product information guide
m70ds distributed sound loudspeaker
The Mission m7ds bipole loudspeaker is designed specifically to integrate with any of the m70 series loudspeakers
in home theatre installations to provide the rear "surround" channels. Visually attractive styling and versatility of
placement allows the m7ds to be easily wall or shelf mounted. Superb sound distribution over a wide listening angle
envelops all listeners in the movie theatre experience wherever the speakers are located.
Two low frequency units provide the dynamics for transient performance blending seamlessly with twin sheer microfibre dome treble units for outstanding dispersion and rear effect localisation. The smoothly contoured baffle
provides excellent spatial dispersion, minimising "hot seat" effects, and the bipole configuration ensures the ideal
performance for Dolby Surround or Dolby Digital/DTS sources.
features benefits
Bipole twin speaker configuration The ideal combination of good dispersion for Dolby
Surround and precise rear effect localisation for Dolby
Digital/DTS sources.
High Impact moulded baffle Excellent HF dispersion and low diffraction to improve
stereo imaging and create precise images in space.
High dB/watt efficiency Equivalent to extra power for amplifier — greater
dynamic range.
Sheer Micro-Fibre soft dome HF unit Ensures excellent high and low level resolution.
Neodymium HF unit magnet Improved microdynamics and reduced signal induced
demagnetisation effects.
Laser trimmed pressure balanced dome Improved dynamics and reduced time smear.
High-quality crossover components Silicon Steel inductors reduce level dependent
distortion.
Audiophile grade Polyester Capacitors increase detail
transmission.
Bonded woven glass composite LF cone Stiff and light ensuring good sensitivity with superb LF
response.
Pressure balanced, ventilated spider Improved dynamics and reduced time smear.
Magnetically shielded Suitable for all AV systems.
construction
Enclosure Mineral filled polypropylene
Baffle High impact moulding
Ports Tuned port-tube
Grille Acoustically transparent
Damping Acoustic long-hair fibre
electrical
L.F. Units Twin 110mm bonded woven glass composite cone with
H.F. Unit Twin 25mm sheer Micro-Fibre soft dome with FF
Cross-Over Acoustic Second Order.
Terminals Gold-plated, multi-way binding posts.
25mm voice coil.
cooling.
Phone: +44 (0) 1480 423 700 Fax: +44 (0) 1480 423 701 Web: www.mission.co.uk
Mission, Symphonix Limited, Huntingdon, PE29 6EY, England
Product designs and specifications subject to change without notice E & OE
Copyright Symphonix Limited 2002
specifications
Enclosure type 2-Way Reflex Loaded
Frequency response ±3dB 75Hz to 20kHz
Nominal Impedance 8 Ohm compatible (min. 4.2 Ohms)
Sensitivity SPL/m/2.83v 89dB
Recommended amplifier power 25 — 100W
Crossover frequency 2.8kHz
Effective volume 4.2 Litres
Cabinet dimensions (HxWxD) 230 x 360 x 105 (mm)
Weight
Finish Charcoal and Satin Silver
setting up
• RUN IN for a minimum of 24 hours with music programme.
• Wall or shelf mount on rear or side walls. A high location will improve sound distribution.
• Maybe used with any competent budget electronics. Will clearly show improvements as
source improves.
Note: The recommended amplifier power rating is for undistorted power. Loudspeakers will be damaged by
amplifiers overdriven into distortion, no matter what the power rating of the amplifier. For larger rooms or high
listening levels it is safer to choose an amplifier with a power output near the maximum rating of the loudspeaker.
