Motorola XT862 User Guide

USER GUIDE

Congratulations

DROID3™ by Motorola

DROID3 by Motorola lets you do more and be more. Pound out emails and texts faster than ever before, efficiently and accurately, using the spacious fifth row QWERTY keypad with improved tactile response.

Your new smartphone is a productivity powerhouse:

• Take crisp, quality photos with the 8MP camera on

the back, then videochat with the camera on the front.

• Always stay a step ahead—edit documents and

presentations on the fly with Quick Office.

• Find the hottest retail deals or get into the must-see

concerts with ALOQA by Motorola. With a single click you've got reservations and tickets. And Google Map™ gets you there in a flash with turn-by-turn directions, traffic alerts, and arrival times.

Note: Certain apps and features may not be available

in all countries.

Caution: Before assembling, charging, or using your

phone for the first time, please read the important safety, regulatory and legal information in this guide.

0

Congratulations

More

•Answers: Touch > Help Center.

•Updates: Smartphone updates, computer software,

online help, and more at www.motorola.com/mydroid3

• Accessories: Find accessories for your smartphone

at www.motorola.com/products

Notes:

• All screen shots in this guide are simulated.

Actual displays may vary.

• Instructions to perform tasks in this guide may

change depending on the software version on your phone.

• Unless specified otherwise, all instructions to

perform tasks in this guide assume that you are starting from the home screen.

.

Your phone

1:53

PM

Browser

72º

CHICAGO

12:45

My Accounts Mobil Browser Help Center

3.5mm Headset Connector

Microphone

Volume/ Zoom Keys

Power/

Lock Key

Back Key

Search Key

Micro USB

Connector

HDMI

Connector

Menu Key

Home Key

To u chscreen

1 2 3 4 5 6 7 8 9 0

?

Scroll & Select

Enter

Space

@ Key

Alternate

Shift

Delete

Search

Tab

Voice Recognition

the important keys & connectors

Your phone

1

Contents

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

MEDIA CONNECTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Apps & updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Bluetooth® wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Memory card & file management . . . . . . . . . . . . . . . . . . . . . . 42

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Global Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Service & repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

2

Contents

Let’s go

let’s get you up and running

Assemble & charge

1 cover off 2 microSD in (may be

1080p|8MP

HD VIDEO

sold separately)

1080p|8MP

HD VIDEO

Caution: Please read “Battery Use & Safety” on

page 60.

Note: GSM and UMTS-based global services work

only with a SIM card supplied by Verizon Wireless® or by another GSM or UMTS service provider. When you set your phone to use a GSM 900/1800 or UMTS 2100 network (see “Select a network” on page 14), you may be prompted to enter a subsidy code. To get this code, contact Verizon Wireless.

Tip: To save battery life, see “Battery tips” on

page 22.

3 SIM in (already in) 4 battery in

1080p|8MP

HD VIDEO

1080p|8MP

HD

VIDEO

5 cover on 6 charge up

1080p|8MP

HD

VIDEO

Set up & go

The first time you turn on your phone, a setup wizard guides you through signing in to your Gmail™ account. If you don’t have one, don’t worry, the wizard will help you create one.

After you log into Gmail, you can set up social networking, or you can do it later.

Note: This phone supports data-intensive apps and

services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details.

3H

Let’s go

3

1 Press and hold Power/Lock on

top of your phone to turn it on.

2 Select a language.

3 Follow the setup wizard to create or

log in to your Gmail account.

Note: If you have an existing Gmail

account, your contacts from that account are synced to your phone. Whenever you choose to select all contacts for the one you want, your phone shows every contact, in every group.

Wi-Fi connect

If you want to use a Wi-Fi network for even faster Internet access, touch Menu >

Wireless & networks > Wi-Fi settings. Touch Wi-Fi to

> search for and connect to wireless networks. There’s more in “Wi- Fi” on page 45.

Settings

Cool content & more

Browse and download thousands of the coolest apps on the planet from Android Market™.

Download new apps with “Apps & updates” on page 41.

4

Let’s go

Touchscreen & keys

1:53

PM

12:45

a few essentials

Touch tips

It’s all in the touch:

• Touch: Choose an icon or option.

• Touch & Hold: Open options.

•Drag: Scroll or move slowly.

•Flick: Scroll or move quickly.

• Pinch-to-zoom: Get a closer look at Google

Maps™, web pages, or photos.

To zo om in or out, slide two fingers apart or together.

Drag or flick to scroll.

Touchscreen on/off

On when you need it and off when you don’t.

• To make your touchscreen sleep or wake up, just

press Power/Lock .

• When you talk on your phone, the touchscreen

sleeps to prevent accidental touches.

• To change how long your phone waits before the

screen goes to sleep automatically, touch Menu

Settings > Display > Screen timeout.

>

• To make the screen lock when it goes to sleep, use

“Screen lock” on page 56. To unlock the screen, press Power/Lock or open the phone. Then, drag to the right.

Note: Your touchscreen

might stay dark if the sensor above it is covered. Don't use covers or screen protectors (even clear ones) that cover this sensor. To find Motorola accessories for your phone, visit www.motorola.com/products

.

Touchscreen & keys

5

Key tips

Browser

72º

CHICAGO

Voicemail Email Browser Market

Back

Search

Menu

Home

Menu, home, back, & search

Touch Home to close any menu or app and return to the home screen. In the home screen, touch and hold Home to show the last few apps you used, then touch an app to open it.

Touch Menu to open menu options.

Touch Back to go back.

Touch Search for text search, or touch and hold for voice search.

Power/Lock

Press and hold Power/Lock to turn Airplane mode

Silent mode on or off, or turn off your smartphone

or

Power off).

(

To save your battery, prevent accidental touches, or when you want to wipe smudges off your touchscreen, put the touchscreen to sleep by pressing

Power/Lock . To wake up the touchscreen, just press Power/Lock again or touch Home .

To change how long your smartphone waits before the screen goes to sleep automatically, touch Menu

Settings > Display > Screen timeout.

>

Tip: To lock the screen when it goes to sleep, use

“Screen lock” on page 56.

Volume

Press the volume keys to change the ring volume (in the home screen), or the earpiece volume (during a call).

When playing music or video files, press the volume keys to adjust media volume.

Rotate the screen

When you turn your phone, the touchscreen can rotate to stay right-side up:

Find it: Menu >

screen

Settings > Display > Auto-rotate

6

Touchscreen & keys

Quick tips

If you’re not sure what to do next, try one of these:

To .. .

Get the details—Open a

text message, see details for a contact, or open items in other lists.

See screen me nu—Open

a menu for the current screen.

See item options—Open

an options menu (if available) for an item on the screen.

Start again—Go back to

the home screen.

Wake up your phone—Turn on a

sleeping touchscreen.

Touch the message, contact, or item.

Touch Menu .

Touch & hold the item.

Touch Home .

Press Power/Lock or open the phone.

Touchscreen & keys

7

Home screen

12:4512:45

1:53

PM

12:45

2:02

Flick left or right to see more panels.

Shortcuts

Touch to open.

Status Indicators

Notifications

Flick this bar down to see details.

Open the app menu. Touch Back to close.

Voicemail Email Browser Market

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in one place. It’s what you see when you turn on your phone or touch Home from a menu:

The home screen extends left and right to give you more room for adding shortcuts, widgets, and more. Flick the home screen left and right to see more panels or to add widgets or shortcuts.

Use & change your home screen

On your home screen, shortcuts are icons that open your favorite apps, web bookmarks, contacts, mail labels, or music playlists. Widgets show you news, weather, messages, and other updates.

Flick the home screen left or right to open other panels of shortcuts and widgets.

• To open something, touch it. Touch Home to

return to the home screen.

Tip: When you open a widget, touch Menu to

show any options or settings (you can choose accounts for

Messages, or Calendar widgets).

There’s more about social networking widgets in “Social networking” on page 25.

Social Networking, Social Status,

Note: Your home screen might look a little different.

8

Home screen

• To resize a widget, touch

Kristine Kelley

Not even ready to go back to school

8

3pm

Budget Meeting

THU

JUL

m

g

THU

JU

L

Google

Touch here to enter text, then touch Go to search.

Touch to search by voice.

Touch to search:

Web Apps

Contact Search

All

C

and hold the widget until you feel a vibration, then drag.

3p

Budget Meetin

• To add something or

change your wallpaper, touch and hold an empty spot until you see the

to Home screen

Add

menu.

You can add a folder to organize your shortcuts.

• To move or delete something, touch and hold it

until you feel a vibration, then drag it to another spot, another panel, or the trash at the top of the screen.

Search

Touch Search on the front of the phone, or touch Search on your phone’s slide-out keypad. Then use the search window that appears.

To search by voice, touch , then speak your keyword(s) when prompted.

To type your search, touch the search window, then enter your keyword(s) and touch

Go.

Smartphone status & notifications

The status bar at the top of the screen has icons that tell you about messages and smartphone status. To view your notifications, touch the status bar and drag it down. Touch a notification to select it.

Home screen

9

Tip: To see today’s date, touch and hold the status bar

2:50 PM

2:47 PM

2:45 PM

2:41 PM

Mary Micci

Copy Revisions

Jim Somers

Meet me outside the theater...

New email

paul.wang6@gmail.com(2)

New voicemail

Dial *86

Notifications

Clear

11:35

Verizon Wireless

May 14, 2011

at the top of the screen.

10

Home screen

Calls

Connected

00:12

Add call

Bluetooth Mute

Dialpad

End call

Mobile (555) 555-7931

Chicago, IL

Kristine Kelley

Speaker

11:35

12:45

1:53

PM

12:45

2:02

Call Timer

Mute or unmute the call.

Hang up.

Turn the speaker on or off.

Enter numbers during a call.

Switch to a Bluetooth device.

Create a 3-way call.

it’s good to talk

Quick start: Calls

Dialing options

From the home screen, touch . .

1:53

Dialer

Most recent

Abe Baudo

Mobile 1-555-555-5555 May 25

1

GHI

4

7

*

Recent Contacts Favorites

2

5

8

0

ABC DEF

3

+ #

MNO

6

9

JKL

TUVPQRS WXYZ

Recent Calls List

12:45

2:02

12:45

PM

Touch to open, then touch an entry to call.

Return call.

Delete

Add number to contacts.

Enter a phone number & touch here to call it.

Voice dial.

In-call options

During a call:

• To use a Bluetooth® device, touch Bluetooth. (The

device must be turned on and previously paired—see “Connect new devices” on page 43.

Calls

11

• To mute a call, touch Mute.

Ignore

End call

• To use the speakerphone, touch

Speaker.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Tip: You can touch Home or Back to leave the

active call display. To reopen it, touch Home >

Return to call in progress.

>

Make & answer calls

To make a call, touch , enter a number, then touch

.

To answer a call when the screen is locked, drag to the right.

To answer a call when the display is active:

• Answer—Touch .

12

Calls

Answer

• Ignore—Touch . You can send a text message

to the caller and touch

Ok, or touch Cancel.

12:45

2:02

12:45

1:53

PM

While the display is not active, answer by dragging to the right. To ignore a call, touch

Ignore.

End calls

Touch .

Note: When you hold your phone to your ear, the

display goes dark to prevent accidental touches. When you move the phone away from your ear, the display lights up again.

calls (outside the U.S.)

Your phone has an assisted dialing feature that makes dialing easy. For local calls, just dial the local number. For international calls, dial the country code, the area code (if applicable), then the phone number.

Recent calls

Find it: > Recent

• To call an entry, touch beside it.

• To remove the entry from the list, send a text

message to the entry, or for other options, touch and hold an entry.

• To clear the list, touch Menu > Clear list.

12:45

2:02

1:35

12:45

1:53

PM

Recent FavoritesContacts

Dialer

All calls

Abe Baudo

mobile 654-322-4343

Allie Smyth

mobile 223-555-2323

Anna Medina

mobile 564-234-2424

Astrid Fanning

mobile 434-123-4567

Abe Baudo

mobile 654-322-4343

Unknown

5 mins ago

35 mins ago

2 hours ago

5 hours ago

13 hours ago

Set how calls are viewed.

Call

Touch & hold to remove from list, send a text

message, & more.

Frequent calls

Find it: > Favorites

• To call a number, touch it.

• To send a text message, view a contact, or other

options, touch and hold an entry.

Calls

13

• To add a contact to Favorites, select the contact and

Favorites until the star is green.

touch

Conference calls

To start a conference call, dial the first number. After the call connects, touch number, or select it from contacts or favorites. When the next number answers, touch

Add Call. Dial the next

Merge calls.

TTY mode

Your phone can use an optional teletypewriter (TTY) device, for people who are hard of hearing or have a speech impairment.

1 Plug the TTY device into the phone’s headset

connector.

2 Touch Menu >

mode

and choose a TTY setting.

Settings > Call settings > TTY

Select a network

DROID3 Global by Motorola switches effortlessly between CDMA, GSM 900, GSM 1800, and UMTS 2100 networks, so you can make calls in over 200 countries worldwide.

Note: To use your phone on a GSM or UMTS network,

you need to insert a SIM card (see “Assemble & charge” on page 3), supplied by Verizon Wireless® or

a compatible GSM or UMTS network ser vice provider.

To set your phone to roam globally:

Find it: Menu >

Mobile networks > Network Mode > Global

>

Settings > Wireless & networks

Your phone number

Find it: Menu > Settings > About phone > Status

My phone number

>

14

Calls

Emergency calls

Note: Your service provider programs one or more

emergency phone numbers (such as 911 or 112) that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

1 Touch . (if your phone is locked, touch Emergency

Call

).

2 Enter the emergency number.

3 Touch to call the emergency number.

Note: Your mobile device can use GPS and AGPS

signals to help emergency services find you. See “Location Services (GPS & AGPS) ” on page 65.

Cool down

In very limited circumstances, such as where your phone has been exposed to extreme heat, “Cool Down” message screens will appear. To avoid possible damage to your battery and phone, you should follow these instructions until the phone is within its recommended temperature range. When your phone is in “Cool Down” mode, only emergency calls can be made.

Calls

15

Contacts

Abe Baudo

Dialer

Recent FavoritesContacts

Allie Smyth

Anna Medina

Astrid Fanning

# A B C D E F G H I J K L M N O

12:45

1:53

12:45

2:02

Group

Create & view groups of contacts.

Create Contacts

Contacts List

Touch to view contact information. Touch & hold to call, send a text message, & more.

Touch a letter to jump to contact names that start with that letter.

contacts like you’ve never had before

Quick start: Contacts

Find it: > Contacts

Tip: You can also touch > Contacts.

16

Contacts

Call contacts

Find it: > Contacts

Touch a contact to open its details. If a phone number is available for the contact, you’ll see to the right of the contact name. Touch to call the contact.

View & use contacts

When you set up a social networking account (see “Social networking” on page 25), you’ll know what everybody’s up to and when. Every time you pick up a call, check a message, or look up a friend’s contact info, you’ll see their name and number, but you can see their social network status and smiling face, too.

Find it: >

Contacts

• To find a contact, just type the name.

Touch a contact to open its details. While viewing details, you can start a call or message by touching a phone number or other info.

• To change which contacts are shown and how they

are sorted, touch Menu >

Display options.

Edit or delete contacts

Find it: > Contacts

Touch and hold the contact, then touch Edit contact or

Delete contact.

Transfer contacts

Sara

Walker

Contacts

Phone

Google contact

from youraccount@gmail.com

Home

Email

Home

Postal address

Save

Cancel

More

Organization

Add details.

Add a line for another entry.

Remove the entry.

Save your entries.

Get all your contacts, all in one place. Here’s a few helpful hints:

• Use Gmail

All your Gmail contacts will automatically get synced to your phone. Various computer applications for mobile phones and email accounts allow you to export your contacts as a “.CSV” file. You can then use Gmail to import the file. For more details, go to www.motorola.com/transfercontacts to your Gmail account on your computer and select ”Help”.

• Use a SIM

You can transfer contacts from your old phone to your new Motorola phone using your SIM card—see “Transfer contacts using your SIM” on page 17.

• More

There are other methods and tools to help you at

www.motorola.com/transfercontacts

Transfer contacts using your SIM

1 On your old phone, copy all the contacts you want

to your SIM card.

2 Insert your SIM card in your new phone, see

“Assemble & charge” on page 3.

.

or log in

3 Import the contacts from your SIM card,

touch >

Manage contacts > Import contacts from SIM

>

card

Contacts, then touch Menu

.

Create contacts

Find it: > Contacts > Menu > Add contact

Slide out the keypad, or touch any entry area to open the touchscreen keypad.

Contacts

17

When you’re finished, touch Save.

Dialer

Recent FavoritesContacts

12:45

1:53

PM

12:45

2:02

Touch to create & view groups.

Where are contacts saved? Your phone saves new

contacts in its memory and to your Google™ account. It also updates your social networking account.

Synchronize contacts

When you change one of your contacts, your phone automatically updates your other social networking accounts. Whenever you change a friend in your social networking accounts, your phone updates your contacts and social networking account.

Groups

Find it: > Contacts >

You can put your contacts into groups that you create (like “friends”, “family”, or “work”). You can then find contacts faster by showing one group at a time.

18

Contacts

Tip: Your phone updates your contacts and social

networking account whenever you change a friend in your social networking accounts.

Text entry

Delete

Return/ New Line

Space

Letters/Numbers

Touch to open a keypad for symbols or numbers.

Shift

Microphone

Touch for voice input.

think keyboard, now think smaller

Touchscreen keypad

When your phone is closed, you can open a touchscreen keypad by touching a text entry field.

To...

Enter one capital letter Press Shift .

Enter only capital letters Press Shift

Select text Hold Shift and

Cut, Copy, or Paste

selected text

Delete a character (hold to

delete more)

twice. Press again to revert to lowercase.

press a navigation key.

Touch and hold the text box to open the editing menu.

Press Delete .

Typing tips

To use the full keypad, just open your phone:

To .. .

Enter symbols Touch Symbol .

Input methods

To select an input method for a touchscreen keypad, touch and hold a text entry area on the screen to open

Edit text menu. Touch Input method, then touch

the the method you want:

Text entry

19

Swype™ text entry

day

book

For double letters, circle the letter.

Who

To capitalize, go above the keypad.

Swype lets you enter words on your touchscreen keypad with one continuous motion. To enter a word, just drag your finger over the letters in the word.

Tips:

• To enter apostrophes in common words (like “I’ll”),

drag through the

• To enter several symbols, touch

n as though it was an apostrophe.

SYM.

• To correct a word, double-tap it. Swype shows a

small menu of other word options. Swype might also show a menu if it can’t guess your word.

• If Swype doesn’t know a word, you can still touch

the letter keys to enter it. Swype remembers, so next time you can just drag over the letters.

Multi-touch keyboard

Enter text on a touchscreen keypad one letter at a time. As you type, your phone suggests words from your dictionary and chosen language. Your phone also automatically enters apostrophes in some words, like “dont.” You can also touch two keys at the same time, such as Shift with a letter.

20

Text entry

Text entry settings

When you enter text, your phone automatically corrects or suggests words. To change these settings, touch Menu > then:

• To edit your word suggestion dictionary, touch

dictionary

Settings > Language & keyboard,

User

.

• To change the language and the style for your

touchscreen keypad, touch

Select locale.

• To change the sounds, corrections, and other

settings for your touchscreen keypad, touch

Multi-touch keyboard.

or

Swype

• To change the automatic correction settings for your

full keypad, touch

Built-in keyboard.

Text entry

21

Tips & tricks

a few handy hints

General tips

• If you can’t to see the screen while wearing

sunglasses, take them off. Screen brightness changes as your phone senses the current lighting conditions.

• To return to home screen, touch Home .

• To see recently dialed numbers, touch >

• To sleep/wake your phone, press Power/Lock .

• To set screen timeout, touch Menu >

Display > Screen timeout.

>

• To search, touch Search .

• To show last few apps, touch and hold Home .

• To turn sound on/off, press and hold Power/Lock

Silent mode.

>

• To turn airplane mode on/off, press and hold

Power /Lock >

22

Tips & tricks

Airplane mode.

Recent.

Settings

Battery tips

Want to extend your battery life? Try these:

• To select a battery profile that suits your phone use,

touch Menu >

manager

> Battery mode.

• To turn off automatic applications sync, touch

Menu >

Data delivery.

>

• To turn off Bluetooth® power, touch Menu

Settings > Wireless & networks > Bluetooth.

>

• To turn off Wi-Fi, touch Menu >

Wireless & networks > Wi-Fi.

>

Settings > Battery & Data

Settings > Battery & data manager

Settings

Messaging

11:35

2:50 PM

2:47 PM

2:45 PM

2:41 PM

Copy Revisions Hi Paul, Please take a look at the ...

Arthur Bando

Meeting invitation Meeting is set for next Thursday at...

Mary Micci

freelancers Paul, We’re going to need help w...

Universal Inbox (3)

Jim Somers

Meet me outside the theater at 8 and don’t forget your ID. Would yo...

Anna Medina

2:02

Create a message.

Touch to open. Touch & hold to

move, delete, & more.

Check for messages now.

Message Type

sometimes it’s best to text, or IM, or email . . .

Quick start: Messaging

Find it: > Messaging > Universal Inbox

Tip: To see more messages, flick or drag up.

Read & reply to messages

Find it: > Messaging > Universal Inbox

Note: Universal Inbox shows all of your messages

together—text, email, and social networking

messages. To show only one type of message, touch a message type instead of

Universal Inbox.

• To open a text message or social networking

message and all of its replies, touch it.

• To respond to a message, just open it and enter

your response in the text box at the bottom.

To for ward a text message, touch and hold a message in the conversation, then touch

message

.

Forward

• To open options, touch and hold a message.

Create messages

Find it: > Messaging >

Choose a message type, such as

Text Messaging or

Facebook. Then, enter the recipient and message. In

text messages and emails, touch Menu for options

Insert... or Delete.

like

receive attachments

When you receive a message with an attachment, open the message and touch the file name to download it. Then, touch the name again to open it. Some file formats can be converted to HTML for faster viewing, and your smartphone will show

version

.

Get HTML

Messaging

23

While viewing the attachment, touch it to save it, share it, and more.

Tip: To send and receive large attachments faster, use

a Wi-Fi connection, in “Wi-Fi” on page 45.

Set up messaging

To add email accounts, touch > My Accounts

Add account.

>

Corporate Sync is for Exchange server work email

•

accounts. Enter details from your IT administrator.

Tip: You might need to enter your domain name

with your user name (like domain/username).

Email is for most personal email accounts. For

•

account details, contact the account provider.

Note: To add other email accounts to your

Messaging widget and Universal Inbox, touch

accounts

To change your settings, touch > > Menu , then touch:

Compose to write a new message.

•

Manage accounts to add or remove an account.

•

Edit Universal Inbox to choose which accounts

•

show messages in the

24

Messaging > Menu > Manage

>

> Add account > Email.

Universal Inbox.

Messaging

• Messaging Settings to set the notification for each

account type (along with other preferences, for email).

Voicemail

When you have a new voicemail, appears at the top of your screen. Drag down the status bar and touch the notification.

If you need to change your voicemail number, in the home screen touch Menu >

settings

> Voicemail settings.

Settings > Call

Social networking

my life, your life

Your social networking account

You can set up a social network account that integrates and syncs all your social networking accounts. No opening and closing apps and menus.

Add accounts

You can add your more accounts to your social networking account. If you don’t have accounts on these sites, visit their websites to set them up.

Find it: >

Add an account by touching it. Then enter your user name and password for that account.

When you sign into social networking accounts, you’ll see your friends and contacts in your your status and updates can appear in your

Networking

screen.

change & delete accounts

Find it: > My Accounts

My Accounts > Add account

Contacts list, and

Social

and Social Status widgets on your home

Touch and hold an account, then touch Open account to change settings, or touch remove it (along with its contacts and messages).

Note: You can’t delete the Google™ account you used

or created when you set up your phone. That account is locked when you set it up.

Remove account to

Social Status & Networking Widgets

Social Status widgets are Motorola widgets used to display status announcements from your social networking accounts. You can use these widgets to update your own status on selected accounts or on all social networks attached to the widget.

To create the widgets:

1 Touch and hold the home screen until the Add to

Home screen

2 Touch

3 Scroll down and touch the widget you want to add

to the home screen—

Status

menu appears.

Widgets.

Social Networking or Social

.

Social networking

25

MEDIA CONNECTIONS

DLNA

Play media

Copy media

to server

Share media

Copy media

to phone

11:35

connect and enjoy

Share, copy, & play media

Note: Copyright—do you have the right? Always follow

the rules. See “Content Copyright” in your legal and safety information.

Share your photos, videos, and songs with friends and family easily.

Find it: >

Note: Connect to a

Wi-Fi network or use your own Wi-Fi hotspot (see “Wi-Fi” on page 45). You’ll need to allow access to other devices to download media from your smartphone and to share your files. If you want to access media files on other devices, they must allow access.

26

MEDIA CONNECTIONS

DLNA

• Play media—Select media for playback on another

device in a Wi-Fi network.

Copy media to server—Sync the media files on your

•

smartphone with other devices.

Copy media to phone—Copy a picture from one

•

smartphone to another.

• Share media—Allow other devices to access media

files on your smartphone. Without downloading any media from your smartphone, other people can view your pictures or videos, or play your songs, on their own devices.

HD viewing

You can create your own HD videos (see “HD videos” on page 29) to view on your wide screen HDTV or monitor.

1 From the camcorder viewfinder, adjust the viewable

area on the HDMI screen by touching Menu

Settings > Video Resolution. Select from a list of

> options.

2 Connect an HDMI cable (sold separately) from the

HDMI connector on your smartphone (see “Your phone” on page 1) to an HDMI port on the TV

monitor.

Mirror mode

Connect your smartphone to your HDTV, monitor, or projector so you can view and interact with your smartphone on the big screen. Show off your photos, videos, and downloaded movies. Enjoy the big screen for gaming, movies, the web, and more. Just attach an HDMI cable (sold separately) to your smartphone and plug it into your big screen.

Note: You cannot play DRM-protected files in mirror

mode.

MEDIA CONNECTIONS

27

Photos & videos

see it, capture it, share it!

Photos

Take photos

Take that family photo, and post it online for everyone to see.

Find it: >

Tag videos with your location.

00:00:00 Locating

Go to your

gallery.

To take the photo, touch and hold .

28

Photos & videos

Camera

Camera Capture Settings

Adjust for greater creative contol.

Note: Photos are stored on your smartphone’s internal

memory unless you switch it to a microSD memor y card (sold separately).

To view your photos, see “Share photos & videos” on page 30

Photo options

You can adjust the camera to optimize your shot. Touch Menu (or touch the screen and drag open the options from the left of the screen):

Settings—Widescreen, Video Resolution, Storage

•

Location

, Geo-tag, and Shutter Tone. Select

Geo-tag to add location information to your photos

Effects—Change photo look: Normal, Black and

•

White

, Negative, and more.

Scenes—Select Auto, Portrait, Landscape, and

•

more.

Modes—Single shot, Panorama, and Multi shot.

•

Brightness—Slide the toggle back and forth to

•

desired brightness.

Flash—Select Flash Off, Flash On, or Auto Flash.

•

Videos

Tag videos with your location.

Drag right to

open settings.

Salt Lake City, Utah

Switch cameras (front or back).

Touch to record.

Switch modes (video/photo).

Touch a setting to

see options.

Zoom in/out.

Record videos

Find it: > Camcorder

Note: To get the clearest videos, wipe the camera lens

clean with a soft, dry cloth before you record a video.

To record a video, touch . Touch again to stop the recording.

To view your videos, see “Share photos & videos” on page 30

HD videos

You can capture HD-quality videos to watch on an HDTV or monitor.

To record an HD quality video, be sure to select the

Video resolution. From the active camcorder

correct viewfinder, touch Menu >

resolution

> HD+ (1080p).

Settings > Video

Camcorder options

You can adjust the camcorder to optimize your recording. Touch Menu (or touch the screen and drag open the options from the left of the screen):

Settings—Widescreen, Video Resolution (HD+

•

(1080p))

, Storage Location, Geo-tag, and Shutter

Tone

. Select Geo-tag to add location information to

your videos.

Effects—Change video look: Normal, Black and

•

White

, Negative, and more.

Audio scenes—You can record audio along with the

•

video. Set audio level: more.

Modes—Select Normal video or Video Message.

•

Brightness—Slide the toggle back and forth to

•

desired brightness.

Light—Select Light Off, or Light on.

•

Everyday, Outdoors, and

Photos & videos

29

View & share photos & videos

11:35

Add social network

12:45

1:53

12:45

2:02

View your captured photos & videos.

Sort your photos & videos.

See your online albums (like Picasa, Flickr, or Facebook).

Go to your friends’ online albums.

See media from DNLA Connected devices on your Wi-Fi network.

Find it: > Gallery

3

Camera roll

My library Online

Friends DLNA servers

Touch a thumbnail to view a photo or video.

Share photos & videos

Find it: > Gallery

1 Touch a photo or video, then touch .

30

Photos & videos

2 Choose how you want to share—like Bluetooth,

Email, Text Messaging, or an online album.

Manage photos & videos

Find it: > Gallery

Touch a thumbnail image from your camera roll or library, then:

• To delete a photo or video, touch Menu >

Delete.

• To set a photo as a contact picture, social network

profile picture, or wallpaper, touch Menu >

as

.

Set

Tip: To copy photos to/from a computer, go to “USB

connection” on page 47.

Edit photos & videos

Find it: > Gallery> picture > Menu > Edit

You can choose advanced editing features to resize, crop, or change the color.

Music

Brook Fairfax

2 songs

Albums Songs Playlists

Max Keppler And AnnaLee...

Miller Heaton/Sprinklesky

3 songs

Running Roughshod

1 song

2 songs

Genres

Artists

Categories

Touch to select music by artist, album, song, or playlist.

Last Played

Touch to play again.

when music is what you need...

Quick start: Music

Note: Copyright—do you have the right? Always follow

the rules. See “Content Copyright” in your legal and safety information.

Find it: >

To play music, touch a category, then touch the song or playlist you want to play.

Tip: When a song is playing, you can add it to a playlist

by touching Menu >

Before you select a song or playlist, touch a category to see these options:

Music

Add to playlist.

Play All, Audio effects, and

Shuffle all. (The options you see are different for

different categories.)

Set up music

What music transfer tools do I need?

To put music on your computer and then load it on your smartphone, you need:

• Microsoft® Windows® computer or Apple®

Macintosh™.

• USB data cable (included with your smartphone).

Note: Your smartphone supports optional,

removable microSD memory cards (sold separately). To make sure your memor y card is installed, go to “Assemble & charge” on page 3.

Tip: To see the available memory on your memory

card, touch Menu >

What audio file formats can I play?

Your smartphone can play many types of files: AAC, AMR, MP3, WAV, WMA, AAC+, and MIDI.

What headphones can I use?

Your smartphone has a 3.5mm headset jack for wired stereo listening (required for FM radio). You can also go wireless with Bluetooth® stereo headphones or speakers (see “Bluetooth® wireless” on page 43).

Settings > Storage.

Music

31

Get music

Transfer music from your computer to your smartphone using a USB cable. See “USB connection” on page 47 to learn how.

Or, download your favorite music from V CAST Music.

Find it: >

VCAST Music

Play music

Touch a song or playlist to start playing music.

Open Playlist

Shuffle On/Off

Repeat Off/All /Current

Max Kepler And AnnaLee...

Running Roughshod

Libby Went Trailriding Without Me

1:14 3:45

32

Music

To t al Song T ime

Progress Bar

Use these music player controls:

• Play/pause—Touch / .

• Previous/next—Touch / .

• Fast for ward/rewind—Touch and hold / .

• View playlist—Touch .

• Shuffle—Touch .

• Repeat—Touch .

• Volu m e—Press the side volume keys.

While playing music, touch Menu for these

Audio effects, Library, Add to playlist, Use as

options:

ringtone

, Use as notification, and Delete.

Hide, wake, turn off

Touch Home to use another app. Your music continues to play.

When you see in the status bar, a song is playing. Flick down to see details. Touch the song to return to the music controls.

To turn off your music, touch .

Playlists

To add a song from the music library to a playlist, touch and hold the song then touch an existing playlist, or touch

Add to playlist. Choose

New to create one.

To add a song to the playlist you're playing, press Menu >

Add to playlist in the music player.

To edit, delete and rename playlists, touch and hold the playlist in the music library.

Music

33

Web

surf the web with your smartphone

Quick start: Browser

Find it: > Browser

11:35 PM

Google

Web Images

Local News

more

Connect

Your smartphone uses the mobile phone network (over the air) or a Wi-Fi connection to automatically access the Web.

Note: Your service provider may charge to surf the

Web or download data.

To use a wireless network, touch Menu >

Wireless & networks. Touch Wi-Fi to turn it on, and

>

Wi-Fi settings to search for nearby wireless

touch networks. Touch a network to connect.

Note: If you can’t connect, contact your service

provider.

Settings

See places near:

New window

Refresh

Chicago -

Sign in

Bookmarks

Forward

update

Windows

More

▼

Touch a link to select it. Touch and hold for more options.

Touch for browser options.

Tip: To zoom, touch the display with two fingers, then

move them apart.

34

Web

Select links

When you touch a link, your phone outlines it and goes to that page. If you touch and hold the link, your phone shows options, like

link

.

Open in new window or Bookmark

Play web videos

The browser features the Adobe® Flash® Player, which adds animation, video, and interactivity to web pages. Touch to begin video playback. Double-tap the video during playback to enlarge it for better viewing.

Browser options

Touch Menu to see browser options:

options

New Window Open a new browser window.

Bookmarks See your bookmarks.

Windows View the browser windows that

Refresh Reload the current page.

Back/Forward Go to previously viewed pages.

More View additional browser options.

are currently open.

YouTube™

Share videos with YouTube users everywhere. You don’t need a YouTube account to browse and view videos.

Find it: >

Note: If you want a YouTube account, go to

www.youtube.com

Menu > touch Menu .

YouTube

. To create an account or sign in, touch

My Channel. To Browse or Upload videos,

Web

35

Personalize

add your personal touch

Widgets

Add widgets

1 Touch and hold the empty spot on your screen.

Tip: You can flick left or right to open other panels

on your home screen.

Widgets and choose a widget.

2 Touch

Set up widgets

You can customize some widgets. Touch a widget to open it, then touch Menu .

Your home screen may already have these widgets:

Messages: Change the widget name or choose how

•

long it shows new messages. To add email accounts, “Set up messaging” on page 24.

Music: Set this widget to an artist, album, song,

•

playlist, or just touch Menu > There’s more about “Music” on page 31.

News: Change the widget name, choose how long it

•

shows new stories, or choose a news source. To choose a source, touch , then choose preset

36

Personalize

Shuffle all.

Bundles or Channels, or choose Custom to enter a

URL for a

Weather: Change temperature units or add

•

locations. To add locations, touch , enter a city, and touch widget, flick left to see other locations you added.

Webpage or an RSS feed.

Search. When you open the weather

Shortcuts

To add shortcuts for apps, bookmarks, and more to the home screen, touch and hold an empty spot on the home screen, touch

Tip: To change one of the docked shortcuts that

always appears at the bottom of the home screen (no matter what panel you’re viewing), touch and hold the shortcut.

Shortcuts, and select a shortcut.

Ringtones

To personalize your ringtones:

Find it: Menu >

ringtone

or Notification ringtone

To set your vibrate options:

Find it: Menu >

Settings > Sound > Phone

Settings > Sound > Vibrate

Wallpaper

To apply a new wallpaper:

1 Touch and hold an empty spot on your home screen.

Wallpapers.

2 Touch

Live wallpapers, Gallery, or Wallpapers, and

3 Touch

choose a wallpaper.

Note: Some apps are designed so that your

smartphone can “animate” them by rotating, fading, moving, and stretching one or more images.

Date & time

Set date, time, time zone, and formats:

Find it: Menu >

Settings > Date & time

Sounds

• To play dial pad tones, touch Menu > Settings

Sound > Audible touch tones.

>

• To play sound on a screen selection, touch

Menu >

• To customize the sound settings for media and

videos, touch Menu >

Media audio effects.

>

Settings > Sound > Audible selection.

Settings > Sound

Display settings

• To set display brightness, touch Menu

Settings > Display > Brightness.

>

• To set orientation, touch Menu >

Display > Auto-rotate screen.

>

• To set animation, touch Menu >

Display > Animation.

>

Settings

Language & region

Set your menu language and region:

Find it: Menu >

Select locale

>

Settings > Language & keyboard

Personalize

37

Location

v

e

aassttt

t

Join Latitude More

Directions

Starred Places

Search Maps

Touch Menu for options.

Find places.

Change the view by adding layers.

Center the map on your current location.

Clear Map

Search

where you are, where you’re going

Set your location sources

Set your phone to determine your location using GPS satellite signals (highly accurate, but uses battery power) or using the mobile network (less accurate, but conserves battery power).

To set your location, touch Menu >

Location & security > Google l ocation services, then

>

Standalone GPS services, and/or VZW location

select

services

.

Settings

Ontario St

E Ontario St

N Wabash Ave

Grand Red

M

N Dearborn St

N Clark St

Wacker Dr

E Wacker Pl

State/Lake

W Lake St W Lake St

M

Lake

Randolph/

Wabash

M

E Randolph St

Messaging

Washington-Blue

M

N Rush St

N Micigan Ave

E Ohio St

E Grand A

N Micigan Ave

E S WaterSt

Randolph St Metra

Google maps™

Find it: > Maps

Where am I? What’s around here? Don’t worry—let Google Maps help you explore your surroundings and find what you’re looking for.

38

Location

Note: The map image you see may be a little different.

Google Maps offers powerful, user-friendly mapping technology and local business information—including business locations, contact information, and driving directions.

For help, press Menu >

More > Help.

Tip: Want to know what’s in your immediate area? Try

Google Places™. Touch >

Places to see listings

for Restaurants, ATMs, Gas Stations, and more based

+

X

on your current location.

Google Latitude™

Find it: > Latitude

Join Google Latitude

See where your friends and family are on Google Maps™. Plan to meet up, check that your parents got home safely, or just stay in touch.

Don’t worry, your location is not shared unless you agree to it. You need to join Google Latitude, and then invite your friends to view your location or accept their invitations. When using Maps (in any mode except in Street View), touch Menu > the privacy policy and if you agree with it, touch

& Share

.

Don’t worry, your location is not shared unless you agree to it. You need to join Latitude, and then invite your friends to view your location or accept their invitations. When using Google Maps, touch Menu

Latitude. Read the privacy policy and if you agree

> with it, touch

Agree & Share.

Add & remove friends

To add friends:

1 Touch to show your friends list.

Join Latitude. Read

Agree

2 Touch .

Select from Contacts, then touch a contact.

3 Touch

Or, touch

Add via email address, then enter an

email address.

Add friends.

4 Touch

If your friends already use Latitude, they’ll receive an email request and a notification. If they have not yet joined Latitude, they’ll receive an email request that invites them to sign in to Latitude with their Google account.

To remove friends:

1 Touch to show your friends list.

2 Touch beside the name you want to delete.

Share location

When you receive a request to share location details you can choose to:

Accept and share back: See your friend’s location,

•

and your friend can see yours.

Accept, but hide my location: See your friend's

•

location, but they can't see yours.

Don't accept: Location information is not shared

•

between you and your friend.

Location

39

Hide your location

To hide your location, touch Menu > Settings

Detect your location.

>

Socializing

Find it: > Social Location

see. With a couple of clicks, you buy tickets and reserve seats! How cool is that?

It's customizable, expandable—make it exactly the handheld concierge you need.

Social Location

Favorites FriendsChannels

HOT Coffee Yelp Rest.

Yelp Bars & Clubs Order Food To GO

last.fm

Book a Hotel Nearby

Add channels

Local Deals

Housing

Make your own favorites list.

Touch to see everything in in this collection.

Add more channels as your world grows.

Searching for preferred dining, entertainment, or special promotions can be difficult. Social Location helps you find what you want by searching the web and then showing you only the most relevant suggestions, activities, or promotions, based on your preferences and location. You can learn instantly if tickets are available for the hot concert you jus have to

40

Location

Apps & updates

S

get the app you want

Android Market™

Find it: > Market

Get all the fun games and cool apps you want! Android Market provides access to applications from developers worldwide, so you can find the app you want. If you need help or have questions about Android Market, touch Menu >

Browse & install apps

Tip: Choose your apps and updates carefully, from

trusted sites like phone’s performance—see “Choose carefully” on page 41.

Find it: >

Select a category or touch Search to find the app you want. Then, touch

Note: When installing an app, make sure you read the

alerts that tell you what information the app will access. If you don’t want the app to have access to this information, cancel the installation.

Market, as some may impact your

Market

Install (if app is free) or Buy.

Help.

Manage & restore apps

Find it: > Market >Menu >My apps

There are lots of apps available and many are free. So you might find that you have downloaded and installed lots of apps on your phone. That’s fine, but you may want to uninstall apps that you no longer use.

To uninstall touch an app in the list, and then touch

Uninstall.

If you have trouble removing an app, turn off your phone, then press and hold the key while you turn on your phone. Your screen will show lower left corner, and you can remove the app.

To restore an app, touch the app in the list - the

downloads

For other app management features including clearing app data and cache, touch Menu > >

list shows previously installed apps.

Manage applications, then touch an app in the list.

Safe Mode in the

My

Settings

Choose carefully

Apps are great. There's something for everyone. Play, communicate, work, or just for fun. But remember, choose your apps carefully. Here's a few tips to help:

• To help prevent spyware, phishing or viruses

affecting your phone or privacy, use apps from trusted sites, like

Market.

Apps & updates

41

• In Market, check the apps’ ratings and comments

before installing. This will help you choose the best ones for you.

• If you doubt the safety of an app, don't install it.

• Like all apps, downloaded apps will use up memory,

data, battery, and processing power—some more than others. For example, simple settings widget will use less than a streaming music player app. After installing an app, if you're not happy with how much memory, data, battery or processing power it's using, uninstall it. You can always install it again later.

• Just like web browsing, you may want to monitor

childrens’ access to apps to help prevent exposure to inappropriate content.

• Certain apps may not provide completely accurate

information. Take care, especially when it comes to personal health.

Important customer information

Please be advised that many services and applications offered through this unique device are provided by Google and various application developers. If you use, link to or download a Google service, or an application such as a non-Verizon Wireless location based GPS-type service, chat room, marketplace or social

42

Apps & updates

network from this device, you should carefully review the terms of such service or application. If you use any of these non-Verizon Wireless services or applications, personal information you submit may be read, collected, or used by the service or application provider and/or other users of those forums.

Motorola Mobility, Inc. and Verizon Wireless are not responsible for your use of those applications or information you choose to submit or share with others. Specific terms and conditions, terms of use, and privacy polices apply to those applications and services. Please review carefully any and all terms and conditions applicable to those applications and services including those related to any location-based services for any particular privacy policies, risks or waivers.

Your Verizon Wireless customer agreement terms and conditions and certain other specifically identified terms govern your use of any Verizon Wireless products and services.

Bluetooth® wireless

Bluetooth devices

Bluetooth settings

Motorola Phone

Device name

Scan for devices

Make device discoverable

Discoverable

Bluetooth

Pair with this device

Motorola Headset

Touch to turn on & off & to scan.

Touch to re-scan.

Touch to connect.

lose the wires and go wireless

Quick start: Bluetooth wireless

Find it: Menu > Settings > Wireless & networks

Bluetooth settings

>

Turn Bluetooth power on or off

Find it: Menu > Settings > Wireless & networks

Bluetooth

>

Note: To extend battery life, turn Bluetooth power

off when not in use.

Connect new devices

Note: This feature requires an optional accessory.

To connect with a new device, you need to pair with it. You only need to do this once for each device—to connect again, just turn on the device.

1 Make sure the device you are pairing with is in

discoverable mode.

Note: Refer to the guide that came with the device

for details.

2 Touch Menu >

Bluetooth settings.

>

Bluetooth to turn on and scan. If Bluetooth

3 Touch

power is already on, touch

4 Touch a device to connect.

5 If necessary, touch

0000) to connect to the device. When the

(like device is connected, the Bluetooth indicator appears in the status bar.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Settings > Wireless & networks

Scan for devices.

OK, or enter the device passkey

Bluetooth® wireless

43

Note: The Bluetooth Enhanced Audio setting is not

recommended for older Bluetooth headsets, as it may not deliver acceptable sound quality.

Reconnect devices

To automatically reconnect your phone with a paired device, simply turn on the device.

To manually reconnect your phone with a paired device, touch the device name in the

devices

list.

Bluetooth

Disconnect devices

To automatically disconnect your phone from a paired device, simply turn off the device.

To manually disconnect your phone from a paired device, touch the device name in the devices list, then touch Menu >

Disconnect.

Edit properties

Touch Menu > Settings > Wireless & networks

Bluetooth settings > Device name. Enter a name

> and touch

44

OK.

Bluetooth® wireless

Wi-Fi

Wi-Fi networks

Notify me when a secure network is available

Secure Network

Wi-Fi

Jenny’s Coffee Shoppe

Network notification

Notify me when an open network is available

Open Network

Add Wi-Fi network

Manage Networks

Secured with WEP

Wi-Fi settings

Touch to turn on & scan.

Touch to connect.

home, office, or hotspot

Quick start: Wi-Fi

Find it: Menu > Settings > Wireless & networks

> Wi-Fi settings

Note: Your phone's Wi-Fi features and power levels

are not allowed for outdoor operation in France. To avoid unlawful interference with radio signals, do not use the Wi-Fi features in France unless you are indoors.

Use a wireless network for fast Internet access and to download data.

Turn Wi-Fi on or off

Find it: Touch Menu > Settings > Wireless &

networks

> Wi-Fi

Note: To extend battery life, turn off Wi-Fi power when

not in use.

Wi-Fi search & connect

To find networks in your range:

1 Touch Menu > Settings > Wireless & networks

Wi-Fi settings.

>

Wi-Fi

45

2 Touch Wi-Fi to turn on and scan. If Wi-Fi is already

on, touch Menu > networks it finds within range.

Tip: To see your phone’s MAC address or other

Wi-Fi details, touch Menu >

3 Touch a network to connect.

4 If necessary, enter

Wireless password, and touch Connect. When your

phone is connected to the network, the wireless indicator appears in the status bar.

Tip: When you are in range and Wi-Fi is on, you will

automatically reconnect to available networks you’ve connected to before.

Scan. Your phone lists the

Advanced.

Network SSID, Security, and

Wi-Fi hotspot

Note: You need to subscribe to Wi-Fi hotspot service

to use this feature. Contact your service provider.

You can set up your phone as a Wi-Fi hotspot to provide portable, convenient internet access to other Wi-Fi enabled devices.

Activate hotspot

Find it: > Mobile Hotspot > Mobile Hotspot

When your Wi-Fi hotspot is active, other Wi-Fi enabled devices can connect by entering your hotspot’s

46

Wi-Fi

SSID,

selecting a Security type, and entering the correct

Wireless password,

Setup

Find it: > Mobile Hotspot > >Configure

Mobile Hotspot

Touch a setting to modify it:

• Network SSID—Enter a unique name for your

hotspot and touch

• Security—Select

password. Other users can access your Wi-Fi hotspot only if they enter the correct password.

• Broadcast Channel—Select a channel that

minimizes potential interference. You may need to try different channels after your hotspot is active for a time.

Save when the settings are complete.

Touch

Next.

Open or WPA2 PSK. Enter a unique

Memory card & file management

copy photos, music, and more to your phone

Memory card

Note: You need the memory card installed for some

features on your phone, like

To insert a memory card, see “Assemble & charge” on page 3.

To see the files on your phone and memory card, touch

Files, then select a file storage location. Touch

>

a file or folder to open it. Touch and hold a file to

Rename, or Delete it.

Note: Do not remove your memory card while your

phone is using it or writing files on it.

Warning: When you format a memory card, all data on

the card is deleted.

To remove or format your memory card, you need to unmount it. Touch Menu >

Unmount SD card. Then, to format your memory

> card, touch

Format SD card

Camera.

Settings > Storage

USB connection

You can connect your phone to a computer with a USB cable.

Note: Copyright—do you have the right? Always follow

the rules. See “Content Copyright” in your legal and safety information.

Note: The first time you use a USB connection, your

computer may indicate that drivers are being installed. follow any prompts you see to complete the installation. this may take a few minutes.

1 With a memory card inserted, and your phone

showing the home screen, connect a Motorola micro USB data cable from your phone’s micro USB port to a USB port on your computer. Your phone should show in the status bar.

Note: Make sure to connect the phone to a high

power USB port. Typically, these are located directly on your computer.

2 On your phone, flick down the status bar to see the

USB connection options.

3 Touch an option:

PC Mode.

•

Windows Media Sync—Use Windows Media

•

Player to sync media files on your computer and phone.

Memory card & file management

47

• USB Mass Storage—Drag and drop files

between your computer and memory card folders. When you’re done, use “Safely Remove Hardware” before disconnecting the USB cable.

Note: You can’t use the files on your memory

card while it is connected.

Charge Only—Use the connection to charge

•

your phone’s battery.

48

Memory card & file management

Tools

Alarm Timer

every day

7:00

8:30

9:00

Tuesday

AM

Tue, Fri

PM

July 2011

Sun Mon Tue Wed Thu Fri Sat

Calendar: Month

All calendars

stay on top of things

Alarm clock

Find it: > Alarm & Timer

To turn on an alarm, touch the check box.

When an alarm sounds,

Dismiss to turn it

slide to

Snooze to delay for

off or five minutes.

To add an alarm, touch Menu > then enter alarm details.

To enable or disable an alarm, touch the check box.

Note: Your phone’s clock

automatically adjusts to the local time when you travel internationally.

Add alarm,

Calendar

Find it: > Calendar

Touch to view your calendar events by

Day, or Week. When you

highlight an event, more details appear.

Add calendar events

From any view, touch . Enter the event start time and other details. You can even set a reminder so you don’t forget about the event. (When you set the reminder time to time.)

Tip: Reminders will play only if you’ve selected a

notification ringtone (see “Ringtones” on page 36).

When you finish entering event details, touch

Manage calendar events

To edit an event, touch it, then touch the pencil at the top of the screen.

To delete an event, touch and hold it.

Agenda,

0minutes, it plays at the event start

Save.

Tools

49

Calculator

Find it: > Calculator

Your calculator has basic and advanced views. To change views, touch Menu >

Basic panel. To clear history, touch Menu > Clear history

.

Advanced panel or

Accessibility

See, hear, speak, feel, and use. Accessibility features are there for everyone, helping to make things easier.

Note: For general information, accessories, and more,

visit www.motorola.com/accessibility

Voice recognition

Use your voice—just touch and speak.

• Dialing and commands: Touch >

Commands

Note: You need to activate

can double-touch Home : touch Menu

• Search: Touch and hold Search , then say what

you want to search for, like “Motorola accessories”.

• Text entry: Touch a text entry field to open the

touchscreen keypad. Touch , then say what you want to type.

50

”.

Settings > Accessibility.

>

Tools

Accessibility before you

Voice

Tip: Speak naturally, but clearly. Use the microphone in

a similar way to a speakerphone, so no need to shout or hold the phone close to your mouth.

To change your voice settings, see “Voice settings” on page 51.

Voice readouts (TalkBack)

Get your navigation and selections, read out loud to you.

To turn on voice readouts (similar to TalkBack), touch Menu >

Accessibility to enable the settings, then touch Voice readouts.

Note: You may be asked to download additional

“text-to-speech” software (data charges may apply).

To use voice readouts:

• Menus and screens: In menus and screens, touch

an item to highlight it (the item will be read out loud), and double-touch to open it.

Note: Touch a home screen widget or shortcut to

open it.

• Dialer & text entry: As you type, each number or

letter is read out loud.

• Notification: When you flick the notifications bar

down, all notifications are read out loud.

Settings > Accessibility. Touch

Tip: Navigate through your apps and menus to hear

how voice readouts work on your phone.

To change your voice settings, see “Voice settings” on page 51.

Caller ID

When you want to hear who’s calling:

• Read out loud: Have your caller announced—touch

Menu >

Readout

• Ringtones: Assign a unique ringtone to a

contact—touch > touch Menu >

To change your voice settings, see “Voice settings” on page 51.

Settings > Call settings > Caller ID

.

Contacts, open a contact, then

Options > Ringtone.

Voice settings

Personalize your voice settings:

• Voice recognition: Touch Menu >

Voice input & output > Voice recognizer settings.

> From here, you can set options like language and censorship.

• Voice commands: Touch >

> Menu > recognition of your voice ( options like prompts and shortcuts.

Settings. From here, you can refine

Adaptation) and set

Settings

Voice Commands

• Text-to-speech: Touch Menu > Settings

Voice input & output > Text-to-speech settings.

> From here, you can set options like speed and language.

Volume & vibrate

Choose volume and vibrate settings that work for you. Touch Menu >

•Volume: Touch

Tip: To set separate ring and notification volumes,

uncheck

• Vibrate: Select

Settings > Sound:

Volume and use the sliders.

Use incoming call volume for notifications.

Vibrate to feel your phone ring.

Zoom

Get a closer look. Open a magnification window that you can drag around the screen, or pinch to zoom in on maps, web pages, and photos.

• Magnification window: Touch Menu

Settings > Accessibility. Touch Accessibility to

> enable the settings, then touch

• Pinch to zoom: To zoom in, touch the screen with

two fingers and then slide them apart. To zoom out, drag your fingers together.

Zoom Mode.

Tools

51

Display brightness

Set a brightness level that works for you. Touch Menu > sure that can set your own level.

Settings > Display > Brightness. Make

Automatic brightness is unchecked so you

Touchscreen & keys

All these touch features are great, and sometimes it’s nice to hear or feel your touches too. Touch Menu

Settings > Sound:

>

• Touchscreen: To hear screen touches (click), select

Audible selection.

•Keys: To feel key touches (vibrate), select

feedback

•Screen lock: To hear when you lock/unlock the

screen (click), select

.

Screen lock sounds.

Haptic

Messages

From a simple text message to IM, email, and more. Create, send, and receive them all, in one place.

Find it: >

And to make text entry even easier, you can use features like auto-complete, auto-correct, and auto-punctuate—touch Menu >

Language & keyboard > Multi-touch keyboard. Of

>

52

Tools

Messaging > Universal inbox

Settings

course if you don’t want to type at all, then use your voice—touch on the touchscreen keypad.

Hearing aids

To help get a clear sound when using a hearing aid or cochlear implant, your phone may have been rated for use with hearing aids. If your phone’s box has “Rated for Hearing Aids” printed on it, then please read the following guidance.

Note: Ratings are not a guarantee of compatibility, see

”Hearing Aid Compatibility with Mobile Phones” in your legal and safety information. You may also want to consult your hearing health professional, who should be able to help you get the best results.

• Settings: Touch Menu >

settings

> HAC mode settings. Select Microphone

to optimize your phone for microphone coupling, or

Telecoil to optimize your phone for telecoil

select coupling.

• Call volume: During a call, press the side volume

keys to set a call volume that works for you.

Settings > Call

•Position: During a call, hold the phone to your ear

as normal, and then rotate/move it to get the best position for speaking and listening.

TTY

You can use your phone in TTY mode with standard teletype machines. Touch Menu >

settings > TTY mode

TTY full: Type and read text on your TTY device.

•

TTY HCO: Hearing-Carry-Over—type text on your

•

and select the mode you need:

TTY device and listen to voice replies on your phone’s speaker.

TTY VCO: Voice-Carry-Over—speak into your phone

•

and read text replies on your TTY device.

Note: You’ll need a cable/adapter to connect your TTY

device to the headset jack on your phone.

Refer to your TTY device guide for mode and usage information.

Settings > Call

Apps

Want more? No problem. Android Market™ provides access to thousands of apps, and many provide useful accessibility features.

Find it: >

Select a category or touch Search to find the app you want.

Tip: Choose your apps carefully, from trusted sites like

Market, as some may impact your phone’s

performance.

Market

Tools

53

Management

stay in control

Wireless manager

Find it: Menu > Settings > Wireless & networks

Manage all your wireless connections: Wi-Fi, Bluetooth®, airplane mode, & mobile networks (“Network” on page 54).

Airplane mode

Use airplane mode to turn all your wireless connections off—useful when flying. Press Power/Lock >

Note: When you select airplane mode, all wireless

services are disabled. You can then turn Wi-Fi and/or Bluetooth back on, if permitted by your airline. Other wireless voice and data services (such as calls and text messages) remain off in airplane mode. Emergency calls to your region's emergency number (e.g., 911) can still be made.

Network

You should not need to change any network settings. Contact your service provider for help.

54

Management

Airplane mode.

Touch Menu > Settings > Wireless & networks

Mobile networks to show options for roaming

> networks, network selection, operator selection, and access point names.

Data roaming (outside the U.S.)

Data roaming is turned off for this phone. You can turn it on to connect to data services when roaming globally.

Find it: Menu >

manager

> Data delivery > Data roaming

Note: You may incur signficant roaming charges when

this feature is turned on. Go to verizonwireless.com/global for rates, countries, coverage limitations, and features.

Settings > Battery & data

Update my phone

Stay up to date with the latest software for your phone. You can check, download, and install updates using your phone or your computer:

• Using your phone:

You may get an automatic notification of an available update on your phone. Follow the instructions to download and install.

To manually check for updates, touch Menu

Settings > About phone > System updates.

>

Your phone downloads any updates over your mobile network. Remember, these updates can be quite large (25MB or more) and may not be available in all countries. If you don’t have an unlimited data plan, or mobile network updates are not available in your country, you can update using a computer.

• Using your computer:

On your computer, go to

www.motorola.com/mydroid2global

and check the “Software” links. If an update is available, simply follow the installation instructions.

Management

55

Security

Location & security settings

Security

Lock screen with a pattern, PIN, or password

Set up screen lock

Set up restriction lock

Data encryption

20 minutes

Security lock timer

Manage restriction lock

Passwords

Show password as you type

Visible passwords

Allow Voice Commands to be launched via Bluetooth Multi-function button while device is locked

Allow Bluetooth bypass

Protect the data on your phone or memory card. Requires screen lock

Data encryption

Set lock timer.

Turn on.

help keep your phone safe

Quick start: Security

Find it: Menu > Settings > Location & security

56

Security

You can set a pattern, PIN, or password to prevent unauthorized access to your device.

Screen lock

Note: You can make emergency calls on a locked

phone (see “Emergency calls” on page 14). A locked phone still rings, but you need to unlock it to

answer.

Lock the screen in the following ways:

• Press Power/Lock .

• Let the screen time out (don’t press anything).

• Switch the power off.

To unlock the screen, press Power/Lock . Then, drag to the right.

Lock pattern

To set the lock pattern, touch Menu > Settings

Location & security > Set up screen lock > Pattern.

>

Follow the instructions to draw your lock pattern.

When prompted, draw the pattern to unlock the phone.

Passcode lock

To set the passcode, touch Menu > Settings

Location & security > Set up screen lock

>

Password.

>

Enter the password, then confirm it.

When prompted, enter the password to unlock the phone.

Forgot your pattern or passcode?

If you forget your pattern or passcode, contact your service provider.

Reset

To reset your phone to factory settings and erase all the data on your phone, touch Menu >

Privacy > Factory data reset > Reset phone.

>

Warning: All data on your phone will be deleted.

(Nothing on your memory card is deleted.)

Settings

Remote wipe a lost or stolen phone

Don't you just hate it when your life is on your phone and it all goes wrong? Lost, or even worse—stolen! If necessary, you can use your email account on a Microsoft™ Exchange ActiveSync 2007 server to clear the personal data from your phone and memory card.

You need to be assigned permissions before you can remote wipe data from your phone and memory card. Contact your IT system administrator for the information and permissions you need to perform the remote wipe procedure.

Warning: All downloaded apps and user data on your

phone and memory card will be deleted.

Security

57

Global Phone

HD VIDEO

1080p|8MP

HD

VIDEO

1080p|8MP

Global Phone offers you reliable, consistent voice service at home and abroad. Use one phone and one number for voice coverage in more than 220 countries. Get one bill for both domestic and international calls. In order to get the full benefits of Global Phone service you must subscribe to a Global Phone calling plan and ensure that you have a SIM card installed. Go to

verizonwireless.com/global

limitations and features.

Your phone comes with an installed SIM card that enables you to make and receive calls and text messages while traveling outside of the U.S. in supported destinations. Should your SIM card be lost or damaged, please follow these instructions to install a new SIM card:

1 Remove the battery cover and remove the battery.

2 Remove the SIM card from its packaging.

3 Hold the SIM card so that

the metal contacts on the SIM card face down and the cutoff corner of the SIM card points toward the top-left corner of your phone.

58

Global Phone

for rates, countries, coverage

1080p|8MP

HD VIDEO

4 Slide the SIM card into the SIM card holder until

it stops.

5 Insert the battery so that

the metal contacts on the battery align with the metal contacts on your phone.

6 Place the battery cover

into the slots and push up, so that the cover clicks into place.

Yo u r SI M (Subscriber Identity Module) card is a small rectangular plastic card that stores your phone number and other important information. Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water or dirt. If your SIM card is lost or damaged while in the U.S., please dial

*611

from your Verizon Wireless device or 1-800-922-0204 from any phone to speak with a Customer Service Representative. From outside of the U.S., please refer to the Verizon Wireless Global Support Guide, welcome letter and calling card that came with your device. This will enable you to make calls toll free from landlines in most countries where we offer Global Phone service.

Service & repairs

we’re here to help

If you have questions or need assistance, we’re here to help.

Go to www.motorola.com/repair

www.motorola.com/support

select from a number of customer care options. You can also contact the Motorola Customer Support Center at: 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

(United States) or

(Canada), where you can

Service & repairs

59

SAFETY, REGULATORY, & LEGAL

032375o

Battery Use & Safety

The following battery use and safety information applies to all Motorola mobile devices. If your mobile device uses a non-removable main battery (as stated in your product information), details related to handling and replacing your battery should be disregarded—the battery should only be replaced by a Motorola-approved service facility, and any attempt to remove or replace your battery may damage the product.

Important:

Handle and store batteries properly to avoid injury or damage. Most battery issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to

change the form of your battery.

• Don’t let the mobile device or battery come in contact with liquids.*

Liquids can get into the mobile device’s circuits, leading to corrosion.

• Don’t allow the battery to touch metal objects.

jewelry, stay in prolonged contact with the battery contact points, the battery could become very hot.

• Don’t place your mobile device or battery near a heat source.*

temperatures can cause the battery to swell, leak, or malfunction.

• Don’t dry a wet or damp battery with an appliance or heat source

a hair dryer or microwave oven.

DOs

• Do avoid leaving your mobile device in your car in high temperatures.*

• Do avoid dropping the mobile device or battery.*

especially on a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your mobile device or

battery has been damaged by dropping, liquids or high temperatures.

*Note:

Always make sure that the battery compartment and any connector covers

are closed and secure to avoid direct exposure of the battery to any of these

60

If metal objects, such as

Dropping these items,

High

, such as

conditions, eve n if your product informati on states that your mobile devi ce can resist damage from these conditions.

Important: Motorola recommends you always use Motorola-branded batteries and chargers for quality assurance and safeguards.

warranty does not cover damage to the mobile device caused by non-Motorola batteries and/or chargers. To help you identify authentic Motorola batteries from non-original or counterfeit batteries (that may not have adequate safety protection), Motorola provides holograms on its batteries. You should confirm that any battery you purchase has a “Motorola Original” hologram. If you see a message on your display such as

Unable to Charge

•

Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and try charging it again;

•

If the message remains, contact a Motorola authorized service center.

Warning:

explosion, leakage, or other hazard.

Proper and safe battery disposal and recycling:

only important for safety, it benefits the environment. You can recycle your used batteries in many retail or service provider locations. Additional information on proper disposal and recycling can be found at www.motorola.com/recycling

Disposal:

regulations. Contact your local recycling center or national recycling organizations for more information on how to dispose of batteries.

Warning:

Battery Charging

Notes for charging your product’s battery:

•

During charging, keep your battery and charger near room temperature for efficient battery charging.

•

New batteries are not fully charged.

, take the following steps:

Use of a non-Motorola battery or charger may present a risk of fire,

Promptly dispose of used batteries in accordance with local

Never dispose of batteries in a fire because they may explode.

Invalid Battery

Proper battery disposal is not

Motorola’s

or

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.

Third Party Accessories

Use of third party accessories, including but not limited to batteries, chargers, headsets, covers, cases, screen protectors and memory cards, may impact your mobile device’s performance. In some circumstances, third party accessories can be dangerous and may void your mobile device’s warranty. For a list of Motorola accessories, visit

www.motorola.com/products

Driving Precautions

Responsible and safe driving is your primary responsibility when behind the wheel of a vehicle. Using a mobile device or accessory while driving may cause distraction and may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.

While driving, NEVER:

•

Type or read messages.

•

Enter or review written data.

•

Surf the web.

•

Input navigation information.

•

Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

•

Keep your eyes on the road.

•

Enter destination information into a navigation device

•

Use voice activated features (such as voice commands) and speaking features (such as audible directions), if available.

•

Obey all local laws and regulations for the use of mobile devices and accessories in the vehicle.

•

End any task if you cannot concentrate on driving.

Remember to follow the “Smart Practices While Driving” in this guide.

before

driving.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing videos or games. These may occur even if a person has never had a previous seizure or blackout. If you have experienced seizures or blackouts, o r if you have a family history of such occurrences, please consult with your physician before playing videos or games or enabling a flashing-lights feature (if available) on your mobile device. Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are tired.

Caution about High Volume Usage

Warning:

Exposure to loud noise from any source for extended periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected. To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears, or muffled speech, you should stop listening to the device through your headset or headphones and have your hearing checked. For more information about hearing, see our website at direct.motorola.com/hellomoto/nss/AcousticSafety.asp only).

(in English

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you contin ue to have discomfort during or after such use, stop use and see a physician.

61

Children

032374o

032376o

032375o

Keep your mobile device and its accessories away from small children.

These products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn. Similar to a computer, if a child does use your mobile device, you may want to monitor their access to help prevent exposure to inappropriate apps or content.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and can include fueling areas, such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders. When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries unless it is a radio product type especially qualified for use in such areas as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas, sparks can occur and cause an explosion or fire.

62

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Do not dispose of your battery or mobile device with your household waste. See “Recycling” for more information.

Do not use tools.

For indoor use only.

Operational Restrictions

Wi-Fi Operation

If this product supports Wi-Fi 802.11a (see product specifications), the following applies:

Operation is restricted to indoor use only.

to avoid interference with other signals. To be compliant, do not operate this device in Wi-Fi mode when outdoors.

This regulatory restriction is

Radio Frequency (RF) Energy

Exposure to RF Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your network access controls the power level at which your mobile device transmits. Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances, your mobile device may cause interference with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so. In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airli ne staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator, consult your physician before using this mobile device. Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the

implantable medical device when the mobile device is turned ON.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place. Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your mobile device with your implantable medical device, consult your healthcare provider.

Specific Absorption Rate (FCC)

SAR (IEEE)

YOUR MOBILE DEVICE MEETS FCC LIMITS FOR EXPOSURE TO RADIO WAVES.

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) adopted by the Federal Communications Commission (FCC). These limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. The highest SAR value under the FCC guidelines for your device model is listed below:

Head SAR CDMA 800/1900,

Body SAR CDMA 800/1900,

During use, the actual SAR values for your device are usually well below the values stated. This is because, for purposes of system efficiency and to minimize interference on the network, the operating power of your mobile device is automatically decreased when full power is not needed for the wireless connection. The lower the power output of the device, the lower its SAR value. If you are interested in further reducing your RF exposure then you can easily do so by limiting your usage or simply using a hands-free kit to keep the device away from the head and body. Additional information can be found at

Wi-Fi, Bluetooth

www.motorola.com/rfhealth

0.77 W/kg

1.46 W/kg

.

63

European Union Directives Conformance

0168

[Only Indoor Use Allowed In France for Bluetooth and/or Wi-Fi]

0168

Product Approval Number

Statement

EU Conformance

The following CE compliance information is applicable to Motorola mobile devices that carry one of the following CE marks:

Hereby, Motorola declares that this product is in compliance with:

•

The essential requirements and other relevant provisions of Directive 1999/5/EC

•

All other relevant EU Directives

The above gives an example of a typical Product Approval Number. You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at DoC, enter the Product Approval Number from your product’s label in the “Search” bar on the website.

FCC Notice to Users

FCC Notice

The following statement applies to all products that bear the FCC logo on the product label.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b).

64

www.motorola.com/rtte

(in English only). To find your

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi tions: (1) This device may not cause harmful interfe rence, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(a)(3). Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21. For products that support Wi-Fi 802.11a (as defined in the product specifications available at

www.motorola.com equipment has the capability to operate Wi-Fi in the 5 GHz Unlicensed National Information Infrastructure (U-NII) band. Because this band is shared with MSS (Mobile Satellite Service), the FCC has restricted such devices to indoor use only (see 47 CFR 15.407(e)). Since wireless hot spots operating in this band have the same restriction, outdoor services are not offered. Nevertheless, please do not operate this device in Wi-Fi mode when outdoors.

Industry Canada Notice to Users

Industry Cana da Notice

Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference

), the following information applies. This

that may cause undesired operation of the device. See RSS-GEN 7.1.5. This Class B digital apparatus complies with Canadian ICES-003.

Location Services (GPS & AGPS)

GPS & AGPS

The following information is applicable to Motorola mobile devices that provide location based (GPS and/or AGPS) functionality. Your mobile device may use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device. Your mobile device may also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges, and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details.

Your Location

Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile devices which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

Navigation

The following information is applicable to Motorola mobile devices that provide navigation features. When using navigation features, note that mapping information, directions and other navigational data may contain inaccurate or incomplete data. In some countries, complete information may not be available. Therefore, you should visually

confirm that the navigational instructions are consistent with what you see. All drivers should pay attention to road conditions , closures, traffic, and all other factors that may impact driving. Always obey posted road signs.

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas—for example, handsfree use only may be required. Go to

www.motorola.com/callsmart

Note:

Voice call features may not be available on all products. Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wirel ess connection is available and s afe conditions allow. When driving a car, driving is your first responsibi lity. If you choose to use your mobile device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as voice

commands and “read out loud” features.

you to use your device without taking your attention off the road.

• When available, use a handsfree device.

of convenience to your mobile device with one of the many Motorola Original handsfree accessories available today.

• Position your mobile device within easy reach.

mobile device without removing your eyes from the road. If you receive a call at an inconvenient time, if possible, let your voicemail answer it for you.

• Let the person you are speaking with know you are driving; if necessary,

suspend the call in heavy traffic or hazardous weather conditions.

sleet, snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up information while driving.

do” list or going through your address book takes attention away from your primary responsibility—driving safely.

• Assess the traffic; if possible, place calls when your car is not moving or

before pulling into traffic.

such as voice commands, check the road and your mirrors, then continue.

(in English only) for more information.

If available, these features help

If possible, a dd an additional layer

Be able to access your

Rain,

Jotting down a “to

If you must make a call while moving, use features

65

• Do not engage in stressful or emotional conversations that may be distracting.

Make people you are talking with aware you are driving and

suspend conversations that can divert your attention away from the road.

Privacy & Data Security

Privacy & Data Se curity

Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

• Monitor access

others may have unmonitored access. Use your device’s security and lock features, where available.

• Keep software up to date

releases a patch or software fix for your mobile device that updates the device’s security, install it as soon as possible.

• Secure Personal Information

information in various locations including your SIM card, memory card, and internal memory. Be sure to remove or clear all personal information before you recycle, return, or give away your device. You can also backup your personal data to transfer to a new device.

Note:

go to

• Online accounts

(such as MOTOBLUR). Go to your account for information on how to manage the account, and how to use security features such as remote wipe and device location (where available).

• Applications and updates

install from trusted sources only. Some apps can impact your product’s performance and/or have access to private informat ion including account details, useage data, location details and network resources.

• Wireless

Wi-Fi networks. Also, when using your device as a hotspot (where available) use

66

—Keep your mobile device with you and do not leave it where

—If Motorola or a software/application vendor

—Your mobile device can store personal

For information on how to backup or wipe data from your mobile device,

www.motorola.com/support

—Some mobile devices provide a Motorola online account

—Choose your apps and updates carefully, and

—For mobile devices with Wi-Fi features, only connect to trusted

network security. These precautions will help prevent unauthorized access to your device.

• Location-based information

information that can be used to determine the approximate location of a mobile device. Products which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

• Other information your device may transmit

testing and other diagnostic (including location-based) information, and other non-personal information to Motorola or other third-party servers. This

information is used to help improve products and services offered by Motorola. If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at privacy@motorola.com

Use & Care

To care for your Motorola mobile device, please observe the following:

liquids

Don’t expose your mobile device to water, rain, extreme humidity, sweat, or other liquids. If it does get wet, don’t try to accelerate drying with the use of an oven or dryer, as this may damage the mobile device.

extreme heat or cold

Don’t use, recharge or store your mobile device in temperatures below 0°C (32°F) or above 35°C (95°F).

—Location-based information includes

—Your device may also transmit

, or contact your service provider.

microwaves

Don’t try to dry your mobile device in a microwave oven.

dust and dirt

Don’t expose your mobile device to dust, dirt, sand, food, or other inappropriate materials.

cleaning solutions

To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

shock and vibration

Don’t drop your mobile device.

protection

To help protect your mobile device, always make sure that any battery, connector and compartment covers are closed and secure.

Recycling

Mobile Devices & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste, or in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at:

www.motorola.com/recycling

Packaging & Product Guides

Product packaging and pr oduct guides should only be dis posed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

California Perchlorate Label

Perchlorate Label

Some mobile devices use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label: Perchlorate Material – special handling may apply when the battery is recycled or disposed of. See English only). There is no special handling required by consumers.

www.dtsc.ca.gov/hazardouswaste/perchlorate

(in

Hearing Aid Compatibility with Mobile Devices

Hearing Aid Compat ibili ty

Some Motorola products are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies. When some mobile devices are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and mobile devices also vary in the amount of interference they generate. The mobile devices industry has developed ratings for some of their products, to assist hearing device users in finding products that may be compatible with their hearing devices. Not all mobile devices have been rated. Products that are rated have the rating on their box or a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for this mobile device, use only the original equipment battery model. This mobile device has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. However, there may be some newer wireless technologies used in this device that have not been tested yet for use with hearing aids. It is important to try the different features of this product thoroughly and in

67

different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Contact your service provider or Motorola for information on hearing aid compatibility. If you have questions about return or exchange policies, contact your service provider or retailer. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated mobile device successfully. Trying out the product with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings:

Products rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than produc ts that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings:

Products rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated products. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.) Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile devices.

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly o r by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the

68

normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA MOBILITY, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA The Motorola website contains information regarding Motorola's use of open source. Motorola has created the portal for interaction with the software community-at-large. To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please touch >

Legal information >Open source licenses

Motorola device may include self-contained applications that present supplemental notices for open source packages used in those applications.

opensource.motorola.com

Apps >Settings >About tablet

(in English only) also

website to serve as a

. In addition, this

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Product Registration

Registration

Online Product Registration: www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage. Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status. Thank you for choosing a Motorola product.

(in English only)

Service & Repairs

If you have questions or need assistance, we’re here to help. Go to

www.motorola.com/repair www.motorola.com/support of customer care options. You can also contact the Motorola Customer Support Center at: 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

How to Obtain Service or Other Information

1. Please access and review the onlin e Customer Support section of Motorola 's con-

sumer website prior to requesting warranty service.

2. If the Product is still not functioning properly after making use of this resource,

please contact the Warrantor listed at the Motorola website or the contact information for the corresponding location.

(United States) or

(Canada), where you can select from a number

3. A representative of Motorola, or of a Motorola Aut horized Repair Center, will help determine whether your Product requires service. You may be required to download, or otherwi se obtain and accept software updates from Motorola or a Motorola Authorized Repair Center. You are responsible for any applicable carrier service fees incur red while obtaining the required downloads . Complying with the warranty process, repair instructions and accepting such software updates is required in order to receive additional warranty support.

4. If the software update does not fix the problem, you will receive instructions on how to ship the Product to a Motorola Authorized Repair Center or other entity.

5. To obtain warranty service, as per mitted by applicable law, you ar e required to include: (a) a copy o f your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) your address and telephone number. In the event the Product is not covered by the Motorola Limited Warranty, Motorola will inform the con sumer of the availability, price and other conditions applicable to the repair of the Product.

ALL INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS, INCLUDING BUT NOT LIMITED TO PERSONAL CONTACTS, ADDRESS BOOKS, PICTURES, MUSIC AND GAMES WILL BE ERASED DURING THE REPAIR PROCESS, AND CAN NOT BE REINSTALLED BY MOTOROLA.

losing such info rmation, data, software or other appl ications please create a back up before you deliver your Product for warranty service, and disable any security passwords. You will be responsible for reinstalling all such information, data, software, other applications and passwords. Your Product or a replacement Product will be returned to you as your Product was configured when originally purchased, subject to applicable software updates. Motorola may install operating system software updates as part of warranty service that may prevent the Product from reverting to an earlier version of the operating system software. Third party applications installed on the Product may not be compatible or work with the Product as a result of the operating system software update. Motorola and its Authorized Service Centers are not responsible for the loss of, or inability to use, such information, data, software or other applications.

To obtain service or other information, please access and review the online Customer Support section of Motorola's consumer website at www.motorola.com.

To avoid

69

Limited Global Warranty Motorola Tablet Computer

Warra nty

Note: This Limited Warranty is not applicable in Quebec, Canada. FOR CONSUMERS WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR REGULATIONS IN THEIR COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED WARRANTY ARE IN ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY SUCH CONSUMER PROTECTION LAWS AND REGULATIONS.

Who is Covered?

This Limited Warranty extends only to the first consumer purchaser of the Product, and is not transferable.

What Does this Limited Warranty Cover?

Motorola's warranty obligations are limited to the terms and conditions set forth herein and are only available in the country where the Product was purchased. Subject to the exclusions contained below, Motorola warrants this Tablet Computer (“Product”) against defects in materials and workmanship, under normal consumer use, for a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser (“Warranty Period”). Products repaired or replaced under this Limited Warranty are covered for the balance of the original warranty period, or 90 days from the date of service, whichever is longer. Any upgrade to the original product will be covered only for the duration of the Warranty Period. This Limited Warranty applies only to new Products which are a) manufac tured by or for Motorola as identified by the “Motorola” trademark, trade name, or logo legally affixed to them; b) purchased by consumers from an authorized reseller or distr ibutor of Motorola Products; and c) accompanied by this written Limited Warranty.

What Will Motorola Do?

If a covered defect or damage arises and a valid warranty claim is received within the applicable Warranty Period, Motorola, at its sole option, unless otherwise required by applicable law, will either (1) repair, at no charge, the defect or damage using new, used or reconditioned/refurbished functionally equivalent replacement

70

parts; or (2) exchange the Product with a replacement Product that is new or which has been reconditioned/refurbished or otherwise remanufactured from new or used parts and is func tionally equivalent to the ori ginal Product; or (3) refund the purchase price of any Products covered by the terms and conditions of this Limited Warranty. Products, parts and supporting documentation provided to Motorola as part of the warranty process, shall become the property of Motorola, and may not be returned. When a replacement or refund is given, the Product for which the replacement or refund is provided must be returned to Motorola and shall become the property of Motorola.

Exclusions (Products and Accessories)

This warranty does not apply to:

(a)

Consumable parts

below 50% of their rated capacity within the first year from the date of purchase; or protective coatings designed to diminish over time unless failure has occurred due to a defect in materials or workmanship. (b)

Cosmetic damage

cosmetic damage. (c)

Damage caused by use with non-Motorola products.

that result from the use of non-Motorola branded or certified Products, accessories or other peripheral equipment, including without limitation housings, parts, or software, are excluded from coverage. (d)

Damage caused by accident, abuse, misuse, liquid contact, fire,

earthquake or other external causes

usage or operation (e.g. operating the Product outside their permitted or intended uses as defined by Motorola, including but not limited to as set forth by Motorola in the Products' User Manual, Quick Start Guide, Online Tutorials, and other documentation), improper storage (e.g. subjecting the Product to extreme temperatures), abuse or neglect (e.g. broken/bent/missing clips/fasteners/connectors); impact damage (e.g. dropping the Product) (ii) contact with liquids, water, rain, extreme humidity, heavy perspiration or other moisture; sand, food, dirt or similar substances; (iii) use of the Products for commercial rental purposes; or (iv) external causes or acts which are not the fault of Motorola,

, such as batteries, unless its fully charged capacity falls

, including but not limited to scratches, dents, cracks or other

Defects or damage

; including but not limited to: (i) improper

including but not limited to flood, fire, earthquake, tornado or other acts of God, are excluded from coverage. (e)

Damage caused by unauthorized Service or Modification.

damage resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way, including but not limited to tampering with or altering the software, by someone other than Motorola, or its authorized service centers, are excluded from coverage. (f)

A product or part that has been modified in any manner without the

written permission of Motorola.

so as to prevent Motorola from determining whether such Products are covered under the terms of this Limited Warranty are excluded from coverage. The forgoing shall include but not be limited to (i) serial numbers, date tags or other manufacturer coding that has been removed, altered or obliterated; (ii) mismatched or duplicated serial numbers; or (iii) broken seals or other evidence of tampering. Do not open the Product or attempt to repair the Product yourself; such conduct may cause damage that is not covered by this warranty. (g)

Normal wear and tear or otherwise due to the normal aging of the

Product.

(h)

Defects, damages, or the failure of the Product due to any communication service or network you subscribe to or use with the Products.

(i)

All software, including operating system software, third-party software,

applications, and all other software of any kind.

Motorola is provided “AS-IS” and “AS AVAILABLE,” “WITH ALL FAULTS” and without a warranty of any kind. The Limited Warranty does not apply to any non-Motorola product or any software, even if packaged or sold with the Motorola Product hardware, unless otherwise required by applicable local law. (j)

Products that have been refurbished, reconditioned, or remanufactured.

The foregoing does not apply to Produc ts repaired or replaced pursuant to the terms of this Limited Warranty.

Products that have been altered in any manner

Defects or

Software distributed by

What Other Limitations are There?

TO THE EXTENT PERMITTED BY APPLICABLE LAW:

•

THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES AND REMEDIES, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR IMPLIED. NO ORAL OR WRITTEN REPRESENTATI ONS MADE BY MOTOROLA OR ANY SELLER, RESELLER OR DISTRIBUTOR OF THE PRODUCTS, INCLUDING EMPLOYEES AND AGENTS THEREOF, SHALL CREATE ANY ADDITIONAL WARRANTY OBLIGATIONS, INCREASE THE SCOPE, OR OTHERWISE MODIFY IN ANY MANNER THE TERMS OF THIS LIMITED WARRANTY.

•

MOTOROLA SPECIFICALLY DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT AND ALL WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. WHERE SUCH STATUTORY OR IMPLIED WARRANTIES CANNOT LAWFULLY BE DISCLAIMED, THEN TO THE EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE DURATION OF THE EXPRESS LIMITED WARRANTY CONTAINED HEREIN AND THE REMEDIES OF REPAIR, REPLACEMENT, OR REFUND AS DETERMINED BY MOTOROLA IN ITS SOLE DISCRETION SHALL BE THE EXCLUSIVE REMEDY OF THE CONSUMER.

•

MOTOROLA DOES NOT WARRANT THAT THE OPERATION OF ANY PRODUCTS OR SOFTWARE COVERED UNDER THIS LIMITED WARRANTY WILL MEET YOUR REQUIREMENTS, WORK IN COMBINATION WITH ANY HARDWARE OR SOFTWARE APPLICATIONS OR THIRD PARTY SERVICES, BE UNINTERRUPTED, ERROR-FREE, OR WITHOUT RISK TO, OR LOSS OF, ANY INFORMATION, DATA, SOFTWARE OR APPLICATIONS CONTAINED THEREIN, OR THAT DEFECTS IN THE PRODUCTS OR SOFTWARE WILL BE CORRECTED.

•

IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT, TORT OR UNDER OTHER LEGAL THEORY (INCLUDING NEGLIGENCE), FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCTS, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS; LOSS OF BUSINESS; BUSINESS INTERRUPTION; LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION; LOSS OF, DAMAGE TO, OR CORRUPTION OF INFORMATION, DATA, SOFTWARE OR APPLICATIONS (INCLUDING ANY COSTS ASSOCIATED WITH RECOVERING, PROGRAMMING, OR REPRODUCING ANY INFORMATION, DATA, SOFTWARE OR

71

APPLICATIONS STORED ON OR USED WITH MOTOROLA PRODUCTS, OR ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF ANY INFORMATION OR DATA STORED ON THE PRODUCTS); OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS.

SOME STATES OR JURISDICTIONS DO NOT ALLOW THE LIMITATION OR EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE EXCLUSION OR LIMITATION ON THE LENGTH OF AN IMPLIED WARRANTY, OR THE LIMITATION OR EXCLUSION OF DAMAGES FOR PERSONAL INJURIES CAUSED BY NEGLIGENCE, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE OR JURISDICTION.

In the event that any term or provision contained in this Limited Warranty is found to be invalid, illegal or unenforceable by a court of competent jurisdiction, then such provision shall be deemed modified to the extent necessary to make such provision enforceable by such court, taking into account the intent of the parties. The invalidity in whole or in part of any portion of this Limited Warranty shall not impair or affect the validity or enforceability of the remaining provisions of this Limited Warranty.

Use & Care

To care for your Motorola mobile device, please observe the following:

liquids

Don’t expose your mobile device to water, rain, extreme humidity, sweat, or other liquids. If it does get wet, don’t try to accelerate drying with the use of an oven or dryer, as this may damage the mobile device.

extreme heat or cold

Don’t use, recharge or store your mobile device in temperatures below 0°C (32°F) or above 35°C (95°F).

72

microwaves

Don’t try to dry your mobile device in a microwave oven.

dust and dirt

Don’t expose your mobile device to dust, dirt, sand, food, or other inappropriate materials.

cleaning solutions

To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

shock and vibration

Don’t drop your mobile device.

protection

To help protect your mobile device, always make sure that any battery, connector and compartment covers are closed and secure.

Recycling

Mobile Devices & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste, or in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at:

www.motorola.com/recycling

Packaging & Product Guides

Product packaging and pr oduct guides should only be disp osed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

California Perchlorate Label

Perchlorate Label

Some mobile devices use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label: Perchlorate Material – special handling may apply when the battery is recycled or disposed of. See English only). There is no special handling required by consumers.

www.dtsc.ca.gov/hazardouswaste/perchlorate

(in

Hearing Aid Compatibility with Mobile Devices

Hearing Aid Compatibility

Some Motorola products are me asured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies. When some mobile devices are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and mobile devices also vary in the amount of interference they generate. The mobile devices industry has developed ratings for some of their products, to assist hearing device users in finding products that may be compatible with their hearing devices. Not all mobile devices have been rated. Products that are rated have the rating on their box or a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for this mobile device, use only the original equipment battery model. This mobile device has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. However, there may be some newer wireless technologies used in this device that have not been tested yet for use with hearing aids. It is important to try the different features of this product thoroughly and in

different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Contact your service provider or Motorola for information on hearing aid compatibility. If you have questions about return or exchange policies, contact your service provider or retailer. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated mobile device successfully. Trying out the product with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings:

Products rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than products that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings:

Products rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated products. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.) Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile devices.

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the

73

normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA MOBILITY, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA The Motorola website contains information regarding Motorola's use of open source. Motorola has created the portal for interaction with the software community-at-large. To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please touch >

Legal information >Open source licenses

Motorola device may include self-contained applications that present supplemental notices for open source packages used in those applications.

74

opensource.motorola.com

Apps >Settings >About tablet

(in English only) also

website to serve as a

. In addition, this

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

PRODUCT REGISTRATION

Registration

Online Product Registration: www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage. Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status. Thank you for choosing a Motorola product.

(in English only)

Service & Repairs

If you have questions or need assistance, we’re here to help. Go to

www.motorola.com/repair www.motorola.com/support of customer care options. You can also contact the Motorola Customer Support Center at: 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

How to Obtain Service or Other Information

6. Please access and review the onlin e Customer Support section of Motorola' s con-

sumer website prior to requesting warranty service.

7. If the Product is still not functioning properly after making use of this resource,

please contact the Warrantor listed at the Motorola website or the contact information for the corresponding location.

(United States) or

(Canada), where you can select from a number

8. A representative of Motorola, or of a Motorola Authorized Repair Center, will help determine whether your Product requires service. You may be requi red to download, or otherwise obtain and accept software updates from Motorola or a Motorola Authorized Repair Center. You are responsible for any applicable carrier service fees incur red while obtaining the required downloads . Complying with the warranty process, repair instructions and accepting such software updates is required in order to receive additional warranty support.

9. If the software update does not fix the problem, you will receive instructions on how to ship the Product to a Motorola Authorized Repair Center or other entity.

10.To obtain warranty service, as permit ted by applicable law, you are required to include: (a) a copy o f your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) your address and telephone number. In the event the Product is not covered by the Motorola Limited Warranty, Motorola will inform the consumer of the availability, price and other conditions applicable to the repair of the Product.

ALL INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS, INCLUDING BUT NOT LIMITED TO PERSONAL CONTACTS, ADDRESS BOOKS, PICTURES, MUSIC AND GAMES WILL BE ERASED DURING THE REPAIR PROCESS, AND CAN NOT BE REINSTALLED BY MOTOROLA.

losing such infor mation, data, software or other appl ications please create a back up before you deliver your Product for warranty service, and disable any security passwords. You will be responsible for reinstalling all such information, data, software, other applications and passwords. Your Product or a replacement Product will be returned to you as your Product was configured when originally purchased, subject to applicable software updates. Motorola may install operating system software updates as part of warranty service that may prevent the Product from reverting to an earlier version of the operating system software. Third party applications installed on the Product may not be compatible or work with the Product as a result of the operating system software update. Motorola and its Authorized Service Centers are not responsible for the loss of, or inability to use, such information, data, software or other applications.

To obtain service or other information, please access and review the online Customer Support section of Motorola's consumer website at www.motorola.com.

To avoid

Limited Global Warranty Motorola Tablet Computer

Warra nty

Note: This Limited Warranty is not applicable in Quebec, Canada. FOR CONSUMERS WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR REGULATIONS IN THEIR COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED WARRANTY ARE IN ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY SUCH CONSUMER PROTECTION LAWS AND REGULATIONS.

Who is Covered?

This Limited Warranty extends only to the first consumer purchaser of the Product, and is not transferable.

What Does this Limited Warranty Cover?

Motorola's warranty obligations are limited to the terms and conditions set forth herein and are only available in the country where the Product was purchased. Subject to the exclusions contained below, Motorola warrants this Tablet Computer (“Product”) against defects in materials and workmanship, under normal consumer use, for a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser (“Warranty Period”). Products repaired or replaced under this Limited Warranty are covered for the balance of the original warranty period, or 90 days from the date of service, whichever is longer. Any upgrade to the original product will be covered only for the duration of the Warranty Period. This Limited Warranty applies only to new Products which are a) manufactured by or for Motorola as identified by the “Motorola” trademark, trade name, or logo legally affixed to them; b) purchased by consumers from an authorized reseller or distr ibutor of Motorola Products; and c) accompanied by this written Limited Warranty.

What Will Motorola Do?

If a covered defect or damage arises and a valid warranty claim is received within the applicable Warranty Period, Motorola, at its sole option, unless otherwise required by applicable law, will either (1) repair, at no charge, the defect or damage using new, used or reconditioned/refurbished functionally equivalent replacement

75

parts; or (2) exchange the Product with a replacement Product that is new or which has been reconditioned/refurbished or otherwise remanufactured from new or used parts and is func tionally equivalent to the ori ginal Product; or (3) refund the purchase price of any Products covered by the terms and conditions of this Limited Warranty. Products, parts and supporting documentation provided to Motorola as part of the warranty process, shall become the property of Motorola, and may not be returned. When a replacement or refund is given, the Product for which the replacement or refund is provided must be returned to Motorola and shall become the property of Motorola.

Exclusions (Products and Accessories)

This warranty does not apply to:

(a)

Consumable parts

below 50% of their rated capacity within the first year from the date of purchase; or protective coatings designed to diminish over time unless failure has occurred due to a defect in materials or workmanship. (b)

Cosmetic damage

cosmetic damage. (c)

Damage caused by use with non-Motorola products.

that result from the use of non-Motorola branded or certified Products, accessories or other peripheral equipment, including without limitation housings, parts, or software, are excluded from coverage. (d)

Damage caused by accident, abuse, misuse, liquid contact, fire,

earthquake or other external causes

usage or operation (e.g. operating the Product outside their permitted or intended uses as defined by Motorola, including but not limited to as set forth by Motorola in the Products' User Manual, Quick Start Guide, Online Tutorials, and other documentation), improper storage (e.g. subjecting the Product to extreme temperatures), abuse or neglect (e.g. broken/bent/missing clips/fasteners/connectors); impact damage (e.g. dropping the Product) (ii) contact with liquids, water, rain, extreme humidity, heavy perspiration or other moisture; sand, food, dirt or similar substances; (iii) use of the Products for commercial rental purposes; or (iv) external causes or acts which are not the fault of Motorola,

76

, such as batteries, unless its fully charged capacity falls

, including but not limited to scratches, dents, cracks or other

Defects or damage

; including but not limited to: (i) improper

including but not limited to flood, fire, earthquake, tornado or other acts of God, are excluded from coverage. (e)

Damage caused by unauthorized Service or Modification.

damage resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way, including but not limited to tampering with or altering the software, by someone other than Motorola, or its authorized service centers, are excluded from coverage. (f)

A product or part that has been modified in any manner without the

written permission of Motorola.

so as to prevent Motorola from determining whether such Products are covered under the terms of this Limited Warranty are excluded from coverage. The forgoing shall include but not be limited to (i) serial numbers, date tags or other manufacturer coding that has been removed, altered or obliterated; (ii) mismatched or duplicated serial numbers; or (iii) broken seals or other evidence of tampering. Do not open the Product or attempt to repair the Product yourself; such conduct may cause damage that is not covered by this warranty. (g)

Normal wear and tear or otherwise due to the normal aging of the

Product.

(h)

Defects, damages, or the failure of the Product due to any communication service or network you subscribe to or use with the Products.

(i)

All software, including operating system software, third-party software,

applications, and all other software of any kind.

Motorola is provided “AS-IS” and “AS AVAILABLE,” “WITH ALL FAULTS” and without a warranty of any kind. The Limited Warranty does not apply to any non-Motorola product or any software, even if packaged or sold with the Motorola Product hardware, unless otherwise required by applicable local law. (j)

Products that have been refurbished, reconditioned, or remanufactured.

The foregoing does no t apply to Products repaired or replaced pursuant to the terms of this Limited Warranty.

Products that have been altered in any manner

Defects or

Software distributed by

What Other Limitations are There?

TO THE EXTENT PERMITTED BY APPLICABLE LAW:

•

THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES AND REMEDIES, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR IMPLIED. NO ORAL OR WRITTEN REPRESENTATIONS MADE BY MOTOROLA OR ANY SELLER, RESELLE R OR DISTRIBUTOR OF THE PRODUCTS, INCLUDING EMPLOYEES AND AGENTS THEREOF, SHALL CREATE ANY ADDITIONAL WARRANTY OBLIGATIONS, INCREASE THE SCOPE, OR OTHERWISE MODIFY IN ANY MANNER THE TERMS OF THIS LIMITED WARRANTY.

•

MOTOROLA SPECIFICALLY DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT AND ALL WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. WHERE SUCH STATUTORY OR IMPLIED WARRANTIES CANNOT LAWFULLY BE DISCLAIMED, THEN TO THE EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE DURATION OF THE EXPRESS LIMITED WARRANTY CONTAINED HEREIN AND THE REMEDIES OF REPAIR, REPLACEMENT, OR REFUND AS DETERMINED BY MOTOROLA IN ITS SOLE DISCRETION SHALL BE THE EXCLUSIVE REMEDY OF THE CONSUMER.

•

MOTOROLA DOES NOT WARRANT THAT THE OPERATION OF ANY PRODUCTS OR SOFTWARE COVERED UNDER THIS LIMITED WARRANTY WILL MEET YOUR REQUIREMENTS, WORK IN COMBINATION WITH ANY HARDWARE OR SOFTWARE APPLICATIONS OR THIRD PARTY SERVICES, BE UNINTERRUPTED, ERROR-FREE, OR WITHOUT RISK TO, OR LOSS OF, ANY INFORMATION, DATA, SOFTWARE OR APPLICATIONS CONTAINED THEREIN, OR THAT DEFECTS IN THE PRODUCTS OR SOFTWARE WILL BE CORRECTED.

•

IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT, TORT OR UNDER OTHER LEGAL THEORY (INCLUDING NEGLIGENCE), FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCTS, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS; LOSS OF BUSINESS; BUSINESS INTERRUPTION; LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION; LOSS OF, DAMAGE TO, OR CORRUPTION OF INFORMATION, DATA, SOFTWARE OR APPLICATIONS (INCLUDING ANY COSTS ASSOCIATED WITH RECOVERING, PROGRAMMING, OR REPRODUCING ANY INFORMATION, DATA, SOFTWARE OR

APPLICATIONS STORED ON OR USED WITH MOTOROLA PRODUCTS, OR ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF ANY INFORMATION OR DATA STORED ON THE PRODUCTS); OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS.

SOME STATES OR JURISDICTIONS DO NOT ALLOW THE LIMITATION OR EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE EXCLUSION OR LIMITATION ON THE LENGTH OF AN IMPLIED WARRANTY, OR THE LIMITATION OR EXCLUSION OF DAMAGES FOR PERSONAL INJURIES CAUSED BY NEGLIGENCE, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE OR JURISDICTION.

In the event that any term or provision contained in this Limited Warranty is found to be invalid, illegal or unenforceable by a court of competent jurisdiction, then such provision shall be deemed modified to the extent necessary to make such provision enforceable by such court, taking into account the intent of the parties. The invalidity in whole or in part of any portion of this Limited Warranty shall not impair or affect the validity or enforceability of the remaining provisions of this Limited Warranty.

77

Copyright & Trademarks

Motorola Mobility, Inc. Consumer Advocacy Office 600 N US Hwy 45 Libertyville, IL 60048 www.motorola.com

Note:

Do not ship your product to the above address. If you need to return your product for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at: 1-800-734-5870 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) Certain features, services and applications are network dependent and may not be available in all areas; additional terms, conditions and/or charges may apply. Contact your service provider for details. All features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

Note:

The images in this guide are examples only. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, the Google logo, Google Maps, Google Talk, Google Latitude, Gmail, YouTube, Picasa, Google Books, Google Docs, Google Goggles, Google Finance, Google Places, Google Maps Navigation Beta, Google Calendar, Android and Android Market are trademarks of Google, Inc. All other product or service names are the property of their respective owners. © 2011 Motorola Mobility, Inc. All rights reserved.

Caution:

Motorola does not take responsibility for changes/modification to the transceiver. Product ID:DROID3 (XT860) Manual Number: 68014834001-B

www.motorola.com

Motorola XT862 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
