Moog LDW75CLG-SP Installation Instructions
© 2012, Moog Videolarm, Inc. All Rights Reserved
L i b e r t y ™ S e r i e s
Cellular & WiFi Enabled Camera Enclosure
Installation and Operation Instructions for the following models:
LDW75CLG LibertySerieswirelessIPReadydome.Includecellularrouter,powersupply
forthecompletesystem.Cellularbroadbandadaptersoldseparately.
110/220VACinput.DesignedtoworkwithMoogVideolarmIPReadySeries
ofIPcamerahousings
Beforeattemptingtoconnectoroperatethisproduct,pleasereadtheseinstructionscompletely.
www.moogvideolarm.com
W81-IN5453
08-02-2012
