Instruments and Controls (Driver’s area)
E00100106379
LHD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1. Shift paddles* p. 4-29
2.
Wiper and washer switch p. 3-52
Rear window wiper and washer switch p. 3-56
3. Cruise control switches* p. 4-55
4. Ignition switch p. 1-11, 1-18, 4-13
5. Supplemental restraint system - airbag (for driver’s seat) p. 2-21,
2-25
Horn switch p. 3-58
6. Steering wheel height adjustment lever p. 4-09
7. Supplemental restraint system - driver’s knee airbag* p. 2-26
8. Bluetooth® 2.0 interface* p. 5-72
9. Bonnet release lever p. 8-03
10. Fuses p. 8-21
11. Active stability control (ASC) OFF switch* p. 4-53
Auto Stop & Go (AS&G) OFF switch* p. 4-22
12. Headlamp levelling switch* p. 3-48
13. Steering wheel audio remote control switches* p. 5-61
14. Combination headlamps and dipper switch p. 3-44
Turn-signal lever p. 3-49
Front fog lamp switch* p. 3-51
Rear fog lamp switch p. 3-52
Headlamp washer switch* p. 3-57
15. Multi-information meter switch p. 3-07
16. Instruments p. 3-02
