Mustek PL408H USER GUIDE

Portable DVD Player
User Guide
English
Español
Français
Playable Disk Format: DVD/VCD/CD/CD-R/CD-RW
82-171-00410
Table of Contents
FCC and Safety Information.................................................................................. 4
Important Safety Instructions............................................................................... 5
Precautions..................................................................................................... 6
Selecting the type of disc for the type of TV connected................................................ 7
Chapter 1. DVD
1-1 DVD Playback.............................................................................................. 8
Basic Playback......................................................................................................................... 8
Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The Disc)...................8
Stopping Playback.................................................................................................................... 9
Rapid Advance and Rapid Reverse............................................................................................... 9
Skipping Ahead or Back to Chapters............................................................................................ 9
Still Picture (PAUSE).................................................................................................................. 9
Repeat Viewing....................................................................................................................... 10
1-2 Convenient functions..................................................................................11
Displaying Scene Information..................................................................................................... 11
Changing Audio Soundtrack Language......................................................................................... 11
Clearing/Displaying Subtitles (A)................................................................................................. 11
Changing Subtitle Language (B)..................................................................................................12
Viewing From Another Angle................................................................................. .....................12
Mute the DVD Player................................................................................................................ 13
Using DVD Menu...................................................................................................................... 13
Using the Menu Function.........................................................................................................13
Chapter 2. Audio CD
2-1 Audio CD Playback..................................................................................... 14
Basic Playback........................................................................................................................ 14
Stopping Playback................................................................................................................... 14
Rapid Advance and Rapid Reverse.............................................................................................. 14
Skipping Ahead or Back to Tracks.............................................................................................. 15
Pause Playback....................................................................................................................... 15
2-2 Information [Audio CDs]................................................................................15
Displaying Track Information......................................................................................................15
Chapter 3. Special Functions
3-1 Playing Kodak Picture CDs........................................................................... 16
Basic Playback........................................................................................................................ 16
Slide Show.............................................................................................................................. 17
Rotate Mode.......................................................................................................................... 17
Program Mode........................................................................................................................ 18
Thumbnail Mode..................................................................................................................... 18
3-2 Playing JPEG picture CDs.............................................................................19
Basic Playback........................................................................................................................ 19
File Manager........................................................................................................................... 20
Playing Mode......................................................................................................................... 20
Program Mode........................................................................................................................ 21
Thumbnail Mode..................................................................................................................... 21
En 2
Table of Contents-continued
Chapter 4. Setup
4-1 Language Setup........................................................................................ 22
On Screen Display (OSD) Language Setting.................................................................................. 22
DVD MENU Language Setting..................................................................................................... 23
AUDIO Soundtrack Language Selection [DVD]............................................................................... 24
SUBTITLE Language Selection [DVD]............................................................................................ 25
4-2 Screen Setup............................................................................................26
TV Type Setting....................................................................................................................... 26
Screen Saver Setting................................................................................................................ 27
TV System Setting.................................................................................................................... 28
Video Out Setting....................................................................................................................29
4-3 AUDIO Setup............................................................................................ 31
Digital Out Setting.................................................................................................................. 31
Analog Out Setting...................................................................................................................32
4-4 Custom Setup........................................................................................... 33
Parental Control Setting [DVD]................................................................................................... 33
Password Setting [DVD]............................................................................................................ 34
Angle Mark Setting [DVD]......................................................................................................... 35
Default Setting........................................................................................................................ 36
4-5 LCD Setup............................................................................................... 37
Panel Setting......................................................................................................................... 37
Color Setting.......................................................................................................................... 37
Brightness Setting....................................................................................................................38
Panel Close Setting.................................................................................................................. 39
Chapter 5.For Your Reference
5-1 Troubleshooting....................................................................................... 40
5-2 Disc Handling and Maintenance.................................................................... 41
5-3 Definition of Terms................................................................................... 42
En 3
FCC and Safety Information
CAUTION:
This unit employs a laser. Due to possible eye injury, only qualified service personnel should remove the cover or attempt to service this device. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Since it is usual for DVD movies to be released at different times in different regions of the world, all players have region codes and disc can have an optional region code. If you load a disc of a different region code to your player, you will see the region code notice on the screen. The disc will not play, and should be unloaded.
(Possible region codes:)
There are 6 regions (also called “locals”). Each DVD player and disc will be played in one region ONLY. 1: Canada, U.S., U.S. Territories 2: Japan, Europe, South Africa, Middle East (including Egypt) 3: Southeast Asia, East Asia (including Hong Kong) 4: Australia, New Zealand, Pacific Islands, Central America, Mexico, South America, Caribbean 5: Former Soviet Union, Indian Subcontinent, Africa (also North Korea, Mongolia) 6: China
Never make or change connections with the power switched on.
CAUTION VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM
(WARNING LOCATION: INSIDE ON LASER COVERSHIELD)
For DVD Players with 525p, but not 625p, progressive scan output:
‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING YOUR TV SET COMPATIBILITY WITH THIS MODEL 525p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.’
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential Unpublished Works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved.
En 4
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a damp cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized-type plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lighting storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way; such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Outdoor use or wet location applications:
An apparatus that does not comply with the requirements in Appendix A# (Outdoor Use and Wet Location Apparatus) shall be marked or the instruction manual packed with the word “WARNING” and the following or equivalent: “To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
A Class II APPARATUS shall be permanently marked with the words “DOUBLE INSULATION” or “Double insulated” and “When servicing use only identical replacement parts.”
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
En 5
Precautions
Please read these precautions before operating this unit.

Power cord protection

To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please observe the following.
Hold the plug firmly when connecting or disconnecting the AC power cord.Keep the AC power cord away from heating appliances.Never put any heavy object on the AC power cord.Do not attempt to repair or reconstruct the AC power cord in any way.

Placement

Avoid placing the unit in areas of:
direct sunlight or heating radiators, or closed automobileshigh temperature (over 35much dust as the internal parts may be seriously damaged.

Non-use periods

When the unit is not being used, turn it off. When left unused for a long period of time, the unit should be unplugged from the household AC outlet.

No fingers or other objects inside

Touching internal parts of this unit is dangerous, and may cause serious damage to the unit. Do not attempt to
disassemble the unit.
Do not put any foreign object on the disc tray.
0
C) or high humidity (over 90%)

Keep away from water/magnet

Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious damage could
occur.
Never bring a magnet or magnetized object near the unit.

Stacking

Place the unit in a horizontal position, and do not place anything heavy on it.

Condensation

Moisture may form on the lens in the following conditions:
immediately after a heater has been turned onin a steamy or very humid roomwhen the unit is suddenly moved from a cold environment to a warm one
If moisture forms inside this unit, it may not operate properly. In this case, turn on the power and wait about one hour for the moisture to evaporate.

If there is noise interference on the TV while a broadcast is being received

Depending on the reception condition of the TV, interference may appear on the TV monitor while you watch a TV broadcast and the unit is left on. This is not a malfunction of the unit or the TV. To watch a TV broadcast, turn off the unit.
En 6
Selecting the type of disc for the type of TV connected
DVDs are recorded in PAL or NTSC formats. Please refer to the table below to find the appropriate format for your region.
Connecting to a multi-system TV
Connecting to a NTSC TV

Connecting to a PAL TV

En 7
1
1-1 DVD Playback
Preparation
Attach the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment, please perform the following:
Press on the power button of the TV set, and select “Video” as the TV input.Press on the power button of the stereo system if the player has been connected to one.
DVD
Push the AV OUT/IN slide switch to AV OUT.
Basic Playback
1 Press POWER on. 2 Press <OPEN> to open the disc cover. 3 Hold the edge of the disc to put it in the center with the printed side up.
Hold the disc without touching its surfaces, position it with the printed title side facing up, align it with the
guides, and place it in its proper position.
4 Close the disc cover.
Close the disc cover and the portable DVD player starts playback if the disc does not have any menus recorded
on it.
If the disc has one or more titles recorded on it, a menu screen will appear on the screen.
5 Press < / / / > or the number button(s) to select the preferred title.
<< NOTE: To select a title, input the number, i.e. 1 for chapter 1, 10 for chapter 10, and etc. >>
6 Press <PLAY/SEL.> .
The player now starts playing the selected item.
Stopping Playback and Returning to The Menu Screen (If a Menu Screen Is Available on The Disc)
Press <MENU>.
The portable DVD player stops playback and displays the menu screen.
After operation
When the portable DVD player is not in use, remove the disc and press POWER to turn off the player. Close the display panel.
<< NOTE >>
The disc continues to rotate while the menu is displayed even after the player has finished playing a particular
disc. When no further selections are to be played, be sure to press the <STOP> button to clear the menu
screen. If the disc is placed in upside down (and it is a single sided disc), the player will display “NO DISC”.
For your reference:
When “ ” appears while a button is being operated, it means that the corresponding operation is prohibited
by the player.
En 8
1-1 DVD Playback-continued
Stopping Playback
Press <STOP> once to prestop. Press <STOP> twice to stop.
Rapid Advance and Rapid Reverse
Press <F.BWD> or <F.FWD> during playback.
Normal playback is resumed when you press <PLAY/SEL.>.
The speed of advance ( x2, x4, x8, x16, x32) or reverse ( x2, x4, x8, x16,
x32) changes with each press of the <F.FWD> or <F.BWD> button.
Skipping Ahead or Back to Chapters
You can skip a specific chapter or track to playback.
Skipping Ahead
1
DVD
Press
Skips a chapter each time you press the button.
Skipping Back
Press
When you press the button once midway through a chapter, the portable DVD player returns to the beginning of the chapter being played back. The player skips a chapter each time you press the button.
<NEXT> during playback.
<PREVIOUS> during playback.
Still Picture (PAUSE)
Press <PAUSE> during playback.
The screen is paused.
To return to normal playback
Press <PLAY/SEL.>.
En 9
1
1-1 DVD Playback-continued
Repeat Viewing
Press <1/ALL REPEAT> during playback.
Each time you press the button, the disc will repeat a chapter or title. Press once: CHAPTER (Repeat chapter)
DVD
Press twice: TITLE (Repeat title)
Press three times: DISC (Repeat disc)
Press four times: off (Repeat cancelled)
To return to normal playback
Press <1/ALL REPEAT> several times until “ Off” appears on the screen.
<< NOTE >>
Repeat playback works only with discs for which the elapsed playing time appears on the player’s display during
playback.
Repeat playback may not work correctly with some DVDs.
En 10
1-2 Convenient functions
Displaying Scene Information
Displaying Scene Information
1
Press
Press <INFO.> a number of times, the title number, chapter number, and other information will show on the
screen.
Stop Displaying Scene Information
Press
<INFO.> during playback.
<INFO.> a number of times until the information disappears.
Changing Audio Soundtrack Language
You can change the audio language from the one selected at the initial settings to a different language. (This operation functions only with discs on which multiple audio soundtrack languages are recorded.)
1 Press <AUDIO> during playback.
2 Press <AUDIO> a number of times until the preferred language is selected.
For your reference:
When the preferred language is not selected even after pressing the button several times, it may indicate that
language is not available on the disc.
When you turn on or remove the disc, the portable DVD player will playback the language which is selected at
the initial setting. If you select a language which is not recorded on the disc, the portable DVD player will playback a prior language programmed on the disc.
DVD
Clearing/Displaying Subtitles (A)
If a disc provides subtitles, you can choose to hide or display them. (This operation works only with discs that provide subtitles.)
Press <SUBTITLE> during playback to display subtitles or hide them.
When you press <SUBTITLE> once, the first subtitle recorded on the disc will display. The rest of the
subtitles recorded will display in sequence as you press the button.
You may change to another language with this function, or you can clear the subtitle by pressing this button a
number of times until “SUBTITLE OFF” appears on the screen.
En 11
1
1-2 Convenient functions-continued
Changing Subtitle Language (B)
You can change the subtitle language with the initial settings. (This operation works only with discs on which multiple subtitle languages are included.)
DVD
1 Press <SUBTITLE> during playback.
When no subtitles are recorded, “ ” will display instead of the language number.
2 Press <SUBTITLE> a number of times until the preferred language is selected.
<< NOTE: In some cases, the subtitle language may not change immediately to the selected one. >>
For your reference:
When the preferred subtitle language is not selected even after pressing the button several times, it may
indicate that the language is not available on the disc.
When you turn on or remove the disc, the portable DVD player will playback the subtitle language which is
selected at the initial setting. If you select a subtitle language which is not recorded on the disc, the portable DVD player will playback a prior subtitle language programmed on the disc.
Viewing From Another Angle
Some DVD discs may contain scenes which have been shot simultaneously from a number of different angles. For these discs, the same scenes can be viewed from each of these different
angles using the <ANGLE> button. (The recorded angles vary depending on the disc pro­grammed.)
1 Press <ANGLE> during playback.
2 Press <ANGLE> a number of times until the preferred viewing angle is selected.
Press <ANGLE> button a number of times to change the viewing angle.
<< NOTE >>
The viewing angles are shown on the player’s display and you can select one from them for viewing.
En 12
1-2 Convenient functions-continued
Mute the DVD Player
Press <MUTE> button during playback.
When “MUTE” appears on the screen, the portable DVD player is mute. To resume sound, press the button until “MUTE OFF” appears on the screen.
Using DVD Menu
Some DVD discs have unique menu structures. For example, DVDs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language. Although the DVD menu’s contents and operation vary from disc to disc, the following explains basic operation when this feature is used.
1 Press <TITLE> in stop mode.
The DVD menu available on the disc now appears.
2 Press < / / / > to select the preferred item.
3 Press <PLAY/SEL.>.
You now enter to the selected item.
1
DVD
To enter other menu screen
Repeat steps 2 and 3.
To return to the previous menu screen
Press <TITLE>.
Using the MENU Function
1 Press <PLAY/SEL.>.
2 Press <MENU>.
A DVD chapter menu with brief broadcast of each paragraph now appears. You may see the introduction of each chapter and then decide which chapter to start.
3 Press < / / / > or number button(s) to select the preferred item.
<< Note: The menu details vary depending on discs recorded. >>
En 13
2
Audio CD
2-1 Audio CD Playback
Preparation
Attach the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment, please perform the following:
Press on the power button of the TV set, and select “Video” as the TV input.Press on the power button of the stereo system if the player has been connected to one.Push the AV OUT/IN SWITCH button to AV OUT.
Basic Playback
1 Press POWER on. 2 Press <OPEN> to open the disc cover. 3 Hold the edge of the disc to put it in the center with the printed side up.
Hold the disc without touching its surfaces, position it with the printed title side facing up, align it with the
guides, and place it in its proper position.
4 Close the disc cover.
For audio CDs without playback control:
The portable DVD player starts to playback.
For audio CDs provided with playback control:
A menu appears after a few seconds.
Stopping Playback
Press <STOP> once to prestop. Press <STOP> twice to stop.
Rapid Advance and Rapid Reverse
Press <F.BWD> or <F.FWD> during playback.
Normal playback is resumed when you press <PLAY/SEL.>.
The speed of advance ( x2, x4, x8, x16, x32) or reverse ( x2, x4, x8, x16,
x32) changes with each press of the <F.FWD> or <F.BWD> button.
En 14
2-1 Audio CD Playback-continued
Skipping Ahead or Back to Tracks
Skipping Ahead
2
Press
A track is skipped each time you press the button.
Skipping Back
Press
When you press the button once midway through a track, the portable DVD player returns to the beginning of the track being played. The player skips a track each time the button is pressed.
<NEXT> during playback.
<PREVIOUS> during playback.
Pause
Press <PAUSE> once during playback.
The player will pause playback.
To return to normal playback
Press <PLAY/SEL.>.
Audio CD
2-2 Information [Audio CDs]
Displaying Track Information
Displaying Track Information
Press
Press <INFO.> a number of times, the elapsed time, track number and other information will show on the
screen.
Stop Displaying Track Information
Press
<INFO.> during playback.
<INFO.> a number of times until the information disappears.
En 15
3
3-1 Playing Kodak Picture CDs
Basic Playback
You can play Kodak picture CDs for viewing on the screen.
Load a kodak picture CD.
After few seconds, the portable DVD player starts to play back the pictures in a slide show automatically.
OR You can press the number buttons corresponding to the order of the picture, then press
<PLAY/SEL.>.
Press <INFO.>, the current picture number and total picture numbers will show on the screen. Press the
number button corresponding to the order of the picture, then press <PLAY/SEL.>. The portable DVD
player will begin the slide show from the selected picture.
To pause slide show
Press <PAUSE>, the slide show will pause.
Special Functions
To stop slide show
Press <STOP>, then enter Thumbnail mode.
<<Note: Press <TITLE>, you can also enter Thumbnail mode.>>
To resume slide show
Press <PLAY/SEL.> again.
Mode switch
There are four modes while playing Kodak picture CD: “Thumbnail Mode”, “Slide show”, “Rotate Mode” and “Program Mode”.
1 Press <STOP> a number of times to stop and exit the present mode, then press
<RIGHT> button or <LEFT> button to select the preferred mode.
2 Press <PLAY/SEL.> to enter the selected mode.
En 16
3-1 Playing Kodak Picture CDs-continued
Slide Show
1 Press <NEXT> to view the next picture or <PREVIOUS> to view the previous
picture.
2 Press <RIGHT> button or <LEFT> button to rotate the picture.
Press <RIGHT> button to rotate right by 90 degrees.
Press <LEFT> button to rotate left by 90 degrees.
To pause slide show
Press <PAUSE>, the slide show will pause.
To stop slide show
Press <STOP>, then enter Thumbnail mode.
3
<<Note: Press <TITLE>, you can also enter Thumbnail mode.>>
To resume slide show
Press <PLAY/SEL.> again.
Rotate Mode
1 Press <NEXT> or <PREVIOUS> to select the preferred page, then press
< / / / > to select the preferred picture.
2 Press <PLAY/SEL.> to rotate the picture.
Every time you press
To stop Rotate mode
Press <STOP> to stop Rotate mode.
To reset the rotated pictures
Press <STOP> to stop Rotate mode and select “Reset” by pressing <RIGHT> button or
<PLAY/SEL.>, the picture is rotated right by 90 degrees.
Special Functions
<LEFT> button; then press
To exit Rotate mode
Press <STOP> to stop Rotate mode and select “Return” by pressing <RIGHT> button or
<LEFT> button; then press <PLAY/SEL.> to exit Rotate mode.
<PLAY/SEL.> to reset all rotated pictures.
En 17
3
3-1 Playing Kodak Picture CDs-continued
Program Mode
1
Press
<PLAY/SEL.>; the selected picture is marked by the yellow frame and add it in the program list.
To unmark the selected picture, press <PLAY/SEL.> again until the yellow frame is cancelled.
< <
/ /
/ /
/ /
<
/
< <
/ /
/
/ /
>>
/
> to choose the preferred picture, then press
/ /
>>
2 Repeat the above step to complete the program list.
3 Press <STOP> a number of times to back to menu bar and press <RIGHT>
button to select “Program list” and press <PLAY/SEL.>.
4 Press <STOP> to back to menu bar and press <RIGHT> button to select “
and press <PLAY/SEL.> to play the programmed files.
Special Functions
To delete the file from the program list
Press <RIGHT> button or <LEFT> button to select the file, then press <PLAY/SEL.> to delete the file from the program list.
To delete all files from the program list
Select “CLEAR ALL”, then press <PLAY/SEL.> to delete all files from the program list.
To exit the program list
Press <STOP> and select “Return” by pressing <RIGHT> button or <LEFT> button;
then press
To exit Program mode
Press <LEFT> button.
<PLAY/SEL.> to return to Program mode.
Thumbnail Mode
While in Thumbnail mode, there are 15 pictures per page for viewing.
1 Press < / / / > to select the picture in the thumbnail. If you want to view
the selected picture in its original size, press
When you view the picture in its original size, you can press <STOP> to view the pictures in the thumbnail.
<PLAY/SEL.>.
2 Press <NEXT> or <PREVIOUS> to view the next or previous thumbnail page.
To exit Thumbnail mode
Press <STOP> once to stop, and then press <STOP> a number of times to exit.
En 18
3-2 Playing JPEG picture CDs
Basic Playback
You can play JPEG pictures CDs for viewing on the screen.
Load a JPEG picture CD.
After few seconds, the portable DVD player starts to play back the pictures in a slide show automatically.
OR You can press the number button corresponding to the order of the picture, then press
<PLAY/SEL.>.
Press <INFO.>, the current picture number, total picture numbers and other information will show on the
screen. Press the number button corresponding to the order of the picture, then press <PLAY/SEL.>. The
portable DVD player will begin the slide show from the selected picture.
To pause slide show
Press <PAUSE>, the slide show will pause.
3
To stop slide show
Press <STOP>, then enter the File Manager.
To resume slide show
Press <PLAY/SEL.> again.
Mode switch
There are four modes while playing JPEG picture CD: “File Manager”, “Playing Mode”, “Program Mode” and “Thumbnail Mode”.
1 Press <STOP> to stop the present mode, and press <LEFT> button a number
of times to exit the present mode, then press <RIGHT> button or <LEFT>
button to select the preferred mode.
2 Press <PLAY/SEL.> to enter the selected mode.
Special Functions
En 19
3
3-2 Playing JPEG picture CDs-continued
File Manager
1 Under File Manager Menu, press < / / / > to choose the preferred picture,
then press
<PLAY/SEL.> to playback the picture.
2 Press <NEXT> to skip for the next six pictures or <PREVIOUS> to skip for the
previous six pictures.
To exit File Manager
Press <LEFT> a number of times to exit File Manager Menu.
Playing Mode
1 Press <NEXT> to view the next picture or <PREVIOUS> to view the previous
Special Functions
picture.
2 Press <RIGHT> button or <LEFT> button to rotate the picture.
Press <RIGHT> button to rotate right by 90 degrees.
Press <LEFT> button to rotate left by 90 degrees.
To pause playback
Press <PAUSE>.
To stop playback
Press <STOP>, then enter to the File Manager.
To resume playback
Press <PLAY/SEL.> again.
En 20
3-2 Playing JPEG picture CDs-continued
Program Mode
3
1
Press
<PLAY/SEL.>; the selected picture is marked by the yellow frame and add it in the program list.
To unmark the selected picture, press <PLAY/SEL.> again until the yellow frame is cancelled.
< <
/ /
/ /
/ /
<
/
< <
/ /
/
/ /
> >
/
> to choose the preferred picture, then press
/ /
> >
2 Repeat the above step to complete the program list.
3 Press <LEFT> button a number of times to back to menu bar and press
<RIGHT> button to select “Program list” and press <PLAY/SEL.>.
4 Press <LEFT> button to back to menu bar and press <RIGHT> button to
select “
To delete the file from the program list
Under program list, press <UP> button or <DOWN> button to select the file, then press
<PLAY/SEL.> to delete the file from the program list.
To delete all files from the program list
Select “CLEAR ALL”, then press <PLAY/SEL.> to delete all files from the program list.
To exit the program list
Press <LEFT> button to back to menu bar and select “Return” by pressing <RIGHT>
” and press <PLAY/SEL.> to play the programmed files.
Special Functions
button or <LEFT> button; then press
To exit Program mode
Press <LEFT> button a number of times.
<PLAY/SEL.> to return to Program mode.
Thumbnail Mode
While in Thumbnail mode, there are 15 pictures per page for viewing.
1 Press < / / / > to select the picture in the thumbnail. If you want to view
the selected picture in its original size, press
When you view the picture in its original size, you can press <STOP> to view the pictures in thumbnail.
<PLAY/SEL.>.
2 Press <NEXT> or <PREVIOUS> to view the next or previous thumbnail page.
To exit Thumbnail mode
Press <STOP> once to stop, and then press <STOP> a number of times to exit.
En 21
4
4-1 Language Setup
On Screen Display (OSD) Language Setting
Allows you to set various languages for the on screen display (OSD).
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Language Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “OSD”, and then press
<PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred language.
5 Press <PLAY/SEL.>.
Language Setup
OSD
Menu
Audio
Subtitle
English
French
German
Italian
Spanish
Setup
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
En 22
4-1 Language Setup-continued
DVD Menu Language Setting
You can select a preferred language that has been recorded on the disc menu.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Language Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Menu”, and then press
<PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred language.
5 Press <PLAY/SEL.>.
Language Setup
4
OSD
Menu
Audio
Subtitle
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press
<LEFT> button.
<SETUP> to exit or select EXIT from SETUP MENU screen.
English
Chinese
Japanese
French
German
Setup
En 23
4
4-1 Language Setup-continued
AUDIO Soundtrack Language Selection [DVD]
You can select a preferred soundtrack language that has been recoreded on DVD discs.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Language Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Audio”, and then press
<PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred language.
5 Press <PLAY/SEL.>.
ORIGINAL:
The top-priority language of each disc will always playback first.
Language Setup
English
Chinese
Japanese
French
German
Setup
OSD
Menu
Audio
Subtitle
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
For your reference:
If the language selected is not recorded on the disc, the portable DVD player will playback the top-
<LEFT> button.
priority language of the disc.
En 24
4-1 Language Setup-continued
SUBTITLE Language Selection [DVD]
You can select a preferred language that has been recorded on the DVD.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Language Setup”, and then
4
press
3 Press <UP> button / <DOWN> button to select “Subtitle”, and then press
<PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred language.
5 Press <PLAY/SEL.>.
<PLAY/SEL.>.
Language Setup
OSD
Menu
Audio
Subtitle
English
Chinese
Japanese
French
German
Setup
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
For your reference:
If the language selected is not recorded on the disc, the portable DVD player will playback the top-
<LEFT> button.
priority language of the disc.
En 25
4
4-2 Screen Setup
TV Type Setting
The kind of TV set (4:3 or 16:9) connected to the player and a wide-screen picture type for a 4:3 TV can be selected.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “TV Type”, and then press
<PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select a preferred TV display.
5 Press <PLAY/SEL.>.
Screen Setup
TV Type
Screen Saver
TV System
Video Output
Setup
: Move : Select SETUP: Quit
To finish the setup operation
Press
4:3 Pan Scan
Select 4:3 PS for a conventional size TV set. Video material formatted in the pan & scan style has the left and right edges trimmed.
<SETUP> to exit or select EXIT from SETUP MENU screen.
4:3 PS
4:3 LB
16:9
4:3 Letter Box
Select 4:3 LB for a conventional size TV set. Black bands appear at top and bottom of screen (letter-box style).
16:9 Wide Select 16:9 for a wide-screen TV set. Played in “FULL” size.
Setting the wide-screen TV to “FULL” mode is also necessary.Each screen shows an example when the video material for a wide-screen is
played.
En 26
4-2 Screen Setup-continued
Screen Saver Setting
This function will ONLY function when the player is stopped.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Screen Saver”, and then
press <PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select “On” or “Off ”.
5 Press <PLAY/SEL.>.
The waiting time of the screen saver is set to 10 minutes.
Screen Setup
4
TV Type
Screen Saver
TV System
Video Output
On
Off
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
Setup
En 27
4
4-2 Screen Setup-continued
TV System Setting
The player provides “PAL”, “NTSC” and “AUTO” settings for your selection. When connecting the portable DVD player to your TV, set the “TV SYSTEM” from the on-screen display to the format that is compatible with your TV’s system. Set “AUTO” if your system is a multi-TV system that supports both PAL and NTSC.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “TV System”, and then
press <PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the appropriate TV system for
your clearest view.
5 Press <PLAY/SEL.>.
Screen Setup
Setup
TV Type
Screen Saver
TV System
Video Output
NTSC
PAL
AUTO
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
En 28
4-2 Screen Setup-continued
Video Output Setting
Please choose the preferred video output supported by your equipment.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Screen Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Video Output”, and then
press <PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred video output
setting.
5 Press <PLAY/SEL.>.
Screen Setup
4
TV Type
Screen Saver
TV System
Video Output
S-Video
P-SCAN
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press <LEFT> button.
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
Setup
En 29
4
4-2 Screen Setup-continued
Video Output Setting-continued
If you choose “P-Scan”, the following will show on the screen as the reminder.
Screen Setup
TV Type
Screen Saver
TV System
Please make sure your
Video Output
TV support P-Scan Continue Press PLAY Stop Press STOP
4
: Move : Select SETUP: Quit
If your TV doesn’t support P-Scan feature, press
<<Troubleshooting>>
What if the screen turns black while operating...
Setup
Solution: Press
<Mode> to switch to “S-Video” mode.
S-Video
P-SCAN
<STOP>.
En 30
4-3 Audio Setup
Digital Out Setting
The portable DVD player provides three options, “SPDIF/PCM”, “SPDIF/RAW” and “Off” for the digital out setting.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Audio Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Digital Out”, and then
press <PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred digital out
setting.
5 Press <PLAY/SEL.>.
Audio Setup
4
Digital Out
Analog Out
SPDIF/PCM
SPDIF/RAW
Off
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
For your reference:
If you have a Dolby Digital 5.1 or DTS capable amplifier, you must set the audio output to SPDIF/RAW.
<LEFT> button.
If you have a 2-channel Dolby Digital amplifier, you must set the audio output to SPDIF/PCM.
Setup
En 31
4
4-3 Audio Setup-continued
Analog Out Setting
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Audio Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Analog Out”, and then
press <PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select the preferred analog out
setting.
5 Press <PLAY/SEL.>.
Audio Setup
Digital Out
Analog Out
2 Channel
Setup
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
En 32
4-4 Custom Setup
Parental Control Setting [DVD]
A built-in viewer rating setting enables you to lock the videos that you do not want children to view. For example, setting the rating limit to PG-13 will prevent the unit from playing the videos rated R, NC-17 or X unless the correct password is entered.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then
4
press
<PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Parental Ctrl”, and then
press <PLAY/SEL.>.
4 Enter a 4-digit password before selecting ratings and press <PLAY/SEL.>.
Factory pre-set password: 0000
You need to enter “0000” to set the rating for the first time when purchasing your DVD from the store.
5 Press <UP> button / <DOWN> button to select the preferred ratings.
6 Press <PLAY/SEL.>.
Custom Setup
Parental Ctrl
Password ...
Angle Mark
Default
1
2
3: PG
4: PG13
5
Setup
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
For your reference:
You can use the parental control lock ONLY with DVD discs featured with the parental lock
Please keep in mind that discs not encoded with rating lock protection will play regardless of rating
<LEFT> button.
function.
and content.
En 33
4
4-4 Custom Setup-continued
Password Setting [DVD]
You can change the password to the portable DVD player.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Password”, and then
press <PLAY/SEL.>.
4 Enter your old password and then press <PLAY/SEL.>.
Factory pre-set password: 0000
5 Enter your new password and then press <PLAY/SEL.>.
6 Re-enter your password to verify it and then press <PLAY/SEL.>.
Custom Setup
Setup
Parental Ctrl
Password ...
Angle Mark
Old: _ _ _ _
Default
New: _ _ _ _
Verify: _ _ _ _
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
En 34
4-4 Custom Setup-continued
Angle Mark Setting [DVD]
You can choose to display or hide the angle mark “ ” on the screen.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then
4
press
3 Press <UP> button / <DOWN> button to select “Angle Mark”, and then
press <PLAY/SEL.>.
4 Press <UP> button / <DOWN> button to select “On” or “Off”, and then
press <PLAY/SEL.>.
<< NOTE >>
Pressing the <ANGLE> button will change camera angles for movies that support this feature regardless
of whether the ANGLE MARK feature is “On” or “Off”.
<PLAY/SEL.>.
Custom Setup
Parental Ctrl
Password ...
Angle Mark
Default
On
Off
Setup
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
En 35
4
4-4 Custom Setup-continued
Default Setting
You may re-set the previous settings in CUSTOM SETUP to the default setting.
1 Press <SETUP> in the stop mode.
2 Press <UP> button / <DOWN> button to select “Custom Setup”, and then
press <PLAY/SEL.>.
3 Press <UP> button / <DOWN> button to select “Default”, and then
press <PLAY/SEL.>.
4 Press <RIGHT> button to select “Read”, and then press <PLAY/SEL.>.
<< EXCEPTION>>
The viewer rating and the password setting will NOT be changed even though you re-set to the default setting.
Custom Setup
Read
Setup
Parental Ctrl
Password ...
Angle Mark
Default
: Move : Select SETUP: Quit
To return to the SETUP MENU screen
Press
To finish the setup operation
Press <SETUP> to exit or select EXIT from SETUP MENU screen.
<LEFT> button.
En 36
4-5 LCD Setup
Panel Setting
The portable DVD player provides three options for panel adjustment: “Normal”, “16:9” or “4:3”.
1 Press <LCD>, the LCD setting information shows on the screen.
2 Press <LCD> a number of times to select “Panel”.
3 Press <LEFT> button or <RIGHT> button to choose the preferred panel
setting. The panel will change to the selected setting.
PP
anel:anel:
P
anel:
PP
anel:anel:
Panel: 16:9Panel: 16:9
Panel: 16:9
Panel: 16:9Panel: 16:9
Panel: 4:3Panel: 4:3
Panel: 4:3
Panel: 4:3Panel: 4:3
To finish setup operation
Press
<LCD> again until the LCD setting information disappears.
Nor Nor
Nor
Nor Nor
malmal
mal
malmal
4
Color Setting
You can adjust the color of video with this setting to a soothing view for your eyes.
1 Press <LCD>, the LCD setting information shows on the screen.
2 Press <LCD> a number of times to select “Color”.
3 Press <LEFT> button or <RIGHT> button to choose the preferred color
setting, and then the panel will change to the selected setting.
ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor
To finish the setup operation
Press
<LCD> again until the LCD setting information disappears.
::
+3 +3
:
+3
::
+3 +3
::
+2 +2
:
+2
::
+2 +2
::
+1 +1
:
+1
::
+1 +1
::
0 0
:
0
::
0 0
::
-1 -1
:
-1
::
-1 -1
::
-2 -2
:
-2
::
-2 -2
::
-3 -3
:
-3
::
-3 -3
Setup
En 37
4
4-5 LCD Setup-continued
Brightness Setting
1 Press <LCD>, the LCD setting information shows on the screen.
2 Press <LCD> a number of times to select “Bright”.
3 Press <LEFT> button or <RIGHT> button to choose the preferred bright
setting, and then the panel will change to the selected setting.
Bright: +3Bright: +3
Bright: +3
Bright: +3Bright: +3
Bright: +2Bright: +2
Bright: +2
Bright: +2Bright: +2 Bright: +1Bright: +1
Bright: +1
Bright: +1Bright: +1 Bright: 0Bright: 0
Bright: 0
Bright: 0Bright: 0 Bright: -1Bright: -1
Bright: -1
Bright: -1Bright: -1 Bright: -2Bright: -2
Bright: -2
Bright: -2Bright: -2 Bright: -3Bright: -3
Bright: -3
Bright: -3Bright: -3
To finish the setup operation
Press
<LCD> again until the LCD setting information disappears.
Setup
En 38
4-5 LCD Setup-continued
Panel Close Setting
1 Press <LCD>, the LCD setting information shows on the screen.
2 Press <LCD> a number of times to select “Close”.
3 Press <LEFT> button or <RIGHT> button to choose the preferred panel
setting, and then the panel will change to the selected setting.
Close: OffClose: Off
Close: Off
Close: OffClose: Off
Close: OnClose: On
Close: On
Close: OnClose: On
<< NOTE: When you choose “Close” in the panel setting, the LCD turns off and the power indicator will blink in yellow light.>>
To finish the setup operation
Press <LCD> again until the LCD setting information disappears.
4
Setup
En 39
5
5-1 Troubleshooting
Before requesting service for your portable DVD player, check the chart below for a possible cause of the problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper operation.
SYMPTOM (COMMON) REMEDY
No power. · Insert the power plug securely into the power outlet.
The player does not start playback · Condensation may have formed. Try again in 1 to 2 hours to ensure that the when PLAY is pressed. condensation has evaporated.
The player starts playback but stops · The disc may be dirty and may require cleaning. immediately. · Ensure that the disc is installed with the label side up. No picture. · Ensure that the equipment is connected properly.
No sound. · Ensure that the equipment is connected properly.
Distorted sound. · Ensure that the input settings for the TV and stereo system are proper.
No audio at Digital Output. · Check the digital connections.
capabilities. Distorted picture. · Check the disc for fingerprints and clean it with a soft cloth, wiping it from center
Completely distorted picture or no color · The disc format is not compatible to the TV-set used (PAL/NTSC). in picture. Picture is distorted during rapid · The picture will be somewhat distorted at times: this is normal. advance or rapid reverse.
No rapid advance (or rapid reverse) · Some discs may have sections which prohibit rapid advance (or rapid reverse). playback.
For Your Reference
No 4:3 (16:9) picture. · Choose the correct setup “TV DISPLAY” item which matches the TV set used. Picture is distorted during rapid · The picture will be somewhat distorted at times: this is normal. advance or rapid reverse. No operations perform with the · Check the batteries are installed with the correct polarity (+ and –). remote control. · The batteries are depleted: replace them with new ones.
No key operation (by the DVD player · Turn the unit off and then back on. Alternatively, turn off the unit, disconnect the AC power and/or the remote control) is cord and then re-connect it. (The player may not be operating properly due to
effective. lightning, static electricity or some other external factor.) PLAY does not start playback even · This may be a result of the parental lock function that has been set. when title is selected. Confirm the “PARENTAL” setup. Audio soundtrack and/or subtitle · If the audio soundtrack and/or subtitle language does not exist on the disc, the language is not the one selected language selected at the initial settings will not be seen/heard. at the initial settings. No subtitles. · Subtitles appear only with discs that contain them.
Alternative audio soundtrack · An alternative language can not be selected may result of no more than one language (or subtitle) languages cannot be selected. available. Angle cannot change. · This function depends on software availability. Even if a disc has a number of angles recorded, these angles may be recorded for specific scenes only.
· Check if the ON/OFF button on the right of the player is set to on.
· Check if no power at the AC outlet may be the fault by plugging in another appliance for a test.
· Ensure that the disc format is supported by your DVD player.
· Check if the disc is defective by trying another disc.
· Check the region (local) code.
· Ensure that the input setting for the TV is “Video”.
· Check if external equipment is on.
· Select the same channel and source on the TV as on the player.
· Check if the LCD is on.
· If using a HiFi amplifier, try another sound source.
· Check the Audio Output Setting menu to make sure that Analog Output is selected.
· Check the Volume Adjustment.
· No sound is heard during still picture (pause).
· Check the settings menu to make sure that the digital output is set to on.
· Check if the audio format of the selected audio language matches your receiver
to edge.
· Sometimes a small amount of picture distortion may appear. This is not a malfunction.
· Point the remote control unit at the remote control signal sensor and operate.
· Operate the remote control unit at a distance but no more than 6 meters from the remote control signal sensor.
· Remove obstacles between the remote control unit and remote control signal sensor.
· Subtitles are hidden from the TV screen. Press SUBTITLE to display the subtitles.
En 40
5-2 Disc Handling and Maintenance
Handling Precautions
Hold the disc by the edges so the surface will not be soiled with fingerprints. (A)
Fingerprints, dirt and scratches can cause skipping and distortion.
Do not write on the label side with a ball-point pen or other writing utensils that can leave indentations or
scratch the surface of the disc.
Do not use record cleaning sprays, benzene, thinner, static electricity prevention liquids or any other solvent.Be careful not to drop or bend the disc.Do not install more than 1 disc on the disc tray.Do not try to close the disc cover when the disc is not installed properly.Be sure to store the disc in its exclusive case when not in use.
If the surface is soiled (B)
Wipe gently with a soft, damp (water only) cloth. When wiping discs, always move the cloth from the center hole toward the outer edge. (If you wipe the discs using a circular motion, circular scratches are likely to occur, which will cause noise.)
(A) (B)
5
If the disc is brought from a cold to a warm environment, moisture may form on the disc
Wipe this moisture off with a soft, dry, lint-free cloth before using the disc.
Improper disc storage
You can damage discs if you store them in the following places:
Areas exposed to direct sunlightHumid or dusty areasAreas directly exposed to a heat outlet or heating appliance
Disc which cannot be played with this player
CD-ROM (Application Program)CVDCD-GDVD with a Locale No. other than that shown on the DVD unit’s Region Code Label on the rear panel
Maintenance
Be sure to turn the unit off and disconnect the AC power cord before performing maintenance the unit.Wipe this unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has been
dipped in a weak soap-and-water solution and wrung out thoroughly, and then wipe again with a dry cloth.
Never use alcohol, benzene, thinner, cleaning fluid or other chemicals. Do not use compressed air to remove
dust.
For Your Reference
En 41
5
5-3 Definition of Terms
Angle
Recorded onto some DVD discs are scenes which have been simultaneously shot from a number of differ­ent angles (the same scene is shot from the front, from the left side, from the right side, etc.). With such discs, the ANGLE button can be used to view the scene from different angles.
Chapter Number
These numbers are recorded on DVD discs. A title is subdivided into many sections, each of which is numbered, and specific parts of video presentations can be searched quickly using these numbers.
DVD
These refer to a high-density optical disc on which high-quality pictures and sound have been recorded by means of digital signals. Incorporating a new video compression technology (MPEG II) and high-density recording technology, DVD enables aesthetically pleasing full-motion video to be recorded over long periods of time (for instance, a whole movie can be recorded). DVD has a structure consisting of two 0.6 mm thin discs which are adhered to each other. Since the thinner the disc, the higher the density at which the information can be recorded, a DVD disc has a greater capacity than a single 1.2 mm thick disc. Since the two thin discs are adhered to each other, there is the potential to achieve double-sided play sometime in the future for even longer duration play.
Subtitles
These are the printed lines appearing at the bottom of the screen which translate or transcribe the dialogue. They are recorded on DVD discs.
Time Digit
This indicates the play time which has elapsed from the start of a disc or a title. It can be used to find a specific scene quickly. (It may not work with some discs.)
Title Number
These numbers are recorded on DVD discs. When a disc contains two or more movies, these movies are numbered as title 1, title 2, etc.
Track Number
For Your Reference
These numbers are assigned to the tracks which are recorded on audio CDs. They enable specific tracks to be located quickly.
En 42
Reproductor DVD portátil – Manual del usuario
Ajustes iniciales
1. Pulse el botón <SETUP>.
2. En pantalla aparece el menú CONFIGURACIÓN.
Configuración idioma
OSD
Menú
Audio
Subtítulo
: Mover : Seleccionar SETUP: Salir
3. Pulse las teclas <ARRIBA> <ABAJO> <IZDA.> <DCHA.> para seleccionar la opción deseada.
Español
4. Pulse el botón <PLAY/SEL.>.
Para los ajustes:
Repita el procedimiento descrito arriba y véanse las instrucciones del OSD para efectuar los ajustes siguientes.
Configuración idioma
OSD
Menú
Audio
Subtítulo
: Mover : SeleccionarSETUP: Salir
Configuración audio
Salida digital
Salida analógica
Configuración pantalla
Tipo de TV
Protector de pantalla
Sistema TV
Salida de vídeo
: Mover : SeleccionarSETUP: Salir
Configuración personalizada
Control menores
Contraseña
Marca perspectiva
Predeterminado
: Mover : Seleccionar SETUP: Salir
: Mover : SeleccionarSETUP: Salir
43
Esquema del menú Configuración
Idioma (Las opciones de idioma sólo se dan como referencia. Para la
Español
información adecuada, véase el reproductor DVD portátil.)
OSD Inglés
Francés Alemán Italiano Español Portugués
Menú Inglés
Chino Japonés Francés Alemán Italiano Español Portugués ... Otros
Audio Inglés
Chino Japonés Francés Alemán Italiano Español Portugués ... Otros
Subtítulos Inglés
Chino Japonés Francés Alemán Italiano Español Portugués ... Otros Desactivado
44
Esquema del menú Configuración - continuación
Pantalla Tipo de TV 4:3 PS
4:3 LB 16:9
Protector de pantalla Activado
10 minutos)
Desactivado
Sistema TV NTSC
PAL AUTO
Salida de vídeo S-Vídeo
BARRIDO PROGRESIVO (véase figura 1-1)
Audio Salida digital SPDIF/PCM
SPDIF/RAW Desactivado
Salida analógica 2 canales
Personalizada Control menores (Antes de poder cambiar el nivel, debe escribir
una contraseña de 4 dígitos. Contraseña predeterminada: 0000)
1.
2.
3. PG
4. PG13
5.
6. R
7. NC-17
8.
Contraseña Indique la contraseña (Contraseña
predeterminada: 0000) Indique la NUEVA contraseña Indique la contraseña otra vez
Marca perspectiva Activado
Desactivado
Predeterminado Lectura
(Tiempo de espera para el protector de pantalla:
(ver la NOTA siguiente)
(ver la NOTA siguiente)
(ver la NOTA siguiente)
(ver la NOTA siguiente)
Español
NOTA:
1. PG: se recomienda el acompañamiento por parte de los padres.
2. PG-13: el contenido no es apto para menores de 13 años.
3. R: acompañamiento de los padres – restringido; se recomienda que los padres no dejen que los niños menores de 17 años vean el contenido o que éstos al menos sean supervisados por los padres o una persona adulta.
4. NC-17: No apto para menores de 17 años.
45
Esquema del menú Configuración - continuación
FIGURA 1-1
Configuración pantalla
Español
Si selecciona la opción “Barrido progresivo”, los datos anteriores se mostrarán en pantalla como recordatorio. Si su televisor admite el barrido progresivo,
pulse
Tipo de TV Protector de pantalla
Asegúrese de que su televisor admite el barrido progresivo
Continuar Pulse el botón PLAY. Detener Pulse el botón STOP.
4
S-Vídeo BARRIDO PROGRESIVO
: Mover : Seleccionar SETUP: Salir
<PLA<PLA
<PLA
<PLA<PLA
<<Resolución de problemas>> Si desaparece la imagen durante la operación... Solución: Pulse el botón <MODE> para cambiar al modo de “S-Video”.
Y/SEL.>Y/SEL.>
Y/SEL.>. De lo contrario, pulse
Y/SEL.>Y/SEL.>
<ST<ST
<ST
<ST<ST
OP>OP>
OP>.
OP>OP>
46
Preparación
Conecte el reproductor DVD portátil a una toma eléctrica y conéctelo a los auriculares u otros equipos externos. Si lo conecta a equipos externos:
z Encienda su televisor y seleccione “Vídeo” como entrada de señal de TV. z Encienda su sistema de alta fidelidad si el reproductor de DVD está conectado a un
sistema alta fidelidad.
z Coloque el conmutador AV OUT/IN en la posición AV OUT.
Reproducción básica
Español
1.1.
1. Pulse el botón
1.1.
2.2.
2. Para abrir la bandeja, pulse el botón
2.2.
3.3.
3. Coja el disco por el borde y colóquelo con cuidado en la bandeja con la
3.3.
<POWER><POWER>
<POWER>.
<POWER><POWER>
<OPEN><OPEN>
<OPEN>.
<OPEN><OPEN>
cara impresa hacia arriba.
4.4.
4. Cierre la tapa de discos.
4.4.
z Cierre la bandeja de disco. El reproductor de DVD inicia la reproducción si el
disco no tiene ningún menú grabado en él.
z Si el disco tiene uno o más títulos grabados en él, aparecerá un menú en la
pantalla.
5.5.
5. Pulse
5.5.
<ARRIB<ARRIB
<ARRIB
<ARRIB<ARRIB
A> <ABA> <AB
A> <AB
A> <ABA> <AB
AJO> <IZDAJO> <IZD
AJO> <IZD
AJO> <IZDAJO> <IZD
A.> <DCHA.>A.> <DCHA.>
A.> <DCHA.> o las teclas
A.> <DCHA.>A.> <DCHA.>
numéricas para seleccionar su título favorito.
Nota: Para seleccionar un título, teclee el número, p.ej. 1 para el capítulo
1, 10 para el capítulo 10, etc.
6.6.
6. Pulse el botón
6.6.
El reproductor DVD portátil inicia ahora la reproducción del elemento seleccionado.
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
Detener la reproducción
<ST<ST
Pulse
<ST<ST
OP>OP>
<ST
OP> dos veces para detenerla definitivamente.
<ST<ST
OP>OP>
OP>OP>
<ST
OP> una vez para detener la reproducción temporalmente. Pulse
<ST<ST
OP>OP>
Avance y Rebobinado rápido
<F<F
Pulse el botón
z La reproducción normal se reanudará cuando pulse el botón <PLAY/SEL.>.
z La velocidad de avance o rebobinado rápido cambia cada vez que se pulsa el botón
<F.BWD> o <F.FWD>.
.BWD>.BWD>
<F
.BWD> o
<F<F
.BWD>.BWD>
<F<F
.FWD>.FWD>
<F
.FWD> durante la reproducción.
<F<F
.FWD>.FWD>
47
Saltar capítulos (hacia adelante o hacia atrás)
Saltar hacia adelante
Pulse el botón
Salta un capítulo cada vez que pulsa el botón.
Español
Saltar hacia atrás
<SIGUIENTE><SIGUIENTE>
<SIGUIENTE> durante la reproducción.
<SIGUIENTE><SIGUIENTE>
Pulse el botón
Salta un capítulo cada vez que pulsa el botón.
<ANTERIOR> <ANTERIOR>
<ANTERIOR> durante la reproducción.
<ANTERIOR> <ANTERIOR>
PAUSA
<P <P
AA
Pulse una vez el botón
La pantalla se detiene en modo de pausa.
Para reanudar la reproducción normal
Pulse el botón <PLAY/SEL.>.
USE>USE>
<P
A
USE> durante la reproducción.
<P <P
AA
USE>USE>
Repetir la reproducción
Pulse el botón
Cada vez que presiona el botón, el disco repite un capítulo o un título. Si lo pulsa 1 vez: CAPÍTULO (Repetición capítulo) Si lo pulsa 2 veces: TÍTULO (Repetición título) Si lo pulsa 3 veces: DISCO (Repetición disco) Si lo pulsa 4 veces: apagada (Repetición apagada)
Para reanudar la reproducción normal
Pulse el botón <1/ALL REPEAT> varias veces hasta que aparezca la indicación “ apagada”.
<1/ALL REPEA<1/ALL REPEA
<1/ALL REPEA
<1/ALL REPEA<1/ALL REPEA
T>T>
T> durante la reproducción.
T>T>
48
Visualización en pantalla de la información sobre la escena
Pulse el botón título, número de capítulo y otros datos en pantalla.
Para dejar de mostrar la información sobre la escena
Pulse <INFO.> repetidamente hasta que desaparezca la información.
<INFO.><INFO.>
<INFO.> varias veces hasta que aparezcan el número de
<INFO.><INFO.>
Seleccionar el idioma de la pista de audio
Puede cambiar el idioma de la pista de audio del disco si dicha opción está disponible en su disco. Para seleccionar el idioma:
<A<A
1.1.
1. Pulse el botón
1.1.
2.2.
2. Pulse varias veces el botón
2.2.
esté seleccionado.
UDIO>UDIO>
<A
UDIO> durante la reproducción.
<A<A
UDIO>UDIO>
<A<A
UDIO> UDIO>
<A
UDIO> hasta que el idioma favorito
<A<A
UDIO> UDIO>
Español
Nota: Si después de haber pulsado varias veces el botón, el idioma no
aparece todavía, puede que no esté disponible en el disco.
Seleccionar el idioma para subtítulos
Puede cambiar el idioma de los subtítulos si dicha opción está disponible en su disco. Para seleccionar el idioma:
1.1.
1. Pulse el botón
1.1.
2.2.
2. Pulse varias veces el botón
2.2.
favorito esté seleccionado.
Nota: Si no queda seleccionado el idioma deseado, es posible que éste no
esté disponible en el disco.
<SUBTITLE><SUBTITLE>
<SUBTITLE> durante la reproducción.
<SUBTITLE><SUBTITLE>
<SUBTITLE> <SUBTITLE>
<SUBTITLE> hasta que el idioma
<SUBTITLE> <SUBTITLE>
49
Seleccionar ángulos de perspectiva
Con ciertos discos, se pueden visualizar las mismas escenas desde puntos de vista diferentes.
1.1.
1. Pulse el botón
1.1.
<ANGLE><ANGLE>
<ANGLE> durante la reproducción.
<ANGLE><ANGLE>
2.2.
2. Pulse varias veces el botón
2.2.
Español
Función de silencio
Pulse el botón
Para restablecer el sonido
Pulse de nuevo el botón <MUTE> hasta que aparezca en pantalla el mensaje “Silencio: No”.
<ANGLE><ANGLE>
<ANGLE> hasta que la perspectiva
<ANGLE><ANGLE>
deseada esté seleccionada.
Nota: Esta función sólo está disponible en los discos que disponen de
varios ángulos grabados. Si la función no está disponible, aparece el icono de error “ ”.
<MUTE><MUTE>
<MUTE> durante la reproducción.
<MUTE><MUTE>
Nota: Cuando en pantalla aparezca el mensaje “Silencio”, el reproductor
DVD portátil no emite ningún sonido.
Ajustes del panel LCD
Este reproductor DVD portátil permite tres ajustes para el panel de visualización: “Normal”, “16:9” ó “4:3”.
1.1.
1. Pulse el botón
1.1.
ajustes LCD.
2.2.
2. Pulse el botón
2.2.
“Panel”.
3.3.
3. Pulse los botones
3.3.
panel deseado.
PP
anel:anel:
P
anel:
PP
anel:anel:
Panel: 16:9Panel: 16:9
Panel: 16:9
Panel: 16:9Panel: 16:9
Panel: 4:3Panel: 4:3
Panel: 4:3
Panel: 4:3Panel: 4:3
Salir de las operaciones de configuración
Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.
Nor Nor
Nor
Nor Nor
<LCD><LCD>
<LCD>. Se mostrará la información sobre los
<LCD><LCD>
<LCD><LCD>
<LCD> varias veces para seleccionar la opción
<LCD><LCD>
malmal
mal
malmal
<IZD<IZD
<IZD
<IZD<IZD
A.>A.>
A.> o
A.>A.>
<DCHA.><DCHA.>
<DCHA.> para seleccionar el ajuste de
<DCHA.><DCHA.>
50
Ajustes de color del LCD
Puede ajustar el color de vídeo para obtener una representación más agradable para sus ojos.
1.1.
1. Pulse el botón
1.1.
<LCD><LCD>
<LCD>. Se mostrará la información sobre los
<LCD><LCD>
ajustes LCD.
2.2.
2. Pulse el botón
2.2.
3.3.
3. Pulse los botones
3.3.
<LCD><LCD>
<LCD> varias veces para seleccionar la opción “Color”.
<LCD><LCD>
<IZD<IZD
<IZD
<IZD<IZD
A.>A.>
A.> o
A.>A.>
<DCHA.><DCHA.>
<DCHA.> para seleccionar el ajuste de
<DCHA.><DCHA.>
color deseado.
ColorColor
Color
ColorColor
ColorColor
Color
ColorColor
ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor
Salir de las operaciones de configuración
Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.
::
+3 +3
:
+3
::
+3 +3
::
+2 +2
:
+2
::
+2 +2
::
+1 +1
:
+1
::
+1 +1
::
0 0
:
0
::
0 0
::
-1 -1
:
-1
::
-1 -1
::
-2 -2
:
-2
::
-2 -2
::
-3 -3
:
-3
::
-3 -3
Español
Ajustes de brillo del LCD
Puede aumentar o reducir el brillo de la imagen de vídeo manualmente.
1.1.
1. Pulse el botón
1.1.
ajustes LCD.
2.2.
2. Pulse el botón
2.2.
(Brillo).
3.3.
3. Pulse los botones
3.3.
brillo deseado.
Bright: +3Bright: +3
Bright: +3
Bright: +3Bright: +3 Bright: +2Bright: +2
Bright: +2
Bright: +2Bright: +2 Bright: +1Bright: +1
Bright: +1
Bright: +1Bright: +1 Bright: 0Bright: 0
Bright: 0
Bright: 0Bright: 0 Bright: -1Bright: -1
Bright: -1
Bright: -1Bright: -1 Bright: -2Bright: -2
Bright: -2
Bright: -2Bright: -2 Bright: -3Bright: -3
Bright: -3
Bright: -3Bright: -3
<LCD><LCD>
<LCD>. Se mostrará la información sobre los
<LCD><LCD>
<LCD><LCD>
<LCD> varias veces para seleccionar la opción “Bright”
<LCD><LCD>
<IZD<IZD
<IZD
<IZD<IZD
A.>A.>
A.> o
A.>A.>
<DCHA.><DCHA.>
<DCHA.> para seleccionar el ajuste de
<DCHA.><DCHA.>
Salir de las operaciones de configuración
Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.
51
Ajustes de cierre del panel LCD
1.1.
1. Pulse el botón
1.1.
2.2.
2. Pulse el botón
2.2.
Español
3.3.
3. Pulse los botones
3.3.
Salir de las operaciones de configuración
Pulse el botón <LCD> nuevamente hasta que la información sobre los ajustes LCD desaparezca.
ajustes LCD.
“Close” (Cerrar).
panel deseado.
Close: OffClose: Off
Close: Off
Close: OffClose: Off
Close: OnClose: On
Close: On
Close: OnClose: On
<LCD><LCD>
<LCD>. Se mostrará la información sobre los
<LCD><LCD>
<LCD><LCD>
<LCD> varias veces para seleccionar la opción
<LCD><LCD>
<IZD<IZD
<IZD
<IZD<IZD
A.>A.>
A.> o
A.>A.>
<DCHA.><DCHA.>
<DCHA.> para seleccionar el ajuste de
<DCHA.><DCHA.>
Reproducción de CDs de imágenes de Kodak y CDs de imágenes JPEG
Puede reproducir CDs de imágenes de Kodak o imágenes JPEG para visualizarlas en pantalla.
Inserte un CD de imágenes Kodak o JPEG. Al cabo de unos instantes, automáticamente se iniciará una representación de diapositivas del contenido del CD. O
Pulse los botones numéricos correspondientes al número de la imagen y pulse
<PLA<PLA
<PLA
<PLA<PLA
Para detener la reproducción temporalmente/completamente
Pulse <PAUSE> para detener la reproducción temporalmente; pulse <STOP> para detenerla por completo.
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
52
Programación
En el modo de programación
En el modo de programación puede programar archivos de imagen o MP3.
1.1.
1. Pulse los botones
1.1.
<ARRIB<ARRIB
<ARRIB
<ARRIB<ARRIB
A> <ABA> <AB
A> <AB
A> <ABA> <AB
AJO> <IZDAJO> <IZD
AJO> <IZD
AJO> <IZDAJO> <IZD
A.> <DCHA.>A.> <DCHA.>
A.> <DCHA.> para
A.> <DCHA.>A.> <DCHA.>
seleccionar el archivo deseado y pulse
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>; el archivo
Y/SEL.>Y/SEL.>
seleccionado queda enmarcado en un recuadro amarillo y es añadido a la lista de programación.
2.2.
2. Repita los pasos anteriores para terminar de definir el contenido de la
2.2.
lista de programación.
3.3.
3. Pulse el botón
3.3. <DCHA.><DCHA.>
<DCHA.> para seleccionar “Lista de programación” y luego pulse
<DCHA.><DCHA.> <PLA<PLA
<PLA
<PLA<PLA
4.4.
4. Pulse el botón
4.4. <DCHA.><DCHA.>
<DCHA.> para seleccionar “
<DCHA.><DCHA.>
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
<IZD<IZD
<IZD
<IZD<IZD
<IZD<IZD
<IZD
<IZD<IZD
A.>A.>
A.> para regresar a la barra de menú, pulse
A.>A.>
A.>A.>
A.> para regresar a la barra de menú, pulse
A.>A.>
” y luego pulse
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.> para
Y/SEL.>Y/SEL.>
reproducir los archivos programados.
Para borrar un archivo/todos los archivos de la lista de programación
Pulse los botones <ARRIBA> o <ABAJO> para seleccionar el archivo y pulse <PLAY/SEL.> para borrarlo de la lista.
Para borrar todos los archivos de la lista de programación
Español
Seleccione “BORRAR TODO” y pulse <PLAY/SEL.> para borrar todos los archivos de la lista de programación.
53
Manuel de l’utilisateur du lecteur DVD portable
Paramètres initiaux
1. Appuyez sur le bouton <SETUP>.
2. L’écran MENU CONFIG. s’affiche.
Français
3. Utilisez le bouton <HAUT> <BAS> <GAUCHE> <DROITE> pour
Configuration de la langue
OSD
Menu
Audio
Sous-titre
: Dépl. Sél.: SETUP : Quitter
sélectionner l’option désirée.
4. Appuyez sur le bouton
<PLAY/SEL.>.
Pour les paramétrages :
Répétez la procédure décrite ci-dessus et suivez les instructions OSD pour effectuer le paramétrage ci-après.
Configuration de la langue
OSD
Menu
Audio
Sous-titre
: Dépl. Sél.: SETUP : Quitter
Configuration audio
Sortie numérique
Sortie analogique
Configuration écran
Type TV
Écran de veille
Système TV
Sortie vidéo
: Dépl. Sél.: SETUP : Quitter
Configuration personnalisée
Contrôle parental
Mot de passe
Visualisation angles
Par défaut
: Dépl. Sél.: SETUP : Quitter
: Dépl. Sél.: SETUP : Quitter
54
SCHÉMA DU MENU DE CONFIGURATION
Langue (Les options de langues servent uniquement de référence.
Veuillez consulter votre lecteur DVD portable pour les informations correctes).
O.S.D. Anglais
Français Allemand Italien Espagnol Portugais
Menu Anglais
Chinois Japonais Français Allemand Italien Espagnol Portugais ... Autres
Audio Anglais
Chinois Japonais Français Allemand Italien Espagnol Portugais ... Autres
Sous-titres Anglais
Chinois Japonais Français Allemand Italien Espagnol Portugais ... Autres Off
Français
55
SCHÉMA DU MENU DE CONFIGURATION - suite
Écran Type TV 4:3 PS
Français
Audio Sortie numérique SPDIF/PCM
Personnalisé Contrôle parental (Avant de sélectionner les niveaux, tapez un mot
4:3 LB 16:9
Écran de veille On
(temps d’attente de l’écran de veille : 10 minutes).
Off
Système TV NTSC
PAL AUTO
Sortie vidéo S-Vidéo
P-SCAN (voir figure 1-1)
SPDIF/RAW Off
Sortie analogique Canal 2
de passe à 4 chiffres. Mot de passe par défaut : 0000)
1.
2.
3. PG
4. PG13
(reportez-vous à la REMARQUE ci-après)
(reportez-vous à la REMARQUE ci-après)
5.
(reportez-vous à la REMARQUE ci-après)
6. R
7. NC-17
(reportez-vous à la REMARQUE ci-après)
8.
Mot de passe Indiquez un mot de passe (mot de passe par
défaut : 0000) Indiquez un NOUVEAU mot de passe Indiquez le mot de passe à nouveau
Visualisation angles On
Off
Par défaut Lecture
REMARQUE :
1. PG : Surveillance parentale recommandée.
2. PG-13: Ce matériel n’est pas approprié pour des enfants de moins de 13 ans.
3. R : Surveillance parentale -restreinte ; il est recommandé que les parents restreignent aux enfants de moins de 17 ans de regarder ou autorisent les enfants à regarder uniquement lorsqu’ils sont surveillés par un parent ou une personne adulte.
4. NC-17: Aucun enfant de moins de 17 ans; il n’est pas recommandé que les enfants de moins de 17 ans regardent.
56
SCHÉMA DU MENU DE CONFIGURATION - suite
FIGURE 1-1
Configuration écran
Type TV Écran de veille
Vérifiez que votre téléviseur prend en charge le balayage progressif (P-Scan)
Continuer Appuyez sur PLAY Stop Appuyez sur STOP
4
S-Vidéo P-SCAN
: Dépl. Sél.: SETUP : Quitter
Si vous sélectionnez le balayage progressif (P-Scan), les options ci-dessus s’affichent sur l’écran comme rappel. Si votre téléviseur prend en charge la
fonction de balayage progressif (P-Scan), appuyez sur
<ST<ST
Sinon, appuyez sur
<<Dépannage>> Si l’écran devient noir en cours d’utilisation… Solution : Appuyez sur le bouton <MODE> pour passer au mode de balayage progressif “S-Video”.
<ST
<ST<ST
OP>OP>
OP>.
OP>OP>
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
Français
57
Préparations
Veuillez connecter ce lecteur DVD portable à l’alimentation et connectez-le avec des écouteurs ou aux équipements extérieurs. En cas de connexion à des équipements extérieurs :
z Allumez votre téléviseur et sélectionnez “Video” comme entrée TV. z Appuyez sur le bouton Power du système stéréo si le lecteur a été connecté à celui-ci. z Mettez le bouton AV OUT/IN sur AV OUT.
Lecture de base
1.1.
1. Appuyez sur le bouton
1.1.
2.2.
2. Appuyez sur le bouton
Français
2.2.
3.3.
3. Maintenez le bord du disque pour le placer au centre avec le côté
3.3.
4.4.
4. Refermez le couvercle.
4.4.
5.5.
5. Appuyez sur le bouton
5.5.
6.6.
6. Appuyez sur
6.6.
<POWER><POWER>
<POWER>.
<POWER><POWER>
<OPEN><OPEN>
<OPEN> pour ouvrir le couvercle.
<OPEN><OPEN>
imprimé vers le haut.
z Refermez le couvercle. Le lecteur DVD portable démarre la lecture si le
disque ne possède pas de menus enregistrés.
z Si le disque a un ou plusieurs titres enregistrés dessus, une page de menu
s’affiche sur l’écran du téléviseur.
<HA<HA
<HA
<HA<HA
UT> <BUT> <B
UT> <B
UT> <BUT> <B
AS> <GAAS> <GA
AS> <GA
AS> <GAAS> <GA
UCHE> <DRUCHE> <DR
UCHE> <DR
UCHE> <DRUCHE> <DR
OITE>OITE>
OITE>
OITE>OITE>
ou sur les touches numériques pour sélectionner votre titre préféré.
Remarque : Pour sélectionner un titre, vous devez entrer le numéro, par
exemple, 1 pour le chapitre 1, 10 pour le chapitre 10, etc.
<PLA<PLA
<PLA
<PLA<PLA
Le lecteur DVD portable démarre la lecture de l’élément sélectionné.
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
Arrêt de la lecture
Appuyez sur
OP>OP>
<ST
OP> pour un pré-arrêt. Appuyez sur
<ST<ST
OP>OP>
<ST<ST
OP>OP>
<ST
OP> deux
<ST<ST
OP>OP>
<ST<ST
fois pour arrêter.
Avance rapide/ Retour rapide
<F<F
Appuyez sur
z La lecture normale reprendra lorsque vous appuierez sur le bouton <PLAY/SEL.>. z La vitesse de l’avance rapide ou du retour rapide change chaque fois que vous appuyez sur le
bouton
<F.BWD> ou <F.FWD>.
.BWD>.BWD>
<F
.BWD> ou
<F<F
.BWD>.BWD>
<F<F
.FWD>.FWD>
<F
.FWD> pendant la lecture.
<F<F
.FWD>.FWD>
58
Saut avant ou retour aux chapitres
Saut avant
Appuyez sur le bouton
Vous sauterez un chapitre à chaque fois que vous appuierez sur le bouton.
Saut arrière
Appuyez sur le bouton
Vous sauterez un chapitre à chaque fois que vous appuierez sur le bouton.
<SUIV<SUIV
<SUIV
<SUIV<SUIV
<PRÉCÉDENT><PRÉCÉDENT>
<PRÉCÉDENT> pendant la lecture.
<PRÉCÉDENT><PRÉCÉDENT>
ANT>ANT>
ANT> pendant la lecture.
ANT>ANT>
Image immobile (PAUSE)
<P <P
AA
Appuyez une fois sur le bouton
L’écran est suspendu.
Pour retourner en mode de lecture normale
<P
<P <P
USE>USE>
A
USE> pendant la lecture.
AA
USE>USE>
Français
Appuyez sur <PLAY/SEL.>.
Répétition
Appuyez sur le bouton
Chaque fois que vous appuyez sur ce bouton, le disque répète un chapitre ou un titre. Appuyez une fois : CHAPITRE (Répétition chapitre) Appuyez deux fois : TITRE (Répétition titre) Appuyez trois fois : DISQUE (Répétition disque) Appuyez quatre fois : off (Répétition annulée)
Pour retourner en mode de lecture normale
Appuyez plusieurs fois sur <1/ALL REPEAT> jusqu’à ce que “ off” s’affiche à l’écran.
<1/ALL REPEA<1/ALL REPEA
<1/ALL REPEA
<1/ALL REPEA<1/ALL REPEA
T>T>
T> pendant la lecture.
T>T>
59
Affichage des informations sur la scène
Appuyez plusieurs fois sur numéro du titre, le numéro du chapitre et autres informations s’affichent à l’écran.
Pour arrêter l’affichage des informations sur la scène
Appuyez plusieurs fois sur <INFO.> jusqu’à ce que les informations disparaissent.
Français
Sélection de la langue des pistes sonores
Vous pouvez changer la langue des pistes sonores du disque si cette option est disponible sur votre disque. Pour sélectionner la langue souhaitée :
1.1.
1. Appuyez sur le bouton
1.1.
2.2.
2. Appuyez plusieurs fois sur
2.2.
<INFO.><INFO.>
<INFO.> pendant la lecture jusqu’à ce que le
<INFO.><INFO.>
préférée soit sélectionnée.
<A<A
UDIO>UDIO>
<A
UDIO> pendant la lecture.
<A<A
UDIO>UDIO>
<A<A
UDIO>UDIO>
<A
UDIO> jusqu’à ce que votre langue
<A<A
UDIO>UDIO>
Remarque : Si la langue préférée n’est toujours pas sélectionnée après avoir
appuyé plusieurs fois sur ce bouton, cela signifie que cette langue n’est pas disponible sur ce disque.
Sélection de la langue de sous-titrage
Vous pouvez sélectionner la langue du sous-titrage du disque si cette option est disponible sur votre disque. Pour sélectionner la langue souhaitée :
1.1.
1. Appuyez sur le bouton
1.1.
2.2.
2. Appuyez plusieurs fois sur
2.2.
langue préférée soit sélectionnée.
Remarque : Si la langue préférée n’est pas sélectionnée, il se peut que la
langue en question ne soit pas disponible sur ce disque.
<SUBTITLE><SUBTITLE>
<SUBTITLE> pendant la lecture.
<SUBTITLE><SUBTITLE>
<SUBTITLE><SUBTITLE>
<SUBTITLE> jusqu’à ce que votre
<SUBTITLE><SUBTITLE>
60
Sélection des angles
Pour certains disques, les mêmes scènes peuvent être visualisées sous différents angles.
1.1.
1. Appuyez sur le bouton
1.1.
2.2.
2. Appuyez plusieurs fois sur
2.2.
<ANGLE><ANGLE>
<ANGLE> pendant la lecture.
<ANGLE><ANGLE>
<ANGLE><ANGLE>
<ANGLE> jusqu’à ce que votre angle
<ANGLE><ANGLE>
de prise de vues préféré soit sélectionné.
Remarque : Cette fonction n’est disponible qu’avec des disques sur lesquels ont
été enregistrés plusieurs angles de prise de vues. Si cette fonction n’est pas disponible, l’icône d’erreur “ ” s’affichera.
Fonction Muet
Appuyez sur le bouton
Remarque : Si l’indication “Muet” s’affiche à l’écran, cela signifie que le
<MUTE><MUTE>
<MUTE> pendant la lecture.
<MUTE><MUTE>
lecteur DVD portable est désactivé.
Français
Pour restaurer le son
Appuyez à nouveau sur <MUTE> jusqu’à ce que le message “Muet Off” s’affiche à l’écran.
Paramétrage du panneau LCD
Ce lecteur portable DVD offre trois options sur le réglage du panneau : “Normal”, “16:9” ou “4:3”.
1.1.
1. Appuyez sur
1.1.
l’écran LCD s’afficheront.
2.2.
2. Appuyez plusieurs fois sur
2.2.
(Panneau).
3.3.
3. Appuyez sur le bouton
3.3.
paramétrage de panneau préféré. Le panneau adoptera le paramétrage sélectionné.
PP
anel:anel:
P
anel:
PP
anel:anel:
Panel: 16:9Panel: 16:9
Panel: 16:9
Panel: 16:9Panel: 16:9
Nor Nor
Nor
Nor Nor
<LCD><LCD>
<LCD>. Les informations sur le paramétrage de
<LCD><LCD>
<LCD><LCD>
<LCD> pour sélectionner “Panel”
<LCD><LCD>
<GA<GA
malmal
mal
malmal
UCHE>UCHE>
<GA
UCHE> ou
<GA<GA
UCHE>UCHE>
<DR<DR
OITE>OITE>
<DR
OITE> pour choisir le
<DR<DR
OITE>OITE>
Panel: 4:3Panel: 4:3
Panel: 4:3
Panel: 4:3Panel: 4:3
Pour terminer l’opération de configuration
Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.
61
Paramétrage couleur de l’écran LCD
Vous pouvez régler la couleur de l’image avec ce paramétrage pour votre confort visuel.
1.1.
1. Appuyez sur
1.1.
2.2.
2. Appuyez plusieurs fois sur
2.2.
3.3.
3. Appuyez sur le bouton
3.3.
Français
Pour terminer l’opération de configuration
<LCD><LCD>
<LCD>. Les informations sur le paramétrage de
<LCD><LCD>
l’écran LCD s’afficheront.
<LCD><LCD>
<LCD> pour sélectionner “Color”
<LCD><LCD>
(Couleur).
<GA<GA
UCHE>UCHE>
<GA
UCHE> ou
<GA<GA
UCHE>UCHE>
<DR<DR
OITE>OITE>
<DR
OITE> pour choisir le
<DR<DR
OITE>OITE>
paramétrage de couleur préféré. Le panneau adoptera le paramétrage sélectionné.
ColorColor
Color
ColorColor
ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor
::
+3 +3
:
+3
::
+3 +3
::
+2 +2
:
+2
::
+2 +2
::
+1 +1
:
+1
::
+1 +1
::
0 0
:
0
::
0 0
::
-1 -1
:
-1
::
-1 -1
::
-2 -2
:
-2
::
-2 -2
::
-3 -3
:
-3
::
-3 -3
Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.
Paramétrage de la luminosité de l’écran LCD
Vous pouvez augmenter ou diminuer manuellement la luminosité de l’image.
1.1.
1. Appuyez sur
1.1.
LCD s’afficheront.
2.2.
2. Appuyez plusieurs fois sur
2.2.
(Luminosité).
3.3.
3. Appuyez sur le bouton
3.3.
paramétrage de luminosité préféré. Le panneau adoptera le paramétrage sélectionné.
Bright: +3Bright: +3
Bright: +3
Bright: +3Bright: +3
Bright: +2Bright: +2
Bright: +2
Bright: +2Bright: +2 Bright: +1Bright: +1
Bright: +1
Bright: +1Bright: +1 Bright: 0Bright: 0
Bright: 0
Bright: 0Bright: 0 Bright: -1Bright: -1
Bright: -1
Bright: -1Bright: -1
<LCD><LCD>
<LCD>, les informations sur le paramétrage de l’écran
<LCD><LCD>
<LCD><LCD>
<LCD> pour sélectionner “Bright”
<LCD><LCD>
<GA<GA
UCHE>UCHE>
<GA
UCHE> ou
<GA<GA
UCHE>UCHE>
<DR<DR
OITE>OITE>
<DR
OITE> pour choisir le
<DR<DR
OITE>OITE>
Bright: -2Bright: -2
Bright: -2
Bright: -2Bright: -2 Bright: -3Bright: -3
Bright: -3
Bright: -3Bright: -3
Pour terminer l’opération de configuration
Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.
62
Paramétrage de fermeture du panneau LCD
1.1.
1. Appuyez sur
1.1.
<LCD><LCD>
<LCD>. Les informations sur le paramétrage de
<LCD><LCD>
l’écran LCD s’afficheront à l’écran.
2.2.
2. Appuyez plusieurs fois sur
2.2.
3.3.
3. Appuyez sur le bouton
3.3.
<GA<GA
<GA
<GA<GA
<LCD><LCD>
<LCD> pour sélectionner “Fermer”.
<LCD><LCD>
UCHE>UCHE>
UCHE> ou
UCHE>UCHE>
<DR<DR
OITE>OITE>
<DR
OITE> pour choisir le
<DR<DR
OITE>OITE>
paramétrage de panneau préféré. Le panneau adoptera le paramétrage sélectionné.
Close: OffClose: Off
Close: Off
Close: OffClose: Off
Close: OnClose: On
Close: On
Close: OnClose: On
Pour terminer l’opération de configuration
Appuyez sur <LCD>. Les informations sur le paramétrage de l’écran LCD disparaissent.
Français
Lecture des CD d’images Kodak et JPEG
Vous pouvez lire les CD d’images Kodak et JPEG et les visualiser à l’écran.
Chargez un CD d’images Kodak/JPEG. Après quelques secondes, le lecteur DVD portable commencera automatiquement à lire les images les unes après les autres. Ou Vous pouvez également appuyer sur les touches numériques correspondant au
<PLA<PLA
numéro d’ordre des images puis sur
Pour suspendre/arrêter la lecture
Appuyez sur <PAUSE> pour suspendre la lecture et sur <STOP> pour arrêter.
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
63
Programmation
En mode Programme
Vous pouvez programmer la lecture de fichiers image ou MP3 en mode Programme.
1.1.
1. Appuyez sur le bouton
1.1.
<HA<HA
<HA
<HA<HA
UT> <BUT> <B
UT> <B
UT> <BUT> <B
AS> <GAAS> <GA
AS> <GA
AS> <GAAS> <GA
UCHE> <DRUCHE> <DR
UCHE> <DR
UCHE> <DRUCHE> <DR
OITE>OITE>
OITE>
OITE>OITE>
2.2.
2. Répétez l’étape ci-avant pour terminer la liste des programmes.
2.2.
3.3.
3. Appuyez sur le bouton
Français
3.3.
4.4.
4. Appuyez sur le bouton
4.4.
Pour supprimer un fichier / tous les fichiers de la liste des programmes
Appuyez sur le bouton <UP> ou <DOWN> pour choisir le fichier puis sur <PLAY/SEL.> pour supprimer le fichier de la liste des programmes.
Pour supprimer tous les fichiers de la liste des programmes
pour choisir le fichier préféré puis sur
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>. Le fichier
Y/SEL.>Y/SEL.>
sélectionné est indiqué avec le cadre jaune ; ajoutez-le dans la liste des programmes.
<GA<GA
UCHE>UCHE>
<GA
UCHE> pour revenir à la barre des menus
<GA<GA
UCHE>UCHE>
et sur le bouton programmation” puis appuyez sur
et sur le bouton
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.> Y/SEL.>
Y/SEL.> pour lire les fichiers programmés.
Y/SEL.> Y/SEL.>
<DROITE><DROITE>
<DROITE> pour sélectionner “Liste de
<DROITE><DROITE>
<PLA<PLA
<PLA
<PLA<PLA
<GA<GA
UCHE>UCHE>
<GA
UCHE> pour revenir à la barre des menus
<GA<GA
UCHE>UCHE>
<DROITE><DROITE>
<DROITE> pour sélectionner “
<DROITE><DROITE>
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
” puis appuyez sur
Sélectionnez “Effacer tout” puis appuyez sur <PLAY/SEL.> pour supprimer tous les fichiers de la liste des programmes.
64
Manual do utilizador do leitor DVD portátil
Definições iniciais
1. Prima o botão <SETUP>.
2. Apresentação do ecrã do MENU SETUP.
Configuração do idioma
OSD
Menu
Áudio
Legenda
: Mover : Selec. SETUP: Sair
3. Utilize o botão <PARA CIMA> <PARA BAIXO> <ESQUERDA> <DIREITA> para seleccionar a opção pretendida.
4. Prima o botão
<PLAY/SEL.>
Para as definições:
Repita o procedimento acima e consulte as instruções do OSD para realizar a seguinte definição:
Configuração do idioma
OSD
Menu
Áudio
Legenda
Configuração do ecrã
Tipo de televisão
Protector de ecrã
Sistema da televisão
Saída do vídeo
Português
: Mover : Selec. SETUP: Sair
Configuração do áudio
Saída digital
Saída analógica
: Mover : Selec. SETUP: Sair
: Mover : Selec. SETUP: Sair
Configuração personalizada
Controlo parental
Palavra-passe
Símbolo do ângulo
Predefinido
: Mover : Selec. SETUP: Sair
65
DIAGRAMA DO MENU CONFIGURAR
Idioma (As opções do idioma são apenas para referência, para obter as
Português
informações correctas, consulte o seu leitor de DVD portátil.)
O.S.D. Inglês
Francês Alemão Italiano Espanhol Português
Menu Inglês
Chinês Japonês Francês Alemão Italiano Espanhol Português ... Outros
Áudio Inglês
Chinês Japonês Francês Alemão Italiano Espanhol Português ... Outros
Legendas Inglês
Chinês Japonês Francês Alemão Italiano Espanhol Português ... Outros Off
66
DIAGRAMA DO SETUP MENU - continuação
Ecrã Tipo de TV 4:3 PS
4:3 LB 16:9
Protector de ecrã Activado
ecrã: 10 minutos.)
Desactivado
Sistema da TV NTSC
PAL AUTO
Saída do vídeo S-Vídeo
VARRIMENTO-P (consulte a figura 1-1)
Áudio Saída digital SPDIF/PCM
SPDIF/RAW Off
Saída analógica 2 canais
Personalizar Controlo parental (Antes de seleccionar as classificações,
introduza uma palavra-passe com 4 dígitos. a palavra-passe predefinida pelo fabricante é:
0000)
1.
2.
3. PG
4. PG13
5.
6. R
7. NC-17
8.
Palavra-passe Introduzir palavra-passe (palavra-passe
predefinida pelo fabricante é: 0000) Introduzir palavra-passe NOVA Voltar a introduzir palavra-passe
Símbolo do ângulo Aceso
Apagado
Predefinido Leitura
(Trata-se do tempo de espera do protector de
(veja a NOTA abaixo)
(veja a NOTA abaixo)
(veja a NOTA abaixo)
(veja a NOTA abaixo)
Português
NOTA:
1. PG: Sugere-se Parental Guidance (Orientação Parental).
2. PG-13: O material não se adequa a crianças com idade inferior a 13 anos.
3. R: Orientação Parental – Restricted (Limitada); recomenda-se que os pais impeçam a visualização por parte de crianças com idade inferior a 17 anos, ou que tal aconteça apenas quando vigiadas por um dos pais ou por um guardião adulto.
4. NC-17: No Children (Não para Crianças); não se recomenda a visualização por parte de crianças com idade inferior a 17 anos.
67
DIAGRAMA DO MENU SETUP - continuação
FIGURA 1-1
Configuração do ecrã
Português
Se seleccionar “Varrimento-P”, a mensagem acima aparece no ecrã como lembrete. De seguida, se a sua TV suportar a opção “Varrimento-P”, prima o
botão
<<Resolução de problemas>> O que é que se deve fazer se o ecrã ficar em branco com o dispositivo ligado? Solução: Prima o botão <MODE> para mudar para o modo “S-Video”.
Tipo de televisão Protector de ecrã
Certifique-se de que a sua TV suporta o Varrimento-P
Continuar Prima PLAY Parar Prima STOP
4
S-Vídeo VARRIMENTO-P
: Mover : Selec. SETUP: Sair
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>. Caso contrário, prima o botão
Y/SEL.>Y/SEL.>
<ST<ST
<ST
<ST<ST
OP>OP>
OP>.
OP>OP>
68
Preparações
Ligue este leitor de DVD portátil à alimentação e ligue-o aos auriculares/auscultadores ou ligue-o a equipamentos externos. Se ligar o leitor de DVD portátil a equipamentos externos: z Prima o botão de alimentação da televisão e seleccione “Vídeo” como a entrada da
televisão.
z Prima o botão de alimentação do sistema estéreo, se o leitor de DVD tiver sido ligado a
um sistema estéreo.
z Faça com que a AV OUT/IN deslize para a AV OUT.
Reprodução básica
1.1.
1. Prima
1.1.
2.2.
2. Prima
2.2.
3.3.
3. Segure com cuidado a extremidade do disco e, de seguida, coloque-o ao
3.3.
<POWER><POWER>
<POWER>.
<POWER><POWER>
<OPEN><OPEN>
<OPEN> para abrir a tampa do compartimento dos discos.
<OPEN><OPEN>
centro com o lado impresso virado para cima.
4.4.
4. Feche a tampa do compartimento dos discos.
4.4.
z Feche a tampa do compartimentos dos discos e o leitor de DVD dá início à
reprodução do DVD, se este não tiver menus gravados.
z Se o disco tiver um mais títulos gravados, aparece um ecrã menu no ecrã da
televisão.
5.5.
5. Prima o botão
5.5. <DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
A>A>
A> ou o(s) número(s) numerado(s) para seleccionar o título
A>A>
<P<P
ARA CIMA> <PARA CIMA> <P
<P
ARA CIMA> <P
<P<P
ARA CIMA> <PARA CIMA> <P
ARA BARA B
ARA B
ARA BARA B
AIXAIX
O> <ESQO> <ESQ
AIX
O> <ESQ
AIXAIX
O> <ESQO> <ESQ
UERDUERD
UERD
UERDUERD
A>A>
A>
A>A>
pretendido.
Nota: Para seleccionar um título, introduza o número, por exemplo 1 para
o capítulo 1, 10 para o capítulo 10, etc..
6.6.
6. Prima o botão
6.6.
O leitor de DVD dá início à reprodução do item seleccionado.
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
Português
Paragem da reprodução
<ST<ST
Prima o botão
<ST<ST
botão
OP>OP>
<ST
OP> duas vezes para parar.
<ST<ST
OP>OP>
OP>OP>
<ST
OP> uma vez para realizar a paragem prévia. Prima o
<ST<ST
OP>OP>
Avanço rápido/recuo rápido
<F<F
Prima o botão
z A reprodução normal é reposta quando prime o botão <PLAY/SEL.>. z A velocidade do avanço rápido ou na reprodução de recuo é alterada cada vez que toca no
botão
<F.BWD> ou <F.FWD>.
.BWD>.BWD>
<F
.BWD> ou
<F<F
.BWD>.BWD>
<F<F
.FWD>.FWD>
<F
.FWD> durante a reprodução.
<F<F
.FWD>.FWD>
69
Saltar capítulos para a frente ou para trás
Saltar para a frente
Prima o botão
Prima este botão para saltar um capítulo.
Saltar para trás
Prima o botão
Prima este botão para saltar um capítulo.
Português
Imagem fixa (PAUSAR)
Prima o botão
O ecrã fica imóvel.
Para voltar para a reprodução normal:
Prima o botão <PLAY/SEL.>.
<NEXT><NEXT>
<NEXT> durante a reprodução.
<NEXT><NEXT>
<PREVIOUS> <PREVIOUS>
<PREVIOUS> durante a reprodução.
<PREVIOUS> <PREVIOUS>
<P <P
AA
<P
<P <P
USE>USE>
A
USE> uma vez durante a reprodução.
AA
USE>USE>
Nova visualização
Prima o botão
Sempre que premir este botão, o disco repetirá um capítulo ou título. Premir uma vez: CHAPTER (Repete o capítulo) Premir duas vezes: TITLE (Repete o título) Premir três vezes: DISC (Repete o disco) Premir quatro vezes: off (Repetição cancelada)
Para voltar para a reprodução normal
Prima <1/ALL REPEAT> diversas vezes até aparecer “ off” no ecrã.
<1/ALL REPEA<1/ALL REPEA
<1/ALL REPEA
<1/ALL REPEA<1/ALL REPEA
T>T>
T> durante a reprodução.
T>T>
70
Apresentação das informações relativas a uma cena
Prima o botão capítulo e outras informações aparecem no ecrã.
Para parar a apresentação das informações no ecrã
Prima o botão <INFO.> diversas vezes até as informações desaparecerem.
<INFO.><INFO.>
<INFO.> diversas vezes, número do título, número do
<INFO.><INFO.>
Selecção do idioma da faixa de áudio
O idioma da pista sonora pode ser alterado, se esta opção estiver disponível no DVD. Para seleccionar o idioma pretendido:
1.1.
1. Prima o botão
1.1.
2.2.
2. Prima o botão
2.2.
ter sido seleccionado.
<A<A
UDIO>UDIO>
<A
UDIO> durante a reprodução.
<A<A
UDIO>UDIO>
<A<A
UDIO>UDIO>
<A
UDIO> diversas vezes até o idioma pretendido
<A<A
UDIO>UDIO>
Português
Nota: Quando não se consegue seleccionar o idioma pretendido, mesmo
depois de premir o botão várias vezes, isso significa que o idioma não está contido no disco.
Selecção do idioma das legendas
O idioma das legendas pode ser seleccionado, se esta opção estiver disponível no DVD. Para a seleccionar:
1.1.
1. Prima o botão
1.1.
2.2.
2. Prima o botão
2.2.
pretendido ter sido seleccionado.
Nota: Quando o idioma pretendido não é seleccionado, poderá indicar que
o idioma não está disponível no disco.
<SUBTITLE> <SUBTITLE>
<SUBTITLE> durante a reprodução.
<SUBTITLE> <SUBTITLE>
<SUBTITLE><SUBTITLE>
<SUBTITLE> diversas vezes até o idioma
<SUBTITLE><SUBTITLE>
71
Selecção dos ângulos
Em alguns discos, as mesmas cenas podem ser visualizadas a partir de diversos ângulos.
1.1.
1. Prima o botão
1.1.
<ANGLE> <ANGLE>
<ANGLE> durante a reprodução.
<ANGLE> <ANGLE>
2.2.
2. Prima o botão
2.2.
Português
Função de corte do som
Prima o botão
Para repor o som
Prima o botão <MUTE> novamente até “Som reposto” aparecer no ecrã.
<ANGLE><ANGLE>
<ANGLE> diversas vezes até o ângulo de
<ANGLE><ANGLE>
visualização pretendido ser seleccionado.
Nota: Esta função só funciona em discos onde foram gravados ângulos de
visualização diferentes. Se esta função não estiver disponível, aparece o ícone inválido “ ”.
<MUTE> <MUTE>
<MUTE> durante a reprodução.
<MUTE> <MUTE>
Nota: Quando a opção “Corte do som” aparece no ecrã, é porque este
leitor de DVD portátil não tem som.
Definições do painel LCD
Este leitor de DVD portátil dispõe de três opções acerca do ajuste do painel: “Normal”, “16:9” ou “4:3”.
1.1.
1. Prima o botão
1.1.
LCD aparecem no ecrã.
2.2.
2. Prima o botão
2.2.
(Painel).
3.3.
3. Prima o botão
3.3.
definição preferida do painel, e de seguida, o painel muda para a definição seleccionada.
PP
anel:anel:
P
anel:
PP
anel:anel:
Panel: 16:9Panel: 16:9
Panel: 16:9
Panel: 16:9Panel: 16:9
Panel: 4:3Panel: 4:3
Panel: 4:3
Panel: 4:3Panel: 4:3
Para concluir a operação de configuração:
Nor Nor
Nor
Nor Nor
<LCD><LCD>
<LCD>, as informações relativas às definições do
<LCD><LCD>
<LCD><LCD>
<LCD> diversas vezes para seleccionar “Panel”
<LCD><LCD>
<ESQ<ESQ
<ESQ
<ESQ<ESQ
malmal
mal
malmal
UERDUERD
UERD
UERDUERD
A>A>
A> ou
A>A>
<DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
A>A>
A> para seleccionar a
A>A>
Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.
72
Definição das cores do LCD
Pode utilizar esta definição para ajustar a cor do vídeo para uma vista de disparo dos seus olhos.
1.1.
1. Prima o botão
1.1.
<LCD><LCD>
<LCD>, as informações relativas às definições do
<LCD><LCD>
LCD aparecem no ecrã.
2.2.
2. Prima o botão
2.2.
<LCD><LCD>
<LCD> diversas vezes para seleccionar “Color “
<LCD><LCD>
(Cor).
3.3.
3. Prima o botão
3.3.
<ESQ<ESQ
<ESQ
<ESQ<ESQ
UERDUERD
UERD
UERDUERD
A>A>
A> ou
A>A>
<DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
A>A>
A> para seleccionar a
A>A>
definição preferida da cor, e de seguida, o painel muda para a definição seleccionada.
ColorColor
Color
ColorColor
ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor ColorColor
Color
ColorColor
Para concluir a operação de configuração:
Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.
::
+3 +3
:
+3
::
+3 +3
::
+2 +2
:
+2
::
+2 +2
::
+1 +1
:
+1
::
+1 +1
::
0 0
:
0
::
0 0
::
-1 -1
:
-1
::
-1 -1
::
-2 -2
:
-2
::
-2 -2
::
-3 -3
:
-3
::
-3 -3
Português
Definição da luminosidade do LCD
Pode aumentar ou diminuir a luminosidade do vídeo.
1.1.
1. Prima o botão
1.1.
LCD aparecem no ecrã.
2.2.
2. Prima o botão
2.2.
(Luminosidade).
3.3.
3. Prima o botão
3.3.
definição preferida da luminosidade, e de seguida, o painel muda para a definição seleccionada.
Bright: +3Bright: +3
Bright: +3
Bright: +3Bright: +3
Bright: +2Bright: +2
Bright: +2
Bright: +2Bright: +2 Bright: +1Bright: +1
Bright: +1
Bright: +1Bright: +1 Bright: 0Bright: 0
Bright: 0
Bright: 0Bright: 0 Bright: -1Bright: -1
Bright: -1
Bright: -1Bright: -1 Bright: -2Bright: -2
Bright: -2
Bright: -2Bright: -2 Bright: -3Bright: -3
Bright: -3
Bright: -3Bright: -3
Para concluir a operação de configuração:
<LCD><LCD>
<LCD>, as informações relativas às definições do
<LCD><LCD>
<LCD><LCD>
<LCD> diversas vezes para seleccionar “Bright”
<LCD><LCD>
<ESQ<ESQ
<ESQ
<ESQ<ESQ
UERDUERD
UERD
UERDUERD
A>A>
A> ou
A>A>
<DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
A>A>
A> para seleccionar a
A>A>
Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.
73
Definição para fechar o painel LCD
1.1.
1. Prima o botão
1.1.
2.2.
2. Prima o botão
2.2.
3.3.
3. Prima o botão
3.3.
Português
Para concluir a operação de configuração:
Volte a premir o botão <LCD> até as informações da definição do LCD desaparecerem.
<LCD><LCD>
<LCD>, as informações relativas às definições do
<LCD><LCD>
LCD aparecem no ecrã.
<LCD><LCD>
<LCD> diversas vezes para seleccionar “Close”
<LCD><LCD>
(Fechar).
<ESQ<ESQ
<ESQ
<ESQ<ESQ
UERDUERD
UERD
UERDUERD
A>A>
A> ou
A>A>
<DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
A>A>
A> para seleccionar a
A>A>
definição preferida do painel, e de seguida, o painel muda para a definição seleccionada.
Close: OffClose: Off
Close: Off
Close: OffClose: Off
Close: OnClose: On
Close: On
Close: OnClose: On
Reprodução de CD com fotografias da Kodak e com fotografias em formato JPEG
Pode reproduzir CD com fotografias da Kodak e com fotografias em formato JPEG para visualizar no ecrã.
Introduza um CD com fotografias da Kodak e com fotografias em formato JPEG, após alguns segundos, este leitor de DVD portátil inicia automaticamente a reprodução de fotografias sob a forma de diapositivos. Ou Pode premir os botões numerados correspondentes à ordem da fotografia, e de
<PLA<PLA
seguida, premir o botão
Para pausar/parar a reprodução
Prima o botão <PAUSE> para pausar a reprodução e prima <STOP> para parar.
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
74
Programação
No modo de programação
Pode programar ficheiros de fotografias ou MP3 no modo de programação.
1.1.
1. Prima o botão
1.1. <DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
A>A>
A> para seleccionar o ficheiro preferido e, de seguida, prima
A>A>
<P<P
ARA CIMA> <PARA CIMA> <P
<P
ARA CIMA> <P
<P<P
ARA CIMA> <PARA CIMA> <P
ARA BARA B
ARA B
ARA BARA B
AIXAIX
O> <ESQO> <ESQ
AIX
O> <ESQ
AIXAIX
O> <ESQO> <ESQ
UERDUERD
UERD
UERDUERD
A>A>
A>
A>A>
o botão
<PLA<PLA
<PLA
<PLA<PLA
Y/SEL.>Y/SEL.>
Y/SEL.>; o ficheiro seleccionado está assinalado
Y/SEL.>Y/SEL.>
pela moldura amarela e adicione-o à lista de programas.
2.2.
2. Repita o passo acima para concluir a lista de programas.
2.2.
3.3.
3. Prima o botão
3.3.
prima o botão por último prima o botão
4.4.
4. Prima o botão
4.4.
prima o botão botão
Para eliminar o ficheiro/todos os ficheiros da lista de programas
Prima o botão <PARA CIMA> ou <PARA BAIXO> para seleccionar o ficheiro, e de seguida, prima o
botão <PLAY/SEL.> para eliminar o ficheiro da lista de programas.
Para eliminar todos os ficheiros da lista de programas
Seleccione “LIMPAR TUDO” e, de seguida, prima o botão <PLAY/SEL.> para eliminar todos os
<PLA<PLA
<PLA
<PLA<PLA
<ESQ<ESQ
<ESQ
<ESQ<ESQ
<DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
<ESQ<ESQ
<ESQ
<ESQ<ESQ
<DIREIT<DIREIT
<DIREIT
<DIREIT<DIREIT
UERDUERD
UERD
UERDUERD
UERDUERD
UERD
UERDUERD
Y/SEL.>Y/SEL.>
Y/SEL.> para reproduzir os ficheiros programados.
Y/SEL.>Y/SEL.>
A>A>
A> para voltar para a barra de menus,
A>A>
A>A>
A> para seleccionar “Lista de programas” e
A>A>
<PLA<PLA
<PLA
<PLA<PLA
A>A>
A> para voltar para a barra de menus,
A>A>
A>A>
A> para seleccionar “
A>A>
Y/SEL.>Y/SEL.>
Y/SEL.>.
Y/SEL.>Y/SEL.>
” e por último prima o
Português
ficheiros da lista de programas.
75
Loading...
