NAVIGON 72 Easy, 72 Plus, 72 Plus Live, 72 Premium User Manual

0 (0)

NAVIGON 72 Easy NAVIGON 72 Plus NAVIGON 72 Plus Live NAVIGON 72 Premium

User’s manual

English (United Kingdom)

October 2011

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of- life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal waste.

Imprint

NAVIGON AG Schottmüllerstraße 20A

D-20251 Hamburg

The information contained herein may be changed at any time without prior notification. Neither this manual nor any parts thereof may be reproduced for any purpose whatsoever without the express written consent of NAVIGON AG, nor may they be transmitted in any form either electronically or mechanically, including photocopying and recording. All technical specifications, drawings etc are subject to copyright law.

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Table of contents

1	Introduction		.......................................................................................	7
	1.1	About this manual................................................................................		7
		1.1.1 ..........................................................................	Conventions	7
		1.1.2 ................................................................................	Symbols	7
	1.2	Legal notice .........................................................................................		7
		1.2.1 .................................................................................	Liability	7
		1.2.2 .........................................................................	Trade marks	8
	1.3	Questions ................................................................about the product		8

2	Before you begin...............................................................................			8
	2.1	Scope of Delivery ................................................................................		8
	2.2	Description of the navigation device.....................................................		9
	2.3	Important safety information ................................................................		9
		2.3.1	Navigation safety information..............................................	10
		2.3.2	Safety information for the navigation device........................	10
		2.3.3	Safety information for installing the device in your car.........	11
	2.4	Preparing the navigation system for use ............................................		11
		2.4.1	SIM card .............................................................................	11
		2.4.2	Installing the navigation system in the vehicle.....................	12
		2.4.3	Memory card.......................................................................	14
	2.5	Activating the NAVIGON Live services ..............................................		14
	2.6	Navigating with GPS..........................................................................		15

3	Switching on the navigation device ..............................................			16
	3.1	Switching on the device .....................................................................		16
	3.2	Switching the navigation device to standby mode ..............................		16
	3.3	Switching off the navigation device ....................................................		17
4	Using the Navigation System for the First Time ..........................			17
5	Operating the navigation system ..................................................			19
	5.1	Switching to a different application.....................................................		20
		5.1.1	Scrolling..............................................................................	20
		5.1.2	Using the button bar ...........................................................	20
		5.1.3	Options...............................................................................	20
	5.2	Information ........................................................................................		20
	5.3	Software keyboard.............................................................................		24
		5.3.1	Special keys .......................................................................	24
		5.3.2	Latin keyboard layout..........................................................	24
		5.3.3	Cyrillic and Greek keyboard layout......................................	25
		5.3.4	Entering data ......................................................................	26
6	Voice Command..............................................................................			26
	6.1	Activating the voice commands function ............................................		27
	6.2	Use Voice Command.........................................................................		27
	6.3	Help...................................................................................................		28
	6.4	Deactivation of the voice commands function ....................................		28
	6.5	Configuring the voice commands function..........................................		28

User’s manual

Table of contents w III

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

7	Navigation........................................................................................			29
	7.1	Starting the navigation application .....................................................		29
	7.2	Specifying a destination.....................................................................		30
		7.2.1	Specifying the country in which the destination is
			situated...............................................................................	31
		7.2.2	Enter an Address................................................................	31
		7.2.3	Announcing the address .....................................................	33
		7.2.4	Points of interest.................................................................	34
		7.2.5	Information about the destination........................................	37
		7.2.6	Favourites...........................................................................	38
		7.2.7	Last Destinations ................................................................	39
		7.2.8	From the phone book..........................................................	39
		7.2.9	Navigating home.................................................................	40
		7.2.10	Selecting destinations on the map ......................................	40
		7.2.11	Options in the Destination window ......................................	41
		7.2.12	Route preview.....................................................................	41
	7.3	Managing destinations.......................................................................		44
		7.3.1	Saving destinations.............................................................	44
		7.3.2	Deleting a destination .........................................................	45
		7.3.3	Renaming a destination from the Favourites list..................	45
		7.3.4	Defining the home address .................................................	46
		7.3.5	Changing the home address...............................................	46
	7.4	Multi-leg routes..................................................................................		47
		7.4.1	Opening the route planning.................................................	47
		7.4.2	Planning a new route ..........................................................	47
		7.4.3	Editing route points.............................................................	48
		7.4.4	Managing routes.................................................................	49
		7.4.5	Restoring the last route.......................................................	51
		7.4.6	Calculating and displaying routes........................................	51
		7.4.7	Simulating routes................................................................	52
		7.4.8	Route preview.....................................................................	52

8 Working with the map.....................................................................			54
8.1	Selecting the navigation map.............................................................		54
8.2	Map in Standard mode ......................................................................		54
8.3	Map in Route preview mode ..............................................................		56
8.4	Map in Navigation mode ....................................................................		58
	8.4.1	Navigation in Vehicle mode.................................................	58
	8.4.2	Navigation in Pedestrian mode ...........................................	62
	8.4.3	Map options in Navigation mode.........................................	64
	8.4.4	Quitting navigation..............................................................	65
8.5	Map in Destination search mode........................................................		65
	8.5.1	Changing the map section ..................................................	66
	8.5.2	Set destination....................................................................	67
	8.5.3	Shifting the destination point...............................................	67
	8.5.4	Deleting a destination point.................................................	67

IV  Table of contents

User’s manual

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

9	Useful functions..............................................................................			68
	9.1	Route Profiles....................................................................................		68
		9.1.1	Route profile settings ..........................................................	68
		9.1.2	NAVIGON basic profiles .....................................................	68
		9.1.3	Creating a new route profile ................................................	69
		9.1.4	Selecting a route profile ......................................................	69
		9.1.5	Managing route profiles ......................................................	70
	9.2	Screenshots ......................................................................................		71
		9.2.1	Enabling screenshots ..........................................................	71
		9.2.2	Creating a screenshot .........................................................	71
	9.3	Parking near the destination ..............................................................		72
		9.3.1	Special functions along a route with several stages ............	73
	9.4	MyBest POI: POI on Your Route........................................................		74
		9.4.1	Displaying POIs along the route ..........................................	75
		9.4.2	Navigating to one of the destinations ..................................	76
		9.4.3	Selecting categories ...........................................................	76
	9.5	GPS Status, saving the current location.............................................		77
	9.6	Block	.................................................................................................	77
	9.7	TMC ...................................................................(Traffic Information)		78
		9.7.1 .........................................	Route Optimisation: On Request	78
		9.7.2 ............................................	Route Optimisation: Automatic	80
		9.7.3 ...............................................	Displaying traffic information	81
		9.7.4 ....................................................	Filtering traffic messages	83
		9.7.5 ....................................	Showing a single message in detail	83
		9.7.6 ...........................................................................	Edit Mode	84
		9.7.7 ...............................................	Options (Traffic Information)	85
		9.7.8 ...............................................	Settings (Traffic Information)	86

10 Handsfree Module...........................................................................			87
10.1	Bluetooth Connection ........................................................................		89
	10.1.1 Searching for and pairing Bluetooth devices .......................		89
	10.1.2 Pairing from the mobile phone ............................................		91
	10.1.3 Connecting to a device .......................................................		91
	10.1.4	Activating a mobile phone...................................................	93
	10.1.5	Deleting devices .................................................................	93
	10.1.6	Import Phone Book.............................................................	94
	10.1.7	Import recent calls ..............................................................	96
10.2	Taking a call ......................................................................................		96
10.3	Receiving a text message..................................................................		96
10.4	Making a call .....................................................................................		97
	10.4.1 Dialling a telephone number ...............................................		97
	10.4.2 Dialling a Speed Call number..............................................		97
	10.4.3 Calling a contact from the phone book................................		98
	10.4.4 Calling most recently dialled, received or missed
		numbers .............................................................................	98
	10.4.5 Transferring a call from your mobile telephone ...................		99

User’s manual

Table of contents w V

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

	10.5	During a call ......................................................................................		99
		10.5.1 Go back to entering a destination........................................		99
		10.5.2 Moving the map to the foreground ......................................		99
		10.5.3	Entering numbers ...............................................................	99
		10.5.4	Muting the microphone .....................................................	100
		10.5.5 Transferring a call to the mobile phone .............................		100
		10.5.6	Ending the call ..................................................................	100
	10.6	Useful functions ...............................................................................		100
		10.6.1 Navigating to a contact from the phone book ....................		100
		10.6.2	Opening the mailbox.........................................................	101
	10.7	Configuring the hands-free function .................................................		101
		10.7.1	Preset...............................................................................	101
		10.7.2	Settings ............................................................................	102
11	NAVIGON Live ...............................................................................			103
		11.1.1	Costs ................................................................................	105
	11.2	Using the NAVIGON Live services...................................................		105
		11.2.1	Weather Service Live........................................................	105
		11.2.2 Safety Cameras Live (Mobile Safety Camera Live) ...........		107
		11.2.3 Parking Live (CleverParking Live).....................................		108
		11.2.4	Fuel Live...........................................................................	109
		11.2.5 Local Search (Google Local Search).................................		111
		11.2.6	Events Live.......................................................................	112
		11.2.7	Traffic Information (Traffic Live) ........................................	114
	11.3	Configuring the NAVIGON Live services..........................................		115
	11.4	Indicating the status.........................................................................		115
	11.5	NAVIGON Live modem check..........................................................		116
	11.6	Information about all aspects of the navigation system ....................		116
12 Configuring the Navigation System ............................................				117
13	Appendix .......................................................................................			119
	13.1	Technical data of the navigation device ...........................................		119
	13.2	NAVIGON Licensing Policy..............................................................		121
	13.3	Declaration of conformity .................................................................		125
14	Troubleshooting............................................................................			125
15	Index	..............................................................................................		128

VI  Table of contents

User’s manual

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

1 Introduction

1.1About this manual

1.1.1Conventions

For better legibility and clarification, the following styles are used in this manual:

Bold and italics:	Names of products
SMALL CAPITALS:	Names of windows and dialogue boxes
Bold:	Highlighting of important parts in the text
Underlined:	Descriptions of buttons, input boxes and other
	elements on the user interface
Underlined and italics:	Names of control elements on the navigation device

1.1.2Symbols

The following symbols draw attention to specific passages of text:

Instructions and tips for operating the software

More detailed information and explanations

Warnings

1.2Legal notice

1.2.1Liability

The software and manual are subject to change without notice. NAVIGON AG is not liable for the accuracy of the information contained in this manual or for damages resulting from the use of this manual.

Suggestions for improvements and information regarding errors are always welcome so that we can supply you with even better products in the future.

Introduction

- 7 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

1.2.2Trade marks

All brand and trade marks mentioned in this document and registered by third parties are subject without reservation to copyright law and the proprietary rights of their respective owners. All trade marks, trade names and company names used in this document are or may be trade marks or registered trademarks of their respective owners. All rights reserved except those explicitly granted.

If the registered trade marks used in this manual are not explicitly identified as such, this does not imply that the name is not subject to the rights of a third party.

►Microsoft, Outlook, Excel and Windows are registered trade marks of the Microsoft Corporation.

►NAVIGON is a registered trade mark of NAVIGON AG.

1.3Questions about the product

You have a question concerning your product? Then visit our website www.navigon.com and click on "Customer Services". There you will find an area with frequently asked questions (FAQ Center) along with details of how to contact us by phone or e-mail.

2 Before you begin

2.1Scope of Delivery

Please check that the contents are complete. If anything is missing, get in touch immediately with the dealer who sold you the product.

The purchased product includes the following:

►Navigation device

►Designer car cradle

►Car charger cable (12V adapter for the vehicle's cigarette lighter) with integrated TMC antenna

►USB cable

►Illustrated installation instructions Only NAVIGON 72 Plus Live:

►Quick guide NAVIGON Live Services

►SIM card holder. The card holder is glued in the leaflet and can be removed easily. The SIM card has been broken out of its holder already.

►SIM card (is already inserted in the navigation device)

- 8 -

Before you begin

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Note: Keep the SIM card holder in a safe place! You will need the data printed on this holder if you ever have to contact the NAVIGON Service Centre for assistance.

2.2Description of the navigation device

On/Off

2Touch-screen

3Microphone (only NAVIGON 72 Premium)

4	Mini USB socket for USB cable / mains adapter
5	Slot for microSD memory card
6	Reset

7LED

8Slot for SIM card (only NAVIGON 72 Plus Live)

2.3Important safety information

In your own interest, please read the following safety information and warnings carefully before starting up your navigation system.

Before you begin

- 9 -

NAVIGON 72 Easy, 72 Plus, 72 Plus Live, 72 Premium User Manual

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

2.3.1Navigation safety information

Use the navigation system at your own risk.

Caution! To prevent accidents, do not operate the navigation system while driving.

Caution! Do not look at the screen unless it is absolutely safe to do so!

Caution! Traffic regulations have priority over any instructions from the navigation system.

Caution! Follow the instructions of the navigation system only when the circumstances and the road traffic regulations allow you to do so! The navigation system will still guide you to your destination even if you deviate from the calculated route.

Caution! Check that the cradle is secured and adjusted properly before each journey.

2.3.2Safety information for the navigation device

Caution! Protect the device from moisture. The device is neither waterproof nor protected against splash water.

Caution! Do not open the case of the navigation device under any circumstances.

Caution! Do not expose the navigation device to extreme heat or cold.

This may damage the device or impair its function (see "Technical data " on page 119).

Caution! Never unplug by pulling the cable. Doing so could severely damage or destroy the device.

Caution! Do not subject the navigation device to severe temperature fluctuations. This can lead to condensation.

Note: Do not kink the cable. Make sure that the cable cannot be damaged by sharp-edged objects.

Note: Create a backup of the data which exist in the internal memory of your navigation device.

This is very easy to do with the NAVIGON Fresh software which can be downloaded free of charge from our website www.navigon.com/fresh.

- 10 -

Before you begin

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

2.3.3Safety information for installing the device in your car

Caution! Fasten the cradle so that the navigation device is easy to see and operate by the driver. Make sure that the driver's view of the traffic is not impeded.

Caution! Do not attach the cradle within the working zone of any airbags.

Caution! Do not fasten the cradle too close to the steering wheel or other controls. The driver must not be obstructed in operating any car functions.

Caution! When installing the cradle, make sure that it will not pose a risk in the event of an accident.

Caution! Do not run cables within the operating radius of airbags or in the direct vicinity of other safety-relevant devices and power supply lines.

Caution! Check that the cradle is secured and adjusted properly before each journey. The suction cup may become loose after a while.

Caution! After installation, check all safety-relevant equipment in the car.

Caution! Connect the car charger cable only to cigarette lighters with an operating voltage of 12V.

Caution! Disconnect the car charger cable from the cigarette lighter whenever you park the car. The integrated mains adapter always consumes a small amount of energy and could drain the car battery.

2.4Preparing the navigation system for use

2.4.1SIM card

This chapter is relevant for you only if your navigation device is a

NAVIGON 72 Plus Live.

Before you begin

- 11 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Inserting the SIM card

The SIM card is already inserted The SIM card slot is on the left side of

the navigation device (see illustration, point 8 in chapter "Description of the navigation device" on page 9).

Removing the SIM card

1. .Switch off the navigation device. Do this by briefly pressing the (On/Off) key and then tapping on the Switch off button.

2.Press the memory card gently into the device until the lock disengages.

Note: If the SIM card is not correctly inserted, it may be impossible to establish a connection to the NAVIGON server. In this case the NAVIGON Live services will not be available.

Note: If no connection can be established to the NAVIGON Live server, you can perform a modem test (see "NAVIGON Live modem check" on page 116).

Note: Do not remove the SIM card except for an important reason.

Removing and reinserting the card frequently may impair the card's function.

2.4.2Installing the navigation system in the vehicle

Caution! Be sure to refer to all the safety information in chapter "Important safety information" on page 9.

Securing the cradle

1.Clean the suction cup and that part of the windscreen to which you want to secure the cradle. Both must be dry and free of dirt and grease.

2.Open the lever on the suction cup as far as possible.

- 12 -

Before you begin

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

3.Place the cradle suction cup against the windscreen.

4.Press the lever towards the windscreen.

Inserting the navigation device into the cradle

On the back of the navigation device you will see a circle with two recesses.

1.Hang the navigation device by the upper recess on the upper lug of the cradle (see the figure).

2.Then press it towards the cradle so that it latches in place.

Supplying power to the navigation device

Included in delivery of the navigation device is a car charger cable with which power can be supplied to the navigation device via the vehicle's cigarette lighter.

Note: Use only the charger cable supplied with your navigation device or an equivalent model from NAVIGON!

If you use a different charger cable, the NAVIGON Live services might not be available.

►Connect the car charger cable to the vehicle's cigarette lighter and to the mini USB socket of the navigation device.

The LED on the bottom of the navigation device lights up orange during charging.

As soon as the battery is fully charged, the LED lights up green.

Caution! Connect the car charger cable only to cigarette lighters with an operating voltage of 12V.

Caution! Be sure to refer to all the safety information in chapter "Important safety information" on page 9.

Before you begin

- 13 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Note: Insert the USB connector securely in the corresponding USB sockets!

Note: It takes approx. 3 hours to charge the device when the battery is flat.

A fully charged battery enables up to 3 hours of use depending on the device configuration.

TMC antenna

The navigation device has an integrated TMC receiver. The TMC antenna is integrated in the car charger cable. Once the car charger cable is connected, the device can receive current traffic messages. If required, it can change your route dynamically, e.g. in order to avoid a traffic jam.

2.4.3Memory card

A memory card is not required to operate the navigation system because all the data required for navigation are stored in the internal memory of the device.

When you connect the navigation system to your computer using a USB cable, the internal memory is detected as the 'NAVIGON' drive. The slot for the memory card is detected as the 'NAVIGON SD' drive.

Data back-ups, software updates and navigation map updates can be carried out quickly and conveniently with the NAVIGON Fresh software, which you can download free of charge from the website www.navigon.com/fresh.

If you purchase additional navigation maps but no longer have enough space for them in the internal memory of your navigation device, it is also possible for you to save these maps on a memory card microSD which you then insert in the device. The navigation system can use navigation maps from both memories.

2.5Activating the NAVIGON Live services

This chapter is relevant for you only if your navigation device is a

NAVIGON 72 Plus Live.

The NAVIGON Live services must be activated before they are used for the first time. (See "Costs" on page 105)

The SIM card is already inserted.

The NAVIGON Live Services quick guide with the activation code which came with device is to hand.

1.Switch on the navigation device. The NAVIGATION window opens.

- 14 -

Before you begin

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

2.Tap on (NAVIGON Live).

You will be asked whether you want to activate the NAVIGON Live services.

3.Tap on OK.

4.The ACTIVATION CODE window opens.

5.Enter the activation code.

6.Tap on OK.

The NAVIGON Live services are now activated.

7.Tap on OK.

The following message appears: "You are sending 'Floating Car Data' to NAVIGON in anonymised form. The evaluation of these data will help us, our affiliates, and our partners in calculating times of arrival more precisely, in recognizing traffic congestion sooner, and in planning alternative routes more reliably. No information about your person can be derived from the data. If you do not agree, select 'No' for the setting 'Optimise Traffic Recognition'."

8.Tap on Next.

The NAVIGATION window is opened. From here you have access to all the functions of your navigation device and all available NAVIGON Live services.

Note: Even after activation, location-related NAVIGON Live services

(e.g. Fuel Live or Events Live) will be available only when the navigation device has GPS reception and can determine its position.

2.6Navigating with GPS

GPS is based on a total of at least 24 satellites orbiting the Earth and continuously transmitting signals of their position and time. The GPS receiver receives this data and calculates its own geographical position on the basis of the information transmitted by the various satellites.

Data from at least three satellites is required for positioning with an acceptable degree of accuracy. With data from four or more satellites it is possible in addition to determine the position's altitude above sea level. Positioning is accurate to within three metres.

Once the navigation device has determined your position, this position can be used as a starting point for calculating a route.

The map data on your navigation device includes the geographical coordinates of all digitally recorded points of interest, streets and places. This enables the device to calculate a route between a starting point and a destination.

Before you begin

- 15 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Calculation of the current position and its representation on the map take place approximately once every second. In other words, your current position is always shown on the map.

3 Switching on the navigation device

The navigation device can be in one of three states:

►On: The navigation device is on and can be operated.

►Standby: When you switch the navigation device to standby mode, the next time it is switched on it will start very quickly and with the window which was active when switched off. In standby mode the device still consumes a small amount of energy however. Depending on how full the battery is, it can become flat within a few days or a few weeks.

►Off: When you switch off the device, it consumes hardly any energy. It can then take several months for the battery to become flat. Switching the device on again triggers a restart which can take some time (approx. 60 seconds). Your settings and your saved destinations and routes will be retained.

3.1Switching on the device

►Press the (On/Off) key and keep it pressed until the device switches on.

The NAVIGATION window opens.

3.2Switching the navigation device to standby mode

►Press briefly on the (On/Off) key (max. 1 second).

A message will appear telling you that the device will be switched to standby mode in several seconds.

►Wait for the device to be switched to standby mode or tap on Standby.

Automatic Standby

You can configure the navigation device so that it is automatically switched to standby mode when not in use.

► In the NAVIGATION window tap on (More) > System Settings > Power and Screen > Automatic Standby.

►Select after how much time you want the navigation device to be switched to standby mode (Never, After 10 mins., After 20 mins., After 30 mins.).

- 16 -

Switching on the navigation device

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

►Select Power Loss in order to switch the device to standby mode when the external power supply is interrupted. As soon as the device is connected again to the external power supply it will switch on again automatically.

3.3Switching off the navigation device

►Press the (On/Off) key and keep it pressed until the device switches off (approx. 10 seconds).

- or -

1.Press briefly on the (On/Off) key (max. 1 second).

A message will appear telling you that the device will be switched to standby mode in several seconds.

2.Tap on Switch off.

4Using the Navigation System for the First Time

When you switch on the navigation system for the first time, you will be asked to make a number of basic settings:

The LANGUAGE window opens.

1.Select your preferred language for using the software.

2.Tap on OK.

The DISTANCE UNIT window opens.

3.Determine how you want distances to be shown ('Kilometres' or 'Miles').

4.Tap on OK.

The TIME FORMAT window opens.

5.Determine the time format ('12h (am/pm)' or '24h').

6.Tap on OK.

The DATE FORMAT window opens.

7.Select the date format. This means:

►YYYY: the year in 4 digits

►MM: the month in 2 digits

►DD: the day in 2 digits

8.Tap on OK.

If you purchased your navigation system together with the add-on

NAVIGON Safety Camera, the WARN OF SAFETY CAMERAS window will open.

Using the Navigation System for the First Time

- 17 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

9.Read the text in this window very carefully. It describes the settings which you can make for the add-on.

10.Tap on OK.

The WARN OF SAFETY CAMERAS window opens.

11.Select the setting you want.

12.Tap on OK.

►If you have selected the Uninstall option, you will be asked to confirm the deinstallation of the add-on.

►Tap on Yes.

Note: If you deinstall NAVIGON Safety Camera, the add-on can be installed again only by using the NAVIGON Fresh software.

The PRESENTATION MODE window opens.

Presentation mode is intended solely for presenting the product when no GPS reception is possible.

When presentation mode is active, navigation is not possible. Presentation mode is designed solely to simulate navigation to the centre of the indicated destination.

13.Make sure that the Start in Presentation Mode checkbox is not activated. If necessary, tap on the checkbox in order to set the

value Yes (	checkbox activated) to No (	checkbox not
activated).
14. Tap on OK.

Note: How to deactivate presentation mode is explained in

"Troubleshooting" in section "I have accidentally activated presentation mode" on page 126).

There then follows a series of pictures which demonstrate the basic operations of the navigation device.

You can use the	(Next) button and the	(Back)
button to switch between the other pictures.

15.Look at all the pictures. - or -

►Tap on Done.

Note: In the NAVIGATION windw tap on (More) > Show Introduction if you want to see the introduction again later.

A window with the following message opens:

- 18 -

Using the Navigation System for the First Time

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

"Please note that the road traffic regulations are prior to the instructions of the navigation system. Please do not operate the device while driving."

16.After you have read and fully understood the message, tap on OK.

If you do not accept the content of the message, tap on Cancel in order to exit the navigation application.

A window with several buttons opens.

17.Tap on any point of the screen. The NAVIGATION window opens.

5 Operating the navigation system

Note: You received a brief introduction to the navigation system's operation when you first started it. In the NAVIGATION window tap on

(More) > Show Introduction if you want to see the introduction

again.

Essentially, the navigation software comprises several applications whose number varies according to the range of functions offered by your navigation device. From these applications you have access to all the functions and settings possible with the navigation system.

At the bottom edge of the screen is a bar with several buttons.

Each button represents an application. A coloured bar over a button indicates that the related application is currently open (here:

NAVIGATION)

(Handsfree Module): Opens the HANDSFREE MODULE window, see "Handsfree Module" on page 87. (only NAVIGON 72 Premium)

(Navigation): Opens the NAVIGATION window; there you have access to all the methods for entering and selecting a destination

(Show Map): Opens the map in Standard mode when no

navigation is in progress (see "Map in Standard mode" on page 54), or opens it in Navigation mode when navigation is in progress (see "Map in Navigation mode" on page 58).

(Navigation Options): Opens the NAVIGATION OPTIONS window; in it you will find useful functions for navigation and for adjusting the map.

(NAVIGON Live): Opens the NAVIGON LIVE window. There you have access to all NAVIGON Live services, see "NAVIGON Live" on page 103 (only NAVIGON 72 Plus Live).

Operating the navigation system

- 19 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

5.1Switching to a different application

Switching between applications is possible in various ways.

5.1.1Scrolling

Drag your finger horizontally over the screen in order to scroll between the applications.

►Drag you finger from left to right over the screen in order to open the application which lies to the left of the current application.

►Drag you finger from right to left over the screen in order to open the application which lies to the right of the current application.

5.1.2Using the button bar

You can use the button bar to switch quickly between different applications.

►Tap on a button to open the corresponding application.

The button bar is hidden on the map in Standard and Vehicle modes.

►Tap on the map to show the button bar.

►Tap on a button to open the corresponding application.

5.1.3Options


At the top right edge of many windows is the		(More) button
which you can use to move to more functions.
Touch the	(Cancel) button to close the window again without
executing a function.
More options can be reached via the		(Navigation Options)

button on the button bar. Here you will find useful functions for navigation and for adjusting the map.

5.2Information

Various information symbols are located at the top of many windows.

GPS

The GPS symbol can show the following GPS reception status:

No GPS (No symbol): The built-in GPS receiver is not operational. Contact us if the problem persists (see "Questions about the product" on page 8).

No Signal: Data is being received from less than three satellites. Position cannot be calculated.

- 20 -

Operating the navigation system

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

GPS Ready: Data is being received from at least 3 satellites. Position can be calculated.

Simulation: If a simulation is in progress, the Demo symbol will appear instead of the GPS symbol.

For details of the GPS status refer to chapter "GPS Status, saving the current location" on page 77.

Compass

The Compass symbol indicates in which direction you are currently heading. It can indicate the following points of the compass:

N, NE, E, SE, S, SW, W, NW

Energy

The Energy symbol can indicate the following states of the integrated battery:

The device is being supplied by an external power source. The battery is fully charged.

The battery cannot be charged because its temperature is too high.

The device is being supplied by an external power source. The battery is being charged.

The device is being supplied by its internal battery. The battery is fully charged.

The device is being supplied by its internal battery. The battery charge is sufficient.

The device is being supplied by its internal battery. The battery charge is low.

Traffic Information

TMC

The navigation system has an integrated TMC receiver which supplies up-to-date traffic information. Using this information the navigation system can change your route dynamically, for example in order to avoid a traffic jam.

Note: This function is only available if TMC traffic messages are being transmitted in the country in which you are travelling. This is not the case in all countries.

Operating the navigation system

- 21 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

The TMC symbol can display the following TMC reception status:

Tuning (in red): The TMC receiver is operational but cannot find a transmitter that is sending TCM signals. There are no active traffic messages.

Tuning: The TMC receiver is operational but cannot find a station that is transmitting TMC signals. Traffic messages are active however. This can be the case, for example, when travelling through a tunnel.

TMC on Standby (in white): Traffic messages can be received.

Note: The TMC antenna is integrated in the car charger cable. The

Tuning symbol may still appear therefore when the car charger cable is not connected to the navigation device.

For details of the TMC function refer to chapter "TMC (Traffic

Information)" on page 78.

Traffic Live

This section is relevant for you only if your navigation device is a

NAVIGON 72 Plus Live.

You can draw traffic information either from the NAVIGON Live services (Traffic Live) or from radio stations (TMC). (Refer to "Configuring the NAVIGON Live services" on page 115.)

The Traffic Live symbol appears when you are drawing traffic information from the NAVIGON Live service.

The Traffic Live symbol can indicate the following traffic information reception states:

(Red) Connecting: The last attempt to call up traffic information from the NAVIGON Live server failed. This can be the case, for example, when travelling through a tunnel. Information which was called up previously may still be active however.

(White) Traffic Live Ready: Traffic information was called up successfully. The active information is up to date.

Muting

The Muting symbol can indicate the following states: No symbol: The navigation application is not muted.

Muting: The navigation application is muted. If the device is navigating at the moment, you will not hear any driving instructions.

- 22 -

Operating the navigation system

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Note: This symbol indicates only the muted state of the navigation instructions. It says nothing about the volume of the hands-free module.

Bluetooth / Phone

This section is relevant for you only if your navigation device is a

NAVIGON 72 Premium.

The navigation device has an integrated Bluetooth hands-free module. This enables you to use the device as a hands-free kit for up to two mobile phones with Bluetooth capability.

The Phone symbol can display the following states of the hands-free module:

No Bluetooth (No symbol): The Bluetooth function is deactivated.

Not connected (red mobile phone): The navigation device has no Bluetooth connection to another device.

Connected (white mobile phone): The navigation device is connected to a mobile phone and can be used as a hands-free car kit. The number indicates which of the two phones is currently active.

Call in Progress (green mobile phone): The hands-free module of the navigation device is being used for a phone call. The number indicates which of the two phones is being used to make the call.

Headset: A headset is connected. All the instructions given by the navigation system are heard over the headset. The telephone functions of the hands-free module are not available.

NAVIGON Live Services

This section is relevant for you only if your navigation device is a

NAVIGON 72 Plus Live.

The NAVIGON Live Services symbol indicates the availability of the NAVIGON Live services. The following states can be symbolised:

(No symbol) No NAVIGON Live Services: The NAVIGON Live services are deactivated. (Refer to "Configuring the NAVIGON Live services" on page 115)

Operating the navigation system

- 23 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

(Red) Connecting: There is no connection yet to the NAVIGON Live server. This can be due to the following:

►The mobile radio connection is interrupted.

►The NAVIGON Live server is not answering.

(White) NAVIGON Live Services Ready: There is a connection to the NAVIGON Live server. The NAVIGON Live services are available.

5.3Software keyboard

A software keyboard appears on the screen when text entries are necessary.

When you want to enter addresses, names or POIs, the keyboard with the alphabet for the country in question will open automatically.

When you want to save a destination to Favourites or when you enter a POI category or a country, the keyboard with the alphabet of the user interface will open automatically.

All entries can be made on the software keyboard using your fingertips. Only capital letters can be entered.

When entering town or street names you need not enter any special characters or umlauts. The navigation system fills in these characters for you automatically. For example, if you are looking for the town of "Bärnau", then simply type in the word "BARNAU". Special characters may be helpful however when naming saved destinations and routes.

5.3.1Special keys

inserts a space.

deletes the character in front of the cursor.

5.3.2Latin keyboard layout

With the two buttons at the bottom right and bottom left edge of the screen you can switch between the keyboard for letters, the keyboard for special characters and the keyboard for numbers.

Left key:

/ : Switches between the keyboard for numbers and the keyboard for letters.

- 24 -

Operating the navigation system

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Right key:

/ : Switches between the keyboard for special characters and the keyboard for numbers.

Note: The layout for the keyboard with the Latin alphabet can be configured.

► In the NAVIGATION window tap on (More) > System Settings > Language and Keyboard > Keypad layout (Latin).

►Select the layout you want to use: Alphabetical (ABCDEF), English (QWERTY), German (QWERTZ), French (AZERTY).

5.3.3Cyrillic and Greek keyboard layout

You can also switch from the Cyrillic or Greek keyboard to the Latin keyboard. Many addresses can then also be entered as transliterations or in the language of the user interface.

Example: The language of the user interface is English. You want to navigate to Moscow. You have the following options:

►"Москва" (Cyrillic)

►"Moskva" (transliterated)

►"Moscow" (English).

Note: Street names and place names can be entered only in the language of the user interface if that is how they exist in the map's database.

With the button at the bottom left edge of the screen you can switch between the Latin and Cyrillic or the Latin and Greek keyboard, with the button at the bottom right edge of the screen you can switch between the keyboard for letters, the keyboard for special characters and the keyboard for numbers.

Cyrillic keyboard layout

Left key:

/ : Switches between the Latin and Cyrillic keyboard layout.

Right key:

Switches between the keyboard for special characters, the keyboard for numbers and the keyboard for letters of the current keyboard layout.

Operating the navigation system

- 25 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Greek keyboard layout

Left key:

/ : Switches between the Latin and Greek keyboard layout.

Right key:

Switches between the keyboard for special characters, the keyboard for numbers and the keyboard for letters of the current keyboard layout.

5.3.4Entering data

Often you can select an entry from a list. This is the case, for example, when you enter a location.

As soon as you enter the first letter, the largest city in the given country that begins with this letter appears.

Enter more letters and after each entry the first city which begins with these letters will appear.

► When the correct location appears, tap on	(OK) in order to
complete the entry.

You can open at any time a list containing all the locations which begin with the letters or include the text already entered. The more letters you enter, the shorter the list becomes.

►Tap on (Open List) in order to call up this list.

You can use the	(Up) and	(Down) buttons to scroll
through the list page by page.

►Tap on an entry in the list to select it and transfer it to the input box.

The list closes once an entry has been selected. You are now finished with entering the city.

►Tap on (Close List) in order to close the list without selecting an entry.

Note: The list opens automatically as soon as it contains only 4 or less entries.

6 Voice Command

This section is relevant for you only if your navigation device is a

NAVIGON 72 Premium.

- 26 -

Voice Command

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

Note: The Voice Command function is not available in every language.

For languages in which this function is not available, the Voice Command button is not shown in the NAVIGATION window.

Many functions of your navigation device can be called up conveniently by voice command.

6.1Activating the voice commands function

The voice commands function is automatically active in many windows. This applies in particular to windows in which you are expected to provide an answer, for example when there is a new traffic message concerning your route.

On the map in Standard or Navigation mode, the Voice Command function will be activated as soon as the button bar is shown.

►Tap on any point on the map.

You will hear a single acknowledgement tone and you can utter your command.

6.2Use Voice Command

When the functions in a window can be called up by voice command, this is indicated in the bottom left corner of the window by the symbol

(Voice command active).

A single signal tone and the symbol (Speak) indicate that the navigation system is waiting for your voice command.

►Say a command.

The positive acknowledgement tone sounds (two high-pitch tones) and the function is executed.

If the navigation system has not understood your instruction or if you do not say anything within a certain time, the negative acknowledgement tone (two short low-pitch tones) will sound.

►Say the command again.

If the navigation system has not understood you after several repetitions, the prompt "Say Help" will appear.

Note: Navigation instructions and warnings are muted for as long as the navigation device expects to receive voice commands from you.

Voice Command

- 27 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

6.3Help

Say only "Help" if you want to know which voice commands are currently possible. In nearly all windows in which voice commands are supported the navigation system will then tell you which commands you can say in the current window.

6.4Deactivation of the voice commands function

The voice commands function will be deactivated under the following conditions:

►If you operate the navigation device with your finger while a voice command is expected from you.

►If a call is received and during an active phone call if the navigation device is being used as a hands-free module.

6.5Configuring the voice commands function

You can configure for which tasks you want to use the voice commands.

► In the NAVIGATION window tap on	(More) > System
Settings > Voice Command.

Select the tasks for which you want to use Voice Command:

►Entering Addresses: You can enter only addresses with the voice command function.

►Answering: You can enter addresses and answer questions asked by the navigation device.

►Complete: You can use all the voice command functions.

Note: For details of how to enter a destination using voice commands refer to the chapter "Announcing the address" on page 33.

The volume of the voice commands assistant can be controlled independently of the volume of the navigation instructions. This means you can still hear the input requests when you have muted the navigation instructions.

1. In the NAVIGATION window tap on (More) > System Settings > Voice Command > Volume of the Assistant.

2. Select the volume for the assistant.

Note: For details of how to configure the navigation system refer to the chapter "Configuring the Navigation System" on page 117.

- 28 -

Voice Command

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

7 Navigation

Use the navigation system at your own risk.

Caution! Be sure to refer to all the safety information in chapter "Important safety information" on page 9.

Impaired GPS reception

If GPS reception is impaired (e.g. because you are in a tunnel), navigation will be continued. The navigation system will then calculate your likely position from the route data and your previous driving profile. As soon as GPS signals are received again, navigation will be continued with real GPS data.

Arriving at your destination

When you have reached your selected destination, a message to this effect will be displayed.

Only your current position (orange arrow) and the destination flag will now be shown on the map.

7.1Starting the navigation application

You have switched on the navigation device. The following message appears:

"Please note that the road traffic regulations are prior to the instructions of the navigation system. Please do not operate the device while driving."

►After you have read and fully understood the message, tap on OK.

If you do not accept the content of the message, tap on Cancel in order to exit the navigation application.

The NAVIGATION window is opened. From here you can access all the functions of the navigation application.

Initialising the GPS receiver

Note: Good reception of GPS data requires an unobstructed path from the GPS receiver to the satellites. Tunnels, narrow thoroughfares between buildings and reflecting house fronts can restrict GPS reception greatly or make it impossible. If the GPS receiver or the navigation device is inside a vehicle, a metallised windscreen or a windscreen heater can be the cause of poor GPS reception.

As soon as the navigation device has been switched on, initialisation of the GPS receiver will begin.

Navigation

- 29 -

User’s manual NAVIGON 72 Easy | 72 Plus | 72 Plus Live | 72 Premium

The integrated GPS receiver is not initialised for the first time until the navigation application is started for the first time. It can take up to

5 minutes to initialise the GPS receiver for the first time.

Each time you switch on the navigation device after this, GPS reception will start within a short time.

If the navigation device has not been switched on for more than a week, it can take up to 10 minutes to re-initialise the receiver.

Note: Directly after the GPS symbol indicates the GPS Ready state, the accuracy of the positioning may be reduced for a few minutes.

In the top right hand corner of the screen you will see the GPS symbol. As soon as data from at least three satellites is received, the symbol will

change to (GPS Ready).

Note: Initialisation takes the least time if you do not start driving until the initialisation has finished.

For more details about the GPS symbol refer to chapter "GPS" on page 20.

Returning to the Navigation window

The NAVIGATION window opens when the navigation application is started.

If a window with a visible button bar is opened:

►In the bar tap on (Navigation).

If the map is open in Standard mode or in Vehicle mode:

►Call up the button bar (see "Button bar" on page 61).

►In the bar tap on (Navigation).

If a different window of the navigation application is open:

►	Tap on	(Back). This will return you to the window you
	came from.
►	Tap on	(Back) repeatedly until the NAVIGATION window is
	opened.

7.2Specifying a destination

You can either enter a new destination or select a saved destination. To enter a new destination you can

►enter the address of the destination (see "Enter an Address" on page 31).

- 30 -

Navigation
