Warning: Charge the handset for 24 hours before use.
Motorola CL1I
Models: CL101I, CL102I, CL103I and CL104I
Corded Telephone with
Digital Cordless Handset
Welcome...
to your new Motorola CL1I Corded Telephone with Digital Cordless
Handset!
• Dial on the corded base or cordless handset.
• Emergency mode to make calls on the corded base without AC power.
1
• Bright backlit display on the corded base and cordless handset.
• Cordless handset for locating anywhere within range.
• 40 Number phonebook that can be up to 24 digits.
• Time, date and alarm facility.
• Call timer on the display will automatically time the duration of all external calls.
• Speakerphone on the cordless handset for hands-free conversations.
• Hands-free dialling and monitoring for the corded base.
• Caller ID on the corded base and cordless handset shows you who’s calling.
2
• Redial up to 10 of the last numbers called.
• Register up to 4 handsets to the corded base and register each handset to just one
base.
• Make internal calls, transfer external calls, hold 3-way conversation between two
internal callers on handsets and an external caller.
• Choose from 18 dierent polyphonic ringer melodies on the corded base and
cordless handset for external calls.
Need help?
If you have any problems setting up or using your CL1I, please contact Customer
Services on 1800 2700 361.
Alternatively, you may nd the answer in the ‘Help’ section at the back of this guide.
1
Limited functions only.
2
You must subscribe to your network provider’s Caller ID service for this feature to
work. A subscription fee may be payable.
This user guide provides you with all the information you
need to get the most from your phone.
To set up your phone, follow the simple instructions in
‘Getting Started’, on the next few pages.
IMPORTANT
• Only use the telephone line cord supplied.
• Got everything?
• Corded base
• Corded handset and curly cord
• Power adaptor for the base
• Cordless handset & charger
• 2x rechargeable Ni-MH battery cells
• Power adaptor for the charger
• Telephone line cord
• User guide
If you have purchased a CL1I multiple pack you will also have the following additional
items:
• CL1I serial cordless handset and charger
• 2x rechargeable Ni-MH battery cells
• Power adaptor for the charger
4
1. Getting started .....................................................................7
2. Getting to know your phone ..............................................11
Using your corded base ............................................................17
3. Using the phone .................................................................17
3.1 Calls ...............................................................................................................17
3.1.1 Make a call ...........................................................................................17
3.1.2 Preparatory dialling .............................................................................17
3.1.3 End a call .............................................................................................17
3.1.4 Receive a call ......................................................................................17
3.2 Adjust the earpiece volume...........................................................................17
3.3 Hold ................................................................................................................17
3.4 Intercom.........................................................................................................18
3.4.1 Make an internal call ...........................................................................18
3.4.2 Receive an internal call .......................................................................18
3.4.3 Transfer a call .......................................................................................18
3.5 Redial .............................................................................................................18
3.5.1 View or dial an entry ............................................................................18
3.5.2 Copy a Redial list number to the phonebook ....................................19
3.5.3 Delete an entry ....................................................................................19
3.5.4 Delete the entire Redial list .................................................................19
4. Phonebook .........................................................................20
4.1 Store a number ..............................................................................................20
4.2 View or dial an entry.......................................................................................20
4.3 Edit a phonebook entry .................................................................................20
4.4 Delete an entry ..............................................................................................20
4.5 Delete all entries ............................................................................................20
5. Caller ID and the Calls list ..................................................21
5.1 Caller ID .........................................................................................................21
5.2 Calls list ..........................................................................................................21
5.2.1 View the Calls list ................................................................................21
5.2.2 Dial a number in the Calls list .............................................................21
5.2.3 Copy a number to the phonebook ....................................................21
5.2.4 Delete an entry ....................................................................................21
5.2.5 Delete the entire Calls list ...................................................................22
6. Base settings .......................................................................23
6.1 Set the ringer melody ....................................................................................23
6.2 Set the ringer volume ....................................................................................23
6.3 Set the date and time.....................................................................................23
6.4 Set the alarm ..................................................................................................23
6.5 Contrast .........................................................................................................24
5
6.6 Dial mode.......................................................................................................24
6.7 Flash time .......................................................................................................24
6.8 PABX access code .........................................................................................24
6.9 Area code .......................................................................................................24
6.10 Restore default settings .................................................................................25
6.11 Default settings ..............................................................................................26
7. Registration .........................................................................27
7.1 Register an additional handset ......................................................................27
7.2 De-register a handset ....................................................................................27
Using your cordless handset .....................................................28
8. Using the phone .................................................................28
8.1 Switch the cordless handset on / o .............................................................28
8.2 Calls ...............................................................................................................28
8.2.1 Make a call ...........................................................................................28
8.2.2 Preparatory dialling .............................................................................28
8.2.3 End a call .............................................................................................28
8.2.4 Receive a call ......................................................................................28
8.3 Adjust the earpiece volume...........................................................................28
8.4 Mute ...............................................................................................................28
8.5 Intercom.........................................................................................................29
8.5.1 Make an internal call ...........................................................................29
8.5.2 Receive an internal call .......................................................................29
8.5.3 Transfer a call .......................................................................................29
8.5.4 3-way conference call .........................................................................29
8.6 Hands-free speakerphone .............................................................................30
8.6.1 Make a hands-free call ........................................................................30
8.6.2 Answer a call hands-free .....................................................................30
8.6.3 Switch to hands-free during a call ......................................................30
8.7 Redial .............................................................................................................30
8.7.1 View or dial an entry ............................................................................30
8.7.2 Copy a Redial list number to the phonebook ....................................30
8.7.3 Delete an entry ....................................................................................31
8.7.4 Delete the entire Redial list .................................................................31
8.8 Lock / unlock the keypad ..............................................................................31
9. Phonebook .........................................................................32
9.1 Store a number ..............................................................................................32
9.2 View or dial an entry.......................................................................................32
9.3 Edit a phonebook entry .................................................................................32
9.4 Delete an entry ..............................................................................................32
9.5 Delete all entries ............................................................................................32
6
10. Caller ID and the Calls list ..................................................33
10.1 Caller ID .........................................................................................................33
10.2 Calls list ..........................................................................................................33
10.2.1 View the Calls list ..............................................................................33
10.2.2 Dial a number in the Calls list ...........................................................33
10.2.3 Copy a number to the phonebook ..................................................33
10.2.4 Delete an entry ..................................................................................33
10.2.5 Delete the entire Calls list .................................................................34
11. Handset settings .................................................................35
11.1 Set the ringer melody ....................................................................................35
11.2 Set the ringer volume ....................................................................................35
11.3 Set the date and time .....................................................................................35
11.4 Set the alarm ..................................................................................................35
11.5 Contrast .........................................................................................................36
11.6 Auto answer ...................................................................................................36
11.7 Restore default settings .................................................................................36
11.8 Default settings ..............................................................................................37
12. Registration .........................................................................38
12.1 Register an additional handset ......................................................................38
12.2 De-register a handset ....................................................................................38
13. Help .....................................................................................39
14.
General information ............................................................41
7Getting started
1. Getting started
IMPORTANT
Do not place your CL1I in the bathroom or other humid areas.
Location
You need to place your CL1I base within 2 metres of the mains power and telephone
wall sockets so that the cables will reach. The socket-outlet shall be installed near the
equipment and shall be easily accessible.
Make sure that it is at least 1 metre away from other electrical appliances to avoid
interference. Your CL1I works by sending radio signals between the cordless handset and
corded base. The strength of the signal depends on where you place the base. Placing it
as high as possible ensures the best signal.
CORDLESS HANDSET RANGE
The unit has a range of up to 300 metres outdoors when there is a clear line of sight
between the base and handset. Any obstruction between the base and handset will
reduce the range signicantly. With the base indoors and the handset either indoors or
outdoors, the range will normally be up to 50 metres. Thick concrete and stone walls can
severely aect the range.
SIGNAL STRENGTH
The
icon on your handset indicates that you are within range of the base. When out of
range of the base, the
icon bars will reduce until they have disappeared. If you are on a
call, you will hear a warning beep.
The line will hang up if the cordless handset moves out of range of the base. Move closer to
the base. The cordless handset will automatically reconnect to the base.
Setting up
IMPORTANT
The cordless handset to work the base station must be plugged into the mains power at
all times. Do not connect the telephone line cord into the wall socket until the cordless
handset is fully charged. Use only the power adaptor and telephone line cord supplied
with the product.
Connecting the corded base and handset
8 Getting started
1. Plug the telephone line cord into the socket marked on the rear of the base.
2. Plug the power adaptor into the socket marked
on the rear of the base and plug the
other end into the mains power wall socket. Switch on the mains power.
3. Plug the curly cord into the corded handset and the telephone base.
Connecting the charger and charging the cordless handset
1. Plug the power adaptor into the socket marked on the underside of the charger
and plug the other end into the mains power wall socket.
2. Remove the battery cover from the back of the handset and insert the 2 x AAA NiMH
rechargeable batteries supplied. Please note the ‘+’ and ‘-’ markings inside the battery
compartment and insert in the correct direction.
3. Slide the battery cover back into place.
4. If you are charging the batteries for the rst time, place the handset on the charger to
charge for at least 24 hours continuously.
5. When the handset is fully charged,
will appear steady on the display. The display will
show the time and handset number to indicate that it is registered to the base.
Press
down
1
Slide
2
9Getting started
IMPORTANT
Warning! Use only the approved rechargeable Ni-MH battery cells supplied with your
CL1I.
BATTERY LOW WARNING
If
flashes on the display and you hear a warning beep every minute during a call, you
will need to recharge the handset before you can use it again.
When charging,
will scroll on the display.
INTELLIGENT CHARGING
Your CL1I supports Intelligent Charging, this means when the handset is fully charged, the
base will automatically detect this and stop drawing power from the mains to charge the
handset, saving unnecessary power usage.
BATTERY PERFORMANCE
In ideal conditions, fully charged batteries should give up to 7 hours talk time or up to 130
hours standby time on a single charge.
1
Note that new batteries do not reach their full capacity until they have been put to normal
use for several days.
To keep your batteries in the best condition, leave the handset o the charger for a few
hours at a time.
Running the batteries right down at least once a week will help them last as long as
possible.
The charge capacity of rechargeable batteries will reduce with time as they wear out,
giving the handset less talk / standby time. Eventually they will need to be replaced.
After charging your handset for the rst time, subsequent charging time is about 6–8 hours
a day. Batteries and handset may become warm during charging. This is normal.
1
All talk and standby times are approximate and depend on features selected and usage
pattern.
10 Getting started
Date and time
If you have subscribed to a Caller ID service and it is FSK mode, the date and time is set
automatically when you receive your rst call.
If you do not have Caller ID service, you can set the date and time manually.
Set the date and time on the handset
1. Press
m the display shows .
2. Scroll
d
to and press m.
3. The month flashes, using the
U
or d scroll to the correct month and press m.
4. Repeat to enter the day, hour and minute.
5. Press
m to conrm.
Set the date and time on the base
1. Press
M the display shows .
2. Scroll
d
to and press M.
3. The month flashes, using the
U
or d scroll to the correct month and press M.
4. Repeat to enter the day, hour and minute.
5. Press
M to conrm.
Your CL1I is now ready for use.
11Getting to know your phone
2. Getting to know your phone
Overview of your cordless handset
A Earpiece
B
Display
See page 12 for an overview of the display icons.
C Menu / OK / Mute
Press to open the Menu.
Press to select menu options and to conrm a displayed option.
Press to switch mute on / o during a call.
D Talk / Hands-free
Press to make a call.
Press to switch hands-free on or o during a call.
A
B
G
F
E
D
C
I
H
M
J
N
L
K
LNR
12 Getting to know your phone
E Volume down / Scroll down / Redial list
During a call, press to decrease the volume of the caller.
Press to scroll through the menu options, redial list, calls list and phonebook entries.
In standby mode, press to open the redial list.
F * / Keypad lock
Press and hold to lock / unlock the keypad.
G Flash / Back / Delete
During a call press to hang up a call and reconnect to a new line.
Use with switchboard / PABX services and some network services.
Press to go back an option level when in menu mode.
In editing mode, press to delete characters and digits.
When viewing the redial / calls list, press to delete the displayed entry or press and
hold to delete all entries.
H Volume up / Scroll up / calls list
During a call, press to increase the volume of the caller.
Press to scroll through the menu options, redial list, calls list and phonebook entries.
In standby mode, press to open the calls list.
I
Phonebook
In standby mode, press to open the phonebook list.
J End Call / Switch Handset on/o / Exit
Press to end a call.
Press and hold for 3 seconds to switch the handset on / o.
Press to return to standby when in the call list, redial list and phonebook.
K #
Dial a #.
L Intercom
Used to make internal calls and transfer calls to the corded base or other CL1I handsets
registered to the base.
M
Redial / Pause
Press to redial the last number dialled.
When dialling or storing a number press to enter a pause (P).
N Microphone
13Getting to know your phone
Cordless handset display
Indicates signal strength.
Indicates the phone is in use.
Indicates hands-free is activated.
Indicates the mute is switch on.
Alarm is on.
Indicates the phonebook is open.
Indicates the redial list is open.
Indicates there is a missed call.
Indicates the incoming calls list is open.
Indicates the number or position of a number in the calls lists.
Indicates a repeat call.
Battery is fully charged.
Flashes when the battery is almost fully discharged.
Registration mode.
De-register handset mode.
LCD contrast mode.
Ringer is set to o.
Ringer mode.
Date and time mode.
14 Getting to know your phone
Overview of your corded handset
A Earpiece
To listen to your caller.
B Microphone
To speak to your caller.
C Curly cord socket
Where you plug in your curly cord.
Corded base display
On to indicate new voicemail messages.
O when you have no voicemail messages.
1
Local code mode.
Area code mode.
All other corded base display icons are the same as the cordless handset display.
1
For this feature to work, you must subscribe to Caller ID Service from your network
operator. A subscription fee may be payable.
A
B
C
Loading...
