PRODUCT INFORMATION

MINOX DTC 1100 WILDLIFE CAMERA

MINOX is expanding its range of game and observation cameras with the new model DTC 1100 that features GSM and 4G function for an even better and future-orientated network coverage. The images captured are transferred quickly and directly to a stored cell phone number by MMS, or by mail to an e-mail address. The advantage being that the user can respond immediately to the situation, from anywhere, and take any necessary action.

It has never been so easy to install a camera with cellphone module. As soon as the SIM card is inserted the DTC 1100 is ready to go and the user can select from a range of preinstalled network providers with easy and fast access via Plug+Play.

If there is a poor signal the camera automatically chooses the network with the best reception (GSM or 4G) to ensure permanent data transmission.

The high-power infrared flash with a range of up to 18 meters ensures reliable images, even in unfavorable light or in twilight conditions. A black filter fitted in front of the infrared flash makes the wavelength range of the flash invisible to people and animals alike.

The remote control function of the DTC 1100 allows photos to be taken via SMS and then transferred directly (snapshot). The Switch-on time function also means that fixed times can be set in which the camera is active. The time lapse mode allows shots to be taken at fixed intervals without motion detection.

The intelligent design of the motion detector offers greater flexibility when recording.

Due to its individually adjustable sensitivity the camera only captures desired objects and excludes all recordings of irrelevant motions such as moving branches or grass.

And the short shutter delay of the DTC 1100 is less than 1 second. All data are additionally stored on an SD card with up to 32 GB, or they can be directly read off from the integrated 2-inch monitor.

The reliable camera technology is protected by a sturdy and weather-resistant plastic body that keeps out water, dust, cold and heat. A security box for protection against theft is also available as an optional accessory.

The new MINOX DTC 1100 comes with a fixing strap, SD card and USB cable.

PRODUCT FEATURES / TECHNICAL DATA:

– Sends images instantly per

MMS or e-mail to the mobile phone or PC

– Preinstalled network providers

for easy and fast access via

Plug+Play – 4G (HSPA+) or GSM network – High range IR-ﬂash of 18 meters

MINOX GmbH · Walter-Zapp-Str. 4 · 35578 Wetzlar, Germany · Tel.: +49 (0) 6441 / 917-0 · Fax: +49 (0) 6441 / 917-612 · E-mail: info@minox.com · minox.com

– Adjustable motion sensor – 8 Megapixel resolution – Convenient 2“ TFT colour display – Short shutter release delay of

under 1 second – Photo burst or short videos – HD video resolution – Switch-on time function

– Time lapse mode (ﬁxed intervals

without motion detection)

– Built-in microphone for audio

in video mode – Multilingual menu navigation – SD/SDHC card up to 32 GB

(card included) – Password protected

– Padlock lockable – Power supply: 12 x 1,5 V batteries – Dimensions: 101 x 149 x 55 mm – Weight: 406 g
