motorola W161
W160
W156
Getting Started Guide
get started
You can download a full user manual by going
online to: www.motorola.com/support.
install SIM card & battery
1
3 4
removing the battery
2
Note: Your battery is
intentionally tight fi tting.
get started
charge battery
New batteries are
not fully charged.
To charge your
phone’s battery,
plug the battery
charger into your
phone and into an
electrical outlet. Your phone may take several seconds
to start charging the battery.
When charging is fi nished, your display shows
Charge Complete
For tips on battery life and charging, see the Battery T ips
section of this guide.
.
get started
turn phone on & off
Press and hold O for a
few seconds, or until the
display turns on or off.
make a call
Enter a phone number and
press N.
answer a call
When your phone rings and/or
vibrates, press N.
end a call
Press O.
Note: The send/end key on wired headsets is not
supported on this phone. Use the N and O keys
on the phone to answer and end calls.
basics
your phone
Left Soft Key
Make &
answer calls.
Connect a
headset.
Note: Your phone may not appear exactly as the
images in this manual. However, all key locations,
sequences, and functions are the same.
Right Soft Key
Turn on & off,
hang up, exit menus.
Open menus &
select items.
Navigate menus.
Charge up.
basics
menus
1
Press s to open the
Main Menu.
2
Press the navigation key
S
up, down, right, or left
to highlight a menu option.
3
Press the center key s
or
SELECT
to select the
highlighted option.
basics
emergency calls
To call the emergency
number:
Press keypad keys to enter
the emergency number,
then press
Your service provider programs one or more emergency
phone numbers (such as 112 or 911) that you can call
under any circumstances, even when your phone is
locked or the SIM card is not inserted.
Note: Emergency numbers vary by country. Your
phone’s preprogrammed emergency number(s) may
not work in all locations. Sometimes an emergency
call cannot be placed due to network, environmental,
or interference issues.
N
to call it.
basics
voicemail
Find it: s > e
recent calls
Find it: s > s
Shortcut: Press N from the home screen to see a list
of dialed calls.
lock/unlock your keypad
Press s > w
or
Automatic Lock
then press OK.
Messages
>
Voicemail
Recent Calls
Settings
>
Security
>
. Enter the four-digit unlock code,
Phone Lock > Lock Now
basics
status indicators
Status indicators show at the top of the home screen:
Signal
Strength
Headset
Active
Roaming
Active
Active Call
Line 1 or 2
Service Provider
08/23/06
s
SETTING
e
n
t
8:45am
MESSAGE
Battery
Level
Ring
Style
New
Message
basics
menu map
e
Messages
• Create Message
• Voicemail
• Inbox
• Info Services
• Quick Notes
• Outbox
• Drafts
n
Phonebook
s
Recent Calls
• Received Calls
• Dialed Calls
• Notepad
• Call Times
• Call Cost *
Q
Games
É Offi ce Tools
• Calculator
• MyMenu
• Alarm Clock
• Calendar
• Stop Watch
• Quick Dial *
• Fixed Dial *
• Service Dial *
• STK *
t
Ring Styles
• Style
• Ring Detail
• My Tones
w
Settings
• Call Forward
• Phone Status
• In-Call Setup
• Security
• Initial Setup
• Network
• Headset
r
FM Radio **
l
Personalize
• Home Screen
• Main Menu
• Greeting
• Quick Dial *
* Network Dependent
** W161/W160 only
This is the standard main menu layout.
Your phone’s menu may be a little different.
customize
change ring
To change ring volume:
s
> t
Ring Styles
> style
>
Style
Soft Ring
Vibe and Ring
Silent
Detail
Change
.
Select
:
Find it:
1
Scroll to
2
Press S right or left to raise or lower volume.
To change ring style:
Find it:
Scroll to the style you want and press
y
Î
}
s
> t
Loud Ring
Vibrate
Vibe then Ring
Ring Volume
Ring Styles
and press
z
Ó
Ò
customize
set phone to vibrate
Find it: s > t
Scroll to Vibrate and press
To quickly change to the vibrate mode, press
and hold #. Press and hold # again to return
TIP
to the previous ring style.
set backlight
Find it: s > w
1
Press S up or down to scroll to a time-out setting.
2
Press OK to select the setting.
3
Press
To save battery life, choose a shorter backlight
TIP
display time.
Ring Styles
>
Style
Select
.
Settings
>
Initial Setup
>
Backlight
BACK
to return to the previous menu.
FM radio
listen to radio*
1
Plug a 2.5 mm headset into your phone.
Note: The headset must be inserted into the phone
for the FM radio to function. If you try to turn it
on without inserting the earpiece, your phone will
display
Please Insert The Earpiece.
2
Press
s
> r
FM Radio
.
3
Press ON (left soft key).
To tune to a station, press
To scan available stations, hold S left or right.
To adjust volume, press
To turn the radio off, press
headset.
* Provided on the W161/W160 only.
S
left or right.
S
up or down.
FM RADIO
or unplug the
FM radio
store favorite stations
You can store up to nine FM stations as radio presets.
When listening to a station, press and hold a number
1
through 9 to store the station as a preset.
key
1
To select a preset station, press the number key
through 9 for the station you want.
calendar
schedule an event
Find it: s > É
s
>
New
A title is required for a calendar event. All other
information is optional.
view an event
Find it: s > É
s
>
Day View
Offi ce Tools
>
Calendar
Offi ce Tools
>
Calendar
> highlight an entry >
> highlight a day >
> highlight a day >
Vie w
phonebook
store phonebook entry
Enter a phone number from the home screen.
1
Press
STORE
.
2
Press
CHANGE
to open the
3
Enter a name for the new phonebook entry.
4
Press
DONE
to store the entry.
call phonebook entry
Find it: s > n
Scroll to the entry you want to call and press N.
Phonebook
Name
entry area.
text messages
send a text message
Find it: s > e
1
Type the message and press OK.
2
In the To screen, enter the number you want to
send to using the keypad keys and press OK.
Press
TIP
(predictive text entry), Tap Extended, Numeric,
or Symbol.
3
Press
Messages
>
Create Message
#
to switch text entry mode to iTAP™
SEND
to send the message.
text messages
enter text
You can enter text for text messages:
Flashing
cursor
indicates
insertion
point.
INSERT
Press
to insert a
quick note.
Character
AB
INSERT
Msg
P
0
CANCEL
counter.
CANCEL
Press
to exit without
saving any
changes.
Battery Use & Battery Safety
• Motorola recommends you always use Motorola-branded
batteries and chargers. The warranty does not cover damage
caused by non-Motorola batteries and/or chargers. Caution:
Use of an unqualifi ed battery or charger may present a risk of fi re,
explosion, leakage, or other hazard. Improper battery use, or use
of a damaged battery, may result in a fi re, explosion, or other hazard.
• Battery usage by children should be supervised.
• Important: Motorola mobile devices are designed to work best with
qualifi ed batteries. If you see a message on your display such as
Invalid Battery or Unable to Charge, take the following steps:
• Remove the battery and inspect it to confi rm that it bears a
Motorola “Original Equipment” hologram;
• If there is no hologram, the battery is not a qualifi ed battery;
• If there is a hologram, replace the battery and retry charging it;
• If the message remains, contact a Motorola Authorized Service
Center.
• New batteries or batteries stored for a long time may take more time
to charge.
• Charging precautions: When charging your battery, keep it near
room temperature. Never expose batteries to temperatures below
0°C (32°F) or above 45°C (113°F) when charging. Always take your
mobile device with you when you leave your vehicle.
• When storing your battery, keep it in a cool, dry place.
• It is normal over time for battery life to decrease, and for the battery
to exhibit shorter runtime between charges or require more frequent
or longer charging times.
• Avoid damage to battery and mobile device. Do not disassemble,
open, crush, bend, deform, puncture, shred, or submerge the battery or
mobile device. Avoid dropping the battery or mobile device, especially
on a hard surface. If your battery or mobile device has been subjected
to such damage, take it to a Motorola Authorized Service Center
before using. Do not attempt to dry it with an appliance or heat
source, such as a hair dryer or microwave oven.
• Use care when handling a charged battery—particularly when
placing it inside a pocket, purse, or other container with metal objects.
Contact with metal objects (such as jewelry, keys, beaded chains)
could complete an electrical circuit (short circuit), causing the battery
to become very hot, which could cause damage or injury.
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center for proper battery
032375o
disposal.
Warning: Never dispose of batteries in a fi re because they may
explode. Before using your phone, read the battery safety information
in the “Safety and General Information” section.
Motorola, Inc.,
Consumer Advocacy Offi ce,
1307 East Algonquin Road,
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain features
may not be activated by your service provider, and/or the provider's
network settings may limit the feature’s functionality. Always contact your
service provider about feature availability and functionality. All features,
functionality, and other product specifi cations, as well as the information
contained in this user's guide are based upon the latest available
information and are believed to be accurate at the time of printing.
Motorola reserves the right to change or modify any information or
specifi cations without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Offi ce. All other product or service names are the property of
their respective owners. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license.
© Motorola, Inc., 2007.
Caution: Changes or modifi cations made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the
equipment.
Specifi c Absorption Rate Data
This model meets international guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed the limits for exposure to radio waves recommended
by international guidelines. These guidelines were developed by
the independent scientifi c organization ICNIRP and include safety
margins designed to assure the protection of all persons, regardless
of age and health.
The guidelines use a unit of measurement known as the Specifi c
Absorption Rate, or SAR. The ICNIRP SAR limit for mobile devices
used by the general public is 2 W/kg and the highest SAR value
for this device when tested at the ear was 0.51 W/kg.
devices offer a range of functions, they can be used in other
positions, such as on the body as described in this user guide.
In this case, the highest tested SAR value is 0.77 W/kg.
As SAR is measured utilizing the device’s highest transmitting power,
the actual SAR of this device while operating is typically below that
indicated above. This is due to automatic changes to the power level
of the device to ensure it only uses the minimum level required to
reach the network.
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements
to this product model could cause differences in the SAR value for
later products; in all cases, products are designed to be within the
guidelines.
1
As mobile
2
1
The World Health Organization has stated that present scientifi c
information does not indicate the need for any special precautions for
the use of mobile devices. They note that if you want to reduce your
exposure then you can do so by limiting the length of calls or using
a “hands-free” device to keep the mobile phone away from the head
and body.
Additional Information can be found on the websites of the
World Health Organization (http://www.who.int/emf) or Motorola,
Inc. (http://www.motorola.com/rfhealth).
1.
The tests are carried out in accordance with international guidelines for
testing. The limit incorporates a substantial margin for safety to give
additional protection for the public and to account for any variations in
measurements. Additional related information includes the Motorola
testing protocol, assessment procedure, and measurement uncertainty
range for this product.
2.
Please see the Safety and General Information section about body worn
operation.
European Union Directives
Conformance Statement
Hereby, Motorola declares that this product is in
compliance with
• The essential requirements and other relevant
provisions of Directive 1999/5/EC
• All other relevant EU Directives
0168
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC)
to Directive 1999/5/EC (to R&TTE Directive) at
www.motorola.com/rtte. To fi nd your DoC, enter the Product
Approval Number from your product’s label in the “Search” bar on
the web site.
Product
Approval
Number
Loading...
