Mitsubishi ODYSSEY, AURA, MYSTRAL, Trium Aura, Trium Mystral User Manual

...

This guide describes the operation of the Trium dual band GSM/GPRS telephones

Aura - Mystral - Odyssey

Edition 1, 2002. © Mitsubishi Electric Telecom Europe, 2002 Whilst every effort has been made to ensure the accuracy of the instructions contained in this guide, Mitsubishi Electric reserves the right to make improvements and changes to the product described in this guide and/or to the guide itself, without prior notice.

English

SAR

THIS AURA, MYSTRAL OR ODYSSEY PHONE MEETS THE EU REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Before a phone model is available for sale to the public, compliance with the European R&TTE directive (1999/5/CE) must be shown. This directive includes as one essential requirement the protection of the health and the safety for the user and any other person. Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits for exposure to radiofrequency (RF) energy recommended by The Council of the European Union1 . These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines were developed by independent scientific organisations through periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for mobile phones (CENELEC standard EN 50360: 2000) employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit2 recommended by The Council of the European Union is 2.0 W/kg. Tests for SAR have been conducted using standard operating positions (with reference to CENELEC standard EN 50361: 2000) with the phone transmitting at its highest certified power level in all tested frequency bands3. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station antenna, the lower the power output. The highest SAR value for this Trium Aura, Mystral or Odyssey model when tested for compliance against the standard was 1.120 W/kg. While there may be differences between the SAR levels of various phones and at various positions, they all meet the EU requirements for RF exposure. There are a number of independent sources of information available to users including:

Royal Society of Canada: www.rsc.ca

The International Commission on Non-Ionizing Radiation Protection (ICNIRP):

www.icnirp.de

The US Food and Drug Administration: www.fda.gov/cdrh/ocd/mobilphone.html

The World Health Organization: www.who.int/emf

Mitsubishi Electric belongs to the MMF, an international association of radio equipment manufacturers. The MMF produces information such as this in accordance with its purpose of developing and presenting industry positions to independent research organisations, government and other research bodies.

Mobile Manufacturers Forum

Diamant Building, 80 Blvd. A. Reyers

B-1030 Brussels

Belgium

www.mmfai.org

1. European recommendation 1999/519/CE

2. The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten grams of tissue. The limit incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements

3. The maximum level of GSM emitted power is 250mW at 900 MHz and 125 mW at 1800 MHz according to the GSM standard.

Aura, Mystral and Odyssey at a glance (key shape varies slightly depending on model)

ANTENNA

PROGRAMMABLE SOFTKEYS

Display above key indicates function

ON/OFF, END KEY

See next page

ALPHANUMERIC KEYS

- , , . Press to enter numbers, characters and punctuation

, hold down to call

voice mail

to , hold down for

speed dialling

, hold down to enter + prefix, 'P' (pause) or '_' (wildcard)

, hold down to lock keypad. To unlock, press

Unlock then

EARPIECE

GRAPHIC DISPLAY

See next page.

CURSOR KEY

See next page

CALL/SEND KEY

See next page

CHANGEABLE FRONT

COVER (except Mystral)

See page 59

CHANGEABLE BATTERY

COVER (at the back of the

phone)

See page 12

MICROPHONE

HEADSET, ACCESSORIES AND

AC/DC CHARGER SOCKET

Using the keys to follow the actions described in this guide

To help you quickly understand your way around this manual we have used symbols and expressions that are present on the keys and in the display.

Graphic display

The display shows icons, alphabet characters, numbers, menu list and instructions to the user. Use the above keys to navigate to the phone book, Internet/WAP™ and the menu. The rest of this guide gives the procedures to access these functions. Icons in the display are described on page 5.

LEFT SOFTKEY. The function of the softkey appears in the graphic display above the key.

CALL/SEND key. Press to make/answer a call. In stand-by, press to display the last dialled numbers you dialled.

RIGHT SOFTKEY.

END key. Hold down to turn the phone on/off. Press to end a call or return to stand-by.

UP ARROW on the cursor key. Press to scroll up menus (while in the menu). In stand-by, press to access the volume control.

DOWN ARROW on the cursor key. Press to scroll down menus (while in the menu). In stand-by, press to access the alert mode (ring, silent, vibrate, etc.)

RIGHT ARROW on the cursor key. Press to access the main menu or select a menu option.

LEFT ARROW on the round cursor key. Press to access the

phone book or return to the previous display.

Function Softkey with the corresponding function name.

For example, Internet means press the softkey under

the word Internet. Messages Words in this format are the words in the display. Select means use and on the cursor key to scroll to the re-

quired item in the menu and validate by pressing . For ex-

ample, "select Phone Book" means scroll to the menu item

Phone Book and validate by pressing . Press means press the corresponding key.

Press means press the SEND key.

Understanding the icons

Icons in the display have the following meaning:

SIM memory in use Phone memory in use. When you enter a name and address you can

choose the icon you want to go with it.

Roaming. Displayed when the phone is logged on to a network different from its home network.

Short message service (SMS). Displayed when you have one or more messages to read. It flashes when the SMS message bank is full and cannot store new messages. Delete one or more old messages to make space. The availability of this feature is network dependent.

Voice mail. Displayed when you have a voice mail message to read. The availability of this feature is network dependent.

Call diverting. Indicates whether incoming calls are permanently being diverted. The availability of this feature is network dependent.

Battery level indicator. Permanently displayed to indicate the current charge level of the battery. Three levels are shown. low, medium, full. It flashes when the battery is almost empty.

Arrow keys. Displayed during menu operation to indicate that more items in the menu can be displayed if or are pressed.

Line 2. Indicates the second line is in use. The availability of this feature is network dependent.

Unanswered call. Displayed when an incoming call is unanswered. Signal strength level. It indicates the strength of the received sig-

nal. The more bars the stronger the signal. If no network is available the display remains blank.

Keypad lock. Indicates whether keypad lock is on or off. Alarm clock icon. Vibrator alert icon. Ring tone off. All tones are off. Mute icon. Tegic edit mode icon. WAP™ 'live' connection icon. WAP™ 'live' connection in security mode icon. GPRS attached in idle mode icon WAP™ GPRS connection icon. WAP™ GPRS connection in security mode icon. Auto-switch function activated icon.

Introduction

Thank you for purchasing the Trium Aura, Mystral or Odyssey dual band mobile telephone. The mobile telephone described in this guide is approved for use on all GSM 900/1800 and GPRS networks. Services and display messages may be different. This depends on your operator’s implementation. As with all types of radio transceivers this mobile telephone emits electromagnetic waves and conforms to international regulations when it is used under normal conditions and in accordance with the safety and warning messages given below and on page 13.

General safety

It is important to follow any special regulations regarding the use of radio equipment, due to the possibility of radio frequency, RF, interference. Please follow the safety advice given below. More safety information is described on page 13.

This apparatus is intended for use only when supplied with power from AC/DC adaptor chargers (FZ14130070, FZ14130060, FZ14130050, FZ14130080, FZ14130090 or FZ14130100) and the vehicle kit (FZ14180040). Use of any other charger or adaptor will invalidate any approval given to this apparatus and may be dangerous.

Switch off phone and remove the battery when in an aircraft. The use of mobile telephones in an aircraft may endanger the operation of the aircraft, disrupt the cellular mobile phone network and is illegal. Failure to observe this instruction may lead to suspension or denial of mobile telephone services to the offender, or legal action, or both. Respect national regulations on the use of mobile telephones in vehicles. Do not use a handheld phone while driving. If you don't have a hands free car kit, stop and park your vehicle safely before using your phone. Switch off phone when at any refuelling point or near inflammable material. Switch off phone in hospitals and any other place where medical equipment may be in use. Respect restrictions on the use of radio equipment in fuel depots, chemical plants or where blasting operations are in progress. There may be a hazard associated with the operation of phones close to inadequately protected personal medical devices such as hearing aids and pacemakers. Consult your doctor or the manufacturers of the medical device to determine if it is adequately protected. Operation of phone close to other electronic equipment may also cause interference if the equipment is inadequately protected. Observe any warning signs and manufacturers recommendations. Avoid prolonged contact between the antenna and your skin when the phone is switched on.

Table of contents

1. Getting started........... 8

Preparing to make your

first call ............................. 8

Making your first call ........ 9

Battery ............................ 11

2. Safety information .. 13

Vehicle safety .................. 13

Emergency calls............... 13

Care and maintenance .... 13

AC/DC adaptor chargers.. 14

Battery use ...................... 14

Your responsibility........... 15

Security codes ................. 15

Disposing of waste

packaging ....................... 15

3. Using your phone..... 16

Standby display............... 16

Important icons............... 16

Dialling from memory ..... 17

Last dialled numbers ....... 17

Speed dialling ................. 18

Silent and vibrate

alert modes ..................... 18

Hands free features......... 18

Muting ............................ 18

Volume adjustment......... 19

Sending DTMF tones ....... 19

Pause feature .................. 19

Holding and retrieving

a call................................ 20

Call waiting, swapping and multi-party

conference calls............... 20

4. The menu .................. 22

Access to the menus ........ 22

Menu map ....................... 22

Entering text .................... 22

Network services .............. 25

Phone book...................... 25

Messages (SMS) ............... 29

Calls & Times.................... 33

Settings - customising

your phone ...................... 36

Using the office tools....... 51

Games.............................. 53

Currency-converter........... 53

Internet/Wireless Application

Protocol (WAP™) ........... 54

GSM man machine

interface codes................. 57

5. Accessories ............... 58

Using the headset ............ 58

Changing the front cover (for Aura and Odyssey

only)................................. 59

6. Appendix................... 60

Glossary ........................... 60

Trouble shooting.............. 62

Error messages................. 63

Guarantee ........................ 66

7. Declaration of com-

pliance ...................... 67

Getting started

In order to become familiar with the phone quickly, follow these simple steps.

Preparing to make your first call

Inserting the SIM card

Unpack the phone and insert the SIM card into the holder, as shown below, with the gold contacts facing down.

Fitting the battery

Connect the battery as shown below.

Placing the battery cover

Place the battery cover as shown below.

Getting started

Making your first call

Turning on the phone

Stand-by display

From the stand-by display:

See page 44 to set the time and date.

Making a call

The phone can only make and receive calls when it is switched on, unlocked (see page 16), has a valid SIM card inserted and has GSM/GPRS* network service coverage. If the phone cannot find a valid network the display remains blank.

* The availability of GPRS depends on your mobile phone model and on your subscription

If there is not enough charge in the battery to power the phone follow the instructions for battery charging on page 11.

Press and hold down for two seconds. If this is the first time you have used the phone or you removed and replaced the battery, the phone prompts you for the date and time. If you inserted the SIM card incorrectly, the error message Check SIM! appears. Remove the cover and battery and make sure the SIM is inserted with the gold contacts facing down.

If the mobile is locked, Code: appears. Enter the 4digit phonelock code and press OK . The default is 4zeros, e.g. 0000. If your SIM is PIN protected, Enter PIN: appears. Enter the PIN code and press OK . An animated screen icon appears, then the stand-by display.

See page 41 to change your PIN and lock codes!

Press... to...

enter phone menu.

directly access to numbers stored

in phone books. access volume control. access alert tones. access the last dialled numbers list. stop the dialling or end a call.

enter numbers in the display (see also "Speed dialling", page 18).

Enter the desired telephone number using the numeric keys ( -

). You can enter a maximum of 46 digits. Correct any mistakes by pressing Clear . Hold down this key or press to clear the whole display. To dial (send) the number press .

12312

The phone rings and the call connects like a normal telephone. A call timer appears.

You can also get the following messages if the call does not connect or you use the second line:

If the dialled number matches one stored in the phone book then the name of the called person appears in the display.

Receiving a call

The phone rings (or vibrates, see page 37 to set) when it receives a call. See page 38 to set the incoming ring tone. See page 39 to set the backlight.

Answering the call

No ring

Pressing No ring stops the sound of the ring tone, which allows you to, for example, go out of a room before pressing.

Service number presentation

If you have the service number presentation your phone displays the following information.

If you have a second line, appears if the call has been received on your line 2 number (see page 20 for details).

Rejecting the call

To reject, or return a busy signal to the caller:

Ending a call

You can prefix international calls with 00 or +. To enter the + symbol before a number press and hold down .

Your phone

displays...

if the...

Busy called party is engaged.

Not allowed

(fixed dialling)

number dialled is not authorised by the FDN list (see page 28). call is made using the second line (see page 36).

Press .

If the ring tone volume is set to zero (off) or if the phone has been set to 'Vibrate' mode, no audible sound is heard.

Your phone displays... if the number is...

Unknown number, then Call1 when connected

unavailable.

the caller’s number available but not in phone books. Withheld number, then Call1 when connected

withheld.

Press .

Press . The call timer stops and disappears.

Getting started

The phone stores the caller's number, if available, in the received calls log (see page 33).

Turning off the phone

The mobile turns off.

Battery

Low battery warning

When the battery power falls to its lowest level the message Low Battery! appears and a low battery warning tone sounds. If you are on a call, terminate the call and turn off the phone by pressing and holding down . Recharge the battery as shown below or swap it for a charged one. Do not turn off the phone by removing the battery, data can be lost.

Charging the battery

To ensure a long life for your battery, re-charge it only when the Low Bat- tery! warning appears and the 'low battery' tone is heard. Connect the charger to the phone as shown.

Plug the charger into the wall socket and turn on the mains. The battery starts to charge. The phone can be used while charging but this increases the charging time.

Charging indicators when the mobile is off

During charging Charging... appears. When charging is finished, Battery full appears. It is normal for the battery to get warm during charging.

Charging indicators when the mobile is on

During charging the icon flashes 1-2-3 bars continuously. When charging completes the battery indicator shows three solid bars.

Waiting a few seconds or pressing the Exit softkey returns the phone to the stand-by display.

Press and hold down .

While inserting the plug in the phone AC/DC connector make sure the Trium logo () appears on top.

Disconnecting the charger

At the end of charging, disconnect the charger from the phone (see below), switch off and remove the plug from the mains.

Typical charging times using the AC/DC adaptors (FZ14130070, FZ14130060, FZ14130050, FZ14130080, FZ14130090 or FZ14130100)

Removing the battery

Remove the battery as shown below.

Battery type Typical charging time

Standard battery (FZ14130130) 2 hours 10 minutes

Safety information

Vehicle safety

• Respect national regulations on the use of mobile telephones in vehicles.

• Road safety always comes first! Always give your full attention to driving.

• Do not use a hand-held phone while driving. If you do not have a ‘hands free’ car kit, stop and park your vehicle safely before using your phone.

• If equipped with a correctly installed vehicle kit allowing ‘hands free’ operation and you need to make or receive a call, ensure that it is done sensibly and safely. Use pre-programmed numbers where possible and keep calls short and routine.

• If incorrectly installed in a vehicle the operation of mobile telephones can interfere with the correct operation of the vehicle electronics, such as ABS antilock brakes or air bags. To avoid such problems ensure that only qualified personnel carry out the installation. Verification of the protection and operation of the vehicle electronics should form part of the installation. If in doubt consult the manufacturer.

• Do not place the phone on the passenger seat or where it could break loose during sudden breaking or a collision. Always use the holder.

• The use of an alert device to operate a vehicle's lights or horn on public roads is not permitted.

Emergency calls

In Europe, provided the phone has GSM service, emergency calls can be made using the European standard emergency number, 112, even if you do not have a SIM in the phone. Emergency calls can even be made if the phone is PIN or electronically locked or call barred. In some countries local emergency numbers can still be used for emergency purposes but the phone may have to contain a valid SIM card. When making an emergency call remember to give all the necessary information as accurately as possible. The phone may be the only means of communication at the scene of an emergency therefore do not cut off the call until told to do so.

Care and maintenance

This mobile telephone is the product of advanced engineering, design and craftsmanship and should be treated with care. The suggestions below can help you to enjoy this product for many years.

• Do not expose the phone to any extreme environment where the temperature or humidity is high.

• Do not expose or store in cold temperatures. When the phone warms up after switch on, to its normal temperature, moisture can form inside which can damage the electrical parts.

• Do not attempt to disassemble the phone. There are no user serviceable parts inside.

• Do not expose the phone to water, rain or spilt beverages. It is not waterproof.

Mobile phones rely on wireless and landline networks which cannot be guaranteed in all conditions. Therefore you should never rely solely on wireless phones for essential emergency communications.

• Do not abuse this phone by dropping, knocking or violent shaking. Rough handling can damage it.

• Do not clean the phone with strong chemicals or solvents. Wipe it only with a soft, slightly dampened cloth.

• Do not place the telephone alongside computer discs, credit or travel cards or other magnetic media. The information contained on discs or cards may be affected by the phone.

• Do not connect incompatible products. The use of third party equipment or accessories, not made or authorised by Mitsubishi Electric, invalidates the warranty of your phone and can be a safety risk.

• Do not remove the labels. The numbers on it are important for service and other related purposes.

• Do contact an authorised service centre in the unlikely event of a fault.

AC/DC adaptor chargers

This apparatus is intended for use only when supplied with power from AC/DC adaptor chargers (FZ14130070, FZ14130060, FZ14130050, FZ14130080, FZ14130090 or FZ14130100). Use of any other charger or adaptors will invalidate any approval given to this apparatus and may be dangerous.

Battery use

You can charge a battery hundreds of times but gradually it wears out. When the operating time (stand-by and talk time) is noticeably shorter than normal it is time to buy a new battery.

• Do not leave batteries connected to a charger longer than necessary. Overcharging shortens battery life.

• Disconnect battery chargers from the power source when not in use.

• Do not expose batteries to high temperatures or humidity.

• Do not dispose of the batteries in fire. They can explode.

• Avoid putting the batteries into contact with metal objects which can short circuit the battery terminals (e.g. keys, paper clips, coins, chains etc.).

• Do not drop or subject the batteries to strong physical shocks.

• Do not try to disassemble any of the battery packs.

• Use only the recommended battery chargers (see page 6).

• If the battery terminals become soiled, clean them with a soft cloth.

• It is normal for batteries to become warm during charging.

• Old batteries must be returned to the place of sale or to a place where used batteries are properly disposed of. Do not dispose of old batteries together with household waste.

Battery disposal

In compliance with European environmental protection directives, used batteries must be returned to the place of sale, where they are collected free of charge. Don't throw away your batteries in your household waste.

Safety information

Your responsibility

This GSM mobile telephone is your responsibility. Please treat it with care respecting all local regulations. It is not a toy; please keep it in a safe place at all times and out of the reach of children. Become familiar with and use the security features to block unauthorised use if your phone and/or SIM card are lost or stolen. Call your service provider immediately to prevent illegal use. When not in use lock, turn off the phone and remove the battery.

Security codes

The phone and SIM card are delivered to you pre-programmed with codes that protect the phone and SIM card against unauthorised use. A short description of each follows. See page 42 to change your PIN and phonelock codes.

PIN and PIN2 codes (4-8 digits)

All SIM cards have a PIN (Personal Identity Number). It protects the card against unauthorised use. Some SIM cards also have a PIN2 code that protects specific features such as fixed dialling numbers. Entering the wrong PIN code three times in succession disables the SIM card and the message SIM Blocked. Enter PUK: appears. To unblock the SIM you need the PUK (PIN Unblock Key) code, obtainable only from your service provider.

PUK and PUK2 codes (8 digits)

Obtain the PUK code from your service provider. Use it to unblock a disabled SIM card (see page 43). The PUK2 code is required to unblock the PIN2 code (see above).

Call barring password (4 digits)

This password is used to bar various types of calls, made or received, from the phone (see page 43).

Voice mail password

This password protects you against unauthorised access to your voice mail.

Phonelock code (4 digits)

This code is set to all zeros on delivery. You can change it. Once changed it cannot be identified by the manufacturer over the phone. Please refer to page 41 for more details.

You must remember and make yourself familiar with the purpose and operation of these codes.

Disposing of waste packaging

The packaging used for this phone is made of recyclable materials and as such should be disposed of in accordance with your national legislation on the protection of the environment.

Please take care to separate the cardboard and plastic elements and to dispose of them in the correct manner.

Using your phone

For turning on/off the mobile and making/receiving calls, see pages 8 to 11.

Standby display

Keypad lock

To prevent accidental operation of the phone, turn on keypad lock. You can still answer calls by pressing . When you end a call, the keypad lock reactivates automatically. To turn keypad lock on:

To turn keypad lock off:

You can also use the menu:

Internet/Wireless Application Protocol (WAP™)

Press Internet in the stand-by display to access the internet main menu to access your home page or any WAP™ portal. You can configure up to 5WAP™ profiles and 10bookmarks. See page 54 for more information.

Messages (SMS)

Press SMS in the stand-by display to access the short messages menu. You can also access it from the main menu. See page 29 for more information.

Backlight operation

The backlight is normally off. When a key is pressed the display and keypad backlight turns on for 10 seconds. If an incoming call is received the backlight turns on and remains on for 10 seconds after the call is answered.

Important icons

• displays when you do not answer one or more calls. Press Read to view the callers' numbers if available and the date and time the call was received. Press to call the number. The phone stores unanswered call numbers in the unanswered calls log (see page 33 for details).

• appears when you receive one or several messages. Press Read to view the message or press to speed dial your voice mail message centre (see pages 5 and 40 for more details).

• appears when you receive one or several SMS messages. Press Read to view the SMS inbox message.

Press and hold down . appears.

Press Unlock plus or press and hold .

Press . Select Settings. Select Phone settings. Select Keypad lock to turn keypad lock

on. Press Unlock plus to turn keypad lock off or press and

hold .

123

Using your phone

If flashes, your inbox is full. Delete one or more old messages to make space for one or more new messages (see page 29 for more details).

The display shows the number and type of messages:

Press Read to select the type of message you want to read. Press Select or to view the message.

Dialling from memory

You can dial any number stored in the SIM, or the phone memory. To do this:

from the phone book

from the calls log memory list

The phone stores the last 10 numbers dialled, the last 10 unanswered call numbers (if available) and the last 10 received answered numbers.

Last dialled numbers

Quick access to the last 10 dialled numbers can also be obtained by pressing.

When one indicator displays the date is temporarily cleared. When two or three indicators display the time and date are temporarily cleared.

Press to enter the phone book list. Use or to scroll to the name required. Press .

In case of a SIM memory contact or of a phone memory con- tact with one number assigned, the phone dials the number. In case of a phone memory contact with many numbers assigned, use or to scroll to the number required and

press . The phone dials the number.

See page 25.

Press . Select Calls & Times. Select Calls log. Select Last dial, Unanswered or Received. Use or to scroll to the number required. Press to dial the number.

See page 33.

In the stand-by mode pressing displays a list of the last dialled numbers. Use or to scroll to the number required.

Press to dial the number.

The phone stores the last dialled numbers in the phone memory, not in the SIM.

12312345123

Speed dialling

You can assign any key to any telephone number stored in the SIM. To dial such a number:

By default, is always allocated to the voice mail number (see page44). See page 40 to allocate numbers to the speed dialling keys.

Silent and vibrate alert modes

To avoid disturbing others you can silence the incoming ring and alert tones.

Turning on

displays when the silent alert mode feature is activated. displays

when the Vibrate or Vibrate then Ring features are activated.

Turning off

Hands free features

When you want to share your call with an audience, or you are in your car, use the “hands free” feature.

Turning the hands free feature on

When making a call:

When receiving a call:

Turning the hands free feature off

Muting

You can mute the microphone during a call, e.g. when you want to talk to someone nearby without the person on the phone hearing.

Turning the microphone off

Turning the microphone on

Press and hold down the key ( - ). The number appears and attempts to connect.

Press . Select Silent, Vibrate or Vibrate then Ring.

Press . Select Ring or Vibrate & Ring.

If the ring tone volume is set to 0 a warning message appears in the display.

Press Speak.on to turn the hands free feature on during the calling process.

Press Speak.on to accept the incoming call.

Press Speak.off .

Press Options . Select Mute and select Yes. A warning message appears in the display. also appears.

Press Options .

1212121

Using your phone

Volume adjustment

To adjust the volume:

Sending DTMF tones

Some remote access services require DTMF tones. These tones are used by regular telephones when you dial and when you answer questions from an automated voice service. If you are in a conversation and manually entering the numbers, no extra configuration is necessary. If, however, you want to send a number stored in memory, you must set DTMF to automatic.

Manually

To send individual DTMF tones directly from the keypad during a conversation:

The tones are heard in the earpiece and sent immediately.

Automatically

To send a consecutive string of DTMF tones during a conversation:

Pause feature

You can enter and store telephone numbers and a sequence of DTMF tones together as long as you separate them by a 'pause'. To enter a pause between numbers, press and hold down . The letter p appears. The phone can store several pauses together for a maximum of 20-46 characters (dependent upon the SIM and the phone memory capacity).

Select Unmute. A warning message appears in the display. disappears.

A new call restores the microphone to on.

Use or to increase or decrease the volume and press OK . Press Exit or wait 2 seconds to return to the previous display.

See also page 38.

Press the required keys.

Press Options . Select Auto DTMF. Enter the DTMF numbers into the display either directly using the keypad or from a number stored in the phone book (under Names ). Press OK . The phone sends the tones and then shows the normal conversation display.

DTMF tones cannot be sent when a call is on hold.

2121234

Holding and retrieving a call

To put a call on hold during a conversation:

To retrieve a call:

To make a second call when one call is on hold:

Alternatively, use Options to display a menu of the actions described above. Scroll to the required option and press Select or (see also "Multi-party or conference calls", page21).

Call waiting, swapping and multi-party conference calls

Call waiting

Use call waiting, a network feature, to receive a second incoming call when already engaged in a call. This puts an existing call 'on hold' while you answer or make a second call. To turn the call waiting service on or off:

Action when receiving a second call

You hear a 'double beep' when your phone receives a second call. An animated phone icon and the telephone number (if available) also appear. To accept the second call

To reject the second call:

To swap between the two connected calls:

Press .

Enter a number in the display. Press to dial the number. After the second call has been established press to swap

between the two calls. To end either the current call or the held call select End active or End held in the Options menu. The remaining call is automatically retrieved.

Press to end the remaining call.

Both calls can be ended at the same time by pressing .

Press . Select Settings. Select GSM Services. Select Call waiting. Select Activate or Cancel. The network confirms your request.

The confirmation can take several seconds. Press Exit or to return to the standby display.

Press . This answers the second call and puts the first call on hold.

Press Reject . This returns a busy signal to the second caller.

Press .

1234123

Using your phone

Multi-party or conference calls

Use this feature to make or receive between 2 to 5calls at the same time with all parties being able to hear and talk with each other.

* These items in the Options menu appear if more than 2 calls are joined in the conference call. Throughout the conference call the display confirms and shows the actions you selected from the options menu.

Make and establish a call in the normal way and press . Enter another number into the display and press . The first call

is put on hold when the second call becomes active. Press Options for the following menu:

Option Description

Auto DTMF to enter a DTMF string to the active call only

Swap Swaps between active and call on hold

Join

Joins active and call on hold to make a multi-party or conference call

Mute/Unmute Turns on or off the microphone

End held Ends the call on hold

End active

Ends the active call and connects with the call on hold

End all Ends all the calls

* Private with

Allows you to select and have a private conversation with one of the conference callers while putting all the other calls on hold

Hold/Retrieve Holds or retrieves the conference call

* End one

Allows you to select and end one of the conference call participants

For alternate line service (ALS), you cannot make subscribers conference calls between Line 1 and Line 2.

123

The menu

Use the round cursor key to access the menu system. Your menu options can vary. Some may not appear. This depends on your network operator and your subscription.

Access to the menus

Press to view all stored telephone numbers. Press to enter the main menu. Hold down Exit or press to exit the menus (if no call is in progress).

Menu map

Items in italics depend on your subscription and your network operator.

Entering text

To add names to the phone books (see page 25) and write text messages (see page30) you must enter text. The phone displays in lower case mode and in upper case mode when you can enter text. Use the keypad to enter/edit text. You can enter text/numbers using T9 text entry or Multitap text entry.

Currency

Games

Reshape

Push

Options

Office Tools

Scratchpad

Alarm clock

Auto-switch

Calculator

Settings

Phone settings

Voice mail

GSM Services

Broadcast

Internet

Home page

Bookmarks

Other site Profile list

Settings

Calls & Times

Calls log Call timers

Call costs Line selection

Network Server

Applications Services Information

Phone Book

Recall Store Remaining Own numbers

Fixed dialling

Phone book

tones

Messages

Inbox Outbox

Write new

Settings Draft texts Alert Storage

The menu

T9 text entry

Press to swap between T9 text entry and the Multitap method. To enter text with T9:

Tips and operation

Example To enter Card in the display:

• Press and select Messages.

• Select Write new.

• Press : appears.

• Press . A appears.

• Press . Ca appears.

• Press . Car appears.

• Press . Case appears. If the displayed word is not the one you want, press as many times as necessary to view Card.

• Press to exit from this example and return to the stand-by display.

Multitap text entry

Press on to swap between T9 text entry and the Multitap method. To enter text with multitap:

Press the key with the required letter only once. Do not be put off if the character you want is not immediately displayed. The ‘active’ word changes as you type, so type to the end of the word. If your word is not displayed, press for other matching words. If your word is not recognised, press to swap to the Multitap method to complete the word. Use or to locate the cursor in the text to insert characters or make corrections.

Key Action

Shift - upper/lower case

Clear

Clear or backspace

Press and hold Numbers

Space Another matching word Smart punctuation Swap between T9 and Multitap method

Press the key with the required letter. If it is not the first letter, press key repeatedly until the letter appears. See the table that follows for a key to character correspondence. Enter the next character. If two characters are on the same key wait for the display at the top of the screen to clear or press before pressing the same key again.

1234512

The following table displays the available English characters. Other languages display different character sets.

Example To enter Card in the display:

• Press and select Messages.

• Select Write new.

• Press and hold until appears. Press briefly three times, C appears.

• Wait for the available characters to go from the display, press and hold until appears. Press briefly once, a appears.

• Press briefly three times, r appears.

• Press briefly once, d appears. The word Card appears.

• Press to exit from this example and return to the stand-by display.

To access special characters (23 available), hold down . A table appears. Press the key that corresponds to the character.

Press Clear briefly to correct back one letter. Hold down to clear all text. Press or to move the cursor in the text to insert characters or make corrections.

Key Character

Lower case Upper case

1 . , - ' @ : ?

a b c 2 A B C 2 d e f 3 D E F 3 g h i 4 G H I 4

j k l 5 J K L 5 m n o 6 M N O 6 p q r s 7 P Q R S 7 t u v 8 T U V 8 w x y z 9 W X Y Z 9 0 0

Short press swaps next letter between upper or lower case.

Long press swaps all next letters between upper or lower case.

Short press, enters space.

Long press gives access to special characters.

( ) % ! ; " _ @ § + # * / & = < > ¥ $ £ ¡ ¿ €

Short press moves the cursor through the text one place.

Swap between Multitap and T9.

345

The menu

Network services

Your network operator provides value added services and contact phone numbers. Depending on your operator’s implementation Applications, Services, and/or Information appears in the display. Press and select Network Services to access these menus.

Phone book

The phone book stores data, usually names and telephone numbers, in the phone or SIM memory.

• The phone can store up to 100 ‘phone phone book cards’ which can contain: family name, first name, icon, home phone number, work phone number, cellular phone number and a note.

• SIMs can store up to 255 ‘SIM phone book cards’. Actual numbers and capacity depends on your SIM. SIM phone book cards only contain the name and number.

Both the SIM and the phone memories are searched when you use the phone book.

Storing names and telephone numbers

You can enter the names and numbers in the phone book manually or copy them from SMS messages, scratchpad or last dialled number lists, etc. You can store the characters *, +, P (pause), # and _ together with numbers. See page 22 to learn how to enter text.

Store numbers in international format using the '+' prefix (or 00) before the country code followed by the telephone number. This ensures that the number can also be dialled from abroad.

There are several ways to store numbers into the phone or SIM memory:

Phone memory

• Directly from the stand-by display:

Enter the number. Press Store . Select Phone names. A list appears. Select the item corresponding to the number you entered: home, work or cellular. The following fields appear:

Field Purpose

Family name Family or last name First name First name

Enter the requested data. Confirm each entry by pressing OK

12345

• Using the menu:

• From last dialled, received and unanswered lists:

SIM phone book memory

You can enter the SIM memory from the stand-by display, menu or other locations.

• Directly from the stand-by display:

• Using the menu:

Select an icon. The icons correspond to - keys on the keypad. Press the key corresponding to the required icon. In this example pressing selects .

The following fields appear:

Field Purpose

Phone number (Home) Home phone number Phone number (Work) Work phone number Phone number (Cellular)

Cellular phone number

Note Note or comments for this card

Enter the requested data. Press OK

Confirmation and number of free locations appear. Press Exit or to return to the stand-by display.

Press . Select Phone Book. Select Store. Select Phone names. Follow the steps in the previous procedure (“Directly from the

stand-by display”) starting with step .

Display a number from one of the above, then press Options . Select Store. Select Phone names. Follow the steps in the “Directly from the stand-by display” pro-

cedure starting with step .

During number and name entry a short press on Clear clears the last character. A long press clears the whole display.

Enter the number. Press Store . Select SIM names. Press OK . Modify or confirm the number and press OK . Enter the name. Press OK .

Confirmation and number of free locations appear. Press Exit or to return to the stand-by display.

Press . Select Phone Book.

678912341233123

451

The menu

• From other stored locations

Numbers stored in the last dialled, received, unanswered, scratchpad and SMS message locations can all be stored in the phone book:

A warning message appears when selecting the phone book when the SIM or phone memory is full.

Free space in the phone book

To see the remaining free space in the SIM or phone:

Viewing and calling numbers in the phone book

You can edit, delete, copy, move or access phone book entries stored in the phone or SIM. There are two ways to view and call numbers in the phone book:

• Directly from the stand-by display:

• Using the menu:

Pressing or scrolls through the phone book. To go directly to another entry press the corresponding alphabet key. For example to go directly to entries starting with 'N' press twice. If you did not enter any initials, the phone book displays the first entry.

Select Store. Select SIM names. Enter the number and press OK .

Enter the name and press OK . Confirmation and number of remaining locations appears.

Press Exit or to return to the stand-by display.

Display a number from one of the above then press Options . Follow the steps from the previous procedure “Using the menu”

starting with step .

During number and name entry a short press on Clear clears the last character. A long press clears the whole display.

Press . Select Phone Book. Select Remaining and use or to display the remaining

memory spaces in the phone or SIM. Press Exit or to return to the stand-by display.

If available, the free memories in the FDN list also appears.

Press to display the phone book list.

Press and select Phone Book. Select Recall. Either press OK or enter up to the first 3 initials of the name required and then press OK .

Press to dial the number. If there is a choice of numbers for the phone book entry, these appear. Select the one that corresponds and press .

2341221231234

Pressing Options displays the following menu choices:

Own number display

The phone can display to your correspondent your main 'Line 1' voice mobile number, the voice mobile number for Line 2 (Alternate Line Service) and your data and fax numbers. The SIM stores these numbers. You can enter them manually and name them. For example, you can name Line 1 'Office'. To view, name and edit your own display number(s):

Fixed dialling numbers (FDN)

Fixed dialling only allows you to call a group of numbers. All other numbers are rejected. FDN also prevents call diverting and sending SMS messages to numbers not in the FDN list. You can use wildcards to define the groups. As this is a SIM dependent feature, some SIM›s might not support it. SIM capacity determines the maximum number of FDN numbers you can configure. To activate/deactivate FDN you must have the PIN2 code. To turn on or off FDN operation:

To view the numbers in the list:

To enter, edit or delete numbers in the FDN list:

Item Function

Edit Edits the name and number entry

Delete Deletes the entry

Send

SMS

Sends SMS message

Copy

Copies the entry to the SIM or the phone or vice versa. You can edit before copying

Move

Moves the entry to another position. You can edit before moving

Call Calls the number displayed

Press Exit or to return to the stand-by display.

Press . Select Phone Book. Select Own numbers. The mobile number for Line 1 appears. Use or to view line 2, data and fax numbers. To add or edit a name or number press Edit . Press Exit or to return to the stand-by display.

Press . Select Phone Book. Select Fixed Dialling. Select Status. Select On or Off. Enter the PIN2 number. Press OK to confirm the setting.

Press . Select Phone Book. Select Fixed Dialling. Select View and use or to scroll through the entries. Press Options to edit, delete and copy numbers to the phone or

SIM.

Press . Select Phone Book.

5123451234123

The menu

Phone book tones

30 pre-set ring tones are available, 10 with tri-tones (generally sound better) and 20 with mono-tones. Storage of up to 40 ring tones is possible. That is, you can add one self-composed ring tone and 9 other ring tones you download in addition to the existing 30 ring tones. If you want, you can replace any of these ring tones except the Trium ring tone. You cannot replace the memory space used for the self-composed ring tone. To have different tones for incoming calls where the identities are known in the SIM or phone memory:

Messages (SMS)

You can exchange short text messages of up to 160 characters with other mobile phones with SMS. You can also store, edit and forward messages and save any of the numbers they contain.

Reading a received SMS message

When the phone receives an SMS message a new SMS alert tone sounds and appears. The SIM stores the message. If flashes there is no more space in the SIM to store new messages. Delete previous messages to make space for new ones.

Reading stored SMS messages

You can now read all stored messages. For a given message, shows the message is new. shows you have already read the message.

Select Fixed Dialling. Select Add new. Enter the PIN2 number if asked. Add, edit, delete or copy new numbers to the phone or SIM.

You can use wild card spaces with numbers stored in the FDN list. For example the number +441707 278_ _ 9 allows you to call all numbers between 278009 to 278999.

Press . Select Phone Book. Select Phone Book Tones. Select Phone names or SIM names. Press Select . Select the tone you want and press Select . The phone stores

your selection.

Press Read to read all received messages (Inbox).

Press . Select Messages. Select Inbox to display the first message header.

Use and to select the message. Press or select Options /Read text to read the message

text.

231234123

Managing received and stored SMS messages

After reading the SMS message press Options for the following menu:

Turning on or off the message alert tone

Each time a message is received the SMS alert tone sounds. To turn on or off this tone:

Preparing the phone to send SMS messages

You can write and send text messages. To use SMS, check that the number for the message centre is configured:

If a number appears do nothing. If empty, enter the number manually (in international format) or from a stored memory. If you do not have this number, ask your service provider for it.

If required you can also choose the validity period, format, paid reply request and request a delivery report. Default settings are assumed if not set.

Creating a draft text

Parts of a message are often the same, such as the greeting or signature.

Item Function

Read text Displays the remainder of the text

Delete Deletes the message

Reply Replies to the sender of the message Reply

(+ text)

Replies to the sender of the message with the initial text

Forward Forwards the message to another user

Forward to n Forwards a set of several (5 maximum) messag-

es to 5 different addressees

Numbers

Stores or calls the number(s) contained in the SMS header or text

The items of this menu depend on the type of message received.

Press . Select Messages. Select Alert. Select On or Off. Press Exit or to return to the stand-by display.

Press . Select Messages. Select Settings. Select Message centre.

Press Exit or to return to the stand-by display.

Option Description Default

Validity Period

Time held at message centre. 12hours, 1day, 2 days or Maximum (defined by operator)

Maximum

Format

Selects format of message, text, voice, fax or pager

Text

Paid Reply to Reply requested Off

Status report to Delivery report Off

1231234

The menu

To save time, you can create a draft text with these parts. Then when you want to write a message, you access the draft text and only write the specific part of the message. You can set up to 10 message drafts, which can hold up to 50 characters each. Your total message, when complete can only be up to 160 characters. The mobile memory stores the drafts. To create a draft text:

Editing a draft text

Sending a new SMS message to one addressee

Sending a new SMS message to many addressees

Press . Select Messages. Select Draft texts. Choose any blank template ([...]) and press Edit . Enter the draft text and press OK . Press Exit or to return to the stand-by display.

Press . Select Messages. Select Draft texts. Select the draft text to modify and press Edit . Edit the text and press OK . Press Exit or to return to the stand-by display.

Press . Select Messages. Select Write new. You can either choose a draft text (if you set one up) or enter the message text and press OK . Select Send. Choose a message template and then enter the destination number or select Names to choose a number from a phone

book entry. Press to validate your choice. Press OK .

Sending and sent confirmation appears for each addressee. Press Exit or to return to the stand-by display.

Press . Select Messages. Select Write new. You can either choose a draft text (if you set one up) or enter the message text and press OK . Select Multicast. Choose a message template. Enter up to 5 destination numbers or select Names to choose

up to 5 numbers in the phone book. Press to validate your choice. Press OK .

Sent confirmation appears. Press Exit or to return to the stand-by display.

123451234512345612345

Storing a new SMS message

Modifying and re-sending messages in the outbox

The outbox contains unsent draft messages, stored sent messages and sent but undelivered messages. You can modify and re-send these as new messages. To select an outbox message:

Status request on sent messages

If you request the status of a delivered message the delivery date and time appears. If you request the status of a sent message the network sends a status report (if this feature is supported). Press OK to acknowledge the report. To act upon a received status report and its related message:

Re-usable message templates

The Msg templates menu option appears in the Messages - Settings menu if your SIM supports this feature. Message templates are sets of message parameters and are stored in SIM memory. You can name and select the templates when needed. To create a message template:

Press . Select Messages. Select Write new. You can either choose a draft text or enter the message text and press OK . Select Store. Press Exit or to return to the stand-by display.

Press . Select Messages. Select Outbox and use or to scroll to the desired message. Messages are either “transmitted” ( ) or “to be sent” ( ). Press Options to read, delete, request a status report, send

(or re-send) to one addressee, edit a sent message and send (or re-send) to many addressees. Follow the instructions displayed on the screen.

Press Options . The following menu appears:

Item Action

Deletemessage

Deletes the corresponding sent SMS message and the status report

Clear

To acknowledge the status report and clear the display

Associated

message

Displays the corresponding sent SMS message

Send again Sends the same message again

Select the action required and press OK .

Press . Select Messages. Select Settings. Select Msg templates. Choose any blank template ([...]).

123451234

121

The menu

Default settings for pay reply and status are assumed 'off' unless set and are common to all templates. If you only set one template the phone uses it by default. Otherwise select the template you want when sending a message.

Storage consumption

To consult the memory used by SMS:

Calls & Times

Access the Calls & Times menu to check the details of individual incoming and outgoing calls, the duration of the last call or the total time for all previous calls.

Calls log

Calls log stores the identity, time, date and call duration of the last 10numbers dialled, the last 10 received unanswered calls and the last 10received calls. The call logs are common for both Line 1 and Line 2.

If the caller’s number is not available Unknown number appears (unanswered and received lists). Pressing while on a displayed number calls that number. Pressing Options accesses the following menu:

Use or to select the required option and follow the display prompts. Press Exit or to return to the stand-by display.

Call times

Call times stores the duration of the last call, total accumulated time of all

Enter the template Name, Message centre number, Validity period and Format.

Press . Select Messages. Select Storage. Use or to view all the SMS storage information (SMS stor-

age, SMS outbox and SMS inbox). Press Exit or to return to the stand-by display.

Press . Select Calls & Times. Select Calls Log. Select Last dial, Unanswered or Received. Use or to scroll through the list.

Item Action

Store Stores the number in the phone book

Delete Deletes the entry

Delete all Deletes all the entries

Edit Edits the displayed number

Details

Views the details - name, number, time and date and call duration of the highlighted number

Call Makes a call to the number

Send SMS Sends SMS message

Press when in stand-by display to access the last 10 dialled calls.

312341234

calls and total time for Line 1 and Line 2. The Details sub-menu stores times for calls made and received through the subscription network and through other (national and international) networks.

The call type and the accumulated times of outgoing and incoming calls appears.

Balance information (subscription service only)

Some networks provide your remaining airtime balance. You have to call a specific number (given by your network operator) in order to get this information. Contact your service provider for availability and details.

Reminder - Call duration

You can set a call duration reminder in multiples of 1 minute (1 - 59 min.) intervals. It beeps at the set intervals.

Press . Select Calls & Times. Select Call timers. Select Show. If you reset the call timers (see page 35) the date of the last reset

of the counters appears briefly. Use or to view all the timer information.

Press Details to display details of roaming and international calls.

Press or Exit to return to the previous display. Press and hold Exit or to return to the stand-by display.

If Line 2 is subscribed to 'All Calls' for Line 1 and Line 2 appear separately.

Press . Select Calls & Times. Select Call timers. Select Balance information. Select Set number (only necessary the first time you use this

service) to check that the balance information centre number is set. If not, enter the number provided by your service provider and press OK .

Select Call. The phone calls the centre. Press when you want to end the call.

Press Exit or to return to the stand-by display.

Press . Select Calls & Times. Select Call timers. Select Reminder.

123456123456123

The menu

Call timer - reset

To reset all the call timers, you need the 4 digit phone lock code.

Call costs - management (subscription service only)

An Advice of Charge (AoC) subscription service shows the cost of the last call made, the accumulated total cost of all calls and the remaining balance in units or currency of any 'cost limit' you set. Check with your service provider to see if they offer this feature. Select the currency and cost per unit; otherwise call costs display in generic units. To set currency and cost per unit:

To set call cost type to units:

Setting the credit limit - in units or currency

You can set a credit limit in units or currency. The phone prevents making and receiving all chargeable calls when the phones reaches the credit limit. You can still make emergency calls.

Select On (or Off). Select the period (between 1 and 59 mins). Press OK . Press Exit or to return to the stand-by display.

Press . Select Calls & Times. Select Call timers. Select Reset. Select Yes or No. Enter the phone lock code and press OK . Press Exit or to return to the stand-by display.

Press . Select Calls & Times. Select Call costs. Select Display cost type. Select Currency. The present currency settings appears. Press Edit . Enter the PIN 2 code and press OK . Enter the abbreviated letters of the currency. Press OK . Enter the cost per unit in the selected currency. Press OK . Press Exit or to return to the stand-by display.

Press . Select Calls & Times. Select Call costs. Select Display cost type. Select Units. Press Exit or to return to the stand-by display.

When you set the cost type to units the credit limit and the remaining credit appear in units.

Press . Select Calls & Times. Select Call costs.

4567123456123456781234512

Show costs

Call costs - resetting all costs to zero

To reset all the call costs to zero you need the PIN 2 code.

Alternate line service - selecting line 2 (subscription service)

Some GSM 1800 operators support the use of a second line for users. You can have two mobile phone numbers, e.g. a business and personal line. To select the line for outgoing calls:

Settings - customising your phone

Phone settings

Keypad lock

See page 16 for more information.

Select Credit Limit. The present credit limit setting appears. Press Edit . Enter the PIN 2 code and press OK .

Enter the credit limit (use to enter a decimal point). Press OK to validate. Press Exit or to return to the stand-by display.

When you enter a credit limit the selection from the 'Credit Limit' displays Edit or Set No Limit.

Press . Select Calls & Times. Select Call costs. Select Show. Use or to display the cost of the Last Call, All Calls and the Remaining credits. Press Exit or to return to the stand-by display.

The Cost Type menu units or currency setting determines whether the remaining credit displays units or currency.

Press . Select Calls & Times. Select Call costs. Select Reset. Select Yes to reset the costs or No to exit. If you select Yes, enter the PIN 2 number and press OK . All

Costs Reset appears briefly. Press Exit or to return to the stand-by display.

Press . Select Calls & Times. Select Line selection.

The current line selection appears. Use or to scroll to the line required and press Select

or to validate your choice. Press Exit or to return to the stand-by display.

You can assign names to Line 1 and Line 2, e.g. Office and Home. See page 28 for details. You must select the line to make outgoing calls. You can receive calls from either line.

34561234512345123

The menu

Language selection

To select the language of your choice:

Tones - Alert mode

To turn on or off the audible incoming ring tone, alert and alarm tones:

• Using the menu:

• Directly from the stand-by display:

Ring tone selection

To choose an incoming ring tone:

Press . Select Settings. Select Phone settings. Select Language. Use or to select a language from the displayed list. Press to validate. Press Exit or to return to the stand-by display.

To reset the phone to the language of the SIM enter *#0000#. To reset the phone language to English enter *#0044#.

Press . Select Settings. Select Phone settings. Select Tones. Select Alert tones. Select Ring, Vibrate, Vibrate & ring or Vibrate then ring. Press Exit or to return to the stand-by display.

Press displays Ring, Silent, Vibrate, Vibrate & ring or Vibrate then ring. Scroll to the desired setting. Press to validate your choice. (If any of the vibrate options are selected the phone briefly vibrates). appears.

1. If you select Ring but the ring tone volume is off the icon appears.

2. appears if you select Vibrate, Vibrate & ring or Vibrate then ring. It takes precedence over .

3. When the phone is connected to either the Desk Top Charger, HF kit, CLA or AC adaptor the phone rings instead of vibrates.

4. If you choose the 'Vibrate' or 'Vibrate then ring' option, the vibrating action replaces all the alert and alarm tones.

Press . Select Settings. Select Phone settings. Select Tones. Select Melodies. To help you identify incoming calls you can give the Standard/ Line 1, Phone names, SIM names and Line 2 calls and Alarm different ring tones. Use or to highlight the required call type and press to select it. Use or to listen to the different ring tones. Press to select the current tone. Press Exit or to return to the stand-by display.

123412345121234

Volume adjustments

To individually adjust the volume level of the ring tone, key tones, alarm tones and incoming audio from the stand-by display, press . Alternatively, access Volume control from the Settings menu:

The display confirms the selection, naming the volume to be adjusted.

During a call, you can adjust the conversation volume by using or .

Ramping

Ramping causes the incoming ring tone to increase in increments to the maximum volume level.

Melody composer

To compose your own melodies:

Use the actions in the following table to modify the notes. The tempo

Press . Select Settings. Select Phone settings. Select Tones. Select Volume. Select Ring, Keys, Conversation or Alarm.

Use or to adjust the setting. Press OK to validate the setting. Press Exit or to return to the stand-by display.

If the ring tone volume level is set to 0 displays.

Press . Select Settings. Select Phone settings. Select Tones. Select Volume. Select Ramping. Select On or Off. Press Exit or to return to the stand-by display.

When turned on the volume of the incoming ring tone starts from the minimum and rises to the maximum volume until answered.

Press . Select Settings. Select Phone settings. Select Tones. Select Melody composer. Select Edit. Enter notes using the keypad (see table below):

Note C D E F G A B

Key

Select OK. The phone stores your melody Select Play to play your melody or Delete to delete it.

Press Exit or to return to the stand-by display.

1234567123456

45678

The menu

is fixed.

Melody download

You can also download melodies from the Trium web site. This site downloads the melodies to your phone using SMS. When the download completes,

Backlight - setting

To set the backlight during key entry or incoming ring tone, you have two options:

• On for 10 sec.: the display and key backlight stays on for 10seconds after the last key press or incoming call.

• Off: the backlight stays off.

Display contrast

To modify the display contrast because of bad light conditions:

Menu graphics

Choose from a set of graphics to personalise your main menu images, and icons. There are 5 menu themes which all have night and day idle screens. The idle screen changes to the night one at 9 p.m. and to the day one at 7 a.m. To change the menu graphics:

Symbol Action

P Use to insert the ‘P’, which inserts a pause

+/-

Press after a note to increase it one octave (+ appears) or press to decrease it one octave (- appears)

# Use after a note to increase the note one half-tone

2, 3 or 4

Use keys , and after a note to increase the length of the note by 400 ms, 600 ms or 800 ms

Press Options and then select Play to play the melody. Press Options and then select Install to store the melody.

Press . Select Settings. Select Phone settings. Select Display. Select Backlight. Select one of the two settings. Press to validate.

Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Display. Select Contrast. Adjust the contrast using or . Press OK to validate the setting. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Menu graphics. Use or to scroll to the sets of menu graphics and press Select or to validate your choice.

1234512345612

Any key answer

To enable any key (except and No ring ) to be pressed to answer an incoming call:

Softkeys - programming the softkeys

You can change the function of the softkeys. There are two ways:

• Directly from the stand-by display:

• Using the menu:

Speed dialling

You can assign phone book numbers to keys - . Hold down the key to dial the number. The phone reserves exclusively for the voice mail number. The phone assigns this automatically when you (or the SIM) store(s) the voice mail number (see Voice mail, page 44). You can select any stored number. To assign phone book numbers to the speed dialling keys:

Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Keys. Select Any key answer. Select On or Off. Press Exit or to return to the stand-by display.

Press and hold down the left or right . Use or to scroll through the choice of softkey options.

Press Select to validate your choice. The screen confirms your selection and returns to the stand-by display showing your new softkey function.

Press . Select Settings. Select Phone settings. Select Keys. Select Softkeys functions. Select Left softkey or Right softkey. Press Select on the softkey option of your choice. Press Exit or to return to the stand-by display.

(......) in the display means that a previously SIM dependent or subscription service assigned to

that softkey is no longer available. For example Line 2 selection.

Press . Select Settings. Select Phone settings. Select Keys. Select Speed Dial. Use or to scroll to the next key. Select Names to choose the phone book entry and press Select to validate your choice. Press Exit or to return to the stand-by display.

If you delete the number from the phone book this deletes it from the key.

412345123412345612345

The menu

Auto answer

This feature only works when you connect the phone to a hands free car kit or headset. The phone automatically answers an incoming call after approximately 5 seconds.

Auto-retry

To automatically retry the number of a failed call (up to 10 times):

When activated, Auto-retry and a countdown timer to the next call attempt appears. An auto-retry warning tone sounds each time the phone attempts a new retry. If successful, proceed with the call as normal. Press Exit or any key during the retrying process to cancel auto-retry and end the dialling process for that call.

Security features

The security features described in this section protects your phone from unauthorised use.

For all codes

When requested, enter the code, which appear as asterisks (*) and press OK . If you make a mistake press Clear and enter the correct digit(s) before pressing OK .

KEEP A RECORD OF YOUR CODES AND KEEP THEM IN A SAFE PLACE. FAILURE TO DO SO CAN CAUSE YOU CONSIDERABLE INCONVENIENCE.

Phone lock code

A phone lock code prevents unauthorised access to the phone and WAP™ settings. You also need it to reset the call timers. The factory setting is 0000. Reset this code and keep it in a safe place, separate from the phone. When enabled the phone asks for the code each time the phone is turned on. To change the phone lock code:

Press . Select Settings. Select Phone settings. Select Auto features. Select Auto-answer. Select On or Off. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Auto features. Select Auto-retry. Select On or Off. Press Exit or to return to the stand-by display.

Avoid using codes similar to emergency numbers such as 999 or 112 to prevent accidental dialling of these numbers.

Press . Select Settings. Select Phone settings. Select Security.

12345123451

To turn on or off the phone lock code:

PIN code

The 4-8 digit PIN code for the SIM protects it from unauthorised use. When enabled the phone requests the PIN code each time the phone is turned on. If you enter the wrong PIN code three times in succession your SIM card is blocked and you need the 8 digit PUK code from your service provider (see page 43). To turn on and off the PIN:

To change the PIN code (PIN must first be enabled):

PIN2 code

The PIN2 code prevents unauthorised access to FDN operations, modifying the FDN phone book, setting calls costs to zero, modifying the costs display features. You can change it but you can not turn it on or off. To change the PIN2 code:

Select Phone lock. Select Change code and follow the display prompts. Press OK to validate the new code. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Security. Select Phone lock. Select On or Off. The phone requests the phone lock code to authorise your selection. Press Exit or to return to the stand-by display.

Phone lock still enables you to make emergency calls.

Press . Select Settings. Select Phone settings. Select Security.

If already off, PIN enable appears. If already on, PIN disable and PIN change appear.

Press Select and follow the display prompts. Press OK to validate your entry. PIN enabled or PIN disa-

bled appear briefly to confirm your action. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Security. Select PIN change and follow the display prompts. Press OK to validate your new PIN. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Phone settings. Select Security. Select PIN2 change and follow the display prompts.

34561234561234512345123

The menu

PUK code

Only your service provider can give you the 8 digit PUK (PIN unblock key). Use it to 'unblock' a PIN whose code has been entered incorrectly three times. A PUK code cannot be changed. Enter the PUK code and press OK . Enter a new PIN code by following the display prompts.

PUK2 code

Only your service provider can give you the 8 digit PUK2. Use it to unblock a PIN2 whose code has been entered incorrectly three times. You cannot change the PUK2 code. Enter the PUK2 code. Enter a new PIN2 code by following the display prompts.

Call barring password

Use the call barring password to select the call barring levels outlined in the GSM Services - Call barring menu (see page 48). Your service provider gives you the initial password. To change the password:

Summary of code/password entry chart

Press OK to validate your new PIN2 code. Press Exit or to return to the stand-by display.

If you enter the wrong PUK code 10 times in succession your SIM card cannot be used again. Contact your service provider for a new card.

If you enter the wrong PUK2 code 10 times in succession you are unable to use the features requiring the PIN2 code. Contact your service provider for a new card.

Press . Select Settings. Select GSM Services. Select Call barring. Select Change password and follow the display prompts. Press OK to validate. Press Exit or to return to the stand-by display.

Password Length

Number of tries

allowed

If blocked or

forgotten

Phone

unlock code

4 digits Unlimited

Return phone to manufac-

turer

4-8

digits

3 tries

Unblocked by use of PUK

code

PIN2

4-8

digits

3 tries

Unblocked by use of PUK2

code

PUK 8 digits 10 tries

Contact your service pro-

vider

PUK2 8 digits 10 tries

Contact your service pro-

vider

Call barring

password

4 digits

Network

determined

Contact your service pro-

vider

4512345

Time & date setting

To set the current time and/or date:

Default (factory) settings

Use the Settings menu to return to the factory settings. This does not affect the phone book entries, phone lock code or SIM.

The following are the factory default settings:

Voice mail

Voice mail operates like an answering machine. Contact your service provider for details.

Storing a voice mail centre number

If your SIM does not automatically include the voice mail centre number, you must manually set it:

Press . Select Settings. Select Phone settings. Select Time & date. Select Set time or Set date. Enter the time (in 24 hour format) or date in the format shown.

(If required use and ) Press OK to validate your selection. Press Exit or to return to the stand-by display.

1. An error message appears if you make a wrong entry.

2. The time/date displays when the phone is on. It does not show the year.

3. An internal battery maintains the date and time setting for up to 3 hours when the phone is switched off and without a battery, or with a completely discharged battery attached. After this time you must reset the clock (if needed) when you switch on the phone.

Press . Select Settings. Select Phone settings. Select Default settings. Select Yes or No. Press Exit or to return to the stand-by display.

Feature Factory setting

Alert Tones Ring Ring Tones Trium Volumes, Ring, Key, Speech and Alarm. Mid values Backlight and Contrast On for 10 sec. and mid value Any Key, Auto-Retry and Auto Answer

features.

Off

Ramping Off Menu graphics Trium

Press . Select Settings. Select Voice Mail. Select Number. When prompted enter the number manually or

from a stored memory. Press OK to validate your entry. Press Exit or to return to the stand-by display.

1234561

2341234

The menu

Turning on/off the voice mail alert tone

To turn on/off the voice mail alert tone:

Calling the voice mail centre to check for messages

There are two ways:

• To dial the voice mail centre directly after the receipt of a message:

• Or from the menu:

Dialling proceeds as for a normal call.

GSM services

Diverting incoming calls (network service)

Call diverting diverts incoming calls, whether voice, fax or data, to another number. To turn on call divert:

If you subscribe to the 'Line 2' service, store the voice mail centre number separately for that line. The phone automatically assigns the voice mail number to speed dial location number 1 (see Speed dialling on page 40).

Press . Select Settings. Select Voice Mail. Select Alert. Select On or Off. Press Exit or to return to the stand-by display.

Press and hold down .

Press . Select Settings. Select Voice Mail. Select Call.

If a voice mail number is not stored when you select Call, the phone asks you to enter the voice mail number. Proceed as described in Storing a voice mail centre number, page 44.

Press . Select Settings. Select GSM Services. Select Call diverting to access the follow-

ing menu:

Divert options Action

Always Diverts all incoming voice calls unconditionally

When not reachable

Diverts all voice calls when the phone cannot be reached, i.e. out of service

On no reply

Diverts all voice calls when the phone does not answer

When busy Diverts all voice calls when the phone is busy

All conditions

Diverts all voice calls when Not Reachable, No Reply and When Busy

Cancel all Cancels all diverts

All FAX calls Diverts unconditionally all incoming fax calls

All DATA calls Diverts unconditionally all incoming data calls

Use or to select the divert condition and validate by pressing Select or . Select Activate.

12341231234

To turn off or check the status of call divert:

To cancel all (multiple) diverts:

Caller Line Identity - showing/hiding your mobile number

Most networks allow the Caller Line Identity feature (CLI) i.e. showing the incoming number (ID) while receiving a call. Selecting Receiving caller ID allows you to check its availability from the network.

Receiving caller ID

To find out whether a network presents the ID of incoming calls:

To hide your number, on a call by call basis, add #31# before the number you are calling. Alternatively you can ask your service operator to always disable the sending of your mobile number. In this case to reveal your number, on a call by call basis, add *31# before the number you wish to call.

Standard network setting

To reset the standard network setting for sending your mobile ID:

Use or to choose between Voice Mail, Names or Number. Press Select or to validate your selection.

The display confirms your request. Press Exit or to return to the stand-by display.

1. If you select 'On no reply' option you must also enter a delay period of 5, 15 or 30 seconds.

2. Call diverts for both Line 1 and Line 2 must be set individually. Select the out-going line before following the above procedure. To carry out a call divert on the other line you must select this other line first (menu Calls & Times - Line selection).

Press . Select Settings. Select GSM Services. Select Call diverting. Select from the divert options and press . Select Cancel or Status. The phone confirms your selection. Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Call diverting. Select Cancel all. The phone confirms your selection. Press Exit or to return to the stand-by display.

This action cancels all voice diverts (for voice, faxes and data calls) for the line currently in use. To cancel call diverts for the other line you must select this other line first (menu Calls & Times - Line selection).

Press . Select Settings. Select GSM Services. Select Receiving caller ID.

The network returns either Presentation available or Presen- tation unavailable.

Press Exit or to return to the stand-by display.

Press . Select Settings.

567123451234123

The menu

Hiding or showing your number

Finding out your current ID setting

Network

When turned on, the phone automatically searches for the last network it was registered on. If this is not available, the phone automatically searches and, if able and allowed, selects a network.

Editing the preferred list

You can change the order and names in the preferred networks list stored in your SIM by choosing from the list in your phone. This is useful while roaming if you know a network provider that is more economical than another.

Your SIM may contain a forbidden list of networks which cannot be

Select GSM Services. Select Sending my ID. Select My settings. Select Preset. The phone resets to the network setting agreed with your service provider. Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Sending my ID. Select My settings. Select Hide my ID or Show my ID. Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Sending my ID. Select Status.

The phone displays your current setting, taking into account both network and phone settings.

Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Network. Select Preferred list. A list of networks appears. Use or to view the list. Press Options to change it. The following items appear:

Option Description

Modify by list Displays the general list of all known networks

contained in the phone in alphabetical order

Modify by

code

Edits or enters a network number (MCC MNC) if you know this information.

Delete Deletes an entry

Press Select to confirm the selection. Press Exit or to return to the stand-by display.

2345123451234123456

used. To view the forbidden list or show the home network:

Selecting manual search

To select a specific network, e.g. one which provides better coverage in your current location:

Selecting automatic search (normal default setting)

To perform an automatic search from the preferred list:

Call barring (network service)

To stop different types of calls being made and received on the phone, you need a call barring password available only from your service provider.

Press . Select Settings. Select GSM Services. Select Network. Select either Forbidden or Home network.

A list of the forbidden networks or the home network appears. Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Network. Select Search. Select Manual. A confirmation screen and Scanning for net- works... appears. Use or to select a network from the list shown. Press to confirm the selection. Requesting... followed by the name of the network appears. The phone then returns to the stand-by display.

You cannot delete a network from the forbidden list. This list is automatically updated when you perform the manual network selection.

Press . Select Settings. Select GSM Services. Select Network. Select Search. Select Automatic. Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Call barring. Select Outgoing calls or Incoming calls. Choose:

Select Meaning

Outgoing - All outgoing

Bars all outgoing calls

- Int'nal calls

Bars only all outgoing international calls

- Int'nal excl. home

Bars all outgoing international calls except to other subscribers within the users home network

Incoming - All incoming

Bars all incoming calls

- Roaming only

Bars all incoming calls when not on the home network

12341234561234512

The menu

To cancel or check the status of a call bar:

To change the password:

Broadcast - cell broadcast messages (Network Service)

Networks can broadcast messages to all GSM users that can give information about local area dialling codes, weather reports, traffic news etc. You can decide what type of information to receive by choosing the corresponding number. You can program to receive up to 5 different types of messages. You can select from a list of 16 standard message types. New message types can be programmed into the selection list using the 3 digit cell broadcast type number. Contact your service provider for more details. Enter at least one message type into the selection list or you cannot activate the service.

To enter a message type in the selection list

You can enter up to 5 different message types.

Select the option using or . Press Select . Select Activate. Enter the password and press OK .

The network confirms the selection. Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Call barring. Use or to select the bar to cancel or check the status and

Press . You must have the password to cancel a call bar.

Press Exit or to return to the stand-by display.

Press . Select Settings. Select GSM Services. Select Call barring. Select Change password. Enter the old password once and the new password twice when

prompted. The phone confirms the change. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Broadcast. Select Message types. Press Options . Select Modify by list (or Modify by code if type number is

known). Scroll to the message type required. Press Select to validate

your selection. The display confirms your choice. Press Options again to select more message types from the

list, enter a message type number if known, or delete a message type.

Press Exit or to return to the stand-by display.

45612341234123456

To turn on or off the broadcast service

Reading broadcast messages

Broadcast messages appear in the stand-by display only. The phone suppresses them during conversation or menu operation. A message can be up to 93 characters in length and cover several pages. Pages scroll automatically about every five seconds. To scroll down, press .

Options during message display

Press on Exit to clear the message currently displayed. Press to dial the number displayed in the message. Pressing Options displays the following menu:

Turning the broadcast alert tone on or off

To turn on or off the alert tone the phone gives when a broadcast message arrives:

Deleting or editing a message type from the list

To delete or edit a message type:

Broadcast language

To select the broadcast language:

Press . Select Settings. Select Broadcast. Select On/Off. Select On or Off. Press Exit or to return to the stand-by display.

Option Action

Delete Delete the current message

Delete All Delete all messages stored in the queue

Numbers

Display all phone numbers found in the message text. This allows dialling or storing them in the scratchpad if required

Broadcast Off Turns off cell broadcast

Press . Select Settings. Select Broadcast. Select Alert. Select On or Off. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Broadcast. Select Message types. Press Options . Select Delete, Edit or Get from list. Press Exit or to return to the stand-by display.

Press . Select Settings. Select Broadcast. Select Language.

12345123451234512

The menu

Using the office tools

The Office Tools menu contains a scratchpad, an alarm clock, an auto-switch feature and a calculator.

Scratchpad

You can store up to 5 separate entries of 36 characters in the scratchpad.

Press Options when reading entries to access the following menu:

Alarm clock

To set a daily 'Reminder Alarm':

The alarms sounds for up to 1minute. Alarm clock and a vibrating bell symbol appear with the current time and the softkeys, Valid. and No ring . During a call, the alarm also sounds. To stop the alarm:

To use as a Reminder or Snooze Alarm:

You can repeat the snooze for up to 15 minutes, after which the phone returns to its previous state, either off or on stand-by. To turn off the alarm:

Use or to select a language from the displayed list. Press to validate.

Press Exit or to return to the stand-by display.

Press . Select Office Tools. Select Scratchpad. Select Read. Use or to scroll through the entries.

Select Write to make a new scratchpad entry.

Item Action

Store Save a number to the phone book

Edit Modify an entry

Delete Delete an entry

Delete all Delete all entries

Call Call the number displayed in the entry

Press . Select Office Tools. Select Alarm clock. Select On and enter the alarm time (in 24 hour format) or press OK to accept the displayed time.

Confirmation appears. Press Exit or to return to the stand-by display.

appears.

When 'on' the alarm activates at the same time every day until turned off.

Press Valid. .

Press No ring , or any other key (except Valid. ) to stop the alarm. The alarm icons remain in the display and the alarm rings again 3 minutes later.

Press . Select Office Tools.

451231234

Auto-switch

You can set your phone to switch on and off automatically. Turning it off helps to conserve battery life. Please note that during auto-switch on, you must re-enter your PIN code. The phone does not go into power saving mode until you enter your code. To activate the auto-switch:

To turn off the auto-switch:

Calculator

To access and use the calculator:

Select Alarm clock. Select Off. Confirmation appears. Press Exit or to return to the stand-by display.

Caution - Please remember to turn off the alarm feature when boarding an aircraft where the use of a mobile phone is not permitted and is illegal. Alternatively, you can remove the battery after turning off the phone. See the General safety warnings on page 6.

Press . Select Office Tools. Select Auto-switch. Select Auto-switch-on. Select On. Enter the time you want the phone to turn on and press OK .

Confirmation appears. Select Auto-switch-off. Select On. Enter the time you want the phone to turn off and press OK .

Press Exit or to return to the stand-by display. The icon appears in the stand-by display.

Press . Select Office Tools. Select Auto-switch. Select Auto-switch-on. Select Off. Stored appears. Select Auto-switch-off. Select Off. Stored appears. Press Exit or to return to the stand-by display.

Press . Select Office Tools. Select Calculator. Enter a number and press several times to choose +, -, * or /.

Enter the second number and either repeat step or select = to compute. Select Clear to correct any mistakes or clear the display. Press to return to the stand-by display.

2341234567891234567123435

The menu

Games

The availability and appearance of the games depends on your network operator. There are at least two games in the phone: Reshape and Push. Game instructions appear when you select the game. Select sound effects from the menu item Options.

To select a game:

Reshape and Push have skill levels. When you win a level, you go to the next level. After successfully playing 'X' number of levels the game gives you a code to enable you to re-enter the game at your previously attained skill level. The game can record player names and scores. If you receive a call while playing, answer in the normal way. The game resumes when the call finishes. To exit from the games menu press Exit or press to return to the stand-by display.

Currency-converter

To use the converter, set the currencies and the exchange rate:

To calculate the conversion between the chosen currencies:

Press . Select Games. Choose the game and press Select or . Select Help for instructions and controls.

If you have already played the game and reached a certain skill level, select Code to enter and play the game at that level. Select Play to start the game.

Press . Select Currency. Select Settings. Enter the first currency name (e.g. Dollar). Press OK .

Enter the second currency name (e.g. Yen). Press OK . Enter the exchange rate using to enter a comma.

Press OK to validate the entry. Press Exit or to return to the stand-by display.

To use your Currency-converter as a Euro converter for participating currencies in the European Monetary Union (“Euroland currencies”), please enter the complete Euro exchange rate with six significant figures. For example: 1 Euro = £ 0.61871.

Press . Select Currency. Select one of the two first options. In our example: either Dollar->Yen or Yen->Dollar. Enter the amount to be converted. Press to insert a comma, if

needed. Press OK . The converted amount appears. Press Exit or to return to the stand-by display.

Conversion from one Euroland currency to another, or to non-Euroland currencies, normally follows "triangulation" rules (i.e. conversion of local currency to Euro and then Euro to other local currency). Your Currency-converter does not provide this possibility. Accordingly, your result is only a close approximation.

1234512345123

Internet/Wireless Application Protocol (WAP™)

Your phone has an WAP™ internet browser to access services, such as stock buying, news, sports, weather, TV listings etc., supplied by your operator and/or your internet provider. The types of services offered depend on the internet provid-

er and network operator.

You must have a DATA subscription to access these services. Either your phone is pre-programmed with the settings or you must enter them. See below to enter the settings. If you cannot access the settings, they are pre-programmed.

Configuring General Packet Radio Service (GPRS) access points*

To use the faster speed packed data service (higher data rate than GSM) you must configure at least one GPRS access point. If you just use circuit switching skip this procedure. If you use both packet and circuit perform this procedure. You can configure up to 10 access points.

To configure one GPRS access point:

Storing/editing connection settings (operator provided)

You can enter up to 5 different profiles. To enter and store the profile details:

* The availability of GPRS depends on your mobile phone model and on your subscription

Access to the connection settings depend upon whether the settings have been pre-programmed prior to shipment from the factory. In some cases and to avoid errors these settings are 'locked' and are not user programmable.

For further information about GPRS, the services available and the charges, please contact your service provider.

Press . Select Internet. Select Settings. Select GPRS access points *.

Select an empty profile ([...]) and press New .

Enter the Alias name and press OK . Enter the Full name and press OK . Enter the Login name and press OK . Enter the Login password and press OK .

Press . Select Internet. Select Profile list.

Select an empty profile ([...]) and press Options . Select Edit.

Enter the 4 digit phone lock code (default code 0000) and press OK . Enter the Proxy name and press OK . Select the connection mode (Circuit, Packets or Circuit+packets).

123412345

The menu

Depending on your choice of connection mode, the questions that follow vary. Follow the column that corresponds to your choice, entering or selecting and confirming with OK or Select :

Personalising your connection settings

Optimise the behaviour of your phone while connected to the internet with the following settings:

Circuit Packets Circuit+Packets

Phone number Access point Access Point Analog or numeric IP address Phone number 9600 or 14400 Home page: http:// Analog or numeric Login name Activate security 9600 or 14400 Login password - Login name IP address - Login password Home page: http:// - IP address Activate security - Home page: http://

- - Activate security To activate the required profile, use or to select it from the

displayed list. Press Options and select Select to validate.

Press Exit or to return to the stand-by display.

1. You can also access the Internet menu directly by pressing the Internet softkey from the standby display (provided you have not personalised the left softkey).

2. If the phone number, login names and password, Home page http address and IP address are not predefined, get these from your network operator and/or internet provider.

Press . Select Internet. Select Settings. Scroll to the following items and turn on or off as required:

Option Action

Clear cache

Clears the memory used to store information that you downloaded. To clear this memory, select the

Yes option.

Download

pictures

Select the Off option to reject picture downloading. This decreases the page downloading time.

Scripting

Used to allow or forbid the execution of scripts within a page.

Auto-

disconnect

Disconnects the mobile from the internet after a set period of inactivity for packets or circuit connections. Enter the period (0 - 60 minutes) and press OK . 0 deactivates the auto-disconnect function.

67123

Going online

To go online:

Once connected, your provider specific menu options appear. The icon indicates a 'live' circuit connection. The icon indicates a GPRS* connection. By default the connection is not secure. To have a secure connection, set “Security on” (see page 54). The icon indicates a 'live' secure circuit connection. The icon indicates a secure GPRS* connection.

Using while online

Press while online presents the following options:

The appearance of these items depends on the operator and/or values in the Settings menu.

Ending the online connection

To end the online connection:

* The availability of GPRS depends on your mobile phone model and on your subscription

Option Action

Preferred

bearer

Choose your preferred connection circuit or packets. If your preferred connection is not available, the phone asks to use the other bearer.

GPRS access

points *

Choose the GPRS access point you want used first. At least one must be defined if you choose packet bearer. The access point is operator specific. When roaming you must change the access point.

Press Exit or to return to the stand-by display.

Press . Select Internet. Select Home page. Connecting to followed by your proxy name appears. Then the word Loading... (of the home page) appears.

Item Action

Back Returns to the previous page

Zoom +/- Increases or decreases the displayed text size

Add bookmarks Adds a current card to the list of bookmarks

Go to bookmarks Goes to a bookmark

Reload Reloads the current page

Home page Reloads the home page

Other Site Enter a different site

Disconnect

Disconnects the browser from the network but

leaves the current page locally active

Close session Disconnects the phone from the internet

Press .

You can also select Close session item under the options menu.

412

The menu

Creating bookmarks

To revisit specific cards more quickly, use bookmarks to store the card address. This function depends on your provider. You can create a maximum of 10bookmarks. Create bookmarks from the stand-by display or while viewing a page.

Directly from the stand-by display:

During a live connection while viewing page:

Using bookmarks

Bookmarks can be used from the stand-by display or while browsing.

• Directly from the stand-by display:

• While browsing the internet:

Other site

You can enter another internet address directly by using the Other site option from the Internet menu. Addresses are not stored and must be en- tered each time.

GSM man machine interface codes

The phone supports the standard GSM key sequences using the * and # characters sent directly from the keypad to the network. These sequences are used to activate all the supplementary services provided by the network. Consult your service provider for a complete list.

Press . Select Internet. Select Bookmarks. Press Options , select Modify and enter the following:

Option Action

Alias Name you wish to give to your bookmark Address Home page address

Press OK to validate each entry. Press Exit or to return to the stand-by display.

Press to display the options menu. Select Add bookmark, enter the Alias name and press OK .

Bookmarks can only be Edited or Deleted from the Bookmarks item under the Internet menu options while offline.

Press . Select Internet. Select Bookmarks. Select the bookmark name you require.

To access the Internet directly use the Internet softkey (if not personalised).

Press to display the options menu. Select Go to bookmarks. Select the bookmark name you require.

1234512123123

Accessories

Using the headset

Connecting the headset

Using the headset

Disconnecting the headset

Insert the headset plug in the phone headset connector as shown below.

While inserting the headset plug in the phone headset connector make sure the Trium logo ( ) appears on top. Otherwise the headset does not work properly.

Place the headset earpiece in your ear. The headset microphone is then at a convenient level for operation. You can answer, reject and end calls using or

(see page 9). Adjust the earpiece volume level using or

Tilt the headset plug down as shown below.

Earpiece

Microphone

Accessories

Changing the front cover (for Aura and Odyssey only)

Before changing the cover always switch off the phone and disconnect from any charging device or car kit.

Removing the cover

Remove the front cover as shown below.

Replacing the cover

Replace the front cover as shown below.

Do not use unnecessary force when changing the cover. Avoid excessive bending. Avoid removing and replacing the front cover too often: this can weaken the front cover hooks and clips. Do not leave in direct sunlight. Always use the phone with the cover attached. Do not clean the phone and/or front cover with alcohol, strong chemicals or solvents. Wipe it only with a soft, slightly dampened cloth. Read the Care and maintenance instructions, page 13.

Slot

Clips

Hook slots

Hooks

Appendix

Glossary

Expression Meaning

AC/DC charger Alternating Current/Direct Current charger

Active call The call currently in conversation

ALS Alternate Line (Line 2) Service

AoC Advise of Charge - subscription service

APN GPRS Access Point Name

CB Cell Broadcast

CLI Caller Line Identity - displays callers telephone number

Conversation mode When the phone is making or receiving a call

DES Data Encryption standard

Diverting Diverts incoming calls to the phone to another number

DTC Desk Top Charger

DTMF Dual Tone Multifrequency Tones

FDN Fixed Dialling Number

GPRS General Packet Radio Service

GSM Global System for Mobile communications

http HyperText Transfer Protocol

IN Information Numbers of your operator

IP Internet Protocol

LCD Liquid Crystal Display

MMI Man machine Interface

PIN/PIN2 Personal Identification Number. Supplied by your net-

work/service provider

Appendix

PPP Point to Point Protocol

PUK/PUK2 PIN Unblocking Key. Used to unlock PIN and PIN2. Sup-

plied by your network/service provider

Roaming (Rm) The ability to use your telephone at home or abroad.

SDN Service Dialling Number. Of your operator or service

provider

SIM Subscriber Identity Module. Supplied by your network/

service provider

SMS Short Message Service

SPN Service Provider Name

SR Status Report - relates to SMS messages

Stand-by mode When the phone is on, registered onto a network but

not making or receiving a call

URL Uniform Resource Locator

WAE Wireless Application Environment

WAP™ Wireless Application Protocol

WSP Wireless Session Protocol

WTP Wireless Transport Protocol

Trouble shooting

Problem Possible cause and solution

Phone will not switch onCheck that the battery is fully charged and correctly

connected to the phone.

No flashing battery icon There may be no mains supply. Try a different electrical

socket. The AC/DC charger may be faulty. Return to your dealer and try substitution with another Mitsubishi adaptor. If faulty contact your dealer.

Short stand-by and talk times

Cell broadcast is permanently on, using more battery power. Phone is in a poor signal area and therefore always on full power. Incorrect charging and discharging. Always charge and discharge your battery fully. The battery is wearing out. Replace the battery.

Calls cannot be made or received

Check that you have at least one signal strength bar ( ). Try in a stronger signal strength area. If the name of a network is not displayed, check your SIM is OK, check registration with your network/service provider. Call barring option is turned on. Turn it off (see page48). Call cost limit is reached (see page 35).

Stored telephone numbers cannot be recalled

Fixed Dialled Number or Call Barring features are turned on. Check features and turn them off (see pages28 and48).

Numbers cannot be entered in the display

Keypad lock is on ( appears). Press Unlock and to turn off.

Phone switches on but there is no display

Display contrast is turned down too low. Reset contrast (see page 39).

Battery icon not flashing 1-2-3 during charging

Indicates a charging or battery problem. Turn off and disconnect the charger. Reconnect and try again. If the problem remains contact your dealer.

Flashing There is not enough memory to store another SMS mes-

sage. You must delete one or more of the existing stored messages (see page 29).

(......) softkey Function no longer available in the SIM or was subscrip-

tion dependent. Reprogram the softkey (see page 40).

Appendix

Error messages

Problem Possible cause and solution

Allowed credit reached!

You are trying to place an outgoing call and the allowed credit is already reached. The allowed credit limit is reached during an outgoing call (the call is then aborted).

Busy

You are trying to make a call and the call fails because the destination number is already engaged in conversation.

Call failed

The user is unreachable. The outgoing call fails due to: the network cannot take the call due to system busy or the number is out of order or the number is unreachable or the network does not answer or the option to hide your phone number when calling is not supported by the network Control the ability to hide your ID when making a call (service availability in network).

Cancelled. No type selected

Cell broadcast activation has been requested but no message type has been selected.

Cannot execute command

You have made a request which is impossible to be executed in the current call situation.

Can't display message

The short message text cannot be displayed (characters not recognised, incorrect format etc.)

Check SIM!

There is no SIM present or the SIM is incorrectly inserted. See page 8 for more details.

Check your password

You changed the call barring password or You changed the call barring service status. The entered password seems to be wrong or incorrect.

Check your request

You made a request for a service that seems to be impossible to fulfil.

Check your subscription

You tried to activate a GSM service. You are requested to check your subscription regarding the related service rights of use/access.

Error!

The network cannot perform your request and generates an error result.

Failed

An SMS sending process failed (the short message cannot be sent).

Incorrect entry

You entered a character string with a syntax error.

Invalid number

You tried to make a call and the call is rejected by the network because the network does not recognise the phone number structure or you tried to store a phone number that is too long to be stored in the selected location or you tried to move a phone entry to a location that is unable to receive the phone number (phone number too long)

Keypad locked "Unlock" # to unlock

A press on any key is made with keypad locked.

Low battery!

This text appears when the battery becomes too low and the mobile soon switches off automatically.

Network busy

You tried to make a call. The call is rejected by the network due to congestion problems.

Network not allowed

When selecting network manual search, you have selected a network that rejects the connection.

New PIN incorrect. Try again

Changing PIN: the new PIN code values differ (value control).

New PIN2 incorrect. Try again

Changing PIN2: the new PIN2 code values differ (value control).

No action performed

When a copy/move operation is made on memories but no conditions have been changed (same memory, number and name).

No response

You made a call to a remote user and no response has been received.

Not allowed

Your number/character entry is not allowed.

Not allowed (fixed dialling)

A call is tried, but cancelled due to fixed dialling control (the number dialled does not match with one of the fixed dialling numbers in memory).

Not Available

There is no more SIM storage.

Number changed

The called number has changed.

PIN blocked

A wrong PIN code has been entered 3 times.

PIN2 blocked

A wrong PIN2 code has been entered 3 times.

Appendix

PUK2 blocked

A wrong PUK2 code has been entered 10 times. The SIM services protected by the PIN2 code have now been permanently disabled.

Reaching allowed credit!

The cost limit is about to be reached. The connected call ends automatically when the limit is reached.

Ring volume Off

The ring volume is set to 0 (no volume).

Service not available

Activating some GSM services that are not available on the network

SIM blocked. Contact provider

A wrong PUK has been entered 10 times. The SIM card has been permanently disabled and needs to be replaced by a new one.

SIM blocked. Enter PUK:

A wrong PIN code has been entered 3 times. Enter the PUK code to unblock the SIM card.

SIM fixed full SIM names full Phone names full

The corresponding memory is full.

SMS memory locations are full

The storage of new messages (when writing a new SMS) is impossible.

Wrong code. Try again

A wrong phone lock code has been entered.

Wrong new code. Try again

The new phone lock codes do not match (value control).

Wrong PIN, try again Wrong PIN2, try again Wrong PUK, try again Wrong PUK2, try again

The wrong code has been entered.

Guarantee

Pan European Service

If you require service, then in the first instance, you should contact your supplier. Should you experience any difficulty then please contact your nearest MITSUBISHI location listed below for information on other service centres.

To obtain Warranty Service, you will require your original equipment purchase invoice or irrefutable proof of purchase. Please see warranty terms and conditions for in warranty service.

Pan-european GSM End-user Guarantee Conditions

1.You can benefit from this guarantee only if you are the original end-user purchaser.

2.MITSUBISHI guarantees that for a period of twelve (12) months from the date of purchase from your dealer, the Product shall be free from defects in materials and workmanship. Subject to the conditions below, Mitsubishi will indemnify you against all cost of parts and labour for repairs to or replacement of the product or parts (which may include equipment of similar type) where conducted by an authorised MITSUBISHI GSM service centre. MITSUBISHI shall be entitled to retain product which has been replaced.

3.Any claims must be made to an authorised MITSUBISHI GSM service centre in the countries mentioned in the service card enclosed with the product. In case of difficulty you can contact the Mitsubishi companies listed in the service card to obtain details of your nearest authorised MITSUBISHI GSM service centre. As a condition of this guarantee, the date of your purchase must be confirmed by producing your original invoice from your supplier or your sales receipt, showing the serial number, together with the service card. Final determination of guarantee claim eligibility shall be made by MITSUBISHI. MITSUBISHI shall not be liable for shipment costs to and from an authorised GSM MITSUBISHI service centre; the product travels at your risk.

4.This guarantee does not cover: a)battery defects of any nature; b)non-compliance with directions for use; c)installation or removal charges where the product is installed in a vehicle; d)defects or failures caused by accident, misuse, improper installation or improper repair

by an unauthorized repairer, alteration or modification, neglect, failure to use for normal purpose, Acts of God, water ingress, use in adverse environmental conditions (humidity or temperature);

e)cost of or performance of modifications to product to adapt or adjust to conform to

national or local safety laws, where such safety laws go beyond harmonised European

Union standards; f)loss of use of the product or consequential loss of any nature; g)loss of use of air-time, loss of use of any loaned equipment or ancillary equipment; h)provision of incorrect or insufficient signal on air-time network, upgrading of product

software to changes in network operating parameters, mains supply voltage fluctua-

tions, incorrect SIM card (memory card) parameters for connection to airtime retailer; i)damage caused by non-MITSUBISHI accessories.

5.Any guarantee claim or service does not extend the original guarantee period unless so required by prevailing national law.

6.This guarantee is valid only if the product is purchased and used in the European Union, Norway, Iceland or Switzerland.

THIS GUARANTEE DOES NOT AFFECT YOUR STATUTORY RIGHTS.

UNITED KINGDOM

Tel: (0800) 912 00 20

ESPAÑA

Tel: (902) 11 68 58

BELGIUM

Tel: (0800) 775733

FRANCE

Tel: (0825) 86 82 83

ITALIA

Tel: (800) 27 59 02

SWITZERLAND

Tel: 032 843 65 11

DEUTSCHLAND

Tel: (01803) 33 71 84

IRELAND

Tel: (1800) 92 70 12

THE NETHERLANDS

Tel: (0800) 0223825

Declaration of compliance

DECLARATION OF COMPLIANCE

6 June 2001,

Viet Mailam Managing Director

Declaration of compliance

Name : Mitsubishi Electric Telecom Europe S.A.

RCS Nanterre B 307 593 129 Address : 25, boulevard des Bouvets Town : Nanterre Cedex Postal code : 92741

Identification of the product

Nature : Mobile Cell Telephone Type : Dual band GSM 900/DCS 1800 Sales reference : MT-060 Other information :

Identification of the notified organization

Name : Autorité de Régulation des Télécommunications (ART) Identification number : 0165 Procedure followed : Annex III of the directive 1999/5/CE

Declares under its entire responsibility that the product described above complies with the following basic applicable requirements (and in particular those in the 1999/5/CE directive):

Article 3.1a: (health protection and user safety)

73/23/CEE, ES 59005

Article 3.1b: (protection requirements concerning electromagnetic compatibility)

89/336/CEE, ETS 300 342-1

Article 3.2: (proper use of the radio-electric spectrum so as to avoid damaging interference)

EN 301 511

To this effect, declares that all the radio test series have been carried out.

DECLARATION OF COMPLIANCE

6 June 2001,

Viet Mailam Managing Director

Name : Mitsubishi Electric Telecom Europe S.A.

RCS Nanterre B 307 593 129 Address : 25, boulevard des Bouvets Town : Nanterre Cedex Postal code : 92741

Identification of the product

Nature : Mobile Cell Telephone Type : Dual band GSM 900/DCS 1800 Sales reference : MT-160 Other information :

Identification of the notified organization

Name : Autorité de Régulation des Télécommunications (ART) Identification number : 0165 Procedure followed : Annex III of the directive 1999/5/CE

Declares under its entire responsibility that the product described above complies with the following basic applicable requirements (and in particular those in the 1999/5/CE directive):

Article 3.1a: (health protection and user safety)

73/23/CEE, ES 59005

Article 3.1b: (protection requirements concerning electromagnetic compatibility)

89/336/CEE, ETS 300 342-1

Article 3.2: (proper use of the radio-electric spectrum so as to avoid damaging interference)

EN 301 511

To this effect, declares that all the radio test series have been carried out.

Declaration of compliance

DECLARATION OF COMPLIANCE

6 June 2001,

Viet Mailam Managing Director

Name : Mitsubishi Electric Telecom Europe S.A.

RCS Nanterre B 307 593 129 Address : 25, boulevard des Bouvets Town : Nanterre Cedex Postal code : 92741

Identification of the product

Nature : Mobile Cell Telephone Type : Dual band GSM 900/DCS 1800 Sales reference : MT-260 Other information :

Identification of the notified organization

Name : Autorité de Régulation des Télécommunications (ART) Identification number : 0165 Procedure followed : Annex III of the directive 1999/5/CE

Declares under its entire responsibility that the product described above complies with the following basic applicable requirements (and in particular those in the 1999/5/CE directive):

Article 3.1a: (health protection and user safety)

73/23/CEE, ES 59005

Article 3.1b: (protection requirements concerning electromagnetic compatibility)

89/336/CEE, ETS 300 342-1

Article 3.2: (proper use of the radio-electric spectrum so as to avoid damaging interference)

EN 301 511

To this effect, declares that all the radio test series have been carried out.

Index

Alarm

Clock .............................. 51

Alert mode ............................ 37

Alert tone

Turning on/off ................ 30

Alias ...................................... 54

Any key answer ..................... 40

Auto

Answer ........................... 41

Retry .............................. 41

Auto-disconnect .................... 55

Automatic search .................. 48

Auto-switch ........................... 52

Backlight ........................ 16, 39

Balance Info .......................... 34

Balance information .............. 34

Barring password

Call ................................. 43

Basic operations

SMS ............................... 16

Unanswered call ............. 16

Voice mail ...................... 16

Battery .................................... 8

Alarm volume ................ 38

Charging ........................ 11

Disposal ......................... 14

Fitting ............................ 11

Low battery warning ...... 11

Removing ....................... 11

Safety information ......... 14

Use ................................. 14

Battery cover

Replacing ......................... 8

Bookmarks

Creating ......................... 57

Deleting ......................... 57

Using ............................. 57

Broadcast .............................. 49

Alert ............................... 50

Language ....................... 50

Message types ........ 49, 50

On/Off ............................ 50

Cache memory

Clearing ......................... 55

Calculator .............................. 52

Call

Conference ..................... 21

Duration ......................... 34

Holding .......................... 20

Multi-party ..................... 21

Reminder ....................... 34

Retrieving ....................... 20

Times ............................. 33

Waiting .......................... 20

Call barring ........................... 48

Password ........................ 15

Call costs

Reset .............................. 36

Call timer

Reset .............................. 35

Caller line identity ................. 46

Calling ..................................... 9

Calls & Times ......................... 33

Call costs ................. 35, 36

Call timers ............... 34, 35

Calls log ......................... 33

Costs .............................. 35

Line selection ................. 36

Calls Log ............................... 33

Care and maintenance .......... 13

CB ......................................... 49

CB messages

Deleting ......................... 50

Editing ........................... 50

Reading .......................... 50

Cell broadcast ....................... 49

CLI ......................................... 46

Conference call ..................... 21

Connection profile ................ 54

Cost management ................. 35

Cover

changing ........................ 59

removing ....................... 59

Replacing ....................... 59

Creating a draft text ....... 30, 31

Credit limit ............................ 35

Currency-converter ................ 53

Date setting .......................... 44

Default settings ..................... 44

Dialling

Calls Log memory .......... 17

Phonebook ..................... 17

Dialling from memory ........... 17

Display contrast .................... 39

Diverting ............................... 45

Draft text

Creating ......................... 30

Editing ........................... 31

DTMF tones ........................... 19

Emergency calls ..................... 13

Ending a call ......................... 10

Entering text ......................... 22

Error messages ...................... 63

FDN ....................................... 28

Fixed dialling numbers .......... 28

Front cover

Replacing ....................... 59

Full name .............................. 54

Games ................................... 53

General

Safety ............................... 6

Getting started ........................ 8

Glossary ................................ 60

GSM man machine interface co-

des .................................... 57

GSM Services ........................ 45

Call barring ...... 43, 48, 49

Call diverting .......... 45, 46

Network .................. 47, 48

Receiving caller ID .......... 46

Sending my ID ............... 47

Guarantee ............................. 66

Handsfree features ................ 18

Headset

Use ................................ 58

Holding a call ........................ 20

In-call options ....................... 22

Incoming Calls

Diverting ........................ 45

Internet .......................... 16, 54

Alias ............................... 54

Bookmarks ..................... 57

Full name ....................... 54

Going online .................. 56

Home page .................... 56

Other site ....................... 57

Personalising .................. 55

Profile list ....................... 54

Proxy name .................... 54

Settings .................. 54, 55

Keypad lock ................... 16, 36

Language selection ............... 37

Last dialled numbers ............. 17

Line 1 ........ 28, 33, 34, 36, 46

Line 2 ..................... 28, 33, 34,

......................... 36, 40, 45, 46

Making a call .......................... 9

Managing SMS messages ...... 30

Melodies ............................... 37

Melody composer ................. 38

Melody download ................. 39

Menu .................................... 22

Menu graphics ...................... 39

Menu map ............................ 22

Message templates ............... 32

Messages ....................... 16, 29

Alert ............................... 30

Draft texts ...................... 31

Inbox ............................. 29

Msg. Templates ............. 32

Outbox .......................... 32

Settings ......................... 30

Storage .......................... 33

Write new ............... 31, 32

Index

Mobile number

Hiding ............................ 46

Showing ........................ 46

Multi-party call ..................... 21

Muting .................................. 18

Network ................................ 47

Network services ................... 25

Office Tools

Alarm clock .................... 52

Scratchpad .................... 51

Office tools ........................... 51

Online connection ................. 56

Bookmarks ..................... 57

Ending ........................... 56

Personalising ................. 55

Outbox .................................. 32

Own number ........................ 28

Pause feature ........................ 19

Phone

Customising ................... 36

Phone Book

Calling numbers ............ 27

Fixed Dialling ................. 28

Free space ...................... 27

Own numbers ................ 28

Recall ............................. 27

Remaining ..................... 27

Store .............................. 26

Viewing numbers .......... 27

Phone lock ............................ 41

Code ....................... 15, 41

Phone settings ...................... 36

Phonebook ........................... 25

PIN code ............................... 42

PIN/PIN2 codes ...................... 15

PIN2 code ............................. 42

Problems ............................... 63

Programmable

Softkeys ......................... 40

Speed dialling ................ 18

Proxy name ........................... 54

PUK code .............................. 43

PUK/PUK2 Codes ................... 15

PUK2 code ............................ 43

Push ...................................... 53

Ramping ............................... 38

Reading an SMS message ..... 29

Receiving a call ..................... 10

Reminder - call time .............. 34

Reshape ................................ 53

Responsibility ........................ 15

Retrieving a call .................... 20

Ring ...................................... 37

Ring tone .............................. 37

Safety information .................. 6

Battery ........................... 14

Care and maintenance ... 13

Emergency calls ............. 13

Responsibility ................ 13

Security codes ............... 13

Vehicle safety ................ 13

Scratchpad ............................ 51

Scripting ............................... 55

Second call ........................... 20

Security ................................. 41

Codes ............................ 15

Features ......................... 41

Sending an SMS message ..... 31

Settings ................................ 36

Auto features ................ 41

Broadcast ............... 49, 50

Default settings ............. 44

Display ........................... 39

GSM Services .. 43, 45, 46,

47, ...................... 48, 49

Internet ......................... 54

Keypad lock ................... 16

Keys ............................... 40

Language ...................... 37

Menu graphics .............. 39

Phone settings 16, 37, 38,

39, ........ 40, 41, 42, 44

Security .................. 41, 42

Time & date ................... 44

Tones ...................... 37, 38

Voice Mail .............. 44, 45

Show costs ........................... 36

Silent .................................... 37

Silent alert mode .................. 18

SIM

Card ................................ 8

SMS ............................... 16, 29

SMS messages

Managing ...................... 30

Preparing your phone .... 30

Reading ......................... 29

Sending ......................... 31

Storing .......................... 32

Softkey programming ........... 40

Solutions ....................... 62, 63

Speed dialling ................ 18, 40

Standby display ...................... 9

Storage consumption ........... 33

Storing an SMS message ...... 32

Storing names and numbers . 25

T9 text entry ......................... 23

Tegic (T9) .............................. 23

Time & date .......................... 44

Time settings ........................ 44

Trouble shooting .................. 62

Turning

Off ................................. 11

On ................................... 9

Vehicle safety ........................ 13

Vibrate .................................. 37

& ring ............................ 37

then ring ....................... 37

Vibrate alert modes .............. 18

Voice Mail

Alert .............................. 45

Call ................................ 45

Number ......................... 44

Voice mail ............................. 44

Password ....................... 15

Volume ................................. 18

Adjustment ................... 18

Alert mode .................... 38

Conversation ................. 38

Keys tones ..................... 38

Ring tone ....................... 38

WAP™ ................................... 54

FA9M070510-A

Mitsubishi ODYSSEY, AURA, MYSTRAL, Trium Aura, Trium Mystral User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
