Mustek PL510 USER GUIDE

Portable DVD Player

User Guide

Playable Disk Format: DVD/VCD/CD/MP3/CD-R/CD-RW/SD card/MMC card

82-179-00060

Table of Contents

FCC and Safety Information...................................................................................... 4

Important Safety Instructions................................................................................... 5

Precautions......................................................................................................... 6

Selecting the type of disc for the type of TV connected.................................................... 7

Chapter 1. DVDChapter 1. DVD

Chapter 1. DVD

Chapter 1. DVDChapter 1. DVD

1-1 DVD Playback...................................................................................................8

Basic Playback.......................................................................................................................... 8

Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The Disc)................................8

Stopping Playback...................................................................................................................... 9

Rapid Advance and Rapid Reverse....................................................................................................9

Skipping Ahead or Back to Chapters................................................................................................ 9

Still Picture (PAUSE).................................................................................................................... 9

Repeat Viewing........................................................................................................................10

1-2 Convenient functions...................................................................................... 11

Displaying Scene Information....................................................................................................... 11

Changing Audio Soundtrack Language............................................................................................ 11

Clearing/Displaying Subtitles (A)................................................................................................... 11

Changing Subtitle Language (B).................................................................................................... 12

Viewing From Another Angle................................................................................. ........................12

Mute the DVD Player..................................................................................................................12

Using DVD Menu....................................................................................................................... 13

Using the Menu Function............................................................................................................ 13

Chapter 2. Audio CDChapter 2. Audio CD

Chapter 2. Audio CD

Chapter 2. Audio CDChapter 2. Audio CD

2-1 Audio CD Playback..........................................................................................14

Basic Playback......................................................................................................................... 14

Stopping Playback.....................................................................................................................14

Rapid Advance and Rapid Reverse.................................................................................................. 14

Skipping Ahead or Back to Tracks.................................................................................................. 15

Pause.....................................................................................................................................15

Displaying Track Information....................................................................................................... 15

Chapter 3. Special FChapter 3. Special F

Chapter 3. Special F

Chapter 3. Special FChapter 3. Special F

unctionsunctions

unctions

unctionsunctions

3-1 Playing Kodak Picture CDs................................................................................ 16

Basic Playback......................................................................................................................... 16

Slide Show...............................................................................................................................16

Thumbnail Mode....................................................................................................................... 17

3-2 Playing JPEG picture CDs................................................................................. 18

Basic Playback......................................................................................................................... 18

File Manager........................................................................................................................... 18

Playing Mode.......................................................................................................................... 19

Thumbnail Mode....................................................................................................................... 19

3-3 Playing MP3 Music Discs.................................................................................. 20

Basic Playback......................................................................................................................... 20

3-4 Playing a CD containing JPEG pictures and MP3 music..............................................21

Basic Playback......................................................................................................................... 21

Playing Mode.......................................................................................................................... 21

Thumbnail Mode....................................................................................................................... 22

3-5 Playing JPEG & MP3 files from MMC/SD card.......................................................... 23

Basic Playback......................................................................................................................... 23

Playing Mode.......................................................................................................................... 23

2

Table of Contents-continued

Chapter 4. SetupChapter 4. Setup

Chapter 4. Setup

Chapter 4. SetupChapter 4. Setup

4-1 Language Setup.............................................................................................24

On Screen Display (OSD) Language Setting...................................................................................... 24

DVD MENU Language Setting.......................................................................................................25

AUDIO Soundtrack Language Selection [DVD]................................................................................... 26

SUBTITLE Language Selection [DVD]...............................................................................................27

4-2 Screen Setup................................................................................................ 28

TV Type Setting........................................................................................................................28

Screen Saver Setting................................................................................................................. 29

TV System Setting.....................................................................................................................30

Video Out Setting.....................................................................................................................31

4-3 AUDIO Setup................................................................................................. 33

Digital Out Setting................................................................................................................... 33

Analog Out Setting....................................................................................................................34

4-4 Custom Setup............................................................................................... 35

MMC/SD Setting.......................................................................................................................35

Parental Control Setting [DVD]..................................................................................................... 36

Password Setting [DVD]............................................................................................................. 37

Angle Mark Setting [DVD]........................................................................................................... 38

Default Setting........................................................................................................................ 39

4-5 LCD Setup................................................................................................... 40

Panel Setting.......................................................................................................................... 40

Color Setting...........................................................................................................................40

Bright Setting..........................................................................................................................41

Contrast Setting......................................................................................................................42

Sharpness Setting.....................................................................................................................43

Chapter 5. FChapter 5. F

Chapter 5. F

Chapter 5. FChapter 5. F

or Yor Y

or Y

or Yor Y

our Rour R

our R

our Rour R

eferenceeference

eference

eferenceeference

5-1 Troubleshooting........................................................................................... 44

5-2 Disc Handling and Maintenance........................................................................ 45

5-3 Defintion of Terms........................................................................................ 46

3

FCC and Safety Information

CAUTION:

This unit employs a laser. Due to possible eye injury, only qualified service personnel should remove the cover or attempt to service this device. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Since it is usual for DVD movies to be released at different times in different regions of the world, all players have region codes and disc can have an optional region code. If you load a disc of a different region code to your player, you will see the region code notice on the screen. The disc will not play, and should be unloaded.

(Possible region codes:)

There are 6 regions (also called “locals”). Each DVD player and disc will be played in one region ONLY. 1: Canada, U.S., U.S. Territories 2: Japan, Europe, South Africa, Middle East (including Egypt) 3: Southeast Asia, East Asia (including Hong Kong) 4: Australia, New Zealand, Pacific Islands, Central America, Mexico, South America, Caribbean 5: Former Soviet Union, Indian Subcontinent, Africa (also North Korea, Mongolia) 6: China

Never make or change connections with the power switched on.

CAUTION VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM

(WARNING LOCATION: INSIDE ON LASER COVERSHIELD)

For DVD Players with 525p, but not 625p, progressive scan output:

‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING YOUR TV SET COMPATIBILITY WITH THIS MODEL 525p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.’

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

4

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a damp cloth.

7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized-type plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Unplug this apparatus during lighting storms or when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way; such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Outdoor use or wet location applications:

An apparatus that does not comply with the requirements in Appendix A# (Outdoor Use and Wet Location Apparatus) shall be marked or the instruction manual packed with the word “WARNING” and the following or equivalent: “To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

A Class II APPARATUS shall be permanently marked with the words “DOUBLE INSULATION” or “Double insulated” and “When servicing use only identical replacement parts.”

WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

5

Precautions

Please read these precautions before operating this unit.



Power cord protection



To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please observe the following.

 Hold the plug firmly when connecting or disconnecting the AC power cord.  Keep the AC power cord away from heating appliances.  Never put any heavy object on the AC power cord.  Do not attempt to repair or reconstruct the AC power cord in any way.



Placement



Avoid placing the unit in areas of:

 direct sunlight or heating radiators, or closed automobiles  high temperature (over 35  much dust as the internal parts may be seriously damaged.



Non-use periods



When the unit is not being used, turn it off. When left unused for a long period of time, the unit should be unplugged from the household AC outlet.



No fingers or other objects inside



 Touching internal parts of this unit is dangerous, and may cause serious damage to the unit. Do not attempt to

disassemble the unit.

 Do not put any foreign object on the disc tray.

0

C) or high humidity (over 90%)



Keep away from water/magnet



 Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious damage could

occur.

 Never bring a magnet or magnetized object near the unit.



Stacking



 Place the unit in a horizontal position, and do not place anything heavy on it.



Condensation



Moisture may form on the lens in the following conditions:

 immediately after a heater has been turned on  in a steamy or very humid room  when the unit is suddenly moved from a cold environment to a warm one

If moisture forms inside this unit, it may not operate properly. In this case, turn on the power and wait about one hour for the moisture to evaporate.



If there is noise interference on the TV while a broadcast is being received



Depending on the reception condition of the TV, interference may appear on the TV monitor while you watch a TV broadcast and the unit is left on. This is not a malfunction of the unit or the TV. To watch a TV broadcast, turn off the unit.

6

Selecting the type of disc for the type of TV connected

DVDs are recorded in PAL or NTSC formats. Please refer to the table below to find the appropriate format for your region.

 

 Connecting to a multi-system TV

 

 Connecting to a NTSC TV

 



 Connecting to a PAL TV



7

DVDDVD

DVD

DVDDVD

1-1 DVD Playback

Preparation

Attache the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment, please perform the following:

 Press on the power button of the TV set, and select “Video” as the TV input.  Press on the power button of the stereo system if the player has been connected to one.  Push the AV OUT/IN silde switch to AV OUT.

Basic Playback

1 Press POWER on. 2 Press <OPEN> to open the disc cover. 3 Hold the edge of the disc to put it in the center with the printed side up.

Hold the disc without touching its surfaces, position it with the printed title side facing up, align it with the

guides, and place it in its proper position.

4 Close the disc cover.

 Close the disc cover and the portable DVD player starts playback if the disc does not have any

 If the disc has one or more titles recorded on it, a menu screen will appear on the screen.

menus recorded on it.

5 Press < / / / > or the number button(s) to select the preferred title.

<< NOTE: To select a title, input the number, i.e. 1 for chapter 1, 10 for chapter 10, and etc. >>

6 Press <PLAY/SEL.> .

The player now starts playing the selected item.

Stopping Playback and Returning to The Menu Screen (If a Menu Screen Is Available on The Disc)

Press <MENU>.

The portable DVD player stops playback and displays the menu screen.

After operation

When the portable DVD player is not in use, remove the disc and press POWER to turn off the player. Close the display panel.

<< NOTE >>

 The disc continues to rotate while the menu is displayed even after the player has finished playing a

particular disc. When no further selections are to be played, be sure to press the <STOP>

button to clear the menu screen.

 If the disc is placed in upside down (and it is a single sided disc), the player will display “NO DISC”.

For your reference:

 When “ ” appears while a button is being operated, it means that the corresponding operation is prohibited by

the player.

8

1-1 DVD Playback-continued

DVDDVD

DVD

DVDDVD

Stopping Playback

Press <STOP> once to prestop. Press <STOP> twice to stop.

Rapid Advance and Rapid Reverse

Press <F.BWD> or <F.FWD> during playback.

 Normal playback is resumed when you press <PLAY/SEL.>.

 The speed of advance ( x2, x4, x8, x16, x32) or reverse ( x2, x4, x8, x16, x32)

changes with each press of the <F.FWD> or <F.BWD> button.

Skipping Ahead or Back to Chapters

You can skip a specific chapter or track.

Skipping Ahead

Press

Skips a chapter each time you press the button.

Skipping Back

Press

When you press the button once midway through a chapter, the portable DVD player returns to the beginning of the chapter being played back. The player skips a chapter each time you press the button.

<NEXT> during playback.

<PREVIOUS> during playback.

Still Picture (PAUSE)

Press <PAUSE> during playback.

The screen is paused.

*To return to normal playback

---Press <PLAY/SEL.>.

9

DVDDVD

DVD

DVDDVD

1-1 DVD Playback-continued

Repeat Viewing

Press <1/ALL REPEAT> during playback.

Each time you press the button, the disc will repeat a chapter or title.

Press once: Chapter (Repeat chapter)

Press twice: Title (Repeat title)

Press three times: Disc (Repeat disc)

Press four times: off (Repeat cancelled)

*To return to normal playback

---Press <1/ALL REPEAT> several times until “ Off” appears on the screen.

<< NOTE >>

 Repeat playback works only with discs for which the elapsed playing time appears on the player’s

 Repeat playback may not work correctly with some DVDs.

display during playback.

10

1-2 Convenient functions

DVDDVD

DVD

DVDDVD

Displaying Scene Information

Press <INFO.> during playback.

Press <INFO.> a number of times, the title number, chapter number, and other information will show on the

screen.

*To stop displaying scene information

---Press <INFO.> a number of times until the information disappears.

Changing Audio Soundtrack Language

You can change the audio language from the one selected at the initial settings to a different language. (This operation functions only with discs on which multiple audio soundtrack languages are recorded.)

1 Press <AUDIO> during playback.

2 Press <AUDIO> a number of times until the preferred language is selected.

For your reference:

 When the preferred language is not selected even after pressing the button several times, it may indicate that

language is not available on the disc.

 When you turn on or remove the disc, the portable DVD player will playback the language which is selected at the

initial setting. If you select a language which is not recorded on the disc, the portable DVD player will playback a prior language programmed on the disc.

Clearing/Displaying Subtitles (A)

If a disc provides subtitles, you can choose to hide or display them. (This operation works only with discs that provide subtitles.)

Press <SUBTITLE> during playback to display subtitles or hide them.

When you press <SUBTITLE> once, the first subtitle recorded on the disc will display. The rest of the subtitles

recorded will display in sequence as you press the button.

 You may change to another language with this function, or you can clear the subtitle by pressing this button a

number of times until “SUBTITLE OFF” appears on the screen.

11

DVDDVD

DVD

DVDDVD

1-2 Convenient functions-continued

Changing Subtitle Language (B)

You can change the subtitle language with the initial settings. (This operation works only with discs on which multiple subtitle languages are included.)

1 Press <SUBTITLE> during playback.

When no subtitles are recorded, “ ” will display instead of the language number.

2 Press <SUBTITLE> a number of times until the preferred language is selected.

<< NOTE: In some cases, the subtitle language may not change immediately to the selected one. >>

For your reference:

 When the preferred subtitle language is not selected even after pressing the button several times, it may indicate

that the language is not available on the disc.

 When you turn on or remove the disc, the portable DVD player will playback the subtitle language which is selected

at the initial setting. If you select a subtitle language which is not recorded on the disc, the portable DVD player will playback a prior subtitle language programmed on the disc.

Viewing From Another Angle

Some DVD discs may contain scenes which have been shot simultaneously from a number of different angles. For these

discs, the same scenes can be viewed from each of these different angles using the <ANGLE> button. (The

recorded angles vary depending on the disc programmed.)

1 Press <ANGLE> during playback.

2 Press <ANGLE> a number of times until the preferred viewing angle is selected.

Press <ANGLE> button a number of times to change the viewing angle.

<< NOTE >>

 The viewing angles are shown on the player’s display and you can select one for viewing.

Mute the DVD Player

Press <MUTE> button during playback.

 When “MUTE” appears on the screen, the portable DVD player is mute. To resume sound, press the button until

“MUTE OFF” appears on the screen.

12

1-2 Convenient functions-continued

DVDDVD

DVD

DVDDVD

Using DVD Menu

Some DVD discs have unique menu. For example, DVDs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language. Although the DVD menu’s contents and operation vary from disc to disc, the following explains basic operation when this feature is used.

1 Press <TITLE> in stop mode.

The DVD menu available on the disc now appears.

2 Press < / / / > to select the preferred item.

3 Press <PLAY/SEL.>.

You now enter to the selected item.

*To enter other menu screen

---Repeat steps 2 and 3.

*To return to the previous menu screen

---Press <TITLE>.

Using the MENU Function

1 Press <PLAY/SEL.>.

2 Press <MENU>.

A DVD chapter menu with brief broadcast of each paragraph now appears. You may see the introduction of each chapter and then decide which chapter to start.

3 Press < / / / > or number button(s) to select the preferred item.

<< Note: The menu details vary.>>

13

Audio DVDAudio DVD

Audio DVD

Audio DVDAudio DVD

2-1 Audio CD Playback

Preparation

Attache the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment, please perform the following:

 Press on the power button of the TV set, and select “Video” as the TV input.  Press on the power button of the stereo system if the player has been connected to one.  Push the AV OUT/IN SWITCH button to AV OUT.

Basic Playback

1 Press POWER on. 2 Press <OPEN> to open the disc cover. 3 Hold the edge of the disc to put it in the center with the printed side up.

Hold the disc without touching its surfaces, position it with the printed title side facing up, align it with the

guides, and place it in its proper position.

4 Close the disc cover.

For audio CDs without playback control:

The portable DVD player starts to playback.

For audio CDs provided with playback control:

A menu appears after a few seconds.

Stopping Playback

Press <STOP> once to prestop. Press <STOP> twice to stop.

Rapid Advance and Rapid Reverse

Press <F.BWD> or <F.FWD> during playback.

 Normal playback is resumed when you press <PLAY/SEL.>.

 The speed of advance ( x2, x4, x8, x16, x32) or reverse ( x2, x4, x8, x16, x32)

changes for each press of the <F.FWD> or <F.BWD> button.

14

2-1 Audio CD Playback-continued

Skipping Ahead or Back to Tracks

Skipping Ahead

Audio DVDAudio DVD

Audio DVD

Audio DVDAudio DVD

Press

A track is skipped each time you press the button.

Skipping Back

Press

When you press the button once midway through a track, the portable DVD player returns to the beginning of the track being played back. The player skips a track each time the button is pressed.

<NEXT> during playback.

<PREVIOUS> during playback.

Pause

Press <PAUSE> once during playback.

The player will pause playback.

To return to normal playback

Press <PLAY/SEL.>.

Displaying Track Information

Press

Press <INFO.> a number of times, the elapsed time, track number and other information will show on the

screen.

<INFO.> during playback.

*To stop displaying track information

---Press <INFO.> a number of times until the information disappears.

15

Special FSpecial F

Special F

Special FSpecial F

unctionsunctions

unctions

unctionsunctions

3-1 Playing Kodak Picture CDs

Basic Playback

You can play Kodak picture CDs for viewing on the screen.

Load a kodak picture CD.

After few seconds, the portable DVD player starts to play back the pictures in slide show automatically.

OR You can press the number buttons corresponding to the order of the picture, then press

<PLAY/SEL.>.

Press <INFO.>, the current track number and total track numbers will show on the screen. And press the number

buttons corresponding to the order of the picture, then press <PLAY/SEL.>. The portable DVD player will begin

the slide show from the selected picture.

*To pause slide show

---Press <PAUSE>, the slide show will pause.

*To stop slide show

---Press <STOP>, then enter Thumbnail mode.

<<Note: Press <TITLE>, you can also enter Thumbnail mode.>>

*To resume slide show

---Press <PLAY/SEL.> again.

Slide Show

1 Press <NEXT> to view the next picture or <PREVIOUS> to view the previous

picture.

2 Press <RIGHT> button or <LEFT> button to rotate the picture.

Press <RIGHT> button to rotate right by 90 degrees.

Press <LEFT> button to rotate left by 90 degrees.

*To pause slide show

---Press <PAUSE>, the slide show will pause.

*To stop slide show

---Press <STOP>, then enter Thumbnail mode.

<<Note: Press <TITLE> to enter Thumbnail mode.>>

*To resume slide show

---Press <PLAY/SEL.> again.

16

Special FSpecial F

Special F

3-1 Playing Kodak Picture CDs-continued183-2 Playing JPEG picture CDs

Thumbnail Mode

Special FSpecial F

unctionsunctions

unctions

unctionsunctions

1 Press <TITLE> to enter Thumbnail mode.

While in Thumbnail mode, there are 20 pictures per page for viewing.

2 Press < / / / > to select the picture in thumbnail. If you want to view the

selected picture in its original size, press

When you view the picture in its original size, you can press <STOP> to view the pictures in thumbnail.

<PLAY/SEL.>.

3 Press <NEXT> or <PREVIOUS> to view the next or previous thumbnail page.

17

Special FSpecial F

Special F

Special FSpecial F

unctionsunctions

unctions

unctionsunctions

Basic Playback

You can play JPEG pictures CDs for viewing on the screen.

Load a JPEG picture CD.

After few seconds, the portable DVD player starts to play back the pictures in a slide show automatically.

OR You can press the number buttons corresponding to the order of the picture, then press

<PLAY/SEL.>.

Press <INFO.>, the current picture number, total picture numbers and other information will show on the screen.

Press the number button corresponding to the order of the picture, then press <PLAY/SEL.>. The portable DVD

player will begin the slide show.

*To pause slide show

---Press <PAUSE>, the slide show will pause.

*To stop slide show

---Press <STOP>, then enter the File Manager.

*To resume slide show

---Press <PLAY/SEL.> again.

File Manager

1 Under File Manager Menu, press < / / / > to choose the preferred picture,

then press

<PLAY/SEL.> to playback the picture.

2 Press <NEXT> to skip for the next six pictures or <PREVIOUS> to skip to the

previous six pictures.

3-2 Playing JPEG Picture CDs-continued

Special FSpecial F

Special F

Special FSpecial F

unctionsunctions

unctions

unctionsunctions

Playing Mode

1 Press <NEXT> to view the next picture or <PREVIOUS> to view the previous

picture.

2 Press <RIGHT> button or <LEFT> button to rotate the picture.

Press <RIGHT> button to rotate right by 90 degrees.

Press <LEFT> button to rotate left by 90 degrees.

*To pause playback

---Press <PAUSE>.

*To stop playback

---Press <STOP>, then enter to the File Manager.

<<Note: Press <TITLE> to enter Thumbnail mode.>>

*To resume playback

---Press <PLAY/SEL.> again.

Thumbnail Mode

1 Press <TITLE> to enter Thumbnail mode.

While in Thumbnail mode, there are 20 pictures per page for viewing.

2 Press < / / / > to select the picture in the thumbnail. If you want to view

the selected picture in its original size, press

When you view a picture in its original size, you can press <STOP> to view the pictures in thumbnail.

<PLAY/SEL.>.

3 Press <NEXT> or <PREVIOUS> to view the next or previous thumbnail page.

19

Special FSpecial F

Special F

Special FSpecial F

unctionsunctions

unctions

unctionsunctions

Basic Playback

1 Press POWER on. 2 Press <OPEN> to open the disc cover. 3 Insert the MP3 disc and close the cover. 4 Close the cover.

Playback will start automatically after approximately 5 seconds.  MP3 files will begin to playback automatically. To play a specific file, find the file using the up and

*To pause playback

---Press <PAUSE>.

*To resume playback

---Press <PLAY/SEL.>.

*To stop playback

---Press <STOP>.

down buttons and once selected, press the play button.

3-3 Playing MP3 Music Discs

20

3-4 Playing a CD containing JPEG pictures and MP3 music

Basic Playback

1 Load a disc containing JPEG pictures and MP3 music.

After few seconds, the unit will enter File Manager.

2 Under File Manager Menu, press < / / / > to choose the preferred file.

3 Press <PLAY/SEL.> to playback the picture or MP3 music.

*To pause playback

---Press <PAUSE>.

*To resume playback

---Press <PLAY/SEL.>.

*To stop playback

---Press <STOP>, it will enter File Manager.

Playing Mode

1 Press <NEXT> to view the next picture or playback the next track.

2 Press <PREVIOUS> to view the previous picture or playback the previous track.

For JPEG pictures only

Press <RIGHT> button or <LEFT> button to rotate the picture.

 Press <RIGHT> or <LEFT> button to rotate right or left by 90 degrees.

*To pause playback

---Press <PAUSE>.

*To resume playback

---Press <PLAY/SEL.>.

*To stop playback

---Press <STOP>, it will enter File Manager.

21

Special FSpecial F

Special F

Special FSpecial F

Thumbnail Mode

unctionsunctions

unctions

unctionsunctions

3-4 Playing a CD containing JPEG pictures and MP3 music

1 Press <TITLE> to enter Thumbnail mode.

While in Thumbnail mode, there are 20 pictures per page.

2 Press < / / / > to select the picture in the thumbnail. If you want to view

the selected picture in its original size, press

When you view the picture in its original size, you can press <STOP> to view the pictures in the thumbnail.

<PLAY/SEL.>.

3 Press <NEXT> or <PREVIOUS> to view the next or previous thumbnail page.

22

3-5 Playing JPEG & MP3 files from MMC/SD card

Special FSpecial F

Special F

Special FSpecial F

unctionsunctions

unctions

unctionsunctions

Basic Playback

1 Load a MMC/SD card containing JPEG pictures and MP3 music.

After few seconds, the unit will enter File Manager.

2 Under File Manager Menu, press < / / / > to choose the preferred file.

3 Press <PLAY/SEL.> to playback the picture or MP3 music.

*To pause playback

---Press <PAUSE>.

*To resume playback

---Press <PLAY/SEL.>.

*To stop playback

---Press <STOP>.

Playing Mode

1 Press <NEXT> to view the next picture or playback the next track.

2 Press <PREVIOUS> to view the previous picture or playback the previous track.

For JPEG pictures only

Press <RIGHT> button or <LEFT> button to rotate the picture.

 Press <RIGHT> or <LEFT> button to rotate right or left by 90 degrees.

*To pause playback

---Press <PAUSE>.

*To resume playback

---Press <PLAY/SEL.>.

*To stop playback

---Press <STOP>, it will enter File Manager.

23

SetupSetup

Setup

SetupSetup

On Screen Display (OSD) Language Setting

Allows you to set various languages for the on screen display (OSD).

4-1 Language Setup

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Language Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “OSD”, and then press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred language.

5 Press <PLAY/SEL.>.

Language Setup

OSD

Menu

Audio

Subtitle

English

French

German

Italian

Spanish

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

<LEFT> button.

24

4-1 Language Setup-continued

DVD Menu Language Setting

You can select a language that has been recorded on the disc menu.

SetupSetup

Setup

SetupSetup

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Language Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Menu”, and then press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred language.

5 Press <PLAY/SEL.>.

Language Setup

OSD

Menu

Audio

Subtitle

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press

<LEFT> button.

<SETUP> to exit or select EXIT from SETUP MENU screen.

English

Chinese

Japanese

French

German

25

SetupSetup

Setup

SetupSetup

4-1 Language Setup-continued

AUDIO Soundtrack Language Selection [DVD]

You can select a preferred soundtrack language that has been recoreded on the DVD discs.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Language Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Audio”, and then press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred language.

5 Press <PLAY/SEL.>.

ORIGINAL: The top-priority language of each disc will always playback first.

Language Setup

OSD

Menu

Audio

Subtitle

English

Chinese

Japanese

French

German

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press

For your reference:

 If the language selected is not recorded on the disc, the portable DVD player will playback the top-

<LEFT> button.

<SETUP> to exit or select EXIT from SETUP MENU screen.

priority language of the disc.

26

SetupSetup

Setup

4-1 Language Setup-continued

SetupSetup

SUBTITLE Language Selection [DVD]

You can select a preferred language that has been recorded on the DVD.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Language Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Subtitle”, and then press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred language.

5 Press <PLAY/SEL.>.

Language Setup

OSD

Menu

Audio

Subtitle

English

Chinese

Japanese

French

German

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press

For your reference:

 If the language selected is not recorded on the disc, the portable DVD player will playback the top-

<LEFT> button.

<SETUP> to exit or select EXIT from SETUP MENU screen.

priority language of the disc.

27

SetupSetup

Setup

SetupSetup

4-2 Screen Setup

TV Type Setting

The kind of TV set (4:3 or 16:9) connected to the player and a wide-screen picture type for a 4:3 TV can be selected.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “TV Type”, and then press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select a preferred TV display.

5 Press <PLAY/SEL.>.

Screen Setup

TV Type

Screen Saver

TV System

Video Output

4:3 PS

4:3 LB

16:9

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press <LEFT> button.

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

4:3 Pan Scan

Select 4:3 PS for a conventional size TV set. Video material formatted in the pan & scan style has the left and right edges trimmed.

4:3 Letter Box

Select 4:3 LB for a conventional size TV set. Black bands appear at top and bottom of screen (letter-box style).

16:9 Wide Select 16:9 for a wide-screen TV set. Played in “FULL” size.

 Setting the wide-screen TV to “FULL” mode is also necessary.  Each screen shows an example when the video material for a wide-screen is played.

28

4-2 Screen Setup-continued

Screen Saver Setting

This function will ONLY function when the player is stopped.

SetupSetup

Setup

SetupSetup

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Screen Saver”, and then

press <PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select “On” or “Off ”.

5 Press <PLAY/SEL.>.

The waiting time of the screen saver is set to 10 minutes.

Screen Setup

TV Type

Screen Saver

TV System

Video Output

On

Off

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press <LEFT> button.

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

29

SetupSetup

Setup

SetupSetup

TV System Setting

The player provides “PAL”, “NTSC” and “AUTO” settings for your selection. When connecting the portable DVD player to your TV, set the “TV SYSTEM” from the on-screen display to the format that is compatible with your TV’s system. Set to "AUTO" if your system is a multi-TV system that supports both PAL and NTSC.

4-2 Screen Setup-continued

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “TV System”, and then

press <PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the appropriate TV system

for your clearest view.

5 Press <PLAY/SEL.>.

Screen Setup

TV Type

Screen Saver

TV System

Video Output

NTSC

PAL

Auto

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

<LEFT> button.

30

4-2 Screen Setup-continued

Video Output Setting

Please choose the preferred video output supported by your equipment.

SetupSetup

Setup

SetupSetup

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Video Output”, and then

press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred video output

setting.

5 Press <PLAY/SEL.>.

Screen Setup

TV Type

Screen Saver

TV System

Video Output

S-Video

P-SCAN

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

<LEFT> button.

31

SetupSetup

Setup

SetupSetup

Video Output Setting-continued

If you choose “P-Scan”, the following will show on the screen as a reminder.

Screen Setup

4-2 Screen Setup-continued

TV Type

Screen Saver

Your TV support P-Scan

TV System

Video Output

S-Video

P-SCAN

YES Press Play NO Press Stop

4

: Move : Select SETUP: Quit

If you TV doesn’t support P-Scan feature, press

<<Troubleshooting>>

What if the screen turns black while operating...

Solution: Press

<Mode> to switch to “S-Video” mode.

<STOP>.

32

4-3 Audio Setup

SetupSetup

Setup

SetupSetup

Digital Out Setting

The portable DVD player provides three options, “SPDIF/PCM”, “SPDIF/RAW” and “Off” for the digital out setting.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Audio Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Digital Out”, and then

press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred digital out

setting.

5 Press <PLAY/SEL.>.

Audio Setup

Digital Out

Analog Out

SPDIF/PCM

SPDIF/RAW

Off

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

<LEFT> button.

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

For your reference:

 If you have a Dolby Digital 5.1 or DTS capable amplifier, you must set the audio output to SPDIF/RAW.

If you have a 2-channel Dolby Digital amplifier, you must set the audio output to SPDIF/PCM.

33

SetupSetup

Setup

SetupSetup

Analog Out Setting

4-3 Audio Setup-continued

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Audio Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Analog Out”, and then press

<PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select the preferred analog out

setting.

5 Press <PLAY/SEL.>.

Audio Setup

Digital Out

Analog Out

2 Channel

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

<LEFT> button.

34

4-4 Custom Setup

SetupSetup

Setup

SetupSetup

MMC/SD Setting

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “MMC/SD”, and then

press <PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select “On” or “Off ”, and then

press

<< Important >>

 You can only change the MMC/SD setting to “On” or “Off” while there is no disc inside the DVD

 While the disc is played back, you can only press the <Mode> button to switch to MMC/SD mode.

<PLAY/SEL.>.

player. If you set the MMC/SD setting to “On”, the portable DVD player can only read SD/MMC card. The portable DVD player can’t playback any discs.

Custom Setup

MMC/SD

Parental Ctrl

Password ...

Angle Mark

On

Off

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

<LEFT> button.

*To finish the setup operation

---Press

<SETUP> to exit or select EXIT from SETUP MENU screen.

35

SetupSetup

Setup

SetupSetup

4-4 Custom Setup-continued

Parental Control Setting [DVD]

A built-in viewer rating setting enables you to lock the videos that you do not want children to view. For example, setting the ratting limit to PG-13 will prevent the unit from playing video rated R, NC-17 or X unless the correct password is entered.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Parental Ctrl”, and then

press <PLAY/SEL.>.

4 Enter a 4-digit password before selecting ratings and press <PLAY/SEL.>.

Factory pre-set password: 0000 You need to enter “0000” to set the rating for the first time when purchasing your DVD from the store.

5 Press <UP> button / <DOWN> button to select the preferred ratings.

6 Press <PLAY/SEL.>.

<< Rating Explanations >>

3.PG: Parental Guidance suggested.

4.PG13: Material is unsuitable for children under the age of 13.

6.R: Restricted, children under 17 would not be admitted without an accompanying parent or adult guardian.

7.NC17: No children under the age of 17, not recommended viewing for children under age 17.

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press

<LEFT> button.

<SETUP> to exit or select EXIT from SETUP MENU screen.

Custom Setup

MMC/SD

Parental Ctrl

Password ...

Angle Mark

4: PG13

5

6: R

7: NC 17

8

: Move : Select SETUP: Quit

For your reference:

 You can use the parental control lock ONLY with DVD discs featured with the parental lock function.  Please keep in mind that discs not encoded with rating lock protection will play regardless of rating

36

and content.

4-4 Custom Setup-continued

Password Setting [DVD]

You can change the password on the portable DVD player.

SetupSetup

Setup

SetupSetup

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Password”, and then

press <PLAY/SEL.>.

4 Enter your old password and then press <PLAY/SEL.>.

Factory pre-set password: 0000

5 Enter your new password and then press <PLAY/SEL.>.

6 Re-enter your password to verify it and then press <PLAY/SEL.>.

Custom Setup

MMC/SD

Parental Ctrl

Password ...

Old: _ _ _ _

Angle Mark t

New: _ _ _ _

Verify: _ _ _ _

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press <LEFT> button.

*To finish the setup operation

---Press <SETUP> to exit or select EXIT from SETUP MENU screen.

37

SetupSetup

Setup

SetupSetup

4-4 Custom Setup-continued

Angle Mark Setting [DVD]

You can choose to display or hide the angle mark “ ” on the screen.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then

press

<PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Angle Mark”, and then

press <PLAY/SEL.>.

4 Press <UP> button / <DOWN> button to select “On” or “Off ”, and then

press <PLAY/SEL.>.

<< NOTE >>

 Pressing the

feature regardless of whether the ANGLE MARK feature is "On" or "Off".

<ANGLE> button will change camera angles for movies that support this

Custom Setup

MMC/SD

Parental Ctrl

Password ...

Angle Mark

On

Off

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press

38

<LEFT> button.

<SETUP> to exit or select EXIT from SETUP MENU screen.

4-4 Custom Setup-continued

SetupSetup

Setup

SetupSetup

Default Setting

You may re-set the previous settings in CUSTOM SETUP to the default setting.

1 Press <SETUP> in the stop mode.

2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then

press <PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “Default”, and then press

<PLAY/SEL.>.

4 Press <RIGHT> button to select “Read”, and then press <PLAY/SEL.>.

<< EXCEPTION>>

 The viewer rating and the password setting will NOT be changed even though you re-set

to the default setting.

Custom Setup

Parental Ctrl

Password ...

Angle Mark

Default

: Move : Select SETUP: Quit

*To return to the SETUP MENU screen

---Press

*To finish the setup operation

---Press

<LEFT> button.

<SETUP> to exit or select EXIT from SETUP MENU screen.

Read

39

SetupSetup

Setup

SetupSetup

Panel Setting

The portable DVD player provides two options for panel adjustment: “Normal” or “4:3”.

4-5 LCD Setup

1 Press <LCD>, the LCD setting information shows on the screen.

2 Press <LCD> a number of times to select “PANEL”.

3 Press <LEFT> button or <RIGHT> button to choose the preferred panel

setting. The panel will change to the selected setting.

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

*To finish setup operation

Nor Nor

Nor

Nor Nor

4:3 4:3

4:3

4:3 4:3

malmal

mal

malmal

---Press

Color Setting

You can adjust the color of video with this setting to a soothing view for your eyes.

<LCD> again until the LCD setting information disappears.

1 Press <LCD>, the LCD setting information shows on the screen.

2 Press <LCD> a number of times to select “COLOR”.

3 Press <LEFT> button or <RIGHT> button to choose the preferred color

setting, and then the panel will change to the selected setting.

<< NOTE>> The color range is from +9 to -9.

COLOR: +9COLOR: +9

COLOR: +9

COLOR: +9COLOR: +9

COLOR: +8COLOR: +8

COLOR: +8

COLOR: +8COLOR: +8

COLOR: +7COLOR: +7

COLOR: +7

COLOR: +7COLOR: +7

COLOR: +6COLOR: +6

COLOR: +6

COLOR: +6COLOR: +6

COLOR: +5COLOR: +5

COLOR: +5

COLOR: +5COLOR: +5

COLOR: +4COLOR: +4

COLOR: +4

COLOR: +4COLOR: +4

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

COLOR: +3COLOR: +3

COLOR: +3

COLOR: +3COLOR: +3

COLOR: +2COLOR: +2

COLOR: +2

COLOR: +2COLOR: +2

COLOR: +1COLOR: +1

COLOR: +1

COLOR: +1COLOR: +1

COLOR: 0COLOR: 0

COLOR: 0

COLOR: 0COLOR: 0

*To finish the setup operation

---Press

40

<LCD> again until the LCD setting information disappears.

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

-3-3

-3

-3-3

-2-2

-2

-2-2

-1-1

-1

-1-1

4-5 LCD Setup-continued

Brightness Setting

SetupSetup

Setup

SetupSetup

1 Press <LCD>, the LCD setting information shows on the screen.

2 Press <LCD> a number of times to select “BRIGHT”.

3 Press <LEFT> button or <RIGHT> button to choose the preferred bright

setting, and then the panel will change to the selected setting.

<< NOTE>> The bright range is from +9 to -9.

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

*To finish the setup operation

---Press

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

::

+1 +1

:

+1

::

+1 +1

::

0 0

:

0

::

0 0

<LCD> again until the LCD setting information disappears.

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

::

:

::

:

::

:

::

:

::

:

::

:

::

:

::

:

::

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

-2-2

-2

-2-2

-1-1

-1

-1-1

41

SetupSetup

Setup

SetupSetup

Contrast Setting

You can adjust the contrast of video with this setting to a soothing view for your eyes.

4-5 LCD Setup-continued

1 Press <LCD>, the LCD setting information shows on the screen.

2 Press <LCD> a number of times to select “CONTRAST”.

3 Press <LEFT> button or <RIGHT> button to choose the preferred contrast

setting, and then the panel will change to the selected setting.

<< NOTE>> The contrast range is from +9 to -9.

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

*To finish the setup operation

---Press

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

::

+1 +1

:

+1

::

+1 +1

::

0 0

:

0

::

0 0

<LCD> again until the LCD setting information disappears.

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

::

-9 -9

:

-9

::

-9 -9

::

-8 -8

:

-8

::

-8 -8

::

-7 -7

:

-7

::

-7 -7

::

-6 -6

:

-6

::

-6 -6

::

-5 -5

:

-5

::

-5 -5

::

-4 -4

:

-4

::

-4 -4

::

-3 -3

:

-3

::

-3 -3

::

-2 -2

:

-2

::

-2 -2

::

-1 -1

:

-1

::

-1 -1

42

4-5 LCD Setup-continued

Sharpness Setting

You can adjust the sharpness of video with this setting to a soothing view for your eyes.

SetupSetup

Setup

SetupSetup

1 Press <LCD>, the LCD setting information shows on the screen.

2 Press <LCD> a number of times to select “SHARPNESS”.

3 Press <LEFT> button or <RIGHT> button to choose the preferred sharpness

setting, and then the panel will change to the selected setting.

<< NOTE>> The sharpness range is from 0 to 4.

SHARPNESS: 4SHARPNESS: 4

SHARPNESS: 4

SHARPNESS: 4SHARPNESS: 4

SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 3

SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 2SHARPNESS: 2

SHARPNESS: 2

SHARPNESS: 2SHARPNESS: 2

SHARPNESS: 1SHARPNESS: 1

SHARPNESS: 1

SHARPNESS: 1SHARPNESS: 1

SHARPNESS: 0SHARPNESS: 0

SHARPNESS: 0

SHARPNESS: 0SHARPNESS: 0

*To finish the setup operation

---Press <LCD> again until the LCD setting information disappears.

43

FF

or Yor Y

F

or Y

FF

or Yor Y

our Rour R

our R

our Rour R

eferenceeference

eference

eferenceeference

5-1 Troubleshooting

Before requesting service for your portable DVD player, check the chart below for a possible cause of the problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper operation.

SYMPTOM (COMMON) REMEDY

No power. · Insert the power plug securely into the power outlet.

The player does not start playback · Condensation may have formed. Try again in 1 to 2 hours to ensure that the condensation when PLAY is pressed. has evaporated.

The player starts playback but stops · The disc may be dirty and may require cleaning. immediately. · Ensure that the disc is installed with the label side up. No picture. · Ensure that the equipment is connected properly.

No sound. · Ensure that the equipment is connected properly.

Distorted sound. · Ensure that the input settings for the TV and stereo system are proper.

No audio at Digital Output. · Check the digital connections.

capabilities. Distorted picture. · Check the disc for fingerprints and clean it with a soft cloth, wiping it from center

Completely distorted picture or no color · The disc format is not compatible to the TV-set used (PAL/NTSC). in picture. Picture is distorted during rapid · The picture will be somewhat distorted at times: this is normal. advance or rapid reverse.

No rapid advance (or rapid reverse) · Some discs may have sections which prohibit rapid advance (or rapid reverse). playback.

No 4:3 (16:9) picture. · Choose the correct setup “TV DISPLAY” item which matches the TV set used. Picture is distorted during rapid · The picture will be somewhat distorted at times: this is normal. advance or rapid reverse. No operations perform with the · Check the batteries are installed with the correct polarity (+ and –). remote control. · The batteries are depleted: replace them with new ones.

No key operation (by the DVD player · Turn the unit off and then back on. Alternatively, turn off the unit, disconnect the AC power and/or the remote control) is cord and then re-connect it. (The player may not be operating properly due to

effective. lightning, static electricity or some other external factor.) PLAY does not start playback even · This may be a result of the parental lock function that has been set. when title is selected. Confirm the “PARENTAL” setup. Audio soundtrack and/or subtitle · If the audio soundtrack and/or subtitle language does not exist on the disc, the language is not the one selected language selected at the initial settings will not be seen/heard. at the initial settings. No subtitles. · Subtitles appear only with discs that contain them.

Alternative audio soundtrack · An alternative language can not be selected may result of no more than one language (or subtitle) languages cannot be selected. available. Angle cannot change. · This function depends on software availability. Even if a disc has a number of angles recorded, these angles may be recorded for specific scenes only.

· Check if the ON/OFF button on the right of the player is set to on.

· Check if no power at the AC outlet may be the fault by plugging in another appliance for a test.

· Ensure that the disc format is supported by your DVD player.

· Check if the disc is defective by trying another disc.

· Check the region (local) code.

· Ensure that the input setting for the TV is “Video”.

· Check if external equipment is on.

· Select the same channel and source on the TV as on the player.

· Check if the LCD is on.

· If using a HiFi amplifier, try another sound source.

· Check the Audio Output Setting menu to make sure that Analog Output is selected.

· Check the Volume Adjustment.

· No sound is heard during still picture (pause).

· Check the settings menu to make sure that the digital output is set to on.

· Check if the audio format of the selected audio language matches your receiver

to edge.

· Sometimes a small amount of picture distortion may appear. This is not a malfunction.

· Point the remote control unit at the remote control signal sensor and operate.

· Operate the remote control unit at a distance but no more than 6 meters from the remote control signal sensor.

· Remove obstacles between the remote control unit and remote control signal sensor.

· Subtitles are hidden from the TV screen. Press SUBTITLE to display the subtitles.

44

5-2 Disc Handling and Maintenance

FF

or Yor Y

F

or Y

FF

or Yor Y

our Rour R

our R

our Rour R

eferenceeference

eference

eferenceeference

Handling Precautions

 Hold the disc by the edges so the surface will not be soiled with fingerprints. (A)

Fingerprints, dirt and scratches can cause skipping and distortion.

 Do not write on the label side with a ball-point pen or other writing utensils that can leave indentations or scratch

the surface of the disc. .

 Do not use record cleaning sprays, benzene, thinner, static electricity prevention liquids or any other solvent.  Be careful not to drop or bend the disc.  Do not install more than 1 disc on the disc tray.  Do not try to close the disc cover when the disc is not installed properly.  Be sure to store the disc in its exclusive case when not in use.

If the surface is soiled (B)

Wipe gently with a soft, damp (water only) cloth. When wiping discs, always move the cloth from the center toward the outer edge. (If you wipe the discs using a circular motion, circular scratches are likely to occur and may cause noise or skipping.)

(A) (B)

If the disc is brought from a cold to a warm environment, moisture may form on the disc

Wipe this moisture off with a soft, dry, lint-free cloth before using the disc.

Improper disc storage

You can damage discs if you store them in the following places:

 Areas exposed to direct sunlight  Humid or dusty areas  Areas directly exposed to a heat outlet or heating appliance

Disc which cannot be played with this player

 CD-ROM (Application Program)  CVD  CD-G  DVD with a Locale No. other than that shown on the DVD unit’s Region Code Label on the rear panel

Maintenance

 Be sure to turn the unit off and disconnect the AC power cord before performing maintenance on the unit.  Wipe this unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has been

dipped in a weak soap-and-water solution and wrung out thoroughly, and then wipe again with a dry cloth.

 Never use alcohol, benzene, thinner, cleaning fluid or other chemicals. Do not use compressed air to remove dust.

45

FF

or Yor Y

F

or Y

FF

or Yor Y

our Rour R

our R

our Rour R

eferenceeference

eference

eferenceeference

5-3 Definition of Terms

Angle

Recorded onto some DVD discs are scenes which have been simultaneously shot from a number of different angles (the same scene is shot from the front, from the left side, from the right side, etc.). With such discs, the ANGLE button can be used to view the scene from different angles.

Chapter Number

These numbers are recorded on DVD discs. A title is subdivided into many sections, each of which is numbered, and specific parts of video presentations can be searched quickly using these numbers.

DVD

These refer to a high-density optical disc on which high-quality pictures and sound have been recorded by means of digital signals. Incorporating a new video compression technology (MPEG II) and high-density recording technology, DVD enables aesthetically pleasing full-motion video to be recorded over long periods of time (for instance, a whole movie can be recorded). DVD has a structure consisting of two 0.6 mm thin discs which are adhered to each other. Since the thinner the disc, the higher the density at which the information can be recorded, a DVD disc has a greater capacity than a single 1.2 mm thick disc. Since the two thin discs are adhered to each other, there is the potential to achieve double-sided play sometime in the future for even longer duration play.

Subtitles

These are the printed lines appearing at the bottom of the screen which translate or transcribe the dialogue. They are recorded on DVD discs.

Time Digit

This indicates the play time which has elapsed from the start of a disc or a title. It can be used to find a specific scene quickly. (It may not work with some discs.)

Title Number

These numbers are recorded on DVD discs. When a disc contains two or more movies, these movies are numbered as title 1, title 2, etc.

Track Number

These numbers are assigned to the tracks which are recorded on audio CDs. They enable specific tracks to be located quickly.

46

Reproductor DVD portátil – Manual del usuario

Ajustes iniciales

1. Pulse el botón

<SETUP>.

2. En pantalla aparece el menú CONFIGURACIÓN.

Configuración idioma

OSD

Menú

Audio

Subtítulo

: Mover : Seleccionar SETUP: Salir

3. Pulse las teclas <ARRIBA> <ABAJO> <IZDA.> <DCHA.> para seleccionar la opción deseada.

4. Pulse el botón

<PLAY/SEL.>.

Para los ajustes:

Repita el procedimiento descrito arriba y véanse las instrucciones del OSD para efectuar los ajustes siguientes.

Español

Configuración idioma

OSD

Menú

Audio

Subtítulo

: Mover : SeleccionarSETUP: Salir

Configuración audio

Salida digital

Salida analógica

: Mover : Seleccionar SETUP: Salir

Configuración pantalla

Tipo de TV

Protector de pantalla

Sistema TV

Salida de vídeo

: Mover : SeleccionarSETUP: Salir

Configuración personalizada

MMC/SD

Control menores

Contraseña

Marca perspectiva

Predeterminado

: Mover : SeleccionarSETUP: Salir

47

Esquema del menú Configuración

Idioma (Las opciones de idioma sólo se dan como referencia. Para la

Español

información adecuada, véase el reproductor DVD portátil.)

OSD Inglés

Francés Alemán Italiano Español Portugués

Menú Inglés

Chino Japonés Francés Alemán Italiano Español Portugués ... Otros

Audio Inglés

Chino Japonés Francés Alemán Italiano Español Portugués ... Otros

Subtítulos Inglés

Chino Japonés Francés Alemán Italiano Español Portugués ... Otros Desactivado

48

Esquema del menú Configuración - continuación

Pantalla Tipo de TV 4:3 PS

4:3 LB 16:9

Protector de pantalla Activado (Tiempo de espera para el protector de pantalla:

10 minutos)

Desactivado

Sistema TV NTSC

PAL AUTO

Salida de vídeo S-Vídeo

BARRIDO PROGRESIVO (véase figura 1-1)

Audio Salida digital SPDIF/PCM

SPDIF/RAW Desactivado

Salida analógica 2 canales

Personalizada MMC/SD Activado (véase figura 1-2)

Desactivado

Control menores (Antes de poder cambiar el nivel, debe escribir

una contraseña de 4 dígitos. Contraseña predeterminada: 0000)

1.

2.

3. PG (ver la NOTA siguiente)

4. PG13 (ver la NOTA siguiente)

5.

6. R (ver la NOTA siguiente)

7. NC-17 (ver la NOTA siguiente)

8.

Contraseña Indique la contraseña (Contraseña

predeterminada: 0000) Indique la NUEVA contraseña Indique la contraseña otra vez

Marca perspectiva Activado

Desactivado

Predeterminado Lectura

NOTA:

1. PG: se recomienda el acompañamiento por parte de los padres.

2. PG-13: el contenido no es apto para menores de 13 años.

3. R: acompañamiento de los padres – restringido; se recomienda que los padres no dejen que los niños menores de 17 años vean el contenido o que éstos al menos sean supervisados por los padres o una persona adulta.

4. NC-17: No apto para menores de 17 años.

Español

49

Esquema del menú Configuración - continuación

FIGURA 1-1

Configuración pantalla

Español

Si selecciona la opción “Barrido progresivo”, los datos anteriores se mostrarán en pantalla como recordatorio. Si su televisor admite el barrido progresivo,

pulse

Tipo de TV Protector de pantalla

Su TV admite barrido progresivo

SÍ Pulse PLAY NO Pulse STOP

4

S-Vídeo BARRIDO PROGRESIVO

: Mover : Seleccionar SETUP: Salir

<PLA<PLA

<PLA

<PLA<PLA

<<Resolución de problemas>> Si desaparece la imagen durante la operación...

Solución: Pulse el botón

Y/SEL.>Y/SEL.>

Y/SEL.>. De lo contrario, pulse

Y/SEL.>Y/SEL.>

<MODE> para cambiar al modo de “S-Video”.

<ST<ST

<ST

<ST<ST

OP>OP>

OP>.

OP>OP>

FIGURA 1-2

Configuración personalizada

MMC/SD Control menores Contraseña ... Marca perspectiva

: Mover : Selecc. SETUP: Salir

<< Importante >>

z Si activa la opción «MMC/SD», el reproductor de DVD portátil sólo podrá leer tarjetas SD/MMC, eso es, no

podrá reproducir ningún disco.

z Pulse el botón <Mode> del mando a distancia o del panel frontal para cambiar al modo de MMC/SD.

Activado Desactivado

50

Preparación

Conecte el reproductor DVD portátil a una toma eléctrica y conéctelo a los auriculares u otros equipos externos. Si lo conecta a equipos externos:

z Encienda su televisor y seleccione “Vídeo” como entrada de señal de TV. z Encienda su sistema de alta fidelidad si el reproductor de DVD está conectado a un

sistema alta fidelidad.

z Coloque el conmutador AV OUT/IN en la posición AV OUT.

Reproducción básica

Español

1.1.

1. Pulse el botón

1.1.

2.2.

2. Para abrir la bandeja, pulse el botón

2.2.

3.3.

3. Coja el disco por el borde y colóquelo con cuidado en la bandeja con la

3.3.

<POWER>.

<OPEN>.

cara impresa hacia arriba.

4.4.

4. Cierre la tapa de discos.

4.4.

z Cierre la bandeja de disco. El reproductor de DVD inicia la reproducción si el

disco no tiene ningún menú grabado en él.

z Si el disco tiene uno o más títulos grabados en él, aparecerá un menú en la

pantalla.

5.5.

5. Pulse

5.5.

<ARRIB<ARRIB

<ARRIB

<ARRIB<ARRIB

A> <ABA> <AB

A> <AB

A> <ABA> <AB

AJO> <IZDAJO> <IZD

AJO> <IZD

AJO> <IZDAJO> <IZD

A.> <DCHA.>A.> <DCHA.>

A.> <DCHA.> o las teclas

A.> <DCHA.>A.> <DCHA.>

numéricas para seleccionar su título favorito.

Nota: Para seleccionar un título, teclee el número, p.ej. 1 para el capítulo

1, 10 para el capítulo 10, etc.

6.6.

6. Pulse el botón

6.6.

El reproductor DVD portátil inicia ahora la reproducción del elemento seleccionado.

<PLA<PLA

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

Detener la reproducción

<ST<ST

Pulse

<ST<ST

OP>OP>

<ST

OP> dos veces para detenerla definitivamente.

<ST<ST

OP>OP>

<ST

OP> una vez para detener la reproducción temporalmente. Pulse

<ST<ST

OP>OP>

Avance y Rebobinado rápido

<F<F

Pulse el botón

z La reproducción normal se reanudará cuando pulse el botón <PLAY/SEL.>.

z La velocidad de avance o rebobinado rápido cambia cada vez que se pulsa el botón

<F.BWD> o <F.FWD>.

.BWD>.BWD>

<F

.BWD> o

<F<F

.BWD>.BWD>

<F<F

.FWD>.FWD>

<F

.FWD> durante la reproducción.

<F<F

.FWD>.FWD>

51

Saltar capítulos (hacia adelante o hacia atrás)

Saltar hacia adelante

Pulse el botón

Salta un capítulo cada vez que pulsa el botón.

Español

Saltar hacia atrás

<SIGUIENTE> durante la reproducción.

Pulse el botón

Salta un capítulo cada vez que pulsa el botón.

<ANTERIOR> durante la reproducción.

PAUSA

<P <P

AA

Pulse una vez el botón

La pantalla se detiene en modo de pausa.

Para reanudar la reproducción normal

Pulse el botón <PLAY/SEL.>.

USE>USE>

<P

A

USE> durante la reproducción.

<P <P

AA

USE>USE>

Repetir la reproducción

Pulse el botón

Cada vez que presiona el botón, el disco repite un capítulo o un título. Si lo pulsa 1 vez: CAPÍTULO (Repetición capítulo) Si lo pulsa 2 veces: TÍTULO (Repetición título) Si lo pulsa 3 veces: DISCO (Repetición disco) Si lo pulsa 4 veces: apagada (Repetición apagada)

Para reanudar la reproducción normal

Pulse el botón <1/ALL REPEAT> varias veces hasta que aparezca la indicación “ apagada”.

<1/ALL REPEA<1/ALL REPEA

<1/ALL REPEA

<1/ALL REPEA<1/ALL REPEA

T>T>

T> durante la reproducción.

T>T>

52

Visualización en pantalla de la información sobre la escena

Pulse el botón título, número de capítulo y otros datos en pantalla.

Para dejar de mostrar la información sobre la escena

Pulse <INFO.> repetidamente hasta que desaparezca la información.

<INFO.><INFO.>

<INFO.> varias veces hasta que aparezcan el número de

<INFO.><INFO.>

Seleccionar el idioma de la pista de audio

Puede cambiar el idioma de la pista de audio del disco si dicha opción está disponible en su disco. Para seleccionar el idioma:

Español

1.1.

1. Pulse el botón

1.1.

2.2.

2. Pulse varias veces el botón

2.2.

esté seleccionado.

Nota: Si después de haber pulsado varias veces el botón, el idioma no

aparece todavía, puede que no esté disponible en el disco.

<A<A

UDIO>UDIO>

<A

UDIO> durante la reproducción.

<A<A

UDIO>UDIO>

<A<A

UDIO> UDIO>

<A

UDIO> hasta que el idioma favorito

<A<A

UDIO> UDIO>

Seleccionar el idioma para subtítulos

Puede cambiar el idioma de los subtítulos si dicha opción está disponible en su disco. Para seleccionar el idioma:

1.1.

1. Pulse el botón

1.1.

2.2.

2. Pulse varias veces el botón

2.2.

<SUBTITLE> durante la reproducción.

<SUBTITLE> hasta que el idioma

favorito esté seleccionado.

Nota: Si no queda seleccionado el idioma deseado, es posible que éste no

esté disponible en el disco.

53

Seleccionar ángulos de perspectiva

Con ciertos discos, se pueden visualizar las mismas escenas desde puntos de vista diferentes.

1.1.

1. Pulse el botón

1.1.

<ANGLE> durante la reproducción.

2.2.

2. Pulse varias veces el botón

2.2.

Español

Función de silencio

Pulse el botón

Para restablecer el sonido

Pulse de nuevo el botón <MUTE> hasta que aparezca en pantalla el mensaje “Silencio: No”.

<ANGLE> hasta que la perspectiva

deseada esté seleccionada.

Nota: Esta función sólo está disponible en los discos que disponen de

varios ángulos grabados. Si la función no está disponible, aparece el icono de error “ ”.

<MUTE> durante la reproducción.

Nota: Cuando en pantalla aparezca el mensaje “Silencio”, el reproductor

DVD portátil no emite ningún sonido.

Ajustes del panel LCD

Este reproductor DVD portátil permite dos ajustes para el panel de visualización: “Normal” ó “4:3”.

1.1.

1. Pulse el botón

1.1.

ajustes LCD.

2.2.

2. Pulse el botón

2.2.

“PANEL”.

3.3.

3. Pulse los botones

3.3.

panel deseado.

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

Salir de las operaciones de configuración

Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.

Nor Nor

Nor

Nor Nor

4:3 4:3

4:3

4:3 4:3

<LCD>. Se mostrará la información sobre los

<LCD> varias veces para seleccionar la opción

malmal

mal

malmal

<IZD<IZD

<IZD

<IZD<IZD

A.>A.>

A.> o

A.>A.>

<DCHA.><DCHA.>

<DCHA.> para seleccionar el ajuste de

<DCHA.><DCHA.>

54

Ajustes de color del LCD

Puede ajustar el color de vídeo para obtener una representación más agradable para sus ojos.

1.1.

1. Pulse el botón

1.1.

ajustes LCD.

2.2.

2. Pulse el botón

2.2.

3.3.

3. Pulse los botones

3.3.

color deseado.

<< NOTA>> Puede ajustar un color entre +9 y -9.

COLOR: +9COLOR: +9

COLOR: +9

COLOR: +9COLOR: +9 COLOR: +8COLOR: +8

COLOR: +8

COLOR: +8COLOR: +8 COLOR: +7COLOR: +7

COLOR: +7

COLOR: +7COLOR: +7 COLOR: +6COLOR: +6

COLOR: +6

COLOR: +6COLOR: +6 COLOR: +5COLOR: +5

COLOR: +5

COLOR: +5COLOR: +5 COLOR: +4COLOR: +4

COLOR: +4

COLOR: +4COLOR: +4 COLOR: +3COLOR: +3

COLOR: +3

COLOR: +3COLOR: +3 COLOR: +2COLOR: +2

COLOR: +2

COLOR: +2COLOR: +2 COLOR: +1COLOR: +1

COLOR: +1

COLOR: +1COLOR: +1

<LCD>. Se mostrará la información sobre los

<LCD> varias veces para seleccionar la opción “Color”.

<IZD<IZD

<IZD

<IZD<IZD

A.>A.>

A.> o

A.>A.>

COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR:

<DCHA.><DCHA.>

<DCHA.> para seleccionar el ajuste de

<DCHA.><DCHA.>

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

-2-2

-2

-2-2

-1-1

-1

-1-1

Español

COLOR: 0COLOR: 0

COLOR: 0

COLOR: 0COLOR: 0

Salir de las operaciones de configuración

Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.

55

Ajustes de brillo del LCD

Puede aumentar o reducir el brillo de la imagen de vídeo manualmente.

1.1.

1. Pulse el botón

1.1.

2.2.

2. Pulse el botón

Español

2.2.

3.3.

3. Pulse los botones

3.3.

<LCD>. Se mostrará la información sobre los

ajustes LCD.

<LCD> varias veces para seleccionar la opción “BRIGHT”

(BRILLO).

<IZD<IZD

<IZD

<IZD<IZD

A.>A.>

A.> o

A.>A.>

<DCHA.><DCHA.>

<DCHA.> para seleccionar el ajuste de

<DCHA.><DCHA.>

brillo deseado.

<< NOTA>> Puede ajustar un brillo entre +9 y -9.

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

::

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

-2-2

-2

-2-2

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

+1 +1

:

+1

::

+1 +1

::

0 0

:

0

::

0 0

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

::

-1-1

-1

-1-1

Salir de las operaciones de configuración

Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.

56

Ajuste del contraste

Puede ajustar el contraste de vídeo para obtener una representación más agradable para sus ojos.

1. Pulse el botón

ajustes LCD.

2. Pulse el botón

“CONTRAST” (CONTRASTE).

3. Pulse los botones

contraste deseado.

<<<<

<< NOTA

<<<<

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

>>

>> Puede ajustar un contraste entre +9 y -9.

>>

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

::

+1 +1

:

+1

::

+1 +1

<LCD>. Se mostrará la información sobre los

<LCD> varias veces para seleccionar la opción

<IZD<IZD

<IZD

<IZD<IZD

A.>A.>

A.> o

A.>A.>

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

<DCHA.><DCHA.>

<DCHA.> para seleccionar el ajuste de

<DCHA.><DCHA.>

::

-9 -9

:

-9

::

-9 -9

::

-8 -8

:

-8

::

-8 -8

::

-7 -7

:

-7

::

-7 -7

::

-6 -6

:

-6

::

-6 -6

::

-5 -5

:

-5

::

-5 -5

::

-4 -4

:

-4

::

-4 -4

::

-3 -3

:

-3

::

-3 -3

::

-2 -2

:

-2

::

-2 -2

::

-1 -1

:

-1

::

-1 -1

Español

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

::

0 0

:

0

::

0 0

Salir de las operaciones de configuración

Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.

57

Nitidez de imagen en el LCD

Puede ajustar la nitidez de vídeo para obtener una representación más agradable para sus ojos.

1. Pulse el botón

Español

2. Pulse el botón

3. Pulse los botones

Salir de las operaciones de configuración

Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.

ajustes LCD.

“SHARPNESS” (NITIDEZ).

nitidez deseado.

SHARPNESS: 4SHARPNESS: 4

SHARPNESS: 4

SHARPNESS: 4SHARPNESS: 4 SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 3

SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 2SHARPNESS: 2

SHARPNESS: 2

SHARPNESS: 2SHARPNESS: 2 SHARPNESS: 1SHARPNESS: 1

SHARPNESS: 1

SHARPNESS: 1SHARPNESS: 1 SHARPNESS: 0SHARPNESS: 0

SHARPNESS: 0

SHARPNESS: 0SHARPNESS: 0

<LCD>. Se mostrará la información sobre los

<LCD> varias veces para seleccionar la opción

<IZD<IZD

<IZD

<IZD<IZD

A.>A.>

A.> o

A.>A.>

<DCHA.><DCHA.>

<DCHA.> para seleccionar el ajuste de

<DCHA.><DCHA.>

Reproducción de CDs de imágenes de Kodak y CDs de imágenes JPEG

Puede reproducir CDs de imágenes de Kodak o imágenes JPEG para visualizarlas en pantalla.

Inserte un CD de imágenes Kodak o JPEG. Al cabo de unos instantes, automáticamente se iniciará una representación de diapositivas del contenido del CD. O

Pulse los botones numéricos correspondientes al número de la imagen y pulse

<PLA<PLA

<PLA

<PLA<PLA

Para detener la reproducción temporalmente/completamente

Pulse <PAUSE> para detener la reproducción temporalmente; pulse <STOP> para detenerla

por completo.

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

58

Manual do utilizador do leitor DVD portátil

Definições iniciais

1. Prima o botão

<SETUP>.

2. Apresentação do ecrã do MENU SETUP.

Configuração do idioma

OSD

Menu

Áudio

Legenda

: Mover : Selec. SETUP: Sair

3. Utilize o botão <PARA CIMA> <PARA BAIXO> <ESQUERDA> <DIREITA> para seleccionar a opção pretendida.

4. Prima o botão

Português

Para as definições:

Repita o procedimento acima e consulte as instruções do OSD para realizar a seguinte definição:

Configuração do idioma

OSD

Menu

Áudio

Legenda

: Mover : Selec. SETUP: Sair

Configuração do áudio

Saída digital

Saída analógica

Configuração do ecrã

Tipo de televisão

Protector de ecrã

Sistema da televisão

Saída do vídeo

: Mover : Selec. SETUP: Sair

Configuração personalizada

MMC/SD

Controlo parental

Palavra-passe

Símbolo do ângulo

Predefinido

: Mover : Selec. SETUP: Sair

59

DIAGRAMA DO MENU CONFIGURAR

Idioma (As opções do idioma são apenas para referência, para obter as

Português

informações correctas, consulte o seu leitor de DVD portátil.)

O.S.D. Inglês

Francês Alemão Italiano Espanhol Português

Menu Inglês

Chinês Japonês Francês Alemão Italiano Espanhol Português ... Outros

Áudio Inglês

Chinês Japonês Francês Alemão Italiano Espanhol Português ... Outros

Legendas Inglês

Chinês Japonês Francês Alemão Italiano Espanhol Português ... Outros Off

60

DIAGRAMA DO SETUP MENU - continuação

Ecrã Tipo de TV 4:3 PS

4:3 LB 16:9

Protector de ecrã Activado (Trata-se do tempo de espera do protector de

ecrã: 10 minutos.)

Desactivado

Sistema da TV NTSC

PAL AUTO

Saída do vídeo S-Vídeo

VARRIMENTO-P (consulte a figura 1-1)

Áudio Saída digital SPDIF/PCM

SPDIF/RAW Off

Saída analógica 2 canais

Personalizar MMC/SD Aceso (consulte a figura 1-2)

Apagado

Controlo parental (Antes de seleccionar as classificações,

introduza uma palavra-passe com 4 dígitos. a palavra-passe predefinida pelo fabricante é:

0000)

1.

2.

3. PG (veja a NOTA abaixo)

4. PG13 (veja a NOTA abaixo)

5.

6. R (veja a NOTA abaixo)

7. NC-17 (veja a NOTA abaixo)

8.

Palavra-passe Introduzir palavra-passe (palavra-passe

predefinida pelo fabricante é: 0000) Introduzir palavra-passe NOVA Voltar a introduzir palavra-passe

Símbolo do ângulo Aceso

Apagado

Predefinido Leitura

NOTA:

1. PG: Sugere-se Parental Guidance (Orientação Parental).

2. PG-13: O material não se adequa a crianças com idade inferior a 13 anos.

3. R: Orientação Parental – Restricted (Limitada); recomenda-se que os pais impeçam a visualização por parte de crianças com idade inferior a 17 anos, ou que tal aconteça apenas quando vigiadas por um dos pais ou por um guardião adulto.

4. NC-17: No Children (Não para Crianças); não se recomenda a visualização por parte de crianças com idade inferior a 17 anos.

Português

61

DIAGRAMA DO MENU SETUP - continuação

FIGURA 1-1

Configuração do ecrã

Português

Se seleccionar “Varrimento-P”, a mensagem acima aparece no ecrã como lembrete. De seguida, se a sua TV suportar a opção “Varrimento-P”, prima o

botão

<<Resolução de problemas>> O que é que se deve fazer se o ecrã ficar em branco com o dispositivo ligado?

Solução: Prima o botão

Tipo de televisão Protector de ecrã

A sua TV suporta o varrimento progressivo

SIM Prima PLAY NÃO Prima STOP

4

S-Vídeo VARRIMENTO-P

: Mover : Selec. SETUP: Sair

<PLA<PLA

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>. Caso contrário, prima o botão

Y/SEL.>Y/SEL.>

<MODE> para mudar para o modo “S-Video”.

<ST<ST

<ST

<ST<ST

OP>OP>

OP>.

OP>OP>

FIGURA 1-2

Configuração Personalizada

MMC/SD Controlo parental Palavra-passe ... Símbolo do ângulo

: Mover : Seleccionar SETUP: Sair

<< Importante >>

z Se colocar a definição do MMC/SD em "Aceso", o leitor de DVD portátil não pode senão ler o cartão

SD/MMC. Isto é, o leitor de DVD não pode reproduzir quaisquer discos.

z Também pode utilizar o botão <Mode> do controlo remoto ou do painel para mudar para o modo

MMC/SD.

Aceso Apagado

62

Preparações

Ligue este leitor de DVD portátil à alimentação e ligue-o aos auriculares/auscultadores ou ligue-o a equipamentos externos. Se ligar o leitor de DVD portátil a equipamentos externos: z Prima o botão de alimentação da televisão e seleccione “Vídeo” como a entrada da

televisão.

z Prima o botão de alimentação do sistema estéreo, se o leitor de DVD tiver sido ligado a

um sistema estéreo.

z Faça com que a AV OUT/IN deslize para a AV OUT.

Reprodução básica

1.1.

1. Prima

1.1.

2.2.

2. Prima

2.2.

3.3.

3. Segure com cuidado a extremidade do disco e, de seguida, coloque-o ao

3.3.

<POWER>.

<OPEN> para abrir a tampa do compartimento dos discos.

centro com o lado impresso virado para cima.

4.4.

4. Feche a tampa do compartimento dos discos.

4.4.

z Feche a tampa do compartimentos dos discos e o leitor de DVD dá início à

reprodução do DVD, se este não tiver menus gravados.

z Se o disco tiver um mais títulos gravados, aparece um ecrã menu no ecrã da

televisão.

5.5.

5. Prima o botão

5.5. <DIREIT<DIREIT

<DIREIT

<DIREIT<DIREIT

A>A>

A> ou o(s) número(s) numerado(s) para seleccionar o título

A>A>

<P<P

ARA CIMA> <PARA CIMA> <P

<P

ARA CIMA> <P

<P<P

ARA CIMA> <PARA CIMA> <P

ARA BARA B

ARA B

ARA BARA B

AIXAIX

O> <ESQO> <ESQ

AIX

O> <ESQ

AIXAIX

O> <ESQO> <ESQ

UERDUERD

UERD

UERDUERD

A>A>

A>

A>A>

pretendido.

Nota: Para seleccionar um título, introduza o número, por exemplo 1 para

o capítulo 1, 10 para o capítulo 10, etc..

6.6.

6. Prima o botão

6.6.

O leitor de DVD dá início à reprodução do item seleccionado.

<PLA<PLA

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

Português

Paragem da reprodução

<ST<ST

Prima o botão

<ST<ST

botão

OP>OP>

<ST

OP> duas vezes para parar.

<ST<ST

OP>OP>

<ST

OP> uma vez para realizar a paragem prévia. Prima o

<ST<ST

OP>OP>

Avanço rápido/recuo rápido

<F<F

Prima o botão

z A reprodução normal é reposta quando prime o botão <PLAY/SEL.>. z A velocidade do avanço rápido ou na reprodução de recuo é alterada cada vez que toca no

botão

<F.BWD> ou <F.FWD>.

.BWD>.BWD>

<F

.BWD> ou

<F<F

.BWD>.BWD>

<F<F

.FWD>.FWD>

<F

.FWD> durante a reprodução.

<F<F

.FWD>.FWD>

63

Saltar capítulos para a frente ou para trás

Saltar para a frente

Prima o botão

Prima este botão para saltar um capítulo.

Saltar para trás

Prima o botão

Português

Prima este botão para saltar um capítulo.

Imagem fixa (PAUSAR)

Prima o botão

O ecrã fica imóvel.

Para voltar para a reprodução normal:

Prima o botão <PLAY/SEL.>.

<NEXT> durante a reprodução.

<PREVIOUS> durante a reprodução.

<P <P

AA

USE>USE>

<P

A

USE> uma vez durante a reprodução.

<P <P

AA

USE>USE>

Nova visualização

Prima o botão

Sempre que premir este botão, o disco repetirá um capítulo ou título. Premir uma vez: CHAPTER (Repete o capítulo) Premir duas vezes: TITLE (Repete o título) Premir três vezes: DISC (Repete o disco) Premir quatro vezes: off (Repetição cancelada)

Para voltar para a reprodução normal

Prima <1/ALL REPEAT> diversas vezes até aparecer “ off” no ecrã.

<1/ALL REPEA<1/ALL REPEA

<1/ALL REPEA

<1/ALL REPEA<1/ALL REPEA

T>T>

T> durante a reprodução.

T>T>

64

Apresentação das informações relativas a uma cena

Prima o botão capítulo e outras informações aparecem no ecrã.

Para parar a apresentação das informações no ecrã

Prima o botão <INFO.> diversas vezes até as informações desaparecerem.

<INFO.><INFO.>

<INFO.> diversas vezes, número do título, número do

<INFO.><INFO.>

Selecção do idioma da faixa de áudio

O idioma da pista sonora pode ser alterado, se esta opção estiver disponível no DVD. Para seleccionar o idioma pretendido:

Português

1.1.

1. Prima o botão

1.1.

2.2.

2. Prima o botão

2.2.

ter sido seleccionado.

Nota: Quando não se consegue seleccionar o idioma pretendido, mesmo

depois de premir o botão várias vezes, isso significa que o idioma não está contido no disco.

<A<A

UDIO>UDIO>

<A

UDIO> durante a reprodução.

<A<A

UDIO>UDIO>

<A<A

UDIO>UDIO>

<A

UDIO> diversas vezes até o idioma pretendido

<A<A

UDIO>UDIO>

Selecção do idioma das legendas

O idioma das legendas pode ser seleccionado, se esta opção estiver disponível no DVD. Para a seleccionar:

1.1.

1. Prima o botão

1.1.

<SUBTITLE> durante a reprodução.

2.2.

2. Prima o botão

2.2.

pretendido ter sido seleccionado.

Nota: Quando o idioma pretendido não é seleccionado, poderá indicar que

o idioma não está disponível no disco.

<SUBTITLE> diversas vezes até o idioma

65

Selecção dos ângulos

Em alguns discos, as mesmas cenas podem ser visualizadas a partir de diversos ângulos.

1.1.

1. Prima o botão

1.1.

<ANGLE> durante a reprodução.

2.2.

2. Prima o botão

2.2.

Português

Função de corte do som

Prima o botão

Para repor o som

Prima o botão <MUTE> novamente até “Som reposto” aparecer no ecrã.

<ANGLE> diversas vezes até o ângulo de

visualização pretendido ser seleccionado.

Nota: Esta função só funciona em discos onde foram gravados ângulos de

visualização diferentes. Se esta função não estiver disponível,

aparece o ícone inválido “ ”.

<MUTE> durante a reprodução.

Nota: Quando a opção “Corte do som” aparece no ecrã, é porque este

leitor de DVD portátil não tem som.

Definições do painel LCD

Este leitor de DVD portátil dispõe de três opções acerca do ajuste do painel: “Normal”, ou “4:3”.

1.1.

1. Prima o botão

1.1.

LCD aparecem no ecrã.

2.2.

2. Prima o botão

2.2.

(Painel).

3.3.

3. Prima o botão

3.3.

definição preferida do painel, e de seguida, o painel muda para a definição seleccionada.

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

Para concluir a operação de configuração:

Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.

Nor Nor

Nor

Nor Nor

4:3 4:3

4:3

4:3 4:3

<LCD>, as informações relativas às definições do

<L<L

CD>CD>

<L

CD> diversas vezes para seleccionar “PANEL”

<L<L

CD>CD>

<ESQ<ESQ

<ESQ

<ESQ<ESQ

malmal

mal

malmal

UERDUERD

UERD

UERDUERD

A>A>

A> ou

A>A>

<DIREIT<DIREIT

<DIREIT

<DIREIT<DIREIT

A>A>

A> para seleccionar a

A>A>

66

Definição das cores do LCD

Pode utilizar esta definição para ajustar a cor do vídeo para uma vista de disparo dos seus olhos.

1.1.

1. Prima o botão

1.1.

LCD aparecem no ecrã.

2.2.

2. Prima o botão

2.2.

(Cor).

3.3.

3. Prima o botão

3.3.

definição preferida da cor, e de seguida, o painel muda para a definição seleccionada.

<<<<

<< NOTA

<<<<

COLOR: +9COLOR: +9

COLOR: +9

COLOR: +9COLOR: +9

COLOR: +8COLOR: +8

COLOR: +8

COLOR: +8COLOR: +8

COLOR: +7COLOR: +7

COLOR: +7

COLOR: +7COLOR: +7

COLOR: +6COLOR: +6

COLOR: +6

COLOR: +6COLOR: +6

COLOR: +5COLOR: +5

COLOR: +5

COLOR: +5COLOR: +5

COLOR: +4COLOR: +4

COLOR: +4

COLOR: +4COLOR: +4

COLOR: +3COLOR: +3

COLOR: +3

COLOR: +3COLOR: +3

COLOR: +2COLOR: +2

COLOR: +2

COLOR: +2COLOR: +2

>>

>> O intervalo de cores é de +9 a -9.

>>

<LCD>, as informações relativas às definições do

<LCD> diversas vezes para seleccionar “COLOR”

<ESQ<ESQ

<ESQ

<ESQ<ESQ

UERDUERD

UERD

UERDUERD

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

COLOR:

COLOR: COLOR:

A>A>

A> ou

A>A>

<DIREIT<DIREIT

<DIREIT

<DIREIT<DIREIT

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

-2-2

-2

-2-2

A>A>

A> para seleccionar a

A>A>

Português

COLOR: +1COLOR: +1

COLOR: +1

COLOR: +1COLOR: +1

COLOR: 0COLOR: 0

COLOR: 0

COLOR: 0COLOR: 0

COLOR: COLOR:

COLOR:

COLOR: COLOR:

-1-1

-1

-1-1

Para concluir a operação de configuração:

Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.

67

Definição da luminosidade do LCD

Pode aumentar ou diminuir a luminosidade do vídeo.

1.1.

1. Prima o botão

1.1.

2.2.

2. Prima o botão

2.2.

3.3.

3. Prima o botão

3.3.

Português

<LCD>, as informações relativas às definições do

LCD aparecem no ecrã.

<LCD> diversas vezes para seleccionar “BRIGHT”

(BRILHO).

<ESQ<ESQ

<ESQ

<ESQ<ESQ

UERDUERD

UERD

UERDUERD

A>A>

A> ou

A>A>

<DIREIT<DIREIT

<DIREIT

<DIREIT<DIREIT

A>A>

A> para seleccionar a

A>A>

definição preferida da luminosidade, e de seguida, o painel muda para a definição seleccionada.

<<<<

<< NOTA

<<<<

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

>>

>> O intervalo de brilho é de +9 a -9.

>>

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

::

:

::

:

::

:

::

:

::

:

::

:

::

:

::

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

-2-2

-2

-2-2

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

+1 +1

:

+1

::

+1 +1

::

0 0

:

0

::

0 0

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

::

-1-1

-1

-1-1

Para concluir a operação de configuração:

Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.

68

Definição do Contraste do LCD

Pode utilizar esta definição para ajustar o contraste do vídeo para um valor confortável para os seus olhos.

1. Prima

<LCD>. As informações relativas às definições do LCD

aparecem no ecrã.

2. Prima

<LCD> diversas vezes para seleccionar “CONTRAST”

(CONTRASTE).

3. Prima o botão <ESQUERDA> ou <DIREITA> para seleccionar a definição preferida de contraste. O painel muda, de seguida, para a definição que seleccionou.

<<<<

<< NOTA

<<<<

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

>>

>> O intervalo de contraste é de +9 a -9.

>>

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

::

-9 -9

:

-9

::

-9 -9

::

-8 -8

:

-8

::

-8 -8

::

-7 -7

:

-7

::

-7 -7

::

-6 -6

:

-6

::

-6 -6

::

-5 -5

:

-5

::

-5 -5

::

-4 -4

:

-4

::

-4 -4

::

-3 -3

:

-3

::

-3 -3

::

-2 -2

:

-2

::

-2 -2

Português

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

::

+1 +1

:

+1

::

+1 +1

::

0 0

:

0

::

0 0

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

::

-1 -1

:

-1

::

-1 -1

Para concluir a operação de configuração:

Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.

69

Definição de Nitidez do LCD

Pode utilizar esta definição para ajustar a nitidez do vídeo para um valor confortável para os seus olhos.

1. Prima

aparecem no ecrã.

2. Prima

Português

3. Prima o botão

Para concluir a operação de configuração:

Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.

<LCD>. As informações relativas às definições do LCD

<LCD> diversas vezes para seleccionar “SHARPNESS”

(NITIDEZ).

<ESQ<ESQ

<ESQ

<ESQ<ESQ

UERDUERD

UERD

UERDUERD

A>A>

A> ou

A>A>

<DIREIT<DIREIT

<DIREIT

<DIREIT<DIREIT

A>A>

A> para seleccionar a

A>A>

definição preferida de nitidez. O painel muda, de seguida, para a definição que seleccionou.

SHARPNESS: 4SHARPNESS: 4

SHARPNESS: 4

SHARPNESS: 4SHARPNESS: 4

SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 3

SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 2SHARPNESS: 2

SHARPNESS: 2

SHARPNESS: 2SHARPNESS: 2

SHARPNESS: 1SHARPNESS: 1

SHARPNESS: 1

SHARPNESS: 1SHARPNESS: 1

SHARPNESS: 0SHARPNESS: 0

SHARPNESS: 0

SHARPNESS: 0SHARPNESS: 0

Reprodução de CD com fotografias da Kodak e com fotografias em formato JPEG

Pode reproduzir CD com fotografias da Kodak e com fotografias em formato JPEG para visualizar no ecrã.

Introduza um CD com fotografias da Kodak e com fotografias em formato JPEG, após alguns segundos, este leitor de DVD portátil inicia automaticamente a reprodução de fotografias sob a forma de diapositivos. Ou Pode premir os botões numerados correspondentes à ordem da fotografia, e de

<PLA<PLA

seguida, premir o botão

Para pausar/parar a reprodução

Prima o botão <PAUSE> para pausar a reprodução e prima <STOP> para parar.

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

70

Manuel de l’utilisateur du lecteur DVD portable

Paramètres initiaux

1. Appuyez sur le bouton <SETUP>.

2. L’écran MENU CONFIG. s’affiche.

Configuration de la langue

OSD

Menu

Audio

Sous-titre

: Dépl. Sél.: SETUP : Quitter

3. Utilisez le bouton <HAUT> <BAS> <GAUCHE> <DROITE> pour sélectionner l’option désirée.

4. Appuyez sur le bouton

<PLAY/SEL.>.

Pour les paramétrages :

Répétez la procédure décrite ci-dessus et suivez les instructions OSD pour effectuer le paramétrage ci-après.

Configuration de la langue

OSD

Menu

Audio

Sous-titre

Configuration écran

Type TV

Écran de veille

Système TV

Sortie vidéo

Français

: Dépl. Sél.: SETUP : Quitter

Configuration audio

Sortie numérique

Sortie analogique

: Dépl. Sél.: SETUP : Quitter

Configuration personnalisée

MMC/SD

Contrôle parental

Mot de passe

Visualisation angles

Par défaut

: Dépl. Sél.: SETUP : Quitter

71

SCHÉMA DU MENU DE CONFIGURATION

Langue (Les options de langues servent uniquement de référence.

Français

Veuillez consulter votre lecteur DVD portable pour les informations correctes).

O.S.D. Anglais

Français Allemand Italien Espagnol Portugais

Menu Anglais

Chinois Japonais Français Allemand Italien Espagnol Portugais ... Autres

Audio Anglais

Chinois Japonais Français Allemand Italien Espagnol Portugais ... Autres

Sous-titres Anglais

Chinois Japonais Français Allemand Italien Espagnol Portugais ... Autres Off

72

SCHÉMA DU MENU DE CONFIGURATION - suite

Écran Type TV 4:3 PS

4:3 LB 16:9

Écran de veille On (temps d’attente de l’écran de veille : 10 minutes).

Off

Système TV NTSC

PAL AUTO

Sortie vidéo S-Vidéo

P-SCAN (voir figure 1-1)

Audio Sortie numérique SPDIF/PCM

SPDIF/RAW Off

Sortie analogique Canal 2

Personnalisé MMC/SD On (voir figure 1-2)

Off

Contrôle parental (Avant de sélectionner les niveaux, tapez un mot

de passe à 4 chiffres. Mot de passe par défaut : 0000)

1.

2.

3. PG (reportez-vous à la REMARQUE ci-après)

4. PG13 (reportez-vous à la REMARQUE ci-après)

5.

6. R (reportez-vous à la REMARQUE ci-après)

7. NC-17 (reportez-vous à la REMARQUE ci-après)

8.

Mot de passe Indiquez un mot de passe (mot de passe par

défaut : 0000) Indiquez un NOUVEAU mot de passe Indiquez le mot de passe à nouveau

Visualisation angles On

Off

Par défaut Lecture

REMARQUE :

1. PG : Surveillance parentale recommandée.

2. PG-13: Ce matériel n’est pas approprié pour des enfants de moins de 13 ans.

3. R : Surveillance parentale -restreinte ; il est recommandé que les parents restreignent aux enfants de moins de 17 ans de regarder ou autorisent les enfants à regarder uniquement lorsqu’ils sont surveillés par un parent ou une personne adulte.

4. NC-17: Aucun enfant de moins de 17 ans; il n’est pas recommandé que les enfants de moins de 17 ans regardent.

Français

73

SCHÉMA DU MENU DE CONFIGURATION - suite

FIGURE 1-1

Configuration écran

Français

Si vous sélectionnez le balayage progressif (P-Scan), les options ci-dessus s’affichent sur l’écran comme rappel. Si votre téléviseur prend en charge la

fonction de balayage progressif (P-Scan), appuyez sur

Sinon, appuyez sur

<<Dépannage>> Si l’écran devient noir en cours d’utilisation…

Solution : Appuyez sur le bouton

Type TV Écran de veille

Votre TV prend en charge le balayage progressif

OUI Appuyez sur PLAY NON Appuyez sur STOP

4

S-Vidéo P-SCAN

: Dépl. Sél.: SETUP : Quitter

<ST<ST

OP>OP>

<ST

OP>.

<ST<ST

OP>OP>

<MODE> pour passer au mode de balayage

progressif “S-Video”.

<PLA<PLA

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

FIGURE 1-2

Configuration personnalisée

MMC/SD Contrôle parental Mot de passe ... Visual. angles

: Dépl. : Selecti. SETUP: Quitter

<< Important >>

z Si vous avez activé le mode MMC/SD, le lecteur de DVD portable peut uniquement lire les cartes SD/

MMC et il ne peut donc pas lire les disques.

z Vous pouvez également appuyer sur le bouton <Mode> de la télécommande ou du panneau pour

activer le mode MMC/SD.

On Off

74

Préparations

Veuillez connecter ce lecteur DVD portable à l’alimentation et connectez-le avec des écouteurs ou aux équipements extérieurs. En cas de connexion à des équipements extérieurs :

z Allumez votre téléviseur et sélectionnez “Video” comme entrée TV. z Appuyez sur le bouton Power du système stéréo si le lecteur a été connecté à celui-ci. z Mettez le bouton AV OUT/IN sur AV OUT.

Lecture de base

1.1.

1. Appuyez sur le bouton

1.1.

2.2.

2. Appuyez sur le bouton

2.2.

3.3.

3. Maintenez le bord du disque pour le placer au centre avec le côté

3.3.

<POWER>.

<OPEN> pour ouvrir le couvercle.

imprimé vers le haut.

4.4.

4. Refermez le couvercle.

4.4.

z Refermez le couvercle. Le lecteur DVD portable démarre la lecture si le

disque ne possède pas de menus enregistrés.

z Si le disque a un ou plusieurs titres enregistrés dessus, une page de menu

s’affiche sur l’écran du téléviseur.

5.5.

5. Appuyez sur le bouton

5.5.

<HA<HA

<HA

<HA<HA

UT> <BUT> <B

UT> <B

UT> <BUT> <B

AS> <GAAS> <GA

AS> <GA

AS> <GAAS> <GA

UCHE> <DRUCHE> <DR

UCHE> <DR

UCHE> <DRUCHE> <DR

ou sur les touches numériques pour sélectionner votre titre préféré.

Remarque : Pour sélectionner un titre, vous devez entrer le numéro, par

exemple, 1 pour le chapitre 1, 10 pour le chapitre 10, etc.

6.6.

6. Appuyez sur

6.6.

Le lecteur DVD portable démarre la lecture de l’élément sélectionné.

<PLA<PLA

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

OITE>OITE>

OITE>

OITE>OITE>

Français

Arrêt de la lecture

Appuyez sur

<ST

<ST<ST

OP>OP>

OP> pour un pré-arrêt. Appuyez sur

OP>OP>

<ST<ST

<ST

<ST<ST

OP>OP>

OP> deux

OP>OP>

<ST<ST

fois pour arrêter.

Avance rapide/ Retour rapide

<F<F

Appuyez sur

z La lecture normale reprendra lorsque vous appuierez sur le bouton <PLAY/SEL.>. z La vitesse de l’avance rapide ou du retour rapide change chaque fois que vous appuyez sur le

bouton

<F.BWD> ou <F.FWD>.

.BWD>.BWD>

<F

.BWD> ou

<F<F

.BWD>.BWD>

<F<F

.FWD>.FWD>

<F

.FWD> pendant la lecture.

<F<F

.FWD>.FWD>

75

Saut avant ou retour aux chapitres

Saut avant

Appuyez sur le bouton

Vous sauterez un chapitre à chaque fois que vous appuierez sur le bouton.

Saut arrière

Appuyez sur le bouton

Vous sauterez un chapitre à chaque fois que vous appuierez sur le bouton.

Français

Image immobile (PAUSE)

Appuyez une fois sur le bouton

L’écran est suspendu.

Pour retourner en mode de lecture normale

Appuyez sur <PLAY/SEL.>.

<SUIV<SUIV

<SUIV

<SUIV<SUIV

<PRÉCÉDENT><PRÉCÉDENT>

<PRÉCÉDENT> pendant la lecture.

<PRÉCÉDENT><PRÉCÉDENT>

ANT>ANT>

ANT> pendant la lecture.

ANT>ANT>

<P <P

AA

USE>USE>

<P

A

USE> pendant la lecture.

<P <P

AA

USE>USE>

Répétition

Appuyez sur le bouton

Chaque fois que vous appuyez sur ce bouton, le disque répète un chapitre ou un titre. Appuyez une fois : CHAPITRE (Répétition chapitre) Appuyez deux fois : TITRE (Répétition titre) Appuyez trois fois : DISQUE (Répétition disque) Appuyez quatre fois : off (Répétition annulée)

Pour retourner en mode de lecture normale

Appuyez plusieurs fois sur <1/ALL REPEAT> jusqu’à ce que “ off” s’affiche à l’écran.

<1/ALL REPEA<1/ALL REPEA

<1/ALL REPEA

<1/ALL REPEA<1/ALL REPEA

T>T>

T> pendant la lecture.

T>T>

76

Affichage des informations sur la scène

Appuyez plusieurs fois sur numéro du titre, le numéro du chapitre et autres informations s’affichent à l’écran.

Pour arrêter l’affichage des informations sur la scène

Appuyez plusieurs fois sur <INFO.> jusqu’à ce que les informations disparaissent.

<INFO.><INFO.>

<INFO.> pendant la lecture jusqu’à ce que le

<INFO.><INFO.>

Sélection de la langue des pistes sonores

Vous pouvez changer la langue des pistes sonores du disque si cette option est disponible sur votre disque. Pour sélectionner la langue souhaitée :

1.1.

1. Appuyez sur le bouton

1.1.

2.2.

2. Appuyez plusieurs fois sur

2.2.

préférée soit sélectionnée.

Remarque : Si la langue préférée n’est toujours pas sélectionnée après avoir

appuyé plusieurs fois sur ce bouton, cela signifie que cette langue n’est pas disponible sur ce disque.

<A<A

UDIO>UDIO>

<A

UDIO> pendant la lecture.

<A<A

UDIO>UDIO>

<A<A

UDIO>UDIO>

<A

UDIO> jusqu’à ce que votre langue

<A<A

UDIO>UDIO>

Sélection de la langue de sous-titrage

Vous pouvez sélectionner la langue du sous-titrage du disque si cette option est disponible sur votre disque. Pour sélectionner la langue souhaitée :

Français

1.1.

1. Appuyez sur le bouton

1.1.

2.2.

2. Appuyez plusieurs fois sur

2.2.

langue préférée soit sélectionnée.

Remarque : Si la langue préférée n’est pas sélectionnée, il se peut que la

langue en question ne soit pas disponible sur ce disque.

<SUBTITLE> pendant la lecture.

<SUBTITLE> jusqu’à ce que votre

77

Sélection des angles

Pour certains disques, les mêmes scènes peuvent être visualisées sous différents angles.

1.1.

1. Appuyez sur le bouton

1.1.

<ANGLE> pendant la lecture.

2.2.

2. Appuyez plusieurs fois sur

2.2.

Français

Fonction Muet

Appuyez sur le bouton

Pour restaurer le son

Appuyez à nouveau sur <MUTE> jusqu’à ce que le message “Muet Off” s’affiche à l’écran.

<ANGLE> jusqu’à ce que votre angle

de prise de vues préféré soit sélectionné.

Remarque : Cette fonction n’est disponible qu’avec des disques sur lesquels ont

été enregistrés plusieurs angles de prise de vues. Si cette fonction

n’est pas disponible, l’icône d’erreur “ ” s’affichera.

<MUTE> pendant la lecture.

Remarque : Si l’indication “Muet” s’affiche à l’écran, cela signifie que le

lecteur DVD portable est désactivé.

Paramétrage du panneau LCD

1.1.

1. Appuyez sur

1.1.

l’écran LCD s’afficheront.

2.2.

2. Appuyez plusieurs fois sur

2.2.

(PANNEAU).

3.3.

3. Appuyez sur le bouton

3.3.

paramétrage de panneau préféré. Le panneau adoptera le paramétrage sélectionné.

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

PP

ANEL:ANEL:

P

ANEL:

PP

ANEL:ANEL:

Pour terminer l’opération de configuration

Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.

Nor Nor

Nor

Nor Nor

4:3 4:3

4:3

4:3 4:3

<LCD>. Les informations sur le paramétrage de

<L<L

CD>CD>

<L

CD> pour sélectionner “PANEL”

<L<L

CD>CD>

<GA<GA

malmal

mal

malmal

UCHE>UCHE>

<GA

UCHE> ou

<GA<GA

UCHE>UCHE>

<DR<DR

OITE>OITE>

<DR

OITE> pour choisir le

<DR<DR

OITE>OITE>

78

Paramétrage couleur de l’écran LCD

Vous pouvez régler la couleur de l’image avec ce paramétrage pour votre confort visuel.

1.1.

1. Appuyez sur

1.1.

<LCD>. Les informations sur le paramétrage de

l’écran LCD s’afficheront.

2.2.

2. Appuyez plusieurs fois sur

2.2.

(COULEUR).

3.3.

3. Appuyez sur le bouton

3.3.

<GA<GA

<GA

<GA<GA

paramétrage de couleur préféré. Le panneau adoptera le paramétrage sélectionné.

<<<<

<< REMARQUE

<<<<

COLOR: +9COLOR: +9

COLOR: +9

COLOR: +9COLOR: +9 COLOR: +8COLOR: +8

COLOR: +8

COLOR: +8COLOR: +8 COLOR: +7COLOR: +7

COLOR: +7

COLOR: +7COLOR: +7 COLOR: +6COLOR: +6

COLOR: +6

COLOR: +6COLOR: +6 COLOR: +5COLOR: +5

COLOR: +5

COLOR: +5COLOR: +5 COLOR: +4COLOR: +4

COLOR: +4

COLOR: +4COLOR: +4 COLOR: +3COLOR: +3

COLOR: +3

COLOR: +3COLOR: +3 COLOR: +2COLOR: +2

COLOR: +2

COLOR: +2COLOR: +2

>>>>

>> La gamme de couleurs est comprise entre +9 et -9.

>>>>

COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR: COLOR: COLOR:

COLOR:

COLOR: COLOR:

<LCD> pour sélectionner “COLOR”

UCHE>UCHE>

UCHE> ou

UCHE>UCHE>

<DR<DR

OITE>OITE>

<DR

OITE> pour choisir le

<DR<DR

OITE>OITE>

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

-2-2

-2

-2-2

Français

COLOR: +1COLOR: +1

COLOR: +1

COLOR: +1COLOR: +1 COLOR: 0COLOR: 0

COLOR: 0

COLOR: 0COLOR: 0

COLOR: COLOR:

COLOR:

COLOR: COLOR:

-1-1

-1

-1-1

Pour terminer l’opération de configuration

Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.

79

Paramétrage de la luminosité de l’écran LCD

Vous pouvez augmenter ou diminuer manuellement la luminosité de l’image.

1.1.

1. Appuyez sur

1.1.

2.2.

2. Appuyez plusieurs fois sur

2.2.

3.3.

3. Appuyez sur le bouton

3.3.

Français

<LCD>, les informations sur le paramétrage de l’écran

LCD s’afficheront.

<LCD> pour sélectionner “BRIGHT”

(CLAIR).

<GA<GA

UCHE>UCHE>

<GA

UCHE> ou

<GA<GA

UCHE>UCHE>

<DR<DR

OITE>OITE>

<DR

OITE> pour choisir le

<DR<DR

OITE>OITE>

paramétrage de luminosité préféré. Le panneau adoptera le paramétrage sélectionné.

<< REMARQUE>> La gamme de lumineux est comprise entre +9 et -9.

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

:: ::

:

::

-9-9

-9

-9-9

-8-8

-8

-8-8

-7-7

-7

-7-7

-6-6

-6

-6-6

-5-5

-5

-5-5

-4-4

-4

-4-4

-3-3

-3

-3-3

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

+2 +2

:

+2

::

+2 +2

::

+1 +1

:

+1

::

+1 +1

::

0 0

:

0

::

0 0

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

::

:

:: ::

:

::

-2-2

-2

-2-2

-1-1

-1

-1-1

Pour terminer l’opération de configuration

Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.

80

Contraste de l'écran LCD

Vous pouvez régler le contraste vidéo à l'aide de ce paramètre pour votre confort visuel.

1. Appuyez sur

<LCD>. Les informations de paramétrage de l’écran

LCD s'affichent.

2. Appuyez plusieurs fois sur

(CONTRASTE).

3. Appuyez sur le bouton

niveau de contraste. La sélection s'affiche sur le panneau.

<<<<

<< REMARQUE

<<<<

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

>>

>> Le niveau de contraste peut être compris entre +9 et -9.

>>

::

+9 +9

:

+9

::

+9 +9

::

+8 +8

:

+8

::

+8 +8

::

+7 +7

:

+7

::

+7 +7

::

+6 +6

:

+6

::

+6 +6

::

+5 +5

:

+5

::

+5 +5

::

+4 +4

:

+4

::

+4 +4

::

+3 +3

:

+3

::

+3 +3

::

+2 +2

:

+2

::

+2 +2

::

+1 +1

:

+1

::

+1 +1

<LCD> pour sélectionner “CONTRAST”

<GA<GA

UCHE>UCHE>

<GA

UCHE> ou

<GA<GA

UCHE>UCHE>

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

<DR<DR

<DR

<DR<DR

::

-9 -9

:

-9

::

-9 -9

::

-8 -8

:

-8

::

-8 -8

::

-7 -7

:

-7

::

-7 -7

::

-6 -6

:

-6

::

-6 -6

::

-5 -5

:

-5

::

-5 -5

::

-4 -4

:

-4

::

-4 -4

::

-3 -3

:

-3

::

-3 -3

::

-2 -2

:

-2

::

-2 -2

::

-1 -1

:

-1

::

-1 -1

OITE>OITE>

OITE> pour choisir le

OITE>OITE>

Français

CONTRASTCONTRAST

CONTRAST

CONTRASTCONTRAST

::

0 0

:

0

::

0 0

Pour terminer l’opération de configuration

Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.

81

Netteté de l'écran LCD

Vous pouvez régler la netteté vidéo à l'aide de ce paramètre pour votre confort visuel.

1. Appuyez sur

LCD s'affichent.

2. Appuyez plusieurs fois sur

3. Appuyez sur le bouton

Français

Pour terminer l’opération de configuration

Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.

<LCD>. Les informations de paramétrage de l’écran

<LCD> pour sélectionner

“SHARPNESS” (NETTETÉ).

<LEFT> ou

<RIGHT> pour choisir le

paramétrage de netteté. La sélection s'affiche sur le panneau.

SHARPNESS: 4SHARPNESS: 4

SHARPNESS: 4

SHARPNESS: 4SHARPNESS: 4 SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 3

SHARPNESS: 3SHARPNESS: 3

SHARPNESS: 2SHARPNESS: 2

SHARPNESS: 2

SHARPNESS: 2SHARPNESS: 2 SHARPNESS: 1SHARPNESS: 1

SHARPNESS: 1

SHARPNESS: 1SHARPNESS: 1 SHARPNESS: 0SHARPNESS: 0

SHARPNESS: 0

SHARPNESS: 0SHARPNESS: 0

Lecture des CD d’images Kodak et JPEG

Vous pouvez lire les CD d’images Kodak et JPEG et les visualiser à l’écran.

Chargez un CD d’images Kodak/JPEG. Après quelques secondes, le lecteur DVD portable commencera automatiquement à lire les images les unes après les autres. Ou Vous pouvez également appuyer sur les touches numériques correspondant au

<PLA<PLA

numéro d’ordre des images puis sur

Pour suspendre/arrêter la lecture

Appuyez sur <PAUSE> pour suspendre la lecture et sur <STOP> pour arrêter.

<PLA

<PLA<PLA

Y/SEL.>Y/SEL.>

Y/SEL.>.

Y/SEL.>Y/SEL.>

82

Mustek PL510 USER GUIDE

Specifications and Main Features

Frequently Asked Questions

User Manual
