Mitsubishi MCF-13NV-E3, MUCF-13NV-E3 Service Manual

FLOOR AND CEILING TYPE AIR CONDITIONERS

SERVICE MANUAL

Wireless type
Model

No. OB239

MCF-13NV-

(When installed on the floor)

(When installed on the ceiling)

(WH)

·MUCF-13NV-

CONTENTS

1. TECHNICAL CHANGES ····································2

2. PART NAMES AND FUNCTIONS······················2

3. SPECIFICATION·················································4

4. NOISE CRITERIA CURVES ······························ 5

5. OUTLINES AND DIMENSIONS·························6

6. WIRING DIAGRAM ············································7

7. REFRIGERANT SYSTEM DIAGRAM················8

8. PERFORMANCE CURVES································9

9. MICROPROCESSOR CONTROL ····················15

10. SERVICE FUNCTIONS·····································21

11. TROUBLESHOOTING ······································22

12. DISASSEMBLY INSTRUCTIONS·····················28

13. PARTS LIST······················································32

14. OPTIONAL PARTS ···········································35

E3E3

MCF-13NV -

E3

1

TECHNICAL CHANGES

MCF-13NV - ➔MCF-13NV -

1. Indoor unit model name has changed.

E3E2

MUCF-13NV - ➔MUCF-13NV -

1. Outdoor unit model has changed.

2

PART NAMES AND FUNCTIONS

E3E2

MCF-13NV -

E3

INDOOR UNIT

(When installed on the floor)

Operation section

(When the air inlet grille is opened.)

Vertical vanes
Horizontal vane
Operation indicator lamp

Receiving section
Front panel

Air cleaning filter (whilte bellows type)(option)

Air inlet
Air filter

Deodorizing filter (gray sponge type)(option)

Remote controller

Emergency operation switch

(When installed on the ceiling)

2

MUCF-13NV -

OUTDOOR UNIT

E3

Air inlet

(back and side)

Piping

Drain hose

Air outlet

Drain outlet

MCF-13NV -

E3

REMOTE CONTROLLER

CLOCKCLOCK

3

RESETRESET

3

Model

Function

Power supply
Capacity
Dehumidification
Air flow
Power outlet
Running current
Power input
Auxiliary heater
Power factor
Starting current
Compressor motor current
Fan motor current

kW

R/h

K/h

A
A

W

A(kW)

%

A
A
A

W

"

"

"

mm
mm
mm
mm
mm
mm

kg
kg

dB

dB
rpm
rpm

kg

cc
k"
k"

Capacity

Electrical
data

Coefficient of performance(C.O.P)

Compressor

Indoor
fan motor

Outdoor
fan motor

Dimensions

Indoor unit

Indoor unit

Width
Height
Depth
Width
Height
Depth

Indoor unit
Outdoor unit
Indoor unit
Outdoor unit
Indoor unit
Outdoor unit

RT11(at 25:)
RT12(at 25:)

Sound level
(Hi)
Fan speed
(Hi)
Fan speed
regulator

Outdoor unit

Outdoor unit
Air direction

Refrigerant filling capacity(R-22)
Refrigerating machine oil <Model>

Thermistor

Weight

Special
remarks

Model
Output
Winding resistance (at 20:)
Model

Winding resistance (at 20:)

Model

Winding resistance (at 20:)

MCF-13NV-

E3

Cooling

Single phase, 220-240V, 50Hz

3.7

1.6

678

10

6.3-6.3

1,310-1,380

—
95-91
35-38

5.74-5.72

0.56-0.58

2.82-2.68

RH-231VHAT

1,100

C-R2.11 C-S3.97

RA6V33-CB
WHT-BLK 176
BLK-RED 413

34

5

43-44

49

1,080-1,130

700-750

3
1

0.85

520 <MS-56>

10
10

1,100

650
180
780
540
255

26

RB4V19-AB

WHT-BLK 203.2 BLK-YLW 45.9
YLW-BLU 32.7 BLU-BRN 44.4
BRN-RED 23.3

SPECIFICATION

NOTE:Test conditions

Cooling : Indoor DB27°C WB19°C Outdoor DB35°C WB24°C

4

4

90

80

70

60

50

40

30

20

10

63 125 250 500 1000 2000 4000 8000

NC-60

NC-50

NC-40

NC-30

NC-20

NC-70

OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.002 MICRO BAR

BAND CENTER FREQUENCIES, Hz

Test conditions,
Cooling : DB 27

:

WB 19

:

APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE

Hi

(220-240V)

NOTCH

43-44

SPL(dB

(A)) LINE

NOISE CRITERIA CURVES

MCF-13NV -

E3

MUCF-13NV -

E3

NOTCH

Hi

SPL(dB

49

(A)) LINE

Test conditions,

90

Cooling : DB 35

:

WB 24

:

80

70

NC-70

60

NC-60

50

NC-50

40

NC-40

30

NC-30

APPROXIMATE

20

THRESHOLD OF
HEARING FOR

OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.002 MICRO BAR

CONTINUOUS
NOISE

10

63 125 250 500 1000 2000 4000 8000

NC-20

BAND CENTER FREQUENCIES, Hz

5

5

(When installed on the floor)

(When installed on the ceiling)

50cm or more

50cm or more

50cm or more

50cm or more

100cm or more

650

616.5

80.8 906 112.8

114

16

1100

93

77

113

143

180

17042.5

160

56

17.5

12.7

Gas line

6.35

Liquid line

320

25

43-

35-

155

90

104

74

260

10

780

500

122

40

540

320

285

255

Service panel

Gas refrigerant
pipe joint
Refrigerant pipe
(flared)[12.7

Liquid refrigerant
pipe joint
Refrigerant pipe
(flared) [6.35

Airout

Air in

Air in

109

32

110

147

Drainage
3holes [33

If clearance
behind the outdoor
units only 40

B or 50

B

side

A must be

fully open.

10cm or more

10cm or more

10cm or more

Outdoor

unit

35cm or more

REQUIRED SPACE

A

40cm or more

OUTLINES AND DIMENSIONS

MCF-13NV -

INDOOR UNIT

E3

Unit: mm

MUCF-13NV -

OUTDOOR UNIT

E3

6

WIRING DIAGRAM6

SYMBOL

MF

TB

SYMBOL

F

MC

SYMBOL

C1
C2

NAME

NAME NAME
COMPRESSOR CAPACITOR
OUTDOOR FAN CAPACITOR

FUSE(2A)
COMPRESSOR(INNER THERMOSTAT)

OUTDOOR FAN MOTOR(INNER THERMOSTAT)
TERMINAL BLOCK

W

W

MF

BLK

WHT

RED

N

2

220-240V~

BLU

BLU

WHT

BLK

RED

C1

TB

F

C2

RED

WHT

1
2
3

GRN/YLW

FROM
INDOOR UNIT
CONNECTING

C

S

R

MC

WHT

WHT

MCF-13NV -

INDOOR UNIT

CIRCUIT BREAKER

TO OUTDOOR
UNIT
CONNECTING

REMOTE
CONTROLLER

SYMBOL

C11
F11

HIC1

MF

NOTE:1. For the outdoor electric wiring refer to the outdoor unit electric wiring diagram for servicing.

2. Use copper conductors only.(For field wiring)

3. Symbols below indicate.
: Terminal block, : Connector

E3

MODEL WIRING DIAGRAM

TB

PE

GRN/YLW

N

BLU

W

L

W

BRN

POWER SUPPLY
~/N 220-240V
50Hz

GRN/YLW

N

W

BLU

2

220-240v~

INDOOR FAN CAPACITOR
FUSE (3.15A)
DC/DC CONVERTER
INDOOR FAN MOTOR(INNER FUSE)

W

WHT

DISPLAY &
RECEIVER
P.C.BOARD

NAME

AUTO RESTART
ASSEMBLY

SYMBOL

CN
101

5

5

MV
NR11
RT11
RT12

W

4

52C

3

W

TRANS

ELECTRONIC CONTROL P.C BOARD

CN
104

CN
113

5

3
2
1

CN201

CN
151

4

6
6

MV

SW/THERMO
P.C.BOARD

RT11

NAME NAME
VANE MOTOR
VARISTOR
ROOM TEMPERATURE THERMISTOR
COIL TEMPERATURE THERMISTOR

HIC1

F11

C11

NR11

SR144

SR142
SR143

SYMBOL
SR142~
SR144

TB

52C

2

CN
112

LDCOM
LDC11

LDC12

LDFH
LDFL
LDFM

2

WHT
ORN
RED

BLK
BLU
YLW

SOLID STATE RELAY
TERMINAL BLOCK

CONTACTOR

1
2
3
7
4
6
5
8

RT12

WHT
ORN
RED
BRN
BLK
BLU
YLW

GRN/YLW

MF

MUCF-13NV -

OUTDOOR UNIT

E3

MODEL WIRING DIAGRAM

NOTE : 1. Use copper conductors only (For field wiring).

2. “W” shows the terminals with a lock mechanism,
so they cannot be removed when you pull the lead wire.
Be sure to pull the lead wire by pushing the locking lever
(projected part) of the terminal with a finger.

7

1Slide the sleeve.
2Pull the wire while pushing the locking lever.

REFRIGERANT SYSTEM DIAGRAM7

Refrigerant flow in cooling

Indoor
heat
exchanger

Indoor coil
thermistor
RT12

Room
temperature
thermistor
RT11

(option)
(With heat insulation)

Refrigerant pipe

[

12.7

(option)
(With heat insulation)

Refrigerant pipe

[

6.35

Flared

connection

Stop valve
(with service port)

Stop valve

Compressor

Strainer

Capillary tube

[3.0 ✕[1.6 ✕ 300

Outdoor

heat

exchanger

Distributor

Length : m (ft)

A

15(49)

Gas

[12.7(1/2)

Liquid

[6.35(1/4)

Piping size O.D : mm(in.)

Model

MCF-13NV - E3

Outdoor unit precharged

850

15m

120

8m

15

10m

45

MCF-13NV - E3

Calculation : Xg=15g/mx(A-7)m

Model

Refrigerant piping length (one way)

14m

105

13m

90

11m6012m

75

9m

30

7m

0

MCF-13NV -

Unit:mm

E3

MUCF-13NV -

E3

INDOOR UNIT

MAX. REFRIGERANT PIPING LENGTH & MAX. HEIGHT DIFFERENCE

OUTDOOR UNIT

MAX. HEIGHT DIFFERENCE

✽Height difference should be within

5m regardless of which unit,
indoor or outdoor position is high.

A: Refrigerant piping
Max.length
15m(49ft)

ADDITIONAL REFRIGERANT CHARGE (R-22 : g)

5m(16ft)

Max. Height difference

✽

8

8

Air in

Air out

Wet-and dry-bulb
thermometers

FRONT VIEW

Dry-bulb
thermometers

BACK VIEW

PERFORMANCE CURVES

MCF-13NV -

The standard data contained in these specifications apply only to the operation of the air conditioner under normal conditions,
Since operating conditions vary according to the areas where these units are installed. The following information has been
provided to clarify the operating characteristics of the air conditioner under the conditions indicated by the performance curve.

E3

(1) GUARANTEED VOLTAGE

Rated voltage : ±10% (198~264V), 50Hz

(2) AIR FLOW

Air flow should be set at MAX.

(3) MAIN READINGS

(1) Indoor intake air wet-bulb temperature : ˚CWB
(2) Indoor outlet air wet-bulb temperature : ˚CWB
(3) Outdoor intake air dry-bulb temperature : ˚CDB
(4) Total input : W

Indoor air wet-bulb temperature difference on the left side of the chart on this page shows the difference between the
indoor intake air wet-bulb temperature and the indoor outlet air wet-bulb temperature for your reference at service.

How to measure the indoor air wet-bulb temperature difference

1. Attach at least 2 sets of wet-and dry-bulb thermometers to the indoor air intake as shown in the figure, and at least 2 sets of
wet-and-dry-bulb thermometers to the indoor air outlet. The thermometers must be attached to the position where air speed
is high.

2. Attach at least 2 sets of dry-bulb thermometers to the outdoor air intake.
Cover the thermometers to prevent direct rays of the sun.

3. Check that the air filter is cleaned.

4. Open windows and doors of the room.

5. Press the EMERGENCY OPERATION switch to start the EMERGENCY COOL MODE.

6. When system stabilizes after more than 15 minutes, measure temperature and take an average temperature.

7. 10 minutes later, measure temperature again and check that the temperature does not change.

INDOOR UNIT

10.4

9.5

8.7

7.8

7.0

6.2

OUTDOOR UNIT

E3

MCF-13NV-

intake

intake

9

OUTDOOR LOW PRESSURE AND OUTDOOR UNIT CURRENT

20 25 30

0.3

0.4

0.5

0.6

0.7

0.8

20 25 30

3

4

5

6

7

8

Ambient temperature (:)
Ambient humidity(%)

18

50 60 70

32

(:)

(%)

Ambient temperature (:)
Ambient humidity(%)

18

50 60 70

32

(%)

Outdoor unit current (A)

Outdoor low pressure

7

6

5

4

3

8

(kgf/F•G)(MPa•G)

(:)

220-240V

220-240V

COOL operation
1 Both indoor and outdoor units are under the same temperature/humidity condition

Dry Bulb temperature (˚C)

20
25
30

Relative humidity (%)

50
60
70

2 Air flow should be set at MAX.
3 The unit of pressure has been changed to MPa on the international system of units(SI unit system).

ff

The conversion factor is : 1(MPa • G) =10.2(kgf/

MUCF-13NV -

E3

• G)

10

PERFORMANCE DATA
COOL operation(220V)

MCF-13NV - : MUCF-13NV -

CAPACITY: 3.7 kW INPUT : 1310 W SHF : 0.70

INDOOR INDOOR

DB(:) WB(:)

21 18 4.35 2.26 0.52 1048 4.16 2.16 0.52 1100 4.00 2.08 0.52 1153 3.85 2.00 0.52 1205
21 20 4.53 1.81 0.40 1100 4.35 1.74 0.40 1166 4.22 1.69 0.40 1192 4.07 1.63 0.40 1245
22 18 4.35 2.43 0.56 1048 4.16 2.33 0.56 1100 4.00 2.24 0.56 1153 3.85 2.15 0.56 1205
22 20 4.53 1.99 0.44 1100 4.35 1.91 0.44 1166 4.22 1.86 0.44 1192 4.07 1.79 0.44 1245
22 22 4.72 1.51 0.32 1140 4.55 1.46 0.32 1212 4.44 1.42 0.32 1245 4.26 1.36 0.32 1297
23 18 4.35 2.61 0.60 1048 4.16 2.50 0.60 1100 4.00 2.40 0.60 1153 3.85 2.31 0.60 1205
23 20 4.53 2.18 0.48 1100 4.35 2.09 0.48 1166 4.22 2.02 0.48 1192 4.07 1.95 0.48 1245
23 22 4.72 1.70 0.36 1140 4.55 1.64 0.36 1212 4.44 1.60 0.36 1245 4.26 1.53 0.36 1297
24 18 4.35 2.78 0.64 1048 4.16 2.66 0.64 1100 4.00 2.56 0.64 1153 3.85 2.46 0.64 1205
24 20 4.53 2.36 0.52 1100 4.35 2.26 0.52 1166 4.22 2.19 0.52 1192 4.07 2.12 0.52 1245
24 22 4.72 1.89 0.40 1140 4.55 1.82 0.40 1212 4.44 1.78 0.40 1245 4.26 1.70 0.40 1297
24 24 4.96 1.39 0.28 1192 4.77 1.34 0.28 1258 4.66 1.31 0.28 1297 4.51 1.26 0.28 1362
25 18 4.35 2.96 0.68 1048 4.16 2.83 0.68 1100 4.00 2.72 0.68 1153 3.85 2.62 0.68 1205
25 20 4.53 2.54 0.56 1100 4.35 2.43 0.56 1166 4.22 2.36 0.56 1192 4.07 2.28 0.56 1245
25 22 4.72 2.08 0.44 1140 4.55 2.00 0.44 1212 4.44 1.95 0.44 1245 4.26 1.87 0.44 1297
25 24 4.96 1.59 0.32 1192 4.77 1.53 0.32 1258 4.66 1.49 0.32 1297 4.51 1.44 0.32 1362
26 18 4.35 3.13 0.72 1048 4.16 3.00 0.72 1100 4.00 2.88 0.72 1153 3.85 2.77 0.72 1205
26 20 4.53 2.72 0.60 1100 4.35 2.61 0.60 1166 4.22 2.53 0.60 1192 4.07 2.44 0.60 1245
26 22 4.72 2.26 0.48 1140 4.55 2.18 0.48 1212 4.44 2.13 0.48 1245 4.26 2.04 0.48 1297
26 24 4.96 1.78 0.36 1192 4.77 1.72 0.36 1258 4.66 1.68 0.36 1297 4.51 1.63 0.36 1362
26 26 5.11 1.23 0.24 1258 4.96 1.19 0.24 1323 4.88 1.17 0.24 1362 4.74 1.14 0.24 1402
27 18 4.35 3.30 0.76 1048 4.16 3.16 0.76 1100 4.00 3.04 0.76 1153 3.85 2.92 0.76 1205
27 20 4.53 2.90 0.64 1100 4.35 2.78 0.64 1166 4.22 2.70 0.64 1192 4.07 2.60 0.64 1245
27 22 4.72 2.45 0.52 1140 4.55 2.37 0.52 1212 4.44 2.31 0.52 1245 4.26 2.21 0.52 1297
27 24 4.96 1.98 0.40 1192 4.77 1.91 0.40 1258 4.66 1.86 0.40 1297 4.51 1.81 0.40 1362
27 26 5.11 1.43 0.28 1258 4.96 1.39 0.28 1323 4.88 1.37 0.28 1362 4.74 1.33 0.28 1402
28 18 4.35 3.48 0.80 1048 4.16 3.33 0.80 1100 4.00 3.20 0.80 1153 3.85 3.08 0.80 1205
28 20 4.53 3.08 0.68 1100 4.35 2.96 0.68 1166 4.22 2.87 0.68 1192 4.07 2.77 0.68 1245
28 22 4.72 2.64 0.56 1140 4.55 2.55 0.56 1212 4.44 2.49 0.56 1245 4.26 2.38 0.56 1297
28 24 4.96 2.18 0.44 1192 4.77 2.10 0.44 1258 4.66 2.05 0.44 1297 4.51 1.99 0.44 1362
28 26 5.11 1.63 0.32 1258 4.96 1.59 0.32 1323 4.88 1.56 0.32 1362 4.74 1.52 0.32 1402
29 18 4.35 3.65 0.84 1048 4.16 3.50 0.84 1100 4.00 3.36 0.84 1153 3.85 3.23 0.84 1205
29 20 4.53 3.26 0.72 1100 4.35 3.13 0.72 1166 4.22 3.04 0.72 1192 4.07 2.93 0.72 1245
29 22 4.72 2.83 0.60 1140 4.55 2.73 0.60 1212 4.44 2.66 0.60 1245 4.26 2.55 0.60 1297
29 24 4.96 2.38 0.48 1192 4.77 2.29 0.48 1258 4.66 2.24 0.48 1297 4.51 2.17 0.48 1362
29 26 5.11 1.84 0.36 1258 4.96 1.78 0.36 1323 4.88 1.76 0.36 1362 4.74 1.70 0.36 1402
30 18 4.35 3.83 0.88 1048 4.16 3.66 0.88 1100 4.00 3.52 0.88 1153 3.85 3.39 0.88 1205
30 20 4.53 3.44 0.76 1100 4.35 3.30 0.76 1166 4.22 3.21 0.76 1192 4.07 3.09 0.76 1245
30 22 4.72 3.02 0.64 1140 4.55 2.91 0.64 1212 4.44 2.84 0.64 1245 4.26 2.72 0.64 1297
30 24 4.96 2.58 0.52 1192 4.77 2.48 0.52 1258 4.66 2.42 0.52 1297 4.51 2.35 0.52 1362
30 26 5.11 2.04 0.40 1258 4.96 1.98 0.40 1323 4.88 1.95 0.40 1362 4.74 1.89 0.40 1402
31 18 4.35 4.00 0.92 1048 4.16 3.83 0.92 1100 4.00 3.68 0.92 1153 3.85 3.54 0.92 1205
31 20 4.53 3.63 0.80 1100 4.35 3.48 0.80 1166 4.22 3.37 0.80 1192 4.07 3.26 0.80 1245
31 22 4.72 3.21 0.68 1140 4.55 3.09 0.68 1212 4.44 3.02 0.68 1245 4.26 2.89 0.68 1297
31 24 4.96 2.78 0.56 1192 4.77 2.67 0.56 1258 4.66 2.61 0.56 1297 4.51 2.53 0.56 1362
31 26 5.11 2.25 0.44 1258 4.96 2.18 0.44 1323 4.88 2.15 0.44 1362 4.74 2.08 0.44 1402
32 18 4.35 4.17 0.96 1048 4.16 4.00 0.96 1100 4.00 3.84 0.96 1153 3.85 3.69 0.96 1205
32 20 4.53 3.81 0.84 1100 4.35 3.65 0.84 1166 4.22 3.54 0.84 1192 4.07 3.42 0.84 1245
32 22 4.72 3.40 0.72 1140 4.55 3.28 0.72 1212 4.44 3.20 0.72 1245 4.26 3.06 0.72 1297
32 24 4.96 2.97 0.60 1192 4.77 2.86 0.60 1258 4.66 2.80 0.60 1297 4.51 2.71 0.60 1362
32 26 5.11 2.45 0.48 1258 4.96 2.38 0.48 1323 4.88 2.34 0.48 1362 4.74 2.27 0.48 1402

Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT

21 25 27 30

E3E3

OUTDOOR DB(:)

NOTE Q : Total capacity (kW) SHF : Sensible heat factor

SHC : Sensible heat capacity (kW) INPUT : Total power input (W)

11

OUTDOOR DB(:)

INDOOR INDOOR

35 40 43

DB(:) WB(:)

Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT
21 18 3.63 1.89 0.52 1284 3.33 1.73 0.52 1362 3.20 1.66 0.52 1389
21 20 3.81 1.52 0.40 1336 3.55 1.42 0.40 1402 3.42 1.37 0.40 1441
22 18 3.63 2.03 0.56 1284 3.33 1.86 0.56 1362 3.20 1.79 0.56 1389
22 20 3.81 1.68 0.44 1336 3.55 1.56 0.44 1402 3.42 1.51 0.44 1441
22 22 4.03 1.29 0.32 1389 3.77 1.21 0.32 1467 3.64 1.17 0.32 1493
23 18 3.63 2.18 0.60 1284 3.33 2.00 0.60 1362 3.20 1.92 0.60 1389
23 20 3.81 1.83 0.48 1336 3.55 1.70 0.48 1402 3.42 1.64 0.48 1441
23 22 4.03 1.45 0.36 1389 3.77 1.36 0.36 1467

3.64 1.31 0.36 1493
24 18 3.63 2.32 0.64 1284 3.33 2.13 0.64 1362 3.20 2.05 0.64 1389
24 20 3.81 1.98 0.52 1336 3.55 1.85 0.52 1402 3.42 1.78 0.52 1441
24 22 4.03 1.61 0.40 1389 3.77 1.51 0.40 1467 3.64 1.46 0.40 1493
24 24 4.26 1.19 0.28 1441 4.00 1.12 0.28 1507 3.89 1.09 0.28 1539
25 18 3.63 2.47 0.68 1284 3.33 2.26 0.68 1362 3.20 2.18 0.68 1389
25 20 3.81 2.13 0.56 1336 3.55 1.99 0.56 1402 3.42 1.92 0.56 1441
25 22 4.03 1.77 0.44 1389 3.77 1.66 0.44 1467 3.64 1.60 0.44 1493
25 24 4.26 1.36 0.32 1441 4.00 1.28 0.32 1507 3.89 1.24 0.32 1539
26 18 3.63 2.61 0.72 1284 3.33 2.40 0.72 1362 3.20 2.30 0.72 1389
26 20 3.81 2.29 0.60 1336 3.55 2.13 0.60 1402 3.42 2.05 0.60 1441
26 22 4.03 1.94 0.48 1389 3.77 1.81 0.48 1467 3.64 1.75 0.48 1493
26 24 4.26 1.53 0.36 1441 4.00 1.44 0.36 1507 3.89 1.40 0.36 1539
26 26 4.48 1.07 0.24 1493 4.22 1.01 0.24 1559 4.09 0.98 0.24 1592
27 18 3.63 2.76 0.76 1284 3.33 2.53 0.76 1362 3.20 2.43 0.76 1389
27 20 3.81 2.44 0.64 1336 3.55 2.27 0.64 1402 3.42 2.19 0.64 1441
27 22 4.03 2.10 0.52 1389 3.77 1.96 0.52 1467 3.64 1.90 0.52 1493
27 24 4.26 1.70 0.40 1441 4.00 1.60 0.40 1507 3.89 1.55 0.40 1539
27 26 4.48 1.25 0.28 1493 4.22 1.18 0.28 1559 4.09 1.14 0.28 1592
28 18 3.63 2.90 0.80 1284 3.33 2.66 0.80 1362 3.20 2.56 0.80 1389
28 20 3.81 2.59 0.68 1336 3.55 2.42 0.68 1402 3.42 2.33 0.68 1441
28 22 4.03 2.26 0.56 1389 3.77 2.11 0.56 1467 3.64 2.04 0.56 1493
28 24 4.26 1.87 0.44 1441 4.00 1.76 0.44 1507 3.89 1.71 0.44 1539
28 26 4.48 1.43 0.32 1493 4.22 1.35 0.32 1559 4.09 1.31 0.32 1592
29 18 3.63 3.05 0.84 1284 3.33 2.80 0.84 1362 3.20 2.69 0.84 1389
29 20 3.81 2.74 0.72 1336 3.55 2.56 0.72 1402 3.42 2.46 0.72 1441
29 22 4.03 2.42 0.60 1389 3.77 2.26 0.60 1467 3.64 2.19 0.60 1493
29 24 4.26 2.04 0.48 1441 4.00 1.92 0.48 1507 3.89 1.86 0.48 1539
29 26 4.48 1.61 0.36 1493 4.22 1.52 0.36 1559 4.09 1.47 0.36 1592
30 18 3.63 3.19 0.88 1284 3.33 2.93 0.88 1362 3.20 2.82 0.88 1389
30 20 3.81 2.90 0.76 1336 3.55 2.70 0.76 1402 3.42 2.60 0.76 1441
30 22 4.03 2.58 0.64 1389 3.77 2.42 0.64 1467 3.64 2.33 0.64 1493
30 24 4.26 2.21 0.52 1441 4.00 2.08 0.52 1507 3.89 2.02 0.52 1539
30 26 4.48 1.79 0.40 1493 4.22 1.69 0.40 1559 4.09 1.64 0.40 1592
31 18 3.63 3.34 0.92 1284 3.33 3.06 0.92 1362 3.20 2.94 0.92 1389
31 20 3.81 3.05 0.80 1336 3.55 2.84 0.80 1402 3.42 2.74 0.80 1441
31 22 4.03 2.74 0.68 1389 3.77 2.57 0.68 1467 3.64 2.48 0.68 1493
31 24 4.26 2.38 0.56 1441 4.00 2.24 0.56 1507 3.89 2.18 0.56 1539
31 26 4.48 1.97 0.44 1493 4.22 1.86 0.44 1559 4.09 1.80 0.44 1592
32 18 3.63 3.48 0.96 1284 3.33 3.20 0.96 1362 3.20 3.07 0.96 1389
32 20 3.81 3.20 0.84 1336 3.55 2.98 0.84 1402 3.42 2.87 0.84 1441
32 22 4.03 2.90 0.72 1389 3.77 2.72 0.72 1467 3.64 2.62 0.72 1493
32 24 4.26 2.55 0.60 1441 4.00 2.40 0.60 1507 3.89 2.33 0.60 1539
32 26 4.48 2.15 0.48 1493 4.22 2.02 0.48 1559 4.09 1.96 0.48 1592

CAPACITY: 3.7 kW INPUT : 1310 W SHF : 0.70

PERFORMANCE DATA
COOL operation(220V)

MCF-13NV - : MUCF-13NV -

NOTE Q : Total capacity (kW) SHF : Sensible heat factor

SHC : Sensible heat capacity (kW) INPUT : Total power input (W)

E3E3

12

OUTDOOR DB(:)

INDOOR INDOOR

21 25 27 30

DB(:) WB(:)

Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT
21 18 4.35 2.26 0.52 1104 4.16 2.16 0.52 1159 4.00 2.08 0.52 1214 3.85 2.00 0.52 1270
21 20 4.53 1.81 0.40 1159 4.35 1.74 0.40 1228 4.22 1.69 0.40 1256 4.07 1.63 0.40 1311
22 18 4.35 2.43 0.56 1104 4.16 2.33 0.56 1159 4.00 2.24 0.56 1214 3.85 2.15 0.56 1270
22 20 4.53 1.99 0.44 1159 4.35 1.91 0.44 1228 4.22 1.86 0.44 1256 4.07 1.79 0.44 1311
22 22 4.72 1.51 0.32 1201 4.55 1.46 0.32 1277 4.44 1.42 0.32 1311 4.26 1.36 0.32 1366
23 18 4.35 2.61 0.60 1104 4.16 2.50 0.60 1159 4.00 2.40 0.60 1214 3.85 2.31 0.60 1270
23 20 4.53 2.18 0.48 1159 4.35 2.09 0.48 1228 4.22 2.02 0.48 1256 4.07 1.95 0.48 1311
23 22 4.72 1.70 0.36 1201 4.55 1.64 0.36 1277 4.44 1.60 0.36 1311 4.26 1.53 0.36 1366
24 18 4.35 2.78 0.64 1104 4.16 2.66 0.64 1159 4.00 2.56 0.64 1214 3.85 2.46 0.64 1270
24 20 4.53 2.36 0.52 1159 4.35 2.26 0.52 1228 4.22 2.19 0.52 1256 4.07 2.12 0.52 1311
24 22 4.72 1.89 0.40 1201 4.55 1.82 0.40 1277 4.44 1.78 0.40 1311 4.26 1.70 0.40 1366
24 24 4.96 1.39 0.28 1256 4.77 1.34 0.28 1325 4.66 1.31 0.28 1366 4.51 1.26 0.28 1435
25 18 4.35 2.96 0.68 1104 4.16 2.83 0.68 1159 4.00 2.72 0.68 1214 3.85 2.62 0.68 1270
25 20 4.53 2.54 0.56 1159 4.35 2.43 0.56 1228 4.22 2.36 0.56 1256 4.07 2.28 0.56 1311
25 22 4.72 2.08 0.44 1201 4.55 2.00 0.44 1277 4.44 1.95 0.44 1311 4.26 1.87 0.44 1366
25 24 4.96 1.59 0.32 1256 4.77 1.53 0.32 1325 4.66 1.49 0.32 1366 4.51 1.44 0.32 1435
26 18 4.35 3.13 0.72 1104 4.16 3.00 0.72 1159 4.00 2.88 0.72 1214 3.85 2.77 0.72 1270
26 20 4.53 2.72 0.60 1159 4.35 2.61 0.60 1228 4.22 2.53 0.60 1256 4.07 2.44 0.60 1311
26 22 4.72 2.26 0.48 1201 4.55 2.18 0.48 1277 4.44 2.13 0.48 1311 4.26 2.04 0.48 1366
26 24 4.96 1.78 0.36 1256 4.77 1.72 0.36 1325 4.66 1.68 0.36 1366 4.51 1.63 0.36 1435
26 26 5.11 1.23 0.24 1325 4.96 1.19 0.24 1394 4.88 1.17 0.24 1435 4.74 1.14 0.24 1477
27 18 4.35 3.30 0.76 1104 4.16 3.16 0.76 1159 4.00 3.04 0.76 1214 3.85 2.92 0.76 1270
27 20 4.53 2.90 0.64 1159 4.35 2.78 0.64 1228 4.22 2.70 0.64 1256 4.07 2.60 0.64 1311
27 22 4.72 2.45 0.52 1201 4.55 2.37 0.52 1277 4.44 2.31 0.52 1311 4.26 2.21 0.52 1366
27 24 4.96 1.98 0.40 1256 4.77 1.91 0.40 1325 4.66 1.86 0.40 1366 4.51 1.81 0.40 1435
27 26 5.11 1.43 0.28 1325 4.96 1.39 0.28 1394 4.88 1.37 0.28 1435 4.74 1.33 0.28 1477
28 18 4.35 3.48 0.80 1104 4.16 3.33 0.80 1159 4.00 3.20 0.80 1214 3.85 3.08 0.80 1270
28 20 4.53 3.08 0.68 1159 4.35 2.96 0.68 1228 4.22 2.87 0.68 1256 4.07 2.77 0.68 1311
28 22 4.72 2.64 0.56 1201 4.55 2.55 0.56 1277 4.44 2.49 0.56 1311 4.26 2.38 0.56 1366
28 24 4.96 2.18 0.44 1256 4.77 2.10 0.44 1325 4.66 2.05 0.44 1366 4.51 1.99 0.44 1435
28 26 5.11 1.63 0.32 1325 4.96 1.59 0.32 1394 4.88 1.56 0.32 1435 4.74 1.52 0.32 1477
29 18 4.35 3.65 0.84 1104 4.16 3.50 0.84 1159 4.00 3.36 0.84 1214 3.85 3.23 0.84 1270
29 20 4.53 3.26 0.72 1159 4.35 3.13 0.72 1228 4.22 3.04 0.72 1256 4.07 2.93 0.72 1311
29 22 4.72 2.83 0.60 1201 4.55 2.73 0.60 1277 4.44 2.66 0.60 1311 4.26 2.55 0.60 1366
29 24 4.96 2.38 0.48 1256 4.77 2.29 0.48 1325 4.66 2.24 0.48 1366 4.51 2.17 0.48 1435
29 26 5.11 1.84 0.36 1325 4.96 1.78 0.36 1394 4.88 1.76 0.36 1435 4.74 1.70 0.36 1477
30 18 4.35 3.83 0.88 1104 4.16 3.66 0.88 1159 4.00 3.52 0.88 1214 3.85 3.39 0.88 1270
30 20 4.53 3.44 0.76 1159 4.35 3.30 0.76 1228 4.22 3.21 0.76 1256 4.07 3.09 0.76 1311
30 22 4.72 3.02 0.64 1201 4.55 2.91 0.64 1277 4.44 2.84 0.64 1311 4.26 2.72 0.64 1366
30 24 4.96 2.58 0.52 1256 4.77 2.48 0.52 1325 4.66 2.42 0.52 1366 4.51 2.35 0.52 1435
30 26 5.11 2.04 0.40 1325 4.96 1.98 0.40 1394 4.88 1.95 0.40 1435 4.74 1.89 0.40 1477
31 18 4.35 4.00 0.92 1104 4.16 3.83 0.92 1159 4.00 3.68 0.92 1214 3.85 3.54 0.92 1270
31 20 4.53 3.63 0.80 1159 4.35 3.48 0.80 1228 4.22 3.37 0.80 1256 4.07 3.26 0.80 1311
31 22 4.72 3.21 0.68 1201 4.55 3.09 0.68 1277 4.44 3.02 0.68 1311 4.26 2.89 0.68 1366
31 24 4.96 2.78 0.56 1256 4.77 2.67 0.56 1325 4.66 2.61 0.56 1366 4.51 2.53 0.56 1435
31 26 5.11 2.25 0.44 1325 4.96 2.18 0.44 1394 4.88 2.15 0.44 1435 4.74 2.08 0.44 1477
32 18 4.35 4.17 0.96 1104 4.16 4.00 0.96 1159 4.00 3.84 0.96 1214 3.85 3.69 0.96 1270
32 20 4.53 3.81 0.84 1159 4.35 3.65 0.84 1228 4.22 3.54 0.84 1256 4.07 3.42 0.84 1311
32 22 4.72 3.40 0.72 1201 4.55 3.28 0.72 1277 4.44 3.20 0.72 1311 4.26 3.06 0.72 1366
32 24 4.96 2.97 0.60 1256 4.77 2.86 0.60 1325 4.66 2.80 0.60 1366 4.51 2.71 0.60 1435
32 26 5.11 2.45 0.48 1325 4.96 2.38 0.48 1394 4.88 2.34 0.48 1435 4.74 2.27 0.48 1477

CAPACITY: 3.7 kW INPUT : 1380 W SHF : 0.70

PERFORMANCE DATA
COOL operation(240V)

MCF-13NV - : MUCF-13NV -

NOTE Q : Total capacity (kW) SHF : Sensible heat factor

SHC : Sensible heat capacity (kW) INPUT : Total power input (W)

E3E3

13

OUTDOOR DB(:)

INDOOR INDOOR

35 40 43

DB(:) WB(:)

Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT
21 18 3.63 1.89 0.52 1352 3.33 1.73 0.52 1435 3.20 1.66 0.52 1463
21 20 3.81 1.52 0.40 1408 3.55 1.42 0.40 1477 3.42 1.37 0.40 1518
22 18 3.63 2.03 0.56 1352 3.33 1.86 0.56 1435 3.20 1.79 0.56 1463
22 20 3.81 1.68 0.44 1408 3.55 1.56 0.44 1477 3.42 1.51 0.44 1518
22 22 4.03 1.29 0.32 1463 3.77 1.21 0.32 1546 3.64 1.17 0.32 1573
23 18 3.63 2.18 0.60 1352 3.33 2.00 0.60 1435 3.20 1.92 0.60 1463
23 20 3.81 1.83 0.48 1408 3.55 1.70 0.48 1477 3.42 1.64 0.48 1518
23 22 4.03 1.45 0.36 1463 3.77 1.36 0.36 1546

3.64 1.31 0.36 1573
24 18 3.63 2.32 0.64 1352 3.33 2.13 0.64 1435 3.20 2.05 0.64 1463
24 20 3.81 1.98 0.52 1408 3.55 1.85 0.52 1477 3.42 1.78 0.52 1518
24 22 4.03 1.61 0.40 1463 3.77 1.51 0.40 1546 3.64 1.46 0.40 1573
24 24 4.26 1.19 0.28 1518 4.00 1.12 0.28 1587 3.89 1.09 0.28 1622
25 18 3.63 2.47 0.68 1352 3.33 2.26 0.68 1435 3.20 2.18 0.68 1463
25 20 3.81 2.13 0.56 1408 3.55 1.99 0.56 1477 3.42 1.92 0.56 1518
25 22 4.03 1.77 0.44 1463 3.77 1.66 0.44 1546 3.64 1.60 0.44 1573
25 24 4.26 1.36 0.32 1518 4.00 1.28 0.32 1587 3.89 1.24 0.32 1622
26 18 3.63 2.61 0.72 1352 3.33 2.40 0.72 1435 3.20 2.30 0.72 1463
26 20 3.81 2.29 0.60 1408 3.55 2.13 0.60 1477 3.42 2.05 0.60 1518
26 22 4.03 1.94 0.48 1463 3.77 1.81 0.48 1546 3.64 1.75 0.48 1573
26 24 4.26 1.53 0.36 1518 4.00 1.44 0.36 1587 3.89 1.40 0.36 1622
26 26 4.48 1.07 0.24 1573 4.22 1.01 0.24 1642 4.09 0.98 0.24 1677
27 18 3.63 2.76 0.76 1352 3.33 2.53 0.76 1435 3.20 2.43 0.76 1463
27 20 3.81 2.44 0.64 1408 3.55 2.27 0.64 1477 3.42 2.19 0.64 1518
27 22 4.03 2.10 0.52 1463 3.77 1.96 0.52 1546 3.64 1.90 0.52 1573
27 24 4.26 1.70 0.40 1518 4.00 1.60 0.40 1587 3.89 1.55 0.40 1622
27 26 4.48 1.25 0.28 1573 4.22 1.18 0.28 1642 4.09 1.14 0.28 1677
28 18 3.63 2.90 0.80 1352 3.33 2.66 0.80 1435 3.20 2.56 0.80 1463
28 20 3.81 2.59 0.68 1408 3.55 2.42 0.68 1477 3.42 2.33 0.68 1518
28 22 4.03 2.26 0.56 1463 3.77 2.11 0.56 1546 3.64 2.04 0.56 1573
28 24 4.26 1.87 0.44 1518 4.00 1.76 0.44 1587 3.89 1.71 0.44 1622
28 26 4.48 1.43 0.32 1573 4.22 1.35 0.32 1642 4.09 1.31 0.32 1677
29 18 3.63 3.05 0.84 1352 3.33 2.80 0.84 1435 3.20 2.69 0.84 1463
29 20 3.81 2.74 0.72 1408 3.55 2.56 0.72 1477 3.42 2.46 0.72 1518
29 22 4.03 2.42 0.60 1463 3.77 2.26 0.60 1546 3.64 2.19 0.60 1573
29 24 4.26 2.04 0.48 1518 4.00 1.92 0.48 1587 3.89 1.86 0.48 1622
29 26 4.48 1.61 0.36 1573 4.22 1.52 0.36 1642 4.09 1.47 0.36 1677
30 18 3.63 3.19 0.88 1352 3.33 2.93 0.88 1435 3.20 2.82 0.88 1463
30 20 3.81 2.90 0.76 1408 3.55 2.70 0.76 1477 3.42 2.60 0.76 1518
30 22 4.03 2.58 0.64 1463 3.77 2.42 0.64 1546 3.64 2.33 0.64 1573
30 24 4.26 2.21 0.52 1518 4.00 2.08 0.52 1587 3.89 2.02 0.52 1622
30 26 4.48 1.79 0.40 1573 4.22 1.69 0.40 1642 4.09 1.64 0.40 1677
31 18 3.63 3.34 0.92 1352 3.33 3.06 0.92 1435 3.20 2.94 0.92 1463
31 20 3.81 3.05 0.80 1408 3.55 2.84 0.80 1477 3.42 2.74 0.80 1518
31 22 4.03 2.74 0.68 1463 3.77 2.57 0.68 1546 3.64 2.48 0.68 1573
31 24 4.26 2.38 0.56 1518 4.00 2.24 0.56 1587 3.89 2.18 0.56 1622
31 26 4.48 1.97 0.44 1573 4.22 1.86 0.44 1642 4.09 1.80 0.44 1677
32 18 3.63 3.48 0.96 1352 3.33 3.20 0.96 1435 3.20 3.07 0.96 1463
32 20 3.81 3.20 0.84 1408 3.55 2.98 0.84 1477 3.42 2.87 0.84 1518
32 22 4.03 2.90 0.72 1463 3.77 2.72 0.72 1546 3.64 2.62 0.72 1573
32 24 4.26 2.55 0.60 1518 4.00 2.40 0.60 1587 3.89 2.33 0.60 1622
32 26 4.48 2.15 0.48 1573 4.22 2.02 0.48 1642 4.09 1.96 0.48 1677

CAPACITY: 3.7 kW INPUT : 1380 W SHF : 0.70

PERFORMANCE DATA
COOL operation(240V)

MCF-13NV - : MUCF-13NV -

NOTE Q : Total capacity (kW) SHF : Sensible heat factor

SHC : Sensible heat capacity (kW) INPUT : Total power input (W)

E3E3

14

9

RESETRESET

CLOCKCLOCK

MICROPROCESSOR CONTROL

WIRELESS REMOTE CONTROLLER

INDOOR UNIT DISPLAY SECTION

OPERATION INDICATOR

The operation indicator at the right side of the indoor
unit indicates the operation state.

Operation Indicator

lamp

lighting

not lighting

MCF-13NV -

E3

Once the operation mode are set, the same operation mode
can be repeated by simply turning the
OPERATE/STOP(ON/OFF) button ON.
Indoor unit receives the signal with a beep tone.
When the system turns off, 3-minutes time delay will operate
to protect system from overload and compressor will not
restart for 3 minutes.

9-1. “I FEEL CONTROL”

( ) OPERATION

(1) Press OPERATE/STOP(ON/OFF) button on the remote

controller. OPERATION INDICATOR lamp of the indoor
unit turns on with a beep tone.

(2) Select “I FEEL CONTROL” ( )mode with the

OPERATION SELECT button.

(3) The operation mode is determined by the room

temperature at start-up of the operation.

Initial room temperature

25: or more

more than 13:,

less than 25:

Mode

COOL mode of

"I FEEL CONTROL"

DRY mode of

"I FEEL CONTROL"

● Once the mode is fixed, the mode does not change by
room temperature afterwards.

● Under the ON-TIMER ( )operation, mode is
determined according to the room temperature at set
time the operation starts.

● When the system is stopped with the
OPERATE/STOP(ON/OFF) button on the remote
controller, and restarted within 2 hours in “I FEEL
CONTROL” ( )mode, the system operates in previous
mode automatically regardless of the room temperature

Example

Previous operation

COOL mode of
“I FEEL CONTROL”

Restart

COOL mode of
“I FEEL CONTROL”

or COOL mode

.

Indication

Operation state

This shows that the air
conditioner is operating
to reach the target temp­erature.
Please wait until the
target temperature is
obtained.

This shows that the
room temperature is
approaching the target
temperature.

Difference
between set
temperatuer
and room
temperature

Approx. 2 : 
or more

Approx. 2 : 
or less

When the system is restarted after 2 hours and more, the
operation mode is determined by the room temperature at
start-up of the operation.

Example

Restart

COOL or DRY mode of

Previous operation

COOL mode of “I FEEL
CONTROL” or COOL
mode

“I FEEL CONTROL” that
is determined by room
temperature at start-up
of the operation.

15

(4) The initial set temperature is decided by the initial room temperature.

OFF

ON

Indoor fan

(continuously at set speed)

OFF

ONON

Compressor
Outdoor fan

1deg.

4deg.

2deg.

1.7deg.

Mode

Initial room temperature

Initial set temperature

COOL mode of

"I FEEL CONTROL"

DRY mode of

"I FEEL CONTROL"

26: or more

25: to 26:

more than 13:, less than 25:

Initial room temperature
minus 2:

Initial room temperature
minus 2:

24:

❈1 When the system is restarted with the remote controller, the system operates with the previous set temperature

regardless of the the room temperature at restart.
The set temperature is calculated by the previous set temperature.

(5) TEMPERATURE buttons

In “I FEEL CONTROL” ( ) mode, set temperature is decided by the microprocessor based on the room temperature.
In addition, set temperature can be controlled by TOO WARM or TOO COOL buttons when you feel too warm or too cool.
Each time the TOO WARM or TOO COOL button is pressed, the indoor unit receives the signal and emits a beep tone.

● Fuzzy control

When the TOO COOL or TOO WARM button is pressed, the microprocessor changes the set temperature, considering
the room temperature, the frequency of pressing TOO COOL or TOO WARM button and the user’s preference to heat or
cool. So this is called “Fuzzy control”, and works only in “I FEEL CONTROL” mode.
In DRY mode of “I FEEL CONTROL”, the set temperature doesn’t change.

▲TOO
COOL… To raise the set temperature 1~2 degrees(°C)

▼ TOO
WARM … To lower the set temperature 1~2 degrees(°C)

❈1

— COOL mode of “I FEEL CONTROL” —

1. Indoor fan speed control

Indoor fan operates at the set speed by FAN SPEED CONTROL button.
In Auto the fan speed is as follows.

Initial temperature difference Fan speed
Room temperature minus set temperature : 2 degrees or more·········································Hi
Room temperature minus set temperature : Between 1 and 2 degrees·····························Me
Room temperature minus set temperature : less than 1 degree·········································Lo

2. Coil frost prevention

① Temperature control

When the indoor coil thermistor RT12 reads -1°C or below, the coil frost prevention mode starts immediately.
However, the coil frost prevention doesn’t work after 5 minute since the compressor has started.
The indoor fan operates at the set speed and the compressor stops for 5 minutes.
After that, if RT12 still reads below -1°C, this mode prolonged until the RT12 reads over -1°C.

② Time control

When the three conditions as follows have been satisfied for 1 hour and 45 minutes, compressor stops for 3 minutes.
a. Compressor has been continuously operating.
b. Indoor fan speed is Lo or Me.
c. Room temperature is below 26°C.
When compressor stops, the accumulated time is cancelled and when compressor restarts, time counting starts from
the beginning.
Time counting also stops temporarily when the indoor fan speed becomes Hi or the room temperature exceeds 26°C.
However, when two of the above conditions (b. and c.) are satisfied again. Time accumulation is resumed.

Operation chart

Example

Difference between room
temperature and set
temperature during operation.

16

—DRY mode of “I FEEL CONTROL”—

ON

OFF

Thermostat

Indoor fan

Outdoor fan
Compressor

8 min.

1 min.

4 min.

3 min.

OFF

OFF

OFF

OFF

OFF

OFF

OFF

ON

ON

ON

ONONON

ON

35

30

25

20

15

10

:

10 15 20 25 30 35

Set temperature

Initial room temperature

Set temperature and
initial room temperature in DRY mode

:

The system for dry operation uses the same refrigerant circuit as the cooling circuit.
The compressor and the indoor fan are controlled by the temperature.
By such controls, indoor air flow amounts will be reduced in order to lower humidity without much room temperature

decrease.

1. Indoor fan speed control

Indoor fan operates at the set speed by FAN SPEED CONTROL button.
However, in AUTO fan operation, fan speed becomes Lo.

2. The operation of the compressor and indoor / outdoor fan

Compressor operates by temperature control and time control.
Set temperature is controlled to fall 2°C from initial room temperature.
Indoor fan and outdoor fan operate in the same cycle as the compressor.

• When the room temperature is 23°C or over:
When the thermostat is ON, the compressor repeats 8 minutes ON and 3 minutes OFF.
When the thermostat is OFF, the compressor repeats 4 minutes OFF and 1 minute ON.

• When the room temperature is under 23°C:
When the thermostat is ON, the compressor repeats 2 minutes ON and 3 minutes OFF.
When the thermostat is OFF, the compressor repeats 4 minutes OFF and 1 minute ON.

Operation time chart

Example

3. Coil frost prevention

• The operation is as same as coil frost prevention during COOL mode of “I FEEL CONTROL”.

• Indoor fan operates at the set speed and the compressor stops for 5minutes, because protection (Coil frost
prevention)has the priority. However, when coil frost prevention works while the compressor is not operating, it’s speed
becomes Lo.

9-2. COOL ( ) OPERATION

(1) Press OPERATE/STOP(ON/OFF) button.

OPERATION INDICATOR lamp of the indoor unit turns on with a
beep tone.

(2) Select COOL mode with the OPERATION SELECT button.
(3) Press the TEMPERATURE buttons.

(TOO WARM or TOO COOL button) to select the desired
temperature.
The setting range is 16 ~ 31°C
✻ Indoor fan continues to operate regardless of thermostat’s OFF-

ON at set speed.

✻ Coil frost prevention is as same as COOL mode of “I FEEL

CONTROL”.

9-3. DRY ( ) OPERATION

(1) Press OPERATE/STOP(ON/OFF) button.

OPERATION INDICATOR lamp of the indoor unit turns on with a
beep tone.

(2) Select DRY mode with the OPERATION SELECT button.
(3) The microprocessor reads the room temperature and determines the

set temperature. Set temperature is as shown on the right chart.
Thermostat (SET TEMP.) does not work.
The other operations are as same as DRY mode of “I FEEL CONTROL”.

(4) DRY operation will not function when the room temperature is 13°C or below.
(5) When DRY operation functions, the fan speed is lower than cool operation.

17

9-4. FAN ( ) OPERATION

1

2

3

4

5

AUTO

4

1

1

2

3

4

5

(1) Press OPERATE/STOP (ON/OFF) button.
(2) Select FAN mode with the OPERATION SELECT button.
(3) Select the desired fan speed. When AUTO, it becomes Lo.

Only indoor fan operates.
Outdoor unit does not operate.

9-5. AUTO VANE OPERATION

(1) Vane motor drive

This model is equipped with a stepping motor for the vane. The rotating direction, speed, and angle of the motor are
controlled by pulse signals (approx. 12V) transmitted from indoor microprocessor.

(2) Each time the VANE CONTROL ( ) button is pressed, angle of horizontal vane is changed in sequence, from 1, 2, 3,

4, 5 to AUTO.

(3) Positioning

The vane is once pressed to the vane stopper below to confirm the standard position and then set to the desired angle.
Confirming of standard position is performed in case of follows.
(a) When the OPERATE/STOP(ON/OFF) button is pressed.
(b) When the vane control is changed from AUTO to MANUAL.
(c) When the SWING is finished.
(d) When the test run starts.
(e) When the power supply turns ON.

(4) VANE AUTO mode

In VANE AUTO mode, the microprocessor automatically determines the vane angle and operation to make the optimum
room-temperature distribution.

1. In COOL and DRY operation

Vane angle is fixed to position 1.

2. In FAN operation

Vane angle is fixed to position 4.

(5) STOP (operation OFF) and ON-TIMER standby

When the following cases occur, the vane returns to the closed position.
(a) When the OPERATE/STOP (ON/OFF) button is pressed (POWER OFF).
(b) When the operation is stopped by the emergency operation.
(c) When the ON-TIMER is on standby.

(6) Dew prevention

During COOL or DRY operation at Position 4 or 5 when the compressor cumulative operation time exceeds 1 hour, the
angle of horizontal vane automatically changes to Position 1 for dew prevention.

(7) SWING MODE ( )

By pressing the SWING ( ) button, horizontal vane swings vertically between Position 1 and 5. The remote controller
displays “ ”.
If the VANE CONTROL( ) button or SWING ( ) button is pressed during SWING mode or the operation stops or

changes to other mode, SWING mode is released.

18

9-6. TIMER OPERATION

1. How to set the timer

(1) Press OPERATE/STOP(ON/OFF) button to start the air conditioner.
(2) Check that the current time is set correctly.

NOTE : Timer operation will not work without setting the current time. Initially “AM0:00” blinks at the current time display of

TIME MONITOR, so set the current time correctly with CLOCK SET button.

(3) Press ON-TIMER, OFF-TIMER button to select the operation.

“ ” button ... AUTO START operation (ON timer)
“ ” button ... AUTO STOP operation (OFF timer)

(4) Press HR. and MIN. button to set the timer. Time setting is 10-minute units.

HR. and MIN. button will work when “ ” or “ ” mark is flashing.
These marks disappear in 1 minute.
After setting the ON timer, check that OPERATION INDICATOR lamp of the indoor unit lights.

NOTE1 : Be sure to place the remote controller at the position where its signal can reach the air conditioner even during

TIMER operation, or the set time may deviate within the range of about 10 minutes.

NOTE2 : Reset the timer in the following cases, or the set time may deviate and other malfunctions may occur.

● A power failure occurs.

● The circuit breaker functions.

2. Cancel

TIMER setting can be cancelled with the TIMER CONTROL buttons. (“ ” or “ ”)
To cancel the ON timer, press the “ ” button.

To cancel the OFF timer, press the “ ” button.
TIMER is cancelled and the display of set time disappears.

PROGRAM TIMER

●The OFF timer and ON timer can be used in combination.

● “➝” and “ ” display show the order of the OFF timer and ON timer operation.

(Example 1) The current timer is 8:00 PM.

NOTE : TIMER setting will be cancelled by power failure or breaker functioning.

➝

The unit turns off at 11:00 PM, and on at 6:00 AM.

(Example 2) The current time is 11:00 AM.

The unit turns on at 5:00 PM, and off at 9:00 PM.

19

9-7. EMERGENCY-TEST OPERATION

When the remote controller is missing, has failed or the batteries run down, press the EMERGENCY OPERATION
switch on the front of the indoor unit. The unit will start and the OPERATION INDICATOR lamp will light.
The first 30 minutes of operation is the test run operation. This operation is for servicing. The indoor fan speed runs at
high notch and the system is in continuous operation. (The thermostat is ON)
After 30 minutes of test run operation the system shifts to EMERGENCY COOL MODE with a set temperature of 24˚C.
The fan shifts to Me notch.
This operation continues until the EMERGENCY OPERATION switch is pressed again or the unit receives any signal from
the remote controller. In case of latter normal operation will start.
The coil frost prevention works even in this operation.
In the test run or emergency operation, the horizontal vane operates in VANE AUTO mode.

NOTE : Do not press the EMERGENCY OPERATION switch during normal operation.

EMERGENCY
OPERATION switch

OPERATION INDICATOR lamp

Press once <Cool>
Press once again <Stop>

9-8. AUTO RESTART FUNCTION

When the indoor unit is controlled with the remote controller, the operation mode, set temperature, and the fan speed
are memorized by the the auto restart P.C. board.
The “AUTO RESTART” function sets to work the moment the power has restored after power failure. Then, the unit will
restart automatically. However if the unit is operated in “I FEEL CONTROL” mode, before power failure, the operation is
not memorized. In “I FEEL CONTROL” mode, the operation is decided by the initial room temperature.

NOTE :

•The operation settings are memorized when 10 seconds have passed after the remote controller was operated.

•If the main power is turned off or a power failure occurs while AUTO START/ STOP timer is active, the timer setting is
cancelled.

•If the unit has been off with the remote controller before power failure, the auto restart function does not work as the
power button of the remote controller is off.

•To prevent breaker off due to the rush of starting current, systematize other home appliances not to turn on at the
same time.

•When some air conditioners are connected to the same supply system, if they are operated before power failure, the
starting current of all the compressors may flow simultaneously at restart.
Therefore, the special counter-measures are required to prevent the main voltage-drop or the rush of the starting
current by adding to the system that allows the units to start one by one.

20

SERVICE FUNCTIONS10

MCF-13NV -

E3

10-1. TIMER SHORT MODE

For service, set time can be shortened by short circuit of JPG and JPS on the electronic control P.C. board.
The time will be shortened as follows.
3-minutes time delay : 3-minutes → 3-seconds.
AUTO START : 1 hour → 1-minute
AUTO STOP : 1 hour → 1-minute

Short the connector during the timer mode.

}

10-2. P.C. BOARD MODIFICATION FOR INDIVIDUAL OPERATION

A maximum of 4 indoor units with wireless remote controllers can be used in a room. In this case, to operate each
indoor unit individually by each remote controller, P.C. boards of remote controller must be modified according to the
number of the indoor unit.

How to modify the remote controller P.C. board

Remove batteries before modification.
The board has a print as shown below;

“J1” and “J2” Jumper wires

NOTE : Fore remodelling, take out the batteries at first.

After finish remodelling, put back the batteries then push the RESET button.

The P.C. board has the print “J1” and “J2”. Jumper wires are mounted to each “J1” and “J2”. Cut J1 and J2
according to the number of indoor unit as shown in Table 1.
After modification, push the RESET button.

Table1.

No.1 unit
No.2 unit
No.3 unit

1 unit operation
No modification

2 units operation

Same as at left

Cut J1

3 units operation

Same as at left
Same as at left

Cut J2

No.4 unit

NOTE : At power supply failure or installation, indoor unit deletes the memory about remote controller. When

the power supply is turned on and indoor unit receives the first signals from the remote controller, the remote
controller number is designated as the indoor unit number. Therefore at and after the second time indoor unit
accepts the remote controller of the initial setting number.
At setting-error, turn the power supply off to cancel the individual operation, and then turn the power supply on
to restart the setting.

10-3. RELEASE OF AUTO RESTART FUNCTION

The jumper line is soldered with “JHA (refer to page 27)” on the indoor electronic control P.C. board.
Remove the auto restart P.C. board from “Connector CN104”.

4 units operation

Same as at left
Same as at left
Same as at left

Cut both J1 and J2

21

11

RESET button

TROUBLESHOOTING

MCF-13NV -

E3

11-1. Cautions on troubleshooting

1. Before troubleshooting, check the following:

1) Check the power supply voltage.

2) Check the indoor/outdoor connecting wire for mis-wiring.

2. Take care the following during servicing.

1) Before servicing the air conditioner, be sure to first turn off the remote controller to stop the main unit, and then after
confirming the horizontal vane is closed, turn off the breaker.

2) When removing the electronic control P.C. board, hold the edge of the board with care NOT to apply stress on the
components.

3) When connecting or disconnecting the connectors, hold the housing of the connector. DO NOT pull the lead wires.

3 Troubleshooting procedure

1) First, check if the OPERATION INDICATOR lamp on the indoor unit is flashing on and off to indicate an abnormality.
To make sure, check how many times the abnormality indication is flashing on and off before starting service work.

2) If the electronic control P.C. board is supposed to be defective, check the copper foil pattern for disconnection and the
components for bursting and discoloration.

3) When troubleshooting, refer to the flow chart and the check table on page 23.

4 How to replace batteries

Weak batteries may cause the remote controller malfunction.
In this case, the remote controller can not be repaired only by the battery replacement. To operate the remote controller
normally, replace the batteries in the following order.
This remote controller has the RESET button. After refilling new batteries, press the RESET button with tip end of ball
point pen or the like, and then use the remote controller.

22

11-2. Instruction of troubleshooting

OPERATION
INDICATOR
lamp

Start

Indoor unit operates.
Outdoor unit doesn’t
operate.

Outdoor unit
operates in
only Test
Run
operation.

Check
room
temperatur
e
thermistor.

Outdoor unit
doesn’t
operate
even in Test
Run
operation.

Refer to
“Check of
outdoor
unit” on
page 26.

Indoor unit
doesn’t receive
the signal from
remote
controller.

Refer to

B

“Check of
receiver P.C.
board” on page

25.

When the remote
controller is pressed
or when the
EMERGENCY
OPERATION switch
is pressed, the fan
doesn’t rotate, with
OPERATION
INDICATOR lamp

Refer to “Check

A

of indoor fan
motor” on page

OPERATION
INDICATOR lamp on
the indoor unit is
flashing on and off.

2-time flash

2.5-second OFF

Indoor unit doesn’t
receive the signal from
remote controller.
Also, OPERATION
INDICATOR lamp
doesn’t flash, when the
EMERGENCY
OPERATION switch is
pressed.

Refer to “Check of

C

indoor electronic control
P.C. board” on page 26.

25.

D

Cause:Indoor unit
2-time-Room temperature/Indoor coil thermistor

trouble

Check indoor coil
thermistor. Refer to
“Test point diagram
and voltage” on page

27.

Check room
temperature thermistor.
Refer to “Test point
diagram and voltage”
on page 27.

1. troubleshooting check table

❈ Before taking measures, make sure that the symptom reappears, for accurate troubleshooting.
Self check table

Abnormal

NO.

point

Indoor coil
thermistor

1

Room
temperatur
e
thermistor

2-time flash

2.5-second OFF

Indication

Symptom

Outdoor unit
does not run.

Detect method

Detect Indoor coil/room
temperature thermistor short
or open circuit every 8
seconds during operation.

23

● Check resistance of thermistor.

● Reconnect connector.

● Check indoor electronic control P.C.

board.

Check point

C

S

R

BLK

RED

WHT

P

BLK RED ORNYLWBLU BRN

WHT

GRN

YLW

P

BLK

RED

WHT

MAIN
AUX

P

BRN

YLW

PNK
RED
ORN

BLU

ROTOR

MCF-13NV -

E3

2. Trouble criterion of main parts

Part name

Room
temperature
thermistor

Measure the resistance with a tester.
(Part temperature 10°C ~ 30°C)

Indoor coil
thermistor

Measure the resistance between the terminals with a tester.
(Coil wiring temperature -10°C ~ 40°C)

Check method and criterion

Normal

8kΩ ~ 20kΩ

Figure

Abnormal

Opened or short-circuited

Compressor

Indoor fan
motor

Abnormal

Opened or

short-circuited

C-R
C-S

Normal

1.86~2.28Ω

3.5~4.29Ω

Measure the resistance between the terminals with a tester.
(Coil wiring temperature10°C ~ 30°C)

WHT-BLK

Normal

195~212Ω

Abnormal

BLK-YLW 44.1~47.8Ω
YLW-BLU 31.4~34.1Ω

Opened or

short-circuited

BLU-BRN 42.6~46.1Ω

BRN-RED 22.3~24.2Ω

Measure the resistance between the terminals with a tester.
(Coil wiring temperature -10°C ~ 40°C)

Outdoor fan
motor

Vane
motor

WHT-BLK

BLK-RED

Normal

155 ~ 191Ω
363 ~ 445Ω

Abnormal

Opened or

short-circuited

Measure the resistance between the terminals with a tester.
(Part temperature10°C ~ 30°C)

Normal Abnormal

Resistant per phase

329

~357

Ω

Opened or

short-circuited

24

: INNER THERMOSTAT

P

A

● Re-install the unit away from lights.

● Attach a filter on receiving part.

Switch on the remote controller.

Is LCD display on the remote
controller visible?

Replace the batteries.(see page 22.)

Remove the batteries and then set them back.
Check if the unit operates with the remote controller.

Does the unit operate with remote controller?

Turn on a radio to AM and press
switch on remote controller.

Is noise heard from radio?

Replace the remote controller.

Are there any fluorescent lights
of inverter or rapid-start type
within the range of 1m?

Turn ON the power supply.
Measure the voltage between receiver P.C. board connector No.2(+) and No.1 when the remote controller button is pressed.

Is the voltage approx. 4V DC?

No
(5V DC or 0V DC)

Replace the receiver P.C. board.

No
(not clear)

Yes

Yes

No

OK

No

Yes

Yes

Yes

No

Replace the indoor electronic control P.C. board.

Replace the auto restart P.C. board.

Yes

Disconnect AUTO RESTART P.C. board from CN104
and short CN104 1 to 5.

Does the unit receive the signal
from the remote controller?

No

Check of indoor fan motor

Indoor fan does not operate.

No

Reconnect the lead wires.

Check of remote controller and receiver P.C. board

B

Are lead wires connected?

Disconnect lead wires from connector (Fan motor) on indoor electronic control P.C. board.
Measure resistance between lead wires No.1 and No.4 and then No.3 and No.4 of the fan motor.

Turn OFF the power supply.
Check connector (Fan motor) visually.

Yes

Is resistance 0 (short circuit) or ∞ (open circuit)?

Yes ( 0 or ∞ )

Repair the indoor fan motor.

Is soldered point normal?

Yes

Replace the indoor electronic control
P.C. board.

No

(others)

No

Resolder it.

Indoor unit operates by pressing the EMERGENCY OPERATION switch, but does not operate with the remote
controller.

WCheck if the remote controller is exclusive for this air conditioner.

25

Check of indoor electronic control P.C. board

C

The unit doesn’t operate with the remote controller.
Also, the OPERATION INDICATOR lamp doesn’t light up by pressing the EMERGENCY OPERATION switch.

Replace the fuse.

Is fuse(F11)blown?

Check both “parts side”and “pattern

side” of indoor electronic control P.C.
board visually.

Check of outdoor unit

D

Be sure to check both fuse
and varistor in any case.

Is varistor(NR11)burnt?

Replace the varistor.

Compressor and / or outdoor fan does not operate.

Yes

No

Replace the indoor electronic
control P.C. board.

No

Yes

Start

Yes

Check the outdoor unit fan

motor and the compressor.

Yes

Check the continuity of indoor

and outdoor unit connection.

Press the EMERGENCY
OPERATION switch. 3-minute time
delay works. Test run operation
operates for 30 minutes.

Check voltage to terminal
block of outdoor unit. Is there
220-240V AC to terminal
block between 2 - N ?

No

Check voltage to the
terminal block of indoor unit.
Is there 220-240V AC to
terminal block between 2 -

No

Replace the indoor

electronic control P.C.

board.

26

TEST POINT DIAGRAM AND VOLTAGE
MCF-13NV -

Indoor electronic control P.C. board

75643218

E3

Fan motor power supply

Lo Hi

Fan motor voltage
220-240V AC

Fuse 250V AC 3.15A

Power supply
input 220-240V AC

EMERGENCY OPERATION switch

GILMS

RT11

TH113

DE00R697B

Room temperature
thermistor(RT11)

12

CH313

Indoor coil thermistor (RT12)
Room temperature thermistor (RT11)

To the indoor
electronic control
P.C.board CN113

+

12V DC

–

}

+

5V DC

–

}

CN104

JHA(Release of AUTO RESTART
FUNCTION.Refer to page 21.)

Time short point

Indoor coil thermistor (RT12)

40

30

20

Resistance (K')

10

0

0

10 20 30 40 50 60

Temperature ( C)

27

12

DISASSEMBLY INSTRUCTIONS

<"Terminal with lock mechanism" Detaching points>

In case of terminal with lock mechanism, detach the terminal as shown below.
There are two types ( Refer to (1) and (2)) of the terminal with lock mechanism.
The terminal with no lock mechanism can be removed by pulling it out.
Check the shape of the terminal and work.

(1) Slide the sleeve and check if there is a locking lever or not.

Sleeve

1Slide the sleeve.
2Pull the terminal while

Locking lever

12-1. MCF-13NV-

E3

pushing the locking
lever.

INDOOR UNIT

OPERATING PROCEDURE PHOTOS

1. Removing the electronic control P. C . board.

(1) Pull out the upper part of the grill. ( photo 1. )
(2) Remove the screws of the grill.
(3) Remove screws of terminal block cover.

Remove the terminal block cover and remove the terminal

block.
(4) Remove the screws of the electronic box cover.
(5) Pull out the electronic control P.C. board.

Photo 3

(2) The terminal with this connector is a terminal

with lock mechanism

1Hold the sleeve, and
pull out the terminal
slowly.

Connector

Photo 1

2. Removing the indoor fan motor

(1) Remove the grill. ( Refer to 1. (1) (2) )
(2) Remove the screws of the pipe support assembly.
(3) Remove the fan casings.(upper)
(4) Disconnect the connector of the indoor fan motor.
(5) Disconnect the ground wire of the fan motor.
(6) Remove the screws of the motor band and remove the

catch.

(7) Take out the sirocco fan and the indoor fan motor.

Photo 2

Photo 4

Fan casing

(upper)

Screws of the grill

Electronic box

Terminal box

Motor band

28

Indoor fan motor

Screws of
the motor band

Fan
casing(upper)

OPERATING PROCEDURE PHOTOS

3. Removing the indoor heat exchanger.

(1) Remove the grill. (Refer to 1. (1) (2))
(2) Remove the screws on both side and in front of the front

panel. (Photo 5)
(3) Remove the screws of the nozzle assembly. (Photo 6)
(4) Remove the electronic box. (Refer to 1)
(5) Remove the indoor fan motor. (Refer to 2)
(6) Remove the screws of the motor support.
(7) Remove the fan casing. (Iower)
(8) Remove the installations of the drain pan and remove the

screws. (Photo 7)
(9) Remove the screws under the drain pan. (Photo 8)

)

(

Remove the drain pan.

10

(11)

Remove the indoor heat exchanger.

Photo 5

Screws of
the front
panel

Photo 6

Screws of
the nozzle
assembly

Photo 7

Photo 8

Installations and screws

29

screws under
the drain pan

12-2. MUCF-13NV-

OUTDOOR UNIT

OPERATING PROCEDURE PHOTOS

E3

1. Removing the cabinet

(1) Remove the screws of the top panel.
(2) Remove the screws of the service panel.
(3) Remove the screws of the cabinet.
(4) Remove the screws of the front panel and motor support.
(5) Remove the service panel, and remove the screw from

the insides.
(6) Remove the top panel.
(7) Remove the cabinet.

Photo 3

Screws of the
service panel

Screws of the
top panel

Service
panel

Photo 1

Screws
of the
cabinet

Photo 2

Screws of the front panel
and motor support

Screws of the cabinet

Screws of
the top panel

2. Removing the electrical parts

(1) Remove the service panel and the cabinet.(Refer to 1)
(2) Remove the following parts.

•Compressor capacitor (C1)

•Outdoor fan capacitor (C2)

•Terminal block

Screws of
the cabinet

Photo 4

Outdoor fan capacitor

30

Compressor capacitor

Terminal block

OPERATING PROCEDURE PHOTOS

3. Removing the propeller fan and the outdoor fan
motor

(1) Remove the cabinet. (Refer to 1.)
(2) Remove the propeller fan nut.
(3) Remove the propeller fan.

NOTE : Loose the propeller fan in the rotating direction for

removal.

When attaching the propeller fan, align the mark on the
propeller fan and the motor shaft cut section.
Set the propeller fan in position by using the cut on the

shaft and the mark on the propeller fan.
(4) Remove lead clamps and fan motor lead wires.
(5) Remove screws fixing the fan motor.
(6) Remove the outdoor fan motor.

Photo 5

Set screws of
outdoor fan motor

Propeller fan

Hook

Lead clamps

4. Removing the compressor

(1) Remove the cabinet. (Refer to 1)
(2) Remove the relay panel.
(3) Remove the soundproof felt.
(4) Remove the terminal cover on the compressor.
(5) Disconnect lead wires from the glass terminal of the

compressor.
(6) Release gas from the refrigerant circuit.
(7) Disconnect the welded part of the discharge pipe.
(8) Disconnect the welded part of the suction pipe.
(9) Remove nuts fixing the compressor.

)

(

Remove the compressor.

10

NOTE

● Before using a burner, purge gas from the pipes until the
pressure gauge shows 0 kg/cm

● Use the burner under the condition that gas can be released
even when the inner pressure rises by heat.

2

.

Propeller fan nut

Photo 6

Glass
terminal

Compressor

fan motor

Discharge pipe

Outdoor

Suction pipe

31

Compressor
set nuts

Terminal cover

PARTS LIST13

No. Part No.

Part name Remark

Q'ty/unit

1
2
3
4
5
6
7
8

9
10
11
12
13
14

15

16

E02 179 000
E02 179 010
E02 227 040
E02 179 100
E02 179 231
E02 227 235
E02 179 237
E02 179 238
E02 179 620
E02 215 700
E02 179 667
E02 138 667
E02 179 971
E02 179 972
E02 179 142
E02 227 303

FRONT PANEL(WH)
GRILLE(WH)
VANE(WH)
AIR FILTER
BACK PANEL(IN)
NOZZLE(WH)
FAN CASING(U)
FAN CASING(L)
INDOOR HEAT EXCHANGER
DRAIN PAN
UNION(GAS)
UNION(LIQUID)
INSTALLATION METAL(L)
INSTALLATION METAL(R)
GRILLE CATCH(WH)
VANE MOTOR




















{12.7
{6.35

3PCS/SET

1
1
1
2
1
1
2
2
1
1
1
1
1
1
3
1

Symbol

in Wiring

Diagram

MCF-

13NV- E3 (WH)

VM

1718E02 227 426

E02 141 083

REMOTE CONTROLLER
REMOTE CONTROLLER HOLDER

1
1

MCF-13NV - (WH)

E3

13-1. INDOOR UNIT

STRUCTURAL PARTS

16

13

1

4

2

13-2. ACCESSORY P ART AND

REMOTE CONTROLLER

3

9 5

6

UNION(LIQUID)

12

14

1817

10

UNION(GAS)

13-1. INDOOR UNIT STRUCTURAL PARTS

Part number that is circled is not shown in the illustration.

13-2. ACCESSORY P ART AND REMOTE CONTROLLER

32

8711

No. Part No.

Part name

Remark

Symbol

in Wiring

Diagram

Q'ty/unit

1

2

3

4

5

6

7

8

9

10

11

E02 227 300
E02 179 500
E02 179 505
E02 227 375
E02 228 375

E02 215 328

E02 324 450
E02 127 382
E02 227 468
E02 324 307
E02 336 385
E02 324 452

INDOOR FAN MOTOR
SIROCCO FAN
FAN MOTOR RUBBER MOUNT
TERMINAL BLOCK
TERMINAL BLOCK

SWITCH &
ROOM TEMPERATURE P.C. BOARD

ELECTRONIC CONTROL P.C. BOARD
FUSE
RECEIVER P.C. BOARD
INDOOR-COIL THERMISTOR
VARISTOR
AUTO RESTART P.C. BOARD

RA4V19-

2PCS/SET
FigureA
FigureB

3.15A

1
2
2
1
1

1

1
1
1
1
1
1

MF

TB
TB

F11

RT12
NR11

MCF-

13NV- E3 (WH)

13-3. INDOOR UNIT

FUNCTIONAL PARTS AND ELECTRICAL PARTS

MCF-13NV - (WH)

6

5

11

E3

9

8

4

2

1

3

Part number that are circled are not shown in the illustration.

33

No. Part No.

Part name

Remark

Q'ty/unit

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17

18

19

E02 336 232
E02 336 521

E02 336 245
E02 336 630
E02 336 515
E02 141 900
E02 340 290
E02 438 301
E02 336 501
E02 079 353
E02 095 350
E02 197 374
E02 414 936
E02 075 506
E02 139 662
E02 340 661
E02 339 233
E02 336 297
E02 095 382

CABINET
GRILLE(OUT)
SERVICE PANEL
OUTDOOR HEAT EXCHANGER
MOTOR SUPPORT
COMPRESSOR
BASE
OUTDOOR FAN MOTOR
PROPELLER FAN
COMPRESSOR CAPACITOR
OUTDOOR FAN CAPACITOR
TERMINAL BLOCK(OUT)
CAPILLARY TUBE
COMPRESSOR RUBBER SET
STOP VALVE(LIQUID)
STOP VALVE(GAS)
BACK PANEL(OUT)
TOP PANEL
FUSE

RH-231VHAT

RA6V33-

30+/440VAC

1.5+/440VAC

{3.0X{1.6X300
3RUBBERS/SET

{6.35
{12.7

250V2A

1
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1

MC

MF

C1
C2
TB

F

Symbol

in Wiring

Diagram

MUCF-

13NV- E3

13-4. OUTDOOR UNIT

STRUCTURAL PARTS,
ELECTRICAL PARTS AND
FUNCTIONAL PARTS

MUCF-13NV-

5

4

1

2

E3

9

8 12

1118

10

3

Part number that are circled are not shown in the illustration.

6

14

34

7

16

15

17

OPTIONAL PARTS14

Remove the air
filter and the
deodorizing
filter together.

Separate the deodorizing
filter (gray sponge type)
from the air filter.

Remove the air
filter and the
air cleaning filter
together.

Separate the air
cleaning filter
(white bellow type)
from the air filter.

Model

Part No.

MAC-1200FT

MCF-13NV-

E3

MAC-1700DF

Model

Part No.

MCF-13NV-

E3

14-1. AIR CLEANING FILTER

● If the air cleaning filter is clogged, it may reduce the air conditioner capacity or cause condensation at the air outlet.

● The air cleaning filter is disposable. The standard usable term is about 4 months. However, if the color of the filter

turns to dark brown, replace soon.

14-2. DEODORIZING FILTER

● Clean the filter every two weeks. When it becomes too dirt, clean it more often.

● Replace the filter with a new one when its color can not be restored even after washing or when the filter becomes

dark.

● Standard interval for the filter replacement is about 1 year.

35

HEAD OFFICE MITSUBISHI DENKI BLDG.MARUNOUCHI TOKYO100-8310 TELEX J24532 CABLE MELCO TOKYO

CC

Copyright 1999 MITSUBISHI ELECTRIC ENGINEERING CO., LTD.
Issued in Jun. 1999. No.OB239 268
Printed in Japan

New publication, effective Jun. 1999.
Specifications subject to change without notice.
