1-1
Hardware Setup
Thank you for purchasing 651M/650GXM Combo
Series (MS-6769) v1.X Micro ATX mainboard. The 651M/
650GXM Combo is based on SiS® 651/650GX (702 pin BGA)
& SiS® 962L MuTIOL Media I/O (371 BGA) chipsets and
provides 6 USB 2.0 ports for high-speed data transmission. With
all these special designs, the 651M/650GXM Combo delivers a
high performance and professional desktop platform solution.
Getting Started
1-2
MS-6769 Micro ATX Mainboard
Mainboard Specifications
CPU
h Core frequency from 1.7GHz to 2.8 GHz
h Socket 478 for P4 processors (Williamette 478 / Northwood 478 / Celeron
478) at 400 MHz (SiS 650GX) / 533 MHz (SiS 651)
Chipset
h SiS 651/650GX (702 pin BGA)
- High performance host interface 533 MHz (SiS 651)
- High performance host interface 400 MHz (SiS 650GX)
- 64 Bit high performance PC133/266 memory controller
- Support AGP 4X/2X interface with fast write transaction
- High throughput SiS MuTIOL connect to SiS962L MuTIOL Media I/O
- High performance 2D/3D and Video Accelerator
h SiS 962L MuTIOL Media I/O (371BGA)
- High performance MuTIOL connect to SiS series NB
- Integrated multi-threaded I/O link ensures concurrency of up/down stream
data transfer with 1.2GB/s bandwidth
- Integrated MuTIOL connect to PCI bridge
- Dual IDE Master/Slave controller
- Integrated USB 2.0/1.1 host controller and Fast Ethernet MAC controller
- Integrated audio controller with AC97 interface
- Advanced power management and PC2001 compliance
- Integrated RTC, DMA, interrupt, and keyboard controllers
- Integrated PCI to LPCC bridge
Main Memory
h Supports two memory banks using two 184-pin unbuffered DDR 200/266
DIMMs, or two 168-pin unbuffered SDR 100/133 DIMMs.
h Supports up to 2GB memory size.
Slots
h One AGP (Accelerated Graphics Port) slot that supports AGP 2.0 4X/2X.
h Three PCI 2.2 32-bit Master PCI Bus slots (support 3.3V/5V PCI bus
interface).
1-3
Hardware Setup
On-Board IDE
h Dual IDE controllers integrated in SiS 962L.
h Support Bus Master, Ultra DMA 66/100/133 operation modes.
h Can connect up to four IDE devices.
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.
88 Mbytes.
- 1 serial port (COM1) and 1 VGA port
- 1 parallel port supports SPP/EPP/ECP mode
- 6 USB 2.0/1.1 ports (Rear * 2 / Front * 4)
- 1 Line-In/Line-Out/Mic-In port
- 1 game port
- 1 LAN RJ45 connector (optional)
Audio
h AC97 link controller integrated in Intel SiS 962L SB.
h 6 channels S/W audio codec (Realtek ALC650 codec): compliance with
AC97 2.1 Spec and meets PC2001 audio performance requirement.
h Support SPDIF out bracket (Optional).
LAN (Optional)
h SiS 962L integrated MAC + Realtek 8201BL PHY
- Support 10Mb/s and 100Mb/s auto-negotiation operation.
- Compliance with PCI 2.2 and PC99 standard.
h Supports Wake-On-LAN and remote wake-up.
h Supports ACPI power management.
BIOS
h 2MB Award BIOS with PNP BIOS, ACPI, SMBIOS 2.3, Green and Boot
Block.
h Provides DMI 2.0, WFM 2.0, WOL, WOR, chassis intrusion, and SMBus
for system management.
Dimension
h Micro-ATX Form Factor: 24.5 cm (L) x 24.5 cm (W).
1-4
MS-6769 Micro ATX Mainboard
Mounting
h 6 mounting holes.
Others
h Support Intel® Pentium4 /Celeron Socket 478 processor at 400/533 MHz
System Bus frequencies
h Live BIOS/Live Driver Update
h PC2001 Compliant
h Suspends to RAM/Disk
1-5
Hardware Setup
Mainboard Layout
651M/650GXM Combo Series (MS-6769) v1.X
Micro ATX Mainboard
BATT
+
SiS
962L
SiS
650GX / 651
JAUD1
JFP2
JFP1
JUSB2 JUSB1
A
T
X
P
o
w
e
r
S
u
p
p
l
y
SYSFAN1
CPUFAN1
JBAT1
BIOS
PCI Slot 3
PCI Slot 2
PCI Slot 1
I
D
E
1
I
D
E
2
Top : Parallel Port
Bottom:
COM A
VGA port
Top : m ou se
Bottom: keyboard
Top: LAN Jack
Bottom: USB
ports
JCD1
Codec
JSP1
Realtek
8201BL
Winbond
W83697HF
ATX1
Top :
Game port
Bottom:
Line-Out
Line-In
Mic
F
D
D
1
D
I
M
M
1
D
I
M
M
2
D
D
R
1
D
D
R
2
AGP Slot
1-6
MS-6769 Micro ATX Mainboard
PC Alert™ 4
The PC AlertTM 4 is a utility you can find in the CD-ROM disk. The
utility is just like your PC doctor that can detect the following PC hardware
status during real time operation:
Ø monitor CPU & system temperatures
Ø monitor fan speeds
Ø monitor system voltages
If one of the items above is abnormal, the program main screen will be
immediately shown on the screen, with the abnormal item highlighted in red.
This will continue to be shown until the condition returns to the normal status.
Users can use the Adjusting Keys to change the minimum and maximum threshold of each item for the system to send out a warning message.
Click Temperature to select the temperature modes of either Fahrenheit (oF)
or Celsius (oC). The PC Alert4 icon on the Status Area will show the current
CPU temperature.
temperature
modes
Adjusting Keys
COOLER XP
MSI Special Features
1-7
Hardware Setup
MSI Reminds You...
The new feature COOLER XP will work only if your mainboard
supports AMD Athlon XP CPU.
Items shown on PC Alert 4 vary depending on your system’s status.
To better protect the CPU from overheating, a new feature, COOLER
XP, has been added to decrease the temperature of AMD Athlon XP CPU.
To do so, simply click COOLER XP and the screen will show the Cute skin
(as shown below) with information about the CPU and chipset. Right-click
the mouse to select the skin you want to switch to.
Cute
1-8
MS-6769 Micro ATX Mainboard
Live BIOS™/Live Driver™
The Live BIOS™/Live Driver™ is a tool used to detect
and update your BIOS/drivers online so that you don’t need to
search for the correct BIOS/driver version throughout the Web
site. To use the function, you need to install the “MSI Live
Update 2” application. After the installation, the “MSI Live
Update 2” icon (as shown on the right) will appear on the screen.
Double click the “MSI Live Update 2” icon, and the following screen will appear:
Five buttons are placed on the leftmost pane of the screen. Click the desired
button to start the update process.
zz
zz
z Live BIOS – Updates the BIOS online.
zz
zz
z Live Driver – Updates the drivers online.
zz
zz
z Live VGA BIOS – Updates the VGA BIOS online.
zz
zz
z Live VGA Driver – Updates the VGA driver online.
zz
zz
z Live Utility – Updates the utilities online.
If the product you purchased does not support any of the functions listed
above, a “sorry” message is displayed. For more information on the update
instructions, insert the companion CD and refer to the “Live Update Guide”
under the “Manual” Tab.
1-9
Hardware Setup
You can right-click the MSI Live Monitor icon to perform the functions
listed below:
Ø Auto Search – Searches for the BIOS/drivers version you need immediately.
Ø View Last Result – Allows you to view the last search result if there is any.
Ø Preference – Configures the Search function, including the Search schedule.
Ø FAQ – Provides a link to a database which contains various possible questions
about MSI’s products for users to inquire.
Ø Exit – Exits the Live Monitor™ application.
Live Monitor™
The Live Monitor™ is a tool used to schedule the search
for the latest BIOS/drivers version on the MSI Web site. To use
the function, you need to install the “MSI Live Update 2”
application. After the installation, the “MSI Live Monitor” icon
(as shown on the right) will appear on the screen. Double click
this icon to run the application.
Double click the “MSI Live Monitor” icon at the lower-right corner
of the taskbar, and the following dialog box will appear. You can specify
how often the system will automatically search for the BIOS/drivers version,
or change the LAN settings right from the dialog box.
2-1
Hardware Setup
Chapter 2. Hardware
Setup
This chapter tells you how to install the CPU, memory
modules, and expansion cards, as well as how to setup the jumpers on the mainboard. It also provides the instructions on connecting the peripheral devices, such as the mouse, keyboard,
etc.
While doing the installation, be careful in holding the
components and follow the installation procedures.
Hardware Setup
2-2
MS-6769 Micro ATX Mainboard
Quick Components Guide
SDR DIMMs, p.2-7
CPU, p.2-3
Back Panel
I/O, p.2-11
FDD1, p.2-16
JFP2, p.2-23
JUSB1, p.2-21
PCI Slots, p.2-25
IDE1, IDE2,
p.2-17
JUSB2, p.2-19
ATX1, p.2-9
JAUD1, p.2-20
CONN1, p.2-10
JBAT1, p.2-24
JCD1, p.2-23
CPUFAN1, p.2-18
JFP1, p.2-19
SYSFAN1, p.2-18
DDR DIMMs, p.2-7
JSP1, p.2-22
2-3
Hardware Setup
Central Processing Unit: CPU
CPU Core Speed Derivation Procedure
If CPU Clock = 100MHz
Core/Bus ratio = 17
then CPU core speed = Host Clock x Core/Bus ratio
= 100MHz x 17
= 1.7 GHz
The mainboard supports Intel® Pentium® 4 Williamette, Celeron,
Northwood processor in the 478 pin package. The mainboard uses a CPU
socket called PGA478 for easy CPU installation. When you are installing the
CPU, make sure the CPU has a heat sink and a cooling fan attached on
the top to prevent overheating. If you do not find the heat sink and cooling
fan, contact your dealer to purchase and install them before turning on the
computer.
MSI Reminds You...
Overheating
Overheating will seriously damage the CPU and system, always make sure the cooling fan can work properly to protect
the CPU from overheating.
Replacing the CPU
While replacing the CPU, always turn off the ATX power supply or unplug the power supply’s power cord from grounded
outlet first to ensure the safety of CPU.
2-4
MS-6769 Micro ATX Mainboard
CPU Installation Procedures for Socket 478
1. Please turn off the power and
unplug the power cord before
installing the CPU.
2. Pull the lever sideways away
from the socket. Make sure
to raise the lever up to a 90degree angle.
3. Look for the gold arrow. The
gold arrow should point towards the lever pivot. The
CPU can only fit in the correct orientation.
4. If the CPU is correctly
installed, the pins should be
completely embedded into the
socket and can not be seen.
Please note that any violation
of the correct installation
procedures may cause
permanent damages to your
mainboard.
5. Press the CPU down firmly
into the socket and close the
lever. As the CPU is likely to
move while the lever is being
closed, always close the lever
with your fingers pressing
tightly on top of the CPU to
make sure the CPU is properly and completely embedded into the socket.
Open Lever
90 degree
Sliding
Plate
Close
Lever
Press down
the CPU
Gold arrow
Gold arrow
Gold arrow
Correct CPU placement
Incorrect CPU place me n t
X
O
2-5
Hardware Setup
Installing the CPU Fan
As processor technology pushes to faster speeds and higher performance,
thermal management becomes increasingly important. To dissipate heat, you
need to attach the CPU cooling fan and heatsink on top of the CPU. Follow
the instructions below to install the Heatsink/Fan:
2. Position the heatsink onto the retention mechanism.
1. Locate the CPU and its retention
mechanism on the motherboard.
3. Mount the fan on top of the heatsink.
Press down the fan until its four clips
get wedged in the holes of the retention mechanism.
4. Press the two levers down to fasten
the fan. Each lever can be pressed
down in only ONE direction.
retention mechanism
levers
2-6
MS-6769 Micro ATX Mainboard
5. Connect the fan power cable from the mounted fan to the 3-pin fan power connector
on the board.
fan power cable
NOTES
2-7
Hardware Setup
Memory
SDR DIMM Slots
(DIMM 1~2)
MSI Reminds You...
Make sure that you install only one type of memory modules
(either SDR or DDR) at one time. DO NOT install both types at
the same time. For security reason, the system will automatically power off if you simultaneously install SDR & DDR
memory modules onboard.
The mainboard provides two 184-pin unbuffered PC2700/PC2100/
PC1600 DDR SDRAM or two 168-pin unbuffered PC100/133 SDRAM and
supports the memory size up to 2GB. To operate properly, at least one DIMM
module must be installed.
DDR DIMM Slots
(DDR 1~2)
2-8
MS-6769 Micro ATX Mainboard
DDR Module Combination
Install at least one DIMM module on the slots. Memory modules can be
installed on the slots in any order. You can install either single- or doublesided modules to meet your own needs.
Memory modules can be installed in any combination as follows:
Installing DDR Modules
1. The DDR DIMM has only one notch on the center of module. The mod-
ule will only fit in the right orientation.
2. Insert the DIMM memory module vertically into the DIMM slot. Then
push it in until the golden finger on the memory module is deeply inserted in the socket.
3. The plastic clip at each side of the DIMM slot will automatically close.
MSI Reminds You...
You can barely see the golden finger if the module is properly
inserted in the socket.
Volt
Notch
S: Single Side D: Double Side
Slot Memory Module Total Memory
DDR 2
(Bank 2 & 3) S/D 64MB~1GB
Maximum System Memory Supported 64MB~2GB
DDR 1
(Bank 0 & 1) S/D 64MB~1GB
2-9
Hardware Setup
Installing SDR Modules
1. The SDR DIMM slot has 2 Notch Keys “VOLT and DRAM”, so the
DIMM memory module can only fit in one direction.
2. Insert the DIMM memory module vertically into the DIMM slot. Then
push it in.
3. The plastic clip at each side of the DIMM slot will automatically close.
SDR Module Combination
At least one DIMM module should be installed on the motherboard.
Memory modules can be installed on the slots in any order. The single-/doublesided memory modules that each DIMM slot supports are listed as below:
Volt
Notch
MSI Reminds You...
You can barely see the golden finger if the module is properly
inserted in the socket.
S: Single Side D: Double Side
Slot Memory Module Total Memory
DIMM 2
(Bank 2 & 3) S/D 64MB~1GB
Maximum System Memory Supported 64MB~2GB
DIMM 1
(Bank 0 & 1) S/D 64MB~1GB
2-10
MS-6769 Micro ATX Mainboard
Power Supply
The mainboard supports ATX power supply for the power system. Before inserting the power supply connector, always make sure that all components are installed properly to ensure that no damage will be caused.
ATX 20-Pin Power Connector: CONN1
This connector allows you to connect to an ATX power supply. To
connect to the ATX power supply, make sure the plug of the power supply is
inserted in the proper orientation and the pins are aligned. Then push down
the power supply firmly into the connector.
ATX 12V Power Connector: ATX1
This 12V power connector is used to provide power to the CPU.
PIN SIGNAL
1 GND
2 GND
3 12V
4 12V
ATX1 Pin Definition
PIN SIGNAL
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 -5V
19 5V
20 5V
PIN SIGNAL
1 3.3V
2 3.3V
3 GND
45V
5 GND
65V
7 GND
8 PW_OK
9 5V_SB
10 12V
CONN1 Pin Definition
CONN1
10
1
20
11
1
3
ATX1
2
4
2-11
Hardware Setup
The back panel provides the following connectors:
Back Panel
Mouse Connector
The mainboard provides a standard PS/2® mouse mini DIN connector
for attaching a PS/2® mouse. You can plug a PS/2® mouse directly into this
connector. The connector location and pin assignments are as follows:
PIN SIGNAL DESCRIPTION
1 Mouse DATA Mouse DATA
2 NC No connection
3 GND Ground
4 VCC +5V
5 Mouse Clock Mouse clock
6 NC No connection
Pin Definition
PS/2 Mouse (6-pin Female)
2
1
3
4
5
6
Mouse
Parallel
USB PortsKeyboard L-in MICL-out
LAN
(Optional)
COMA VGA Port
Midi/Joystick
Loading...
