Page 1
National Mower Company 2006 Master Parts List
PART
NUMBER
02012 HHCS 5/16-24 X 1
02036 HHCS 3/8-24 X 2 1/4
02070 BOLT, 1/2 20 X 2 3/4
02097 SCREW, 1/4-20 X 3/4 BUTT ON HD
02106 SCREW, 1/2-13 X 2 SFMS
02109 SCREW, 5/16 X 24 X 3/4 FSCS
02114 WHEEL BOLT 7/16-20 X 1 7/32
DESCRIPTION
02149 SCREW, 1/4-20 X 1 1/4 FLAT HD
02154 HHCS 1/2-13 X 1/2"
02212 NUT, HEX, 1/2"-20 NF
02228 FHJN 5/16-24
02236 FHJN 9/16-18
02238 FHJN 5/8-11
02240 FHJN 3/4-16 BZ
02250 WHEEL NUT 7/16-20
02262 FHN N/E 5/16-24
02263 FHN N/E 3/8-24
02272 FHJN N/E 1-12
02277 FHJN 5/16-24 FLEX LOC
02286 FHJN 7/8-9
02294 NUT, CASTLE, 3/4-16
02296 FHJN 5/16-18
02301 WASHER, LOCK 1/4"
02402 WASHER, FLAT 5/16 SAE
02407 WASHER, FLAT 5/8
02501 WASHER MACH 1 1/4 X 3/4 X .030
02502 WASHER MACH 1 1/4 X 3/4 X .060
02503 WASHER MACH 1 1/4 X 3/4 X .134
02505 WASHER, 1/32" X 7/8" I.D.
02506 WASHER, 1/16" x 7/8" I.D.
02507 WASHER, 1/8" X 7/8" I.D.
Page 1 of 34
Page 2
National Mower Company 2006 Master Parts List
PART
NUMBER
02510 WASHER, 1/8" X 1-1/8" I.D.
02511 THRUST WASHER
02512 THRUST WASHER
02602 DUST CAP, 3/4" I.D.
02603 DUST CAP, 7/8" I.D.
02607 WASHER, AXLE, OUTSIDE 1/8"
02621 WASHER
02622 WASHER, BEARING CARRIER
02623 WASHER, 1" I.D.
02624 WASHER, 1-5/8" I.D.
02632 DUST CAP, ROLLER BRACKET
02637 INNER SEAL WASHER, ROLLER
02641 ROLLER WASHER
DESCRIPTION
02644 PUSH ARM WASHER
02651 WASHER, FLAT 3/4 SAE
02751 HEX JAM NUT, NYLOCK,3/4-16
03010 BEVEL GEAR, SIDE DIFF.
03011 PINION GEAR, DIFFERENTIAL
03102 SPROCKET, REAR MOWER,
03103 SPROCKET, CLUTCH
03105 SPROCKET, REAR MOWER,
03106 SPROCKET, REAR MOWER CTS
03107 SPROCKET, SLOW DOWN, 20T
03108 SPROCKET, HI SPEED, 15T
03109 SPROCKET, REAR MOWER, 16T
03111 DRIVE SPROCKET 11T
03115 SPROCKET, REEL 28 TOOTH
03116 SPROCKET, REAR MOWER CTS
03119 SPROCKET, IDLER
03502 O-RING, 7/8"
03503 SEAL, OIL
03504 O-RING, 1-1/8"
03506 OIL SEAL
03507 SEAL, REAR AXLE
03508 REEL CARRIER SEAL
03509 OIL SEAL, INNER
Page 2 of 34
Page 3
National Mower Company 2006 Master Parts List
PART
NUMBER
03510 OIL SEAL, OUTER
03511 O-RING, 3/4" I.D. (PREC.)
03512 SEAL, REAR AXLE (HX835)
03513 OIL SEAL, OUTER PARTS ONLY
03514 O-RING, 2-5/8" I.D. (PREC.)
03516 OIL SEAL , INNER (ROLLER)
03517 GEAR SHIFT OIL SEAL
03518 OIL SEAL 8400 WHEEL HUB
03601 PULLEY, WING MOWER, BC50 X 3/4
03602 2300 X 1"
03603 PULLEY, DRIVE, LOWER CTS
03604 PULLEY, MOWER, LOWER CTS
03606 PULLEY, HIGH SPEED
DESCRIPTION
03607 PULLEY (PLATE YELLOW ZINC)
03608 PULLEY, ENGINE CLUTCH
03609 PULLEY, MOTOR 2250x1
03613 PULLEY, CTS., (SLOW DOWN)
03614 PULLEY
03615 PULLEY, COUNTERSHAFT, BC50 7/8
03617 IDLER MAIN MOWING CLUTCH
03618 PULLEY, STEP
03623 PULLEY, MOWING CLUTCH
03629 PULLEY D2800 X 3/4 (2) 5/16-18
03630 PULLEY BC38 X 3/4 (2 5/16-18
03631 PULLEY-IDLER
03655 PULLEY
03901 BELT, A29, COUNTERSHAFT
03902 BELT, DRIVE, B66
03903 BELT, 6844 GATES, POWER RATED
03904 BELT, 6843 GATES, POWER RATED
03905 BELT, A42, REAR MOWER
03906 BELT, WING MOWER A36
03908 BELT, MAIN MOWER CLUTCH,
03909 BELT, MAIN DRIVE, NOTCHED BX83
03911 BELT, REAR MOWER, B47
03913 BELT, TRANSPORT CLUTCH A42BARE
Page 3 of 34
Page 4
National Mower Company 2006 Master Parts List
PART
NUMBER
03914 BELT, MOWING CLUTCH
03916 BELT, WING MOWER, B43
03918 BELT B-41
03919 BELT, HI SPEED B42
03921 BELT, ENGINE, WISC A43/ BS A45
03922 BELT, TRANSPORT,
03923 BELT, MAIN DRIVE, B85
03924 BELT, ENGINE, A38V NOTCHED
03926 BELT, TRANSPORT DL68 6841
03928 BELT-GATES #6840
03929 BELT-GATES #BX58
03930 BELT-GATES #BX38
03931 WING MOWER BELT (A34)
DESCRIPTION
03932 WING MOWER BELT (A35)
03935 GATES #6941 POWERRATED BELT
03939 BELT, MOWING & TRANS. IM 25
03945 BELT, GATES 6834
03946 RM BELT 8400 B48
04006 GREASE FITTING, 1/4-28
04007 SET SCREW, 5/16-18 X 3/8
04008 ROLL PIN 5/16 X 1 1/8
04011 SNAP RING, 3/4"
04013 WOODRUFF #11 KEY
04015 GREASE FITTING, 45° 1/4-28THD
04016 ROLL PIN 1/4 X 1 3/4
04020 SNAP RING, 7/8"
04022 PIN, CLEVIS, 3/8" I.D. X 1-1/4
04029 COTTER PIN .125 X 1.5
04030 RIVETS, BEDKNIFE, PAN HEAD
04035 GREASE FITTING, 90°
04049 PLUG, WELCH, DIFF. CASE
04055 ROLL PIN 1/8 X 3/4
04056 ROLL PIN 1/4 X 1 1/8
04069 WOODRUFF #5 KEY
04071 SNAP RING, 2" EXTERNAL
04074 STEERING ROD END
Page 4 of 34
Page 5
National Mower Company 2006 Master Parts List
PART
NUMBER
04076 ROD END #SPF-6
04077 ROD END #SPF-8
04079 EXT. RET.RING, 1.00 ID, H/D, McM #98585A121
04087 PRESSURE RELIEF VALVE
04096 BALL JOINT
04097 ROD END-CYLINDER
04099 KEY 3/16 SQUARE
04100 KEY 3/16 SQUARE
04101 SNAP RING, 7/8 EXTERNAL
04102 SNAP RING, 5/16"
04104 SET SCREW, 5/16-18 X 5/8
04107 U-BOLT 1/4-20 x 1.25 ID x 2.25
04501 SPRING, MAIN BELT IDLER ARM
DESCRIPTION
04502 SPRING, SHIFTER LEVER
04504 SPRING, REAR MOWER
04505 SPRING, PULL ROD, WING MOWER
04506 SPRING, CLUTCH, RM
04510 SPRING, COUNTERSHAFT
04511 SPRING, BELL CRANK, WING MOWER
04512 SPRING, SEAT
04515 SPRING, CLUTCH RELEASE
04516 Spring, Rear Mower
04517 TORSION SPRING
04519 SPACER, DIFFERENTIAL BEARING
04520 SPRING, BRAKE RETURN
04521 SPRING, W.M. PULL YOKE
04522 SPRING, HI-SPEED PIVOT BRACKET
04523 SPRING, HI-SPEED PIVOT BRACKET
04524 SPRING, PEDAL
04526 LOCK RING,
04531 SPRING, PINION PAWL
04533 LIFT SPRING, RIGHT
04535 REEL ADJUST SPRING
04538 LIFT SPRING, LEFT
04540 IDLER SPRING
04541 BELT TENSION SPRING
Page 5 of 34
Page 6
National Mower Company 2006 Master Parts List
PART
NUMBER
04543 CU C_BALANCE SPRING
04544 CU C_BALANCE SPRING
04547 SPRING(PLATED)-LIFT CHAIN
04549 REEL ADJUSTING SPRING 2" REV B
05001 ADJUSTER, STEERING GEAR
05002 BOLT, FOR CARRYING HANDLE
05022 PIN, CLUTCH, REAR MOWER
05050 COLLAR
05072 SPACER
05073 PUSH ARMS SHAFT
05075 REEL HEX ADJUSTER
05078 ROLLER PIN
05080 ROLLER SHAFT
DESCRIPTION
05105 NUT,BED KNIFE ( USE WITH
06002 BUSHING SAE 841
06003 BUSHING, REVERSE GEAR C321
06004 BUSHING, BULL GEAR C304
06005 BUSHING, WHEEL HUB, RIGHT
06006 BUSHING SAE 841
06007 BUSHING, PULLEY, RM, CTS E344
06008 BUSHING, AXEL PIVOT
06009 BUSHING SAE 841
06010 BUSHING, 1-1/6" O.D.
06011 BUSHING,
06012 BUSHING,
06014 BUSHING, CTS HOUSING
06015 BUSHING, ROLLER, EXTRUSION
06016 BUSHING, ROLLER HI-CUT
06026 BSH. 84" MAN. LIFT KIT
06030 BUSHING (#FF1011-4)
06031 BUSHING-PUSH ARM
06032 BUSHING #AA-1212-2
06035 BUSHING #AA-2203-7
06036 BUSHING (FF-600-5)
06038 THRUST BEARING
06039 BUSHING #AA-1043-4
Page 6 of 34
Page 7
National Mower Company 2006 Master Parts List
PART
NUMBER
06042 BUSHING #AA838-5
06101 BEARING, NEEDLE, 7/8" I.D.
06102 BEARING, NEEDLE, 3/4" I.D.
06103 BEARING, NEEDLE, 1-3/8" I.D.
06104 BEARING, BALL, 1-1/8" I.D.
06105 BEARING, LOWER COUNTERSHAFT
06107 BEARING, NEEDLE, 7/8" I.D.
06108 BEARING, ROLLER, 1-31/32" I.D.
06109 BEARING, PILLOW BLOCK, 7/8" ID
06110 BEARING, SEALED, 7/8" I.D.
06112 BEARING, BALL, FLANGE, 3/4" ID
06113 BEARING, BALL, FLANGE, 7/8" ID
06117 BEARING, CLUTCH PULLEY
DESCRIPTION
06118 BEARING, ASSEMBLY, STEER GEAR
06119 BEARING, SEALED, ROLLER
06120 REEL BEARING
06121 RACE, TAPER REEL BEARING
06122 RACE , ROLLER BRG.
06123 CONE , ROLLER BRG.
06124 BEARING-FLANGE
06125 BEARING-PILLOW BLOCK
06127 BEARING BLOCK
06129 NEUTRAL RETURN CONTROL BRG.
06130 REAR FORK BEARING
06131 REAR FORK BRG. RACE
06132 2 BOLT FLUSHMOUNT BEARING
06133 3 BOLT ECONOMOUNT BEARING
06136 BEARING, UPPER COUNTERSHAFT
06140 BEARING, BALL
06141 BEARING, C_SHAFT
06142 BEARING, ROLLER
070008 BELT TOOL KIT
070009 H.O.C. KIT
07001 TIE ROD COMPLETE
070018 COUPLING REPLACEMENT KIT
07003 GASKET, BACK PLATE COVER
Page 7 of 34
Page 8
National Mower Company 2006 Master Parts List
PART
NUMBER
07006 GASKET SET, 2-07010 1-07006
07007 GRIP, SHIFTER, 1/4 X 1"
07009 GASKET SET, 1-07009 1-07011
07018 WHEEL & TIRE, REAR
07019 1 1/2" SADDLE CLAMP
07021 CHAIN, REAR MOWER
07023 GRIP, LEVER, 3/16" X 3/4"
07024 KNOB VENDOR #0065-C 732-01 RED
07032 THROTTLE, WIRE & CONDUIT
07033 INTERLOCK SWITCH
07034 KEY SWITCH, BRIGGS & STRATTON
07035 SWITCH, SAFETY, NORMALLY OPEN
07036 SEAT, PADDED -V1500 (68")
DESCRIPTION
07037 DECALS, SET, 68"
07038 WHEEL & TIRE, FRONT
07039 GRIP, HANDLE, 3/8" X 1-1/4"
07043 SPACER, ROLLER 1-15/32"
07045 ROLLER, ANTI-SCALP KIT
07048 CHAIN, CTS #50X42P
07049 LINK, MAIN CONNECTING
07050 LIFTER CHAIN
07051 1/4" COLD SHUT
07053 JOINT, BALL
07054 CALIPER
07057 SOLENOID
07060 KEYSWITCH, ELECTRIC
07061 WIRING HARNESS, KOHLER ELEC.
07063 METER, HOUR 2"
07064 METER, AMP 2" FARIA APO532
07065 SWITCH,IGNITION (B&S VANGUARD)
07071 LEGEND STEERING WHEEL-HARD RIM
07073 WHEEL, REAR 8 X 12
07075 TIRE & WHEEL, 23/850 X 12
07076 DECALS (SET)
07077 CHAIN-RM-#40 47P
07078 LINK, CONNECTING
Page 8 of 34
Page 9
National Mower Company 2006 Master Parts List
PART
NUMBER
07079 LINK, CONNECTING
07090 SWITCH, SAFTEY, N/C REV.A
07101 SEAT, ADJUSTER
07102 PLUG, WIRING HARNESS
07104 WIRE, BATTERY GROUND
07109 HARNESS, WIRING,
07110 CABLE, CHOKE
07112 THROTTLE
07127 WIRE & CONDUIT, ONLY
07128 WHEEL, FRONT, ONLY (NO TIRE)
07130 LUG TIRE, RT.
07136 TIRE 8 X 12
07137 FRONT TIRE, ONLY, 16-650X8
DESCRIPTION
07138 FRONT WHEEL, W/BRG., LESS TIRE
07140 GAS CAP, METAL TANK
07161 THROTTLE CONTROL, (COMPLETE)
07165 VALVE, INLINE, GAS TANK
07167 GAS TANK, PLASTIC
07175 GAS LINE CLAMP
07176 GAS CAP, PLASTIC TANK
07177 ATV - RIM ONLY
07178 ATV - TIRE ONLY
07181 KNOB, ENGAGEMENT LEVER
07203 LUG TIRE LT. 68"
07220 CENTER CAP FOR STEERING WHEEL
07226 GRIP, WING MOWER, ARM
07230 GRIP, 84" MAN. LIFT KIT
07240 LINK-LIFT VALVE
07241 THROTTLE CONTROL
07252 DECAL-NATIONAL
07256 DECAL-DOWN
07257 DECAL-UP
07258 CAP-BEARING
07261 NON-SKID R.H.
07262 NON-SKID L.H.
07265 LIFT CHAIN 6 LINKS REV A
Page 9 of 34
Page 10
National Mower Company 2006 Master Parts List
PART
NUMBER
07269 WHEEL BOLT 1/2-20 NF
07272 MODEL 11 PUMP 1120-039
07274 LIFT VALVE
07276 FILTER ASSY
07277 FILTER HEAD
07278 FILTER ELEMENT
07299 HOSE-CASE DRAIN R.H.
07303 HOSE-MOTOR TO TEE
07305 HOSE-MOTOR TO TEE
07308 LINE-TEE MOTOR CASE DRAIN
07318 HUB-REAR WHEEL
07325 SWITCH-REEL CONTROL
07326 SWITCH-NEUTRAL CONTROL
DESCRIPTION
07328 WIRE HARNESS
07332 SWITCH-SEAT
07333 SEAT
07338 BASKET-FRONT
07339 OIL TANK CAP
07347 RH BRAKE CABLE
07348 LH BRAKE CABLE
07350 RH BRAKE CALIPER
07351 LH BRAKE CALIPER
07352 BRAKE DISC
07354 ROLLER SPACER 1 1/32"
07355 RUBBER TANK BASE
07358 DECAL SET
07361 WM SHIELD SHAFT PLUG
07365 LIFT CHAIN 7 LINK REV A
07372 CE MARK 84"
07375 LINE-PUMP TO VALVE
07382 HOSE-BULKHEAD TO BULKHEAD
07384 WIRE-HARNESS TO TOGGLE SWITCH
07385 WIRE-SOLENOID GROUND
07386 TOGGLE SWITCH
07388 WHEEL MOTOR
07399 KNOB DAVIES PN# 3035
Page 10 of 34
Page 11
National Mower Company 2006 Master Parts List
PART
NUMBER
07403 DECAL-PARKING BRAKE CE
07404 DECAL-NOISE Lwa 106
07406 DECAL-SLOPE CE
07408 DECAL-INST. CE
07409 DECAL-DASH 3-WD
07411 DANGER HANDS & FEET DECAL
07424 TIRE 18-8.50 X 8.0
07428 WIRE HARNESS-HYDRO 84 VANGUARD
07429 CHAIN-C_SHAFT REV B
07430 MUFFLER CLAMP
07433 MUFFLER CLAMP 1 1/4"
07437 DECAL HYDRO 70
07438 EXPANSION PLUG
DESCRIPTION
07460 PUMP, MODEL 11 W/ TOW VALVE
07476 HOSE, PUMP/MOTOR
07480 HOSE, SUCTION
07481 CHAIN, REAR MOWER
07491 WIRE HARNESS
07494 GAS CAP #468324
07495 INTERLOCK MODULE
07496 SWITCH, ELECTRIC CLUTCH
07498 INTERLOCK MODULE
07501 SEAL KIT, CYLINDER
07504 SWITCH, SEAT
07505 CHAIN #40 52 PITCHES
07508 CHAIN-COUPLER 4016
07513 3.5 H.P. B&S ENG. IM 25
07521 NYLON WASHER 1/2 ID X 3/4 OD
07526 HOSE, REMOTE FILTER
07529 CHAIN-C_SHAFT #50
07530 CABLE-BRAKE
07531 CABLE-BRAKE
07532 REPAIR KIT, MODEL 11
07537 HOSE-CASE DRAIN
07542 FITTING-HYD
07543 FITTING-HYD
Page 11 of 34
Page 12
National Mower Company 2006 Master Parts List
PART
NUMBER
07544 FITTING-HYD
07547 TURF TAMER 23 X 10-50 X 12
07550 BELT, PUMP B-37K
07562 SEAL KIT FOR POWER STEERING
07573 ELECTRIC CLUTCH
07576 TS22 DECAL
07578 IS22 HOC DECAL
07590 DECAL, MOWER CLUTCH REAR
07596 DECAL,HOC SCALE VCU
07600 DECAL, CUTTING UNIT DANGER
07688 FILTER
07689 ELEMENT ONLY
07692 LIFT VALVE,
DESCRIPTION
07695 STARTER SOLENOID RELAY, WAYTEK #75002
07700 CIRCUIT BREAKER, WAYTEK #46374
07706 SEAT
07714 LIFT SPRING - REAR PULL ARM
07719 BUSHING - 1X1.5X2, BOSTON #B1624-16
07733 PRE-CLEANER
07748 HOSE I TRIM
07762 HOSE I TRIM
07764 HOSE I TRIM
07765 HOSE I TRIM
07778 DECAL WARN LIGHTS-PARK
07779 DECAL IGNITION MOWER ON-OFF
07780 DECAL MOWER RAISE-LOWER
07781 LINCH PIN
07782 LYNCH PIN, .44", McM #90170A221
07792 DECAL I-TRIM LOGO
07794 DECAL NATIONAL MOWER
07797 DECAL DIESEL FLUID ONLY
07838 CENTER CAP FOR STEERING WHEEL
07840 LATCH
07851 VALVE, CARTRIDGE, 12V HYDRAULI
07869 Seal Kit -Base pump -K50827-100
07870 Seal Kit -MS Control- K50827-101
Page 12 of 34
Page 13
National Mower Company 2006 Master Parts List
PART
NUMBER
07871 Seal Kit - Tow Valve -K50827-104
07872 O-Ring, Gear Pump 2-042
07873 Seal Repair kit, Gear Pump -9900205-000
07874 Seal Kit, Check Valve -SK08-2N-T
07875 Seal Kit, Deck Motor, R, Rear 8772-023-00S
07876 Seal Kit, Deck Valve -Inlet w/standard relief -6009250
07877 Seal Kit, Deck Valve -Single Section -6029520
07878 Seal Kit, Deck Valve -Outlet with pow beyond -6029522
07879 Seal Kit, Solonoid and flow control -SK12-3N-MM
07880 Seal Kit, relief valve -SK10-2N-B
07957 ENGINE, 6.75 HP
08010 U-BOLT, SHIFTER
08013 LINKAGE, LOWER
DESCRIPTION
08030 ROD, PULL
08033 ROD, SIDE POST BATTERY
08037 ROD, PARKING BRAKE
08038 ROD, PARKING BRAKE
08046 STUD, BELT GUIDE, OUTSIDE
08047 STUD, BELT GUIDE, INSIDE
08083 BAR, ADJUSTMENT, HANDLE BAR
09002 GUARD, ENGINE CLUTCH
09004 WASHER, REEL ADJUSTER
09012 RING
09014 DRAG LINK, COMPLETE
09026 SHIM, CLUTCH SHAFT CARIER,1/32
09031 SHIELD, PULLEY
09033 SHIELD, MAIN BELT, INCL. R EXT
09034 CUP, BEARING, INNER
09035 CUP, BEARING, OUTER
09044 GUARD, CLUTCH, REAR MOWER
09046 PURCHASE - 10GA LARGE HOLE
09047 PURCHASE - 22GA LARGE HOLE
09050 BRACKET, ROLLER ASSEMBLY
09052 DASHBOARD
09054 BALL JOINT, DRAG LINK
09057 CALIPER, PUCK
Page 13 of 34
Page 14
National Mower Company 2006 Master Parts List
PART
NUMBER
09072 TIRE, LO-CUT, 10" DIA.
09077 PAWL, PINION
09083 COVER, BATTERY
09090 CABLE, ROLLER SCRAPER
09092 CABLE,ROLLER SCRAPER
09100 MOTOR BELT SHIELD DL68
09114 TOWER COVER
09169 CABLE-ROLLER SCRAPER
09170 GUARD, CLUTCH, REAR MOWER
09173 REEL GUARD
09182 CABLE, ROLLER SCRAPER
09183 CABLE, ROLLER SCRAPER
09198 CONTROL, THROTTLE IM 25
DESCRIPTION
09199 CONTROL, DRIVE IM 25
09207 CONTROL DRIVE
09213 SHIELD COVER, LIFT ARM LH
09220 SHIELD COVER, LIFT ARM RH
130400 BEARING
140102 BELT
140104 BELT B65
141000 SPROCKET
141800 COUNTERSHAFT
200045 HOUSING, INTERMEDIATE SHAFT
200049 SHAFT, REVERSE GEAR
200050 GEAR, REVERSE & BSHG
200051 SLIDING WASHER, DIFFER. CASE
200054 GEAR, SHIFTING, 11T
200055 COUNTERSHAFT, SHIFTING REVB
200056 CARRIER UNIT, COUNTERSHAFT
200063 CARRIER, SHIFTER
200064 LEVER, SHIFTER
200065 COVER, DIFFERENTIAL, OUTSIDE
200066 BULL GEAR ASSEMBLY
200069 PINION, DIFFERENTIAL
200070 INTERMEDIATE SHAFT UNIT
200075 REAR AXLE WELDMENT
Page 14 of 34
Page 15
National Mower Company 2006 Master Parts List
PART
NUMBER
200079 HUB, WHEEL, RIGHT REAR,
200084 SEAL, DISC-SPLIT, WHEEL HUB
200088 SLEEVE, BEARING, AXLE
200090 HUB, LEFT REAR WHEEL
200095 COLLAR, REAR AXLE
200096 CAP, AXLE, LEFT END
200097 BRAKE DRUM
200099 BAND, BRAKE WITH LINING
200102 LEVER, BRAKE BAND
200109 RM PULL BRKT
200115 IDLER ARM UNIT, REAR MOWER
200123 BUSHING, PULL YOKE
200124 LIFTER ROD, REAR MOWER
DESCRIPTION
200128 CARRIER, LOWER COUNTERSHAFT
200133 BUSHING, PULL ROD
200135 COUNTERSHAFT, LOWER
200139 FOOT REST, RIGHT
200145 PULL ARM UNIT, RIGHT, WM
200150 PULL ARM UNIT, LEFT, WM
200151 PULL ROD, WING MOWER
200154 HOUSING, MAIN COUNTERSHAFT
200157 COUNTERSHAFT, MAIN
200158 STEP PULLEY, MAIN COUNTERSHAFT
200167 LEVER, LOWER COUNTERSHAFT
200170 ROD, COUNTERSHAFT CLUTCH
200182 COLLAR, LOCK, 1-1/16" O.D.
200184 ARM, MAIN BELT IDLER
200193 SPINDLE ASSEMBLY, LEFT HAND
200196 SPINDLE ASSEMBLY, RIGHT HAND
200203 BRACKET - THROTTLE CONTROL
200234 COVER, DIFFERENTIAL, INSIDE
200235 UPRIGHT, SHIELD, WING MOWER
200236 REEL, TAKE-UP
200237 PIVOT TUBE, REAR MOWER
200241 6-BLADE REEL ASSEMBLY
200252 REEL CARRIER ASSEMBLY, RIGHT
Page 15 of 34
Page 16
National Mower Company 2006 Master Parts List
PART
NUMBER
200256 ADJUSTING SCREW & NUT, BEARING
200257 SHAFT ASSEMBLY, REAR MOWER
200263 COUNTERSHAFT, REAR MOWER REVA
200264 PULLEY W/BUSHING, COUNTERSHAFT
200266 CLUTCH, SLIDING JAW, RM
200268 GUARD, REAR MOWER CHAIN
200271 YOKE, SHIFTER, REAR MOWER
200273 BRACKET, CLUTCH LEVER, RM
200276 SHIFTER LEVER, CLUTCH, RM
200287 SCRAPER, PULLEY
200293 BED KNIFE, WING MOWER, 21"
200296 REEL ASSY. 6 BLADE 7" DIA
200302 SHAFT, ROLLER, WING MOWER
DESCRIPTION
200350 FRONT AXLE UNIT
200354 KING PIN, RIGHT
200359 KING PIN, LEFT
200363 PULL ROD, WING MOWER
200365 FOOT REST, RIGHT
200366 HINGE ROD, FOOT REST
200368 SHAFT, CLUTCH
200371 BEARING CARRIER, LOWER CTS.
200373 COUNTERSHAFT, LOWER
200374 CLUTCH JAW, SLIDING
200377 GUIDE, W.M. CL. BELL CRANK
200382 BELL CRANK, CLUTCH, WING MOWER
200385 SHIELD, WING MOWER PULLEY,LEFT
200388 LUG, SHIFTER YELLOW - ZINC
200389 SHIELD, WING MOWER PULLEY, RT.
200397 DIFFERENTIAL WITH AXLES
200398 DIFFERENTIAL CASE, LEFT
200399 BULL GEAR WITH HUB
200402 DIFFERENTIAL CAGE
200405 WASHER, PINION GEAR, DIFF.
200406 PINION SHAFT, DIFF.
200407 THRUST WASHER, DIFF.
200408 INTERMEDIATE GEARS,
Page 16 of 34
Page 17
National Mower Company 2006 Master Parts List
PART
NUMBER
200413 SPLINE SHAFT
200414 INPUT GEAR 12T
200415 REVERSE GEARS, INC. SHAFT
200419 SHIFTER FORK
200422 DIFFERENTIAL CASE, RIGHT
200426 STEP PULLEY
200427 RT AXLE HOUSING
200436 BRACE, BATTERY BOX
200437 LT AXLE HOUSING
200441 AXLE, REAR - Include 5ea.02114
200451 HANDLE
200454 PIVOT
200458 ROD, PULL
DESCRIPTION
200462 HINGE , SEAT
200466 COLLAR, SHIFT LEVER
200468 BUSHING, RM PULL BRACKET
200469 YOKE, PULL, REAR MOWER
200475 IDLER ARM, RM 84"
200478 BRACKET, REAR SHIFTER
200479 SHIFTER LEVER REV B
200482 PIVOT, BRAKE
200486 DISC, BRAKE
200488 PIVOT, BRAKE
200493 LEVER, FOOT BRAKE
200496 BRACKET, FOOT BRAKE LEVER
200497 ROD, BRAKE LINKAGE
200509 LEVER, MAIN MOWING CLUTCH
200512 PEDAL, TRANSPORT
200530 GUIDE, BELT, H.S. PULLEY
200531 SUPPORT PIVOT
200541 MOTOR PULLEY, 3 GROOVE
200542 KEY, SQUARE, ENGINE
200546 GUIDE,BELT,ENGINE PULLEY
200559 FRAME, MOWER,
200560 FRAME, LEFT W.M. WELDMENT
200572 REEL, SIX BLADE
Page 17 of 34
Page 18
National Mower Company 2006 Master Parts List
PART
NUMBER
200584 REEL CARRIER, LEFT
200587 BRACKET
200596 HOOK, LEFT WING MOWER
200597 HOOK, RIGHT WING MOWER
200601 FRAME, REAR MOWER
200608 PULLEY,REAR MOWER 84 W/BSH
200610 COUNTERSHAFT, R M, 18-1/2"
200611 GUARD, RM CHAIN
200613 BRACKET, R.M. CLUTCH SHIELD
200616 ROLLER BRKT, RIGHT COMPLETE
200617 BRACKET, ROLLER, RIGHT (WELD)
200618 ROLLER BRKT, LEFT COMPLETE
200619 BRACKET, ROLLER, LEFT (WELD)
DESCRIPTION
200624 SHAFT, ROLLER 34.2857"
200625 SLEEVE, ADJUSTER, ROLLER
200636 ADJUSTER, ROLLER BRKT
200639 TUBE WELDMENT, MUFFLER, KOHLER
200640 BRACKET, RT. W.M. REAR YOKE
200642 SHIFTER LEVER, CLUTCH, REAR
200644 ADJUSTING WRENCH
200655 HOOK, LEFT, WING MOWER
200656 HOOK, RIGHT, WING MOWER
200667 PLATE, CALIPER MOUNT
200674 BUSHING, TIE ROD END
200675 BUSHING, SHIFTER LEVER SPRING
200676 BUSHING, 9/16" X 25/64"
200686 SHIM, OUT REAR AXLE,
200697 W.M. BELL CRANK ASSY
200698 LOWER COUNTERSHAFT SPROCKET
200705 R.M. COUNTERSHAFT & BUSHINGS
200722 BED KNIFE, LOW - CUT, 30"
200742 SHAFT IDLER PIVOT
200751 Rod, Rear Mower Roller Adj 84"
200752 ASSEMBLY,ROLLER BRKT,L REAR
200753 ASSEMBLY,ROLLER BRKT,RT REAR
200762 MOTOR PULLEY, 3 GROOVE
Page 18 of 34
Page 19
National Mower Company 2006 Master Parts List
PART
NUMBER
200763 BUMPER, VANGUARD
200768 BRACKET, SAFETY SWITCHES
200774 BRACE, SIDE POST BATTERY
200777 HI SPEED CLUTCH LINK ASSEMBLY
200814 HINGE, SEAT
200820 BED KNIFE FRAME, WING MOWER
200822 DRAG LINK
200828 SPRING LOCK, HOOK
200829 PEDAL, HIGH SPEED
200830 STEERING GEAR
200839 8 BLADE REEL, 30"
200844 CLUTCH ROD, ENGINE
200863 CLEVIS
DESCRIPTION
200867 DRAG LINK, BALL JOINT
200890 WASHER, AXLE, LEFT
200900 SPRING, ROD, COUNTERSHAFT IDLE
200959 BELT GUIDE, KOHLER
200964 LINK, TRANSPORT CLUTCH
200967 PULLEY SHIELD
200978 KEY, ENGINE, SQUARE
200985 LEVER, TRANSPORT CLUTCH
200991 STEERING SECTOR
200994 WRIST PIN, STEERING, THREADED
201025 CLUTCH SLIDE PLATE
201026 CLUTCH FINGER
201029 CLUTCH THROWOUT
201030 SHAFT,
201031 SLEEVE
201033 SLEEVE, CLUTCH BELL CRANK
201035 BRASS YOKE CLUTCH
201044 BELT GUIDE, CLUTCH SHAFT
201047 SPACER, CLUTCH PULLEY BEARING
201048 WASHER, CLUTCH
201055 SPACER
201056 SHAFT, IDLER PIVOT
201092 PULL PLATE, REAR MOWER
Page 19 of 34
Page 20
National Mower Company 2006 Master Parts List
PART
NUMBER
201095 CUP, BEARING, OUTER
201099 SEAL CARRIER, REAR AXLE
201121 HOLDER, GAS TANK
201122 HOLDER, GAS TANK
201129 PITMAN ARM, STEERING GEAR
201139 STEERING SHAFT
201140 TUBE, STEERING GEAR
201141 NATIONAL STEERING GEAR
201147 HOUSING, STRG. GEAR
201231 BED KNIFE, LO-CUT
201257 PIN, ASSEMBLY, STEERING GEAR
201275 DIFF. COMPLETE LESS AXLES
201277 ADJUSTER, ROLLER BRACKET
DESCRIPTION
201279 HOLDER, ADJUSTABLE, GAS TANK
201283 MOWER SKID, LEFT
201284 MOWER SKID, RIGHT
201324 WHEEL, W/GEAR, LO-CUT
201335 TUBE, ROLLER, 68" (WELD)
201356 PINION
201383 CAP SCREW, PULLEY SCRAPER, SPC
201394 BRACKET, BELT GUIDE, UPPER
201395 BRACKET, BELT GUIDE, LOWER
201407 30" BOLT ON BEDKNIFE
201418 SHAFT, ROLLER, 68" WING MOWER
201420 SHAFT, ROLLER, 68" REAR MOWER
201427 FRONT AXLE WELD WITH BSH
201430 RADIUS ROD WITH NUTS
201437 TAKE UP REEL BEARING
201445 SHAFT, PLASTIC ROLLER, WM
201446 SHAFT, PLASTIC ROLLER, RM
201449 BRACKET, ROLLER
201452 LEVER, PARKING BRAKE (WELD)
201453 SLIDE, PARKING BRAKE (WELD)
201457 MOUNT, PARKING BRAKE (WELD)
201474 IDLER ARM ASSEMBLY
201478 ROLLER BRKT ASSY 68" & P.M.
Page 20 of 34
Page 21
National Mower Company 2006 Master Parts List
PART
NUMBER
201479 ROLLER BRKT ASSY
201482 PLATE, BOTTOM, BATTERY BOX
201492 HOLD DOWN, SIDE POST, BATTERY
201504 21" BOLT ON BEDKNIFE
201509 GUIDE, MAIN CL BRKT
201513 BRKT. MOWER SHIELD
201519 RM SHIELD P. COAT GREEN
201520 WM SHIELD, RT. P, COAT GREEN
201521 WM SHIELD, LT. P. COAT GREEN
201536 WM PULL ARM WELDMENT
201538 BELT GUIDE, UPPER, 68" KAW ENG
201541 BELT GUIDE, LOWER, 68" KAW ENG
201585 SKID, WING MOWER
DESCRIPTION
201597 GAS LINE, 1/4" ID NEOPRENE
201641 RM FRAME WELDMENT
201646 LIFT SHAFT
201647 CABLE BRKT.
201650 LT. SWITCH ROD PLATED
201659 LIFT HANDLE WELD.
201660 LIFT LEVER WELD.
201661 HOOK-BRKT WELDMENT
201662 LIFT HOOK PLATED
201663 LIFT CHAIN ASSY
201673 CAP REPLACES 07148
201681 ROLLER SCRAPER ADJ., WM RH
201682 ROLLER SCRAPER ADJ, REAR M, RH
201684 ROLLER SCRAPER ADJ, WM, LH
201685 ROLLER SCRAPER ADJ, REAR M, LH
201695 CLUTCH PIVOT CARRIER, L.H.
201696 CLUTCH PIVOT CARRIER, R.H.
201721 TRANSPORT FOOT LEVER
201770 MAIN CLUTCH SHAFT
201773 BED KNIFE FRAME, R/M W/BOLT
201775 BED KNIFE FRAME, W/M W/BOLT
201782 PULLEY SCRAPER
201802 NUT, BED KNIFE (USE WITH
Page 21 of 34
Page 22
National Mower Company 2006 Master Parts List
PART
NUMBER
201804 RM CTS. HSG. W/ BUSHINGS
201821 SHAFT, ANTI-SCALP ROLLER 30"
201831 SQUARE KEY, MANUAL LIFT
201840 TIRE & WHEEL, LO CUT
201841 BEDKNIFE FRAME W/BOLT-ON
201851 TIE ROD 68"
201859 ROLLER SHAFT & COLLARS
201860 THROTTLE CONTROL ASSY
201871 MAIN COUNTERSHAFT
201872 MAIN CTS STEP PULLEY
201880 WM ARM PIN WELDMENT
201881 MOWING BELT RETAINER
201884 TRANSPORT BELT RETAINER
DESCRIPTION
201889 ENGINE BELT RETAINER BRKT
201919 TRANSPORT CLUTCH ROD
201924 MAIN CTS HOUSING WITH BRGS
201928 UPPER BELT GUIDE
201960 DRILLED AXLE PIVOT BSH
201961 DRILLED AXLE PIVOT BSH
202072 GRASS SHIELD BRACE
202073 GRASS SHIELD BRKT
202074 FRONT ROLLER BRKT WELD
202076 RM GRASS SHIELD
202090 WM GRASS SHIELD
202091 21" TIMKIN ROLLER
202092 21" TIMKIN TUBE W/ PLUGS
202095 21" SHAFT W/ COLLARS
202210 PLASTIC ROLLER MACHINED
202301 SEAT BRACE
202332 RH OUTSIDE RM SHIELD
202373 DRAG LINK
202374 CLEVIS PIN, TIE ROD, DRILLED
202375 COLLAR, COUNTERSHAFT, DRILLED
202436 #9 WOODRUFF KEY HT. TREATED
202437 ENGINE CL. ROD SPRING PLATED
202438 RM CL LEVER SPRING PLATED
Page 22 of 34
Page 23
National Mower Company 2006 Master Parts List
PART
NUMBER
202439 MAIN CLUTCH LINK SPRING PLATED
202440 TRANSPORT CL SPRING PLATED
202441 TRANS. PEDAL RETURN SPRING
202442 MAIN MOWING CL. LINK PLATED
202443 LOWER MAIN CL ROD PLATED
202445 MOTOR PULLEY STUD PLATED
202450 WM PIN WITH NUT
202466 FRT TIRE & WHEEL WITH BRG 84"
202494 MOTOR-HYDRAULIC
202495 SPACER-DRIVE SHAFT (DIFF)
202496 SHAFT-INPUT W.A.
202500 REAR AXLE W.A. L.H.
202502 REAR PULL ARM W.A.
DESCRIPTION
202503 SHAFT-R.M. C_SHAFT
202506 PULLEY-REAR DIFF. D4400X7/8
202507 PULLEY-ENGINE BC54X1
202509 PULLEY-IDLER
202511 MOTOR-POWER STEERING
202585 PULLEY-LOWER C_SHAFT BC78X7/8
202587 SPROCKET-30 TOOTH
202677 FRONT AXLE ASSEMBLY W/BUSHINGS
202681 SPINDLE R.H.W.A.
202682 SPINDLE L.H. W.A.
202683 TIE ROD ASSY
202684 GAS TANK
202686 SHAFT-DIFF IDLER
202702 SPROCKET-DRIVER
202703 SPROCKET-IDLER
202719 CARRIER W.A
202730 SPACER-SPROCKET
202747 LINE-HYD
202748 LINE-HYD
202750 LINE-HYD
202769 DIFF.COMPLETE LESS AXLES
202772 HOUSING R.M. C_SHAFT W/BUSHING
202776 SEAL KIT-WHEEL MOTOR
Page 23 of 34
Page 24
National Mower Company 2006 Master Parts List
PART
NUMBER
202780 BELT GUIDE WELDMENT
202798 MAIN CLUTCH SPRING PLATED
202809 HOSE-BLKHD/STEERING CYL
202834 CLUTCH DISC
202836 EXHAUST PIPE
202838 SPROCKET-12 TOOTH
202839 SPROCKET - 24 TOOTH
202863 2 GROOVE PULLEY
202866 HUB-PULLEY
202868 HUB-DRIVE
202927 FENDER- L.H.
202959 SHIELD, OUTSIDE, W.M.
202960 SHIELD, L.H. OUTSIDE, W.M.
DESCRIPTION
202961 SHIELD, R.H. OUTSIDE,
202982 PULLEY & BUSHING, PUMP REV C
202990 SWITCH-MOWER CLUTCH
202996 HOOD PIVOT W.A.
203007 REMOTE OIL FILL
203015 SHAFT-H-FRAMES
203018 H-FRAME W.A.
203044 C_SHAFT GUARD R.H. W.A.
203056 NEUTRAL SAFETY SWITCH ASSY
203057 NON-SKID FOOTREST
203086 THROTTLE CONTROL
203091 LIFT CHAIN SUB ASSY
203131 ROLLER ADJ. BRACKET W.A. L.H.
203133 ROLLER ADJ. BRACKET W.A. R.H.
203172 ROLLER BRACKET W.A. R.H.
203173 ROLLER W.A.
203196 MUFFLER COVER
203248 ROLLER BRACKET W.A. L.H.
203250 ROLLER W.A.
203291 HEAT SHIELD W.A.
203298 RUBBER LATCH
203401 HOOD ASSY
203405 FENDER ASY R.H.
Page 24 of 34
Page 25
National Mower Company 2006 Master Parts List
PART
NUMBER
203452 R. M. LIFTER TEE
203470 ROLLER BRACKET ASSY R.H.
203471 ROLLER BRACKET ASSY L.H.
203472 ARMREST-3 HOLE
203545 BUMPER
203567 SHIFTER LEVER, REAR MOWER
203698 GUAGE, HT OF CUT (chicken bar)
203704 SPIDER (PARTS ONLY)
203727 SKID BAR W.A. R.H.
203728 SKID BAR W.A. L.H.
203768 BLADE, VERTICUT
203788 RUBBER FLAP
203799 GUARD, REEL PULLEY L.H.
DESCRIPTION
203800 GUARD, REEL PULLEY R.H.(BLACK)
203857 SPACER, HANGER
203867 SPACER, SHIELD UPRIGHT
203933 REEL CARRIER, R.H.
203934 REEL CARRIER, L.H.
203947 INTERLOCK MODUAL ASSY
203956 SHAFT-REAR IDLER
203967 OIL SPLASHER HT7
203974 VERTICUT REEL ASSY RH
203975 VERTICUT REEL ASSY L.H
203982 PULLEY, C_SHAFT
203988 STRAP, RUBBER FLAP
203992 Motor Seal Kit for 202494
204000 IDLER SUPPORT, PUMP
204003 SPRING, CHAIN IDLER
204004 SPRING, PUMP IDLER
204007 IDLER ARM W.A., SPROCKET
204008 IDLER ARM W.A., CLUTCH PULLEY
204009 PIN, IDLER
204026 SPRING, CLUTCH IDLER
204061 SHAFT, UPPER C_SHAFT
204062 SHAFT, C_SHAFT
204063 SUPPORT W.A.
Page 25 of 34
Page 26
National Mower Company 2006 Master Parts List
PART
NUMBER
204070 SLEEVE, IDLER
204140 RUBBER COVERED ROLLER 30"
204169 BEARING HANGER R.H.
204170 BEARING HANGER L.H.
204171 SHIELD R.H
204173 SHIELD L.H.
204175 SHIELD W.A.
204178 PULLEY SCRAPPER
204277 PARKING BRAKE ASSY
204310 SPROCKET-15 TOOTH
204331 PULL BRACKET, REAR MOWER
204333 PIN, REAR MOWER PULL
204366 YOKE L.H. W.A.
DESCRIPTION
204367 YOKE R.H. W.A.
204383 HUB-WHEEL INCL. 06130,06131
204404 PIN-SPINDLES
204418 SPROCKET-IDLER
204420 SPROCKET-UPPER C_SHAFT
204430 SHAFT-UPPER C_SHAFT
204440 LINE-REAR TOP R.H.
204441 LINE-REAR BOTTOM R.H.
204447 BUSHING - PULL ARM
204454 SHAFT-UPPER C_SHAFT
204458 SPROCKET
204461 IDLER ARM-PUMP
204462 IDLER SUPPORT-PUMP
204465 HYD LINE ORB/FILTER
204467 HYD LINE PUMP/TEE (TOP)
204471 ROD-BATTERY SUPPORT
204482 BREATHER-OIL TANK
204492 STUB SHAFT, REEL W.M.
204495 ADJUSTER ROD W.A.
204497 Bearing in roller assy. 21"
204498 Bearing in roller assy. 30"
204499 Bearing roller shaft 30"
204504 HOLD DOWN-BATTERY
Page 26 of 34
Page 27
National Mower Company 2006 Master Parts List
PART
NUMBER
204520 WIRE HARNESS-8400TM
204522 IDLER ARM W.A. R.M.
204527 CAM PLATE W.A.
204534 REAR PULL ARM W.A.
204544 HOSE-VENT
204548 FENDER L.H.
204850 BRAKE LINKAGE ASSY
204860 REEL STUB SHAFT
204877 ROLLER ASSEMBLY
204988 INTERLOCK MODUAL ASSEMBLY
204991 SCALE PLATE, HOC ADJUSTER
204995 SPRING, HOC
204996 VINYL CAP
DESCRIPTION
204997 SWIVEL END HOC.
205330 PLASTIC BEARING CAP
205331 Roller brkt assy RH,brg roller
205332 Roller brkt assy LH,brg roller
205339 DECAL, HOC SCALE, RM REV A
205344 THREADED ROD, WELD
205346 DECAL, HOC SCALE, WM REV.A
205348 NO TOOL HOC ADJ. L.H.
205349 NO TOOL HOC ADJ. R.H.
205375 ROLLER SCRAPER BRACKET, RH
205376 ROLLER SCRAPER BRACKET, LH
205388 Cable mtg brkt LH 84 roller
205389 Cable mtg brkt RH 84 roller
205395 Roller brkt wldmt, RH DAH
205396 Roller brkt wldmt, LH DAH
205399 HOC adjuster wldmt, RH DAH
205400 HOC adjuster wldmt, LH DAH
205454 WING MOWER PULL ARM WELDMENT
302064 FOOTREST R.H. W.A.
302092 MOUNTING PLATE POWDERCOATED
302093 FRONT PLATE-AIR DUCT
302128 EXHAUST PIPE
302150 PEDAL PIVOT W.A.
Page 27 of 34
Page 28
National Mower Company 2006 Master Parts List
PART
NUMBER
302169 PUSH ARM W.A.
302171 PULL ARM W.A.
302172 PUSH ARM
302181 SHIELD
302185 SIDE PLATE W.A. (1)
302186 SIDE PLATE W.A. (1)
302205 LEVER
302227 SHAFT
302248 PULL ARM W.A.
302252 PULL ARM W.A.
302255 SLEEVE-REAR PULL ARM
302310 BEDKNIFE 25"
302311 Bedbar And Bedknife Assy.
DESCRIPTION
302336 SHAFT-PULL
302359 AIRBOX POWDERCOATED
302360 SCRAPPER-PULLEY
302437 KEY-ENGINE COUPLER
302455 LIFT BAR W.A
302491 REEL W.A. 6 BLADE 25"
302504 SPACER-FRONT ROLLER
302507 ROLLER W.A. 25"
302511 SIDE PLATE W.A.
302513 ROLLER ASSY
302526 HANGER W.A.
302533 SWITCH ASSY
302539 SKIDBAR, CUTTING UNIT
302549 REEL CARRIER ASSY.- RT.
302550 REEL CARRIER ASSY. - LT.
302551 TANK STRAP, POWDERCOATED
302601 PULL ROD SPRING SLEEVE
302605 ROLLER ADJ ASSY
302606 ROLLER ADJ ASSY
302607 GAS TANK ASSY, 70"
302639 REAR PULL ROD PLATED
302653 END CAP
302656 ROLLER ADJUSTER W.A.
Page 28 of 34
Page 29
National Mower Company 2006 Master Parts List
PART
NUMBER
302657 REAR ROLLER ADJUSTER W.A
302658 SPRING SPACER PLATED
302659 SPRING SPACER PLATED
302669 OIL TANK ASSY 70"
302678 FUEL LINE
302714 SEAL KIT (SERVICE ONLY)
302715 BEARING HOUSING (SERVICE ONLY)
302717 NUT HEX (SERVICE ONLY)
302718 KEY (SERVICE ONLY)
302726 O_RING KIT (SERVICE ONLY)
302738 REEL 8 BLADE 25"
302743 TUBE STEERING
302759 INPUT SHAFT MODEL 11 PUMP
DESCRIPTION
302762 SEAL MODEL 11 PUMP
302763 INPUT BEARING MODEL 11 PUMP
302778 SHAFT-ROLLER 30"
302789 70 REEL 6 BLADE 30"
302791 BRAKE PAD KIT
302845 ROLLER ADJ. ASSY R.H. INSIDE
302846 ROLLER ADJ. ASSY. (6-70)
302847 ROLLER ADJ. ASSY. (6-70)
302849 CROSS BAR ASSY R.H. 30"
302864 ROLLER ADJUSTER ASSY L.H.
302865 ROLLER ADJUSTER ASSY R.H.
302904 SKID BAR W.A. R.H.
302905 SKID BAR W.A. L.H.
302932 END SPACER, VERTICUTS
302934 WASHER, BACKUP VERTICUTS
302936 SNAP RING 1 3/16 EXTERNAL
302965 COUPLER-CHAIN
302968 FAN BLADE REPLACES #07270
305034 MP FILTER ELEMENT
305037 RETURN FILTER
305736 DECK MOTOR - L DECK CW
305737 DECK MOTOR - R, REAR DECKS, CCW
306064 WELDMENT-FRONT ROLLER AXEL
Page 29 of 34
Page 30
National Mower Company 2006 Master Parts List
PART
NUMBER
306067 WELDMENT-REAR ROLLER ADJUSTER
306068 1/4" DECK HEIGHT WASHER PLAIN
306069 WELDMENT-HSNG REAR ROLLER ADJ
306074 WELDMENT-BLADE HOLDER
306129 BUSHING - LONG, RR PULL FRAME
306169 WELDMENT-RIGHT DECK PLATFORM
306171 WELDMENT-DECK PLATFORM RR
306177 BUSHING - PULL ARM INNER
306192 COVER-FUEL TANK
306216 WELDMENT SCREENBOX
306227 HOOD
306234 WELDMENT-LOWER PULL ARM R SIDE
306241 PIVOT PIN - REAR DECK
DESCRIPTION
306245 MULCHING BLADE
306298 COVER-STEERING TOWER
306311 MULCHING BLADE
306318 DECK SPACER, 1"X1.25 PLATED
306319 DECK SPACER .5" X 1.25 PLATED
306341 PANEL-INSTRUMENT, LH
306350 WELDMENT-REAR COVER
306351 ASSY-INSTRUMENT PANEL, RH
306355 WELDMENT CASTER FRAME
306364 DECK SPACER .25" X 1.25 PLATED
306367 26" BLADE LEFT HAND
306368 26" BLADE RIGHT HAND & REAR
306402 WASHER SPACER 1.0X1.88
306403 WASHER SPACER .5 X 1.88
306404 WASHER SPACER .25 X 1.88
306421 HOT AIR DEFLECTOR
306435 WELDMENT-SIDE PANEL, LH
306438 WELDMENT-SIDE PANEL, RH
306442 ASSEMBLY REAR ROLLER
306443 ASSEMBLY, FIXED ROLLER
306444 ASSEMBLY, CASTER ROLLER
306473 SWITCH ASSY, PEDAL NEUTRAL
306488 ASSY - SCREEN s/n above 1058
Page 30 of 34
Page 31
National Mower Company 2006 Master Parts List
PART
NUMBER
400013 PINION RING
400014 RETAINER, PINION
400035 REEL CARRIER, LEFT
400097 SHAFT, ROLLER
400322 FRONT ROLLER
400442 ROLLER ASSEMBLY, FRONT
400460 PIN, BASKET
400625 DOUBLE BAIL KIT
400795 BLADE RETAINER WLDMT
400801 BLADE-21" RECYCLING
400808 SPACER-BLADE RETAINER
400809 PIN-AXLE
400818 WHEEL ASSEEMBLY
DESCRIPTION
400826 KEY-SQUARE,1/4 X 1.50
400905 PIVOT PIN
480004 12 OZ. SPRAY PAINT
480067 ROLLER SCRAPER KIT
480073 PLASTIC GAS TANK KIT
480074 ELECTRIC CLUTCH KIT
480075 HOC ADJUSTER KIT
480076 HOC ADJUSTER KIT WITH ROLLERS
480078 8400 Roller scraper kit DAH
480080 8400 VERTI-CUT CHANGE OVER KIT
501001 BELT,FRONT, B-39
501002 PULLEY, 1" BORE 1/4 KEYWAY
501004 BEARING, PILLOW BLOCK
501074 TORSION SPRING
501088 SHAFT
501090 GEAR BOX 1:1.5
501094 GUARD
501096 GEAR BOX 1:1
501107 GUARD
501108 BELT, B. 46
501110 GUARD
501120 BUSHING
501125 BEVEL GEAR
Page 31 of 34
Page 32
National Mower Company 2006 Master Parts List
PART
NUMBER
501135 SHAFT
501141 SEAL (471744)
501145 NUT
501146 SHAFT
501152 GEAR BOX
501163 HOSE
501164 HOSE
501191 BLADE
501192 BEARING
501200 BELT, BX41
501213 BLOCK, BEARING
501214 BEARING
531007 BELT, 5L-310
DESCRIPTION
531040 BUSHING, PULL YOKE
591215 PINION SHAFT, PRAIRIE GEARBOX
591216 SHAFT, THRU 10-1/2"
860032 68 roller scraper kit
860034 68DL DAH kit
990315 SEAL KIT FOR 07272
BATT-70 BATTERY, 70 & 68DL
BATT-84 BATTERY, 84"
H02708 Circlip Ext 3/4"
H03096 Circlip Ext 1/2"
H03997 Pin Roll 3/16 x 3/4
H09116 Screw Unf 3/8 x 1-1/4
H09273 Washer Spring 3/8 SC
H09280 Washer Plain 1/2 x 1 x 18G
H09286 Washer Plain 5/8 x 1-1/4 x 16G
H09349 Screw Taptite Unc 3/8 x 1-1/4
H09365 Screw Taptite M6 x 16
H09545 Screw Taptite M6 x 16 C/SK POZ
H09546 Screw Taptite M6 x 12 w/HD POZ
H1246 Spring Clutch Shoe Return
H1428 Circlip Ext 5/8 1400 Series
H1662 Key Woodruff #50
H201086 STARLOCK EASHER
Page 32 of 34
Page 33
National Mower Company 2006 Master Parts List
PART
NUMBER
H219023 Lever Jockey Assy
H219028 Plate Securing
H219036 Moulding Front Axel Bearing
H219051 Sprocket 17T Assy
H219053 Sleeve Sprocket Tube
H219054 Chain 30 Pitch 1/2 x 1/8
H219055 Cover Transmission
H219060 Bearing PTO Moulded Housing
H219064 Bracket Belt Guide
H219095 Idler Sprocket Sleeve Assy
H219102 ROLLER BEARING HOUSING
H219106 Sprocket 10T
H219111 Pulley WA
DESCRIPTION
H219143 HUB CAP
H219156 Pulley Jockey (Moulded)
H226013 HANDWHEEL TRIANGULAR
H226024 BOLT HANDLEBAR M8 X 45
H330053 KNOB LEVER
H340011 THROWPLATE
H340015 CUTTERBAR BLADE
H340020 FRONT AXLE WA
H340044 FRAME REAR ROLLER WA
H340049 BELT V (A890) REF EXTN DESC
H340070 GRASSBAG ASSY
H340071 GRASSBAG FABRIC
H340072 GRASSBAG COVER
H340075 GRASSBAG FRAME WA
H340082 SEAL BRUSH SA0086X
H340102 PLATE RATCHET 9T
H340103 HANDLEBAR LOWER N/S
H340105 PULLEY DRIVE
H340109 COUPLING PTO
H340129 ROLLER BUSHING OILITE
H340139 ROLLER WA
H340149 SPACER NYLON 55 X 41.5 X 1 BLK
H340150 ROLLER FREEWHEEL-ROCKET BRAND
Page 33 of 34
Page 34
National Mower Company 2006 Master Parts List
PART
NUMBER
H340162 ROLLER SHAFT WA
H340163 LOCKNUT
H340165 ROLLER SHAFT C/W FREEWHEELS
H340168 SHROUD-FREEWHEEL
H340190 FRONT FIN INSERT 340L
H340206 COVER TRANSMISSION MOULDED
H341028 THROTTLE CONTROL TYPE T60
H341029 HANDLEBAR UPPER MOULDED
H341031 Cable Engine Brake
H341034 CLUTCH CABLE
H4014 DISTANCE PIECE CUTTERBAR
H4452 BUSH 1/2 X 58 X 3/4
H480070W FRICTION DISC WA
DESCRIPTION
H5218 FRONT WHEEL 7 X 1.75 X 7
H5321 KEY WOODRUFF 3/32 X 5/8 NO.30
H5421 SPRING REAR AXLE TENSION
Page 34 of 34
Loading...
