motorola W156
Getting Started Guide
get started
your phone
Left Soft Key
Make &
Connect a
headset.
Note: Your phone may not appear exactly as the images in this manual. However, all key locations, sequences, and functions are the same.
Right Soft Key
Turn on & off, hang up, exit menus.
Open menus & select items.
Navigate menus.
Charge up.
get started
You can download a full user manual by going online to: www.motorola.com/support.
install SIM card & battery
1
3 4
2
get started
charge battery
New batteries are not fully charged. To charge your phone’s battery, plug the battery charger into your phone and into an electrical outlet. Your phone may take several seconds to start charging the battery.
When charging is fi nished, your display shows
Charge Complete
For tips on battery life and charging, see the “Battery T ips” section of this guide.
Note: USB charging via PC is not supported.
.
get started
turn phone on & off
Press and hold O for a few seconds, or until the display turns on or off.
make a call
Enter a phone number and press N.
answer a call
When your phone rings and/or vibrates, press N.
end a call
Press O.
basics
menus
1
Press s to open the
Main Menu.
2
Press the navigation key
S
up, down, right, or left
to highlight a menu option.
3
Press the center key s
or
SELECT
to select the
highlighted option.
basics
emergency calls
To call the emergency number:
Press keypad keys to enter the emergency number, then press
Your service provider programs one or more emergency phone numbers (such as 112 or 911) that you can call under any circumstances, even when your phone is locked or the SIM card is not inserted.
Note: Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations. Sometimes an emergency call cannot be placed due to network, environmental, or interference issues.
N
to call it.
basics
voicemail
Find it: s > e
recent calls
Find it: s > s
Shortcut: Press N from the home screen to see a list
of dialed calls.
lock/unlock your keypad
Press s > w or
Automatic Lock
then press OK.
Messages
>
Voicemail
Recent Calls
Settings
>
Security
>
. Enter the four-digit unlock code,
Phone Lock > Lock Now
basics
status indicators
Status indicators show at the top of the home screen:
Signal
Strength
Headset
Active
Roaming
Active
Active Call Line 1 or 2
Service Provider
08/23/06
s
SETTING
e
n
t
8:45am
MESSAGE
Battery Level
Ring Style
New Message
basics
menu map
e
Messages
Create Message
Voicemail
Inbox
Info Services
Quick Notes
Outbox
Drafts
n
Phonebook
s
Recent Calls
Received Calls
Dialed Calls
Notepad
Call Times
• Call Cost *
Q
Games
É Offi ce Tools
Calculator
MyMenu
Alarm Clock
Calendar
Stop Watch
• Quick Dial *
• Fixed Dial *
• Service Dial *
STK *
t
Ring Styles
Style
Ring Detail
My Tones
w
Settings
Call Forward
Phone Status
In-Call Setup
Security
Initial Setup
Network
Headset
l
Personalize
Home Screen
Main Menu
Greeting
• Quick Dial *
* Network Dependent
This is the standard main menu layout. Your phone’s menu may be a little different.
customize
change ring
To change ring volume:
s
> t
Ring Styles
> style
>
Style
Soft Ring
Vibe and Ring
Silent
Detail
Change
.
Select
:
Find it:
1
Scroll to
2
Press S right or left to raise or lower volume.
To change ring style:
Find it:
Scroll to the style you want and press
y
Î
}
s
> t
Loud Ring
Vibrate
Vibe then Ring
Ring Volume
Ring Styles
and press
z
Ó
Ò
customize
set phone to vibrate
Find it: s > t
Scroll to Vibrate and press
To quickly change to the vibrate mode, press and hold #. Press and hold # again to return
TIP
to the previous ring style.
set backlight
Find it: s > w
1
Press S up or down to scroll to a time-out setting.
2
Press OK to select the setting.
3
Press
To save battery life, choose a shorter backlight
TIP
display time.
Ring Styles
>
Style
Select
.
Settings
>
Initial Setup
>
Backlight
BACK
to return to the previous menu.
calendar
schedule an event
Find it: s > É
s
>
New
A title is required for a calendar event. All other information is optional.
view an event
Find it: s > É
s
>
Day View
Offi ce Tools
>
Calendar
Offi ce Tools
>
Calendar
> highlight an entry >
> highlight a day >
> highlight a day >
Vie w
phonebook
store phonebook entry
Enter a phone number from the home screen.
1
Press
STORE
.
2
Press
CHANGE
to open the
3
Enter a name for the new phonebook entry.
4
Press
DONE
to store the entry.
call phonebook entry
Find it: s >n
Scroll to the entry you want to call and press N.
Phonebook
Name
entry area.
text messages
send a text message
Find it: s > e
1
Type the message and press OK.
2
In the To screen, enter the number you want to
send to using the keypad keys and press OK.
Press # to switch text entry mode to iTAP™
TIP
(predictive text entry), Tap Extended, Numeric, or Symbol.
3
Press
Messages
>
Create Message
SEND
to send the message.
text messages
enter text
You can enter text for text messages:
Flashing
cursor indicates insertion
point.
INSERT
Press
to insert a
quick note.
Character
AB
INSERT
Msg
P
0
CANCEL
counter.
CANCEL
Press to exit without saving any changes.
Battery Use & Battery Safety
Motorola recommends you always use Motorola-branded batteries and chargers. The warranty does not cover damage
caused by non-Motorola batteries and/or chargers. Caution: Use of an unqualifi ed battery or charger may present a risk of fi re, explosion, leakage, or other hazard. Improper battery use, or use of a damaged battery, may result in a fi re, explosion, or other hazard.
• Battery usage by children should be supervised.
Important: Motorola mobile devices are designed to work best with qualifi ed batteries. If you see a message on your display such as Invalid Battery or Unable to Charge, take the following steps:
• Remove the battery and inspect it to confi rm that it bears a
Motorola “Original Equipment” hologram;
• If there is no hologram, the battery is not a qualifi ed battery;
• If there is a hologram, replace the battery and retry charging it;
• If the message remains, contact a Motorola Authorized Service
Center.
• New batteries or batteries stored for a long time may take more time to charge.
Charging precautions: When charging your battery, keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging. Always take your mobile device with you when you leave your vehicle.
• When storing your battery, keep it in a cool, dry place.
• It is normal over time for battery life to decrease, and for the battery to exhibit shorter runtime between charges or require more frequent or longer charging times.
Avoid damage to battery and mobile device. Do not disassemble, open, crush, bend, deform, puncture, shred, or submerge the battery or mobile device. Avoid dropping the battery or mobile device, especially
on a hard surface. If your battery or mobile device has been subjected to such damage, take it to a Motorola Authorized Service Center before using. Do not attempt to dry it with an appliance or heat source, such as a hair dryer or microwave oven.
Use care when handling a charged battery—particularly when placing it inside a pocket, purse, or other container with metal objects. Contact with metal objects (such as jewelry, keys, beaded chains) could complete an electrical circuit (short circuit), causing the battery to become very hot, which could cause damage or injury.
Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center for proper battery
032375o
disposal. Warning: Never dispose of batteries in a fi re because they may explode.Before using your phone, read the battery safety information in the “Safety and General Information” section.
Motorola, Inc., Consumer Advocacy Offi ce, 1307 East Algonquin Road, Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifi cations, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifi cations without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Offi ce. All other product or service names are the property of their respective owners. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license.
© Motorola, Inc., 2007.
Caution: Changes or modifi cations made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment.
service & repairs
If you have questions or need assistance, we're here to help. Go to www.motorola.com/consumer/support, where you can
select from a number of customer care options.
Specifi c Absorption Rate Data
This model meets international guidelines for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientifi c organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as the Specifi c Absorption Rate, or SAR. The ICNIRP SAR limit for mobile devices used by the general public is 2 W/kg and the highest SAR value for this device when tested at the ear was 0.51 W/kg.1 As mobile devices offer a range of functions, they can be used in other positions, such as on the body as described in this user's guide.2 In this case, the highest tested SAR value is 0.77 W/kg.
1
As SAR is measured utilizing the device’s highest transmitting power, the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum level required to reach the network.
While there may be differences between the SAR levels of various phones and at various positions, they all meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.
The World Health Organization has stated that present scientifi c information does not indicate the need for any special precautions for the use of mobile devices. They note that if you want to reduce your exposure then you can do so by limiting the length of calls or using a “hands free” device to keep the mobile phone away from the head and body.
Additional Information can be found on the websites of the World Health Organization (http://www.who.int/emf) or Motorola, Inc. (http://www.motorola.com/rfhealth).
1.
The tests are carried out in accordance with international guidelines for testing. The limit incorporates a substantial margin for safety to give additional protection for the public and to account for any variations in
measurements. Additional related information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.
2.
Please see the Safety and General Information section about body worn operation.
European Union Directives Conformance Statement
Hereby, Motorola declares that this product is in compliance with
The essential requirements and other relevant
provisions of Directive 1999/5/EC
All other relevant EU Directives
IMEI: 350034/40/394721/9
Product
Type: MC2-41H14
The above gives an example of a typical Product Approval Number. You can view your product’s Declaration of Conformity (DoC)
to Directive 1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte. To fi nd your DoC, enter the product Approval Number from your product’s label in the “Search” bar on the web site.
Approval Number
Safety and General Information
This section contains important information on the safe and effi cient operation of your mobile device. Read this information before using your mobile device.*
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits.
Your Motorola mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.
Operational Precautions
For optimal mobile device performance and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions.
External Antenna Care
If your mobile device has an external antenna, use only a Motorola­supplied or approved replacement antenna. Use of unauthorized antennas, modifi cations, or attachments could damage the mobile device and/or may result in your device not complying with local regulatory requirements in your country.
* The information provided in this document supersedes the general safety
information in user’s guides published prior to May 1, 2007.
DO NOT hold the external antenna when the mobile device is IN USE. Holding the external antenna affects call quality and may cause the mobile device to operate at a higher power level than needed.
Product Operation
When placing or receiving a phone call, hold your mobile device just like you would a landline phone.
If you wear the mobile device on your body, always place the mobile device in a Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola—or if you hang your mobile device from a lanyard around your neck—keep the mobile device and its antenna at least 2.5 centimeters (1inch) from your body when transmitting.
When using any data feature of the mobile device, with or without an accessory cable, position the mobile device and its antenna at least
2.5 centimeters (1 inch) from your body. Using accessories not supplied or approved by Motorola may cause
your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in fl ight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defi brillator, consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable medical device when the mobile device is turned ON.
DO NOT carry the mobile device in the breast pocket.
Use the ear opposite the implantable medical device to minimize the
potential for interference.
Turn OFF the mobile device immediately if you have any reason to suspect that interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your mobile device with your implantable medical device, consult your health care provider.
Driving Precautions
Check the laws and regulations on the use of mobile devices in the area where you drive. Always obey them.
When using your mobile device while driving, please:
Give full attention to driving and to the road. Using a mobile device may be distracting. Discontinue use if you can’t concentrate on driving.
Use handsfree operation, if available.
Pull off the road and park before making or answering a call if driving
conditions so require.
Do not place a mobile device in the airbag deployment area.
Responsible driving practices can be found in the “Smart Practices While Driving” section at the end of this guide and/or at the Motorola Web site: www.motorola.com/callsmart.
Note: The use of wireless phones while driving may cause distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not always posted, and can include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fi re.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defi ned as follows:
Symbol
032374o
Defi nition
Important safety information follows.
032376o
Li Ion BATT
032378o
Do not dispose of your battery or mobile device in a fi re.
Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.
Do not throw your battery or mobile device in the trash.
Your mobile device contains an internal lithium ion battery.
Do not let your battery, charger, or mobile device get wet.
Symbol
Defi nition
Listening at full volume to music or voice through a headset may damage your hearing.
Batteries and Chargers
Caution: Improper treatment or use of batteries may present a danger of fi re, explosion, leakage, or other hazard. For more information, see the “Battery Use & Battery Safety” section in this user’s guide.
Choking Hazards
Your mobile device or its accessories may include detachable parts, which may present a choking hazard to small children. Keep your mobile device and its accessories away from small children.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualifi ed service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to fl ashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a fl ashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are very tired.
Caution About High Volume Usage
Listening at full volume to music or voice through a headset may damage your hearing.
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering fi nger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.
FCC Notice to Users
The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID:xxxxxx on the product label.
Motorola has not approved any changes or modifi cations to this device by the user. Any changes or modifi cations could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Hearing Aid Compatibility with Mobile Phones
Some Motorola phones are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies.
When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.
The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in fi nding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box.
The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you fi nd results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.
Information from the World Health Organization
Present scientifi c information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using handsfree devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193 Further information: http://www.who.int/peh-emf
Caring for the Environment by Recycling
This symbol on a Motorola product means the product should not be disposed of with household waste.
Disposal of your Mobile Device and Accessories
Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling
Disposal of your Mobile Device Packaging and User’s Guide
Product packaging and user’s guides should only be disposed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.
Privacy and Data Security
Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:
• Monitor access—Keep your mobile device with you and do not leave it where others may have unmonitored access. Lock your device’s keypad where this feature is available.
• Keep software up to date—If Motorola or a software/application vendor releases a patch or software fi x for your mobile device which updates the device’s security, install it as soon as possible.
• Erase before recycling—Delete personal information or data from your mobile device prior to disposing of it or turning it in for recycling. For step-by-step instructions on how to delete all personal information from your device, see the section entitled “master clear” or “delete data” in this user’s guide.
Note: For information on backing up your mobile device data before
erasing it, go to www.motorola.com and then navigate to the “downloads” section of the consumer Web page for “Motorola Backup” or “Motorola Phone Tools”.
• Understanding AGPS—In order to comply with emergency caller location requirements of the FCC, certain Motorola mobile devices incorporate Assisted Global Positioning System (AGPS) technology. AGPS technology also can be used in non-emergency applications to track and monitor a user’s location—for example, to provide driving directions. Users who prefer not to permit such tracking and monitoring should avoid using such applications.
If you have further questions regarding how use of your mobile device may impact your privacy or data security, please contact Motorola at privacy@motorola.com, or contact your service provider.
Smart Practices While Driving
Drive Safe, Call Smart SM
Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. Go to www.motorola.com/callsmart
Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your fi rst responsibility. If you choose to use your mobile device while driving, remember the following tips:
• Get to know your Motorola mobile device and its features such as speed dial and redial. If available, these features help
you to place your call without taking your attention off the road.
• When available, use a handsfree device. If possible, add an additional layer of convenience to your mobile device with one of the many Motorola Original handsfree accessories available today.
• Position your mobile device within easy reach. Be able to access your mobile device without removing your eyes from the road. If you receive an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.
• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffi c or hazardous weather conditions. Rain, sleet, snow, ice, and even heavy traffi c
can be hazardous.
• Do not take notes or look up phone numbers while driving. Jotting down a “to do” list or going through your address book takes attention away from your primary responsibility—driving safely.
for more information.
• Dial sensibly and assess the traffi c; if possible, place calls when your car is not moving or before pulling into traffi c.
If you must make a call while moving, dial only a few numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that may be distracting. Make people you are talking with aware you are
driving and suspend conversations that can divert your attention away from the road.
• Use your mobile device to call for help. Dial 911 or other local emergency number in the case of fi re, traffi c accident, or medical emergencies.*
• Use your mobile device to help others in emergencies. If you see an auto accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number, as you would want others to do for you.*
• Call roadside assistance or a special non-emergency wireless assistance number when necessary. If you see
a broken-down vehicle posing no serious hazard, a broken traffi c signal, a minor traffi c accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.*
* Wherever wireless phone service is available.
For more information about your phone, please visit: www.motorola.com/support
6802937J26
Loading...
