... E-23
Installing SAS Controller Driver (N8103-104)..................................................................... E-23
Installing SCSI Controller Driver (N8103-107).................................................................... E-23
About Windows Activation ................................................................................................... E-24
Setting for Collecting Memory Dump (Debug Information)..................................................... E-26
x
Appendix F Installing Windows Server 2003............................................................... F-1
Before Installing Windows Server 2003 ......................................................................................F-1
Optional Board Supported by NEC EXPRESSBUILDER...................................................... F-1
Service Pack Which EXPRESSBUILDER Supports .............................................................. F-2
Installing Service Pack ............................................................................................................F-2
Updating System ..................................................................................................................... F-2
Re-installing to the Hard Disk Drive which has been upgraded to Dynamic Disk.................. F-2
MO Device .............................................................................................................................. F-3
Media such as DAT ................................................................................................................. F-3
About the Upgrade to Windows Server 2003 R2 .................................................................... F-3
About the System Partition Size.............................................................................................. F-4
Installing Windows Server 2003..................................................................................................F-6
Creating "Windows Server 2003 OEM-Disk for EXPRESSBUILDER"..................................... F-7
Windows Server 2003 Clean Installation ................................................................................ F-9
Updating the System - Applying Service Pack -.................................................................... F-12
Driver Installation and Advanced Settings................................................................................. F-18
Setting for Receive Side Scaling ........................................................................................... F-18
PROSet .................................................................................................................................. F-19
Network Driver...................................................................................................................... F-21
Optional Network Board Driver (N8104-121/125/126/123A) .............................................. F-22
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................ F-23
Setting WOL.......................................................................................................................... F-25
Installing Disk Array Controller Driver (N8103-90) ............................................................. F-26
Installing RAID Controller Driver (N8103-115)................................................................... F-26
Installing SAS Controller Driver (N8103-104) ..................................................................... F-26
Installing SCSI Controller Driver (N8103-107) .................................................................... F-26
About Windows Activation ................................................................................................... F-27
Available Switch Options for Windows Server 2003 Boot.ini file........................................ F-29
Setting for Collecting Memory Dump (Debug Information) ..................................................... F-30
Appendix G Product Configuration Record Table..................................................... G-1
Hardware .................................................................................................................................G-1
Software...................................................................................................................................G-4
Chapter 1
Notes on Using Your Server
This chapter includes information necessary for proper and safe operation of your server.
1-2 Notes on Using Your Server
WARNING LABELS
The warning label is attached to components with possible danger or their vicinity in your server to
inform the user that a hazardous situation may arise when operating the server. (Do not intentionally
remove or damage any of the labels.)
If you find any labels totally/partially removed or illegible due to damage, contact your sales
representative.
Notes on Using Your Server 1-3
SAFETY NOTES
This section provides notes on using your server safely. Read this section carefully to ensure proper
and safe use of the server. For symbols, see "SAFETY INDICATIONS" provided earlier.
For part names described in the safety instruction chapter in this guide, refer to "Features and
Controls" in Chapter 2.
General
WARNING
Do not use the server for services where critical high availability may directly
affect human lives.
Your server is not intended to be used with or control facilities or devices
concerning human lives, including medical devices, nuclear facilities and
devices, aeronautics and space devices, transportation facilities and devices;
and facilities and devices requiring high reliability. NEC assumes no liability for
any accident resulting in personal injury, death, or property damage if the server
has been used in the above conditions.
Do not use the server if any smoke, odor, or noise is present.
If smoke, odor, or noise is present, immediately turn off the POWER/SLEEP
switch and disconnect the power plug from the outlet, then contact your service
representative. Using the server in such conditions may cause a fire.
Keep needles or metal objects away from the server.
Do not insert needles or metal objects into ventilation holes in the server or
openings in the floppy disk or optical disk drive. Doing so may cause an electric
shock.
Do not use the server in any unapproved place.
Install the server on a standard EIA 19-inch rack cabinet. Do not install the rack
containing the server in a place inappropriate to the rack installation
environment.
Failure to follow these instructions may cause some bad influences to be
imposed on your server and other systems installed on the rack and also a fire
or personal injury due to falling of the rack may occur. For the detailed
explanation on the place where your server should be installed and the
earthquake-resistant construction for the rack, refer to the manual attached to
the rack or contact your service representative.
Always install the server on a rack conforming to the relevant standard.
Install the server on a rack confirming to the EIA standard for the server to be
used. Do not use the server with installed on any other rack than standard EIA
19-inch rack or without the installation on a proper rack. Failure to follow these
instructions may cause your server to operate incorrectly and/or personal injury
or damages of surrounding devices to occur. Contact your service
representative for the racks available for your server.
1-4 Notes on Using Your Server
Keep water or foreign matter away from the server.
Do not let any form of liquid (water etc.) or foreign matter (e.g., pins or paper
clips) enter the server. Failure to follow this warning may cause an electric
shock, a fire, or a failure of the server. When such things accidentally enter the
server, immediately turn off the power and disconnect the power plug from the
outlet. Do not disassemble the server. Contact your service representative.
CAUTION
Notes on Using Your Server 1-5
Notes on Installing and Accessing the Rack Cabinet
CAUTION
Do not carry or install the rack cabinet only by a single person.
More than one person is required to carry or install the rack. Failure to follow this
instruction may cause the rack to fall to result in personal injury and/or breakages of
surrounding devices. In particular, a high rack (such as 44U rack) is unstable if it is
not fixed by stabilizers. More than one person must always carry or install the rack
while they support it.
Do not install the rack cabinet so that the load may be concentrated on a specific
point.
Install stabilizers on the rack so that the total load of the rack and devices mounted on
the rack is not concentrated on a singe point or join more than one rack with each
other to distribute the load. Failure to follow this instruction may cause the rack to fall
to result in personal injury.
Do not install components on the rack cabinet only by a single person.
More than one person is required to install parts including the doors and trays for the
rack. Failure to follow this instruction may cause some parts to fall to be broken
and/or to result in personal injury.
Do not pull out a device from the rack if the rack is unstable.
Always pull out a device from the rack in the state that the rack is made stable (by the
installation of stabilizers or earthquake-resistant construction).
Do not leave more than one device being pulled out from the rack.
Pulling out more than one device from the rack may cause the rack to be fallen. Only
pull out a single device from the rack at a time.
Do not provide the wiring for the server to exceed the rating of the power supply.
To prevent burns, fires, and device damages, the power supplied to the server shall
not exceed the rating load of the power branch circuit. The server requires at least
two power cords or up to four power cords (depends on your configuration). Connect
each power cord to each appropriate wall outlet provided with 20A branch circuit.
Contact your electric constructor or the local power company for the requirements on
the wiring and installation of electric facilities
Maintain reliable earthing
Reliable earthing of rack-mounted equipment should be maintained. Particular
attention should be given to supply connection other than direct connection to the
branch circuit (e.g. use of power strips).
.
1-6 Notes on Using Your Server
Power Supply and Power Cord Use
Do not hold the power plug with a wet hand.
Do not disconnect/connect the plug while your hands are wet. Failure to follow
this warning may cause an electric shock.
Plug in to a proper power source.
Use a grounded wall outlet of specified voltage. Use of an improper power
source may cause a fire or a power leak.
Do not install the server where you need an extension cord. Use of a cord that
does not meet the power specifications of your server may heat up the cord and
cause a fire.
Do not connect the power cord to an outlet that has an illegal number of
connections.
The electric current exceeding the rated flow overheats the outlet, which may
cause a fire.
Insert the power plug into the outlet as far as it goes.
Heat generation resulting from a halfway inserted power plug (imperfect contact)
may cause a fire. Heat will also be generated if condensation is formed on dusty
blades of the halfway inserted plug, increasing the possibility of fire.
Use the authorized power cord only.
Use only the power cord that comes with your server. Use of an unauthorized
power cord may cause a fire when the electric current exceeds the rated flow.
Also, observe the following to prevent an electric shock or fire caused by a
damaged cord.
Do not stretch the cord harness.
Do not pinch the power cord.
Do not bend the power cord.
Keep chemicals away from the power cord.
Do not twist the power cord.
Do not place any object on the power cord.
Do not bundle power cords.
Do not alter, modify, or repair the power cord.
Do not secure the power cord with staples or equivalents.
Do not use any damaged power cord. (Replace a damaged power cord with a
new one of the same specifications. Ask your service representative for
replacement.)
Do not use the attached power cord for any other devices or usage.
The power cord that comes with your server is designed aiming to connect with
this server and to use with the server, and its safety has been tested. Do not use
the attached power cord for any other purpose. Doing so may cause a fire or an
electric shock.
WARNING
CAUTION
Notes on Using Your Server 1-7
Installation, Relocation, Storage, and Connection
CAUTION
Never attempt to lift the server only by yourself.
Your server weighs 47 kg (depending on its hardware configuration). Carrying
the server only by yourself may strain your back. Hold the server firmly by its
bottom with at least three persons to carry it. Do not hold the front bezel to lift the
server. The front door may be disengaged from the server, causing personal
injury.
Do not install your server on a rack with leaving covers removed.
Do not install your server on a rack with the cover being removed. Failure to
follow this instruction may reduce the cooling effect in the server to result in
some malfunction and/or dusts to enter the server to result in a fire or electric
shock.
Do not pinch your finger with rails or other components.
Note sufficiently that your fingers may not be caught between a rail and another
mechanical part or cut by a rail at installation or removal of the server from the
rack. When pressing the safety latch release lever on the rack slide rail, use a
screwdriver or tools to press the release levers on the slide rail. Pressing the
levers with your finger may cause an injury.
Do not apply any load on the server pulled out from the rack.
Do not apply any load on the server pulled out from the rack. Doing so bends the
frame of the server. Consequently, the server cannot be pushed back into the
rack. Placing an object on the server may also cause personal injury if the server
drops.
Do not install the server in any place other than specified.
Do not install the server in the following places or any place other than specified
in this manual. Failure to follow this instruction may cause a fire.
a dusty place
a humid place such as near a boiler
a place exposed to direct sunlight
an unstable place
Do not use the equipment in the place where corrosive gases exist.
Make sure not to locate or use the server in the place where corrosive gases
(sulfur dioxide, hydrogen sulfide, nitrogen dioxide, chlorine, ammonia, ozone,
etc) exist.
Also, do not set it in the environment where the air (or dust) includes
components accelerating corrosion (ex. sulfur, sodium chloride) or conductive
metals. There is a risk of a fire due to corrosion and shorts of an internal printed
board.
1-8 Notes on Using Your Server
Do not connect any interface cable with the power cord of the server plugged to
a power source.
Make sure to power off the server and unplug the power cord from a power
outlet before installing/removing any optional internal device or
connecting/disconnecting any interface cable to/from the server. If the server is
off-powered but its power cord is plugged to a power source, touching an
internal device, cable, or connector may cause an electric shock or a fire
resulted from a short circuit.
Do not use any unauthorized interface cable.
Use only interface cables provided by NEC and locate a proper device and
connector before connecting a cable. Using an authorized cable or connecting a
cable to an improper destination may cause a short circuit, resulting in a fire.
Also, observe the following notes on using and connecting an interface cable.
Do not use any damaged cable connector.
Do not step on the cable.
Do not place any object on the cable.
Do not use the server with loose cable connections.
CAUTION
Cleaning and Working with Internal Devices
WARNING
Do not disassemble, repair, or alter the server.
Never attempt to disassemble, repair, or alter the server on any occasion other
than described in this manual. Failure to follow this instruction may cause an
electric shock or fire as well as malfunctions of the server.
Do not look into the optical disk drive.
A laser beam used in the optical disk drive is harmful to the eyes. Do not look
into or insert a mirror into the drive while the drive is powered. If a laser beam is
caught in your eyes, you may lose your eyesight (the laser beam is invisible).
Do not remove the lithium and NiMH (or Li-Ion) batteries.
Your server contains the lithium and NiMH (or Li-Ion) batteries. Do not remove
the battery. Danger of explosion if the battery is incorrectly replaced. Placing
the battery close to a fire or in the water may cause an explosion.
When the server does not operate appropriately due to the dead lithium and
NiMH (or Li-Ion) batteries, contact your service representative to replace only
with the same or equivalent type recommended by NEC. Do not disassemble
the server to replace or recharge the battery by yourself.
Disconnect all the power plugs before accessing inside the server, or
connecting the peripherals.
Notes on Using Your Server 1-9
The server has two power cords.
Make sure to power off the server and disconnect the all power plugs from a
power outlet before cleaning or installing/removing internal optional devices.
Touching any internal device of the server with its power cords connected to a
power source may cause an electric shock even of the server is off-powered.
Disconnect all the power plugs from the outlet occasionally and clean the plug
with a dry cloth. Heat will be generated if condensation is formed on a dusty
plug, which may cause a fire.
1-10 Notes on Using Your Server
Hot surface
Immediately after the server is powered off, its internal components such as
hard disk drives are very hot. Leave the server until its internal components fully
cool down before installing/removing any component.
Make sure to complete board installation.
Always install a board firmly. An incompletely installed board may cause a
contact failure, resulting in smoking or fire.
Protect the unused connectors with the protective cap.
The unused power supply cable connectors are covered with the protective cap
to prevent short circuits and electrical hazards. When removing the power
supply cable connector from the internal devices, attach the protective cap to the
connector. Failure to follow this warning may cause a fire or an electric shock.
Do not touch any electrical components inside the server during the hot-swap
replacement.
All power flows inside the server while the hot-swap replaceable components
(PCI add-in cards, hard disk drive, cooling fan, and power supply). Do not touch
the electrical components inside the server to avoid an electric shock.
CAUTION
During Operation
Avoid contact with the server during thunderstorms.
Disconnect all the power plugs from the outlet when a thunderstorm is
approaching. If it starts thundering before you disconnect the all power plugs, do
not touch any part of the server including the cables. Failure to follow this
warning may cause a fire or an electric shock.
Keep animals away from the server.
Failure to follow this warning may cause a fire or an electric shock.
Do not place any object on top of the server.
An object placed on top of the server may fall down, resulting in damage to your
property around the server.
Do not remove the cooling fans.
Notes on Using Your Server 1-11
CAUTION
Only an authorized NEC service technician can remove the cooling fans from
the server.
1-12 Notes on Using Your Server
FOR PROPER OPERATION
Observe the following notes for successful operation of the server. Use of the server ignoring the
notes will cause malfunctions or failures of the server.
Install the server in a place that meets requirements for successful operation. For details,
see Chapter 3, "Setting Up Your Server."
Make sure to power off the server before connecting or disconnecting cables between the
server and peripheral devices.
Verify that the access LED on the server is unlit before turning off the server or ejecting
the floppy disk.
The server management logic on your system board monitors and logs system voltage
changes. When plugging the power cord to the system, you may experience 30 seconds
delay from the time you press the POWER/SLEEP switch on the front panel. This is
normal system operation and is required by the server management logic.
When you have just turned off the DC power of the server, wait at least 30 seconds before
turning it back on.
When you have just turned off the AC power of the server, wait at least 60 seconds before
turning it back on.
Do not turn off the server until characters following the "NEC" logo appear on the screen.
The time until the characters appear depends on your system configuration.
Approximately, it may take one to five minutes.
Turn off the power and unplug the power cord from the outlet before relocating the server.
Some software includes a command to eject the optical disk drive tray. Make sure that the
front bezel is removed before running the command. Running this command with the
front bezel installed may cause the optical disk drive tray or the media to hit against the
front bezel, resulting in a failure of the server
Clean the server on a regular basis. (See Chapter 7 for cleaning.) Regular cleaning
proactively prevents various failures of the server.
Lightning may cause a momentary voltage drop. To prevent this problem, it is
recommended to use of an uninterruptible power supply unit.
Check and adjust the system clock before the operation if any of the following conditions
is applicable.
– After carriage of the server
– After storage of the server
– After the server is entered into the pause state under the environmental condition
enduring the server operation (temperature: 10°C - 35°C, humidity: 20% - 80%)
Check the system clock at the rough rate of once per month. When the system clock is
installed in a system requiring high time precision, it is recommended to use a time server
(NTP server).
If the system clock is remarkably delayed or advanced as the passage of time in spite of
adjustment, contact your sales agent to ask maintenance.
Notes on Using Your Server 1-13
Store the unit under the storage condition (temperature: -10°C - 55°C, humidity: 20% -
80%, without condensation) to allow built-in devices and the unit to operate correctly in
the next operation.
Make sure to use optional devices supported by the server. Some non-supported devices
may be physically installed/connected but cause failures of the server as well as a
malfunctions of the server.
NEC recommends you use NEC's genuine products. Some third-party products claim that
they support the server. However, repair of the server due to a failure or damage resulted
from use of such third-party products will be charged.
For the disk which does not conform to the CD or DVD standard, the playback of such a
disk with the DVD drive is not guaranteed.
Turn off the cellular phone or pager. Radio interference may cause malfunctions of the
server.
1-14 Notes on Using Your Server
TRANSFER TO THIRD PARTY
The following must be observed when you transfer (or sell) the server or software provided with the
server to a third party:
NEC Express server
Make sure to provide this manual along with the server to a third party.
IMPORTANT: About data on the hard disk drive
Be sure to take appropriate measures not to leak important data (e.g.,
customers' information or companies' management information) on the
removed hard disk drive to any third parties.
Data seems to be erased when you empty "Recycle Bin" of Windows or
execute the "format" command of the operating system. However, the
actual data remains written on the hard disk drive. Data not erased
completely may be restored by special software and used for
unexpected purposes.
It is strongly recommended that the software or service (both available
at stores) for data erasure should be used in order to avoid the trouble
explained above. For details on data erasure, ask your sales
representative.
Provided software
To transfer or sell any software application that comes with the server to a third party, the following
requirements must be satisfied:
All provided software applications must be transferred and no backup copies must be
retained.
Transfer requirements listed in "Software License Agreement" that comes with each
software application must be satisfied.
Software applications that are not approved for transfer must be uninstalled before
transferring the server.
Notes on Using Your Server 1-15
CONSUMABLES
Your server contains some components that are only good for a limited period of time and require
replacement, such as batteries, fans, the internal optical disk drive, the floppy disk drive, and the
mouse. For stable operation of the server, NEC recommends you replace these components on a
regular basis. Consult with your service representative for replacement or the product lives.
DISPOSAL OF THE SERVER
Dispose the server, all the internal devices, floppy disks, and DVD/CD-ROMs according to all
national laws and regulations. Also dispose of the power cord provided with the server to avoid
diversion to some other devices.
IMPORTANT: For disposal (or replacement) of the battery on the
base board of the server, consult with your service representative.
NOTE: If the real-time clock battery on the base board reaches its life,
the following message appeared on the display while running the POST.
Contact your service representative to replace the battery.
0250 System battery is dead –Replace and run SETUP
1-16 Notes on Using Your Server
Do not remove the lithium and NiMH (or Li-Ion) batteries.
Your server contains the lithium and NiMH (or Li-Ion) batteries. Do not remove
the battery. Danger of explosion if the battery is incorrectly replaced. Placing the
lithium, NiMH, or Li-Ion battery close to a fire or in the water may cause an
explosion.
When the server does not operate appropriately due to the failure of lithium and
NiMH (or Li-Ion) batteries, contact your service representative to replace only
with the same or equivalent type recommended by NEC. Do not disassemble the
server to replace or recharge the battery by yourself.
WARNING
Lithium battery
Base board
Onboard or optional RAID Controller (Disk Array Controller) also contains Ni-MH
or Li-Ion battery.
To dispose of the Ni-MH or Li-Ion battery, remove the RAID Controller (Disk
Array Controller), and then remove the battery from the board.
For battery location of optional RAID Controller (Disk Array Controller), refer to
the manual coming with the RAID Controller (Disk Array Controller).
Notes on Using Your Server 1-17
USER SUPPORT
When the server needs after-sales service, check if the warranty is still valid, and determine which
service is necessary as indicated on the "Certificate".
Before Asking for Repair, do the following when the server appears to fail:
1. Check if the power cord and the cables to other devices are properly connected.
2. See Chapter 8 to find if your problem fits the description. If it does, take the
recommended measure for it.
3. Check if the software required for operation of the server is properly installed.
4. Check the server using a computer virus detection program. Computer virus detection
programs are available for purchase in stores.
If the server still appears to fail after you have taken the above actions, consult with your service
representative immediately. Take notes on LED indications of the server and alarm indications on
the display unit before consultation, which may provide a significant help to your service
representative.
When Having Your Server Repaired
Prepare the following when having your server repaired:
Certificate
Notes of the messages displayed on the display unit
Error information*
Records of the NEC Express server and peripheral equipment
* Error information includes the Error Message shown in Chapter 8.
Prepare the error information only when required by your service representative.
1-18 Notes on Using Your Server
Advice for Health
The longer you keep using the computer equipment, the more you become
tired, which may cause disorders of your body. When you use a computer,
observe the following to keep yourself from getting tired:
Good Working Posture
You have good posture if the following are satisfied when you use a
computer:
• You sit on a chair with your back straight.
• Your hands are parallel with the floor when you put them on the
keyboard.
• You look at the screen slightly lower than your eye height.
You have "good working posture" as described in the above when no part
of your body is under excess strain, in other words when your muscles are
most relaxed.
You have "bad posture" when you sit with your back hunched up or you
operate a display unit with your face close to the screen. Bad working
posture may cause eye strain or poor eyesight.
Adjustment of Display Unit Angles
Most display units are designed for adjustment of the horizontal and
vertical angles. This adjustment is important to prevent the screen from
reflecting bright lights and to make the display contents easy to see. You
will not be able to keep "good working posture" and you will feel more tired
than you should if you operate a display unit without adjusting horizontal
and vertical angles.
Adjustment of Screen Brightness and Contrast
The display unit has brightness and contrast adjustment functions. The
most suitable brightness and contrast depend on the individual and the
working environment (well-lighted room or insufficient light). Adjust
brightness and contrast so that the screen will be easy to see. An
extremely bright or dark screen will give a bad effect to your eyes.
Adjustment of Keyboard Angle
The keyboard provided with the server is designed for adjustment of an
angle. Adjust the keyboard angle at which the keyboard is easy to operate.
The adjustment assists in reducing strain on your shoulders, arms, and
fingers.
Cleaning of Equipment
Clean equipment regularly. It is difficult to see the display contents on a
dusty screen. Keeping equipment clean is also important for your sight.
Fatigue and Rest
If you feel tired, you should stop working and do light exercises.
Chapter 2
General Description
This chapter provides information that you should be familiar with before using the server. It
includes names and functions of the components and features of the server.
2-2 General Description
OVERVIEW
Your server is a highly reliable, high-powered, fault-tolerant, high-capacity, multiprocessing server
based on the Intel® Xeon® Processor 7400 series or Intel® Xeon® Processor 7300 series. It is a
solid performer and offers the latest technology. The combination of compute performance, memory
capacity, and integrated I/O provides a high performance environment for many server market
applications. These range from large corporations supporting remote offices to small companies
looking to obtain basic connectivity capability such as file and print services, e-mail, web access,
web site server, etc.
Your server is housed and available as a rack-mount system. Your server conveniently installs into a
standard EIA 19-inch rack cabinet.
Your server includes an optical disk drive, a 2.5-inch hard disk drive bay, and removable media
device bay (Option). The 2.5-inch hard disk drive bay can contain up to eight hard disk drives.
As application requirements increase, you can expand your server with an additional processor,
additional memory, add-in boards and peripheral devices: tape devices, DVD-ROM, and hard disk
drives.
Top View
General Description 2-3
1
1 Top cover
Open the top cover to install or remove optional memory boards, DIMMs, PCI boards, and fans.
2-4 General Description
Front View
3456 78
21
1 Key hole
Insert the security key to lock/unlock the front bezel
2 Front bezel
Open the front bezel when you access to the POWER/SLEEP switch or optical disk drive, or
install (or remove) 5.25-inch device (option), USB floppy disk drive, hard disk drive, processor,
memory board, and DIMM.
3 DISK access lamp
4 LAN1/2 access lamp
5 LAN3/4 access lamp
6STATUS lamp
7 POWER/SLEEP lamp
8 UID (Unit ID) lamp
ID
1
2
General Description 2-5
Front View (with Front Bezel Removed)
See Chapter 8 for detail information on LED indication.
11-1 1-2 1-3 2345
89
667-0 7-1 7-2 7-3 7-4 7-5 7-6 7-7
1 Optical disk drive
The optical disk drive reads data from the inserted CD/DVD-ROM.
1-1: Access LED (lit orange during accessing)
1-2: CD/DVD tray eject button
1-3: Emergency hole
2 5-inch device bay
Install a 5-inch device into this slot.
3 Monitor connector (only for maintenance use)
Do not connect any display unit. This connector is exclusively used for maintenance.
4 DUMP switch
Press this switch to collect a memory dump if memory dump feature is enabled on operating
system (see Chapter 8).
5 Front USB1 (top) / Front USB2 (middle) / Front USB3 (bottom) connectors
Connect a device supporting US 2.0 (Hi-speed) interface.
6 Front fan box
7 2.5-inch device bay
Install a 2.5-inch hard disk drive. The last digit represents a slot number.
8 DISK Access LED
9 DISK Error LED
2-6 General Description
Front View (Switches and LEDs)
See Chapter 8 for detail information on LED indication.
2
3456 7
12
1
ID
ID
8
9
1 RESET switch
Press this switch to reset the server.
2 DISK Access LED
3 LAN1/2 access LED
4 LAN3/4 access LED
5STATUS LED
6 POWER/SLEEP LED
7 UID (Unit ID) LED
8 UID (Unit ID) switch
Use this switch to turn on or off the ID LED located on the front and rear panels of the server.
Pressing this switch once turns on the UID LED, and pressing again turns off.
9 POWER/SLEEP switch
Use this switch to power on/off the server. If you press the switch once, then the
POWER/SLEEP LED goes on and the power is turned on. If you press the switch again, the
power is turned off. The system is forcibly shut down when the power switch is pressed
continuously for four seconds or longer.
When the sleep feature is enabled, pressing this switch once places the server in sleep (power
saving) mode. Pressing this switch again resumes the normal state (supported in Windows
Server 2003).
Rear View
See Chapter 8 for detail information on LED indication.
General Description 2-7
1
15
14
13
11-1 11-2 11-3
12-1
1 PCI Express slot (#1 to #7 from left)
Slots 1 and 2: Hot-plug PCI Express (x8)
Slots 3 and 4: Non-hot-plug PCI Express (x8)
Slots 5, 6, and 7: Non-hot-plug PCI Express (x4) (Can contain x8 board.)
2 Keyboard connector
Used to connect with the optional keyboard.
3 Mouse connector
Used to connect with the optional mouse.
4 Management LAN port
Upper LED: LINK/ACT LED Lower LED: 100/10 LED
5 LAN connector
Used to connect with a network system on LAN. The last digit represents the port number.
Enabling [Shared BMC LAN] in BIOS SETUP allows port 3 to be used for management LAN as
well as the standard LAN. However, the network performance may be reduced because the
data of both LANs must be transmitted or received (see Chapter 4).
6 1000/100/10 LED
7 UID (Unit ID) LED
8 UID (Unit ID) switch
9 AC inlet
Used to connect with the power cord of the server. To use 200 to 240 VAC power, setting must
be changed.
10 LINK/ACT LED
11 Power supply unit LED
12 Power supply unit
The power supply unit supplies DC powers to the server. The last digit represents slot number.
13 Serial port B connector
The serial port B connector is connected with a device having the serial interface.
The server cannot directly be connected to a leased line through the connector.
14 Monitor connector
Used to connect with the display unit.
15 Rear USB1 (top), Rear USB2 (bottom) connectors
Used to connect with devices accepting the USB 2.0 interface (Hi-speed).
9
12-2
2345-4 5-3
11-1 11-2 11-3
10
5-1
6
5-2
7
8
9
2-8 General Description
Internal View
2
3
1
4 5 3
2
1 5-inch device bay
2 Memory board
3 Rear fan bay
4 Non-hot-plug PCI slot
5 Hot-plug PCI slot
Base Board
General Description 2-9
1-2 1-1 2-B 2-A
11
16-1
16-2
16-3
15
14
13
12
11
1-4 1-3 2-C 10 2-D 98
1 Rear fan connector
The last digit represents port number.
2 Memory board connector
The last digit represents port number.
3 Front panel connector
4 Power BP interface connector
5 Power connector
6 Processor socket
The last digit represents port number.
7 SAS riser connector
8 SATA connector
9 Internal USB connector
10 Lithium battery
11 Connectors for external devices
12 I/O riser connector
13 Jumper switch for clearing password
14 Jumper switch for clearing CMOS
15 Internal serial port A
16 PCI Express board slot (PCI #1 to #7 from top)
16-1: PCI #1 and #2 (Hot-plug PCI Express x8)
16-2: PCI #3 and #4 (Non-hot-plug PCI Express x8)
16-3: PCI #5, #6, and #7 (Non-hot-plug PCI Express x4)
3
4
5
6-1
6-2
6-3
6-4
7
2-10 General Description
Memory Board
1 DIMM slot (The last digit represents slot number.)
1-8
1-7
1-6
1-5
1-4
1-3
1-2
1-1
I/O Riser Board
1
2
3
4
5
1 Mouse connector
2 Keyboard connector
3 Management LAN connector
4 LAN connector #4
5 LAN connector #3
6 Baseboard interface connector
6
SAS Riser Board
General Description 2-11
FRONT
4
REAR
1
5
2
3
1 SAS port A
2 SAS port B
3 DIMM connector for RAID
4 RAID activation key
5 Ni-MH or Li-Ion battery for RAID
2-12 General Description
STANDARD FEATURES
High performance Expandability
Intel
High-speed memory access
High-speed 1000BASE-T/100BASE-TX/
High-reliability Self-diagnosis
Memory mirroring feature
Online sparing memory feature
Memory monitoring feature (error
Memory chipkill feature supported
Memory/processor degradation feature
Bus parity error detection
Thermal sensor
Error notification
Internal cooling fan monitoring feature
Internal voltage monitoring feature
BIOS password feature
Security feature (security lock)
Redundant power supply (for 200 to 240
RAID system (Onboard RAID Controller)
® Xeon® Processor 7400/7300 series
– N8100-1478F: E7310 (Clock speed:
1.6GHz, Secondary cache: 2x2MB)
– N8100-1479F: E7420 (Clock speed:
2.13GHz, Secondary cache: 2x3MB,
Third level cache: 8MB)
– N8100-1480F: X7460 (Clock speed:
2.66GHz, Secondary cache: 3x3MB,
Third level cache: 16MB)
(Supports DDRII 667 FB DIMM -compliant
interleaved memory)
10BASE-T interface (4 ports)
(1000Mbps/100Mbps/10Mbps supported)
correction/error detection)
(logical isolation of a failed device)
VAC power or partially for 100 to 120 VAC)
Wide variety of optional I/O slots
4 PCI Express (x8) slots
(2 slots support hot-plug)
3 PCI Express (x4) slot
(x8 board can be installed)
Large memory of up to 128 GB
2.5-inch hard disk drive bay holds 8 hard
disk drives
Remote power-on feature
Up to four multi-processors are available
for upgrade.
USB 2.0 interface
Backup device bay
Many Available Features
El Torito Bootable CD-ROM (no
emulation mode) format support
POWER switch mask
Software power-off
Remote power-on feature
AC-LINK feature
Intelligent Platform Management
Interface (IPMI) feature
Baseboard Management Controller
(BMC)
Remote console feature
Power On Self-Test (POST)
Test and Diagnosis (T&D)
Maintenance Features
Off-line Maintenance Utility
Memory dump feature using the DUMP
switch
Power Saving Feature
Sleep feature (available for Windows
Server)
Easy and Fine Setup
NEC EXPRESSBUILDER (system setup
utility)
Express Setup
SETUP (BIOS setup utility)
RAID Configuration Utility
Management Utilities
NEC ESMPRO
NEC DianaScope
Remote Management Feature
General Description 2-13
Power Supplies
If your server is operated with 200 to 240 VAC power by using an optional AC cable or with 100
VAC in specific power configuration, the server can continue its operation without interruption even
if a single power supply unit fails (power redundant configuration).
In addition, if the AC power of each power supply unit is divided into two lines, the server can
continue its operation without power interruption even if either of AC power line fails (AC power
redundant configuration).
Maximum configuration that supports redundant feature at 100 VAC
N8100-1478F NEC Express5800/R140a-4 (Intel® Xeon® Processor E7310 Model)
N8101-422 CPU Kit (XMPQ/1.60G (2x2)), 3 sets
N8102-298 Additional 4GB Memory Module set, 3 sets
N8100-1479F NEC Express5800/R140a-4 (Intel® Xeon® Processor E7420 Model)
N8101-423 CPU Kit (XMPQ/2.13G (8)), 3 sets
N8102-298 Additional 4GB Memory Module set, 3 sets
*1 No restriction is imposed except for processor and DIMM.
*2 N8100-1480F does not support this feature.
If the power cord is disconnected from the power supply unit immediately after it is connected, the
event "power degraded" may not be registered in OS event log, and only the event "power
recovered" is registered.
*1, *2
:
IMPORTANT: The AC power cord provided with the server accepts
100 VAC only. Do not use the cord with 200-VAC power. To use the
server with 200 VAC, connect an optional AC cable that can accept 200
VA C .
Redundant Power Configuration
Your server is configured with the 100 VAC non-redundant power supply system at the factory.
To use your server with the redundant power system (100 VAC or 200 VAC), update the Platform
Information Area (PIA) and Sensor Data Record (SDR) in the server firmware.
Download the latest PIA/SDR from the following WEB site.
http://www.nec.co.jp/express/index.html
For updating the server firmware, read README.TXT in the downloaded file.
2-14 General Description
Peripheral Bays
The server is equipped with one slot to install a backup device such as a magnetic tape drive.
Available Devices
The 5-inch device slot can contain a single-height SCSI device.
Setting of SCSI ID
When connecting the 5-inch device with the optional SCSI controller, refer to the manual
that comes with the SCSI controller.
– Setting of terminator
Set the terminator to "OFF".
General Description 2-15
Memory Mirroring Feature
Memory Mirroring Feature
The memory mirroring feature places a memory board as spare memory in standby state. If the
current memory board encounters an uncorrectable error, the memory mirroring feature switches to
the standby memory board. When this feature is used, the current memory board and the standby
memory board should be combined. Available combinations are:
Mirroring with a pair of memory boards A and B and a pair of memory boards C and D
To enable the memory mirroring feature, the combined memory boards must have the DIMMs of
same size and capacities.
Setting BIOS
Start SETUP and select [Advanced] → [Memory Configuration] → [Memory RAS Feature] in
order and set as follows:
To enable the memory mirroring feature: Select [Mirror].
Others
Memory capacity displayed on the OS = total capacity of physically installed memory –
capacity for standby memory
Memory mirroring feature: 1/2 of actually installed memory capacity
Enabling the memory mirroring feature does not influence the operations of applications.
The each feature is automatically disabled when an error message is displayed:
The following indicates that the memory mirroring feature has worked:
a) The failing DIMM group is degraded when the server restarts.
b) If NEC ESMPRO Agent has been installed, the following log is registered as a system
log of Event Viewer:
Source name: ESMCommonService
Event ID: 2313
Explanation: Part of the DIMM was isolated due to a memory error.
Memory number: XX
Date/time: XX
c) If report setting is made through NEC ESMPRO Agent, Manager reporting and
ALIVE reporting is performed. The report contents are as follows:
Explanation: Part of the DIMM was isolated due to a memory error.
Memory number: XX
Date/time: XX
2-16 General Description
System Cooling
The chassis top cover must be installed for proper system cooling. Cooling components must be
hot-swapped within two minutes. This time period applies only to the time that the cooling
component is physically removed, not from the time of failure.
The cooling subsystem consists of hot-swap, redundant (7+1) fans. In a redundant configuration, the
system supports one fault at a time, either one fan fault or one power supply fault, and it supports
hot swapping one component at a time. If a cooling component fails, the system cooling is
maintained and the system continues to operate while the component is hot swapped.
System Board Features
The following subsections describe the system board major components.
Processor
The processor board accommodates one to four Intel® Xeon® Processor 7300/7200 series in the
FC-PGA2 package.
DIMM Memory
To install or remove the DIMM, remove the memory board first. One memory board is factoryinstalled in the server. Up to four memory boards (128GB at the maximum) can be installed in the
server.
Install the DIMM (Dual Inline Memory Module) to the DIMM socket on the memory board in the
server. DIMMs are installed in the ascending order of DIMM socket numbers in the unit of two
modules.
Onboard Video
The baseboard incorporates a Pilot II graphics accelerator with 16MB of video SDRAM.
General Description 2-17
LSI MegaRAID SAS PCI EXPRESS ROMB
The SAS riser card includes the LSI MegaRAID SAS PCI EXPRESS ROMB (called "On
Board RAID (MegaRAID ROMB)" hereafter) The On Board RAID (MegaRAID ROMB) supports
the following features:
Dual-channel SAS interface (CH0 and CH1)
Connect the HDD cage to CH0 and CH1.
RAID levels 0, 1, 5, 6, 10, and 50
512MB of cache memory
Battery-backup cache memory (option)
Network Interface Controllers
NOTE:
To ensure EMC product regulation compliance, the system
must be used with shielded LAN cables.
The base board includes Intel 82563EB Physical Layer Transceiver (PHY), and I/O riser card
includes Intel 82575EB Network Interface Controller (NIC). The both chips support the following
features:
Two channels of 10Base-T, 100Base-TX, and 1000BASE-T networks.
The both chips provide standard IEEE 802.3 Ethernet Interface for 1000Base-T, 100Base-
TX, and 10Base-T (802.3, 802.3u, 802.3ab).
2-18 General Description
Remote Management
The server may be monitored and managed via LAN/WAN by using EXPRESSSCOPE Engine 2
and NEC DianaScope utility stored in NEC EXPRESSBUILDER DVD.
The EXPRESSSCOPE Engine 2 uses BMC (Baseboard Management Controller) as a system
management LSI.
The EXPRESSSCOPE Engine 2 provides the following features:
Monitoring of power supply unit
Monitoring of temperature, voltage, fans, and electric power status
Generation of SEL (system event log) at occurrence of hardware failure
Monitoring of the system management watchdog timer
Monitoring of the periodic SMI timer
Remote management by using Web browser (e.g., resetting the server, power on/off,
viewing System Event Log (SEL))
Remote KVM and remote device features (A separately priced remote management
license is required.)
Remote management via LAN/WAN by using NEC DianaScope and centralized
management of several systems
For more information about remote management using Web browser, remote KVM feature, and
remote device feature, refer to the "EXPRESSSCOPE Engine 2 User's Guide" stored in NEC
EXPRESSBUILDER DVD.
NOTE: The measured value of temperature, voltage, fan, or electric
power may contain an error. Depending on operating environment, an
error may be several tens percent.
General Description 2-19
Degradation Feature
The degradation feature automatically isolates a failed DIMM, processor, or cooling fans to assure
continuous operation of the server when the POST (Power On Self-Test, self-diagnosis program
after power on) detects such a DIMM, processor, or cooling fans.
Failed DIMMs, processors, and cooling fan may be identified on the screen that the POST displays,
or with the BIOS setup utility, "SETUP." They may also be identified on the system that has the
NEC ESMPRO installed.
Remote Power-On Feature (Wake On LAN/PME)
The remote power-on function turns on the server through a network. It sends a special packet from
the management computer to a remote server to turn it on if the server is off-powered.
To enable this feature, you must select "Enabled" for "Wake On LAN/PME" in the Advanced
Chipset Control of the Advanced menu of the BIOS setup utility, "SETUP." (See Chapter 4.)
The remote power-on feature is not available in the following cases. Press the POWER/SLEEP
switch once to start the OS, and turn off the server in an appropriate procedure.
Abnormal previous system shut-down
No power supply to the server (due to turned-off breaker, disconnected power cord, power
blackout, etc.)
NOTE: Wake On LAN feature is supported in 100BASE-
TX/1000BASE-T adapter on the base board and I/O riser board.
AC-LINK Feature
When the power cord of the server is connected to an uninterruptible power supply (UPS) unit, the
server supports the power linkage feature that enables control over the power supply from the UPS
to the server. AC-LINK feature can be enabled or disabled with "AC-LINK" in the Server menu of
the BIOS setup utility, "SETUP." (See Chapter 4.)
2-20 General Description
Security
To help prevent unauthorized entry or use of the system, the system includes a full lockable front
panel and Server Management software that monitors the system intrusion switches.
Security with Mechanical Locks and Monitoring
The front bezel of the server contains a mechanical lock to prevent access to the front of the
computer chassis.
The computer chassis includes an intrusion switch for the top cover. When this cover is opened, the
switch transmits an alarm signal to the system board, where server management software processes
the signal.
Software Locks via the System Setup Utility
The BIOS SETUP Utility provides a number of security features to prevent unauthorized or
accidental access to the system. Once the security measures are enabled, access to the system is
allowed only after the user enters the correct password(s). For example:
Enable the keyboard lockout timer so that the server requires a password to reactivate the
keyboard and mouse after a specified time-out period – 1 to 120 minutes.
Set and enable an administrative password.
Set and enable a user password
Set secure mode to prevent keyboard or mouse input and to prevent use of the front panel
reset, power and sleep switches.
Activate a hot-key combination to enter secure mode quickly.
Disable writing to the floppy disk drive when secure mode is set.
General Description 2-21
NEC EXPRESSBUILDER
The NEC EXPRESSBUILDER helps you install the Operating system/the Management software or
use the maintenance utilities.
Refer to Chapter 6 for details.
The functions of the NEC EXPRESSBUILDER are:
To install the Operating System.
"Express Setup" helps you install the Windows. (See Chapter 5.)
To diagnose the system.
NEC EXPRESSBUILDER includes the Test and diagnostics to check your server. (See
Chapter 6.)
To create the drivers disks*.
Use this function to create the OEM-Disk which uses at the Windows manual installation.
(See Chapter 6.)
To update the BIOS.
Use this function to update the system BIOS or firmware of the server. (See Chapter 6.)
To update the Windows System*.
"Update the system" in Autorun Menu updates the several resources of the Windows. (See
Chapter 6.)
To install the applications*.
You can install the several applications for Windows from Autorun Menu. (See Chapter
6.)
To read the documents*
You can refer to the documents from Autorun Menu. (See Chapter 6.)
* These functions are available under Windows system.
2-22 General Description
NEC ESMPRO
The NEC ESMPRO is server management software that runs on the OS. The NEC ESMPRO
includes the NEC ESMPRO Manager for the server monitoring terminal and the NEC ESMPRO
Agent for the NEC Express server.
NOTE: For details of major functions of the NEC ESMPRO, system
configuration and setups with the NEC ESMPRO, see Chapter 6.
Available functions of the NEC ESMPRO depend on the OS you install.
Ask your service representative for details.
Maintenance Tools
The Maintenance Tools is used for maintenance and fault analysis of the server. This tool is usually
used by the service representative.
See Chapter 7 for details.
System Diagnostic Utility
The system diagnostic utility contained in the NEC EXPRESSBUILDER is useful to detect the
hardware failures. See Chapter 7 for details.
NEC DianaScope
The NEC DianaScope is a software for the remote management of the server.
The NEC DianaScope can control the managed server even if OS is not running on the managed
server.
See Chapter 6 and online document in the NEC EXPRESSBUILDER.
General Description 2-23
USING YOUR SERVER
This section describes basic operations of your server including how to use devices such as the
optical disk drive. See Appendix B for notes on using DVD/CD-ROM, and accessories including
the keyboard and the mouse.
Front Bezel
Remove the front bezel to power on/off the server, to access optical disk drive, and to install/remove
hard disk drives to the 2.5-inch hard disk drive bay.
IMPORTANT: To open the front bezel, you must unlock the door
with the provided security key.
Installing or Removing the Front Bezel
When turning the power of the server on/off, accessing to the optical disk drive, or installing or
removing a hard disk drive on or from the 2.5-inch hard disk drive bay, or removing the top cover,
first remove the front bezel.
IMPORTANT: The front bezel can be opened only when you unlock
it by using the attached security key.
1. Insert the attached security key into the key slot and turn the key to the front bezel side
with it pressed lightly to release the lock.
2. Hold the right end of the front bezel lightly to pull it toward you.
3. Slide the front bezel to the left a little to remove the tab from the frame and then remove
the front bezel from the server.
Tabs
2
1
Frame
Unlock Lock
To install the front bezel, latch the tab at the left side of the front bezel on the server frame.
After the installation, lock the front bezel by using the key for security.
2-24 General Description
POWER/SLEEP Switch
Use the POWER/SLEEP switch to turn on/off the server.
Power On
Press the POWER/SLEEP switch on the front of the computer chassis.
The POWER/SLEEP LED lights in green.
POWER/SLEEP LED
POWER/SLEEP switch
IMPORTANT:
If the power cord is connected to a power control device such as a
UPS (Uninterruptive Power Supply), make sure that the power
control device is powered.
If the power cord is connected to the server, an initial diagnosis of
the hardware starts. The POWER/SLEEP switch does not work
while in diagnosis. Wait for about 30 seconds, then press the
POWER/SLEEP switch.
Do not turn off the server until characters following the "NEC" logo
appear on the screen. The time until the characters appear depends
on your system configuration. Approximately, it may take three to
five minutes.
General Description 2-25
Sleep
The POWER/SLEEP switch allows you to save almost all power of the server (power-saving mode
or sleep mode).
NOTE: To use the SLEEP switch, an OS supporting the sleep feature
is required. (Available in Windows Server 2003)
POWER/SLEEP LED
POWER/SLEEP switch
Provide setting for power saving on operating system, then press the POWER/SLEEP switch on the
front of the server to place the server in the power-saving mode. (The POWER/SLEEP LED blinks.)
In the power-saving mode, the server retains the memory data and the status of the previous
operations.
To resume the original state, press the POWER/SLEEP switch. (It may take a little time to resume
the original state.)
NOTE: The operational level in the power-saving mode depends on
the OS in use. (Available in Windows Server 2003.)
IMPORTANT: Do not change system configuration while turning into
the power-saving mode or in the power-saving mode. Otherwise, you
may fail to resume the original state.
2-26 General Description
POST
POST (Power On Self-Test) is the self-diagnosis feature saved in the base board of the server.
When the power of the server is turned on, POST automatically runs to check the base board, I/O
riser board, memory board, processor, keyboard, and mouse. During POST messages indicating the
starts of several BIOS setup utilities may also appear.
At the shipment of the server, it is set to have the NEC logo appear on the display unit during POST.
Pressing Esc allows the information on the execution of POST to be displayed.
NOTE: The information on the result of diagnosis by POST can be
displayed from the start without the depression of Esc on the BIOS
Setup menu. If you desire it, change the setting of "Boot-time Diagnosis
Screen" on "Advanced" of the BIOS SETUP to "Enabled".
It may not always necessary to check the result of POST. Check the messages which may appear
during POST in the following cases:
Installation of the server
Suspicion of failure
Beep for many times in the period from power-on to OS start
Appearance of an error message on the display unit
General Description 2-27
POST Flow
The flow of operations executed by POST is sequentially described below:
IMPORTANT: Depending on the system configuration, message
"Press Any Key" requesting key entry may appear on the display screen.
This is requested by BIOS on an installed optional board. See the
explanation described in the manual for the option and press any key.
1. After power-on, POST is activated to start the memory check. The message indicating the
counted size of the base memory and that of the additional memory appears at the upper
left corner of the display screen. In addition, the following message appears at the bottom
of the screen.
Press <F2> to enter SETUP or <F12> Network
NOTE: If you change the factory-default for [Extended RAM Step] in
[Advanced] menu of BIOS SETUP and execute the memory test,
pressing Space allows the memory test to be skipped.
It may take several minutes to complete the memory check depending on the size of the
memory installed in the server. Similarly, it may take about a minute to display the proper
information on the screen at rebooting.
2. If your server has some option boards such as RAID Controller installed, POST displays
the message prompting the start of the BIOS setup utility for the option board.
Refer to the manual that comes with the option board for details.
When you press Ctrl and any other key at the same time to start the setup utility of the
option board, the subsequent key entry may sometime fails (e.g., key entry is not accepted
or incorrectly recognized). In the case, press Ctrl again to recover.
3. POST displays SCSI ID numbers used by the connected SCSI devices on the screen.
4. POST detects the Onboard RAID Controller and displays the message prompting the start
of the WebBIOS (without any key entry for several seconds, POST is automatically
continued). Press the proper keys according to the screen display.
LSI MegaRAID SAS-MFI BIOS Version XXXX (Build MMM DD, YYYY)
Copyright (c) 2007 LSI Logic Corporation
HA -X (Bus X Dev X) MegaRAID SAS PCI Express(TM) ROMB
FW package: X.X.X-XXXX
X Logical Drive(s) found on the host adapter.
X Logical Drive(s) handled by BIOS
Press <Ctrl> <H> for WebBIOS
Now press Ctrl + H. The utility starts upon completion of POST.
2-28 General Description
NOTES:
Using WebBIOS allows you to build or change RAID configuration
with internal SAS hard disk drives.
To build or change RAID configuration with SAS hard disk drives
connected to N8103-115 RAID Controller, use Universal RAID
Utility.
WebBIOS does not support this feature.
The Onboard RAID Controller (MegaRAID ROMB) has factory-
installed battery. See Chapter 8 for error messages related to the
battery. See also "Battery for Onboard RAID Controller
(MegaRAID ROMB)" in Chapter 4.
5. Displays the message notifying you of the detection of the processor and the connected
keyboard and mouse.
6. Displays any of the following messages.
Pattern 1:
Press <F2> to enter SETUP or <F12> to Network
Pattern 2:
Press <F1> to resume, <F2> to enter Setup, <F12> to Network
* The displayed message may vary depending on the device status.
General Description 2-29
NOTE: The operation or utility to be started at each key entry is
described below. These operations or utilities may not always be
started.
F2
Press F2 to start the BIOS setup utility. Start the utility to change
the setting of the server to that fit to the environment in which the
server is used. In general, the setting may not be particularly
changed by starting the utility excluding the case in which the
previous message accompanying by an error message appears. See
Chapter 4 for the setting procedures and features of the parameters.
F12
Press F12 to run the network boot.
F1
If message "Press <F1> to resume" appears, an error is detected
during POST. See "Error messages during POST" for the
information on the messages and the proper actions against the
errors. If an error message appears, pressing F1 allows the BIOS
setup utility to be started.
7. When a password is set in the BIOS setup utility SETUP, the screen prompting you to
enter the password appears after the normal termination of POST.
The password can be entered for up to three times. If you enter the password incorrectly
all the time, the server cannot be started. In this case, turn off the power of the server, wait
for about 10 seconds, and then turn on the power to start the server again.
IMPORTANT: Set the password only after OS is installed.
8. Starts OS at the termination of POST.
POST Error Messages
When POST detects an error, it displays an error message on the display unit screen. See Chapter 8
for POST error codes.
IMPORTANT: Take a note on the messages displayed before
consulting with your service representative. Alarm messages are useful
information for maintenance.
2-30 General Description
Power Off
Follow the procedure below to power off the server. If the power cord of the server is connected to a
UPS, refer to the manual that comes with the UPS or the manual for the application that controls the
UPS.
IMPORTANT: Always allow POST to complete before turning off the
server.
1. Shut down the OS.
2. Press the POWER/SLEEP switch on the front of the server.
The POWER/SLEEP LED goes off.
3. Power off peripheral devices.
General Description 2-31
Floppy Disk Drive
Your server is not equipped with floppy disk drive. Use the optional USB floppy disk drive if
necessary.
Optical Disk Drive
Your server is provided with the optical disk drive on its front to read data from a CD/DVD-ROM.
The CD/DVD-ROM provides larger and faster data read than the floppy disk.
CAUTION
Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.
■ Do not leave the tray ejected from the optical disk drive.
Setting/Removing the CD/DVD-ROM
Confirm that the power of the server is on (with the POWER/SLEEP LED being lit)
1.
before setting the CD/DVD-ROM on the optical disk drive.
2. Press the media tray eject button on the front of the optical disk drive. The tray comes out.
Put the CD/DVD-ROM on the tray carefully and securely with the label facing upward.
CD/DVD tray eject button
2-32 General Description
3. Press the CD/DVD tray eject button or push the front of the tray lightly to retract it into
the drive.
IMPORTANT: If a noisy sound in driving the optical disk drive occurs
after setting a CD/DVD-ROM, set it again correctly.
To take out the media from the optical disk drive, press the CD/DVD tray eject button in the similar
way in setting the CD/DVD-ROM to make the tray go out. (If the access LED is lit in orange, the
CD/DVD-ROM is being accessed and CD/DVD tray eject button is disabled.) Some OS has a
command to eject a tray.
After taking out the CD/DVD-ROM, return the tray into the drive.
General Description 2-33
When you fail to eject the CD/DVD-ROM tray with the CD/DVD-ROM tray eject button and take
out the CD/DVD-ROM from the server, follow the procedure below.
1. Press the POWER/SLEEP switch to power off the server. (The POWER/SLEEP LED goes
off.)
2. Insert a metal pin of approximately 1.2 mm in diameter and 100 mm in length (a
straightened large paper clip will make a substitute) into the emergency hole on the upper
front of the optical disk drive and gently push it in until the tray is ejected.
IMPORTANT:
Do not use a toothpick or plastic stick that is easy to break.
If the above procedure does not let you take out the CD/DVD-ROM,
contact your service representative.
3. Hold the tray and pull it out.
4. Take out the CD/DVD-ROM.
5. Push the tray back into position.
2-34 General Description
NOTE: Use of the CD/DVD-ROM
Keep the following notes in mind to use the CD/DVD-ROM for the
server:
For the disk which does not conform to the CD/DVD standard, the
playback of such a disk with the DVD drive is not guaranteed.
Do not drop the CD/DVD-ROM.
Do not place anything on the CD/DVD-ROM or bend the CD/DVD-
ROM.
Do not attach any label onto the CD/DVD-ROM.
Do not touch the signal side (nothing is printed on this side) with
your hand.
Place the CD/DVD-ROM with its printed side upward and gently
put it on the tray.
Do not scratch the CD/DVD-ROM or write anything directly on it
with a pencil or ball-point pen.
Keep the CD/DVD-ROM away from cigarette smoke.
Do not leave the CD/DVD-ROM in a high-temperature place (e.g.,
place exposed to direct sunlight or close to a heater).
When dust or fingerprints are attached on the CD/DVD-ROM, wipe
the CD/DVD-ROM from its center to edge with a dry soft cloth
slowly and gently.
Use the CD cleaner to clean the CD/DVD-ROM. Do not use record
spray/cleaner, benzene, or thinner.
Keep the CD/DVD-ROM in a CD/DVD-ROM case when not in use.
If the CD/DVD-ROM emits large noise in the optical disk drive,
remove the CD/DVD-ROM and insert it back again.
Do not hit the CD/DVD-ROM to the screw fixing the top cover
when setting or removing disc.
Chapter 3
Setting Up Your Server
This chapter describes how to set up your server appropriate for your system, on a step-by-step
basis.
3-2 Setting Up Your Server
SETUP FLOW
Follow the flowchart below to set up the server.
Selecting a site
Select a suitable site for the server.
Unpacking the system
Unpack the server and accessories from the chipping carton box.
Assembling the rack-mount system
Assemble the 19-inch rack cabinet and install the server.
Connecting peripheral devices
Connect peripheral devices to the server.
Connecting the power cord
Connect the power cord to the server.
Turning on the server
Power on the server to start software setups. Setups depend on the optional internal
devices installed and the peripheral devices connected.
Installing the operating system
Install an operating system to the server. See Chapter 5.
Installing the utilities
Install the utilities in the provided NEC EXPRESSBUILDER DVD.
See Chapter 6.
Making backup copies of system information
After all the system setup procedures are completed, make backup copies of system
information.
System information is required for recovering the server from the trouble or after
replacing the system board.
Setting Up Your Server 3-3
SELECTING A SITE
Your server unit should be mounted in a standard EIA 19-inch rack cabinet.
Refer to the documentation attached to the rack or contact your service representative for
installation of the rack.
WARNING
Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages 1-3
to 1-8 for details.
■ Do not use the server in any unapproved place.
CAUTION
Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.
■ Do not carry or install the server only by a single person.
■ Do not install the server where the load may be concentrated on a specific
point.
■ Do not install any component on the server only by a single person.
■ Do not pull out a device from the rack if the rack is unstable.
■ Do not provide the wiring exceeding the rating power.
IMPORTANT: Increase in temperature within rack and air flow
If more than one server are installed on the rack or the ventilation
within the rack is not enough, the temperature in the rack may be raised
by the heat generated from the units to be higher than the operation
temperature of the server (10 to 35°C).
It causes the server to operate improperly. Review the air flow within
the rack or in the room and take sufficient measures so that the
temperature within the rack does not exceed the warranted temperature
range during the system operation.
3-4 Setting Up Your Server
The following figure illustrates a site suitable for installing the rack cabinet.
* It is recommended that the server should be used in a room where
temperature is in the range between 15 to 25ºC.
Room that satisfies the
100 to 120 Vac/200 to 240 Vac
parallel bi-polar wall power outlet
with the ground line.
Wall outlet to connect the
supplied power cord.
1 m
following conditions for
operation: *
Temperature: 10 to 35ºC
Humidity: 20 to 80% (no
condensation)
1 m
1 m
1 m
Place having available
space of 1 m or more in
front, side and rear of the
server.
Setting Up Your Server 3-5
Do not install the rack in the places listed below. Installing the rack or mounting the server on the
rack in such a place may cause some malfunction to occur.
Do Not:
Locate a rack in a narrow space that would inhibit devices from being pulled out from the
rack completely.
Locate the rack on a floor that cannot bear the total weight of the rack and devices
mounted in the rack.
Locate the rack in a place where stabilizers cannot be installed or where the rack can be
installed only after proper earthquake-resistant is constructed.
Locate the rack on an uneven or slanting floor
Locate the rack in an area that has drastic temperature change (near a heater, air
conditioner, or refrigerator).
Locate the rack where intense vibration may be generated.
Locate the rack where corrosive gas is generated (ex. the area, where the vapor of sulphur
is generated), chemicals are nearby, or chemicals may be sprayed accidentally.
Place the rack on a carpet not subject to the anti-static process.
Locate the rack where some objects may fall on the rack.
Locate the rack near a device that is generating intense magnetic fields (such as a TV,
radio, broadcast/communication antenna, power transmission wire, and electromagnetic
crane.) If unavoidable, contact your service representative to request proper shielding.)
Locate the rack where the power cord of the server must be connected to an AC outlet that
shares other devices with large power consumption.
Locate the rack next to equipment that generates power noise (e.g., contact spark at
power-on/power-off of commercial power supply through a relay). If you must install the
server close to such equipment, request your service representative for separate power
cabling or noise filter installation.
Locate the rack where following conditions can not be satisfied.
Conditions for operation: *
Temperature: 10 to 35°C
Humidity: 20 to 80% (no condensation)
* It is recommended that the server should be used in a room where temperature is in the
range between 15 to 25°C.
* If installed in a closed or multi-unit rack assembly, required air flow for cooling might
not be maintained, and this cause the operating ambient temperature of the rack
environment may rise greater than room ambient. Therefore, consideration should be
given to installing the server in an environment compatible with the rated ambient
temperature (10 to 35°C) and appropriate air flow.
3-6 Setting Up Your Server
Installing or Removing the Server into/from the Rack
This subsection provides the instructions for the rack-mount server unit into a standard EIA 19-inch
rack cabinet.
This subsection also describes the removal procedures for the rack mount server unit from the 19inch rack cabinet.
WARNING
Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages
1-3 to 1-8 for details.
■ Do not use any rack which does not conform to the relevant standard.
■ Disconnect the power cord(s) before installing or removing the server.
CAUTION
Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.
■ Do not leave more than one device being pulled out from the rack.
■ Do not lift the server only by a single person.
■ Always install the server in the specified place.
■ Do not install the server on the rack leaving the cover removed.
■ Do not pinch your finger with mechanical components.
Setting Up Your Server 3-7
Checking Components
Confirm that the following tools or components are provided to install the server on the rack.
3
2
1
4
5
No. Item Q'ty Remarks
1 Front bezel 1
2 Slide rail assembly (L) 1 "L" is stamped on the rail.
3 Slide rail assembly (R) 1 "R" is stamped on the rail.
4 Cable arm 1
5 Arm stopper 1
6 Tie-wrap 10 25 cm long.
7 Screw (A) 4 Two are for spare.
8Screw (B) 2
6
7
8
3-8 Setting Up Your Server
Required Tools
#2 Phillips screwdriver and flat tip screwdriver are recommended for assembling the rack-mount
system.
Installation Procedure
Install the server on the rack in the following procedure.
IMPORTANT: You cannot install the server into N8540-28F/29F/38F
NEC rack.
1. Define the position (height) at which the server is installed.
The server has 4U high. The bottom of the rail aligns with the bottom of server.
Template (Front) Template (Rear)
2. Make sure that the black lever surely locks the components.
If not, lock them.
Setting Up Your Server 3-9
NOTE: There are four levers to secure the components. Make sure that
all levers lock the components securely.
3-10 Setting Up Your Server
3. Define the position of slide rail assembly so that the bottom of the rail bracket is located at
the lower position of the server.
IMPORTANT: If the slide rail is inclined during installation, inner
fails may protrude.
NOTES:
Check the direction of installing the slide rail assembly.
– Make the bracket face facing the outside of the rack.
– The slide rail has different shapes in its left and right side. Make
sure the stamp on the rail (Front → L / Front → R).
The front and rear supports of the rack have rectangular holes for
screw fastening. For the NEC rack, round stamps are provided in 1U.
As shown in the figure, locate the slide rail assembly so that a stamp
is positioned at the tip of slide rail assembly (lower side).
The rail bracket has 3U high.
Make sure that the fingers are locked in the rectangular holes.
Make sure that the
fingers are locked in
the rectangular holes.
Stamp (located at the
lower right position of
slide rail assembly)
Setting Up Your Server 3-11
4. Fix left and right sides of slide rail assembly (for the rear side of the rack) with two screws
(A), one for left side and another for right side.
NOTES:
Make sure that the frame tips on the slide rail assembly are contact
to the rectangular hole frames of the rack properly and the four
screw holes of the rail can be seen through the mating rectangular
holes of the rack.
Check that the slide rail assembly is located to the level.
5. Install the other slide rail assembly on the opposite side of the rack in the same procedure
as that described by steps 2 to 4 above.
NOTE: Make sure that the slide rail assembly is installed at the same
level as the other slide rail assembly already installed.
3-12 Setting Up Your Server
6. Hold the server by three or more persons to mount it on the rack.
CAUTION
Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.
■ Do not lift the server only by two or less persons.
■ Do not pinch your fingers with mechanical component.
■ Do not push the release lever with fingers.
Pull the inner rail, and install it so that its cutout engages with the projection on the side of
the server.
IMPORTANT: The center cutout has locking mechanism. Make sure
that it is surely locked.
Mating portion
Locking lever
At the first installation, you may feel strong friction in pushing because the mechanical
components cannot be completely engaged with each other. Push the server intensely.
Setting Up Your Server 3-13
7. Install the cable arm to the inner rail (to the right side viewed from rear of the server).
NOTE: Install the cable arm so that its protrusions align with holes on
the inner rail.
8. Install the other side of cable arm to the outer rail (at the right side viewed from rear of the
server).
3-14 Setting Up Your Server
NOTE: When installing the server into NEC rack, fix the arm stopper
to the slide rail assembly with screw (B).
Viewed from inside
Arm stopper
Push the arm stopper in the direction shown
by arrow mark so that the folded portion hits
the end, then fix it with the screw.
9. Push the server into the rack once to check the installation position.
To push the server into the rack, lift green release levers at both sides of the rail to unlatch
the server. Pay strict attention to your fingers not to be caught.
IMPORTANT:
Push each release lever using a screwdriver or a similar tool.
Pushing a release lever with your fingers may cause the fingers to
be caught and thus injured.
Two release levers are provided on each side of the rail. Be sure to
use green levers only.
Release lever
Setting Up Your Server 3-15
10. Pull out or push the server into the rack for several times to confirm that the slides move
smoothly.
11. Connect the power cord and interface cables.
NOTE: Before connecting cables, be sure to read precautions given in
"Connecting Peripheral Devices".
12. Secure the server to the rack with two thumb nuts.
13. Install the front bezel.
Now the installation is completed.
Screws
3-16 Setting Up Your Server
Removal Procedure
More than one person should remove the server from the rack.
CAUTION
Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages 13 to 1-8 for details.
■ Do not lift the server only by two or less persons.
■ Do not pinch your finger with mechanical components.
■ Note high temperature.
■ Do not pull out a device from the rack if the rack is unstable.
■ Do not leave more than one device being pulled out from the rack.
1. After making sure that the server is off-powered, remove the power cords and all interface
cables from the server.
2. Release the security lock and remove the front bezel.
Frame
Tabs
Unlock Lock
3. Remove two screws (A) located at both side of the front face of the server.
4. Hold the handle to pull out the server from the rack slowly and carefully.
The server clicks to be latched.
Setting Up Your Server 3-17
5. Push the left and right release levers to release the lock and then pull out the server from
the rail slowly.
Release lever
IMPORTANT:
Push each release lever using a screwdriver or a similar tool.
Pushing a release lever with your fingers may cause the fingers to
be caught and thus injured.
Pull out the server slowly with its bottom supported by more than
one person.
See the "Installation procedure" when the mechanical components of the rack are removed also.
3-18 Setting Up Your Server
CONNECTING PERIPHERAL DEVICES
Connect peripheral devices to the server. The server is provided with connectors for wide variety of
peripheral devices on its front and rear. The figure on the next page illustrates available peripheral
devices for the server in the standard configuration and locations of the connectors for the devices.
CAUTION
Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.
■ Do not connect any interface cable with the power cord of the NEC Express
Server plugged to a power source.
■ Do not use any unauthorized interface cable.
IMPORTANT:
Power off the server and a peripheral device before connection.
Connecting a powered peripheral device to the powered server will
cause malfunctions and failures (excluding the USB device).
To connect a third-party peripheral device or interface cable to the
server, consult with your service representative for availability of
such a device or cable. Some third-party devices may not be used
for the server.
A leased line cannot be connected directly to the serial port
connectors.
Secure the power cord(s) and interface cables with a lock spring.
Form the cables in such a way that they will not come into contact
with the door or the guide rails on the sides of the server.
Setting Up Your Server 3-19
FRONT
REAR
Mouse
Hub
(multiport repeater)
100BASE-TX /
10BASE-T
Device with USB
interface
(e.g., keyboard)
Keyboard
Management
PC
Device with USB
interface (USB2.0)
(e.g., keyboard)
Display unit
Device with the serial
interface (e.g., modem /
management PC)
Direct connection to the
leased line is prohibited.
Network system
on LAN
(connected
via a hub)
Finally connect the provided power cord to the receptacle.
If connecting the server to UPS, see the explanation below.
For 100 VAC power, use
the parallel bi-polar wall
power outlet with the
ground line.
For 200 VAC power, use
the AC power cord
dedicated to 200 VAC.
Hub (multiport repeater)
1000BASE-T /
100BASE-TX /
10BASE-T
3-20 Setting Up Your Server
IMPORTANT:
Turn off the power of the server, and then connect the peripheral
devices. Connecting them with the server is on may cause
malfunction or a failure. (This does not apply to USB devices.)
If connecting a non-NEC (third party) peripheral device or interface
cable, ask your service representative if the device/cable is
compatible with the server. Some devices provided by third parties
are not compatible with the server.
Plug in the keyboard and mouse with "∆" on the connector upward.
Secure the power cord firmly with the tie wrap attached to the
power supply unit.
Form the cables so that they will not bump the rack door or the
guide rails on the sides of the rack.
Form the power cord so that it will slack slightly at around the AC
inlet of the server. This is to prevent the cord from coming off when
the server is pulled out.
Confirm that no pressure is applied to the power cord plug.
Be sure to use the cable for 200 VAC (optional), if you use the
server with 200 VAC power. The AC power cord provided with the
server accepts 100 VAC only. Do not use the cord with 200-VAC
power.
CONNECTING POWER CORD
Connect the provided power cord to the server.
Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages 1-3
to 1-8 for details.
■ Do not hold the power plug with a wet hand.
Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.
■ Do not plug the power cord in to an improper power source.
■ Do not connect the power cord to an outlet that has an illegal number of
connections.
■ Insert the power plug into the outlet as far as it goes.
■ Use the authorized power cord only.
Setting Up Your Server 3-21
WARNING
CAUTION
1. Plug the provided power cord into the AC inlet on the rear of the server.
2. Plug the other end of the power cord into the wall outlet.
3. Secure the power cord with a tie wrap.
Tie wrap
3-22 Setting Up Your Server
To connect the power cord from the server to an interruptive power supply (UPS), use service
outlets on the rear of the UPS. Refer to the manual that comes with the UPS for details.
N8142-11B
Input breaker
Option slot
Input connector
(NEMAL5-30P)
Connector for TVSS device
Computer interface port
Voltage sensitivity setting button
Outlet socket
Reset button for
overload prevention
When the power cord from the server to a UPS, change the BIOS setup of the server to link with
power supply from the UPS.
Change a parameter for "AC-LINK" under the Server menu of the BIOS SETUP utility. See Chapter
4 for details.
Setting Up Your Server 3-23
TURNING ON THE SERVER
Turn on the server and follow the on-screen instructions for setup.
IMPORTANT: Before turning on the server:
Some optional boards require setups with the SETUP utility before
installation. If the server has a PCI board with the PCI-to-PCI
bridge installed, the SETUP utility is enabled to launch. Check on
the board specifications to find out whether it requires preinstallation setups before actually installing the board.
Some installed optional devices or connected peripheral devices
require setups before proceeding to the next step.
To use the server with no optional devices installed besides the graphic
board, install a desired OS to the server.
1. Make sure that the floppy disk drive contains no floppy disk and the optical disk drive
contains no bootable CD/DVD-ROM.
2. Press the POWER/SLEEP switch.
NOTES:
If the power cord is connected to the power control unit such as the
UPS, turn on the power control unit.
Connect the power cord and wait about 30 seconds before pressing
the POWER/SLEEP switch. The POWER/SLEEP switch does not
work in about 30 seconds after connecting the power cord due to
BMC (Baseboard Management Controller) firmware start-up.
POWER/SLEEP LED
POWER/SLEEP switch
3-24 Setting Up Your Server
The POWER/SLEEP LED on the front of the server comes on.
In a few seconds, the NEC logo appears on the screen and the Power On Self-Test (POST)
begins.
The POST runs automatically when you power on the server or reset it with a keyboard
operation (Ctrl + Alt + Delete). The POST runs diagnostics, initializes the server, sets
interrupt vectors, detects installed peripheral devices, and boots the operating system (if
installed). See Chapter 2 for detailed description on POST.
If the server halts before completing the POST, the POST emits a beep code indicating a
fatal system error requiring immediate attention. (See Chapter 8, "Troubleshooting," for
troubleshooting information.)
During memory test, the POST displays the amount of memory it was able to access and
test. Depending on the amount of installed memory, it may take several minutes to
complete the memory test.
NOTE: The factory-set is defined to hide the POST screen with the
NEC logo screen. You can always change the NEC logo screen to the
POST screen by pressing Esc. To change the start-up screen, use the
BIOS setup utility, "SETUP." (See Chapter 4 for details.)
During the POST, you will see the banner message to prompt you to launch the BIOS SETUP utility
stored in ROM on system board or on an installed option board.
Start the BIOS SETUP utility appropriate to your system environment to change the BIOS setup.
For the BIOS SETUP for the server, see Chapter 4. For the BIOS SETUP for the option board, refer
to the manual that comes with the option board.
Setting Up Your Server 3-25
INSTALLING OPERATING SYSTEM
See Chapter 5 for installing the Operating system.
IMPORTANT: Before installing the operating system, adjust the
system date and time by using the BIOS setup utility "SETUP". See
Chapter 4 detail.
INSTALLING UTILITIES
Install the utilities that come with the server. See Chapter 6 for details.
3-26 Setting Up Your Server
MAKING BACKUP COPIES OF SYSTEM INFORMATION
The system information includes the current BIOS settings and any specific information for the
server.
Save the information after completing the system setup.
Without the backup data, you will not be able to recover the information.
You can save the information by the following process.
1. Insert the NEC EXPRESSBUILDER DVD into the optical disk drive and reboot the
system.
2. Select [Maintenance Tools (Normal mode)].
3. Select [English].
4. Select [Maintenance Utility].
5. Select [System Information Management].
6. Insert a floppy disk into the floppy disk drive.
7. Select [Save].
IMPORTANT: If "Enabled" is selected for [Server] - [BMC LAN
Configuration] - [Shared BMC LAN] in BIOS SETUP, the procedures
described above will fail to make backup copy of system information
correctly. Change BIOS setting to "Disabled" before making backup
copy. [Shared BMC LAN] option is factory-set to "Disabled".
Chapter 4
Configuring Your Server
This chapter describes Basic Input Output System (BIOS) configuration.
When you install the server for the first time or install/remove optional devices, thoroughly read this
chapter for better understanding and correct setups.
SYSTEM BIOS ~ SETUP ~
The SETUP utility is provided to make basic hardware configuration for the server. This utility is
pre-installed in the flash memory of the server and ready to run.
The server is configured with the correct parameters using the SETUP utility and shipped in the best
conditions. Thus, you don't need to use the SETUP utility in most cases. However, you might wish
to use the SETUP utility in the cases described below.
IMPORTANT:
The SETUP utility is intended for system administrator use only.
The SETUP utility allows you to set a password. The server is
provided with two levels of password: Supervisor and User. With
the Supervisor password, you can view and change all system
parameters of the SETUP utility. With the User password, system
parameters available for viewing and changing are limited.
Do not set any password before installing the OS.
The server contains the latest version of the SETUP utility. Dialog
boxes appear on your SETUP utility, thus, may differ from
descriptions in this manual. If you find anything unclear, see the
online help or ask your service representative.
4-2 Configuring Your Server
Starting SETUP Utility
To run the SETUP utility, perform the following procedures:
1. Turn on the power of the server.
The NEC logo appears on the screen (the POST screen may appear depending on the
setting in SETUP.).
After a while, any of the following messages appears at the bottom of the screen.
Pattern 1:
Press <F2> to enter SETUP or <F12> to Network
Pattern 2:
Press <F1> to resume, <F2> to enter Setup, <F12> to Network
* The displayed message varies depending on the device status.
2. Press F2 to start the SETUP utility and display its Main menu.
If you have previously set a password with the SETUP utility, the password entry screen
appears. Enter the password.
Up to three password entries will be accepted. If you fail to enter the password correctly
for three consecutive times, the server halts. (You can no longer proceed.) Power off the
server.
NOTE: The server is provided with two levels of password:
Supervisor and User. With the Supervisor password, you can view and
change all system parameters. With the User password, system
parameters available for viewing and changing are limited.
Loading...
