Installation and Operation Instructions
Before attempting to connect or operate this product, please
read these instructions completely.
CVFC2-S25
Enhanced Vehicle Detection Camera System
CVFC2-S25................ Environmentally Enclosed Camera System, 120Vac input, feed through wall / pole mount, adjustable sunshield, internal surge
suppression, 128x wide dynamic range, 25x zoom, co-ax, RS-485
© 2013, Moog Inc. All Rights Reserved
Moog Inc.
Sensor and Surveillance Systems
3650 Woodhead Drive Northbrook, IL. USA 60062
+1.847.498.0700 Fax: +1.847.498.1258 www.moogS3.com
81-I N 5 4 9 5 111113
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS
avvertire l’utente alla presenza delle istruzioni importanti nella
MADEIN
BUY AMERICA COMPLIANT • COUNTRY OF ORIGIN U.S.A.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with damp cloth.
7 Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions.
8 Cable Runs- All cable runs must be within permissible distance.
9 Mounting - This unit must be properly and securely mounted to a supporting
structure capable of sustaining the weight of the unit.
Accordingly:
a. This installation should be made by a qualied service person and should conform
to all local codes.
b. Care should be exercised to select suitable hardware to install the unit, taking into
account both the composition of the mounting surface and the weight of the unit.
10 Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus ( including ampliers) that produce heat.
11 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
12 Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
13 Only use attachment/ accessories specied by the manufacturer.
14 Use only with a cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
15 Unplug this apparatus during lighting storms or when unused for long periods of time.
16 Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled of objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Be sure to periodically examine the unit and the supporting structure to make sure that the integrity
of the installation is intact. Failure to comply with the foregoing could result in the unit separating
from the support structure and falling, with resultant damages or injury to anyone or anything struck
by the falling unit.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER ( OR BACK). NO USER- SERVICE-
ABLE PARTS INSIDE. REFER SEVICING
TO QUALIFIED SERVICE PERSONNEL.
The lightning ash with an arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of non-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk to persons.
Este símbolo se piensa para alertar al usuario a la presencia
del “voltaje peligroso no-aisIado” dentro del recinto de los
productos que puede ser un riesgo de choque eléctrico.
Ce symbole est prévu pour alerter I’utilisateur à la presence
“de la tension dangereuse” non-isolée dans la clôture de
produits qui peut être un risque de choc électrique.
Dieses Symbol soll den Benutzer zum Vorhandensein der
nicht-lsolier “Gefährdungsspannung” innerhalb der
Produkteinschließung alarmieren die eine Gefahr des
elektrischen Schlages sein kann.
Este símbolo é pretendido alertar o usuário à presença “di
tensão perigosa non-isolada” dentro do cerco dos produtos
que pode ser um risco de choque elétrico.
Questo simbolo è inteso per avvertire I’utente alla presenza
“di tensione pericolosa” non-isolata all’interno della
recinzione dei prodotti che può essere un rischio di scossa
elettrica
.
The exclamation point within an equilateral
triangle is intended to alert the user to
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
UNPACKING
Unpack carefully. Electronic components can be
damaged if improperly handled or dropped. If an item
appears to have been damaged in shipment, replace
it properly in its carton and notify the shipper.
Be sure to save:
1 The shipping carton and packaging material.
They are the safest material in which to make future
shipments of the equipment.
2 These Installation and Operating Instructions.
Este símbolo del punto del exclamation se piensa para
alertar al usuario a la presencia de instrucciones importantes
en la literatura que acompaña la aplicación.
Ce symbole de point d’exclamation est prévu pour alerter
l’utilisateur à la presence des instructions importantes dans
la littérature accompagnant l’appareil.
Dieses Ausruf Punktsymbol soll den Benutzer zum
Vorhandensein de wichtigen Anweisungen in der Literatur
alarmieren, die das Gerät begleitet.
Este símbolo do ponto do exclamation é pretendido alertar o
usuário à presença de instruções importantes na literatura
que acompanha o dispositivo.
Questo simbolo del punto del exclamaton è inteso per
letteratura che accompagna l'apparecchio.
SERVICE
If technical support or service is needed, contact us at
the following number:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TECHNICAL SUPPORT
AVAILABLE 24 HOURS
1- 800-554 -1124
Product Warranty Registration
Register Your Products Online
www.moogS3.com/technical-support/product-registration
Moog values your patronage. We are solely committed to providing you with the highest quality products and
superior customer service. With 3-Year and 5-Year warranties (depending on the product purchased) we stand
behind every product we sell.
See full warranty details at www.moogS3.com/technical-support/warranty-plan/
:
• Simple and Trouble-Free RMA process
• Product / software updates
• Special promotions
• Eliminate the need to archive purchase documents such as receipts, purchase orders, etc.
Limited Warranty for Moog Products
MANUFACTURER HEREBY DISCLAIMS ANY REPRESENTATIONS OR WARRANTY THAT THE PRODUCT IS COMPATIBLE WITH ANY COMBINATION OF NON-MANUFACTURER
THE LIABILITY OF Manufacturer, IF ANY, AND PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR DAMAGES FOR ANY CLAIM OF ANY KIND WHATSOEVER, REGARDLESS
OF THE LEGAL THEORY AND WHETHER ARISING IN TORT OR CONTRACT, SHALL NOT BE GREATER THAN THE ACTUAL PURCHASE PRICE OF THE PRODUCT WITH RESPECT
Moog - Decatur Operations, subsequently referred to as “Manufacturer,” warrants these products to be free from defects in material or workmanship as follows:
PRODUCT CATEGORY PARTS \ LABOR
All Enclosures and Electronics Five (5) Years
Accessory Brackets Five (5) Years
Controllers Three (3) Years
Power Supplies / IR Illuminators Three (3) Years
™
Poles / PolEvators
Warrior Series
SView Series
DeputyDome
EXO Series
EXO Series
During the labor warranty period, to repair the Product, Purchaser will either return the defective product, freight prepaid, or deliver it to Manufacturer at Moog Decatur
Operations, 2525 Park Central Boulevard, Decatur, Georgia, 30035. The Product to be repaired is to be returned in either its original carton or a similar package affording
an equal degree of protection with a RMA # (Return Materials Authorization number) displayed on the outer box or packing slip. To obtain a RMA# you must contact our
Technical Support Team at 800.554.1124, extension 101. Manufacturer will return the repaired product freight prepaid to Purchaser. Manufacturer is not obligated to
provide Purchaser with a substitute unit during the warranty period or at any time. After the applicable warranty period, Purchaser must pay all labor and/or parts charges.
The limited warranty stated in these product instructions is subject to all of the following terms and conditions.
TERMS AND CONDITIONS
1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation
of the claim shall be given promptly by Purchaser to Manufacturer. All claims for warranty service must be made within the warranty period. If after investigation,
Manufacturer determines the reported problem was not covered by the warranty, Purchaser shall pay Manufacturer for the cost of investigating the problem at its then
prevailing per incident billable rate. No repair or replacement of any Product or part thereof shall extend the warranty period of the entire Product. The specic warranty on
the repaired part only shall be in effect for a period of ninety (90) days following the repair or replacement of that part or the remaining period of the Product parts warranty,
whichever is greater.
/ CamEvator Three (3) Years
™
™
™
, NiteTrac™, Igloo Dome, PurgeDome
™
Dome and Fixed Camera Systems* Three (3) Years 6 months if used in auto scan / tour operation
™
GeminEye Visible and Thermal Camera Systems One (1) Year
/ Q-View
™
Three (3) Years
Three (3) Years 6 months if used in auto scan / tour operation
™
Three (3) Years 6 months if used in auto scan / tour operation
2. EXCLUSIVE REMEDY: ACCEPTANCE: Purchaser’s exclusive remedy and Manufacturer’s sole obligation is to supply (or pay for) all labor necessary to repair any Product
found to be defective within the warranty period and to supply, at no extra charge, new or rebuilt replacements for defective parts.
3. EXCEPTIONS TO LIMITED WARRANTY: Manufacturer shall have no liability or obligation to Purchaser with respect to any Product requiring service during the warranty
period which is subjected to any of the following: abuse, improper use, negligence, accident, or acts of God (i.e., hurricanes, earthquakes), modication, failure of the
end-user to follow the directions outlined in the product instructions, failure of the end-user to follow the maintenance procedures recommended by the International Security
Industry Organization, written in product instructions, or recommended in the service manual for the Product. Furthermore, Manufacturer shall have no liability where a
schedule is specied for regular replacement or maintenance or cleaning of certain parts (based on usage) and the end-user has failed to follow such schedule; attempted
repair by non-qualied personnel; operation of the Product outside of the published environmental and electrical parameters, or if such Product’s original identication
(trademark, serial number) markings have been defaced, altered, or removed. Manufacturer excludes from warranty coverage Products sold AS IS and/or WITH ALL FAULTS
and excludes used Products which have not been sold by Manufacturer to the Purchaser. All software and accompanying documentation furnished with, or as part of the
Product is furnished “AS IS” (i.e., without any warranty of any kind), except where expressly provided otherwise in any documentation or license agreement furnished with
the Product. ANY COST ASSOCIATED WITH REMOVAL OF DEFECTIVE PRODUCT AND INSTALLATION OF REPLACEMENT PRODUCT IS NOT INCLUDED IN THIS WARRANTY.
4. PROOF OF PURCHASE: The Purchaser’s dated bill of sale must be retained as evidence of the date of purchase and to establish warranty eligibility.
DISCLAIMER OF WARRANTY
EXCEPT FOR THE FOREGOING WARRANTIES, MANUFACTURER HEREBY DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO ANY AND/OR ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY WARRANTY WITH REGARD TO ANY
CLAIM OF INFRINGEMENT THAT MAY BE PROVIDED IN SECTION 2-312(3) OF THE UNIFORM COMMERCIAL CODE AND/OR IN ANY OTHER COMPARABLE STATE STATUTE.
PRODUCTS OR NON-MANUFACTURER RECOMMENDED PRODUCTS PURCHASER MAY CHOOSE TO CONNECT TO THE PRODUCT.
LIMITATION OF LIABILITY
TO WHICH SUCH CLAIM IS MADE. IN NO EVENT SHALL MANUFACTURER BE LIABLE TO PURCHASER FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES OF ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION, REPLACEMENT LABOR COSTS, REIMBURSEMENT, OR DAMAGES ON ACCOUNT OF THE LOSS
OF PRESENT OR PROSPECTIVE PROFITS OR FOR ANY OTHER REASON WHATSOEVER.
!!
English
Español
Français
Electrical Specifications
Power 120Vac
Class 2 Only
120Vac: 17 watts Heater (16 watts), Blower (1 watt)
Tools Required: Phillips head screwdriver
120Vac: 17 vatios Calentador (16 vatios), soplador (1 vatio)
Herramientas requeridas: Destornillador principal Phillips
120Vac: 17 watts Réchauffeur (16 watts), ventilateur (1 watt)
Outils requis : Tournevis phillips
CVFC2-S25
Contents of Box
Deutsch
Portuguese
Italiano
120Vac: 17 Watt Heizung (16 Watt), Gebläse (1 Watt)
Werkzeuge erfordert: Kreuzkopfschraubenzieher
120Vac: 17 watts Calefator (16 watts), ventilador (1 watt)
Ferramentas exigidas: Chave de fenda principal de Phillips
120Vac: 17 watt Riscaldatore (16 watt), ventilatore (1 watt)
Gli attrezzi hanno richiesto: Cacciavite phillips
Attach mount to wall with suitable hardware
(not provided).
• Ate el montaje a la pared con el hardware conveniente
(no proporcionado).
• Attachez le bâti au mur avec le matériel approprié (non fourni).
• Bringen Sie Einfassung zur Wand mit der verwendbaren Hardware an
(nicht bereitgestellt).
• Una a montagem à parede com a ferragem apropriada (não fornecida).
• Attacchi il supporto alla parete con ssaggi adatti (non forniti).
If attaching to pole, rst break away tabs with pliers and
remove (4) strap plugs.
• Si atan al poste, el primeros rompen lejos lengüetas con los alicates
y quitan (4) los enchufes de la correa.
• Si attachant au poteau, les premiers cassent loin des étiquettes avec
des pinces et enlèvent (4) des prises de courroie.
• Bei der Befestigung zum Pfosten, brechen erste weg Vorsprünge mit
Zangen und entfernen (4) Bügelstecker.
• Se unindo ao pólo, o primeiros quebram afastado abas com alicates
e removem (4) plugues da cinta.
• Se attaccando al palo, i primi rompono via le linguette con le pinze e
rimuovono (4) la cinghia tappa.
TAB
1
2
Twist
Rotate
Lossen and then rotate the wall mount to achieve the
proper orientation.
• Aoje y gire el soporte de pared para conseguir la orientación adecuada.
• Desserrer et puis tourner le support mural pour atteindre le bon sens.
• Lösen und drehen Sie dann die Wandhalterung, um die richtige
Ausrichtung zu erreichen.
• Solte e, em seguida, gire o suporte de parede para alcançar a
orientação adequada.
• Allentare e quindi ruotare il supporto a parete per raggiungere il
corretto orientamento.
WALL MOUNTING
3
If you are running a conduit to the housing, rst
install the appropriate tting to the wall mount.
• Si usted está funcionando con un conducto a la cubierta, primero instale
la guarnición apropiada al montaje de la pared.
• Si vous courez un conduit au logement, installez d'abord l'ajustage de
précision approprié sur le bâti de mur.
• Wenn Sie ein Rohr zum Gehäuse laufen lassen, bringen Sie zuerst die
passende Befestigung zur Wandeinfassung an.
• Se você está funcionando uma canalização à carcaça, instale
primeiramente o encaixe apropriado à montagem da parede.
• Se stiate facendo funzionare un condotto all'alloggiamento, in primo
luogo installi il montaggio adatto al supporto della parete.
POLE MOUNTING
4
Recommended Hardware for the Mounting Holes: • 5/16” - 18 (or M8 for metric) x minimum 1 ¼” Hex Head Bolt • 5/16” Flat Washer
• 5/16” Lock Washer
5
* Max Strap Width: 0.75”
6
TAB
Attach mount to pole with suitable hardware
(not provided).
• Ate el montaje al poste con el hardware conveniente (no proporcionado).
• Attachez le bâti au poteau avec le matériel approprié (non fourni).
• Bringen Sie Einfassung zum Pfosten mit der verwendbaren Hardware an
(nicht bereitgestellt).
• Una a montagem ao pólo com a ferragem apropriada (não fornecida).
• Attacchi il supporto al palo con ssaggi adatti (non forniti).
7
Hinge housing away from mount by loosening (2)
rear screws.
• Abisagre la cubierta lejos del montaje aojando (2) los tornillos
posteriores.
• Articulez le logement à partir du bâti en desserrant (2) les vis arrière.
• Lagern Sie Gehäuse weg von Einfassung schwenkbar, indem Sie (2)
hintere Schrauben lösen.
• Articule a carcaça longe da montagem afrouxando (2) os parafusos
traseiros.
• Alloggiamento della cerniera a partire dal supporto allentando (2) viti
posteriori.
Run cables through mount either by conduit input or through the back of the mount.
• Funcione con los cables montan a través por el conducto entrado o a través de la parte posterior del montaje.
• Courez les câbles montent à travers par le conduit entré ou par le dos du bâti.
• Laufen lassen Sie Kabel anbringen durch entweder durch das eingegebene Rohr oder durch die Rückseite der Einfassung.
• Funcione cabos montam completamente pela canalização entrada ou através da parte traseira da montagem.
• Faccia funzionare i cavi attraverso montano dal condotto immesso o tramite la parte posteriore del supporto.
8
9
Pass cables through wiring membranes
(use screwdriver to pierce).
.
• Pase los cables a través de las membranas del cableado
(el destornillador del uso a perforar) .
• Passez les câbles par des membranes de câblage
(le tournevis d'utilisation à percer).
• Führen Sie Kabel durch Verdrahtungsmembranen
(zu durchbohren der Gebrauchschraubenzieher) .
• Passe cabos através das membranas da ação
(a chave de fenda do uso a perfurar).
• Passi i cavi tramite le membrane dei collegamenti
(cacciavite di uso da perforare).
10
Hinge the housing closed and tighten (2) rear screws.
.
• Abisagre la cubierta cerrada y apriete (2) los tornillos posteriores.
• Articulez le logement fermé et serrez (2) les vis arrière.
• Lagern Sie das geschlossene Gehäuse schwenkbar und ziehen Sie
(2) hintere Schrauben fest.
• Articule a carcaça fechado e aperte (2) os parafusos traseiros.
• Munisca l'alloggiamento di cardini chiuso e stringa (2) viti posteriori.
11
TAB
Open housing lid.
.
• Abra la tapa de la cubierta.
• Ouvrez le couvercle de logement.
• Öffnen Sie Gehäusekappe.
• Abra a tampa da carcaça.
• Apra il coperchio dell'alloggiamento.
TAB
Remove camera tray by squeezing tabs together.
.
• Quite la bandeja de la cámara exprimiendo lengüetas juntas.
• Enlevez le plateau d'appareil-photo en serrant des étiquettes ensemble.
• Entfernen Sie Kamerabehälter, indem Sie zusammen Vorsprünge
zusammendrücken.
• Remova a bandeja da câmera espremendo abas junto.
• Rimuova insieme il vassoio della macchina fotograca comprimendo le
linguette.
12
Camera installed by Moog Videolarm. Refer to instruction 81-IN5494 (INCLUDED) for camera manual.
• Cámara instalada por Moog Videolarm. Consulte las instrucciones de 81-IN5494 (incluido) para manual de la cámara.
• Caméra installée par Moog Videolarm. Reportez-vous aux instructions 81-IN5494 (INCLUS) pour manuel de l'appareil.
• Kamera durch Moog Videolarm installiert. Siehe Anweisung 81-IN5494 (im Lieferumfang enthalten) für Kamera-Handbuch.
• Câmera instalada por Moog Videolarm. Consulte as instruções de 81-IN5494 (incluído) para manual da câmera.
• Camera installato da Moog Videolarm. Fare riferimento alle istruzioni 81-IN5494 (inclusa) per l'uso della fotocamera.
13
Hex tool
Adjust the aim of the housing by loosening the
screw on the mount arm.
.
• Ajuste la puntería de la cubierta aojando el tornillo en el brazo
del montaje.
• Ajustez le but du logement en desserrant la vis sur le bras de bâti.
• Justieren Sie das Ziel des Gehäuses, indem Sie die Schraube am
Einfassungsarm lösen.
• Ajuste o alvo da carcaça afrouxando o parafuso no braço da montagem.
• Registri lo scopo dell'alloggiamento allentando la vite sul braccio del
supporto.
14
After powering your system up, make necessary
focus and camera adjustments.
• Después de accionar su sistema para arriba, haga los ajustes
.
necesarios del foco y de la cámara.
• Après avoir mis votre système, faites les ajustements nécessaires
de foyer et d'appareil-photo.
• Nachdem Sie oben Ihr System angetrieben haben, nehmen Sie
notwendige Fokus- und Kamerajustagen vor.
• Após ter psto seu sistema acima, faça ajustes necessários do foco
e da câmera.
• Dopo la potenza del vostro sistema in su, procedi alle registrazioni
necessarie della macchina fotograca e del fuoco.
15
Close the housing lid and securely tighten the
(2) lid screws.
• Cierre la tapa de la cubierta y apriete con seguridad (2) los tornillos
.
de la tapa.
• Fermez le couvercle de logement et serrez solidement (2) les vis
de couvercle.
• Schließen Sie die Gehäusekappe und ziehen Sie sicher die (2)
Kappenschrauben fest.
• Feche a tampa da carcaça e aperte rmemente (2) os parafusos
da tampa.
• Chiuda il coperchio dell'alloggiamento e saldamente stringa (2) il
coperchio avvita.
16
The camera tray can be securely locked into place with
the provided 3.5 x 7mm screw. Tighten it through the
rear tray tab.
.
• La bandeja de la cámara se puede trabar con seguridad en lugar con el
tornillo proporcionado de 3.5 x de 7m m. Apriétela a través de la
lengüeta posterior de la bandeja.
• Le plateau d'appareil-photo peut être solidement fermé à clef sur
l'endroit avec la vis fournie de 3.5 x de 7mm. Serrez-le par l'étiquette
arrière de plateau.
• Der Kamerabehälter kann in Platz mit der zur Verfügung gestellten 3.5 x
7mm Schraube sicher verriegelt werden. Ziehen Sie ihn durch den
hinteren Behältervorsprung fest.
• A bandeja da câmera pode ser rmemente fechado no lugar com o
parafuso fornecido de 3.5 x de 7mm. Aperte-a através da aba traseira da
bandeja.
• Il vassoio della macchina fotograca può essere saldamente bloccato nel
posto con la vite fornita di 7mm x di 3.5. Stringalo attraverso la linguetta
posteriore del vassoio.
17
If your housing has a sunshield, adjust it for your
particular lighting conditions by loosening (2) screws.
.
• Si su cubierta tiene un sunshield, ajústelo para que haya sus condiciones
de iluminación particulares aojando (2) los tornillos.
• Si votre logement a un sunshield, ajustez-le à vos états d'éclairage
particuliers en desserrant (2) des vis.
• Wenn Ihr Gehäuse ein sunshield hat, stellen Sie es auf Ihre bestimmten
Beleuchtungzustände ein, indem Sie (2) Schrauben lösen.
• Se sua carcaça tem um sunshield, ajuste-o para suas condições de
iluminação particulares afrouxando (2) os parafusos.
• Se il vostro alloggiamento ha un sunshield, registrilo per ottenere le
vostre condizioni di luce particolari allentando (2) avvita.
18
Black - focus
Red - common
Green - zoom
black - line
white - neutral
green / white - ground
NOTE: (must be connected to
ground for surge protection).
Wiring Diagram
Replacement Parts
CVFC2-S25
1
2
3
4
5
# Part Number Descriptio n
1 RPVL3948 FCH Camera Tray
2 RPVL3950 FCH Heater + Bracket
3 RP76VL2016 FCH 12VDC/24VAC PCB
4 RPFD080 12VDC 40mm Fan
5 RPVL3953 Cable Membrane (0.60" hole)
6 RPFTM2425G FCH Wall Mount Assembly
7 RPFCH11HP FCH Hardware Pack et
8 RP71VLBL09 Outdoor Rated Fan (Thermiq only)
N/S RP76VL2018 FCHQ 12VDC/24VAC PCB
N/S RP76VL2023 FCHQ PoE PCB
7
6
8
Loading...
