SYMBOL TC70
ACCESSORIES
BROCHURE
PAGE 3
SYMBOL
TC70
RUGGED ALL-TOUCH
ANDROID COMPUTER
A robust accessory
family to tailor the
TC70 to meet
any enterprise.
The comprehensive family of accessories
includes a snap-on magnetic stripe reader
for mobile payment, a holster, a hand strap,
a snap-on trigger handle and more, allowing
you to easily tailor the TC70 to meet the needs
of many different types of users performing many
different types of tasks. And multi-slot battery chargers
and the unique ShareCradle — a multi-slot and 2-slot
cradle system that can accommodate charge-only or data needs
for the TC70 and future Motorola mobile computers — make backroom
management easy and cost effective.
PAGE 1
BROCHURE
TC70 ACCESSORIES
ShareCradle System
The ShareCradle System shares the same set of terminal and terminal spare battery “cups” across of suite
of charge-only and communication bases, providing flexible and future proofed solutions in 5-slot and 2-slot
configurations. All of the 2-slot and 5-slot ShareCradles can charge the TC70 with the hand strap and stylus
attached. In addition, the 2-slot and 5-slot charge-only ShareCradles can charge the TC70 with snap-on accessories
attached — including the magnetic stripe reader and trigger handle — making device charging easier than ever.
(The 2- Slot USB/Ethernet and 5-Slot Ethernet Cradles will not support any Snap-On accessories).
2-SLOT CRADLES
The 2-Slot ShareCradle is designed to provide the best desktop solution. Available in Charge-Only or USB/Ethernet variants, the 2-Slot
ShareCradles accommodate 1x TC70 and 1x spare battery. (Note: 2-Slot ShareCradles require power supply PWRS-14000-148R and country
specific AC line cord sold separately.)
Part Number
Description
CRD-TC7X-SE2CU1-01
CRD-TC7X-SE2EU1-01
TC70 2-Slot Charge Only ShareCradle for 1x TC70 & 1x spare battery.
TC7X 2-Slot Charge/USB/Ethernet ShareCradle for 1x TC70 & 1x spare battery.
5-SLOT CRADLES
The 5-Slot ShareCradles provide high Densit y & Flexibility. Available in Charge-Only or Ethernet variants, the 5-Slot ShareCradles can
accommodate either 5x TC70s or 4x TC70s, plus 4x spare batteries off of one power supply via the 4-Slot Bat tery Charger Adapter Cup (sold
separately). The 5-Slot ShareCradles can be racked/mounted in a standard 19 in. rack system via the mounting accessory. (Note: 5-Slot Cradles
require Power Supply PWRS-14000-148C, country specific AC line cord, and DC Line Cord 50-16002-029R, all sold separately. Optional 4-Slot
Battery Charger, 4- Slot Bat tery Charger Adapter Cup and Mounting Accessory sold separately).
Part Number
CRD-TC7X-SE5C1-01
CRD-TC7X-SE5EU1-01
TC7X 5-Slot Charge Only ShareCradle.
TC7X 5-Slot Ethernet ShareCradle.
Description
4-SLOT BATTERY CHARGER AND SHARECRADLE ACCESSORIES
Part Number Description
SAC-TC7X-4BTYC1-01
TC7X Drop in style 4-Slot Battery Charger with LEDs to indicate Charge State. Can be docked and
powered in the 5-Slot Cradle via adapter cup (sold separately) or used standalone. When used stand-
alone requires Power Supply (PWRS-14000-148C) and country specific AC line cord sold separately.
PAGE 2
CUP-SE-BTYADP1-01
KT-SE-MOUNT1-01
ShareCradle 4-Slot battery charger adapter cup. Allows for a TC70 4-Slot Battery Charger to be charged and
docked on the 5-Slot ShareCradles.
Adjustable ShareCradle metal mounting bracket. Allows for rack and wall mounting with
cable routing slots and removable power supply tray.
PowerPrecision Batteries
Best-in-class battery technology provides smart, convenient and flexible information along with business quality,
performance and dependability. Our PowerPrecision batteries are manufactured and tested to meet rigorous controls
and standards. We only use Premium-grade cells in our PowerPrecision batteries to deliver a higher capacity and a
longer life cycle. And the strong and robust housing adds durability and protects performance.
Payment
Cables
Part Number
BTRY-TC7X-46MA1-01
BTRY-TC7X-46MA1-10
Part Number
MSR-TC7X-SNP1-01
Part Number
CHG-TC7X-CBL1-01
CBL-TC7X-USB1-01
CBL-TC7X-SERL1-01
Description
TC7X 4620 MAH LI-ON Battery (Single Pack)
TC7X 4620 MAH LI-ON Battery (10-PK)
Description
TC70 Snap-on Mag Stripe Reader. Reads Tracks 1, 2, & 3. Offers Point-to-point encryption (P2PE) with
Encryption for Tracks 1, 2, and 3, supporting TDES/DUKPT and AES/DUKPT. Compatible with hand strap,
Charge-Only Cradles, and Charging Cable Cups. Not compatible with other accessories.
Description
Charging Cable Cup. Snaps onto the bottom of TC70, allowing the users to charge their TC70 while another
accessory is attached. Requires PWRS-14000-249R and country specific AC line cord sold separately.
Snap-On USB/Charge Cable. Connects to the IO connectors on the rear of Pollux. For charging, PWRS-14000-249R
and Country Specific AC line cord sold separately.
Snap-On Serial Cable. Provides serial communication as well as Power via PWRS-14000-249R sold separately.
(Available April 2015.)
Audio Accessories
Part Number
ADP-TC7X-AUDIO1-01
HDST-25MM-PTVP-01
RCH51
25-124387-02R
Description
Snap-On 2.5 mm Audio Nugget. Headsets sold separately.
2.5 mm Headset for PTT and VoIP with rotating ear piece for right/left ear wearing and built in cord wrap.
Premium Rugged Headset optimized for voice-directed applications and voice communication for workers
in harsh environments. Requires QD to 2.5 mm adapter.
RCH50/RCH51 Adapter Cable to 2.5 mm barrel jack.
PAGE 3
Scanning
Soft Goods
Power Supplies
Part Number
PWRS-14000-148R
Part Number
TRG-TC7X-SNP1-01
Part Number
SG-TC7X-HLSTR1-01
SG-TC7X-HSTRP1-03
SG-TC7X-STYLUS1-03
KT-TC7X-SCRNP1-01
Power Supply: 100-240 VAC,12VDC,4.16A for TC70 2-Slot Cradles and 4-Slot Battery Chargers. Country specific three wire grounded AC
Line Cord sold separately.
TC70 Snap-On Trigger Handle. Easily attaches to bottom housing and easily removed to access battery.
Compatible with the Charge-Only 5-Slot and 2-Slot ShareCradles or Charging Cable Cup.
TC7X soft holster for vertical orientation with open bucket design to accommodate hand strap and snap-ons,
such as the MSR for easy insertion and removal. Includes loop for optional stylus.
TC7X 3-pack of hand straps. Made of leather and hypalon, this adjustable hand strap provides comfort to
support a wide range of hand sizes whiles resisting wear in rugged environments. The hand strap also provides
a loop and tether point for the optional stylus. Plastic clip latches into terminal for easy insertion and removal.
TC7X Stylus with tether 3-pack. Made of conductive carbon-filled plastic material, this Rigid plastic stylus is
optimized for enterprise durability. Clip and tether point to reduce loss.
TC7X Screen Protector 3-pack.
Description
Description
Description
PWRS-14000-241R
PWRS-14000-249R
AC Line Cords
Part Number
50-16000-255R
50-16000-182R
50-16000-255R
50-16000-664R
50-16000-666R
50-16000-668R
50-16000-670R
Power Supply: 100-240VAC,12VDC,9A for TC70 5-Slot Cradles. DC Line Cord (50-16002-029R and country specific three wire grounded AC Line
Cord sold separately.
Power Supply: 100-240VAC, 5.4 VDC, 3A for Charging Cable Cup, Serial Cable, and USB/Charge Cable. Order country specific two wire
grounded AC Line Cord separately.
Description
AC Line Cord, 1.8 m ungrounded, two wire, CEE7/16. (Countries: KR, VN, BE, FR, DE, IT, NL, ES, SE, AR, CL).
US AC line cord, un-grounded, two wire. Associated Country: United States.
AC Line Cord, 1.8 m ungrounded, two wire, CEE7/16. (Countries: KR, VN, BE, FR, DE, IT, NL, ES, SE, AR, CL).
AC Line Cord, 1.8 ungrounded, two wire, GB 2099-1-1996 plug. Associated Country: China.
AC Line Cord, 1.8 m ungrounded, two wire AS 3112 plug. (Countries: AU, NZ).
AC Line Cord, 1.8 m ungrounded, BS 546 Plug. Associated Country: India.
AC Line Cord, 1.8 m ungrounded, two wire, BS 1363 Plug. Associated Countries: Bermuda, Hong Kong, Iraq, Malaysia, Singapore, and
United Kingdom.
PAGE 4
BROCHURE
TC70 ACCESSORIES
AC Line Cords (continued)
Part Number
23844-00-00R
50-16000-217R
50-16000-218R
50-16000-219R
50-16000-220R
50-16000-221R
50-16000-256R
50-16000-257R
50-16000-669R
50-16000-671R
50-16000-672R
50-16000-678R
Description
US AC line cord, 7.5 ft. long, grounded, three wire. Associated Country: United States.
AC Line Cord, 1.9 m, grounded, three wire, AS 3112 plug. Associated Countries: Australia, China, New Guinea.
AC Line Cord, 1.8 m, grounded, three wire, NEMA 1-15P plug. Associated Country: Japan.
AC Line Cord, 1.8 m, three wire, grounded BS1363 plug. Associated Countries: Hong Kong, Iraq, Malaysia, Singapore, United Kingdom.
AC Line Cord, 1.8 m, grounded three wire, CEE 7/7plug. Associated Countries: Europe, Abu Dhabi, Bolivia, Dubai, Egypt, Iran, Korea,
Russia, Vietnam.
AC Line Cord, 1.8 m, grounded, USA NEMA 5-15P. Associated Country: United States.
AC Line Cord, 1.8 m, grounded, three-wire, CEE7/7 plug. Associated Country: Korea.
AC Line Cord, 1.8 m, grounded, three wire, IEC 60320 C13 plug. Associated Country: China.
AC Line Cord, 1.9 m grounded, three wire, BS 546 Plug. Associated Country: India.
AC Line Cord, 1.8 m grounded, three wire. CIE 23-16 plug Associated Country: Italy.
AC Line Cord, 1.9 m grounded, three wire, S132 Plug. Associated Country: Israel.
AC Line Cord, 36 in. L grounded, three wire. Associated Country: United States.
The TC70 — the professional grade Android device with
a true enterprise-class family of accessories designed to
extend and enhance the TC70 to meet your changing and
growing business needs.
For more information, visit www.motorolasolutions.com/tc70 or access
our global contact directory at www.motorolasolutions.com/contactus
Part number BRO-ACC-TC70. Printed in USA 10/14. MOTOROLA, MOTO, MOTOROL A SOLUTIONS and the St ylized M Logo are
trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks
are the property of their respective owners. ©2014 Motorola Solutions, Inc. All rights reserved.
