Yo u r MOTO W418G phone is loaded with great
features, like photos, music, and web access—all in a
stylish flip design.
• Photos. Take photos and send them to your friends.
•Music. Instantly play your music. Just open the
music player and select a playlist.
•Web. Surf to your heart’s content. Search, browse,
everything you want to do, all made easier.
We’ve crammed all the main features of your phone
into this handy guide, and in a matter of minutes we’ll
show you just how easy your phone is to use. You may
be surprised at what you discover.
Note: Certain apps and features may not be available
in all countries.
Caution: Before assembling, charging, or using your
phone for the first time, please read the important
legal and safety information packaged with your
product.
the retainer tab (use a coin or other similar object),
then slide the card out with your thumb.
Turn it on & off
To turn your phone on or off,
press and hold the Power/End
key.
Prepaid service
Find it: Press
Tip: You can also press the Select key to open the
prepaid service app.
With prepaid service, you buy wireless network
services in advance. Your phone works just the same
way as always. Prepaid options let you activate and
deactivate prepaid service, check your prepaid balance,
add money to your account, call customer service, and
provide other information requested by your prepaid
service provider.
Note: Available prepaid service may vary depending on
your service provider or region. Contact your service
provider for availability and more information.
6Let’s go
Menu
(left soft key) >
Prepaid
Make & answer calls
To make a call from the home screen, enter a number,
then press the Send key.
To answer a call, press. To turn off the incoming
call alert, press
To end a call, press the Power/End key.
Reject
.
Cool content & more
Surf the web for cool content and more (see“Web” on
page 23). An optional microSD memory card can be
installed in your phone—you can load it up with music,
photos, and videos from your computer (see “Memory
card & USB” on page 34).
7Let’s go
Keys
a few essentials
Menu navigation
1 From the home screen, press
Menu
(left soft key) to open
the app menu.
2 Press the Navigation key
up, down, left or right to
scroll and highlight a menu
option.
3 Press the Select key to
select the highlighted option.
Shortcut keys
From the home screen press, up, down, left or right
to quickly open
User profiles
8Keys
Music player, Contacts, Messages
.
, or
Adjust volume
Press the volume keys on the side of your phone to
change the ring volume (in the home screen), or the
earpiece volume (during a call).
When playing music or video files, press the volume
keys to adjust media volume.
9Keys
Home screen
10:18 AM
10/12/2012
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information
in one place. It’s what you see when you turn on the
phone or press from a menu. It’s basically like this:
10:18AM
10/12/2012
10/12/2012
10:18 AM
10:18 AM
BrowserMenu
Note: Your home screen might look a little different.
Status Indicators
Right Soft Key
Left Soft Key
Press to open app menu.
10Home screen
App menu
All the apps on your phone are shown in your app menu.
To open the app menu, from the home screen, press
Menu
(left soft key). Press up, down, left or right to
highlight a menu option, then press to select the
highlighted option. You can press to return to the
home screen at any time.
Phone status & notifications
The status bar at the top of the screen contains icons
that tell you about messages and phone status.
status indicators
Signal StrengthRing Only
GPRSVibrate Only
Bluetooth®Vibrate and Ring
RadioVibrate then Ring
Alarm ClockHeadset
New MessageBattery
11Home screen
Calls
it’s good to talk
In-call options
During a call, press
speakerphone.
Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
Tip: To mute your call, press
Recent calls
1 From the home screen, press to see a list of
recent calls.
2 Highlight a call and press to call it. To see call
details, press
12Calls
Spkr On
to use the handsfree
Options >Mute
Options >View
.
.
Emergency calls
Note: Your service provider programs one or more
emergency phone numbers (such as 911 or 112) that
you can call under any circumstances, even when your
phone is locked. Emergency numbers vary by countr y.
Your pre-programmed emergency number(s) may not
work in all locations, and sometimes an emergency
call cannot be placed due to network, environmental,
or interference issues.
1 Enter the emergency number in the home screen.
2 Press to call the emergency number.
Cool down
In very limited circumstances, such as where your
phone has been exposed to extreme heat, “Cool
Down” message screens will appear. To avoid possible
damage to your battery and phone, you should follow
these instructions until the phone is within its
recommended temperature range. When your phone
is in “Cool Down” mode, only emergency calls can
be made.
13Calls
Contacts
contacts like you’ve never had before
Quick start: Contacts
Find it:
Menu
>
Contacts
12:14AM
Contacts
Text Entry Mode
aba
Add new contact
Lisa Lindsay
Press to scroll up/down
through the contact list.
2125550707
Search for a contact.
BackOptions
Select to view, call, edit,
delete, copy, move, or send
the selected contact.
Tip: To see more contacts, press up or down.
14Contacts
Create contacts
Find it:
Menu
>
Contacts >Add new contact
Alternatively, you can enter a phone number in the
home screen, then press
Options >Save to Contacts
Enter the contact name and details. When you’re
finished, press
OK >Yes
to save.
Call contacts
Scroll to a contact and press.
.
15Contacts
Messaging
sometimes it’s better 2 say it in a message
Create & send messages
Find it:
Menu
>
Messages >Create Message
Use the keypad to enter your message. Press
to insert a picture, sound, or video. When you finish
creating the message, press
enter phone numbers or select message recipients
from your contact list. To send the message,
Options >Send
press
Options >Send to
.
Receive a message
When you receive a message, your phone plays an
alert and shows the new message indicator at the
top of the screen.
To read the new message, press
To read messages stored in your inbox, press
Messages >Inbox
>
16Messaging
.
View
Options
to
.
Menu
Photos
see it, capture it, share it!
Find it: Press Camera
Tip: You can also press
Menu
>
Tools >Camera
Shots Remaining
(Phone Memory)
.
250
1
Options
Press up/down
to zoom in/out.
x
Press right to change
to video recorder.
Select to adjust camera
settings.
To take the photo, press.
Your phone saves the photo, and briefly shows the
photo in the screen.
• To send the photo in a message, press
Send
.
>
Options
17Photos
• To delete the photo, press
To see photos you’ve taken, press
My Folder >Phone Memory
>
Photos
>
.
Options >Delete
Menu
or
Memory card
.
To record a v ideo, go to the camera viewfinder screen
and press right to change to the video recorder.
Alternatively, you can press
Video recorder
>
18Photos
.
Menu >Tools
Music player
when music is what you need...
Get music
You can transfer music from your computer to your
phone by using a USB connection.
For more information on transferring music, see “USB
drag & drop” on page 35.
Note: Copyright—do you have the right? Always follow
the rules. See “Content Copyright” in your legal and
safety information.
Play music
To create a music playlist:
Menu
>
Find it:
My playlists
>
1 Enter a name for the playlist, then press
Done
.
>
Tools >Music player
, press
Options >New playlist
2 Select the playlist name, then press
Add
to add a song from your phone or memory
>
card.
3 If necessary, select
Phone Memory
to specify where the song file is located.
4 Scroll to the song, and press
OK
playlist. Repeat to add other songs to the playlist.
Options
Load >Options
or
Memory card
to add it to the
19Music player
To play a playlist, select it and press
Play
.
>
To delete a playlist, select it and press
Load >Options
Delete
.
To adjust music player settings, when the player is
running, press
20Music player
Options >Settings >Player settings
.
Radio
news and music on the go
Note: The FM radio only works when an optional
wired headset accessory is plugged into the phone’s
headset jack.
Menu
>
Find it:
To seek local radio stations, press
To tune a station, press left or right.
Options
Press
options
Radio On(Off)
Channel list
Manual input
Auto search
Settings
Record
Tools >FM radio
to see radio options:
Turn the radio on and off.
Store up to nine radio
channels.
Enter a channel frequency.
Automatically search for radio
channels and store them to
the channel list.
Activate background play,
activate the loudspeaker, set
recording format, audio
quality, and storage location.
Record radio programs.
Seek
.
21Radio
options
Append
File list
22Radio
Return to the previous
recorded file and continue
recording to the same file.
Manage recorded files.
Web
surf the web with your phone
Note: To use the browser, you must have data service
activated for your account (additional fees may apply
for this service).
Use your phone’s browser to surf your favorite web
sites, upload videos to a video blog, and download files
and applications to your phone. Log onto your
internet-based email account to check your email.
Menu
>
Find it:
To .. .
Go to your
home page
Go to a web pageSelect
Bookmark a web
page
Go to a link on a
web page
Note: If you can’t connect, contact your service
provider.
Browser
Select
Press
Add to Bookmarks
>
Select the link.
Home
.
Go to URL
Options
.
.
23Web
Tips & tricks
a few handy hints
To .. .
Return to
home screen
See recent
incoming &
outgoing calls
Create a new
contact in your
contact list
Adjust sound
volume
Tu rn airplane mode
on/off
24Tips & tricks
Press.
Menu
Press
>
Missed calls
>
Received calls
or
Recent calls
or
Dialed calls
.
Enter a phone number in the
home screen, then press
Options >Save to Contacts
From the home screen, press
the up/down volume keys.
Menu
>
Settings
Press
Phone Settings
>
Airplane mode
>
Airplane mode
>
Normal Mode
or
.
.
To .. .
Set app menu styleSet the app menu to display
as a grid or list: Press
Settings
>
Phone settings >Display
>
Main Menu Style >Matrix
>
List
.
or
Menu
Battery tips
Want to extend your battery life? Try these:
Menu
Menu
>
Settings
• Turn off Bluetooth® power: Press
Settings >Connectivity >Bluetooth >Power
>
• Reduce the time your phone display stays on:
Menu
>
Press
Backlight
>
Settings >Phone settings
, and set
Time (sec)
to a lower setting.
• Turn off the screen saver: Press
Phone settings >Display >Screen Saver
>
Settings >Status >Off
>
, then pressOK.
25Tips & tricks
Text entry
think keyboard, now think smaller
Use the phone keypad to enter text and create
messages or notes. Indicators at the top right of the
text screen show the current text entry mode.
Tip: Use your phone’s T9 feature to enter words using
one keypress per letter. The phone predicts each word
as you enter it. To activate, press
On
.
>
To change the text entry mode, press
Input method
>
:
entry modes
Abc
ABC
abc
Numeric
To delete letters to the left of the cursor, press.
To enter symbols, press
enter a space in symbol mode, press.
26Text entry
Options >Set T9
Options
Capitalize the first letter of a
new sentence.
Enter capital letters in the
text field.
Enter lowercase letters in the
text field.
Enter numbers in the text
field.
Options >Insert symbol
. To
Personalize
add your personal touch
Profiles
Your phone has different profiles.You can customize
ringtones, alerts, and volumes for each profile.
Menu
>
Find it:
You can select these profiles:
profiles
General
Meeting
Outdoor
Indoor
Silent
Headset
BluetoothAdjust profile settings for
Settings >User profiles
Standard profile default
setting.
Ringtone is off, vibrate is on.
Ringtone and key tone
volume are set to maximum.
Ringtone is off, vibrate is on.
Vibrate is on, all tones are off.
Adjust profile settings for
when a wired headset is
plugged into your phone.
when a Bluetooth® headset
is connected to your phone.
27Personalize
To change a profile’s settings, press
Customize
>
. You can adjust these settings:
Options
settings
Tone settings
Set ringtones for incoming
calls and messages, key
tones, and other events.
Volume
Set the volume for ringtones
and key tones.
Alert type
Ring type
Extra tone
Answer options
Set to
Ring only, Vib. only
Vib. and ring
Vib. then ring
Set to
Ascending
, or
.
Single, Repeat
.
, or
Play an extra tone for
Warning, Error, Camp on
Connect
and
.
Set to answer calls by
,
opening the flip or pressing
any key.
Wallpaper
Set the wallpaper (background) image in your home
screen.
28Personalize
,
Find it:
Menu
>
Display >Wallpaper >Pre-loaded
>
Settings >Phone settings
or
User Defined
> picture
Screen saver
Select and activate a screen saver image. The screen
saver appears after a specified period of inactivity.
Menu
>
Find it:
Display >Screen saver
>
Settings >Phone settings
To turn the screen saver on or off, select
Status >On
>
To set the delay interval, select
5sec, 15 sec, 30 sec
>
or
Off
.
, or
Settings >Timeout
1minute
.
To set the screen saver image, select
Pre-loaded
>
or
User Defined
> picture.
Settings
Select
Time & date
To show time and date in the home screen.
Menu
>
Find it:
Display>Show date/time
>
Settings >Phone settings
Language
Set menu language.
Menu
>
Find it:
Language
>
Settings >Phone settings
29Personalize
Manage your life
stay on top of things
Calendar
Find it:
Menu
>
Tools >Calendar
To set the calendar view, press
Go to monthly view
>
or
To add an event, scroll to the day, then press
Add event
>
event—
. You can set three types of
Reminder, Meeting
To view an event, scroll to the day, then press
View
. Select the event to see its details.
>
When your phone shows/sounds an event reminder,
OK
press
to dismiss the reminder. Press
delay the reminder for eight minutes.
Alarms
Find it:
Menu
>
Tools >Alarm
To set an alarm, select it and turn it on, then specify
the alarm time, recurrence, and alert type.
When your phone shows/sounds an alarm,
Stop
press
the alarm for eight minutes.
30Manage your lif e
to turn off the alarm. Press
Options
Course
.
Snooze
Snooze
Go to weekly view
, or
.
Options
Options
to
to delay
Tasks
Find it:
Menu
>
Tools >Tasks
To add a task, press
Add >Date, Call
, or
Anniversary
Calculator
Find it:
Menu
>
Tools >Calculator
Airplane mode
Use airplane mode to turn all your wireless
connections off—useful when flying.
Find it:
>
Settings >Phone Settings
Airplane mode >Airplane mode
Note: When you select airplane mode, all wireless
services are disabled. You can then turn Bluetooth®
back on, if permitted by your airline. Other wireless
voice and data services (such as calls and text
messages) remain off in airplane mode. Emergency
calls to your region's emergency number (e.g., 911)
can still be made.
or
Normal mode
.
.
31Manage your life
Bluetooth® wireless
lose the wires and go wireless
Turn Bluetooth power on or off
Find it:
Menu
>
Bluetooth >Power
>
Settings >Connectivity
When Bluetooth power is on, the Bluetooth
indicator appears in the home screen.
Note: To extend battery life, turn off Bluetooth power
when not in use.
Connect new devices
To connect with a new device, you need to pair with it.
You only need to do this once for each device—to
connect again, see “Reconnect devices” on page 33.
1 Make sure the device you are pairing with is in
discoverable mode (see device instructions).
Menu
>
2 Press
Bluetooth >My Device >Inquiry new device
>
Note: If Bluetooth power is not turned on, your
phone will ask if you want to
Bluetooth first?
3 Your phone lists the devices it finds within range.
Select a device to connect.
32Bluetooth® wireless
Settings >Connectivity
Yes
Power on
.
Select
.
4 If necessary, enter the device passkey (like
connect to the device.
Tip: For specific information about a device, check the
instructions that came with it. For more Bluetooth
support, go to www.motorola.com/Bluetoothsupport
For maximum Bluetooth security, always connect
Bluetooth devices in a safe, private environment.
Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
0000
) to
Reconnect devices
To automatically reconnect your phone with a paired
device, simply turn on the device.
To manually reconnect your phone with a paired
device, select the device name in the
My device
list.
Disconnect devices
To automatically disconnect your phone from a
paired device, simply turn off the device.
To manually disconnect your phone from a paired
device, select the device name in the
My device
list.
.
33Bluetooth® wireless
Memory card & USB
load photos, music, and more on your phone
microSD memory card
Note: You need an optional microSD memory card
installed for some features on your phone, like the
music player.
Menu
or
Move
.
.
Options
Menu
.
To format your memory card, press
My Folder >Memory card >Format
>
Warning: When you format a memory card, all data on
the card is deleted.
To see files stored on your memory card, press
My Folder >Memory card
>
.
To copy or move a file from your phone to your
memory card:
1 Press
Menu
>
My Folder >Phone Memory
2 Select the file, then select
3 Select
Memory card
Copy
.
4 Scroll to the destination folder and press
Select
.
>
34Memory card & USB
USB drag & drop
Note: This feature requires an optional accessory.
You can drag & drop your pictures, videos, music, and
more from your computer to your phone’s memory
card.
Note: Copyright—do you have the right? Always follow
the rules. See “Content Copyright” in your legal and
safety information.
Note: When your phone is connected to a computer, it
cannot be used for anything else, including making
emergency calls. To restore the phone to normal use,
disconnect it from the computer.
1 With a memory card inserted
and your phone showing the
home screen, connect a
Motorola micro USB data cable
from your phone’s micro USB
port to a USB port on your
computer.
2 Your phone shows a
Mass storage
USB config
and pressOK. You can’t use the files
on your memory card while it is connected.
3 On your computer, use the “My Computer”
window to find “Removable Disk.”
4 Click on the “Removable Disk” icon to access the
memory card.
dialog. Scroll to
35Memory card & USB
5 Drag & drop files between your computer and
memory card folders.
6 When you’re done, use the “Safely Remove
Hardware” feature to finish.
36Memory card & USB
Security
help keep your phone safe
Codes & passwords
Your phone password is originally set to
service provider didn’t change the phone password,
you should change it:
Menu
>
Find it:
Change Password >Phone password
>
Settings >Security Settings
You can also change your SIM card PIN and
codes.
If you forget your phone password: At the
Input password
prompt, try entering
four digits of your phone number. If that doesn’t work,
contact your service provider.
If you forget other codes: If you forget your SIM PIN
code or PIN2 code, contact your service provider.
Lock your phone
You can lock your phone to keep others from using it.
You’ll need to enter your four-digit phone password to
lock or unlock the phone.
To automatically lock your phone whenever you turn
it off:
Menu
>
Find it:
Phone Lock
>
Settings >Security Settings
1122
1122
. If your
PIN2
or the last
37Security
To unlock your phone:
When you see
Input password
phone password and press
38Security
, enter your four-digit
OK
.
Troubleshooting
we’re here to help
Crash recovery
In the unlikely event that your phone stops responding
to key presses, try a quick reset. Remove the back
cover and battery (“Assemble & charge” on page 5),
then replace and turn on your phone as usual.
Reset
Reset default factory settings on your phone. You’ll
need to enter your phone password to reset the
phone.
Caution: This option erases all information you have
entered (including contacts and calendar entries) and
content you have downloaded (including pictures,
videos, and music files) stored in your phone’s
memory. After you erase the information, you can’t
recover it. This option does not delete SIM card or
memor y card information.
Menu
>
Find it:
Settings >Reset Factory Settings
39Troubleshooting
Service & Repairs
If you have questions or need assistance, we're here
to help.
Go to www.motorola.com/repair
www.motorola.com/support
select from a number of customer care options. You
can also contact the Motorola Customer Support
Center at 1-800-331-6456 (United States),
1-888-390-6456 (TTY/TDD United States for hearing
impaired), or 1-800-461-4575 (Canada).
40
(United States) or
(Canada), where you can
Safety, Regulatory & Legal
Battery Use & Safety
Battery Use & Safety
Important: Handle and store batteries properly to avoid injury or damage.
Most battery issues arise from improper handling of batteries, and particularly from
the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to
change the form of your battery.
• Don’t let the mobile device or battery come in contact with water.*
can get into the mobile device’s circuits, leading to corr osion. If the mobile device
and/or battery get wet, have them checked by your service provider or contact
Motorola, even if they appear to be working properly.*
• Don’t allow the battery to touch metal objects.
jewelry, stay in prolonged contact with the battery contact points, the battery
could become very hot.
• Don’t place your mobile device or battery near a heat source.*
temperatures can cause the battery to swell, leak, or malfunction.
• Don’t dry a wet or damp battery with an appliance or heat source
a hair dryer or microwave oven.
DOs
• Do avoid leaving your mobile device in your car in high temperatures.*
• Do avoid dropping the battery or mobile device.*
especially on a hard surface, can potentially cause damage.*
• Do contact your service provider or Motorola if your mobile device or
battery has been damaged from dropping or high temperatures.
* Note:
Always make sure that the battery compartment is closed and secure to
avoid direct exposure of the battery to any of these conditions.
If metal objects, such as
Dropping these items,
Water
High
, such as
41
Important: Use Motorola Original products for quality assurance and
032375o
safeguards.
To aid consumers in identifying authentic Motorola batteries from
non-original or counterfeit batteries (that may not have adequate safety protection),
Motorola provides holograms on its batteries. Consumers should confirm that any
battery they purchase has a “Motorola Original” hologram.
Motorola recommends you always use Motorola-branded batteries and
chargers.
Motorola mobile devices are designed to work with Motorola batteries.
If you see a message on your display such as
Unable to Charge
•
Remove the battery and inspect it to confirm that it has a “Motorola Original”
hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and try charging it again;
•
If the message remains, contact a Motorola authorized service center.
Important:
by non-Motorola batteries and/or chargers.
Warn ing:
Use of a non-Motorola battery or charger may present a risk of fire,
explosion, leakage, or other hazard.
Proper and safe battery disposal and recycling:
only important for safety, it benefits the environment. Consumers may recycle their
used batteries in many retail or service provider locations. Add itional information on
proper disposal and recycling may be found on the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling
organizations for more information on how to dispose of batteries.
Warn ing:
Never dispose of batteries in a fire because they may explode.
42
, take the following steps:
Motorola’s warranty does not cover damage to the mobile device caused
Invalid Battery
(in English only)
or
Proper battery disposal is not
Battery Charging
Battery Chargi ng
Notes for charging your product’s battery:
•
During charging, keep your battery and charger near room temperature for
efficient battery charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery
from damage from overcharging.
Driving Precautions
Responsible and safe driving is your primary responsibility when behind the wheel
of a vehicle. Using a mobile device or accessory for a call or other application while
driving may cause distraction. Using a mobile device or accessory may be prohibited
or restricted in certain areas, always obey the laws and regulations on the use of
these products.
While driving, NEVER:
•
Type or read texts.
•
Enter or review written data.
•
Surf the web.
•
Input navigation information.
•
Perform any other functions that divert your attention from driving.
While driving, ALWAYS:
•
Keep your eyes on the road.
•
Use a handsfree device if available or required by law in your area.
•
Enter destination information into a navigation device
•
Use voice activated features (such as voice dial) and speaking features (such as
audible directions), if available.
•
Obey all local laws and regulations for the use of mobile devices and accessories
in the vehicle.
•
End your call or other task if you cannot concentrate on driving.
Remember to follow the “Smart Practices While Driving” in this guide and at
www.motorola.com/callsmart
(in English only).
before
driving.
43
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to
flashing lights, such as when playing videos or games. These may occur even if a
person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with your physician before playing videos or games or
enabling a flashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or
disorientation. It is always a good idea to hold the screen away from your eyes,
leave the lights on in the room, take a 15-minute break every hour, and stop use if
you are tired.
Caution About High Volume Usage
Warn ing:
Exposure to loud noise from any source for extended
periods of time may affect your hearing. The louder the volume sound
level, the less time is required before your hearing could be affected.
To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness
in your ears, ringing in your ears, or muffled speech, you should stop listening to the
device through your headset or headphones and have your hearing checked.
For more information about hearing, see our Web site at
hellomoto/nss/AcousticSafety.asp
(in English only).
direct.motorola.com/
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in your hands,
arms, shoulders, neck, or other parts of your body. If you continue to have discomfort
during or after such use, stop use and see a physician.
[Nov0109]
44
Small Children
032374o
Keep your mobile device and its accessories away from small children.
These products are not toys and may be hazardous to small children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if
the product is dropped on a hard surface or receives a substantial impact. If glass
breaks, do not touch or attempt to remove. Stop using your mobile device until the
glass is replaced by a qualified service center.
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted and
can include fueling areas, such as below decks on boats, fuel or chemical transfer or
storage facilities, or areas where the air contains chemicals or particles, such as
grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove,
install, or charge batteries. In such areas, sparks can occur and cause an explosion
or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
SymbolDefinition
Important safety information follows.
45
SymbolDefinition
032376o
032375o
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
Do not dispose of your battery or mobile device with your
household waste. See “Recycling” for more information.
For indoor use only.
Listening at full volume to music or voice through a headset may
damage your hearing.
Radio Frequency (RF) Energy
Exposure to RF Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your mobile device, the
system handling your call controls the power level at which your mobile device
transmits.
Your mobile device is designed to comply with local regulatory requirements in your
country concerning exposure of human beings to RF energy.
RF Energy Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF
energy does not exceed the guidelines set forth in the relevant standards, always
follow these instructions and precautions:
46
•
When placing or receiving a phone call, hold your mobile device just like you
would a landline phone.
•
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved clip, holder, holster, case, or body harness. If you
do not use a body-worn accessory supplied or approved by Motorola, keep the
mobile device and its antenna at least 2.5 centimeters (1 inch) from your body
when transmitting.
•
Using accessories not supplied or approved by Motorola may cause your mobile
device to exceed RF energy exposure guidelines. For a list of Motorola-supplied
or approved accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external
sources if inadequately shielded, designed, or otherwise configured for RF energy
compatibility. In some circumstances, your mobile device may cause interference
with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do
so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline
staff. If your mobile device offers an airplane mode or similar feature, consult airline
staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator,
consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the
implantable medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential
for interference.
•
Turn OFF the mobile device immediately if you have any reason to suspect that
interference is taking place.
47
Read and follow the directions from the manufacturer of your implantable medical
device. If you have any questions about using your mobile device with your
implantable medical device, consult your healthcare provider.
Specific Absorption Rate (IEEE)
SAR (IEEE)
Your model wireless phone meets the governmental
requirements for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed and
manufactured to not exceed limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the U.S. Government and by the
Canadian regulatory authorities. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed for the safety o f all persons,
regardless of age or health, and to account for any variations in measurements.
The exposure standard for mobile devices employs a unit of measurement known as
the Specific Absorption Rate (SAR). The IEEE SAR limit set by the FCC and by the
Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over one
gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC
and by Industry Canada with the mobile device transmitting at its highest certified
power level in all tested frequencies. Although the SAR is determined at the highest
certified power level, the actual SAR level of the mobile device while operating can
be below the maximum value. This is because the mobile device is designed to
operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station, the lower the
power output.
Before a mobile device is available for sale to the public in the U.S. and Canada, it
must be tested and certified to the FCC and Industry Canada that it does not exceed
the limit established by each government for safe exposure. The tests are performed
in positions and locations (e.g., at the ear and worn on the body) submitted to the
FCC and available for review by Industry Canada. The highest SAR value for this
mobile device when tested for use at the ear is 1.40 W/kg, and when worn on the
48
body, as described in this guide, is 1.46 W/kg. The SAR value for this mobile device
in its data transmission mode (body-worn use) is 1.46 W/kg. Body-worn
measurements can differ, depending upon available accessories and regulatory
requirements. The SAR information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this product.
While there may be differences between the SAR levels of various mobile devices
and at various positions, they meet the governmental requirements for safe
exposure. Please note that improvements to this product model could cause
differences in the SAR value for later products ; in all cases, products are designed to
be within the guidelines.
Additional information on SAR can be found on the Cellular Telecommunications
& Internet Association (CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web site:
http://www.cwta.ca
Information from the World Health
Organization
WHO Information
“A large number of studies have been performed over the last two decades to
assess whether mobile phones pose a potential health risk. To date, no adverse
health effects have been established for mobile phone use.”
Source: WHO Fact Sheet 193
Further information:
http://www.who.int/emf
49
FCC Declaration of Conformity
FCC DoC
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola Mobility, Inc.
Address: 600 N US Highway 45
Libertyville, IL 60048 USA
Hereby declares that the product:
Product Name: W418G, WX345
FCC ID: IHDP56LJ5
Conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
FCC Notice to Users
FCC Notice
The following statement applies to all products that have received FCC
approval. Applicable products bear the FCC logo, and/or an FCC ID in the
format FCC ID:xxxxxx on the product label.
Motorola has not approved any changes or modifications to this device by the user.
Any changes or modifications could void the user’s authority to operate the
equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two c onditions: (1) This devic e may not cause harmful interfer ence, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. See 47 CFR Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
50
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Notice to Users
Industry Canada Notice
Operation is subject to the following two conditions: (1) This device may not cause
interference and (2) This device must accept any interference, including interference
that may cause undesired operation of the device. See RSS-GEN 7.1.5. This Class B
digital apparatus complies with Canadian ICES-003.
Smart Practices While Driving
Driving Safety
Check the laws and regulations on the use of mobile devices and their
accessories in the areas where you drive. Always obey them. The use of
these devices may be prohibited or restricted in certain areas—for
example, handsfree use only may be required. Go to
www.motorola.com/callsmart
Your mobile device lets you communicate by voice and data—almost anywhere,
anytime, wherever wireless service is available and safe conditions allow. When
driving a car, driving is your first responsibility. If you choose to use your mobile
device while driving, remember the following tips:
• Get to know your Motorola mobile device and its features such as speed
dial, redial and voice dial.
call without taking your attention off the road.
• When available, use a handsfree device.
of convenience to your mobile device with one of the many Motorola Original
handsfree accessories available today.
• Position your mobile device within easy reach.
mobile device without removing your eyes from the road. If you receive an
incoming call at an inconvenient time, if possible, let your voicemail answer it for
you.
• Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions.
sleet, snow, ice, and even heavy traffic can be hazardous.
(in English only) for more information.
If available, these features help you to place your
If possible, add an additional layer
Be able to access your
Rain,
51
• Do not take notes or look up phone numbers while driving.
“to do” list or going through your address book takes attention away from your
primary responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place calls when your
car is not moving or before pulling into traffic.
moving, dial only a few numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that may be
distracting.
Make people you are talking with aware you are driving and
suspend conversations that can divert your attention away from the road.
• Use your mobile device to call for help.
number in the case of fire, traffic accident, or medical emergencies (wherever
wireless phone service is available).
• Use your mobile device to help others in emergencies.
accident, crime in progress, or other serious emergency where lives are in
danger, call 911 or other local emergency number (wherever wireless phone
service is available), as you would want others to do for you.
• Call roadside assistance or a special non-emergency wireless
assistance number when necessary.
posing no serious hazard, a broken traffic signal, a minor traffic accident where
no one appears injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number (wherever wireless
phone service is available).
Privacy & Data Security
Privacy & Data Se curity
Motorola understands that privacy and data security are important to everyone.
Because some features of your mobile device may affect your privacy or data
security, please follow these recommendations to enhance protection of your
information:
• Monitor access
others may have unmonitored access. Lock your device’s keypad where this
feature is available.
• Keep software up to date
releases a patch or software fix for your mobile device that updates the device’s
security, install it as soon as possible.
52
—Keep your mobile device with you and do not leave it where
—If Motorola or a software/application vendor
Dial 911 or other local emergency
If you see a broken-down vehicle
Jotting down a
If you must make a call while
If you see an auto
• Secure Personal Information
information in various locations including your SIM card, memory card, and
phone memory. Be sure to remove or clear all personal information before you
recycle, return, or give away your device. You can also backup your personal data
to transfer to a new device.
Note:
For information on how to backup or wipe data from your mobile device,
go to
www.motorola.com/support
• Online accounts
(such as MOTOBLUR). Go to your account for information on how to manage the
account, and how to use security features such as remote wipe and device
location (where available).
• Applications
Applications can have access to private information such as call data, location
details and network resources.
• Location-based information
information that can be used to determine the approximate location of a mobile
device. Mobile phones which are connected to a wireless network transmit
location-based information. Devices enabled with GPS or AGPS technology also
transmit location-based information. Additionally, if you use applications that
require location-based information (e.g. driving directions), such applications
transmit location-based information. This location-based information may be
shared with third parties, including your wireless service provider, applications
providers, Motorola, and other third parties providing services.
• Other information your device may transmit
testing and other diagnostic (including location-based) information, and other
non-personal information to Motorola or other third-party servers. This
information is used to help improve products and services offered by Motorola.
If you have further questions regarding how the use of your mobile device may
impact your privacy or data security, please contact Motorola at
privacy@motorola.com
—Install third party applications from trusted sources only.
—Your mobile device can store personal
—Some mobile devices provide a Motorola online account
—Location-based information includes
—Your device may also transmit
, or contact your service provider.
53
Use & Care
Use & Care
To care for your Motorola mobile device, please observe the following:
liquids
Don’t expose your mobile device to water, rain, extreme humidity,
sweat, or other liquids. If it does get wet, don’t try to accelerate drying
with the use of an oven or dryer, as this may damage the mobile device.
extreme heat or cold
Don’t store or use your mobile device in temperatures below -10°C
(14°F) or above 60°C (140°F). Don’t recharge your mobile device in
temperatures below 0°C (32°F) or above 45°C (113°F)
microwaves
Don’t try to dry your mobile device in a microwave oven.
dust and dirt
Don’t expose your mobile device to dust, dirt, sand, food, or other
inappropriate materials.
cleaning solutions
To clean your mobile device, use only a dry soft cloth. Don’t use alcohol
or other cleaning solutions.
shock and vibration
Don’t drop your mobile device.
protection
To help protect your mobile device, always make sure that the battery
compartment and any connector covers are closed and secure.
54
Recycling
Recycling
Mobile Devices & Accessories
Please do not dispose of mobile devices or electrical accessories (such as
chargers, headsets, or batteries) with your household waste, or in a fire.
These items should be disposed of in accordance with the national
collection and recycling schemes operated by your local or regional
authority. Alternatively, you may return unwanted mobile devices and electrical
accessories to any Motorola Approved Service Center in your region. Details of
Motorola approved national recycling schemes, and further information on Motorola
recycling activities can be found at:
Packaging & Product Guides
Product packaging and pr oduct guides should only be disp osed of in accordance with
national collection and recycling requirements. Please contact your regional
authorities for more details.
California Perchlorate Label
Perchlorate Label
Some mobile phones use an internal, permanent backup battery on the printed
circuit board that may contain very small amounts of perchlorate. In such cases,
California law requires the following label:
Perchlorate Material – special handling may apply when the battery is recycled or
disposed of. See
There is no special handling required by consumers.
www.dtsc.ca.gov/hazardouswaste/perchlorate
www.motorola.com/recycling
Hearing Aid Compatibility with Mobile
Phones
Hearing Aid Compatibility
Some Motorola phones are measured for compatibility with hearing aids. If the box
for your particular model has “Rated for Hearing Aids” printed on it, the following
explanation applies.
When some mobile phones are used near some hearing devices (hearing aids and
cochlear implants), users may detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this interference noise, and phone s
also vary in the amount of interference they generate.
55
The wireless telephone industry has developed ratings for some of their mobile
phones, to assist hearing device users in finding phones that may be compatible
with their hearing devices. Not all phones have been rated. Phones that are rated
have the rating on their box or a label on the box. To maintain the published Hearing
Aid Compatibility (HAC) rating for this mobile phone, use only the original equipment
battery model.
The ratings are not guarantees. Results will vary depending on the user’s hearing
device and hearing loss. If your hearing device happens to be vulnerable to
interference, you may not be able to use a rated phone successfully. Trying out the
phone with your hearing device is the best way to evaluate it for your personal
needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and are likely to
generate less interference to hearing devices than phones that are not labeled. M4
is the better/higher of the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are likely to be more
usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than
unrated phones. T4 is the better/higher o f the two ratings. (Note that not all hearing
devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of interference.
Your hearing device manufacturer or hearing health professional may help you find
results for your hearing device. The more immune your hearing aid is, the less likely
you are to experience interference noise from mobile phones.
Software Copyright Notice
Software Copyright Notice
Motorola products may include copyrighted Motorola and third-party software
stored in semiconductor memories or other media. Laws in the United States and
other countries preserve for Motorola and third-party software providers certain
exclusive rights for copyrighted software, such as the exclusive rights to distribute
or reproduce the copyrighted software. Accordingly, any copyrighted software
contained in Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent allowed by law. Furthermore,
the purchase of Motorola products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third-party software provider, except for the
56
normal, non-exclusive, royalty-free license to use that arises by operation of law in
the sale of a product.
Content Copyright
Content Copyright
The unauthorized copying of copyrighted materials is contrary to the provisions of
the Copyright Laws of the United States and other countries. This device is intended
solely for copying non-copyrighted materials, materials in which you own the
copyright, or materials which you are authorized or legally permitted to copy. If you
are uncertain about your right to copy any material, please contact your legal
advisor.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of
America and Canada. The Governments of the United States of America and Canada
may restrict the exportation or re-exportation of this product to certain destinations.
For further information contact the U.S. Department of Commerce or the Canadian
Department of Foreign Affairs and International Trade.
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new Motorola
product. Registering permits us to contact you for product or software updates and
allows you to subscribe to updates on new products or special promotions.
Registration is not required for warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service
of your Motorola Personal Communications Product you will need to provide a copy
of your dated sales receipt to confirm warranty status.
Thank you for choosing a Motorola product.
57
Motorola Limited Warranty for the United
States and Canada
Warra nty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Mobility, Inc. warrants its
mobile telephones (“Products”), Motorola-branded or certified accessories sold for
use with these Products (“Accessories”), and Motorola software contained on
CD-ROMs or other tangible media and sold for use with these Products (“Software”)
to be free fr om defects in materials and wor kma nship under normal consumer usage
for the period(s) outlined below. This limited warranty is a consumer's exclusive
remedy, and applies as follows to new Motorola Products, Accessories, and
Software purchased by consumers in the United States or Canada, which are
accompanied by this written warranty:
Products and Accessories
Products CoveredLength of Coverage
as
One (1) year
Products and Accessories
defined above, unless otherwise
provided for below.
Decorative Accessories and
Cases.
Decorative covers,
bezels, PhoneWrap™ covers and
cases.
Monaural Headsets.
and boom headsets that transmit
mono sound through a wired
connection.
Products and Accessories
that are Repaired or
Replaced.
58
Ear buds
from the date of purchase by
the first consumer purchaser of the product
unless otherwise provided for below.
Limited lifetime warranty
lifetime of ownership by the first consumer
purchaser of the product.
Limited lifetime warranty
lifetime of ownership by the first consumer
purchaser of the product.
The balance of the original warranty or
for ninety (90) days
returned to the consumer, whichever is
longer.
for the
for the
from the date
Exclusions (Products and Accessories)
Normal Wear and Tear.
due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of their
rated capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse.
storage, misuse or abuse, accident or neglect, such as physical damage (cracks,
scratches, etc.) to the surface of the product resulting from misuse; (b) contact with
liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like,
extreme heat, or food; (c) use of the Products or Accessories for commercial
purposes or subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
from the use of non-Motorola branded or certified Products, Accessories, Software
or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification.
service, testing, adjustment, installation, maintenance, alteration, or modification in
any way by someone other than Motorola, or its authorized service centers, are
excluded from coverage.
Altered Products.
that have been removed, altered or obliterated; (b) broken seals or that show
evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming
or non-Motorola housings, or parts, are excluded from coverage.
Communication Services.
Accessories or Software due to any communication service or signal you may
subscribe to or use with the Products Accessories or Software is excluded from
coverage.
Periodic maintenance, repair and replacement of parts
Defects or damage that result from: (a) improper operation,
Defects or damage that res ult
Defects or damages resulting from
Products or Accessories with (a) serial numbers or date tags
Defects, damages, or the failure of Products,
Software
Products CoveredLength of Coverage
Applies only to physical defects in the
Software.
media that embodies the copy of the software (e.g.
CD-ROM, or floppy disk).
Ninety (90) days
the date of purchase.
from
59
Exclusions (Software)
Software Embodied in Physical Media.
will meet your requirements or will work in combination with any hardware or
software applications provided by third parties, that the operation of the software
products will be uninterrupted or error free, or that all defects in the software
products will be corrected.
Software NOT Embodied in Physical Media.
physical media (e.g. software that is downloaded from the Internet), is provided “as
is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not transferable.
No warranty is made that the software
Software that is not embodied in
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the purchase price
of any Products, Accessories or Software that does no t conform to this warranty. We
may use functionally equivalent reconditioned/refurbished/pre-owned or new
Products, Accessories or parts. No data, software or applications added to your
Product, Accessory or Software, including but not limited to personal contacts,
games and ringer tones, wi ll be reinstalled. To avoid losing such data, software, and
applications, please create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
USA
Canada
TTY
You will receive instructions on how to ship the Products, Accessories or Software,
at your expense, t o a Motorola Authorized Repair Center. To obtain service, you must
include: (a) a c opy of your receipt, bill of sale or other comparable proof of purchase;
(b) a written description of the problem; (c) the name of your service provider, if
60
1-800-331-6456
1-800-461-4575
1-888-390-6456
applicable; (d) the name and location of the installation facility (if applicable) and,
most importantly; (e) your address and telephone number.
What Other Limitations are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE
THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS
PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO
EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR
PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR
APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION
WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR
SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or exclusion of
incidental or consequential damages, or limitation on the length of an
implied warranty, so the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights, and you may also have
other rights that vary from state to state or from one jurisdiction to another.
61
Copyright & Trademarks
Motorola Mobility, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.motorola.com
Changes or modifica tions made in the radio phone, not expressly approved
by Motorola, will void the user’s authority to operate the equipment.
Product ID:
MOTO
Manual Number: 68014091001-B
62
W418G
MOTOTM W418G
Guía de Inicio
Felicitaciones
MOTO™ W418G
El teléfono MOTO W418G viene con fabulosas
funciones, como fotografías, música y acceso a
Internet: todo en un elegante diseño de solapa.
•Fotografías. Tome fotografías y envíelas a sus
amigos.
•Música. Reproduzca su música en forma
instantánea. Sólo abra el reproductor de música y
seleccione una lista de reproducción.
•Web. Navegue por toda la red. Buscar, explorar,
todo lo que desea, mucho más fácil.
Hemos reunido todas las funciones principales del
teléfono en esta práctica guía, y en cosa de minutos le
mostraremos lo sencillo que es utilizar su teléfono. Se
sorprenderá con lo que descubra.
Precaución: antes de armar, cargar o usar el
teléfono por primera vez, lea la guía de información
legal y de seguridad importante que se incluye con
el producto.
Más información
En la computadora: vaya a
http://www.motorola.com/support
.
1Felicitaciones
Su teléfono
Te cla Programable
Derecha
Te cla Programable
Izquierda
Te clas de volumen
Conector micro
USB
Conector paraaudífono de
3,5 mm
Te cla de
selección
Seleccionar la
opción resaltada.
Te cla Atrás
Te cla de
cámara
Te cla Enviar
Realizar y contestar
llamadas.
Te cla de
encendido/fin
Encender/apagar,
colgar, salir de
menús.
Te cla de
navegación
Desplazarse hacia
arriba, abajo,
izquierda o derecha.
teclas y conectores importantes
Nota: su teléfono puede verse levemente diferente.
Información de seguridad, reglamentaria y legal . . 43
3Contenido
Allá vamos
H
preparación para usar el dispositivo
Montaje y carga
1 sacar la cubierta2 introducir la
3 insertar batería4 colocar la cubierta
5 cargar
Precaución: lea “Uso y seguridad de las baterías” en
la página 43.
4Allá vamos
tarjeta microSD
4
Consejo: para sacar la tarjeta de memoria microSD,
oprima la lengüeta de retención (use una moneda u
otro objeto similar), luego deslice la tarjeta con su
dedo pulgar.
Encender y apagar
Para encender o apagar el
teléfono, mantenga oprimida la
tecla Encendido/Fin.
Servicio de prepago
Búsqueda: oprima
izquierda) >
Consejo: también puede oprimir la tecla Selecr
para abrir la aplicación de ser vicio de prepago.
Con el servicio de prepago, usted compra los servicios
de red inalámbrica por adelantado. Su teléfono funciona
de la misma forma que siempre. Las opciones de
prepago le permiten activar y desactivar dicho servicio,
revisar su saldo, agregar dinero a la cuenta, llamar a
servicio al cliente y proporcionar otra información
solicitada por su proveedor de servicio de prepago.
Nota: el servicio de prepago disponible puede variar
dependiendo del proveedor de servicio o la región.
Comuníquese con el proveedor de servicio para
conocer la disponibilidad y obtener más información.
Menú
Prepago
(la tecla programable
5Allá vamos
Realizar y contestar llamadas
Para hacer una llamada desde la pantalla principal,
ingrese un número y luego oprima la tecla Enviar.
Para contestar una llamada, oprima. Para
desactivar la alerta de llamada entrante,
Rechazar
oprima
Para finalizar una llamada, oprima la tecla Encendido/
Fin.
.
Contenido genial y más
Explore la web en búsqueda de contenido entretenido
y más (consulte “Web” en la página 22). Se puede
instalar una tarjeta de memoria microSD opcional en el
teléfono: puede cargarla con fotografías, videos y
música de su computadora (consulte “Tarjeta de
memoria y USB” en la página 36).
6Allá vamos
Teclas
algunos aspectos fundamentales
Sugerencias de teclas
Aquí se entregan algunos consejos sobre cómo
navegar por el teléfono.
Navegación por el menú
1 En la pantalla principal,
2 Oprima la tecla de
3 Oprima la tecla Selecr
Menú
oprima
(la tecla
programable izquierda) para
abrir el menú de aplicaciones.
Navegación hacia arriba,
abajo, izquierda o derecha
para desplazarse y resaltar
una opción del menú.
para seleccionar la opción
resaltada.
7Teclas
Teclas de atajo
En la pantalla principal oprima , hacia arriba, abajo,
izquierda o derecha para abrir rápidamente
Reproductor de música, Contactos, Mensajes
Perfiles de usuario
.
, o
Ajustar el volumen
Oprima las teclas de volumen del costado del teléfono
para cambiar el volumen del timbre (en la pantalla
principal) o el volumen del auricular (durante una
llamada).
8Teclas
Pantalla principal
10:18 a.m.
10:18 AM10:18 AM10:18 AM
WebMenú
10/12/201210/12/2 01210/12/2012
Indicadores de estado
Te cla Programable Derecha
Te cla Programable Izquierda
Oprima para el menú de
aplicaciones.
acceso rápido a los elementos más necesarios
Inicio rápido: pantalla principal
La pantalla principal le entrega toda su información
más reciente en un solo lugar. Es lo que verá al
encender el teléfono o al oprimir desde un menú.
Es básicamente lo siguiente:
Nota: la pantalla principal puede diferir en cierta
medida.
9Pantalla principal
Menú de aplicaciones
Todas las aplicaciones del teléfono se muestran en el
menú de aplicaciones.
Para abrir el menú de aplicaciones, en la pantalla
principal, oprima
izquierda). Oprima hacia arriba, abajo, izquierda o
derecha para resaltar una opción del menú, luego
oprima para seleccionar la opción resaltada. Puede
oprimir para volver a la pantalla principal en
cualquier momento.
Menú
(la tecla programable
Estado del teléfono y notificaciones
La barra de estado en la parte superior de la pantalla
contiene iconos que informan acerca de mensajes y
del estado del teléfono.
indicadores de estado
Intensidad de la
señal
GPRSSólo vibración
Bluetooth®Vibrar y timbrar
RadioVibración, luego
AlarmaAudífono
Mensaje NuevoBatería
10Pantalla principal
Sólo timbre
Llamadas
es bueno conversar
Opciones de llamada entrante
Durante una llamada, oprima
usar el altavoz de manos libres.
Nota: el uso de dispositivos o accesorios móviles
mientras conduce puede ocasionar distracción e
infringir la ley. Siempre obedezca las leyes y conduzca
con seguridad.
Consejo: para silenciar una llamada, oprima
Silenciar
>
Llamadas recientes
1 Desde la pantalla principal, oprima para ver una
.
lista de llamadas recientes.
2 Resalte una llamada y oprima para llamarlo. Para
ver detalles de la llamada, oprima
ALTAVOZ ACTIVADO
Opciones
Opciones >Ver
para
.
11Llamadas
Llamadas de emergencia
Nota: su proveedor de servicios programa uno o más
números de emergencia (como 911 ó 112) a los cuales
usted puede llamar en cualquier situación, incluso
cuando su teléfono está bloqueado. Los números de
emergencia varían según el país. El o los números de
emergencia configurados previamente pueden no
funcionar en todas las ubicaciones y, en ocasiones,
una llamada de emergencia puede no cursarse debido
a problemas de red, ambientales o de interferencia.
1 Escriba un número de emergencia en la pantalla
principal.
2 Oprima para llamar al número de emergencia.
Enfriamiento
En circunstancias muy limitadas, como por ejemplo si
su teléfono es expuesto a calor extremo, aparecerán
pantallas con el mensaje “Enfriamiento”. Para evitar
que la batería y el teléfono se dañen, debe seguir
estas instrucciones hasta que el teléfono alcance su
rango de temperatura recomendada. Cuando el
teléfono esté en el modo “Enfriamiento”, solo podrá
hacer llamadas de emergencia.
12Llamadas
Contactos
contactos como nunca los ha tenido antes
Inicio rápido: contactos
Búsqueda:
12:14 a.m.
Menú
>
Contactos
Contactos
Modo de ingreso de texto
aba
Agregar un contacto nuevo
Laura Lineros
Oprima para desplazarse
arriba/abajo a través de la
lista de contactos.
2125550707
Buscar un contacto.
AtrásOpciones
Seleccionar para ver, llamar,
modificar, borrar, copiar,
mover o enviar el contacto
seleccionado.
Consejo: para ver más contactos, oprima arriba o
abajo.
13Contactos
Crear contactos
Búsqueda:
nuevo contacto
Como alternativa, puede ingresar un número de
teléfono en la pantalla principal, luego oprima
Opciones >Guardar en contactos
Ingrese el nombre y los detalles del contacto.
Cuando finalice, oprima
Menú
>
Contactos >Agregar
OK >Sí
.
para guardar.
Llamar a contactos
Desplácese hasta un contacto y oprima.
14Conta ctos
Mensajería
a veces es mejor decirlo en un mensaje
Crear y enviar mensajes
Búsqueda:
Use el teclado para escribir el mensaje. Oprima
Opciones
Cuando termine de redactar el mensaje, oprima
Opciones >Send to
o seleccionar destinatarios de mensaje desde la
lista de contactos. Para enviar el mensaje,
oprima
Recibir un mensaje
Cuando recibe un mensaje, el teléfono reproduce una
alerta y muestra el indicador de mensaje nuevo en
la parte superior de la pantalla.
Para leer el mensaje nuevo, oprima
Para leer mensajes almacenados en la bandeja de
entrada, oprima
entrada
Menú
>
Mensajes >Mensaje nuevo
para insertar una imagen, sonido o video.
para ingresar números telefónicos
Opciones >Enviar
Menú
.
>
Mensajes >Buzón de
Ver
.
.
15Mensajería
Fotografías
¡véalo, captúrelo, compártalo!
Búsqueda: oprima Cámara
Consejo: también puede oprimir
Herramientas >Cámara
>
.
Menú
To m as restantes
(Memoria del teléfono)
250
1x
Opciones
Oprima hacia arriba o
abajo para acercar o alejar la
imagen.
Oprima hacia la derecha
para la videograbadora.
Seleccione para ajustar la
programación de la cámara.
Para tomar la fotografía, oprima.
El teléfono guarda una fotografía y la muestra
brevemente en la pantalla.
• Para enviar la fotografía en un mensaje, oprima
Opciones >Enviar
16Fotografías
.
• Para borrar la fotografía, oprima
Opciones >Borrar
Para ver las fotografías que ha capturado, oprima
Menú
>
Tarjeta de memoria >Fotografías
Mi carpeta >Memoria del teléfono
.
o
Para grabar un video, vaya a la pantalla del visor
de la cámara y oprima a la derecha para cambiar
la videograbadora. Como alternativa, puede oprimir
Menú
>
Herramientas >Videograbadora
.
.
17Fotografías
Reproductor de música
cuando lo que necesita es música...
Obtener música
Puede transferir música desde la computadora al
teléfono mediante el uso de una conexión USB.
Para obtener más información acerca de la transferencia
de música, consulte “Tarjeta de memoria y USB” en la
página 36.
Nota: derechos de autor. ¿Tiene derecho? Siempre
respete las normas. Consulte “Contenido con
derechos de autor” en la información legal y de
seguridad.
Reproducir música
Para crear una lista de reproducción de música:
Menú
>
Búsqueda:
de música
oprima
1 Ingrese un nombre para la lista de reproducción,
>
Mis listas de reproducción
Opciones >Nueva lista de reproducción
luego oprima
2 Seleccione el nombre de la lista de reproducción,
luego oprima
agregar una canción desde el teléfono o tarjeta
de memoria.
18Reproductor de música
Herramientas >Reproductor
,
Opciones >Listo
Cargar >Opciones >Agregar
.
para
3 Si es necesario, seleccione
Tarjeta de memoria
Memoria del teléfono
para especificar el lugar donde
está el archivo.
OK
4 Desplácese hasta la canción y oprima
para
agregarla a la lista de reproducción. Repita para
agregar otras canciones a la lista de reproducción.
Para reproducir una lista, selecciónela, luego
Cargar >Opciones >Reproducir
oprima
.
Para borrar una lista de reproducción, selecciónela y
Borrar
oprima
.
Para ajustar la programación del reproductor de
música, cuando esté funcionando, oprima
Programación >Programación del reproductor
>
Opciones
.
o
19Reproductor de música
Radio
noticias y música en movimiento
Nota: la radio FM sólo funciona cuando hay un
accesorio audífono opcional conectado al conector
para audífonos del teléfono.
Menú
>
Búsqueda:
Para buscar estaciones de radio locales, oprima
Buscar
.
Para sintonizar una estación, oprima izquierda o
derecha.
Opciones
Oprima
opciones
Rad Act (Des)
Lista de canales
Entrada manual
Búsqueda automática
20Radio
Herramientas >Radio FM
para ver las opciones de radio:
Enciende y apaga la radio.
Almacena hasta nueve
canales de radio.
Ingresa una frecuencia
de canal.
Busca automáticamente
canales de radio y los
almacena en la lista
de canales.
opciones
Programación
Grabar
Agregar
Lista de archivos
Activa la reproducción de
fondo, el altavoz, programa
el formato de grabación,
calidad de audio y ubicación
de almacenamiento.
Graba programas de radio.
Regresa al archivo grabado
anterior y sigue grabando
en el mismo archivo.
Administra los archivos
grabados.
21Radio
Web
navegue por la web con el teléfono
Nota: para usar el web, debe tener activado el servicio
de datos para la cuenta (puede que se apliquen cargos
adicionales para este servicio).
Utilice el web del teléfono para navegar por sus sitios
web favoritos, cargar videos a un blog de video y
descargar archivos y aplicaciones al teléfono. Inicie
sesión en la cuenta de email basada en Internet para
revisar el email.
Menú
>
Búsqueda:
Para…
Ir a la
página principal
Ir a la página WebSeleccione
Marcar una página
Web como favorita
Ir a un enlace en
una página web
Nota: si no se puede conectar, póngase en contacto
con el proveedor de servicio.
22Web
Web
Seleccione
Oprima
Agregar a favoritos
>
Principal
Ir a URL
Opciones
Seleccione el enlace.
.
.
.
Consejos y trucos
unos consejos útiles
Para…
Volver a la
pantalla principal
Ver las llamadas
entrantes y
salientes recientes
Crear un nuevo
contacto en la lista
de contactos
Ajustar el volumen
del sonido
Activar/desactivar el
modo avión
Oprima.
Oprima
recientes
Llams realizadas
Llams recibidas
Ingrese un número de
teléfono en la pantalla
principal, luego oprima
Opciones >Guardar
en contactos
En la pantalla principal,
oprima las teclas de volumen
hacia arriba o hacia abajo.
Oprima
>
>
>
o
Menú
>
>
Llams
Llam perdidas
o
.
.
Menú
Programación
Programación del teléfono
Modo avión >Modo avión
Modo normal
.
o
23Consejos y trucos
Para…
Programar un estilo
para el menú de
aplicaciones
Programe el menú de
aplicaciones para mostrarlo
como cuadrícula o lista:
Menú
Oprima
>
Programación del teléfono
>
Pantalla >Estilo del
>
menú principal
Lista
Programación
>
.
Matriz
Consejos acerca de la batería
¿Desea para prolongar la duración de la batería?
Pruebe estas opciones:
Menú
• DesactiveBluetooth®: oprima
Programación >Conectividad >Bluetooth
>
Potencia
>
• Reduzca el tiempo que la pantalla permanece
encendida: oprima
Programación del teléfono >Luz de fondo
>
programe el
Menú >Programación
Tiempo (seg)
en un valor inferior.
• Apague el protector de pantalla: oprima
Programación >Programación del teléfono
>
Pantalla >Prot. pantalla >Programación
>
Estado >Apagado
>
24Consejos y trucos
, oprimaOK.
Menú
o
y
Ingreso de texto
piense en el teclado, y ahora imagíneselo más
pequeño
Use el teclado del teléfono para ingresar texto y crear
mensajes o notas. Los indicadores de la parte superior
derecha de la pantalla de texto muestran el modo de
entrada de texto actual.
Consejo: use la función T9 del teléfono para ingresar
palabras con sólo oprimir una vez cada letra. El
teléfono predice cada palabra mientras la ingresa. Para
activar, oprima
Para cambiar el modo de entrada de texto, oprima
Opciones >Método de entrada
modos de ingreso
Abc
ABC
abc
Numérico
Opciones >Programar T9 >Act
:
Coloca en mayúscula la
primera letra de una nueva
oración.
Escribe letras en mayúscula
en el campo de texto.
Escribe letras en minúscula
en el campo de texto.
Escribe números en el
campo de texto.
.
25Ingreso de texto
Para borrar las letras que se encuentran a la izquierda
del cursor, oprima.
Para ingresar símbolos, oprima
Insertar símbolo
>
. Para ingresar un espacio en modo
Opciones
símbolo, oprima.
26Ingreso de texto
Personalizar
añada su toque personal
Perfiles
El teléfono tiene distintos perfiles. Puede personalizar
los tonos de timbre, alertas y volúmenes para cada
perfil.
Menú
>
Búsqueda:
Puede seleccionar estos perfiles:
perfiles
General
Reunión
Exterior
Interior
Silencioso
Programación >Perfiles
Programación predeterminada
del perfil estándar.
Tono de timbre desactivado,
vibración activada.
El tono de timbre y el
volumen del tono de las
teclas están programados en
el máximo.
Tono de timbre desactivado,
vibración activada.
La vibración está activada,
todos los tonos están
apagados.
27Personalizar
perfiles
Audífono
Ajusta la programación de
perfil para cuando conecta un
audífono al teléfono.
Bluetooth
Ajusta la programación de
perfil para cuando haya un
audífono Bluetooth®
conectado al teléfono.
Para cambiar la programación de un perfil, oprima
Opciones >Personalizar
. Puede ajustar estas
programaciones:
programación
Programación
de tonos
Programa tonos de timbre
para llamadas y mensajes
entrantes, tonos de tecla y
otros eventos.
Volumen
Programa el volumen de los
tonos de timbre y los tonos
de las teclas.
Tipo de alerta
28Personalizar
Programa
Sólo vibrar, Vibrar y timbrar
o
Sólo timbre
Vibrar luego timbrar
,
.
,
programación
Tipo de timbre
Otros tonos
Opciones
para contestar
Programa como
Repetir
o
Único
Ascendente
,
Reproduce un tono adicional
Advertencia, Error
para
Llamada en espera
Conectar
.
,
y
Programa para contestar
llamadas mediante la
apertura de la solapa o al
oprimir cualquier tecla.
Fondo de pantalla
Programe la fotografía como fondo de pantalla en la
pantalla principal.
Búsqueda:
del teléfono
Precargado
>
Menú >Programación >Programación
>
Pantalla >Fondo de pantalla
o
Definido por el usuario
> Imagen
Protector de pantalla
Seleccione y active una imagen de protector de
pantalla. El protector de pantalla aparece después de
un período de inactividad especificado.
Búsqueda:
del teléfono
Menú >Programación >Programación
>
Pantalla >Prot. pantalla
29Personalizar
Para activar o desactivar el protector de pantalla,
seleccione
Programación >Estado >Act
o
Des
.
Para programar el intervalo de retraso, seleccione
Programación >Tiempo activo >5seg, 15 seg, 30 seg
1minuto
o
.
Para programar la imagen del protector de pantalla,
seleccione
usuario
> imagen.
Seleccione >Precargado
o
Definido por el
Hora y fecha
Para mostrar la hora y fecha en la pantalla principal.
Búsqueda:
del teléfono
Menú >Programación >Programación
>
Pantalla>Mostrar fecha/hora
Idioma
Programe el idioma del menú.
Búsqueda:
del teléfono
30Personalizar
Menú >Programación >Programación
>
Idioma
,
Controle su vida
manténgase al día
Calendario
Búsqueda:
Para programar la vista de calendario, oprima
Opciones >Ir a vista mensual
Para agregar un evento, desplácese hasta el día, luego
oprima
tres tipos de eventos:
Para ver un evento, desplácese hasta el día, luego
oprima
sus detalles.
Cuando el teléfono muestra/suena un recordatorio de
evento, oprima
Oprima
ocho minutos.
Alarmas
Búsqueda:
Para programar una alarma, selecciónela y actívela,
luego especifique la hora de la alarma, su periodicidad
y tipo de alerta.
Cuando el teléfono muestra/suena una alarma,
oprima
Posponer
Menú
>
Herramientas >Calendario
o
Ir a vista semanal
Opciones >Agregar evento
Opciones >Ver
Posponer
Menú
Detener
recordatorio, reunión
. Seleccione el evento para ver
OK
para no considerar el recordatorio.
para retrasar los recordatorios por
>
Herramientas >Alarma
para apagar la alarma. Oprima
. Puede programar
para retrasar la alarma por ocho minutos.
o
.
curso
.
31Controle su vida
Tare a s
Búsqueda:
Cree una lista de tareas. Para agregar una tarea,
oprima
fecha
Agregar
,
llamada
Menú
>
Herramientas >Tareas
. Puede programar tres tipos de tareas:
, o
aniversario
.
Calculadora
Búsqueda:
Menú
>
Herramientas >Calculadora
Modo avión
Use el modo de avión para apagar todas las
conexiones inalámbricas, útil durante el vuelo.
Búsqueda:
del teléfono
Modo normal
Nota: cuando selecciona el modo avión, todos los
servicios inalámbricos son inhabilitados. Puede volver
a activar Bluetooth®, si la aerolínea lo permite. Otros
servicios inalámbricos de voz y datos (como llamadas y
mensajes de texto) permanecen apagados en el modo
avión. Todavía se pueden hacer llamadas de
emergencia al número de emergencia de su región
(por ejemplo, 911).
32Controle su vida
Programación >Programación
>
Modo avión >Modo avión
.
o
Conexión inalámbrica Bluetooth®
olvídese de los cables y sea inalámbrico
Activar o desactivar la conexión Bluetooth
Búsqueda:
Bluetooth >Potencia
>
Cuando Bluetooth está activado, el indicador
Bluetooth aparece en la pantalla principal.
Nota: para prolongar la vida útil de la batería, apague
Bluetooth cuando no lo use.
Conectar dispositivos nuevos
Para conectarse a un nuevo dispositivo, necesita
asociarlo. Sólo necesita hacer esto una vez para cada
dispositivo; para volver a conectarse, consulte “Volver
a conectar dispositivos” en la página 34.
1 Asegúrese de que el dispositivo con el que se esté
asociando esté en modo detectable (consulte las
instrucciones del dispositivo).
2 Oprima
>
nuevo dispositivo
Nota: si Bluetooth no está activado, el teléfono le
preguntará
Seleccione
Menú
>
Programación >Conectividad
Menú
>
Bluetooth >Mi Dispositivo >Investigar
Programación >Conectividad
.
¿Activar Bluetooth primero?
Sí
.
33Conexión inalámbrica Bluetooth®
3 El teléfono muestra los dispositivos que encuentra
dentro de su alcance. Seleccione un dispositivo para
conectarse.
4 Si es necesario, escriba la contraseña del dispositivo
0000
(como
) para conectarse.
Consejo: para obtener información específica acerca
de un dispositivo, revise las instrucciones que se
incluyen. Para obtener más soporte para Bluetooth,
vaya a www.motorola.com/Bluetoothsupport
.
Para obtener una seguridad máxima de Bluetooth,
conecte siempre los dispositivos Bluetooth en un
entorno seguro y privado.
Nota: el uso de dispositivos o accesorios móviles
mientras conduce puede ocasionar distracción e
infringir la ley. Siempre obedezca las leyes y conduzca
con seguridad.
Volver a conectar dispositivos
Para reconectar automáticamente el teléfono con un
dispositivo asociado, simplemente encienda el
teléfono.
Para reconectar manualmente el teléfono con un
dispositivo asociado, seleccione el nombre del
dispositivo en la lista
34Conexión inalámbrica Bluetooth®
Mi dispositivo
.
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
