MSI DIGIVOX Duo User guide
MSI DIGIVOX Duo Installation Manual
|
Contents |
|
|
|
V1.0 |
Chapter 1 : MSI DIGIVOX Duo Hardware Installation .................................................................................... |
2 |
|
1.1 |
Package Contents ................................................................................................................................. |
2 |
1.2 |
System Requirements........................................................................................................................... |
2 |
1.3 |
Hardware Installation........................................................................................................................... |
2 |
Chapter 2 : MSI DIGIVOX Duo Installation..................................................................................................... |
3 |
|
2.1 The Driver Installation of MSI DIGIVOX Duo................................................................................... |
3 |
|
2.2 TotalMedia Application Installation of MSI DIGIVOX Duo .............................................................. |
4 |
|
2.3 The Remote Control Installation of MSI DIGIVOX Duo ................................................................... |
6 |
|
Chapter 3 Uninstallation of MSI DIGIVOX Duo........................................................................................... |
7 |
|
3.1 |
The Driver Uninstallation of MSI DIGIVOX Duo............................................................................ |
8 |
3.2 |
The Utilities Uninstallation of MSI DIGIVOX Duo ......................................................................... |
8 |
3.3 |
TotalMedia Application Uninstallation of MSI DIGIVOX Duo........................................................ |
8 |
Chapter 4 : FAQ ................................................................................................................................................. |
9 |
|
4.1 |
How to check if the driver has been installed successfully or not? ..................................................... |
9 |
Chapter 5 :Remote Functions........................................................................................................................... |
10 |
|
Chapter 6 : Use the TotalMedia at the First Time ............................................................................................ |
11 |
|
Chapter 7 : TV Function in TotalMedia ........................................................................................................... |
13 |
|
Chapter 8 : PIP / PBP Mode in TV Function ................................................................................................... |
24 |
|
1
Chapter 1 : MSI DIGIVOX Duo Hardware Installation
1.1 Package Contents
Unpack your MSI DIGIVOX Duo package and make sure that all items are intact. The following items should be included in your package:
MSI DIGIVOX Duo
Software Package CD* Users Manual
Quick Installation Guide Remote Controller DVB-T Antenna** USB Extension Cable
* Includes MAGIX Goya Base software. Goya Base is XP, MCE 2005 and Vista compatible. Some functions are unavailable; please upgrade to MAGIX Goya Multimedia for more functions.
**The included antenna is only suitable for areas with a strong DVB-T signal. If you have reception problems, first try to move or reorient the antenna. Otherwise, you may need to use a stronger antenna for better reception.
1.2 System Requirements
Pentium-IV 2.0GHz or above
512MB RAM of system memory or above One available USB 2.0 port
Graphics Card (Must Support Microsoft DirectX® 9.0) Sound Card (AC97 Compatible Sound Card)
2GB Free HD Space
CD-ROM or DVD-ROM Drive (For software installation) Microsoft DirectX® 9.0
Microsoft Windows ® XP SP2 / XP MCE 2005/ Vista Premium above (when using MCE 2005 OS,an extra 3rd party DVD decoder must be installed)
1.3 Hardware Installation
Please follow the steps shown below for installation of your MSI DIGIVOX Duo and follow the pictorial guide below for peripheral connections.
1.Connect the DVB-T antenna into the TV INPUT connector.
2.Plug MSI DIGIVOX Duo into the USB 2.0 port of your system
Chapter 2 : MSI DIGIVOX Duo Installation
The MSI DIGIVOX Duo package comes with complete Windows software utilities. These utilities can be found on the CD-ROM in this package. During installation, it is highly recommended to disable any sub-programs. These include applications such as antivirus software and system monitoring applications.
When you finish the hardware setup. The “Found New Hardware Wizard” window will pop up. Please click
“Cancel”.
2.1The Driver Installation of DIGIVOX Duo
1.Insert the installation CD into the CD ROM device. The autorun page will appear as the left image. Please choose “Driver Installation”
Note: Your USB device must be plugged in the USB2.0 port before installation.
2.Click “Start” to install the MSI DIGIVOX Duo driver. Please wait, while the installation is in process
3.Now the driver has been installed successfully on your computer and click “OK” to finish driver installation and go to next step.
3
2.2TotalMedia Application Installation of MSI DIGIVOX Duo
1.Return to the autorun page, and choose “TotalMedia Installation”.
2. The InstallShield Wizard will guide you through installation of TotalMedia application. Click “Next” to continue.
3. Click “Yes” accept all the terms of the proceeding License Agreement to install TotalMedia.
4. Please input user information and your TotalMedia serial number. Click “Next” to continue.
4
Note: While installing TotalMedia, it requires serial number. The serial number is printed on the front side of CD paper bag. Please check it from the CD bag.
5.Please choose the destination folder where you want to install the files. You can click “Browse” to change the destination folder. Finally click “Next” to go to next step.
6.Setup will add program icons to the Program Folder’s list. You may type a new folder name, or select one from the existing folders list. Click “Next” to start installing. Please wait while installation in process.
.
7.When the message as the one on the left image, click “Finish” to end the installation and go to next step.
5
2.3The Remote Control Installation of MSI DIGIVOX Duo
1.Return to the autorun page, and choose “Remote Control Installation”.
2. The InstallShield Wizard will guide you through installation of MSI DIGIVOX Duo remote utilities. Click “Next” to continue.
3. MSI DIGIVOX Duo utilities have been installed. Please click “ Finish” to finish your installation.
6
Chapter 3 Uninstallation of MSI DIGIVOX Duo
You can follow the steps to Uninstall.
(For Windows XP) Start -> Settings -> Control Panel -> Add / Remove Program
(For Windows Vista) Start -> Settings -> Control Panel -> Programs and Features
7
3.1The Driver Uninstallation of MSI DIGIVOX Duo
Choose “MSI DigiVox Duo BDA Driver” and click the “Remove”. Follow the instruction on screen to complete the uninstallation.
Note1: Your USB device must be plugged in the original USB2.0 port before uninstallation.
3.2The Utilities Uninstallation of MSI DIGIVOX Duo
Choose “MSI DigiVox Duo Utility” and click the “Remove”. Follow the instruction on screen to complete the uninstallation.
3.3TotalMedia Application Uninstallation of MSI DIGIVOX Duo
Choose “ArcSoft TotalMedia 3.5” and click the “Remove”. Follow the instruction on screen to complete the uninstallation.
8
Chapter 4 : FAQ
4.1 How to check if the driver has been installed successfully or not?
Ans : Right click on “My Computer” on the desktop and choose “Properties”. Once in “Properties” window, click on “Device Manager” in Hardware panel. Click on the plus icon of “Sound, video and game controllers” to open the device list. See Fig.1 below.
Fig.1
9
