MTD 13AM660G700, 13AM660F700, 13AG688H722, 13AF688G722, 13AF685G700 Owner’s Manual

Operator's Manual

_ansmatic Lawn _actor

MODELS 660,680

662,682 663,683 665,685 668,688

IMPORTANT: Read safety rules and instructions carefully before operating equipment.

Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-

covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131

Cleveland, Ohio 44136-9722.

MTB LLC,P.O.BOX361131CLEVELAND,OHIO44136-9722

PRINTED IN U.S.A. FORM NO. 769-00533C,

(3/31/2004)

TABLEOFCONTENTS

Content Customer Support

Important Safe Operation Practices

Tractor Set-up Controls

Operation

Page Content Page

2 Maintenance 20

3 Service 22 8 Off-season Storage 27

11 Attachments & Accessories 28 13 Warranty Back Cover

FINDINGMODELNUMBER

This Operator's Manual is an important part of your new lawn tractor. It will help you assemble, prepare and maintain the unit for best performance. Please read and understand what it says.

Before you start assembling your new equipment, please locate the model plate on the equipment and copy the information from it in the space provided below. A sample model plate is also given below. You can locate the model plate by looking at the underside of the seat. This information will be necessary

to use the manufacturer's web site and/or help from the Customer Support Department or an authorized

service dealer.

Copy the model number here:

P. O. BOX 361131

o.o,,o

CLEVELAND,OH 44136

www, mtdproducts.corn 800-800-7310

330-220-4883

Copy the serial number here:

CUSTOMERSUPPORT

Please doNOTreturn the unRto theretailer wRhoutfirstcontactingCustomerSupport.

If you have difficulty assembling this product or have any questions regarding the controls, operation or maintenance of this unit, you can seek help from the experts. Choose from the options below:

Visit mtdproducts.com for many useful suggestions. Click on Customer Support button and you will get the four options reproduced here. Click on the appropriate button and help is

immediately available.

_nd Answers

_nswey ETye

looking £)r cou!d be just

a mouse crick aw_y/

1__9{1_ te _lleck 1_l_estatl_ ef yelll Illestiel s_ : medif 7 yo!ll h<_qllilies, el II1_1 I've ye_H pe_sel_al

I leHle.

e Locato_

N÷el [<eal as islall_e _ Clik [ieNe t_ fil_l

a_llbe_iz÷ f selvi_:÷ celltels ill yell_ a_ea,

Manuals Online

Iit÷la_!ll_ f_e4_ lecel# mo(le[ yeals,

If you prefer to reach a Customer Support Representative, please call (330) 220-4MTD or 1(800) 800-7310.

{3nswer you are

/ooking £,r cou/d be just

a mouse click aw_y/

Ma ual En ine

The engine manufacturer is responsible for all engine-related issues with regard to

performance, power-rating, specifications, warranty and service. Please refer to the engine manufacturer's Owner's/Operator's Manual, packed separately with your unit, for more

information.

SECTION1: IMPORTANTSAFEOPERATIONPRACTICES

WARNING: This symbol points out important safety instructions which, if not followed, could endanger

the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. When you see this symbol--heed its warning.

DANGER: This machine was built to be operated according to the rules for safe operation in this man-

ual. As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.

_, WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain

GENERAL OPERATION

1. Read, understand, and follow all instructions on the

2. Be familiar with all controls and their proper

3. Never allow children under 14 years old to operate

4. Never allow adults to operate this machine without

5. To help avoid blade contact or a thrown object

6. Thoroughly inspect the area where the equipment

7. Plan your mowing pattern to avoid discharge of

8. Always wear safety glasses or safety goggles

9. Wear sturdy, rough-soled work shoes and close-

or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

10. Be aware of the mower and attachment discharge direction and do not point it at anyone. Do not

machine and in the manual(s) before attempting to assemble and operate. Keep this manual in a safe place for future and regular reference and for ordering replacement parts.

operation. Know how to stop the machine and disengage them quickly.

this machine. Children 14 years old and over

should read and understand the operation instructions and safety rules in this manual and should be trained and supervised by a parent.

proper instruction.

injury, keep bystanders, helpers, children and pets at least 75 feet from the machine while it is in

operation. Stop machine if anyone enters the area.

is to be used. Remove all stones, sticks, wire, bones, toys, and other foreign objects which could

be picked up and thrown by the blade(s). Thrown objects can cause serious personal injury.

material toward roads, sidewalks, bystanders and

the like. Also, avoid discharging material against a

wall or obstruction which may cause discharged material to ricochet back toward the operator.

during operation and while performing an adjustment or repair to protect your eyes. Thrown objects which ricochet can cause serious injury to

the eyes.

fitting slacks and shirts. Loose fitting clothes and jewelry can be caught in movable parts. Never

operate this machine in bare feet or sandals.

operate the mower without the discharge cover or entire grass catcher in its proper place.

11. Do not put hands or feet near rotating parts or

under the cutting deck. Contact with the blade(s)

can amputate hands and feet.

12. A missing or damaged discharge cover can cause blade contact or thrown object injuries.

13. Stop the blade(s) when crossing gravel drives, walks, or roads and while not cutting grass.

14. Watch for traffic when operating near or crossing

roadways. This machine is not intended for use on

any public roadway.

15. Do not operate the machine while under the

influence of alcohol or drugs.

16. Mow only in daylight or good artificial light.

17. Never carry passengers.

18. Disengage blade(s) before shifting into reverse.

Back up slowly. Always look down and behind

before and while backing to avoid a back-over accident.

19. Slow down before turning. Operate the machine smoothly. Avoid erratic operation and excessive speed.

20. Disengage blade(s), set parking brake, stop engine and wait until the blade(s) come to a complete stop before removing grass catcher, emptying grass,

unclogging chute, removing any grass or debris, or making any adjustments.

21. Never leave a running machine unattended. Always turn off blade(s), place transmission in

neutral, set parking brake, stop engine and remove key before dismounting.

22. Use extra care when loading or unloading the

machine into a trailer or truck. This unit should not

be driven up or down ramp(s), because the unit could tip over, causing serious personal injury. The

unit must be pushed manually on ramp(s) to load or unload properly.

23.Mufflerandenginebecomehotandcancausea burn.Donottouch.

24.Checkoverheadclearancescarefullybeforedriving underlowhangingtreebranches,wires,door openingsetc.,wheretheoperatormaybestruckor pulledfromtheunit,whichcouldresultinserious injury.

25.Disengageallattachmentclutches,depressthe brakepedalcompletelyandshiftintoneutralbefore attemptingtostartengine.

26.Yourmachineisdesignedtocutnormalresidential grassofaheightnomorethan10".Donotattempt

tomowthroughunusuallytall,drygrass(e.g.,

pasture)orpilesofdryleaves.Drygrassorleaves maycontacttheengineexhaustand/orbuildupon

themowerdeckpresentingapotentialfirehazard.

27.Useonlyaccessoriesandattachmentsapproved

forthismachinebythemachinemanufacturer.

Read,understandandfollowallinstructions providedwiththeapprovedaccessoryor

attachment.

28.Dataindicatesthatoperators,age60yearsand above,areinvolvedinalargepercentageofriding mower-relatedinjuries.Theseoperatorsshould evaluatetheirabilitytooperatetheridingmower safelyenoughtoprotectthemselvesandothers

fromseriousinjury.

29.Ifsituationsoccurwhicharenotcoveredinthis manual,usecareandgoodjudgment.Contactyour

customerservicerepresentativeforassistance.

SLOPE OPERATION

Slopes are a major factor related to loss of control and tip-over accidents which can result in severe injury or death. All slopes require extra caution. If you cannot back up the slope or if you feel uneasy on it, do not mow

it. For your safety, use the slope gauge included as part of

this manual to measure slopes before operating this unit on a sloped or hilly area. If the slope is greater than 15 degrees as shown on the slope gauge, do not operate this unit on that area or serious injury could

result.

DO:

Mow up and down slopes, not across. Exercise extreme caution when changing direction on slopes.

Watch for holes, ruts, bumps, rocks, or other hidden objects. Uneven terrain could overturn the machine. Tall grass can hide obstacles.

3. Use slow speed. Choose a low enough speed setting so that you will not have to stop or shift while on the slope. Tires may lose traction on slopes even though the brakes are functioning properly. Always keep machine in gear when going down slopes to take advantage of engine braking action.

4. Follow the manufacturer's recommendations for wheel weights or counterweights to improve

stability.

5. Use extra care with grass catchers or other attachments. These can change the stability of the

machine.

6. Keep all movement on the slopes slow and gradual.

Do not make sudden changes in speed or direction.

Rapid engagement or braking could cause the front of the machine to lift and rapidly flip over backwards which could cause serious injury.

7. Avoid starting or stopping on a slope. If tires lose traction, disengage the blade(s) and proceed slowly straight down the slope.

DO NOT:

1. Do not turn on slopes unless necessary; then, turn slowly and gradually downhill, if possible.

2. Do not mow near drop-offs, ditches or embankments. The mower could suddenly turn over if a wheel is over the edge of a cliff, ditch, or if an edge caves in.

3. Do not try to stabilize the machine by putting your foot on the ground.

4. Do not use a grass catcher on steep slopes.

5. Do not mow on wet grass. Reduced traction could cause sliding.

6. Do not shift to neutral and coast downhill. Over- speeding may cause the operator to lose control of

the machine resulting in serious injury or death.

7. Do not tow heavy pull behind attachments (e.g. loaded dump cart, lawn roller, etc.) on slopes

greater than 5 degrees. When going down hill, the extra weight tends to push the tractor and may cause you to loose control. (e.g. tractor may speed

up, braking and steering ability are reduced,

attachment may jack-knife and cause tractor to overturn).

CHILDREN

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the machine and the mowing activity. They do not understand the dangers. Never assume that children will remain where you last

saw them.

a. Keep children out of the mowing area and in

watchful care of a responsible adult other than the operator.

b. Be alert and turn machine off if a child enters

the area.

c. Before and while backing, look behind and

down for small children.

d. Never carry children, even with the blade(s)

shut off. They may fall off and be seriously

injured or interfere with safe machine

operation.

e. Use extreme care when approaching blind

corners, doorways, shrubs, trees or other objects that may block your vision of a child who may run into the machine.

f. Disengage the cutting blade(s) before

shifting in reverse. The "No-Cut-In Reverse" feature is a reminder not to cut in reverse and

to help avoid back over accidents. Do not defeat it.

g. Keep children away from hot or running

engines. They can suffer burns from a hot

muffler.

h. Remove key when machine is unattended to

prevent unauthorized operation.

Never allow children under 14 years old to operate

the machine. Children 14 years old and over should

read and understand the operation instructions and safety rules in this manual and should be trained and supervised by a parent.

TOWING

1. Tow only with a machine that has a hitch designed for towing. Do not attach towed equipment except

at the hitch point.

2. Follow the manufacturers recommendation for

weight limits for towed equipment and towing on slopes.

3. Never allow children or others in or on towed

equipment.

4. On slopes, the weight of the towed equipment may

cause loss of traction and loss of control.

5. Travel slowly and allow extra distance to stop.

6. Do not shift to neutral and coast downhill.

SERVICE

SAFE HANDLING OF GASOLINE:

To avoid personal injury or property damage

use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Serious personal injury can occur when gasoline is spilled on yourself or your clothes which can ignite. Wash your skin and change clothes immediately.

a. Use only an approved gasoline container.

b. Never fill containers inside a vehicle or on a

truck or trailer bed with a plastic liner. Always place containers on the ground away from your vehicle before filling.

c. When practical, remove gas-powered

equipment from the truck or trailer and refuel it on the ground. Ifthis is not possible, then refuel such equipment on a trailer with a portable container, rather than from a gasoline dispenser nozzle.

d. Keep the nozzle in contact with the rim of the

fuel tank or container opening at all times until fueling is complete. Do not use a nozzle lock-open device.

e. Extinguish all cigarettes, cigars, pipes and

other sources of ignition.

f. Neverfuel machine indoors. g. Never remove gas cap or add fuel while the

engine is hot or running. Allow engine to cool at least two minutes before refueling.

h. Never over fill fuel tank. Fill tankto no more

than _/2inch below bottom of filler neck to

allow space for fuel expansion. i. Replace gasoline cap and tighten securely. j. If gasoline is spilled, wipe it off the engine

and equipment. Move unit to another area.

Wait 5 minutes before starting the engine. k. To reduce fire hazards, keep machine free of

grass, leaves, or other debris build-up. Clean

up oil or fuel spillage and remove any fuel

soaked debris. I. Never store the machine or fuel container

inside where there is an open flame, spark or

pilot light as on a water heater, space heater,

furnace, clothes dryer or other gas

appliances. m. Allow a machine to cool at least five minutes

before storing.

GENERAL SERVICE:

1. Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon

monoxide, an odorless, and deadly gas.

2. Before cleaning, repairing, or inspecting, make certain the blade(s) and all moving parts have stopped. Disconnect the spark plug wire and ground against the engine to prevent unintended starting.

3. Periodically check to make sure the blades come to complete stop within approximately (5) five seconds after operating the blade disengagement control. If the blades do not stop within the this time frame, your unit should be serviced professionally by an authorized MTD Service Dealer.

4. Check brake operation frequently as it is subjected to wear during normal operation. Adjust and service as required.

5. Check the blade(s) and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade(s) for damage (e.g., excessive wear, bent, cracked).

Replacetheblade(s)withtheoriginalequipment manufacturer's(O.E.M.)blade(s)only,listedinthis manual."Useofpartswhichdonotmeetthe originalequipmentspecificationsmayleadto improperperformanceandcompromisesafety!"

6. Mowerbladesaresharp.Wrapthebladeorwear gloves,anduseextracautionwhenservicingthem.

7. Keepallnuts,bolts,andscrewstighttobesurethe equipmentisinsafeworkingcondition.

8. Nevertamperwiththesafetyinterlocksystemor othersafetydevices.Checktheirproperoperation regularly.

9. Afterstrikingaforeignobject,stoptheengine, disconnectthesparkplugwire(s)andground againsttheengine.Thoroughlyinspectthe machineforanydamage.Repairthedamage beforestartingandoperating.

10.Neverattempttomakeadjustmentsorrepairsto

themachinewhiletheengineisrunning.

11.Grasscatchercomponentsandthedischarge coveraresubjecttowearanddamagewhichcould exposemovingpartsorallowobjectstobethrown.

Forsafetyprotection,frequentlycheckcomponents

andreplaceimmediatelywithoriginalequipment

manufacturer's(O.E.M.)partsonly,listedinthis manual."Useofpartswhichdonotmeetthe

originalequipmentspecificationsmayleadto

improperperformanceandcompromisesafety!"

12.Donotchangetheenginegovernorsettingsor over-speedtheengine.Thegovernorcontrolsthe

maximumsafeoperatingspeedoftheengine.

13.Maintainorreplacesafetyandinstructionlabels,as

necessary.

14.Observeproperdisposallawsandregulationsfor gas,oil,etc.toprotecttheenvironment.

_ ARNING: YOUR RESPONSIBILITY- Restrict the use of this power machine to persons who

* O0UPAHDDOWNSLOPES_NOTACROSS. * AVOIDSUDDENTURNS.

* ]DONOTOPERATETHE UNITWHEREiT

* iF MACHINESTOPSGOINGUPHiLL_STOP

* ]DONOTMOWWHENCHILDREN

* NEVERCARRYCHILDRENEVENWiTH

* LOOHDOWH&BEHINDBEFOREAND

*HEEP SAFETYDEVICES(GUARDS,

* REMOVEOBJECTSTHATCOULD

* HNOWLOCATIONANDFUNCTIONOFALL

* BESUREBLADE(S)AHDENOIHEARE

* BEFORELEAVINGOPERATOR'SPOSiTiON,

read, understand and follow the warnings and instructions in this manual and on the machine.

TO AVOID SERIOUS

iNJURY OR DEATH

COULDSLIPORTiP.

BLADE(S)ANDBACHDOWNHILLSLOWLY.

OROTHERSAREADOUHD.

BLADESOFF.

WHILEBACHmG.

SHIELDS,ANDSWITCHES,ETC.) iNPLACEADDWORKING.

RETHROWNBYTHEBLADE(S).

CONTROLS.

STOPPEDBEFOREPLACINGHANDS

0R FEETNEARBLADE(S).

DISENOADEBLADE(S),PLACETHECONTROL

LEVERiN NEUTRAL,ENGADEPADKING RRAHE_SHUTOFFANDREMOVEHEY.

READ OPERATOR'S

° I i A CORNER OF A BUILDING

OR A FENCE POST

15°

Z I--

_WARNING

Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower could overturn and cause serious injury. If operating a walk-behind mower on such a slope, it is extremely difficult to maintain your footing and you could slip, resulting in serious injury. Operate RIDING mowers up and down slopes, never across the face of slopes.

SECTION3: TRACTORSET-UP

IMPORTANT:Your tractor is shipped with motor oil in the engine. However, you MUST check the oil level before

starting the engine and operating. Refer to the separate Briggs & Stratton Operator/Owner Manual (or Tecumseh eng ne s Owner s Manua ) packed w th your tractor. Read nstruct ons carefu y.

NOTE: Reference to right or left hand side of the un#

is observed from the driver's seat, facing forward.

ToolsRequiredForSet-up

(1) 1/2" socket wrench (for steering wheel) (1) 9/16" wrench or socket wrench (for models with

standard adjustment seat only) (2) 7/16" wrenches or socket wrenches (for battery)

ShippingBraceRemoval

engine is off, remove the ignition key, and set

WARNING: Make sure the riding mower's the parking brake before removing the

shipping brace.

• Locate the shipping brace and warning tag found on the right side of the mower, between the discharge chute and the cutting deck. See Figure 1

AttachingTheSteeringWheel

The hardware for attaching the steering wheel has been packed within the steering wheel, beneath steering wheel cap. Carefully pry off the steering

wheel cap and remove the hardware.

NOTE: There are two different styles of steering

wheel cap. See Figure 2. Styles vary by modeL

• Remove the steering bellow from its packaged location on the PTO (blade engage) lever (found on

the right hand side of tractor). NOTE: Tractor

models 668 & 688 do NO T require a steering bellow and do NOT come equipped with one.

• On models so equipped, place the steering bellow

over the steering shaft extending through the dash.

See Figure 2.

NOTE: If the openings on each end of the steering

bellow are two different sizes, the smaller end goes

down, against the dash of the lawn tractor.

With the wheels of the tractor pointing straight

forward, place the steering wheel over the steering

shaft. Place the washer (with the cupped side down) over

the steering shaft and secure with the hex bolt. See

Figure 2. Place the steering wheel cap over the center of the

steering wheel and push downward until it "clicks" into place.

Steering _

Figure 1

While holding the discharge chute with your left hand, remove the shipping brace with your right hand by grasping it between your thumb and index

finger and rotating it clockwise.

_, ARNING: The shipping brace, used for

shipping purposes only, must be removed and discarded before operating your riding mower.

WARNING: The mowing deck is capable of

throwing objects. Failure to operate the riding mower without the discharge cover in the proper operating position could result in serious personal injury and/or property damage.

Wheel Cap 1 __'_

Hex Bolt

_=_ & Washer

St;hrif_g

St;e;iring

Figure 2

AttachingTheSeat

Seat styles vary by tractor model and there are three different styles available:

• Standard Adjustment

• Quick Adjustment &

• Knob Adjustment Refer to Figure 3, Figure 4 and Figure 5 to identify your

tractor's seat style and follow applicable instructions below.

NOTE: For shipping reasons, seats are either

fastened to the tractor seat's pivot bracket with a plastic tie, or mounted backward to the pivot bracket. In either case, free the seat form its shipping position and remove the two hex screws (or knobs, on models so equipped) from the bottom of seat before proceeding

with applicable instructions below.

Standard Adjustment

Hex Screws

Shoulder

Screws

Opening

in Slot

Pivot Bracket

Standard AdjustmentSeat

1. Position the shoulder screws (found on the base of the seat) inside the slot openings in the seat pivot

bracket. Figure 3.

2. Slide the seat slightly rearward in the seat pivot

bracket, lining up the rear slots in the pivot bracket with the remaining two holes in the seat's base.

3. Select desired position for the seat, and secure with the two hex screws removed earlier. See Figure 3.

QuickAdjustmentSeat

NOTE: If your seat was shipped mounted backwards

on the seat pivot bracket, pull out the tab found on the seat stop and hold # open while sliding the seat off the seat pivot bracket. See Figure 4.

1. Line up the plastic seat spacers with the slots in

seat pivot bracket.

2. Slide seat in until front seat spacer engages the

seat stop. See Figure 4.

WARNING: Before operating this machine, make sure the seat is engaged in the seat stop, stand behind the machine and pull back on seat until fully engaged into stop.

KnobAdjustmentSeat

1. Position the shoulder screws (found on the base of the seat) inside the slot openings in the seat pivot

bracket. Figure 5.

2. Slide the seat slightly rearward in the seat pivot

bracket, lining up the rear slots in the pivot bracket with the remaining two holes in the seat's base.

3. Select desired position for the seat, and secure with the two knobs removed earlier. See Figure 5.

Figure 3

QuickAdjustment

Seat Stop

Tab--

Pivot Bracket

Figure 4

KnobAdjustment

Knobs

Shoulder

Screws

Opening

in Slot_

Figure 5

GasandOilFill-up

The gasoline tank is located under the hood and has a capacity of 1-1/2 gallons. Do not overfill.

WARNING: Use extreme care when

handling gasoline. Gasoline is extremely flammable and the vapors are explosive.

Never fuel machine indoors or while the engine is hot or running. Extinguish

cigarettes, cigars, pipes, and other sources of ignition.

Service the engine with gasoline and oil as instructed in the separate Briggs & Stratton Operator/Owner Manual (or Tecumseh engine's Owner's Manual) packed with your tractor. Read instructions carefully.

IMPORTANT:Your tractor is shipped with motor oil in the engine. However, you MUST check the oil level before operating. Be careful not to overfill.

TirePressure

_, WARNING: Maximum tire pressure under

The tires on your unit may be over-inflated for shipping purposes. Reduce the tire pressure before operating the tractor. Recommended operating tire pressure is approximately 10 p.s.i for the rear tires & 14 p.s.i, for the front tires. Check sidewall of tire for maximum p.s.i.

any circumstances is 30 psi. Equal tire pressure should be maintained at all times.

Rubber

Boot

Hex Bolt

Figure 6

IMPORTANT:If the battery is put into service after the

date shown on top of battery, charge the battery as instructed on page 24 of this manual prior to operating

the tractor.

Identifyingthe Mulch Plug (ifsoequipped)

On tractor models with 38- and 42-inch decks so equipped, a mulch plug can be found within the cutting

deck's discharge opening.

NOTE: Refer to Mulchingon page 15 for more detailed information.

AttachingtheBatteryCables

NOTE: Some models are shipped with the battery

cables already connected.

NOTE: The positive battery terminal is marked Pos.

(+). The negative battery terminal is marked Neg. (-).

• The positive cable (heavy red wire) is secured to the positive battery terminal (+) with a hex bolt and

hex nut at the factory. Make certain that the rubber boot covers the terminal to help protect itfrom

corrosion.

• Remove the hex bolt and hex nut from the negative

cable.

• Remove the black plastic cover, if present, from the

negative battery terminal and attach the negative cable (heavy black wire) to the negative battery

terminal (-) with the bolt and hex nut.

• Make certain the hold-down rod is in position over the battery, securing it in place. See Figure 6.

If you'd prefer to operate the cutting deck without mulching, simply remove the mulch plug by

unthreading the plastic wing nut which fastens itto the cutting deck. This will allow the grass clippings to discharge out of the discharge opening during operation. See Figure 7.

Plastic Wing Nut

Figure 7

Mulch Plug

+ 22 hidden pages
