SAFETY INSTRUCTIONS

Before using your appliance for the first time, please read these instructions carefully and follow the appliance’s instructions for use.

• Before plugging the appliance into

the mains, check that the

appliance’s supply voltage is compatible with that of your electricity supply. Otherwise, you

could damage the appliance or hurt yourself. Any error in connection will invalidate the warranty.

• This appliance has been designed for domestic use only. Use of the appliance for commercial or professional purposes may overload the appliance, causing damage to the appliance, or personal injury. The guarantee shall no longer apply in such conditions.

• To avoid electric shocks, never use the appliance with wet hands or on a damp or wet surface. Avoid wetting the appliance’s electrical components. Never immerse them in water.

• Do not allow children to use the appliance unsupervised.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capacities, or persons with a lack of experience or knowledge, unless they are supervised or have

been given instructions on how to use the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Always unplug the appliance when you have finished using it, when assembling and disassembling accessories and during cleaning.

• Do not use your appliance if it does not operate correctly, if it has been damaged or if the power cord or plug is damaged. To avoid all danger, these parts must be replaced by an approved service centre (see list in the service booklet).

• Any maintenance other than routine cleaning and upkeep by customers must be carried out by an approved service centre.

• Do not immerse the appliance, cord or plug in liquid.

• The power cord must be kept out of the reach of children and must not be placed near or come into contact with the hot parts of the appliance, sources of heat or sharp corners.

• To ensure that the guarantee remains valid and avoid any technical problems, never try to disassemble or repair the appliance yourself and do not let

an unqualified person do so. Bring your appliance to an approved service centre for repair.

• Do not move or unplug the appliance by pulling on the cord as it may cause an accident or cause the appliance to malfunction.

• The use of elements and accessories not recommended by the manufacturer may lead to personal injury, damage to the appliance or faulty operation, and the warranty will no longer apply.

• To avoid electric shocks, make sure that your fingers do not come into contact with the prongs on the plug when you plug in or unplug the appliance.

• Do not plug other appliances into the same mains socket using adapters to avoid any electrical overload which could damage the appliance or cause an accident. Do not use an extension lead unless you have checked it is in good condition.

For your safety, this appliance complies with applicable standards and regulations:

- Low Voltage Directive

- Electromagnetic Compatibility

- Environment

- Materials in contact with food

• To avoid all accidents, make sure that your hair, clothes and other objects do not get caught in the moveable parts of the appliance.

• Whilst in operation do not touch the beaters or mixers and do not insert any object (knife, fork, spoon, etc.) to avoid hurting yourself and causing an accident to others or damaging the appliance. You may use a spatula once the product is not in operation.

• To avoid damaging the appliance, never place the appliance and its accessories in the freezer, oven or microwave.

• The accessories are designed to prepare food products. Do not use them to mix other products.

• Do not use the mini mincer or the blender bowl accessories without the stabilising base.

DESCRIPTION

a. Mixer

a1. Ejection button to remove

kneaders or beaters

a2. Speed control/ turbo button

b. Multi-blade beaters for light

preparations (depending on model)

c. Multi-blade beaters for light

preparations (depending on model)

d. Kneaders for heavy dough

(depending on model)

e. Kneaders for heavy dough

(depending on model)

f. Metal collar g. Base (depending on model) h. Bowl (depending on model) i. Hinged arm lock/unlock button

(depending on model)

j. Mixer lock/unlock button

(depending on model)

BEFORE FIRST USE

• Remove the accessories from their packaging and clean using warm water.

k. Spatula (depending on model) l. Plastic blender shaft (depending

on model)

m. Stainless steel blender shaft

(depending on model)

n. 500 ml mini-chopper

(depending on model) n1 Bowl n2 Blade n3 Reducer

o. 800 ml blender bowl

(depending on model) o1 Graduated bowl o2 Blade o3 Leak-tight lid o4 Reducer

p. Measuring bowl (depending on

model)

q. Stabilising base (depending on

model)

r. Lid (depending on model)

Attention: The blender shaft (l or m)

and the blade of the mini-chopper (n2) and of the blender bowl (o2) are very sharp. Care should be

taken when handling.

USING THE APPLIANCE

Important: NEVER USE THE BEATERS OR KNEADERS AT THE SAME TIME AS THE BLENDER SHAFT, MINI-CHOPPER OR BLENDER BOWL.

MIXER FUNCTION WITH BEATERS OR KNEADERS:

• Manual use:

• Check that the appliance is unplugged, that the speed control (a2) is set to "0" and that there is neither blender shaft, nor minichopper nor blender connected to the back of the appliance.

• Insert the rods of each beater (b) or kneader (d) into the corresponding holes and lock into place. The beaters and kneaders

have a specific shape. The kneader or beater equipped with the metal collar (f) should be positioned to the left into the biggest hole (Fig. 1).

• Connect the appliance:

- Your appliance has 5 speed

levels and a turbo button. Always begin mixing or kneading at speed 1 initially, then move to speed 2, 3, 4 or 5 (Fig. 2).

- To knead thick dough, we

recommend using speed 5 only.

- You can also increase the speed

by pressing the turbo button. We however recommend that you use it only briefly (a maximum of 30 seconds for thick dough).

• After finishing, set the speed control

(a2) to "0".

• Disconnect.

• Then press the ejection button (a1)

to remove the beaters or kneaders.

• Using with the base (g): (depending on model)

• Check that the appliance is

unplugged, that the speed control (a2) is set to "0" and that there is no blender shaft.

• Insert the rods of each beater (c)

or kneader (e) into the corresponding holes and lock into place. The beaters and kneaders

have a specific shape. The kneader or beater with the metal collar (f) should be positioned to

the left, in the biggest hole (Fig. 1).

• Place the base (g) on the worktop:

- To raise the arm, unlock by

pressing the button (i) (Fig. 3).

- Position the bowl (h) (Fig. 3).

- Press the button (i) to unlock the

arm and lower it (Fig. 4).

- Place the mixer fitted with the kneaders or beaters on the hinged arm until you hear it click into place (Fig. 5).

Note: INSERT THE MIXER BY POSITIONING THE BEATERS OR KNEADERS IN THE NOTCHES (Fig. 5).

• Connect the appliance:

- Your appliance has 5 speed levels

and a turbo button. Always begin mixing or kneading at speed 1

initially, then move to speed 2, 3, 4 or 5 (Fig. 2).

- To knead thick dough, we

recommend using speed 5 only.

- You can also increase the speed

by pressing the turbo button (a2); We however recommend that you use it only briefly (a maximum of 30 seconds for thick dough).

• After finishing, set the speed control

(a2) to "0".

• Disconnect and press the unlock

button (i) to raise the hinged arm. Then press the mixer unlock button (j) to remove the mixer from its stand.

• Then press the ejection button (a1)

to remove the beaters or kneaders.

BLENDER FUNCTION (DEPENDING ON MODEL)

• Check that the appliance is unplugged, that the speed control (a2) is set to "0" and that the beaters or kneaders have been removed from the appliance.

• Lift the panel at the back of the appliance and screw the blender shaft (l or m) anti-clockwise without forcing it until you hear a click (Fig. 6).

• Connect the appliance:

- Dip the blender shaft into the

preparation before starting to avoid splashing.

- Start using the speed control (a2),

(Fig. 2), initially at speed 1 then 2, 3, 4, 5. Use the Turbo button (a2) if

the recipe requires more power.

- Stop the appliance before removing the blender shaft from the preparation (to avoid splashing).

If you feel resistance when screwing in, this means that shaft is not correctly aligned. You should remove it completely and screw it in again correctly.

Removing the blender shaft:

• Stop the appliance by selecting

"0", disconnect it and unscrew the blender shaft (l or m) by turning clockwise.

Do not use the blender shaft:

• In a saucepan on the hob.

• Do not use it empty or with ice cubes, to chop raw meat, dried fruit (almonds, hazelnuts, etc.).

500ML MINI-CHOPPER FUNCTION (DEPENDING ON MODEL)

- Place the bowl (n1) on the

stabiliser base (q).

- Place the blade (n2) on the shaft

of the bowl (n1).

- Place the food in the bowl (n1)

and then place the reducer (n3).

• Check that the appliance is unplugged, that the speed control (a2) is set to "0" and that the beaters or kneaders are no longer on the appliance.

- Lift the panel at the back of the

appliance and place the appliance on the reducer (n3) of

the mini-chopper.

- Connect the appliance and start

using the speed control (a2),

(Fig. 2), initially at speed 1 then 2, 3, 4, 5. Use the Turbo button (a2) if

the recipe requires more power.

- Once the preparation is finished, stop the appliance and disconnect it.

- Remove the appliance and then the reducer (n3).

- Remove the blade (n2) holding it by the plastic part.

- After use, remove the food.

- Do not operate this accessory empty.

800ML BLENDER BOWL FUNCTION (DEPENDING ON MODEL)

- Place the bowl (o1) on the stabiliser base (q).

- Place the blade (o2) on the shaft of the bowl (o1).

- Place the food in the bowl (o1) and then place the leak-tight lid (o3) and the reducer (o4).

• Check that the appliance is unplugged, that the speed control

(a2) is set to "0" and that the beaters or kneaders are no longer on the appliance.

- Lift the panel at the back of the

appliance and place the appliance on the reducer (o4) of the blender bowl.

- Connect the appliance and start

using the speed control (a2),

(Fig. 2), initially at speed 1 then 2, 3, 4, 5.

Use the Turbo button (a2) if the recipe requires more power.

- Once the preparation is finished,

stop the appliance and disconnect it.

- Remove the appliance, the

reducer (o4) and then the lid (o3).

- Remove the blade (o2) holding it

by the plastic part.

- After use, remove the food.

- Do not operate this accessory

empty.

QUANTITIES AND PREPARATION TIMES

Accessories Maximum quantity Maximum time Speed

Multi-blade

beaters

Whipped egg

whites

Pound cake

12 egg whites 4 min 5

9 eggs,

470 g plain flour,

470 g melted butter,

470 g sugar,

1 teaspoon baking powder,

2 pinches of salt,

1 sachet vanilla sugar

5 min 5

Kneaders with base

Bread dough

Kneaders

without base

Bread dough

Blender shaft

Soup

Mini-chopper

Chopped

parsley

Blender bowl

Milkshake

500 g flour,

300 ml water,

10 g salt,

10 g baker's yeast

500 g flour,

300 ml water,

10 g salt,

10 g baker's yeast

160 g cooked vegetables,

240 g stock

25 g parsley 15 s Turbo

150 g banana,

300 ml milk, 6 ice cubes

3 min 5

55 sec ON

with a rest time

of 1 min at least

Do not operate more

than 5 times

consecutively

45s Turbo

Turbo

CLEANING

• Make sure that the appliance is unplugged.

• Clean the beaters (b/c), kneaders (d/e), blender shaft (l/m), mini- chopper (n) and blender bowl (o) immediately after use to avoid remains of mixtures with egg or oil sticking or drying on them.

• You can wash the beaters (b/c), kneaders (d/e), the plastic and metal blender shaft (l/m), bowl, blade, mini chopper stabilising base (n1/n2/q) and the bowl, blade, sealing lid and stabilising base of the blender (o1/o2/o3/q) in water with a sponge and some washing-up liquid.

- The beaters (b/c), kneaders (d/e), bowl, blade and mini chopper stabilising base (n1/n2/q) and the bowl, blade, sealing lid and stabilising base of the blender bowl (o1/o2/o3/q) can be placed in the dishwasher.

The blender shaft (l/m) can be washed in the top basket of the dishwasher with the blades facing upwards.

• Blades are very sharp, ensure care is taken when placing and removing the blades from the dishwasher.

• Clean the base (g), the reducer of the mini-chopper (n3), the reducer of the blender (o4), the appliance body (a) only with a wet sponge and dry thoroughly.

• Never wash the motor unit in the dishwasher.

• Do not use scouring pads or objects containing metal parts.

• Never immerse the motor unit in water. Wipe with a dry or slightly damp cloth.

Attention: The blender shafts (l or m), the blade of the mini-chopper (n2) and the blade of the blender (o2) are very sharp. Care should be taken when cleaning them.

END-OF-LIFE ELECTRIC OR ELECTRONIC PRODUCTS

Think of the environment!

Your appliance contains valuable materials which can be recovered or recycled.

Take it to a local civic waste collection point.
