Monroe Electronics 282IS User Manual
Operator’s Manual
for
Monroe Electronics, Inc.
Model 282 I S Digital Stat-Arc 2
Electrostatic Fieldmeter
for Hazardous Locations
P/N 0340110
282/100
Rev A
1-800-821-6001 585-765-2254 fax: 585-765-9330 monroe-
100 Housel Ave PO Box 535 Lyndonville NY 14098
electronics.com
Description
Model 282 I S Digital Stat-Arc 2 is a pocket-size, non-contacting static meter which
produces consistently accurate readings, is easy to use, and is backed by a
2-year warranty, the best in the business.
The 282 I S features:
Pulsing-beam range finder for always obtaining the correct reading
Drift- free accuracy even in ionized environments
HOLD button to capture transient readings
Recorder output and 40-hour battery life for unattended monitoring
Exclusive auto-zero circuit
Available charged-plate adaptor (Model 282CPS)
With the Model 282 I S, accuracy is unquestioned. Simply hold the instrument so the range
finder LED beams form a non-pulsing circle indicating you’re at exactly the right distance (1
inch) from the target for readings up to 20 kV. To read higher voltage, use the greater distances
given in Specifications.
For location where it’s hard to read the display, you can freeze it, and then read it. Simply
position the meter at the correct distance from the target, press and release the HOLD button,
move the instrument to a more convenient position, then read the display.
Zeroing is push-button simple, and Model 282 I S ‘s chopper stabilized circuitry is immune to
ionization so accuracy is assured in all environments. For long term monitoring, the front panel
output jack provides easy interfacing with a recorder, oscilloscope or automated data acquisition
system.
Specifications
Display: LCD 3 ½ digit, auto-polarity readout, HOLD and LOW BATT indicators
Range: 0 to 19.99kV at 1 inch. Voltages of 20kV and higher may be read by
increasing the distance to the target:
Kv Distance Multiply Reading
By
0 - 40 4.0 inches 2
0 - 60 6.5 inches 3
0 - 80 8.5 inches 4
Accuracy: 5% of reading, + zero offset, + 2 lsd
Analog Output:
Jack Type: Accepts standard 3/32 inch (2.5mm) monaural phone plug
Amplitude: 1V signal denotes 10kV reading at 1 inch for high impedance loads
Impedance: 10k Load > 1 meg for < 1% error. Sleeve GND tip 1/10,000
Response
Time: Typ. 80 – 100 m sec 10 – 90%
Battery Type: 9V NEDA #1604 or equivalent life: 40 hours normal use,
with alkaline battery (refer to Safety Considerations on bacl.)
Physical: (L x W x H) 2.4 x 4.2 x 0.9 inches (6.1 x 10.7 x 2.3cm)
Weight: 5 oz. (142 gm) with battery
Operating
Environment: 0 –50
0
C, 0-85% RH (non-condensing) unaffected by ionizing equipment
