Msi MS-96D9 user Manual

MS-96D9

(v1.X) Server Board

i

Preface

MS-96D9

▍

Copyright Notice

The material in this document is the intellectual property of MICRO-STAR INTER­NATIONAL. We take every care in the preparation of this document, but no guar­antee is given as to the correctness of its contents. Our products are under con­tinual improvement and we reserve the right to make changes without notice.

Trademarks

All trademarks are the properties of their respective owners.

MSI® is registered trademark of Micro-Star Int’l Co.,Ltd.

￭

NVIDIA® is registered trademark of NVIDIA Corporation.

￭

ATI® is registered trademark of ATI Technologies, Inc.

￭

AMD® is registered trademarks of AMD Corporation.

￭

Intel® is registered trademarks of Intel Corporation.

￭

Windows

￭

AMI® is registered trademark of Advanced Micro Devices, Inc.

￭

Award® is a registered trademark of Phoenix Technologies Ltd.

￭

Sound Blaster® is registered trademark of Creative Technology Ltd.

￭

Realtek® is registered trademark of Realtek Semiconductor Corporation.

￭

JMicron

￭

Netware® is a registered trademark of Novell, Inc.

￭

®

is registered trademarks of Microsoft Corporation.

®

is registered trademark of JMicron Technology Corporation.

Revision History

Revision Revision History Date

V1.0 First release 2010/11

Technical Support

If a problem arises with your system and no solution can be obtained from the
user’s manual, please contact your place of purchase or local distributor. Alterna­tively, please try the following help resources for further guidance.

◙

Visit the MSI website for FAQ, technical guide, BIOS updates,
driver updates, and other information: http://www.msi.com/index.
php?func=service

◙

Contact our technical staff at: http://ocss.msi.com

ii

MS-96D9

Safety Instructions

Always read the safety instructions carefully.

￭

Keep this User’s Manual for future reference.

￭

Keep this equipment away from humidity.

￭

Lay this equipment on a reliable at surface before setting it up.

￭

The openings on the enclosure are for air convection hence protects the

￭

equipment from overheating. DO NOT COVER THE OPENINGS.
Make sure the voltage of the power source and adjust properly 110/220V

￭

before connecting the equipment to the power inlet.
Place the power cord such a way that people can not step on it. Do not place

￭

anything over the power cord.
Always Unplug the Power Cord before inserting any add-on card or mod

￭

ule.
All cautions and warnings on the equipment should be noted.

￭

Never pour any liquid into the opening that could damage or cause electrical

￭

shock.
If any of the following situations arises, get the equipment checked by ser

￭

vice personnel:

The power cord or plug is damaged.

◯

Liquid has penetrated into the equipment.

◯

The equipment has been exposed to moisture.

◯

The equipment does not work well or you can not get it work according

◯

to User’s Manual.
The equipment has dropped and damaged.

◯

The equipment has obvious sign of breakage.

◯

DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDI-

￭

TIONED, STORAGE TEMPERATURE ABOVE 60oC (140oF), IT MAY DAM­AGE THE EQUIPMENT.

MS-96D9

-

-

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer.

警告使用者:
這是甲類資訊產品，在居住的環境中使用時，可能會造成無線電干擾，在這種情

況下，使用者會被要求採取某些適當的對策。

廢電池請回收

For better environmental protection, waste batteries should be col
lected separately for recycling or special disposal.

iii

-

Preface

MS-96D9

▍

FCC-B Radio Frequency Interference Statement

This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are
designed to provide reasonable pro­tection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the measures listed below.

Reorient or relocate the receiving antenna.

◯

Increase the separation between the equipment and receiver.

◯

Connect the equipment into an outlet on a circuit different from that to

◯

which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.

◯

Notice 1

The changes or modications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RE­SEAU.

Micro-Star International

MS-96D9

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:

this device may not cause harmful interference, and

1)
this device must accept any interference received, including interference that

2)
may cause undesired operation.

iv

MS-96D9

MS-96D9

WEEE Statement

ENGLISH

To protect the global environment and as an environmentalist, MSI must
remind you that...

Under the European Union (“EU”) Directive on Waste Electrical and
Electronic Equipment, Directive 2002/96/EC, which takes effect on Au
gust 13, 2005, products of “electrical and electronic equipment” cannot be discarded
as municipal waste anymore and manufacturers of covered electronic equipment will
be obligated to take back such products at the end of their useful life. MSI will comply
with the product take back requirements at the end of life of MSI-branded products
that are sold into the EU. You can return these products to local collection points.

DEUTSCH

Hinweis von MSI zur Erhaltung und Schutz unserer Umwelt
Gemäß der Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte dürfen

Elektro- und Elektronik-Altgeräte nicht mehr als kommunale Abfälle entsorgt werden.
MSI hat europaweit verschiedene Sammel- und Recyclingunternehmen beauftragt,
die in die Europäische Union in Verkehr gebrachten Produkte, am Ende seines Leb
enszyklus zurückzunehmen. Bitte entsorgen Sie dieses Produkt zum gegebenen
Zeitpunkt ausschliesslich an einer lokalen Altgerätesammelstelle in Ihrer Nähe.

FRANÇAIS

En tant qu’écologiste et an de protéger l’environnement, MSI tient à rappeler

ceci...
Au sujet de la directive européenne (EU) relative aux déchets des équipement élec

triques et électroniques, directive 2002/96/EC, prenant effet le 13 août 2005, que les
produits électriques et électroniques ne peuvent être déposés dans les décharges

ou tout simplement mis à la poubelle. Les fabricants de ces équipements seront
obligés de récupérer certains produits en n de vie. MSI prendra en compte cette
exigence relative au retour des produits en n de vie au sein de la communauté

européenne. Par conséquent vous pouvez retourner localement ces matériels dans
les points de collecte.

-

-

-

РУССКИЙ

Компания MSI предпринимает активные действия по защите окружающей

среды, поэтому напоминаем вам, что....

В соответствии с директивой Европейского Союза (ЕС) по предотвращению
загрязнения окружающей среды использованным электрическим и электронным
оборудованием (директива WEEE 2002/96/EC), вступающей в силу 13
августа 2005 года, изделия, относящиеся к электрическому и электронному
оборудованию, не могут рассматриваться как бытовой мусор, поэтому
производители вышеперечисленного электронного оборудования обязаны
принимать его для переработки по окончании срока службы. MSI обязуется
соблюдать требования по приему продукции, проданной под маркой MSI на
территории EC, в переработку по окончании срока службы. Вы можете вернуть
эти изделия в специализированные пункты приема.

v

Preface

MS-96D9

▍

ESPAÑOL

MSI como empresa comprometida con la protección del medio ambiente, recomien­da:

Bajo la directiva 2002/96/EC de la Unión Europea en materia de desechos y/o equi
pos electrónicos, con fecha de rigor desde el 13 de agosto de 2005, los productos

clasicados como “eléctricos y equipos electrónicos” no pueden ser depositados en

los contenedores habituales de su municipio, los fabricantes de equipos electrónic­os, están obligados a hacerse cargo de dichos productos al termino de su período
de vida. MSI estará comprometido con los términos de recogida de sus productos

vendidos en la Unión Europea al nal de su periodo de vida. Usted debe depositar

estos productos en el punto limpio establecido por el ayuntamiento de su localidad o
entregar a una empresa autorizada para la recogida de estos residuos.

NEDERLANDS

Om het milieu te beschermen, wil MSI u eraan herinneren dat….
De richtlijn van de Europese Unie (EU) met betrekking tot Vervuiling van Electrische

en Electronische producten (2002/96/EC), die op 13 Augustus 2005 in zal gaan kun
nen niet meer beschouwd worden als vervuiling. Fabrikanten van dit soort producten
worden verplicht om producten retour te nemen aan het eind van hun levenscyclus.
MSI zal overeenkomstig de richtlijn handelen voor de producten die de merknaam
MSI dragen en verkocht zijn in de EU. Deze goederen kunnen geretourneerd wor­den op lokale inzamelingspunten.

SRPSKI

Da bi zaštitili prirodnu sredinu, i kao preduzeće koje vodi računa o okolini i prirodnoj

sredini, MSI mora da vas podesti da…
Po Direktivi Evropske unije (“EU”) o odbačenoj ekektronskoj i električnoj opremi, Di-

rektiva 2002/96/EC, koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju

pod “elektronsku i električnu opremu” ne mogu više biti odbačeni kao običan otpad
i proizvođači ove opreme biće prinuđeni da uzmu natrag ove proizvode na kraju
njihovog uobičajenog veka trajanja. MSI će poštovati zahtev o preuzimanju ovakvih

proizvoda kojima je istekao vek trajanja, koji imaju MSI oznaku i koji su prodati u EU.

Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.

-

-

POLSKI

Aby chronić nasze środowisko naturalne oraz jako rma dbająca o ekologię, MSI
przypomina, że...

Zgodnie z Dyrektywą Unii Europejskiej (“UE”) dotyczącą odpadów produktów elek­trycznych i elektronicznych (Dyrektywa 2002/96/EC), która wchodzi w życie 13 sier­pnia 2005, tzw. “produkty oraz wyposażenie elektryczne i elektroniczne “ nie mogą
być traktowane jako śmieci komunalne, tak więc producenci tych produktów będą
zobowiązani do odbierania ich w momencie gdy produkt jest wycofywany z użycia.
MSI wypełni wymagania UE, przyjmując produkty (sprzedawane na terenie Unii Eu­ropejskiej) wycofywane z użycia. Produkty MSI będzie można zwracać w wyznac-

zonych punktach zbiorczych.

vi

MS-96D9

MS-96D9

TÜRKÇE

Çevreci özelliğiyle bilinen MSI dünyada çevreyi korumak için hatırlatır:
Avrupa Birliği (AB) Kararnamesi Elektrik ve Elektronik Malzeme Atığı, 2002/96/EC

Kararnamesi altında 13 Ağustos 2005 tarihinden itibaren geçerli olmak üzere, elek­trikli ve elektronik malzemeler diğer atıklar gibi çöpe atılamayacak ve bu elektonik
cihazların üreticileri, cihazların kullanım süreleri bittikten sonra ürünleri geri topla­makla yükümlü olacaktır. Avrupa Birliği’ne satılan MSI markalı ürünlerin kullanım
süreleri bittiğinde MSI ürünlerin geri alınması isteği ile işbirliği içerisinde olacaktır.
Ürünlerinizi yerel toplama noktalarına bırakabilirsiniz.

ČESKY

Záleží nám na ochraně životního prostředí - společnost MSI upozorňuje...
Podle směrnice Evropské unie (“EU”) o likvidaci elektrických a elektronických

výrobků 2002/96/EC platné od 13. srpna 2005 je zakázáno likvidovat “elektrické
a elektronické výrobky” v běžném komunálním odpadu a výrobci elektronických
výrobků, na které se tato směrnice vztahuje, budou povinni odebírat takové výrobky
zpět po skončení jejich životnosti. Společnost MSI splní požadavky na odebírání
výrobků značky MSI, prodávaných v zemích EU, po skončení jejich životnosti. Tyto
výrobky můžete odevzdat v místních sběrnách.

MAGYAR

Annak érdekében, hogy környezetünket megvédjük, illetve környezetvédőként fel­lépve az MSI emlékezteti Önt, hogy ...

Az Európai Unió („EU”) 2005. augusztus 13-án hatályba lépő, az elektromos és elek­tronikus berendezések hulladékairól szóló 2002/96/EK irányelve szerint az elektro-

mos és elektronikus berendezések többé nem kezelhetőek lakossági hulladékként,

és az ilyen elektronikus berendezések gyártói kötelessé válnak az ilyen termékek
visszavételére azok hasznos élettartama végén. Az MSI betartja a termékvisszavé­tellel kapcsolatos követelményeket az MSI márkanév alatt az EU-n belül értékesített
termékek esetében, azok élettartamának végén. Az ilyen termékeket a legközelebbi

gyűjtőhelyre viheti.

ITALIANO

Per proteggere l’ambiente, MSI, da sempre amica della natura, ti ricorda che….
In base alla Direttiva dell’Unione Europea (EU) sullo Smaltimento dei Materiali

Elettrici ed Elettronici, Direttiva 2002/96/EC in vigore dal 13 Agosto 2005, prodotti
appartenenti alla categoria dei Materiali Elettrici ed Elettronici non possono più es

sere eliminati come riuti municipali: i produttori di detti materiali saranno obbligati
a ritirare ogni prodotto alla ne del suo ciclo di vita. MSI si adeguerà a tale Direttiva

ritirando tutti i prodotti marchiati MSI che sono stati venduti all’interno dell’Unione

Europea alla ne del loro ciclo di vita. È possibile portare i prodotti nel più vicino

punto di raccolta.

vii

-

Preface

▍

CONTENTS

▍

Copyright Notice �����������������������������������������������������������������������������������ii
Trademarks ������������������������������������������������������������������������������������������� ii
Revision History ����������������������������������������������������������������������������������� ii
Technical Support ��������������������������������������������������������������������������������ii
Safety Instructions ������������������������������������������������������������������������������ iii
FCC-B Radio Frequency Interference Statement ����������������������������� iv
WEEE Statement�����������������������������������������������������������������������������������v
Chapter 1 Overview ���������������������������������������������������������������������������1-1

Mainboard Specications ............................................................................ 1-2

Mainboard Layout
Watch Dog Timer Setting

.......................................................................................1-4

.......................................................................... 1-11

Chapter 2 Hardware Setup����������������������������������������������������������������2-1

Quick Components Guide ........................................................................... 2-2

Memory ....................................................................................................... 2-3

Power Supply .............................................................................................. 2-4

Rear Panel I/O ............................................................................................2-6

Connector .................................................................................................. 2-11

Jumper ...................................................................................................... 2-17

Slot ............................................................................................................ 2-19

Chapter 3 BIOS Setup �����������������������������������������������������������������������3-1

Entering Setup ............................................................................................3-2

The Menu Bar .............................................................................................3-4

Main

............................................................................................................3-5

Advanced .................................................................................................... 3-6

Chipset

...................................................................................................... 3-14

Boot ...........................................................................................................3-17

Security

..................................................................................................... 3-19

Save & Exit

................................................................................................ 3-20

viii

Chapter 1

Overview

Thank you for choosing the MS-96D9 v1.X, an excellent
server board from MSI.

Based on the Intel® ICH8M chipset for optimal system

efciency, the MS-96D9 accommodates the Intel® Pinev-

iew processor (CPU + GPU + Northbridge) and supports
up to 2 SO-DIMM slots to provide the maximum of 4GB
memory capacity.

In the entry-level and mid-range market segment, the
MS-96D9 can provide a high-performance solution for
today’s front-end and general purpose workstation, as
well as in the future.

1-1-1

Overview

MS-96D9

▍

Mainboard SpecificationS

Processor

Intel Pineview D425/D525 processor (CPU + GPU + Northbridge)

■

FSB

667MHz

■

Chipset

South Bridge: Intel ICH8M chipset

■

Memory

2 DDR3 800MHz SO-DIMM slots

■

Supports the maximum of 4GB Unbuffered / non-ECC DIMM

■

LAN

Supports Gigabit LAN by Intel 82574L Gb Ethernet controller

■

Supports Ethernet bypass function with Programming Relay (4 ports)

■

SATA

2 SATA 3Gb/s ports by Intel ICH8M

■

IDE

1 IDE port by Intel ICH8M

■

Supports Ultra DMA 66/100, PIO, Bus Master operation mode

■

CF

1 CompactFlash socket by Intel ICH8M

■

Onboard Input/Output

Front Panel

■

4 or 6 Gigabit LAN ports

-

2 USB 2.0 ports

-

1 RJ-45 serial console port

-

Onboard Connectors

■

1 USB 2.0 pinheader (2 ports)

-

1 serial port connector

-

1 SMBus connector

-

1 SPI Flash ROM pinheader (for debugging)

-

1 chassis intrusion connector

-

1 TPM connector

-

1 VGA port

-

1 keyboard/mouse connector

-

1-2

MS-96D9

Slot

1 PCIE x4 edge-type slot (with 2 PCIE x1 signal, for 4 GbE LAN sku only)

■

1 PCIE x1 edge-type slot (optional)

■

Form Factor

Mini-ITX: 170mm x 170mm

■

Mounting

4 mounting holes

■

MS-96D9

1-3

Overview

MS-96D9

▍

Mainboard Layout

1-4

MS-96D9 v1�X Mainboard (ATX Power, 6 GbE LAN)

MS-96D9

MS-96D9

MS-96D9 v1�X Mainboard (ATX Power, 4 GbE LAN, PCIE x4)

1-5

Overview

MS-96D9

▍

1-6

MS-96D9 v1�X Mainboard (ATX Power, 6 GbE LAN, PCIE x1)

MS-96D9

MS-96D9

MS-96D9 v1�X Mainboard (ATX Power, 4 GbE LAN, PCIE x4, PCIE x1)

1-7

Overview

MS-96D9

▍

1-8

MS-96D9 v1�X Mainboard (DC Power, 6 GbE LAN)

MS-96D9

MS-96D9

MS-96D9 v1�X Mainboard (DC Power, 4 GbE LAN, PCIE x4)

1-9

Overview

MS-96D9

▍

MS-96D9 v1�X Mainboard (DC Power, 4 GbE LAN, PCIE x4, PCIE x1)

1-10

MS-96D9

Watch dog tiMer Setting

Setup procedures

A. Enter super I/O conguration mode -

mov dx, 04eh
mov al, 087h
out dx, al
out dx, al

B. Set pin 77 to WDTO# function

mov dx,04eh
mov al,02Dh;; ;Register 2Dh
out dx,al
inc dx
in al,dx

and al,0FEh ;Cong Bit 0 As 0
out dx,al ;Cong PIN 77 as WDTO#

MS-96D9

C. Select Logical Device 8
mov dx, 04eh
mov al, 07h
out dx, al ;point to Logical Device Number Register
inc dx
mov al, 08h ;select Logical Device 8
out dx, al

1-11
