NAVIGON 42 Easy, 42 Plus, 42 Premium User Manual
NAVIGON 42 Easy
NAVIGON 42 Plus
NAVIGON 42 Premium
User’s manual
English (United Kingdom)
August 2011
The crossed-out wheeled bin means that within the European Union
the product must be taken to separate collection at the product end-oflife. This applies to your device but also to any enhancements marked
with this symbol. Do not dispose of these products as unsorted
municipal waste.
Imprint
NAVIGON AG
Schottmüllerstraße 20A
D-20251 Hamburg
The information contained herein may be changed at any time without prior
notification. Neither this manual nor any parts thereof may be reproduced for any
purpose whatsoever without the express written consent of NAVIGON AG, nor may
they be transmitted in any form either electronically or mechanically, including
photocopying and recording. All technical specifications, drawings etc are subject to
copyright law.
2011, NAVIGON AG
All rights reserved.
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Table of contents
1 Introduction ....................................................................................... 7
1.1 About this manual ................................................................................ 7
1.1.1 Conventions.......................................................................... 7
1.1.2 Symbols ................................................................................ 7
1.2 Legal notice ......................................................................................... 7
1.2.1 Liability ................................................................................. 7
1.2.2 Trade marks ......................................................................... 8
1.3 Questions about the product ................................................................ 8
2 Before you begin ............................................................................... 8
2.1 Scope of Delivery ................................................................................ 8
2.2 Description of the navigation device ..................................................... 9
2.3 Important safety information ................................................................ 9
2.3.1 Navigation safety information ................................................ 9
2.3.2 Safety information for the navigation device ........................ 10
2.3.3 Safety information for installing the device in your car ......... 10
2.4 Preparing the navigation system for use ............................................ 11
2.4.1 Installing the navigation system in the vehicle ..................... 11
2.4.2 Memory card ....................................................................... 13
2.5 Navigating with GPS .......................................................................... 13
3 Switching on the navigation device .............................................. 14
3.1 Switching on the device ..................................................................... 14
3.2 Switching the navigation device to standby mode .............................. 14
3.3 Switching off the navigation device .................................................... 15
4 Using the Navigation System for the First Time .......................... 15
5 Operating the navigation system .................................................. 17
5.1 Switching to a different application ..................................................... 18
5.1.1 Scrolling .............................................................................. 18
5.1.2 Using the button bar ........................................................... 18
5.1.3 Options ............................................................................... 18
5.2 Information ........................................................................................ 18
5.3 Software keyboard ............................................................................. 21
5.3.1 Special keys ....................................................................... 21
5.3.2 Latin keyboard layout .......................................................... 21
5.3.3 Cyrillic and Greek keyboard layout ...................................... 22
5.3.4 Entering data ...................................................................... 23
6 Voice Command .............................................................................. 23
6.1 Activating the voice commands function ............................................ 24
6.2 Use Voice Command ......................................................................... 24
6.3 Help ................................................................................................... 25
6.4 Deactivation of the voice commands function .................................... 25
6.5 Configuring the voice commands function .......................................... 25
7 Navigation........................................................................................ 26
7.1 Starting the navigation application ..................................................... 26
User’s manual Table of contents w III
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
7.2 Specifying a destination ..................................................................... 27
7.2.1 Specifying the country in which the destination is
situated ............................................................................... 28
7.2.2 Enter an Address ................................................................ 28
7.2.3 Announcing the address ..................................................... 30
7.2.4 Points of interest ................................................................. 31
7.2.5 Information about the destination ........................................ 34
7.2.6 Favourites ........................................................................... 35
7.2.7 Last Destinations ................................................................ 36
7.2.8 From the phone book .......................................................... 36
7.2.9 Navigating home ................................................................. 37
7.2.10 Selecting destinations on the map ...................................... 37
7.2.11 Options in the Destination window ...................................... 38
7.2.12 Route preview ..................................................................... 39
7.3 Managing destinations ....................................................................... 41
7.3.1 Saving destinations ............................................................. 41
7.3.2 Deleting a destination ......................................................... 42
7.3.3 Renaming a destination from the Favourites list .................. 42
7.3.4 Defining the home address ................................................. 43
7.3.5 Changing the home address ............................................... 43
7.4 Multi-leg routes .................................................................................. 44
7.4.1 Opening the route planning ................................................. 44
7.4.2 Planning a new route .......................................................... 44
7.4.3 Editing route points ............................................................. 45
7.4.4 Managing routes ................................................................. 46
7.4.5 Restoring the last route ....................................................... 48
7.4.6 Calculating and displaying routes ........................................ 48
7.4.7 Simulating routes ................................................................ 49
7.4.8 Route preview ..................................................................... 49
8 Working with the map ..................................................................... 51
8.1 Selecting the navigation map ............................................................. 51
8.2 Map in Standard mode ...................................................................... 51
8.3 Map in Route preview mode .............................................................. 53
8.4 Map in Navigation mode .................................................................... 55
8.4.1 Navigation in Vehicle mode................................................. 55
8.4.2 Navigation in Pedestrian mode ........................................... 59
8.4.3 Map options in Navigation mode ......................................... 61
8.4.4 Quitting navigation .............................................................. 62
8.5 Map in Destination search mode ........................................................ 62
8.5.1 Changing the map section .................................................. 63
8.5.2 Set destination .................................................................... 64
8.5.3 Shifting the destination point ............................................... 64
8.5.4 Deleting a destination point ................................................. 64
IV Table of contents User’s manual
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
9 Useful functions .............................................................................. 65
9.1 Route Profiles .................................................................................... 65
9.1.1 Route profile settings .......................................................... 65
9.1.2 NAVIGON basic profiles ..................................................... 65
9.1.3 Creating a new route profile ................................................ 66
9.1.4 Selecting a route profile ...................................................... 66
9.1.5 Managing route profiles ...................................................... 67
9.2 Screenshots ...................................................................................... 68
9.2.1 Enabling screenshots.......................................................... 68
9.2.2 Creating a screenshot ......................................................... 68
9.3 Parking near the destination .............................................................. 68
9.3.1 Special functions along a route with several stages ............ 70
9.4 MyBest POI: POI on Your Route ........................................................ 71
9.4.1 Displaying POIs along the route .......................................... 71
9.4.2 Navigating to one of the destinations .................................. 73
9.4.3 Selecting categories ........................................................... 73
9.5 GPS Status, saving the current location ............................................. 74
9.6 Block ................................................................................................. 74
9.7 TMC (Traffic Information) ................................................................... 75
9.7.1 Route Optimisation: On Request......................................... 75
9.7.2 Route Optimisation: Automatic ............................................ 77
9.7.3 Displaying traffic information ............................................... 78
9.7.4 Filtering traffic messages .................................................... 80
9.7.5 Showing a single message in detail .................................... 80
9.7.6 Edit Mode ........................................................................... 81
9.7.7 Options (Traffic Information) ............................................... 82
9.7.8 Settings (Traffic Information) ............................................... 83
10 Handsfree Module ........................................................................... 84
10.1 Bluetooth Connection ........................................................................ 86
10.1.1 Searching for and pairing Bluetooth devices ....................... 86
10.1.2 Pairing from the mobile phone ............................................ 88
10.1.3 Connecting to a device ....................................................... 88
10.1.4 Activating a mobile phone ................................................... 90
10.1.5 Deleting devices ................................................................. 90
10.1.6 Import Phone Book ............................................................. 91
10.1.7 Import recent calls .............................................................. 93
10.2 Taking a call ...................................................................................... 93
10.3 Receiving a text message .................................................................. 93
10.4 Making a call ..................................................................................... 94
10.4.1 Dialling a telephone number ............................................... 94
10.4.2 Dialling a Speed Call number .............................................. 94
10.4.3 Calling a contact from the phone book ................................ 95
10.4.4 Calling most recently dialled, received or missed
numbers ............................................................................. 95
10.4.5 Transferring a call from your mobile telephone ................... 96
User’s manual Table of contents w V
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
10.5 During a call ...................................................................................... 96
10.5.1 Go back to entering a destination ........................................ 96
10.5.2 Moving the map to the foreground ...................................... 96
10.5.3 Entering numbers ............................................................... 96
10.5.4 Muting the microphone ....................................................... 97
10.5.5 Transferring a call to the mobile phone ............................... 97
10.5.6 Ending the call .................................................................... 97
10.6 Useful functions ................................................................................. 97
10.6.1 Navigating to a contact from the phone book ...................... 97
10.6.2 Opening the mailbox ........................................................... 98
10.7 Configuring the hands-free function ................................................... 98
10.7.1 Preset ................................................................................. 98
10.7.2 Settings .............................................................................. 99
11 Configuring the Navigation System ............................................ 101
12 Appendix ....................................................................................... 103
12.1 Technical data of the navigation device ........................................... 103
12.2 NAVIGON Licensing Policy .............................................................. 104
12.3 Declaration of conformity ................................................................. 108
13 Troubleshooting ............................................................................ 108
14 Index .............................................................................................. 111
VI Table of contents User’s manual
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
1 Introduction
1.1 About this manual
1.1.1 Conventions
For better legibility and clarification, the following styles are used in this
manual:
Bold and italics: Names of products
MALL CAPITALS: Names of windows and dialogue boxes
S
Bold: Highlighting of important parts in the text
Underlined: Descriptions of buttons, input boxes and other
Underlined and italics: Names of control elements on the navigation device
1.1.2 Symbols
The following symbols draw attention to specific passages of text:
Instructions and tips for operating the software
More detailed information and explanations
elements on the user interface
Warnings
1.2 Legal notice
1.2.1 Liability
The software and manual are subject to change without notice.
NAVIGON AG is not liable for the accuracy of the information contained
in this manual or for damages resulting from the use of this manual.
Suggestions for improvements and information regarding errors are
always welcome so that we can supply you with even better products in
the future.
Introduction - 7 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
1.2.2 Trade marks
All brand and trade marks mentioned in this document and registered
by third parties are subject without reservation to copyright law and the
proprietary rights of their respective owners. All trade marks, trade
names and company names used in this document are or may be trade
marks or registered trademarks of their respective owners. All rights
reserved except those explicitly granted.
If the registered trade marks used in this manual are not explicitly
identified as such, this does not imply that the name is not subject to the
rights of a third party.
► Microsoft, Outlook, Excel and Windows are registered trade marks
of the Microsoft Corporation.
► NAVIGON is a registered trade mark of NAVIGON AG.
1.3 Questions about the product
You have a question concerning your product? Then visit our website
www.navigon.com and click on "Customer Services". There you will find
an area with frequently asked questions (FAQ Center) along with details
of how to contact us by phone or e-mail.
2 Before you begin
2.1 Scope of Delivery
Please check that the contents are complete. If anything is missing, get
in touch immediately with the dealer who sold you the product.
The purchased product includes the following:
► Navigation device
► Designer car cradle
► Car charger cable (10-24V adapter for the vehicle's cigarette lighter)
with integrated TMC antenna
► USB cable
► Illustrated installation instructions
- 8 - Before you begin
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
2.2 Description of the navigation device
1 On/Off
2 Touch-screen
3 Microphone (only NAVIGON 42 Premium)
4 Reset
5 Mini USB socket for USB cable / mains adapter
6 LED
7 Slot for microSD memory card
2.3 Important safety information
In your own interest, please read the following safety information and
warnings carefully before starting up your navigation system.
2.3.1 Navigation safety information
Use the navigation system at your own risk.
Caution! To prevent accidents, do not operate the navigation system
while driving.
Before you begin - 9 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Caution! Follow the instructions of the navigation system only when the
Caution! Do not expose the navigation device to extreme heat or cold.
Note: Do not kink the cable. Make sure that the cable cannot be
Note: Create a backup of the data which exist in the internal memory of
Caution! Fasten the cradle so that the navigation device is easy to see
Caution! Do not look at the screen unless it is absolutely safe to do so!
Caution! Traffic regulations have priority over any instructions from the
navigation system.
circumstances and the road traffic regulations allow you to do so! The
navigation system will still guide you to your destination even if you
deviate from the calculated route.
Caution! Check that the cradle is secured and adjusted properly before
each journey.
2.3.2 Safety information for the navigation device
Caution! Protect the device from moisture. The device is neither
waterproof nor protected against splash water.
Caution! Do not open the case of the navigation device under any
circumstances.
This may damage the device or impair its function (see "Technical data"
on page 103).
Caution! Never unplug by pulling the cable. Doing so could severely
damage or destroy the device.
Caution! Do not subject the navigation device to severe temperature
fluctuations. This can lead to condensation.
damaged by sharp-edged objects.
your navigation device.
This is very easy to do with the NAVIGON Fresh software which can be
downloaded free of charge from our website www.navigon.com/fresh.
2.3.3 Safety information for installing the device in your car
and operate by the driver. Make sure that the driver's view of the traffic
is not impeded.
- 10 - Before you begin
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Caution! Do not fasten the cradle too close to the steering wheel or
Caution! Do not run cables within the operating radius of airbags or in
Caution! Disconnect the car charger cable from the cigarette lighter
Caution! Do not attach the cradle within the working zone of any
airbags.
other controls. The driver must not be obstructed in operating any car
functions.
Caution! When installing the cradle, make sure that it will not pose a
risk in the event of an accident.
the direct vicinity of other safety-relevant devices and power supply
lines.
Caution! Check that the cradle is secured and adjusted properly before
each journey. The suction cup may become loose after a while.
Caution! After installation, check all safety-relevant equipment in the
car.
Caution! Connect the car charger cable only to cigarette lighters with
an operating voltage of 10-24V.
whenever you park the car. The integrated mains adapter always
consumes a small amount of energy and could drain the car battery.
2.4 Preparing the navigation system for use
2.4.1 Installing the navigation system in the vehicle
Caution! Be sure to refer to all the safety information in chapter
"Important safety information" on page 9.
Securing the cradle
Before you begin - 11 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
1. Clean the suction cup and that part of the windscreen to which you
want to secure the cradle. Both must be dry and free of dirt and
grease.
2. Open the lever on the suction cup as far as possible.
3. Place the cradle suction cup against the windscreen.
4. Press the lever towards the windscreen.
Inserting the navigation device into the cradle
On the back of the navigation device you will see a circle with two
recesses.
1. Hang the navigation device by the upper recess on the upper lug of
the cradle (see the figure).
2. Then press it towards the cradle so that it latches in place.
Supplying power to the navigation device
Included in delivery of the navigation device is a car charger cable with
which power can be supplied to the navigation device via the vehicle's
cigarette lighter.
Note: Use only the charger cable supplied with your navigation device
or an equivalent model from NAVIGON!
► Connect the car charger cable to the vehicle's cigarette lighter and
to the mini USB socket of the navigation device.
The LED on the bottom of the navigation device lights up orange during
charging.
As soon as the battery is fully charged, the LED lights up green.
Caution! Connect the car charger cable only to cigarette lighters with
an operating voltage of 10-24V.
- 12 - Before you begin
Caution! Be sure to refer to all the safety information in chapter
Note: Insert the USB connector securely in the corresponding USB
Note: It takes approx. 3 hours to charge the device when the battery is
"Important safety information" on page 9.
sockets!
flat.
A fully charged battery enables up to 3 hours of use depending on the
device configuration.
TMC antenna
The navigation device has an integrated TMC receiver. The TMC
antenna is integrated in the car charger cable. Once the car charger
cable is connected, the device can receive current traffic messages. If
required, it can change your route dynamically, e.g. in order to avoid a
traffic jam.
2.4.2 Memory card
A memory card is not required to operate the navigation system
because all the data required for navigation are stored in the internal
memory of the device.
When you connect the navigation system to your computer using a USB
cable, the internal memory is detected as the 'NAVIGON' drive. The slot
for the memory card is detected as the 'NAVIGON SD' drive.
Data back-ups, software updates and navigation map updates can be
carried out quickly and conveniently with the NAVIGON Fresh software,
which you can download free of charge from the website
www.navigon.com/fresh.
If you purchase additional navigation maps but no longer have enough
space for them in the internal memory of your navigation device, it is
also possible for you to save these maps on a memory card microSD
which you then insert in the device. The navigation system can use
navigation maps from both memories.
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
2.5 Navigating with GPS
GPS is based on a total of at least 24 satellites orbiting the Earth and
continuously transmitting signals of their position and time. The GPS
receiver receives this data and calculates its own geographical position
on the basis of the information transmitted by the various satellites.
Data from at least three satellites is required for positioning with an
acceptable degree of accuracy. With data from four or more satellites it
is possible in addition to determine the position's altitude above sea
level. Positioning is accurate to within three metres.
Before you begin - 13 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Once the navigation device has determined your position, this position
can be used as a starting point for calculating a route.
The map data on your navigation device includes the geographical
coordinates of all digitally recorded points of interest, streets and
places. This enables the device to calculate a route between a starting
point and a destination.
Calculation of the current position and its representation on the map
take place approximately once every second. In other words, your
current position is always shown on the map.
3 Switching on the navigation device
The navigation device can be in one of three states:
► On: The navigation device is on and can be operated.
► Standby: When you switch the navigation device to standby mode,
the next time it is switched on it will start very quickly and with the
window which was active when switched off. In standby mode the
device still consumes a small amount of energy however.
Depending on how full the battery is, it can become flat within a few
days or a few weeks.
► Off: When you switch off the device, it consumes hardly any
energy. It can then take several months for the battery to become
flat. Switching the device on again triggers a restart which can take
some time (approx. 60 seconds). Your settings and your saved
destinations and routes will be retained.
3.1 Switching on the device
► Press the (On/Off) key and keep it pressed until the device
switches on.
AVIGATION window opens.
The N
3.2 Switching the navigation device to standby mode
► Press briefly on the (On/Off) key (max. 2 seconds).
A message will appear telling you that the device will be switched to
standby mode in several seconds.
► Wait for the device to be switched to standby mode or tap on
Standby.
Automatic Standby
You can configure the navigation device so that it is automatically
switched to standby mode when not in use.
- 14 - Switching on the navigation device
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
► In the NAVIGATION window tap on (More) > System
Settings > Power and Screen > Automatic Standby.
► Select after how much time you want the navigation device to be
switched to standby mode (Never, After 10 mins., After 20 mins.,
After 30 mins.).
► Select Power Loss in order to switch the device to standby mode
when the external power supply is interrupted. As soon as the
device is connected again to the external power supply it will switch
on again automatically.
3.3 Switching off the navigation device
► Press the (On/Off) key and keep it pressed until the device
switches off (approx. 6 seconds).
- or -
1. Press briefly on the (On/Off) key (max. 2 seconds).
A message will appear telling you that the device will be switched to
standby mode in several seconds.
2. Tap on Switch off.
4 Using the Navigation System for the First
Time
When you switch on the navigation system for the first time, you will be
asked to make a number of basic settings:
The L
ANGUAGE window opens.
1. Select your preferred language for using the software.
2. Tap on OK.
The DISTANCE UNIT window opens.
3. Determine how you want distances to be shown ('Kilometres' or
'Miles').
4. Tap on OK.
The TIME FORMAT window opens.
5. Determine the time format ('12h (am/pm)' or '24h').
6. Tap on OK.
The DATE FORMAT window opens.
7. Select the date format. This means:
► YYYY: the year in 4 digits
► MM: the month in 2 digits
Using the Navigation System for the First Time - 15 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: If you deinstall NAVIGON Safety Camera, the add-on can be
Note: How to deactivate presentation mode is explained in
► DD: the day in 2 digits
8. Tap on OK.
If you purchased your navigation system together with the add-on
NAVIGON Safety Camera, the W
will open.
9. Read the text in this window very carefully. It describes the settings
which you can make for the add-on.
10. Tap on OK.
The WARN OF SAFETY CAMERAS window opens.
11. Select the setting you want.
12. Tap on OK.
► If you have selected the Uninstall option, you will be asked to
confirm the deinstallation of the add-on.
► Tap on Yes.
installed again only by using the NAVIGON Fresh software.
The PRESENTATION MODE window opens.
Presentation mode is intended solely for presenting the product
when no GPS reception is possible.
When presentation mode is active, navigation is not possible.
Presentation mode is designed solely to simulate navigation to the
centre of the indicated destination.
13. Make sure that the Start in Presentation Mode checkbox is not
activated. If necessary, tap on the checkbox in order to set the
value Yes ( checkbox activated) to No ( checkbox not
activated).
14. Tap on OK.
ARN OF SAFETY CAMERAS window
"Troubleshooting" in section "I have accidentally activated presentation
mode" on page 109).
There then follows a series of pictures which demonstrate the basic
operations of the navigation device.
You can use the (Next) button and the (Back)
button to switch between the other pictures.
15. Look at all the pictures.
- or -
► Tap on Done.
- 16 - Using the Navigation System for the First Time
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: You received a brief introduction to the navigation system's
Note: In the N
Introduction if you want to see the introduction again later.
A window with the following message opens:
AVIGATION window tap on (More) > Show
"Please note that the road traffic regulations are prior to the
instructions of the navigation system. Please do not operate the
device while driving."
16. After you have read and fully understood the message, tap on OK.
If you do not accept the content of the message, tap on Cancel in
order to exit the navigation application.
A window with several buttons opens.
17. Tap on any point of the screen.
The N
AVIGATION window opens.
5 Operating the navigation system
operation when you first started it. In the NAVIGATION window tap on
(More) > Show Introduction if you want to see the introduction
again.
Essentially, the navigation software comprises several applications
whose number varies according to the range of functions offered by
your navigation device. From these applications you have access to all
the functions and settings possible with the navigation system.
At the bottom edge of the screen is a bar with several buttons.
Each button represents an application. A coloured bar over a button
indicates that the related application is currently open (here:
N
AVIGATION)
(Handsfree Module): Opens the H
ANDSFREE MODULE window, see
"Handsfree Module" on page 84. (Only NAVIGON 42 Premium)
(Navigation): Opens the N
AVIGATION window; there you have
access to all the methods for entering and selecting a destination.
(Show Map): Opens the map in Standard mode when no
navigation is in progress (see "Map in Standard mode" on page 51), or
opens it in Navigation mode when navigation is in progress (see "Map
in Navigation mode" on page 55).
Operating the navigation system - 17 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
(Navigation Options): Opens the NAVIGATION OPTIONS window; in it
you will find useful functions for navigation and for adjusting the map.
5.1 Switching to a different application
Switching between applications is possible in various ways.
5.1.1 Scrolling
Drag your finger horizontally over the screen in order to scroll between
the applications.
► Drag you finger from left to right over the screen in order to open
the application which lies to the left of the current application.
► Drag you finger from right to left over the screen in order to open
the application which lies to the right of the current application.
5.1.2 Using the button bar
You can use the button bar to switch quickly between different
applications.
► Tap on a button to open the corresponding application.
The button bar is hidden on the map in Standard and Vehicle modes.
► Tap on the map to show the button bar.
► Tap on a button to open the corresponding application.
5.1.3 Options
At the top right edge of many windows is the (More) button
which you can use to move to more functions.
Touch the (Cancel) button to close the window again without
executing a function.
More options can be reached via the (Navigation Options)
button on the button bar. Here you will find useful functions for
navigation and for adjusting the map.
5.2 Information
Various information symbols are located at the top of many windows.
GPS
The GPS symbol can show the following GPS reception status:
No GPS (No symbol): The built-in GPS receiver is not operational.
Contact us if the problem persists (see "Questions about the product"
on page 8).
- 18 - Operating the navigation system
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: This function is only available if TMC traffic messages are being
No Signal: Data is being received from less than three satellites.
Position cannot be calculated.
GPS Ready: Data is being received from at least 3 satellites. Position
can be calculated.
Simulation: If a simulation is in progress, the Demo symbol will appear
instead of the GPS symbol.
For details of the GPS status refer to chapter "GPS Status, saving the
current location" on page 74.
Compass
The Compass symbol indicates in which direction you are currently
heading. It can indicate the following points of the compass:
N, NE, E, SE, S, SW, W, NW
Energy
The Energy symbol can indicate the following states of the integrated
battery:
The device is being supplied by an external power source. The battery
is fully charged.
The battery cannot be charged because its temperature is too high.
The device is being supplied by an external power source. The battery
is being charged.
The device is being supplied by its internal battery. The battery charge
is sufficient.
The device is being supplied by its internal battery. The battery charge
is low.
TMC
The navigation system has an integrated TMC receiver which supplies
up-to-date traffic information. Using this information the navigation
system can change your route dynamically, for example in order to
avoid a traffic jam.
transmitted in the country in which you are travelling. This is not the
case in all countries.
Operating the navigation system - 19 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: The TMC antenna is integrated in the car charger cable. The
The TMC symbol can display the following TMC reception status:
Tuning (in red): The TMC receiver is operational but cannot find a
transmitter that is sending TCM signals. There are no active traffic
messages.
Tuning: The TMC receiver is operational but cannot find a station that
is transmitting TMC signals. Traffic messages are active however. This
can be the case, for example, when travelling through a tunnel.
TMC on Standby (in grey): Traffic messages can be received.
Tuning symbol may still appear therefore when the car charger cable is
not connected to the navigation device.
For details of the TMC function refer to chapter "TMC (Traffic
Information)" on page 75.
Bluetooth / Phone
This section is relevant for you only if your navigation device is a
NAVIGON 42 Premium.
The navigation device has an integrated Bluetooth hands-free module.
This enables you to use the device as a hands-free kit for up to two
mobile phones with Bluetooth capability.
The Phone symbol can display the following states of the hands-free
module:
No Bluetooth (No symbol): The Bluetooth function is deactivated.
Not connected (red mobile phone): The navigation device has no
Bluetooth connection to another device.
Connected (white mobile phone): The navigation device is connected
to a mobile phone and can be used as a hands-free car kit. The number
indicates which of the two phones is currently active.
Call in Progress (green mobile phone): The hands-free module of the
navigation device is being used for a phone call. The number indicates
which of the two phones is being used to make the call.
Headset: A headset is connected. All the instructions given by the
navigation system are heard over the headset. The telephone functions
of the hands-free module are not available.
- 20 - Operating the navigation system
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: This symbol indicates only the muted state of the navigation
Muting
The Muting symbol can indicate the following states:
No symbol: The navigation application is not muted.
Muting: The navigation application is muted. If the device is navigating
at the moment, you will not hear any driving instructions.
instructions. It says nothing about the volume of the hands-free module.
5.3 Software keyboard
A software keyboard appears on the screen when text entries are
necessary.
When you want to enter addresses, names or POIs, the keyboard with
the alphabet for the country in question will open automatically.
When you want to save a destination to Favourites or when you enter a
POI category or a country, the keyboard with the alphabet of the user
interface will open automatically.
All entries can be made on the software keyboard using your fingertips.
Only capital letters can be entered.
When entering town or street names you need not enter any special
characters or umlauts. The navigation system fills in these characters
for you automatically. For example, if you are looking for the town of
"Bärnau", then simply type in the word "BARNAU". Special characters
may be helpful however when naming saved destinations and routes.
5.3.1 Special keys
inserts a space.
deletes the character in front of the cursor.
5.3.2 Latin keyboard layout
With the two buttons at the bottom right and bottom left edge of the
screen you can switch between the keyboard for letters, the keyboard
for special characters and the keyboard for numbers.
Left key:
/ : Switches between the keyboard for numbers and the
keyboard for letters.
Operating the navigation system - 21 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: The layout for the keyboard with the Latin alphabet can be
Note: Street names and place names can be entered only in the
Right key:
/ : Switches between the keyboard for special characters
and the keyboard for numbers.
configured.
► In the NAVIGATION window tap on (More) > System
Settings > Language and Keyboard > Keypad layout (Latin).
► Select the layout you want to use: Alphabetical (ABCDEF), English
(QWERTY), German (QWERTZ), French (AZERTY).
5.3.3 Cyrillic and Greek keyboard layout
You can also switch from the Cyrillic or Greek keyboard to the Latin
keyboard. Many addresses can then also be entered as transliterations
or in the language of the user interface.
Example: The language of the user interface is English. You want to
navigate to Moscow. You have the following options:
► "Москва" (Cyrillic)
► "Moskva" (transliterated)
► "Moscow" (English)
language of the user interface if that is how they exist in the map's
database.
With the button at the bottom left edge of the screen you can switch
between the Latin and Cyrillic or the Latin and Greek keyboard, with the
button at the bottom right edge of the screen you can switch between
the keyboard for letters, the keyboard for special characters and the
keyboard for numbers.
Cyrillic keyboard layout
Left key:
/ : Switches between the Latin and Cyrillic keyboard layout.
Right key:
Switches between the keyboard for special characters, the keyboard for
numbers and the keyboard for letters of the current keyboard layout.
- 22 - Operating the navigation system
Greek keyboard layout
Note: The list opens automatically as soon as it contains only 4 or less
Left key:
/ : Switches between the Latin and Greek keyboard layout.
Right key:
Switches between the keyboard for special characters, the keyboard for
numbers and the keyboard for letters of the current keyboard layout.
5.3.4 Entering data
Often you can select an entry from a list. This is the case, for example,
when you enter a location.
As soon as you enter the first letter, the largest city in the given country
that begins with this letter appears.
Enter more letters and after each entry the first city which begins with
these letters will appear.
► When the correct location appears, tap on (OK) in order to
complete the entry.
You can open at any time a list containing all the locations which begin
with the letters or include the text already entered. The more letters you
enter, the shorter the list becomes.
► Tap on (Open List) in order to call up this list.
You can use the (Up) and (Down) buttons to scroll
through the list page by page.
► Tap on an entry in the list to select it and transfer it to the input box.
The list closes once an entry has been selected. You are now
finished with entering the city.
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
► Tap on (Close List) in order to close the list without selecting
an entry.
entries.
6 Voice Command
This section is relevant for you only if your navigation device is a
NAVIGON 42 Premium.
Voice Command - 23 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: The Voice Command function is not available in every language.
Note: Navigation instructions and warnings are muted for as long as the
For languages in which this function is not available, the Voice
Command button is not shown in the NAVIGATION window.
Many functions of your navigation device can be called up conveniently
by voice command.
6.1 Activating the voice commands function
The voice commands function is automatically active in many windows.
This applies in particular to windows in which you are expected to
provide an answer, for example when there is a new traffic message
concerning your route.
On the map in Standard or Navigation mode, the Voice Command
function will be activated as soon as the button bar is shown.
► Tap on any point on the map.
You will hear a single acknowledgement tone and you can utter
your command.
6.2 Use Voice Command
When the functions in a window can be called up by voice command,
this is indicated in the bottom left corner of the window by the symbol
Voice command active).
A single signal tone and the symbol (Speak) indicate that the
navigation system is waiting for your voice command.
► Say a command.
The positive acknowledgement tone sounds (two high-pitch tones)
and the function is executed.
If the navigation system has not understood your instruction or if you do
not say anything within a certain time, the negative acknowledgement
tone (two short low-pitch tones) will sound.
► Say the command again.
If the navigation system has not understood you after several
repetitions, the prompt "Say Help" will appear.
navigation device expects to receive voice commands from you.
- 24 - Voice Command
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: For details of how to configure the navigation system refer to the
6.3 Help
Say only "Help" if you want to know which voice commands are
currently possible. In nearly all windows in which voice commands are
supported the navigation system will then tell you which commands you
can say in the current window.
6.4 Deactivation of the voice commands function
The voice commands function will be deactivated under the following
conditions:
► If you operate the navigation device with your finger while a voice
command is expected from you.
► If a call is received and during an active phone call if the navigation
device is being used as a hands-free module.
6.5 Configuring the voice commands function
You can configure for which tasks you want to use the voice
commands.
► In the NAVIGATION window tap on (More) > System
Settings > Voice Command.
Select the tasks for which you want to use Voice Command:
► Entering Addresses: You can enter only addresses with the
voice command function.
► Answering: You can enter addresses and answer questions
asked by the navigation device.
► Complete: You can use all the voice command functions.
Note: For details of how to enter a destination using voice commands
refer to the chapter "Announcing the address" on page 30.
The volume of the voice commands assistant can be controlled
independently of the volume of the navigation instructions. This means
you can still hear the input requests when you have muted the
navigation instructions.
1. In the N
2. Select the volume for the assistant.
AVIGATION window tap on (More) > System
Settings > Voice Command > Volume of the Assistant.
chapter "Configuring the Navigation System" on page 101.
Voice Command - 25 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: Good reception of GPS data requires an unobstructed path from
7 Navigation
Use the navigation system at your own risk.
Caution! Be sure to refer to all the safety information in chapter
"Important safety information" on page 9.
Impaired GPS reception
If GPS reception is impaired (e.g. because you are in a tunnel),
navigation will be continued. The navigation system will then calculate
your likely position from the route data and your previous driving profile.
As soon as GPS signals are received again, navigation will be
continued with real GPS data.
Arriving at your destination
When you have reached your selected destination, a message to this
effect will be displayed.
Only your current position (orange arrow) and the destination flag will
now be shown on the map.
7.1 Starting the navigation application
You have switched on the navigation device.
The following message appears:
"Please note that the road traffic regulations are prior to the instructions
of the navigation system. Please do not operate the device while
driving."
► After you have read and fully understood the message, tap on OK.
If you do not accept the content of the message, tap on Cancel in
order to exit the navigation application.
The N
AVIGATION window is opened. From here you can access all the
functions of the navigation application.
Initialising the GPS receiver
the GPS receiver to the satellites. Tunnels, narrow thoroughfares
between buildings and reflecting house fronts can restrict GPS
reception greatly or make it impossible. If the GPS receiver or the
navigation device is inside a vehicle, a metallised windscreen or a
windscreen heater can be the cause of poor GPS reception.
As soon as the navigation device has been switched on, initialisation of
the GPS receiver will begin.
- 26 - Navigation
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: Initialisation takes the least time if you do not start driving until
The integrated GPS receiver is not initialised for the first time until the
navigation application is started for the first time. It can take up to
minutes to initialise the GPS receiver for the first time.
Each time you switch on the navigation device after this, GPS reception
will start within a short time.
If the navigation device has not been switched on for more than a week,
it can take up to 10 minutes to re-initialise the receiver.
Note: Directly after the GPS symbol indicates the GPS Ready state,
the accuracy of the positioning may be reduced for a few minutes.
In the top right hand corner of the screen you will see the GPS symbol.
As soon as data from at least three satellites is received, the symbol will
change to (GPS Ready).
the initialisation has finished.
For more details about the GPS symbol refer to chapter "GPS" on
page 18.
Returning to the Navigation window
The NAVIGATION window opens when the navigation application is
started.
If a window with a visible button bar is opened:
► In the bar tap on (Navigation).
If the map is open in Standard mode or in Vehicle mode:
► Call up the button bar (see "Button bar" on page 58).
► In the bar tap on (Navigation).
If a different window of the navigation application is open:
► Tap on (Back). This will return you to the window you
came from.
► Tap on (Back) repeatedly until the NAVIGATION window is
opened.
7.2 Specifying a destination
You can either enter a new destination or select a saved destination.
To enter a new destination you can
► Enter the address of the destination (see "Enter an Address" on
page 28).
Navigation - 27 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: If you are entering a new destination for the first time, the
Note: The selection list contains only those countries whose maps are
► Select a point of interest (see "Points of interest" on page 31).
COUNTRY window opens. Tap on the country in which your destination
lies.
To select a saved destination you can select from the following lists of
destinations and addresses:
► FAVOURITES: All destinations that you have entered and then saved
(see "Favourites" on page 35).
Two special destinations are also saved in the F
► My Address: The address which was saved as the home
AVOURITES list:
address (see "Defining the home address" on page 43).
► My Vehicle: The location of your vehicle is automatically saved
when you use the Parking Close to Destination function (see
"Parking near the destination" on page 68).
► LAS T DESTINATIONS: Destinations to which you have navigated on a
previous occasion (see "Last Destinations" on page 36).
► FROM THE PHONE BOOK: All the destinations from the telephone
book of a connected mobile phone (see "From the phone book" on
page 36).
7.2.1 Specifying the country in which the destination is situated
If you enter an address (see “Enter an Address“on page 28), a POI in a
town (see POI in a particular location on page 32) or a nationwide POI
(see “POI of nationwide significance“ on page 33), the Country button
will appear in the first input window at top left. It bears the flag of the
country in which you can currently select destinations for the navigation
application.
If your destination is in a different country, then proceed as follows:
1. Tap on the Country button.
2. Enter the name of the country in which your destination is situated.
The button shows the flag of the destination country.
available to the navigation device.
7.2.2 Enter an Address
1. In the NAVIGATION window, tap on Enter Destination > Enter an
Address.
If the navigation device contains the map of a country in which
the street is usually listed first (e.g. Sweden, Norway, ...), the
I
NPUT MODE FOR ADDRESS DATA window will open.
- 28 - Navigation
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
Note: You can define and change the order in the N
window
Note: The following description is based on City First as the order for
► Select the order of entry you want (Street First or City First). If
you would like to save this setting permanently and without
being asked again, first activate the checkbox alongside 'Use
these settings in future for address information'.
under (More) > Navigation Settings > General > Input Mode for
Address Data.
Please note however that the Street First order of entry is not possible
for all countries. If the map of the selected country does not support
both modes, you must enter the town first.
entering the address.
The CITY window opens.
1. Enter the name or the postal code of the destination town.
2. Enter the name of the destination street.
If you enter an address in the Czech Republic or in Russia and
have selected the corresponding map, you can also enter the
land register number instead of the street name.
► In the STREET window tap on (More) > Enter Address
Point and enter the land register number.
The navigation system will then calculate a route to this
address.
3. Enter the house number. If you do not know the house number,
then leave this box empty.
If you don't know the house number but know the name of a nearby
side street, then tap in the N
Cross Street and enter this name. The navigation system will
calculate a route to the intersection of the streets you have entered.
The D
ESTINATION window opens.
4. Tap on Start Navigation in order to navigate to the stipulated
address.
- or -
Tap on (Parking) in order to search for and navigate to a car
park near your destination.
Sometimes the destination cannot be found exactly because, for
example, the entered combination of place and street name exists
several times.
In this case a window will open with a list of all the addresses
matching your entry plus additional information.
► Tap on the address to which you want to navigate.
AVIGATION
O. window on (More) > Enter
Navigation - 29 -
User’s manual NAVIGON 42 Easy | 42 Plus | 42 Premium
For detailed information on how to start navigation, please refer to
Note: You don't have to enter all the address details. You can also start
If the entered house number is not included on the map, the window
will show an address with the house number closest to the one
entered.
The system calculates the route. When the route calculation is
finished, the map opens in Route preview mode. The destination is
indicated on the map.
A description of all the options available in the D
be found in the chapter "Options in the Destination window" on page 38.
chapter "Route preview" on page 39. Please read on there.
the navigation before then by tapping on the (Take Me There)
button which is indicated underneath the entry box alongside the
already entered town or street.
If you specify the town only, the navigation system will calculate a route
to the town centre.
If you specify only the town and street without specifying a house
number or cross street, the navigation system will calculate the best
route to this street.
7.2.3 Announcing the address
It is particularly convenient to select the destination address by voice
command.
1. In the N
AVIGATION window tap on Voice Command.
When you call up the Voice Command function for the first time, a
window will open with general information and tips on how to use
the voice commands function.
► Tap on "Show this message again next time." so that this
window will not reappear when you use the voice commands
function again.
► Tap on Next.
The CITY window opens.
Indicated at the top is the country for which you can select
addresses.
► Tap on the country if your destination address is situated in a
different country. Then follow the instructions given by the
navigation system.
You will be asked for the address data in this order: City > Street >
House number.
ESTINATION window can
- 30 - Navigation
Loading...
