Mitsubishi Q80BD-J71GP21S-SX, Q80BD-J71GP21-SX User Manual

CC-Link IE

Controller Network

Interface Board

User’s Manual

(Hardware)

Q80BD-J71GP21-SX

Q80BD-J71GP21S-SX

Thank you for purchasing the Mitsubishi program logic controller
MELSEC-Q series.

Prior to use, please read this and relevant manuals thorougly to fully
understand the product.

MODEL
MODEL

CODE

IB(NA)-0800386-D(0809)MEE

© 2007 MITSUBISHI ELECTRIC CORPORATION

MNETG-B-SW1-H

13JY32

SAFETY PRECAUTIONS

(Be sure to read these instructions before using the product.)

Before using this product, read this manual and the relevant manuals introduced
in this manual carefully and handle the product correctly with full attention to
safety.
Note that these precautions apply only to this product. Refer to the user's manual
of your CPU module for safety precautions on programmable controller systems.
In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".

Indicates that incorrect handling may cause

DANGER

CAUTION

Note that failure to observe the CAUTION level instructions may also lead to
serious results depending on the circumstances.

Be sure to observe the instructions of both levels to ensure personal safety.
Please store this manual in a safe place for future reference. This manual must be
forwarded to the end user.

hazardous conditions, resulting in death or severe
injury.

Indicates that incorrect handling may cause
hazardous conditions, resulting in minor or moderate
injury or property damage.

A-1

[Installation Precautions]

DANGER

Do not touch connectors while current is applied.
Doing so may cause an electric shock or malfunction.

Be sure to shut off all phases of the external power supply used by the
system before installing the CC-Link IE Controller Network board to or
removing it from the personal computer.
Failure to do so may cause an electric shock or damage to the product.

CAUTION

Use the CC-Link IE Controller Network board in an environment that meets
the general specifications provided in this manual. Using it in an environment
that does not meet the general specifications may result in an electric shock,
fire, malfunction, damage to or deterioration of the product.

Securely insert the CC-Link IE Controller Network board into the PCI bus slot
following the board installation instruction of the personal computer.
Incorrect insertion of the CC-Link IE Controller Network board may lead to a
malfunction, failure or drop of the board.

When installing the CC-Link IE Controller Network board, take care not to get
injured by an implemented component or a surrounding member.

Before handling the CC-Link IE Controller Network board, touch a grounded
metal object to discharge the static electricity from the human body. Failure to
do so may cause a failure or malfunction of the CC-Link IE Controller
Network board.

Handle the CC-Link IE Controller Network board in a place where static
electricity will not be generated.
Failure to do so may cause a failure or malfunction.

Do not directly touch a conductive part of the CC-Link IE Controller Network
board.
Doing so may cause a failure or malfunction.

Fix the CC-Link IE Controller Network board by tightening the board-fixing
screws within the specified torque range.
Insufficient tightening may result in a malfunction.

The CC-Link IE Controller Network board is included in an antistatic
envelope.
When storing or transporting it, be sure to put it in the antistatic envelope.
Failure to do so may cause a failure or malfunction.

Do not disassemble or remodel the CC-Link IE Controller Network board.
Doing so may result in a failure, malfunction, injuries and/or a fire.

Do not drop or apply a strong impact to the CC-Link IE Controller Network
board.
Doing so may cause a failure or malfunction.

A-2

[Wiring Precautions]

DANGER

Be sure to shut off all phases of the external power supply used by the
system before installing the CC-Link IE Controller Network board or starting
wiring.
Failure to do so may cause an electric shock, damage to the product or
malfunction.

Before applying power to operate the system after installation of the CC-Link
IE Controller Network board and wiring, be sure to put the cover on the
module.
Failure to do so may result in an electric shock.

CAUTION

Special skills and tools are required to connect the communication cable to
the connector plug, which is an exclusive product.
When purchasing it, please consult your local Mitsubishi representative.
Incomplete connection can result in a short, fire or malfunction.

Securely plug the communication cable to the connector of the CC-Link IE
Controller Network board. Then, check for any incomplete connection.
Poor contact may cause an erroneous input or output.

Place the communication cables and external power supply cable connected
to the CC-Link IE Controller Network board in a duct or clamp them.
If not, dangling cables may swing or inadvertently be pulled, resulting in
damage to the board or cables or malfunctions due to poor cable contact.

When disconnecting the cable from the CC-Link IE Controller Network board,
do not pull the cable part.
Pulling the cable that is still connected to the CC-Link IE Controller Network
board may damage the board and/or cable, or cause a malfunction due to
poor contact.

Prevent foreign matter such as chips or wiring debris from getting into the
personal computer.
Failure to do so can result in a fire, failure or malfunction.

Verify the rated voltage and pin-out, and connect the external power supply
cable properly.
Connecting a power supply with a different voltage rating, imperfect cable
crimping or faulty wiring may cause a fire or failure.

Use a specified tool for crimping of the cable and contacting pin. Imperfect
crimping may cause a malfunction.

Verify the pin-out and fully insert the crimped contacting pin into the
connector. Imperfect insertion may cause a failure or malfunction.

A-3

[Wiring Precautions]

CAUTION

Insert the wired external power supply cable into the external power supply
cable connector until a click is heard.
Imperfect insertion may cause a failure or malfunction.

Keep the external power supply cable away from the main circuit cable,
power cables and/or the load cables for any other than programmable
controllers. Ensure a distance of 100 mm (3.94 in.) between them. Failure to
do so may result in a malfunction due to noise, surge or induction.

Always ground the personal computer to the protective ground conductor.
Failure to do so may cause a malfunction

[Disposal Precautions]

CAUTION

When disposing of this product, treat it as industrial waste.

A-4

Revisions

* The manual number is given on the bottom right of the cover.

Print Date *Manual Number Revision

Apr., 2007 IB(NA)-0800386-A First edition

Oct., 2007 IB(NA)-0800386-B

Jan., 2008 IB (NA)-0800386-C

Sep., 2008 IB (NA)-0800386-D

Correction
Chapter 5, Section 7.2, Chapter 8

Correction
SAFETY PRECAUTIONS, Manual, Chapter 1,
Chapter 2, Chapter 3, Chapter 4, Chapter 5,
Chapter 6, Chapter 7

Correction
Chapter 2

This manual confers no industrial property rights or any rights of any other kind, nor does it
confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any
problems involving industrial property rights which may occur as a result of using the contents
noted in this manual.

© 2007 MITSUBISHI ELECTRIC CORPORATION

A-5

CONTENTS

1. OVERVIEW..................................................................................................... 1

2. PERFORMANCE SPECIFICATIONS ............................................................. 2

3. HANDLING ..................................................................................................... 4

3.1 Handling precautions ................................................................................ 4

3.2 Installation environment............................................................................ 6

4. PART NAMES................................................................................................. 7

5. EMC AND LOW VOLTAGE DIRECTIVE ...................................................... 10

5.1 Requirements for conformance to EMC Directive .................................. 10

5.1.1 Standards applicable to the EMC Directive..................................... 11

5.1.2 Installing devices in the control panel ............................................. 12

5.1.3 Noise filter (power supply line filter) ................................................ 14

5.2 Requirements for conformance to Low Voltage Directive ...................... 14

6. WIRING......................................................................................................... 15

6.1 Optical fiber cable ................................................................................... 18

6.2 External power supply cable................................................................... 19

7. INSTALLING SOFTWARE PACKAGES ....................................................... 21

7.1 Installation procedures ........................................................................... 21

7.2 Icons to be Registered............................................................................ 23

8. EXTERNAL DIMENSIONS ........................................................................... 24

A-6

Manual

The following is the manual relevant to this product.
Please purchase it if necessary.

Relevant Manuals

Manual Name

MELSECNET/G Network System Reference Manual (Controller Network)

This manual explains the system configuration, performance
specification, functions, handling and wiring instructions, and
troubleshooting of the CC-Link IE Controller network system.

CC-Link IE Controller Network Interface Board User's Manual (For
SW1DNC-MNETG-B)

This manual explains the system configuration, software package
installation and uninstallation, operating method for utilities, accessible
ranges and devices, and troubleshooting of the CC-Link IE Controller
Network board.

(Sold separately)

(Sold separately)

Manual Number

(Model Code)

SH-080668ENG

(13JV16)

SH-080691ENG

(13JZ02)

A-7

1. OVERVIEW

This manual explains the handling of the Q80BD-J71GP21(S)-SX CC­Link IE Controller Network interface board (hereinafter referred to as
CC-Link IE Controller Network board).
The CC-Link IE Controller Network board can be used as a control
station or normal station in the CC-Link IE Controller network system.

The packing list of the CC-Link IE Controller Network board is given
below.

Item

Q80BD-J71GP21-SX
CC-Link IE Controller Network interface
board

Q80BD-J71GP21S-SX
CC-Link IE Controller Network interface
board
Connector set
(for external power supply cable)
CC-Link IE Controller Network Interface
Board User's Manual (Hardware)
SW1DNC-MNETG-B CC-Link IE
Controller Network software package (CD-

*1

ROM)

Software license agreement 1 1

Software registration card 1 1

Q80BD-J71GP21-SX Q80BD-J71GP21S-SX

*1 The CD-ROM contains the User's Manual in PDF format.

Quantity

1—

—1

—1

11

11

1

2. PERFORMANCE SPECIFICATIONS

Performance specifications of the CC-Link IE Controller Network board
are shown below.

Q80BD-J71GP21-SX, Q80BD-J71GP21S-SX

Item

LB 32K points (32768 points, 4K bytes)

Max. link points
per network

Max. link points
per station

Transient transmission
capacity
Communications speed 1G bps
Number of stations per
network
Connection cable Optical fiber cable (Multi-mode fiber)
Overall cable distance 66000 m (When 120 stations are connected)

Station-to­station distance

Max. number of networks 239
Max. number of groups 32
Transmission path Duplex loop
Communication method Token ring method
Synchronization method Flag synchronization (Frame synchronization)
Encoding method 8B10B
Transfer format Ethernet II

Error control system

RAS functions

Transient transmission N: N communications

LW 128K points (131072 points, 256K bytes)
LX 8K points (8192 points, 1K byte)
LY 8K points (8192 points, 1K byte)
LB 16K points (16384 points, 2K bytes)
LW 16K points (16384 points, 32K bytes)
LX 8K points (8192 points, 1K byte)
LY 8K points (8192 points, 1K byte)

Min. 2 m
Max. 550 m (Core/clad = 50/125 ( m))

Q80BD-J71GP21-SX Q80BD-J71GP21S-SX

120 stations (Control station: 1; Normal station: 119)

FCS (Frame Check Sequence, CRC32 of the frame, Ethernet-

Loop back function by error detection and cable disconnection,

System-down prevention by control station switching,

Error detection by link special relays and link special registers,

Specification

Up to 1920 bytes

compliant)

etc.

2

Item

Number of boards that can be
installed

Installation slot PCI bus slot (Half size) or PCI-X bus slot (Half size)
Occupied slots 1 slot

External power
supply

PCI bus performance

5 V DC Internal current
consumption
Weight 0.12 kg 0.14 kg

Voltage
Current 0.27 A

Connector Connector set (Accessory)

Applicable
cable size

Allowable

*2

momentary
power failure
time

Noise durability

Q80BD-J71GP21-SX Q80BD-J71GP21S-SX

(No external power supply)

Bus voltage: 5V or 3.3 V DC (Universal PCI compliance)

0.88 A 0.88 A

Specification

*1

Up to 4

20.4 V to 31.2 V DC

0.50 to 1.25 mm2 [AWG20-16]

1ms (level PS1)

Noise voltage: 500vp-p

Noise width: 1 s

(By the noise simulator with

noise frequency 25 to 60Hz)

Bus width: 32 bit

Bus frequency: 33MHz

*1 This indicates the number of CC-Link IE Controller Network boards that can

be installed to a personal computer, not including any other boards such as

MELSECNET/H boards.

Note that it cannot exceed the number of physical PCI slots of the personal

computer.

*2 Use the power complies with CLASS2.

3

3. HANDLING

This section explains precautions for handling and installation
environment of the CC-Link IE Controller Network board.

3.1 Handling precautions

The following explains precautions for handling the CC-Link IE
Controller Network board.

DANGER

Do not touch connectors while current is applied.
Doing so may cause an electric shock or malfunction.

Be sure to shut off all phases of the external power supply
used by the system before installing the CC-Link IE
Controller Network board to or removing it from the
personal computer.
Failure to do so may cause an electric shock or damage to
the product.

4

CAUTION

For the tightening torque of the CC-Link IE Controller Network board­fixing screws, refer to the manual supplied with the personal computer.

Securely insert the CC-Link IE Controller Network board
into the PCI bus slot following the board installation
instruction of the personal computer.
Incorrect insertion of the CC-Link IE Controller Network
board may lead to a malfunction, failure or drop of the
board.

When installing the CC-Link IE Controller Network board,
take care not to get injured by an implemented component
or a surrounding member.

Before handling the CC-Link IE Controller Network board,
touch a grounded metal object to discharge the static
electricity from the human body.
Failure to do so may cause a failure or malfunction of the
CC-Link IE Controller Network board.

Handle the CC-Link IE Controller Network board in a place
where static electricity will not be generated.
Failure to do so may cause a failure or malfunction.

Do not directly touch a conductive part of the CC-Link IE
Controller Network board.
Doing so may cause a failure or malfunction.

Fix the CC-Link IE Controller Network board by tightening
the board-fixing screws within the specified torque range.
Insufficient tightening may result in a malfunction.

The CC-Link IE Controller Network board is included in an
antistatic envelope.
When storing or transporting it, be sure to put it in the
antistatic envelope.
Failure to do so may cause a failure or malfunction.

Do not disassemble or remodel the CC-Link IE Controller
Network board.
Doing so may result in a failure, malfunction, injuries and/
or a fire.
Do not drop or apply a strong impact to the CC-Link IE
Controller Network board.
Doing so may cause a failure or malfunction.
Prevent foreign matter such as chips or wiring debris from
getting into the personal computer.
Failure to do so can result in a fire, failure or malfunction.
When disposing of this product, treat it as industrial waste.

5

3.2 Installation environment

For installation of the personal computer in which the CC-Link IE
Controller Network board is installed, refer to the manual for the
personal computer.

CAUTION

Use the CC-Link IE Controller Network board in an
environment that meets the general specifications
provided in this manual.
Using it in an environment that does not meet the general
specifications may result in an electric shock, fire,
malfunction, damage to or deterioration of the product.

Always ground the personal computer to the protective
ground conductor.
Failure to do so may cause a malfunction.

6

4. PART NAMES

This section explains each part name and setting of the CC-Link IE
Controller Network board.

(1) Q80BD-J71GP21-SX

1)

RUN

ERR.

RD

SD
IN

2)

OUT

BD808C
317G51

(2) Q80BD-J71GP21S-SX

E.PW

4)

3)

E.PW

RUN
ERR.

1)

SD RD
IN

2)

OUT

E.PW

+24VDC
24G

NC

BD808C
317G51

7

No. Name Description

Indicator LED

RUN ERR.

1)

SD

Indicates the operating status of the CC-Link IE Controller Network
board.
The display format has three types: normal mode, error mode and
channel number confirmation.
(1) Normal mode

When the RUN LED is OFF or ON, the LED display becomes
normal mode.
If a communication error occurs in the mode, determine the error
in Select station network device status display on the "CC-Link
IE Controller Network diagnostics result" screen of the CC IE
Control utility.
For the Select station network device status display, refer to
"CC-Link IE Controller Network Interface Board User's Manual
(For SW1DNC-MNETG-B)".
LED name Status Description

RUN

SD

RD

ERR.

(2) Error m ode

RD

When the RUN LED is flashing, the LED display becomes error
mode.
If an error occurs in the mode, check the error description on the
Event Viewer screen.
LED name Status Description

RUN

SD

RD

ERR.

(3) Channel number confirmation mode

This mode is for checking the channel No. of each board.
The LED displays the channel No. assigned to each board.
For details, refer to "CC-Link IE Controller Network Interface
Board User's Manual (For SW1DNC-MNETG-B)".

A WDT error occurred or the board

OFF

is being reset.
ON In normal operation
OFF Data has not been sent.
ON During data transmission
OFF Data has not been received.
ON During data reception
OFF No error
ON Error

Indicates the display format is in
Flashing

error mode.
ON

Indicates the display format is not in
OFF

error mode.
OFF —
ON —
OFF No driver response error
ON A driver response error occurred.
OFF No PCI bus error
ON A PCI bus error occurred.

8

No. Name Description

Connector for connecting optical fiber cable
(1) The cable terminal is as shown below.

IN Reverse loop transmission

Optical fiber cable

2)
connector

External power
supply LED

3)

E.PW

(2) For wiring of an optical fiber cable, refer to "CC-Link IE

Controller Network Interface Board User's Manual (For
SW1DNC-MNETG-B)".

Indicates the status of external power supply.

LED name Status Description

E.PW

Connector for connecting external power supply cable
The cable terminal is as shown below.

IN Forward loop reception

OUT Forward loop transmission

OUT Reverse loop reception

External power supply is not

OFF

supplied.
External power supply is being

ON

supplied.

External power

4)

supply cable
connector

(Board top)

9

24V
24G

E.PW

5. EMC AND LOW VOLTAGE DIRECTIVE

For the products sold in European countries, the conformance to the
EMC Directive, which is one of the European Directives, has been a
legal obligation since 1996. Also, conformance to the Low Voltage
Directive, another European Directive, has been a legal obligation since

1997.
Manufacturers who recognize their products must conform to the EMC
and Low Voltage Directives are required to declare that their products
conform to these Directives and put a "CE mark" on their products.

5.1 Requirements for conformance to EMC Directive

The EMC Directive specifies that products placed on the market must
"be so constructed that they do not cause excessive electromagnetic
interference (emissions) and are not unduly affected by electromagnetic
interference (immunity) ". The applicable products are requested to
meet these requirements.
The sections 5.1.1 through 5.1.3 summarize the precautions on
conformance to the EMC Directive of the machinery constructed using
the CC-Link IE Controller Network board.
The details of these precautions has been prepared based on the
control requirements and the applicable standards. However, we will not
assure that the overall machinery manufactured according to these
details conforms to the above-mentioned directives.
The final decision on the method for the EMC Directive conformance
and the application must be made by the manufacturer of the
machinery.

10

5.1.1 Standards applicable to the EMC Directive

The standards applicable to the EMC Directive are listed below.
All test items were tested by installing each device on a personal
computer bearing a CE certification logo.

Specification Test item Test details Standard value

Measures
electromagnetic
emissions from the
product.

Measures
electromagnetic
emissions from the
product to the power
line.

Immunity test in
which static
electricity is applied
to the cabinet of the
equipment.

Immunity test in
which a burst noise
is applied to a power
line and signal line.

Immunity test in
which a field is
irradiated to the
product.

Immunity test in
which a high
frequency noise is
applied to a power
line and signal line.

Immunity test in
which a lightning
surge is applied to a
power line and
signal line.

EN61131-2:
2003

EN61000-6-4
Radiated noise

EN61000-6-4
Conducted noise

EN61000-4-2
Electrostatic
immunity

EN61000-4-4
Electrical fast
transient/ burst
immunity

EN61000-4-3
Radiated
electromagnetic
field immunity (AM
modulation)

EN61000-4-6
Conducted
disturbances
immunity

EN61000-4-5
Surge immunity

*1 QP: Quasi-peak value, Mean: Mean value

30M-230MHz QP: 30 dB V/m
(30 m in measurement range)
230M-1000MHz QP: 37 dB V/m
(30 m in measurement range)

150k-500kHz QP: 79 dB, Mean: 66

*1

dB
500k-30MHz QP: 73 dB, Mean: 60

*1

dB

4 kV Contact discharge
8 kV Aerial discharge

Power line: 2 kV
Data communication: 1 kV
Digital/Analog I/O (shielded): 1 kV

10 V/m, 26-1000 MHz,
80%AM modulation@1 kHz

3 V

Power line: 2 kV (CM), 1 kV (DM)
Data communication (shielded): 1 kV
(CM)
Digital/Analog I/O (shielded): 1 kV
(CM)

*1

*1

11

5.1.2 Installing devices in the control panel

Installing devices in the control panel has a considerable effect, not only
securing safety but also shielding the noise generated from the personal
computer in the control panel.

(1) Control panel

(a) Use a conductive control panel.

(b) When attaching the control panel's top plate or base plate,

mask painting and weld so that good surface contact can be
made between the panel and plate.

(c) To ensure good electrical contact with the control panel, mask

the paint on the installation bolts of the inner plate in the
control panel so that contact between surfaces can be ensured
over the widest possible area.

(d) Ground the control panel with a thick wire so that a low

impedance connection to ground can be ensured even at high
frequencies.

(e) Holes made in the control panel must be 10 cm (3.94 in.)

diameter or less. If the holes are 10 cm (3.94 in.) or larger,
radio frequency noise may be emitted.
In addition, because radio waves leak through a clearance
between the control panel door and the main unit, reduce the
clearance as much as practicable. The leakage of radio waves
can be suppressed by the direct application of an EMI gasket
on the paint surface.

Maker name Series type

KITAGAWA INDUSTRIES CO., LTD. US series

ZIPPERTUBING (JAPAN) LTD. 71TS series

SEIWA ELECTRIC MFG CO., LTD. E02S A

Our tests have been carried out on a panel having the
damping characteristics of 37 dB max. and 30 dB mean
(measured by 3 m method with 30 to 300MHz).

12

(2) Connection of power and ground cable

The power supply cable and ground cable for a personal computer
should be laid out as follows:

(a) Provide a grounding point near the power supply of personal

computer. Ground the FG (frame ground) terminal of the
personal computer and the SLD (shield) terminal of the CC­Link IE Controller Network board with the thickest and shortest
grounding wire (wire for grounding) possible (about 30 cm
(11.81 in.) or less in length). Since the FG and SLD terminals
function to ground the noise generated in the personal
computer, it is necessary to ensure the lowest possible
impedance.
As the wires are used to relieve the noise, the wire itself
contains a large amount of noise and thus short wiring
prevents from functioning as an antenna.

(b) Twist the ground cable leading to the ground point with the

power supply cable. By twisting it with the ground cable, the
noise leaking from the power supply cable may be grounded at
a higher rate. However, twisting the power supply cable with
the ground cable may not be necessary if a noise filter is
installed on the power supply cable.

13

5.1.3 Noise filter (power supply line filter)

A noise filter is a component which has an effect on conducted noise.
It is not required to fit the noise filter to the power supply line, but fitting it
can further suppress noise. (The noise filter has the effect of reducing
conducted noise of 10MHz or less.)
The precautions required when installing a noise filter are described
below.

(1) Do not bundle the wires on the input side and output side of the

noise filter.
When they are bundled, the output side noise will induct into the
input side wires.

Input side

(power supply side)

Introduction

Filter Filter

Output side

(device side)

Input side

(power supply side)

Output side

(device side)

(a) The noise will induct into input side when

the input and output wires are bundled.

(b) Separate the input and output wires.

(2) Ground the ground terminal of the noise filter to the control panel

using as short wiring as possible (about 10 cm (3.94 in.)).

Remarks

Reference noise filters are shown below.

Noise filter type Maker name Rated current Rated voltage

FN343-3/01

ZHC2203-11 TDK 3 A

SCHAFFNER

3 A

250 VFN660-6/06 6 A

5.2 Requirements for conformance to Low Voltage Directive

The CC-Link IE Controller Network board is out of the requirement for
conformance to the Low Voltage Directive, since it does not use the
power supply in the range of 50 to 1000V AC and 75 to 1500V DC.

14

6. WIRING

This section explains precautions for connecting cables to the CC-Link
IE Controller Network board.

(1) Precautions for general wiring

DANGER

Be sure to shut off all phases of the external power supply
used by the system before installing the CC-Link IE
Controller Network board or starting wiring.
Failure to do so may cause an electric shock, damage to
the product or malfunction.

Before applying power to operate the system after
installation of the CC-Link IE Controller Network board
and wiring, be sure to put the cover on the module.
Failure to do so may result in an electric shock.

CAUTION

When disconnecting the cable from the CC-Link IE
Controller Network board, do not pull the cable part.
Pulling the cable that is still connected to the CC-Link IE
Controller Network board may damage the board and/or
cable, or cause a malfunction due to poor contact.

Prevent foreign matter such as chips or wiring debris from
getting into the personal computer.
Failure to do so can result in a fire, failure or malfunction.

Always ground the personal computer to the protective
ground conductor. Failure to do so may cause a
malfunction.

15

(2) Precautions for communication cable wiring

CAUTION

Remarks

For optical fiber cables, refer to the "MELSECNET/G Network System
Reference Manual (Controller Network)".

Special skills and tools are required to connect the
communication cable to the connector plug, which is an
exclusive product.
When purchasing it, please consult your local Mitsubishi
representative.
Incomplete connection can result in a short, fire or
malfunction.

Securely plug the communication cable to the connector
of the CC-Link IE Controller Network board. Then, check
for any incomplete connection.
Poor contact may cause an erroneous input or output.

Place the communication cables connected to the CC­Link IE Controller Network board in a duct or clamp them.
If not, dangling cables may swing or inadvertently be
pulled, resulting in damage to the board or cables or
malfunctions due to poor contact.

16

(3) Precautions for external power supply cable wiring

CAUTION

Remarks

For details of the wiring method, refer to "CC-Link IE Controller Network
Interface Board User's Manual (For SW1DNC-MNETG-B)".

Verify the rated voltage and pin-out, and connect the
external power supply cable properly.
Connecting a power supply with a different voltage rating,
imperfect cable crimping or faulty wiring may cause a fire
or failure.

Use a specified tool for crimping of the cable and
contacting pin. Imperfect crimping may cause a
malfunction.

Verify the pin-out and fully insert the crimped contacting
pin into the connector. Imperfect insertion may cause a
failure or malfunction.

Insert the wired external power supply cable into the
external power supply cable connector until a click is
heard. Imperfect insertion may cause a failure or
malfunction.

Keep the external power supply cable away from the main
circuit cable, power cables and/or the load cables for any
other than programmable controllers. Ensure a distance of
100 mm (3.94 in.) between them. Failure to do so may
result in a malfunction due to noise, surge or induction.

Place the external power suppply cables connected to the
CC-Link IE Controller Network board in a duct or clamp
them.
If not, dangling cables may swing or inadvertently be
pulled, resulting in damage to the board or cables or
malfunctions due to poor contact.

17

6.1 Optical fiber cable

The following explains precautions for connecting the optical fiber
cables with the Q80BD-J71GP21-SX and Q80BD-J71GP21S-SX.

(1) Precautions for connection

(a) Use the dedicated optical fiber cable shown below for the

controller network system.

Type Model name (maker)

Multi-mode fiber (GI) QG series (Mitsubishi electric system & service Co., Ltd.)

(b) When connecting an optical fiber cable to the Q80BD-

J71GP21-SX and Q80BD-J71GP21S-SX, the cable bend
radius is restricted.
For details, check the specifications of the cable used.

(c) When laying the optical fiber cables, do not touch the fiber

cores of the cable-side and board-side connectors, and protect
them from dirt and dust.
If oil from the hand, dirt or dust is attached to the core, it can
increase transmission loss, causing a problem in data link.

(d) When connecting or disconnecting an optical fiber cable, hold

the connector part of the cable.

(e) Make a full connection between the cable-side and board-side

connectors until a "click" can be heard.

(f) When installing the Q80BD-J71GP21-SX or Q80BD-

J71GP21S-SX to the personal computer, secure a space of
around 10 mm (0.39 in.) to the right and left of the optical
connector. Depending on the adjacent boards and installing
slot position, connecting/disconnecting the optical cable may
be difficult. In this case, use the following dedicated tool.

Model name Maker

SCT-SLM Mitsubishi electric system & service Co., Ltd.

CC-Link IE Controller Network board

Board-side connector

Cable-side connector

Connector hook

18

6.2 External power supply cable

This section explains the method for connecting external power supply
cable to the Q80BD-J71GP21S-SX.

(1) Parts and tools required for external power supply cable

The following parts and tools are required for making external
power supply cable.

(a) Connector set (accessories)

Check that the following parts are included with the attached
connector set.

Type Model name Applicable wire size Quantity
Connector 1-178288-3 — 1
Contact 175218-2 AWG#20-16 3 (Spare 1)

(b) Cable

Use an external power supply cable with heat-resistant vinyl
sheath of 0.5 to 1.25 mm

(c) Tool

Use the following specified crimp tools.

Model Applicable wire size Inquiry
91558-1
1762956-1

AWG#20-16 Tyco Electronics

(2) Making external power supply cable

(a) Crimping a contacting pin

Using a crimp tool, crimp the cable and contacting pin.
Set the contacting pin and cable in the grooves of the crimp
tool, squeeze the handle, and make them stick together tightly.
For details of the crimp, refer to the instruction of the tool.
A strip length of the cable should be 5 to 7 mm (1/5 to 2/7 in.)

2

[AWG 20 to 16].

(b) Check for a crimp

Check if the cable (including a part of
the sheath) is evenly crimped to the
contacting pin.
If the cable part is crimped but not the
sheath part or the cable is stuck out,
the cable cut or a malfunction may
result.

19

Contacting pin

Cable

(c) Connecting to the connector

According to the following
pin-out, fully insert the
crimped cable to the
connector until a click is
heard.

Pin No. Description

124V
2 24G
3 Open

(3) Connecting external power supply cable to the board

Properly insert the wired external power supply cable to the
external power supply cable connector of the Q80BD-J71GP21S­SX until a click is heard.
Keep the cable away from the main circuit cable, power cables and/
or the load cables for any other than programmable controllers.
Ensure a distance of 100 mm (3.94 in.) between them.

POINT

Be sure to twist the external power supply cable.

Connector

Contacting pin

24V

24G

20

7. INSTALLING SOFTWARE PACKAGES

This chapter explains about installing the software packages and icons
to be registered.
For the uninstallation method, refer to "CC-Link IE Controller Network
Interface Board User's Manual (For SW1DNC-MNETG-B)".

7.1 Installation procedures

For details of the installation procedure, refer to "CC-Link IE Controller
Network Interface Board User's Manual (For SW1DNC-MNETG-B)".

POINT

(1) Multi-processor personal computers cannot be used because the driver

does not support them.
For details of the operating environment, refer to "CC-Link IE Controller

Network Interface Board User's Manual (For SW1DNC-MNETG-B)".
(2) Log on as a user having administrator authority.
(3) Cancel all applications registered in Startup and install the driver after

restarting Windows .
(4) Make sure to close other applications running on Windows (including

resident software such as antivirus software) before installation.
(5) If the installation failed, uninstall the software package if possible.
(6) When reinstalling the software package, do so after uninstalling the

current software package and restarting the personal computer.

21

START

Power OFF the personal computer.

Install the CC-Link IE Controller
Network board to the personal computer.

Power ON the personal computer.

Install SW1DNC-NMETG-B (driver).

Install SW1DNC-NMETG-B (utility).

END

22

7.2 Icons to be Registered

After installing the software packages, the icons shown below are
registered in [MELSEC], selected from [Start] - [Program].

Remarks

When using Windows XP Professional/Windows XP Home Edition/
Windows Vista
Programs] - [MELSEC].

Icon Utility name Description

CC IE Control utility Starts CC IE Control utility.

Device Monitor Utility Starts Device monitor utility.

MELSEC Data Link Function
HELP

*1 Generic term for Microsoft Windows Vista Home Basic Operating System,

Microsoft Windows Vista Home Premium Operating System,
Microsoft Windows Vista Business Operating System,
Microsoft Windows Vista Ultimate Operating System, and
Microsoft Windows Vista Enterprise Operating System.

*1

, the following icons are registered in [Start] - [All

Starts HELP for the data link function.

23

8. EXTERNAL DIMENSIONS

(1) Q80BD-J71GP21-SX

RUN

ERR.

RD

SD
IN

121

(4.76)

OUT

BD808C
317G51

18.5

(0.73)

174.5 (6.87)

181 (7.13)

168 (6.61)

107 (4.21)

98.5 (3.88)

(Unit: mm (inch))

24

(2) Q80BD-J71GP21S-SX

E.PW

E.PW

RUN

ERR.

SD RD
IN

121

(4.76)

OUT

E.PW

+24VDC

24G

NC

BD808C
317G51

18.5

(0.73)

174.5 (6.87)

181 (7.13)

168 (6.61)

107 (4.21)

98.5 (3.88)

(Unit: mm (inch))

Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States
and other countri es.
Ethernet is a registered trademark of Xerox.co.ltd in the United States.
Other company names and product names used in this document are trademarks or registered
trademarks of respective companies.

25

Warra nty

p

Mitsubishi will not be held liable for damage caused by factors found not to be the cause of
Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage,
secondary damage, accident compensation caused by special factors unpredictable by
Mitsubishi; damages to products other than Mitsubishi products; and to other duties.

For safe use

• This product has been manufactured as a general-purpose part for general industries, and

has not been designed or manufactured to be incorporated in a device or system used in
purposes related to human life.

• Before using the product for special purposes such as nuclear power, electric power,

aerospace, medicine or passenger movement vehicles, consult with Mitsubishi.

• This product has been manufactured under strict quality control. However, when installing the

product where major accidents or losses could occur if the product fails, install appropriate
backup or failsafe functions in the system.

Country/Region Sales office/Tel

U.S.A Mitsubishi Electric Automation Inc.
500 Corporate Woods Parkway Vernon
Hills, IL 60061
Tel : [phone]
Brazil MELCO-TEC Rep. Com.e Assessoria
Tecnica Ltda.
Rua Correia Dias, 184,
Edificio Paraiso Trade Center-8 andar
Paraiso, Sao Paulo, SP Brazil
Tel : [phone]
Germany Mitsubishi Electric Europe B.V. German
Branch
Gothaer Strasse 8 D-40880 Ratingen,
GERMANY
Tel : [phone]
U.K Mitsubishi Electric Europe B.V. UK
Branch
Travellers Lane, Hatfield, Herts., AL10
8XB,UK
Tel : [phone]
Italy Mitsubishi Electric Europe B.V. Italian
Branch
Centro Dir. Colleoni, Pal. Perseo-Ingr.2
Via Paracelso 12, 20041 Agrate B.,
Milano, Italy
Tel : [phone]
Spain Mitsubishi Electric Europe B.V. Spanish
Branch
Carretera de Rubi 76-80
08190 Sant Cugat del Valles,
Barcelona, Spain
Tel : [phone]
France Mitsubishi Electric Europe B.V. French
Branch
25 Boulevard des Bouvets, F-92741
Nanterre Cedex, France
TEL: [phone]
South Africa Circuit Breaker Industries LTD.
Tripswitch Drive, Elandsfontein Gauteng,
South Africa
Tel : [phone]

HEAD OFFICE : 1-8-12, OFFICE TOWER Z 14F HARUMI CHUO-KU 104-6212, JAPAN
NAGOYA WORKS : 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA, JAPAN

When exported from Japan, this manual does not require application to the Ministry
of Economy, Trade and Industry for service transaction permission.

Country/Region Sales office/Tel

Hong Kong Ryoden Automation Ltd.
10th Floor, Manulife Tower, 169 Electric
Road, North Point, HongKong
Tel : [phone]
China Ryoden Automation Shanghai Ltd.
3F Block5 Building Automation
Instrumentation Plaza 103 Cao Bao Rd.
Shanghai 200233 China
Tel : [phone]
Taiwan Setsuyo Enterprise Co., Ltd.
6F., No.105 Wu-Kung 3rd.RD, Wu-Ku
Hsiang, Taipei Hsine, Taiwan
Tel : [phone]
Korea HAN NEUNG TECHNO CO.,LTD.
1F Dong Seo Game Channel Bldg.,
660-11, Deungchon-dong Kangsec-ku,
Seoul, Korea
Tel : [phone]
Singapore Mitsubishi Electric Asia Pte, Ltd.
307 Alexandra Road #05-01/02,
Mitsubishi Electric Building
Singapore 159943
Tel : [phone]
Thailand F. A. Tech Co.,Ltd.
898/28,29,30 S.V.City Building,Office
Tower 2, Floor 17-18 Rama 3 Road,
Bangkpongpang, Yannawa,
Bangkok 10120
Tel : [phone]
Indonesia P.T. Autoteknindo SUMBER MAKMUR
Jl. Muara Karang Selatan Block a Utara
No.1 Kav. No.11 Kawasan Industri/
Pergudangan Jakarta - Utara 14440
Tel : [phone]
India Messung Systems Put,Ltd.
Electronic Sadan NO:111 Unit No15,
M.I.D.C BHOSARI,PUNE-411026, India
Tel : [phone]
Australia Mitsubishi Electric Australia Pty. Ltd.
348 Victoria Road, PostalBag, No 2,
Rydalmere, N.S.W 2116, Australia
Tel : [phone]

Specifications subject to change without notice.

Printed in Ja

an on recycled paper.
