<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
DESCRIPTION
The RA55H3340M is a 55-watt RF MOSFET Amplifier Module for
12.5-volt mobile radios that operate in the 330- to 400-MHz range.
The battery can be connected directly to the drain of the
enhancement-mode MOSFET transistors. Without the gate voltage
(V
=0V), only a small leakage current flows into the drain and the RF
GG
input signal attenuates up to 60 dB. The output power and drain current
increase as the gate voltage increases. With a gate voltage around
4V (minimum), output power and drain current increases substantially.
The nominal output power becomes available at 4.5V (typical) and 5V
(maximum). At V
=5V, the typical gate current is 1 mA.
GG
This module is designed for non-linear FM modulation, but may also be
used for linear modulation by setting the drain quiescent current with
the gate voltage and controlling the output power with the input power.
FEATURES
• Enhancement- Mode MOSFET Transistors
(I
≅0 @ VDD=12.5V, VGG=0V)
DD
>55W, ηT>35% @ VDD=12.5V, VGG=5V, Pin=50mW
• P
out
• Broadband Frequency Range: 330-400MHz
• Low-Power Control Current I
• Module Size: 66 x 21 x 9.88 mm
• Linear operation is possible by setting the quiescent drain current with
the gate voltage and controlling the output power with the input power
RoHS COMPLIANCE
• RA55H3340M-101 is a RoHS compliant products.
• RoHS compliance is indicate by the letter “G” after the Lot Marking.
• This product include the lead in the Glass of electronic parts and the lead in
electronic Ceramic parts.
However, it is applicable to the following exceptions of RoHS Directions.
1.Lead in the Glass of a cathode-ray tube, electronic parts, and fluorescent
tubes.
2.Lead in electronic Ceramic parts.
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
=1mA (typ) at VGG=5V
GG
BLOCK DIAGRAM
2
1
1 RF Input (Pin)
2 Gate Voltage (V
3 Drain Voltage (V
4 RF Output (P
5 RF Ground (Case)
out
GG
DD
)
PACKAGE CODE: H2S
3
4
5
), Power Control
), Battery
ORDERING INFORMATION:
ORDER NUMBER SUPPLY FORM
RA55H3340M-101
Antistatic tray,
10 modules/tray
Publication Date : Oct.2011
1
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
MAXIMUM RATINGS
SYMBOL PARAMETER CONDITIONS RATING UNIT
VDD Drain Voltage VGG<5V 17 V
VGG Gate Voltage VDD<12.5V, Pin=0mW 6 V
Pin Input Power 100 mW
P
Output Power 65 W
out
T
Operation Case Temperature Range
case(OP)
T
Storage Temperature Range -40 to +110 °C
stg
(T
=+25°C, unless otherwise specified)
case
f=330-400MHz,
Z
G=ZL
=50Ω
-30 to +110 °C
Note1. The above parameters are independently guaranteed.
Note2. In order to keep high reliability of the equipment, it is better to keep the module temperature of the module is
recommended to keep lower than 90
under all conditions, and to keep lower than 60°C under standard conditions.
°C
ELECTRICAL CHARACTERISTICS
(T
=+25°C, ZG=ZL=50Ω, unless otherwise specified)
case
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNIT
f Frequency Range 330 - 400 MHz
P
Output Power 55 - - W
out
=12.5V
ηT
2fo 2nd Harmonic - - -50 dBc
ρin
IGG Gate Current
— Stability
— Load VSWR Tolerance
Total Efficiency 35 - - %
Input VSWR - - 3:1 —
V
DD
V
=5V
GG
=50mW
P
in
VDD=10.0-15.2V, Pin=25-70mW,
P
<65W (VGG control), Load VSWR=3:1
out
VDD=15.2V, Pin=50mW, P
Load VSWR=20:1
=55W (VGG control),
out
- 1 - mA
No parasitic oscillation —
No degradation or destroy —
All parameters, conditions, ratings, and limits are subject to change without notice.
Publication Date : Oct.2011
2
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
TYPICAL PERFORMANCE
OUTPUT POWER, TOTAL EFFICIENCY, 2nd, 3rd HARMONICS versus FREQUENCY
and INPUT VSWR versus FREQUENCY
80
70
(W)
60
out
(-)
in
ρ
50
40
30
20
INPUT VSWR
10
OUTPUT POWER P
0
ρ
in
320 330 340 350 360 370 380 390 400 410
FREQUENCY f(MHz)
OUTPUT POWER, POWER GAIN and OUTPUT POWER, POWER GAIN and
DRAIN CURRENT versus INPUT POWER DRAIN CURRENT versus INPUT POWER
60
50
Gp
40
30
(dBm)
out
P
20
OUTPUT POWER
10
POWER GAIN Gp(dB)
0
-10 -5 0 5 10 15 20
INPUT POWER P
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
(T
=+25°C, ZG=ZL=50Ω, unless otherwise specified)
case
P
out
η
T
I
DD
in
VDD=12.5V
=5V
V
GG
=50mW
P
in
P
out
f=330MHz,
V
DD
V
GG
(dBm)
=12.5V,
=5V
24
20
16
12
8
4
0
80
70
60
50
40
30
20
10
0
-30
-40
(%)
T
η
TOTAL
EFFICIENCY
-50
-60
HARMONICS (dBc)
-70
-80
320 330 340 350 360 370 380 390 400 410
FREQUENCY f(MHz)
60
(A)
DD
50
Gp
40
30
(dBm)
out
P
20
OUTPUT POWER
10
DRAIN CURRENT I
POWER GAIN Gp(dB)
I
DD
0
-10 -5 0 5 10 15 20
INPUT POW ER P
VDD=12.5V
=5V
V
GG
=50mW
P
in
f=365MHz,
V
V
(dBm)
in
rd
3
nd
2
=12.5V,
DD
=5V
GG
24
P
out
20
(A)
DD
I
16
12
8
4
DRAIN CURRENT
0
OUTPUT POWER, POWER GAIN and
DRAIN CURRENT versus INPUT POWER
60
50
Gp
P
out
40
30
(dBm)
out
P
20
OUTPUT POWER
10
POWER GAIN Gp(dB)
0
I
DD
f=400MHz,
=12.5V,
V
DD
V
=5V
GG
-10 -5 0 5 10 15 20
INPUT POWER P
(dBm)
in
24
20
16
12
8
4
0
(A)
DD
DRAIN CURRENT I
OUTPUT POWER and DRAIN CURRENT OUTPUT POWER and DRAIN CURRENT
versus DRAIN VOLTAGE versus DRAIN VOLTAGE
120
110
f=330MHz,
100
(W)
out
90
80
V
GG
P
in
=5V,
=50mW
70
60
50
40
30
20
OUTPUT POWER P
10
0
2 4 6 8 10 12 14 16
DRAIN VOLTAGE V
DD
(V)
24
22
20
(A)
18
P
out
16
DD
14
12
I
DD
10
8
6
4
2
DRAIN CURRENT I
0
(W)
out
OUTPUT POWER P
120
110
100
90
80
70
60
50
40
30
20
10
0
f=365MHz,
=5V,
V
GG
P
=50mW
in
2 4 6 8 10 12 14 16
DRAIN VOLTAGE V
24
22
20
(A)
P
out
18
16
DD
14
12
10
I
DD
8
6
4
2
DRAIN CURRENT I
0
(V)
DD
Publication Date : Oct.2011
3
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
TYPICAL PERFORMANCE
OUTPUT POWER and DRAIN CURRENT
versus DRAIN VOLTAGE
120
110
f=400MHz,
100
(W)
out
90
80
V
GG
P
in
=5V,
=50mW
70
60
50
40
30
20
OUTPUT POWER P
10
0
2 4 6 8 10 12 14 16
DRAIN VOLTAGE V
OUTPUT POWER and DRAIN CURRENT OUTPUT POWER and DRAIN CURRENT
versus GATE VOLTAGE versus GATE VOLTAGE
90
f=330MHz,
80
V
(W)
out
OUTPUT POWER P
=12.5V,
DD
70
=50mW
P
in
60
50
40
30
20
10
0
2.5 3 3.5 4 4.5 5 5.5
GATE VOLTAGE V
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
(T
=+25°C, ZG=ZL=50Ω, unless otherwise specified)
case
24
22
20
(A)
18
P
out
16
DD
14
I
12
DD
10
8
6
4
2
DRAIN CURRENT I
0
(V)
DD
18
16
P
out
I
DD
14
12
10
(A)
DD
8
6
4
2
DRAIN CURRENT I
0
(V)
GG
90
f=365MHz,
80
V
=12.5V,
(W)
DD
70
out
P
in
=50mW
P
out
60
50
40
30
20
10
OUTPUT POWER P
0
2.5 3 3.5 4 4.5 5 5.5
GATE VOLTAGE V
(V)
GG
18
16
14
(A)
DD
12
10
I
DD
8
6
4
2
DRAIN CURRENT I
0
OUTPUT POWER and DRAIN CURRENT
versus GATE VOLTAGE
90
f=400MHz,
80
=12.5V,
V
DD
(W)
70
out
P
in
=50mW
60
50
40
30
20
10
OUTPUT POWER P
0
2.5 3 3.5 4 4.5 5 5.5
GATE VOLTAGE V
P
out
I
DD
(V)
GG
18
16
14
12
10
8
6
4
2
0
(A)
DD
DRAIN CURRENT I
Publication Date : Oct.2011
4
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
OUTLINE DRAWING (mm)
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
3.0 ±0.3
7.25 ±0.8
21.0 ±0.5
9.5 ±0.5
2.0 ±0.5
14.0 ±1
12.0 ±1
16.5 ±1
66.0 ±0.5
60.0 ±0.5
51.5 ±0.5
5
2
1
43.5 ±1
3
4
Ø0.45 ±0.15
2-R2 ±0.5
17.0 ±0.5
4.0 ±0.3
55.5 ±1
3.1 +0.6/-0.4
0.09 ±0.02
(9.88)
7.5 ±0.5
(50.4)
2.3 ±0.3
1 RF Input (Pin)
2 Gate Voltage (V
3 Drain Voltage (V
4 RF Output (P
out
)
GG
)
DD
)
5 RF Ground (Case)
Publication Date : Oct.2011
5
<Silicon RF Power Modules >
Ω
Ω
RA55H3340M
RoHS Compliance , 330-400MHz
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
TEST BLOCK DIAGRAM
Signal
Generator
Attenuator
Pre-
amplifier
C1, C2: 4700pF, 22uF in parallel
Attenuator
Power
Meter
Directional
Coupler
ZG=50
C1 C2
- +
DC Power
Supply V
GG
DUT
4321
+ -
DC Power
Supply V
DD
5
Z
=50
Directional
Coupler
1 RF Input (Pin)
2 Gate Voltage (V
3 Drain Voltage (V
4 RF Output (P
5 RF Ground (Case)
Spectrum
Analyzer
Attenuator
out
Power
Meter
)
GG
)
DD
)
EQUIVALENT CIRCUIT
Publication Date : Oct.2011
6
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
RECOMMENDATIONS and APPLICATION INFORMATION:
Construction:
This module consists of an alumina substrate soldered onto a copper flange. For mechanical protection, a plastic cap is
attached with silicone. The MOSFET transistor chips are die bonded onto metal, wire bonded to the substrate, and coated
with resin. Lines on the substrate (eventually inductors), chip capacitors, and resistors form the bias and matching circuits.
Wire leads soldered onto the alumina substrate provide the DC and RF connection.
Following conditions must be avoided:
a) Bending forces on the alumina substrate (for example, by driving screws or from fast thermal changes)
b) Mechanical stress on the wire leads (for example, by first soldering then driving screws or by thermal expansion)
c) Defluxing solvents reacting with the resin coating on the MOSFET chips (for example, Trichloroethylene)
d) ESD, surge, overvoltage in combination with load VSWR, and oscillation
ESD:
This MOSFET module is sensitive to ESD voltages down to 1000V. Appropriate ESD precautions are required.
Mounting:
Heat sink flatness must be less than 50 µm (a heat sink that is not flat or particles between module and heat sink may
cause the ceramic substrate in the module to crack by bending forces, either immediately when driving screws or later
when thermal expansion forces are added).
A thermal compound between module and heat sink is recommended for low thermal contact resistance and to reduce
the bending stress on the ceramic substrate caused by the temperature difference to the heat sink.
The module must first be screwed to the heat sink, then the leads can be soldered to the printed circuit board.
M3 screws are recommended with a tightening torque of 4.0 to 6.0 kgf-cm.
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
Soldering and Defluxing:
This module is designed for manual soldering.
The leads must be soldered after the module is screwed onto the heat sink.
The temperature of the lead (terminal) soldering should be lower than 350°C and shorter than 3 second.
Ethyl Alcohol is recommend for removing flux. Trichloroethylene solvents must not be used (they may cause bubbles in
the coating of the transistor chips which can lift off the bond wires).
Thermal Design of the Heat Sink:
At P
=55W, VDD=12.5V and Pin=50mW each stage transistor operating conditions are:
out
P
Stage
1st
2nd
in
(W)
0.05 1.5 23.0 0.26
1.5 13.0 2.4 3.10
P
out
(W)
R
th(ch-case)
(°C/W)
@ η
(A)
=38%
T
VDD
(V)
12.5
I
DD
3rd 13.0 55.0 1.2 8.15
The channel temperatures of each stage transistor Tch = T
T
= T
ch1
T
= T
ch2
T
= T
ch3
+ (12.5V x 0.26A – 1.5W + 0.05W) x 23.0°C/W = T
case
+ (12.5V x 3.10A - 13.0W + 1.5W) x 2.4°C/W = T
case
+ (12.5V x 8.15A - 55.0W + 13.0W) x 1.2°C/W = T
case
+ (VDD x IDD - P
case
case
case
case
+ Pin) x R
out
+ 41.4 °C
+ 65.4°C
+ 71.9 °C
th(ch-case)
are:
For long-term reliability, it is best to keep the module case temperature (T
temperature T
P
) of the heat sink, including the contact resistance, is:
in
R
th(case-air)
=60°C and P
air
=55W, the required thermal resistance R
out
= (90°C - 60°C) / (55W/38% – 55W + 0.05W) = 0.33 °C/W
) below 90°C. For an ambient
case
th (case-air)
= ( T
case
- T
) / ( (P
air
/ ηT ) - P
out
out
When mounting the module with the thermal resistance of 0.33 °C/W, the channel temperature of each stage transistor is:
= T
= T
= T
air
air
air
+ 71.4 °C
+ 95.4 °C
+ 101.9 °C
T
ch1
T
ch2
T
ch3
The 175°C maximum rating for the channel temperature ensures application under derated conditions.
+
Publication Date : Oct.2011
7
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
Output Power Control:
Depending on linearity, the following two methods are recommended to control the output power:
a) Non-linear FM modulation:
By the gate voltage (VGG).
When the gate voltage is close to zero, the RF input signal is attenuated up to 60 dB and only a small leakage current flows from
the battery into the drain.
Around V
Around V
b) Linear AM modulation:
By RF input power Pin. The gate voltage is used to set the drain’s quiescent current for the required linearity.
=4V, the output power and drain current increases substantially.
GG
=4.5V (typical) to VGG=5V (maximum), the nominal output power becomes available.
GG
Oscillation:
To test RF characteristics, this module is put on a fixture with two bias decoupling capacitors each on gate and drain, a 4.700 pF chip
capacitor, located close to the module, and a 22 µF (or more) electrolytic capacitor.
When an amplifier circuit around this module shows oscillation, the following may be checked:
a) Do the bias decoupling capacitors have a low inductance pass to the case of the module?
b) Is the load impedance Z
c) Is the source impedance Z
=50Ω?
L
G
ATTENTION:
1.High Temperature; This product might have a heat generation while operation,Please take notice that have a possibility to receive a
burn to touch the operating product directly or touch the product until cold after switch off.
At the near the product,do not place the combustible material that have possibilities to arise the fire.
2. Generation of High Frequency Power; This product generate a high frequency power. Please take notice that do not leakage the
unnecessary electric wave and use this products without cause damage for human and property per normal operation.
3. Before use; Before use the product,Please design the equipment in consideration of the risk for human and electric wave obstacle
for equipment.
=50Ω?
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
PRECAUTION FOR THE USE OF MITSUBISHI SILICON RF POWER AMPLIFIER DEVICES:
1.The specifications of mention are not guarantee values in this data sheet. Please confirm additional details regarding operation of
these products from the formal specification sheet. For copies of the formal specification sheets, please contact one of our sales
offices.
2.RA series products (RF power amplifier modules) and RD series products (RF power transistors) are designed for consumer mobile
communication terminals and were not specifically designed for use in other applications.
In particular, while these products are highly reliable for their designed purpose, they are not manufactured under a quality
assurance testing protocol that is sufficient to guarantee the level of reliability typically deemed necessary for critical communications
elements. In the application, which is base station applications and fixed station applications that operate with long term continuous
transmission and a higher on-off frequency during transmitting, please consider the derating, the redundancy system, appropriate
setting of the maintain period and others as needed. For the reliability report which is described about predicted operating life time of
Mitsubishi Silicon RF Products , please contact Mitsubishi Electric Corporation or an authorized Mitsubishi Semiconductor product
distributor.
3.RA series products use MOSFET semiconductor technology. They are sensitive to ESD voltage therefore appropriate ESD
precautions are required.
4.In order to maximize reliability of the equipment, it is better to keep the devices temperature low. It is recommended to utilize a
sufficient sized heat-sink in conjunction with other cooling methods as needed (fan, etc.) to keep the case temperature for RA series
products lower than 60deg/C under standard conditions, and less than 90deg/C under extreme conditions.
5.RA series products are designed to operate into a nominal load impedance of 50 ohms. Under the condition of operating into a severe
high load VSWR approaching an open or short, an over load condition could occur. In the worst case there is risk for burn out of the
transistors and burning of other parts including the substrate in the module.
6.The formal specification includes a guarantee against parasitic oscillation under a specified maximum load mismatch condition. The
inspection for parasitic oscillation is performed on a sample basis on our manufacturing line. It is recommended that verification of no
parasitic oscillation be performed at the completed equipment level also.
7.For specific precautions regarding assembly of these products into the equipment, please refer to the supplementary items in the
specification sheet.
8.Warranty for the product is void if the products protective cap (lid) is removed or if the product is modified in any way from it’s original
form.
9.For additional “Safety first” in your circuit design and notes regarding the materials, please refer the last page of this data sheet.
10. Please refer to the additional precautions in the formal specification sheet.
Publication Date : Oct.2011
8
<Silicon RF Power Modules >
RA55H3340M
RoHS Compliance , 330-400MHz
55W 12.5V, 3 Stage Amp. For MOBILE RADIO
Keep safety first in your circuit designs!
Mitsubishi Electric Corporation puts the maximum effort into making semiconductor products better and more
reliable, but there is always the possibility that trouble may occur with them. Trouble with semiconductors
may lead to personal injury, fire or property damage. Remember to give due consideration to safety when
making your circuit designs, with appropriate measures such as (i) placement of substitutive, auxiliary
circuits, (ii) use of non-flammable material or (iii) prevention against any malfunction or mishap.
•These materials are intended as a reference to assist our customers in the selection of the Mitsubishi
semiconductor product best suited to the customer’s application; they do not convey any license under any
intellectual property rights, or any other rights, belonging to Mitsubishi Electric Corporation or a third party.
•Mitsubishi Electric Corporation assumes no responsibility for any damage, or infringement of any
third-party’s rights, originating in the use of any product data, diagrams, charts, programs, algorithms, or
circuit application examples contained in these materials.
•All information contained in these materials, including product data, diagrams, charts, programs and
algorithms represents information on products at the time of publication of these materials, and are subject
to change by Mitsubishi Electric Corporation without notice due to product improvements or other reasons. It
is therefore recommended that customers contact Mitsubishi Electric Corporation or an authorized
Mitsubishi Semiconductor product distributor for the latest product information before purchasing a product
listed herein.
The information described here may contain technical inaccuracies or typographical errors. Mitsubishi
Electric Corporation assumes no responsibility for any damage, liability, or other loss rising from these
inaccuracies or errors.
Please also pay attention to information published by Mitsubishi Electric Corporation by various means,
including the Mitsubishi Semiconductor home page (http://www.MitsubishiElectric.com/).
•When using any or all of the information contained in these materials, including product data, diagrams,
charts, programs, and algorithms, please be sure to evaluate all information as a total system before making
a final decision on the applicability of the information and products. Mitsubishi Electric Corporation assumes
no responsibility for any damage, liability or other loss resulting from the information contained herein.
•Mitsubishi Electric Corporation semiconductors are not designed or manufactured for use in a device or
system that is used under circumstances in which human life is potentially at stake. Please contact
Mitsubishi Electric Corporation or an authorized Mitsubishi Semiconductor product distributor when
considering the use of a product contained herein for any specific purposes, such as apparatus or systems
for transportation, vehicular, medical, aerospace, nuclear, or undersea repeater use.
•The prior written approval of Mitsubishi Electric Corporation is necessary to reprint or reproduce in whole or
in part these materials.
•If these products or technologies are subject to the Japanese export control restrictions, they must be
exported under a license from the Japanese government and cannot be imported into a country other than
the approved destination.
Any diversion or re-export contrary to the export control laws and regulations of Japan and/or the country of
destination is prohibited.
•Please contact Mitsubishi Electric Corporation or an authorized Mitsubishi Semiconductor product distributor
for further details on these materials or the products contained therein.
Notes regarding these materials
© 2011 MITSUBISHI ELECTRIC CORPORATION. ALL RIGHTS RESERVED.
Publication Date : Oct.2011
9
Loading...
