Getting Started
1. Getting Started
1.1 Introduction
Thank you for choosing the DigiVOX mini II V3.0 TV tuner and video capture unit.
This product turns your PC into a powerful desktop multimedia system quickly and
easily. Capture video and still images and experience real-time MPEG-2 recording.
The DigiVOX mini II V3.0 provides you with a high quality TV viewing experience with
true stereo sound!
1.2 Features
Antenna ready DVB-T Silicon Tuner
Watch TV in a resizable window or full-screen
Listen to DVB radio
Teletext and EPG support
TimeShifting functions
Record digital TV perfectly to MPEG-2
Scheduled recording and one-touch recording from EPG
Capture still images
Ultra-portable design you can take anywhere
Windows Vista Premium Certified
1.3 Package Contents
When removing the contents of the package, please inspect all items to ensure no
damage was sustained during shipping. The following items should be included in the
package:
DigiVOX mini II V3.0
Software Package CD*
User Manual
Quick Installation Guide
Portable antenna for DVB-T**
Remote control
* Includes MAGIX Goya Base software. Goya Base is XP, MCE 2005 and Vista compatible. Some
functions are unavailable; please upgrade to MAGIX Goya Multimedia for more functions.
** The included antenna is only suitable for areas with a strong DVB-T signal. If you have reception
problems, first try to move or reorient the antenna. Otherwise, you may need to use a stronger
antenna for better reception.
1
Getting Started
1.4 System Requirements
To successfully use the DigiVOX mini II V3.0 solution, please ensure that your
system meets the following requirements:
Pentium® 4 or AMD Athlon 2.0 GHz or faster, 2.4GHz or faster recommended
256 MB RAM (minimum), 512 MB RAM recommended
One available USB 2.0 port
AC97 compatible sound card
1GB free HD space
CD-ROM drive (for driver/software installation)
DirectX 9.0c or higher installed
Graphics card/chipset with full support for DirectX 9.0 or above; Windows XP MCE
2005 certified card/chipset required if using Windows XP MCE 2005
Microsoft XP SP2, XP MCE 2005* or Vista installed
* When using the DigiVOX mini II V3.0 with Windows Media Center in Windows XP MCE 2005, you
must install a 3rd party MPEG-2 decoder (such as Power DVD 6 or WinDVD6 or NVIDIA MPEG-2
decoder) in order to use the DigiVOX mini II V3.0 with Windows Media Center.
2
Installation
X
X
X
P
P
P
2. Installation
The following sections provide step-by-step instructions on installing and configuring
The following sections provide step-by-step instructions on installing and configuring
the card, accessories and software.
t ard, accessories and software
Before installing your DigiVOX mini II V3.0, insert the installation CD and an
Before installing your DIGIVOX mini II V3.0, please insert the installation CD and
installati n menu should load aut m ti lly.
installation menu should load automatically.
.
If you use Windows XP or MCE 2005, click on Windows XP/MCE 2005. If you use
If the Autostart program does not appear automatically when you insert your
Windows Vista, click on Windows Vista.
installation CD, start it manually by running the
If the Autostart program does not appear automatically
Autorun.exe file located on the installation CD, or by
when you insert your Installation CD, start it manually by
clicking the Start button, choosing Run…., and typing in
running the InstallCD.exe file located on the Installation
D:\autorun.exe (if D: is your CD-ROM drive)
CD, or by clicking the Start button, choosing Run…, and
typing in D:\InstallCD.exe.
(if D: is your CD-ROM drive)
Autorun.exe
2.1 DirectX 9.0
DIGIVOX mini II V3.0 requires to be supported by
Click on DirectX 9.0 and follow the prompts to
DirectX 9.0 or above. If the DriectX on your PC is
install DirectX. After the installation is completed,
lower then 9.0 version, please install DirectX 9.0
shut down the computer.
from autorun page.
Clicks on DirectX 9.0 and follow the prompts to
install DirectX. After the installation is completed,
shut down the computer.
3
Installation
2.2 Connecting the DigiVOX mini II V3.0
Connect the RF dongle to the connection port on the DigiVOX mini II V3.0. Connect
your digital antenna to the RF dongle.
Now plug the DigiVOX mini II V3.0 unit into an open USB 2.0 port on your PC.
4
2.3 Driver Installation
X
X
X
P
P
P
From the installation menu, please click on Driver Installation to install DIGIVOX
mini II V3.0 driver. Follow the prompts to complete installation of the driver.
2.4 Installation of the TV application
Installation
.
Install the TV software by clicking “Arcsoft Total Media”. Just follow the prompts to
install the software
2.5 Installation of MAGIX Goya Base
Click on MAGIX Goya Base to install the software. Just follow the prompts to
complete installation
.
5
Installation
Click on Settings.
Now click on TV.
Click on Set Up TV Signal.
A warning message will appear. Click
Yes.
Click Next.
Select Yes, use this region to
configure TV services if your current
region is displayed. If not, select No, I
want to select a different region.
Click Next.
2.6 Setup of Media Center (MCE 2005)
Double-click the My TV icon on your desktop to start Media Center.
6
Installation
If you chose to select your region,
select your region from the list and
click Next.
Click the circle next to Set Up Guide
Settings and click Next.
Click on Next.
If you want to use the Media Center
Guide, select Yes and follow the
onscreen prompts. If not, select No.
Click Next.
Click Start Scan to begin a channel
scan.
Windows MCE will now scan for
available channels in your area. This
may take a few minutes.
7
Installation
When the scan is finished, click Next
To watch TV, click on My TV from the
main menu.
Click on Live TV and you can now start
watching TV! For more details on how
to use Media Center, consult your
Windows MCE user manual or online
help.
! In order to use the DigiVOX mini II V3.0 (V3.0) with MCE 2005, you must install
an MCE Certified MPEG-2 decoder (also known as a DVD decoder) in order to
watch and record TV in Windows MCE. This DVD decoder is not included on
the installation CD. To install a DVD decoder, you can install software such as
CyberLink PowerDVD, InterVideo XPack, Sonic CinePlayer, nVidia DVD
Decoder or other such product that includes a DVD decoder.
! If you are unable to scan any channels or configure both tuners, make sure you
have updated your copy of Windows MCE through Update Rollup 2 (KB900325)
8
and through all available updates on Windows Update (including optional
updates).
2.7 Setup Media Center (Vista Premium Users)
1. Click on the Media Center icon
from the Start Menu or the QuickStart bar.
2. From the welcome screen, select
Custom setup and click OK.
3. Click Next and follow the onscreen
instructions to set up Media Center.
4. When you reach the Optional
Setup screen, select Configure tuner,
TV signal, and Guide and click Next.
5. If you are in the currently displayed
region, select Yes, use this region to
configure TV services and click Next.
Otherwise, click No, I want to select a
different region, click Next, and choose
your region from the list that appears then
click Next.
6. Here, select your TV signal
source. Select Antenna and click Next.
Installation
9
Installation
7. Here, choose Digial Terrestrial and
click Next
.
8. Click Start Scan and let the
channel scan finish, then click Next after
it finishes.
9. Here, select Yes if you want to use
Media Center’s Guide feature, or No if not.
Click Next.
10. This completes setup of your TV
card with Media Center. You can
continue to set up the rest of the options,
or you can select I am finished and
Next to finish setup.
.
10
__________________________________________________________
Total Media
3.Total Media
3.1 Total Media Interface Overview
1
2
3
4
5
6
7
8
10
11
9
23
12
1. Full Screen
2. EPG
3. Channels
4. Recorded TV
5. Schedule
6. Capture Frame
7. Teletext
8. Settings
9. Playback
10. Stop
11. Backward
13
14
15
16
17
18
19
21
20
22
12. Forward
13. Skip to beginning
14. Skip to end
15. Volume Bar
16. Volume Down
17. Volume Up
18. Channel Down
19. Channel Up
20. My Favorite
21. Aspect Ratio
22. MTS
23.RECORD
__________________________________________________________
11
Total Media
__________________________________________________________
3.2 Main Menu
Total Media is a Media Center Like software. You can not only watch Digital TV but a
Picture and Video Management tool. The below software instruction will guide you to
learn the magic of Total Media 3.
3.3 Total Media setting
Before you start to watch Totalmedia, you have to follow instruction to scan down all
available channels in your region.
3.3.1
On the TV Signal Setting, please
select your country and click “Next”
3.3.2
Click “Start” to scan Total Media
channels. All scanned channels
will be shown on channel list.
When scan is completed,
click “Next” to the next step.
__________________________________________________________
12
__________________________________________________________
3.3.3
Please click “Finish” to finish the
channel scanning.
3.4 Total Media Interface Instruction
Total Media
3.4.1 Full Screen
Click “ Full Screen” to enlarge TV
on
full monitor
Total Media
3.4.2 EPG Information
On EPG information page, you can
check TV program name list on
Total Media
3.4.3 Channel Information
When click “Channels” , All
Total Media
Channel list
channels for next few days
Channels will be on
__________________________________________________________
13
Total Media
__________________________________________________________
3.4.4 Recorded TV
All recorded TV will be saved on your
hard drive, and you can directly watch
all recorded TV from “Recorded TV”
option. You can also run “Video
Setting” from this page. (Please refer
to 3.6 for “Video Setting” Information)
3.4.5 Schedule
When click “Schedule”, the schedule
recording list will be shown. You can
choose “Add” to set new recording
schedule.
3.4.5.1 Add
You can set a new Total Media
channel,
schedule recording.
3.4.5.2Capture Frame
When “Capture Frame” is clicked, the
frame will be captured and on the left
up of screen, a “Frame Captured”
mark will be shown.
frequency and time table for
__________________________________________________________
14
__________________________________________________________
3.4.6 Teletext
Teletext service is only supported
on specific region. “Teletext”
option can only be enable when
the region provide teletext service.
3.4.7 Setting
On “setting” option, you can Reset
TV Signal / Edit Channel / TV
settings / Import or Export
Channel list.
Total Media
3.4.8 Recording Bar
On Recording Bar, you can record
TV program / Play recorded
programs / Adjust volume /
Change Channel / Show favorite
list / Adjust aspect ratio / adjust
MTS setting
__________________________________________________________
15
Total Media
__________________________________________________________
3.5 Picture Management
3.5.1
Please select your picture folder.
Click “Play” to play slide show. For
slide show setting,
3.5.2
On Slide Show Setting, you can
adjust the “interval” / “Transition”
and add Music Soundtrack
__________________________________________________________
16
__________________________________________________________
Total Media
3.6 Video Management
3.6.1 Video Information
To preview, rename or edit a video file, begin
by selecting the video. If the file is not in the
current directory, use the navigation control at
the top of the screen to go to the folder
containing the file.
3.6.2 Capture
If capture device is connected, you
can capture video clips from your DV /
Camcorder / VCR
3.6.3 Video Setting
Please refer to 3.7.5 for Video Setting
information
__________________________________________________________
17
Total Media
__________________________________________________________
3.7 Setting
3.7.1 General Setting
From General Setting, you can set
up the “Printer” / “Frame Storage”
and “Video Recording Storage”
location / Display setting on
hardware acceleration and 3D
effect.
On “About Total Media”,you can
see the TM version.
For online registration and version
update, you can upgrade the TM
to latest version by one button
clicking.
__________________________________________________________
18
__________________________________________________________
3.7.2 TV Setting
3.7.2.1.1 Reset TV signal
Reset your region and click “Next”
to rescan channels
3.7.2.1.2 Scan Channel
Click “Start” to rescan DVB-T
channels. When the scan is
Total Media
completed, click “Next” to finish
the channel rescan.
3.7.2.2 Edit Channel
It is editable or removable on
channel information. You can
directly change the channel name
from “Edit Channel” option.
__________________________________________________________
19
Total Media
__________________________________________________________
3.7.2.3 TV Settings
In some regions, Subtitle service
is provided by broadcaster. Right
click “Subtitle” to support
subtitling.
3.7.2.4 Import Channel List
If you would like to import any
Channel list, just choose the
correct route and click “Import” to
import new channel list.
3.7.2.5 Export Channel List
If you would like to save the
channel list, just choose the
correct route and click “Export” to
export new channel list
__________________________________________________________
20
__________________________________________________________
3.7.3.1 Video Setting
On regions supporting Subtitle
service, you can enable “Subtitle”
option for recorded TV program.
(Note: For not support subtitle
service region, Subtitle will not be
able to enabled)
3.7.3.2 Capture Setting
If capture device is detected, you
can find the device information
and adjust the setting from
“Capture Setting” option.
Total Media
3.7.4 Picture Setting
On Picture Setting, you can adjust
the slide show parameters to fit in
your request. You can also add
your favorite music to create better
slide show for your pictures.
__________________________________________________________
21
Remote Control
__________________________________________________________
4.1 Remote Control
1
2
3
3.7.2.3 TV Settings
In some regions, Subtitle service
is provided by broadcaster. Right
click “Subtitle” to support
subtitling.
4
1. POWER
2. MUTE
3. FAVORITE
4. NUMBER 0 to 9
5. Volume Up
6. Volume Down
7. ENTER
8. Channel Up
9. Channel Down
5
6
7
3.7.2.4 Import Channel List
If you would like to import any
Channel list, just choose the
correct route and click “Import” to
import new channel list.
3.7.2.5 Export Channel List
If you would like to save the
channel list, just choose the
correct route and click “Export” to
export new channel list
8
9
Note: Remote control can ony support TotalMedia, not MCE
__________________________________________________________
22
Loading...
