User's manual

NAVIGON 7100 | 7110

English (UK)

February 2008

This symbol showing a crossed-throughrefuse container signifies that, within the European Union, the product must be disposed of as sorted waste. This applies both to the product itself, as well as to all accessories that carry this symbol. This product may not be disposed of with unsorted household waste.

Imprint

NAVIGON AG Schottmüllerstraße 20A

D-20251Hamburg

The information contained herein may be changed at any time without prior notification. This manual nor any parts thereof may not be reproduced for any purpose whatsoever without the express written consent of NAVIGON AG, nor transmitted in any form either electronically or mechanically, including photocopying and recording. All technical specifications, drawings etc are subject to copyright law.

© 2008, NAVIGON AG All rights reserved.







User's manual NAVIGON 7100 | 7110

Table of Contents



1

Introduction.......................................................................................

6



1.1

About this manual.....................................................................................

6





1.1.1

Conventions.................................................................................

6





1.1.2

Symbols.......................................................................................

6



1.2

Legal notice ..............................................................................................

6





1.2.1

Liability.........................................................................................

6





1.2.2

Trademarks .................................................................................

6



1.3

Questions concering the product..............................................................

7

2

Before you begin...............................................................................

7



2.1

Scope of Delivery .....................................................................................

7



2.2

Description of the NAVIGON 7100 | 7110................................................

8



2.3

Preparing NAVIGON 7100 | 7110 for use ................................................

9





2.3.1 Charging the rechargeable battery ..............................................

9





2.3.2 Inserting a memory card..............................................................

9





2.3.3 Preparing the navigation system for use ...................................

10



2.4

Navigation with GPS ..............................................................................

11



2.5

Important safety information...................................................................

11





2.5.1

Navigation safety information ....................................................

11





2.5.2 Safety information for the navigation device..............................

12





2.5.3 Safety guidelines when installing in your car.............................

13

3

Operating the navigation software ................................................

14



3.1

Volume

...................................................................................................

14



3.2

Information .............................................................................................

14



3.3

Software keyboard .................................................................................

16



3.4

Lists ........................................................................................................



16



3.5

Options

...................................................................................................

17



3.6

Menus.....................................................................................................



17

4

Password Lock................................................................................

17



4.1

Activating password protection...............................................................

17



4.2

Changing a password.............................................................................

18



4.3

Cancelling password protection .............................................................

18



4.4

Switching on NAVIGON 7100 | 7110 .....................................................

18





4.4.1

Forgotten your password?.........................................................

18

5

Navigation

.......................................................................................

18



5.1

Starting NAVIGON 7100 | 7110 .............................................................

19

User's manual

Table of Contents III

User's manual NAVIGON 7100 | 7110





5.1.1 Initialising the GPS receiver ......................................................

19



5.2

Specifying a new destination..................................................................

20





5.2.1 Specifying the destination country.............................................

20





5.2.2

Destination address...................................................................

21





5.2.3

Special destinations...................................................................

22





5.2.4 Quick access to special destinations.........................................

24





5.2.5 Information about the destination ..............................................

24



5.3

Selecting a saved destination.................................................................

25





5.3.1

Last Destinations .......................................................................

25





5.3.2

Favourites..................................................................................

25



5.4

Navigating homewards...........................................................................

26



5.5

Voice commands....................................................................................

26



5.6

Determining destinations on the map.....................................................

27



5.7

Starting navigation..................................................................................

27

6

Managing Destinations...................................................................

28



6.1

Saving a destination ...............................................................................

29



6.2

Defining a destination as home address ................................................

29



6.3

Setting up a voice command ..................................................................

29

7

Routes with stages .........................................................................

30



7.1

Route planning .......................................................................................

30





7.1.1 Entering the starting point..........................................................

30





7.1.2

Entering route points .................................................................

31





7.1.3

Editing route points....................................................................

31



7.2

Managing routes.....................................................................................

32





7.2.1

Saving routes.............................................................................

32





7.2.2

Loading routes...........................................................................

32



7.3

Navigation ..............................................................................................

32





7.3.1 Calculating and displaying routes..............................................

32





7.3.2

Simulating routes.......................................................................

33





7.3.3

Starting navigation.....................................................................

33

8

Options ............................................................................................



34

9

Working with the map.....................................................................

36



9.1

Maps.......................................................................................................



36



9.2

Map in Preview mode.............................................................................

36



9.3

Map in Navigation mode.........................................................................

38



9.4

Reality View............................................................................................

40



9.5

Map in Destination search mode............................................................

41





9.5.1 Operating in Destination search mode ......................................

42

IV Table of Contents

User's manual

User's manual NAVIGON 7100 | 7110

10

Useful functions..............................................................................

43



10.1

GPS status, storing the current location.................................................

43



10.2

Turn-by-Turn List....................................................................................

43





10.2.1

Blocking route sections ..............................................................

44





10.2.2 Removing blocks and using original routes ...............................

44



10.3

TMC (Traffic Information) .......................................................................

45





10.3.1

Displaying traffic messages .......................................................

45





10.3.2

TMC Settings .............................................................................

45



10.4

Logbook..................................................................................................

46

11 Configuring NAVIGON 7100 | 7110 ................................................

47

12

Handsfree Module...........................................................................

48



12.1

Opening and closing the hands-free module..........................................

48



12.2

Bluetooth Manager .................................................................................

48



12.3

Connecting to a telephone .....................................................................

49





12.3.1 Pairing with a mobile phone ......................................................

49





12.3.2 Connecting to a mobile phone...................................................

50



12.4

Accepting a call ......................................................................................

50



12.5

Calling

....................................................................................................

51





12.5.1 ......................................................Dialling a telephone number

51





12.5.2 .......Calling most recently dialled, received or missed numbers

51





12.5.3 .....................................................Dialling on the mobile phone

52



12.6

During ...........................................................................................a call

52





12.6.1 .................................................................

Adjusting the volume

53





12.6.2 ..............................................................

Muting the microphone

53





12.6.3 .....................................Transferring a call to the mobile phone

53





12.6.4 .........................Transferring a call from your mobile telephone

53





12.6.5 ......................................................................

Entering numbers

54





12.6.6 ...................Bringing the navigation software to the foreground

54





12.6.7 ...........................................................................

Ending the call

54



12.7

Hands- .......................................................free module troubleshooting

55

13

Appendix .........................................................................................



56



13.1

Technical ........................................................................................data

56



13.2

Declaration .......................................................................of Conformity

57

14

Index ................................................................................................



58

User's manual

Table of Contents V

User's manual NAVIGON 7100 | 7110

1 Introduction

1.1About this manual

1.1.1Conventions

For better legibility and clarification, the following styles are used in this manual:

Bold and italics: Registered names, company and product descriptions.

SMALL CAPITALS: Window and dialogue box titles.

Bold:

Highlighting of important parts in the text.

Underlined: Descriptions of buttons, input fields and other elements on the user interface.

1.1.2Symbols

The following symbols refer to specific passages of text:

Instructions and tips for operating the software

More detailed information and explanations

Warnings

1.2Legal notice

1.2.1Liability

The software and the manual are subject to change without notice. NAVIGON AG is not liable for the accuracy of the information contained in this manual or for damages resulting from the use of this manual.

We always appreciate any suggestions that will allow us to offer improved performance of our products in the future, or information regarding malfunction.

1.2.2Trademarks

All brands and trademarks mentioned in this document are possibly registered by third parties and are subject to the current legislation and to the rights of their respective owners without reservation. All mentioned names of products, societies, or brands may be registered

- 6 -

Introduction

User's manual NAVIGON 7100 | 7110

trademarks of their respective owners. Every right that is not explicitly accorded is reserved.

The absence of the explicit labelling of registered trademarks used in this manual does not imply that the brand is not subject to the rights of a third party.

Windows and ActiveSync are trademarks of the Microsoft Corporation.

NAVIGON is a registered trademark of NAVIGON AG.

1.3Questions concering the product

You have a question concerning your product? Then visit our webseite www.navigon.com and click on "Support". There you will find an area with frequently asked questions (FAQ Center) along with details of how to contact us by phone ore-mail.

2 Before you begin

2.1Scope of Delivery

Please check that the contents of the delivery are complete. If the contents are incomplete, please notify us within 14 days of purchasing. The purchased product includes the following:

NAVIGON 7100 | 7110 navigation device

Car cradle

Car charger cable ( 12V-adapterfor the vehicle's cigarette lighter)

Mains adapter

USB-cable

SD-cardcontaining software and navigation maps

Manual

CD with manuals (PDF, including languages not printed)

Pouch

Before you begin

- 7 -

User's manual NAVIGON 7100 | 7110

2.2Description of the NAVIGON 7100 | 7110

1Touch screen

2Microphone

3 Reset

4Headset socket (also used to connectTMC-antenna)

5LED

6

Mini-USB-socketforUSB-cable /Mains adapter / Car



charger cable

7Stylus

8Show Map

9

On/Off/Standby

10

Slot for SD-memorycard

11

Connection for external GPS-antenna

- 8 -

Before you begin

User's manual NAVIGON 7100 | 7110

2.3Preparing NAVIGON 7100 | 7110 for use

2.3.1Charging the rechargeable battery

It is possible that the rechargeable battery is not fully charged when you remove it from the packaging. We recommend that you fully charge the battery before using the device for the first time.

Press the mains socket adapter provided into the designated slot on the mains adapter until it locks into place.

Connect the mains adapter to the navigation device and to a mains socket.

The LED of the NAVIGON 7100 | 7110 lights orange during charging. The LED lights green when theNAVIGON 7100 | 7110 is fully charged.

Note: It takes approx.4-5hours to charge the device when the battery is flat.

A fully charged battery enables 4 hours of use.

2.3.2Inserting a memory card

Insert the memory card provided into the device (see image). Press the card into the device until it locks into place.

Removing the memory card

1.Switch the navigation device off by pressing the (On/Off/Standby) switch for at least 6 seconds.

2.Press the memory card gently into the device until the lock disengages.

Before you begin

- 9 -

User's manual NAVIGON 7100 | 7110

2.3.3Preparing the navigation system for use

Caution! Please be sure to refer to the safety information in chapter"Important safety information" on page11.

Securing the cradle

1.Clean that part of the windscreen to which you would like to secure the cradle. The windscreen must be dry and free of dirt and grease.

2.Using the suction cup, fix the cradle provided to the windscreen. The cradle should be as level as possible.

3.Press the lever on the suction cup down.

Securing the navigation device to the cradle

The navigation device is secured to the cradle by means of a bayonet fitting. This connection functions in a similar way to attaching a lens to a camera or putting the lid on a pressure cooker.

1.Place the navigation device on the bayonet in such a way that the lugs on the bayonet ring correspond exactly with the recesses on the cradle. This is achieved by rotating it approx. 45° to the left.

2.Turn the navigation device clockwise until the bayonet fitting locks into place.

3.Adjust the navigation device so that it can be seen easily.

Supplying power to the navigation device

Included in delivery of the NAVIGON 7100 | 7110 is a car charger cable with which power can be supplied to the navigation device via the vehicle's cigarette lighter.

The car charger cable is connected to the NAVIGON 7100 | 7110 via themini-USB-socketon the bottom of the device.

- 10 -

Before you begin

User's manual NAVIGON 7100 | 7110

Caution! The car charger cable is to be connected to cigarette lighters with an operating voltage of 12V only.

Connecting the TMC-antenna

The NAVIGON 7100 | 7110 has an integratedTMC-receiver.For optimal reception, you should use theTMC-antennaprovided.

1.Connect the TMC-antennato the headset socketon the bottom of theNAVIGON 7100 | 7110.

2.Secure the antenna to the windscreen using the suction cups.

2.4Navigation with GPS

GPS is based on a total of 24 satellites that circle the earth and, in doing so, are constantly transmitting their position and time. The GPS receiver receives this data and calculates its own geographical position on the basis of the information transmitted by the various satellites.

For a sufficiently precise positioning it is necessary to obtain the data from at least three satellites. With the data from 4 or more satellites the altitude above sea level can also be ascertained. The determination has an accuracy of about 3 yards.

Once the navigation device has determined your position, this position can be used as a starting point for route calculation.

The map data on your navigation device includes the geographical coordinates of all digitally recorded points of interest, streets and places. This enables the device to calculate a route between a starting point and a destination.

The calculation of the current position and its representation on the map takes place once every second. So your current position is always shown on the map.

2.5Important safety information

In your own interest, please read the following notices and safety information carefully before starting up your navigation system.

2.5.1Navigation safety information

Use navigation system at your own risk.

Caution! To prevent accidents, do not operate the navigation system while driving.

Before you begin

- 11 -

User's manual NAVIGON 7100 | 7110

Caution! Do not look at the display unless it is absolutely safe to do so!

Caution! Traffic regulations have priority over any instructions from the navigation system.

Caution! Only follow the instructions of the navigation system when the circumstances and the road traffic regulations allow you to do so! The navigation system will guide you to your destination even if you deviate from the calculated route.

Caution! Check that the cradle is secured and adjusted properly before each journey.

Note: If you have not understood the spoken instructions, or you're not sure about what to do next, you can refer briefly to the map or arrow view of your navigation system.

2.5.2Safety information for the navigation device

Caution! Protect the device from moisture. The device is neither waterproof nor is it protected against splash water.

Caution! Unplug the navigation device's power supply when you park the vehicle. The navigation device requires power instandby-modus,and may drain the vehicle's battery.

Caution! Do not open the navigation device's casing under any circumstances.

Caution! Do not expose the navigation device to extreme heat or cold. This may damage the device or impair its function.

Caution! Use only the charger provided or one that has been approved of by the manufacturer.

Connect the charger to a suitable power supply. The voltage requirements can be found on the device case and/or the packaging.

Note: Ensure that there are no kinks in the cable and that it will not be damaged by any sharp objects.

Note: To clean the navigation device, use a moist cloth only .

- 12 -

Before you begin

User's manual NAVIGON 7100 | 7110

Note: Do not unplug by pulling on the cable. Doing so could damage the cable!

Note: If you want to transport the navigation device, use the cover provided in order to protect the touchscreen from scratches.

Note: Create a backup of the data contained on the memory card provided. This is very easy to do with theNAVIGON Fresh software which can be downloaded free of charge from our websitewww.navigon.com.

Note: The memory card must remain inserted in the device during operation of the navigation system.

Note: Use SDorMMC-memorycards only! Ensure that memory card contacts are clean and undamaged.

2.5.3Safety guidelines when installing in your car

Caution! Secure the cradle and theTMC-antennain such a way that the driver's visibility is not impaired.

Caution! Do not attach the cradle within the deployment zone of airbags.

Caution! When installing the cradle, ensure that it does not represent a risk in the event of an accident.

Caution! Do not run cables directly next tosafety-relevantdevices and power supplies.

Caution! After installation, check allsafety-relevantequipment in the car.

Caution! The car charger cable is to be connected to cigarette lighters with an operating voltage of 12V only.

Before you begin

- 13 -

User's manual NAVIGON 7100 | 7110

3 Operating the navigation software

3.1Volume

The volume of the spoken driving instructions can be adjusted during navigation.

You have started navigation. The map is open in Navigation or

Destination search mode.

1.Tap the (Volume) button.

The volume bar opens. It contains three buttons for adjusting the volume:

(Louder),(Quieter),(Volume on/off).

2.Tap the (Volume) button again. The volume bar closes.

3.2Information

Symbols located at the top of the screen are used to display information.

GPS

The GPS symbol can show the followingGPS-receptionstatus:

No GPS: Thebuilt-inGPS receiver is not operational. Contact customer service if the problem persists.

No Signal: Data is being received from less than three satellites. Position cannot be calculated.

GPS Ready: Data is being received from at least three satellites. Position can be calculated.

For more detailed information regarding GPS status, please refer to chapter "GPS status" on page 43.

Energy

The Energy symbol can display the following conditions of thebuilt-inbattery:

- 14 -

Operating the navigation software

User's manual NAVIGON 7100 | 7110

The device is being supplied by an external power source. The battery is being charged.

The device is being supplied by its internal battery. The battery charge is sufficient.

The device is being supplied by its internal battery. The battery charge is low.

Direction

The Direction symbol shows you in which direction you are currently heading. It can show the following points of the compass: N, NE, E, SE, S, SW, W and NW.

TMC (Traffic Information)

The NAVIGON 7100 | 7110 has an integratedTMC-receiverwhich provides the navigation system with up to date traffic messaging. If necessary, it can alter the route dynamically in order to avoid a traffic jam for example.

Note: This function is only available if TMC traffic messages are being transmitted in the country in which you are travelling. This is not the case in all countries.

The TMC symbol can display the followingTMC-receptionstatus:

No Symbol: There is no TMC receiver connected, or the connected orbuilt-inTMC receiver is not operational.

Tuning: TheTMC-receiveris operational, but cannot find a station that is transmitting TMC signals.

TMC on Standby: Traffic messages can be received.

For details on TMC functionality, please refer to chapter "TMC (Traffic Information)" on page45.

Bluetooth

The NAVIGON 7100 | 7110 has an integrated Bluetoothhands-freemodule. This enables you to use the device as ahands-freekit for a mobile phone with Bluetooth capability.

The Bluetooth symbol can display the following states for the handsfree module:

No Bluetooth: Bluetooth is deactivated.

Operating the navigation software

- 15 -

User's manual NAVIGON 7100 | 7110

Connected: TheNAVIGON 7100 | 7110 is connected to another device.

Not connected: TheNAVIGON 7100 | 7110 is not connected to another device. Bluetooth is activated.

3.3Software keyboard

A software keyboard appears on the screen when text entries are necessary.

All entries can be made on the software keyboard using the fingertips. Only capital letters can be entered.

When entering town or street names you need not enter any special characters or umlauts. The navigation system fills in these characters for you automatically. If, for example, you are searching for “Würzburg”, then simply enter "WURZBURG". Special characters may be helpful when naming saved destinations and itineraries, however.

Special keys

enters a space character.

deletes the character in front of the cursor.

opens the numeric keypad.

opens the letter keyboard.

opens the special character keyboard. As soon as you have entered a special character, the letter keyboard reappears automatically.

3.4Lists

Often, lists appear from which you can select an entry. This is the case, for example, when you enter a location.

As soon as you enter the first letter, the largest city in the country specified which begins with this letter appears.

As soon as you enter the second letter, a list appears with all locations that begin with the letters entered.

If you enter additional letters, the list adapts to your entries. It only contains entries that begin with the text that has been entered or contain the text in the name. The more letters you enter, the shorter the list will become.

- 16 -

Operating the navigation software

User's manual NAVIGON 7100 | 7110

You can toggle the list by means of the (Up) and(Down) buttons.

In order to accept an entry from the list, simply tap on it. The list closes as soon as you have accepted an entry.

3.5Options

Some windows offer options that lead to further functions.

A description of all available options can be found in chapter "Options" on page34.

3.6Menus

Some buttons have menus which open when activated. Tap on a menu button to execute its function.

If you would like to quit the options list without selecting a function, tap on the button you used to open the menu.

4 Password Lock

By creating a password, you can protect your navigation system from unauthoriised use.

Note: Password protection only comes into effect after the navigation

device has been switched off completely. To do this, press the (On/Off/Standby) switch for at least 6 seconds.

4.1Activating password protection

1.In the MAIN WINDOW, tap onOptions >Settings >Options >Password Lock.

The PASSWORD LOCK window opens.

2.Enter a new password in the New password field.

3.Enter this password in the Confirm new password field again.

4.Tap the Save password button.

Note: The password must contain precisely 4 digits.

Password Lock

- 17 -

User's manual NAVIGON 7100 | 7110

4.2Changing a password

1.In the MAIN WINDOW, tap onOptions >Settings >Options >Password Lock.

The PASSWORD LOCK window opens.

2.Enter the password that is currently valid in the Old password field.

3.Enter a new password in the New password field.

4.Enter the new password in the Confirm new password field again.

5.Tap the Change password button.

Note: The new password must contain precisely 4 digits.

4.3Cancelling password protection

The PASSWORD LOCK window is open.

1.Tap on Options >Deactivate password lock.

2.Enter the password that is currently valid in the Enter password field.

3.Tap the Deactivate password lock button.

4.4Switching on NAVIGON 7100 | 7110

1.Press the (On/Off/Standby) switch for at least 6 seconds.

If password protection has been activated, the ENTER PASSWORD window opens.

2.Enter the password.

3.Tap the Continue button.

4.4.1Forgotten your password?

If you have forgotten your password, proceed as follows:

1.Tap the (Info) button.

2.Follow the instructions on the screen.

5 Navigation

Use navigation system at your own risk.

Caution! Please be sure to refer to the safety information in chapter"Important safety information" on page11.

- 18 -

Navigation

User's manual NAVIGON 7100 | 7110

Impaired GPS reception

If GPS reception is impaired, navigation will be interrupted. The navigation software remains active.

As soon as GPS reception is restored, the navigation system calculates any change of position which has occurred in the meantime. Navigation may simply be continued.

Arriving at your destination

When you have reached the specified destination, a message to this effect will be displayed.

Only your current position (triangle in orange) will now be shown on the map.

5.1Starting NAVIGON 7100 | 7110

1.Switch your navigation device on.

Each time the navigation device has been switched off completely

(by pressing the (On/Off/Standby) switch for at least 6 seconds) the following message appears when the software is started again:

"Please note that the road traffic regulations are prior to the instructions of the navigation system. Please do not operate the device while driving."

2.After you have read and fully understood the text, tap the OK button.

If you do not accept these instructions, then tap the Cancel button in order to quit the navigation software.

The MAIN WINDOW will open. You can reach all of the navigation software functions via theMAIN WINDOW.

5.1.1Initialising the GPS receiver

Note: It can take up to 20 minutes to initialise the integrated GPS receiver for the first time.

Each time you switch on the receiver after this, the GPS reception will start within one minute.

If the navigation device has been switched off for more than a week, the next initialisation can take up to 10 minutes.

As soon as the navigation device has been switched on, initialisation of the GPS receiver will begin.

Navigation

- 19 -

User's manual NAVIGON 7100 | 7110

In the right-handtop corner of the display, you will see theGPS symbol. As soon as data from at least 3 satellites is received, the symbol

changes to GPS Ready.

Note: If theGPS symbol displaysGPS Ready after considerably less than 20 minutes, it is advisable to leave the receiver switched on for at least a further 15 minutes so as to ensure reliable operation.

Caution! If you have connected the navigation device to the power supply via the vehicle's cigarette lighter, remove the connector before you leave the vehicle standing for a longer period of time.

As the GPS receiver requires a constant supply of power, it could drain the vehicle´s battery.

Opening the Main Window

The MAIN WINDOW opens when the navigation software starts.

If another window is open, tap the (Back) button. The previous window will open.

Tap the (Back) button repeatedly, until the MAIN WINDOWopens.

5.2Specifying a new destination

New destinations for the NAVIGON 7100 | 7110 are all destinations that you have not yet navigated, or you have not yet stored.

You can enter an address here, select a special destination, or select a destination from the quick search function.

When you enter a new destination for the first time, the COVERED COUNTRIESlist opens.

Tap on the country in which your destination lies.

5.2.1Specifying the destination country

Above the right-handupper corner of the uppermost entry field of the

ADDRESS, POI IN ACITY, and POI OFNATIONALSIGNIFICANCEwindows, is the Country button. It shows the country code of the country from which navigation destinations can currently be entered.

If your destination is in a different country, then proceed as follows:

1.Tap the Country button.

The COVERED COUNTRIESlist opens.

2.Tap on the country in which your destination lies.

- 20 -

Navigation
