Mitsubishi LGH-15RX5, LGH-25RX5, LGH-35RX5, LGH-50RX5, LGH-65RX5 Service Manual

Repair work should be performed by
the manufacturer, its service agent or
similarly qualified person in order to
avoid hazards.

January 2009 No. U155

LOSSNAY

HAND BOOK

(For HONG KONG)

Model: LGH-15RX

5-E

LGH-25RX

5-E

LGH-35RX5-E
LGH-50RX

5-E

LGH-65RX5-E
LGH-80RX

5-E

LGH-100RX5-E

Nameplate

LGH-150RX5-E
LGH-200RX

5-E

Nameplate

Model: PZ-60DR-E

Model: PZ-25RF

8-E PZ-35RF8-E

PZ-50RF

8-E PZ-65RF8-E

PZ-80RF

8-E PZ-100RF8-E

FOR DEALERS

Remote controller (Parts number is not set.)

Filter (Parts number is not set.)

Contents

1. Safety precautions....................................................................3

2. Specifications ....................................................................... 4-8

3. Outside dimensions............................................................ 9-18

4. Electrical wiring diagrams ................................................ 19-20

5. Basic circuit diagram ............................................................. 21

6. Fundamentals of operation .............................................. 22-44

7. Troubleshooting ............................................................... 45-65

8. Disassembly and assembly.............................................. 66-68

9. Parts catalog .................................................................. 69-123

LGH-15RX

5-E ............................................................... 70-75

LGH-25RX

5-E ............................................................... 76-81

LGH-35RX

5-E ............................................................... 82-87

LGH-50RX

5-E ............................................................... 88-93

LGH-65RX

5-E ............................................................... 94-99

LGH-80RX

5-E ........................................................... 100-105

LGH-100RX

5-E .......................................................... 106-111

LGH-150RX

5-E .......................................................... 112-117

LGH-200RX5-E.......................................................... 118-123

♦♦

Turn off the power supply

Be sure to shut off the power supply isolator
before disassembling the unit for repair.

(Failure to heed this warning may result in elec-

tric shock.)

♦♦

Use proper parts and tools

For repair, be sure to use the parts listed in the service
parts list of the applicable unit model and
use the proper tools.

(Failure to heed this warning may result in elec-

tric shock, fire and/or bodily injury.)

♦♦

Proper electric work

Use the electric wires designated for electric work, and
conduct electric work in accordance with the "Electric
Installation Engineering Standard," the "Indoor Wiring
Regulations," and the Installation Work
Guide.

(Incomplete connection or wiring installation may

result in electric shock and/or fire.)

♦♦

Replace damaged and/or degraded parts

Be sure to replace the power-supply cord and lead wire
in the event that they are damaged and/or
degraded.

(Failure to heed this warning may result in elec-

tric shock and/or fire.)

♦♦

Check insulation

Be sure to measure the insulation resistance once the
repair work is complete, and turn on the power supply
after verifying that an insulation resistance
of at least 10MΩ is obtained.

(If an insulation problem exists, it may result in

electric shock.)

♦♦

Electric shock

If you must inspect the circuitry while the
power is on, do not touch the live parts.

(Failure to heed this warning may result in elec-

tric shock.)

♦♦

Modification is prohibited

Do not modify the unit.

(Failure to heed this warning may result in elec-

tric shock, fire and/or bodily injury.)

Incorrect handling of the product may result in serious injury
or death.

♦♦

Caution for bodily injury

Do not conduct any work at a location
where you do not have a sure footing.

(Failure to heed this caution may result in a fall.)

♦♦

Wear gloves

Wear gloves when conducting work.

(Failure to heed this caution may result in injury
to your hands from sharp metal or other edges.)

•Inspect the grounding, and repair it if incomplete. Make sure that a power supply isolator is being installed, if
not, install one.

GMake sure that the product operates correctly upon completion of repair. Clean the product as well as the sur-

rounding area, and then notify the customer of the completion of repair.

Incorrect handling of the product may result in serious injury
or damage to properties including buildings and equipment.

Request during repair

—3—

1. Safety precautions

GPlease be sure to read the following safety precautions thoroughly before commencing with the maintenance

work, and conduct the inspection and repair of the product in a safe manner.

GThe types and levels of danger that may arise if the product is handled incorrectly are described by using the

warning symbols shown below.

Warning

Caution for

electric shock

Prohibited

Be sure to follow

this instruction.

Be sure to follow

this instruction.

Be sure to follow

this instruction.

Be sure to follow

this instruction.

Be sure to follow

this instruction.

Caution

Prohibited

Be sure to follow

this instruction.

—4—

2. Specifications

—5—

—6—

—7—

—8—

Unit (mm)

LGH-15RX5-E

3. Outside dimensions

—9—

Unit (mm)

LGH-25RX5-E

—10—

Unit (mm)

LGH-35RX5-E

—11—

—12—

Unit (mm)

LGH-50RX5-E

Unit (mm)

LGH-65RX5-E

—13—

—14—

Unit (mm)

LGH-80RX5-E

Unit (mm)

LGH-100RX5-E

—15—

—16—

Unit (mm)

LGH-150RX5-E

Unit (mm)

LGH-200RX5-E

—17—

—18—

Unit (mm)

PZ-60DR-E

Unit (mm)

PZ-25RF8-E, PZ-35RF8-E, PZ-50RF8-E, PZ-65RF8-E, PZ-80RF8-E, PZ-100RF8-E

—19—

POWER SUPPLY

220-240V 50Hz

2

1

TB5 (M-NET)

(*1)
Optional Remote controller

AB

S

(PZ-60DR-E)

*When the optional Remote Controller PZ-60DR-E

cable
(non-polar)

24VDC 2A 5VDC 100mA

MAX 240VAC 2A MIN 220VAC 100mA

L

L

N

N

M

1

M

2

PE

monitor output

Operation or Delay1

LS

TR

TM1

CN1

CN2

CN7

BLUE

BROWN

YELLOW

RED

BROWN

RED

BLUE

BLUE

EXHAUST
FAN MOTOR

SUPPLY
FAN MOTOR

WHITE

ORANGE

YELLOW

GREY

BLACK

C

C

SA2

SA1

SW2

SW5

SW1

CN6

ORANGE

ORANGE

TH1 (OA)

TH2 (RA)

ORANGE
ORANGE
ORANGE
ORANGE

TM2

BROWN

PZ­60DR-E

Transmission

TB5

TM3

TAB3

TAB5

CN10

CN9

TAB1

TAB2

Isolator

X12 X11

CN32

X10

S

BA

9

2

1

CN5

321678

10

CN16

TM4

RED

GREEN/YELLOW

BROWN

output 7 , 8

Malfunction monitor

monitor output 6 , 7

By-pass or Delay2

MAX 240VAC 1A

12V or 24V DC

Mr.Slim

(non-polar)

2nd remote controller (Max. two remote controllers installable)
2nd LOSSNAY unit (Up to max 15 units)

MELANS

cable

transmission

M-NET

Shield Wire

24VDC 1A

MAX 240VAC 1A

5VDC

100mA

MIN 220VAC 100mA

Unchanged a-contact

13

External control input

TM4

(Max. two remote controllers

2nd remote controller

Shield Wire

cable

transmission

M-NET

2nd or later main units

installable)

(*1)

PZ-41SLB-E and PZ-52SF-E cannot
be used when using PZ-60DR-E.

is used as the M-NET System, connect it to
of TM4 terminal block, and connect M-NET
transmission wire to , on TB5 terminal
block.

1

2

AB

GM

CN16
(Unchanged a-contact)

HI

LO

EXTRA-LO

BY-PASS

M

CC

(*2) LGH-100RX5 has two
capacitors per motor
as following drawing.

(*2)

(*2)

(*1)

With this product, the wiring installation method will
vary according to the design of the system.
Perform electrical installation to meet local electrical regulations.
.Always use double insulated PVC cable for the transmission cables.
.Wiring work must be performed by qualified professionals.
.All supply circuits must be disconnected before obtaining access to the terminal devices.

NOTE 1.TM1, TM2, TM3, TM4, TB5 shown
in dotted lines are field work.

2.Isolator should be provided by the customer.

3.Be sure to connect the grounding wire.

*Attention

BROWN

RED
ORANGE
YELLOW
GREEN

4. Electrical wiring diagrams

LGH-15RX5-E, LGH-25RX5-E, LGH-35RX5-E, LGH-50RX5-E, LGH-65RX5-E, LGH-80RX5-E, LGH-100RX5-E

Definition of Symbols

M1: Motor for exhaust fan CN1: Connector (Transformer primary

)

M2: Motor for supply fan CN2: Connector (Transformer secondary

)

C: Capacitor CN5: Connector (Thermistor

)

GM: Motor for By-pass operation CN6: Connector (Microswitch

)

LS: Microswitch CN7: Connector (Motor for By-pass operation

)
TH1: Thermistor for outside air TAB3: Tab connector(Fan motor)
TH2: Thermistor for return air TAB5: Tab connector (Fan motor

)

SW1: Switch (Main/Sub change

)

CN9: Connector (Fan motor

)

SW2, 5: Switch (Function selection

)

CN10: Connector (Fan motor

)

TM1: Terminal block (Power supply

)

CN16: Connector (High/Low/Extra Low/By-pass switch

)

TM2: Terminal block

(External control input)

CN32: Connector (Remote control selection

)

TM3: Terminal block (Monitor output

)

SA1: Address setting rotary switch (10 digit

)

TM4 :

Terminal block (Transmission cable and monitor output

)

SA2: Address setting rotary switch (1 digit

)

TB5 : Terminal block (M-NET Transmission cable

)

SYMBOL : Indicates terminal block.

TAB1,TAB2

: Connector (Power supply)

: Connector.

TR: Control circuit transformer

: Board insertion connector or fastening

X10,X11,X12

: Relay contact

connector of control board.

*Specifications may be subject to change without notice.

—20—
