Motorola XT886 User Guide

MOTOROLA XT886

Congratulations

MOTOROLA XT886

Introducing your new MOTOROLA XT886, the slim, fast, and intelligent phone. It has tons of advanced features for everything you want to do—web browsing, multimedia, and more.

• A blistering fast dual-core 1.2 GHz processor lets your

phone download web pages in under a second, and makes multi-tasking a snap.

• SMARTACTIONS™ lets you set the rules for the

ultimate in phone customization and power optimization.

• Capture life's moments in full 1080p HD video with

your 8MP camera. Your phone’s 4.3" qHD Super AMOLED Advanced display makes video playback crisper and more vivid than ever before.

Note: Certain apps and features may not be available in all countries.

Caution: Before assembling, charging, or using your phone for the first time, please read the important safety, regulatory and legal information provided with your product.

This product meets the applicable limit for exposure to radio waves (known as SAR) of

1.6 W/kg (FCC & IC). The limits and guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The highest SAR values measured for this device are listed in the regulatory information packaged with your product.

Note: When using the product while worn on your body, either use an approved accessory such as a holster or maintain a distance of 2.5 cm (1 inch) from the body to ensure compliance with SAR requirements. Note that the product may be transmitting even if you are not making a phone call.

•Answers: Phone—touch Apps >

• Updates: Phone updates, computer software, user

guides, and more at www.motorola.com/myXT886

• Accessories: Find accessories for your phone at

www.motorola.ca

• Social: The latest news, tips & tricks, videos, and so

much more—join us on:

Yo u Tu b e ™ www.youtube.com/motorola

Facebook™ www.facebook.com/motorola

Twitter www.twitter.com/motorola

Help Center

1Congratulations

Your phone

04:00

CameraTextPhone People

Browser

1 of 7

See all your apps.

Touch the Launcher icon.

Gmail Maps Play Store

Micro USB

Connector

SIM Slot

microSD Slot

3.5mm

Headset Jack

Volume Keys

Power Key

Press = sleep Hold = power

8MP Camera (on back)

Recent AppsHomeBack

Front

Camera

Notification

Light

the important keys & connectors

Note: Your phone might look a little different.

2 Your phone

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Apps & updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Social networking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Personalize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Tips & tricks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Product Safety & Legal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 511

Let’s go

let’s get you up and running

Assemble & charge

SIM in.

4:00

Fri, February 10

microSD in.

Note: This product uses a non-removable battery. The battery should only be replaced by a Motorola-approved service facility. Any attempt to remove or replace your battery may damage the product and void your warranty.

Tip: In the unlikely event that your device becomes unresponsive, try a forced reboot—press and hold both the Power key and the Down volume key for up to 10 seconds.

Tip: To save battery life, see “Battery tips” on page 40.

Service Provider

Charge up.

SIM

micro SIM micro SIM

Note: Pull

down the cover

to insert the

SIM and

microSD cards.

+ Adapter

Note: To avoid SIM card damage, turn off your phone before you insert or remove the SIM card.

3Let’s go

Set up & go

4:00

Fri, February 10

Service Provider

vicce

Select a language.

Complete initial setup steps.

Finish.

Turn on.

Welcome

English (Canada)

Start

Make it Google

Got Gmail? Sign in now.

Never lose your stuff again. A Google Account keeps everything safe.

Get an account

Not now

Setup

Congratulations!

Your setup is now complete!

If you have setup any accounts, we will now import your content, such as contacts and email. This may take up to 30 minutes but you can start using your phone right away.

We recommend setting a Security Lock for this phone by going into Settings > Security.

Done

Wi-Fi connect

To use a Wi-Fi network for even faster Internet access, touch the status bar at the top of the home screen and drag it down. Touch the

Wi-Fi networks available

notification to select a network.

You can also touch Apps >

Settings >Wi-Fi >SCAN

to search for and connect to wireless networks. There’s more in “Wi-Fi networks” on page 37.

Cool content & more

Browse and download thousands of the coolest apps on the planet from Google Play™.

Download new apps with “Browse & install apps” on page 13. You can install a microSD memory card in your phone, and load it up with photos, videos, and music from your computer (see “Memory card & file management” on page 45).

Note: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. Contact your service provider for details.

4 Let’s go

Controls

Slide two fingers apart or together to zoom in or out.

Drag or flick to scroll.

a few essentials

Touch

It’s all in the touch:

• Touch: Choose an icon or option.

• Touch & Hold: Move items in the home screen.

•Drag or flick: Scroll slowly (drag) or quickly (flick).

• Pinch or double-touch: Zoom in and out on

websites, photos, and maps.

lark St

born St

Lock, UNLOCK, on, & off

To lock the screen, press the Power key, or let the screen time out (don’t press anything).

To unlock the screen, press the Power key, then touch and flick to .

Touch and flick to

Mon, May 21

Phone

turn sound on/off.

Wacker D r

E Randolph St

E Wacker Pl

State/Lake

W Lake St W Lake St

Lake

Randolph/

Wabash

Touch and flick to:

N Micigan

Camera

Messages

Unlock

unlock.

make a call.

send a text.

open the camera.

Your touchscreen is on when you need it and off when you don’t.

5Controls

• When you hold the phone to your ear during calls,

Recent

Apps

Home

Back

your touchscreen sleeps to prevent accidental touches.

• To make your touchscreen sleep or wake up, just

press the Power key.

• To change how long your phone waits before the

screen goes to sleep automatically, touch Apps >

Settings >Display >Sleep

• To make the screen lock when it goes to sleep, see

“Screen lock” on page 48.

Note: Your touchscreen might stay dark if the sensor just above it is covered. Don't use covers or screen protectors (even clear ones) that cover this sensor.

Rotate the screen

When you turn your phone, the touchscreen can rotate to stay right-side up:

Find it: Apps >

screen

Settings >Display >Auto-rotate

Back, home, & Recent apps

Tou ch Ho m e t o close any menu or app and return to the home screen. In the home screen, touch Recent Apps to show the most recent apps used, then touch an app to open it.

Touch Back to go back .

In some apps you can touch Menu to open menu options, and touch to start a search.

Press

Power KEY menu

Press and hold the Power key to turn off your phone

Power off

( phone into low-power and off, or change the sound setting.

), turn off all wireless connections and put the

Sleep

mode, turn

Airplane mode

6 Controls

Adjust volume

Press the volume keys to change ring volume (in the home screen) or earpiece volume (during a call).

When playing music or video files, press the volume keys to adjust media volume.

Speak

Voice actions

You can do a lot of things just by talking to your phone—call or text your friends, get directions, set an alarm, and more.

1 Touch Apps >

Shortcut: Touch in the Google™ Search widget.

2 Say what you want to do.

If voice search doesn’t understand what you said, it shows a list of search terms and actions you can touch to choose.

Some actions, like “send email” and “note to self,” prompt you to complete the action by saying or typing more information.

Voice Action Commands

Say Followed by

words you

Example: “Motorola accessories.”

want to search for

contact name

Example: “Mike LeBeau” (opens Mike’s contact card).

“Call” Contact name & optionally, “home”,

“mobile”, or “work.”

Example: “Call Mike LeBeau at home.”

“Call” Digits of a phone number.

Example: “Call 650 555 1234.”

“Call” Business name.

Example: “Call Ruth’s Floral Shoppe.”

“Map of” Address, name, business name, type

of business, or other location.

Example: “Map of Golden Gate Park, San Francisco.”

7Controls

Say Followed by

“Directions to” or “Navigate to”

“Go to” Search string or URL.

“Send text” or “Send SMS”

“Send email”

8 Controls

Address, name, business name, type of business, or other destination.

Example: “Directions to 1299 Colusa Avenue, Berkeley, California,” or “Navigate to Union Square, San Francisco.”

Example: “Go to Google.com.”

“To” & contact names, “Message” & message text (speak punctuation).

Example: “Send text to Hugh Briss, subject, new shoes, message, I can’t wait to show you my new shoes, period.”

One or more of: “To” & contact names, “Cc” & contact names, “Bcc” & contact names, “Subject” & subject text, “Message” & message text (speak punctuation).

Example: “Send email to Hugh Briss, subject, new shoes, message, I can’t wait to show you my new shoes, period.”

Say Followed by

“Note to self”

“Set alarm” “Time” or “for” & time (such as

“Listen to” Words to search YouTube for (such as

For more information, touch Apps >

Help >Help Center >Tutorial

Message text.

Example: “Note to self: remember the milk.”

“10:45 a.m.” or “20 minutes from now”), “Label” & name of alarm.

Example: “Set alarm for 7:45 p.m., label, switch the laundry.”

the name of a song, artist, or album).

Example: “Listen to: Black Hole Sun.”

Voice text entry

Touch a text entry field to open the touchscreen keypad. Touch , then say what you want to type.

SmartActions™

Tired of doing the same tasks over and over again? Let

SMARTACTIONS

do things, like automatically dim the touch screen when the battery is low, set your ringer to vibrate at work, or send auto-reply messages when you’re busy.

do them for you. You can create rules to

Find it: Apps >

SAVE CANCEL

Meeting Rule

TRIGGERS

ACTIONS

Calendar events

from all calendars

Location

Select a location

Ringer volume

Silent - Vibrate

Touch here to add

Auto reply text

“Auto-reply: In a mtg, I’ll...

See Smart Actions options.

Save your changes.

Add triggers (like events, times, or places) that activate the actions.

Deactivate triggers or actions by dragging them to the right.

Add actions (like silencing the ringer) to make them happen when trigger conditions are met.

To learn how to use

SMARTACTIONS

app and touch Menu >

Touch to create a

SMARTACTIONS

, open the

Help

rule.

Screen capture

Share a screen capture of your favorite playlist, or your new high score. If you can see it on your phone, you can share it with your friends.

To capture the screen, press the Power key and down

volume key. Follow the instructions to name and store the file.

For more information, touch Apps

SMARTACTIONS

>Menu >

Help

9Controls

Home screen

04:00

CameraText

Phone People

Browser

1 of 7

See all your apps.

Touch the Launcher icon.

Gmail Maps Play Store

Status Bar

Flick left or right to see more pages of widgets & shortcuts.

Shortcuts

Touch to open.

Notifications

Drag this bar down to see details.

Favorites Tray

Touch Apps to see all your apps & widgets.

Navigate

Back , Home & Recent Apps .

Kristine Kelley

Not even ready to go back to school

3pm

Budget Meeting

THU

JUL

THU

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in one place. It’s what you see when you turn on the phone or touch Home from a menu. It’s basically like this:

Note: Your home screen might look a little different.

10 Home screen

Use & change your home screen

On your home screen, shortcuts are icons that open your favorite apps, web bookmarks, contacts, mail labels, playlists, and more. Widgets are live apps or tools that provide news, weather, messages, and other updates.

To see other pages of shortcuts and widgets, flick the home screen left or right.

• To open something, touch it. Touch Home or

Back to return to the home screen.

Tip: When you open a widget, touch Menu to see any options or settings. You can choose accounts for

Calendar, Email

• To resize widgets, touch

and hold a side until you feel a vibration, then drag.

• To add shortcuts to the

home screen, touch Apps , touch and hold an app, then drag it to a spot on the home screen.

To c r e a t e a shortcut folder, drag one shortcut on top of another to put them both in a folder. To add other shortcuts, drag them onto the folder icon. To name the folder, touch it and enter a name at the bottom.

, and widgets.

Budget Meetin

• To add widgets, touch Apps , touch

Touch here to enter text.

Touch to search by voice.

4:00

June 26, 2012

New voicemail

Dial *86

10:41 AM

Wi-Fi networks available

Select a Preferred Network

11:20 AM

Jim Somers: Meeting time?

paul.wang.6@gmail.com

11:23 AM

3 new messages

Yahoo!

10:49 AM

Widgets

touch and hold a widget (or flick left to see more widgets).

• To move widgets or shortcuts, touch and hold them,

then drag to a new location.

• To rem ove shortcuts or widgets from the home

screen, touch and hold them, then drag to

Remove

the top.

• To change wallpaper, touch and hold a blank spot on

the home screen.

Shortcuts in the Favorites Tray at the bottom of the home screen appear in all page views. To change a shortcut in your Favorites Tray (except Apps ), touch and hold a shortcut, then drag it out of or into the Favorites Tray.

Search

Touch the Google™ Search widget in the home screen (or touch Apps > search text.

), then start typing your

, then

As you type, suggestions appear below the search field:

• To search for a suggestion, touch it.

• To add a suggestion to the search field, touch the

arrow beside it.

• To search for the text in the search field, touch on

the touchscreen keypad.

The browser shows a list of search results.

To set where Google™ Search looks on your phone, touch Menu >

Settings >Searchable items

. To adjust

Google Search privacy settings, touch Menu

Settings >Google Search

phone status & notifications

Icons at the top of the screen notify you about messages and phone status. To see your notifications, touch the status bar and drag it down. Touch a notification to select it.

To remove a notification from the list, flick it left or right. To remove all notifications, touch .

11Home screen

Status & notification icons

network (full signal) 3G (fast data)

network (roaming) 4G (fastest data)

network (no connection)

Wi-Fi in range Wi-Fi connected

Bluetooth™ on Bluetooth

USB connected background

downloading warning

active call missed call

airplane mode microSD card

new text message alarm set

new email calendar event

new voicemail music player active

vibrate speakerphone on

sound off call muted

battery (charging) battery (full charge)

Tip: Network and Wi-Fi connection icons turn blue when your phone exchanges data with your Google™ account.

12 Home screen

GPS active

connected

data sync

reminder

Note: Apps you download from Google Play™ may show other icons in the status bar to alert you to specific events.

Apps & updates

ALL APPS

WIDGETS

All apps

New group

Downloaded

Frequent

Add to Home

Select the apps screen view.

Choose the app group you want to see.

Find new apps on Google Play™.

Create a new app group.

Add app group shortcut to home screen.

get the app you want

Quick start: Apps & updates

Touch Apps in any home screen page, then flick left or right to see all your apps.

All apps

In the app list, touch groups.

To add an app group shortcut to the home screen, touch its name in the apps screen and touch

To close the app list, touch Home or Back .

to view or create app

Add to home

Recent apps

Your phone remembers the apps that you used most recently. From the home screen, touch Recent Apps . To remove an app from the list, flick it left or right.

Browse & install apps

Get all the fun games and cool apps you want! Google Play™ provides direct access to apps, games, books, and movies that you can download and install on your phone.

Find it: Apps >

Scroll to and touch the app you want to install. Then,

Install

touch

(if app is free) or

New apps that you install are added to the app list.

Tip: Choose your apps and updates carefully, from trusted sites, like your phone’s performance—see “Choose carefully” on page 14.

Note: When installing an app, make sure you read the alerts that tell you what information the app will access. If you don’t want the app to have access to this information, cancel the installation.

Play Store

Buy

, as some may impact

13Apps & updates

Manage & restore apps

From the home screen, touch Apps >

Apps

Touch an app in the list, then touch you downloaded),

Clear cache

, or other options.

Uninstall

Settings

(for apps

Choose carefully

Apps are great. There's something for everyone. Play, communicate, work, or have fun. But remember, choose your apps carefully. Here are a few tips:

• To help prevent spyware, phishing, or viruses from

affecting your phone or privacy, use apps from trusted sites, like

• In

comments before installing.

• If you doubt the safety of an app, don't install it.

• Like all apps, downloaded apps will use up memory,

data, battery, and processing power—some more than others. For example, a simple battery level widget will use less than a streaming music player app. After installing an app, if you're not happy with how much memory, data, battery or processing power it's using, uninstall it. You can always install it again later.

14 Apps & updates

Play Store

, check the apps’ ratings and

• Just like web browsing , you may want to monitor

childrens’ access to apps to help prevent exposure to inappropriate content.

• Certain apps may not provide completely accurate

information. Take care, especially when it comes to personal health.

Update my phone

You can check, download, and install phone software updates using your phone, or using your computer:

• Using your phone:

You may get an automatic notification of an available update on your phone. Simply follow the instructions to download and install.

To manually check for updates, touch Apps >

Your phone downloads any updates over your mobile network. Remember, these updates can be quite large (25MB or more) and may not be available in all countries. If you don’t have an unlimited data plan, or mobile network updates are not available in your country, you can update using a computer.

• Using your computer:

On your computer, go to www.motorola.com/myXT886

Settings >About phone >System updates

and check the

“Software” links. If an update is available, follow the installation instructions.

Calls

it’s good to talk

Quick start: Calls

Dialing options

Find it: Apps >

Tip: If the screen is locked, touch and flick to .

DIALER PHONEBOOKRECENT

Most recent

Victor Harp

Mobile 555-555-4570

1 2

GHI

PQRS

Phone

See phone options.

June 26, 2012

ABC

JKL

TUV

Flick the screen left or right to see dialer, recent calls, or phonebook.

DEF

MNO

Add Number to Contacts

WXYZ

Call

Enter a phone number & touch here to call it.

Voice Dial

15Calls

Tip: Search for contacts right from the dialpad. For

Victor Harp

Mobile (555) 555-4570

00:12

MuteBluetooth Speaker

Add call

DialpadEnd call

Call Timer

End Call

Connect to a Bluetooth headset or car kit.

Mute/Unmute

Speakerphone On/Off

Add another person for a conference call.

Enter numbers during a call.

Can’t talk now. What’s up?

Custom message...

I’ll call you right back.

I’ll call you later.

Can’t talk now. Call me later?

Jeff

example, to find

in your contacts list, touch 5-3-3-3.

Matching contacts appear above the number field.

In-call options

To use a Bluetooth™ device, touch

Bluetooth

. (The device needs to be turned on and previously paired—see “Connect new devices” on page 38.)

Tip: You can touch Home or Back to leave the active call display. To reopen it, touch Home

Phone

Note: Using a mobile device or accessory while driving may cause distraction and may be illegal. Always obey the laws and drive safely.

16 Calls

Make & answer calls

To make a call, touch

Phone

, enter a number, then

touch .

Tip: If the screen is locked, touch and flick to .

To answer a call, touch and flick to .

To ignore a call, touch and flick to . If you want to ignore an incoming call, but send a text message to the caller, touch and flick to . Select a message

Send

and touch

to send it.

Tip: To silence an incoming call alert, press the Power key or the volume keys.

Note: When you hold the phone to your ear, the display goes dark to prevent accidental touches. When you move the phone away from your ear, the display lights up again.

Recent calls

Find it:

• To call a number, touch next to the entry.

• To see call details, touch the entry.

• To send a text message, create a contact, view a

• To search the recent calls list, touch .

• To clear the list, touch Menu >

Phone >Recent

contact, or other options, touch and hold the entry.

Clear list

Favorites

Find it: Apps >

• To call, text, email, or view contact information, touch

the contact.

• To edit, share, delete, or set a ringtone for a contact,

touch the contact, then touch Menu .

People >FAVORITES

Conference calls

To start a conference call, call the first number. After the call connects, touch select it from contacts or favorites. When the next number answers, touch

Add call

. Dial the next number, or

Merge

Your phone number

Find it: Apps >

My phone number

Settings >About phone >Status

Speed dial

Your phone can store nine phone numbers that you can call with a single keypress. To store a speed dial number, touch and insert a number in an empty speed dial slot.

To call a speed dial number, touch and hold the single-digit speed dial number.

Phone

> Menu >

Speed dial setup

Voicemail

When you have a new voicemail, appears at the top of the screen. Drag down the status bar and touch the

New voicemail

message.

notification to listen to your voicemail

Emergency calls

Note: Your service provider programs one or more emergency phone numbers that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

17Calls

MEME

Set up my proﬁle

297 contacts

Abe Baudo

Astrid Fanning

Anna Medina

Avery Durning

Allie Smyth

GROUPS FAVORITESPEOPLE

Create & view groups of contacts.

Contacts List

Touch to view contact information, then you can call, send a text message, & more.

Add contacts.

Touch a letter to jump to contact names that start with that letter.

View your favorites.

1 Touch

Emergency Call

Phone

(if your phone is locked, touch

2 Enter the emergency number.

3 Touch to call the emergency number.

Note: Your phone can use location based services (GPS

and AGPS) to help emergency services find you. See “Location Services” on page 54.

Cool down

In very limited circumstances, such as where your phone has been exposed to extreme heat, you may see “Cool Down” messages. To avoid possible damage to your battery and phone, you should follow these instructions until the phone is within its recommended temperature range. When your phone is in “Cool Down” mode, only emergency calls can be made.

18 Contacts

Contacts

contacts like you’ve never had before

Quick start: Contacts

Find it: Apps >

Tip: To search the list, touch to open a touchscreen

keypad, then type a name.

People

Transfer & sync contacts

your.account@gmail.com

Set a picture.

Set the number type.

Remove a number.

Set where contact is saved (Google, Local, or SIM).

Add another number.

Get all your contacts, all in one place:

• Use Gmail™

All your Gmail contacts will automatically get synced to your phone. Various computer applications for mobile phones and email accounts allow you to export your contacts as a “.CSV” file. You can then use Gmail to import the file. For more details, go to www.motorola.com/transfercontacts Gmail account on your computer and select “Help”.

• More

There are other methods and tools to help you at www.motorola.com/transfercontacts

Combine contacts

You might have two or more contacts for the same person, maybe a Gmail contact who is also stored on your phone, or one friend with two email addresses. To combine these contacts:

Find it: Apps >

Touch a contact to open it, touch Menu >

Join

Menu >

, then touch the second contact.

People

or log in to your

Edit

Create contacts

Find it: Apps >

Touch any entry area to open the touchscreen keypad.

When you’re finished, touch

Where are contacts saved? Your phone saves new

contacts in its memory, and syncs them remotely with your Google™ account. Contacts on the Google Server

People

Done

19Contacts

are backed up, and are accessible from every device you use to access your Google account.

• To change how you view the list of contacts, touch

Menu >

Settings >Display options

Edit or delete contacts

Keep your contacts up to date and add a photo.

People

Find it: Apps >

Edit

Add a photo: Tou c h contact >Menu >

Set a ringtone: Touch contact >Menu >

Delete

> contact > Menu

Edit

Set ringtone

View CONTACTS

When you set up a social networking account (see “Social networking” on page 25), you’ll know what everybody’s up to and when. Every time you pick up a call, check a message, or look up a friend’s contact info, you’ll see their name and number, but you can see their social network status and smiling face, too.

Find it: Apps >

• To find a contact, touch and type a contact name.

Touch a contact to open its details. While viewing details, you can start a call or message by touching the phone number, message icon , email address, or social network.

• To change which group of contacts is shown (like

contacts

or contacts from your Gmail account) touch

Menu >

20 Contacts

People

Contacts to display

All

Groups

Find it: Apps >

You can put your contacts into groups (like “Friends” or “Family”). Then, you can find contacts faster by showing one group at a time.

To create a new group, touch Apps >

GROUPS

People >GROUPS

Favorites

To add a contact to your favorites list, touch the contact to open it, then touch .

To see your favorites list:

Find it: Apps >

People >FAVORITES

Call, TEXT, or email contacts

Find it: Apps >

Touch a contact to open it, then:

• To call touch, the contact’s number.

• To text message, touch next to the number.

• To email touch the contact’s email address.

People

> group name

People

Messages

Meet me outside the theater at 8 and don’t

Messaging

Create message.

Message List

Touch to open a message.

Open options.

Messaging search.

sometimes it’s best to text, or IM, or email . . .

Quick start: Messages

Find it: Apps >

Tip: If the screen is locked, touch and flick to .

Anna Medin

Copy Revisions

ease take a look at the new revisions...

m Somer

don’t forget your ID. Would you maybe like

Arther Bando

eeting invitatio eeting is set for next Thursday at 10:00

on Anderso

Your last messa

’m fine with that.

Mary Morga

Freelancers We’re going to need help with the new...

Tip: To see more messages, flick or drag up.

Read & reply to messages

Find it: Apps >

• To open a text message and all of its replies, touch it.

Messages

Mar 14

Mar

Feb 2

Feb 22

Feb 4

Messages

• To respond to a text message, open it and enter your

response in the text box at the bottom.

• To delete a message, touch and hold to select it, then

drag it to the trash can .

• To adjust message options, touch Menu

Messaging settings

in your message list.

Create messages

Find it: Apps >

Enter the recipient and message. Touch Menu to

Insert smiley, Add Cc

Tip: To add an attachment, touch .

Messages

, or

Add subject

, then touch

Send

Send & receive attachments

To send a file in a message, touch .

When you receive a message with an attachment, open the message and touch the file name to download it. Then, touch the name again to open it. Some file formats can be converted to HTML for faster viewing, and your phone will show

While viewing the attachment, touch it to save it, share it, and more.

Tip: To send and receive large attachments faster, use a Wi-Fi connection (see “Wi-Fi networks” on page 37).

Get HTML version

21Messages

Gmail

The first time you turned on your phone, you probably set up or logged in to your Google™ Gmail™ account.

If not, you can set up a Gmail account by touching Apps >

Google

To read and reply to messages on your Gmail account, touch Apps >

Tip: For more information, touch Apps > >Menu >

Settings >Accounts & sync >ADD ACCOUNT

Gmail

Help

Gmail

Email

You can set up and use multiple email accounts on your phone.

Settings

To add email accounts, touch Apps >

Accounts & sync >ADD ACCOUNT

Corporate

•

Enter details from your IT administrator.

Tip: You might need to enter your domain name with your user name (like domain/username).

•

account details, contact the account provider.

To read and reply to messages on your email accounts, touch Apps >

22 Messages

is for Exchange server work email accounts.

is for most personal email accounts. For

Instant messages

To send and receive instant messages, you can use Google Talk™.

Find it: Apps >

Tip: You can also download an instant messaging app

from Google Play™.

Talk

Text entry

asdfghj k l

zxcvbnm

ertyuiopqw

21 09876543

!?,

?123

Dinner at Bistro Fanta

Done

Open a keypad for numbers & symbols.

Voice Input/ Dictation

Delete

Shift

Space

Return/ New Line

Text Box

Touch to open touchscreen keypad.

Shift

keys when you need them

Touchscreen keypad

You can open a keypad on your screen by touching a text box.

Tip: To close the keypad without saving any text (for example, to select a different text box), touch Back .

Tip: To enter text by voice, touch and say what you want to type.

Input methods

To select a text input method, touch and hold Space to open the method you want.

Motorola English input

Enter text a letter at a time. As you type, your phone suggests words from your dictionary and chosen language.

To add a word to your dictionary, touch the word, then select

Swype

Enter words with one continuous motion. Just drag your finger over the letters in the word.

Anne

Tips:

• To enter apostrophes in common words (like “I’ll”),

drag through the

Select input method

+ add to dictionary

Anne Annex AbbeyAbbrAbbe

21 09876543

ertyuiopqw

@$&_()

asdf gh j k l

!#= /+

zxcvbnm

123

+ ! =

as though it was an apostrophe.

menu, then touch the

;

Done

”

To enter a word, just trace a path through the letters. To capitalize, go above the keypad. For double letters, circle the letter.

23T ext entry

• To enter other punctuation, numbers, or symbols,

touch Symbols .

• To correct a word, double-touch it (tap twice, quickly).

Swype shows a small menu of other word options. Swype might also show a menu if it can’t guess your word.

• If Swype doesn’t know a word, you can still touch the

letter keys to enter it. Swype remembers, so next time you can just drag over the letters.

Motorola Chinese Input

Enter text a letter at a time. As you type, your phone suggests words from your dictionary and chosen language.

Typing tips

To .. .

Enter one capital letter

Enter only capital letters

Move the text entry

cursor

24 Text entry

Tou ch Sh i f t .

Touch and hold Shift . Touch again to revert to lowercase.

Touch the text where you want the cursor to go.

To .. .

Select text Touch and hold text to

Cut or Copy selected

text

Paste cut or copied

text at cursor location

Delete character to left

of cursor

select it. If necessary, drag the text boundary markers to select the text you want.

Touch icons at the top of the screen to selected text. In a landscape display, touch

Copy

Tou ch th e top of the screen. In a landscape display, touch >

Touch Delete (hold to delete more).

Paste

Cut

Paste

Copy

Edit >Cut

icon at the

Text input settings

Find it: Apps >

• To change the language for your phone and

touchscreen keypad, touch

• To change the default text input method, touch

KEYBOARD & INPUT METHODS

under

Settings >Language & input

Locale

Edit

Default

• To change text input settings, touch next to

Motorola English Input, Motorola Chinese Input Swype

Social networking

my life, your life

Quick start: social networking

You can add your networking accounts. If you don’t have accounts on these sites, visit their websites to set them up.

Find it: Apps >

ACCOUNT

Add an account by touching it. Then enter your user name and password for that account.

When you sign into social networking accounts, you’ll see your friends and contacts in your

Tip: To download updates faster, see “Wi-Fi networ ks” on page 37.

Edit & delete accounts

Find it: Apps >

To sync an account, touch account name > Menu >

Sync now

To delete an account, touch account name >Menu

Remove account

Facebook, Twitter

Settings >Accounts & sync >ADD

Settings >Accounts & sync

, or other social

Contacts

list.

25Social networking

Photos & videos

see it, capture it, share it!

Photos

Take & share photos

Find it: Apps >

Tip: If the screen is locked, touch and flick to .

See last photo or video.

Geo-Tag Location

Honolulu, Hawaii

Adjust camera or camcorder settings.

26 Photos & videos

Camera

Zoom

Capture photo

in/out.

Autofocus Box

Touch screen to

change focus location.

or video.

Select front or back camera.

Select camera or camcorder.

Note: Photos are stored in your phone’s internal memory, unless you switch it to a microSD memory card. Photo resolution can be set to 8MP or

Widescreen

(6MP).

Tip: Press the volume keys to zoom in and out on the viewfinder image.

To take the photo, touch in the viewfinder screen.

Your phone stores the photo, and shows a thumbnail image in the corner of the screen. To see the photo you just took, touch the thumbnail. Then:

• To set the photo as a wallpaper, contact photo, or

Set as

social network photo, touch Menu >

• To share the photo in a message or post it online,

touch . For more info on sharing your photos, see “Share photos & videos” on page 29.

• To upload the photo to an online photo album,

touch Menu >

Quick upload

• To print the photo, touch Menu >

(follow the

on screen instructions to set up a printer).

Delete

• To delete the photo, touch Menu >

Panoramic photos

In the viewfinder, drag the tab in the lower left corner, then touch photo. The camera auto-captures up to six multiple

Modes >Panorama

to take a wide panoramic

shots as you move the camera, and joins them together

01:13:12 Los Angeles, CA

to make one large image.

Camera settings

Drag the tab in the lower left corner of the viewfinder to adjust camera settings:

Options

Settings

Effects

Scenes

Modes

•

Picture Widescreen

photo resolution)

Video Resolution

•

VGA , or QVGA )

Volume Key Function

•

keys to zoom)

Geo-tag

•

(auto location information)

Storage Location

microSD memory card)

Shutter Tone

•

Set a photo effect:

White

Negative

, and more.

Set the type of photo you want to

Auto, Portrait, Landscape, Sport

take: and more.

Set to

Single shot, Panorama

Multi-shot

, or

Timer

(6MP or 8MP

(1080p, 720p, DVD,

(use volume

(phone or

Normal, Black and

Options

Exposure

Flash

Select an exposure setting.

Set

Flash On, Flash Off

Videos

Record & share videos

Find it: Apps > switch to the right.

Watch your

last video.

Remaining

HDHD 01:13:12 Los Angeles, CA

Adjust camcorder

settings.

Camera

Time

, or

, then drag the camera

Switch between front

& back cameras.

Record

video.

Zoom

in/out.

Auto Flash

Switch to

camera.

27Photos & videos

To record a video, touch in the viewfinder screen. To

stop the video recording, touch again.

Your phone stores the video, and shows a thumbnail image of the video in the corner of the screen. To see the video you just took, touch the thumbnail. Then:

• To play the video, touch .

• To share the video in a message or post it online,

touch . For more info on sharing your video, see “Share phot os & videos” on page 29.

• To upload the video to an online album,

Picasa

touch Menu >

• To delete the video, touch Menu >

Delete

HD videos

You can capture HD-quality videos to watch on an HDTV or monitor.

To record an HD-quality video, be sure to select the

Video resolution

correct viewfinder screen, drag the tab in the lower left corner of the viewfinder screen, then touch

Resolution

28 Photos & videos

HD+ (1080p)

. From the active camcorder

Settings >Video

High Definition (720p)

Camcorder settings

Drag the tab in the lower left corner of the viewfinder to adjust camcorder settings:

Options

Settings

Effects

Audio Scenes

Modes

Exposure

Light

•

Video Resolution

(1080p, 720p, DVD,

VGA , or QVGA )

Volume Key Function

•

(use volume

keys to zoom)

Geo-tag

•

(auto location information)

Video Stabilization

(reduce

shakiness during video capture)

Storage Location

•

(phone or

microSD memory card)

Shutter Tone

•

Set a video effect:

White

Negative

Set sound recording options:

Wind Reduction, Concert

Set to

Normal video, Video Message

Normal, Black and

, and more.

Stereo

Select an exposure setting.

Turn the camcorder light on or off.

View photos & videos

Find it: Apps >

View all of your photos and your friends’ photos/videos from different media sites, like Picasa™, Flickr, PhotoBucket, and Facebook™. You can add comments to others’ photos, and see comments that others have posted.

Note: To see the controls when a video is playing, touch the display.

Share photos & videos

Find it: Apps >

Touch , then choose how you want to share—like

Bluetooth, Email, Text Messaging, Twitter

album.

Manage photos & videos

Find it: Apps >

Touch Menu , then select an option from

Set picture as

Tip: To copy photos to/from a computer, go to “USB cables” on page 39.

, and more.

Edit photos & videos

Find it: Apps >

Gallery

> photo or video

Gallery

> photo or video

Gallery

> photo or video

, or an online

Edit, Delete

Tou ch Me n u > features to resize, crop, or change the color. To undo a change, touch . When you’re finished, touch

Edit

. You can choose advanced editing

Movies

You can find and rent movies to watch on your tablet or computer:

Find it: Apps >

To shop, rent, or watch on a computer, go to www.google.com/play

To pay for rentals, set up your Google™ Wallet at www.google.com/wallet

YouTube

Watch videos from YouTube users everywhere—or log into your account to share your own.

Find it: Apps >

•Watch: Touch

• Upload: Touch

Tip: A YouTube account lets you subscribe to YouTube's

premium content channels, and have your favorite channels synced to your phone for HD playback anytime. For optimal content sync, your phone should be plugged into a charger and have a Wi-Fi connection.

touch the image to play it.

account, then touch .

Play Movies

and choose “Movies.”

YouTube

BROWSE

or to find a video, then

ACCOUNT

, choose your Google™

SAVE

29Photos & videos

Music

SONGS GENRESPLAYLISTS

Last added

Allie live shows

Portland

road trip

summer songs

workout 1

Allie’s mix

Song Title

Artist

During a song:

See details & settings.

Touch to skip.

Hold to scan.

Flick left or right for songs, playlists, genres, & more.

Touch for options.

See Music Options

when music is what you need...

Quick Start: Music

Find it: Apps >

Play Music

• Go back: When you open a song or artist list,

touch in the top left to go back.

• Set shuffle or repeat: During a song, touch to

show shuffle and repeat at the bottom. Touch once to repeat the current song list, or twice to repeat only the current song.

• Adjust volume: Press the volume keys.

• Hide the music player: To use another app while

your music plays, touch Home . To return to the music player, flick down the status bar and touch the song title.

Tip: Control music playback from the home screen by adding the

Google Play Music

widget.

• Playlists: Touch and hold a song in your library to add

it to a playlist or show other options. To edit, delete and rename a playlist, touch and hold its name in the music library.

•Help: For more information, touch Apps >

Music

>Menu >

Help

Play

• Computer: To access your Google Play™ music from

a computer, visit www.google.com/music

• During a flight: Press and hold the Power key, then

Airplane mode

touch

to turn off all your network and wireless connections and listen to music during a flight.

30 Music

Your phone can play MP3, M4A, AAC, AAC+, MIDI, and

www.google.com/

Web

Images Places News more

Restaurants

Chicago, IL - update

Bars More

History Sign out

Coffee

your.account@gmail.com

SettingsiGoogle Help

View Google in: Mobile Classic

Touch a link to select it. Touch & hold for more options.

Touch for browser options. View open browser tabs, or open a new tab.

update

WAV file t ypes.

FM Radio

Plug in a 3.5mm headset and surf the airwaves for fresh music.

Find it: Apps >

FM Radio

Web

surf the web with your phone

Quick start: Browser

Find it: Apps >

Browser

Tip: To zoom in, touch the display with two fingers, then move them apart.

31Web

Connect

Your phone uses the mobile phone network (over the air) or a Wi-Fi connection to automatically access the web.

Note: Surfing the web or downloading data over the mobile phone network uses your monthly data subscription allowance.

To use a Wi-Fi network for faster Internet access, touch the status bar at the top of the home screen and drag it down. Touch the select a preferred network. For more info, see “Wi-Fi networks” on page 37.

Note: If you can’t connect, contact your service provider.

Wi-Fi networks available

notification to

Downloads

To download files in your browser, touch a file link or touch and hold a picture to choose

To see the files you downloaded, touch Apps

Downloads

> see details, or remove it from the list.

You can download “Apps & u pdates” on page 13.

32 Web

. Touch and hold an item to open it,

Save image

Browser options

Touch Menu to see browser options:

Options

Bookmarks

Save to bookmarks

Request desktop site

Refresh

Settings

Exit

See your bookmarks.

Bookmark the current web page.

Open the standard desktop website instead of the mobile device version.

Reload the current page.

Adjust browser settings.

Close the browser app.

YouTube™

Share videos with YouTube users everywhere. You don’t need a YouTube account to browse and view videos.

Find it: Apps >

Note: If you want a YouTube account, go to

www.youtube.com

ACCOUNT

touch

YouTube

. To create an account or sign in,

Personalize

add your personal touch

rates for access to the latest info. See weather reports for your current location, and for any other locations you specify.

Widgets

Add widgets

Fill your home screen with widgets—make it yours.

Widgets

Touch Apps > drag it to a spot on the home screen.

Tip: Flick left to see more widgets.

Personalize widgets

You can customize some widgets. Touch a widget to open it, then touch Menu .

Your home screen may already have these widgets:

Favorite People

•

favorite contacts. To add people to your Favorites list, see “Favorites” on page 20.

Calendar

•

: Sync your calendars and review upcoming events at a glance with the scrollable calendar widget. To add calendar events, see “Calendar” on page 41.

My music

playlist, genre, or just touch Menu > There’s more about “Music” on page 30.

News & Weather

interest you, then customize downloads and refresh

: Set this widget to an artist, album, song,

, touch and hold a widget, then

: Quickly call, text, or email your

Shuffle all

: Hand pick the news topics that

Shortcuts

To add app shortcuts to the home screen, touch Apps , touch and hold an app, then drag it to a spot on the home screen.

Tip: To change a shortcut in your Favorites Tray (except Apps ), touch and hold a shortcut, then drag it out of or into the Favorites Tray.

Ringtones

• To personalize your ringtones, touch Apps

Settings>Sound >Phone ringtone

notification

• To make your phone ring and vibrate, touch Apps

• To silence your phone and make it vibrate for

incoming calls, touch Apps > >

• To set a ringtone for a contact, touch Apps

Settings >Sound >Vibrate and ring

Silent mode >Vibrate

People

> contact > Menu >

Default

Settings >Sound

Set ringtone

33Personalize

Wallpaper

To apply a new wallpaper, touch and hold an empty spot on your home screen, then choose a wallpaper image

Live wallpapers, Gallery

from

, or

Wallpapers

Sounds

• To set volume for ringtones, media, and alarms, touch

Apps >

• To play dial pad tones, touch Apps >

• To play sounds for screen selections, touch Apps

• To customize the sound settings for media and

videos, touch Apps > (internal) or speakers).

Settings >Sound >Volumes

Sound >Dial pad touch tones

Settings >Sound >Touch sounds

Wired stereo devices

Settings >Sound

(connected external

Settings

Speaker

Display

• To set display brightness, touch Apps >

Display >Brightness

• To set orientation, touch Apps >

Auto-rotate screen

• To set the font size for menus and settings, touch

Apps >

34 Personalize

Settings >Display >Font size

Settings

Settings >Display

Date & time

Set date, time, time zone, and formats:

Find it: Apps >

Settings >Date & time

Language & region

Set your menu language and region:

Find it: Apps >

Settings >Language & input >Locale

Location

Elmhurst

Addison

Cicero

Oak Lawn

East

oChicago

Evanston

Des Plaines

Elmwood

La Grange

Harvey

Calumet

City

Orland Park

GGary

Blue Island

Northbrook

Highland Park

ein

and

ammoammo

oon

Hammond

Tinley

Tinley Park

inley Park

Tinley Park

ey Park

arkark

Chicago

Chicagoaaaa

Chicago

Heights

Heightsssgg

Heights

Highland

ghlan

Highland

where you are, where you’re going

Google Maps™

Find it: Apps >

Maps

lein

Highland Park

Grove

Northbrook

hts

Evanston

Des Plaines

Elmwood

294

Orland Park

Park

Oak Park

La Grange

Tinley Park

Chicago, IL

Cicero

Oak Lawn

Blue Island

Addison

Elmhurst

Note: The map image you see may be a little different.

Maps

Select a map or navigation view.

Center the map on my location.

290

Chicago

Calumet

City

Harvey

Hammond

Highland

Chicago

Heights

hts

Hei

Search maps.

Get Directions.

Find nearby Places.

East

Add Layers of information

Chicag

to map view.

Touch for options like, My Places & Help.

Google Maps offers powerful, user-friendly mapping technology and local business information—including business locations, contact information, and driving directions.

Help

For help, touch Menu >

Tip: Want to know what’s in your immediate area? Try

Maps

Google Places™. Touch Apps >

Maps

view control in the upper-left, then touch

, touch the

Places

to see listings for restaurants, cafes, bars, and more, based on your current location.

Google Maps Navigation Beta

Google Maps Navigation Beta is a complete GPS navigation system with voice guidance that shows you the way.

Find it: Apps >

Navigation

Follow the prompts to speak or type your destination.

For more information, go to www.google.com/mobile/navigation

Google Latitude™

See where your friends and family are on Google Maps. Plan to meet up, check that your parents got home safely, or just stay in touch.

Don’t worry, your location is not shared unless you agree to it. You need to join Google Latitude, and then invite

35Location

your friends to view your location or accept their invitations.

To start Google Latitude, touch Apps >

Join Latitude

• To add friends, touch

• To remove friends, touch

in your list, then touch

. Then:

FRIENDS LIST

Remove this friend

Latitude

, touch a friend

• To turn off Google Latitude, touch your Latitude

name tag in map view, then touch

Sign out of Latitude

36 Connect

Location settings

Connect

wired or wireless

Quick start: Wireless

Connect your phone to fast Wi-Fi networks or Bluetooth™ devices.

To connect, touch Apps >

Bluetooth

Wi-Fi

Network 1 Name

Connected

Network 2 Name

Network security type

Network 3 Name

Network security type

SCAN ADD NETWORK

Connect to this device.

Turn Bluetooth

power on & off.

Settings >Wi-Fi

Turn Wi-Fi power on & off.

Connect to this network.

AVAILABLE DEVICES

Bluetooth

XT886

Not visible to other Bluetooth devices

TOUCH TO PAIR

Motorola Headset

SEARCH FOR DEVICES

Wi-Fi networks

OFF

Turn Wi-Fi power on or off

Tu r n on : Touch Apps >

OFF

power switch to the right.

Tu r n of f : Drag the

Note: To extend battery life, turn off Wi-Fi power when

not in use.

Wi-Fi search & connect

When Wi-Fi is on, the Wi-Fi in range indicator appears in the status bar when a network is available. Drag down the status bar and touch the

available

notification to select and connect to a network,

that you have used before.

To search for a network when Wi-Fi is off:

1 Touch Apps >

Wi-Fi

2 Drag the

turn on and scan. If Wi-Fi power is already on, touch within range.

Tip: To see your phone’s MAC address or other Wi-Fi details, touch Menu >

3 Touch a network to connect. If necessary,

enter

Connect

power switch to the right to

SCAN

. Your phone lists the networks it finds

Network SSID, Security

Settings

, then drag the

Wi-Fi

power switch to the left.

Settings >Wi-Fi

Advanced

, and

Wi-Fi networks

Password

, and touch

Wi-Fi

When your phone is connected to the network, the Wi-Fi connected indicator appears in the status bar.

Tip: When you are in range and Wi-Fi power is on, you will automatically reconnect to available networks you’ve connected to before.

Wi-Fi hotspot

You can make your phone a Wi-Fi hotspot to provide portable, convenient internet access to other Wi-Fi enabled devices.

Caution: This application significantly impacts batter y life. You may want to run this application with the charger connected.

Note: You need to subscribe to Wi-Fi hotspot service to use this feature. Contact your service provider.

To set up your phone as a Wi-Fi hotspot:

1 Touch Apps >

Mobile Hotspot

hotspot.

Mobile Hotspot settings >Configure Mobile

2 To uc h

Hotspot

to change hotspot security and configuration

settings:

Network SSID

•

hotspot and touch

Security

•

WEP, WPA

Settings >Tethering &

Mobile Hotspot

to turn on the

: Enter a unique name for your

: Select the type of security you want:

, or

WPA2

. Enter a unique password.

37Connect

Other users can access your Wi-Fi hotspot only if

OFF

they enter the correct password.

Note: Keep it secure. To protect your phone and hotspot from unauthorized access, it is strongly recommended that you set up hotspot (

WPA2

is the most secure), including password.

•

Broadcast Channel

: Select a channel that

Security

minimizes potential interference. You may need to try different channels after your hotspot is active for a time.

Save

3 Touch

when the settings are complete.

When your Wi-Fi hotspot is active, other Wi-Fi enabled devices can connect by entering your hotspot’s

Security

selecting a

Password

type, and entering the correct

SSID

Wi-Fi modes

For those who like to get a bit more technical, your phone supports the following Wi-Fi modes:

802.11 b, g, n.

Bluetooth wireless

Turn Bluetooth power on or off

Tu r n on : Touch Apps >

Bluetooth

38 Connect

power switch to the right.

Settings

, then drag the

Tu r n of f: Drag the

Bluetooth

power switch to the

left.

Note: To extend battery life, turn off Bluetooth power when not in use.

Connect new devices

Note: This feature requires an optional accessory.

To connect with a new device, you need to pair with it. You only need to do this once for each device—to connect again, just turn on the device.

1 Make sure the device you are pairing with is in

discoverable mode.

Note: Refer to the guide that came with the device for details.

2 Touch Apps >

3 Drag the

Bluetooth

Settings >Bluetooth

OFF

power switch to the right to

turn on and scan. If Bluetooth power is already on,

SEARCH FOR DEVICES

touch

4 Touch a device to connect.

5 If necessary, touch

0000

(like

) to connect to the device. When the device

, or enter the device passkey

is connected, the Bluetooth connected indicator appears in the status bar.

Note: Using a mobile device or accessory while driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Reconnect devices

To automatically reconnect your phone with a paired device, simply turn on the device.

To manually reconnect your phone with a paired device, touch the device name in the

AVAILABLE DEVICES

list.

Disconnect devices

To automatically disconnect your phone from a paired device, simply turn off the device.

To manually disconnect your phone from a paired device, touch the device name in the devices list, then touch

Change device name

Touch Apps > power on, then touch Menu > name and touch

Settings >Bluetooth

, turn Bluetooth

Rename phone

. Enter a

Printers

Print email, documents, pictures, and contacts directly to shared printers on a Wi-Fi network—no printer drivers necessary. You can even save your favorite printers and geo-tag their location for future use.

Print a document or file

To print something from the apps, open it and touch Menu >

Email, Quickoffice

, or

Gallery

Add a printer

Open the document or file you want to print, then touch Menu >

Add printers

USB cables

You can connect your phone to a computer with a USB cable.

Note: The first time you use a USB connection, your computer may indicate that drivers are being installed. Follow any prompts you see to complete the installation.

This may take a few minutes.

1 With your phone showing the home screen, connect

a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.

Note: Make sure to connect the phone to a high power USB port. Typically, these are located directly on your computer.

2 Drag and drop files between your computer and

phone folders. When you’re done, use “Safely Remove Hardware” before disconnecting the USB cable.

Note: You can’t use files on an installed microSD memory card while your phone is connected to the computer.

39Connect

Tips & tricks

a few handy hints

General tips

• Screen brightness changes as your phone senses the

current lighting conditions.

• To return to the home screen, touch Home .

Phone

• To see recently dialed numbers, touch

Recent

• To sleep/wake your phone, press the Power key.

• To set screen timeout, touch >

Sleep

• To search, touch Apps >

Settings >Display

• To automate everyday tasks, touch Apps

SMARTACTIONS

(touch

Help

, in the app to learn

more).

• To show the most recent apps you’ve used, touch

Recent Apps .

• To change a shortcut in your Favorites Tray (except

Apps ), touch and hold a shortcut, then drag it out of or into the Favorites Tray.

• To turn sound on/off, press and hold the Power key,

then touch or .

• To turn airplane mode on/off, press and hold the

Power key >

40 Tips & tricks

Airplane mode

Battery tips

Want to extend your battery life? Try these:

• To help minimize battery use, touch Apps

SMARTACTIONS

> that enable battery savings:

Battery Extender

and

• To turn off background data transfers, touch Apps

Settings >Data usage

background data

• To turn off Bluetooth power, touch Apps >

Settings

, then drag the

to the left to turn it off.

• To turn off Wi-Fi power, touch Apps >

then drag the turn it off.

. Check out the sample rules

Nighttime Battery Saver

> Menu >

Bluetooth

Wi-Fi

power switch to the left to

power switch

Restrict

Settings

Tools

May 26 (1)

Pick up birthday cake

Due: Sat, May 26, 2012

Untagged

All tasks

)

kkk

Due:

taa

All tasks

By priority

Overdue

Due today

Starred

stay on top of things

Calendar

Find it: Apps >

Your calendar events can be viewed in different ways: Touch the date, then touch

Day, Week, Month

When you highlight an event, more details appear.

Tip: To add a calendar widget to your home screen, touch Apps > and hold

Widgets

Calendar

it to a spot on the home screen.

Add calendar events

From any view, touch Menu > the event start time and other details. You can even set a reminder so you don’t forget about the event. (When you set the reminder time to event start time).

New event

Calendar

, or

Agenda

, touch

, then drag

. Enter

0minutes

, it plays at the

Tip: Reminders will play only if you’ve selected a notification ringtone (see “Ringtones” on page 33).

When you finish entering event details, touch

SAVE

Manage calendar events

To edit an event, touch it, then touch

SAVE

you’re done, touch

To delete an event, touch it, then touch .

Edit event

. When

Tasks

Find it: Apps >

To add a task, touch .

From the tasks main screen,

All tasks

touch tasks by due date, priority, and more.

Tip: To add a tasks widget to your home screen, touch Apps > and hold

Widgets

Task

screen.

Tasks

y 26 (1

to view your

, touch

, then drag it to a spot on the home

41Tools

Calculator

12345

Every day

7:00 AM

9:00 AM

8:30 AM

Add alarm

Mon, Tue, Wed, Thu, Fri

TIMERALARMS

Find it: Apps >

To switch between basic and advanced functions, touch Menu >

Advanced panel

history, touch Menu >

Calculator

Basic panel

Clear history

. To clear

Alarm clock

Find it: Apps >

To turn on an alarm, touch the check box.

When an alarm sounds,

Dismiss

select touch the screen to snooze for five minutes.

To add an alarm, touch , then enter alarm details.

To enable or disable an alarm, touch the check box.

42 Tools

Alarm & Timer

to turn it off or

Accessibility

See, hear, speak, feel, and use. Accessibility features are there for everyone, helping to make things easier.

Note: For general information, accessories, and more, visit www.motorola.com/accessibility

Voice recognition

Use your voice—just touch and speak.

• Dialing and commands: Touch Apps >

Commands

. To dial, say “

Call

” and then a contact name or phone number. Or, say a command from the list shown, like “

Send Message

” or “

Go To

•Search: Touch , then say what you want to search

for, like “Motorola accessories”.

• Text entry: Touch a text entry field to open the

touchscreen keypad. Touch , then say what you want to type.

Tip: Speak naturally, but clearly. Use the microphone in a similar way to a speakerphone, so no need to shout or hold the phone close to your mouth.

To change your voice settings, see “Voice settings” on page 43.

Voice

”.

TalkBack (voice readouts)

Your navigation and selections, read out loud.

To turn on TalkBack voice readouts, touch Apps

Settings >Accessibility >TalkBack

TalkBack

OFF

switch to the right to turn it on.

, then drag the

To use TalkBack voice readouts:

• Menus and screens: In menus and screens, touch an

item to select or open it. The item is read out loud, or your action is described.

• Dialer & text entry: As you type, each number or

letter is read out loud.

Tip: Navigate through your apps and menus to hear how TalkBack voice readouts work on your phone.

To change TalkBack settings, touch Apps >

Accessibility >TalkBack >SETTINGS

Settings

Caller ID

When you want to hear who’s calling:

• Read out loud: Have your caller announced—touch

Phone

>Menu >

• Ringtones: Assign a unique ringtone to a

contact—touch touch Menu >

Settings >Caller ID Readout

People

, touch a contact, then

Set ringtone

Voice settings

Personalize your voice settings:

• Voice search: Touch Apps >

& input

Voice Search

. From here, you can set

Settings >Language

options like language, personalized voice recognition, and censorship.

• Voice typing: To uc h A p ps >

& input

Google voice typing

Language & input

. From here, you can select input

Settings >Language

, then touch next to

language and block offensive words.

• Text-to-speech: Tou ch A pp s >

Language & input >Text-to-speech output

> here, you can set speed options and listen to a spoken text example.

Volume & vibrate

Choose volume and vibrate settings that work for you.

Tou ch Ap p s >

•Volume: To u ch

• Vibrate: Touch

ring.

Settings >Sound

Volumes

Vibrate and ring

and use the sliders.

to feel your phone

Zoom

Get a closer look. To zoom in, touch the screen with two fingers and then slide them apart. To zoom out, slide your fingers together.

Settings

. From

43Tools

Display brightness

Set a brightness level that works for you. Touch Apps

Settings >Display >Brightness >Adjust brightness

level

. Make sure that

Automatic brightness

unchecked so you can set your own level.

Touchscreen & keys

All these touch features are great, and sometimes it’s nice to hear or feel your touches too. Touch Apps

Settings >Sound

• Touchscreen: To hear screen touches (click), select

Touch sounds

•Keys: To feel key touches (vibrate), select

touch

Vibrate on

• Screen lock: To hear when you lock/unlock the screen

(click), select

Screen lock sound

Messages

From a simple text message to IM, email, and more. Create, send, and receive them all on your phone.

And to make text entry even easier, you can use features like auto-correct, auto-punctuate, and auto-capitalization—touch Apps >

Language & input

Input

. Of course if you don’t want to type at all, then use

, then touch next to

your voice—touch on the touchscreen keypad.

44 Tools

Settings

Moto English

TTY

You can use your phone in TTY mode with standard teletype machines. Touch

Settings >TTY mode

TTY full

•

: Type and read text on your TTY device.

TTY HCO

: Hearing-Carry-Over—type text on your TTY device and listen to voice replies on your phone’s speaker.

TTY VCO

•

: Voice-Carry-Over—speak into your phone

and read text replies on your TTY device.

Note: You’ll need a cable/adapter to connect your TTY device to the headset jack on your phone.

Refer to your TTY device guide for mode and usage information.

Phone

> Menu

and select the mode you need:

Apps

Want more? No problem. Google Play™ Store provides access to thousands of apps, and many provide useful accessibility features.

Find it: Apps >

Select a category or touch Search to find the app you want.

Tip: Choose your apps carefully, from trusted sites, like

Play Store

, as some may impact your phone’s

performance.

Play Store

Management

stay in control

Memory card & file management

Your photos, videos, and other files are automatically stored in your phone’s internal memory. You can set individual applications (camera, camcorder, etc.) to store files on a microSD card. To install a microSD card, go to “Assemble & charge” on page 3.

Tip: To move media from internal memory to a microSD card, touch Apps >

Manage internal storage

Delete or share files on your phone

Find it: Apps >

Touch a file or folder to open, then touch and hold a file

Delete

Files >Device storage

Remove a microSD card

Note: Do not remove a microSD card while your phone is using it or writing files on it.

Before you remove a microSD card you need to stop your phone using it. Touch Apps >

Unmount SD card

Settings >Storage

Settings

SD card

Storage

Data usage

You can track the amount of data uploaded and downloaded by your phone, and set a limit on your monthly data usage.

Note: Usage information is provided to help you manage your phone. This may not match the amounts charged by your service provider, as they’re not measured in the same way.

45Management

Find it: Apps >

Data usage

Mobile data

Set mobile data limit

Apr 26 - May 26

Data usage cycle

May 19

26: about 38.65MB used

Apr 26 May 26

Measured by your phone. Your carrier’s data usage accounting may differ.

Browser

14.46MB

7.28MB

limit

4.0

warning

1.5

Activate data limit.

Mobile data on/off.

Touch an app to see details & restrict background data.

Drag up/down to set data usage limit.

Drag up/down to set data usage warning.

Drag left/right to see data usage for time period.

Timeframe.

Options.

The data usage screen shows information and settings for data transferred over your service provider's mobile network.

Tip: You can also track Wi-Fi usage, by touching Apps

Settings >Data usage

Restrict background data

46 Management

Settings >Data usage

> Menu >

Show Wi-Fi usage

Set a data usage warning

Tou ch Ap p s > right side of the orange bar up/down to set the data warning level. You'll receive a notification when your data usage reaches the specified level.

Settings >Data usage

Set a data usage limit

Touch Apps >

limit

, then drag the right side of the red bar up/down to

set the data usage limit.

When you reach your data usage limit, mobile data is turned off automatically and many of your phone’s features won't work correctly. You'll receive a notification when mobile data is turned off.

Settings >Data usage >Set mobile data

Restrict background data usage by app

Some apps transfer data in the background, when you're not using them. You can restrict background data usage for individual apps to help reduce your overall data usage.

Tou ch Ap p s > to see which apps are transferring data over the mobile network. Touch an app, then touch >

data

Settings >Data usage

Restrict background

, then drag the

, and scroll down

Restrict all background data

You can restrict background data for all apps across all available networks (mobile, Wi-Fi, and/or Ethernet).

Find it: Apps >

Restrict background data

Caution: Restricting all background data can cause some features to stop working altogether.

Settings >Data usage

>Menu

Wireless manager

Find it: Apps >

NETWORKS

Manage all your wireless connections: Wi-Fi, Bluetooth™, mobile data, airplane mode, & mobile hotspot.

section

Settings

, then go to the

WIRELESS &

Airplane mode

Use airplane mode to turn all your wireless connections off—useful when flying. Press and hold the Power key

Airplane mode

Note: When you select airplane mode, all wireless services are disabled. You can then turn Wi-Fi and/or Bluetooth back on, if permitted by your airline. Other wireless voice and data ser vices (such as calls and text messages) remain off in airplane mode. Emergency calls to your region's emergency number can still be made.

Network

You should not need to change any network settings. Contact your ser vice provider for help.

Tou ch Ap p s > see network settings options.

Settings >More... >Mobile networks

47Management

Security

Security & Screen Lock

Screen lock

Slide

SCREEN SECURITY

SIM CARD LOCK

PASSWORDS

Owner info

Set up SIM card lock

Make passwords visible

Enter text to appear on the lock screen.

Select & set up a screen lock method.

See the passwords you enter.

help keep your phone safe

Quick start: Security

Find it: Apps >

48 Security

Settings >Security & Screen Lock

Screen lock

To prevent accidental touches, you can make the screen lock when it goes to sleep. Touch >

Security & Screen Lock >Screen lock

> lock type:

None

: Turn off the screen lock.

•

Slide

: Flick to the right to unlock.

•

Face Unlock

•

Pattern

•

Password

•

: Look at your phone to unlock it.

: Draw a pattern to unlock.

: Enter a numeric PIN to unlock.

: Enter a password to unlock.

Note: You can make emergency calls on a locked phone (see “Emergency calls” on page 17). A locked phone still rings, but you need to unlock it to answer.

Face unlock

Use face recognition to unlock your phone.

This feature is less secure than a pattern, PIN, or password.

To get started, touch Apps >

Screen Lock

Follow the prompts and look at the front camera lens. When face capture is complete, choose a pattern or PIN (for backup and to change the lock setting).

Screen lock

Face Unlock

Settings

, then select the

Settings

Security &

Set it up

To unlock the phone, flick to the right and look at the front camera lens.

Lock pattern

To set the lock pattern, touch Apps >

Security & Screen Lock >Screen lock >Pattern

Follow the instructions to draw your lock pattern.

When prompted, draw the pattern to unlock the phone.

Settings

PIN lock

To set a PIN, touch Apps >

Screen Lock

Enter a numeric PIN, then confirm it.

When prompted, enter the PIN to unlock the phone.

Screen lock >PIN

Settings >Security &

Password lock

To set the password, touch Apps >

Security & Screen Lock >Screen lock >Password

Enter a password (up to eight characters), then confirm it.

When prompted, enter the password to unlock the phone.

Settings

Personalize your lock screen

To change your timeout, touch Apps >

Display >Sleep

. If you don’t touch the screen or press

Settings

any keys for the amount of time you select, the screen locks automatically.

Lock & unlock

To lock your phone screen, do any one of these:

• Press the Power key.

• Let the screen time out (don’t press anything).

• Switch off the power.

To unlock the phone screen, press the Power key, or touch Home . When you switch on the phone you see the unlock screen.

Forgot your pattern, PIN, or password?

If you make five unsuccessful attempts to enter your lock pattern, you can touch Gmail user name and password you set up as your main Gmail account when you registered your device. You will then be able to create a new pattern and unlock your device.

If you forget your PIN or password, contact your service provider to have your device factory reset.

Warn in g: A factory reset will delete all data on your phone.

Forgot pattern

and enter the

49Security

Reset

To reset your phone to factory settings and erase all the data on your phone, touch Apps >

Factory data reset >Reset phone

Warn in g: All data on your phone will be deleted. (Nothing on the microSD memory card is deleted.)

50 Troubleshooting

Settings >Privacy

Troubleshooting

Crash recovery

In the unlikely event that your phone stops responding to touches and key presses, try a forced reboot—press and hold both the Power key and the down volume key for up to 10 seconds.

Service & Repairs

If you have questions or need assistance, we’re here to help.

Go to www.motorola.com/support select from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

, where you can

Product Safety & Legal

032375o

Battery Use & Safety

The following battery use and safety information applies to all Motorola mobile devices. If your mobile device uses a non-removable main battery (as s tated in your product information), details related to handling and replacing your battery should be disregarded—the battery should only be replaced by a Motorola-approved service facility, and any attempt to remove or replace your battery may damage the product.

Important: Handle and store batteries properly to avoid injury or damage.

battery safety issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the form of your battery.

• Don’t use tools, sharp objects, or excessive force to insert or remove the battery as this can damage the batte ry.

• Don’t let the mobile device or battery come in contact with liquids.*

get into the mobile device’s circuits, leading to corrosion.

• Don’t allow the battery to touch metal objects.

in prolonged contact with the battery contact points, the battery could become very hot.

• Don’t place your mobile device or battery near a heat source.*

can cause the battery to swell, leak, or malfunction.

• Don’t dry a wet or damp battery with an appliance or heat source

dryer or microwave oven.

DOs

• Do avoid leaving your mobile device in your car in high temperatures.*

• Do avoid dropping the mobile device or battery.*

on a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your mobile device or battery has been damaged in any of the ways listed here.

* Note:

Always make sure that any battery, connector and compartment covers are closed and secure to avoid direct exposure of the battery to any of these conditions, even if your product information states that your conditions.

mobile device

If metal objects, such as j ewelry, stay

Dropping these items, especially

can resist damage from these

Most

Liquids can

High temperatures

, such as a hair

Important: Motorola recommends you always use Motorola-branded batteries and chargers for quality assurance and safeg uards.

damage to the mobile device caused by non-Motorola batteries and/or chargers. To help you identify authentic Motorola batteries from non-original or counterfeit batteries (that may not have adequate safety protection), Motorola provides holograms on its batteries. You should confirm that any battery you purchase has a “Motorola Original” hologram. If you see a message on your display such as

Unable to Charge

•

Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and try charging it again;

•

If the message remains, contact a Motorola authorized service center.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire, explosion,

leakage, or other hazard.

Proper and safe battery disposal and recycling:

important for safety, it benefits the environment. You can recycle your used batteries in many retail or service provider locations. Additional information on proper disposal and recycling can be found at

Disposal:

Promptly dispose of used batteries in accordance with local regulations. Contact your loca l recycling center or national recycling organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

Battery Charging

Notes for cha rging your product’s battery:

•

During charging, keep your battery and charger near room temperature for efficient battery charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.

, take the foll owing steps:

www.motorola.com/recycling

Motorola’s warranty does not cover

Invalid Battery

Proper battery disposal is not only

Third Party Accessories

Use of third party accessories, including but not limited to batteries, chargers, headsets, covers, cases, screen protectors and memory cards, may impact your mobile device’s performance. In some circumstances, third party accessories can be dangerous and may void

51Product Safety & Legal

your mobile device’s warranty. For a list of Motorola accessories, visit www.motorola.com/products

Driving Precautions

Responsible and safe driving is your primary responsibility when behind the wheel of a vehicle. Using a mobile device or accessory for a call or other application while driving may cause distraction, and may be prohibited or restricted in certain areas—always obey the laws and regulations on the use of these products.

While driving, NEVER:

•

Type, read, enter or review texts, emails, or any other written data.

•

Surf the web.

•

Input navigation information.

•

Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

•

Keep your eyes on the road.

•

Use a handsfree device if available or required by law in your area.

•

Enter destination information into a navigation device

•

Use voice activated features (such as voice dial) and speaking features (such as audible directions), if available.

•

Obey all local laws and regulations for the use of mobile devices and accessories in the vehicle.

•

End your call or other task if you cannot concentrate on driving. Remember to follow the “Smart Practices While Driving” at www.motorola.com/callsmart

(in English only).

before

driving.

Seizures, Blackouts & Eyestrain

To reduce eyestrain and avoid headaches, it is always a good idea to hold the screen a comfortable distance from your eyes, use in a well-lit area, and take frequent breaks. Some people may be susceptible to seizures or blackouts (even if they have never had one before) when exposed to flashing lights or light patterns, such as when playing video games, or watching videos with flashing-light effects. Discontinue use and consult a physician if any of the following symptoms occur: seizures, blackout, convulsion, eye or muscle twitching, loss of awareness, or disorientation. If you or someone in your family has experienced seizures or blackouts, please consult with your physician before using an application that produces flashing-light effects on your mobile device.

52 Product Safety & Legal

Caution About High Volume Usage

High Volume

Warning:

Exposure to loud noise from any source for extended periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected. To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears, or muffled speech, you should stop listening to the device through your headset or headphones and have your hearing checked. For more information about hearing, see our website at http://direct.motorola.com/hellomoto/nss/AcousticSafety.asp only).

(in English

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.

Children

Keep your mobile device and its accessories away from small children.

products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Supervise access for older children.

your mobile device, you may want to monitor their access to help prevent:

•

Exposure to inappropriate apps or content.

•

Improper use of apps or content.

•

Loss of data.

Similar to a computer, if an older child does use

These

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Operational Warnings

032374o

032376o

032375o

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Areas

Potentially explosive areas are often, but not always, posted and can include blasting areas, fueling stations, fueling areas (such as below decks on boats), fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders. When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries, unless it is a radio product type especially qualified for use in such areas and certified as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas, sparks can occur and cause an explosion or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Do not dispose of your battery or mobile device with your household waste. See “Recycling” for more information.

Do not use tools.

Symbol Definition

For indoor use only.

Radio Frequency (RF) Energy

Exposure to RF Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits. Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

RF Energy Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions:

•

When placing or receiving a phone call, hold your mobile device just like you would a

landline phone.

•

If you wear the mobile device on your body, always place the mobile device in a

Motorola-supplied or approved accessory (e.g. clip, holder, holster, case or arm band). If

you do not use a body-worn accessory supplied or approved by Motorola, ensure that

whatever product is used is free of any metal and that it positions the mobile device at

least 2.5 cm (1 inch) away from the body.

•

Using accessories not supplied or approved by Motorola may cause your mobile device to

exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved

accessories, visit our website at:

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances, your mobile device may cause interference with other devices.

www.motorola.com

53Product Safety & Legal

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so, such as hospitals or health care facilities. In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.

Medical Devices

If you have a medical device, including an implantable medical device such as a pacemaker or defibrillator, consult your healthcare provider and the device manufacturer’s directions before using this mobile device. Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that interference is taking place.

Regulatory Information

Your Motorola mobile device is designed to comply with national and international regulatory requirements. For full compliance statements and details, please refer to the regulatory information in your printed product guide.

Location Services

GPS & AGPS

The following information is applicable to Motorola mobile devices that provide location based functionality. Location sources can include GPS, AGPS and Wi-Fi. Your mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device. Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges, and/or additional charges

54 Product Safety & Legal

may apply in accordance with your service plan. Contact your wireless service provider for details. Your mobile device can also use Wi-Fi signals to determine your approximate location, using information from known and available Wi-Fi networks.

Your Location

Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile devices which are connected to a wireless network transmit location-based information. Devices enabled with location technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS technology in your mobile device to tell the emergency responders your approximate location. AGPS has limitations and

•

Always tell the emergency responder your location to the best of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

Navigation

The following information is applicable to Motorola mobile devices that provide navigation features. When using navigation features, note that mapping information, directions and other navigational data may contain inaccurate or incomplete data. In some countries, complete information may not be available. Therefore, you should visually confirm that the navigational instructions are consistent with what you see. All drivers should pay attention to road conditions, closures, traffic, and all other factors that may impact driving. Always obey posted road signs.

Privacy & Data Security

Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

might not work in your area

. Therefore:

• Monitor access

may have unmonitored access. Use your device’s security and lock features, where available.

• Keep software up to date

patch or software fix for your mobile device that updates the device’s security, install it as soon as possible.

• Secure Personal Information

various locations including your SIM card, memory card, and phone memory. Be sure to remove or clear all personal information before you recycle, return, or give away your device. You can also backup your personal data to transfer to a new device.

Note:

www.motorola.com/support

• Online accounts

MOTOBLUR). Go to your account for information on how to manage the account, and how to use security features such as remote wipe and device location (where available).

• Applications and updates

trusted sources only. Some apps can impact your phone’s performance and/or have access to private information including account details, call data, location details and network resources.

•Wireless

networks. Also, when using your device as a hotspot (where available) use network security. These precautions will help prevent unauthorized access to your device.

• Location-based information

technologies such as GPS, AGPS or Wi-Fi, can transmit location-based information. See “Location Services” for more details.

• Other information your device may transmit

and other diagnostic (including location-based) information, and other non-personal information to Motorola or other third-party servers. This information is used to help

improve products and services offered by Motorola. If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at your service provider.

—Keep your mobile device with you and do not leave it where others

—If Motorola or a software/application vendor releases a

—Your mobile device can store personal information in

For information on how to backup or wipe data from your mobile device, go to

—Some mobile devices provide a Motorola online account (such as

—Choose your apps and updates carefully, and install from

—For mobile devices with Wi-Fi features, only connect to trusted Wi-Fi

—Mobile devices enabled with location based

—Your device may also transmit testing

privacy@motorola.com

, or contact

Use & Care

Use & CareUse & Care

To care for your Motorola mobile device, please observe the following:

liquids

Don’t expose your mobile device to water, rain, extreme humidity, sweat, or other li quids.

drying

Don’t try to dry your mobile device using a microwave oven, conventional oven, or dryer, as this may damage the mobile device.

extreme heat or cold

Don’t store or use your mobile device in temperatures below -10°C (14°F) or above 60°C (140°F). Don’t recharge your mobile device in temperatures below 0°C (32°F) or above 45°C (113°F).

dust and dirt

Don’t expose your mobile device to dust, dirt, sand, food, or other inappropriate materials.

cleaning

To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

shock and vibration

Don’t drop your mobile device.

protection

To help protect your mobile device, always make sure that any battery, connector and compartment covers are closed and secure.

55Product Safety & Legal

Recycling

Mobile Devices & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste, or in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling

Packaging & Product Guides

Product packaging and product guides should only be disposed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

California Perchlorate Label

Perchlorate Label

Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label: Perchlorate Material – special handling may apply when the battery is recycled or disposed of. See

www.dtsc.ca.gov/hazardouswaste/perchlorate

There is no special handling required by consumers.

(in English only).

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices

Hearing Aid Compatibility

On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01- 309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to require digital wireless phones be compatible with hearing-aids. The intent of the HAC Act is to ensure reasonable access to telecommunications services for persons with hearing disabilities. While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate. The wireless telephone industry has developed a rating system for wireless

56 Product Safety & Legal

phones, to assist hearing device users find phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings:

Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.The Motorola XT886 (IHDT56NH4) is rated M3.

T-Ratings:

Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing aid’s telecoil than phones that are not rated. T4 is the better/higher of the two ratings. The Motorola XT886 (IHDT56NH4) is rated T3. The handset has not been rated for hearing aid compatibility with respect to the Wi-Fi capability. Please power off the Bl uetooth function while using hearing aid devices with your Motorola XT886 (IHDT56NH4). Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this rating. Higher ratings mean that the hearing device is relatively immune to interference noise. The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered acceptable for normal use. A sum of 6 is considered for better use. A sum of 8 is considered for best use. In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level rating, the sum of the two values equal M5. This should provide the hearing aid user with “normal usage” while using their hearing aid with the particular wireless phone. “Normal usage” in this context is defined as a signal quality that is acceptable for normal operation. This methodology applies equally for T ratings. The M mark is intended to be synonymous with the U mark. The T mark is intended to be synonymous with the UT mark. The M and T marks are recommended by the Alliance for Telecommunications Industries Solutions (ATIS). The U and UT marks are referenced in Section 20.19 of the FCC Rules. The HAC rating and measurement procedure are described in the American National Standards Institute (ANSI) C63.19 standard. The Motorola XT886 (IHDT56NH4) was tested for use with hearing aid compatibility using the ANSI C63.19 2007 Standard. For information about hearing aids and digital wireless phones FCC Hearing Aid Compatibility and Volume Control: Gallaudet University, RERC:

http://www.fcc.gov/cgb/dro/hearing.html

https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm

Software Copyright

Software Copyrig ht Notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA MOBILITY, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA The Motorola website information regarding Motorola's use of open source. Motorola has created the interaction with the software community-at-large. To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please touch

opensource.motorola.com

(in English only) also contains

website to serve as a portal for

Apps >

Settings >About phone >Legal information

Open source licenses

self-contained applications that present supplemental notices for open source packages used in those applications.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Product Registration

Registration

Online Product Registration: www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product you will need to provide a copy of your dated sales receipt to confirm warranty status. Thank you for choosing a Motorola product.

. In addition, this Motorola device may include

(in English only)

Service & Repairs

If you have questions or need assistance, we're here to help. Go to

www.motorola.com/repair www.motorola.com/support customer care options. You can also contact the Motorola Customer Support Center at 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

How to Obtain Service or Other Information

1. Please access and review the online Customer Support section of Motorola's consumer

website prior to requesting warranty service.

2. If the Product is still not functioning properly after making use of this resource, please

contact the Warrantor listed at the Motorola website or the contact information for the

(United States) or

(Canada), where you can select from a number of

57Product Safety & Legal

corresponding location.

3. A representative of Motorola, or of a Motorola Authorized Repair Center, will help determine whether your Product requires service. You may be required to download, or otherwise obtain and accept software updates from Motorola or a Motorola Authorized Repair Center. You are responsible for any applicable carrier service fees incurred while obtaini ng the required downloads. Complying with the warranty process, repair instructions and accepting such software updates is required in order to receive additional warranty support.

4. If the software update does not fix the problem, you will receive instructions on how to ship the Product to a Motorola Authorized Repair Center or other entity.

5. To obtain warranty service, as permitted by applicable law, you are required to include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) your address and telephone number. In the event the Product is not covered by the Motorola Limited Warranty, Motorola will inform the consumer of the availability, price and other conditions applicable to the repair of the Product.

To obtain service or other information, please access and review the online Customer Support section of Motorola's consumer website at

www.motorola.com

Motorola Mobility Inc. Limited Global Warranty Mobile Phones

Warranty

Note: This Limited Warranty is not app licable in Quebec, Canada. FOR CONSUMERS WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR REGULATIONS IN THEIR COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED WARRANTY ARE IN ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY SUCH CONSUMER PROTECTION LAWS AND REGULATIONS.

Who is Covered?

This Limited Warranty extends only to the first consumer purchaser of the Product, and is not transfe rable.

What Does this Limited Warranty Cover?

Motorola Mobility Inc. or its subsidiaries' warranty obligations are limited to the terms and conditions set forth herein. Subject to the exclusions contained below, Motorola Mobility Inc or its subsidiaries ("Motorola") warrant this Mobile Phone, and any in-box accessories which

58 Product Safety & Legal

accompany such Mobile Phone ("Product") against defects in materials and workmanship, under normal consumer use, for a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser, or the period of time required by the laws of the country where the Product is purchased, whichever is longer ("Warranty Period"). Repairs made under this Limited Warranty are covered for the balance of the original Warranty Period, or 90 days from the date of service, whichever is longer. Any upgrade to the original product will be covered only for the duration of the original Warranty Period. This Limited Warranty is only available in the country where the Product was purchased. Motorola may provide service outside the country of purchase, to the extent that it is possible and under the terms and conditions of the country of purchase. This Limited Warranty applies only to new Products which are a) manufactured by or for Motorola as identified by the "Motorola" trademark, trade name, or logo legally affixed to them; b) purchased by consumers from an authorized reseller or distributor of Motorola Products; and c) accompanied by this written Limited Warranty.

What Will Motorola Do?

If a covered defect or damage arises and a valid warranty claim is received within the applicable Warranty Period, Motorola, at its sole option, unless otherwise required by applicable law, will either (1) repair, at no charge, the defect or damage using new, used or reconditioned/refurbished functionally equivalent replacement parts; or (2) exchange the Product with a replacement Product that is new or which has been reconditioned/refurbished or otherwise remanufactured from new or used parts and is functionally equivalent to the original Product; or (3) refund the purchase price of any Products covered by the terms and conditions of thi s Limited Warranty. Products, parts and supporting documentation provided to Motorola as part of the warranty process, shall become the property of Motorola, and may not be returned. When a replacement or refund is given, the Product for which the replacement or refund is provided must be returned to Motorola and shall become the property of Motorola.

Exclusions (Products and Accessories)

This warranty does not apply to:

(a)

Consumable parts

time unless failure has occurred due to a defect in materials or workmanship. As with all batteries, the maximum capacity of the battery will decrease with time and use; this is not a defect. Only defective batteries and batteries that leak are covered by this warranty. (b)

Cosmetic damage

cosmetic damage.

, such as batteries or protective coatings designed to diminish over

, including but not limited to scratches, dents, cracks or other

(c)

Damage caused by u se with non-Motorola products.

from the use of non-Motorola branded or certified Products, accessories or other peripheral equipment, including without limitation housings, parts, or software, are excluded from coverage. (d)

Damage caused by accident, abuse, misuse, liquid contact, fire, earthquake or

other external causes

operating the Product outside their permitted or intended uses as defined by Motorola, including but not limited to as set forth by Motorola in the Products' User Manual, Quick Start Guide, Online Tutorials, and other documentation), improper storage (e.g. subjecting the Product to extreme temperatures), abuse or neglect (e.g. broken/bent/missing clips/fasteners/connectors); impact damage (e.g. dropping the Product) (ii) contact with liquids, water, rain, extreme humidity, heavy perspiration or other moisture; sand, food, dirt or similar substances (except for Products sold as resistant to such substances, but only to the extent the damage was not caused by incorrectly securing the phone's protective elements or subjecting the Product to conditions beyond its stated specifications or limits); (iii) use of the Products for commercial rental purposes; or (iv) external causes or acts which are not the fault of Motorola, including but not limited to flood, fire, earthquake, tornado or other acts of God, are excluded from coverage. (e)

Unauthorized Service or Modification.

testing, adjustment, installation, maintenance, alteration, or modification in any way, including but not limited to tampering with or altering the software, by someone other than Motorola, or its authorized service centers, are excluded from coverage. Notwithstanding the foregoing, any Product which has had its bootloader unlocked, or whose operating system has been altered, including any failed attempts to unlock the bootloader or alter such operating system, is not covered by this warranty, regardless of whether such modifications are authorized, approved, or otherwise sanctioned by Motorola. (f)

A product or part that has been modified in any manner without the written

permission of Motorola.

Motorola from determining whether such Products are covered under the terms of this Limited Warranty are excluded from coverage. The forgoing shall include but not be limited to (i) serial numbers, date tags or other manufacturer coding that has been removed, altered or obliterated; (ii) mismatched or duplicated serial numbers; or (iii) broken seals or other evidence of tampering. Do not open the Product or attempt to repair the Product yourself; such conduct may cause damage that is not covered by this warranty. (g)

Normal wear and tear or otherwise due to the normal aging of the Product.

(h)

Defects, damages, or the failure of the Product due to any communication

service or network you subscribe to or use with the Products.

; including but not limited to: (i) improper usage or operation (e.g.

Defects or damage resulting from service,

Products that have been altered in any manner so as to prevent

Defects or damage that result

(i)

All software, including operating system software, third-party software,

applications, and all other software of any kind.

provided "AS-IS" and "AS AVAILABLE," "WITH ALL FAULTS" and without a warranty of any kind. The Limited Warranty does not apply to any non-Motorola product or any software, even if packaged or sold with the Motorola hardware, unless otherwise required by applicable local law. (j)

Products that hav e been refurbished, recondit ioned, or remanufactured

Products repaired or replaced pursuant to the terms of this Limited Warranty. If dama ge is outside t he scope of warr anty coverage, repair servi ces may be availa ble, but all costs associated with such out of warranty repair will be your responsibility.

What Other Limitations are There?

•

TO THE EXTENT PERMITTED BY APPLICABLE LAW, THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES AND REMEDIES, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR IMPLIED. NO ORAL OR WRITTEN REPRESENTATIONS MADE BY MOTOROLA OR ANY SELLER, RESELLER OR DISTRIBUTOR OF THE PRODUCTS, INCLUDING EMPLOYEES AND AGENTS THEREOF, SHALL CREATE ANY ADDITIONAL WARRANTY OBLIGATIONS, INCREASE THE SCOPE, OR OTHERWISE MODIFY IN ANY MANNER THE TERMS OF THIS LIMITED WARRANTY.

•

TO THE EXTEN T PERMITTED BY APPLICABLE LAW, MOTOROLA SPECIFICALLY DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT AND ALL WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. WHERE SUCH STATUTORY OR IMPLIED WARRANTIES CANNOT LAWFULLY BE DISCLAIMED, THEN TO THE EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE DURATION OF THE EXPRESS LIMITED WARRANTY CONTAINED HEREIN AND THE REMEDIES OF REPAIR, REPLACEMENT, OR REFUND AS DETERMINED BY MOTOROLA IN ITS SOLE DISCRETION SHALL BE THE EXCLUSIVE REMEDY OF THE CONSUMER.

•

TO THE EXTENT PERMITTED BY APPLICABLE LAW, MOTOROLA DOES NOT WARRANT THAT THE OPERATION OF ANY PRODUCTS OR SOFTWARE COVERED UNDER THIS LIMITED WARRANTY WILL MEET YOUR REQUIREMENTS, WORK IN COMBINATION WITH ANY HARDWARE OR SOFTWARE APPLICATIONS OR THIRD PARTY SERVICES, BE UNINTERRUPTED, ERROR-FREE, OR WITHOUT RISK TO, OR LOSS OF, ANY INFORMATION, DATA, SOFTWARE OR APPLICATIONS CONTAINED THEREIN, OR THAT DEFECTS IN THE PRODUCTS OR SOFTWARE WILL BE CORRECTED.

Software distributed by Motorola is

, except for

59Product Safety & Legal

•

TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT, TORT OR UNDER OTHER LEGAL THEORY (INCLUDING NEGLIGENCE), FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCTS, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS; LOSS OF BUSINESS; BUSINESS INTERRUPTION; LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION; LOSS OF, DAMAGE TO, OR CORRUPTION OF INFORMATION, DATA, SOFTWARE OR APPLICATIONS (INCLUDING ANY COSTS ASSOCIATED WITH RECOVERING, PROGRAMMING, OR REPRODUCING ANY INFORMATION, DATA, SOFTWARE OR APPLICATIONS STORED ON OR USED WITH MOTOROLA PRODUCTS, OR ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF ANY INFORMATION OR DATA STORED ON THE PRODUCTS); OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS.

•

SOME STATES OR JURISDICTIONS DO NOT ALLOW THE LIMITATION OR EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE EXCLUSION OR LIMITATION ON THE LENGTH OF AN IMPLIED WARRANTY, OR THE LIMITATION OR EXCLUSION OF DAMAGES FOR PERSONAL INJURIES CAUSED BY NEGLIGENCE, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE OR JURISDICTION.

• DATA BACKUP:

INCLUDING BUT NOT LIMITED TO PERSONAL CONTACTS, ADDRESS BOOKS, PICTURES, MUSIC AND GAMES WILL BE ERASED DURING THE REPAIR PROCESS, AND CAN NOT BE REINSTALLED BY MOTOROLA. TO AVOID LOSING SUCH INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS PLEASE CREATE A BACK UP BEFORE YOU DELIVER YOUR PRODUCT FOR WARRANTY SERVICE, REMOVE ANY CONFIDENTIAL, PROPRIETARY OR PERSONAL INFORMATION AND DISABLE ANY SECURITY PASSWORDS. YOU WILL BE RESPONSIBLE FOR REINSTALLING ALL SUCH INFORMATION, DATA, SOFTWARE, OTHER APPLICATIONS AND PASSWORDS. MOTOROLA AND/OR ITS AUTHORIZED SERVICE CENTERS ARE NOT RESPONSIBLE FOR THE LOSS OR MISUSE OF ANY DATA, FILES, CONTENT, APPLICATIONS AND PROGRAMS WHEN THE PRODUCT IS DELIVERED FOR WARRANTY SERVICE. YOUR PRODUCT OR A REPLACEMENT PRODUCT WILL BE RETURNED TO YOU AS YOUR PRODUCT WAS CONFIGURED WHEN ORIGINALLY PURCHASED, SUBJECT TO APPLICABLE SOFTWARE UPDATES. MOTOROLA MAY INSTALL OPERATING SYSTEM SOFTWARE UPDATES AS PART OF WARRANTY SERVICE THAT MAY PREVENT THE PRODUCT FROM REVERTING TO AN EARLIER VERSION OF THE OPERATING SYSTEM SOFTWARE. THIRD PARTY APPLICATIONS INSTALLED ON THE

60 Product Safety & Legal

ALL INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS,

PRODUCT MAY NOT BE COMPATIBLE OR WORK WITH THE PRODUCT AS A RESULT OF THE OPERATING SYSTEM SOFTWARE UPDATE. MOTOROLA AND ITS AUTHORIZED SERVICE CENTERS ARE NOT RESPONSIBLE FOR THE LOSS OF, OR INABILITY TO USE, SUCH INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS.

• WARNING AGAINST UNLOCKING THE B OOTLOADER OR ALTERING A PRODUCT'S OPERATING SYSTEM SOFTWARE:

RECOMMENDS AGAINST ALTERING A PRODUCT'S OPERATING SYSTEM, WHICH INCLUDES UNLOCKING THE BOOTLOADER, ROOTING A DEVICE OR RUNNING ANY OPERATING SOFTWARE OTHER THAN THE APPROVED VERSIONS ISSUED BY MOTOROLA AND ITS PARTNERS. SUCH ALTERATIONS MAY PERMANENTLY DAMAGE YOUR PRODUCT, CAUSE YOUR PRODUCT TO BE UNSAFE AND/OR CAUSE YOUR PRODUCT TO MALFUNCTION. IN SUCH CASES, NEITHER THE PRODUCT NOR ANY DAMAGE RESULTING THEREFROM WILL BE COVERED BY THIS WARRANTY.

• IMPORTANT FCC INFORMATION:

TO THE PRODUCT THAT WILL IMPACT ITS FCC GRANT OF EQUIPMENT AUTHORIZATION. THE FCC GRANT IS BASED ON THE PRODUCT'S EMISSION, MODULATION, AND TRANSMISSION CHARACTERISTICS, INCLUDING: POWER LEVELS, OPERATING FREQUENCIES AND BANDWIDTHS, SAR LEVELS, DUTY-CYCLE, TRANSMISSION MODES (E.G., CDMA, GSM), AND INTENDED METHOD OF USING THE PRODUCT (E.G., HOW THE PRODUCT IS HELD OR USED IN PROXIMITY TO THE BODY). A CHANGE TO ANY OF THESE FACTORS WILL INVALIDATE THE FCC GRANT. IT IS ILLEGAL TO OPERATE A TRANSMITTING PRODUCT WITHOUT A VALID GRANT.

YOU MUST NOT MAKE OR ENABLE ANY CHANGES

MOTOROLA STRONGLY

Copyright & Trademarks

Motorola Mobility, Inc. Consumer Advocacy Office 600 N US Hwy 45 Libertyville, IL 60048 www.motorola.com

Note:

Do not ship your product to the above address. If you need to return your product for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at: 1-800-734-5870 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) Certain features, services and applications are network dependent and may not be available in all areas; additional terms, conditions and/or charges may apply. Contact your service provider for details. All features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

Note:

The images in this guide are examples only. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, the Google logo, Google Maps, Google Talk, Google Latitude, Gmail, YouTube, Picasa, Google Books, Google Docs, Google Goggles, Google Finance, Google Places, Google Maps Navigation Beta, Google Calendar, Android and Google Play are trademarks of Google, Inc. All other product or service names are the property of their respective owners. © 2012 Motorola Mobility, Inc. All rights reserved.

Caution:

Motorola does not take responsibility for changes/modification to the transceiver. Product ID: MOTOROLA XT886 Manual Number: 68017214001-B

61Product Safety & Legal

Motorola XT886 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Congratulations

Your phone

Contents

Let’s go

Assemble & charge

Set up & go

Wi-Fi connect

Cool content & more

Controls

Touch

Press

Speak

SmartActions™

Screen capture

Home screen

Quick start: Home screen

Use & change your home screen

Search

phone status & notifications

Apps & updates

Quick start: Apps & updates

Recent apps

Browse & install apps

Manage & restore apps

Choose carefully

Update my phone

Calls

Quick start: Calls

Make & answer calls

Recent calls

Favorites

Conference calls

Your phone number

Speed dial

Voicemail

Emergency calls

Cool down

Contacts

Quick start: Contacts

Transfer & sync contacts

Combine contacts

Create contacts

Edit or delete contacts

View CONTACTS

Groups

Favorites

Call, TEXT, or email contacts

Messages

Quick start: Messages

Read & reply to messages

Create messages

Send & receive attachments

Gmail

Email

Instant messages

Text entry

Touchscreen keypad

Input methods

Typing tips

Text input settings

Social networking

Quick start: social networking

Edit & delete accounts

Photos & videos

Photos

Videos

View photos & videos

Movies

Music

Quick Start: Music

Quick start: Browser

Connect

Downloads

Browser options

YouTube™

Personalize
