Moog Sensor and

Moog produces high-quality, scalable physical-security solutions that are designed and made in the USA. High-denition (HD) network camera systems for harsh environments, rugged xed and PTZ camera enclosures, pan and tilt positioners, tripods, infrared illuminators, mounting poles, camera lowering devices, and other accessories are a few of the surveillance solutions Moog provides to the global marketplace. Moog stands behind every product with exceptional technical support and industry leading warranties.

www.moogS3.com

Table of Contents

Markets Served .............................................................................4

Capabilities ....................................................................................5

Customization ...............................................................................6

Thermal Camera Selection Guide ..................................................8

Visible Camera Selection Guide .....................................................9

Fixed Network Camera Systems..................................................10

EXO Fixed Vandal Resistant / Pressurized ...............................11

EXO Fixed Thermal Camera ....................................................12

PTZ Surveillance Systems ...........................................................13

SView ....................................................................................14

EXO Pressurized PTZ HD Camera ...........................................15

EXO Corrosion Resistant HD Camera ......................................16

EXO Vandal Resistant HD Camera ...........................................17

GeminEye Integrated Systems ................................................18

EXO GeminEye Dual HD Camera System

with Thermal Option ...............................................................20

EXO Variable Near IR and White Light Illuminator ....................21

Near IR Integrated Systems ....................................................22

Mercury Camera System Series .............................................23

Single Visible Integrated Systems ...........................................24

Single Thermal Integrated Systems ........................................25

Dual Visible / Thermal Integrated Systems..............................26

PTZ Controllers and Interfaces ....................................................27

Analog / Pan & Tilt Controller ..................................................28

QuickTrac & Unicom / Unicom LT ............................................29

Moog PTZ Controller ...............................................................30

Video Tracking Systems .........................................................31

Pan & Tilt Positioners ...................................................................32

Pan and Tilt Conguration ......................................................33

QPT-20 IC Series ....................................................................34

QPT-35 IC Series ....................................................................35

QPT-50 IC Series ....................................................................36

QPT-90 IC Series ....................................................................37

QPT-130 IC Series ..................................................................38

QPT-200 and 500 IC Series ....................................................39

Analog Pan / Tilt Series .........................................................40

QPT-RF Series ........................................................................41

Mercury Series .......................................................................42

Taurus/Taurus-R Series ..........................................................43

Tripods .........................................................................................44

Gibraltar Series ......................................................................45

Hercules Series ......................................................................46

Samson Series .......................................................................47

Camera Enclosures ......................................................................49

Box

Fusion Camera Housing (Thermiq) ..........................................50

Fusion Camera Housing ........................................................51

Fusion Pressurized and Dust-Proof Housings ..........................52

RC200C ................................................................................53

ACEM20C, ACE20C / AMS90, AMS180 ....................................54

Fusion Stainless Steel Tubular Camera Housing ......................55

Dome

Fusion Stainless Steel Dome ..................................................56

FusionDome ...........................................................................57

RuggedDome .........................................................................58

Pressurized FusionDome ........................................................59

SuperDome ............................................................................60

RM7 / MR7 Recessed Dome Ceiling Housings ........................61

Accessories .................................................................................62

P1600 and P1800 ..................................................................63

PolEvators ..............................................................................64

Brackets and Mounts .............................................................65

Dome Mount Adapters ............................................................66

Dome Brackets / Parapet Mounts ...........................................67

Surge Protection ....................................................................68

Infrared Illuminators ...............................................................69

Miscellaneous ........................................................................70

Power and Wireless .....................................................................71

PB24 Power Boxes .................................................................72

PB26 Wireless and Power Boxes ............................................73

MIMO Wireless .......................................................................74

www.moogS3.com

COMMUNICATION

BORDER SECURITY

VEHICLE AND MAN-PORTABLE

PERIMETER SECURITY

OIL & GAS

ENERGY

BROADCAST COMMUNICATIONS

LAW ENFORCEMENT

CITY-WIDE SURVEILLANCE

Markets Served

TRANSPORTATION

MARITIME

Markets Served

Moog Sensor and Surveillance Systems, a business unit of Moog Space and Defense Group, is comprised of strategic acquisitions. The acquired companies were formally known as QuickSet International and Videolarm Inc. This consortium serves surveillance needs on a broad scale spanning Commercial, Industrial and Military markets.

Moog designs and produces high-quality, scalable physical security and process monitoring solutions for extreme environments. Our unique offerings enable 24/7/365 asset protection, threat intervention, border protection, system health monitoring, and communication around the world.

Commercial

AIRPORT SECURITY DRONE DETECTION/TRACKING

Industrial

Military

OUR UNIQUE OFFERINGS INCLUDE:

• Camera Systems (IP and Analog)

– Multi-spectral (HD / SD / Network / Analog) – Thermal

• Custom Integrated Sensor Solutions

• Pan and Tilt Positioners

• Tripods

• Specialty Camera Enclosures

• Camera Poles and Lowering Devices

• Power Sources

• Wireless Systems

Markets Served

www.moogS3.com

Capabilities

The Floor

Building Excellence

Whether designing products for a new market need or making adjustments to an existing system, the Moog team of engineers provides full design and rapid prototyping for our customers.

Moog engineers have a reputation for building strong relationships with customers’ engineers. Our people roll up their sleeves and become members of our customers’ project teams, collaborating to understand application challenges and design effective solutions.

We believe in taking a true systems engineering approach, giving our teams a broad perspective on the various systems, components, and technical issues involved. Moog engineers bring new energy, ideas, and viewpoints to projects, while continuing their focus on specialized areas of expertise.

• Systems Engineering

• Mechanical Design

• Electrical Design

• OEM Design

• Software Design

• Project Engineering

• Product Engineering

• Manufacturing Engineering

• Quality Engineering

• On-Site and Field Testing

• Rapid Prototyping

• Integrated System Design

• After sales service – Spare parts

logistics, servicing, inspection

Capabilities

www.moogS3.com

Customization

Security and surveillance are critical 24/7 operations that cannot afford downtime – no matter what visibility, terrain, or environmental challenges are present. When off-the-shelf surveillance systems can’t meet your needs, a well-designed integrated sensor imaging system may be your best defense in protecting your assets.

Moog is an industry leader in integrated sensor systems for a wide range of markets and mission critical applications. Our strategy is to supply customizable sensor solutions that are robust, reliable and highly supportable - providing the best possible protection of your assets:

• Highly ruggedized • Quality and durable products reduce cost of ownership

• Various payload integration • Built to withstand extreme environments

• Quick change modules with true plug and play performance • Excellent performance in challenging terrains

Identication Through Glass Barriers Long Wave Infrared (LWIR) Mobile Installation, Mobile Targets

Customization

VISIBLE CAMERAS INFRARED CAMERAS LASER RANGE FINDERS

Detection, Recognition, and ID Detection, Recognition and ID Distance to Target

Long Range Surveillance Smoke, Fog, and Haze Penetration Fixed Installation, Moving Targets

Still Shots and Full Motion Video Medium Wave Infrared (MWIR) Geolocation

HD/IP/Megapixel Imaging Short Wave Infrared (SWIR)

Thermal Signature and Change Detection

www.moogS3.com

Our experienced program management team has the hands-on knowledge to guide you through building a solid foundation for asset protection and threat intervention.

Key Considerations When Building an Integrated Sensor System:

• Potential threats to be detected • Asset protection objectives

• Assets to be protected • Environmental challenges

• Terrain challenges • Detection range required

NON-LETHAL DETERRENTS ACTIVE IMAGING / COMMUNICATIONS DEVICES* ADDITIONAL INTEGRATION OPTIONS*

Acoustic Hailers Radar Systems and RF Antenna Pointing Chem-Bio Sensors

Directed Communication Slew to Cue Radar and GPS Systems Radiation Sensors

Dazzler Point to Point Microwave Threat Detection

High-Intensity Illumination Scanning Systems Threat Classication

Command and Control of Unmanned Systems Chemical Cloud Detection

Satellites Lighting Systems

*Payloads provided and integrated by the OEM.

Customization

www.moogS3.com

Thermal Camera Selection Guide

Thermal Camera Selection

The performance of thermal systems is highly dependent on atmospheric and environmental conditions. Factors such as ocean waves or weather related conditions like rain, snow, fog or mist will affect the performance of the sensors. Please contact a Moog sales representative to discuss your application before selecting a sensor.

640x512 sensor w/ 9mm lens

640x512 sensor w/ 35mm lens

640x512 sensor w/ 13mm lens

640x512 sensor w/ 50mm lens

640x512 sensor w/ 19mm lens

640x512 sensor w/ 60mm lens

THERMAL CAMERA SELECTION

RESOLUTION f/# FOV (H X V)

9mm

13mm 19mm 25mm 35mm 50mm 60mm

100mm

15 -100mm

640 x 480 (NTSC) - 640 x 512 (PAL) 640 x 480 (NTSC) - 640 x 512 (PAL) 1.25 45˚ x 37˚ 640 x 480 (NTSC) - 640 x 512 (PAL) 1.25 32˚ x 26˚ 640 x 480 (NTSC) - 640 x 512 (PAL) 1.1 25˚ x 20˚ 640 x 480 (NTSC) - 640 x 512 (PAL) 1.2 18˚ x 14˚ 640 x 480 (NTSC) - 640 x 512 (PAL) 1.2 12.4˚ x 9.9˚ 640 x 480 (NTSC) - 640 x 512 (PAL) 1.25 10.4˚ x 8.3˚ 640 x 480 (NTSC) - 640 x 512 (PAL) 1.6 6.2˚ x 5.0˚

640 x 480 (NTSC) - 640 x 512 (PAL) 1.4 6.2˚ x 5.0˚ to 42˚ x 54˚

1.25 6.9˚ x 56˚

GEMINEYE THERMAL IMAGING RANGES

9mm Lens

13mm

Lens

19mm

Lens

25mm

Lens

35mm

Lens

50mm

Lens

60mm

Lens

100mm

Lens

These products are subject to export control laws and regulations of the United States government and fall under the control jurisdiction of either ITAR or EAR regulations. Please contact our company Export Representative at +1-716-687-4930 for additional export information

69˚

HFOV

45˚

HFOV

32˚

HFOV

25˚

HFOV

18˚

HFOV

12.4˚ HFOV

10.4˚ HFOV

25˚

HFOV

63 meters-Recognition

31 meters-Identication

95 meters-Recognition

47 meters-Identication

144 meters-Recognition

72 meters-Identication

104 meters-Identication

142 meters-Identication

250 meters-Detection

390 meters-Detection

570 meters-Detection

820 meters-Detection

210 meters-Recognition

1140 meters-Detection

280 meters-Recognition

1500 meters-Detection

380 meters-Recognition

190 meters-Identication

1750 meters-Detection

450 meters-Recognition

225 meters-Identication

2450 meters-Detection

650 meters-Recognition

330 meters-Identication

640x512 sensor w/ 25mm lens

640x512 sensor w/ 100mm lens

Camera Selection Guide

www.moogS3.com

Visible Camera Selection Guide

Visible Camera Selection

LATEST TECHNOLOGIES:

High Denition delivers wide area surveillance plus extreme detail resulting in excellent pictures for viewing, storage and analysis.

HD 1080p

HD 720p

4CIF

704x480 pixels

FOR EXTREME ENVIROMENTS:

Extreme Temperature Range

Industry leading high and low temperature specications achieved via optimized air routing and custom designed electronics with hardened components.

Advantages:

• Better video at low and high temperatures

• Temperature resilience extends camera life

• Meets NEMA TS 2 standards

1280x720

pixels

Superior Surge Protection

Dual stage surge protection for power, alarms, and network / video guard against voltage spikes and surges.

Advantages:

• Reduces the chance of power related failure

• Saves on maintenance: no need to reset

camera with auto recovery

• Eliminates need for third party surge protection

1920x1080

pixels

Corrosion Resistance

Stainless steel 316L construction protects video surveillance equipment, electronics and lenses from debris, harsh chemicals, and other contaminants.

Advantages:

• Corrosion resistant materials extend camera life

• Perfect for marine, chemical plants, food processing, and high-humidity environments

Camera Selection Guide

www.moogS3.com

Fixed Network Camera Systems

Fixed Network Camera

Sensor and Surveillance Systems

Steadfast Asset Protection

FIXED NETWORK CAMERA SYSTEMS

EXO Fixed Vandal Resistant / Pressurized ............................................................................................................................................................11

Fixed Thermal Camera .......................................................................................................................................................................................12

Available accessories can be found in the following sections: Accessories, and Power and Wireless.

Fixed Network Camera Systems

www.moogS3.com

EXO Fixed Vandal Resistant / Pressurized

IK10

NEMA

CERTIFIED

EXO Fixed

PRODUCT OVERVIEW

The EXO Fixed Vandal Resistant and Pressurized High Denition (HD) Network Camera Systems are the professional’s choice for capturing high denition video. The vandal resistant model is great for urban areas, prisons, and other high risk applications. The pressurized model is prefect for marine, coastal areas, trafc monitoring, and other areas of high contamination. Pressurized models include a schraeder valve to ll the camera with nitrogen or another clean stable gas, and a 5-7 psi pressure relief valve so that the unit cannot be over pressurized. This product is built with hardened components to withstand extreme temperature ranges, power surges and heavy impacts.

PRODUCT SPECIFICATIONS

Available Features

• HD 1080P

• 12x optical zoom with auto focus

• Easy camera setup, no mechanical focus or focal length adjustment needed

• Improved WDR

• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API, supported

• H.264 High Prole, MJPEG compression

• Temperature range: -58°F to 140°F (-50°C to 60°C), up to 165°F (74°C), Per NEMA TS2

• Proprietary surge protection (Ethernet and power), with warranty, eliminates need for 3rd party protection

• Meets NEMA 4 and NEMA TS2 standards

• PoE IEEE802.3at or 24Vac power

• Video motion detection

• Feed-through wall / pole mount included

IP67

TS2

Models Description

EXVF5C-1 12x optical zoom, IK10 Vandal Resistant with wall / pole mount

EXPF5C-1 12x optical zoom, IP67 Pressurized with wall / pole mount

Image Sensor: 1/4-type Exmor CMOS

Dimensions: 8.25” x 11.75” x 19.5” (209 x 298 x 495mm)

Net Weight: 10 lb (4.5 kg.)

Mounting Style: Includes: wall / pole • Optional: mast arm or flat plate

Housing: Aluminum and stainless steel hardware

psi

SPECIFICATIONS

GENERAL

Fixed Network Camera Systems

www.moogS3.com

EXO Fixed Thermal Camera

IK10

EXO Fixed Thermal

PRODUCT OVERVIEW

The Moog Fixed Thermal Camera System is the professional’s choice for capturing infrared video. This product is built with hardened components to withstand extreme temperature ranges and power surges.

PRODUCT SPECIFICATIONS

System Features

• Outstanding resolution thermal optics detect objects in

complete darkness or in a variety of difcult-to-see conditions

– 640 x 480, 320 x 240, or 160 x 120 resolution options

• Rugged outdoor-ready system with extreme temperature range

for 365/24/7 surveillance in challenging environments

– Integrated heater / blower to maintain ideal

system temperature

– IP66 for high-level protection against dust and

Shown with square mount

powerful water jets

• Broad range of lens options for different applications

• Scalable to augment existing systems

• Wide detection range through multiple resolution and lens

conguration options

• Extreme temperature range allows for installation in tough

outdoor environments

IP66

IP Specic Features

• H.264 video compression with multiple video

streams minimizes bandwidth and storage requirements, yet produce effective high-quality video

• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API,

supported

• Dual stage surge protection for power, alarms,

and network / video guard against voltage spikes and surges increases reliability and minimizes maintenance downtime

• Built-in SD memory card slot

• Quick and easy installation and setup with PoE,

included wall / pole mount, and easy to congure camera settings

• High-quality, cost-effective, thermal detection in

tough outdoor environments

Models

THFDN1-9 THFDA1-9 THFDN3-9 THFDA3-9 THFDN6-9

THFDA6-9 THFDN1-13 THFDA1-13 THFDN3-13 THFDA3-13 THFDN6-13 THFDA6-13 THFDN1-19 THFDA1-19 THFDN3-19 THFDA3-19 THFDN6-19 THFDA6-19 THFDN3-25 THFDA3-25 THFDN6-25 THFDA6-25 THFDN3-35 THFDA3-35 THFDN6-35 THFDA6-35 THFDN3-50 THFDA3-50 THFDN6-50 THFDA6-50

THFDN3-60 THFDA3-60 THFDN6-60 THFDA6-60

SPECIFICATIONS

Type

IP Analog EXO

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

• •

•

GENERAL

Image Sensor: Uncooled VOx microbolometer

FOV Sensor

9mm 160

9mm 320

9mm 640

13mm 160

13mm 320

13mm 640

19mm 160

19mm 320

19mm 640

25mm 320

25mm 640

35mm, f/1.2

50mm

60mm 320

60mm 640

320

640

320

640

Digital Zoom: 2x to 8x (model dependent) Sensitivity: < 50mk Horizontal Viewing Angle: 9mm, 13mm, 25mm, 35mm, 50mm, 60mm Image Settings: White Hot • Black Hot Humidity: 0-100% N.C per MIL-E-5400T, paragraphs 3.2.24.4 Maximum Windload: 150mph (240kph) Dimensions: 8.25” x 11.75” x 19.5” (209 x 298 x 495mm)

Operating Temperature:

Mounting Style: Includes: Wall / Pole • Optional: Mast Arm or Flat Plate Housing: Aluminum and stainless steel hardware

-40°F to 140°F (-40°C to 60°C), up to 165°F (74°C) for short periods of time Per NEMA TS2

Fixed Network Camera Systems

www.moogS3.com

PTZ Surveillance Systems

Sensor and Surveillance Systems

Robust Solutions for All Environments

PTZ NETWORK AND ANALOG INTEGRATED SURVEILLANCE SYSTEMS

SView ......................................................................................... 14

EXO Pressurized PTZ HD Camera ................................................... 15

EXO Corrosion Resistant HD Camera .............................................. 16

EXO Vandal Resistant HD Camera .................................................. 17

GeminEye Integrated Systems ........................................................ 18

EXO GeminEye Dual HD Camera System

with Thermal Option ...................................................................... 20

Available accessories can be found in the following sections: Accessories, and Power and Wireless.

EXO Variable Near IR and White Light Illuminator ............................. 22

Near IR Integrated Systems............................................................ 23

Mercury Camera System Series ..................................................... 24

Single Visible Integrated Systems ................................................... 25

Single Thermal Integrated Systems ................................................ 26

Dual Visible / Thermal Integrated Systems ...................................... 27

PTZ Surveillance Systems

www.moogS3.com

SView

36x

ZOOM

IK10

SView

PRODUCT OVERVIEW

All-in-One PTZ Video Monitoring System

Moog offers a highly sophisticated PTZ camera system with superb video quality; the SView is available in either IP or analog format. Designed for outdoor use, consisting of metal gearing and a durable Pan / Tilt, the SView system features an auto focus, hi-res, true Day / Night camera; 360x zoom (36x optical and 10x digital); two adjustable privacy zones; and 64 presets. Backed by an impressive industry leading 5-year warranty.

PRODUCT SPECIFICATIONS

Available Features

• Heavy-duty construction including metal gearing and a durable Pan / Tilt

• Auto focus, high-res true Day / Night camera (36x optical and 10x digital zoom)

• 64 presets and 3 auto-tours (sequential and random)

• Intelligent video capabilities: ONVIF compliant

• 360° continuous rotation

• Auto protocol and baud-rate selection

• Proportional zoom / Pan and Zoom / Tilt

• Two adjustable privacy zones

• Industry leading 5-year warranty

• Multiple H.264 streams

SPECIFICATIONS

Models Description

PFD7CN-3

Network Interface: 10 / 100 Base-T Ethernet

Power Consumption: (Watts) 30W for Camera: up to 50W for Heater / Blower

Preset Accuracy: +/- .05 degree

Pan & Tilt Speed: 0.5°-80°/sec manual operation, 120°/sec preset

Tilting Angle: 2° to -90°, Automatic Flip

Operating Temperature: -50°F to 165°F (-45°C to 74°C)

Imager: ¼” Exview HAD CCD

Lenses: 36x Zoom, 3.4-122.4mm, F1.6 to F4.5 Auto-Iris

Video: Motion JPEG, MPEG-4 Part 2 (H.264)

Minimum Illumination: Color 3 lux, B&W: 0.02 lux

Resolution:

Video Streaming:

7” outdoor pressurized IP PTZ camera system, OptiClear polycarbonate dome, fully pressurized, IP67 rated, pendant mount, with 24Vac input, heater / blower. No dust or moisture concerns

17 x 120 to 720 x 576

Multi-stream H.264 and Motion JPEG: 3 simultaneous, individually configured steams in max. resolution at 30/25 fps; more streams if identical or limited in frame rate/resolution. Controllable frame rate and bandwidth VBR/CBR H.264

GENERAL

H.264

Network

Security: Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log

System Integration

Intelligent Video: Video motion detection, active tampering alarm, audio detection

PTZ Surveillance Systems – Network / Analog

www.moogS3.com

EXO Pressurized PTZ HD Camera

IK10

EXO Pressurized PTZ

PRODUCT OVERVIEW

The EXO Pressurized High Denition (HD) Network Camera System is the professional’s choice for capturing brilliant, 1080P full HD video in areas of high contamination. The EXO Series is built tough to withstand extreme temperature ranges, power surges, heavy impacts, and contamination from debris, chemicals and water.

The pressurized outdoor pan-tilt-zoom high denition (HD) IP video camera totally protects electronics and lenses from debris, chemicals and other contaminants; thereby reducing service calls and extending camera life. Each pressurized unit includes a Schraeder valve to ll the housing with Nitrogen or another clean stable gas, and a 5-7psi pressure relief valve so that the unit cannot be over pressurized.

PRODUCT SPECIFICATIONS

Available Features

• HD 1080P

• 20x / 30x optical zoom models

• 30x zoom models have image stabilization

• Day / Night with auto IR-cut lter, Wide Dynamic Range

• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API, supported

• Meets NEMA 4X and NEMA TS2 standards

• Micro-SD / SDHC / SDXC / support

• H.264 High Prole, MJPEG compression

• Video motion detection

• Audio synchronization

• Temperature range: -58ºF to 140ºF (-50°C to 60°C), up to 165ºF (74ºC) (Per NEMA TS2)

• Proprietary surge protection (Ethernet, power and alarm / data wires)

• IK10 Vandal Resistant

NEMA

TS2

CERTIFIED

Models Description

EXPF7C2-2 20x optical zoom, Pressurized, pendant mount with sunshield

EXPF7C2-3 30x optical zoom, Image Stabilization, Pressurized, pendant mount with sunshield

Housing Style: High-impact engineered plastic, UV protected with UL flame rating of UL94-5vA, Aluminum sunshield

Dome: OptiClear, special Nylon blend

Mounting Style: Pendant mount

Net Weight: 13 lb (5.9 kg.)

Dimensions (H x W x D): 14.4” x 11.2” x 11.2” (366 x 285 x 285mm)

Image Sensor: 1/2.8-type Exmor CMOS

Humidity: 0-100% N.C per MIL-E-5400T, paragraphs 3.2.24.4

Ingress Protection Rating: IP67

Maximum Windload: 150mph (240kph)

IP67

psi

SPECIFICATIONS

GENERAL

Vibration: Conforms to NEMA TS2, para 2.1.9

Input Voltage / Power Input: 24Vac / 80W

PTZ Surveillance Systems – Network

www.moogS3.com

EXO Corrosion Resistant HD Camera

IK10

EXO Corrosion Resistant

PRODUCT OVERVIEW

The EXO Corrosion Resistant High Denition (HD) Network Camera System is the professional’s choice for capturing brilliant, 1080P full HD video in areas of extreme corrosion, including applications in food, pharmaceutical, marine, coastal and petrochemical environments. The EXO Corrosion Resistant series, constructed of high-grade 316L Stainless Steel and available in both pressurized and non-pressurized models, is built tough to withstand extreme temperature ranges, power surges, heavy impacts and contamination from debris, chemicals and water.

PRODUCT SPECIFICATIONS

Available Features

• HD 1080P

• H.264 High Prole, MJPEG compression

• Manufactured with high-grade 316L SS

• 20x / 30x optical zoom models

• 30x zoom models have image stabilization

• Day / Night with auto IR-cut lter, Wide Dynamic Range

• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API, supported

• Meets NEMA 4X and NEMA TS2 standards

• Micro-SD / SDHC / SDXC / support

• Video motion detection

• Audio synchronization

• Temperature range: -58ºF to 140ºF

(-50°C to 60°C), up to 165ºF (74ºC) (Per NEMA TS2)

• Proprietary surge protection

(Ethernet, power and alarm / data wires)

• IP67 (IP68 on Pressurized Models)

• Optional stainless steel wall mount

NEMA

TS2

CERTIFIED

Models Description

EXSS7C2-2 20x optical zoom, pendant mount with sunshield

EXSP7C2-2 20x optical zoom, Pressurized, Pendant mount with sunshield

EXSS7C2-3 30x optical zoom, Image Stabilization, Pendant mount with sunshield

EXSP7C2-3 30x optical zoom, Image Stabilization, Pressurized, Pendant mount with sunshield

Dome: OptiClear special Nylon blend

Schraeder Valve (Pressurized Model): Nitrogen input

Pressure Relief Valve (Pressurized Model): 5-7 psi

Net Weight: 16 lb (7.4 kg.)

Dimensions (H x W x D): 14.3” x 11.3” x 11.3” (364 x 288 x 288mm)

Image Sensor: 1/2.8-type Exmor CMOS

Humidity: 0-100% N.C per MIL-E-5400T, paragraphs 3.2.24.4

Impact Rating: IK10

IP67

SPECIFICATIONS

GENERAL

Maximum Windload: 150mph (240kph)

Vibration: Conforms to NEMA TS2, para 2.1.9

Input Voltage / Power Input: 24Vac / 80W

PTZ Surveillance Systems – Network

www.moogS3.com

EXO Vandal Resistant HD Camera

IK10

EXO Vandal Resistant

PRODUCT OVERVIEW

The EXO Vandal Resistant High Denition (HD) Network Camera System is the professional’s choice for capturing brilliant, 1080P full HD video in urban areas, prisons, and other high risk applications. The unit is built with hardened components to withstand extreme temperature ranges, power surges and heavy impacts.

PRODUCT SPECIFICATIONS

Available Features

• HD 1080P

• 20x / 30x optical zoom models

• 30x zoom models have image stabilization

• Day / Night with auto IR-cut lter, Wide Dynamic Range

• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API, supported

• Meets NEMA 4 and NEMA TS2 standards

• Micro-SD / SDHC / SDXC / support

• H.264 High Prole, MJPEG compression

• Video motion detection

• Audio synchronization

• Temperature range: -58ºF to 140ºF (-50°C to 60°C), up to 165ºF (74ºC), Per NEMA TS2

• Proprietary surge protection (Ethernet, power and alarm / data wires)

• Multiple mounting options

• IK10 Vandal Resistant

NEMA

TS2

CERTIFIED

SPECIFICATIONS

Models Description

EXVW7C2-2 20x optical zoom, Wall mount with sunshield

EXVP7C2-2 20x optical zoom, Pendant mount with sunshield

EXVW7C2-3 30x optical zoom, Image Stabilization, Wall mount with sunshield

EXVP7C2-3 30x optical zoom, Image Stabilization, Pendant mount with sunshield

GENERAL

Dome: Polycarbonate

Housing Style: Aluminum and Stainless steel hardware

Mounting Style: Wall and pendant mount models

Net Weight: 13 lbs (5.9 kg.)

Dimensions (H x W x D): 14.7” x 8.2” x 14.7” (375 x 210 x 375mm)

Image Sensor: 1/2.8-type Exmor CMOS

Humidity: 0-100% N.C per MIL-E-5400T, paragraphs 3.2.24.4

Shutter Speed: Automatic or user selectable

Maximum Windload: 150mph (240kph)

Vibration: Conforms to NEMA TS2, para 2.1.9

Input Voltage / Power Input: 24Vac / 80W

Mounting Pattern: Pendant: 1.5”npt • Wall: (4) 2”x5.5” bolt pattern, .38” dia.

PTZ Surveillance Systems – Network

www.moogS3.com

GeminEye Integrated Systems

GeminEye Integrated

PRODUCT OVERVIEW

The GeminEye® Modular Imaging Systems embrace high performance in a small package, and are designed to be congured for multiple applications.

The GeminEye can be congured with single or dual camera blocks for day, night or day/night capability. Various wavelength band sensors and illuminator modules are available. As a system, GeminEye is completely upgradable with image blocks swappable in the eld by the user.

PRODUCT SPECIFICATIONS

Dual Camera GeminEye

Available Features

• Compact / light weight

• Quick-change camera modules (blocks) with true

plug and play performance

• Network controllable or dedicated (UniCom

LT)

controller

• HD Daylight Camera Systems available

• Mil-STD-810F, IP67, sealed and

pressurized camera housings

• Qualied to random vibration,

Salt/FogMIL-STD-810F, Method 509.4

• 10-30 Vdc operations

• Continuous pan rotation

• Mobile or inverted operation

• Mounting kits

• Illuminators with Quick-Site

™

boresight mechanism

• Pelco compatible

IP67

VISIBLE BLOCKS

Part Number Description Sensor Size Focal Length Optical Zoom Lens Type Focus Type

GVB-S10XXN VISB 1/4" CCD 995 3.4-122 12x 36x ZA N 1/4” CCD 3.5 - 98 28X Zoom Auto

GVB-S11XXN VISB 1/4" CCD 1020 3.4-122 12x 36x ZA N 1/4” CCD 3.4 - 122 36X Zoom Auto

THERMAL BLOCKS*

Part Number Description Sensor Size Pixel Size FOV Focal length Digital Zoom ƒ Lens Type Focus Type

GTB-F10F1NF LWIR 320x256 25µ 25mm 4x ƒ1.1 F F NF 320 x 256 25 µ 18° x 14° 25mm 4X ƒ1.1 Fixed Fixed

GTB-F10F2NF LWIR 320x256 25µ 50mm 4x ƒ1.2 F F NF 320 x 256 25 µ 9.1° x 6.9° 50mm 4X ƒ1.2 Fixed Fixed

GTB-F10F3NF LWIR 320x256 25µ 100mm 4x ƒ1.6 F F NF 320 x 256 25 µ 4.6° x 3.4° 100mm 4X ƒ1.6 Fixed Fixed

GTB-F11F2NF LWIR 640x512 17µ 50mm 4x ƒ1.2 F F NF 640 x 512 17 µ 12.4° x 9.9° 50mm 4X ƒ1.2 Fixed Fixed

GTB-F11F3NF LWIR 640x512 17µ 100mm 4x ƒ1.6 F F NF 640 x 512 17 µ 6.2° x 5° 100mm 4X ƒ1.6 Fixed Fixed

GTB-F11Z1NF LWIR 640X512 17µ 15-100 4X ƒ1.4 ZR NF 640 x 512 17 µ 39.9° x 6.2° 15-100mm 4X ƒ1.4 Continuous Zoom Remote

ILLUMINATOR BLOCKS

Part Number Description

GIB-LU10 Illuminator Block 10° FOV GIB-SC10 10° 850nm

GIB-LU20 Illuminator Block 20° FOV GIB-SC20 20° 850nm

GIB-LU30 Illuminator Block 30° FOV GIB-SC30 30° 850nm

GIB-LU60 Illuminator Block 60° FOV GIB-SC60 60° 850nm

Old Part Number F.O.V. Wavelength

VISIBLE AND THERMAL CAMERA SYSTEMS*

Part Number Description

GVTS-S11XXN-F10F2NF GEYE DUAL SYS VISB 1/4” CCD 36X ZOOM 320 x 256 9.1° x 6.9° 50mm ƒ1.2 Fixed Fixed GVB-S11XXN GTB-F10F2NF N/A

GVTS-S10XXN-F10F2NF GEYE DUAL SYS VISB 1/4” CCD 28X ZOOM 320 x 256 9.1° x 6.9° 50mm ƒ1.2 Fixed Fixed GVB-S10XXN GTB-F10F2NF N/A

GVTS-S10XXN-F10F1NF GEYE DUAL SYS VISB 1/4” CCD 28X ZOOM 320 x 256 18° x 14° 25mm ƒ1.1 Fixed Fixed GVB-S10XXN GTB-F10F1NF N/A

GVTS-S11XXN-F10F1NF GEYE Dual SYS VISB 1/4” CCD 36X ZOOM 320 x 256 18° x 14° 25mm ƒ1.1 Fixed Fixed GVB-S11XXN GTB-F10F1NF N/A

GVTS-S11XXN-F11Z1NF GEYE Dual SYS Sony1020 LWIR 640 w/15-100m 640 X 512 39.9° - 6.2° 15- 100 ƒ1.4 Continuous Zoom Remote GVB-S11XXN GTB-F11Z1NF N/A

GVTS-S10XXN-F11Z1NF GEYE Dual SYS VISB 1/4” CCD 28X ZOOM 640 X 512 39.9° - 6.2° 15- 100 ƒ1.4 Continuous Zoom Remote GVB-S10XXN GTB-F11Z1NF N/A

GVTS-S11XXN-F11F3NF GEYE DUAL SYS SONY 1020 LWIR 640 100MM NF 640 X 512 6.2° x 5° 100mm ƒ1.6 Fixed Fixed GVB-S11XXN GTB-F11F3NF N/A

GVTS-S10XXN-F11F2NF GEYE DUAL SYS VISB 1/4” CCD 28X ZOOM 640 X 512 12.4° x 9.9° 50mm ƒ1.2 Fixed Fixed GVB-S10XXN GTB-F11F2NF N/A

GVTS-S11XXN-F11F2NF GEYE DUAL SYS VISB 1/4” CCD 36X ZOOM 640 X 512 12.4° x 9.9° 50mm ƒ1.2 Fixed Fixed GVB-S11XXN GTB-F11F2NF N/A

GVTS-S11XXN-F10F3NF GEYE DUAL SYS SONY 1020 LWIR 320 100MM NF 320 x 256 4.6° x 3.4° 100mm ƒ1.6 Fixed Fixed GVB-S11XXN GTB-F10F3NF N/A

PTZ Surveillance Systems – Analog Integrated System

Sensor Size FOV Focal Length ƒ Lens Type Focus Type

Thermal Camera

Visible Block

www.moogS3.com

Thermal

Block

Illuminator

Block

VISIBLE SENSOR ONLY SYSTEMS

Part Number Description

GVS-S10XXN GeminEye Single V SYS-VISB 1/4” CCD 28X ZOOM N/A N/A N/A N/A N/A N/A GVB-S10XXN N/A N/A

GVS-S11XXN GeminEye Single V SYS-VISB 1/4” CCD 36X ZOOM N/A N/A N/A N/A N/A N/A GVB-S11XXN N/A N/A

Sensor Size FOV Focal Length ƒ Lens Type Focus Type

Thermal Camera

Visible Block

Thermal

Block

THERMAL SENSOR ONLY SYSTEMS

Part Number Description

GTS-F10F1NF GeminEye Single T SYS-LWIR 320 w/ 25mm on LT-901 N/A 320 x 256 18° x 14° 25mm ƒ1.1 Fixed Fixed N/A GTB-F10F1NF N/A

GTS-F10F2NF GeminEye Single T SYS-LWIR 320 w/ 50mm on LT-901 N/A 320 x 256 9.1° x 6.9° 50mm ƒ1.2 Fixed Fixed N/A GTB-F10F2NF N/A

GTS-F10F3NF GeminEye Single T SYS-LWIR 320 w/ 100mm on LT-901 N/A 320 x 256 4.6° x 3.4° 100mm ƒ1.6 Fixed Fixed N/A GTB-F10F3NF N/A

GTS-F11F3NF GeminEye Single T SYS-LWIR 640 w/ 100mm on LT-901 N/A 640 X 512 6.2° x 5° 100mm ƒ1.6 Fixed Fixed N/A GTB-F11F3NF N/A

GTS-F11Z1NF GeminEye Single T SYS-LWIR 640 w/ 15-100mm on LT-901 N/A 640 X 512 39.9° - 6.2° 15- 100 ƒ1.4 Continuous Zoom Remote N/A GTB-F11Z1NF N/A

Visible

Camera

Sensor Size FOV Focal Length ƒ Lens Type Focus Type

Model

Thermal Camera

Visible Block

Thermal

Block

HD GEMINEYE - ANALOG COMPONENT VIDEO

Part Number Description

GVSHD-S13XXN Component HD GeminEye - 1/2.8 CMOS Visible Camera Only

GVTSHD-S13XXN-F10F1NF-S

GVTSHD-S13XXN-F10F3NF-S

GVTSHD-S12XXN-F11Z1NF-S

GVTSHD-S13XXN-F10Z1NF-S

GVTSHD-S13XXN-F11F1NF-S

GVTSHD-S13XXN-F11F2NF-S

GVTSHD-S13XXN-F11F3NF-S

GVTSHD-S13XXN-F11Z1NF-S

Component HD GeminEye - 1/2.8 CMOS Visible and 25mm

Component HD GeminEye - 1/2.8 CMOS Visible and 50mm

Component HD GeminEye - 1/2.8 CMOS Visible and 100mm

Component HD GeminEye - 1/2.8 CMOS Visible and 15-100mm

Component HD GeminEye - 1/2.8 CMOS Visible and 25mm

Component HD GeminEye - 1/2.8 CMOS Visible and 50mm

Component HD GeminEye - 1/2.8 CMOS Visible and 100mm

Component HD GeminEye - 1/2.8 CMOS Visible and 15-100mm

320x256 thermal

640x480 thermal

Image Sensor Lens Signal System No. of Pixels Angle of View Video Output Sensor Size Lens

30x Optical

1/2.8-type

‘Exmor’ CMOS

Zoom, f=4.3 mm (wide) ~

129.0mm (tele), F1.6 to F4.

HD Camera Specications Thermal Camera Specification*

HD: 1080p/29.97,

1080p/25, 1080i/59.94

(frame out 29.97 PsF),

1080i/50 (frame out: 25PsF)

720/59.94p, 720/50p,

720p/29.97, 720p/25

Approx. 3.27

million

H) 1080p/30

mode: 55.4° (wide end)

to 2.9° (tele end)

720p/60, 30

mode: 37.6° (wide end)

to 1.95° (tele end)

HD Analog: Component

Y/Pb/Pr

320x256

640x480

n/a

15-100mm zoom

ILLUMINATOR SYSTEMS

Illuminator

Block

Illuminator

Block

25mm

50mm

100mm

25mm

50mm

100mm

Part Number Description Illuminator FOV Options Visible Block Illuminator Block

GVS-S10XXN-LU10/20/30/60 GeminEye Illuminator System with VISB 1/4” CCD 28X ZOOM 10°, 20°, 30°, 60° GVB-S10XXN GIB-LU10/20/30/60

GVS-S11XXN-LU10/20/30/60 GeminEye Illuminator System with VISB 1/4” CCD 36X ZOOM 10°, 20°, 30°, 60° GVB-S11XXN GIB-LU10/20/30/60

IMAGE BLOCKS

The camera blocks are designed for quick disconnect from the positioner. Customers can recongure systems from day to night payloads or install both at the same time. The image blocks contain embedded translation of the camera operating protocol to the universal protocol of the system. Cameras can be swapped without any change to the system commands. Combined with the Unicom

LT controller or with the system GUI interface, all camera functions are available immediately

upon installation. Each camera block is fully sealed and pressurized to assure moisture free operation and long lifetime.

IR ILLUMINATOR

IR illuminators are available for enhancing camera penetration during nighttime or low light situations. The illuminators have the options of covert and semi-covert wavelengths. The Quick-Site boresight mechanism is available for near / far eld visibility adjustments.

Available Accessory (the following products can be found in the following section: TRIPODS pg.61)

PTZ Surveillance Systems – Analog Integrated System

www.moogS3.com

EXO GeminEye Dual HD Camera System

IK10

EXO GeminEye

with Thermal Option

PRODUCT OVERVIEW

The IP-based EXO GeminEye High Denition (HD) Network Thermal and HD Visible Imaging System is the professional’s choice for capturing brilliant, 1080P full HD video in maritime, transportation, and other high risk applications. As the market presses for more technologically advanced imaging products, the environment these products function in grows increasingly hostile. The EXO GeminEye modular Pan / Tilt imaging system meets the growing demand for high-performance surveillance solutions.

Completely customizable, the EXO GeminEye consists of a modular system of imager blocks that can be easily adjusted to accommodate multiple congurations. The dual integrated Moog sensor system offers the best of both worlds for Day / Night, real-time surveillance. Employing 24/7, clear and accurate observation through difcult environmental challenges signicantly enhances detection, identication, and appropriate response to potential threats. The integration of various sensors into your surveillance system increases the level of intelligence available to your team.

PRODUCT SPECIFICATIONS

Available Features

• Cost effective, easy integration

• Detection in obscured environments

• 365/24/7 surveillance in challenging environments

• Scalable to augment existing systems

• Networked control

• Integrated H.264 and M-JPEG encoder with real

time streaming video

SPECIFICATIONS

Models Description

EXGVSHD-S13XXN EXO IP HD GeminEye - 1/2.8 CMOS Visible Camera Only

320 x 256 Resolution Thermal Models*

EXGVTSHD-S13XXN-F10F1NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 25mm thermal

EXGVTSHD-S13XXN-F10F9NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 35mm thermal

EXGVTSHD-S13XXN-F10F2NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 50mm thermal

EXGVTSHD-S13XXN-F10F10NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 60mm thermal

EXGVTSHD-S13XXN-F10F3NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 100mm thermal

EXGVTSHD-S13XXN-F10Z1NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 15-100mm thermal

640 x 480 Resolution Thermal Models*

EXGVTSHD-S13XXN-F11F1NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 25mm thermal

EXGVTSHD-S13XXN-F11F9NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 35mm thermal

EXGVTSHD-S13XXN-F11F2NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 50mm thermal

EXGVTSHD-S13XXN-F11F10NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 60mm thermal

EXGVTSHD-S13XXN-F11F3NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 100mm thermal

EXGVTSHD-S13XXN-F11Z1NF EXO IP HD GeminEye - 1/2.8 CMOS Visible and 15-100mm thermal

GENERAL

Input Voltage: 12 - 32Vdc

Surge Protection: Proprietary surge protection

Image Sensor: 1/2.8-type Exmor CMOS

Lens: 30x optical zoom, f=4.6mm (wide) to 138.0mm (tele)

Minimum Illumination: Color: 0.5 lux at 50 IRE F1.6 • B/W: 0.04 lux at 50 IRE F1.6

Shutter Speed: Automatic or user selectable

Pan / Tilt: Pan Speed: 0.25° - 100°/sec • Tilt Speed: 0.25° - 60°/sec

Repeatability: 0.25°

Horizontal Viewing Angle: 1080p mode 59.5 (wide end) to 2.1 (tele end)

Minimum Object Distance: 10mm (wide end) to 1,200mm (tele end)

Digital Zoom: 12x (360x with optical zoom)

*These products are subject to export control laws and regulations of the United States government and fall under the control jurisdiction of either ITAR or EAR regulations. Please contact our company Export Representative at +1-716-687-4930 for additional export information.

• Approx. 3.27 Megapixels daylight camera

• Quick change daylight and thermal camera modules

with true Plug and Play performance

• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API,

supported

• Edge recording (16GB micro SDHC Class 10 UHS-I)

PTZ Surveillance Systems – Network

www.moogS3.com

EXO Variable Near IR and White Light Illuminator

Variable Near IR and White

PRODUCT OVERVIEW

Moog has recently introduced a revolutionary step forward in PTZ technology. By combining state of the art Varifocal Illumination System (VIS) illuminators with the Moog GeminEye Modular Imaging System, the camera and illumination now zoom together for optimal image quality. This unique Imaging System was jointly designed to provide the quality, ruggedness, reliability, and performance customer have come to expect from all Moog products.

The varifocal illuminator in this system was designed for ultimate performance when combined with PTZs. Capable of synchronized zooming with the camera, VIS illuminators place light where you need it when you need it. When the camera is zoomed in by the operator or via a preset, the illuminator will also zoom, reaching an impressive 6 eld of illumination in white light and 9 in infrared. When the camera is zoomed out, these same illuminators will zoom out to a maximum of 70 in white light and 95 in infrared.

Using this advanced technology, the GeminEye Modular Imaging System is now capable of both infrared and white light. Simply select IR when covert operation is required, or white light when covert operation or color imagery is desired.

When paired with the rugged Moog GeminEye, the versatility and functionality of VIS illuminators created a new class of integrated illumination PTZ systems.

PRODUCT SPECIFICATIONS

Available Features

• Fully integrated with all VIS IR and white light illuminators, including new award-winning True Hybrid illuminators

• Supports presets, including IR or White Light selection and zoom position to best match camera eld of view

• Illuminators zoom in and out as the camera is zoomed in and out

IP67

IP66

• Continuously adjustable illumination angle eliminates hot spots and wasted light, maximizing video quality in all situations

VIS 80W Illumination Distance, Hybrid

400m

350m

300m

250m

200m

150m

100m

50m

0 10 20 30 40 50 60 70 80 90

Illumination Angle [degrees]

SPECIFICATIONS

Models Analog IP

GVIS-S11XXN-LU6-90: EXGVISHD-S13XXN-LU6-90-MWS:

IP Rating: IP66 water and dust protection Operating Temperature: VIS-1040: -40°C to 60°C Pan Range: Continuous (non-HD) / ± 180 (HD conguration) Tilt Range: ± 90° Motor: Stepper motor drive IP Rating: Meets IP67 requirements Maximum Dimensions: 253.1 x 467.2 x 215.3cm

•

GENERAL

•

VIS-1080: -40°C to 50°C

1312f

1148f

984f

820f

656f

492f

328f

164f

80W Cool White

40W Cool White

80W 850nm

40W 850nm

All data , including distances and

•

PTZ Surveillance Systems – Analog / Network

www.moogS3.com

Near IR Integrated Systems

PRODUCT OVERVIEW

The Moog engineered Near IR systems provide 365/24/7 visibility in low-light and night-time conditions. Through a combination of IR Illuminators and Day/Night sensors, our Near IR systems provide levels of recognition and identication that are unachievable with thermal sensors. Short, medium and long range systems push performance boundaries of illumination range, ensuring the highest level of surveillance is achieved.

PRODUCT SPECIFICATIONS

Available Features

•

Cost effective, easy integration

•

Offers 32 programmable preset locations

•

Ethernet or Serial Control options

Distances: 500 ft 1400 ft 3000 ft

Short Range:

Medium Range:

Long Range:

Categories 0.15 km

•

Re-programmable tours to accommodate specic surveillance requirements

•

Built to withstand extreme environments

•

Scalable to augment existing systems

SYSTEM RANGE PERFORMANCE

0.42 km 0.91 km

Key Applications Include:

•

Critical Infrastructure Protection

•

Perimeter Security

•

Oil & Gas Installations

•

Electrical Substation Installations

Model: GVIS-961-S09XXN-LUi8 • Description: GeminEye, 1/4” CCD camera; NIR illuminator (850 nm).

SHORT RANGE SPECIFICATIONS

Sensor

1/4” CCD 380,000

Size

Effective

Pixels

Visible Camera Lens

Digital

Zoom

12x (336x

with optical

zoom)

StableZoom Image Stabilization,

Digital Output (ITU-R BT656),

Enhancement, White Balance:

Key

Features

Sodium Vapor Lamp,

Temperature Readout, Color

Outdoor Auto Mode

Description Focus HFOV

Integrated 3.5 -

98mm, F1.35 - 3.7

IR Corrected

Autofocus

2.1° -

55.8°

Focal

Length

3.5 -

98mm

Illuminator

48W, 850 nm

NIR illuminator

20°x10° Field of Illumination

Model: PVIS-26100-90201-02192 • Description: QPT-35; 720p. w/ IPS (IP Streaming) video. NTSC/PAL for SD video. 1/3”; NIR illuminator (850 nm).

MEDIUM RANGE SPECIFICATIONS

Sensor

Size

1/3”

CMOS HD

Sesor

Visible Camera Lens

Active Pixels Resolution (H x V) Description Focus NFOV WFOV Min. Lux.

Sensitivity (3200 K, scene

reectivity 89%, F1.2)

Minimum illumination (30 IRE)

Color 0.017 lx (0.0017 fc)

Monochrome 0.0057 lx

(0.00057 fc)

1305 x 1049

720p HD 1280 x 720

480p SD Encoding:

704 x 480

8.6 - 154.0mm F2.5 - 360

IR Corrected

Autofocus 1.77° 58.3°

Illuminator

48W, 850 nm NIR illuminator 20°x10° Field

of Illumination

Model: PVIS-66100-90201-02191 Description: QPT-50, 7-66100-BGP; 720p/30 w/ IPS (IP Streaming) video. NTSC/PAL for SD video. 1/3”; 11M Candlepower Spotlight + 715 nm or 850 nm NIR lter.

LONG RANGE SPECIFICATIONS

Sensor

Size

1/3”

CMOS HD

Sesor

Visible Camera Lens

Active Pixels Resolution (H x V) Description Focus NFOV WFOV Min. Lux.

Sensitivity (3200 K, scene

reectivity 89%, F1.2)

Minimum illumination (30 IRE)

Color 0.017 lx (0.0017 fc)

Monochrome 0.0057 lx

(0.00057 fc)

1305 x 1049

720p HD 1280 x 720

480p SD Encoding:

704 x 480

8.6 - 154.0mm F2.5 - 360

IR Corrected

Autofocus 1.77° 58.3°

Spotlight

11M Candlepower + 715 or 850 nm

NIR lter

PTZ Surveillance Systems – Integrated Systems

www.moogS3.com

Mercury Camera System Series

Mercury Camera Series

PRODUCT OVERVIEW

Moog introduces the Mercury Positioner, ideal for mobile and xed payloads up to 75 lbs. The new Mercury Positioner is certied to hold payloads up to 50 lbs / mobile and 75 lbs / xed and withstands HMMWV shock and vibration standards, making it ideal for applications in harsh environments and rugged terrain.

PRODUCT SPECIFICATIONS

Available Features

• Meets NEMA Type 4 and IP66 standards

• Extremely ruggedized, built to withstand extreme environments

• Networked IP control, 2/4 channel available

• Continuous 360° rotation

• Networked IP control

• Stabilized conguration available

• MIL-STD-810, Salt / Fog

• Enclosure IP66

• Payload Weight – Fixed 75 lbs

• Payload Weight – Mobile 50 lbs

• Choice of camera systems

• Easy integration with open source protocol

IP66

MVTS-9LC225-90375-MWS Dual Visible/Thermal Camera System with 640 x 480 Thermal Imager 25-225mm with Continuous Zoom lens and Daylight Imager with 15-375mm lens

MVTS-9LC225-90750-MWS Dual Visible/Thermal Camera System with 640 x 480 Thermal Imager 25-225mm with Continuous Zoom lens and Daylight Imager with 30-750mm lens

Load Capacity:

Operating Voltage Range:

Operating Current:

Pan-Axis Range:

Pan-Axis Speed:

Tilt-Axis Range:

Tilt-Axis Speed:

Internal Heater:

Operating Temperature:

Feedback:

Repeatability:

Motor Type / Drive:

Communication to Pan & Tilt:

Control Protocol:

Connector Specications:

Load Connector Interfaces:

Weight:

Test Cable and Software:

Power Supply:

NEMA

TS2

CERTIFIED

Models Description

CAMERA SPECIFICATIONS

STANDARD PERFORMANCE

Mobile: 50 lbs balanced load • Fixed: 75 lbs balanced load

18 – 32 VDC

1.25 amp (steady state); 4.2 amp (both axes moving)

360° continuous rotation (slip ring)

0.05°/sec to 100°/sec

180° (±90°)

0.05°/sec to 100°/sec

Thermostatically controlled (32° on / 35° off)

-40°C to 70°C

Magnetic Encoders (0.01° readout)

0.05°

Stepper

IP and Serial (RS232 / 422 / 485)

Moog QuickSet PTCR-96 or Pelco D

25 Shell 43 Pin Base Connector

Mil-Spec 26-Soc, 16 Shell

44 lbs base unit, 53 lbs with wings

6 ft. test cable

Available upon request

PTZ Surveillance Systems – Pan & Tilt Positioners

www.moogS3.com

Single Visible Integrated Systems

Single Visible Integrated

PRODUCT OVERVIEW

Moog single visible integrated systems offer effective broad range surveillance solutions with unsurpassed reliability at an affordable price. Our strategy is to supply sensor solutions that are robust, reliable and highly supportable, and provide the best possible protection of your assets.

PRODUCT SPECIFICATIONS

Available Features

• Quick plug and play features

• Easily scalable to augment existing systems

• Field replaceable modules

• Individual remote-controlled cameras

• 32 programmable preset locations

• Programmable tours to accommodate specic

surveillance requirements

SPECIFICATIONS

System Part Numbers Visible Sensor R anges Camera Lens Focus

PVS-90098 Short 1/4"/ 768 x 494 5 - 98mm Auto 55.8 2.1 1.35 3.7 0.65 —

PVS-90122 Short 1/4"/ 768 x 494 3.4 - 122.4mm Auto 57.8 1.7 1.6 4.5 1.4 —

PVS-90240 Short 1/2"/ 768 x 494 12 - 240mm Motor Remote 35.3 1.5 1.5 360 0.03 0.004

PVS-90375 Medium 1/2"/ 768 x 494

PVS-90750 Long 1/2"/ 768 x 494

PVS-91500 Very Long 1/2"/ 768 x 494

375mm

f/2.3 - 360

750mm

f/4.6 - 720

1500mm

f/3.8 - 6000

Motor Remote 23.2 0.99 2.3 360 0.03 0.004

Motor Remote 11.8 0.5 4.6 720 0.03 0.004

Motor Remote 14.6 0.25 3.8 6000 0.03 0.004

HFOV F/# min lux (F/1.2)

WFOV NFOV WFOV NFOV Color B/W

• Networked control

• Ruggedized

• Built to withstand extreme environments

• Excellent performance in challenging terrains

• High quality, durable products

• Mobile applications available

Pan Speed/Tilt Speed

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

PTZ Surveillance Systems – Analog Integrated Camera

www.moogS3.com

Single Thermal Integrated Systems

Single Thermal Integrated

PRODUCT OVERVIEW

Integrated thermal imaging systems provide the ability to detect threats normally invisible to the naked eye. When you need to quickly detect intrusions before they occur, a thermal integrated system is your rst line of defense in asset protection. Thermal systems are ideal for detecting people, objects, and incidents in total darkness or challenging environmental situations.

PRODUCT SPECIFICATIONS

Available Features

System Part Numbers

PTS-9L025 LWIR, 17um, 25mm Fixed N/A 25 50 mK @ f/1.0

PTS-9L050 LWIR, 17um, 50mm Fixed N/A 12 50 mK @ f/1.0

PTS-9L100 LWIR, 17um, 100mm Fixed N/A 6.2 50 mK @ f/1.0

Positionable Single Thermal Imaging System Dual

Positionable Single Thermal Imaging System

Field of View (DFOV)

PTS-9M250

PTS-9M500

PTS-9M750

Continuous Zoom

PTS-9M275

PTS-9M490

PTS-9M735

PTS-9M11X

• Reliable, high level of accuracy

• Detection in obscured environments

• 365/24/7 surveillance

• Easily scalable to augment existing systems

• Network control

Camera Thermal: Vox Microbolometer

(LWIR) 7.5 – 13.5µm

Imager Thermal: InSb Cooled (MWIR)

DFOV 3.5 – 5µm

640x480, 15um,

50 / 250mm DFOV

640x480, 15um,

100 / 500mm DFOV

640x480, 15um,

100 / 750mm DFOV

Imager Thermal: InSb Cooled (MWIR)

Continuous Zoom

640x480, 15um,

22 - 275mm CZ

640x480, 15um,

39 - 490mm CZ

640x480, 15um,

59 - 735mm CZ

640x480, 15um, 88 - 1100mm CZ

SPECIFICATIONS

Focus

Motorized Remote 11 2.2 75mK @ f/1.0

Motorized Remote 5.5 1.1 75mK @ f/1.0

Motorized Remote 3.6 0.7 75mK @ f/1.0

Motorized Remote 25 2 75mK @ f/1.0

Motorized Remote 14.1 1.1 75mK @ f/1.0

Motorized Remote 9.4 0.75 75mK @ f/1.0

Motorized Remote 6.3 0.5 75mK @ f/1.0

HFOV

WFOV NFOV

• 32 programmable preset locations

• Programmable tours to accommodate specic

surveillance requirements

• Ruggedized systems built to withstand extreme

environments

Sensitivity NEdT

Pan Speed / Tilt Speed

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

.005 - 25˚/sec

.005 - 8˚/sec

PTZ Surveillance Systems – Analog Integrated Camera

www.moogS3.com

Dual Visible / Thermal Integrated Systems

Dual Visible / Thermal

PRODUCT OVERVIEW

Dual integrated sensor systems offer the best of both worlds for day/night, real-time surveillance. Employing 24/7, clear and accurate observation through difcult environmental challenges signicantly enhances detection and appropriate response to potential threats. The integration of various sensors into your surveillance system increases the level of intelligence available to your team.

PRODUCT SPECIFICATIONS

Available Features

Dual Visible /Thermal Vision System with Single

Field of View (SFOV) LWIR Thermal Camera

PVTS-90098-9L100 Short 1/4”/ 768x494 Integral 3.5 - 91mm Auto 42.2 1.6 1.6 3.8 2 — PVTS-90122-9L100 Short 1/4”/ 768x494 Integral 3.4 - 122.4mm Auto 57.8 1.7 1.6 4.5 1.4 —

Dual Visible /Thermal Vision System with Dual

Field of View (DFOV) MWIR Thermal Camera

PVTS-90240-9M250 Short 1/2”/ 768x494 12 - 240mm f/1.4 - 360 Motor Remote 35.3 1.5 1.5 360 1.4 — PVTS-90375-9M250 Medium 1/2”/ 768x494 15 - 375mm f/2.3 - 360 Motor Remote 23.2 0.99 2.3 360 0.03 0.004 PVTS-90750-9M250 Long 1/2”/ 768x494 30 - 750mm f/4.6 - 720 Motor Remote 11.8 0.5 4.6 720 0.03 0.004 PVTS-90750-9M500 Long 1/2”/ 768x494 30 - 750mm f/4.6 - 720 Motor Remote 11.8 0.5 4.6 720 0.03 0.004 PVTS-91500-9M500 Very Long 1/2”/ 768x494 12.5 - 1500mm f/3.8 - 6000 Motor Remote 14.6 0.25 3.8 6000 0.03 0.004 PVTS-91500-9M750 Very Long 1/2”/ 768x494 12.5 - 1500mm f/3.8 - 6000 Motor Remote 14.6 0.25 3.8 6000 0.03 0.004

Dual Visible /Thermal Vision System with

Continuous Zoom (CZ) MWIR Thermal Camera

PVTS-90750-9M490 Long 1/2”/ 768x494 30 - 750mm f/4.6 - 720 Motor Remote 11.8 0.5 4.6 720 0.03 0.004 PVTS-91500-9M735 Very Long 1/2”/ 768x494 12.5 - 1500mm f/3.8 - 6000 Motor Remote 14.6 0.25 3.8 6000 0.03 0.004 PVTS-91500-9M11X Very Long 1/2”/ 768x494 12.5 - 1500mm f/3.8 - 6000 Motor Remote 14.6 0.25 3.8 6000 0.03 0.004

Visible Range

• Cost effective, easy integration

• Detection in obscured environments

• 365/24/7 surveillance in challenging environments

• Scalable to augment existing systems

• Networked control

VISIBLE SENSOR SPECIFICATIONS

Camera (Visible) Lens Focus

• 32 programmable preset locations

• Programmable tours to accommodate specic

surveillance requirements

• Ruggedized systems built to withstand extreme

environments

HFOV F/# min lux (F/1.2)

WFOV NFOV WFOV NFOV

THERMAL SENSOR SPECIFICATIONS*

Dual Visible /Thermal Vision System with Single

Field of View (SFOV) LWIR Thermal Camera

PVTS-90098-9L100 Short 640x480, 17um, 100mm Fixed N/A 6.2 50 mK @ f/1.0 .005 - 50°/sec. / .005 - 12°/sec. PVTS-90122-9L100 Short 640x480, 17um, 100mm Fixed N/A 6.2 50 mK @ f/1.0 .005 - 50°/sec. / .005 - 12°/sec.

Dual Visible /Thermal Vision System with Dual

Field of View (DFOV) MWIR Thermal Camera

PVTS-90240-9M250 Short/Medium 640x480, 15um, 50 / 250mm DFOV Motorized Remote 11 2.2 75 mK @ f/1.0 .005 - 50°/sec. / .005 - 12°/sec. PVTS-90375-9M250 Medium 640x480, 15um, 50 / 250mm DFOV Motorized Remote 11 2.2 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec. PVTS-90750-9M250 Medium 640x480, 15um, 50 / 250mm DFOV Motorized Remote 5.5 2.2 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec. PVTS-90750-9M500 Long 640x480, 15um, 100 / 500mm DFOV Motorized Remote 5.5 1.1 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec. PVTS-91500-9M500 Long 640x480, 15um, 100 / 500mm DFOV Motorized Remote 5.5 1.1 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec. PVTS-91500-9M750 Very Long 640x480, 15um, 100 / 750mm DFOV Motorized Remote 3.6 0.7 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec.

Dual Visible /Thermal Vision System with

Continuous Zoom (CZ) MWIR Thermal Camera

PVTS-90750-9M490 Very Long 640x480, 15um, 39 - 490mm CZ Motorized Remote 14.1 1.1 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec. PVTS-91500-9M735 Very Long 640x480, 15um, 59 - 735mm CZ Motorized Remote 9.4 0.75 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec. PVTS-91500-9M11X Very Long 640x480, 15um, 88 - 1100mm CZ Motorized Remote 6.3 0.5 75 mK @ f/1.0 .005 - 25°/sec. / .005 - 8°/sec.

* These products are subject to export control laws and regulations of the United States government and fall under the control jurisdiction of either ITAR or EAR regulations. Please contact our company Export Representative

at +1-716-687-4930 for additional export information.

PTZ Surveillance Systems – Analog Integrated Camera

Thermal

Range

Camera Thermal: Microbolometer

Un-Cooled (LWIR / 7.5 - 13.5)

Camera Thermal: InSb Cooled (MWIR / 3.4 - 5um)

DFOV

Continuous Zoom

Focus

HFOV

WFOV NFOV

NEdT Pan Speed/ Tilt Speed

www.moogS3.com

PTZ Controllers and Interfaces

PTZ Controllers

Moog S3 analog and digital interface controllers are designed to access and control all functions of our line of Pan and Tilt positioners.

Our digital controllers can also interface with many state-of-the-art sensor payloads. The Unicom of serial digital RS-232 / RS-422 / RS-485 based positioners including Ethernet (IP) networked systems.

The Unicom / RS-422 based positioners for less complex and lower cost applications.

We also provide advanced video tracking systems designed to allow you to zoom in and precisely track distant boats, aircraft, vehicles or people.

When your applications require consolidated and versatile control, Moog provides a state-of-the-art Graphical User Interface for our IC products. Highly customizable and expandable, our GUI provides remote access to positioners and camera feeds, with real-time operation and video feed at the convenience of a centralized location.

LT was designed specifically to control our GeminEye line of positioners, but also can control our serial digital RS-232

is designed to control our full line

Sensor and Surveillance Systems

Precision Control and Feedback

CONTROLLERS GUIs

Analog / Pan & Tilt Controller ......................................................... 28

QuickTrac & Unicom / Unicom LT ................................................... 29

Supported Products (additional product can be found throughout)

PTZ Controllers and Interfaces

Moog PTZ Controller ..................................................................... 30

Video Tracking Systems ................................................................. 31

www.moogS3.com

Analog / Pan & Tilt Controller

PRODUCT OVERVIEW

Moog offers a variety of controllers for analog and IC systems.

Analog Standard analog controllers are a cost-efcient solution for primarily AC and 115Vdc powered analog pan and tilts. Low voltage DC solutions are also available.

QuickTrac pan and tilts.

IC Unicom communication. If networked pan and tilt or system control is desirable, use the Unicom Controller.

Part Number Description Pan and Tilt Joystick

C124212 Controller, 12Vdc/12Vdc Prop. Speed, No Meters 20/50 Joystick 1/2 Rack 17 - Pin 12Vdc 12 – – –

C151111 Controller 115Vac/24Vac, Non-variable Spd. 20/90 Joystick Tabletop 17 - Pin 115 / 120Vac – 24

C173431 Controller 115-240Vac/24/120Vac, Non-variable Spd. ,Meters 200/500 Joystick Full 17 - Pin 120 / 240Vac – 24 / 120 X X

C162421 Controller 240Vac/115Vac, Non-variable Spd., A/Z Meters 90/130 Joystick Full 17 - Pin 240Vac – 115 X X

C173421 Controller 120-240Vac/24 / 120Vac, Non variable Spd.A/Z Meters 90/130 Joystick Full 17 - Pin 120 / 240Vac – 24 / 120 X X

C167212 Controller 220-240Vac/115Vdc, Prop Speed, No Meters 90/130 Joystick Plug 1/2 Rack 17 - Pin 220 - 240Vdc 115 –

C157422 Controller 120Vac/115Vdc, Prop Speed, A/Z Meters 90/130 Joystick Full 17 - Pin 120Vdc 115 – X X

C167422 Controller 220-240Vac/115Vdc, Prop Speed, A/Z Meters 90/130 Joystick Full 17 - Pin 220 - 240Vdc 115 – X X

C167432 Controller 220-240Vac/115Vdc, Prop Speed, A/Z Meters 200/500 Joystick Full 17 - Pin 220 - 240Vdc 115 – X X

C177212 Controller 115/220-240Vac/115Vdc, Prop Speed 200/500 Joystick 1/2 Rack 17 - Pin 115 / 220-240Vdc 115 –

C177422 Controller 120Vac/115Vdc, Prop Speed, A/Z Meters 90/130 Joystick Full 17 - Pin 115 / 220Vdc 115 – X X

C177432 Controller 120Vac/115Vdc, Prop Speed, A/Z Meters 200/500 Joystick Full 17 - Pin 115 / 220Vdc 115 – X X

Controllers are the versatile solutions from Moog for low voltage (12 and 24Vdc) powered analog

-LT Controllers are the cost-efcient solution for primarily one-to-one pan and tilt and payload

ANALOG CONTROLLERS SPECIFICATIONS

Output Meters

DC AC Azimuth Elevation

12Vdc Output

24Vac Output

115Vdc Output

Rack-

Connector Voltage Input

mount

ANALOG PAN AND TILT TO CONTROLLER CABLES SPECIFICATIONS

Part Number Description Pan and Tilt

6-19247-1.5 Cable, Analog, w/ 17 Socket / Pin Plugs, , 1.5ft. 20/50/90/130/200 17- Socket 17 - Pin 115 115 1.5, 10, 25, 100, 25, 100, 125, 150, 200, 250

PTZ Controllers and Interfaces

Connector Voltage (Max.)

Pan and Tilt Controller DC AC

Standard Lengths (in feet)

www.moogS3.com

QuickTrac & Unicom / Unicom LT

QuickTrac & Unicom

QUICK TRAC® CONTROLLERS SPECIFICATIONS

Part Number Description Pan and Tilt Joystick Rackmount Connector Voltage Input

12Vdc Output

C102 Controller 12Vdc/12Vdc Prop Speed 20/50/90 Joystick Plug Full / 1/2 Rack 17 - Pin 12Vdc 12 NA

C107 Controller 12Vdc/12Vdc Prop Speed A/Z Meters 20/50/90 Joystick Plug Full / 1/2 Rack 17 - Pin 12Vdc 12 NA X X

C322 Controller 115Vac/12Vdc Prop Speed 20/50/90 Joystick Plug Full / 1/2 Rack 17 - Pin 115Vdc 12 NA

C327 Controller 115Vac/12Vdc Prop Speed 20/50/90 Joystick Plug Full / 1/2 Rack 17 - Pin 115Vdc 12 NA X X

C422 Controller 230Vac/12Vdc Prop Speed 20/50/90 Joystick Plug Full / 1/2 Rack 17 - Pin 230Vdc 12 NA

C427 Controller 230Vac/12Vdc Prop Speed A/Z Meters 20/50/90 Joystick Plug Full / 1/2 Rack 17 - Pin 230Vdc 12 NA X X

24Vdc Output

C202 Controller 24Vdc/24Vdc Prop Speed 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 24Vdc 24 NA

C207 Controller 24Vdc/24Vdc Prop Speed A/Z Meters 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 24Vdc 24 NA X X

C207HT Controller 24Vdc/24Vdc Prop Speed A/Z Meters 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 24Vdc 24 NA X X

C332 Controller 115Vac/24Vdc Prop Speed 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 115Vdc 24 NA

C337 Controller 115Vac/24Vdc Prop Speed A/Z Meters 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 115Vdc 24 NA X X

C337HT Controller 115Vac/24Vdc Prop Speed A/Z Meters 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 115Vdc 24 NA X X

C432 Controller 230Vac/24Vdc Prop Speed 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 230Vdc 24 NA

C437 Controller 230Vac/24Vdc Prop Speed A/Z Meters 20/50/90/130 Joystick Plug Full / 1/2 Rack 17 - Pin 230Vdc 24 NA X X

QUICK TRAC® CONTROLLERS ACCESSORIES

Part Number Description

CA100 Full Rack Kit

CA101 Half Rack Kit

CA102 Joystick Remote with 15 ft. Cable

CA102-30 Joystick Remote with 30 ft. Cable

CA112 Joystick Remote with 15 ft. Cable w/ Mil Spec Connector

Output Meters

DC AC Azimuth Elevation

PRODUCT OVERVIEW

The Unicom and Unicom LT digital interface tabletop controllers are designed to access and control all functions of Moog Pan and Tilt Postioners including many state-of-the-art sensor payloads. The

UNICOM

Unicom is designed to control the full line of serial digital RS-232 / RS-422 / RS-485 based positioners including Ethernet (IP) networked systems. The Unicom LT was designed specically to control the GeminEye line of positioners, but also can control Moog serial digital RS-232 / RS-422 / RS-485 based positioners for less complex and lower cost applications.

PRODUCT SPECIFICATIONS

Unicom

• Proportional Joystick with high speed or

precision movement for pan and tilt movement

• 20 character by-line LCD display screen

• Control and program of presets and tours

• Rugged metal weatherproof chassis

UNICOM LT

• RJ45 Connector for Ethernet 10 / 100

Base T interface

IC CONTROLLERS SPECIFICATIONS

Part Number Description Control Interface Applicable Models Touchscreen Compatable

Unicom

CLT-1000 CONTROLLER JOYSTICK - UNICOM LT RS-232, RS-422, RS-485 GeminEye, QPT- 20,50,90,200,500,QMP,QMP-R NO

CLT-1000R CONTROLLER JOYSTICK - UNICOM LT Ruggedized RS-232, RS-422, RS-485 GeminEye, QPT- 20,50,90,200,500,QMP,QMP-R NO

C-JCC-116-NL CONTROLLER JOYSTICK - UNICOM Ruggedized RS-232, RS-422, RS-485, IP (TCP-IP) GeminEye, QPT-20,50,90,200,500,QMP,QMP-R YES

Unicom

Unicom LT

• 9-32Vdc Power input

• 120Vac wall transformer

• Sensor compatibility

• Manual control of zoom, focus and

iris commands

• Auto control of focus and iris commands

PTZ Controllers and Interfaces

www.moogS3.com

Moog PTZ Controller

GRAPHICAL USER INTERFACE PRODUCT OVERVIEW

When your applications require consolidated and versatile control, Moog provides a state-of-the-art Graphical User Interface for IC products. Highly customizable and expandable, our GUI provides remote access to positioners and camera feeds, with real-time operation and video feed at the convenience of a centralized location.

PRODUCT SPECIFICATIONS

Available Features

• Full ‘Node‘ Control

• Pan / Tilt Control

• Pan / Tilt Setting and Conguration

• Camera and Lens Control

• Video display of multiple streaming video feeds (**NOTE: Video display is available on Windows-based

installations only at this time)

• Tours managed in the application and Tours managed in the pan / tilt

• User Congurable Look and Feel

• User selectable views

• User selectable colors, fonts, and font sizes

• User denable layout

GUI SPECIFICATIONS

Part Number Description

S-11000 Moog Graphical User Interface

PTZ Controllers and Interfaces

www.moogS3.com

Video Tracking Systems

PRODUCT OVERVIEW

We provide a multitude of advanced video tracking techniques designed to allow you to zoom in and precisely track distant boats, aircraft, vehicles or people. Examples of the tracking techniques include traditional contrast and correlation algorithms, and specially designed algorithms for tracking boats on the water and airplanes in the sky. In all cases, the objective is to zoom in and automatically follow the object of interest precisely.

MULTI-FUNCTION UNIT PROVIDES THE FOLLOWING CAPABILITIES:

• Precision video tracking (on switchable Visible or Thermal video signals)

• AC-to-DC power converter for 24Vdc @ 20 amps (Max.) for Pan / Tilt / Payload power

• Video over IP for up to 4 video signals

• IP control data interfacing to Moog Pan / Tilt based surveillance nodes

• Serial interface for: pan/tilt, visible camera, thermal imager, and other optional payloads

VIDEO TRACKING ALGORITHMS

• Hottest Spot

• Dynamic Centroid

• Dynamic Correlation

• Ground Vehicle / Boat Tracking

• Ground to Air/Air to Ground Tracking

• Scene Lock

• Threshold Tracking

• Motion Tracking

• Motion on Motion Tracking

OPTIONAL FEATURES FOR MARITIME APPLICATIONS:

• Rugged Joystick Controller: Splash proof joystick controller (dash-mount or handheld

models available)

• Radar Slew-to Cue: Automatically slews the camera to marine radar contacts (ARPA

targets).

• Gyro Stabilization: 2-axis stabilization maintains a target in a 3 degree FOV image

while the host vessel undergoes up to +/- 20 degrees of pitch/roll motion and 360 degrees of yaw motion.

PAN / TILT NODE INTERFACE

DC Output Power / Video / Serial Data Control Connector:

• Mil – Spec Receptacle, 43 Socket, 28 Shell -CT2-28-21-SS provides interfacing to

the following:

– Dual NTSC / Pal input from video sensors. (switchable to provide tracking mode in

visible or thermal video)

– Pan/Tilt Control (RS-422) – Individual camera (or other payload) serial data control (RS-422)

• 24Vdc power for Pan / Tilt node operation

• Control / Video Data Network Interface Mil-Spec RJ45 Receptacle for IP Control, Video

Data, and Video Tracking Communication to Control / Monitor site Local Video and Serial Connections Two local video server input (BNC) connections. Interface for local RS-422 control communication (Mil-Spec receptacle, 15 socket, 14 Shell) Environmental

• Designed for IP66 use

• Temp Range: -15°C to 55°C (Storage); -15°C to 40°C (Operating)

PTZ Controllers and Interfaces

www.moogS3.com

Pan & Tilt Positioners

Sensor and Surveillance Systems

Rugged and Durable Sensor Positioning

PAN & TILT POSITIONERS

Pan and Tilt Conguration .............................................................. 33

QPT-20 IC Series .......................................................................... 34

QPT-35 IC Series .......................................................................... 35

QPT-50 IC Series .......................................................................... 36

QPT-90 IC Series .......................................................................... 37

QPT-130 IC Series ........................................................................ 38

Available accessories can be found in the following sections: Accessories, and Power and Wireless.

QPT-200 and 500 IC Series ........................................................... 39

Analog Pan / Tilt Series ................................................................ 40

QPT-RF Series .............................................................................. 41

Mercury Series ............................................................................. 42

Taurus/Taurus-R Series ................................................................. 43

Pan & Tilt Positioners

www.moogS3.com

Pan and Tilt Conguration

PAN AND TILT CONFIGURATIONS

Moog pan and tilt models have been divided into several basic congurations:

1. Analog

2. IC: Integrated Control

3. ICM: Integrated Control Marine

4. ICMS: Integrated Control Marine Sentry

5. ICM – RF: Integrated Control Marine Radio Frequency

6. ICMS – RF: Integrated Control Marine Sentry Radio Frequency

Analog: All electrical power is delivered from the controller almost directly to the pan and tilt axis motors. There is one motor for each axis.

IC: Integrated Control (IC) includes electrical drivers from external controllers to inside the pan and tilt.

Marine: Pan and tilts are housed in rugged, welded, sealed enclosures that increase the range of its use to extreme and challenging environments. They are designed to

be used primarily in coastal, marine, frigid, humid, dirty, sandy, and salty atmospheres. (Note: Marine versions of the QPT-20 use extruded aluminum housings.)

Sentry: The Sentry designation refers to the use of higher reliability stepper motor technology. Stepper motor drives are used for applications where constant velocity, higher dynamic range in rotational speed, torque, and incremental movement capability are required over that of the basic brush motor units.

RF: These units provide a means to pass RF signals through the body of the pan and tilt for continuous rotation applications.

PAN AND TILT WIRING AND CABLE CONFIGURATIONS

Formed Tabletop (FT): Basic tabletop; no payload interconnections going into or out of the pan and tilt to the payload.

Formed Tilt A (FTA): Formed tabletop with a single Mil-Spec I/O connector port located at the tilt axis. Pre-wired internal connections to this port allow the payload to

interface with the power, serial control, lens control, A/D conversion, and capabilities of the pan and tilt.

Formed Tilt B (FTB): Formed tabletop with Mil-Spec I/O connector port located at the tilt axis. Pre-wired I/O connections to this connector go directly to the base connector. This allows the option to connect directly to the payload.

Universal: Wiring interface design incorporates multiple Mil-Spec connectors on the tabletop pre-wired for data, power and sensor control.

Single Ended Cables (SE): This cable conguration extends directly from the pan and tilt to the control point without any breakouts when the controller, power supply, and

video interfaces are co-located at the same point.

Bifurcated Cables (Bi): This conguration takes into consideration the fact that DC power, required by our IC based units, cannot be located as far away from the pan and tilt as a control site can. Serially controlled pan and tilts, over copper wire, can be located as far as 4,000 ft. away using RS-422 / 485 formats. Ethernet based systems can be located up to 328 ft. away without a switch.

TESTED AND CERTIFIED

Moog products have been qualied to the following performance levels:

Product

GeminEye 0.25 deg Passed Passed Passed Passed Passed (8 lbs) Passed (8 lbs)

Apollo Class 0.05 deg Passed Passed Passed Passed Passed (50 lbs) Passed (50 lbs)

QPT-90 0.05 deg Passed Passed Passed Passed Passed (90 lbs) Passed (90 lbs)

QMP-R 0.05 deg Qualied by Similarity Passed Passed Passed Passed (150 lbs) Passed (150 lbs)

Abbreviated list of qualied products. Contact your sales rep for a full list.

Repeatability

(Line of Sight)

Salt Spray Testing

MIL-STD-810F

Sand and Dust

Penetration (IP 6X)

Water Spray Penetration

(IP X6)

Temp Range

(Up to -40°C)

Vibration

(HMMWV)

AVAILABLE SYSTEM COLORS – STANDARD

Marine White – MWS*

* Unless otherwise noted MWS is the default nish # Federal Standard 595B Contact your sales rep for custom nishes and pricing

Pan & Tilt Positioners

Marine Navy Gray – MNG Flat Black – FB

37030 # CARC Black – CBLK

Unless Otherwise Noted, product falls under the jurisdiction of the United States Government under the EAR (Export Administration Regulations) as EAR-99. Please contact our company Export Representative at +1-716-687-4930 for additional export information.

Desert Tan – BGP 33446 # CARC – Desert Tan – BGC

Olive Drab – OD 34084 # CARC Green – GRN

www.moogS3.com

Shock

(HMMWV)

QPT-20 IC Series

PRODUCT OVERVIEW

The QPT-20 Series of pan and tilts are rugged and durable enough for virtually any environment, including port surveillance and mobile vehicle vision systems. The QPT-20 can handle payloads from 8 – 20 lb-ft, and provides tabletop and/or tilt axis load mounting for multiple sensor array applications. Digital Serial Integrated Control (IC) units communicate via network interface or through a dedicated controller (e.g. UniCom

PRODUCT SPECIFICATIONS

Available Features

• ICM congurations – 8 lb-ft (tilt) lifting torque

• ICMS congurations – 20 lb-ft (tilt) lifting torque

• Digital Serial Integrated Control (IC) models

• Mounting platforms include plain formed tabletop

and tabletop with single tilt-axis connector

• Internal wire tabletop for pass-through or IC sensor

wiring on certain models

• Fixed, Inverted, or Mobile Installations

Standard Conguration

• Mil-Spec Connectors

• Aluminum housings and hardened steel gearing

for durability in harsh environments

• Marine conguration that meets IP66 standard

• Connector (base): 32-Pin

• Connector (tilt axis): 26-Soc

IP66

Sensor Integration

• Multi-Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

• Communication antennas

SPECIFICATIONS

Part

Number

7-2200A ICM FT-A 12 Serial / IP PTCR-20/Pelco D 1 - 14°/ sec. 1 - 5°/ sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-2200B ICM FT-B 12 Serial / IP PTCR-20/Pelco D 1 - 14°/ sec. 1 - 5°/ sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-22HSA ICM HS FT-A 24 Serial / IP PTCR-20/Pelco D 1 - 30°/ sec. 1 - 12°/ sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-22HSB ICM HS FT-B 24 Serial / IP PTCR-20/Pelco D 1 - 30°/ sec. 1 - 12°/ sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-2300A ICM CR FT-A 12 Serial / IP PTCR-20/Pelco D 1 - 14°/ sec. 1 - 5°/ sec. Continuous 180°(± 90°) 0.25°

7-2300B ICM CR FT-B 12 Serial / IP PTCR-20/Pelco D 1 - 14°/ sec. 1 - 5°/ sec. Continuous 180°(± 90°) 0.25°

7-23HSA ICM CR HS FT-A 24 Serial / IP PTCR-20/Pelco D 1 - 30°/ sec. 1 - 12°/ sec. Continuous 180°(± 90°) 0.25°

7-23HSB ICM CR HS FT-B 24 Serial / IP PTCR-20/Pelco D 1 - 30°/ sec. 1 - 12°/ sec. Continuous 180°(± 90°) 0.25°

7-2500A ICMS CR FT-A 12 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 4°/sec. Continuous 180°(± 90°) 0.05°

7-2500B ICMS CR FT-B 12 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 4°/sec. Continuous 180°(± 90°) 0.05°

7-25HSA ICMS CR HS FT-A 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-25HSB ICMS CR HS FT-B 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

ICM - Marine / Brush Motor, ICMS - Marine Sentry (Stepper), CR - Continuous. Rotation, HS - High Speed Serial: RS-232, RS-422, IP: Ethernet TCP/IP FT – Formed Tabletop * At stated load capacity and nominal voltage

Conguration

Load Mount/

Interface

Nominal Voltage

Vdc

Communication

Interface

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan and Tilt

Pan & Tilt Positioners

www.moogS3.com

QPT-35 IC Series

PRODUCT OVERVIEW

The QPT-35 provides rugged, durable performance for short to mid-range imaging applications. It is also ideal for positioning smaller antennae in almost any environment. The QPT-35 excels in operations where situational awareness is the key to success.

The QPT-35 can support both single and dual payloads. Its high payload to positioner weight ratio of more than 3:1 for xed installation optimizes the efciency of employing a system. It delivers great pointing repeatability to less than 0.05 degrees. The QPT-35 is also designed and tested for mobile use, making it one the most well rounded products in our extensive catalog.

PRODUCT SPECIFICATIONS

Available Features

Standard Conguration

• ICMS congurations – 35 lb-ft (tilt) lifting torque

• Digital Serial Integrated Control (IC) models

• Mounting platforms include plain formed tabletop

with dual tilt-axis connectors.

• Fixed, Inverted, or Mobile Installations

• Mil-Spec Connectors

• Tough metal housing and gearing for durability in

harsh environments

• Marine conguration that meets IP66 standard

• Connector (base): 28-Pin

• Connector (tilt axis): One 23-soc and one 26-soc

Sensor Integration

• Multi-Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

• Communication antennas

IP66

SPECIFICATIONS

Part

Number

7-26000 ICMS Universal 24 Serial / IP PTCR-96/Pelco D 0.005 - 20°/ sec. 0.005 - 5°/ sec. CR 180°(± 90°) 0.05°

ICM - Marine / Brush Motor, ICMS - Marine Sentry (Stepper), CR - Continuous Rotation, HS - High Speed Serial: RS-232, RS-422, IP: Ethernet TCP/IP FT – Formed Tabletop * At stated load capacity and nominal voltage

Conguration

Load Mount/

Interface

Nominal Voltage

Vdc

Communication

Interface

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan and Tilt

Pan & Tilt Positioners

www.moogS3.com

QPT-50 IC Series

PRODUCT OVERVIEW

The QPT-50 Series of pan and tilts are rugged and durable for virtually any environment. The QPT-50 can handle payloads up to 50 lb-ft of torque making it suitable for a wide range of sensors.

Integrated Control (IC) units communicate via networked PC or through a separate controller. IC units feature integrated dual sensor serial control, lens drive, and power supply interface, making sensor integration quick and easy. The Sentry line takes our products to the next level by utilizing stepper motor technology into the design for more precise accuracy and broader speed control.

PRODUCT SPECIFICATIONS

Available Features

• Payloads up to 50 lb-ft (67.8 Nm)

Apollo® Series

• Digital Serial Integrated Control (IC) models

• Mounting platforms include formed tabletop with

single tilt-axis connector and 4 connector Universal models

• Internal wire tabletop for pass-through or IC sensor

wiring on certain models

• Fixed, inverted or mobile installations

• Mil-Spec connectors

• Tough metal housing and gearing for durability in

harsh environments

• Marine conguration that meets IP66 standard

• Models available with RF pass-through connectivity

(RF rotary joint, 1 and 2 channels)

• Apollo Series meets IP67 standard

• Pressurized housing available with formed

tabletop models

• Connector (base): 43-Pin

• Connector (tilt axis): 26-Soc (1 or 4)

Sensor Integration

• Multi-Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

• Communication antennas

• Acoustic devices

Standard Conguration

IP67

ICM - Marine / Brush Motor, ICMS - Marine Sentry (Stepper), CR - Continuous Rotation, HS - High Speed Serial: RS-232, RS-422, IP: Ethernet TCP/IP * At stated load capacity and nominal voltage FT – Formed Tabletop

IP66

SPECIFICATIONS

Part

Number

7-6100A IC FT-A 24 Serial / IP PTCR-20/Pelco D 1 - 25°/sec. 0.3 - 7°/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-6100B IC FT-B 24 Serial / IP PTCR-20/Pelco D 1 - 25°/sec. 0.3 - 7°/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-6200A ICS FT-A 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. 435°(± 217.5°) 180°(± 90°) 0.1°

7-6200B ICS FT-B 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. 435°(± 217.5°) 180°(± 90°) 0.1°

7-6300A ICS CR FT-A 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.1°

7-6300B ICS CR FT-B 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.1°

7-6600A ICMS CR Apollo FT-A 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-6600B ICMS CR Apollo FT-B 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-66000 ICMS CR Apollo Universal 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-66480 ICMS CR HS Apollo Universal 48 Serial / IP PTCR-96/Pelco D .005 - 60°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

Conguration

Load Mount/

Interface

Nominal Voltage

Vdc

Communication

Interface

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan and Tilt

Pan & Tilt Positioners

www.moogS3.com

QPT-90 IC Series

PRODUCT OVERVIEW

The QPT-90 Series of pan and tilts are a high performance and versatile platform designed for a wide variety of positioning and sensor support applications. The QPT-90 supports payloads requiring 90 lb-ft of torque. Integrated Control processor (IC) units feature dual sensor serial control, lens drive, and power supply interfaces, making sensor integrations quick and easy. Serial IP units communicate via networked communications or dedicated joystick controller (Unicom

The Sentry line takes our products to the next level by integrating stepper motors into the design for higher precision movements and broader speed control. Universal congurations provide internal and external payload interfacing. Our RF units provide one to three pass-through channels for up to 18GHz bandwidth performance.

PRODUCT SPECIFICATIONS

Available Features

• Payloads up to 90 lb-ft (122 Nm)

ICMS Model (Universal Shown)

• Digital Serial Integrated Control (IC) models

• Mounting platforms include formed tabletop

with single tilt-axis connector and 4 connector Universal models

• Internal wire tabletop for IC or pass-through

sensor wiring

• Fixed, inverted or mobile installations

• Mil-Spec connectors

• Tough metal housing and gearing for durability

in harsh environments

• Marine conguration that meets IP67 standard

• Models available with RF pass-through connectivity

(RF rotary joint, 1-3 channels)

controller).

• Thermostatically controlled heaters standard

• Connector (base): 43-Pin

• Connector (tilt axis): 26-Soc (1 or 4)

Sensor Integration

• Multi-Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

• Communication antennas

• Acoustic devices

Standard Conguration (IC)

IP67

SPECIFICATIONS

Part

Number

7-7400A IC FT-A 24 Serial / IP PTCR-20/Pelco D 1 - 8°/sec. 1 - 4.5 °/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-7400B IC FT-B 24 Serial / IP PTCR-20/Pelco D 1 - 8°/sec. 1 - 4.5 °/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-7500A ICM FT-A 24 Serial / IP PTCR-20/Pelco D 1 - 8°/sec. 1 - 4.5 °/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-7500B ICM FT-B 24 Serial / IP PTCR-20/Pelco D 1 - 8°/sec. 1 - 4.5 °/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-7600A ICMS FT-A 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. 435°(± 217.5°) 180°(± 90°) 0.05°

7-7600B ICMS FT-B 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. 435°(± 217.5°) 180°(± 90°) 0.05°

7-76000 ICMS Universal 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. 435°(± 217.5°) 180°(± 90°) 0.05°

7-7700A ICMS CR FT-A 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-7700B ICMS CR FT-B 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-77000 ICMS CR Universal 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-77480 ICMS CR HS Universal 48 Serial / IP PTCR-96/Pelco D .005 - 45°/sec. .005 - 14°/sec. Continuous 180°(± 90°) 0.05°

Conguration

Load Mount/

Interface

Nominal Voltage

Vdc

Communication

Interface

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan and Tilt

Pan & Tilt Positioners

www.moogS3.com

QPT-130 IC Series

PRODUCT OVERVIEW

The QPT-130 Series of pan and tilts are built to withstand harsh environments, and can hold up to 130 lb-ft of torque.

PRODUCT SPECIFICATIONS

Available Features

• Payloads up to 130 lb-ft

• Digital Serial Integrated Control (IC) models

• Mounting platform is formed tabletop

• Fixed, inverted or mobile installations

• Mil-Spec connectors

• Tough metal housing and gearing for durability

in harsh environments

• Thermostatically controlled heaters standard

• Connector (base): 17-Pin

• Stainless steel base

• Heavy-duty tabletop

Sensor Integration

• Multi-Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

• Communication antennas

• Acoustic devices

Standard Conguration (IC)

SPECIFICATIONS

Part

Number

7-45510A IC FT 24 Serial PTCR-20 1 - 8°/sec. 1 - 4.5 °/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-45514 IC FT 24 Serial PTCR-20 1 - 8°/sec. 2 - 8 °/sec. 435°(± 217.5°) 180°(± 90°) 0.25°

7-55510 IC FT 24 Serial PTCR-90 1 - 8°/sec. 1 - 3 °/sec. 435°(± 217.5°) 180°(± 90°) 0.05°

IC - Classic / Brush Motor, ICS - Classic / Sentry (Stepper) Serial: RS-232, RS-422, IP: Ethernet TCP/IP FT – Formed Tabletop * At stated load capacity and nominal voltage

Conguration

Load Mount/

Interface

Nominal Voltage

Vdc

Communication

Interface

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan and Tilt

Pan & Tilt Positioners

www.moogS3.com

QPT-200 and 500 IC Series

PRODUCT OVERVIEW

The QPT 200 and 500 Series of pan and tilts are rugged and durable enough for virtually any environment. The QPT-200 and QPT-500 can handle payloads up to 200 or 500 lb-ft of torque, respectively, making each suitable for a wide range of sensors.

Integrated Control (IC) units can communicate via networked PC or separate controller. The Sentry line takes our products to the next level by integrating stepper motors into the design for higher accuracy and speed control.

PRODUCT SPECIFICATIONS

Available Features

200/500 Series ICMS Model

• Heavy duty payloads up to 200 and 500 lb-ft

• Digital Serial Integrated Control (IC) models

• Internal wire tabletop for pass-through or IC sensor

wiring on certain models

• Fixed, inverted or mobile installations

• Mil-Spec connectors

• Tough metal housing and gearing for durability in

harsh environments

• Marine conguration that meets IP67 standard

• Models available with RF pass-through connectivity

(RF rotary joint, 1-3 channels)

• Connector (base): 43-Pin

• Connector (tilt axis): 26-Soc (1 or 4)

Sensor Integration

• Multi-Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

• Communication antennas

• Acoustic devices

IP67

SPECIFICATIONS

Part

Number

7-4100A ICS FT-A 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4100B ICS FT-B 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4200A ICMS FT-A 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4200B ICMS FT-B 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-42000 ICMS Universal 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4300A ICMS CR FT-A 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-4300B ICMS CR FT-B 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-43000 ICMS CR Universal 24 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-4400A ICS FT-A 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4400B ICS FT-B 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4500A ICMS FT-A 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4500B ICMS FT-B 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-45000 ICMS Universal 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. 420°(± 210°) 180°(± 90°) 0.1°

7-4600A ICMS CR FT-A 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-4600B ICMS CR FT-B 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-46000 ICMS CR Universal 48 Serial / IP PTCR-96/Pelco D .001 - 20°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

Conguration

Load Mount/

Interface

Nominal Voltage

Vdc

Communication

Interface

Control

Protocol

QPT-200 IC Series

QPT-500 IC Series

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan & Tilt

Pan & Tilt Positioners

www.moogS3.com

Analog Pan / Tilt Series

PRODUCT OVERVIEW

The Moog line of analog pan and tilts are ideal for applications where electronic control is not needed or available. The analog series offers a cost-efcient solution to rst responders, emergency and broadcast vehicles.

We offer a full range of rack-mountable controllers to complement all analog series pan and tilts.

PRODUCT SPECIFICATIONS

Available Features

• All AC models have a 14-pin base connector

• All Vdc models have a 17-pin base connector

• All analog units are formed tabletop

QPT-90 (Shown)

SPECIFICATIONS

Part

Number

7-07000-ODD Analog HS Pots, Heater C207, C207HT, C337, C337HT, C437 24

7-07045-D * Analog N/A C151111

7-07050-D ** Analog Pots, No Heater C107, C327, C427 12

7-07051-D Analog Pots, Heater C107, C327, C427 12

7-62120-MWS Analog Pots C107, C327, C427 12

7-58000-4H Analog Pots C173421 7-59005-2G Analog Pots C207, C337, C437 24

7-59120-F Analog Stow, No Pots C102, C322, C422 12 7-59126-SW Analog Dual Stow, No Pots C102, C322, C422 12 7-59206-6F Analog Stow, No Pots C167212, C177212 115

7-59207-5F Analog Pots C177412 115

7-59510 Analog Pots, Heater, Stow C177422

7-56050-1B Analog Pots, Heater C177432 115

7-60056-2B Analog Pots, Heater C177432

SPECIAL CONFIGURATIONS: * No feedback ** Heaters optional CR – Contiuous rotation (slip ring) HS – High Speed Pots – Potentiometer Feedback

Conguration Special Features Suitable Controllers

Voltage Rotation Speeds Rotation Range

Vdc AC Pan Tilt Pan Tilt

QPT-20 Analog

–

1 - 35°/ sec. 1 - 12°/ sec. 435°(± 217.5°) 180°(± 90°) –

–

QPT-50 Analog

QPT-90 Analog

–

QPT-130 Analog

115 –

QPT-200 Analog

QPT-500 Analog

115 –

24 1 - 8°/ sec. 1 - 3°/ sec. 435°(± 217.5°) 180°(± 90°) –

–

1 - 23°/ sec. 1 - 12°/ sec. 435°(± 217.5°) 180°(± 90°) –

–

1 - 23°/ sec. 1 - 12°/ sec. 435°(± 217.5°) 180°(± 90°) –

–

0.5 - 8°/sec. 0.1 - 3 °/sec. 435°(± 217.5°) 180°(± 90°) –

115 1 - 8°/sec. 1 - 3°/sec. 435°(± 217.5°) 180°(± 90°) Restraining Cable

–

1 - 8°/sec. 1 - 4.5°/sec. 435°(± 217.5°) 180°(± 90°) Restraining Cable

–

1 - 10°/sec. 1 - 3°/sec. 435°(± 217.5°) 180°(± 90°) Restraining Cable

–

1 - 10°/sec. 1 - 3°/sec. 435°(± 217.5°) 180°(± 90°) Restraining Cable

–

1 - 8°/sec. 1 - 3°/sec. 435°(± 217.5°) 180°(± 90°) Restraining Cable

–

1 - 8°/sec. 1 - 3°/sec. 435°(± 217.5°) 180°(± 90°) Restraining Cable

1 - 8°/sec. 1 - 3°/sec. 435°(± 217.5°) 180°(± 90°) Stainless Steel Base

–

1 - 10°/sec. 1 - 3°/sec. 350° (+/-175°) 180°(± 90°) –

Special Notes

ANALOG CONTROLLERS SPECIFICATIONS

Part Number Description Pan and Tilt Joystick

12Vdc Output

C124212 Controller, 12Vdc/12Vdc Prop. Speed, No Meters 20/50 Joystick 1/2 Rack 17 - Pin 12Vdc 12 – – –

24Vac Output

C151111 Controller 115Vac/24Vac, Non-variable Spd. 20/90 Joystick Tabletop 17 - Pin 115 / 120Vac – 24 C173431 Controller 115-240Vac/24/120Vac, Non-variable Spd. ,Meters 200/500 Joystick Full 17 - Pin 120 / 240Vac – 24 / 120 X X C162421 Controller 240Vac/115Vac, Non-variable Spd., A/Z Meters 90/130 Joystick Full 17 - Pin 240Vac – 115 X X

C173421 Controller 120-240Vac/24 / 120Vac, Non variable Spd.A/Z Meters 90/130 Joystick Full 17 - Pin 120 / 240Vac – 24 / 120 X X

C167212 Controller 220-240Vac/115Vdc, Prop Speed, No Meters 90/130 Joystick Plug 1/2 Rack 17 - Pin 220 - 240Vdc 115 – C157422 Controller 120Vac/115Vdc, Prop Speed, A/Z Meters 90/130 Joystick Full 17 - Pin 120Vdc 115 – X X C167422 Controller 220-240Vac/115Vdc, Prop Speed, A/Z Meters 90/130 Joystick Full 17 - Pin 220 - 240Vdc 115 – X X C167432 Controller 220-240Vac/115Vdc, Prop Speed, A/Z Meters 200/500 Joystick Full 17 - Pin 220 - 240Vdc 115 – X X C177212 Controller 115/220-240Vac/115Vdc, Prop Speed 200/500 Joystick 1/2 Rack 17 - Pin 115 / 220-240Vdc 115 – C177422 Controller 120Vac/115Vdc, Prop Speed, A/Z Meters 90/130 Joystick Full 17 - Pin 115 / 220Vdc 115 – X X

C177432 Controller 120Vac/115Vdc, Prop Speed, A/Z Meters 200/500 Joystick Full 17 - Pin 115 / 220Vdc 115 – X X

ANALOG PAN & TILT TO CONTROLLER CABLES SPECIFICATIONS

Part Number Description Pan & Tilt

6-19247-1.00 Cable, Analog, w/ 17 Socket / Pin Plugs, , 1.5ft. 20/50/90/130/200 17- Socket 17 - Pin 115 115 1.5, 10, 25, 100, 25, 100, 125, 150, 200, 250

Pan & Tilt Positioners

115Vdc Output

Pan & Tilt Controller DC AC

Rack-

Connector Voltage Input

mount

Connector Voltage (Max.)

Output Meters

DC AC Azimuth Elevation

Standard Lengths (in feet)

www.moogS3.com

QPT-RF Series

PRODUCT OVERVIEW

The QPT-RF Series of pan and tilts employ RF Rotary Joint technology for management of radio frequency signals. These rugged antenna positioners support a wide range of antenna sizes, frequency bands, and up to 3 isolated channels of RF pass-through signals. Auxiliary sensor loads, such as visible and/or thermal cameras, can be mounted with the antenna and are completely supported. Applications include: UAV tracking/telemetry, satellite communications, radar, GPS, and many others.

All RF, video, power, and control data cables are pass-through to eliminate cables in motion with the pan and tilt making cable management simple, neat, and safe. IP, RS-232 and RS-422, Pelco D, serial control of the pan and tilt, and sensors are standard. Serial data and lens controls provide plug and play camera load interfaces.

PRODUCT SPECIFICATIONS

Available Features

• Supports antennas from man-portable up to 3-meters.

• Multiple RF channel pass-through from DC up to 18 GHZ.

• Auxiliary payload support (cameras, laser range nders,

laser designator, GPS, etc.)

• Network ready

• Connector (base): 43-Pin

• Connector (tilt axis): 26-Soc

• Connector (RF) all N-Type

SPECIFICATIONS

Part

Number

7-61BRFA-18G IC -RF I 18GHz/Single FT-A 1 24 Serial / IP PTCR-20/Pelco D 1.7 - 25°/sec. 0.3 - 7°/sec. Continuous 180°(± 90°) 0.25°

7-61BRFB-18G IC -RF I 18GHz/Single FT-B 1 24 Serial / IP PTCR-20/Pelco D 1.7 - 25°/sec. 0.3 - 7°/sec. Continuous 180°(± 90°) 0.25°

7-61RFA-18G ICMS -RF I 18GHz/Single FT-A 1 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-61RFB-18G ICMS -RF I 18GHz/Single FT-B 1 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-62RFA-1816G ICMS -RF II 18/16GHz HBW/ Dual FT-A 2 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-62RFB-1816G ICMS -RF II 18/16GHz HBW/Dual FT-B 2 24 Serial / IP PTCR-96/Pelco D .005 - 50°/sec. .005 - 12°/sec. Continuous 180°(± 90°) 0.05°

7-71RFA-18G ICMS -RF I 18GHz/Single FT-A 1 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-71RFB-18G ICMS -RF I 18GHz/Single FT-B 1 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-72RFA-184G ICMS -RF II 18/4GHz HP/Dual FT-A 2 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-72RFB-184G ICMS -RF II 18/4GHz HP/Dual FT-B 2 24 Serial / IP PTCR-96/Pelco D .005 - 25°/sec. .005 - 8°/sec. Continuous 180°(± 90°) 0.05°

7-51RFU-18G ICMS -RF I 18GHz/Single Univ. 1 48 Serial / IP PTCR-96/Pelco D .001 - 20.°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-52RFA-1816G ICMS -RF II 18/16GHz HBW/Dual FT-A 2 48 Serial / IP PTCR-96/Pelco D .001 - 20.°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-52RFB-1816G ICMS -RF II 18/16GHz HBW/Dual FT-B 2 48 Serial / IP PTCR-96/Pelco D .001 - 20.°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-52RFU-184G ICMS -RF II 18/4GHz HP/Dual Univ. 2 48 Serial / IP PTCR-96/Pelco D .001 - 20.°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

7-52RFU-1816G ICMS -RF II 18/16GHz HBW/Dual Univ. 2 48 Serial / IP PTCR-96/Pelco D .001 - 20.°/sec .001 - 4°/sec. Continuous 180°(± 90°) 0.1°

Conguration / Channel

Load

Mount/

Interface

Channels

# RF

Nominal

Voltage

Vdc

Communication

Interface

QPT-50 (lb-ft torque)

QPT-90 (lb-ft torque)

QPT-500 (lb-ft torque)

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Sensor Integration

• Antennas

• Multi–Spectrum cameras

• Thermal imagers

• IR and visible illuminators

• Laser range nders

Repeatability

Pan & Tilt

Pan & Tilt Positioners

www.moogS3.com

Mercury Series

PRODUCT OVERVIEW

PRODUCT SPECIFICATIONS

Available Features

• Meets NEMA Type 4 and IP66 standards

• Extremely ruggedized, built to withstand extreme environments

• Networked IP control, 2/4 channel available

• Continuous 360° rotation

• Networked IP control

• Stabilized conguration available

• MIL-STD-810, Salt / Fog

• Enclosure IP66

• Payload Weight – Fixed 75 lbs

• Payload Weight – Mobile 50 lbs

• Choice of camera systems

• Easy integration with open source protocol

NEMA

CERTIFIED

Part

Number

7-35000-MWS ICMS CR (Mercury) Universal 24 Serial / IP PTCR-96 / Pelco D .005 - 100°/sec .005 - 100°/sec Continuous 180°(± 90°) 0.05°

ICM - Marine / Brush Motor, ICMS - Marine Sentry (Stepper), CR - Continuous Rotation, HS - High Speed Serial: RS-232, RS-422, IP: Ethernet TCP/IP

* Maximum speed depends upon payload conguration

Load Capacity:

Operating Voltage Range:

Operating Current:

Pan-Axis Range:

Pan-Axis Speed:

Tilt-Axis Range:

Tilt-Axis Speed:

Internal Heater:

IP66

Conguration

SPECIFICATIONS

Load Mount/

Interface

Mobile: 50 lbs balanced load • Fixed: 75 lbs balanced load

18 – 32 Vdc

1.25 amp (steady state); 4.2 amp (both axes moving)

360° continuous rotation (slip ring)

0.05°/sec to 100°/sec

180° (±90°)

0.05°/sec to 100°/sec

Thermostatically controlled (32° on / 35° off)

Nominal

Voltage Vdc

Communication

Interface

STANDARD PERFORMANCE

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan & Tilt

Operating Temperature:

Feedback:

Repeatability:

Motor Type / Drive:

Communication to Pan & Tilt:

Control Protocol:

Connector Specications:

Load Connector Interfaces:

Weight:

Test Cable and Software:

Power Supply:

Pan & Tilt Positioners

-40°C to 70°C (-40°F to 158°F)

Magnetic Encoders (0.01° readout)

0.05°

Stepper

IP and Serial (RS232 / 422 / 485)

Moog QuickSet PTCR-96 or Pelco D

25 Shell 43 Pin Base Connector

Mil-Spec 26-Soc, 16 Shell

44 lbs base unit, 53 lbs with wings

6 ft. test cable

Available upon request

www.moogS3.com

Taurus/Taurus-R Series

PRODUCT OVERVIEW

Designed and built for the harshest mobile or stationary environments, the Taurus™ enables simple integration into existing systems and various platform mounting congurations. The Taurus-R that can be positioned independently from the pan and tilt.

PRODUCT SPECIFICATIONS

Taurus

Available Features

• Balanced payload stationary: up to 300 lbs total,

balanced on-axis, up to 150 lbs per side

• Balanced payload mobile: up to 150 lbs total,

™

balanced on-axis, up to 75 lbs per side

• Stationary or mobile installations

• Mil-Spec connectors

• Marine conguration that meets IP67 standard

• Universal wiring for sensor integration

• Thermostatically controlled heaters

• Connector (Base): 43-Pin

• Connector (tilt axis): 26-Soc

• RF pass-through turret

• 4 payload connectors (2 per side)

Sensor Integration

• Radar antenna systems

• Multi-Spectrum cameras

• IR and visible illuminators

• Laser range nders

• Communication antennas

• Acoustic devices

™

supports radar or other payloads

Taurus-R

™

IP67

SPECIFICATIONS

Part

Number

7-53400 ICMS CR (Taurus) Universal 24 Serial / IP PTCR-96 / Pelco D .005 - 30°/sec .005 - 30°/sec. Continuous 180°(± 90°) 0.05°

7-53450 ICMS CR (Taurus-R) Universal 24 Serial / IP PTCR-96 / Pelco D .005 - 30°/sec .005 - 30°/sec. Continuous 180°(± 90°) 0.05°

7-54800 ICMS CR HS (Taurus) Universal 48 Serial / IP PTCR-96 / Pelco D .005 - 45°/sec .005 - 45°/sec. Continuous 180°(± 90°) 0.05°

7-54850 ICMS CR HS (Taurus-R) Universal 48 Serial / IP PTCR-96 / Pelco D .005 - 45°/sec .005 - 45°/sec. Continuous 180°(± 90°) 0.05°

ICM - Marine / Brush Motor, ICMS - Marine Sentry (Stepper), CR - Continuous Rotation, HS - High Speed Serial: RS-232, RS-422, IP: Ethernet TCP/IP * Maximum speed depends upon payload conguration

Conguration

Load Mount/

Interface

Nominal

Voltage Vdc

Communication

Interface

Control

Protocol

Rotation Speeds* Rotation Range

Pan Tilt Pan Tilt

Repeatability

Pan & Tilt

Pan & Tilt Positioners

www.moogS3.com

Tripods

With over 75 years of experience designing and manufacturing tripod supports and positioning systems, Moog has earned the reputation for unsurpassed performance and reliability. As the leader in instrument support and positioning systems we offer a variety of tripods, heads and accessories to meet the challenging demands of industrial, military and custom solutions.

FEATURES OVERVIEW: SENSOR INTEGRATION OVERVIEW:

• Payload capacity up to 400 lbs • Antennas

• Alodine finished parts for resistance to harsh environments • Radar and microwave dishes

• Adapters and heads for any sensor payload • Cameras (Visible and Thermal)

• Rapid deployment • Laser range finders

• Communication Antennas

• Acoustic Devices

Sensor and Surveillance Systems

Superior Payload Support

TRIPODS

Gibraltar Series ..................................................................................................................................................................................................45

Hercules Series ..................................................................................................................................................................................................46

Samson Series ...................................................................................................................................................................................................47

Tripods

www.moogS3.com

Gibraltar Series

PRODUCT OVERVIEW

When your application relies upon critical performance the Moog Gibraltar tripod series provides unsurpassed quality and reliability even in the most severe conditions.

PRODUCT SPECIFICATIONS

Available Features

• Payload capacity up to 400 lbs

• Anodized and powder coat nished parts for

resistance to harsh environments

• Adapters and heads for any sensor payload

• Rapid deployment

GIBRALTAR SPECIFICATIONS

Part Number Description

4-60450-0

4-60450-0A

4-60450-OD

4-63020-8A *

4-63120-6A *

* All Column Diameters (O.D.) 2-3/8 inches/6.03cm

Tripod, Load Capacity 400 lbs/181 kg,

Max. Height 41 in/104cm, 4 in/10cm Foot Plate

Tripod, Load Capacity 400 lbs/181 kg,

Max. Height 41 in/104cm, 6 in/15.2cm Foot Plate

Tripod, Load Capacity 400 lbs/181 kg,

Max. Height 41 in/104cm - Color: Olive Drab

Tripod, Elevator Column, Load Capacity 200 lbs/90 kg,

3/4 Tripod, Elevator Column, Load Capacity 200 lbs/90 kg,

Max. Height 85 in/215cm

65 in/165cm Max. Height

Load Capacity Height

lbs. kg Max in. (cm) Min in. (cm)

400 181.8 41 (104) 25 (64.5) 55 (139.7) N/A N/A 2 22 (10) FP4 14 x 30.5 (33.5 x 77)

400 181.8 41 (104) 25 (64.5) 55 (139.7) N/A N/A 2 22 (10) FP6 14 x 30.5 (33.5 x 77)

200 91 85 (216) 41.5 (105) 81 (205) 18 (45) 2.375 (6.03) 2 42 (19.1) FP6 17.5 x 49.5 (44x124)

200 91 65 (165.1) 31.5 (80) 65 (165.1) 18 (45) 2.375 (6.03) 2

Maximum

Spread

Diameter

Column

Travel

in. (cm)

Sensor Integration

• Antennas

• Radar and microwave dishes

• Cameras

• Laser range nders

• Communication antennas

• Acoustic devices

Column

O.D.

in. (cm)

Leg

Sections

Weight

lbs. (kg)

33.5

(151)

(Foot Plate)

Feet

FP6 17.5 x 37 (44x93)

Dimensions

(Transport) in. (cm)

GIBRALTAR HEADS, RELAY AND GEARED TYPE SPECIFICATIONS

Part Number Description

4-62050-6 Gibraltar Microwave Relay Head 330 149 6.5 x 6.5 x 7

4-62051-4 Gibraltar Microwave Relay Head, with heavy duty locks 330 149 6.5 x 6.5 x 7

4-62926-7

* Price does include control arm 4-65330-9, has 1/2-13 female receptacle. ** Has 3/8-16 camera screws.

Instrument Geared Head, Calibrated AZ/EL,

Load Capacity 200 lbs/90 kg

Load Capacity L x W x H

lbs. kg in. cm

200 90 10 x 10 x 12

16.5 x 16.5 x 17.8

25.4 x 25.4 x 30.5

Pan

(deg)

360° 30° / 38° Spanner Nut

360° 53° / 67° Post O.D.

Tilt

(deg)

Type

Dimension

in. (cm)

2.75 - 12 (6.8)

1.75

(4.37)

Control

Camera

Arm

Screw

0.5 - 13

Optional

Female

0.5 - 13

Optional

Female

None 3/8 - 16 21 (9.5)

GIBRALTAR DOLLY AND CABLE GUARDS

Part Number Description

4-56021 Dolly, 4 inches/10cm Wheels, for Herc/Gibr Tripods with 4 inches/10cm or 6 in/15.2cm Footplates

GIBRALTAR ACCESSORIES

Part Number Description

4-55110-7 Spike Tips (Set of 3) for 4-60450-0

4-55860-7 Adapter, to t 4-60450-0 and accept Hercules Heads

4-65330-9 Control Arm for 4-62050-6 and 4-62051-4, 14 in/35cm Long

4-65701-1 Wedge Plate Adapter

4-65740-9 Adapter, QTP 90, 130/150, 200, 500 to 4-60450-0

4-65850-6 Adapter to Mount 4-62926-7 Head to 4-60450-0 Tripod

4-65901-7 Wedge Plate Only

4-65911 Transit Adapter - Modied

4-69010-3 Adapter, ts Gibraltar Column, accepts Hercules Heads

4-69020-2 Adapter, Conversion, ts Hercules Tripods accepts Gibraltar Heads w/post mount

FOOT PLATE 6” (15.2cm) diam. w/ 5/8” spike hole - FP6”; 4” (10cm) diam. w/ 5/8” spike hole - FP4” Rubberball - Spike 1.5” diam. (3.8cm) - RBS1.5 Shovel Foot Small - SFS ; Shovel Foot Large - SFL

Weight

lbs. (kg)

30 (13.6)

Camera Plate

in. (cm)

6.5 x 6.5 Fixed (16.5 x 16.5)

8 x 10 Fixed

(20 x 25.4)

Dimensions

in. (cm)

31 x 17.5 x 10.5

(78 x 44.5 x 26.6)

Tripods

www.moogS3.com

Hercules Series

PRODUCT OVERVIEW

Our Hercules tripod series is designed to withstand the harshest environments, supporting critical sensor payloads without sacricing performance.

PRODUCT SPECIFICATIONS

Available Features

• Payload capacity up to 150 lbs

• Rack and pinion driven center column provides

vertical height adjustments

• Anodized tubular construction guarantees years

of reliable service

HERCULES SPECIFICATIONS

Part Number Description

4-53021-8* Tripod, w/ Elevator Column 150 68 70 (178) 33.5 (85) 73 (185) 18 (45) 2 (5) 2 23 (10.4) FP4 40.5 x 12.5 (102 x 31.3)

4-53031-7BQ* Tripod, Extended Height w/ Elevator Column, w/Adapter 150 68 175 (444) 90 (228) 139 (353) 17.5 (44.5) 2 (5) 2 46 (20.9) FP4 77 x 12.5 (193 x 31.3)

4-53220-6* 3/4 Tripod, Short Elevator Column 150 68 57 (144) 26 (66) 50.5 (128) 18 (45) 2 (5) 2 18 (8.2) FP4 30 x 12.5 (76 x 31.3)

4-54504-2 Mobile Pedestal 80 36 56 (142) 38 (96.5) 34 (85) 18 (45) 2 (5) 2 35 (15.9) Wheel Size: 4" 38 x 14 (97 x 35)

4-58001-5 Stationary Pedestal 80 36 50 (127) 32 (81) N/A 18 (45) 2.375 (6.03) 2 16.5 (7.5) FP6 29 x 12 (73 x 30)

4-52202 Tripod, No Column 150 68 52 (132) 30 (76) 73 (185) N/A N/A N/A 20 (9.07) FP4 5 x 12.5 (102 x 31.3)

* All column diameters (O.D.) 2 inches/5cm

Load Capacity Height

lbs. kg Max in. (cm) Min in. (cm)

Maximum

Diameter

Spread

Column

Travel

in. (cm)

Sensor Integration

• Antenna

• Radar and microwave dishes

• Cameras

• Laser range nders

• Communication antennas

• Acoustic devices

Column

O.D.

in. (cm)

Leg

Sections

Weight

lbs. (kg)

Feet

(Foot Plate)

Demensions (Transport)

in. (cm)

HERCULES HEADS AND GEARED TYPE SPECIFICATIONS

Part Number Description

4-52217-3C Hercules Instrument Geared Head 50 22.7

4-52304-9* Hercules Cam Head 80 36

4-52926-9C

* Includes 2 Control Arms.

Hercules Geared Head, Calibrated QHH-11

Large Platform

Load Capacity L x W x H

lbs. kg in. cm

30 13

8 x 10.5

x 11.5

11.75 x 8.25 x 5.50

8 x 9.5 x 10.75

20 x 26.6

x 29.2

30 x 21

x 14

20 x 23.7

x 26.9

Pan

(deg)

360° 45° / 45°

360° 35° / 45°

360° 45° / 90°

Tilt

(deg)

Type

Post

1.25 x 1.5

Post

1.25 x 1.5

Post

1.25 x 1.5

Dimension

in.

31.5 x 38

Control

Arm

Hand

Wheel

Hand

Wheel

Hand

Wheel

Camera

Screw

3/8 -16

1/4 x 20 / 3/8 -16

1/4 - 20

HERCULES DOLLY AND CABLE GUARDS

Part Number Description

4-56021 Dolly, 4 in/10cm Wheels, for Herc/Gibr Tripods with 4 in/10cm or 6 in/15.2cm Footplates

4-56120-5 Cable Guards (Set of 3)

HERCULES ACCESSORIES

Part Number Description

4-55040-6 Control Arm for 4-52304-9, Telescoping 14-19.5 in/35-49cm Long

4-55110-7 Spike Tips (Set of 3)

4-55141-2 Transit Adapter 3-1/2 x 8 to 5/8-11

4-55142-0 Theodolite Adapter 5/8-11 Screw, Rotatable 360°

4-55143 Adapter 3-1/2-8 360 Rotatable

4-55144 Adapater Theodolite Rot. 3/8-16 x .600

4-55730-2 Adapter for QPT 20,50,90,130 to Hercules

4-55732 Adapter for QPT90/130/DOD/Marine

4-55901-9A Adapter, Transit 3-1/2x8 xed

4-65901-7 Adapter Wedge Plate QGWP

4-65701-1 Adapter Wedge Plate QGWPA

4-69020-2 Adapter, Conversion, ts Hercules accepts mounting posts Gibraltar Heads

4-75760-5 Adapter, Conversion, accepts Samson Heads with Sleeve Mount

FOOT PLATE 6” (15.2cm) diam. w/ 5/8” spike hole - FP6” 4” (10cm) diam. w/ 5/8” spike hole - FP4” Rubberball - Spike 1.5” diam. (3.8cm) - RBS1.5 Shovel Foot Small - SFS Shovel Foot Large - SFL

Camera Plate

in. (cm)

9 x 6

(22.5 x 15)

4.5 x 10

(11.25 x 39)

4 x 4

(10 x 10)

Tripods

www.moogS3.com

Samson Series

PRODUCT OVERVIEW

The Samson tripod series focuses on precision manufacturing, detailed assembly, and quality parts. The Samson’s sturdy construction makes it ideal for industrial use.

PRODUCT SPECIFICATIONS

Available Features

• Payload capacity up to 90 lbs

• Anodized tubular construction guarantees years

of reliable service

• Adapters and heads for any sensor payload

SAMSON SPECIFICATIONS

Part Number Description

4-73010-7B Tripod,w/ Safety Elev Elevator 40 18 76 (193) 34 (86.4) 68 (173) 18 (45) 1.75 (4.4) 2 10 (4.5) Spike Tip

4-73500-7B 3/4 Tripod Safety Elev Col, Short 40 18 60 (152) 24 (61) 47 (119) 18 (45) 1.75 (4.4) 3 8.5 (3.8) Spike Tip

4-74425-6A Tripod, w/ Elevator and Foot Plates 40 18 76 (193) 34 (86.4) 68 (173) 18 (45) 1.75 (4.4) 2 11 (5) FP4

4-74500-6 Mobile Pedestal, Safety Elev Col 40 18 55 (139) 37 (94) 28 (71) 18 (45) 1.75 (4.4) N/A 23 (10.5) Wheels 4"

4-74420-7B Microwave Tripod with Friction Head, 1/4-20 screw 35 16 64 (162) 40.5 (103) 60 (152) N/A N/A 2 15.5 (7) FP4

4-74424-9C Microwave Tripod w/ Head w/ Quick Change Plate 6-17019-5 35 15 64 (162) 40.5 (103) 60 (152) N/A N/A 2 17 (7.8) FP4

4-74431-OR Tripod, Samson 50 22.7 48 (122) 20 (51) 58 (147) N/A N/A 3 11 (5) SFL

4-74433 -FB Shovel Foot Tripod. 40 18 40 (102) 20 (51) 58 (147) N/A N/A 3 11 (5) SFS

4-74432-FB

4-73513-FB Tripod, Samson Short 90 40.8 60 (152) 21 (53) 85.5 (217) N/A N/A 4 9.6 (7.8) Spike Tip

4-74429-FB Tripod Samson Short Light weight 50 22.7 42 (107) 19 (48) 58 (147) N/A N/A 3 7 (3.2) FP4

4-74434 Tripod, 3-Section Leg 40 18 40 (102) 20 (51) 58 (147) N/A N/A 3 10 (4.5) FP4

All Column Diameters (O.D.) 1-3/4 in/4.4cm

Tripod, Samson w/ PTU Adaptor MountQPT-20, 50

and GemninEye

Load Capacity Height

lbs. kg Max in. (cm) Min in. (cm)

40 18 58 (147) 31 (79) 68 (173) N/A N/A 2 10 (4.5) FP4

Maximum

Spread

Diameter

Sensor Integration

• Antenna

• Radar and microwave dishes

• Cameras

• Laser range nders

• Communication antennas

• Acoustic devices

Column

Travel

in. (cm)

O.D.

in. (cm)

Sections

Leg

Weight

lbs. (kg)

Feet

(Foot Plate)

SAMSON HEADS, VIDEO, AND GEARED TYPE SPECIFICATIONS

Part Number Description

4-72011-6B* Friction Head, Counterbalance Spring 35 15

4-72512-3 Geared Photo Head 25 11

4-72612-S3 Geared Movie Head 25 11.4

All heads have 1/4-20 camera screw. * Includes 2 control arms.

Tripods

Load Capacity L x W x H

lbs. kg in. cm

5.5 x 6.5 x 6.5

8.5 x 6.5

x 6

6 x 6.5

x 7.5

14.1 x 16.6 x 16.6

21.6 x 16.5 x 15.2

15.2 x 16.5

x 15

Pan

(deg)

360° 45/90 Sleeve 44.4 2 1/4 - 20

360° 45/90 Sleeve 44.4 0 1/4 - 20

360° 45/90 Sleeve 44.4 1 1/4 - 20

Tilt

(deg)

Type

Dimen-

sion

in. (cm)

Control

Arm

Camera

Screw

www.moogS3.com

Camera Plate

in. (cm)

2.25 x 4.25 (5.6 x 10.6)

6.5 x 8.5

(16.5 x 21.6)

2.25 x 4.25 (5.6 x 10.6)

DOLLY AND ACCESSORIES

Part Number Description

4-20042-L Replacement Control Arm Left for 4-25090-8

4-20042-R Replacement Control Arm Right for 4-25090-8

4-56030-6 Dolly for 4-73010-7, 4-73500-7

4-75350-5 Hi-Hat

4-75750-6 Column Adapter Samson/Hercules

4-75910-6A Adapter, Transit 3-1/2 x 8 to Samson Column

4-75915 Adapter, Samson / QPT20

6-15000-7 Spike and Ball Foot for 4-73010-7 (Set of 3)

6-15001-5 Replacement Footpad Assembly for 4-74420, 4-74424, and 4-74425 (Set of 3)

6-15004-9 Spike and Ball Foot for 4-73500-7 (Set of 3)

6-17019-5 Instrument Plate for 4-74424-9 System

LEVELERS

Part Number Description

4-75920-XY Leveler

GEMINEYE ACCESSORIES

Part Number Description

L Brackets

LT-475LB QPT-LT “L”BRACKET SLAVE SIDE w/ Pass-through wiring

LT-450LB QPT-LT “L”BRACKET DRIVE SIDE w/ Pass-through wiring

Power Supply Outdoor

7-08964 Power Supply, Outdoor, Pole Mountable, 24Vdc, 10.2A

Outdoor Power Supply AC Input Cables

6-19235-8/16/50 Cable, Input Power, 115Vac, available in 8, 16, and 50ft lengths

Tripod

4-74434-FB Tripod Samson 3 Section Leg, No Column, 40” Max. Height

4-74432-FB Tripod Samson 2 Section Leg w/ Mount for QPT-20, QPT-50, and GeminEye, 58” Max Height

Test Stand Kit

7-17555 Kit Test Stand GeminEye

Mounts

7-17567 Pedestal Mount

7-17564 Wall Mount

7-17565 Pole adapter (requires addition of wall mount)

7-17566 Corner adapter (requires addition of wall mount)

Video Management

LT-V1CUBE IP Video Encoder Cube

All visible camera part numbers are NTSC, and all thermal camera part numbers are fast frame rate. PAL and slow frame rate options are also available. * These products are subject to export control laws and regulations of the United States government and fall under the control jurisdiction of either

ITAR or EAR regulations. Please contact our company Export Representative at +1-716-687-4930 for additional export information.

4-74434-FB

Tripods

4-74432-FB

www.moogS3.com

Camera Enclosures

Versatile Solutions

BOX CAMERA ENCLOSURE DOME CAMERA ENCLOSURE

Fusion Camera Housing (Thermiq) .................................................. 50

Fusion Camera Housing ................................................................ 51

Fusion Pressurized and Dust-Proof Housings .................................. 52

RC200C ...................................................................................... 53

ACEM20C, ACE20C / AMS90, AMS180 .......................................... 54

Fusion Stainless Steel Tubular Camera Housing .............................. 55

Fusion Stainless Steel Dome .......................................................... 56

FusionDome ................................................................................. 57

RuggedDome ................................................................................ 58

Pressurized FusionDome ............................................................... 59

SuperDome .................................................................................. 60

RM7 / MR7 Recessed Dome Ceiling Housings ................................ 61

Available accessories can be found in the following sections: Accessories, and Power and Wireless.

Camera Enclosures

www.moogS3.com

Fusion Camera Housing (Thermiq)

IK10

Fusion Camera (Thermiq)

PRODUCT OVERVIEW

The professional grade outdoor Fusion Camera Housing with Thermiq Technology is designed to keep advanced IP xed cameras operating at top performance. A major threat to outdoor cameras is heat. Today’s IP cameras generate a lot of heat and radiation from the sun is a substantial contributor as well. A typical outdoor camera system may operate in an ambient temperature of 105°F (40°C), but the temperature inside the camera can be 120°F (50°C) or higher. Over time high temperatures reduce the performance of the camera and can lead to premature failure.

Moog Engineers developed Thermiq Technology, a technologically advanced yet simple and effective solution to combat camera heat. Unlike other camera cooling solutions on the market, Thermiq Technology requires very little power and maintains the camera enclosure’s rugged IP66 rating while ensuring that heat does not build up in the camera. By owing warm internal air and cool external air over a heat sink designed for maximum efciency, heat generated by IP camera electronics and sun radiation is evacuated from the housing. Thermiq Technology removes up to 75% of heat generated by the camera and solar energy, keeping the internal housing temperature closer to ambient.

Intuitive design also played a key role in the formation of the Fusion Line. Smart features include: a side hinge that allows for easy camera servicing and setup; a camera mounting sled that snaps into the housing for simple and secure camera installation; a strategically placed heater that defogs the housing window and lens for clear viewing; and a heavy-duty feed through wall / pole mount with conduit input for clean aesthetics. Available with 24Vac / 24Vdc / 12Vdc input or Moog PoE plus with (Patent Pending) Dynamic Power Allocation (DPA) technology. There’s a Fusion model ideal for your particular surveillance application.

PRODUCT SPECIFICATIONS

IP66

NEMA

CERTIFIED

Available Features

• Meets NEMA Type 4 and IP66 standards

• IK10 impact rated

• Thermostatically controlled blower

• Standard wall / pole mount

• Accommodates wide-angle lenses up to 135º

• Fits most xed camera / lens combinations

SPECIFICATIONS

Part Numbers Description

FCH11C2WQ Environmental housing with heat exchanger, feed-thru wall / pole mount 24Vac / Vdc or 12Vdc input, Heater / Blower, adjustable sunshield

FCH11C8WQ PoE input, with DPA, supports IEEE802.3af cameras, 30 watt midspan included, heater/ blower, adjustable sunshield

FCH11C4WQ 24Vac input, output 802.3af PoE for the camera, Heater / Blower, adjustable sunshield

FCH11C4WQ-MM 24Vac input, output 802.3af PoE for the camera, Heater / Blower, adjustable sunshield with MSA compliant multi-mode fiber-optic transceiver

FCH11C4WQ-SM 24Vac input, output 802.3af PoE for the camera, Heater / Blower, adjustable sunshield with MSA compliant single-mode fiber-optic transceiver

GENERAL

Dimensions: 19.2” x 6.1” x 11.1” (488 x 155 x 282mm)

Max. Camera Length: 11” (280mm)

Weight: 5.3 lbs

Blower (Internal): Yes (Continuous)

Heater Activates At: 60°F (15.5°C)

Heater Deactivates At: 80°F (27°C)

Power Consumption: 24Vac / Vdc: 30 watts: Heater / Blower 12Vdc: 13 watts: Heater / Blower PoE: 30 watts: Camera, Heater / Blower

Maximum Windload: 150mph (240kph)

Construction Body and Top: Polycarbonate

Mounting Bracket Construction: Cast aluminum

Input Voltage / Power Input: 24Vac, 80W

Camera Enclosures – Box

www.moogS3.com

Fusion Camera Housing

APD

IK10

Fusion Camera Housing

PRODUCT OVERVIEW

The Fusion Camera Housing Series of environmental camera enclosures is designed to t a multitude of rugged outdoor surveillance applications. The housing is constructed of resilient polycarbonate and has a wall / pole mount comprised of cast aluminum with a durable powder coat nish, all of which ensure protection of your camera even in the harshest of conditions. Additionally, the heavy-duty wall / pole mount keeps cables protected and out of sight due to its feed-thru capability. This feature coupled with the side-hinged lid and tool-free camera tray ensures easy installation and servicing of your camera.

PRODUCT SPECIFICATIONS

Available Features

• Meets NEMA Type 4 and IP66 standards

• IK10 impact rated

• Accommodates wide-angle lenses up to 135º

• Hinged wall mount allows for easy installation

• Standard wall / pole mount

• 12/24v input models

PoE models

– Supports PoE Plus IEEE802.3at compliant cameras – True PoE power to the camera (no splitter needed) – Automatically adjusts for power loss in long cable runs – DPA ensures maximum power to the camera

IP66

Models Description

FCH11CW Environmental housing with feed-thru wall / pole mount, no electronics

FCH11C2WY 24Vac or 12Vdc input, Heater / Blower, adjustable sunshield

FCH11C8WY PoE input, with DPA, supports IEEE802.3af cameras, 30 watt midspan included, Heater / Blower, adjustable sunshield

FCH11C4WY 24Vac input, output 802.3af PoE for the camera, Heater / Blower, adjustable sunshield

FCH11C4WY-SM 24Vac input, output 802.3af PoE for the camera, Heater / Blower, adjustable sunshield, MSA compliant single-mode fiber-optic transceiver

FCH11C4WY-MM 24Vac input, output 802.3af PoE for the camera, Heater / Blower, adjustable sunshield, MSA compliant multi-mode fiber-optic transceiver

Dimensions: 17.9” x 5.7” x 10.5” (455 x 145 x 267mm)

Max. Camera Length: 11” (280mm)

Weight: 4.5 lbs

Blower (Internal): Yes (Continuous)

Heater Activates At: 60°F (15.5°C)

Heater Deactivates At: 80°F (27°C)

NEMA

CERTIFIED

DYNAMIC

POWER

ALLOCATION

SPECIFICATIONS

GENERAL

Power Consumption: 24Vac: 27 watts: Heater / Blower 12Vdc: 10 watts: Heater / Blower PoE: 25 watts: Camera, Heater / Blower

Maximum Windload: 150mph (240kph)

Construction Body and Top: Polycarbonate

Mounting Bracket Construction: Cast aluminum

Input Voltage / Power Input: 24Vac, 80W

Camera Enclosures – Box

www.moogS3.com

Fusion Pressurized and Dust-Proof Housings

APD

IK10

Fusion Pressurized

PRODUCT OVERVIEW

The Fusion Pressurized and Dust-Proof Housings for xed cameras are engineered with camera protection, ease of installation and true exibility in mind. The Moog “elegantly simple by design” philosophy ensures affordability in the nished product.

The Fusion tubular housing body is constructed of treated aircraft-grade aluminum and 316 stainless steel hardware to ensure camera protection in harsh, corrosive environments. Pressurization protects the camera and lens from debris, chemicals and other containments, extending the life of the camera and reducing service calls. Each pressurized unit includes a 16-pin hermetically-sealed connector to simplify connections. A heavy-duty feed through wall / pole mount, with conduit input, protects and conceals wiring.

Fusion Pressurized Housings are potentially the easiest pressurized enclosure to install and maintain on the market. Easy access to the camera and all serviceable parts allows service to be performed while the camera position and viewing angle are maintained. Other easy-to-install features include: a camera sled that can be rotated within the housing to ensure the desired eld of view; a rear endcap that allows for easy wire installation through the mount; and a simple plug-in connection board.

Flexible features include: 12/24v or PoE Plus option, with patent pending Dynamic Power Allocation

™

(DPA); and distinct

models offering dust proof or pressurization to meet required levels of protection.

PRODUCT SPECIFICATIONS

Available Features

psi

NEMA

CERTIFIED

IP67

DYNAMIC

POWER

ALLOCATION

• Powder coated aluminum and 316 stainless steel hardware

• Thermostatically controlled heater, with continuous blower

• Meets IP67 and NEMA Type 4 standards

• 5-7psi pressure relief valve eliminates over pressurization

• Schraeder valve to ll the housing with Nitrogen or another

clean stable gas

• Standard wall / pole mount (no pole adapters needed)

• IK10 vandal resistant (model available upon request)

• PoE or 12/24v input model

• PoE Ready™ models: – PoE Plus IEEE802.3at compliant device,

compatible with any PoE IEEE802.3af camera

– True PoE power to the camera (no splitter needed

for camera)

– DPA ensures maximum power to the camera with

remaining power provided to the Heater / Blower

– Automatically adjusts to power loss for long cable runs

Models Description

PFH10C2W

PFH10C2WY

PFH10C8WY

DFH10C2W

DFH10C2WY

DFH10C8WY

Dimensions:

Max. Camera Length:

Weight:

Mounting Style:

Heater Activates At:

Heater Deactivates At:

Power Consumption:

Power Output:

Maximum Windload:

Construction Body and Top:

Mounting Bracket Construction:

Blower:

SPECIFICATIONS

Pressurized tubular housing, 24Vac or 12Vdc input, Heater / Blower with feed-thru wall / pole mount

Pressurized tubular housing, 24Vac or 12Vdc input, Heater / Blower with feed-thru wall / pole mount, adjustable sunshield

Pressurized tubular housing, PoE input with Dynamic Power Allocation, 30 watt midspan included, Heater / Blower with feed-thru wall / pole mount, supports .af PoE cameras, adjustable sunshield

Dust-Proof tubular housing, 24Vac or 12Vdc input, Heater / Blower with feed-thru wall / pole mount

Dust-Proof tubular housing, 24Vac or 12Vdc input, Heater / Blower with feed-thru wall / pole mount, adjustable sunshield

Dust-Proof tubular housing, PoE input with Dynamic Power Allocation, 30 watt midspan included, Heater / Blower with feed-thru wall / pole mount, supports .af PoE cameras, adjustable sunshield

GENERAL

20” x 12” x 6” (510 x 305 x 153mm)

10” (250mm)

10 lbs (4.6 kg.) (WITH MOUNT AND SUNSHIELD)

Wall or Pole (STANDARD)

60°F (15.5°C)

80°F (27°C)

24Vac: 29 watts: Heater / Blower 12Vdc: 11 watts: Heater / Blower PoE: 25 watts: Camera, Heater / Blower

24/12v: Same as input, minus power for Heater / Blower PoE: IEEE802.3af

150mph (240kph)

Extruded aluminum

Cast aluminum

Yes (Continuous)

Camera Enclosures – Box

www.moogS3.com

RC200C

PRODUCT OVERVIEW

This low prole camera housing is designed for use in suspended ceiling applications, replacing a standard 2’ x 2’ ceiling tile. Its unique design allows the unit to be manually rotated 360°, and the compact size is ideal for use with a xed, 11” camera and lens combination. The light weight of the RC200C means no special supports are needed.

PRODUCT SPECIFICATIONS

Available Features

• Housing is manufactured from high-impact, off-white ABS plastic

RC200C

Models Description

RC200C

Dimensions:

Dust Cover (Optional):

Viewing Window:

Operating Temperature:

The housing shall be capable of 360° manual rotation without the use of secondary brackets or plates. The view panning adjustment shall be unlimited, with locking tabs provided to secure desired viewing angle. An adjustable stainless steel camera bracket shall be included.

IP Fixed Network: The RC200C is constructed from a high-impact, off white plastic. The IP network ready rotating xed ceiling camera housing is meant to replace a 2’ x 2’ ceiling tile. No special ceiling support attachments needed. Fully adjustable for\ 360° positioning

2’ x 2’ (51 x 51mm)

Housing Bracket Snap-In Mount

94HB ABS plastic Stainless steel 4” x 2.9” (102 x 74mm)

Metal

Clear acrylic

-20ºF to 120ºF (-29°C to 49°C)

• OD1 optional metal back box available for plenum applications to comply with standard building codes

• The unit is fully adjustable for 360° positioning

• Lightweight plastic housing requires no special ceiling support attachments

• Viewing window sonically welded to a snap-in mount

SPECIFICATIONS

GENERAL

Construction

Camera Enclosures – Box

www.moogS3.com

ACEM20C, ACE20C / AMS90, AMS180

ACEM20C, ACE20C /

PRODUCT OVERVIEW

Moog offers an array of indoor vandal resistant housings. No matter what the application Moog has the solution for any surface be it wall or ceiling. Designed to house a solid-state camera unit in a compact casing these discrete housings are ideal for environments were a higher level of security is needed.

ACEM20C

ACE20C

Available Features

• Easy-to-replace Window Guard

restored to clarity

™

paint shield allows vandalized viewing window to be quickly and economically

PRODUCT SPECIFICATIONS

ACEM20C

• Easy installation to any type of ceiling

• Optional 24Vac heater / thermostat for

protected outdoor applications and for defogging the window

Models Description

ACEM20C

ACE20

ACE20T

Indoor Steel, Surface Mount: An off-white powder coat 14-gauge steel ceiling wedge housing with clear 3/16” polycarbonate window with Window Guard paint shield

Indoor Surface Mount Wedge: An off-white polycarbonate ceiling wedge housing with clear viewing window

Indoor Surface Mount Wedge: An off-white polycarbonate ceiling wedge housing with tinted viewing window

CAMERA SIZE (ACE20 / ACE20T)

Camera / lens combinations are based on various cameras tted with a 4mm xed lens (Computar TG0412FCS-3) with a lens length of 1 ¼” and a 3.5-8mm varifocal lens (Computar TG223514F- CS-2) with a lens length of 1 ¾”

ACE20C

• Easy installation to any type of ceiling

• Fully adjustable camera bracket for top

or bottom mounting

• Right-angle BNC connector included

for longer length cameras

SPECIFICATIONS

AMS90

AMS180

PRODUCT OVERVIEW

PRODUCT SPECIFICATIONS

Available Features

• Easy-to-replace Window Guard

restored to clarity

• Mounting hardware fully contained within unit to guard against tampering

• Can be mounted with top against ceiling, while still permitting hinged lid to open for full access to the unit

• Rugged, 14-guage cold-rolled steel construction with welded seams

Models Description

AMS90

AMS180

™

paint shield allows vandalized viewing window to be quickly and economically

SPECIFICATIONS

Indoor Corner Mount: An off-white powder coated vandal resistant construction; 14-gauge steel housing for corner mount with barrel / cam lock, clear .22” thick Lexan® viewing window, and Window Guard paint shields. The housing includes an adjustable bracket for xed camera. MCL 8” (Maximum Camera Length)

Wall Mount: An off-white powdercoated vandal resistant construction; 14-gauge steel housing for wall mount with barrel / cam lock, clear .22” thick Lexan® viewing window, and Window Guard paint shields. The housing includes bracket for xed camera. MCL 8”

Camera Enclosures – Box

www.moogS3.com

Fusion Stainless Steel Tubular Camera Housing

316

Fusion Stainless Steel

PRODUCT OVERVIEW

The Fusion Stainless Steel (SS) Tubular Camera Housing is designed to protect surveillance cameras in the harshest environments while supporting crystal-clear video capture. The IP67-rated, 316 SS camera enclosure is the perfect solution for surveillance applications in corrosive marine / coastal applications, as well as medical / pharmaceutical, food processing, transportation, and oil / gas processing environments. The Fusion Stainless Steel Tubular Housing also thrives in adverse urban environments.

Being part of the Moog Fusion line, the Stainless Steel Tubular Housing is compatible with most xed box-style cameras.

PRODUCT SPECIFICATIONS

Available Features

• 316 SS construction guards against harsh environmental conditions

• Offers protection against corrosive chemicals

• Meets NEMA type 6P and IP67 standards

• Thermostatically controlled 24Vac Heater / Blower model available

• Optional 316 SS wall mount

IP67

NEMA

T6P

CERTIFIED

Models Description

SPECIFICATIONS

SSH10CY

SSH10C2Y

Dimensions (With Sunshield):

Weight:

Construction Body:

Gland Seal Accommodates Wire Diameters (B / T):

Window:

Input Voltage:

Power Consumption:

Power Output 24/12v:

Operating Temperature-Ambient:

Stainless steel tubular housing, sunshield

Stainless steel tubular housing, 24Vac input, Heater / Blower, sunshield

GENERAL

7.0” x 6.7” x 18.0” (180 x 171 x 457mm)

16.9 lbs (7.7 kg.)

316 alloy stainless steel, corrosion and heat-resistant

0.250” and 0.375” (6.35 and 9.525mm)

Glass 5mm thickness, 87mm circular

12/24v input model

24Vac: 29 watts: Heater / Blower 12Vdc: 11 watts: Heater / Blower

Same as input, minus power for Heater / Blower (No Voltage Compression)

Environmental Specifications (Indoor / Outdoor)

-58°F to 122°F (-50°C TO 50°C)

Camera Enclosures – Box

www.moogS3.com

Fusion Stainless Steel Dome

316

IK10

Fusion Stainless Steel Dome

PRODUCT OVERVIEW

The Fusion Stainless Steel (SS) Dome is designed to protect surveillance cameras in the harshest environments while supporting crystal-clear video capture. Corrosive marine and coastline applications, as well as heavily-saturated chemical environments are no match for the 316 L SS housing and sunshield; nor the specially-engineered, optically-clear lower dome. The lower dome offers both better optics, and more resistance to harsh chemicals than traditional acrylic and polycarbonate domes.

This IP67-rated camera housing is the perfect solution for surveillance applications in marine, medical, pharmaceutical, food processing, transportation, and even oil / gas processing environments. A pressurized model eliminates the negative effects of contamination. An IK10 impact rating allows the Fusion Stainless Steel Dome to thrive, in adverse urban environments.

Being part of the Moog Fusion line: the Stainless Steel Dome is compatible with most camera manufacturers’ PTZ lines.

PRODUCT SPECIFICATIONS

Available Features

• 316 L SS construction guards against harsh environmental conditions

• Offers protection against corrosive chemicals

• With impact resistance that rivals polycabonate, the optically clear and durable lower dome is manufactured

from chemical-resistant engineered plastic. (The dome is resistant to most organic solvents and alkalis, unaffected by petroleum fractions, oils and fats. Resistant to dilute mineral acid and most organic acids.)

• Thermostatically controlled 24Vac Heater / Blower (outdoor models)

• Standard pendant mount (1½” male pipe thread)

• Optional SS wall mount

• Pressurized models available

• Meets NEMA type 4X/6 and IP67 standards

IP67

NEMA

CERTIFIED

T4x/

• IK10 impact rated

SPECIFICATIONS

Part Numbers Description

SSDP75CN Stainless steel dome, pendant mount, no electronics

SSDP75C2N Stainless steel dome, pendant mount, 24Vac input, Heater / Blower

SSDP75C2NY Stainless steel dome, pendant mount, 24Vac input, Heater / Blower, sunshield

SSPDP75C2N Pressurized stainless steel dome housing, pendant mount, 24Vac input, Heater / Blower

SSPDP75C2NY Pressurized stainless steel dome housing, pendant mount, 24Vac input, sunshield, Heater / Blower

GENERAL

Dimensions (H x W): 14.3” x 11.3” (364 x 288mm)

Weight: 14.3 lbs (6.5 kg.)

Power Consumption: 24Vac: 52 watts: Heater / Blower

Power Output 24Vac: Same as input, minus power for Heater / Blower

Blower: Yes (Continuous)

Heater: Yes (Outdoor models)

Maximum Windload: 150mph (240kph)

Operating Temperature: -50°F to 120°F (-45.5°C to 49°C)

Operating Humidity: Up to 100% (dessicants on both normal and pressurized models)

Camera Enclosures – Dome

www.moogS3.com

FusionDome

PRODUCT OVERVIEW

With its attractive design and compact size, the FusionDome from Moog offers versatility and added protection to your video surveillance system.

Compatible with most of today’s leading IP and analog camera manufacturers, the FusionDome is constructed of a durable engineered plastic top, 94V0 UV protected, and includes an enhanced optical dome. To better meet the demands of your particular surveillance application, the FusionDome is available with several unique options: pendant or wall mount, 12Vdc input, Heater / Blower, xed or PTZ camera bracket, and more.

PRODUCT SPECIFICATIONS

Available Features

• Thermostatically controlled 12Vdc or 24Vac heater and surge protection (outdoor models only)

• Integrated wall mount standard; pendant mount available (1½” pipe thread)

• Enhanced optically clear lower dome for increased visibility

• Universal mounting plate accepts most IP network and analog camera systems

• Durable engineered plastic top, 94V0 UV protected

• IP66 rated

• PoE models are also available

PoE Available Features

• Reduces installation cost by allowing a network camera to use the same cabling that is used for all other devices on

a network (one contractor installs all cabling)

• Eliminates the need for power outlets at the camera location

• Combines easily with industry-standard uninterruptible power supplies (UPS) to guarantee 24 / 7 / 365 operation

• Installation can be completed without an electrician

• One cable connection, one midspan powers everything

IP66

SPECIFICATIONS

Models Description

FDW75C2N

IFDP75TN Indoor dome housing with pendant mount, tinted dome, for an IP network PTZ camera, no electronics

FDW75C12N 12Vdc version of the FDW75C2N

FDW75F2N IP network ready 7” outdoor dome housing with wall mount, clear polycarbonate dome, with 24Vac input, Heater / Blower, for an IP fixed camera, 120 to 24Vac transformer

IFDP75TF Indoor dome housing with pendant mount, tinted dome, for an IP network fixed camera, no electronics

FDW75C8N Standard outdoor wall mount dome housing for PoE and PoE Plus enabled PTZ / fixed cameras. DPA system, 60W, 100-240Vac input, midspan included

FDW75CF8N Fixed outdoor wall mount dome housing for PoE and PoE Plus enabled PTZ / fixed cameras. DPA system, 60W, 100-240Vac input, midspan included

Dimensions (H x W x D): 14.7” x 8.2” x 14.5” (374 x 208 x 369mm)

Weight: 11

Power Requirements: 24Vac 55W (Heater / Blower 27W)

Dome 24Vac Model: 12Vdc, 50W

Dome 12Vdc Model: (Includes 20W for heater)

Input Power: 802.3at (PoE Ultra)

IP network ready 7” outdoor dome housing with wall mount, clear polycarbonate dome, with 24Vac input, Heater / Blower, for an IP network PTZ camera, 120 to 24Vac transformer

GENERAL

lbs

. (5 kg.)

Supported Cameras: 802.3af or 802.3at

Operating Temperature: -20°F to 120°F (-29°C to 49°C) • PoE models: -20°F to 122°F (-29°C to 50°C)

Maximum Windload: 150mph (240kph)

Camera Enclosures – Dome

www.moogS3.com

RuggedDome

PRODUCT OVERVIEW

Ideal for applications needing extra protection from vandalistic attacks. The Moog 7” vandal resistant, rugged housing (RHW75 Series) offers versatility and adequate camera protection in a compact / attractive design. Constructed of a cast aluminum top, and polycarbonate dome, the RHW75 Series boasts an IP66 rating. The RHW75 Series is available in a variety of models, designed to suit your individual needs. Select from one of our outdoor or indoor, wall or pendant mount options. The RHW75 Series includes a Moog universal camera bracket system which enables you to utilize most of today’s leading IP or analog camera systems (xed or PTZ). Outdoor models include two heaters and two blowers.

PRODUCT SPECIFICATIONS

Available Features

• Rugged, vandal-resistant cast aluminum top and polycarbonate dome

• Equipped with a thermostatically controlled Heater system and a sustaining Air Circulation Fan, the FusionDome

allows efcient dome views during every season

• Comes standard with wall mount; optional pendant mount available

• Meets IP66 standards for dust and water penetration (pendant mount)

• Indoor and outdoor models; outdoor models include two heaters and blowers

• Great for monitoring applications: parking lots, high crime areas, schools

™

IP66

Models Description

RHW75C2N

IRHP75TN

RHW75C12N

RHW75CF2N

IRHP75TF

Dimensions (H x W x D):

Weight:

Construction:

Mount Bracket:

Power Requirements:

Operating Temperature:

SPECIFICATIONS

IP network ready 7” vandal resistant outdoor dome housing with wall mount, rugged aluminum top and polycarbonate clear dome, with 24Vac input, Heater / Blower, for an IP network PTZ camera, 120 to 24Vac transformer

Indoor version of the RHW75C2N and has no electronics

12Vdc version of the RHW75C2N

IP network ready 7” vandal resistant outdoor dome housing with wall mount, rugged cast aluminum top and polycarbonate clear dome, with 24Vac input, Heater / Blower, for an IP network fixed camera, 120 to 24Vac transformer

Indoor version of the RHW75CF2N with no electronics

GENERAL

14.7” x 8.2” x 14.5” (374 x 208 x 369mm)

13 lbs. (6 kg.)

TOP: 3mm engineered plastic • DOME: Polycarbonate

Aluminum

Standard Outdoor Model: 24Vac 52W • Network Outdoor Model: 24Vac, 80W (includes 50W for heater)

-40°F to 120°F (-40°C to 49°C)

Camera Enclosures – Dome

www.moogS3.com

Pressurized FusionDome

IK10

Pressurized FusionDome

PRODUCT OVERVIEW

Eliminate the negative effects of moisture, dirt, and pollution on valuable camera equipment with the Pressurized FusionDome. The PFDW75 protects your surveillance investment while offering an effective monitoring solution.

Essential for monitoring ocean shore environments, agricultural processing and industrial manufacturing plants, the IP67 rated Pressurized FusionDome is designed to keep most minute foreign objects from entering the enclosure by maintaining constant pressure within the inner housing area, via an inert gas.

PRODUCT SPECIFICATIONS

Available Features

• Constructed of durable engineered plastic to withstand intense levels of solar heat (UL 94-5VA, UV protected)

• IP67 rating: designed to withstand water and dust intake

• Includes both Schrader and pressure relief valves

• Pressurized to 7psi, able to maintain pressure for 2-3 years

• IK10 impact rating

• Universal mounting plate accepts most IP network camera systems (PTZ or xed), including a model for larger cameras

• Pendant mount standard with optional mounting brackets

• Heater / Blower feature standard

COMPRESSED AIR OR INERT GAS:

Although the Pressurized FusionDome may be purged with common compressed air, utilizing an inert gas like nitrogen provides pressure longevity and reduces the risk of contaminated compressed air in the system

IP67

psi

Models Description

PFDW75C2N/AX

PFDW78C2N

PFDW75CF2N

Dimensions (H x W x D):

Weight:

Construction:

Mount Bracket:

Power Requirements:

Dome 12Vdc model:

Operating Temperature: -50°F to 120°F (-45.5°C to 49°C)

Heater Activates at: 60°F (15°C)

The PFDW75C2N is a pressurized dome housing with WM20G gooseneck wall mount, clear dome, 24Vac input, Heater / Blower. Accommodates an IP network PTZ camera, (includes: 120 to 24Vac, 96 watts transformer)

An extended trim ring model for larger cameras with a maximum camera depth of 243.3mm (9.58”)

Pressurized dome housing with WM20G gooseneck wall mount, clear dome, 24Vac input, Heater / Blower, (1) fixed camera bracket (7.5” MCL), 120 to 24Vac, 96W transformer

Standard Model: 14.8” x 11.4” x 11.4” (375.9 x 289.5 x 289.5mm) • Larger Model: 15.2” x 11.4” x 11.4” (386 x 289.5 x 289.5mm)

11 lbs. (5 kg.)

TOP: 0.125” (3mm) engineered plastic • DOME: Polycarbonate

Aluminum

24Vac 80W (Heater / Blower 52W)

(Includes 21W for Heater / Blower) + camera

SPECIFICATIONS

GENERAL

Heater Deactivates at: 80°F (27°C)

Effective Projected Area (EPA): Approx. 0.12 m^2

Operating Humidity: Up to 100%

Camera Enclosures – Dome

www.moogS3.com

SuperDome

PRODUCT OVERVIEW

The SuperDome is a general purpose dome camera housing. This unit is available with either a 12” or 16” dome and comes with a pendant mount. It features a ¼” UV rated, ABS plastic upper dome and a 1/8” cell-cast acrylic lower dome. The 12” model allows two xed cameras, the 16” unit allows for three cameras.

PRODUCT SPECIFICATIONS

Available Features

• Available with clear or tinted dome

• Optional inner liner available

• Security fasteners standard equipment

• Houses single or multiple xed cameras

• Optional Heater / Blower

Moog specializes in housings for xed, multi-camera applications. These congurations offer an inexpensive alternative to Pan / Tilts. The SuperDome™ offers:

• Ability to accommodate up to 3 xed cameras:

SDP12 MCL: 8” for 1 camera / 7” for 2 cameras SDP16 MCL: 12” for 1 camera / 8” for 2 cameras / 7” for 3 cameras

• Adjustable viewing in many directions

• Easy Installation

NOTE: If the application calls for more than one camera in the unit, an additional FM1 bracket will be needed for each additional camera.

SPECIFICATIONS

Models Description

SDP12CHB

SDP16C

SDP16CHB

Power Source:

Power Consumption:

Pan / Tilt Power Consumption:

Maximum Load:

Weight:

Each unit in the SuperDome™ general purpose, outdoor housing series shall be equipped with a pre-attached, optional pendant mount, and shall be available with either a 12”or 16” clear or tinted (1 F-stop light reduction) lower dome made from 1/8” cell-cast acrylic. The upper dome shall be ¼” ABS plastic. Optional items shall include: 24Vac, 2.08 Amp heater and surge protector; 24Vac, 16 Amp blower and surge protector, or Heater / Blower combination; 355 integral pre-wired 12° per second.

12” outdoor / indoor fixed camera dome housing. Includes 1 fixed camera bracket; can accommodate up to 2 full-body fixed cameras (FM1). Security fasteners, optional pendant mount, Heater / Blower (included in outdoor models), MCL 7”-8”

16” outdoor / indoor fixed camera dome housing. Includes 1 fixed camera bracket; can accommodate up to 2 full-body fixed cameras (FM1). Security fasteners, optional pendant mount, MCL 10”

16” outdoor / indoor fixed camera dome housing. Includes 1 fixed camera bracket; can accommodate up to 2 full-body fixed cameras (FM1). Security fasteners, optional pendant mount, Heater / Blower (included in outdoor models), MCL 10”

GENERAL

24Vac

52vA (camera not included)

16vA (Max.) - .625 Amps P/T

5 lbs. balanced

3.25 lbs. (1.47 kg.)

Camera Enclosures – Dome

www.moogS3.com

RM7 / MR7 Recessed Dome Ceiling Housings

RM7 / MR7 Recessed Ceiling

PRODUCT OVERVIEW

The Moog RM7 provides the functionality and security of a low-prole, recessed ceiling mount dome with a rugged vandal resistant construction. Engineered for both indoor and outdoor scenarios, and plenum rated for re resistant ceilings, the RM7 is ideal for tactical surveillance in urban schools and ofce / business environments.

PRODUCT SPECIFICATIONS

IP66

RM7

Available Features

• Vandal resistant, cast aluminum top with a (clear

or tinted) polycarbonate lower dome

• Available in both outdoor / indoor models. Outdoor

models include Heater / Blower systems to maintain camera temperature and eliminate condensation

• IP Network models available with internal power /

supply providing 12Vdc power for camera and external 110Vac power supply that provides 24Vac to the dome

• Includes a decorative trim ring with safety lanyard and

captive security fasteners

• Easy installation and servicing from below

the ceiling or overhang

• Compatible with most major camera

manufacturers – xed and PTZ (MLC 7.5” 190.5mm)

• Housing extends only 4.7” (119.4mm)

below ceiling

• Designed to be water and dust tight, IP66

• UL File Number: E306312

PRODUCT OVERVIEW

Moog MR7 is a low-prole, indoor, recessed, ceiling mount dome housing. It features a 7” (177.8mm) dome that accommodates standard-body xed cameras up to 8” (203.2mm) in length or PTZ cameras (see compatibility chart). For xed models, an opaque liner hides the direction of the camera in both the clear and tinted domes. The upper body is made of steel, and a white powder coat trim ring gives the MR7 a clean, streamlined look.

MR7

Models Description

RM7C2N

IRM7TN

RM7CF2N

IRM7TF

MR7TL

MR7TN

IP network compatible housing for PTZ network cameras, 24Vac input, 18/12Vdc output for camera, clear dome, Heater / Blower, and 110Vac wall transformer

IP network housing for PTZ network cameras, tinted dome

IP network compatible housing for fixed network cameras, 24Vac input, 18/12Vdc output for camera, clear dome, Heater / Blower, 110Vac wall transformer, MCL 7.5”

Analog camera housing for fixed camera, tinted dome

7” (177.8mm) recessed ceiling mount dome housing, tinted dome, plus (1) fixed camera bracket, and decorative trim ring, includes liner; MCL 8” (Maximum Camera Length 203.2mm)

IP network ready 7” (177.8mm) recessed ceiling mount dome housing, tinted dome, for an IP network PTZ camera, includes trim ring

PRODUCT SPECIFICATIONS

Available Features

• Housing extends only 3.5” (88.9mm) below ceiling

• Camera can be mounted on either side of the xed

mount camera bracket

• Includes a decorative trim ring with quick-release

pressure springs

• Plenum rated for non-re resistant ceilings

• Units available with either clear or tinted domes

• UL File Number: E106941 and E306312

SPECIFICATIONS

GENERAL

FIXED

• Accepts standard body xed camera and lens

[up to 8” (203.2mm) in length}

• Includes black liner with pre-cut viewing window

PTZ

• Accepts many network PTZ cameras

Dimensions (H x W x D):

Weight:

Consumption:

Outdoor Model:

Operating Temperature:

Camera Enclosures – Dome

RM7: 11.2” x 11.2” x 11.5” (284 x 284 x 292mm) • MR7: 9” x 11” x 12.25” (230 x 280 x 312mm)

10 lbs. (4.6 kg.)

Back Box: (RM7) 10-gauge aluminum (MR7) 18-and 20-Gauge Steel • Trim Ring: (RM7) Die-cast aluminum (MR7) 19-Gauge Steel Dome: Polycarbonate • Body: (MR7) Steel

(RM7) 24Vac 27W (va)

(RM7) -20˚F to 120˚F, Outdoor Model: -29˚C to 49˚C • (MR7) 32ºF to 120ºF (0°C to 49°C)

www.moogS3.com

Accessories

Sensor and Surveillance Systems

Diverse Tools for Integration

POLES AND LOWERING DEVICES MOUNTS AND BRACKETS ADDITIONAL ACCESSORIES

P1600 and P1800 .....................................63

PolEvators .................................................64

Brackets and Mounts .................................65

Dome Mount Adapters ................................66

Dome Brackets / Parapet Mounts ................67

Surge Protection ........................................68

Infrared Illuminators ...................................69

Miscellaneous ............................................70

Available Accessory (supported products can be found throughout)

Accessories

www.moogS3.com

P1600 and P1800

PRODUCT OVERVIEW

Pole mounted video surveillance offers several monitoring benets, but at the same time can turn into installation nightmares and service headaches due to faulty pole construction and picture/video distortion. To counter these frustrations, Moog offers its line of video surveillance rated steel poles.

Constructed of heavy-gauge steel, Moog surveillance poles are engineered with the sole purpose to enhance video surveillance. Capable of supporting up to 75 lbs and withstanding wind gusts of up to 170 mph, Moog poles are ideal for optimizing your video surveillance system.

PRODUCT SPECIFICATIONS

Available Features

• Designed specically for video surveillance camera systems

• Solid construction; designed to reduce or eliminate vibration from strong wind loads up to 170 mph

• Compatible with most major camera manufacturers (Contact a Moog associate for appropriate mounting brackets)

• Powder coat nish for greater longevity

• Supports up to 75 lbs

Models Description

P1600

P1800

P1800TB P1800 without NEMA Box or electronics

Standard 16’ steel pole (4” x 4” tubing) with access panels on top and bottom, square base with a maximum load of 75 lbs

Moog designed a solid construction 16’ steel pole with 2’ transformer base NEMA enclosure. Base includes terminal strip, 115Vac to 24Vac transformer and surge protection

SPECIFICATIONS

GENERAL

Construction: Steel

Max. Wind Capacity: 35 lbs. at 12u (Max.)

Max. Wind Load: 170 mph (16’ pole without base. Up to 3 cameras)

P1600 P1800

Weight + Base: 155 lbs. (70.3 kg.) + 34 lbs. (15 kg.) 200 lbs. (90.72 kg.) + 34 lbs. (15 kg.)

Max. Housing Height: 15.5’ raised / 5’ lowered’ 17.2’ raised / 6.7’ lowered

Call Moog for complete dimensional information on separately boxed items.

Accessories – Poles and Lowering Devices

www.moogS3.com

PolEvators

PRODUCT OVERVIEW

Save money, time and labor with the innovative Moog PolEvator. One technician, using a standard drill, can quickly, easily and safely service or repair pole-mounted cameras without the need for high-reach devices, such as bucket trucks, ladders or multiple technicians. With its unique, patented, self-lubricating lowering mechanism, the Moog PolEvator is built to smoothly lower its payload to ground level yet withstand harsh outdoor conditions.

Constructed of extruded aluminum, the PolEvator is designed to withstand high wind gusts of 150mph, resulting in little to no picture distortion. Available in 16’ or 18’ models, the PolEvator accepts a wide range of cameras and video surveillance accessories.

PRODUCT SPECIFICATIONS

Available Features

• Cost-effective solution eliminates the need for

renting expensive bucket trucks and reduces labor requirements

• Solid construction; designed to reduce or eliminate

vibration from strong wind loads up to 150mph

• Patented, self-lubricating lowering mechanism,

withstands many up-down iterations

SPECIFICATIONS

Models Description

PV16N

PV18N

GENERAL PV16N PV18N

16’ Free-standing aluminum pole complete with universal mounting plate, exible shaft lowering tool, lifting plate, power and data connections and video input

PV16N with 2’ transformer base. Base includes NEMA box, terminal strip, 115Vac to 24Vac transformer and surge protection for video / data

• Factory wired plug n’ play, includes power, video

and data connections

• Compatible with most major camera manufacturers.

(Contact a Moog associate for appropriate mounting brackets)

• Increases safety for technicians and surroundings

• US Patent #6,447,150 B1

Dimensions: 16 feet height: (4.75” x 4.75” Pole + 12” x 12” Base) 18 feet height: (4.75” x 4.75” Pole + 13” x 13” Base)

Weight:

Max. Housing Height: 15.5’ raised / 5’ lowered’ 17.2’ raised / 6.7’ lowered

Max. Wind Capacity:

Max. Wind Load: 150mph

Construction: Extruded aluminum

With the PolEvator’s patented, self-lowering capabilities you will save on high costfees associated with servicing pole mounted surveillance systems.

Item Unit Price

Bucket Truck $ 975.00

Cost of Technicians $ 120.00

(Most jobs require at least two technicians for safety reasons. $20/hr x 3 visits x 1 hr / visit x 2 techs)

Cost of Slower Response Time $ 250.00

Cost of Training $ 15.00

Administrative Costs $ 150.00

(Scheduling of personnel, paperwork required for insurance and / or government purposes, etc)

Total Yearly Cost Estimate** $1,510.00

155

lbs. (70.3 kg.) 200 lbs. (90.72 kg.)

lbs. at 12u (Max.)

COST SAVINGS WITH THE POLEVATOR:

Invoice

(Average service calls per year – 3; average daily truck rental - $325)

(Delays in scheduling can result in substantial loss of revenue from the service)

(Some facilities require personnel operating bucket trucks to be trained)

** NOTE: This is an estimate based on focus groups and industry information. Costs may vary with location and other factors.

Accessories – Poles and Lowering Devices

www.moogS3.com

Brackets and Mounts

PRODUCT OVERVIEW

Moog offers a diverse portfolio of mounts and brackets that are designed to the exacting quality standards of Moog for use anywhere, including outdoor, harsh environments. Specication and engineering test data for all Moog products are available upon request. Custom designs and specic client requests should be directed to a Moog sales person.

SPECIFICATIONS

Model Description

WM800

• 12-gauge steel

• Designed for mounting to a at wall or round pole (larger than 3.5” diameter)

Model Description

WM1A Adapter plate for WM800 and WM800IR, for use with PolEvator

Medium-duty steel wall mount bracket, Max. load 20

SPECIFICATIONS

lbs.

™

and outdoor aluminum brackets

SPECIFICATIONS

Model Description

WM10SS

Model Description

CM945 Aluminum ceiling mount bracket for a xed camera housing with a 45° adjustment

10” (257mm) 316L Stainless steel wall mount with 1.5” NPT threaded connection for EXO Series Cameras, and other dome enclosures

SPECIFICATIONS

Accessories – Brackets and Mounts

www.moogS3.com

Dome Mount Adapters

PRODUCT OVERVIEW

Moog offers an array of diverse mounts and brackets to complement our dome camera housings. These mounts and brackets allow the dome enclosures to t a variety of applications.

SPECIFICATIONS

Part Number Description

ACA2 Aluminum corner mount bracket with female inserts (black)

ACA2W Aluminum corner mount bracket with female inserts (white)

• Durable powder coat nish

• All aluminum construction

• Threaded bolt inserts to make installation easier and quicker

• 75

lbs. load rating

SPECIFICATIONS

Part Number Description

APM3 Aluminum pole mount bracket with female inserts (black)

APM3W Aluminum pole mount bracket with female inserts (white)

Part Number Description

APM6 Aluminum pole / wall mount adapter with pole straps (black)

APM6W Aluminum pole / wall mount adapter with pole straps (white)

• Mounts to poles 3”- 6” dia. with included pole straps (2)

• Conduit holes on sides with (2) knockouts on the back

• 25

lbs. load rating

• Threaded bolt inserts to make installation quicker and easier

• Durable powder coat nish

• Sealed junction box for terminating wires

Part Number Description

CA15 Ceiling mount adapter, with junction box, includes 1½” NPT

SPECIFICATIONS

Accessories – Brackets and Mounts

www.moogS3.com

Dome Brackets / Parapet Mounts

Dome Brackets / Parapet

PRODUCT OVERVIEW

Moog offers an array of diverse mounts and brackets to complement our dome camera housings. These mounts and brackets allow the dome enclosures to t a variety of applications.

SPECIFICATIONS

Model Description

WM20G Aluminum gooseneck wall bracket (black)

WM20GW Aluminum gooseneck wall bracket (white)

• Durable powder coat nish

• All aluminum construction

• 1½” pipe thread on end for quick and easy dome mounting

• 60

lbs. load rating

SPECIFICATIONS

Model Description

WM40W Wall mount bracket

Model Description

WM30G Aluminum parapet mount bracket, includes 1½” NPT

• Durable powder coat nish

• All aluminum construction

• 1½” pipe thread on end for quick and easy dome mounting

• 50 Lbs. load rating

Model Description

PRM50G Heavy-duty aluminum parapet mount bracket with 20” extension, includes 1½” NPT

SPECIFICATIONS

Accessories – Brackets and Mounts

www.moogS3.com

Surge Protection

PRODUCT OVERVIEW

Extend the life of your electronics, with a surge protector from Moog, the rst line of defense when keeping your equipment safe from surges. surge protection lowers the potential for over-heating and frying. Radio frequency interference (RFI) and other forms of electrical interference, such as surges and spikes, are a very common problem in the security industry. Low level signals such as closed-circuit television and associated data links are extremely susceptible to even small disruptions. Our surge protectors employ semiconductor clamping devices which protect against spikes and surges.

SPVO50 SPVP110 SPVRJ01

SPECIFICATIONS

Model Description

SPVO50 Coax Video Surge Protection (BNC CONNECTOR)

Reliable protection • Small package • Easy to install

Model Description

SPVP110 110Vac power surge protection

Model Description

SPVRJ01 Data / power over ethernet power / data surge protection

Video Input:

Maximum Video Level: Line to Shield Current (Max.): Response Time: Shield to Ground Current (Max.): Frequency Response:

24Vac Power Input:

Input Voltage (Max.): Maximum Current: Normal Operating Current: Maximum Surge Current: Response Time: Interference Filter: Differential Mode Attenuation: Common Mode Attenuation:

Control Line Input:

Maximum Signal Level

Maximum Surge Current

Response Time: Frequency Response:

AC: DC: Differential Mode: Common Mode:

SPECIFICATIONS

MECHANICAL SPECIFICATIONS

This protects the video line to the camera by means of fast acting diode clamps

5.0 Volts / 1.0 Volt is normal 3000 Amps

1.0 Picosecond 6500 Amps DC to 12 MHz

Protects camera and Pan / Tilt power

40 Volts

3.0 Amps

2.0 Amps 4000 Amps

1.0 Picoseconds 100 kHz to 25 MHz (noise)

50.0 dB

30.0 dB

Protects 2 wire control line for Pan / Tilt.

16 Volts - RS-232 has a Voltage of ± 15 Volts 25 Volts 2000 Amps 4000 Amps

5.0 Nanoseconds DC to 3 MHz

Accessories – Additional Accessories

www.moogS3.com

Infrared Illuminators

PRODUCT OVERVIEW

The IR200-36 and IR100-36N infrared illuminators enhance video surveillance for all low light applications. Constructed of a lightweight, rugged, weather-resistant material, the IR200-36 and IR100-36N are capable of illuminating multiple distances and angles with a simple switch. Adjust the beam angle to 30°, 45°, or 60° and manipulate the power setting to illuminate variable distances to control camera washouts / hot spots. For more covert surveillance applications, the IR100-36N operates at 940 nanometer wavelength, making the LED untraceable to the human eye.

Equipped with advanced LED technology, that requires low power and offers a 20,000-hour lifespan, Moog offers two fully adjustable IR illuminators that come backed by an impressive ve year warranty.

PRODUCT SPECIFICATIONS

Available Features

• Fully adjustable – one model for all applications

• Adjustable beam angle: 30°, 45°, or 60°

• Adjustable IR power setting for illuminating various distances and / or compensating for camera hot spots

• Light sensor automatically activates or deactivates IR

• Low power requirements: 24Vac or 18-30Vdc

• 940 nanometer for covert surveillance; LEDs untraceable by the naked eye (IR100-36N Only)

SPECIFICATIONS

Model Description

IR200-36

Fully adjustable infrared illuminator – 850 nanometer beams. Multiple beam angles: 30°, 45°, 60° and projection distances up to 330 feet (100 meters) depending on camera. Includes surge protection and automatic fan for heat dissipation

• Automatic fan for heat dissipation

• Surge protection, user replaceable fuse

• Optional brackets and mounts available

• LED technology: 20,000 hour life cycle

• Full ve year warranty

Model Description

IR100-36N

Fully adjustable infrared illuminator – 940 nanometer beams for covert surveillance (untraceable by human eye). Multiple beam angles: 30°, 45°, 60° and projection distances up to 330 feet (100 meters) depending on camera. Includes surge protection and automatic fan for heat dissipation

WHAT ARE INFRARED ILLUMINATORS?

For surveillance applications where light is not sufcient, i.e. night-time scenarios, an infrared illuminator is strongly recommended for enhancing your view of sight. Composed of multiple light emitting diodes (LEDs), the infrared illuminators produce an infrared beam of light that when paired with either a Day / Night or black and white camera will illuminate the surrounding area for increased visibility.

Dimensions (H x W x D): 11.5” x 7.0” x 7.0” (292 x 178 x 178mm)

Weight: 5.25 lbs. ( 2.4 kg.)

Back Plate: Aluminum

Trim Ring: Polycarbonate

Front: Polycarbonate

Body: Extruded Aluminum

Power Requirements: 24Vac or 18-30Vdc, 15-45W

Operating Temperature: -40°F to 120°F (-40°C to 49°C)

SPECIFICATIONS

ADJUSTABLE IR BEAM ANGLE: 30º, 45º OR 60º:

Benets of a Fully Adjustable IR:

• Expand or decrease illumination parameters with a simple switch.

Ideal for temporary video surveillance adjustments

• Power setting adjusts for wash outs / hot spots, resulting in huge cost

savings from new cameras or IRs

• Save on costly IR upgrades, due to application surveillance changes

GENERAL

Accessories – Additional Accessories

www.moogS3.com

Miscellaneous

PRODUCT OVERVIEW

Moog provides a wide range of accessories designed and produced to the same quality specications as our other products. Common accessories are listed below, please contact a Moog representative for additional products.

Video tracking, video stabilization, and video encoding are available.

SYSTEM INTERFACE UNITS SPECIFICATIONS

Part Number Description Application

7-08625-MWS Power Supply, Video Tracking, and Video IP Encoding For PVS, PVTS, and PTS Systems

QS51105

Part Number Description Application

SM-1110 Stabilization Module Cube with Internal MEMs Gyro.

L-PVU-Console-1 PVU Marine Dash Mount Joystick Controller Dash Mountable Joystick Controller

6-20124-30

Video Tracking with Gyro Stabilization

and Radar Slewing

QS VIDEO MARINE SYSTEM SPECIFICATIONS

30ft Interface Cable Between SM-1110

and C-PVU-Console-1

For PVS, PVTS, and PTS Systems

Mounts GeminEye Positioner, Senses 3-Axis

and Provides 2-Axis Stabilization

For SM-1110 and C-PVU-Console-1

Part Number Description Application

6-21022 Mount, L Bracket for QPT-90ICM Payloads

6-21085 Mount, Bore Sight Pan+/-1.4° Tilt+/-1.4° Compatible with 6-21002 L Bracket

7-17567 Pedestal Mount Supports GeminEye and QPT-20 systems

7-17564 Wall Mount Supports GeminEye and QPT-20 systems

7-17565

7-17566 Corner Adapter (requires addition of wall mount) Supports GeminEye and QPT-20 systems

7-08964*

7-08801* Power Supply, Outdoor, Pole Mountable, 48Vdc, 13.0A

7-08802* Power Supply, Outdoor, Pole Mountable, 24Vdc, 14.0A For QPT90 /QMP / QMP-R / QPT-50 Pan and Tilts

7-08804*

7-08805*

* Parts are not available in multiple colors

ACCESSORY SPECIFICATIONS

Payload Mount Interfaces

QS Visible Camera Heads 7-79960-MWS

and 7-79968-MWS, thermal payloads

Mounts

Pole Adapter (requires addition

of wall mount component)

Power Supplies, Outdoor Enclosure, Weather Resistant, Mil Spec Input AC / Output DC Connectors

Power Supply, Outdoor, Pole Mountable,

Power Supply, Outdoor, Pole Mountable, 48Vdc,

24Vdc, 10.2A

48Vdc, 22.0A

22.0A, 110Vac Pass-Through

w/ Serial Controlled On/Off Relay

Supports GeminEye and QPT-20 systems

For QPT90 /QMP /QMP-R / QPT-50/

QPT-20 Pan and Tilts

For QPT-500 and QPT90 /QMP/

QPT-50 High Speed Pan and Tilts

For QPT-500 and QPT90 /QMP /

QPT-50 High Speed Pan and Tilts

For QPT-500 and QPT90 /QMP /

QPT-50 High Speed Pan and Tilts

Accessories – Additional Accessories

www.moogS3.com

Power and Wireless

power and Wireless

Sensor and Surveillance Systems

Dependable Connections

POWER AND WIRELESS

PB24 Power Boxes ............................................................................................................................................................................................72

PB26 Wireless and Power Boxes .........................................................................................................................................................................73

MIMO Wireless ..................................................................................................................................................................................................74

Available Accessory (supported products can be found throughout)

Power and Wireless

www.moogS3.com

PB24 Power Boxes

PRODUCT OVERVIEW

Moog offers an extremely versatile, PB24 Series of UL approved outdoor rugged power boxes to provide an economical solution for supplying your video surveillance system with electrical current. Incorporating a vandal-resistant design, the rugged cast aluminum NEMA4 box enclosure meets IP66 standards to prevent the ingress of minute particles. The PB24 outdoor power box series mounts directly to a Moog FusionDome™ (FDW housings), Vandal Resistant Dome (RHW housings).

Moog power boxes are available in two distinct model classes. Each model incorporates several innovative accessories focused on better optimizing your video surveillance system via standard and signal converters.

PRODUCT SPECIFICATIONS

Available Features

• Available in three model classes: Standard and Signal Converters

• Mounts directly to Moog outdoor wall mount housings

• Provides 4 amps of power at 24Vac

• Designed for direct conduit connections

IP66

• Pole-mounting clips included

• Provides four amps of power at 24Vac

• Designed for direct conduit connections

• Mounts directly to Moog outdoor wall-mount housing

• Meets IP66 standards to prevent the ingress of

minute particles and liquids

• No programming necessary

• Save on costly cabling fees

• Benet from the versatility of an IP network system

• EOF2N: Transmit Ethernet data through high-speed

ber optic cable

Dimensions (H x W x D): 8.75” x 7.82” x 3.92” (222.3 x 198.6 x 99.6mm) Power Consumption: 1-Amp (120W) at 120Vac

Weight: 10

Power Output: PB24: 96va (96W)

lbs

. (4.54 kg.) Power Input: 120Vac or 240Vac, 50 / 60Hz

NEMA

CERTIFIED

SPECIFICATIONS

Models Description

PB24 Standard Power Box: 220 / 115Vac input converting to 24Vac and 96W output power

SPECIFICATIONS

Models Description

PB24 + EOF2N Transmit Ethernet data through high-speed ber optic cable

PB24FM-SC * Will need and EOF2N for termination side if ber

GENERAL

Power and Wireless

www.moogS3.com

PB26 Wireless and Power Boxes

PB26 Power Boxes

PRODUCT OVERVIEW

Moog offers the PB26 Series of outdoor power boxes provide an economical solution for supplying your camera system with electrical current, while offering ample space for the inclusion of additional user electronics.

Constructed out of an steel NEMA box enclosure, the PB26 Series has been designed to complement a variety of Moog wall mount camera housings / domes by simply bolting to the wall mount back. This simple yet effective design reduces installation and servicing times. Available in two distinct model types: Standard and Wireless.

PRODUCT SPECIFICATIONS

Available Features

• Provides 4 amps of power at 24Vac (220 / 115Vac input converting to 24Vac and 96W output)

• Designed for direct conduit connections

• Pole mounting clips included

• Provides adequate space for additional user electronics

• Mounts directly to Moog outdoor wall mount camera enclosures

SPECIFICATIONS

Models Description

PB26

Dimensions (H x W x D):

Weight:

Consumption:

Operating Temperature:

Network Compatibility:

Buttons / Switches:

LED Indicators:

Outdoor power box with 220 / 115Vac input converting to 24Vac and 96W output. Ample space to include additional user electronics

GENERAL

9.863” x 4.048” x 14.32” (251 x 103 x 364mm)

19 lbs. (8.6 kg.)

Back Box: Steel

-29°C to 49°C (-20°F to 120°F)

Cellular Broadband Modem

IEEE 802.3u compliant Cable and DSL modems with dynamic IP, static IP, PPPoE, PPTP, L2TP connection types

SGNL (signal strength display), Reset button Configuration mode / IP Pass-Through mode

Power, Ethernet LAN Status, USB Modem, Express Card Modem Signal Strength

Power and Wireless

www.moogS3.com

MIMO Wireless

PRODUCT OVERVIEW

Moog Outdoor Wireless Solutions provide dual point-to-point / point-to-multi-point wireless surveillance exibility in one package. An outdoor rugged Power Box, a MIMO (Multiple-Input-Multiple-Output) transmitter/receiver, and system setup software comprise the complete solution set. Utilizing revolutionary MIMO technology, Moog wireless kits employ multiple signal paths to address the channel limitations and multi-path fading associated with earlier wireless technologies. The result: high- throughput, via a reliable and cost effective wireless solution.

PRODUCT SPECIFICATIONS

Available Features

• Easy installation and setup

• Flexible deployment options

• Pole mount hardware included

• Wireless transmitter / receiver for IP cameras

• 120° sectional antennae (provided with receiver)

• Supports up to 150+ Mbps real TCPI / IP

• 300+ subs per receiver

• Low latency

CONSIDER THE LINE-OF-SITE (LOS) AND THE FRESNEL ZONE:

The illustration below demonstrates the properties of 5.8GHz vs. 2.4GHz. Simply put, 5.8GHz is a tighter band meant for greater distances, while 2.4GHz is less constricted by LOS but typically covers shorter distances

SPECIFICATIONS

Models Description

PB24M24 Rugged outdoor wireless box with a 110Vac (220Vac U.K.) input and 24Vac output for camera. Fuse protected with a wireless 2.4GHz MIMO transmitter. Directional antenna

PB24M58 Rugged outdoor wireless box with a 110Vac (220Vac U.K.) input and 24Vac output for camera. Fuse protected with a wireless 5.8GHz MIMO transmitter. Directional antenna

VLRM24 Wireless 2.4GHz MIMO access point, 110Vac input and 24V output

VLRM58 Wireless 5.8GHz MIMO access point, 110Vac input and 24V output

2.4GHZ / 5.8GHZ (PB24M TRANSMITTER) 2.4GHZ / 5.8GHZ (VLRM) RECEIVER

Dimensions:

Weight:

Enclosure Characteristics:

Power Method:

Operating Temperature:

Operating Humidity:

Shock and Vibration:

Power Supply

Max. Power Consumption:

Frequency Range:

Gain:

Polarization:

Cross-pol Isolation:

Max. VSWR:

Hpol Beamwidth (6dB):

Vpol Beamwidth (6dB):

Elevation Beamwidth:

Please refer to the PB24 section for product specics

24V, 0.5A surge protection

2.4GHz: integrated PoE adapter included

2.41-2.46 GHz 5.74-5.82 GHz 2.41-2.46 GHz 5.74-5.82 GHz

10.4-11.2 dBi 14.6-16.1dBi 15.0-16.0 15.0-16.0dBi

23dB minimum 22dB minimum 28dB minimum 22dB minimum

11.6” x 3.1” x 1.2” (29.4 x 8 x 3cm) 6.3” x 3.1” x 1.1” (16 x 8 x 3cm)

0.88 lbs. (0.4 kg.) 1.1 lbs. (0.5 kg.)

Outdoor UV Stabilized plastic

Passive Power over Ethernet (pairs 4, 5+; 7, 8 return)

-30°C to 75°C (-22°F to 167°F)

5 to 95% Condensing

ETSI300-019-1.4

15V, 0.8A surge protection

5.8GHz: integrated PoE adapter included

8 Watts 2.4GHz: 6.5 Watts 5.8GHz: 8 Watts

2.4GHz 5.8GHz 2.4GHz 5.8GHz

Dual Linear

1.6:1 1.5:1

55° 43° 123° 137°

53° 41° 118°

27° 15° 9° 8°

24V, .5A PoE supply included

Power and Wireless

www.moogS3.com

LOCATIONS

Argentina

Australia

Austria

Brazil

Canada

China

Finland

France

Germany

India

Ireland

Italy

Japan

Luxembourg

The Netherlands

Norway

Philippines

Russia

Singapore

South Africa

South Korea

Spain

Sweden

Switzerland

United Arab Emirates

United Kingdom

United States

linkedin.com/

company/moog-sdg

facebook.com/

MoogSDG.USA

Sensor and Surveillance Systems

twitter.com/

MoogSDG

Form 500-700 08182016

Moog 4-53021-MSN, 4-74425-6A, 7-08801 Specsheet

Specifications and Main Features

Frequently Asked Questions

User Manual
