ORDER No.5037
AUTOMOTIVE ELECTRONICS
MITSUBISHI
CQ-JB3160A
CQ-JB0160A
AM/FM MPX ELECTRONIC TUNING
RADIO with CD Player
MITSUBISHI PART No. :
CQ-JB3160A : MR587268
CQ-JB0160A : MR587386
ID CODE :
CQ-JB3160A : P001
CQ-JB0160A : P002
VEHICLE :
CQ-JB3160A : LANCER / DIAMANTE
CQ-JB0160A : PAJERO
DESTINATION : North America
PRODUCED AFTER : Apr., 2001
I0
Specification*
General
Power Supply DC 12V (11V - 16V),
Test Voltage 13.2V,
Negative Ground
Current Consumption Less than 3.0A at 0.5W
Maximum Power Output 35W×4ch (at 4Ω)
Output Impedance 4Ω
AM Radio
Frequency Range 530 - 1,710kHz
Usable Sensitivity 24dB/µV (S/N 20dB)
FM Stereo Radio
Frequency Range 87.7 - 107.9MHz
Usable Sensitivity 7dB/µV (S/N 30dB)
CD Player
Signal to Noise Ratio More than 66dB
Total Harmonic Distortion Less than 0.4%
Channel Separation More than 55dB
Dimension** (W×H×D) 178 × 169 × 150mm
Weight** 1.5kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
CONTENTS
Page Page
1 FEATUERS 2
2 LASER PRODUCTS
3 REAR VIEW AND CONNECTORS
4 FRONT VIEW AND FUNCTIONS
5 WIRING CONNECTION
6 BLOCK DIAGRAM
7 TERMINALS DESCRIPTION
8 PACKAGE AND IC BLOCK DIAGRAM
9 REPLACEMENT PARTS LIST 12
2
10 EXPLODED VIEW (Unit)
11 CD PLAYER PARTS
2
3
12 EXPLODED VIEW (CD Deck)
4
13 WIRING DIAGRAM
14 SCHEMAT IC DIAGRAM (1)
5
7
15 SCHEMAT IC DIAGRAM (2)
9
19
20
21
22
28
29
1 FEATUERS
∙ PLL (Phase Locked Loop) synthesized tuning.
∙ 18-station preset (12-FM, 6-AM)
∙ FM One-tuner diversity.
∙ Electronic control of power and sound.
∙ 4ch × 3 points Fix-Equalizer.
∙ CD random, repeat function.
∙ CD-CH, MD-CH control.
2 LASER PRODUCTS
3 REAR VIEW AND CONNECTORS
2
4 FRONT VIEW AND FUNCTIONS
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
3
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
5 WIRING CONNECTION
4
6 BLOCK DIAGRAM
6.1. Main/Display/Amp Block
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
5
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
6.2. CD Servo Block
6
7 TERMINALS DESCRIPTION
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
7.1. Main Block
IC601 : C2BBGF000256
Pin
No.
1 SUBVOLCLK (Ground pull-down) - 0
2 DIV SW Diversity switch I 5.1
3 SET S2 System function setting O 0
4 AVSS Ground - 0
5 SET S0 System function setting O 0
6 SET S1 System function setting O 0
7 AVREF +5V power supply - 5.1
8 SET R0 System function setting I 0
9 SET R1 System function setting I 0
10 SET R2 System function setting I 0
11 CD DI CD data output O 2.4
12 CD DO CD data input I 1.4
13 CD CLK Shift clock for CD data O 4.9
14 PLL DI PLL data input I 5.0
15 MBUSY OUT M-BUS busy O 0
16 MBUSY IN M-BUS busy I 0
17 MDATA M-BUS data I/O 4.9
18 MCLK M-BUS clock O 4.9
19 PLLDO PLL data output O 0
20 PLLSTB PLL strobe O 0
21 PLLCLK PLL clock O 0
22 MUTE A Mute signal O 0
23 VOL STB Electric volume strobe O 0
24 VOL CLK Electric volume clock O 0
25 VOL DATA Electric volume data O 0
26 AMP CONT Power amp. stand-by O 4.9
27 CD PON CD power control O 4.9
28 CD ON CD control LSI enable O 4.9
29 SW1 CD disc-in SW I 0
30 SW3 CD disc-out SW I 4.8
31 TUNEA Tuner switch signal I 4.7
32 TUNEB Tuner switch signal I 0.5
33 GND Ground - 0
34 VOLINA Volume switch signal I 0
35 VOLINB Volume switch signal I 0
36 CD RESET CD controller reset O 0
37 MAIN Main antenna selection O 4.9
38 SUB Sub. antenna selection O 8.3
39 BIBIRI CNT Rattle noise check control O 5.0
40 SECDI Security data input I 0
41 SECDO Security data output O 0
42 SECCLK Security data read / write
43 SECCS Security ROM select O 0
44 FreqOUT Tone/Burst frequency O 0
45 TONE/TRG Tone/Triger control O 0
46 S.PULSE Speed pulse input I 0
47 Ga INPUT GALA signal input I 5.0
48 ST FM stereo detection I 0.3
49 LCD CONT LCD back ligth on/off O 4.8
50 BUZZER Buzzer output O 0
51 NC No connection - 52 KS0 Key strobe O 0
53 KS1 Key strobe O 0
54 KS2 Key strobe O 0
55 KS3 Not used - 56 KR0 Key data I 0
57 KR1 Key data I 1.6
58 KR2 (Groung pull-down) - 0
59 KR3 (Groung pull-down) - 0
60 RESET Reset input I 4.8
61 M-DATA IN M-BUS data I 4.9
62 CD EJECT CD eject SW I 4.8
63 BATTDET Battery level detection I 5.0
64 ACCDET ACC level detection I 0
65 MUTE_P Power amp. mute O 0
66 ANT Motor antenna power on/off O 0
Port Descriptions I/O Vol.
clock
O 0
(V)
Pin
No.
67 GND Ground - 0
68 VDD +5V power supply - 4.9
69 X2 Crystal oscillator - 0
70 X1 Crystal oscillator - 2.6
71 GND Ground - 0
72 XT2 Crystal oscillator - 2.7
73 XT1 Crystal oscillator - 2.5
74 AVDD +5V power supply - 4.9
75 AV REF0 +5V power supply - 5.0
76 VAM/FM AM/FM vcont I 0
77 REMOTE_A (+5V pull-up) - 5.0
78 BIBIRI.A (Ground pull-down) - 0
79 CLIPCONT Not used - 80 REMOTE_D (Ground pull-down) - 0
Port Descriptions I/O Vol.
(V)
Note 1 : Voltage measuerments are with respect to ground,
with a voltmeter (internal resistance : 10M ohms).
7.2. Display Block
IC901 : YEAMSM6786
Pin
No.
1- 6 SEG1 - 6 LCD segment data O 2.3
7 SEG7 No connection - -
8-20 SEG8-20 LCD segment data O 2.3
21 VDD +5V power supply - 5.0
22-29 SEG21 - 28 LCD segment data O 2.3
30 - No connection - 31-34 KR0 - 3 Key data input I 4.4
35,36 - No connection - 37-40 KS1 - 4 Key scanning O 3.5
41 KS5 Not used - -
42 LOAD LCD LSI chip enable I 0
43 CLK LCD clock I 0
44 DATA I/O LCD/Key dat I/O 0
45 INT LCD interrupt O 3.8
46 /RESET Reset I 4.0
47 LED Not used - -
48 3/4 SEL (Connecting to ground) - 0
49 VDD +5V power supply - 5.0
50 OSC CR oscillator - 2.2
51 VSS Ground - 0
52 TEST (Connecting to ground) - 0
53-56 COM4 - 1 LCD common O 2.3
Port Descriptions I/O Vol.
(V)
7
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
7.3. CD Servo Block
IC201 : MN662748RPMF
Pin
No.
1 BCLK Not used - 2 LRCK Not used - 3 SRDATA Not used - 4 DVDD +5V digital power supply - 5.0
5 DVSS1 Digital ground - 0
6 TX Not used - 7 MCLK MPU command clock I 0
8 MDATA MPU command data I 0
9 MLD MPU command load I 0
10 SENSE Sense signal O 0
11 /FLOCK Focus servo lock O 0
12 /TLOCK Tracking servo lock O 4.9
13 BLKCK Not used - 14 SQCK Q code external clock I 4.9
15 SUBQ Q code output O 2.5
16 DMUTE DSP mute I 0
17 STAT DSP Status output O 3.1
18 /RST Reset input I 4.9
19,20 Not used - -
21 TRV Forced traverse output O 2.5
22 TVD Traverse drive output O 2.5
23 PC Spindle motor control O 0
24 ECM Spindle motor drive O 2.5
25 ECS Spindle motor drive O 2.5
26 KICK Kick pulse output O 2.5
27 TRD Tracking motor drive O 2.5
28 FOD Focus motor drive O 2.5
29 VREF D/A reference voltage I 2.5
30 FBAL Focus balance adjust O 2.5
31 TBAL Tracking balance adjust O 2.5
32 FE Focus error signal I 2.5
33 TE Tracking error signal I 2.5
34 RFENV RF envelope signal I 2.5
35 VDET Vibration detection I 0
36 OFTR Off track signal I 0
37 TRCRS Track closs signal I 2.1
38 /RFDET RF detection signal I 0
39 BDO Drop out signal I 0
40 LDON Laser on/off control O 4.5
41 PLLF2 Not used - 42 TOFS TE offset O 2.5
43 WVEL Not used - 44 ARE RF signal I 1.7
45 IREF Reference current input I 1.6
46 DRF DSL bias I 0
47 DSLF DSL loop filter I/O 2.4
48 PLLF PLL loop filter I/O 1.8
49 VCOF Not used - 50 AVDD2 +5V analog power supply - 5.0
51 AFSS2 Analog ground - 0
52 EFM Not used - 53 PCK/DSLB DSL bias I 2.4
54 VCOF2 Tracking offset O 2.5
55 SUBC Not used - 56 SBCK (Connecting to ground) - 57 VSS Ground - 0
58 X1 Crystal oscillator I 1.7
59 X2 Crystal oscillator O 2.3
60 VDD +5V power supply - 5.0
61,62 - Not used - -
63 FCLK Not used - -
Port Description I/O (V)
64 IPFLAG Not used - 65 FLAG Not used - -
66-69 - Not used - -
70 IOSEL (Connecting to ground) I 0
71 /TEST (Connecting to ground) I 0
72 AVDD1 +5V analog power supply - 4.9
73 OUTL Audio Lch output O 4.9
74 AVSS1 Analog ground - 0
75 OUTR Audio Rch output O 4.9
76 RSEL (Connecting to ground) - 0
77 CSEL (Connecting to ground) - 0
78 PSEL (Connecting to ground) - 0
79 MSEL (Connecting to ground) - 0
80 SSEL mode select I 5.0
IC401 : MN101C117AF
Pin
No.
1 MASHON Servo IC OSC control O 5.0
2 P82 No connection - 3 P81 No connection - 4 P80 (Connection to ground) - 0
5 Q1 Photo sensor signal (DISC IN) I 4.5
6 Q3 Photo sensor signal (DISC OUT) I 4.2
7 Q6 Photo sensor signal (Option) I 5.0
8 SW4 Clamp SW signal I 0
9 SW5 Inner SW signal I 5.0
10 SW2 Feeder arm SW I 5.0
11 PA6 (Connection to ground) - 0
12 PA7/IFR (Connecting to ground) I 0
13 VDD +5V power supply - 5.0
14 OSC2 Crystal oscillator - 5.0
15 OSC1 Crystal oscillator - 3.3
16 VSS Ground - 0
17 NC No connection - 18 SOMI CD control data O 3.2
19 SIMO CD control data I 3.8
20 SCLM Data shift clock I 5.0
21 P06 Not used - 22 BD0 Drop out signal I 0
23 PC1 Loading motor driver control O 5.0
24 PS2 Focus/Tracking driver control O 0
25 VDET Vibration detecting signal I 0
26 P14 No connection - 27 CDON CD on signal I 5.0
28 IRQ1.SENSE(Connecting to groung) - 0
29 IRQ2 (Connecting to ground) - 0
30 LOD Loading motor control - 2.6
31 TRV Traverse motor control - 2.5
32 /PRST Servo IC reset O 5.0
33 STAT Status signal I 4.0
34 DMUTE DSP mute O 0
35 SUBQ Sub code Q data I 2.6
36 SQCK Sub code Q clock O 5.0
37 /TLOCK Tracking servo lock I 0
38 /FLOCK Focus servo lock I 0
39 NRST reset input I 5.0
40 MMOD (Connecting to ground) - 0
41 SENSE Sense signal I 0
42 MLD Command load O 5.0
43 MDATA Command data O 0.9
44 MCLK Command clock O 4.6
Port Description I/O (V)
8
8 PACKAGE AND IC BLOCK DIAGRAM
8.1. Main Block
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
PA51 : YEP0PTA514B0
IC20 : YEAMLC72135C
9
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
IC201 : YEAMSN761026
IC702 : YEAMM945BFT2
8.2. AMP Block
IC604 : YEAMS29130AD
IC602 : MN1382KTX / IC703 MN1382QTX
IC208 : C0ABCB000015
IC251,351 : YEAMLA4708
IC704 : YEAMA61W12ST
10
8.3. CD Servo Block
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
IC101 : YEAMBA6354FS
IC901 : C0GBY0000003
IC601 : C0GBY0000004
11
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
9 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
5. "MCC" marks in remarks column are indicated supply parts
of Matsushita Communication Industrial Corp. of America
(MCC).
6. "A" or "B" marks in remarks column are indicated as
follows :
∙
A : CQ-JB3160A
∙
B : CQ-JB0160A
Ref.
No.
[E6848A] Main/Display Block
IC´s and TRANSISTORs
IC20 YEAMLC72135C IC
IC201 YEAMSN761026 IC
IC203 C0ABBB000179 IC
IC204 YEAMM5243FT1 IC
IC205 C0ABBB000179 IC
IC206 YEAMM5243FT1 IC
IC210 C0ABBB000179 IC
IC601 C2BBGF000256 IC
IC602 MN1382KTX IC
IC603 C0JBAM000048 IC
IC604 C3EBCG000037 IC
IC703 MN1382QTX IC
IC704 YEAMA61W12ST IC
IC901 YEAMSM6786 IC
PA51 YEP0PTA514B0 Electronic Tuner
Q221 YEANC323TKT Transistor
Q222 B1ABCF000042 Transistor
Q223 YEANA124EKTX Transistor
Q321 YEANC323TKT Transistor
Q401 YEANA114YKTX Transistor
Q402 YEANC143EKT Transistor
Q403 B1ABCF000044 Transistor
Q404 B1ABCF000042 Transistor
Q405 B1ABCF000044 Transistor
Q406 B1ABCF000044 Transistor
Q407 B1ABCF000042 Transistor
Q408 B1ABCF000044 Transistor
Q711 YEANA124EKTX Transistor
Q712 B1GBCFJN0005 Transistor
Q713 B1ABCF000042 Transistor
Q720 YEANBP1F3PT Transistor
Q721 2SD245300L Transistor
Q722 2SB1398QTA Transistor
Q723 2SB1398QTA Transistor
Q724 B1GDJEGJ0002 Transistor
Part No. Part Name & Description Remarks
mark
Ref.
No.
Q725 YEANBP1F3PT Transistor
Q731 B1ABCF000044 Transistor
Q732 B1GBCFJN0005 Transistor
Q741 B1BBAC000007 Transistor
Q771 2SD245300L Transistor
Q772 2SD0601AHR Transistor
Q773 YEAN2SD1856 Transistor
Q774 2SB1398QTA Transistor
Q775 2SD0601AHR Transistor
Q911 YEANBP1F3PT Transistor
Q912 B1GDJEGJ0002 Transistor
Q913 2SB1398QTA Transistor
Q914 2SD0601AHR Transistor
DIODEs
D51 MA3X55500L Diode
D71 MA551TX Diode
D401 MA151WKTX Diode
D402 MAZ32700ML Diode
D403 MAZ32700ML Diode
D404 MAZ32700ML Diode
D603 MA151KTX Diode
D610 MA151WKTX Diode
D621 MA741TX Diode
D710 B0BA03300012 Diode
D711 YEADRD91M1T2 Diode
D712 MA151WKTX Diode
D731 YEADRD75M2T1 Diode
D732 MA741TX Diode
D733 YEADRD56M3T1 Diode
D773 YEADRD12M1T1 Diode
D774 B0BC5R100014 Diode
D775 B0EANM000002 Diode
D776 B0EANM000002 Diode
D779 YEAD10E2 Diode
D901 MA151KTX Diode
CAPACITORs
C25 YECUS1H220JM Ceramic, 22PF 50WV
C26 YECUS1H150JM Ceramic, 15PF 50WV
C51 YECUS1H221JM Ceramic, 220PF 50WV
C53 ECEA1AKS221I Electrolytic, 220µF 10WV
C55 YECUS1E223KX Ceramic, 0.022µF 25WV
C56 YECUS1E223KX Ceramic, 0.022µF 25WV
C58 YECUS1H102KX Ceramic, 0.001µF 50WV
C59 YECUS1H102KX Ceramic, 0.001µF 50WV
C60 YECUS1H103KX Ceramic, 0.01µF 50WV
C71 YECUS1H221JM Ceramic, 220PF 50WV
C101 YECUS1C154KX Ceramic, 0.15µF 16WV
C102 YECUS1H153KX Ceramic, 0.015µF 50WV
C103 YECUS1C563KX Ceramic, 0.056µF 16WV
C105 F1J1H2R0A007 Ceramic, 2PF 50WV
C106 YECUS1H101JM Ceramic, 100PF 50WV
C107 YECUS1H272KX Ceramic, 0.0027µF 50WV
C162 YECUS1H103KX Ceramic, 0.01µF 50WV
C163 YECUS1H103KX Ceramic, 0.01µF 50WV
C166 YECUS1H103KX Ceramic, 0.01µF 50WV
C201 ECEA1AKS221I Electrolytic, 220µF 10WV
C202 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C203 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C204 YECUS1H390JM Ceramic, 39PF 50WV
C205 ECEA1EKS4R7I Electrolytic, 4.7µF 25WV
C206 YECUS1H390JM Ceramic, 39PF 50WV
C207 YECUS1H681JM Ceramic, 680PF 50WV
C208 YECUS1H681JM Ceramic, 680PF 50WV
C210 ECEA1HKS010I Electrolytic, 1µF 50WV
C211 ECEA1HKSR22I Electrolytic, 0.22µF 50WV
C212 ECEA1HKS010I Electrolytic, 1µF 50WV
C213 ECEA1ASN100I Electrolytic, 10µF 10WV
C214 YECUS1H103KX Ceramic, 0.01µF 50WV
C217 YECUS1H682KX Ceramic, 0.0068µF 50WV
Part No. Part Name & Description Remarks
12
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
Ref.
No.
C218 YECUS1H821JM Ceramic, 820PF 50WV
C220 ECEA1VSN2R2I Electrolytic, 2.2µF 35WV
C221 YECUS1C683KX Ceramic, 0.068µF 16WV
C222 ECEA1ASN100I Electrolytic, 10µF 10WV
C224 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C225 ECEA1CKS100I Electrolytic, 10µF 16WV
C230 YECUS1C104KX Ceramic, 0.1µF 16WV
C231 YECUS1C104KX Ceramic, 0.1µF 16WV
C232 YECUS1H222KX Ceramic, 0.0022µF 50WV A
C232 YECUS1H332KX Ceramic, 0.0033µF 50WV B
C233 YECUS1H153KX Ceramic, 0.015µF 50WV A
C233 YECUS1H822KX Ceramic, 0.0082µF 50WV B
C236 YECUS1H102KX Ceramic, 0.001µF 50WV A
C237 YECUS1C184KX Ceramic, 0.18µF 16WV B
C238 YECUS1H821JM Ceramic, 820PF 50WV A
C238 YECUS1E473KX Ceramic, 0.047µF 25WV B
C239 YECUS1H153KX Ceramic, 0.015µF 50WV B
C240 YECUS1H822KX Ceramic, 0.0082µF 50WV A
C241 YECUS1H681JM Ceramic, 680PF 50WV A
C241 YECUS1H472KX Ceramic, 0.0047µF 50WV B
C242 YECUS1H272KX Ceramic, 0.0027µF 50WV
C243 YECUS1H561KX Ceramic, 560PF 50WV
C250 ECEA1CKS100I Electrolytic, 10µF 16WV
C260 YECUS1C104KX Ceramic, 0.1µF 16WV
C261 YECUS1C104KX Ceramic, 0.1µF 16WV
C262 YECUS1H183KX Ceramic, 0.018µF 50WV A
C262 YECUB1H393KX Ceramic, 0.039µF 50WV B
C263 YECUS1C334KX Ceramic, 0.33µF 16WV A
C263 YECUS1C394KX Ceramic, 0.39µF 16WV B
C265 YECUS1C184KX Ceramic, 0.18µF 16WV B
C266 YECUS1H562KX Ceramic, 0.0056µF 50WV A
C267 YECUS1H221JM Ceramic, 220PF 50WV A
C267 YECUS1H332KX Ceramic, 0.0033µF 50WV B
C268 YECUS1H183KX Ceramic, 0.018µF 50WV B
C269 F1J1C184A006 Ceramic, 0.18µF 16WV A
C269 YECUS1H103KX Ceramic, 0.01µF 50WV B
C270 YECUS1H561KX Ceramic, 560PF 50WV
C280 ECEA1CKS100I Electrolytic, 10µF 16WV
C302 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C303 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C304 YECUS1H390JM Ceramic, 39PF 50WV
C305 ECEA1EKS4R7I Electrolytic, 4.7µF 25WV
C306 YECUS1H390JM Ceramic, 39PF 50WV
C307 YECUS1H681JM Ceramic, 680PF 50WV
C308 YECUS1H681JM Ceramic, 680PF 50WV
C310 ECEA1HKS010I Electrolytic, 1µF 50WV
C311 ECEA1HKSR22I Electrolytic, 0.22µF 50WV
C312 ECEA1HKS010I Electrolytic, 1µF 50WV
C313 ECEA1ASN100I Electrolytic, 10µF 10WV
C314 YECUS1H103KX Ceramic, 0.01µF 50WV
C317 YECUS1H682KX Ceramic, 0.0068µF 50WV
C318 YECUS1H821JM Ceramic, 820PF 50WV
C320 ECEA1VSN2R2I Electrolytic, 2.2µF 35WV
C321 YECUS1C683KX Ceramic, 0.068µF 16WV
C322 ECEA1ASN100I Electrolytic, 10µF 10WV
C324 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C330 YECUS1C104KX Ceramic, 0.1µF 16WV
C331 YECUS1C104KX Ceramic, 0.1µF 16WV
C332 YECUS1H222KX Ceramic, 0.0022µF 50WV A
C332 YECUS1H332KX Ceramic, 0.0033µF 50WV B
C333 YECUS1H153KX Ceramic, 0.015µF 50WV A
C333 YECUS1H822KX Ceramic, 0.0082µF 50WV B
C336 YECUS1H102KX Ceramic, 0.001µF 50WV A
C337 YECUS1C184KX Ceramic, 0.18µF 16WV B
C338 YECUS1H821JM Ceramic, 820PF 50WV A
C338 YECUS1E473KX Ceramic, 0.047µF 25WV B
C339 YECUS1H153KX Ceramic, 0.015µF 50WV B
C340 YECUS1H822KX Ceramic, 0.0082µF 50WV A
C341 YECUS1H681JM Ceramic, 680PF 50WV A
C341 YECUS1H472KX Ceramic, 0.0047µF 50WV B
C342 YECUS1H272KX Ceramic, 0.0027µF 50WV
C343 YECUS1H561KX Ceramic, 560PF 50WV
C350 ECEA1CKS100I Electrolytic, 10µF 16WV
Part No. Part Name & Description Remarks
Ref.
No.
C360 YECUS1C104KX Ceramic, 0.1µF 16WV
C361 YECUS1C104KX Ceramic, 0.1µF 16WV
C362 YECUS1H183KX Ceramic, 0.018µF 50WV A
C362 YECUB1H393KX Ceramic, 0.039µF 50WV B
C363 YECUS1C334KX Ceramic, 0.33µF 16WV A
C363 YECUS1C394KX Ceramic, 0.39µF 16WV B
C365 YECUS1C184KX Ceramic, 0.18µF 16WV B
C366 YECUS1H562KX Ceramic, 0.0056µF 50WV A
C367 YECUS1H221JM Ceramic, 220PF 50WV A
C367 YECUS1H332KX Ceramic, 0.0033µF 50WV B
C368 YECUS1H183KX Ceramic, 0.018µF 50WV B
C369 F1J1C184A006 Ceramic, 0.18µF 16WV A
C369 YECUS1H103KX Ceramic, 0.01µF 50WV B
C370 YECUS1H561KX Ceramic, 560PF 50WV
C380 ECEA1CKS100I Electrolytic, 10µF 16WV
C401 YECUS1H100CC Ceramic, 10PF 50WV
C402 YECUS1H100CC Ceramic, 10PF 50WV
C501 ECEA1CKS100I Electrolytic, 10µF 16WV
C502 YECUS1H151JM Ceramic, 150PF 50WV
C503 YECUS1H471JM Ceramic, 470PF 50WV
C504 YECUS1E223KX Ceramic, 0.022µF 25WV
C505 YECUS1E223KX Ceramic, 0.022µF 25WV
C506 YECUS1H103KX Ceramic, 0.01µF 50WV
C507 YECUS1H123KX Ceramic, 0.012µF 50WV
C508 YECUS1H123KX Ceramic, 0.012µF 50WV
C600 YECUS1H103KX Ceramic, 0.01µF 50WV
C602 YECUS1C104KX Ceramic, 0.1µF 16WV
C603 ECEA0JKS331I Electrolytic, 330µF 6.3WV
C604 YECUS1H103KX Ceramic, 0.01µF 50WV
C605 YECUS1C104KX Ceramic, 0.1µF 16WV
C606 ECEA0JKS101I Electrolytic, 100µF 6.3WV
C607 ECEA1ESN4R7 Electrolytic, 4.7µF 25WV
C608 YECUS1H103KX Ceramic, 0.01µF 50WV
C609 YECUS1C104KX Ceramic, 0.1µF 16WV
C610 YECUS1H472KX Ceramic, 0.0047µF 50WV
C611 YECUS1H103KX Ceramic, 0.01µF 50WV
C612 YECUS1H821JM Ceramic, 820PF 50WV
C613 ECEA1AKS221I Electrolytic, 220µF 10WV
C614 YECUS1C224KX Ceramic, 0.22µF 16WV
C615 EECS0HD473H Electrolytic, 0.047F 5.5WV
C616 YECUS1C104KX Ceramic, 0.1µF 16WV
C620 YECUS1H220JM Ceramic, 22PF 50WV
C621 YECUS1H220JM Ceramic, 22PF 50WV
C622 YECUS1H390JM Ceramic, 39PF 50WV
C623 YECUS1H220JM Ceramic, 22PF 50WV
C651 YECUS1E223KX Ceramic, 0.022µF 25WV
C701 YECUS1C104KX Ceramic, 0.1µF 16WV
C702 YECUS1C104KX Ceramic, 0.1µF 16WV
C710 ECEA1CSN100I Electrolytic, 10µF 16WV
C711 ECEA1AKS101I Electrolytic, 100µF 10WV
C715 ECEA1CKS100I Electrolytic, 10µF 16WV
C716 YECUS1E473KX Ceramic, 0.047µF 25WV
C718 ECEA1AKS221I Electrolytic, 220µF 10WV
C720 YECUS1H103KX Ceramic, 0.01µF 50WV
C725 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C726 ECEA1AKS101I Electrolytic, 100µF 10WV
C727 ECEA1AKS101I Electrolytic, 100µF 10WV
C731 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C732 F1J1H333A395 Ceramic, 0.033µF 50WV
C734 ECEA1CKS470I Electrolytic, 47µF 16WV
C735 YECUS1C224KX Ceramic, 0.22µF 16WV
C741 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C742 YECUS1H103KX Ceramic, 0.01µF 50WV
C744 ECEA1EKS4R7I Electrolytic, 4.7µF 25WV
C747 EEAFC1A820H Electrolytic, 82µF 10WV
C750 YECUS1C104KX Ceramic, 0.1µF 16WV
C751 ECA1AM221I Electrolytic, 220µF 10WV
C752 YECUS1E223KX Ceramic, 0.022µF 25WV
C753 YECUS1C104KX Ceramic, 0.1µF 16WV
C754 YECUS1C104KX Ceramic, 0.1µF 16WV
C755 YECUS1H102KX Ceramic, 0.001µF 50WV
C758 ECEA0JKS101I Electrolytic, 100µF 6.3WV
C759 YECUS1H103KX Ceramic, 0.01µF 50WV
Part No. Part Name & Description Remarks
13
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
Ref.
No.
C760 ECA1CM102 Electrolytic, 1000µF 16WV
C761 YECUS1H101JM Ceramic, 100PF 50WV
C782 ECEA1AKS221I Electrolytic, 220µF 10WV
C783 YECUS1H103KX Ceramic, 0.01µF 50WV
C784 YECUS1C224KX Ceramic, 0.22µF 16WV
C785 ECEA1CKS220I Electrolytic, 22µF 16WV
C786 YECUS1C334KX Ceramic, 0.33µF 16WV
C787 YECUS1C334KX Ceramic, 0.33µF 16WV
C788 YECUS1C224KX Ceramic, 0.22µF 16WV
C790 EEAFC1A820H Electrolytic, 82µF 10WV
C901 YECUS1C105ZF Ceramic, 1µF 16WV
C902 YECUS1E223KX Ceramic, 0.022µF 25WV
C903 YECUS1E223KX Ceramic, 0.022µF 25WV
RESISTORs
J602 ERJ6GEY0R00 Chip, 0
J701 ERJ6GEY0R00 Chip, 0
J702 ERJ6GEY0R00 Chip, 0
R34 ERJ6GEYJ473 Chip, 47k
R35 ERJ6GEYJ103 Chip, 10k
R51 ERJ6GEYJ564 Chip, 560k
R52 ERJ6GEYJ564 Chip, 560k
R55 ERJ6GEYJ103 Chip, 10k
R56 ERJ6GEYJ563 Chip, 56k
R57 ERJ6GEYJ101 Chip, 100
R58 ERJ6GEYJ272 Chip, 2.7k
R59 ERJ6GEYJ562 Chip, 5.6k
R101 ERJ6GEYJ472 Chip, 4.7k
R102 ERJ6GEYJ153 Chip, 15k
R104 ERJ6GEYJ183 Chip, 18k
R105 ERJ6GEYJ101 Chip, 100
R161 ERJ6GEYJ102 Chip, 1k
R162 ERJ6GEYJ102 Chip, 1k
R164 ERJ6GEYJ473 Chip, 47k
R165 ERJ6GEYJ473 Chip, 47k
R167 ERJ6GEYJ473 Chip, 47k
R201 ERJ6GEYJ103 Chip, 10k
R202 ERJ6GEYJ273 Chip, 27k
R203 ERJ6GEYJ122 Chip, 1.2k
R204 ERJ6GEYJ103 Chip, 10k
R205 ERJ6GEYJ103 Chip, 10k
R207 ERJ8GEYJ273V Chip, 27k
R210 ERJ6GEYJ181 Chip, 180
R212 ERJ6GEYJ182 Chip, 1.8k
R215 ERJ6GEYJ103 Chip, 10k
R216 ERJ6GEYJ682 Chip, 6.8k
R217 ERJ6GEYJ103 Chip, 10k
R221 ERJ6GEYJ153 Chip, 15k
R221 ERJ6GEYJ822 Chip, 8.2k
R222 ERJ6GEYJ103 Chip, 10k
R223 ERJ6GEYJ222 Chip, 2.2k
R224 ERJ6GEYJ222 Chip, 2.2k
R230 ERJ6GEYJ332 Chip, 3.3k
R231 ERJ6GEYJ223 Chip, 22k
R231 ERJ6GEYJ333 Chip, 33k
R232 ERJ6GEYJ333 Chip, 33k
R232 ERJ6GEYJ563 Chip, 56k
R233 ERJ6GEYJ472 Chip, 4.7k
R233 ERJ6GEYJ682 Chip, 6.8k
R234 ERJ6GEYJ472 Chip, 4.7k
R234 ERJ6GEYJ272 Chip, 2.7k
R235 ERJ6GEYJ332 Chip, 3.3k
R235 ERJ6GEYJ682 Chip, 6.8k
R237 ERJ6GEYJ103 Chip, 10k
R237 ERJ6GEYJ123 Chip, 12k
R238 ERJ6GEYJ272 Chip, 2.7k
R240 ERJ6GEYJ332 Chip, 3.3k
R260 ERJ6GEYJ332 Chip, 3.3k
R261 ERJ6GEYJ183 Chip, 18k
R261 ERJ6GEYJ153 Chip, 15k
R262 ERJ6GEYJ683 Chip, 68k
R263 ERJ6GEYJ471 Chip, 470
Part No. Part Name & Description Remarks
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
Ref.
No.
R263 ERJ6GEYJ1R0 Chip, 1.0
R264 ERJ6GEYJ152 Chip, 1.5k
R264 ERJ6GEYJ682 Chip, 6.8k
R265 ERJ6GEYJ222 Chip, 2.2k
R266 ERJ6GEYJ103 Chip, 10k
R267 ERJ6GEYJ272 Chip, 2.7k
R270 ERJ6GEYJ332 Chip, 3.3k
R301 ERJ6GEYJ103 Chip, 10k
R302 ERJ6GEYJ273 Chip, 27k
R303 ERJ6GEYJ102 Chip, 1k
R304 ERJ6GEYJ103 Chip, 10k
R305 ERJ6GEYJ103 Chip, 10k
R307 ERJ8GEYJ273V Chip, 27k
R310 ERJ6GEYJ181 Chip, 180
R312 ERJ6GEYJ182 Chip, 1.8k
R315 ERJ6GEYJ103 Chip, 10k
R316 ERJ6GEYJ682 Chip, 6.8k
R317 ERJ6GEYJ103 Chip, 10k
R321 ERJ6GEYJ153 Chip, 15k
R321 ERJ6GEYJ822 Chip, 8.2k
R330 ERJ6GEYJ332 Chip, 3.3k
R331 ERJ6GEYJ223 Chip, 22k
R331 ERJ6GEYJ333 Chip, 33k
R332 ERJ6GEYJ333 Chip, 33k
R332 ERJ6GEYJ563 Chip, 56k
R333 ERJ6GEYJ472 Chip, 4.7k
R333 ERJ6GEYJ682 Chip, 6.8k
R334 ERJ6GEYJ472 Chip, 4.7k
R334 ERJ6GEYJ272 Chip, 2.7k
R335 ERJ6GEYJ332 Chip, 3.3k
R335 ERJ6GEYJ682 Chip, 6.8k
R337 ERJ6GEYJ103 Chip, 10k
R337 ERJ6GEYJ123 Chip, 12k
R338 ERJ6GEYJ272 Chip, 2.7k
R340 ERJ6GEYJ332 Chip, 3.3k
R360 ERJ6GEYJ332 Chip, 3.3k
R361 ERJ6GEYJ183 Chip, 18k
R361 ERJ6GEYJ153 Chip, 15k
R362 ERJ6GEYJ683 Chip, 68k
R363 ERJ6GEYJ471 Chip, 470
R363 ERJ6GEYJ1R0 Chip, 1.0
R364 ERJ6GEYJ152 Chip, 1.5k
R364 ERJ6GEYJ682 Chip, 6.8k
R365 ERJ6GEYJ222 Chip, 2.2k
R366 ERJ6GEYJ103 Chip, 10k
R367 ERJ6GEYJ272 Chip, 2.7k
R370 ERJ6GEYJ332 Chip, 3.3k
R401 ERJ6GEYJ472 Chip, 4.7k
R402 ERJ6GEYJ562 Chip, 5.6k
R403 ERJ6GEYJ272 Chip, 2.7k
R404 ERJ6GEYJ102 Chip, 1k
R405 ERJ6GEYJ392 Chip, 3.9k
R406 ERJ6GEYJ122 Chip, 1.2k
R407 ERJ6GEYJ561 Chip, 560
R409 ERJ6GEY0R00 Chip, 0
R410 ERJ6GEYJ272 Chip, 2.7k
R411 ERJ6GEYJ102 Chip, 1k
R412 ERJ6GEYJ392 Chip, 3.9k
R413 ERJ6GEYJ122 Chip, 1.2k
R414 ERJ6GEYJ561 Chip, 560
R501 ERJ6GEYJ822 Chip, 8.2k
R502 ERJ6GEYJ823 Chip, 82k
R503 ERJ6GEYJ104 Chip, 100k
R504 ERJ6GEYJ103 Chip, 10k
R505 ERJ6GEYJ184 Chip, 180k
R506 ERJ6GEYJ103 Chip, 10k
R507 ERJ6GEYJ222 Chip, 2.2k
R508 ERJ6GEYJ222 Chip, 2.2k
R509 ERJ6GEYJ101 Chip, 100
R601 ERJ6GEYJ473 Chip, 47k
R602 ERJ6GEYJ473 Chip, 47k
R603 ERJ6GEYJ473 Chip, 47k
R604 ERJ6GEYJ102 Chip, 1k
Part No. Part Name & Description Remarks
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
1/10W
ΩΩΩΩ
1/10W
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
1/10W
14
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
Ref.
No.
R605 ERJ6GEYJ102 Chip, 1k
R606 ERJ6GEYJ102 Chip, 1k
R607 ERJ6GEYJ102 Chip, 1k
R608 ERJ6GEYJ473 Chip, 47k
R609 ERJ6GEYJ222 Chip, 2.2k
R610 ERJ6GEYJ222 Chip, 2.2k
R611 ERJ6GEYJ473 Chip, 47k
R612 ERJ6GEYJ102 Chip, 1k
R614 ERJ6GEY0R00 Chip, 0
R615 ERJ6GEYJ473 Chip, 47k
R616 ERJ6GEYJ104 Chip, 100k
R617 ERJ6GEYJ564 Chip, 560k
R619 ERJ6GEYJ221 Chip, 220
R620 ERJ6GEYJ220 Chip, 22
R621 ERJ6GEYJ103 Chip, 10k
R622 ERJ6GEYJ105 Chip, 1M
R623 ERJ6GEYJ103 Chip, 10k
R624 ERJ6GEYJ105 Chip, 1M
R625 ERJ6GEYJ273 Chip, 27k
R626 ERJ6GEYJ473 Chip, 47k
R627 ERJ6GEY0R00 Chip, 0
R628 ERJ6GEYJ103 Chip, 10k
R631 ERJ6GEYJ153 Chip, 15k
R631 ERJ6GEYJ123 Chip, 12k
R632 ERJ6GEYJ472 Chip, 4.7k
R633 ERJ6GEYJ152 Chip, 1.5k
R634 ERJ6GEYJ151 Chip, 150
R635 ERJ6GEYJ152 Chip, 1.5k
R636 ERJ6GEYJ152 Chip, 1.5k
R637 ERJ6GEYJ473 Chip, 47k
R649 ERJ6GEY0R00 Chip, 0
R650 ERJ6GEY0R00 Chip, 0
R651 ERJ6GEY0R00 Chip, 0
R653 ERJ6GEYJ473 Chip, 47k
R654 ERJ6GEYJ102 Chip, 1k
R655 ERJ6GEY0R00 Chip, 0
R656 ERJ6GEYJ103 Chip, 10k
R657 ERJ6GEYJ473 Chip, 47k
R663 ERJ6GEYJ472 Chip, 4.7k
R664 ERJ6GEYJ472 Chip, 4.7k
R665 ERJ6GEYJ472 Chip, 4.7k
R666 ERJ6GEYJ472 Chip, 4.7k
R668 ERJ6GEYJ102 Chip, 1k
R669 ERJ6GEYJ102 Chip, 1k
R670 ERJ6GEYJ102 Chip, 1k
R715 ERX12SJR22V Metal Film, 0.22
R716 ERJ6GEYJ183 Chip, 18k
R717 ERJ6GEYJ472 Chip, 4.7k
R718 ERJ6GEYJ222 Chip, 2.2k
R719 ERJ6GEYJ222 Chip, 2.2k
R721 ERJ8GEYJ391V Chip, 390
R722 ERJ8GEYJ1R0V Chip, 1.0
R723 ERJ8GEYJ102V Chip, 1k
R724 ERJ6GEYJ333 Chip, 33k
R728 ERJ6GEYJ222 Chip, 2.2k
R729 ERJ6GEYJ222 Chip, 2.2k
R730 ERJ8GEYJ102V Chip, 1k
R731 ERJ6GEYJ103 Chip, 10k
R732 ERX1SJ2R2P Metal Film, 2.2
R733 ERX1SJ2R2P Metal Film, 2.2
R734 ERJ6GEYJ103 Chip, 10k
R735 ERJ6GEYJ334 Chip, 330k
R736 ERJ6GEYJ683 Chip, 68k
R737 ERJ6GEYJ333 Chip, 33k
R738 ERJ6GEYJ333 Chip, 33k
R740 ERJ6GEYJ273 Chip, 27k
R741 ERJ8GEYJ2R2V Chip, 2.2
R742 ERJ6GEYJ333 Chip, 33k
R743 ERJ6GEYJ333 Chip, 33k
R744 ERJ6GEYJ473 Chip, 47k
R747 ERJ6GEYJ103 Chip, 10k
R748 ERJ6GEYJ123 Chip, 12k
R749 ERJ6GEYJ103 Chip, 10k
Part No. Part Name & Description Remarks
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W A
ΩΩΩΩ
1/10W B
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
Ref.
No.
R750 ERJ6GEYJ123 Chip, 12k
R751 ERJ6GEYJ222 Chip, 2.2k
R752 ERJ6GEYJ222 Chip, 2.2k
R753 ERJ6GEYJ222 Chip, 2.2k
R754 ERJ6GEYJ222 Chip, 2.2k
R755 ERJ6GEYJ222 Chip, 2.2k
R756 ERJ6GEYJ222 Chip, 2.2k
R771 ERJ8GEYJ391V Chip, 390
R772 ERJ8GEYJ122V Chip, 1.2k
R773 ERJ6GEYJ182 Chip, 1.8k
R774 ERJ6GEYJ102 Chip, 1k
R775 ERJ6GEYJ473 Chip, 47k
R779 ERJ6GEYJ471 Chip, 470
R780 ERJ6GEYJ103 Chip, 10k
R781 ERJ8GEYJ102V Chip, 1k
R782 ERJ6GEYJ103 Chip, 10k
R783 ERJ6GEYJ472 Chip, 4.7k
R901 ERJ6GEYJ220 Chip, 22
R902 ERJ6GEYJ473 Chip, 47k
R903 ERJ6GEYJ473 Chip, 47k
R904 ERJ6GEYJ471 Chip, 470
R905 ERJ6GEYJ471 Chip, 470
R906 ERJ6GEYJ471 Chip, 470
R907 ERJ6GEYJ471 Chip, 470
R943 ERJ8GEYJ102V Chip, 1k
R944 ERJ8GEYJ102V Chip, 1k
R945 ERJ6GEYJ103 Chip, 10k
R946 ERJ6GEYJ472 Chip, 4.7k
R947 ERJ6GEYJ103 Chip, 10k
R948 ERX1SJ1R0 Metal Film, 1.0
R950 ERJ8GEYJ1R2V Chip, 1.2
R951 ERJ8GEYJ1R2V Chip, 1.2
R952 ERJ8GEYJ4R7V Chip, 4.7
R953 ERJ8GEYJ4R7V Chip, 4.7
R954 ERJ8GEYJ4R7V Chip, 4.7
R955 ERJ8GEYJ4R7V Chip, 4.7
R956 ERJ8GEYJ3R3V Chip, 3.3
R957 ERJ8GEYJ4R7V Chip, 4.7
R958 ERJ8GEYJ3R3V Chip, 3.3
R959 ERJ8GEYJ4R7V Chip, 4.7
R960 ERDS1FJ270 Carbon, 27
R961 ERDS1FJ470 Carbon, 47
R962 ERG1SJ150P Metal Oxid, 15
R963 ERG1SJ150P Metal Oxid, 15
ΩΩΩΩ
1/2W
ΩΩΩΩ
1/2W
ΩΩΩΩ
1/2W
R964 ERG1SJ120P Metal Oxid, 12
R965 ERG1SJ120P Metal Oxid, 12
CONNECTORs
CNP1 K9ZZ00000039 Flat Cable, 14P
CN201 YEAEK623214S Connector, 14P
CN401 YEAE012081A Connector, 13P DIN
CN701 YEAETKCF10QS Connector, 10P
CN702 YEAETKCF08QS Connector, 8P
CN901 K1KA08B00189 Connector, 8P
CN902 K1KA08B00189 Connector, 8P
CP901 YEAETKCF08XY Connector, 8P
CP902 YEAETKCF08XY Connector, 8P
SWITCHEs
SW1 YEAS08042 Switch
SW901 K0F111A00336 Switch
SW902 K0F111A00336 Switch
SW905 K0F111A00336 Switch
SW906 K0F111A00336 Switch
SW907 K0F111A00336 Switch
SW908 K0F111A00336 Switch
SW909 K0F111A00336 Switch
SW910 K0F111A00336 Switch
SW911 K0F111A00336 Switch
SW913 K0F111A00336 Switch
SW914 K0F111A00336 Switch
Part No. Part Name & Description Remarks
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
1/8W
1/8W
1/8W
1/8W
1/8W
1/8W
1/8W
1/8W
1/8W
1/2W
1/2W
1/2W
ΩΩΩΩ
1W
ΩΩΩΩ
1W
ΩΩΩΩ
1W
ΩΩΩΩ
1W
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
15
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
Ref.
No.
SW915 K0F111A00336 Switch
SW916 K0F111A00336 Switch
SW917 EVQBSW00415B Switch
SW918 EVQBSW06309B Switch
LCD
LCD901 L5AAAGC00033 LCD
COILs
L51 YELT02M1R8KT Coil
L52 G1C3R3K00003 Coil
L71 G1C3R3K00003 Coil
L101 YELT02MR82KT Coil
L163 G1C3R3K00003 Coil
L501 G1C3R3K00003 Coil
L502 G1C3R3K00003 Coil
L601 YELT03N5R6KT Coil
L602 G1C3R3K00003 Coil
L603 G1C3R3K00003 Coil
L604 G1C3R3K00003 Coil
L605 G1C3R3K00003 Coil
L751 J0JCC0000012 Coil
L752 J0JCC0000012 Coil
L753 YELTBMHS800T Coil
CRYSTALs
XL20 YEXL49U072TA Crystal
XL601 YEXL49U0419S Crystal
XL602 YEXLMC60327 Crystal
LAMPs
PL901 YEALHSIB045 Pilot Lamp
PL902 YEALHSIB045 Pilot Lamp
PL903 YEALHSIB024 Pilot Lamp
PL904 YEALHSIB024 Pilot Lamp
PL905 YEALHSIB024 Pilot Lamp
PL906 YEALHSIB024 Pilot Lamp
PL907 YEALHSLB010 Pilot Lamp
PL908 YEALHSIB024 Pilot Lamp
PL909 YEALHSLB010 Pilot Lamp
PL910 YEALSRMB011 Pilot Lamp
Z51 J0LE00000004 ZNR
Z71 J0LE00000004 ZNR
Part No. Part Name & Description Remarks
Ref.
No.
IC251 C1BA00000326 IC
Q251 YEANC323TKT Transistor
Q252 YEANA114TK Transistor
Q281 YEANC323TKT Transistor
Q351 YEANC323TKT Transistor
Q352 B1GBCFJN0005 Transistor
Q381 YEANC323TKT Transistor
DIODEs
D771 B0ECMP000002 Diode
D772 B0EANM000002 Diode
CAPACITORs
C251 ECEA1HKSR22 Electrolytic, 0.22µF 50WV
C252 YECUS1H471JM Ceramic, 470PF 50WV
C253 ECA1CM470I Electrolytic, 47µF 16WV
C254 YECUS1C104KX Ceramic, 0.1µF 16WV
C255 YECUS1C224KX Ceramic, 0.22µF 16WV
C256 ECEA1HKA3R3I Electrolytic, 3.3µF 50WV
C281 ECEA1HKSR22 Electrolytic, 0.22µF 50WV
C282 YECUS1H471JM Ceramic, 470PF 50WV
C291 YECUS1C124KX Ceramic, 0.12µF 16WV
C292 YECUS1C124KX Ceramic, 0.12µF 16WV
C293 YECUS1C124KX Ceramic, 0.12µF 16WV
C294 YECUS1C124KX Ceramic, 0.12µF 16WV
C351 ECEA1HKSR22 Electrolytic, 0.22µF 50WV
C352 YECUS1H471JM Ceramic, 470PF 50WV
C381 ECEA1HKSR22 Electrolytic, 0.22µF 50WV
C382 YECUS1H471JM Ceramic, 470PF 50WV
C384 YECUS1H103KX Ceramic, 0.01µF 50WV
C391 YECUS1C124KX Ceramic, 0.12µF 16WV
C392 YECUS1C124KX Ceramic, 0.12µF 16WV
C393 YECUS1C124KX Ceramic, 0.12µF 16WV
C394 YECUS1C124KX Ceramic, 0.12µF 16WV
C701 YECUS1H103KX Ceramic, 0.01µF 50WV
C702 YECUS1H103KX Ceramic, 0.01µF 50WV
C703 ECA1HM100I Electrolytic, 10µF 50WV
C704 YECUS1H103KX Ceramic, 0.01µF 50WV
C706 YECUS1H103KX Ceramic, 0.01µF 50WV
C720 ECA1CM102B Electrolytic, 1000µF 16WV
C721 ECA1CM102B Electrolytic, 1000µF 16WV
C722 ECA1CM102B Electrolytic, 1000µF 16WV
C723 ECA1HM100I Electrolytic, 10µF 50WV
C724 ECQV1H104B46 Plastic Film, 0.1µF 50WV
Part No. Part Name & Description Remarks
NETWORK RESISTORs
RA600 EXBV8V471JV Network Resistor
RA601 EXBV8V222JV Network Resistor
RA602 EXBV8V222JV Network Resistor
RA603 EXBV8V222JV Network Resistor
RA604 EXBV8V222JV Network Resistor
RA605 EXBV8V222JV Network Resistor
RA606 EXBV8V222JV Network Resistor
RA607 EXBV8V222JV Network Resistor
RA608 EXBV8V222JV Network Resistor
RA609 EXBV8V222JV Network Resistor
RA610 EXBV8V222JV Network Resistor
RA611 EXBV8V473JV Network Resistor
RA612 EXBV8V222JV Network Resistor
RA613 EXBV8V222JV Network Resistor
THERMISTERs
R415 D4ZZ00000015 Thermister
R739 D4ZZ00000015 Thermister
[E8997] AMP Block
IC´s and TRANSISTORs
RESISTORs
R250 ERJ6GEYJ222 Chip, 2.2k
R251 ERJ6GEYJ102 Chip, 1k
R252 ERJ6GEYJ103 Chip, 10k
R280 ERJ6GEYJ222 Chip, 2.2k
R281 ERJ6GEYJ102 Chip, 1k
R282 ERJ6GEYJ103 Chip, 10k
R291 ERJ6GEYJ2R2 Chip, 2.2
R292 ERJ6GEYJ2R2 Chip, 2.2
R293 ERJ6GEYJ2R2 Chip, 2.2
R294 ERJ6GEYJ2R2 Chip, 2.2
R350 ERJ6GEYJ222 Chip, 2.2k
R351 ERJ6GEYJ102 Chip, 1k
R352 ERJ6GEYJ103 Chip, 10k
R354 ERJ6GEYJ103 Chip, 10k
R355 ERJ6GEYJ472 Chip, 4.7k
R356 ERJ6GEYJ102 Chip, 1k
R380 ERJ6GEYJ222 Chip, 2.2k
R381 ERJ6GEYJ102 Chip, 1k
R382 ERJ6GEYJ103 Chip, 10k
R391 ERJ6GEYJ2R2 Chip, 2.2
R392 ERJ6GEYJ2R2 Chip, 2.2
R393 ERJ6GEYJ2R2 Chip, 2.2
R394 ERJ6GEYJ2R2 Chip, 2.2
R702 ERX12SJR22V Metal Film, 0.22
16
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
1/10W
ΩΩΩΩ
ΩΩΩΩ
1/10W
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
1/10W
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
ΩΩΩΩ
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
1/10W
ΩΩΩΩ
1/2W
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
Ref.
No.
R704 ERJ6GEYJ472 Chip, 4.7k
R705 ERJ6GEYJ223 Chip, 22k
R724 ERJ8GEYJ561V Chip, 560
R725 ERJ8GEYJ561V Chip, 560
R726 ERJ8GEYJ561V Chip, 560
R727 ERJ8GEYJ561V Chip, 560
CONNECTORs
CJ701 K1KA10B00162 Connector, 10P
CJ702 K1KA08B00189 Connector, 8P
CJ703 YEAE14SDLYS Connector, 14P
COILs
L701 YETQ016F160 Coil
L702 YETQ012G157 Coil
[E8746C] CD Servo Block
IC´s and TRANSISTORs
IC101 C1BB00000173 IC
IC201 MN662748RPMF IC
IC401 MN101C117AF IC
IC601 C0GBY0000004 IC
IC901 C0GBY0000003 IC
Q1 YEADPS1101W Transistor
Q3 YEADPS1101W Transistor
Q6 YEADPS1101W Transistor
Q101 2SB766ATX Transistor
Q451 YEANC113ZKTX Transistor
DIODEs
D1 YEADAN1102W Diode
D3 YEADAN1102W Diode
D6 YEADAN1102W Diode
D201 YEAD1SS355T1 Diode
D401 MA151WKTX Diode
D601 YEAD1SS355T1 Diode
CAPACITORs
C101 YECUZ1C104KX Ceramic, 0.1µF 16WV
C102 YECUZ1C104KX Ceramic, 0.1µF 16WV
C103 F3H0J107A001 Ceramic, 100µF 6.3WV
C104 YECUZ1C104KX Ceramic, 0.1µF 16WV
C105 ECSH0JY475CR Tantalum, 4.7µF 6.3WV
C106 F1H1E273A011 Ceramic, 0.027µF 25WV
C107 F1H1H152A201 Ceramic, 0.0015µF 50WV
C108 YECUZ1H472KX Ceramic, 0.0047µF 50WV
C109 YECUZ1H102KX Ceramic, 0.001µF 50WV
C110 YECUZ1H102KX Ceramic, 0.001µF 50WV
C111 YECSW1A106MA Tantalum, 10µF 10WV
C112 YECUZ1C104KX Ceramic, 0.1µF 16WV
C113 YECUZ1C104KX Ceramic, 0.1µF 16WV
C115 YECUZ1H102KX Ceramic, 0.001µF 50WV
C116 YECUZ1H102KX Ceramic, 0.001µF 50WV
C117 YECUS1A105KX Ceramic, 1µF 10WV
C118 F1H1H681A201 Ceramic, 680PF 50WV
C119 YECUZ1C104KX Ceramic, 0.1µF 16WV
C120 YECUZ1H561KX Ceramic, 560PF 50WV
C121 YECUZ1E123KX Ceramic, 0.012µF 25WV
C122 YECUZ1C104KX Ceramic, 0.1µF 16WV
C133 YECUZ1C104KX Ceramic, 0.1µF 16WV
C145 YECUZ1A124KX Ceramic, 0.12µF 10WV
C201 YECUZ1E123KX Ceramic, 0.012µF 25WV
C203 YECUS1C334KX Ceramic, 0.33µF 16WV
C204 YECUZ1C104KX Ceramic, 0.1µF 16WV
C205 YECSW1A106MA Tantalum, 10µF 10WV
C206 F1H1A4740004 Ceramic, 0.47µF 10WV
C208 YECUZ1C104KX Ceramic, 0.1µF 16WV
C209 YECUZ1C104KX Ceramic, 0.1µF 16WV
Part No. Part Name & Description Remarks
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
Ref.
No.
C210 YECSW1A106MA Tantalum, 10µF 10WV
C214 YECUS1C334KX Ceramic, 0.33µF 16WV
C451 F1H1A4740004 Ceramic, 0.47µF 50WV
C453 YECUZ1H103KX Ceramic, 0.01µF 50WV
C601 YECUS1C334KX Ceramic, 0.33µF 16WV
C602 ECEV1CA470SP Electrolytic, 47µF 16WV
C603 YECUZ1C104KX Ceramic, 0.1µF 16WV
C605 YECUS1A105KX Ceramic, 1µF 10WV
C606 YECUZ1H272KX Ceramic, 0.0027µF 50WV
C901 YECUS1C334KX Ceramic, 0.33µF 16WV
C903 YECUZ1C333KX Ceramic, 0.033µF 16WV
RESISTORs
J403 ERJ3GEY0R00V Chip, 0
J423 ERJ3GEY0R00V Chip, 0
R101 ERJ3GEYJ101V Chip, 100
R102 ERJ14YJ330H Chip, 33
R103 ERJ3GEYJ683V Chip, 68k
R104 ERJ3GEYJ683V Chip, 68k
R105 ERJ3GEYJ333V Chip, 33k
R106 ERJ3GEYJ184V Chip, 180k
R107 ERJ3GEYJ184V Chip, 180k
R108 ERJ3GEYJ823V Chip, 82k
R109 ERJ3GEYJ334V Chip, 330k
R110 ERJ3GEYJ102V Chip, 1k
R111 ERJ3GEYJ102V Chip, 1k
R112 ERJ3GEYJ393V Chip, 39k
R113 ERJ3GEYJ333V Chip, 33k
R114 ERJ3GEYJ153V Chip, 15k
R119 ERJ3GEYJ184V Chip, 180k
R120 ERJ3GEYJ333V Chip, 33k
R147 ERJ3GEYJ153V Chip, 15k
R207 ERJ3GEYJ473V Chip, 47k
R208 ERJ3GEYJ473V Chip, 47k
R209 ERJ3GEYJ391V Chip, 390
R210 ERJ3GEYJ334V Chip, 330k
R211 ERJ3GEYJ124V Chip, 120k
R213 ERJ3GEYJ470V Chip, 47
R214 ERJ3GEYJ272V Chip, 2.7k
R215 ERJ3GEYJ473V Chip, 47k
R401 ERJ3GEYJ563V Chip, 56k
R402 ERJ3GEYJ563V Chip, 56k
R404 ERJ3GEYJ473V Chip, 47k
R411 ERJ3GEYJ334V Chip, 330k
R454 ERJ6GEYJ271 Chip, 270
R456 ERJ3GEYJ472V Chip, 4.7k
R461 ERJ3GEYJ823V Chip, 82k
R463 ERJ3GEYJ823V Chip, 82k
R466 ERJ3GEYJ823V Chip, 82k
R471 ERJ8GEYJ121V Chip, 120
R473 ERJ8GEYJ121V Chip, 120
R476 ERJ8GEYJ121V Chip, 120
R477 ERJ8GEY0R00V Chip, 0
R481 ERJ3GEYJ104V Chip, 100k
R601 ERJ3GEYJ123V Chip, 12k
R602 ERJ3GEYJ103V Chip, 10k
R603 ERJ3GEYJ273V Chip, 27k
R604 ERJ3GEYJ124V Chip, 120k
R605 ERJ3GEYJ103V Chip, 10k
R606 ERJ3GEYJ822V Chip, 8.2k
R607 ERJ3GEYJ103V Chip, 10k
R608 ERJ3GEYJ103V Chip, 10k
R609 ERJ3GEYJ472V Chip, 4.7k
R610 ERJ3GEYJ472V Chip, 4.7k
R613 ERJ3GEYJ122V Chip, 1.2k
R901 ERJ3GEYJ103V Chip, 10k
R902 ERJ3GEYJ333V Chip, 33k
R903 ERJ3GEYJ122V Chip, 1.2k
R924 ERJ3GEY0R00V Chip, 0
R934 ERJ3GEY0R00V Chip, 0
Part No. Part Name & Description Remarks
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/4W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/10W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/8W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
ΩΩΩΩ
1/16W
17
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
Ref.
No.
CONNECTORs
CN101 YEAESFW15R2E Connector, 15P
CN402 K1MN14B00028 Connector, 14P
CN901 K1MN05B00010 Connector, 5P
CN902 K1MN05B00009 Connector, 5P
SWITCHEs
SW2 ESE102MH2 Switch
SW4 YEAS09275 Switch
COIL
L451 YELTBLM21A10 Coil
CRYSTALs
XL201 H2D169500005 Crystal
XL451 YEXLSTCC419T Crystal
Mechanical Parts
MISCELLANEOUS
AJ1 YEAJ071287 Cord w/Plug
AJ2 YEAJ071285 Cord w/Plug
AJ51 YEAA10066 Antenna Receplacle
AJ71 YEAA10074A Antenna Receplacle
AP1 YEAP2711 FPC
AT1 YEAT05014 Terminal
1 YEFA031524 Upper Cover
2 YEFS02307 Felt
3 YEFX0215221 Bracket, Deck
4 YEP0PT8746B0 PCB w/Component RTL
6 YEFF011058 Heat Sink
7 YEFX0215178 Bracket, IC251
9 YEP0PT8997A0 PCB w/Component RTL
10 YEFX0215179 Bracket, CJ703
11 YEFA09551 Side Plate
12 YEFA09663 Side Plate
13 YEFX0213488 Bracket, CN401
14 YEFX0214202 Bracket, IC704
15 YEFX0212830 Bracket, Q773
16 YEFX0214200 Bracket, ANT
17 YEFX0213232B Bracket, AJ71
18 YEFX0213797 Bracket, GND
19 YEP0PT6848A0 PCB w/Component RTL, A
19 YEP0PT6848B0 PCB w/Component RTL, B
20 YEFE07497 Knob, PWR/VOL.
21 YEFE07498 Knob, TUNE/AUDIO
22 YEFC027173A Escucheon Ass´y A
22 YEFC027245A Escucheon Ass´y B
23 YEFA131568 Case, LCD
24 YEFV021785 Optical Shade
25 YEFX0012129A Transparent Plate
26 YEFK06971 Holder, LCD
27 YEFA07559A Front Plate
28 YEFX9991346 Bracket, GND
29 YEFA05810 Bottom Cover
Part No. Part Name & Description Remarks
40 YEJS05016 Screw, M3x15mm
41 YEJS06093 Screw, M3x6mm
42 YEJS06278 Screw,
44 YEJT03120 Tapping Screw, M3x8mm
46 YEJT03131 Tapping Screw, M2.6x5mm
49 XTB3+6FFX Tapping Screw, M3x6mm,
50 XTB3+8FFX Tapping Screw, M3x8mm
52 YEJT03263 Tapping Screw, M2.8x5mm
53 XTB2+8GFX Tapping Screw, M2x8mm
55 XYN2+J4FX Tapping Screw, M2x4mm
18
10 EXPLODED VIEW (Unit)
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
19
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
11 CD PLAYER PARTS
Ref.
No.
1 YGFA011781 Upper Chassis (4-A)
2 YGFX236153 Disk Guide (4-A)
3 YGFX0462017 Link Lever (4-A)
4 YGFX0462018 Detection Lever (2) (4-B)
5 YGFX0052357 Detection Lever (2) Spring (4-B)
6 YEJT03131 Tapping Screw, 2.6 mm* 5mm (2-C)
7 YGFX249461 Clamp Arm (3-A)
8 YGFX007640 Clamper (3-A)
9 YGFX0052363 Clamper Spring Plate (3-A)
10 YEFX999957 Ball Bearing (3-A)
11 YGFX0462013 Detection Lever (1) (3-A)
12 YGFX0052352 Detection Lever (1) Spring (3-A)
13 YGFA011795 Suspension Chassis Ass´y (3-A)
14 YESFD13006 Optical Pick-up Ass´y (3-B)
15 YEFW04150 Feed Screw Housing A (2-B)
16 YEFW04137A Feed Screw Housing B (2-B)
17 YGFX0052386 Thrust Adjusting Spring (2-B)
18 YEFX236144B Traverse Guide (3-A)
19 YGFX9992027 Feed Screw Carrier (3-B)
20 YEFX9991458A FPC Holder (2-A)
21 YGJT03240 Traverse Gear Ass´y (2-B)
22 YEJS02037 Screw, (Pick-up) (3-A)
23 XYN2+C5FX Screw, (FPC) 2mm * 5mm (2-A)
24 XYN2+J10FX Screw, (Housing) 2mm * 10m (2-B)
25 YEFX0051590 Spring Washer (3-A)
26 XUC15V Retaining Ring, 1.5mm (3-A)
27 YEFX9991806A Sealed Plate (3-B)
28 YGP0FX3503 Traverse Motor Ass´y (2-B)
29 YEAS23151A Inner Switch (2-B)
30 YEFR03080 Rubber Belt (2-B)
31 YEFX026124A Idler Pulley (2-B)
32 YGFX018611 Motor Bracket Ass´y (2-B)
33 YEJS02018FZ Screw, (SW) (2-B)
34 XQN2+A25FX Screw, 2mm * 25mm (2-B)
35 YGP0FX3529 Spindle Motor Ass´y (2-A)
36 YEFX0051991C Spring (Motor) (2-A)
37 YGFX0052353 Clamper Spring (2-A)
38 YGAJ071286 Motor Cable (2-A)
39 XQN17+A25FX Screw, 1.7mm * 25mm (3-A)
40 YGFX0462019 Feeder Arm Ass´y (1-A)
41 YGP0FX3507 Roller Gear Ass´y (2-B)
42 YEFW04144 Roller Shaft Collar (1) (2-A)
43 YEFW04138 Roller Shaft Collar (2) (2-A)
44 YEFX218282 Rubber Roller (2-A)
45 YEJW04128 Washer (2-A)
46 YGFX0052362 Spring (Feeder Arm) (1-A)
47 YGFX0462015 Suspension Lock Plate (L) (1-A)
48 YGP0FX3504 Suspension Lock Plate (R)
49 YGFX0052355 Spring (Rack Gear) (1-A)
50 YGFX0052356 Spring (Rack Lock Lever) (1-B)
51 YGFX0052360 Spring (Suspension Lock PlateL)(1-A)
Part No. Part Name & Description Remarks
(2-B)
(3-B)
Ass´y
(1-B)
MISCELLANEOUS
52 YGFX0052361 Spring (Lock Plate) (3-C)
53 YGFA011779 Bottom Chassis Ass´y (3-C)
54 YGFX003940 Driving Gear (1) (3-C)
55 YGFX003941 Driving Gear (2) (3-C)
56 YGP0FX3506 Loding Motor Ass´y (3-C)
57 YGFX018605 Loding Motor Bracket Ass´y (3-C)
58 XQN2+A25FX Screw, (Motor) 2mm * 25mm (3-C)
59 YEJS06188 Screw (2-C)
60 YEFS04693 Oil Dumper (1-C)
61 YGFX0052358 Suspension Spring (A) (2-C)
62 YGFX0052359 Suspension Spring (B) (2-C)
20
12 EXPLODED VIEW (CD Deck)
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
21
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
13 WIRING DIAGRAM
13.1. Main Block (Top View)
14
1
8
7
61
E
E
C
C
B
B
3
2
1
4160
40
1011
20 1
8 5
1 4
20
1
11
10
80
1 20
B
C
E
B
C
E
B
B
C
C
E
E
[E-6848Aa][Top Vie w]
EECCB
25
48
B
21
ECB
24
1
ECB
20
EEB
C
C
B
B
E
B
C
E
B
C
E
B
C
E
B
C
E
E
C
B
E
B
C
C
B
E
E
C
B
B
C
E
8 5
1 4
1
B
C
E
C
5 3 1
24
B
E
1
3
B
E
4
1
8
5
C
B
C
E
B
C
E
B
C
E
B
E
11
10
E
C
B
C
2
C
E
B
C
E
C
B
E
C
B
C
B
E
22
13.2. Main Block (Bottom View)
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
23
[E-6848Aa][Bottom View]
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
13.3. Display Block
1
2
7
8
42 29
43
56
28
15
141
1
2
7
8
[E-6848Ab][Top Vie w] [E-6848Ab][Bottom View]
24
13.4. Amp. Block
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
1
2
24
25
BE
C
BE
BE
C
C
BE
BE
C
C
BE
C
[E-8997][Top Vie w]
[E-8997][Bottom View]
25
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
13.5. CD Servo Block (Top View)
[E-8746Cb]
<TOP VIEW>
[E-8746Cc]
<TOP VIEW>
44
1
11
113
2514
B
E
C
34
33
23
2212
28 15
1
[E-8746Ca]
14
16 1
17 32
<TOP VIEW>
E
C
B
[E-8746Cd]
<TOP VIEW>
26
13.6. CD Servo Block (Bottom View)
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
[E-8746Cc]
[E-8746Cb]
<BOTT OM VIEW>
<BOTT OM VIEW>
[E-8746Ca]
<BOTT OM VIEW>
80
1
20
21 40
61
60
41
27
[E-8746Cd]
<BOTT OM VIEW>
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
14 SCHEMATIC DIAGRAM (1)
14.1. Display Block
28
15 SCHEMATIC DIAGRAM (2)
15.1. Amp. Block
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
29
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
15.2. Main Block
30
15.3. CD Servo Block
MITSUBISHI / CQ-JB3160A / CQ-JB0160A
To Main P.C.B. E-6848Aa CN201
31
Printed in Japan (S) 2001.5 (Recycled Paper)
Loading...
