User’s manual
NAVIGON 63xx
English (United Kingdom)
September 2009
The crossed-out wheeled bin means that within the European Union
the product must be taken to separate collection at the product end-oflife. This applies to your device but also to any enhancements marked
with this symbol. Do not dispose of these products as unsorted
municipal waste.
Imprint
NAVIGON AG
Schottmüllerstraße 20A
D-20251 Hamburg
The information contained herein may be changed at any time without prior
notification. Neither this manual nor any parts thereof may be reproduced for any
purpose whatsoever without the express written consent of NAVIGON AG, nor may
they be transmitted in any form either electronically or mechanically, including
photocopying and recording. All technical specifications, drawings etc are subject to
copyright law.
2009, NAVIGON AG
All rights reserved.
User’s manual NAVIGON 63xx
User’s manual Table of contents III
Table of contents
1 Introduction.......................................................................................7
1.1 About this manual ...................................................................................7
1.1.1 Conventions .............................................................................. 7
1.1.2 Symbols ....................................................................................7
1.2 Legal notice.............................................................................................7
1.2.1 Liability ......................................................................................7
1.2.2 Trademarks ...............................................................................8
1.3 Questions about the product ...................................................................8
2 Before you begin...............................................................................8
2.1 Scope of Delivery ....................................................................................8
2.2 Description of the NAVIGON 63xx ..........................................................9
2.3 NAVIGON Suite ......................................................................................9
2.4 Important safety information..................................................................10
2.4.1 Navigation safety information..................................................10
2.4.2 Safety information for the navigation device ........................... 11
2.4.3 Safety guidelines when installing the device in your car.........11
2.5 Preparing the NAVIGON 63xx for use ..................................................12
2.5.1 Installing the navigation system in the vehicle ........................12
2.5.2 TMC antenna ..........................................................................14
2.5.3 Memory card ...........................................................................14
2.6 Navigation with GPS .............................................................................14
3 Switching on the NAVIGON 63xx...................................................15
3.1 Options..................................................................................................16
4 Password Lock................................................................................17
4.1 Activating password protection .............................................................17
4.2 Changing a password ...........................................................................17
4.3 Cancelling password protection ............................................................17
4.4 Forgotten your password? ....................................................................18
5 Operating the NAVIGON 63xx........................................................18
5.1 Information ............................................................................................18
5.2 Software keyboard ................................................................................20
5.2.1 Special keys............................................................................21
5.2.2 Entering data...........................................................................22
5.3 Options..................................................................................................22
5.4 Menus ...................................................................................................22
User’s manual NAVIGON 63xx
IV Table of contents User’s manual
6 Voice Command..............................................................................23
6.1 Use Voice Command ............................................................................23
6.2 Help.......................................................................................................23
6.3 Deactivation of the voice commands function.......................................24
6.4 Configuring the voice commands function ............................................ 24
7 Navigation .......................................................................................24
7.1 Starting the navigation application ........................................................ 25
7.2 Specifying a destination ........................................................................26
7.2.1 Specifying the country in which the destination is situated .....27
7.2.2 Entering a destination address ...............................................27
7.2.3 Enter Coordinates ...................................................................28
7.2.4 Entering a destination by voice commands ............................30
7.2.5 Points of interest .....................................................................31
7.2.6 Information about the destination............................................ 35
7.2.7 Favourites ...............................................................................36
7.2.8 Last Destinations ....................................................................36
7.2.9 Imported Addresses: Outlook / Internet ..................................37
7.2.10 Imported Addresses from the phone book..............................38
7.2.11 Navigating home .....................................................................38
7.2.12 Selecting destinations on the map ..........................................39
7.2.13 Route preview .........................................................................39
7.3 Managing destinations ..........................................................................41
7.3.1 Saving destinations.................................................................41
7.3.2 Defining the home address ..................................................... 42
7.4 Multi-leg routes or tracks.......................................................................43
7.4.1 Entering the starting point ....................................................... 43
7.4.2 Entering route points...............................................................44
7.4.3 Editing route points .................................................................44
7.4.4 Managing routes .....................................................................44
7.4.5 Loading routes or tracks .........................................................45
7.4.6 Calculating and displaying routes ...........................................45
7.4.7 Simulating routes ....................................................................46
7.4.8 Route preview .........................................................................46
8 Options............................................................................................48
9 Working with the map.....................................................................51
9.1 Selecting the navigation map................................................................51
9.2 Map in Standard mode..........................................................................51
9.3 Map in Preview mode............................................................................52
User’s manual NAVIGON 63xx
User’s manual Table of contents V
9.4 Map in Navigation mode .......................................................................54
9.4.1 Navigation in Vehicle mode ....................................................54
9.4.2 Navigation in Pedestrian mode ...............................................58
9.4.3 Navigation in Track mode .......................................................59
9.4.4 Navigation in Offroad mode ....................................................60
9.4.5 Map options in Navigation mode.............................................60
9.4.6 Quitting navigation ..................................................................60
9.5 Map in Destination search mode...........................................................61
9.5.1 Operating in Destination search mode.................................... 62
10 Useful functions..............................................................................62
10.1 Route profiles ........................................................................................62
10.1.1 Route profile settings ..............................................................63
10.1.2 NAVIGON basic profiles .........................................................63
10.1.3 Creating a new route profile....................................................64
10.1.4 Selecting a route profile ..........................................................64
10.1.5 Managing route profiles ..........................................................64
10.2 Screenshots ..........................................................................................66
10.2.1 Enabling screenshots..............................................................66
10.2.2 Creating a screenshot.............................................................66
10.3 Tracks ...................................................................................................66
10.4 Parking near the destination .................................................................67
10.5 Nearby...................................................................................................69
10.6 Warn from bends...................................................................................69
10.7 Direct Help ............................................................................................70
10.8 GPS Status, saving the current location ...............................................71
10.9 Block .....................................................................................................71
10.10 Turn-by-Turn List...................................................................................72
10.11 TMC (Traffic Information)......................................................................73
10.11.1 Preview TMC...........................................................................73
10.11.2 Displaying traffic messages ....................................................74
10.11.3 Showing a single message in detail........................................76
10.11.4 TMC Settings ..........................................................................76
10.12 Logbook ................................................................................................77
11 Handsfree Module...........................................................................78
11.1 Connection with Mobile Phone..............................................................79
11.1.1 Searching for and pairing Bluetooth devices ..........................79
11.1.2 Pairing from the mobile phone ................................................ 80
11.1.3 Connecting to a device ...........................................................81
11.1.4 Deleting a device ....................................................................82
11.1.5 Import Phone Book .................................................................82
11.1.6 Import recent calls...................................................................83
User’s manual NAVIGON 63xx
VI Table of contents User’s manual
11.2 Taking a call ..........................................................................................83
11.3 Making a call .........................................................................................84
11.3.1 Making a call with the voice commands function ....................84
11.3.2 Dialling a telephone number ...................................................85
11.3.3 Dialling a Speed Call number .................................................85
11.3.4 Calling a contact from the phone book ...................................85
11.3.5 Calling most recently dialled, received or missed
numbers ..................................................................................85
11.3.6 Transferring a call from your mobile telephone....................... 86
11.4 During a call ..........................................................................................86
11.4.1 Moving the navigation application to the foreground ..............86
11.4.2 Entering numbers....................................................................87
11.4.3 Muting the microphone ...........................................................87
11.4.4 Transferring a call to the mobile phone...................................87
11.4.5 Ending the call ........................................................................87
11.5 Useful functions.....................................................................................87
11.5.1 Navigating to a contact from the phone book .........................87
11.6 Configuring the hands-free function ......................................................88
11.6.1 Preset......................................................................................88
11.6.2 Settings ................................................................................... 89
12 Configuring the NAVIGON 63xx.....................................................90
13 Appendix .........................................................................................91
13.1 Technical data.......................................................................................91
13.2 NAVIGON – Licensing Policy................................................................ 92
13.3 Identification and serial number ............................................................ 96
13.4 Declaration of conformity ......................................................................96
14 Troubleshooting..............................................................................97
15 Index ................................................................................................99
User’s manual NAVIGON 63xx
Introduction - 7 -
1 Introduction
1.1 About this manual
1.1.1 Conventions
For better legibility and clarification, the following styles are used in this
manual:
Bold and italics: Names of products
S
MALL CAPITALS: Names of windows and dialogue boxes
Bold: Highlighting of important parts in the text
Underlined
: Descriptions of buttons, input boxes and other
elements on the user interface
Underlined and italics
: Names of control elements on the navigation
device
1.1.2 Symbols
The following symbols refer to specific passages of text:
Instructions and tips for operating the software
More detailed information and explanations
Warnings
1.2 Legal notice
1.2.1 Liability
The software and manual are subject to change without notice.
NAVIGON AG is not liable for the accuracy of the information contained
in this manual or for damages resulting from the use of this manual.
Suggestions for improvements and information regarding errors are
always welcome so that we can supply you with even better products in
the future.
User’s manual NAVIGON 63xx
- 8 - Before you begin
1.2.2 Trademarks
All brand and trade marks mentioned in this document and registered
by third parties are subject without reservation to copyright law and the
proprietary rights of their respective owners. All trade marks, trade
names and company names used in this document are or may be trade
marks or registered trademarks of their respective owners. All rights
reserved except those explicitly granted.
The absence of the explicit labelling of registered trademarks used in
this manual does not imply that the brand is not subject to the rights of a
third party.
► Microsoft, Outlook, Excel and Windows are registered trade marks
of the Microsoft Corporation.
► NAVIGON is a registered trade mark of NAVIGON AG.
1.3 Questions about the product
You have a question concerning your product? Then visit our website
www.navigon.com
and click on "Support". There you will find an area
with frequently asked questions (FAQ Center) along with details of how
to contact us by phone or e-mail.
2 Before you begin
2.1 Scope of Delivery
Please check that the contents are complete. If anything is missing, get
in touch immediately with the dealer who sold you the product.
The purchased product includes the following:
► NAVIGON 63xx navigation device
► 1 GB microSD memory card with software. The memory card is
already inserted in the navigation device.
► Designer car cradle
► Car charger cable (10-24V adapter for the vehicle's cigarette lighter)
with integrated TMC antenna
► USB cable
► Leaflet with illustrated installation instructions
► Fabric pouch
User’s manual NAVIGON 63xx
Before you begin - 9 -
2.2 Description of the NAVIGON 63xx
1
Touch-screen
2
Microphone
3
LED
4
Reset
5
Mini USB socket for USB cable / mains adapter
6
Slot for microSD memory card
7
On/Off
2.3 NAVIGON Suite
NAVIGON Suite is an application for your PC or Mac with many useful
functions.
► Read the manual (PDF file) for your navigation device.
► Get information about useful accessories.
► Install additional software designed to make it even easier for you to
use your navigation system:
► NAVIGON Fresh for keeping your navigation system up to date
at all times and for using additional services
► NAVIGON Sync for transferring contact addresses from
Microsoft Outlook to your navigation system
User’s manual NAVIGON 63xx
- 10 - Before you begin
How to install NAVIGON Suite:
1. Connect the navigation device to your computer with a USB cable.
2. Open the file manager on your PC or Mac (e.g. "Windows-Explorer"
on a PC or "Finder" on a Mac).
3. Open the NAVIGON window.
4. Execute the PC_Start.exe file (PC) or MAC_Start.exe file (Mac).
NAVIGON Suite is opened.
5. Select your language.
6. Select the function you want.
7. Follow the instructions on the screen.
2.4 Important safety information
In your own interest, please read the following safety information and
warnings carefully before starting up your navigation system.
2.4.1 Navigation safety information
Use the navigation system at your own risk.
Caution! To prevent accidents, do not operate the navigation system
while driving.
Caution! Do not look at the display unless it is absolutely safe to do so!
Caution! Traffic regulations have priority over any instructions from the
navigation system.
Caution! Follow the instructions of the navigation system only when the
circumstances and the road traffic regulations allow you to do so! The
navigation system will guide you to your destination even if you deviate
from the calculated route.
Caution! Check that the cradle is secured and adjusted properly before
each journey.
Note: If you have not understood the spoken instructions or are unsure
about what to do at the next junction, you can refer briefly to the map or
schematic view of your navigation system.
User’s manual NAVIGON 63xx
Before you begin - 11 -
2.4.2 Safety information for the navigation device
Caution! Protect the device from moisture. The device is neither
waterproof nor protected against splash water.
Caution! Do not open the case of the navigation device under any
circumstances.
Caution! Do not expose the navigation device to extreme heat or cold.
This may damage the device or impair its function. (Refer to "Technical
data" on p
age 91)
Caution! Never unplug by pulling the cable. Doing so could severely
damage or destroy the device.
Caution! Do not subject the navigation device to severe temperature
fluctuations.
This can cause condensation to form.
Note: Do not kink the cable. Make sure that the cable cannot be
damaged by sharp-edged objects.
Note: The fabric pouch delivered with the navigation device is made of
micro-fibre. The navigation device is best cleaned with this fabric pouch.
Note: Create a backup of the data in the internal memory of your
navigation device and on the supplied memory card.
This is very easy to do with the NAVIGON Fresh software which you
can install on your computer using NAVIGON Suite or download free of
charge from our website www.navigon.com
.
2.4.3 Safety guidelines when installing the device in your car
Caution! Fasten the cradle so that the navigation device is easy to see
and operate by the driver. Make sure that the driver's view of the traffic
is not impeded.
Caution! Do not attach the cradle within the working zone of any
airbags.
Caution! Do not fasten the cradle too close to the steering wheel or
other controls. The driver must not be obstructed in operating any car
functions.
User’s manual NAVIGON 63xx
- 12 - Before you begin
Caution! When installing the cradle, make sure that it will not pose a
risk in the event of an accident.
Caution! Do not run cables directly next to safety-relevant devices and
power supplies.
Caution! Check that the cradle is secured and adjusted properly before
each journey. The suction cup may become loose after a while.
Caution! After installation, check all safety-relevant equipment in the
car.
Caution! Connect the car charger cable only to cigarette lighters with
an operating voltage of 10-24V.
Caution! Disconnect the car charger cable from the cigarette lighter
whenever you park the car. The integrated mains adapter always
consumes a small amount of energy and could drain the car battery.
2.5 Preparing the NAVIGON 63xx for use
2.5.1 Installing the navigation system in the vehicle
Caution! Be sure to refer to all the safety information in chapter
"Important safety information" on page 10.
Securing the cradle
1. Clean the suction cup and that part of the windscreen to which you
want to secure the cradle. Both must be dry and free of dirt and
grease.
2. Open the lever on the suction cup as far as possible.
3. Place the cradle suction cup against the windscreen.
4. Press the lever towards the windscreen.
User’s manual NAVIGON 63xx
Before you begin - 13 -
Inserting the navigation device into the cradle
On the back of the NAVIGON 63xx you will see a circle with two
recesses.
1. Hang the navigation device by the upper recess on the upper lug of
the cradle. (See illustration)
2. Then press it towards the cradle so that it latches in place.
Supplying power to the naviga tion device
Included in delivery of the NAVIGON 63xx is a car charger cable with
which power can be supplied to the navigation device via the vehicle's
cigarette lighter.
► Connect the car charger cable to the vehicle's cigarette lighter and
to the mini USB socket of the navigation device.
Note: Plug the USB connector into the navigation device as far it will
go! (Refer to "Troubleshooting" on page
97.)
Caution! Connect the car charger cable only to cigarette lighters with
an operating voltage of 10-24V.
The LED on the bottom of the navigation device lights up orange during
charging.
As soon as the battery is fully charged, the LED lights up green.
Note: It takes approx. 3-4 hours to charge the device when the battery
is flat.
A fully charged battery enables up to 2 hours of use depending on the
device configuration.
Removing the navigation device from the cradle
On the bottom of the plate in which you hung the navigation device is a
clip.
1. Pull the clip towards yourself so that the device is released from the
clip.
2. Lift the device up and out of the cradle.
User’s manual NAVIGON 63xx
- 14 - Before you begin
2.5.2 TMC antenna
The NAVIGON 63xx has an integrated TMC receiver. The TMC
antenna is integrated in the car charger cable. Once the car charger
cable is connected, the device can receive current traffic messages. If
required, it can change your route dynamically, e.g. in order to avoid a
traffic jam.
2.5.3 Memory card
The scope of delivery includes a 1 GB microSD card containing the
navigation maps.
When you connect the NAVIGON 63xx to your computer using a USB
cable, the internal memory is detected as the 'NAVIGON' drive. The slot
for the memory card is detected as a removable disc.
Data backups, software updates and navigation map updates can be
carried out quickly and conveniently with NAVIGON Fresh, which you
can install on your computer using NAVIGON Suite or download free of
charge from our website www.navigon.com
.
If you purchase additional navigation maps but no longer have enough
space for them in the internal memory of your navigation device, it is
also possible for you to save these maps on a memory card. The
NAVIGON 63xx can use navigation cards from both memories.
The following memory media can be used in the NAVIGON 63xx:
► microSD cards
2.6 Navigation with GPS
GPS is based on a total of at least 24 satellites orbiting the Earth and
continuously transmitting signals of their position and time. The GPS
receiver receives this data and calculates its own geographical position
on the basis of the information transmitted by the various satellites.
Data from at least three satellites is required for positioning with an
acceptable degree of accuracy. With data from four or more satellites it
is possible in addition to determine the position's altitude above sea
level. Positioning is accurate to within three metres.
Once the navigation device has determined your position, this position
can be used as a starting point for calculating a route.
The map data on your navigation device includes the geographical
coordinates of all digitally recorded points of interest, streets and
places. This enables the device to calculate a route between a starting
point and a destination.
Calculation of the current position and its representation on the map
take place approximately once every second. In other words, your
current position is always shown on the map.
User’s manual NAVIGON 63xx
Switching on the NAVIGON 63xx - 15 -
3 Switching on the NAVIGON 63xx
1. Press the (On/Off) key and keep it pressed until the device
switches on. (Approx. 1,5 seconds)
If password protection has been activated, the E
NTER PASSWORD
window opens.
2. Enter the password.
3. Tap on OK
.
The N
AVIGATION window opens.
When you start the navigation application for the first time, the
D
EMO MODE settings window opens.
Demo mode is intended only for demonstrating the product when no
GPS reception is possible.
When demo mode is active, navigation is not possible! Demo mode
is designed solely to simulate navigation to the centre of the
indicated destination.
4. Make sure that the Start in Demo Mode
setting is at No. If
necessary tap on the
(Toggle), button in order to change the
setting from Yes
to No.
5. Tap on OK
.
Note: When you switch on the NAVIGON 63xx for the first time, you
will be asked to make the following settings:
► your preferred language for using for the software
► the unit of length for distances
► the time format
Note: If you have not used the NAVIGON 63xx for a long time, the
battery may be flat.
In this case the device must first be connected to the car charger cable
or to a suitable charger before it can be switched on. Chargers and
other accessories are available in the NAVIGON shop at
www.navigon.com
or in specialist stores.
Forgotten your password?
If you enter the password wrongly three times, a window will open with
instructions telling you what to do now.
► Follow the instructions on the screen.
Switching the navigation device to standby mode
► Press briefly (max. 1,5 seconds) on the (On/Off) key.
User’s manual NAVIGON 63xx
- 16 - Switching on the NAVIGON 63xx
- or -
1. Tap in the N
AVIGATION window of the navigation software on the
(Exit) button.
2. Tap on Standby
.
Automatic St andby
You can configure the NAVIGON 63xx so that the navigation device is
automatically switched to standby mode.
► In the NAVIGATION window tap on Options > Settings > General >
Automatic Standby
.
► Select after how much time you want the navigation device to be
switched to standby mode (Never
, After 10 mins, After 20 mins,
After 30 mins
).
► Select Power Loss in order to switch the device to standby mode
when the external power supply is interrupted. As soon as the
device is connected again to the external power supply it will switch
on again automatically.
Switching off the navigation device
► Press the (On/Off) key and keep it pressed until the device
switches off. (Approx. 4 seconds.)
- or -
1. Tap in the N
AVIGATION window of the navigation software on the
(Exit) button.
2. Tap on Off
.
Note: When you switch the navigation device to standby mode, the next
time it is switched on it will start very quickly with the window which was
active when switched off. In standby mode the device still consumes a
small amount of energy however. The battery may be flat after a few
days.
When you switch off the device, it consumes no energy. It can then take
several months for the battery to become flat. Switching the device on
again triggers a restart which can take some time (approx. 30 seconds).
Your settings and your saved destinations and routes will be retained.
3.1 Options
Some windows offer options that lead to more functions.
A description of all available options can be found in the chapter
"Options" on page 48.
User’s manual NAVIGON 63xx
Password Lock - 17 -
4 Password Lock
You can protect your navigation system from unauthorised use by
creating a password.
4.1 Activating password protection
1. In the NAVIGATION window tap on Options > Settings > Options >
Password Lock
.
The N
EW PASSWORD window opens.
2. Enter a password in the New password
box and tap on Next.
3. Enter this password again in the Confirm new password
box.
4. Tap on Activate
.
Note: The password must have exactly 4 digits.
4.2 Changing a password
1. In the NAVIGATION window tap on Options > Settings > Options >
Password Lock
.
The E
NTER PASSWORD window opens.
2. Enter the currently valid password in the Enter password
box.
3. Tap on Change password
.
The N
EW PASSWORD window opens.
4. Enter a password in the New password
box and tap on Next.
5. Enter this password again in the Confirm new password
box.
6. Tap on Activate
.
Note: The new password must have exactly 4 digits.
4.3 Cancelling password protection
1. In the NAVIGATION window tap on Options > Settings > Options >
Password Lock
.
The E
NTER PASSWORD window opens.
2. Enter the currently valid password in the Enter password
box.
3. Tap on Deactivate
.
User’s manual NAVIGON 63xx
- 18 - Operating the NAVIGON 63xx
4.4 Forgotten your password?
If you enter the password wrongly three times, a window will open with
instructions telling you what to do now.
► Follow the instructions on the screen.
5 Operating the NAVIGON 63xx
5.1 Information
Various information symbols are located at the top of many windows.
GPS
The GPS symbol can show the following GPS reception status:
No GPS (No symbol): The built-in GPS receiver is not operational.
Contact us if the problem persists. (Refer to "Questions about the
product" on
page 8)
No Signal: Data is being received from less than three satellites.
Position cannot be calculated.
GPS Ready: Data is being received from at least 3 satellites. The
position can be calculated.
For details of the GPS status refer to chapter "GPS Status, saving the
current location"
on page 71.
Compass
The Compass symbol indicates in which direction you are currently
heading. It can indicate the following points of the compass: N, NE, E,
SE, S, SW, W, NW.
Track
The (Record Track) symbol indicates that a track is being recorded
at this moment.
For more information about tracks refer to chapter "Tracks" on page 66.
User’s manual NAVIGON 63xx
Operating the NAVIGON 63xx - 19 -
TMC (Traffic Information)
The NAVIGON 63xx has an integrated TMC receiver which provides
the navigation system with traffic information updates. If necessary it
can change your route dynamically, for example in order to avoid a
traffic jam.
Note: This function is only available if TMC traffic messages are being
transmitted in the country in which you are travelling. This is not the
case in all countries.
The TMC symbol can indicate the following TMC reception status:
Tuning (in red): The TMC receiver is operational but cannot find a
transmitter that is sending TCM signals. There are no active traffic
messages.
Tuning: The TMC receiver is operational but cannot find a station that
is transmitting TMC signals. Traffic messages are active however. This
can be the case, for example, when travelling through a tunnel.
TMC on Standby (in grey): Traffic messages can be receiverd.
Note: The TMC antenna is integrated in the car charger cable. The
Tuning symbol may still appear therefore when the car charger cable is
not connected to the NAVIGON 63xx.
For details of the TMC function refer to chapter "TMC (Traffic
Information)
" on page 73.
Energy
The Energy symbol can indicate the following states of the integrated
battery:
The device is being supplied by an external power source. The battery
is fully charged.
- or -
The battery cannot be charged because its temperature is too high or
too low.
The device is being supplied by an external power source. The battery
is being charged.
The device is being supplied by its internal battery. The battery charge
is sufficient.
The device is being supplied by its internal battery. The battery charge
is low.
User’s manual NAVIGON 63xx
- 20 - Operating the NAVIGON 63xx
Bluetooth / Phone
The NAVIGON 63xx has an integrated Bluetooth hands-free module.
This enables you to use the device as a hands-free kit for a mobile
phone with Bluetooth capability.
The Phone
symbol can display the following states of the hands-free
module:
No Bluetooth (No symbol): The Bluetooth function is deactivated.
Not connected (red mobile phone): The NAVIGON 63xx has no
Bluetooth connection to another device.
Connected (white mobile phone): The NAVIGON 63xx is connected to
a mobile phone and can be used as a hands-free car kit.
Call in Progress (green mobile phone): The hands-free module of the
NAVIGON 63xx is being used for a phone call.
Muting
The Muting symbol can indicate the following states:
No symbol: The navigation application is not muted.
Muting: The navigation application is muted. If the device is navigating
at the moment, you will not hear any driving instructions.
Note: This icon indicates only the muted state of the navigation
instructions. It says nothing about the volume of the hands-free module.
5.2 Software keyboard
A software keyboard appears on the screen when text entries are
necessary.
All entries can be made on the software keyboard using your fingertips.
Only capital letters can be entered.
When entering town or street names you need not enter any special
characters or umlauts. The navigation system fills in these characters
for you automatically. For example, if you are looking for the town of
"Bärnau", then simply type in the word "BARNAU". Special characters
may be helpful however when naming saved destinations and routes.
User’s manual NAVIGON 63xx
Operating the NAVIGON 63xx - 21 -
5.2.1 Special keys
inserts a space.
deletes the character in front of the cursor.
opens the keyboard with numerals.
Latin, Cyrillic and Greek alphabet
opens the keyboard with the Latin alphabet.
opens the keyboard with the Cyrillic alphabet.
opens the keyboard with the Greek alphabet.
When you want to enter addresses, names or POIs, the keyboard with
the alphabet for the country in question will open automatically.
When you want to save a destination to Favourites or when you enter a
POI category or a country, the keyboard with the alphabet of the user
interface will open automatically.
You can also switch from the Cyrillic or Greek keyboard to the Latin
keyboard. Many addresses can then also be entered as transliterations
or in the language of the user interface.
Example: The language of the user interface is English. You want to
navigate to Moscow. You have the following options:
► "Москва" (Cyrillic)
► "Moskva" (transliterated)
► "Moscow" (English).
Note: Street names and place names can be entered only in the
language of the user interface if that is how they exist in the map's
database.
Note: The maximum number of keyboards is always 2.
Umlauts, accents and other letters
Another keyboard with special characters is available for each alphabet.
opens the keyboard with Latin special characters.
opens the keyboard with Cyrillic special characters.
opens the keyboard with Greek special characters.
User’s manual NAVIGON 63xx
- 22 - Operating the NAVIGON 63xx
As soon as you have entered a special character, the letter keyboard
reappears automatically.
5.2.2 Entering data
Often you can select an entry from a list. This is the case, for example,
when you enter a location.
As soon as you enter the first letter, the largest city in the given country
that begins with this letter appears.
Enter more letters and after each entry the first city which begins with
these letters will appear.
► When the correct location appears, tap on (OK) in order to
complete the entry.
You can open at any time a list containing all the locations which begin
with the letters or include the text already entered. The more letters you
enter, the shorter the list becomes.
► Tap on (Open List) to call up this list.
You can use the
(Up) button and the (Down) button to
move through the list.
► Tap on an entry in the list to select it and transfer it to the input box.
The list closes once an entry has been selected. You are now
finished with entering the city.
► Tap on (Close List) in order to close the list without selecting
an entry.
Note: The list opens automatically as soon as it contains only 4 or less
entries.
5.3 Options
Some windows offer options that lead to more functions.
A description of all available options can be found in the chapter
"Options" on page 48.
5.4 Menus
Some buttons have menus which open when activated.
► Tap on a menu point to execute its function.
User’s manual NAVIGON 63xx
Voice Command - 23 -
If you would like to quit the options list without selecting a function, tap
on the button you used to open the menu.
6 Voice Command
Note: The Voice Command function is not available in every language.
For languages in which this function is available, the N
AVIGATION button
is shown in the Voice Command
window. For languages which are not
supported, the Voice Command
button is replaced by the Show Map
button.
Many functions of your navigation device can be called up conveniently
by voice commands.
6.1 Use Voice Command
When the functions in a window can be called up by voice command,
this is indicated in the top left corner of the window by the symbol
(Voice command active).
A single signal tone and the symbol
(Speak) indicate that the
navigation system is waiting for your voice command.
► Say a command.
The positive acknowledgement tone sounds (two high-pitch tones)
and the function is executed.
If the navigation system has not understood your instruction or if you do
not say anything within a certain time, the negative acknowledgement
tone (two short low-pitch tones) will sound.
► Say the command again.
If the navigation system has not understood you after several
repetitions, the prompt "Say 'Help'" will appear.
Note: Navigation instructions and warnings are muted for as long as the
navigation device expects to receive voice commands from you.
6.2 Help
Say only "Help" if you want to know which voice commands are
currently possible. In nearly all windows in which voice commands are
supported the navigation system will then tell you which commands you
can say in the current window.
User’s manual NAVIGON 63xx
- 24 - Navigation
6.3 Deactivation of the voice commands function
The voice commands function will be deactivated under the following
conditions:
► If you operate the navigation device with your finger while a voice
command is expected from you.
► If a call is received and during an active phone call if the navigation
device is being used as a hands-free module.
6.4 Configuring the voice commands function
You can configure for which tasks you want to use voice commands.
► In the NAVIGATION window tap on Options > Settings > General >
Use Voice Command
.
Select the tasks for which you want to use Voice Command:
► Complete: You can use all the voice command functions.
► Answering: You can enter addresses and answer questions
asked by the navigation device.
► Entering Addresses: You can enter only addresses with the
voice command function.
Note: For details of how to enter the destination address using voice
commands refer to the chapter "Entering a destination by voice
commands" on p
age 30.
The volume of the voice commands assistant can be controlled
independently of the volume of the navigation instructions. This means
you can still hear the speak prompts when you have muted the
navigation instructions.
1. In the N
AVIGATION window tap on Options > Settings > General >
Volume of the Assistant
.
2. Select the volume for the assistant.
Note:For details of how to configure the navigation system refer to the
chapter "Configuring the NAVIGON 63xx" on page 90.
7 Navigation
Use the navigation system at your own risk.
Caution! Be sure to refer to all the safety information in chapter
"Important safety information" on page 10.
User’s manual NAVIGON 63xx
Navigation - 25 -
Impaired GPS reception
If GPS reception is impaired, navigation will be interrupted. As soon as
GPS reception is restored, the navigation system calculates any change
of position which has occurred in the meantime. Navigation is then
continued automatically.
Arriving at your destination
When you have reached your selected destination, a message to this
effect will be displayed.
Only your current position (orange arrow) and the destination flag will
now be shown on the map.
7.1 Starting the navigation application
You have switched on the navigation device and, if necessary, entered
the password.
The following message appears:
"Please note that the road traffic regulations are prior to the instructions
of the navigation system. Please do not operate the device while
driving."
► After you have read and fully understood the message, tap on OK.
If you do not accept the content of the message, tap on Cancel
in
order to exit the navigation application.
The N
AVIGATION window is opened. From here you can access all the
functions of the navigation application.
► Tap on (Phone) in order to move the hands-free module
into the foreground (refer to "Handsfree Module" on page 78).
► Tap on (Navigation) in order to move the NAVIGATION
window back into the foreground.
Note: How to deactivate demo mode is explained in "Troubleshooting"
in section "I have accidentally activated demo mode" on page 98).
Initialising the GPS receiver
Note: Good reception of GPS data requires an unobstructed path from
the GPS receiver to the satellites. Tunnels, narrow thoroughfares
between buildings and reflecting house fronts can restrict GPS
reception greatly or make it impossible. If the GPS receiver or the
navigation device is inside a vehicle, a metallised windscreen or a
windscreen heater can be the cause of poor GPS reception.
As soon as the navigation device has been switched on, initialisation of
the GPS receiver will begin.
User’s manual NAVIGON 63xx
- 26 - Navigation
The integrated GPS receiver is not initialised for the first time until the
navigation application is started for the first time. It can take up to
20 minutes to initialise the GPS receiver for the first time.
Note: If the GPS
symbol indicates GPS Ready after far less than
20 minutes, it is advisable to leave the navigation device switched on
for at least another 15 minutes in order to ensure reliable operation of
the receiver.
Each time you switch on the navigation device after this, GPS reception
will start within a short time.
If the navigation device has not been switched on for more than a week,
it can take up to 10 minutes to re-initialise the receiver.
In the top right hand corner of the display, you will see the GPS
symbol.
As soon as data from at least three satellites is received, the icon will
change to
(GPS Ready).
Note: Initialisation takes the least time if you do not start driving until
the initialisation has finished.
For more details about the GPS
symbol refer to chapter "GPS" on
page 18.
Returning to the Navigation window
The NAVIGATION window opens when the navigation application is
started.
If another window of the navigation application is open, tap on
(Back). This will return you to the window you came from.
► Tap on (Back) repeatedly until the NAVIGATION window is
opened.
7.2 Specifying a destination
Under New Destination you can enter destinations to which you have
not yet navigated or which you have not saved.
Here you can enter the destination's address or coordinates, select a
POI, or select a destination with the Direct Access function.
Note: The first time that you want to enter a new destination you will be
asked to select the country in which your destination is situated.
User’s manual NAVIGON 63xx
Navigation - 27 -
Under My Destinations the NAVIGON 63xx provides the following lists
of destinations and addresses for you to select from:
► FAVOURITES: All destinations that you have entered in the
NAVIGON 63xx and then saved.
► LAST DESTINATIONS: Destinations to which you have navigated on a
previous occasion.
► IMPORTED ADDRESSES: Here there may be 2 lists to choose from:
► OUTLOOK / INTERNET: All destinations which you have imported
from Microsoft Outlook or from the Internet.
► FROM THE PHONE BOOK: Addresses from a mobile phone which
is connected via Bluetooth.
7.2.1 Specifying the country in which the destination is situated
At top left in the ADDRESS, POI IN A CITY and POI NATIONWIDE windows
you will find the Country
button. It bears the flag of the country in which
you can currently select destinations for the navigation application.
If your destination is in a different country, then proceed as follows:
1. Tap on the Country
button.
2. Enter the name of the country in which your destination is situated.
The button shows the flag of the destination country.
Note: The selection list contains only those countries whose maps are
available to the navigation device.
7.2.2 Entering a destination address
1. In the NAVIGATION window tap on New Destination > Enter an
Address.
Note: The following description is based on City First
as the order for
entering the address.
If the navigation device contains the map of a country in which the
street is usually listed first (e.g. Sweden, Norway, ...), you can also
choose Street First
as the order for entering the destination address.
You can define the order in the N
AVIGATION window at Options >
Settings
> General > Input Mode for Address Data.
Please note however that the Street First
order of entry is not possible
for all countries. In this case you must enter the city first.
The ADDRESS window opens.
2. Enter the name or the postal code of the destination town.
3. Enter the name of the destination street.
User’s manual NAVIGON 63xx
- 28 - Navigation
4. Enter the house number. If you do not know the house number,
then leave this field empty.
If you don't know the house number but know the name of a nearby
side street, then tap on the Cross Street
box and enter the name of
this street. The navigation system will calculate a route to the
intersection of the streets you have entered.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
Indicated on the Activate MyRoutes
button is whether several route
suggestions are to be calculated (Yes
) or not (No).
► Tap on Activate MyRoutes in order to change the setting.
5. Tap on Start Navigation
in order to navigate to the stipulated
address
- or -
Tap on Parking
in order to search for and navigate to a car park
near your destination.
Sometimes the destination cannot be found exactly because, for
example, the entered combination of place and street name exists
several times.
In this case a window will open with a list of all the addresses
matching your entry plus additional information.
► Tap on the address to which you want to navigate.
If the entered house number is not included on the map, the window
will show an address with the house number closest to the one
entered.
The map opens in Preview mode. The destination is indicated on
the map.
For detailed information on how to start navigation, please refer to
chapter "Route preview" on page 39. Please read on there.
Note: It is not necessary to enter all the address details. You can tap on
Start Navigation
before you get that far.
If you specify the town only, the navigation system will calculate a route
to the town centre.
If you specify only the town and street without specifying a house
number or cross street, the navigation system will calculate the best
route to this street.
7.2.3 Enter Coordinates
You can also enter the geographic coordinates of your destination. The
coordinates can be entered as decimal degrees or in degrees, minutes
and seconds.
User’s manual NAVIGON 63xx
Navigation - 29 -
1. In the NAVIGATION window tap on New Destination > Enter an
Address.
The A
DDRESS window opens.
2. In the A
DDRESS window, tap on Options > Enter Coordinates.
The E
NTER COORDINATES window opens.
Entering as a decimal number
3. Enter the degree of latitude.
Begin the entry with a minus sign if you want to enter a southern
degree of latitude.
4. Enter the degree of longitude.
Begin the entry with a minus sign if you want to enter a western
degree of longitude.
Entering with minutes / seconds
3. Enter the degree of latitude.
Use the corresponding buttons shown on the keyboard in order to
enter the units:
(degrees), (minutes), (seconds).
The (N S) button alongside the entry box indicates whether it is a
northern or southern degree of latitude.
► Tap on the button if you want to change the current setting.
4. Enter the degree of longitude.
Use the corresponding buttons shown on the keyboard in order to
enter the units:
(degrees), (minutes), (seconds).
The (E W) button alongside the entry box indicates whether it is an
eastern or western degree of longitude.
► Tap on the button if you want to change the current setting.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
Indicated on the Activate MyRoutes
button is whether several route
suggestions are to be calculated (Yes
) or not (No).
► Tap on Activate MyRoutes in order to change the setting.
5. Tap on Start Navigation
in order to navigate to the stipulated
address.
- or -
Tap on Parking
in order to search for and navigate to a car park
near your destination.
User’s manual NAVIGON 63xx
- 30 - Navigation
Note: If the destination with the coordinates you entered does not lie on
the road system covered by the map, navigation will be performed as
far as the nearest road point using the mode defined by the selected
route profile. From this point on, the navigation system will automatically
switch to Offroad mode. (Refer to "Navigation in Offroad mode" on
page 60)
7.2.4 Entering a destination by voice commands
It is particularly convenient to select the destination by voice
commands.
1. In the N
AVIGATION window tap on Voice Command.
The V
OICE COMMAND window opens.
Entering an address
2. Say "Address".
Indicated at the top is the country for which you can select
addresses.
► Tap on the country if your destination address is situated in a
different country. Then follow the instructions given by the
navigation system.
You will be asked for the address data in this order: City > Street >
House number.
3. Follow the instructions given by the navigation system.
When you have finished entering the address, the map will open in
Preview mode. The destination is indicated on the map.
Entering a POI nearby
2. Say "POI Nearby".
3. Say which category of POI you want (e.g. "Hotel").
A list of nearby hotels opens.
4. Say the number of the hotel to which you want to navigate.
Say "Up" or "Down" in order to scroll in the list.
When you have selected a destination, the map opens in Preview
mode. The destination is indicated on the map.
Entering a Favourite or an address from the phone book
2. Say "My Destinations".
3. A list opens. It contains the destinations found in the F
AVOURITES
list, destinations imported from Outlook, and destinations from the
phone book of a connected mobile phone.
Loading...
