product information guide
m70as active subwoofer loudspeaker
The Mission
films. Its high power capability in combination with an efficient and powerful 250mm bass unit gives tremendous
authority and impact to bass transients.
• High performance and impact from actively driven and equalised 250mm LF drive unit.
• A combination of solid 30mm and 19mm MDF and high density particle board panels form an optimally
• Low distortion, integral 100W amplifier and crossover is dedicated to the high performance driver for
• The adjustable crossover frequency, level control and phase switch optimise the
• Large, anti-turbulence port ensures low distortion Low Frequency Effects whilst maintaining excellent bass
• Downward firing bass unit improves room coupling at low frequencies enabling smooth, analytical bass
construction
Enclosure 30mm and 19mm MDF and high density particle board
electrical
L.F. Units 250mm (10”) treated pulp fibre cone with shielded
Cross-Over Integral active design with overdrive limiter.
Terminals Line level subwoofer input.
specifications
Enclosure type Reflex
Frequency response ±3dB 38Hz to 150Hz
LF response (-6dB) 30Hz
Amplifier power 100W with thermal protection
Crossover frequency 50Hz — 150Hz
Cabinet dimensions (HxWxD) 440 x 270 x 537 (mm) 17¼ x 10½ x 21 (inches)
Weight
Finish Graphite
m70as
is an active subwoofer designed to provide a solid low-frequency foundation for both music and
damped enclosure that reduces box coloration and provides a stable platform for the drive unit.
also supplied with carpet piercing spikes for improved low frequency definition and attack.
optimum low frequency performance with full overload and thermal protection.
m70as
for stereo hi-fi or
dedicated LFE input, enabling seamless integration with almost any size/power hi-fi and AV loudspeakers
and amplifiers.
extension down to 30Hz.
performance in any size of room.
m70as
is
panels.
magnet.
Phone: +44 (0) 1480 423 700 Fax: +44 (0) 1480 423 701 Web: www.mission.co.uk
Mission, Symphonix Limited, Huntingdon, PE29 6EY, England
Product designs and specifications subject to change without notice E & OE
Copyright Symphonix Limited 2002
setting up
• RUN IN for a minimum of 24 hours with music programme.
• Use supplied spikes for improved LF definition.
• Experiment with positioning to achieve an even in-room response.
423701
Phone: +44 (0) 1480 423 700 Fax: +44 (0) 1480 423 701 Web: www.mission.co.uk
Mission, Symphonix Limited, Huntingdon, PE29 6EY, England
Product designs and specifications subject to change without notice E & OE
Copyright Symphonix Limited 2002
